Motorola T56NX2 User Manual

MOTOSMARTTM Me

2012.07.19 FCC

Congratulations

2012.07.19 FCC

MOTOsmart™ ME

Yo u r M OTO SMART Me phone gives you music and the Internet in your pocket.

•Music: Easy access to all your favorite music, see

“Music” on page 36.

• High speed Internet: Browse the web and

pinch-to-zoom on the high resolution touch display in “Web” on page 29.

Note: Certain apps and features may not be available in all countries.

Caution: Before assembling, charging, or using your phone for the first time, please read the important safety, regulatory and legal information provided with your product.

This product meets the applicable SAR limits of

1.6 W/kg (FCC & IC) and 2.0 W/kg (ICNIRP). The

limits and guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The highest SAR values measured for this device are listed in the regulatory information packaged with your product.

Note: When using the product while worn on your body, either use an approved accessory such as a holster or

1Congratulations

maintain a distance of 2.5 cm (1 inch) from the body to

2012.07.19 FCC

ensure compliance with SAR requirements. Note that the product may be transmitting even if you are not making a phone call.

Want more?

More help, more accessories, more free stuff. We’re here to help.

• Updates: Smartphone updates, PC software,

user’s guides, online help, and more at www.motorola.com/support.

• Accessories: Find more for your phone at

www.motorola.com/products.

•Social: The latest news, tips & tricks, videos, and so

much more—join us on:

YouTube™ www.youtube.com/motorola

Facebook™ www.facebook.com/motorola

Twitter www.twitter.com/motomobile.

2 Congratulations

Your phone

Press = sleep. Hold = turn off.

3.5mm

Headset

Jack

Back Key

Menu Key

Home Key

To u chscreen

Power/ Lock Key

Volume Keys

Search Key

Micro USB

Connector

Microphone

Notification

Light

2012.07.19 FCC

the important keys & connectors

3Your phone

Contents

2012.07.19 FCC

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Touchscreen & keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Apps & updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Text entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Web. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Photos & videos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4 Your phone

Let’s go

2MP

micro SIM

microSD (optional)

micro SIM

+ Adapter

SIM

2012.07.19 FCC

let’s get you up and running

Assemble & charge

Caution: Please read “Battery Use & Safety” on page 46.

5Let’s go

Set up & go

2012.07.19 FCC

Note: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. Contact your service provider for details.

When you turn on your new phone, you can create or enter a Google™ account so that you can download apps, use Gmail™, and much more:

1 Press and hold Power/Lock to turn on your phone.

2 Touch the Android™ image to begin setup.

3 Touch a button to Create a Google account, Sign in

with one you have, or Skip.

You can log into your account from a computer at accounts.google.com.

4 When your phone confirms the account, it shows

account sync options.

• To change whether your phone shows the Google

account’s contacts, Gmail™, and calendar, touch the Google account name.

• To add another account, touch Add account. For

details, see “Email” on page 25.

• To exit setup, press Home .

If your phone cannot connect, press Menu >

Settings > Wireless & networks > Wi-Fi settings to

change mobile network settings.

6 Let’s go

Touchscreen & keys

2012.07.19 FCC

a few essentials

sleep & wake up

Your screen sleeps when you hold it to your ear during a call, or when it is inactive. To change the sleep delay, touch Menu > Settings > Display > Screen timeout.

To turn phone sounds on or off from a locked screen, add the Sound shortcut to your lock screen. Touch and hold between the rings until apps appear, then drag an app to the unlock ring. Then, to open the shortcut on the lock screen, drag it to the center.

To unlock the screen, press Power/Lock Key then touch and drag it to the outer circle.

7Touchscreen & keys

Touch tips

Slide two fingers apart or together to zoom in or out.

Drag or flick to scroll.

Touch & hold to show options.

2012.07.19 FCC

It’s all in the touch:

•Touch: Choose an icon or option.

• Touch & Hold: Show options.

•Drag: Scroll or move slowly.

•Flick: Scroll or move quickly.

• Zoom: Slide fingers apart or together to zoom in or

out on Google Maps™, web pages, and photos.

Displaying 297 contacts

In case of emergency

Abe Baudo

Allie Smyth

Abe Baudo

View contact

Anna Medina

Call contact

Astrid Fanning

Text contact

lark St

born St

Wacker D r

State/Lake

W Lake St W Lake St

Lake

E Randolph St

8 Touchscreen & keys

E Wacker Pl

Randolph/

Wabash

N Micigan

Key tips

Key

Home

Key

Back

Key

2012.07.19 FCC

Menu, home, back, & search

Touch H ome to close any menu or app and return to the home screen. In the home screen, touch and hold Home to show the most recent apps used, then touch an app to open it.

Touch Menu to open menu options.

Touch Back to go back.

Touch Search for text search, or touch and hold for voice search.

Power key MENU

Press and hold to turn off your phone (Power off),

Reboot your phone, or turn Airplane mode or Silent mode

on or off.

9Touchscreen & keys

Home screen

GmailBrowser Play Store

Machu Picchu, Peru

August 16, 2012 61,749 views 864 likes, 43 dislikes

11h35

Navigation

Notifications

Flick down for details.

Status Indicators

Shortcuts

Browse your apps.

Widgets

Touch to open. Touch & hold to move or delete.

Drag or flick to open panels (or scroll in lists).

2012.07.19 FCC

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in one place. It’s what you see when you turn on the phone or touch Home from a menu. It’s basically like this:

Note: Your home screen might look a little different.

The home screen extends left and right to give you more room for adding shortcuts, widgets, and more. Flick the

10 Home screen

Nav

home screen left and right to see more panels or to add

Kristine Kelley

Not even ready to go back to school

3pm

Budget Meeting

THU

JUL

2012.07.19 FCC

widgets or shortcuts. Or, touch Home and touch a thumbnail to go to the panel.

Use & change your home screen

On your home screen, shortcuts are icons that open your favorite apps, web bookmarks, contacts, mail labels, or music playlists. Widgets show you news, weather, messages, and other updates.

• To open something, touch it. Touch Home to

return to the home screen.

Tip: When you open a widget, touch Menu to see any options or settings.

• To resize widgets, touch

and hold a corner until you feel a vibration, then drag.

• To add something or

change your wallpaper, touch and hold an empty spot until you see the Add

to Home Screen

menu.

Tip: You can add a folder to organize your shortcuts.

• To move or delete something, touch and hold it until

you feel a vibration, then drag it to another spot, another panel, or quickly move it to the trash at the top of the screen.

Budget Meetin

11Home screen

Shortcuts in the dock at the bottom of the home screen

10/02/2012

5:46PM

Settings Clock FM Radio Music+

02-UK

Clear

Notifications

New voicemail

Dial (Your Voicemail Number) 10:32

2012.07.19 FCC

appear in all panel views. You can change these (except the app shortcut ). Touch and hold a shortcut, then select the shortcut you want to replace it

To change your ringtone, display brightness, and more, touch Menu > Settings > Audio profiles or Display. For details, see “Personalize” on page 17.

Tip: From the home screen, touch Menu > Themes to design different home screens for Work, Home, and

Weekend. Your changes are stored in each theme.

phone status & notifications

In the status bar at the top of your screen, the right side shows phone status. The left side shows new messages or events (for details, flick the bar down).

network strength battery strength

new voicemail new text message

Bluetooth™ on Bluetooth

Wi-Fi connected airplane mode

12 Home screen

connected

USB connected alarm set

2012.07.19 FCC

silent ringer silent ringer, vibrate

mute call speakerphone

13Home screen

Apps & updates

2012.07.19 FCC

get the app you want

Quick start: Apps & updates

You can find all of your apps in one place. From the home screen, touch to open the app menu. To see all of your apps, flick up and down.

From the app menu, touch All apps to view or create app groups.

Open the app groups menu.

All apps

New group

All apps

Recent

Downloaded

To close the app menu, touch Home or Back .

Browse & install apps

Get all the fun games and cool apps you want! Google Play™ provides direct access to apps, games, and books that you can download and install on your phone.

Find it: > Play Store

14 Apps & updates

Find new apps on Play Store™.

Create a new app group.

Choose which app group you want to see.

Scroll to and touch the app you want to install. Then,

2012.07.19 FCC

touch Install (if app is free) or Buy.

New apps that you install are added to the app menu.

Note: When installing an app, make sure you read the alerts that tell you what information the app will access. If you don’t want the app to have access to this information, don’t install it.

Recent apps

Your phone remembers the apps that you used most recently. From the home screen, touch and hold Home to show the most recent apps. Or, touch

> Recent.

Update my phone

You can check, download, and install phone software updates using your phone, or using your computer:

• Using your phone:

You may get an automatic notification of an available update on your phone. Simply follow the instructions to download and install.

To manually check for updates, touch Menu > Settings > About phone > System updates.

Your phone downloads any updates over your mobile network or Wi-Fi. Remember, these updates can be quite large (25MB or more) and may not be available in all countries. If you don’t have an unlimited data

15Apps & updates

plan, or mobile network updates are not available in

2012.07.19 FCC

your country, you can update using a computer.

• Using your computer:

On your computer, go to www.motorola.com/support and check the “Software” links. If an update is available, follow the installation instructions.

16 Apps & updates

Personalize

Display settings

Font style

Screen timeout

Set font

Font size

Overall size of fonts

All window animations are shown

Brightness

General profile settings

General

Incoming calls

Set volume for ringtone, alarm and notification

Set your default incoming calls ringtone

Set your default notifications ringtone

Volume

Vibrate

Vibrate phones for incoming calls

Phone ringtone

Notifications

Feedback

Notification ringtone

Auto-rotate screen

Animation

Adjust the delay before the screen automatically turns off

Screen timeout

Choose separate volume settings for incoming calls, media, alarms, and notifications.

Call & Message Notifications

Set screen brightness

2012.07.19 FCC

add your personal touch

Quick start: Personalize

Customize your phone’s sounds and appearance to make it unique to you:

Find it: Menu > Settings > Audio profiles or

Display.

To show quick settings from the home screen, touch Menu >

Settings > Menu > Quick settings:

17Personalize

• To change your quick settings, touch Menu > Edit.

2012.07.19 FCC

• To return to advance settings, touch Menu >

Advance settings.

Language & region

Set your menu language and region:

Find it: Menu > Settings > Language & keyboard >

Select language.

18 Personalize

Calls

Contacts FavoritesDialer Call log

ABC DEF

MNO

WXYZ

JKL

TUV

GHI

PQRS

11:00PM

e5555555570

Vcc

Mobile 555-555-4570

Victor Harp

Add call DialpadEnd

MuteVoice Record Speaker

Active call

End Call

Time 00:07

Open a list, then touch an entry to call.

Call

2012.07.19 FCC

it’s good to talk

Quick start: Calls

From the home screen, touch .

19Calls

• To make a call, touch , enter a number, then

2012.07.19 FCC

touch .

When dialing, touch Menu to add a pause (pauses two seconds), or wait (waits for your confirmation). To enter the international dialing code, touch and hold .

Note: Using a mobile device or accessory while driving may cause distraction and may be illegal. Always obey the laws and drive safely.

• To answer a call, flick to the right.

•During a call, touch Menu to switch to a

Bluetooth headset (see “connections” on page 39). Touch Home or Back to hide the active call display (to reopen it, touch ).

• To use the speakerphone during a call, touch

Speaker.

• To enter numbers during a call, touch Dialpad.

• To mute or unmute a call, touch Mute.

• To put a call on hold, touch Menu > Hold.

• To end a call, touch End.

• To ignore an incoming call, flick to the left.

Emergency calls

Note: Your service provider programs one or more emergency phone numbers that you can call under any

20 Calls

+ 50 hidden pages
