Motorola T56MG1 User Guide

FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1

Temporary Confidentiality Requested

Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3)

The attached User’s Manual is the final production-intended version of the generic Motorola
International English User Manual. This guide will be adapted to carrier-specific versions, but the key
information herein will be retained. Translations into other languages will also be done to support the
needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to,
placing this product onto the market. Selected portions of the User Guide can be found as indicated
below:

8.1 Safety Section: Page 40

8.2 Part 15B Declaration of Conformity: Page 50

8.3 Specific Absorption Rate (SAR) Data: Page 48

8.4 Guidance for use with Hearing Aids: Page 36, 58

Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN

MOTOROLA i475

Congratulations

MOTOROLA i475

Get the conve nience o f push-to- talk calls t ogether with
a sleek design in an affordable package.

•Private Calls. Stay in touch with your f amily , friends,
and colleagues with the simple touch of a button.

•FM Radio. Listen to your favorite stations wherever
you go.

• My Phone, My Way. It’s your phone—mak e it that
way. Customize your home s creen with personal
pictures, and change wallpapers and ringtones.

Caution: Before assembling, charging or using your
phone for the first time, please rea d the important
legal and safety inform ation packaged with your
product.

More information

On your computer—Go to
www.motorola.com/support/

.

1Congratulations

Your phone

the important keys & connectors

2.5 mm Headphone Jack

Ready

:

-

/

10:05pm 04/23

Contacts Messages

Space Key

r

OK Key

:

Soft Key

.

End/Power Key

)

Speaker Key

Micro USB
Connector

Delete Key
Return Key

Symbol Key

Volume Key

PTT Button

Soft Key

Send Key

Menu Key

Navigation

Key

ALT Key

Shift Key

Note: Your phone might look a little diff erent.

2 Your phone

Contents

Menu map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Push-to-Talk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

SDG calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Media center. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 30

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 37

3Contents

Menu map

main menu

Call Alert
Bluetooth®

• Hands Free

• Link to Devices

• Device History

• Setup

•Find Me

Settings

•(see settings
menu)

Ring Tones

• Vibrate All: On/Off

• Ringtones

•Vibrate

• Silent

Java Apps

• Java System

•FM Radio

GPS

• Position

• Privacy

• Interface

Media Center
Camera
Net

4 Menu map

Datebook
My Info

•My name

• Line 1

• Line 2

• Private ID

• Group ID

• Carrier IP

•IP1 Address

•IP2 Address

VoiceRecord

• [New VoiceRec]

Memo
Recent Calls
Shortcuts

• [Help]

• 1)Shortcuts

• 2)Cntcs[New
Contact]

• 3)Recent Calls

• 4)Contacts

• 5)Datebook

• 6)Messages

• 7)VoiceRecord

•8)Net

• 9)Call Forward

main menu (con’t.)

Contacts

• [New Contact]

• [New SDG List]

• [New Msg Group]

Note:

Your carrier may not offer the

Message Group feature.

Call Forward
Quick PTT
Profiles

• [New Profile]

• Standard

•Car

• Meeting

•Office

• Outdoors

• Headset

•PRVT Only

• CNTCS Only

• Surveillance

Call Timers

• Last Call

• Phone Reset

• Phone Lifetime

• Prvt/Grp Reset

•Prvt/Grp Life

• Kbytes Reset

PT Manager

•Quick PTT

• Send Message

• Send Picture

• Send Event

• Send My Info

• Send Contact

• Configure

Messages

• [Create Message]

•Voice Mail

•Inbox

•Drafts

•Outbox

•Fax Mail

• Net alert

• Sent Items

FM Radio

Note:

Your carrier may not offer the
FM Radio feature.
This is the standard main menu layout.

Your phone’s menu may be
different.

5Menu map

settings menu

Display/Info

• Wallpaper

•Text Size

•Theme

• Home Icons

• Backlight

•Clock

• Menu View

• Large Dialing

• Language

Phone Calls

• Set Line

• Any Key Ans

• Auto Redial

• Call Waiting

•Auto Ans

• Minute Beep

• Call Duration

•TTY

•Hearing Aid

• Notifications

• DTMF Dialing

• Prepend

6 Menu map

2-Way Radio

•Tkgrp Silent

•Tkgrp Area

• One Touch PTT

•Alert Type

• PTT Quick Notes

• On/Off PTT

• Store Rc v d Info

• PTT Backlight

Personalize

• Menu Opt i ons

•Up Key

• Down Key

•Left Key

•Right Key

• Center Key

•Left Softkey

•Right Softkey

•Power Up App

Volume

• Line 1

• Line 2

• Messages

• Earpiece

• Speaker

•Keypad

• Java Earpiece

• Java Spkr

• Data

settings menu (con’t.)

Security

• Phone Lock

• Keypad Lock

• SIM PIN

•GPS PIN

• Change Passwds

Advanced

•Alert Timeout

• Headset/Spkr

• Connectivity

• Reset Defaults

• Return to Home

• Transmitters

• Phone Only

•Baud Rate

7Menu map

Let’s go

let’s get you up and running

Assemble & charge

1 Remove cover 2 SIM in

3 Ba ttery in 4 Cover on

5 Charge up

3H

Caution: Please read “Battery Use & Safety” on
page 37.

8 Let’s go

Turn it on & off

To turn on your phon e, press and hold
End/Power for a few seconds or
until the display tu rns on. If pr ompted,
enter your four-digit unlock code.

Note: If you press End/Power for more than four
seconds, the phone will turn on in

Transmitters Off

mode.
To turn off your phone, press and hold End/Power .

Enable security

You will need to enable security the first time you
power on your phone or within 10 da ys of first
activation of your phone.

1 Press Ok.
2 You are prompted to enable security. Press

follow the on-screen instructions.

3 Press End/Power to return to the home screen.

Yes and

9Let’s go

Basics

Status

Indicators

Left Soft Key

Label

Right Soft Key
Label

Left Soft Key

:

:

Right Soft Key

About this guide

This guide shows how to locate a menu feature as
follows:

Find it: Menu / >
This means that, from the home screen:

1 Press the Menu key / to open the main menu.
2 Press the navigation keys to scroll to the

Settings menu option, and press the c enter key

to select it.

3 Press the navigation keys to scroll to

and press the center key r to select it.

Home screen

Your phone show s the home screen when you are not
on a call or using the menu.

Settings > Phone Calls

Ready

10:05pm 04/23

Phone Calls,

10 Basics

Contacts Messages

Note: Your home screen might look different from the

Volume

Key

one shown, depending on your service provider.
Soft key labels in the home screen show the current

soft key functions.
Indicators at the top of your phone’s display provide

important status information. Here are the indicators
you may see:

indicators

z Signal Strength ~ No Service
% Active Phone Line 2 New Message
! Speaker On 7 Packet Data

" Speaker Off d Battery Level
, Ringer Off c Bluetooth On

5 Vibrate All 3 New Voicemail

Adjust volume

Press the volume keys up or
down to:

• change the earp iece
volume during calls

• change the ringer volume
from the home screen

11Basics

• turn off a call alert before answering the call
Tip: You can quickly set y our ring er to

Vibrate All by

holding down the volume key while on the home
screen.

Navigation key

Press the navigat i o n key up,
down, left , or right to scroll to
items in the display. When you
highlight the desired item,
press r to select it.

Transmitters

Consult airline staf f about the use of the Transmitters

Off

feature during a flight. Turn off your phone

whenever instructed to do so by airline staff.
Find it: Menu / >

Transmitters > Off
Transmitters Off

Bluetooth fea tures in situations where wireless phone
use is prohibited. You can use the phone’s other
non-calling f eatures when the transmitters are turned
off.

Note: When you select
services are disabled. Emergency calls to y our region’ s
emergency number (e.g., 911) can still be made.

12 Basics

Settings > Advanced >

turns off your phone’s calling and

Transmitters Off, all wireless

Calls

it’s good to talk

Make & answer calls

Enter a number, then press Ta lk .
To answer a call, press Talk .
To end a call, press End/Power .

Handsfree

Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.

During a call:

• To use the speakerphone, pr ess Menu / >

Speaker or pre s s S p ea ke r ).

• To connect a Bluetooth™ de vice, press Menu / >

Use Bluetooth.

Recent calls

Find it: Menu / > Recent Calls
Tip: When you’re in the home screen, you can press

Talk to go to
The recent calls list contains information associated

with the last 20 calls you have made and received.
To display call details, highlight an entry and press r.

Recent Calls.

13Calls

Emergency calls

Note: Your service provider programs one or more
emergency phone numbers (such as 911 or 112) that
you can call under any circu mstances, ev en when y our
phone is loc ked. Emergency numbers vary by country.
Your pre-programmed eme rgency numbers may not
work in all locations, and sometimes an emergency
call cannot be placed due to network, environmental,
or interference issues.

1 Enter the emergency number.
2 Press Talk to call the emergency number.
Note: Emergency calls can’t be placed while the

keypad is locked, or if the phone is displaying a No
Service message. To unlock the keypad, press
Menu / > *.

Note: Your mobile device can use AGPS satellite
signals to help emergenc y services find you (see “GPS
& AGPS” on page49).

Cool down

In very limited circumstances, such as where your
phone has been ex posed to e xtrem e hea t, “Co ol Do wn”
message screens will appear. To avoid possible damage
to your battery and phone, you should follow these
instructions until the phone is within its recommended
temperature r ange. W hen y o ur phon e is i n “Co ol Do wn”
mode, only emergency calls can be made.

14 Calls

Push-to-Talk

PTT

Button

one or more, talk to them all

Private calls

Private calls are pu sh-to -talk calls betw een tw o people .
Make and answer private calls

To make a private call:

• Enter the recipient’s PTT
number.

• Press Menu / >

Contacts, and select a

contact that has a PTT
number.

To talk, press and hold the PTT But t on. To listen,
release the PTT Button.

To answer a private call, press the PTT Button after the
caller has stopped talking.

To end a private call, press End/Power or do
nothing. The call will end after a few seconds.

Set push-to-talk speaker
You can listen to push-to-talk calls through your

phone’s speaker or earpiece. Press Speaker ) to turn
the speaker on or off.

15Push-to-Talk

Call alerts
Use call alerts to tell someone you want to speak to

them.
To send a call alert:

• Enter a Private ID, and press

Alert. When prompted,

press the PTT Button.

Contacts, and highlight a contact c ontaining a

• Press
Private ID. Press

Alert, and press the PTT Button

when prompted.

When you receive a call alert, you can:

•Answer: Press the PTT Button to begin a private call
with the sender.

• Queue: Press

Queue to store the call alert to the

call alert queue.

•Clear: Press

Clear to dismiss and delete the call

alert.
Note: Call alerts will automatically be moved to the

queue afte r a f e w minutes of inactiv ity. You won ’ t be
able to make phone cal ls or priv ate calls until the c all
alert is moved, or you’ve chosen one of the options
above.

Turn off a call alert
You can press the volume keys to turn off a call alert

before answering the call.

16 Push-to-Talk

SDG calls

Need to talk to more than one person at a time? With
SDG (Selective Dynamic Group) ca lls you can talk to up
to 20 people at a time.

Note: T o store groups on your phone you need a
group-call-capable SI M card. Contact your service
provider for more information.

Create SDG lists in contacts

Find it: Menu / > Contacts
1 Select [New SDG List].
2 If you want to assign a name to the SDG list, enter

the name.
Note: If you do not assign a name, the SDG list is

named “SDG” follow ed b y the number of membe rs
in the SDG list. For example, “SDG (8)” for an SDG
list with eight members.

3 Add Pri vate IDs.

Save.

4 Press

Make SDG calls

1 From Contacts or the recent calls list, scroll to or

select the SDG list you want.

2 Press the PTT button.

17SDG calls

Web

Find it: Menu / > Net

Connect

Your phone uses the mobile phone netw ork (over the
air) to automatically connect to the Web.

Note: Your service provider may c harge to surf the
Web or download data.

Go to a Web site

1 From the home page, select Go to URL.

Edit.

2 Press
3 Enter the Web address and press

Ok to go to the Web site.

4 Press

Create a bookmark

1 While on a Web page, press and hold Menu / >

Mark page.

2 Name the bookmark and select

Access a bookmark

From any other Web page:

1 Press and hold Menu/ > Favorites.
2 Highlight a bookmark and press r, or press its

number on the keypa d.

18 Web

Done.

Save.

Text entry

Typing tips

To...
Enter symbols ch osen from

a list
Enter alternate characters

at the tops of keys
Enter severa l alterna te

characters, until you press
Alternate again

Enter one capital letter Press Shift
Enter only capital letters,

until you press Shift
again

Delete a character (hold to
delete more)

Start a new line (email or
text messaging)

Press Symbols

Press Alternate

Press and hold
Alternate until

appears in status

bar

Press and hold
Shift until
appears in status bar

Press Delete

Press Return

19Text entry
