INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
EXHIBIT 8
ROKR E2
GSM
motorola.com
HELLOMOTO
Introducing your new Motorola ROKRE2GSM wireless phone. Here’s a quick anatomy lesson.
Go handsfree.
Voice Key
Volume Keys
Left Soft Key
Scroll up, down, left, or right.
Press in to select.
Make & answer calls.
Play music.
Lock keypad.
Right Soft Key
Clear/Back Key
Turn on & off, hang up, exit menus.
Charge up or connect mini USB.
Microphone
1
Home Screen Main Menu
2
Service Provider 10:15
Options Main Menu
Press the
2
soft key to open the
Main Menu
Press and hold the
1
Power Key u
Main Menu
.
few seconds or
until the display
lights up to turn on
your phone.
for a
Main Menu
Messages
Contacts
Browser
Multimedia
Web Access
Settings
Options Back
Office Tools
Recent Calls
Press the Navigation
3
Key
up, down, left, or
right
(S) to highlight
a menu feature.
Help
Press the Navigation
4
Key
in (s
) to select
it.
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. The Bluetooth trademarks
are owned by their proprietor and used by Motorola, Inc. under
license. Java and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S. and
other countries.
© Motorola, Inc., 2006.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
Manual Number:
3
contents
menu map . . . . . . . . . . . . 6
Use and Care . . . . . . . . . . 8
essentials . . . . . . . . . . . . . 9
about this guide. . . . . . . 9
SIM card . . . . . . . . . . . 10
battery . . . . . . . . . . . . . 11
turn it on & off . . . . . . . 13
make a call. . . . . . . . . . 13
answer a call . . . . . . . . 13
store a phone number in
the contact list. . . . . . . 13
call a stored phone
number . . . . . . . . . . . . 14
your phone number . . . 14
main attractions . . . . . . 16
audio player . . . . . . . . . 16
FM radio . . . . . . . . . . . 21
contents
4
airplane mode . . . . . . . 23
memory card. . . . . . . . 23
voice commands . . . . . 27
photos . . . . . . . . . . . . . 29
video clips . . . . . . . . . . 31
Bluetooth™ wireless . . 33
synchronize phone
information . . . . . . . . . 37
phone updates. . . . . . . 38
basics . . . . . . . . . . . . . . . 40
display . . . . . . . . . . . . . 40
text entry . . . . . . . . . . . 43
volume. . . . . . . . . . . . . 47
handsfree speaker . . . . 47
lock & unlock keypad . . 47
lock & unlock phone . . 48
codes & passwords . . . 48
customize. . . . . . . . . . . . 50
profiles. . . . . . . . . . . . . 50
time & date . . . . . . . . . 51
themes . . . . . . . . . . . . 51
display appearance . . . 53
answer options . . . . . . 53
calls. . . . . . . . . . . . . . . . . 55
turn off a call alert . . . . 55
recent calls . . . . . . . . . 55
redial . . . . . . . . . . . . . . 56
return a call . . . . . . . . . 56
notes . . . . . . . . . . . . . . 57
hold or mute a call . . . . 57
call waiting. . . . . . . . . . 57
caller ID . . . . . . . . . . . . 58
emergency calls . . . . . 58
international calls. . . . . 59
speed dial . . . . . . . . . . 59
voicemail . . . . . . . . . . 59
other features . . . . . . . . 60
advanced calling . . . . . 60
contacts . . . . . . . . . . . 63
messages. . . . . . . . . . 68
personalize . . . . . . . . . 70
call times & costs. . . . 73
handsfree . . . . . . . . . . . 74
data & fax calls . . . . . . 75
network . . . . . . . . . . . 76
personal organizer . . . 76
security. . . . . . . . . . . . 80
fun & games. . . . . . . . 80
service and repairs . . . . 83
SAR Data. . . . . . . . . . . . 84
SAR Data. . . . . . . . . . . . 86
EU Conformance . . . . . 87
GNU License . . . . . . . . . 88
Safety Information . . . . 90
Warranty (except Mexico)
. . . . . . . . . . . . . . . . . . . . 95
Warranty (Mexico) . . . . 99
index . . . . . . . . . . . . . . 101
contents
5
<=0>
main menu
n
Contacts
e
Messages
É
Office Tools
6
• Create Message
• Inbox
• My Folders
• Templates
•Drafts
• Outbox
•Email
• Call Voicemail
• Calendar
•Email
•MOTOSYNC
• Download Manager
• File Manager
•AlarmClock
• World Clock
• SIM Applications *
•Calculator
• Dialing Services
• Fixed Dial
• Service Dial *
•TaskList
• Notes
menu map
menu map
h
Multimedia
• Media Finder
•Games
•Camera
• Video Camera
• Voice Recorder
•FM Radio
V
Browser
s
Recent Calls
Tip :
Press # to change the main menu to
a list view and back. For feature help,
1 Help
select
in the main menu.
á
Web Access
•Browser
•My Bookmarks
• My Web Pages
•History
• Go To Page
•Browser Setup
w
Settings
• (see next page)
1
Help
This is the standard main menu layout.
Your phone’s menu may be different.
* optional features
settings menu
•Profiles
•Normal
• Vibrate
• Silent
• Meeting
• Airplane Mode
• Sleeping
•Active
•Car
•Themes
• Connections
• Bluetooth™™
• Modem
• USB Settings
• Data Connections
• Call Settings
• Speed Dial
•CallForward
• In-Call Setup
• My Caller ID
• Call Waiting
• In-Call Message Alert
• Active Line
• In-Call Timer
• Answer Options
• Auto Redial
•RoamAlert
•DTMF
• Call Barring
• Fixed Dialing
• Call Drop Tone
• My SIM Number
• Phone Settings
• Display Settings
• Backlight Timeout
• Display Timeout
• Screensaver Timeout
• Brightness
• Battery Meter
• Battery Save
•Time&Date
• Language
• Talking Phone
•TextEntry
• Reset
• Reset All Settings
• Delete All Data
• Properties
• Java™ System
• Software Update
• Headset Settings
• Auto-Answer
• Voice Dial
• TTY Settings *
•Security
• Phone Lock
• Application Lock
•SIMPINLock
• Change Passwords
•Network
• Current Network
• Scan Available Networks
• Search For New Network
• My Network List
• Search Setup
• Service Tone
Tip:
You can press number keys to select
options that have numbers next to them.
This is the standard main menu layout.
Your phone’s menu may be different.
* optional features
menu map
7
Use and Care
Use and Care
<=0>
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other moisture.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F.
microwaves the ground
Don’t try to dry your phone in a microwave
oven.
Use and Care
8
Don’t expose your phone to dust, dirt, sand,
food, or other inappropriate materials.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
Don’t drop your phone.
essentials
CAUTION:
phone for the first time, read the
Before using the
Important Safety and Legal
Information
edged pages at the back of this
guide.
included in the gray-
about this guide
This guide shows how to locate a menu
feature as follows:
Find it:
>
Calculator
Press
Main Menu >É Office Tools
This example shows that, from the home
screen, you press the
open the menu, scroll to and select
É Office Tools
Press the navigation key up, down, left, or
right
navigation key in
menu feature.
<=0>
symbols
, then scroll to and select
S
to scroll to a menu feature. Press the
This means a feature is
network/subscription dependent
and may not be available in all areas.
Contact your service provider for
more information.
Main Menu
s
to select the highlighted
soft key to
Calculator
essentials
.
9
symbols
This means a feature requires an
optional accessory.
SIM card
Insert the SIM card with the gold plate facing
down and the notch in the upper right corner
as shown:
<=0>
12
Caution:
Don’t bend or scratch your SIM card.
Keep it away from static electricity, water, and
dirt.
Your Subscriber Identity Module (SIM) card
contains personal information like your phone
number and phonebook entries. It can also
contain your voicemail, text message, and
Internet access settings. If you put your SIM
card in another phone, that phone uses your
phone number.
essentials
10
battery
battery installation
<=0>
1
Pull the release
button down
and hold it there
while you lift up
the battery
door.
23
battery charging
New batteries are
not fully charged.
Plug the battery
charger into your
phone and an
electrical outlet.
Your phone might
take several
seconds to start charging the battery. Your
display shows
Tip:
Relax, you can’t overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
Note:
You can charge your battery
by connecting a cable from your
phone's mini-USB port to a USB
port on a computer. Both your
phone and the computer must be turned on,
and your computer must have the correct
Charge Complete
when finished.
essentials
11
software drivers installed. Cables and
software drivers are available in
Motorola Original data kits, sold separately.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
•
Always use
Motorola Original batteries
and chargers. The warranty
does not cover damage
caused by non-Motorola batteries
and/or chargers.
•
New batteries or batteries stored for a
long time may take more time to
charge.
•
When charging your battery, keep it
near room temperature.
essentials
12
•
When storing your battery, keep it
uncharged in a cool, dark, dry place,
such as a refrigerator.
•
Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
•
It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning:
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Never dispose of batteries in a fire
Information” section included in the
gray-edged pages at the back of this guide.
turn it on & off
Caution:
PIN code when you turn them on. If you enter
an incorrect PIN code three times before the
correct code, your SIM card is disabled, and
your display shows
service provider.
To turn on your phone,
press and hold
a few seconds or until
the display lights up. If
prompted, enter your four-digit SIM card PIN
code and/or four-digit unlock code.
To turn off your phone, press and hold
two seconds.
Some phones ask for your SIM card
O
SIM Blocked
for
. Contact your
O
for
make a call
Enter a phone number and press N to make
a call.
To “hang up,” press
O
.
answer a call
When your phone rings and/or vibrates, just
N
press
To “hang up,” press
to answer.
O
.
store a phone number in the contact list
You can store a phone number in your
list.
Note:
You can store a contact in phone
memory or on your SIM card. You can’t set a
Contacts
essentials
13
picture ID or special alerts for contacts stored
on the SIM card. To change your default save
location to phone, SIM card, or both, see
page 63.
1
Enter a phone number in the home
screen.
2
Press the
3
Enter a name for the phone number, and
Save
key.
specify the number type if necessary. To
select a highlighted item, press the
navigation key in
4
Press the
s
Save
key to store the contact.
To edit or store additional information about
the contact, see page 64. To delete a contact,
see page 67.
essentials
14
call a stored phone number
Find it:
1
2
Press the
Main Menu
key >
n Contacts
Scroll to the contact.
Shortcut:
In the contact list, press keypad
keys to enter the first letters of the
contact you want. Press the
s
navigation key in
to go to the contact.
Press N to call the contact.
your phone number
To see your phone number from the home
screen, press the
Call Settings >My SIM Number
>
Main Menu
To see your phone number while you’re on a
call, press the
Options
key >
.
key >
My Telephone Number
w Settings
.
To store or edit your name and phone number
on your SIM card, select the field you want to
edit. If you don’t know your phone number,
contact your service provider.
essentials
15
main attractions
You can do much more with your phone than
make and receive calls!
audio player
load music files on your
computer
To load music on your phone, you need to
have a digital music library on your computer.
Here is how to create a digital music library on
your computer:
1
Insert a music CD in your computer's CD
drive.
main attractions
16
2
Launch your computer's music player
program (such as Windows® Media
Player).
3
Copy the music CD to your media player
program's library (also called ripping the
CD).
If your computer is connected to the Internet
when you insert your music CD, the music
player program may retrieve data about the
Album such as Song Titles, Album name,
Artist name, and Album art work. This data
can be edited or entered manually by using
your computer's music player application. This
data will be displayed in your phone’s audio
player.
load music files on your phone
To transfer your music from your computer’s
digital music library to your phone and its
SD memory card, see page 25. To download
songs from the Web, see page 81. For a list of
the file formats your phone can play, see
page 26.
Note:
Your SD memory card is formatted with
FAT16 and has limits on how many
files/folders you can store at the top level. We
recommend that you create a folder on your
SD card and then store your files inside that
folder.
play music files
Your phone can play and store audio
files (for a list of formats, see page 26).
You can use a removable SD memory card
with your phone to store more songs (see
page 23).
Note:
You can use any stereo
headset with a 3.5 mm plug. For
best performance, use a
Motorola Original headset or a
headset with an impedance rating between
16-32 ohm.
Find it:
Press f. Then, press S up or down
to scroll to an option, and press the
s
navigation key in
<=0>
to select the option:
options
All
Show and play individual songs.
Note:
All of your phone’s songs
All
appear in the
may not have any
Genre
information stored, so they
list. Some songs
Artist, Album
, or
don’t appear in those lists.
Playlists
Create or play a playlist of songs
(see page 20).
main attractions
17
options
Recently
Played
Albums
Artists
Composers
Genres
Preloaded
Ringtones
main attractions
18
See songs you recently played.
Select an album to show or play
its songs.
Select an artist to show or play
their songs.
Select a composer to show or
play their songs.
Select a type of music to show or
play songs.
Show and play your standard
ringtones.
You can control playback with the keys on the
left side of your phone, or with your navigation
key.
Headphone
Jack
Open the
audio player.
Volume Keys
Skip back.
Play or
pause.
Skip forward.
S
Press
up to play or pause. Press S down
to stop. Press
Press up, down, left, right, or in to
select or control music.
S
right or left to go forward or
Lock your
keypad.
Memory Card
Slot
Mini-USB
Jack
(for
computer
connection)
back.
If you receive a call during a song
, the song
pauses until the call is over. You can hear the
call through your headphones and speak into
the microphone on your phone (or the
microphone on your headphones, if available).
Options
During a song, you can press the
key to
show these options:
<=0>
options
Hide
Hide the audio player while music
plays. To see the audio player
S
up. To stop the
Properties
, such as the
O
.
Manage
again, press
hidden audio player, press
Show song
file name, type, and size.
Delete
Delete the song. This does not
appear for preloaded items.
options
Send to
Attach the song to a message,
copy it to your memory card, or
send it over a Bluetooth™
connection.
Apply to
Add the song to a playlist or make
it a ringtone.
Setup
Customize settings (see
page 20).
During a song, the music player shows the
song Title, Artist, Album, and Artwork if
available. To see a larger image of the
Artwork
, press the navigation key ins
(press it again to return to the media player).
main attractions
19
add music files to a playlist
Find it:
Press f. Then, press S up or down
All
to scroll to a folder (such as
s
navigation key in
1
Scroll to a song you want to add to the
to open the folder:
playlist.
Tip:
To select multiple songs for the list,
Options
press the
Select Multiple
key and select
. Your phone shows a song list
where you can scroll to songs you want to
add and press the navigation key in
select them.
2
Press the
>
Options
key and select
Playlist
. Your phone shows a list of
playlists.
3
Scroll to an existing playlist.
To create a new playlist, press the
Options
key and select
name for the playlist and press the
main attractions
20
), and press the
New Playlist
Apply to
. Enter a
s
OK
key.
to
4
Press the
5
Repeat the procedure to add more songs,
or press the
Apply
key.
Back
key to return to the f
menu.
To hear a playlist
to the playlist, press the
Play
.
, press f>
Options
Playlists
key, and select
customize audio player
Find it:
select
<=0>
Press f, press the
Setup
. You can change:
options
Shuffle
Equalizer
Play songs in a random order.
Choose a setting (such as
or
Options
Reggae
) to customize sound.
key, and
. Scroll
Techno
options
End Call
Auto Repeat
Stereo Effect
Settings
Internet
Connection
If you highlight a song in a song list and press
Options
the
the song and list such as
Apply to
If you receive a call during a
song, the song pauses. When
the call is done, this setting
makes the song resume playing
Auto-Play
(
Repeats a song or playlist until
you stop the player.
Set
customize sound.
Choose the Internet connection
profile for the
the
key, you may also see options for
, and
Sort by
) or stay paused (
Spatial Audio
f
.
and
New Ringtone
menu.
Delete, Rename, Send to
Bass Boost
Pause
).
to
link on
FM radio
To listen to an FM radio station on your phone,
you must plug in a headset. Then:
,
main attractions
21
Find it:
Press the
FM Radio
>
Volume Keys
down (hold to
22
.
Headphone
Jack
Move tuner
search).
Mute or
unmute.
Move tuner
up (hold to
search).
main attractions
Main Menu
Hold a number key to
store the current
station as a preset
(1-9). Press a key to
go to its preset.
key >
h Multimedia
Lock your
keypad (up).
Press up or
down to
scroll through
presets.
Press left or
right to move
tuner.
Note:
You can use any stereo
headset with a 3.5 mm plug. For
best performance, use a
Motorola Original headset or a
headset with an impedance rating between
16-32 ohm.
Options
Press the
<=0>
key for these options:
options
Hide
Hide the radio display while it is
on. To see the radio display
again, press the
navigation key in
s
the hidden radio, press
Mute /
Mute or unmute the radio.
Unmute
Switch to
Speaker
Switch
Bands
Switch sound to your phone
speaker.
Switch to
FM1, FM2
, or
band stores presets 1-9.
up. To stop
O
.
FM3
. Each
options
Scan
Scan
Presets
Presets List
To turn off the radio, press O in the radio
display.
Briefly hear each station your
phone can receive. Press the
s
navigation key in
scan.
Briefly hear each station stored
as a preset. Press the
navigation key in
scan.
See the list of preset stations
for the current band. Press the
Options
key to tune, store,
rename, or clear presets.
to stop the
s
to stop the
airplane mode
Airplane mode turns off your phone’s
Bluetooth™ and calling features in locations
where wireless phone use is prohibited. You
can use the phone’s music player and other
non-calling features in airplane mode.
To set airplane mode:
Find it:
>
When airplane mode is active, the airplane
mode indicator
corner of the display. To reactivate your
phones calling features, return to the
menu and select a different profile.
Press the
Profiles >Airplane Mode
Main Menu
A
shows in the top left
key >
w Settings
Profiles
memory card
You can use a removable SD memory
card with your phone to store and
main attractions
23
retrieve multimedia objects (such as photos
and sounds). Your phone can use SD cards
with up to a 2 GB capacity.
Note:
If you download a copyrighted file and
store it on your memory card, you can use the
file only while your memory card is inserted in
your phone. You cannot send, copy, or change
copyrighted files.
install a memory card
Caution:
card. Keep it away from static electricity,
water, and dirt.
Open the memory
card door and
press the
SD memory card
into its slot until it
clicks into place.
Do not remove
24
Don’t bend or scratch your memory
main attractions
your memory card while your phone is using
or writing files on it.
To remove the memory card
in until it clicks. It begins to slide out, and you
can slide it the rest of the way out.
, push the card
see memory card contents
Find it:
>
Note:
refresh the list, press the
To see only the files stored on your memory
card, press the
>
icon (
Tip:
card? Try turning your phone off, then on
again. Then, return to the
Press the
Media Finder
If your phone does not prompt you to
File Manager
y
).
Is your phone not seeing your memory
Main Menu
.
Main Menu
, then choose the memory card
key >
Options
key >
File Manager
h Multimedia
key >
É Office Tools
list.
Refresh
.
copy files from the phone to the
memory card
You can copy files (such as pictures and
photos, video clips, and sound files) from your
phone to the memory card.
Find it:
Press the
File Manager
>
1
Select a folder and scroll to the file you
want to copy.
2
Press the
Note:
the highlighted file is copyright-protected.
Memory Card
The
your phone does not find a memor y card
installed.
Tip:
Did your phone not find the memory card
you installed? Try turning your phone off, then
on again. Then, try to copy the file again.
Main Menu
key >
.
Options
key >
Send to >Memory Card
The
Send to
option does not appear if
option does not appear if
É Office Tools
connect the memory card to a
computer
You can connect your phone to a computer to
transfer files to and from the memory card.
Note:
When your phone is connected to a
computer, you can access the memory card
only through the computer.
On your phone:
Press the
.
>
option might already be selected.
This directs the USB connection to
your memory card. Attach the
Motorola Original USB cable to the
accessory port on your phone and
to an available USB port on your computer.
Then follow these steps:
Main Menu
key >
USB Settings >Memory Card
w Settings >Connections
. The
Memory Card
main attractions
25
On your computer:
1
Find where your phone’s memory card
displays as a “Removable Disk” icon. On
a PC this is the “My Computer” window.
On a Mac it’s on the desktop.
2
Double-click the “Removable Disk” icon
to access the files on your phone’s
memory card.
3
To store the desired files onto the
memory card, drag and drop them onto
the removable disk drive icon.
4
When you finish, remove the phone with
memory card safely from your computer:
If you are using a PC
, right-click the
“Safely Remove Hardware” icon in the
system tray at the bottom of your
computer screen. Then select “USB
Mass Storage Device”.
main attractions
26
If you are using a Mac
, select and drag
the “Removable Disk” icon to the “Trash.”
file formats that work on your phone
Before you copy files to your phone, make
sure the files are in a format that your phone
recognizes:
<=0>
audio
AAC (up to 192 Kbps), AAC+ (16
to 128 Kbps), MP3 (up to 320
Kbps, WAV (no limit), WMA v9 L2,
v3, v7, v8 (up to 160 Kbps), Real
Audio G2, 8 (up to 96 Kbps), Real
Audio 10 (up to 192 Kbps)
.jpg (up to 640 x 480), .png, .bmp,
.gif, .wbmp, .ems (up to 320 x
240)
video
MPEG4 + AAC: video up to 296
Kbps, 320 x 240, 15 fps., 44 kHz,
stereo audio in .mp4, 3gp, .pvs,
.pvp, .pvx file formats. H.263 +
AAC: video up to 296 Kbps, 320 x
240, 15 fps., 44 kHz, stereo audio
in .mp4, 3gp, .pvs, .pvp, .pvx file
formats. Real Audio + video: video
up to 296 Kbps, 320 x 240, 15
fps., 44 kHz, stereo audio in .rm,
.rmvb file formats.
voice commands
You can use voice commands to make calls,
open phone applications, and perform basic
phone functions.
Note:
Not all phone languages support voice
recognition and voice commands.
voice dial a call
You can dial an entry in your contacts list by
speaking the entry’s name, or dial any phone
number by speaking its digits.
Tip:
Speak numbers at a normal speed and
volume, pronouncing each digit distinctly.
Avoid pausing between digits.
1
Press and release A on the right side of
your phone.
Your phone prompts you to say a
command or name.
2
Say the name of an entry in your contacts
list. Your phone confirms the name and
makes the call.
or
Say “Dial Number.” Your phone prompts
you to speak the digits in the phone
main attractions
27
Loading...
