APPLICANT MOTOROLA INC. |
FCC ID: IHDT56LU1 |
INSTRUCTION MANUAL
A representative version of the user's manual follows:
Exhibit 8
GET ON TRACK
MOTOROLA CHARMwith MOTOBLUR
Welcome
MOTOROLA MB502 with MOTOBLUR
The MB502’s compact design offers pocketability, easy handling, and many of the smartphone features its bulkier competitors are touting.
•The sleek design and pinch-to-zoom touch screen keeps your social life at your fingertips.
•The BACKTRACK™ navigation pad provides unobstructed navigation without blocking the screen.
•View your messages and status updates from your latest MOTOBLURHappenings and Messages widgets.
Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information at the back of this
guide. Once your phone is up and running, press Menu > Settings > About phone >
Safety information or Legal information to read the full information.
More
•Answers: Touch > Help Center.
You can also flick your home screen left or right to see the Getting Started and Tips & Tricks widgets.
•Updates: Phone updates, PC software, online help and more at www.motorola.com/mycharm.
•MOTOBLUR: After you create a MOTOBLUR account, open it at www.motorola.com/mymotoblur.
•Accessories: Find accessories for your phone at www.motorola.com/products.
Welcome 1
Your phone
the important keys & connectors
Power Key |
|
Press to put the display to |
|
sleep, or hold to turn off. |
3.5mm Headset Jack |
Volume Keys |
|
298 minutes away from cake. |
||||
|
Trevor Gilley |
Jones Lara |
||||
|
Black turtleneck |
just found a black... |
||||
Menu Key |
and a beret, and |
26 minutes ago |
||||
46 |
|
|
|
|
|
|
Press to open |
|
|
|
|
|
|
NEW YORK |
|
|
||||
Messaging |
Browser |
|
menu options.
Micro USB Connector
Charge or
connect to PC.
Microphone
Home Key
8:52
Press to return to the home screen.
Touchscreen
Back Key
Press to go back.
Touch pad on back
|
|
|
|
8:52 |
|
||||
|
|
|
298 minutes away from cake. |
||||||
|
Trevor Gilley |
Jones Lara |
|||||||
|
Black turtleneck |
just found a black... |
|||||||
|
and a beret, and |
26 minutes ago |
|||||||
|
46° |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
NEW YORK |
|
|
|
|||||
|
Messaging |
Browser |
|
||||||
|
|
|
|
|
|
|
|
|
Delete |
|
|
|
|
|
|
|
|
|
Enter |
Shift |
|
|
|
|
|
|
|||
Alternate |
|
|
|
|
|
Scroll/Select |
|||
Messages |
|
|
|
|
|
Symbols |
|||
Camera |
|
|
|
|
|
|
|||
Search |
|
|
|
|
|
Space |
|||
Press for text, |
|
|
|
|
|
|
|||
hold for voice. |
|
|
|
|
|
|
Note: Your phone might look a little different.
2 Welcome
Contents
Your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Touchscreen & keys. . . . . . . . . . . . . . . . . . . . . . . . . 6 Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Apps & updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Memory card & file transfer . . . . . . . . . . . . . . . . . . 40 Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 48
Let’s go
let’s get you up and running
Assemble & charge
1 SIM in |
2 MicroSD in (may |
|
already be inserted) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 Battery in |
4 Cover on |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 Charge up
3H
Caution: Please read “Battery Use & Safety” on page 48.
Let’s go |
3 |
Tip: To save battery life, see “Battery tips” on page 26.
Set up & go
Note: To use MOTOBLUR, please read the terms and conditions during registration and, if you agree, choose to continue.
Create or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on page 13. Registration is secure, and should only take a few minutes:
Note: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. For details, contact your service provider.
1 Turn on.
2 Select a language.
3 Register or log in.
If you have not |
MOTOBLUR ID: |
|
created a |
user@domain.com |
|
MOTOBLUR |
Password: |
|
|
|
|
account, you’ll need |
Enter password |
|
|
|
|
to register: Enter |
Forgot password |
|
your name, your |
Back |
Next |
current email |
|
|
address (where |
|
|
MOTOBLUR can |
|
|
|
|
send account information), and a new MOTOBLUR password.
4Add your accounts to MOTOBLUR.
To add an account, touch it. Then, enter the user name or email and password that you set up on that account.
Tip: For more, or to add accounts anytime, go to “Add account” on page 13.
5When your phone shows your home screen, import
your SIM contacts: Touch Contacts, then touch Menu
> Settings > Import from SIM card. Touch OK to confirm.
4 Let’s go
Turn it on & off
To turn on your phone,
press Power |
|
on top of |
your phone. |
|
|
To turn off your phone, press
and hold Power |
|
, then |
touch Power off in the menu that opens.
Wi-Fi™ connect
If you want to use a Wi-Fi network for even faster Internet access, touch Menu > Settings >
Wireless & networks > Wi-Fi settings. Touch Wi-Fi to search for and connect to wireless networks. There’s more in “Connect Wi-Fi networks” on
page 39.
Cool content & more
Note: You might not have some features. For details, ask your service provider.
Browse and download thousands of the coolest apps on the planet from Android. On top of that, you get a full HTML browser, so you can surf in style.
Download new apps with “Apps & updates” on page 12. Your phone comes with a microSD memory
card installed—you can load it up with photos, videos, and music from your computer using “Memory card & file transfer” on page 40.
Note: Do not remove your memory card while your phone is using it or writing files on it.
Security
Your contacts are backed-up on MOTOBLUR, so don’t worry. Even if you lose your phone, MOTOBLUR can help you find it or wipe it. And when you get your next MOTOBLUR product, your stored info makes it a snap to set up with just a username and password.
Of course, it doesn't stop there. There are plenty of ways to protect your phone and your information, in “Security” on page 44.
Let’s go |
5 |
Touchscreen & keys
a few essentials
Touch tips
•Touch: Choose an icon or option.
•Touch & Hold: Open options.
•Drag: Scroll or move slowly.
•Flick: Scroll or move quickly.
•Pinch: Zoom in on maps, Web pages, or photos.
|
11:35 |
Touch to open. |
|
|
|
Soooo ready to just 11:35 AM |
|
|
chill ALL summer! |
|
Touch & hold to move |
Kristen Cullen |
|
|
|
items (or open options, |
|
Dec ompression party |
|
in lists). |
afte r the test - my place... |
|
|
10 mi nutes ago
IM Browser
Drag or flick to open panels (or scroll, in lists).
To zoom pictures, Web pages, or maps, pinch two fingers together or apart.
If your screen goes to sleep, press Power .
BACKTRACK™ pad
You can also flick and double-tap the square touch pad on the back of the display!
Tip: Touch and hold to show a focus icon that
you can move to select small links on Web pages. To
turn off this touch pad, touch Menu |
> Settings > |
Sound & display > TouchPad. |
|
Key tips
Menu, home, & back
Touch Menu to open menu options in your home screen, lists, and other places.
Touch Home to close any menu or app and return to the home screen. Touch and hold Home
to show the last few apps you used, then touch an app to open it. In the home screen, touch Home
to open or close the app menu.
Touch Back to go to the previous screen.
6 Touchscreen & keys
Sleep & wake up |
|
|
To save your battery, prevent |
|
|
accidental touches, or when |
|
|
you want to wipe smudges |
|
|
off your touchscreen, put the |
|
|
touchscreen to sleep by |
|
|
pressing Power |
. To wake |
|
up the touchscreen, just press Power |
again. |
To change how long your phone waits before the
screen goes to sleep automatically, touch Menu >
Settings > Sound & display > Screen timeout.
Tip: To make the screen lock when it goes to sleep, use “Screen lock” on page 44.
Power key menu
Press and hold Power to open a menu where you can turn off sound (Silent mode), network and wireless connections (Airplane mode), or the phone (Power off).
Adjust volume
Press the volume keys on the side of the phone to change the ring volume (in the home screen), or the earpiece volume (during a call).
Spin the screen
In many apps, the touchscreen can spin to stay right-side up when you rotate your phone:
Find it: Menu >
Settings > Sound & display >
Orientation
Touchscreen & keys |
7 |
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information in one place. It’s what you see when you turn on the phone or touch Home from a menu.
Use the widgets, shortcuts and panels to see what’s important to you—whether it’s home, work or play.
|
|
|
|
11:35 |
|
|
|
|
|
|
|
||
Soooo ready to just 11:35 AM |
|
|
|
Phone Status |
||
chill ALL summer! |
|
|
|
|
||
|
|
|
||||
Kristen Cullen |
|
|
|
|||
|
|
|
||||
Decompression party |
|
|
Open the app menu. |
|||
after the test - my place... |
|
|
|
|||
10 minutes ago |
|
|
Widgets |
IM Browser
Flick icons down to see notifications.
Touch to open. Touch & hold to move or delete.
Flick left or right to open panels. Touch the
bar at the top to jump to panels.
Use & change your home screen
On your home screen, shortcuts are icons that open your favorite apps, Web bookmarks, contacts, mail
labels, or music playlists. Widgets show you news, weather, messages, and other updates.
Flick the home screen left or right to open other panels of shortcuts and widgets.
•To open something, touch it. Touch Home to return to the home screen.
•To change a widget’s settings, open it and then touch Menu > Settings.
Tip: For each Messages or Happenings widget, you can choose the accounts you want to show.
There’s more about social networking widgets in “View account updates & features” on page 14 and “Update your status” on page 14.
• To resizeMotorola widgets, touch and hold a
corner until you feel a vibration, then drag.
•To add something or change your wallpaper,
touch and hold an empty spot until you see the Add to Home screen menu.
You can add a folder to organize your shortcuts.
•To move or delete something, touch and hold it until you feel a vibration, then drag it to another
8 Home screen
spot, another panel, or the trash at the bottom of the screen.
Search
To search, use a Search widget (if you have one on
your home screen), or just start typing—your phone searches the Web, your apps, and your Contacts!
Type, then touch the icon for a text search.
Touch the icon, then speak for a voice search.
You can set SafeSearch to filter out explicit images (Moderate) or explicit images and text (Strict). After you do a voice search, just touch Menu > Settings > SafeSearch and choose a setting.
Phone status & notifications
At the top of the screen, icons on the left notify you about new messages or events (flick the bar down for details). Icons on the right tell you about phone status:
|
Bluetooth™ active |
|
|
|
|
|
network (full signal) |
|
|
|
|
|
|
|
|
|
GPS active |
|
|
|
|
|
network (roaming) |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
Wi-Fi™ active |
|
|
|
|
|
GPRS (fast data) |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
downloading |
|
|
|
|
|
EDGE (faster data) |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
vibrate |
|
3G (fastest data) |
|
|
|
|
|
silent |
|
flight mode |
|
|
|
|
|
mute call |
|
battery (charging) |
|
|
|
|
|
speakerphone active |
|
battery (full charge) |
|
|
|
|
|
Google™ sync |
|
alarm set |
|
active |
|
|
|
|
|
|
Tip: To see today’s date, touch and hold the status indicators.
Home screen |
9 |
Personalize
add your personal touch
Widgets
Note: You might not have this feature. For details, ask your service provider.
To add a widget:
1Find an empty spot on your home screen where you want to add a widget. You can flick left or right to open other panels on your home screen.
2Touch and hold the empty spot until you see the
Add to Home screen menu.
3Touch Motorola widgets or Downloaded widgets.
4Touch the type of widget. If necessary, enter the widget settings.
Some widgets have settings you can change. Touch a widget to open it, then touch Menu .
Ringtones
To change your ringtone and notifications, touch Menu > Settings > Sound & display.
To set vibrate for messages, touch >
Messaging
> Menu > Messaging Settings > Text Messaging, Email, or Social Messaging.
10 Personalize
Tip: To use a song as a ringtone, touch >
Music> Songs, touch and hold the song name,
then touch Set as ringtone.
Sounds
features
set volume for media and videos
Menu > Settings > Sound & display > Media volume
play tones when using dial pad
Menu > Settings > Sound & display > Audible touch tones
play sound on screen selection
Menu > Settings > Sound & display > Audible selection
clarify sound during calls
Menu > Settings > Call settings > Voice
Quality
Display settings
features
notification LED
Blinks to tell you that a notification has been received. Menu > Settings > Sound & display > Notification LED
set display brightness
Menu > Settings > Sound & display >
Brightness
set orientation
Menu > Settings > Sound & display>
Orientation
set animation
Menu > Settings > Sound & display >
Animation
Quick launch shortcuts
To use a quick launch shortcut, press and hold Search on the keypad, then press the assigned key, like Search
and B to launch the browser.
Date & time
Set date, time, time zone, and formats:
Find it: Menu > Settings > Date & time
Language & region
Set your menu language and region:
Find it: Menu > Settings > Language & keyboard > Select locale
Personalize 11
Apps & updates
get the app you want
Quick start: Apps & updates
You can find all of your apps in one place. From the home screen, just touch or touch Home
to open and close the app menu.
Want more? No problem: To download more apps, touch >
Market.
Your phone can tell you when there’s an updated app or other phone software. To install the update, just follow the instructions on your screen.
Browse & install apps
Note: You might not have this feature. For details, ask your service provider.
Get all the fun games and cool apps you want! Android Market™ provides access to applications developed by developers worldwide, so you can find the app you want. If you need help or have questions about Android Market, touch Menu > Help.
Find it: >
Market
Scroll to and touch the app you want to install. Then, touch Install (if app is free) or Buy.
Recent apps
Touch and hold Home to see the last few apps you used, then touch the app you want. Touch Home
to return to the home screen.
Manage & restore apps
Find it: Menu > Settings > Applications >
Manage applications
Touch an app in the list, then touch Uninstall (for apps you downloaded), Clear cache, or other options.
To reinstall apps from Android Market, touch >
Market > My downloads. Previously installed
apps are listed and available for download.
Update my phone
You can check, download, and install phone software updates using your phone, or using your computer:
•Using your phone:
You may get an automatic notification of an available update on your phone. Simply follow the instructions to download and install.
To manually check for updates, touch Menu >
Settings > About phone > System updates.
Your phone downloads any updates over your mobile network. Remember, these updates can be quite large (25MB or more) and may not be available
12 Apps & updates
in all countries. If you don’t have an unlimited data plan, or mobile network updates are not available in your country, you can update using a computer.
•Using your computer:
On your computer, go to www.motorola.com/mycharm and check the “Software” links. If an update is available, simply follow the installation instructions.
Social networking
my life, your life
Your MOTOBLUR account
The first time you turned on your phone, you registered for a MOTOBLUR account that manages your messages, contacts, and more (“Set up & go” on page 4). You can log into this account from a computer to upload contacts, reset your password, get help, or even locate your phone: www.motorola.com/mymotoblur
What is MOTOBLUR?
Only MOTOBLUR syncs contacts, posts, feeds, messages, emails, photos and
much more—from sources like Facebook™, Twitter, MySpace, your work email, Picasa™, and Photobucket™—and serves them up just the way you want them. No opening and closing apps and menus, it’s all front and center on your home screen and throughout the entire phone, so you can communicate anyway you like.
Add account
Note: You can add your Facebook, MySpace, Twitter, or other accounts to your phone. If you don’t have accounts, you can visit their Web sites to set them up.
Social networking |
13 |
Find it: >
Accounts > Add account
To sign into your account, use the user name or email and password that you set up on that account (the same as on your computer).
When you sign into social networking accounts, you’ll see your friends and contacts in your Contacts list, and your status and updates can appear in Social Status and Happenings widgets.
Twitter and MySpace messages will always appear as “read” on your phone, but your phone notifies you when you receive a new message. MySpace marks your messages as “read” online.
For email accounts, see “Set up messaging” on page 22.
Tip: To download updates faster, see “Connect Wi-Fi networks” on page 39.
Update your status
After you add a social networking account, you can update and see your current status in a Social Status
widget on your home screen.
To update your status, just touch your Social Status widget and enter text. If you have more than one account, you can use the pull-down menu to limit which accounts are updated. When you open the
widget, a number on the right side means you have unread status comments (touch it to open them). To add a Social Status widget:
1Flick your home screen left or right to open the
panel you want. Touch and hold an empty spot to open the Add to Home screen menu.
2Touch Motorola Widgets > Social Status. The widget appears in the empty spot, and will show your status the next time your phone updates from the network.
View account updates & features
After you add a social networking account, you can see and respond to friends’ updates with the Happenings
widget on your home screen. If you don’t see one, set one up in “Widgets” on page 10.
When you touch the Happenings widget to open an update, you can touch to open the full update, then touch the social network’s icon to open its Web site.
Note: Your network or other factors might affect the speed of widget updates.
Edit & delete accounts
Find it: > |
Accounts |
14 Social networking
Touch and hold an account, then touch Open account to edit it, or touch Remove account to remove it
(along with its contacts and messages).
Calls
it’s good to talk
Quick start: Calls
Find it: Dialer
|
|
|
|
|
|
|
|
11:35 |
|
|
Delete |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Search/Add Contacts |
|
|
1 |
|
2 |
|
3 |
|
|
|
|
|||
|
|
|
|
|
|
ABC |
|
DEF |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
5 |
|
6 |
|
|
|
Recent Calls |
||
|
|
|
GHI |
JKL |
|
MNO |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
8 |
|
9 |
|
|
|
|
|||||
Call |
|
PQRS |
TUV |
|
WXY |
|
|
Call a number you |
|||||
|
|
|
|
0 |
|
# |
|
|
|
||||
* |
|
+ |
|
|
|
|
|
|
entered. |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Call Timer |
Active call |
|
|
00:06 |
|
|
||||||||
|
|
|
|
||||||||||
|
|
|
Mary Morgan |
|
|
|
|||||||
|
|
|
|
|
|
||||||||
|
|
|
Mobile 1-555-555-5694 |
|
|
End Call |
|||||||
|
|
|
|
Sleep deprived |
... cramming for |
|
|
||||||
|
|
|
|
design exams |
next week. |
|
|
Hang up. |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Mute |
End call |
|
|
|
|
|
Speakerphone |
||
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
Speaker |
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Mute/Unmute |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Enter numbers during a call.
You can tell your phone to pause, or wait for your confirmation, when it dials a number. Just enter some digits, then touch Menu to add a pause or wait.
Calls 15
During a call, touch Menu to choose Hold, New call, or Use Bluetooth, or to wake up the
touchscreen. Your touchscreen sleeps to avoid accidental touches.
Tip: You can touch Home or Back
to hide the call display. To reopen it, touch
Dialer.
Make & answer calls
To make a call, touch Dialer, enter a number, then touch Call.
Tip: To enter the international dialing code, touch and hold . To add a pause or wait after numbers, touch Menu
.
To answer a call, drag Answer to
the right (when your phone is unlocked, Answer is just a touch
button).
Press Power/Lock button to ignore
Stretch to
Answer
You can also press Power to ignore the call, or press a volume key to silence the ring.
End calls
Touch End call.
Note: When you hold |
End call |
||
Speaker |
|||
Mute |
|||
your phone to your ear, |
|
|
|
|
|
||
the display goes dark to |
|
|
avoid accidental touches. When you move your phone away from your ear, the display lights up again.
Tip: You can touch Home or Back
to hide the active call display. To reopen it, touch
Dialer.
Speed dial
Find it: Dialer > Spd Dial
•To call a number, touch it.
•To add, edit, or clear entries, touch Menu .
Handsfree
Note: Using a mobile device or accessory while driving may cause distraction and may be illegal. Always obey the laws and drive safely.
During a call:
•To use the speakerphone, touch Speaker.
•To use a Bluetooth™ device, touch Menu > Use Bluetooth.
Mute & hold
During a call:
•To mute the current call, touch Mute.
•To put a call on hold, touch Menu > Hold.
16 Calls
Enter numbers during a call
To enter numbers during a call, touch , then touch the dial pad.
End call
Mute Speaker
Recent calls
Find it: Dialer > Recent
•To call a number, touch it.
•To send a text message, create a contact, view a contact, add the call to speed dial, or other options, touch and hold an entry.
All calls
555-1212
1:05 PM
5551212
Add to contacts
•To filter the list, touch the view name (like All calls) at the top.
•To clear the list, touch Menu .
Frequent calls
Find it: Dialer > Frequent
•To call a number, touch it.
•To send a text message, view a contact, add the call to speed dial, or other options, touch and hold an entry.
Conference calls
To start a conference call, call the first number. After they answer, touch Menu > New call and call the
next number. When the next number answers, touch Menu > Join.
Your phone number
Find it: Menu > Settings > About phone > Status > Phone number
Your caller ID
Note: You might not have this feature. For details, ask your service provider.
To hide your number from the people you call, touch Menu > Settings > Call settings > Additional settings > Caller ID.
Call forwarding & waiting
You can forward calls all the time, or only when your phone is busy, unanswered, or unreachable (not on the
network). To set call forwarding, touch Menu >
Settings > Call settings > Call forwarding.
When you’re on a call and a second call comes in, Call waiting lets you answer it by touching Answer. You can turn off Call waiting, to send second calls straight
to your voicemail. To turn call waiting on or off, touch
Calls 17
