Mountain Models Tom-E-Boy 150 Assembly Instruction Manual

Tom-E-Boy 150

Mini Old Timer Electric Model

Tom-E-Boy 150 Specifications

Wingspan: 30.25 in.
Length: 19.4 in.
Wing Area: 159 sq. in.
Weight (Ready to Fly): 4.5 to 5.0 oz.
Wing Loading: 4.0 – 4.5 oz. / sq. ft.

Version 1.0, March 25, 2013

WARRANTY

Mountain Models guarantees this kit to be free from any defects in both mater ial and workmanship at the
time of purchase. This warranty does not cover ANY components or parts damaged by use or modification.
In no case shall Mountain Model’s liability exceed the original cost of the purchased kit. Mountain Models
reserves the right to modify or change this warranty without notice.

LIABILITY RELEASE

In that Mountain Models has no control over the final assembly or material used for final assembly, no
liability shall be assumed or accepted for any damage resulting from the use by th e user of the final user­assembled product. By the act of using the user-assembled product, t he user accepts all resu lting liability.

If the buyer is not prepared to accept the liability associated w ith the use of this product, the buyer is
advised to return the kit immediately in new and unused condition .

THIS PRODUCT IS NOT INTENDED FOR CHILDREN 12 YEARS OF AGE OR YOUNGER.
WARNING: This product may contain chemicals known to the St ate of California to cause cancer and or

birth defects or other reproductive harm.

PRODUCT SUPPORT

This product has been designed to function properly and perform as advertised with the SUGGESTED power
system, speed control, and servos, as described in advertisements and in this manual. We do NOT support,
nor can Mountain Models assist in determining the suitability or use with any other electronics or hardware
not recommended by Mountain Models.

For the proper electronics to complete this model, replacement parts, and produc t assembly questions,
please contact Mountain Models online at www.Mounta inModels.com

Thank you for purchasing the Mountain Models Tom-E-Boy™ 150. The Tom-E-Boy™ 150 is a small model
designed with influence from the famous Vic Smeed Tomboy, to bring back that nostalgic feeling of
yesteryear, in a small field electric packag e. The 30 inch Tom-E-Boy™ 150 is super easy to build and easy
enough for a beginner to learn how to fly with some friendly help.

The Tom-E-Boy™ 150 was designed using a state of the art 3D CAD package, to allow for exceptional
interlocking parts design and fit. 3D design also allows us to provide clearer as sembly image s, without
having to use photos.

The Tom-E-Boy™ 150 is built from self-jigging interlocking laser cut balsa and plywood parts. It's like a 3D jigsaw
puzzle with instructions. Although not needed for building, full size plans are included for reference. If the
instructions are read before hand and followed during the build, the Tom-E-Boy™ 150 can be built up and ready to
fly in only 2 to 4 evenings.

We think you’ll like the Tom-E-Boy™ 150 and look forward to any feedback you might have.

Thank you,
Brian Eberwein

Mountain Models
2935 N Lynndale Drive
Appleton, WI 54914

www.mountainmodels.com

Phone: [phone]

2

Before You Begin

Check to make sure that all of your parts are there and in good shape.

Parts List

Number

in Kit

Bundled Parts

1 Laser Cut Parts (See wood inventory sheet)
1 Plan Sheet (24” x 36”)
1 These instructions of course!

Metal and Misc. (on the back of the wood bundle)

2 0.025” x 18” Wire
2 1/16” Pre-bent landing gear wire
2 12” Length of 072 Pushrod Housing

Bagged Parts

4 #2 x1/4” Motor mount screws
2 DuBro black wheel keepers and set screws
1 Velcro, sticky backed, 2”
2 Wheels
2 DuBro Micro Servo Connectors
2 DuBro EZ Links
2 1/8” x 2-1/2” Dowel
2 Magnets, 1/8” diameter, 1/16” thick
2 DuBro control horn
1 1/16” Wire x 1.5”

Description of Part

Building Materials and Tools You Will Need

 Smooth and FLAT work surface
 Wax paper or clear plastic wrap to protect the work surface
 Thin Cyanoacrylate (CA) glue
 5 Minute Epoxy
 Hobby knife with #11 blades
 Needle nose pliers
 Wire bender or pliers for bending pushrod wires
 Wire cutters
 Screwdrivers
 Sanding block, 320 to 400 grit sandpaper
 Covering Iron

Finishing Materials You Will Need

 Covering material (SoLite, 1 roll)

3

Electronics You Will Need

 3 channel radio minimum
 4 channel mini receiver (Berg 4L or Spektrum 6110e)
 2 ea. 3.7 gram servos (Power HD 1370A or Mountain Models 3.7)
 D1811-2000 10 gram Outrunner
 GWS 6030 HD Prop
 Feigao or Mountain Models 6Amp, 6 gram ESC
 Rhino or PolyQuest 2S-360 LiPo

General Building Tips

 READ THE INSTRUCTIONS all the way through and study the plans BEFORE starting any

work on the model.

 PRE-SANDING: BEFORE removing any parts from the balsa sheets, use a sanding block

with 320 grit sandpaper and lightly sand the back of the balsa sheets. Our balsa suppliers
have been sending us wood that is over sized, so sanding the backs of the balsa sheets
reduces the thickness just slightly and removes any charring from the laser cutting process.

 Tape the plans to your nice clean work surface and cover it with wax paper or plastic wrap.

You want to keep your work surface clean and not glue the parts to the plans, right?

 Balsa is a lightweight and fragile wood, so you do need to be careful with it; however, you

will also need to use a little bit of force to make everything fit properly, so don’t be too
timid.

 Do not remove any pieces from the balsa sheets until they’re ready to be used. That way,

parts won’t get mixed up or disappear.

 Do NOT glue anything until told to do so.
 Join all of your pieces using thin CA (Cyanoacrylate) glue, unless we tell you otherwise. In

general, only a small amount of CA is necessary to glue parts together.

 Don’t over force your pieces together. If they aren’t fitting together properly, make sure you

have the right pieces and that they are oriented correctly. If needed, you can lightly sand
the part to fit after making sure it is the correct part and oriented correctly. On balsa “tabs”,
you can “pinch” the wood with your fingers to get them to fit in slots. (The tabs might be
tighter some times, due to tolerances in wood thickness)

 If you want to remove the charred edges caused by the laser cutting process, lightly

dampen a cloth with bleach and gently rub the affected areas. Removing the char will not
increase the strength but will make it look better. It also keeps that dark edge from showing
under the lightweight coverings.

4
