APPLICANT: MOTOROLA, INC. FCC ID: IHDT5ZG1

INSTRUCTION MANUAL

Enclosed is a draft copy of the Users manual. The final manual will contain the following Safety Information:

Safety Information

IMPORTANT: Read this information before using your wireless handheld phone.

Exposure to Radio Frequency Signals

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, The Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies:

• American National Standards Institute (ANSI) IEEE. C95. 1-1992

• National Council on Radiation Protection and Measurement (NCRP). Report 86

• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996

• Ministry of Health (Canada), Safety Code 6

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1). The design of your phone complies with the FCC guidelines (and those standards). For additional information concerning exposure to radio frequency signals, see the statement by the FDA at the end of this user guide. To maintain compliance with FCC RF exposure guidelines, if you wear a handset on your body, use the Motorola-supplied or approved carrying case, holster, or other body-worn accessory. If you do not use a body-worn accessory, ensure the antenna is at least one inch (2.5 centimeters) from your body when transmitting. Use of non-Motorola accessories may violate FCC RF exposure guidelines.

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

Phone Operation

Normal Operation

Hold the phone as you would any other telephone, with the antenna pointed up and over your shoulder.

Tips on Efficient Operation

Observe the following guidelines to operate your phone most efficiently.

• Extend your antenna fully.

• Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and

may cause the phone to operate at a higher power level than otherwise needed.

Batteries

Caution:All batteries can cause property damage, injury, or burns if a conductive material, such as jewelry, keys or beaded

chains, touches exposed terminals. The material may complete an electrical circuit and become quite hot. To protect against such unwanted current drain, exercise care in handling any charged battery, particularly when placing it inside your pocket, purse, or other container with metal objects. When the battery is detached from the phone, your batteries are packed with a protective battery cover; please use this cover for storing your batteries when not in use.

Driving

Check the laws and regulations on the use of wireless telephones in the areas where you drive. Always obey them. Observe the following guidelines when using your phone while driving.

• Give full attention to driving--driving safely is your first responsibility.

• Use hands-free phone operation, if available.

EXHIBIT 8

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5ZG1

• Pull off the road and park before making or answering a call if driving conditions so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six inches (6") be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research. Persons with pacemakers:

• should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned ON

• should not carry the phone in a breast pocket

• should use the ear opposite the pacemaker to minimize the potential for interference

• should turn the phone OFF immediately if you have any reason to suspect that interference is taking place

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information. Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

Switch OFF your phone before boarding an aircraft. Airline regulations prohibit using your phone while in the air. Check and comply with the policy of your airline regarding the use of your phone while the aircraft is on the ground.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a "blasting area" or in areas posted: "Turn off two-way radio." Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone OFF, do not remove your battery when you are in any area with a potentially explosive atmosphere, and obey all signs and instructions. Sparks from your battery in such areas could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often but not always clearly marked. They include: fueling areas such as gasoline stations; below deck on boats; fuel or chemical transfer or storage facilities; areas where fuel odors are present (for example, if a gas/propane leak occurs in a car or home); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you normally would be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. Do NOT place objects, including both installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

EXHIBIT 8

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5ZG1

INSTRUCTION MANUAL

The following is a draft copy of the instruction manual.

EXHIBIT 8

Welcome

Thank you for choosing your Motorola TDMA digital StarTAC™ phone from a global leader in communications technology. All Motorola digital cellular phones are designed and manufactured to meet Motorola’s rigorous speciﬁcations and worldclass quality standards. During development, our laboratory testing team took your TDMA digital StarTAC™cellular phone through rigorous durability tests including temperature, humidity, shock, dust, vibration, and drop tests—and the phone still worked!

We are conﬁdent that the phone you purchased will meet your own exacting standards. Enjoy your Motorola TDMA digital StarTAC™ phone.

Contents

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . v

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Package Content Options . . . . . . . . . . . . . . . . 10

Phone Overview . . . . . . . . . . . . . . . . . . . . . . . . 11

Understanding the Guide . . . . . . . . . . . . . . . . 12

Using the Battery

About Your Batteries . . . . . . . . . . . . . . . . . . . . 13

Removing and Attaching Battery Covers . . . . 15

Installing and Removing Batteries . . . . . . . . . . 17

Checking Battery Levels . . . . . . . . . . . . . . . . . 18

Charging Batteries . . . . . . . . . . . . . . . . . . . . . . 19

Using the Phone

Turning the Phone On and Off . . . . . . . . . . . . . 23

Reading the Indicators . . . . . . . . . . . . . . . . . . 24

Standby Mode . . . . . . . . . . . . . . . . . . . . . . . . . 26

Storing Your Phone in Its Holster . . . . . . . . . . . 26

Placing a Call . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . 28

Using the Smart Button . . . . . . . . . . . . . . . . . . 29

Redialing a Number . . . . . . . . . . . . . . . . . . . . . 29

Controlling Volume . . . . . . . . . . . . . . . . . . . . . . 30

Using Phone Memory

Using Your Phone’s Built-in Phone Book . . . . . 33

Storing Names and Numbers . . . . . . . . . . . . . 33

Recalling an Entry by Name . . . . . . . . . . . . . . 35

Recalling an Entry by Memory Location . . . . . 36

Clearing a Phone Memory Entry . . . . . . . . . . . 36

Shortcuts for Recalling Phone Book Entries . . 37

Making Notes on the Scratchpad . . . . . . . . . . 38

Using the Menu System

Introducing the Menu Features . . . . . . . . . . . . 39

Navigating the Menu . . . . . . . . . . . . . . . . . . . . 40

Road Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . . . . . . . . . . 13

. . . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . . . . . . . 39

Managing Recent Calls . . . . . . . . . . . . . . . . . . .41

Road Map for Recent Calls . . . . . . . . . . . . . . .42

About Recent Calls . . . . . . . . . . . . . . . . . . . . . .42

Reviewing Received Call . . . . . . . . . . . . . . . . .44

Reviewing Dialed Calls . . . . . . . . . . . . . . . . . . .45

Clearing Caller Line ID . . . . . . . . . . . . . . . . . . .46

Managing the Phone Book

. . . . . . . . . . . . . . . .47

Road Map for Phone Book . . . . . . . . . . . . . . . .48

Recalling an Entry by Name . . . . . . . . . . . . . . .49

Recalling an Entry by Location . . . . . . . . . . . .49

Storing with the Menu . . . . . . . . . . . . . . . . . . . .50

Storing and Placing Numbers with Pause

Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Storing and Placing Numbers for Calling

Card Information . . . . . . . . . . . . . . . . . . . . . . . .53

Editing a Memory Location . . . . . . . . . . . . . . .56

Assigning an Individual Ring Style to a |

Phone Book Entry . . . . . . . . . . . . . . . . . . . . . . .58

Timing Y our Calls

. . . . . . . . . . . . . . . . . . . . . . . .60

Road Map for Call Timers . . . . . . . . . . . . . . . . .61

Viewing the Individual Call Timer . . . . . . . . . . .62

Viewing the Resettable Call Timer . . . . . . . . . .62

Viewing the Cumulative Timer . . . . . . . . . . . . .63

Resetting the Timer . . . . . . . . . . . . . . . . . . . . .63

Displaying the Individual Timer Automatically .64

Setting the One-Minute Audible Timer . . . . . . .64

Setting the Repeating Audible Timer . . . . . . . .65

Setting the Single Timer . . . . . . . . . . . . . . . . . .65

Adjusting T one Controls

. . . . . . . . . . . . . . . . . .67

Road Map for Tone Controls . . . . . . . . . . . . . . .68

Selecting Call Alert Type . . . . . . . . . . . . . . . . .69

Selecting Message Alert Type . . . . . . . . . . . . .70

Selecting a Ring Style . . . . . . . . . . . . . . . . . . .71

Turning Keypad Tones On and Off . . . . . . . . . .71

Turning Scratchpad Tones On and Off . . . . . . .72

Using Lock/Security Features

. . . . . . . . . . . . . .73

Road Map for Lock Security . . . . . . . . . . . . . . .74

Activating Voice Privacy . . . . . . . . . . . . . . . . . .75

Locking/Unlocking Your Phone . . . . . . . . . . . .76

Activating Priority Calling . . . . . . . . . . . . . . . . .77

iii

Viewing the Lock Code . . . . . . . . . . . . . . . . . . 78

Changing the Lock Code . . . . . . . . . . . . . . . . 78

Restricting Call Placement . . . . . . . . . . . . . . . 79

Customizing Phone Options . . . . . . . . . . . . . . 83

Road Map for Phone Options . . . . . . . . . . . . . 84

Activating Pager Mode . . . . . . . . . . . . . . . . . . 85

Viewing Your Own Number . . . . . . . . . . . . . . . 86

Switching Between Numbers . . . . . . . . . . . . . 87

Reviewing Feature Settings . . . . . . . . . . . . . . . 88

Activating Automatic Hands-Free . . . . . . . . . . 89

Activating Multiple Key Answer . . . . . . . . . . . . 90

Deactivating Open to Answer . . . . . . . . . . . . . 90

Activating Automatic Answer . . . . . . . . . . . . . . 91

Selecting Battery Options—Status Light . . . . . 92

Displaying System Identiﬁcation . . . . . . . . . . . 92

Selecting Language . . . . . . . . . . . . . . . . . . . . 93

Using the Message Center

. . . . . . . . . . . . . . . . 94

Road Map for Message Center . . . . . . . . . . . . 95

Voice Mail Alerts . . . . . . . . . . . . . . . . . . . . . . . 96

Dialing Voice Mail . . . . . . . . . . . . . . . . . . . . . . 96

Reading Text Messages . . . . . . . . . . . . . . . . . 97

Editing the Voice Mail Number . . . . . . . . . . . 102

Setting the Scrolling Speed . . . . . . . . . . . . . . 103

Reference Information

. . . . . . . . . . . . . . . . . . . 104

Accessory Options . . . . . . . . . . . . . . . . . . . . 104

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 107

Glossary Index Patent Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

. . . . . . . . . . . . . . . . . . . . . . 119

Safety Information

Important: Read this information before using your

wireless handheld phone.

Exposure to Radio Frequency Signals

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

In August 1996, The Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies:

•

American National Standards Institute (ANSI) IEEE. C95. 1-1992

•

National Council on Radiation Protection and Measurement (NCRP) Report 86

•

International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996

Those standards were based on comprehensive and periodic evaluations of the relevant scientiﬁc literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modiﬁcations, or attachments could damage the phone and may violate FCC regulations.

Phone Operation

Normal Operation

Hold the phone as you would any other telephone, with the antenna pointed up and over your shoulder.

Tip on Efﬁcient Operation

To operate your phone most efﬁciently, do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Batteries

Caution: All batteries can cause property damage,

injury, or burns if a conductive material, such as jewelry, keys or beaded chains, touches exposed terminals. The material may complete an electrical circuit and become quite hot. To protect against such unwanted current drain, exercise care in handling any charged battery, particularly when placing it inside your pocket, purse, or other container with metal objects. When the battery is detached from the phone, your batteries are packed with a protective battery cover; please use this cover for storing your batteries when not in use.

Driving

Check the laws and regulations on the use of wireless telephones in the areas where you drive. Always obey them. Observe the following guidelines when using your phone while driving.

•

Give full attention to driving--driving safely is your ﬁrst responsibility.

•

Use hands-free phone operation, if available.

•

Pull off the road and park before making or answering a call if driving conditions so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

Persons with pacemakers:

•

should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned ON

•

should not carry the phone in a breast pocket

•

should use the ear opposite the pacemaker to minimize the potential for interference

•

should turn the phone OFF immediately if you have any reason to suspect that interference is taking place

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

vii

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Vehicles

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone OFF and do not remove your battery when you are in any area with a potentially explosive atmosphere. Obey all signs and instructions.

Sparks from your battery in such areas could cause an explosion or ﬁre resulting in bodily injury or even death.

viii

Areas with a potentially explosive atmosphere are often but not always clearly marked. They include, but are not limited to: fueling areas such as

gasoline stations; below deck on boats; fuel or chemical transfer or storage facilities; areas where fuel odors are present (for example, if a gas/ propane leak occurs in a car or home); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you normally would be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inﬂates with great force. Do NOT place objects, including both installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inﬂates, serious injury could result.

US050498REV

Overview

Package Content Options

Your TDMA digital StarTAC™ cellular phone is typically packed with a transformer charger and at least one battery. Below is a sampling of the different package options.

Note:

Your phone and accessories may not look

exactly as pictured.

Slim Main Battery with Battery Cover

Digital

TDMA digital StarTAC™ Cellular Telephone

AC Adapter

Holster

Headset

Standard Main Battery with Battery Cover

Slim Auxiliary Battery with Battery Cover

Cigarette Lighter Adapter

Desktop Charger (AC Adapter required)

Phone Overview

See the inside front cover of this guide for a diagram of the components described below.

Antenna —Provides superior connectability. Earpiece —Ultra-compact phone speaker. Accessory Connector Port —Provides the

connections for an external power supply and vehicular and optional accessories.

Headset Jack —Provides the connection for an

optional headset.

Microphone

conversation.

—Positioned for convenient

Overview

Function Keys

—Turns the phone On and Off.

—Acts as a “shift” key to access the secondary

functions of other keys.

—Recalls phone numbers from memory.

‰

—Stores phone numbers into memory.

—Clears characters from the screen.

—Ends phone calls.

—Places or answers calls.

memory entries and menu features.

digital messages and voice mail messages.

information from memory, place and end calls, select menu features, and toggle features on and off. The symbol in your display represents the Smart Button.

and

Message Center Button —Allows access to

Smart Button —Use the Smart Button to recall

—Can be used to scroll through

Volume Keys —The upper and lower volume

keys can adjust keypad, earpiece, and ringer volume. After pressing the Smart Button, the volume keys also scroll through memory entries and menu features.

Understanding the Guide

Key Presses

Key presses are represented in this guide using symbols so that you may locate and use the required sequence quickly. A sequence of key presses may be shown as follows:

ƒ ‚ ‡ Ç

This means you should press

and then

‡,

simultaneously.

, in sequence, not

Prompts and Messages

Your phone responds to key presses by displaying either a prompt that guides you to the next action or a message conﬁrming that your action is complete. Prompts and messages are represented in this guide in LCD style, for example:

Short Cuts and Tips

In the margins of your guide are short cuts and useful hints and ways to improve your phone’s performance. These are especially helpful for experienced Motorola Users, who can ﬁnd many of the same key sequences used with other Motorola models.

followed by

Reset Timer

‚,

Using the Battery

About Your Batteries

Your TDMA digital StarTAC™ phone can use either Lithium Ion (LiIon) or Nickel Metal Hydride (NiMH) batteries. Batteries are available in these sizes: Slim, Standard, and Extra Capacity.

Your phone can use two batteries at the same time. You can use:

•

any single main or auxiliary battery

•

a main and auxiliary battery combination

to ﬁt your needs. You can even extend your talktime by attaching an auxiliary battery at any time, without interrupting your call.

Battery Talk-Time and Standby-Time

Talk-time

phone before the battery is fully discharged.

Standby-time

not used for talking.

Notes:

refers to the time you can talk on your

is the time that your phone is on but

• Talking on the phone uses more power than

leaving it idle. The more power you use for talking, the less you’ll have for standby-time, and vice-versa.

•

All times are approximate and depend on the battery used, network conﬁguration, signal strength, and the features selected.

Batteries

•

Talk and standby times are lower in analog mode.

•

Your phone operates more efﬁciently in Digital mode. If the icon is displayed in the lower left corner, your phone’s

performance is reﬂected in the digital section of the table below. Otherwise, refer to the Analog section.

The following table shows ranges for battery talktimes and standby times.

Digital Analog

Battery

Slim Main LiION 500mAH 60 min. 50 hrs. 35 min. 10 hrs.

Talk (up to)

Standby (up to)

Talk (up to)

Standby (up to)

Standard Main NiMH (500mAH

Extra Capacity LiION 900 mAH

Slim Auxiliary LiION 900 mAH

110 min. 100 hrs. 60 min. 15 hrs.

9 hrs.

Storing and Disposing of Batteries

To prolong the life of your batteries, do not expose them to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your car.

To dispose of batteries, check with your local recycling center for a battery recycler near you. Never dispose of batteries in a ﬁre.

Caution:

metal objects to contact or short-circuit the battery terminals.

To prevent injuries or burns, do not allow

Removing and Attaching Battery Covers

Your phone’s batteries are shipped uncharged and ﬁtted with protective covers. Before you install the batteries, remove these covers, and save them for storing unused batteries. The covers prevent metal objects from contacting the battery terminals, reducing the risk of injury or damage from a battery short circuit.

Removing the Main Battery Cover

Batteries

Press in the release latch.

Rotate the battery upward and lift it out of the cover.

Attaching the Main Battery Cover

Lower the edge of the battery opposite the release latch into the cover.

Drop the side with the release latch down until the latch clicks into place.

Release Latch

Removing the Auxiliary Battery Cover

1. Hold the auxiliary battery securely with one

hand.

2. With your other hand’s thumb, push up on the

bottom of the cover.

3. Continue pushing until the cover slides free

of the pins on the bottom of the battery, and swing the cover away from the battery.

Pins

Attaching the Auxiliary Battery Cover

1. Slide the cover’s narrow end

into the small grooved hook on top of the auxiliary battery.

2. Push the cover ﬁrmly

downward until the base of the cover slides past the battery pins; then release.

Hook

Pins

Installing and Removing Batteries

Installing a Main Battery

1. Set the edge of the

battery opposite the release latch into the cover.

2. Press the release latch

side of the battery into the cover until the latch clicks into place

Release Latch

Removing a Main Battery

1. If you don’t have another battery attached,

press

¡ to turn your phone off.

2. Press the release latch

back toward the battery, and lift the battery out.

Release Latch

Installing an Auxiliary Battery

The auxiliary battery clips onto the back of your phone.

1. Place the hook located

on the narrow end of the battery into the slot on the back of the phone.

Hook

Batteries

2. Pull the battery toward

the bottom of the phone and slide the battery pins over the bottom of the phone.

3. Once the battery clears the bottom of the

phone, release it. Make sure that the pins ﬁt securely into place.

Pins

Removing an Auxiliary Battery

Hook

Pins

1. Pull the battery

down until the pins release from the base of the phone, and pull the base away from the phone.

2. Lift the battery’s hook out of the slot on the

back of the phone.

Checking Battery Levels

Battery Level Indicator

The three bar segments on your phone’s Battery Level Indicator display the amount of charge remaining in your battery. The more segments visible, the greater the charge.

For a detailed battery level reading:

Press

ƒ ›.

One of the following is displayed:

Main

The more segments ﬁlled on the battery gauge, the greater the charge.

Auxiliary

Low Battery Warning

When the battery level is low and only a few

High

Low

minutes of talk-time remain, your phone signals you in three ways:

• Low Battery appears in the ﬁrst line of the

display.

• No bar segments are highlighted.

• A short tone plays periodically.

To conﬁrm low battery signals:

ƒ ›.

Press

Power Status Messages

You may also see one of the following messages:

Auxiliary and/or main batteries ﬁtted;

Auxiliary

Main

Charging Auxiliary

Charging Main

phone is operating from auxiliary battery.

Auxiliary and/or main batteries ﬁtted; phone is operating from main battery.

Auxiliary and main batteries ﬁtted; auxiliary battery is being charged.

Auxiliary and/or main batteries ﬁtted; main battery is being charged.

Charging Batteries

Using the Internal Charger

Your phone has a built-in battery charger. Using either the AC or cigarette lighter adapter, you can plug the handset directly into a power source to charge any attached batteries.

To charge:

1. Plug the AC

adapter or cigarette lighter adapter into the accessory connector on the bottom of your phone as shown, with the release tab facing up.

Tip:

You can still place and answer calls while using either the internal charger or the cigarette lighter adapter. Remember that talking on the phone requires energy, so charging takes more time. To place the phone in charger-only mode, turn off the phone by pressing

once.

Batteries

2. Plug the power adapter into a 110V AC

electrical outlet.

Plug the cigarette lighter adapter into the cigarette lighter opening in the vehicle.

In both cases, a beep-tone sounds, and the battery icon ﬂashes.

See “Charge Times” on page 22 for charge times.

Using the Desktop Charger

You can use the desktop charger to charge batteries while they are attached to your phone, or you can charge a main battery separately.

Tip:

If both a main and auxiliary battery are attached, the main battery is charged to 90% before the auxiliary is charged.

To charge:

1. Plug the AC adapter

into the back of the charger, release tab facing up.

2. Plug the other end of

the adapter into an AC wall socket.

3. With battery(ies) attached, place the phone

into the charger’s pocket.

Note: When the phone is charging, the battery level indicator ﬂashes. When the battery is fully charged, this icon stops ﬂashing. If your phone cannot charge the battery, this indicator does not appear.

PUSH

Desktop Charger Indicator Lights

The lights for charging a battery are:

Red

Flashing yellow

The battery is rapid charging.

The battery is waiting for its charge.

Green

The battery is charged within approximately 90% of its capacity and can be used. Charging the battery for an additional hour brings it up to 1 00% capacity.

Batteries

Flashing red

The light for charging a battery attached to the phone is:

Yellow

Either the battery or the power supply is damaged and cannot be charged.

The phone is inserted and rapid charging.

Charging Two Batteries on the Phone

When you charge your phone with a main and auxiliary battery attached, the main battery is charged ﬁrst.

To ﬁnd out which battery is being charged:

Press

ƒ ›.

Note: If the battery cannot be charged and you

press

ƒ ›, you will see Invalid Battery.

Battery Charging Tips

To ensure that you enjoy maximum battery life and use your battery to its fullest capacity:

• Always use Motorola approved battery

chargers.

“batt” is

Tip:

printed on the

›

key as a

reminder.

• For the best results, Li-Ion batteries should

be charged using the E•P™ Desktop Charger, or your phone’s internal charger.

• The battery should be at or near room

temperature when charging.

• When you don’t intend to use a battery for a

while, store it uncharged in a cool, dark, dry place, such as a refrigerator.

• Do not leave a NiMH battery connected to

any charger for longer than 24 hours.

A new NiMH battery may require several full charge/discharge cycles in order to achieve its optimum performance. After this initial charge, you can recharge your battery at your convenience, using the phone’s rapid travel charger.

Quick Change Power Source (“Seamless Connection”)

The quick change feature enables you to switch power sources while a call is in progress without losing the call. If you hear a low-battery warning while you are in a call, plug in the Cigarette Lighter Adapter or AC Adapter.

Charge Times

Locate your battery by type to see how long your battery takes to charge to a 95% power level:

Charge Time

Battery Type

NiMH Main (500 mAH) 1.25

(hrs)

Internal Charger

Slim LiION Main (500 mAH) 2.5 Extended LiON Main (900

mAH) LiION Auxiliary (900 mAH) 3.0

3.0

After the battery reaches 95%, it begins to slow charge until it is fully charged. It is normal for batteries to become warm during charging.

Using the Phone

Turning the Phone On and Off

1. Open your phone to

expose the keypad.

2. To turn the phone on,

press and hold the display appears and you hear an audible alert.

3. Press and hold

off. Powering off will be displayed, and you will hear an audible alert.

What You Will See

When you turn on your TDMA digital StarTAC™ phone, it performs a self-test to let you know it is operational. When the test is completed, the display shows:

• one of several possible greetings, such as:

- the name of your Service Provider or

- an indication of local or non-local cover-

age area

¡ until

¡ again to turn the phone

Using the Phone

• your phone number

• the Digital or Analog icon

Reading the Indicators

High

Low

3 4567

Signal Strength Indicator (1)

The Signal Strength Indicator (SSI) indicates the strength of your phone’s connection with the local cellular system. A strong signal increases your chances of placing and receiving calls. Low signal strength can occur in a fringe area of the cellular system. Buildings, tunnels, and bad weather can block or interfere with reception.

Digital Indicator (2)

If you are in a digital coverage area, the digital indicator appears.

In Use Indicator (3)

The In Use (IU) Indicator appears when a call is in progress.

In-Building Indicator (4)

The In-Building Indicator lights when the phone accesses an In-Building Cellular System or other non-public system.

No Service Indicator (5)

If you travel beyond the range of a cellular system, the No Service Indicator appears to let you know that calls cannot be placed or received from your location.

SMS Message Waiting Indicator (6)

The Short Message Service (SMS) Message Waiting Indicator is displayed when the phone receives a message. (This is an optional, network

and subscription-dependent feature that is not available in all areas.)

Voice Message Waiting Indicator(7)

The Voice Message Waiting Indicator is displayed when your Voicemail has received a message. (This is an optional, network and subscription-dependent feature that is not available in all areas.)

Battery Level Indicator (8)

The three bar segments on the Battery Level Indicator show the amount of charge remaining in your battery. The more segments you see, the greater the charge. The phone alerts you to a low charge in three ways:

Using the Phone

High

• No bar segments are highlighted.

• Low Battery appears on your screen.

• A short tone plays periodically.

VibraCall™ Alert Indicator

When you select one of the VibraCall™ alert combinations, the following types of indicators appear in the display:

VibraCall on—Your phone’s ringer is turned off

and the VibraCall™ alert is on.

Vibrate then ring—Both your phone’s ringer

and the VibraCall™ alert are on.

Power/Status Indicator

While wearing your phone in its holster or carrying it, you can check the Power/Status indicator on top of the phone for status information on your current type of service and message status. The messages can include voice mails and Short Message Services (SMS) messages, or the receipt of recent calls. (This is an optional, network and subscriptiondependent feature that is not available in all areas.)

During wake-up and while the phone is “ringing,” the Power/Status Indicator ﬂashes alternating red and green. Otherwise, if the ﬂip is closed and the

Low

Status Light setting in the Phone Options menu is set to On, then the Power/Status Indicator ﬂashes according to the following chart. (See “Selecting Battery Options—Status Light” on page 92 for information on the status indicator.)

Service Condition

Service in home system

Roaming (service in non-home system)

No service

No message Message

waiting No message

Message waiting

No message Message

waiting

First Flash

Green

Yellow

Red

Second Flash

Green

Red

Yellow

Red

Off

Red

Note: The Power/Status Indicator is Off when the phone is in charger-only mode or when the status light feature is turned off.

Standby Mode

To conserve energy, your phone may turn off its lights when in standby mode. The display comes back the next time you press a key or open the phone.

Storing Your Phone in Its Holster

To slip your phone into its holster, make sure the main battery is facing the inside of the holster. Then clip the holster onto a belt, purse or briefcase.

Notes:

• For body-worn use, keep the antenna at least

one inch from your body when transmitting.

• The holster has been designed for your

convenience and is not meant to secure your phone under all circumstances.

Placing a Call

To place a call:

1. First, turn the phone on. Press and hold

until the display appears and you hear an audible alert.

2. Enter the number you want to call.

• Press

• Press and hold

You can also recall a previously dialed or stored number. (See “Using Phone Memory” on page 32 for details on storing or recalling.)

3. Press and hold until you hear a second

tone.

Press You will hear a single-tone alert (if the keypad

tones are turned on) and see Dialing XXXXXXX.

4. You can dial phone numbers with up to 32

digits, but only the last 20 digits appear in the display.

Ç to erase one digit at a time if

you make a mistake.

Ç to clear the entire

entry.

æ to place the call.

Using the Phone

Press

‰ to see the entire phone number.

Ending a Call

To end a call:

º or close the phone.

Press

1. Press and hold until you hear a second

tone. You will see

2. Press again to end the call.

§ To End Call.

Receiving a Call

Your phone must be powered on to receive calls. To answer a call:

Press

æ or open the phone when the

phone rings.

Note: Opening the phone does not answer the call if the Open to Answer feature is off. (See “Deactivating Open to Answer” on page 90.)

Unanswered Call Indicator

When you cannot take a call, your TDMA digital StarTAC™ phone keeps a count of your unanswered calls and alerts you with the message Missed XX Calls, where calls.

is the number of missed

Press to view missed calls.

Terminating the Ring or Vibrate Indicator

You can terminate either the ring or the vibrate indicator by pressing either of the volume keys during the ring/vibrate cycle.

Using the Smart Button

Use the Smart Button to place and end calls, enter menus, toggle features on and off, and select items in the display. The Smart Button is the middle key on the left side—easy to feel, easy to ﬁnd, and easy to use.

The symbol Button.

Selecting Items in the Display

The most basic use of the Smart Button is for making selections. Whenever you are given a choice such as a ringer setting, press the Smart Button to select the setting you want.

Toggling Features On and Off

Some of your phone’s features toggle on and off. Use the upper or lower volume key to scroll to the desired feature, then press the Smart Button to select it.

Entering the Menu System

Placing and Ending a Call

You can use the Smart Button to place and end a call, as described in “Placing a Call” on page 27 and “Ending a Call” on page 28.

§ in your display represents the Smart

Press ƒ, then press to access the menu. You will see Recent Calls.

Tip:

You can also enter the menu system by pressing

ƒ ⁄.

Using the Phone

Redialing a Number

Automatic Redial

A fast busy signal indicates that the cellular system is busy. With Automatic Redial, your phone calls continuously for the next four minutes.

When it makes a connection, the phone rings or vibrates. You can distinguish this ring because it is half as long as the ring or vibrate for a new incoming call. When the person you are calling answers, you can begin talking.

If you hear a fast busy signal:

1. You will see Redial Call?

Press

or press æ to redial, or press º

to exit.

2. If the call does not go through after four minutes, press , or press the call attempt.

You will see Redial.

If you hear an ordinary busy signal:

1. Press

2. Press or press

º to hang up.

æ to redial the busy

number. You will see Dialing 5551234.

æ to continue

Controlling Volume

Adjusting Volume

Use the upper and lower volume keys to adjust earpiece, keypad, and ringer volume. When you press these keys, the phone’s speaker demonstrates the current volume level.

To adjust earpiece and keypad volume:

Press to raise or lower the volume.

To adjust the ringer volume:

1. Press

2. Press to raise or lower the ringer volume.

ƒ.

Muting the Microphone

For privacy during a call, mute the microphone. You can hear the person on the other end, but he or she cannot hear you.

1. Press

2. Press

ƒ ﬂ to mute the microphone. You

will see Mute.

ƒ ﬂ again to resume normal

conversation.

Selecting Silent Vibration Mode

In situations where you don’t want your phone to ring, or in noisy places where you may not hear your phone, select the VibraCall™ Alert function for discrete vibration:

Press

ƒ † to toggle between ringer and

vibration mode. You will see Ring only or Vibrate only.

Using the Phone

Using Phone Memory

Use your TDMA digital StarTAC™ phone’s internal Phone Book to store up to 99 names and numbers for easy access.

In this chapter you will learn how to:

• store names and numbers into the Phone

Book

• recall phone numbers from memory

• clear names and numbers

• dial a number with Speed Dial and

Turbo Dial™

• make notes on the scratchpad

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

You can also use your phone’s to scroll through the menu system.

« and » keys

Using Your Phone’s Built-in Phone Book

Each phone number in your phone book is stored in a

memory location

Arrange numbers for easy recall by storing related numbers in groups. If you store the numbers you call most in locations 01-09, then you can use Turbo Dial™ to call those numbers with a single key. (See “Using the Turbo Dial™ Function” on page 37 for details.)

You can also store names to identify phone numbers. Later, you can recall a number by the name that corresponds to it.

numbered 01-99.

Storing Names and Numbers

How to Store Phone Numbers

1. Enter the phone number you want to store. Note: You can store up to 32 digits per phone

number entry.

2. Press ¬ to begin storing.

Using Memory

The phone prompts you to enter a memory location. You will see Location __.

3. Enter the two-digit memory location where you want the sequence stored.

Press « to store the sequence in the ﬁrst available location.

Enter the ﬁrst digit of the memory location, then

press « to store the sequence in the

ﬁrst available location beginning with that digit.

You will see Alpha Or

§.

Tip:

The § symbol in your display represents the Smart Button.

Tip:

Press the upper or lower volume key ﬁrst, to toggle between upper and lower case letters.

4. Enter a name to identify the phone number.

(See the following section for details on entering names.)

5. Press or

name. Your phone conﬁrms your entry by displaying

the information you stored.

¬ when you ﬁnish entering the

How to Enter Letters and Numbers

When the display shows Alpha Or §, you can press the numeric keys one or more times to produce any letter or number in the alphabet. Use the letters printed on each key as a guide. For example, press

¤ to enter “A,” “B,” “C,” or “2” as shown:

press 1 time to insert an “A” press 2 times to insert a “B” press 3 times to insert a “C” press 4 times to insert a “2”

How to Enter a Name

1. Enter a letter by pressing a key as many

times as necessary. Enter punctuation by pressing the chart below. Pressing produces a single space.

⁄ as many times as indicated by

⁄ a single time

2345678910

The cursor advances automatically to the next space after you enter a letter or after three seconds of inactivity. If you are repeating a character, then press advance the cursor to the next space.

2. Press

«or Ç to erase a letter if you make

an error.

» to

3. Press or ¬ when you ﬁnish entering the

name. Your phone conﬁrms your entry by displaying

the information you stored.

Recalling an Entry by Name

After storing names and numbers, you can recall them alphabetically and immediately place calls. Use the Smart Button for instant access to the name directory.

1. Press once to enter your name directory.

2. Press to scroll to the name you are

looking for.

Enter the ﬁrst letter of the name you want to recall. The display shows the ﬁrst name in the phone book that begins with that letter. If no entry beginning with that letter is found, No A s is displayed.

When the name is displayed, the corresponding number is displayed on a third line, and the phone memory location is displayed in the upper right corner.

Using Memory

3. Press and hold , or press

number you selected.

æ, to call the

Recalling an Entry by Memory Location

Each name and number you store is placed in a memory location numbered 01-99. Once you have stored names and numbers, you can recall them by memory location:

1. Press

2. Enter the two-digit memory location of the

3. Press and hold , or press æ to call the

‰.

phone number you want.

number you selected.

Clearing a Phone Memory Entry

Clearing an Entry by Name

1. Recall by name the entry that you want to

erase. (See “Recalling an Entry by Name” on page 35.)

2. Press

3. Press or

Clearing an Entry by Location Number

1. Recall by location the entry that you want to

Ç to clear the entry.

You will see Clear Entry?.

¬ to conﬁrm that you want to

erase the entry. The numbered location of the cleared entry is

shown in the display.

erase.

2. Press

3. Press

4. Press

Ç to clear the display. ¬ and the location you want to clear.

You will see XX Full Change?

¬ to conﬁrm that you want to erase

the entry.

Shortcuts for Recalling Phone Book Entries

Using Speed Dial

If you know the memory location of the number you want to call, try the Speed Dial function:

1. Enter the two-digit memory location (01-99).

2. Press and hold , or press æ to place the

call.

Using the Turbo Dial™ Function

The Turbo Dial™ function enables you to dial numbers stored in locations 01-09 with the push of a single button:

Using Memory

Press and hold a number on the keypad, and your call is placed. You will hear a two-tone alert afterwards.

Your phone’s Priority Call feature gives you fast access to any number stored in location 01. To learn more about this feature, see “Activating Priority Calling” on page 77.

⁄ through ·

Making Notes on the Scratchpad

In addition to your internal phone book, you also have a built-in scratchpad for making quick notes. The scratchpad remembers the last phone number shown on your display.

Entering a Number in the Scratchpad

If you are on the phone and your party gives you another number to call, enter the number on the scratchpad so you can place the call later.

1. Enter the number into the keypad. (The

person on the line can hear tones as you dial.)

2. Press

3. Press

º to end the current call, if

necessary.

æ to call the number you saved on

the Scratchpad.

Storing Numbers During a Call

You can also store numbers during a call:

1. Enter the number into the keypad. (The

person on the line can hear tones as you dial.)

2. Press

¬ and continue storing with step 3 in

“Storing Names and Numbers” on page 33.

Using the Menu System

Your TDMA digital StarTAC™ cellular phone includes many features to help you be more productive. The phone’s user-friendly menu system helps you ﬁnd what you need quickly and easily.

In this chapter you will learn:

• what are the main menu features

• how to navigate through the menus

• how to read a menu road map

Introducing the Menu Features

As you scroll through the menu system, you will see the following icons, each representing a high-level menu.

Recent Calls

Tone Control

Phone Book

Lock Secure

Timers

Phone Options

ˇhe Menu System

Navigating the Menu

You can navigate through the menu system using the three keys located on the left side of the phone. Use the upper and lower volume keys to scroll to sub-menus and to control volume. Use the middle Smart Button to choose menus and functions.

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

Recent Calls

Phone Book

Timers

Tone Control

Lock Secure

Phone Options

You can also use your phone’s

« and » keys

to scroll through the menu system.

Road Maps

To help you navigate through the phone’s menu system, each chapter begins with an easy-to-follow visual “road map.” Simply press the key shown, and observe the message that appears in the display. For example, try this:

1. Press

2. Press to scroll through the menu’s top

3. Press º to exit the menu.

Detailed instructions within each chapter describe how each feature works.

ƒ, then press to enter the menu

features

Press ƒ ⁄. “menu” is printed on the

⁄ key as a reminder.

level, shown here in the margin.

Managing Recent Calls

The recent calls menu option allows you to access your Caller Line ID and review previous calls. Caller Line ID is an optional network and subscriptiondependent feature that is not available in all areas.

In this chapter you will learn how to review all calls that you have received or dialed.

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

You can also use your phone’s to scroll through the menu system.

« and » keys

Recent Calls

Road Map for Recent Calls

To enter the menu system:

ƒ, then press .

Press or

ƒ ⁄.

Press

Start:

Recent Calls

Received Calls

Dialed Calls

To Main Menu

About Recent Calls

The Recent Calls menu allows you to review previous calls that you have received or dialed. Following are some useful tips and information about reviewing recent calls.

• Your TDMA digital StarTAC™ cellular phone

can store the telephone numbers and names of the last thirty incoming calls.

• If the caller’s phone number matches a

phone number stored in the phone’s memory, the phone automatically displays the name associated with that phone number.

• If you subscribe to call waiting and receive a

call while another call is in progress, you hear a call waiting tone, and the caller’s name and number appear on the display. The name and number are automatically stored and can be viewed after ending the call, using the procedure described in “Reviewing Received Call” on page 44.

• Caller Line ID allows you to view the name

and number of the calling party in the phone’s display while the phone is ringing.

Caller Line ID is an optional feature that is not available in all markets. Contact your Service Provider for availability information.

• If the caller has restricted transmission of the

phone number, your phone displays Anonymous. If the Calling Number ID information is not available to the cellular network, your phone displays Unavailabl.

• You can store any number contained in your

Caller Line ID memory to a memory location in the same way you would save any phone number. Once the correct number is displayed, press or

¬ «to autoload. See “Storing with the

Menu” on page 50 for more information on storing phone numbers.

• To view Caller Line ID information prior to

answering a call, you must turn off the Open to Answer feature. (See “Deactivating Open to Answer” on page 90.)

¬ and a memory location

Recent Calls

Getting to Recent Calls

1. Press ƒ, then press to enter the menu system.

2. When you see Recent Calls, press

3. Press to scroll to the following features.

to select.

Reviewing Received Call

Shortcut:

Press

‰ ‰

to view your received calls. You must hold the second

‰ until the

received call list is displayed.

1. Follow the steps in the ”Getting to Recent

Calls…” block to scroll to Received Calls. The total numbers of received calls stored is displayed in the upper right corner. If there are no numbers in the Caller Line ID list, you will see 00 in the upper right corner.

2. Press to enter your Caller Line ID list of

received calls.

3. Press to scroll through the list.

4. Press

The display shows the order in which the call was received in the upper right corner, with the phone number and name of the calling party (if available).

The received call list can range from 01 (the most recent previous phone call) to 30 (the least recent phone call).

The following symbols appear next to the received calls:

Answered Missed

æ to dial the displayed number.

44 Managing Recent Calls

Reviewing Dialed Calls

1. Follow the steps in the ”Getting to Recent

Calls…” block to scroll to Dialed Calls. The total number of dialed calls that are

stored is displayed in the upper right corner. You can see up to the last twenty numbers dialed. If there are no numbers in the Dialed Call list, you will see 00.

2. Press to enter your dialed calls list.

3. Press to scroll through the list. The dialed

4. Press

call list can range from 01 (the most recent dialed phone call) to 20 (the least recent dialed phone call).

The display shows the order of the previously dialed phone call in the upper right corner, with the phone number and name (if available) of the party called.

æ to dial the displayed number.

Shortcut:

Press

‰ ‚

to enter

‚

your dialed calls list.

Recent Calls

Tip:

To erase all entries you must press and hold

whereas to erase a single entry you simply press

Ç.

Clearing Caller Line ID

To erase all entries saved in your Caller Line ID memory:

1. Follow the steps in the ”Getting to Recent

Calls…” block to scroll to Received Calls.

2. Press and hold

name and number is displayed. You will see Clear All?.

3. Press or or

º to leave your Caller Line ID

Press memory intact.

To erase a single entry saved in your Caller Line ID memory:

Ç when a Caller Line ID

¬ to clear.

1. Press

2. Press or

Ç or any other key when a Caller

Line ID name and number is displayed. You will see Clear Entry?.

¬ to clear.

º to leave your Caller Line ID

Press memory intact.

Managing the Phone Book

In “Using Phone Memory” you learned how to store and recall phone numbers with the internal Phone Book. You can access the same features, along with several advanced features, using your phone’s convenient menu system.

In this chapter you will learn how to:

• recall and store phone numbers using the

menu system

• store numbers with pause dialing

• store calling card sequences for easy access

• edit your memory information

• select the individual ringer style

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

You can also use your phone’s to scroll through the menu system.

« and » keys

Phone Book

Road Map for Phone Book

To enter the menu system:

ƒ, then press .

Press or

ƒ ⁄.

Press

Start:

Recent Calls

Phone Book

Recall By Name

Recall By Location

Store Number

Edit

Individual Ring Style

To Main Menu

Getting to Phone Book...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Phone Book, and press

3. Press to scroll to the following features, and press

select.

Recalling an Entry by Name

To recall a stored name with the Phone Book menu:

1. Follow the steps in the ”Getting to Phone

Book…” block above to select Recall By Name. You will see Enter 1st Letter.

2. Enter the ﬁrst letter of the name you want to

recall. The display shows the ﬁrst name in the phone book that begins with that letter. If no entry beginning with that letter is found, No As is displayed.

3. Press to scroll to the name you want.

4. Press and hold , or press

æ to call the

number you selected.

to select.

Tip:

You can also recall phone numbers without using the Phone Book. See “Recalling an Entry by Name” on page 35 or “Recalling an Entry by Memory Location” on page 36.

Phone Book

Recalling an Entry by Location

Each name and number you store is placed in a memory location numbered 01-99. After storing names and numbers, you can recall them by memory location with the Phone Book menu.

1. Follow the steps in the ”Getting to Phone

Book…” block above to select Recall By Location. You will see Location __.

2. Enter the two-digit memory location of the

number you want.

3. Press and hold , or press

number you selected.

æ, to call the

Storing with the Menu

Use the phone’s menu system to store names and numbers into the Phone Book.

1. Follow the steps in the ”Getting to Phone

Book…” block to select Store Number.You will see Enter Number.

2. Enter the phone number you want to store.

See “How to Enter Letters and Numbers” on page 34.

3. Press when you ﬁnish entering the

number. You will see Location __.

Tip:

If the chosen location is full, press

and restart the storing sequence.

4. Press

5. You will see Alpha Or §

6. Press , or

7. Press

«to store the sequence in the next

available location.

Enter the ﬁrst digit of the memory location and press ﬁrst available location beginning with that digit.

Enter the two-digit memory location where you want the sequence stored.

identify the phone number, or skip this step and continue with step 6. (See “How to Enter a Name” on page 34 for details on entering names.)

«to store the sequence in the

Enter a name to

¬, when you ﬁnish entering the

name. Your phone conﬁrms your entry by displaying the location, number, and name you stored. Proceed with step 7 below, or return to step 2 above to store more numbers.

º to exit the menu.

Getting to Phone Book...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Phone Book, and press

3. Press to scroll to the following features, and press

select.

Storing and Placing Numbers with Pause Dialing

Entering a Pause in a Number

When you call automated systems, a recorded message prompts you for PIN numbers, Voice Mail numbers, etc.

You can store these numbers in your phone’s memory, separated by “pauses”—special characters that tell your phone to wait before sending additional numbers.

1. Follow the steps in the ”Getting to Phone

Book…” block above to select Store Number.You will see Enter Number.

to select.

Phone Book

2. Enter the phone number you use to access

the automated system.

3. Press

4. Press to insert a pause (o) into the

5. Enter the next group of numbers (such as an

6. Enter any other required symbols (such as *

ƒ, then press æ.

You will see Insert Wait o.

sequence.

account number or PIN number.)

or #).

7. Insert another pause, and enter the next

group of numbers by repeating steps 3 through 5 as many times as necessary.

You can store up to 32 digits, including pauses. Then store the entire sequence as you would any phone number.

8. Press

9. Enter the two-digit memory location where

10. Enter a name for your sequence.

11. Press when you ﬁnish entering the name.

¬ to begin storing.

You will see Location __.

you want the sequence stored. You will see Alpha Or

(See “How to Enter a Name” on page 34 for details on entering names.)

Your phone conﬁrms your entry by displaying the location, number, and name you stored.

§.

Placing a Call with Pauses

To use your stored sequence:

1. Recall the stored number with the pause

inserted.

2. Press and hold , or press æ, to place the

call.

3. When the recording prompts you for

information, press or set of stored numbers.

æ to send the next

4. Press or press

necessary, to transmit all the numbers.

æ as many times as

Getting to Phone Book...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Phone Book, and press

3. Press to scroll to the following features, and press

select

Storing and Placing Numbers for Calling Card Information

Storing Calling Card Information

Like Pause Dialing, you can store calling card access numbers, separated by pauses, for recall later. You can also store a Number Character in the sequence to save a place for the number you call when you use your calling card.

See “Using Lock/Security Features” on page 73 for more information on protecting your calling card information.

1. Follow the steps in the ”Getting to Phone

Book…” block above to select Store Number.You will see Enter Number.

to select.

Phone Book

2. Enter the phone number you use to access

your calling card system. (Skip this step if you only dial 0.)

3. Press

4. Press to insert a pause (o) into the

5. Enter the next numbers, if needed. (For

6. Press

ƒ æ. You will see Insert Wait o.

sequence.

example, some long distance carriers require you to dial a 0 ﬁrst. If no further numbers are needed, skip to step 7.)

ƒ æ.

7. Press to scroll to the Number Character.

You will see Insert Number 'N.

8. Press to insert the 'N Character.

This special character saves a place for the phone number you will be calling. The number is inserted automatically when you place the call.

9. Press

10. Press to insert another pause, as in steps

11. Enter your calling card PIN number.

12. Press

13. Enter the two-digit memory location where

14. Enter a name for your sequence. (See “How

15. Press when you are ﬁnished entering the

ƒ æ.

3 and 4.

¬ to store your calling card

sequence. You will see Location __.

you want the sequence stored. You will see Alpha Or

to Enter a Name” on page 34 for details on entering names.)

name. Your phone conﬁrms your entry by displaying

the location, number, and name you stored.

§.

Placing a Calling Card Call

To recall your stored calling card information:

1. Recall the calling card information you

stored.

(See “Recalling an Entry by Name”” and “Recalling an Entry by Location” on page 49 for more information on Recalling Numbers.)

2. Press

æ before entering the number. You

will see Enter Number.

3. Enter the phone number you want to call,

including the area code. Enter the number manually, by location, or

recall.

4. Press and hold , or press

call. Your phone dials the number to access your

long distance provider.

5. Press , or press

group of numbers when you are prompted. The phone automatically inserts the selected

number to call at the appropriate time in the sequence.

6. Repeat step 5 to send the next group of

numbers as many times as necessary.

æ, to send the next

æ, to place the

Phone Book

Getting to Phone Book...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Phone Book, and press

3. Press to scroll to the following features, and press

select.

to select.

Editing a Memory Location

After you store names and numbers in the Phone Book, you can edit the information or erase entries at any time.

1. Follow the steps in the ”Getting to Phone

Book…” block above to select Edit.

2. Recall the entry by location or by name.

(See “Recalling an Entry by Name” and “Recalling an Entry by Location” on page 49.)

3. Press to begin editing the phone number.

The display shows the name brieﬂy, then the phone number.

4. Press

5. Enter your changes to the phone number.

6. Press when you ﬁnish editing the phone

7. Press

Ç to erase one digit at a time.

Press and hold number.

number. The display shows the location where your

number is currently stored.

Ç to erase the entire

Ç to erase the memory location, then

enter a new two-digit location.

Press to keep the phone number in its current location.

The display shows the name stored with the phone number you are editing.

8. Enter your changes to the name. (See “How

to Enter a Name” on page 34.) Press

Ç to erase one letter at a time, or

skip to step 9 to leave the name unchanged.

9. Press when you ﬁnish editing the name.

The display shows the new information.

10. Press to save your changes.

Your phone conﬁrms your entry by displaying the location, number, and name you stored.

Press

Ç to leave the information

unchanged. When you see Location __, enter a new two-

digit memory location to avoid overwriting the information in the current location.

Phone Book

11. Press

º to exit, or scroll to other features.

Getting to Phone Book...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Phone Book, and press

3. Press to scroll to the following features, and press

select.

to select.

Assigning an Individual Ring Style to a Phone Book Entry

You can use the individual ring style feature to assign one of nine ring styles to alert you of an incoming call from a phone number listed in your phone book.

Note: This feature will only operate if you subscribe to Caller ID from your service provider. Caller ID is not available in all areas.

1. Follow the steps in the ”Getting to Phone

Book…” block to select Individual Ring Style.

2. Select the phone book entry to which you

want to assign an individual ring style.

a. Enter the ﬁrst letter of the name entry

associated with the phone number.

b. Scroll up and down to reach the desired

phone book entry.

3. When you reach the phone number you want, select it by pressing or

The display will show Press 0-9, 0=OFF.

4. Press

‚ to assign the default ring style for

the number.

Press an entry from ⁄ to · to select one of the nine ring styles.

¬.

5. Press or ¬to select that ring style.

The display conﬁrms the selection by showing Ring Style Assigned.

6. Press º to exit, or scroll to other features.

Phone Book

Timing Your Calls

Your phone’s Call Timers give you a variety of options for managing your time. You can monitor the length of individual calls, set a timer to track monthly usage, or have the phone alert you at intervals that you specify.

In this chapter you will learn how to:

• view the timers

• monitor the length of your calls

• set and view the resettable timer for long-

term monitoring

• program audible timers for your individual

needs

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

You can also use your phone’s to scroll through the menu system.

« and » keys

Road Map for Call Timers

To enter the menu system:

ƒ, then press .

Press or

ƒ ⁄.

Press

Start:

Recent Calls

Phone Book

Timers

Individual XX YY

Resettable XXXXX

Cumulative XXXXX

Reset Timer

Individual Timer Off

One Minute Timer Off

Repeat Timer Off

Single Timer Off

To Main Menu

Call Timers

Getting to Call Timers...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Timers and press

3. Press to scroll to the following features, and press

select.

to select.

Viewing the Individual Call Timer

Shortcut:

Press

‰ »

for a quick

look at this timer.

Shortcut:

‰ »

Press

»» for a

quick look at this timer.

You can view the air-time of the most recent call or the call in progress (in minutes and seconds) at any time using this feature. The Individual Call Timer resets when you place the next call and when you turn the phone off. You can also choose to have the timer display while calls are in progress. See “Displaying the Individual Timer Automatically” on page 64.

1. Follow the steps in the ”Getting to Call Timers…” block above to select Individual XX YY. The display shows the air-time of your last call in minutes (

2. Press

º to exit, or scroll to other features.

) and seconds (YY).

Viewing the Resettable Call Timer

You can track how much air time you have accumulated at any time. Use this feature to view the time elapsed, and follow the instructions in “Resetting the Timer” on page 63 to reset the timer.

1. Follow the steps in the ”Getting to Call Timers…” block above to select Resettable XXXXX. The display shows your air time in minutes since you last reset the timer.

2. Press

º to exit, or scroll to other features.

Viewing the Cumulative Timer

This is a non-resettable timer that keeps track of your phone’s total air time (in minutes).

1. Follow the steps in the ”Getting to Call

Timers…” block to select Cumulative XXXXX. The display shows your air time in minutes since your phone was activated.

Shortcut:

Press

‰ »

»»»

for a quick look at this timer.

2. Press

º to exit, or scroll to other features.

Resetting the Timer

By resetting this timer at the beginning of each billing cycle, you can keep a running tab of your monthly usage. After you reset the timer, it continues to keep track of your air time (in minutes) until you reset it again.

1. Follow the steps in the ”Getting to Call

Timers…” block to select Individual XX YY.

2. Press to scroll to Reset Timer.

3. Press to reset the timer.

4. Press

º to exit, or scroll to other features.

Call Timers

Getting to Call Timers...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Timers and press

3. Press to scroll to the following features, and press

select.

to select.

Displaying the Individual Timer Automatically

Tip:

Activating the Individual Timer may reduce both standby and talk times.

When you turn this feature on, your phone automatically displays your air time in minutes ( and seconds (

1. Follow the steps in the ”Getting to Call Timers…” block to select Individual Timer. You will see Individual Timer Off or Individual Timer On.

2. Press to toggle between Individual Timer Off and Individual Timer On.

3. Press

) during and after each call.

º to exit, or scroll to other features.

Setting the One-Minute Audible Timer

Activate this feature to hear an audible beep 10 seconds before the end of every minute during a call. The party on the other end does not hear the beeps.

1. Follow the steps in the ”Getting to Call Timers…” block to select One Minute Timer. You will see One Minute Timer Off or One Minute Timer On.

2. Press to toggle between One Minute Timer Off and One Minute Timer On.

)

3. Press

º to exit, or scroll to other features.

Setting the Repeating Audible Timer

You can set this timer to beep during your calls at an interval that you select—from 11-999 seconds. You will hear the beep 10 seconds before the end of each interval, but the party on the other end does not hear the beeps.

1. Follow the steps in the ”Getting to Call

Timers…” block to select Repeat Timer. You will see Repeat Timer Off or Repeat Timer On.

2. Press to toggle between Repeat Timer Off

and Repeat Timer On. The prompt to enter seconds appears

you have turned the feature on. If you have turned it off, you will see Repeat Timer Off.

3. Enter the number of seconds you would like

between audible beeps. You will see Beep At YYY Secs.

4. Press to set the timer. The phone conﬁrms

the setting by displaying Set At YYY Secs.

5. Press

º to exit, or scroll to other features.

only if

Setting the Single Timer

Like the Repeating Timer, you can set the Single Timer to beep at a time that you select—from 11999 seconds. It beeps once during each call, 10 seconds before the end of the interval. The party on the other end does not hear the beep.

1. Follow the steps in the ”Getting to Call

Timers…” block to select Single Timer. You will see Single Timer Off or Single Timer On.

Call Timers

2. Press to toggle between Single Timer Off

and Single Timer On. The prompt to enter seconds appears

you have turned the feature on. If you have turned it on, you will see Single Timer Off.

3. Enter the number of seconds you would like between audible beeps. You will see Beep At YYY Secs.

4. Press to set the timer. The phone conﬁrms the setting by displaying Set At YYY Secs.

5. Press

º to exit, or scroll to other features.

only if

Adjusting Tone Controls

Use these features to select vibration mode, personalize your phone’s ringer styles, or turn the ringer off.

In this chapter you will learn how to:

• select the type of Call Alert or Message Alert

• choose from nine different ringer styles

• silence the keypad

• silence the scratchpad

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

You can also use your phone’s to scroll through the menu system.

« and » keys

Tone Controls

Road Map for Tone Controls

To enter the menu system:

ƒ, then press .

Press or

ƒ ⁄.

Press

Start:

Recent Calls

Phone Book

Timers

Tone Control

Call Alert Type

Msg Alert Type

Call Alert Ring Style

Keypad Tone On

Scratchpad Tone On

To Main Menu

Getting to Tone Controls...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to T one Control and press

3. Press to scroll to the following features, and press

select.

Selecting Call Alert Type

to select.

Using this feature, you can choose to be alerted to incoming calls using the vibrating ringer, the ringer, both, or neither. Ring Only is the default.

In particular, the VibraCall™ Alert vibrating alert is ideal for situations where ringing may not be appropriate, or in noisy places where you might not hear the ringer.

When both the ringer and vibrating alerts are selected, the phone alerts you by vibrating for three cycles and then ringing.

Notes:

• Although you set your call alert type below,

the selection is temporarily suppressed if Pager Mode is enabled. See “Activating Pager Mode” on page 85 for details.

• When your phone is connected to an external

power supply and you receive an incoming call, your phone will ring, regardless of the call alert setting.

1. Follow the steps in the ”Getting to Tone

Controls…” block above to select Call Alert Type.The display shows your current alert type setting.

Shortcut:

Press

ƒ †

to toggle the VibraCall™ Alert function on and off.

Tone Controls

2. Press to scroll through your choices:

3. Press when you reach the setting you

Ring Only

Vibrate Only

Ringer On and Vib On

Ringer Off Vib Off

want.

Shortcut:

Press

ƒ †

to toggle among the Message Alert and Call Alert types.

4. Press

º to exit, or scroll to other features.

Selecting Message Alert Type

Using this feature, you can choose to receive an alert to incoming voice mails and short messages using the VibraCall™ alert, beeping alert, or no alert.

The beep tone and vibrating patterns differ if the incoming message is marked urgent versus normal. You will receive one beep for a normal message and three beeps for an urgent message.

1. Follow the steps in the ”Getting to Tone Controls…” block to select Message Alert Type.

2. Press to scroll through your choices:

3. Press when you reach the setting you

4. Press

Messages Beep, Messages Vibrate, Beep Off, and Vib Off. Messages Beep is the default setting.

want.

º to exit, or scroll to other features.

Getting to Tone Controls...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to T one Control and press

3. Press to scroll to the following features, and press

select

Selecting a Ring Style

Your phone lets you select any of nine different ring styles. After you choose a style, the phone give you a brief sample of the new ring style, or vibrates if you have selected the VibraCall™ Alert feature.

1. Follow the steps in the ”Getting to Tone

Controls…” block to select Call Alert Ring Style.

to select.

2. Press

3. Press when you reach the ring style you

4. Press

⁄ through · to hear the different

ring styles, or scroll through the ring styles. Ring Style 1 is the default setting.

want. The display will show Ring Style X Set.

º to exit, or scroll to other features.

Turning Keypad Tones On and Off

Keypad tones are the sounds you hear when you press any key on the phone. By default, keypad tones are turned on. If you want to be discreet, use this feature to silence the audio feedback from the keypad.

Note: The other party still hears tones.

1. Follow the steps in the ”Getting to Tone

Controls…” block to select Keypad Tone. You will see Keypad Tone On or Keypad Tone Off.

Tone Controls

2. Press to toggle between Keypad Tone On

and Keypad Tone Off.

3. Press

º to exit, or scroll to other features.

Turning Scratchpad Tones On and Off

Scratchpad tones are the tones that your phone sends to access automated calling systems like Voice Mail. By default, scratchpad tones are turned on. If you don’t want your party to hear these sounds when you use the scratchpad, turn the scratchpad tones off.

1. Follow the steps in the ”Getting to Tone Controls…” block to select Scratchpad Tone. You will see Scratchpad Tone On or Scratchpad Tone Off.

2. Press to toggle between Scratchpad Tone On and Scratchpad Tone Off.

3. Press

Note: If you turned the scratchpad tones off but

want to access a tone-activated system like Voice Mail, place the call, enter the numbers you need to transmit, then:

º to exit, or scroll to other features.

Press

‰ æ to send the tones.

Using Lock/Security Features

While you probably would not want to leave your phone unattended, your TDMA digital StarTAC™ phone has a number of built-in security features to prevent unauthorized use.

In this chapter you will learn how to:

• activate the Voice Privacy feature

• lock and unlock your phone

• place priority calls

• change your lock code

• restrict call placement and memory access

• reset or clear your phone’s settings

Follow these symbols as a guide for using the keys on the side of your phone:

Press to scroll up.

Press

to select.

Press

to scroll down.

Lock/Security

You can also use your phone’s to scroll through the menu system.

« and » keys

Road Map for Lock Security

To enter the menu system:

ƒ, then press .

Press or

ƒ ⁄.

Press

Start:

Recent Calls

Phone Book

Timers

Tone Control

Lock Secure

Privacy Off

Automatic Lock Off

Priority Call Off

Secure Options

Code

View Lock Code

Change Lock Code

Service Level X

To Main Menu

Master Reset

Master Clear

To Main Menu

Getting to Lock Security...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Lock Secure and press

3. Press to scroll to the following features, and press

select.

to select.

Activating Voice Privacy

When you activate your phone’s Voice Privacy feature, you request your cellular system to search for a Voice Privacy channel with each call. If no Voice Privacy channel is available (or your call is “handed off” to a cell where a Voice Privacy channel is not available), ﬁve short beeps alert you that the call is no longer private.

You must select the Voice Privacy feature before you make a call in order for that call to search for a Voice Privacy channel.

Note: This feature is not available in all markets. Contact your Service Provider for additional information about your service area.

To turn the Voice Privacy feature on or off:

1. Follow the steps in the ”Getting to Lock/

Security…” block above to select Voice Privacy. You will see Privacy Off or Privacy Preferred.

2. Press to toggle between Privacy Off and

Privacy Preferred.

3. Press

º to exit, or scroll to other features.

Lock/SecurityLock/Security

Shortcut:

Press

ƒ, the

Smart Button,

⁄ ﬁ, and

continue with step 2.

Locking/Unlocking Your Phone

For your protection, you must enter the six-digit security code to access the features that your phone contains. The factory-programmed lock code for unlocking the phone is 123. The six-digit security code is 000000. These may have been changed when your phone was activated.

Locking Your Phone Automatically

When you turn this feature on, your phone automatically locks itself each time you turn it off.

1. Follow the steps in the ”Getting to Lock/ Security…” block to select Automatic Lock. You will see Automatic Lock Off or Automatic Lock On.

2. Press to toggle between Automatic Lock Off and Automatic Lock On.

Tip:

“LOCK” is

printed on the

ﬁ

key, as a

reminder.

3. Press

º to exit, or scroll to other features.

Locking Your Phone Manually

You can lock your phone manually at any time to prevent unwanted use. Once you lock the phone, it remains locked whether it is powered on or off.

1. Press

2. Press and hold ﬁ for at least one full

3. Press

ƒ.

second.You will see Lock?.

¬ or to lock. You will see Locked.

Unlocking Your Phone

To unlock your phone:

Once your phone is on, enter your three- digit lock code to unlock your phone. (See “Viewing the Lock Code” on page 78 and “Changing the Lock Code” on page 78 for more information on your lock code.)

Answering Calls While the Phone Is Locked

You can still receive calls when the phone is locked. To answer an incoming call:

1. Enter your three-digit lock code.

2. Press and hold , or press æ to receive

the call.

Activating Priority Calling

Priority Call allows the Turbo Dial™ function to dial from memory location 01—even when the phone is locked. You can store an emergency number or the number of someone you would like to contact in case of emergency.

Note: Some cellular systems have their own emergency numbers and deny access to emergency numbers like 911 (not available in some areas). Check with your Service Provider for more information.

Tip:

If you forget your lock code, try pressing

¤ ‹

last three digits of your cellular phone number.

⁄

or the

By default, Priority Call is activated. To turn it off or to switch it back on, complete the following steps:

1. Follow the steps in the ”Getting to Lock/

Security…” block on the previous page to select Priority Call. You will see Priority Call Off or Priority Call On.

2. Press to toggle between Priority Call

Off and Priority Call On.

3. Press

º to exit, or scroll to other features.

Shortcut:

Press

ƒ, the

Smart Button,

¤ ·, and

continue with step 2.

Lock/Security

Getting to Secure Options...

1. Press ƒ, then press to enter the menu system.

2. Press to scroll to Lock Secure and press

3. Press to scroll to the Secure Options submenu, and press

to select.

4. Enter your six-digit security code, scroll to the following

features, and press

to select.

Viewing the Lock Code

To display the active three-digit lock code:

1. Follow the steps in the ”Getting to Secure

Options…” block above to select View Lock Code. You will see View Lock Code.

2. Press to display your three-digit lock code.

The code appears for a few seconds.

3. Press

º to exit, or scroll to other features.

Changing the Lock Code

To change your three-digit lock code:

1. Follow the steps in the ”Getting to Secure

Options…” block above to select Change Lock Code. You will see Enter Code ___.

2. Enter the new three-digit code. You will see

Changed To XXX.

3. Press

Note: If you try to change your lock code to 911 or

the ﬁrst three digits of an emergency number, you will see Code Invalid, and the code you entered will not be accepted. You will return to step 1 above.

º to exit, or scroll to other features.

Restricting Call Placement

You may want to restrict call placement or hide memory information when loaning your phone to others.

Selecting a Service Level

1. Follow the steps in the ”Getting to Secure

Options…” block to select Service Level. The phone displays your current service level. Refer to the chart on the next page.

2. Press to scroll through the service level

settings, and press to select the service level you want.

If you select Level 7, the phone prompts you for the range of memory locations you want to remain active. You will see Range 1-__.

Enter the range of digits memory locations from which calls are allowed. The phone conﬁrms the allowed range, and you will see 1-XX Allowed.

3. Press

º to exit, or scroll to other features.

Service Level Settings

Each of your phone’s eight service levels offers a different combination of access privileges and restriction.

Note: Caller Line ID is an optional network and subscription feature that is not available in all areas.

Level Description Display

• Calls can be placed from

memory locations 1-10 only.

• No dialing from keypad

• No memory edit or storage

• No access to name

Motorola T5ZG1 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
