Motorola T5HA1 Users manual
APPLICANT: MOTOROLA,INC.
FCC ID: IHDT5HA1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft of the User’s Manual follows this page.
The text on the following two pages will be added to the user manual.
Specific Absorption Rate Data
SAR Data
This model wireless phone meets the
government’s requirements for exposure to radio
waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government and by the Canadian
regulatory authorities. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC and by the Canadian regulatory
authorities is 1.6 W/kg.
standard operating positions accepted by the FCC and by Industry
Canada with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
SAR Data
1
Tests for SAR are conducted using
level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless
base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S.
and Canada, it must be tested and certified to the FCC and Industry
Canada that it does not exceed the limit established by each
government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
reported to the FCC and available for review by Industry Canada.
The highest SAR value for this model phone when tested for use at
1.50 W/kg, and when worn on the body, as described in
the ear is
this user guide, is
(Body-worn
measurements differ among phone models, depending upon
available accessories and regulatory requirements).
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to
this product model could cause differences in the SAR value for
later products; in all cases, products are designed to be within the
guidelines.
0.71 W/kg.
2
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA)
Web site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
2. The SAR information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this
product.
SAR Data
W212
CDMA
motorola.com
HELLOMOTO
Welcome to the world of Motorola digital wireless communications! We are pleased that
you have chosen the Motorola W212 wireless phone.
Menu Key
Opens a sub-menu when
appears in the
display,or selects
a highlighted
feature.
Left Soft Key
Performs functions in lower
left display.
Send/Answer Key
Make & answer calls. Press in
idle screen to see list
of recently dialled calls.
Note:
The above illustration is for reference only. There may be slight differences between the appearances of handset,
keys and contents of display used in this manual and those of your handset. Please refer to your handset for actuality.
Earpiece
Listen to your voice
calls & messages.
Right Soft Key
Performs functions in
lower right display.
Power/End Key
Turn the phone on/off,
end calls, exit menus.
Navigation Key
Scroll up, down, left or right.
Microphone
1
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
ZZZ KHOORPRWR FRP
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners.
© Motorola, Inc. 2006.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
2
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United
States and other countries preserve for Motorola and third-party
software providers certain exclusive rights for copyrighted
software, such as the exclusive rights to distribute or reproduce
the copyrighted software. Accordingly, any copyrighted software
contained in the Motorola products may not be modified, reverseengineered, distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Motorola or any
third-party software provider, except for the normal, non-exclusive,
royalty-free license to use that arises by operation of law in the
sale of a product.
check it out!
Headset Jack
Insert the headset
accessory for
handsfree use.
Battery
Note:
The above illustration is for reference only. There may be slight differences between the appearances of handset,
keys and contents of display used in this manual and those of your handset. Please refer to your handset for actuality.
Note:
The function available on this handset may vary in different regions and nations. Please contact your local customer
service centres, agencies or retailers if you have any questions about the handset function. Motorola reserves all rights to
revise and change this user's manual without obligation to notify any person of such revision or changes.
Power Connector
Charge the battery.
Speakerphone
Note: Your phone may not appear
exactly as the phone image above,
but all the key locations, sequences,
and functions remain the same.
3
contents
check it out!. . . . . . . . . . . 3
Safety and General
Information . . . . . . . . . . . 7
Use and Care . . . . . . . . . 12
essentials . . . . . . . . . . . . 14
about this guide. . . . . . 14
RUIM card . . . . . . . . . . 15
battery . . . . . . . . . . . . . 15
Battery tips . . . . . . . . . 16
turn it on & off . . . . . . . 17
make a call. . . . . . . . . . 18
answer a call . . . . . . . . 18
correcting entry errors. 18
main attractions . . . . . . 19
zoom number display . 19
datebook . . . . . . . . . . . 19
read messages with
iMelody . . . . . . . . . . . . 24
contents
4
iMelody downloadable
ring tones via EMS . . . 24
FM radio . . . . . . . . . . . 24
speakerphone . . . . . . . 26
multi-letter phonebook
search . . . . . . . . . . . . . 26
basics . . . . . . . . . . . . . . . 27
display . . . . . . . . . . . . . 27
menus . . . . . . . . . . . . . 29
text entry . . . . . . . . . . . 31
volume. . . . . . . . . . . . . 33
navigation key . . . . . . . 34
codes & passwords. . . 34
restrict calls . . . . . . . . . 34
customize. . . . . . . . . . . . 35
ring style . . . . . . . . . . . 35
time & date . . . . . . . . . 36
animation. . . . . . . . . . . 36
wallpaper . . . . . . . . . . . 36
screen saver . . . . . . . . 36
answer options . . . . . . 36
calls. . . . . . . . . . . . . . . . . 38
recent calls . . . . . . . . . 38
redial . . . . . . . . . . . . . . 38
speed dialing . . . . . . . . 39
return a call . . . . . . . . . 39
mute a call . . . . . . . . . . 39
speakerphone . . . . . . . 39
caller ID . . . . . . . . . . . . 39
emergency calls . . . . . 40
international calls . . . . . 40
voicemail . . . . . . . . . . . 41
special characters . . . . 41
other features . . . . . . . . 42
phonebook. . . . . . . . . . 42
recent calls . . . . . . . . . 43
messages. . . . . . . . . . 44
settings. . . . . . . . . . . . 46
more features. . . . . . . 51
game . . . . . . . . . . . . . 52
alarm clock . . . . . . . . . 52
voice memo . . . . . . . . 52
service & repairs. . . . . . 53
index . . . . . . . . . . . . . . . 61
contents
5
main menu
e
Messages
• Create Message
•Voicemail
•Text Msgs
•Quick Notes
• Outbox
•Drafts
n
Phonebook
•[New Entry]
s
Recent Calls
• Missed Calls
• Received Calls
• Dialed Calls
• Call Timer
menu map
6
menu map
Q
Games
• Football
•Crazy
• Rebels
x
MyMenu
• [New MyMenu]
A
Alarm Clock
•[New Entry]
y
UTK *
Brew
• Mobile Shop
• Settings
•Help
M
Datebook *
w
Settings
• Ring Styles
• Phone Status
• In-Call Setup
• Security
• Personalize
•Initial Setup
•Network
• Airplane Mode
• Headset
f
More
• Calculator
•Voice Memo
• Stop Watch
• Lantern
• Datebook
•Alarm Clock
•FM Radio
• Service Dial
*
Network Dependent
The above gives an example of the typical
structure of the main menu. Please refer to the
handset for the actual structure.
Safety and General Information
Safety Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this
information before using your mobile device.
*
Exposure to Radio Frequency (RF)
Energy
Your mobile device contains a transmitter and receiver. When it is
ON, it receives and transmits RF energy. When you communicate
with your mobile device, the system handling your call controls the
power level at which your mobile device transmits.
Your Motorola mobile device is designed to comply with local
regulatory requirements in your country concerning exposure of
human beings to RF energy.
Operational Precautions
For optimal mobile device performance and to be sure that human
exposure to RF energy does not exceed the guidelines set forth in
* The information provided in this document supersedes the general
safety information in user’s guides published prior to May 1, 2006.
the relevant standards, always follow these instructions and
precautions.
External Antenna Care
If your mobile device has an external antenna, use only a
Motorola-supplied or approved replacement antenna. Use of
unauthorized antennas, modifications, or attachments could
damage the mobile device and/or may result in your device not
complying with local regulatory requirements in your country.
DO NOT hold the external antenna when the mobile device is IN
USE. Holding the external antenna affects call quality and may
cause the mobile device to operate at a higher power level than
needed.
Product Operation
When placing or receiving a phone call, hold your mobile device
just like you would a landline phone.
If you wear the mobile device on your body, always place the
mobile device in a Motorola-supplied or approved clip, holder,
holster, case, or body harness. If you do not use a body-worn
accessory supplied or approved by Motorola, keep the mobile
Safety Information
7
device and its antenna at least 2.5 centimeters (1 inch) from your
body when transmitting.
When using any data feature of the mobile device, with or without
an accessory cable, position the mobile device and its antenna at
least 2.5 centimeters (1 inch) from your body.
Using accessories not supplied or approved by Motorola may
cause your mobile device to exceed RF energy exposure
guidelines. For a list of Motorola-supplied or approved
accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference
from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some
circumstances your mobile device may cause interference with
other devices.
Follow Instructions to Avoid Interference
Problems
Turn off your mobile device in any location where posted notices
instruct you to do so. These locations include hospitals or health
care facilities that may be using equipment that is sensitive to
external RF energy.
In an aircraft, turn off your mobile device whenever instructed to
do so by airline staff. If your mobile device offers an airplane mode
or similar feature, consult airline staff about using it in flight.
Safety Information
8
Pacemakers
If you have a pacemaker, consult your physician before using this
device.
Persons with pacemakers should observe the following
precautions:
•
ALWAYS keep the mobile device more than
20 centimeters (8 inches) from your pacemaker when the
mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the pacemaker to minimize the
potential for interference.
•
Turn OFF the mobile device immediately if you have any
reason to suspect that interference is taking place.
Hearing Aids
Some mobile devices may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing
aid manufacturer or physician to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult your
physician or the manufacturer of your device to determine if it is
adequately shielded from RF energy.
Driving Precautions
Check the laws and regulations on the use of mobile devices in the
area where you drive. Always obey them.
When using your mobile device while driving, please:
•
Give full attention to driving and to the road. Using a
mobile device may be distracting. Discontinue a call if you
can’t concentrate on driving.
•
Use handsfree operation, if available.
•
Pull off the road and park before making or answering a
call if driving conditions so require.
Responsible driving practices can be found in the “Smart Practices
While Driving” section at the end of this guide and/or at the
Motorola Web site:
www.motorola.com/callsmart
.
Operational Warnings
Obey all posted signs when using mobile devices in public areas,
such as health care facilities or blasting areas.
Automobile Air Bags
Do not place a mobile device in the air bag deployment area.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not
always posted, and can include fueling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, or areas
where the air contains chemicals or particles, such as grain, dust,
or metal powders.
When you are in such an area, turn off your mobile device, and do
not remove, install, or charge batteries. In such areas, sparks can
occur and cause an explosion or fire.
Damaged Products
If your mobile device or battery has been submerged in water,
punctured, or subjected to a severe fall, do not use it until you take
it to a Motorola Authorized Service Center. Do not attempt to dry it
with an external heat source, such as a microwave oven.
Batteries and Chargers
If jewelry, keys, beaded chains, or other conductive
materials touch exposed battery terminals, this
could complete an electrical circuit (short circuit),
become very hot, and could cause damage or
injury. Be careful when handling a charged battery,
particularly when placing it inside a pocket, purse, or other
container with metal objects.
batteries and chargers.
To avoid risk of personal injury, do not dispose of your
Caution:
battery in a fire.
Your battery, charger, or mobile device may contain symbols,
defined as follows:
Use only Motorola Original
Safety Information
9
Symbol Definition
032374o
032376o
032375o
Important safety information follows.
Do not dispose of your battery or mobile
device in a fire.
Your battery or mobile device may require
recycling in accordance with local laws.
Contact your local regulatory authorities
for more information.
Do not throw your battery or mobile device
in the trash.
Li Ion BATT
032378o
Your mobile device contains an internal
lithium ion battery.
Do not let your battery, charger, or mobile
device get wet.
Listening at full volume to music or voice
through a headset may damage your
hearing.
Safety Information
10
Choking Hazards
Your mobile device or its accessories may include detachable
parts, which may present a choking hazard to small children. Keep
your mobile device and its accessories away from small children.
Glass Parts
Some parts of your mobile device may be made of glass. This glass
could break if the product is dropped on a hard surface or receives
a substantial impact. If glass breaks, do not touch or attempt to
remove. Stop using your mobile device until the glass is replaced
by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts
when exposed to flashing lights, such as when playing video
games. These may occur even if a person has never had a previous
seizure or blackout.
If you have experienced seizures or blackouts, or if you have a
family history of such occurrences, please consult with your
physician before playing video games or enabling a flashing-lights
feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. It is always
a good idea to hold the screen away from your eyes, leave the
lights on in the room, take a 15-minute break every hour, and stop
use if you are very tired.
Caution About High Volume Usage
Listening at full volume to music or voice through a
headset may damage your hearing.
Repetitive Motion
When you repetitively perform actions such as pressing keys or
entering finger-written characters, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of
your body. If you continue to have discomfort during or after such
use, stop use and see a physician.
FCC Notice to Users
Motorola has not approved any changes or modifications to this
device by the user. Any changes or modifications could void the
user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. See 47 CFR Sec. 15.19(3).
If your mobile device or accessory has a USB connector, or is
otherwise considered a computer peripheral device whereby it can
be connected to a computer for purposes of transferring data, then
it is considered a Class B device and the following statement
applies:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the
receiver.
•
Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician
for help.
Safety Information
11
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to
water, rain, extreme humidity,
sweat, or other moisture.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or
above 45°C/113°F.
microwaves the ground
Don’t try to dry your phone in a
microwave oven.
12
Don’t expose your phone to
dust, dirt, sand, food, or other
inappropriate materials.
To clean your phone, use only a
dry soft cloth. Don’t use alcohol
or other cleaning solutions.
Don’t drop your phone.
Recycling Information
Caring for the Environment by Recycling
This symbol on a Motorola product means the product
should not be disposed of with household waste.
Disposal of your Mobile Telephone and Accessories
Please do not dispose of mobile telephones or electrical
accessories, such as chargers or headsets, with your household
waste. In some countries or regions, collection systems have been
set up to handle waste electrical and electronic items. Please
contact your regional authorities for more details. If no suitable
scheme exists, you may return unwanted mobile telephones and
electrical accessories to any Motorola Approved Service Centre in
your region.
Recycling Information
13
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it:
This example shows that, from the home
screen, you press
highlight and select
and select
14
Press M >
Dialed Calls
essentials
Recent Calls > Dialed Calls
M
to open the menu,
Recent Calls
.
, then highlight
S
Press
feature. Press
menu feature.
symbols
up or down to highlight a menu
This means a feature is network/
subscription dependent and may
not be available in all areas. Contact
your service provider for more
information.
This means a feature requires an
optional accessory.
SELECT
to select the highlighted
RUIM card
battery
Yo u r Removable-User Identity Module
(RUIM) card contains personal
information like your phone number
and phonebook entries.
battery installation
12
RUIM card installation
12
34
Caution:
card. Avoid exposing your RUIM card to static
electricity, water, or dirt.
Do not bend or scratch your RUIM
essentials
15
battery charging
New batteries are
shipped partially
charged. Before you can
use your phone, install
and charge the battery as
shown in the battery
installation and battery
charging sections. Some
batteries perform best
after several full charge/
discharge cycles.
When the battery
charging is complete, the battery icon will
change to a battery full icon ( ) and the
screen displays
Tip:
Relax, you can't overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
essentials
16
Charging Complete
.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
•
Always use Motorola
Original batteries and
chargers. The warranty
does not cover damage
caused by non-Motorola batteries and/
or chargers.
•
New batteries or batteries stored for a
long time may take more time to
charge.
•
When charging your battery, keep it
near room temperature.
•
When storing your battery, keep it
uncharged in a cool, dark, dry place.
•
Never expose batteries to
temperatures below -10°C (14°F) or
Loading...
