APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EH1

INSTRUCTION MANUAL

A preliminary draft copy of the Users Manual follows:

EXHIBIT 8

User Manual

C-215

START HERE >

Welcome

Left Soft Key

Performs funcions

identified by left dis-

play prompt.

Menu Key

Open a menu when

is in the display.

Power/End Key

Press & hold to

turn phone on &

off. Press &

release to end

phone calls, exit

menu system.

Earpiece

Antenn

Right Soft Key

Performs functions

identified by right

display prompt.

Navigation Keys

Scroll through

lists, set volume.

Send/Answer Key

Make and answer

calls; press in idle to

list recently dialed

calls.

Microphone

Power Connector

Insert charger.

Your phone may ot appear exactly as the phone image above. Note that all key locations, sequences, and functions remain

the same with any of the covers.

Motorola, Inc., Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)

www.motorola.com (United States) www.motorola.ca (Canada)

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. Acrobat and Acrobat Reader are registered trademarks of Adobe Systems Incorporated.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law.

Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Actual part numbers to be provided.

Manual number: 6809457A28-O Cover number: 8988485L61-O

Contents

Safety and General Information ............................................... 12

Getting Started........................................................................... 18

What’s in the Box? ................................................................18

About This Guide...................................................................18

Optional Features.................................................................. 19

Optional Accessories ............................................................19

Installing the Battery.............................................................. 19

Charging the Battery ............................................................. 20

Charging time........................................................................ 21

Battery Use............................................................................22

Changing Your SIM Card ......................................................24

Resetting Your Phone ...........................................................26

Turning Your Phone On ............................................................26

Adjusting the Volume ............................................................27

Making a Call.........................................................................28

Answering a Call ...................................................................29

Dialing Menu ......................................................................... 29

Active Call Menu ................................................................... 29

1. Mute ........................................................................... 29

2. My Phone Number ..................................................... 30

3. Outgoing Calls ...........................................................30

4. Incoming Calls ...........................................................30

5. New Message ............................................................31

6. Voice Privacy .............................................................31

7. Tone Lenght ............................................................... 31

Learning to Use Your Phone ....................................................32

Using the Display .................................................................32

Using the 4-Way Navigation Keys ........................................ 35

Using Menus ........................................................................36

Selecting a Feature Option ...................................................37

Entering Text ........................................................................37

Choosing a Text Entry Method .............................................39

Using the TAP Method .........................................................40

Using the iTAP Method ........................................................42

Using Symbol Method ..........................................................45

Symbol Chart ........................................................................45

Browse (Canned message or Quick Title) ............................ 46

Quick Title ............................................................................47

Recent Calls

Outgoing Calls ......................................................................48

Incoming Calls ......................................................................50

Missed Calls .........................................................................51

Erase History ........................................................................51

1. Outgoing Calls ........................................................51

2. Incoming Calls ........................................................51

3. Missed Calls ...........................................................52

4. All Calls ..................................................................52

Call Time ...............................................................................52

1. Last Call .................................................................52

2. Outgoing Calls ........................................................52

3. Incoming Calls ........................................................53

4. Total .......................................................................53

Data Times ...........................................................................53

Data Volumes .......................................................................53

TONES / IMGS

Theme ..................................................................................54

Picture Viewer ......................................................................55

My Tones ..............................................................................56

New Tone....................................................................57

Edit .............................................................................57

Delete .........................................................................58

Play ............................................................................58

Help ............................................................................58

BROWSER

Launch Browser ............................................................. 59

Interacting with Web Pages ...........................................59

Launch Browser with Web Session Profile ....................60

View Information of Current Profile ................................ 60

View Detail Information of Current Item ......................... 61

Create and Save a Browser New Profile .............................. 61

Setting Profile Discription ..................................................... 62

Service Load ........................................................................62

Downloading Pictures, Games, and Sounds through

Wap Browser ........................................................................ 63

BREW

How to Download 6 .................................................................4

How to Search for Applications 6...................................... 5

Setting ............................................................................65

1 Changing the order of applications .........................66

2 Moving Applications ................................................67

3 Manage Applications ............................................... 67

4 Main Menu View ......................................................68

Help ......................................................................................68

PHONE BOOK

Creating a Phonebook Entry .................................................69

To create an entry:.......................................................... 70

Finding a Phonebook Entry................................................... 72

1. Finding by Name .................................................... 72

2. Finding by Location ................................................ 73

3. Finding by Speed Dial ............................................ 74

Phonebook Option.................................................................75

New, Edit, Delete, Send Message, Set Primary No,

Add Digits, Attach Number, Sort

Speed Dial ............................................................................77

Dialing a Phonebook Entry ...................................................78

Speed Dialing .......................................................................78

Turbo Dialing ........................................................................78

Editing a Phonebook Entry ...................................................79

Viewing My Number .............................................................79

Checking Phonebook Capacity ............................................80

Erasing All Entries ................................................................80

MESSAGING

SMS ......................................................................................81

Sending a Text Message ......................................................81

Receiving a New Message ................................................... 82

Viewing Messages ...............................................................83

Setting Up SMS ....................................................................84

MMS .....................................................................................84

Compose MMS ..............................................................84

Compose MMS using Template......................................85

Send MMS .....................................................................86

Get MMS ........................................................................86

Play MMS .......................................................................87

Menu Description .................................................................87

Remote Box ..........................................................................89

Delivery Report ..................................................................... 89

Setting ..................................................................................89

WAP Alerts ........................................................................... 89

Viewing WAP Message ........................................................89

Voice Mail ............................................................................. 90

Receiving a New Voicemail Message ............................ 90

Listening to a Voicemail Message .................................90

QUICK DIAL

Calling Quick Dial ................................................................. 91

Change Quick Dial ...............................................................91

Delete Quick Dial ..................................................................91

VOICE MAIL

Receiving a New Voicemail Message ...................................92

Listening to a Voicemail Message......................................... 92

OFFICE TOOLS

Datebook ..............................................................................93

Alarm Clock .......................................................................... 95

Calculator .............................................................................96

Access Calculator .................................................................97

Using the Calculator ............................................................. 98

World Time ......................................................................... 103

Stopwatch ...........................................................................104

SETTING UP YOUR PHONE

SOUNDS ............................................................................105

Ringer Volume .............................................................105

Voice Volume ............................................................... 106

Key Beep Volume ........................................................106

Ringer Type ........................................................................ 107

Predefined ............................................................................07

My Tones ............................................................................107

Alerts Service .....................................................................107

Minute Beep .......................................................................108

Voice Mail ........................................................................... 108

Message .............................................................................109

Call Lost .............................................................................109

Date Book ...........................................................................109

Tone Length .......................................................................110

DISPLAY ............................................................................110

Adjusting the Backlight .................................................110

Setting Display Contrast ..............................................111

Selecting a Screen Saver Timer ..................................111

Greetings .....................................................................112

Banner .........................................................................112

Time and Date 112

SECURITY .........................................................................113

Unlocking Your Phone .................................................113

Lock Phone ..................................................................113

Change Lock Code ......................................................114

Phonebook Lock ..........................................................114

Call Restriction .............................................................115

Limit USE .....................................................................115

1. Lock Application 115

2. Special Numbers 117

Master Reset ................................................................118

Master Clear ................................................................118

SYSTEM

System Select .............................................................. 119

Active Line ...................................................................120

Voice Privacy ...............................................................120

Network ........................................................................121

DATA SERVICE ................................................................. 122

OTHERS ............................................................................123

Language .....................................................................123

Answer Options ............................................................124

Phone INFO ................................................................. 127

MORE .......................................................................................129

Specific Absorption Rate Data .................................................. 130

Additional Health and Safety Information Consumer

Information on Wireless Phones from the FDA ........................133

Motorola Limited Warranty for the United States and

Canada What Does this Warranty Cover? ................................139

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.

READ THIS INFORMATION BEFORE USING YOUR PHONE. The information provided in this document supersedes the

general safety information in user guides published prior to December 1, 2002.

Exposure To Radio Frequency (RF) Energy

Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.

Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

To assure optimal phone performance and make sure human exposure to RF energy is within the guidelines set forth in the relevant standards, always adhere to the following procedures.

External Antenna Care

Use only the supplied or Motorola-approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone.

Do NOT hold the external antenna when the phone is IN USE. Holding the external antenna affects call quality and may cause the phone to operate at a higher power level than needed. In addition, use of unauthorized antennas may result in noncompliance with the local regulatory requirements in your country.

Phone Operation

When placing or receiving a phone call, hold your phone as you would a wireline telephone.

Body-Worn Operation

To maintain compliance with RF energy exposure guidelines, if you wear a phone on your body when transmitting, always place the phone in a Motorola-supplied or approved clip, holder, holster, case, or body harness for this phone, if available. Use of accessories not approved by Motorola may exceed RF energy exposure guidelines. If you do not use one of the body-worn accessories approved or supplied by Motorola, and are not using the phone held in the normal use position, ensure the phone and its antenna are at least 1 inch (2.5 centimeters) from your body when transmitting.

Data Operation

When using any data feature of the phone, with or without an accessory cable, position the phone and its antenna at least 1 inch (2.5 centimeters) from your body.

Approved Accessories

Use of accessories not approved by Motorola, including but not limited to batteries and antenna, may cause your phone to exceed RF energy exposure guidelines. For a list of approved Motorola accessories, visit our website at www.Motorola.com.

RF Energy Interference/Compatibility

Note: Nearly every electronic device is susceptible to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your phone may cause interference.

Facilities

Turn off your phone in any facility where posted notices instruct you to do so. These facilities may include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker. Persons with pacemakers should:

•

ALWAYS keep the phone more than 6 inches (15 centimeters) from your pacemaker when the phone is turned ON.

•

NOT carry the phone in the breast pocket.

•

Use the ear opposite the pa cemaker to minimize the potential for interference.

•

Turn OFF the phone immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

Use While Driving

Check the laws and regulations on the use of phones in the area where you drive. Always obey them.

When using your phone while driving, please:

•

Give full attention to driving and to the road.

•

Use hands-free operation, if available.

•

Pull off the road and park before making or answering a call if

driving conditions so require. Responsible driving best practices may be found in the “Wireless Phone Safety Tips” at the end of this manual and at the Motorola website

www.Motorola.com/callsmart

Operational Warnings

For Vehicles With an Air Bag

Do not place a phone in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive atmosphere, unless it is a phone type especially qualified for use in such areas and certified as “Intrinsically Safe”. Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death.

Note:

The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Areas with potentially explosive atmospheres are often but not always posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your phone when you are near electrical blasting caps, in a blasting area, or in areas posted “Turn off electronic devices.” Obey all signs and instructions

Batteries

Batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touch exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

Use only Motorola original batteries and chargers.

Your battery or phone may contain symbols, defined as follows:

Symbol Definition

Important safety information will follow.. Your battery or phone should not be disposed of in a

fire. Your battery or phone may require recycling in accordance with local laws. Contact your local regulatory authorities for more information. Your battery or phone should not be thrown in the trash.

Your phone contains an internal lithium ion battery.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to blinking lights, such as when watching television or playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your doctor before playing video games on your phone or enabling a blinking-lights featureon your phone. (The blinking-light feature is not available on all products.)

Parents should monitor their children's use of video game or other features that incorporate blinking lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation.

To limit the likelihood of such symptoms, please take the following safety precautions:

•

Do not play or use a blinking-lights feature if you are tired or need sleep.

•

Take a minimum of a 15-minute break hourly.

•

Play in a room in which all lights are on.

•

Play at the farthest distance possible from the screen.

Repetitive Motion Injuries

When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow these instructions to avoid problems such as tendonitis, carpal tunnel syndrome, or other musculoskeletal disorders:

•

Take a minimum 15-minute break every hour of game playing.

•

If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.

•

If you continue to have sore hands, wrists, or arms during or after play, stop playing and see a doctor.

Getting Started

What’s in the Box?

Your digital wireless phone typically comes with a battery and a charger. Other accessory options can customize your phone for maximum performance and portability.

To purchase Motorola Original Motorola Customer Call Center at 1-800-331-6456 in the United

Getting start-

States or 1-800-461-4575 in Canada.

About This Guide

This user’s guide describes how to use your Motorola wireless phone.

accessories, contact the

Optional Features

This label identifies an optional network, SIM card, or subscription-dependent feature that may not be offered by all service providers in all geographical areas. Contact your service provider for more information.

Optional Accessories

This label identifies a feature that requires an optional Motorola Original™ accessory.

Installing the Battery

You must install and charge the battery to use your phone.

Your phone is designed to be used only with Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use.

Action

Remove the battery from its protective clear plastic case, if necessary.

Getting started

Separate cover and releasedown on the cover release button at the top of your phone.

Pull the top of the phoneís back cover to release it.

Release

Button

Action

Insert the battery with printed arrows and 2 tabs at the top of the attery compartment.

Push down until the battery is inserted at

Getting start-

the bottom.

Insert the bottom of the back cover.

Press the top of the back cover down until it hooks over the cover release button.

Charging the Battery

New batteries are partially charged. Before you can use your phone, you need to install and charge the battery. Some batteries perform best after several full charge/ discharge cycles.

Caution:

not display charger. Do not attempt to force the charger further in if you do not see an immediate response.

If the battery is fully discharged, your phone may

Charging for up to 1 minute after inserting the

Action

1Plug the travel charger into the

middle jack on the bottom of your phone.

Plug the other end of the travel charger into the appropriate electrical outlet

When your phone indicates travel charger.

When you charge the battery, the battery level indicator in the upper right corner of the display shows how much of the charging process is complete.

Charge Complete

, remove the

Charging time

The Table below displays an approximate battery charging time.

•

The charging time depends upon the reminded capacities of a battery.

•

Charge the battery in the room temperature.

Battery Charging Times

Li-Ion 700mAh Within 5 hours

Getting started

Battery Use

Caution: To prevent injuries or burns, do not allow metal

objects to contact or short-circuit the battery terminals.

To maximize your battery’s performance:

•

Always use Motorola Original™, batteries and battery chargers. The phone warranty does not cover damage caused from using non-Motorola batteries and/or battery chargers.

•

New batteries or batteries that have been stored for a long

Getting start-

time may require a longer initial charge time.

•

Maintain the battery at or near room temperature when charging.

•

Do not expose batteries to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

•

When you do not intend to use a battery for a while,

•

Store it uncharged in a cool, dark, dry place, such as a refrigerator.

•

Over time, batteries gradually wear down and require longer charging times. This is normal. If you charge your battery regularly and notice a decrease in talk time or an increase in charging time, then it is probably time to purchase a new battery.

•

Activities that require intensive keystroke use (such as playing a game or using messaging) reduce your phone’s talk and standby time. To help maximize battery life, activate Battery Save.

Never dispose of batteries in a fire because they may explode. The rechargeable batteries that power this

product must be disposed of properly and may need to be recycled. Contact your local recycling center for proper disposal methods. Refer to your battery’s label for battery type.

Getting started

Resetting Your Phone

If your phone freezes on a display, error message, or power

up, reset it by removing and reinstalling the battery:

Action

Turn off your phone

Remove and reinstall your battery as described on page 19.

Turn on your phone.

Getting start-

Turning Your Phone On

Press and hold ( ) (End/Power key).

End/Power

Note:

If your cellular phone company uses the SIM card,

please proceed as indicated in the step 2 below to turn on the phone, otherwise skip step2 and go directly to step3.

If necessary, enter your 4-digit unlock code and press

OK ()

Note

: The unlock code is originally set to 1234 by Motorola (for more information, see page 111). Your cellular phone provider may have changed the lock code to the last four digits of your phone number or for specific 4-digit code. In this case please contact your cellular phone operator to geet the correct unlock code.

to unlock your phone.

Adjusting the Volume

You can adjust your phone’s earpiece and ring tone volume by pressing right and left on the ( ) :

When You Can Adjust

You are in a call Earpiece voice volume The display is idle ring tone volume

Tip

: At the lowest ring tone volume setting, press ( ) left

once to switch to vibrate alert. Press ( ) left again to switch to "Ringer off "alert in the "vibrate" mode.

Press ( ) left again to switch to "Silence all" in the "Ringer off" mode. Press ( ) right to cycle back to vibrate alert, then ring alert.

Getting started

Making a Call

Press To

keypad keys Dial the phone number

Getting start-

(Send/Answer key)

Tip: If you make a mistake, press

DELETE ( ) to delete the last

digit, or press and hold ( ) to delete all digits.

Make the call

DELETE

(Power/End key)

End the call and “hang up” the phone

Answeri n g a Call

When you receive a call, your phone rings and/or vibrates and displays an incoming call message.

Action

Press ( ) or

Press ( ) (end key) when the call is done.

Note : If the phone is locked, you must unlock it to answer the call.

ANSWER ()

Dialing Menu

Press To

Attach Number

Entering Number(s)

Hide ID

Insert Pause

Insert Wait

Send Message

Active Call Menu

Press ( ) key during the call to access call menu.

Press To

In Call status

Mute

Hold

New Call

My Phone #

Outgoing Calls

Incoming Calls

Getting started

Mute

Press To

Press ( )

•

Unmute

Press

()

on the conversation screen.

The microphone will be turned on.

Getting start-

My Phone #

Press To

Press ( )

Press

UP/DOWN ( ) key to select

“Mute”, and then press The microphone will be turned off.

press

UP/DOWN ( ) key to

select “My Phone #”, and then press

()

You will see your mobile phone number.

()

Outgoing calls

Press To

Press ( )

Incoming calls

Press To

Press ( )

New Message

Press To

Press ( )

press

UP/DOWN ( ) key to

select “Outgoing calls”, and then press

()

You will see outgoing calls list.

press

UP/DOWN ( ) key to

select “Incoming calls”, and then press

()

You will see incoming calls list.

press

UP/DOWN ( ) key to

select “New Message”, and then press

()

You will send text Message.

Getting started

Voice Privacy

Press To

Press ( )

Tone Length

Getting start-

Press To

Press ( )

press

UP/DOWN ( ) key to

select “Voice Privacy”, and then press

()

.You will see Voice

Privacy list

press

UP/DOWN ( ) key to

select “Tone Length”, and then press ( ).

You will see Tone Length list

Learning to Use Your Phone

Using the Display

The idle display (shown below) is the standard display when you are not on a call or using the menu.

Clock

Menu Indicator

Soft Key Labels

Getting started

The ( ) ( indicates you can press the menu key ( ) to display the main menu to see more features.

Labels at the bottom corners of the display show the current soft-key functions. Press the left soft key ( ) or right soft key right soft key label.

) indicator at the bottom center of the display

()

to perform the function indicated by the left or

The following status indicators can display:

Digital / Analog / 1X

SERVICE STATUS

Signal

Strength

Alert Type

Alert Type Indicator Shows the currently selected alert

profile. The default alert profile is loud ring.

Ringer Volume: Silence All -> Ringer Off -> Vibrate -> Low -> Medium -> High -> High & Vib. -> Escalating

Name Icon

Escalating

High & Vib.

Learning to Use Your Phone

High Medium Low Vibrate Ringer Off Silence All

In Use Roam Text Case(if applies)

Message or

Entry Method

Battery Level

Signal Strength Indicator Indicates the strength of your

phone’s connection with the network

You cannot make or answer calls when the “no signal” indicator displays.

Digital/Analog /UIS-1X-SERVICE STATUS

coverage area, lights up the digital indicator. Lights off when you are in an analog coverage area.

In Use Indicator

( ) If you trouble beyond the range of a cellular system, the

Service indicator

placed or received from your location.

Roam/Home

service outside `of your home system. When you leave your wireless Service Area, your phone roams (seeks another wireless system).

Text Case Indicator

editor.

Message or Entry Method Indicator

active Chat session ( ), or when you have a new voice ( ) or text ( ) message waiting. When you enter a text message,

a number here indicates how many more characters can fit in the message.

Battery Level Indicator

battery. The more bars visible, the greater the charge.

Recharge your battery as soon as possible when you see the

Battery

warning message and hear the low battery alert.

( ) Appears when a call is in progress.

appears to let you know that calls cannot be

Lights up when your phone accesses a wireless

Indicates the text case when you are in a text

Shows the amount of charge left in your

If you are in a digital

Indicates when you have an

Learning to Use Your Phone

Low

Using the 4-Way Navig ation Keys

Use the 4-way navigation keys like a joystick to navigate the menu system, change feature settings, and play games.

Tip

: Down and up are the primary movements within menus. Move left and right to change feature settings, navigate the datebook, and edit text.

Learning to Use Your Phone

Navigation Keys

Using Menus

t .

From the idle display, press ( )to display the main menu.

Left Soft Key

Perform functions identified by left display prompt.

Right Soft Ke

Perform function

identified by righ

display prompt

Menu Ke

Power/End Key

Press & hold to turn phone on & off. Press & release to end phone calls, exit menus.

1 4

Enter menu syste

or open a sub-menu

Send/Answer Ke

Places or answers

call

Navigation Key

Scroll throug

menus & lists, se

feature values

Selecting a Menu Feature

From the idle display, select a menu feature as follows:

Find the Feature

Recent Calls

Outgoing Calls

This example shows that from the idle display, you must press ( ), scroll to and select and select

Outgoing Calls

Recent Calls,

to display the dialed calls list. Use

( ) to scroll, and the left/right soft keys to perform the functions in the bottom left and right corners of the display.

then scroll to

Learning to Use Your Phone

Selecting a Feature Option

Some features require you to select an item from a list:

Press ( ) to display the previous screen.

Outgoing Calls

6)Johone Smith

5)123456.....

BACK

VIEW

Highlighted item

Press to display details for the highlighted item.

Press ( ) to open the sub-menu.

•

Press ( ) to scroll up or down to highlight an item.

•

In a numbered list, press a number key to highlight the item.

•

In an alphabetized list, press a key repeatedly to cycle through the letters on the key and highlight the closest matching list item.

•

When an item has a list of possible values, press ( ) to the left or right to scroll and select a value.

Learning to Use Your Phone

•

When an item has a list of possible numeric values, press a number key to set the value.

VIEW ()

Entering Text

Some features require you to enter information: For example, enter "phonebook" menu and select "Add New Entry"menu.

Press ( scroll down to additional items.

Press

) to

Add New

Name:

No.: 12345....

CANCEL

CANCEL ( ) to

exit without making changes.

DONE ( ) displays

CHANGE

Press or number keys to edit the information.

Highlighted item

CHANGE ()

when you enter or edit

The message center lets you compose and send text messages. A flashing cursor shows where text will appear:

Countdown icon (only

Flashing cursor indicates

Message:

insertion point.

Press

CANCEL ( ) to

exit without making changes.

CANCEL

160

BROWSE

Press sub-menu.

input SMS Text Message)

Press

BROWSE

()

to view and

insert stored text.

( )

to open the

Learning to Use Your Phone

When you enter text using the standard tap method, the flashing cursor changes to a block cursor, and the soft key functions change:

Block cursor indicates currently highlighted character. After 2 seconds, the block cursor reverts to a flashing cursor and moves to the next position.

Message:

DELETE

159

Press OK accept and store the text.

Press

DELETE

( ) to delete the character to the left of the insertion point.

Choosing a Text Entry Method

Your Phone includes six methods of editing text in the text editor. The following describes how to change in these

methods.

Learning to Use Your Phone

Press To

-> Select "

Method

menu -> enter

ENTRY

METHOD

-> enter

METHOD

( ) or ( )

()

Entry

" in the editor

ENTRY

screen

In case of a text entry screen to input text message or input the datebook title.

In case of a text entry screen to input phonebook entry, mytones name and others.

To highlight the desired Text Entry Mehod.

To select the highlighted method.

()

Let the phone predict each word as you enter it,

iTAP English

iTAP Spanish

iTAP Portuguese

Tap Method

Numeric

Symbol

Note

: The text entry method you select remains active until you change it by selecting another method. The Text entry is supported Tap Method (and numeric method) at when input Email and canned message edit and input password.

then choose the word from a list. When Established language is English.

When Established language is Spanish. When Established language is Portuguese. Enter characters one at a time by pressing the

key for the letter, number, or symbol see page

41). This is the standard method for entering text. Enter numbers only. Enter symbols only (see page 45).

Using the Tap Method

The Tap Method of text entry method is the standard method. Each number key on the keypad is used to input a series of characters (See Page 41 Character Chart) which can be accessed through pressing a single key multiple times.

Select Tap Method in a

Tap Method Rules

1.1 The first character of every sentence is automatically capitalized.

1.2 If the cursor is the Block cursor:

Press the previously pressed digit key repeatedly to

circulate that of a series of characters.

ENTRY METHOD screen.

Learning to Use Your Phone

Press a different key:Your phone will accept the

character, advance the cursor and insert the first character associated with the last key pressed.

Press To

( )

If no keys are pressed after two seconds, the character in the Block is accepted and the cursor advances to the next

position as an I-Beam.

Press To

( ) or ( )

1.3 If the cursor is the I-Beam cursor:

Press To

Learning to Use Your Phone

( )

Your phone will accept the character and advance the cursor to the next position as an I-Beam.

Your phone will be changed between upper case and lower case.

The cursor will be moved to the left. (If cursor is placed last position and last

character is space, remove space character.) If cursor is placed last position of edited text,

your phone will insert a space character.If cursor is placed among edited texts,The cursor will be moved to the right.

The cursor will be moved to the same position in the line above the current line.(unless it is on the top line, in which same case nothing happens.)

Character Chart

Use this chart as a guide for entering characters with the tap method.

Space . 1 @ ? ! , & : ; “ ( ) ‘ ¿ ¡ % $ _ ~ \ A B C 2 À Ã Á Â Ç D E F 3 É È Ê G H I 4 Í J K L 5 M N O 6 Ñ Ò Õ Ó Ô P Q R S 7 T U V 8 Ù Ú Ü W X Y Z 9 + - 0 * / = > < # § [ ]

Note

: This chart may not reflect the exact character set

available on your phone. Press and Hold 2 seconds to toggle from

Tap m e tho d to

Numeric method

Learning to Use Your Phone

Using the iTAP™ Method

iTAP™ software provides a predictive text entry method that lets you enter a word using one keypress per letter.

Press ( ) iTAP

Entry Method

from a text entry screen and select

Entering Words

Press To

Learning to Use Your Phone

A number key One time

Number Keys (one per letter)

Left or

Right

SELECT

()

enter the first letter of the word associated with the key are shown at the bottom of the display.

(The edit screen is entered to iTAP word screen. )

enter the rest of the word Alternative words and letter combinations are shown at the bottom of the display. The word choices are updated with each keypress.

highlight the word you want

enter the word at the flashing cursor. A space is automatically inserted after

the word. ( The iTAP word screen is escaped to

the edit screen. )

For Example, to spell “art,” press . The display shows:

Flashing cursor indicates insertion point.

Art Apt Cpu Cru

DELETE

159

SELECT

Countdown icon (only input Text Message)

Press ( ) to scroll and see additional choices.

Press

DELETE ( ) to

Press clear the last letter entered.

SELECT ()

the highlighted letters.

Entering Punctuation

- To add a symbol to the end of the word.

Press To

Press

+ - 0 * / > < # § [ ] ' Space . 1 @ ? ! , & : ; “ () ¿ ¡ % $ _ ~

SMS

to insert

Learning to Use Your Phone

Change of capitalization rule

•

Press ( ) : If the words aren’t capitalized, press ( ) once to capitalize the first letters of those words. Press

( ) again to capitalize all of the letters in each word (for example, car->Car->CAR).

•

Press ( ): If the words are capitalized. press ( ) once to capitalizes the first letters of those words. Press

( ) agian to changes the words to all lower case (for example, CAR->Car->car)

Entering Numbers in iTAP Method

•

Press number key: All letters associated with the key are shown at the bottom of the display.

•

Press ( ) or ( ): Move the highlighted cursor to the numeric letter.

•

Press number key : The corresponding digit will be added to the end of numeric letter.

•

Press

()

: Exit iTAP word screen and the numbers are

entered at the flashing cursor position in edit screen.

Learning to Use Your Phone

Deleting Letters and Words

Press To

1 DELETE

DELETE

Hold

( )

( ) and

The last letter of the entered words/numbers will be removed

iTAP word screen.

All the entered words/numbers will be removed in screen and exit screen, return to the edit screen.

iTAP

word

Using Symbol Method

To enter symbol characters in a message, press ( ) >

Entry Method from any text entry screen and select

Press To

A number key one time

left

right

or the

number key repeatedly

SELECT ()

display its symbol options at the bottom of the display.

Highlight the symbol you want

Enter the symbol

Symbol

Symbol Chart

Use this chart as a guide for entering symbols in symbol method.

Key Result

Space . 1 @ ? ! , & : ; “ ( ) ‘ ¿ ¡ % $ _ ~ \ @ _ \ / : ; “ & ‘ ( ) ( ) { } ¿ ¡ ~ < > = $ £ ¥ # % * + - 0 * / = > < # § [ ]

Learning to Use Your Phone

CANNED MESSAGE

"CANNED MESSAGE" is predetermined sentence that are often used, and used only in text message entry.

In text message entry screen :

Press To

1(BROWSE

( ) / ( )

3 ()

( )

Learning to Use Your Phone

( )

) or ( )

Select " > enter The list of canned message will be displayed. (total:20items > 10 default items and 10 user-editable items)

To highlight the desired canned message.

To insert highlited canned message in text message entry screen.

To return to the text message entry screen.

To enter BROWSE OPTION>

- “Add New” : To input new canned message

- “Edit” : To modify the predetermined canned message.

- “Erase” : To delete predetermined canned message.

Browse

" in editor menu

CANNED MSG

BROWSE OPTION

screen.

QUICK TITLE

"QUICK TITLE" is predetermined title that are often used, and used only in "datebook title" entry.

In the "Datebook title" entry screen:

Press To

Select "

Browse

1(BROWSE

)

( ) / ( )

3 ()

( )

) or (

QUICK TITLE

The list of quick title will be displayed.(11 items)

To highlight the desired quick title.

To insert highlighted quick title in

datebook title entry screen

To return to the datebook title entry screen.

" in editor menu -> enter

screen.

Learning to Use Your Phone

Recent Calls

Outgoing Calls

Press To

>Recent Calls >

Outgoing Calls

Incoming Calls

Press To

>Recent Calls >

Incoming Calls

Recent Calls

Missed Calls

Press To

>Recent Calls >

Missed Calls

You can see the list of outgoing calls. If you press can see more information.

You can see the list of incoming calls. If you press can see more information.

You can see the list of missed calls. If you press can see more information.

DETAIL

, you

Note ()

seleceted call.

: When your phone displays

to see the list of calls, and press ( ) to dial the

Missed Calls

, press

Erase History

Outgoing Calls

Press To

> Recent Calls > Erase History > Outgoing Calls

Incoming Calls

Press To

> Recent Calls > Erase History > Incoming Calls

Missed Calls

Press To

> Recent Calls > Erase History > Missed Calls

You can delete the list of missed calls.

All Calls

Press To

> Recent Calls > Erase History > All Calls

You can delete the list of all calls.

You can delete the list of outgoing calls.

You can delete the list of incoming calls.

Recent Calls

Call Time

Last Call

Press To

> Recent Calls > Call Time > Last Call

Outgoing Calls

Press To

>Recent Calls > Call Time > Outgoing Calls

Incoming Calls

Recent Calls

Press To

> Recent Calls > Call Time > Incoming Calls

Total

Press To

> Recent Calls > Call Time > Total Calls

You can see the last call time. You cannot reset this value.

You can see the all of outgoing calls time after recent reset.

You can see the all of incoming calls time after recent reset.

You can see the all of outgoing and incoming calls time after recent reset.

Life time

Press To

> Recent Calls > Call Time > Lifetime

Reset

Press To

> Recent Calls > Call Time > Reset

You can see the all call times. You cannot reset this value.

You can reset call times of outgoing call, incoming calls and total calls.

You cannot reset this value.

Recent Calls

Media Center

Theme

A theme is a group of settings for your phone’s screensaver, wallpaper, ring tone, and other personal preferences. When you select a theme for your phone, the theme instantly applies all of its

settings to your phone. To download a theme, see page ???. When you receive the theme, you can instantly apply its

settings when your phone prompts you to Apply Now? Your phone saves the downloaded files so that you can

always apply them as individual items.

When you select a theme for your phone, the theme instantly applies all of its settings to your phone:

Press To

> Media Center > Theme

Scroll to the theme you want

Tones / IMGS

Select ( )

Apply the theme Open the theme menu to

Delete

themes

Notes:

•

Phone settings that are set by the theme appear with the value (Set by theme). Changing any 1 of the values set by the theme resets the Theme selection to Custom, though the theme’s settings all remain except for the 1 you changed.

ress To

Notes :

•

You can download, use, and delete themes, but you cannot edit them. Downloaded themes may arrive in MTF files, compressed with files that they reference.

Picture Viewer

Your phone contains pictures and animations that you can insert into text messages, and use as wallpaper and screen saver images. To download pictures or animations, see page ??? (Browser section). Your phone may also include predefined images. You cannot rename or delete about predefined images.

Press To

> Tones/Imgs >Picture Viewer

Scroll to the picture

Select ( )

up or down

Details ( )

View the picture View the previous/next picture

View picture information Open the

perform other procedures as described in the follwing list.

Picture Viewer menu to

Tones / IMGS

Menu Options

The Picture Viewer menu can include the following options:

Details

Set as Wallpaper

Set as Screen Saver

Rename

Delete

Note

: When you set an animation as a wallpaper image, only

the first frame of the animation appears.

Note

: The screen saver image is shrunk to fill the display, if

necessary. An animation repeats for 5 times, then the first

frame of the animation displays.

Tones / IMGS

View picture information. Set the picture as your phone’s

wallpaper image. Set the picture as your phone’s Screen

Saverimage. Rename the picture. Delete the picture.

Ringer Type

Predefined

After you choose a style, your phone will give you a brief sample of your new alert sound.

Press To

> Media Center >

Ringer Type > Predefined

Press

Press ( )

Press

( )

To select the feature.

To scroll the ringer styles As you scroll your phone will

give an audible sample of the currently displayed style.

To select the displayed option -> Ring 21(Default: Acoustica)

To e xi t.

My Bell

You can download up to 14 ringer tones over the network.

Press To

> Media Center >

Ringer Type > My Bell

Press

To select the feature.

To scroll the ringer styles As you scroll your phone will

give an audible sample of the currently displayed style.

Tones / IMGS

Press To

Press ( )

Press

( )

To select the displayed option -> My Bell 14

To e xit .

My Tones

This feature allows the user to manage tones, include creating new tones and deleting tones.

Find the Feature

> Media Center >Ringer Type > My Tone

Tone Menu (Submenu of My tones –

New Tone, Edit, Delete, Play, Help

) can

only be accessed from My Tones

List View by pressing the ( ) key.

My Tones

Tone 1

[ New Tone ]

EXIT

EDIT

Tone Menu is not available when (

Ton e

) is highlighted in the My Tones List

View.

Tones / IMGS

New

Tone Menu

New Tone

Edit Delete Play Help

New Tone

Press To

> Media Center >

Ringer Type > My Bell

Select Notes ( )

Select Name ( )

Notes

•

The maximum length of a tone will be 120 characters and tone names are limited to 32 characters.

•

If the user tried to store a tone without name a transient error message “ Tone Name Required” is displayed.

•

If the user tried to store a tone without notes a transient error message “ Tone Notes Required” is displayed.

•

If all user locations are full a transient error message “Memory Full” is displayed.

To select the “New Tone” and press ( )

Enter

Notes and press ( )

Enter the

name and press ( )

Tones / IMGS

Tone9 Tone10 [New Tone]

EXIT

SELECT

Memory Full

Edit

User can access tone detail form by either:

Edit key from

Select Select

Edit from

Press To

> Media Center > Ringer

Type > My Bell

Select

Edit ( )

Press

( )

Delete

The user can delete a selected

deleted a confirmation dialog is displayed to the user.

Press To

> Media Center > Ringer

Type > My Bell

Tones / IMGS

Select

Delete ( )

My Tones List View.

Tone Menu

Select ( ) key from

Tones

You can edit

and press

You can save it.

Select ( ) key from

Tones

Press ( ) you can delete it

list view.

My Tones

list view.

Notes and

( )

. Before an entry is

name

Play

To p la y

My Tones

to the desired entry and select Play from the the user is taken to an animated playback meter.

, the user can do one of the following: Scroll

My Tones menu,

Help

The user can Help menu a selected My Tone.

---- Help ----To enter a note, use the up/down scroll. A note can also be

entered using the key associated with the note letter. Change octaves using the 0 key to insert a ‘ * ’ followed by the octave number. Insert a flat ‘&’ or a sharp ‘#’ using 0 key before the note. Change duration by inserting 0-5 after the note. Modify duration by 1+1/2=’.’ or by 1+3/4=’:’ or by 2/ 3=’;’ using 1 key after note. Insert a rest ‘r’ using 7 key. Scroll left/right using the * and # key.

BROWSER

The WAP browser lets you to access Web pages and web-basic applications on your phone.

Contact your service provider to setup access if necessary.

Launch Browser

You can launch browser.

Press ( )

Press To

Select ( )

EXIT ( )

END ( )

Find the Browser > Launch Browser

Launch Browser and go to url which set as default in web session menu.

Return to the previous menu Exit Browser

Interacting with web pages

Press To

( ) up or

BROWSER

Select menu soft key Open the browser menu Press key Press and hold Press

(input mode state in wap browser)

key

down

key

Scroll through a pages

Open the browser menu Go to homepage

Change input mode

Launch Browser with Web Session profile

You can see profile list and launch browser with a selected profile.

Find the Feature Press ( ) > Browser > Web Session

Press To

( ) up or

Launch

( )

Select ( )

( )

BACK ( )

down

Scroll profiles and ( Launch browser with

selected profile. Enter new profile (view when

a focus is in View information of current

profile Return to the previous menu

New Entry

NEW ENTRY

)

View information of current profile

You can see information of current profile. The profile can be set as a default profile and deleted also.

Find the Feature ( ) > Browser > Web Session > ( )

Press To

( ) up or

down

Scroll in items

)

BROWSER

Press To

Select

( )

BACK

Set current profile as default (Set default)

(name, homepage, wap ip1, wap port1, wap ip2, wap port2, csd no, user name, password) Delete current profile ( ) (Delete)

View detail information of current item

Return to the previous menu

View detail information of current

item

You can see detail information of current item.

Find the Feature ( ) > Browser > Web Session > ( ) > select

Press To

EDIT ( )

( )

BROWSER

BACK

Edit current item Return to the previous menu

Create and save a browser new profile

You can create a new profile and edit a new information.

Find the Feature ( ) > Browser > Web Session >

[New Entry]

Press To

SELECT ( )

BACK ( )

SAVE ( )

Edit current item Return to the previous menu

Save current profile (view this softkey when all items have a value)

Setting profile discription

setting Description

Name Homepabe WAP IP 1 WAP port 1 WAP IP 2 WAP port 2

CSD No.

User name password

Web session name Default home page Primary WAP gateway IP address Primary WAP port number Secondary WAP gateway IP address Secondary WAP port number Phone number to use to set up a CSD

connection User name

Service Load

•

You can set service load option menu.

Find the Feature ( ) > Browser > Service Load

•

Allow - Automatically accepts SL attempts with no user

confirmations.

•

Deny - Rejects all SL attempts with no user confirmations.

•

Ask - Prompts user each time a SL attempt is made.

BROWSER

Downloading Pictures, Games, and Sounds through wap browser

You can download a picture, animation, sound, game upgrade, or theme from a Wap browser by selecting its link. A picture or animation appears when downloading completes. A sound plays when downloading completes.

You can store these object files on your phone, and use them as screen saver images, wallpaper images, and ring tones.

Press To

Press ( ) key,

Browser > Launch Browser

then go to any web site

BROWSER

Find the

During a Wap browsing, go to the Web site and find the

file you want. Follow the directions on the

site to purchase the file (payment details vary). The site sends a text message to your phone, containing the attached file or a URL link to the file

Open the message and store the file

Notes

•

Call charges apply during download sessions.

•

When your phone runs out of memory for downloaded files, you can not download new files. Downloaded files share your phone’s memory, so you can make room for a picture, for example, by deleting ring tones.

Phone Book

Creating a Phonebook Entry

You can store a list of names and phone numbers in your phone’s electronic phonebook. Each memory location from 01 through 100 can store three numbers, one email address, a ringer ID and one name associated with them. For a single contact, you can store multiple numbers – for home, office, mobile.

Entry’s Name Entry’s phone number

Type

Home Office Mobile

To create an entry:

Action

Enter the phone number you want to store, then press ( ). You can store up to 32 digits per phone number entry.

Or, Press ( ) scroll to Phonebook and press ( ) . Scroll to Add

New Entry in the menu list and press ( ).

Scroll up to the name item and press ( ) or number keys to enter a name. In the same way, enter a number item.

Entering text methods (iTAP) are explained in page ??.

Name :

No.: 123456....

Type:Home

DONE

CHANGE

Speed number

Ringer ID

Entries with a speed dial number from 1 to 300 are stored on your phone.

Phone Features

Action

Now scroll down to the type item and choose the number type (home, mobile, office). Press ( )

change the type or press ( ) and select one from the list.

None

Default speed no. is select the displayed number or you can press ( ) to erase the displayed number and enter a new number and press ( ) .

Scroll down to Ringer ID item. Default Ringer ID is Press ( ) left or right to change the Ringer ID or Press ( ) and select a Ringer ID from the list.

Scroll down to Email item. Press ( ) or number keys to enter an email address.Entering text methods(iTAP) are explained in page ??.

Scroll down to If you want to save another number for this entry press

( ) and you see new input fields for one more number. If name and number are not entered, ‘

number required

BROWSER

Edit the fields as above. You can add total three numbers for one entry. If you try to add more than three numbers, a warning message ‘

If you do not want to save another number and you are done, press ( ).

---More---

’ warning message is displayed.

, you can press ( ) and

Can’t add field any more

left or

’ is displayed.

right to

None

Name and

You see

Duplicated Name or

Duplicated Number if the

number or name is the same as one already stored. WhenPrompted

) to store or select

Store anyway? Select

Yes by pressing (

No by pressing ( ) to go back

and re-edit the entry.

BROWSER

Finding a Phonebook Entry

You can locate a phonebook entry by the name stored with that entry or by the entry’s location number (01 through

100), or by the entry’s speed dial number (01 through 300).

Find Name :

Finding by Name

EXIT

Action

Press ( ), scroll to Select

Find Name from the menu list.

Phonebook and press ( ) .

Enter the letters of the name you are finding, and press ( ). You can also press ( ) without entering any letters.

Your phone displays the list of all the entries matching the letters you entered. (sorted alphabetically). If you haven’t entered any letters in the previous screen your phone shows all the entries in the phonebook sorted in alphabetical order. If no name is found matching the

BREW

letters you entered, you see

No Matched Name Found and

you can enter the letters again. Scroll to the name of the entry you want. Or Press the key

with the first letter of the name you want. (If no entry beginning with that letter is found, you see “xxNot Found” xx being the letter you entered.)

Press ( ) to view the details of the entry. Press ( ) you can edit it.

FIND

New

: Insert the new phone number.

Edit

: Edit the selected number.

Delete

: Delete the selected number.

Send Message

: Send a message to the

selected number

Set Primary No

: Changes the primary

no.

Add Digits : Add digits to the number.

Attach Number

: Attach to other stored number.

Phone Book Menu

New

Edit Delete Send Message Set Primary No. Add Digits Attach Number Sort

Sort : Sort the phonebook list by name or by location.

Press ( ) to dial the entry. Or Press ( ) left right to select another number (for

example office or mobile) in the same entry.

Finding by Location

Action

Press ( ), scroll to Select

Find Location from the menu list.

Phonebook and press ( ) .

Enter the number of the position you are finding, and press ( ). You can also press ( ) without entering any location numbers.

Your phone displays the entry stored at that location with a list of all the entries in your phonebook. If you haven’t entered any number location 01 is displayed. If there is no number stored at the location you entered, you see (

xx Not Found, xx being the location you

entered), and you can enter the location number again.

Phone Features

Press the number key one time and the entry at that 1digit location is displayed. Press the second number key within 1.5 seconds and the entry at that 2-digits number’s location is displayed. If there is no entry at that location you see (

Press ( ) to view the details of the entry. Press ( ) to dial the entry. Or Press ( ) left right to select another number (for

example office or mobile) in the same entry.

Finding By Speed Dial

Action

Press ( ), scroll to Select

All the numbers with valid displayed, sorted in speed number order.

Press a number key and the number with that number is highlighted. Press the second number key within 1.5 seconds and the number with that 2-digit speed dial number is highlighted. Same with the 3-digit speed

Phone Features

number.

xx Not Found, xx

Speed Dial

from the menu list.

being the location you entered.)

Phonebook and press ( ).

speed dial numbers are

speed dial

Phonebook Option

You can access when you are in phonebook list or detailed view.

New

Refer to “Creating a phonebook entry”.

Edit

Editing the selected entry. The procedure is the same as “Creating a phonebook entry”.

Delete

Deleting the selected entry. If you delete from the list, whole entry is deleted.

If you delete from the detailed view, only the number showing on screen is deleted.

Send Message

Sends message to the selected number or email. Refer to SMS manual.

Set Primary No.

Changes the

Number

is the number that is displayed initially on the list.

Action

Shows a list of all numbers stored in the selected entry. Scroll to the number you want to set ( ).

Now the show first when the list is displayed.

phonebook option menu by pressing ( )

primary number for the selected entry.

primary

primary number is changed. This number will

Primary

, and press

Phone Features

Add Digits

Shows the number you selected on the screen, you can

digits

to the number and store it or call it as you wish.

Attach Number

Attach another number to the selected number

Action

Attach Number shows a list (Phonebook/Outgoing calls/ Incoming calls) you can choose the number to attach from. Scroll to the list you want, press ( ).

You see all the numbers from the list you just selected. Scroll to the number you want to attach and press ( )

again. Now 2 numbers (the number you originally selected

before pressing ( ) and the number you just selected from the list) are attached and displayed on the screen.

Sort

Sort the phonebook list by name or by location.

Action

Scroll and press ( ) . Once you change the order, the

Phone Features

list will be sorted in this order whenever you access the phonebook.

add

Speed dial

You can assign or remove number.

Action

Press ( ), scroll to Phonebook and press ( ). Select

Speed Dial from the menu list

All the numbers with valid displayed, sorted in speed number order. And empty

Speed Number slots are displayed with space in the list.

When empty slots are highlighted, ( ) will be key and when slots with entries are highlighted ( ) will be

REMOVE key.

Dialing a Phonebook Entry

To call a number stored in your phonebook:

Action

Retrieve the desired number. (See “

Finding a Phonebook Entry

Press ( ) to call the number.

Speed dialing

To call a phonebook entry by pressing its speed dial no.

Action

Entering a 1,2, or 3 digit speed dial position number, then ( ) followed by ( ).

Speed Dial No

speed dial numbers are

” on page ??.)

. for each phone

BROWSE

Phone Features

Pressing the ( ) key before pressing ( ) will show the view detail of the phonebook entry.

Action

Example: Press ( ) ( ) ( ) ( ) to dial phonebook entry with speed number, 22.

Turbo dialing

To call phonebook entries with by one touch.

Action

To call phonebook entries with speed dial position number 1 through 9, press and hold numeric keys 1 to 9 for 1.0

seconds and number is dialed without pressing ( ) key or ( )+( )key.

Example : Press ( ) for 1.0 seconds to dial phonebook entry with speed number, 2..

In addition, you can also call phonebook entries with speed dial position number,10 through 99, by pressing the 1st digit and pressing hold the 2nd digit.

Example : Press ( ) and hold ( ) for 1.0

Phone Features

seconds to dial phonebook entry with speed number, 21.

Editing a Phonebook Entry

Action

Retrieve the desired number. (See “

Entry

” on page ??.)

Press ( ) and when the details are displayed, press ( ) again to begin editing.

Or, Press ( ) and scroll to and press ( ) .

Modify the number, modify the name, type, speed no., email address, ringer id as desired. Editing each field is similar to adding new entry.

Press ( ) to save and exit.

Finding a Phonebook

Edit in the option menu list

Viewing My Number

You can see your phone number.

Action

Press ( ), scroll to to

My Phone # in the menu list and press ( ).

Press ( ) to exit. Or wait for time-out and exit automatically.

Phonebook and press ( ). Scroll

Checking Phonebook Capacity

You can see how much memory space remains for storing phonebook entries on your Phone.

Action

Press ( ), scroll to Phonebook and press( ). Scroll to

Phonebook Status in the menu list and press( ).

Press ( ) to exit. Or wait for time-out and exit automatically.

Phone Features

Erasing All Entries

To erase all entries in your phonebook:

Action

Press ( ), scroll to Phonebook and press ( ). Scroll to press ( ).

You see a prompt for the lock code. Enter the 4-digit lock code you set up (Changing your lock code in page 110). Press ( )

If the lock code is correct, you select ( ) or

If the lock code is not correct, you see and you can enter again.

Phone Features

Erase Phonebook in the menu list and

Ye s by pressing

No by pressing ( ) .

Invalid Lock code

MESSAGING

SMS

You can send text messages and receive alphanumeric messages with your wireless phone.

Sending a Text Message

Find the Feature > Messaging >SMS > New message

Action

Enter the destination phone number and press ( ). You can enter up to 10 destination numbers. After each phone

number enter, press number If you Press( instead of phone number.

Enter the message contents, and press( ). Enter a call back number and press ( ).

(Your number is automatically entered as the call back number.) Scroll to the desired priority level and press ( ). Select ( ) (

then proceed to step 6 to send the message immediately.

Select ( ) (No), then proceed to step 7 to select save or not.

Select ( ) ( time or deliver time.

() (up or down

) and select E-mail, you can use E-mail address

Ye s

) about question, Send Message Now?,

), then proceed to step 8 to set validity

), then enter another

Messaging

Action

The message is sending

- If the message is sent successfully, “ and the phone returns to the previous menu. The sent message is automatically stored in

- If the message is not sent successfully, “ Press ( ) or ( ) to select successful, the message is automatically stored in the

Scroll to the save option and press ( ). If you save the message, the message is stored in the Draft folder.

Scroll to time setting and press ( ). Then you can set validity time or deliver and press ( ). You return to step 5.

Sent Folder

Message sent

Retry

Yes or No. If the resend is not

” is displayed

?” is displayed.

Outbox

Receiving a New Message

When you receive a message, your phone:

Messaging

If you press ( ) ( you return previous state.

Incoming messages are stored in the store up to 20 messages.

- Beep or vibrates

- Displays the ( ) indicator

- Displays

- Displays a call back number, if induded

if the received call back number matches the number of a phonebook entry, the name for that entry is displayed instead of the call back number.

Back

Message!

) in the message dialog state,

Inbox

. The Inbox can

Viewing Messages

Find the Feature > Messaging >SMS > Inbox (or Outbox or Sent Folder or Draft Folder)

Action

Press ( ) (up message headers.

To select a message and view its contents, press ( ).

Press ( ) ( text. Press ( ) (

message.

Your phone displays the message text, and you can see ( ). If you press ( ), you will see option list that depend on Box or Folder. In the message text display, you can:

Press To

> Call

> Reply

> Edit

> Forward

> Resend

> Store number

> Goto

down

) to scroll through the list of

up or

down

) to scroll through the message

left or

right

) to scroll through the list of

Call [I, O, S, D] Send message using callback

number [I] Edit message which is saved [D] Send message with same text to

someone [O,D] Send failed message again [O,S] Store callback number to phone

book [I] Access URL if the message text

include URL [I]

Messaging

Press To

> Lock, Unlock

> Erase

> Erase Box

([I]

Inbox

, [O]

Outbox

, [S]

Lock Message or Unlock Message [I,D]

Erase the message [I, O, S, D] Erase the box or folder [I, O, S, D]

Sent Folder

, [D]

Draft Folder

Setting Up SMS

Find the Feature > Messaging >SMS > Setting

User can select overwrite option when inbox memory buffer is full, phone can overwrite or cannot receive.

Messaging alerting is selectable to once/repeat alert (every 2 minutes)/release.

If user selects outbox, sent folder, and draft folder are deleted.

If you want to receive delivery acknowledge when you send SMS message, select “

If you want to receive user acknowledge when you send

SMS message, select “

Messaging

WAP Alerts

You can receive a WAP message and see it.

Erase All Folder

Yes

”.

Yes

”. (Flex Option)

, All messages in the inbox,

Viewing WAP messages

Find the Feature > Messaging > WAP Alerts

Action

)

Press ( ) (up message headers.

Press

down

) to scroll through the list of

Erase

to erase the WAP message.

Action

press Check(V) to connect a site.

VOICEMAIL

You can listen to your voice mail messages by calling your network voicemail phone number. Voicemail messages are stored on the network-not on your phone.

Receiving a New Voicemail Message

When you receive a voicemail message, your phone displays ( ) (voice message waiting) and

If you press ( ) in the voice mail dialog state, you can listen to voice message.

New Voicemail message

Listening to a Voicemail Message

Find the Feature >Message > Voice Mail > Call Voicemail

You can view voice mail. If you press ( ) , your phone dials the voice mail sever number. If you press

call back number of the voice mail.

()

your phone dials the

Clearing Voicemail Icon

Find the Feature >Message > Voice Mail > Clear Icon

You phone clear ( ) (voice message waiting).

Messaging

Storing Your Server Number

Find the Feature >Message > Voice Mail > Server Num

You can change or view server number.

Press To

Edit

( )

Start editing

Press To

Keypad keys

( )

Enter your server number Store the number

Quick dial Calling Quick Dial

Find the Feature > Quick Dial

You can press ( ) > Quick Dial to dial preset numbers on your phone. If there is no number, you can set your quick dial numbers

Change Quick Dial

You can press dial numbers.

( ) > Quick Dial > ( )

to change quick

Delete Quick Dial

You can press ( ) > Quick Dial > ( ) dial numbers.

Messaging

to delete quick

Office Tools

Datebook

General Description

The Datebook application is a calendar that allows the user to schedule and organize events such as appointments and meetings. The Datebook also is able to show when events exist in a view that shows an entire week. Due to limited space on the display, the view showing events during a week is targeted at showing how full each day’s schedule is during that week and making it easier to navigate from dayto-day in the calendar.

Find the Feature > Office Tools > Datebook.

Press To

Scroll to the day.( ) ( ) view the day in Week View or the event in

Day View

VIEW ( )

up or down

view the event detail(an event including the day of week, time, title, duration, alarm time, and repeat cycle)

View the previous/next event detail Open the datebook menu to perform

other procedures as described in the following list.

Office Tools

* Respond to event reminder : When an event reminder

displays you can press or

EXIT ( ) to dismiss the reminder

VIEW ( ) to view the event,

The Datebook menu can include the following options:.

Option Description

Brings up the Week View including

Go to Today

New

Edit

Delete

Option Description

Setup Option Description

Office Tools

today’s date if in Week View. If in Day View or the Event Information View, brings up the Day View for today

Brings up a selection list Brings up the Event Form with data associated with the selected event Deletes selected event

Determines the beginning

Daily Begin

Delete After

time for the 12-hour time window shown in the Week View

The user can determine how long Datebook data is kept in the phone’s memory. The default will be for events to be deleted that were listed on a date more than 4 weeks prior to today

Alarm Clock

General Description

You can set your phone to alert you at a specific time such as an alarm clock. You can set your phone’s alarm time.

Find the Feature > Office Tools > Alarm Clock.

Press To

scroll to the alarm list

ENABLE ( ) DISABLE (

Snooze ( ) (It is available function when alarm ringing message show up.

alarm ringing time : 3 minutes Respond to alarm : To stop ringing alarm, Press any key. The

Alarm Clock

options:

Option Description

New

Edit

Delete

Delete All

enable or disable alarm

)

Specified the 90 minute rule for “Alarm-Snooze” cycle applies when there’s no user Interaction.

open the alarm clock menu to perform other procedures as described in the following list

menu can include the following

Brings up Alarm Clock form Brings up the Alarm Form with data from

selected alarm Deletes entry Deletes all alarms in the Alarm Clock list

Office Tools

Calculator

General Description

Find the Feature > Office Tools > Calculator

The Calculator application allows the user to calculate simple mathematical equations. The user is able to add, subtract, multiply, divide, currency convert.

The following “buttons” will be available to the user:

Press To

# Inserts a decimal point CClear All Digit E Clear one Digit = Calculates the answer + Adds

- Subtracts XMultiplies / Divides $ Currency Convert.

Currency Convert Menu Left/Right Scroll.

Office Tools

Access Calculator

Find the Feature

> Office Tool > down key > Calculator

Calculator

S C E = + - x /

EXIT

Upon entering the Calculator, the “+” symbol will be

SELECT

highlighted.

The line under the title “

Calculator

” will be the area to display

numbers entered and the calculation.

The Calculator display always starts with a default value of zero.

A right arrow next to the calculation symbols indicates that additional items can be accessed by scrolling right.

A left arrow next to the calculation symbols indicates that additional items can be accessed by scrolling left.

SELECT is used to choose the current calculation symbol that is highlighted

The value entered may not exceed 8 digits and 2 decimal point.

- Any digit entered after the eigth digit shall be ignored. Any decimal points entered when one decimal point is already being displayed shall be ignored.

The largest valid number that can be expressed shall be “99999999”. Any number larger than “99999999” shall be ignored.

The smallest valid number that can be expressed shall be “99999999”. Any number smaller than “-99999999” shall be ignored.

Office Tools

Each digit entered using the keypad will be inserted at the left end of the line, causing preceding digits to shift one position to the right, unless only “0” is displayed.

If “0” is displayed, then the first digit entered will replace “0”. “0” is only shifted to the right by one if “.” is selected.

“.” must always be preceded by a digit.

1. The result of digits entered and a command selected will be displayed in the

Display Window (left justified).

2. The result of one calculation can be used with another command for a different calculation.

3. If another operation is pressed before any digits are entered, the most recent operation shall be ignored.

4. Example: The following was entered: 5, +, -, -, *. The error tone occurred.

LEFT/RIGHT MOVE allows the user to move around the

calculator to highlight a desired calculation symbol.

6. SELECT chooses the highlighted calculation symbol.

Using the calculator (Addition, Subtraction, Multiplication, Division)

Entering value

shows an example of the user trying to find the sum of “1234+56789”.

Office Tools

Number appears left justified in the Display Window. Highlight defaults to the

“

Plus

” sign.

Calculator

1234

S C E = + - x /

EXIT

SELECT

After input digit press left arrow, User moves highlight to “

equals

” sign to

calculate digits.

Calculator

1234+5678

S C E = + - x /

EXIT

SELECT

User continues with a new

calculation

58023

The example of maxium input cipher (The priority of the calculation is calculated in accordance with the sequence of data input. It’s because

123+456+79-234+23+1 234x567.8/25

it doesn’t offer parenthesis). Other operations will be done in the same way

Calculator

S C E = + - x /

EXIT

S C E = + - x /

EXIT

SELECT

Office Tools

Currency Conversion

Exchange Rate:

1.5000

DELETE

Calculator -> Menu key -> Exchange Rate Select.

The Calculator Menu is accessible by pressing MENU from the calculator.

The exchange rate editor is identical to the currency number editor

- the value entered shall have up to five digits before the decimal.

- the value entered shall have up to four digits after the decimal.

- the value shall be followed by nothing.

Converting the displayed number

4 is currently displayed. Scroll to $. Assume the exchange rate has been set to 1.5

Calculator

S C E = + - x /

Office Tools

EXIT

When the current converter symbol is selected, the displayed number shall be multiplied by the exchange rate.

SELECT

World Time

General Description

User can view a world-time of the city to want.

Find the Feature > Office Tools > World Time

Press To

Up(left) or Down (right)

EXIT ( )

The city which the summertime is applied is marked by the daylight icon ( ).

Scroll to the world-time list

End the world-time session and return to the office tools menu

Stopwatch

General Description

The stopwatch application allows the user to count time.

Find the Feature > Office Tools > Stopwatch

Press To

START (

STOP ( )

RST ( )

SPL ( )

REL ( )

EXIT ( )

Start the stopwatch

)

Stop the stopwatch Reset the stopwatch timer into 00:00:00 Split the stopwatch timer Release the stopwatch timer End the stopwatch session and return

to the office tools menu.

Office Tools

Setting Up Your Phone

SOUNDS

VOLUME

RINGER VOLUME

You can adjust the volume of your phone’s ringer.

Find the Feature > Settings > Sounds > Volume > Ringer

Vo lu me

Press To

Select the feature

Select ( )

Silence All

Medium High High&Vib Escalating

•

Silence All: When you receive a call, your phone ringing

•

Ringer Off: When you receive a call, your phone silence.

•

Ring 1~5 : When you receive a call, your phone adjust ringe

volume level.

•

High & Vib

•

Escalating

VOICE VOLUME

Setting Up Your

Save it

Ringer Off Vibrate Low

silence.

: When you receive a call, your phone is 3

vibreate after High volume level

: When you receive a call, your phone ringer

changes from 1 to 5.

level

RINGER VOLUME

You can adjust your voice volume.

Find the Feature > Settings > Sounds > Volume > Voice

Volume

Press To

Adjust your voice volume.

Select ( )

Save it

KEY BEEP VOLUME

You can adjust your key beep volume.

Find the Feature > Settings > Sounds > Volume > Key beep

Volume

Press To

Adjust your key beep volume.

Select ( )

Save it

Setting Up Your Phone

RINGER TYPE

PREDEFINED

After you choose a style, your phone will give you a brief sample of your new alert sound.

Find the Feature > Settings > Sounds > Ringer Type >

Predefined

Press To

To scroll the ringer styles.

Select ( )

MY BELL

You can download up to 14 ringer tones over the network.

Find the Feature > Settings > Sounds > Ringer Type >

Press To

Select ( )

Setting Up Your

As you scroll, your phone will give an audible sample of the currently displayed style.

Save it To Select the displayed option ->

Ring13(Default : Acoustica)

MyBell

To scroll the ringer styles. As you scroll, your phone will give an

audible sample of the currently displayed style

Save it To Select the displayed option -> My Bell 14

MY TONES

User to manage tones.

Find the Feature > Settings > Sounds > Ringer Type >

My Tones

Press To

To scroll the ringer styles. As you scroll, your phone will give an

audible sample of the currently displayed style

Save it

Select ( )

ALERTS

SERVICE

When Service Tones are On, you will be instantly alerted to any change in your wireless service.

Find the Feature > Settings > Sounds > Alerts > Service

Press To

Up or down

Select ( )

To Select the displayed option -> My Tones 10

Select “

ON” or “

Save it

OFF”

Setting Up Your Phone

MINUTE BEEP

If the Minute Beep is set to on, an audible alerts when a minute was passed in call.

Find the Feature > Settings > Sounds > Alerts > Minute Beep

Press To

Up or down

Select ( )

VOICEMAIL

When you receive a new voice mail , your phone alert is repeat until user check this.

Find the Feature > Settings > Sounds > Alerts > Voice Mail

Press To

Up or down

Select ( )

MESSAGE

When you receive a new message, your phone alert is

repeat until user check this.

Find the Feature > Settings > Sounds > Alerts > Message

Press To

Up or down

Select ( )

Select “ON” Save it

Select 1beep~3beep Save it

or “

OFF”

Setting Up Your

CALL LOST

If the Call Lost is set to on, an audible alerts when the current call is dropped because of signal fade.

Find the Feature > Settings > Sounds > Alerts > Call Lost

Press To

Up or down

Select ( )

ON” or “

Save it

OFF”

Select “

DATEBOOK

Find the Feature > Settings > Sounds > Alerts > Datebook

Press To

Up or down

Select ( )

To scroll the feature “Ring1~9” and “Vibration”

Save it

Setting Up Your Phone

TONE LENGTH

Your phone transmits tones to communicate with automated systems like Voice Mail or bank by phone. These tones are called DTMF(Dual Tone Multi-Frequency) tones. This feature allows you to control the duration of the tone when a key is pressed. For most systems, you should use the default setting of short tones, which sends the tones for a preset length of time. If you choose long tones, your phone will transmit the tones for as long as you press and hold the key.

Find the Feature > Settings > Sounds > Tone Length

Press To

Up or down

Select ( )

Select one of the options Long, Short, None

Save it

Display

Adjusting the Backlight

You can set the amount of time that the display backlight remains on, or turn off the backlight to conserve battery power:

Find the Feature > Settings >Display > Baklight Control

Office Tools

Press To

Up or down

Select ( )

Back (

Select one of the options (Continuous, Always off, 8Seconds, 15Seconds)

Confirm your selection Return to the previous menu

)

Motorola T5EH1 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
