1. Introduction

The UC-8100 series computing platform is designed for embedded data acquisition applications. The computer

comes with one or two RS- 232/422/485 serial ports and dual 10/100 Mbps Ethernet LAN ports, as well as a

Mini PCIe socket to support cellular modules. These versatile communication capabilities let users efficiently

adapt the UC-8100 computers to a variety of complex communications solutions.

The following topics are covered in this chapter:

Overview

Model Descriptions

Package Checklist

Hardware Specifications

Hardware Block Diagram

UC-8100 Series HW UM Introduction

1-2

NOTE

The latest specifications for Moxa’s products can be found at

Overview

The UC-8100 Series is built around an Armv7 Cortex-A8 RISC processor that has been optimized for use in

energy monitoring systems, but is widely applicable to a variety of industrial solutions. With flexible interfacing

options, this tiny embedded computer is a reliable and secure gateway for data acquisition and processing at

field sites as well as a useful communication platform for many other large-scale deployments.

Model Descriptions

The UC-8100 Series includes the following models:

• UC-8131-LX: RISC-based platform with 300 MHz CPU, 2 Ethernet ports, 1 serial port, 8 GB eMMC, SD

socket, USB port, and Moxa Industrial Linux pre-installed

• UC-8132-LX: RISC-based platform with 300 MHz CPU, Mini PCIe socket for cellular/Wi-Fi module, 2

Ethernet ports, 2 serial ports, 8 GB eMMC, SD socket, USB port, and Moxa Industrial Linux pre-installed

• UC-8162-LX: RISC-based platform with 600 MHz CPU, Mini PCIe socket for cellular/Wi-Fi module, 2

Ethernet ports, 2 serial ports, 8 GB eMMC, SD socket, USB port, and Moxa Industrial Linux pre-installed

• UC-8112-LX: RISC-based platform with 1 GHz CPU, Mini PCIe socket for cellular/Wi-Fi module, 2 Ethernet

ports, 2 serial ports, 8 GB eMMC, SD socket, USB port, and Moxa Industrial Linux pre-installed

Package Checklist

Before deploying the UC-8100 computer, verify that the package contains the following items:

• UC-8100 embedded computer

• Console cable

• Power jack

• 3-pin terminal block for power (Pre-installed on the UC-8100)

• 5-pin terminal block for UART x 2 (Pre-installed on the UC-8100)

NOTE: Notify your sales representative if any of the above items are missing or damaged.

Hardware Specifications

https://www.moxa.com.

UC-8100 Series HW UM Introduction

1-3

Hardware Block Diagram

+ 14 hidden pages
