Moxa WAPA004 User Manual

Moxa IEEE 802.11a/b/g PCI Module

WAPA004 User’s Manual

www.moxa.com

First Edition, January 2013

Reproduction without permission is prohibited.

WAPA004 User’s Manual

The hardware and software described in this manual is furnished under a license agreement and may be used

only in accordance with the terms of that agreement.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on the part of Moxa.

Moxa provides this document “as is,” without warranty of any kind, either expressed or implied, including, but not limited to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for its use, or for any infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are periodically made to the information herein to correct such errors, and these changes are incorporated into new editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas: Toll-free: 1-888-669-2872 Tel: +1-714-528-6777 Fax: +1-714-528-6778

Moxa Europe Tel: +49-89-3 70 03 99-0 Fax: +49-89-3 70 03 99-99

Moxa China (Shanghai office): Toll-free: 800-820-5036 Tel: +86-21-5258-9955 Fax: +86-10-6872-3958

Moxa Asia-Pacific: Tel: +886-2-8919-1230 Fax: +886-2-8919-1231

Chapter 1 Introduction

Table of Contents

Features Specification

Overview

Chapter 2 Getting Started

Block Diagram Hardware Installation Software Installation

Module Layout

WAPA004 User’s Manual Introduction

Chapter 1 Introduction

The following topics are covered in this chapter:

 Overview  Features  Specifications

WAPA004 User’s Manual Introduction

Overview

WAPA004 PCI Module is designed to provide wireless communication for all wireless device based systems. It communicates via the standard 802.11a/b/g protocols. The WAPA004 uses the AR5414 wireless chipset from Atheros. This module is connected to the PCI bus through a PCI connector and special circuitry to allow for compatibility with either 3.3V or 5V PCI signaling. .

Features

 Dynamic frequency selection (DFS) in required 5-GHz bands  All-CMOS MIMO solution interoperable with IEEE 802.11a/b/g WLANs  No external VCOs or SAW filters needed  2.4/5 GHz WLAN MAC/BB processing  BPSK, QPSK, 16 QAM, 64 QAM, DBPSK,DQPSK, and CCK modulation schemes  802.11e-compatible bursting  Wireless multimedia enhancements quality of service support (QoS)  802.11e-compatible bursting  WEP, TKIP, and AES hardware encryption  Host interface PCI 2.3 and PC Card 7.1

compatible

 IEEE 1149.1 standard test access port and

boundary scan architecture supported

 Case temperature 85°C
