Foldable 6 Wheel Shopping Trolley 10657 Instructions for Use
Please read and retain these instructions for future reference v002:21/10/19
Hub clip
Set of wheels
Handle hole
Handle bar in
upright locked
position
Locking bar
Folding bar
Axle bar and covers
Bag front
Long strap with
hook and loop strip
Detail: Steel tube with paint coating (16 x0.8mm), foldable
Wheel size: 9.6cm diameter – max weight: 30kg
E THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Page 2
Foldable 6 Wheel Shopping Trolley 10657 Instructions for Use
Please read and retain these instructions for future reference v002:21/10/19
1) Remove the axle bar end covers and position the wheels with the centre hole side close to the
axle bar.
2) Position the axle bar end into the centre hole of the wheels.
3) With the wheel in
position push the
hub clip down to
move the wheel onto
the axle bar.
4) Pull the hub clip up to
secure the wheel in
position.
5) With the wheels
attached, drop down
the folding bar to
make the Trolley
stand.
6) Swing the handle
bar up and lock in
place with the
locking bar. On the
reverse of the bag
there is a sleeve
which slides over
the handle bar.
Ensure the bag
front sits on the
folding bar.
7) The long strap
with a hook and
loop edge slots
through the
handle hole and
securely attaches
to the hook and
loop on the back
of the bag
.
8) The 6-Wheel
Shopping
Trolley is now
ready to climb
stairs or
roadside kerbs
with ease.
Hook & loop strip
Sleeve
Bag reverse
DISPOSAL:
• Dispose of all packaging, paper, cartons and plastic, plastic bags in accordance with your
local recycling regulations.
• At the end of the product’s lifespan please dispose of it at an authorised household waste
recycling centre.
