Motorola C350 GSM Mobile

Phone User Guide

Review Draft

January 8, 2003

IMI

Welcome

Internal Antenna

Left Soft Key

Perform functions identified by left display prompt.

Earpiece

Right Soft Key

Perform functions

identified by right display prompt.

Menu Key

Open a menu when you see G in the display

Power/End Key

Press & hold to power phone on & off. Press & release to end phone calls, exit menu system.

IMI

Send/Answer Key

Make and answer calls; press in idle

to see recent dialed calls.

Navigation Key

Scroll through lists, set volume.

USB Connector

Insert data cable.

Microphone

Your C350 Series phone lets you change covers and keypads (see “Changing Your Phone’s Cover” on page 15). Your phone may not appear exactly as the phone image above.

Note that all key locations, sequences and functions remain the same with any of the various covers.

Headset Connector

Power Connector

Insert charger.

Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048

1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)

www.motorola.com www.motorola.ca

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © Motorola, Inc. 2002.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Manual number: 6809457A28-O Cover number: 8988485L49-O

(United States)

(Canada)

IMI

Contents

Safety and General Information Getting Started

What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Changing Your SIM Card. . . . . . . . . . . . . . . . . . . . . . . . 13

Changing Your Phone’s Cover. . . . . . . . . . . . . . . . . . . . 15

Resetting Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Charging the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 19

Adjusting the Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 22

Learning to Use Your Phone

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the 4-Way Navigation Key. . . . . . . . . . . . . . . . . . 26

Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 36

Changing a Code or Password . . . . . . . . . . . . . . . . . . . 38

If You Forget a Code or Password. . . . . . . . . . . . . . . . . 39

Locking and Unlocking the Keypad . . . . . . . . . . . . . . . . 39

Setting Up Your Phone

Storing Your Name and Phone Number . . . . . . . . . . . . 40

Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . 40

Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . . . . . . . . 23

IMI

Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . . 42

Selecting a Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . 42

Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . 43

Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Conserving Battery Power . . . . . . . . . . . . . . . . . . . . . . . 44

Calling Features

Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 45

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 45

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 47

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Calling an Emergency Number. . . . . . . . . . . . . . . . . . . . 47

Dialing International Numbers . . . . . . . . . . . . . . . . . . . . 48

Viewing the Received Calls or Dialed Calls List . . . . . . . 48

Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 51

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 53

Calling With 1-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . . 53

Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Putting a Call on Hold. . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Transferring a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Phone Features

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . 60

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

IMI

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Specific Absorption Rate Data Additional Health and Safety Information Warranty Index Wireless Phone Safety Tips

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

. . . . . . . . . . . . . . . . . . . 71

. . . . . . . . . . 73

. . . . . . . . . . . . . . . . . . . . . . 95

IMI

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR PHONE.

The information provided in this document supersedes the general safety information contained in user guides published prior to July 2000. For information regarding radio use in a hazardous atmosphere please refer to the Factory Mutual (FM) Approval Manual Supplement or Instruction Card, which is included with radio models that offer this capability.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RF Operational Characteristics

Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits radio frequency (RF) energy. The phone operates in the frequency range of 824 MHz to 849 MHz and 1850 MHz to 1910 MHz in digital mode.

When you communicate with your phone, the system handling your call controls the power levels at which your phone transmits. The output power level typically may vary over a range from 0.0 Watts to 1.0 Watt for the 800 MHz band and 0.0 Watts to 1.0 Watt for the 1900 MHz band.

Exposure To Radio Frequency Energy

Your Motorola phone is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy:

•

United States Federal Communications Commission, Code of Regulations; 47 CFR part 2 sub-part J

IMI

•

American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992

•

Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition

•

National Council on Radiation Protection and Measurements (NCRP) of the United States, Report 86, 1986

•

International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998

•

Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999

•

Australian Communications Authority Radiocommunications (Electromagnetic Radiation-Human Exposure) Standard 1999

To assure optimal phone performance and make sure human exposure to radio frequency electromagnetic energy is within the guidelines set forth in the above standards, always adhere to the following procedures:

Portable Phone Operation and EME Exposure

Antenna Care

Use only the supplied or an approved replacement antenna.

Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

Do NOT hold the antenna when the phone is in use.

antenna affects call quality and may cause the phone to operate at a higher power level than needed.

Phone Operation

When placing or receiving a phone call, hold your phone as you would a wireline telephone.

Speak directly into the microphone.

IMI

Holding the

Body-Worn Operation

To maintain compliance with FCC/Health Canada RF exposure guidelines, if you wear a phone on your body when transmitting, always place the phone in a Motorola-supplied or approved clip, holder, holster, case, or body harness for this product. Use of non-Motorola-approved accessories may exceed FCC/Health Canada RF exposure guidelines. If you do not use one of the Motorola-supplied or approved body-worn accessories, and are not using the phone held in the normal use position,

ensure the phone and its antenna are at least one inch (2.5 centimeters) from your body when transmitting.

Data Operation

When using any data feature of the phone, with or without an accessory cable,

position the phone and its antenna at least one inch

(2.5 centimeters) from your body.

Approved Accessories

For a list of approved Motorola accessories, visit our website at

www.mot.com

Electromagnetic Interference/Compatibility

Note:

Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise configured for electromagnetic compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility conflicts, turn off your phone in any facility where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.

IMI

Medical Devices

Pacemakers

The Advanced Medical Technology Association recommends that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker. These recommendations are consistent with the independent research by, and recommendations of, the United States Food and Drug Administration.

Persons with pacemakers should:

•

ALWAYS keep the phone more than six inches (15 centimeters) from your pacemaker when the phone is turned ON.

•

NOT carry the phone in the breast pocket.

•

use the ear opposite the pacemaker to minimize the potential for interference.

•

turn OFF the phone immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

Safety and General Use While Driving

Check the laws and regulations on the use of phones in the area where you drive. Always obey them.

When using your phone while driving, please:

•

give full attention to driving and to the road. use hands-free operation, if available.

IMI

•

pull off the road and park before making or answering a call if driving conditions so require.

Operational Warnings

For Vehicles With an Air Bag

Do not place a portable phone in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive atmosphere, unless the phone is a model specifically identified as being “Intrinsically Safe.” Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death.

Note:

The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders, and any other area where you would normally be advised to turn off your vehicle engine. Areas with potentially explosive atmospheres are often but not always posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your phone when you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.

IMI

Operational Cautions

Antennas

Do not use any portable phone that has a damaged antenna.

damaged antenna comes into contact with your skin, a minor burn can result.

Batteries

All batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touches exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

If a

IMI

Getting Started

What’s in the Box?

Your digital wireless phone has a permanent internal battery, and typically comes equipped with a charger. Other accessory options can customize your phone for maximum performance and portability.

To purchase Motorola Original™ accessories, please contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in

Getting Started

Canada.

About This Guide

This user guide introduces you to your Motorola wireless phone.

Note:

A reference guide for your phone is also available that describes your phone’s features in more detail.

To obtain the reference guide for your phone, or another copy of this user guide, see the Motorola Web site at:

http://motorola.com/consumer/manuals

or contact the Motorola Customer Call Center at 1-800331-6456 in the United States or 1-800-461-4575 in Canada.

IMI

Optional Features

This label identifies an optional network, SIM card, or subscription-dependent feature that may not be offered by all service providers in all geographical areas. Contact your service provider for more information.

Optional Accessories

This label identifies a feature that requires an optional Motorola Original™ accessory.

Changing Your SIM Card

Your SIM (Subscriber Identity Module) card contains your phone number, service details, and phonebook/message memory. It must be installed in the base of the phone. If you have problems with your SIM card, contact your service provider.

Since your C350 Series phone lets you change covers and keypads, it may not appear exactly as the phone pictured. All key locations, sequences, and functions remain the same with any of the various covers.

Caution:

exposing your SIM card to static electricity, water, or dirt.

Do not bend or scratch your SIM card. Avoid

IMI

Getting Started

To Change Your SIM Card

Press down on the cover release button at the top of your phone

Pull the top of the phone’s back cover to release it

Release button

Getting Started

Slide the metal SIM card holder back to unlock it, then lift up to open it slightly. Remove the old SIM card, if necessary.

Insert the new SIM card in the holder with the cut corner on the upper left and the gold plate facing down.

Close the SIM card holder and

slide it forward to lock it.

SIM card holder

IMI

SIM card

Changing Your Phone’s Cover

Your phone uses a convertible cover, keypad, and (in some cases) side band that you may replace to completely change its appearance. Your phone may not appear exactly as the phone pictured. All key locations, sequences, and functions remain the same with any of the various covers.

To Remove a Cover and Keypad

Release button

Side band

IMI

Side tabs

Lanyard loop

Press down on the cover release button at the top of your phone.

Pull the top of the phone’s back cover to release it.

Note:

If your cover has a removable side band, remove it at this point.

Pull the side tabs away from the phone, then

Lift up on the lanyard loop to pull the phone out of the front cover.

Getting Started

Always use the keypad and side band (if applicable) that matches the new cover.

To Install a Cover and Keypad

Note:

has an end cap, install it before attaching the front cover.

Getting Started

Note:

Always use Motorola Original™ covers. The phone warranty does not cover damage caused from using non-Motorola accessories.

If your phone

Slide the top of the phone into the top of the new front cover.

Press the bottom of the phone into the front cover until the side tabs snap into place.

Note:

If your cover has a removable side band, attach it at this point.

IMI

Side tabs

To Install a Cover and Keypad

Insert the bottom of the back cover.

Press the top of the back cover down until it hooks over the cover release button.

Resetting Your Phone

Getting Started

If your phone becomes frozen on a single display, error message, or power up, reset your phone as follows:

To Reset Your Phone

Remove your phone’s back and front cover as described in “Changing Your Phone’s Cover” on page 15.

Use a small object to press the Reset button on the front of your phone.

Your phone display should be restored.

IMI

Reset button

Replace your phone’s cover.

Charging the Phone

Your phone has a built-in battery. Before you can use your phone, you need to fully charge the battery, as indicated by the following instructions. Some batteries perform best after several full charge/discharge cycles.

To Charge the Phone

Getting Started

Plug the travel charger into the middle jack on the bottom of your phone.

Plug the other end of the travel charger into the appropriate electrical outlet.

When your phone indicates that it is fully charged ( charger.

Charge Complete

), remove the travel

IMI

Note:

When you charge the battery, the battery level indicator in the upper right corner of the display shows how much of the charging process is complete. See the “Battery Level Indicator” item on page 24.

Battery Use

Your C350 Series phone has a permanent internal battery. To maximize your battery’s performance:

•

Always use Motorola Original™ battery chargers. The phone warranty does not cover damage caused from using non-Motorola battery chargers.

•

New phones or phones that have been stored for long periods of time may require a longer initial charge time.

•

Maintain the phone at or near room temperature when charging.

•

Do not expose phones to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

Getting Started

Turning Your Phone On

To Turn Your Phone On

Press and hold O (the End/Power key)

End/ Power Key

IMI

If necessary, enter your SIM card PIN code and press

(+) to unlock your SIM card

Note:

If you enter an incorrect PIN code three times in a row, your SIM card is disabled and your phone displays the message (For more information, see “Locking the SIM Card” on page 74.)

SIM Blocked

To Turn Your Phone On

If necessary, enter your four-digit unlock code and press

Note:

(For more information, see page 36.)

(+) to unlock your phone

The unlock code is originally set to 1234.

Adjusting the Volume

You can adjust your phone’s earpiece and ring tone volume by pressing right and left on the

When You C an A djus t

Getting Started

you are in a call earpiece speaker volume the display is idle ring tone volume

Tip:

At the lowest ring tone volume setting, press S left

once to switch to vibrate alert. Press it again to switch to silent alert. Press then ring alert.

right to cycle back to vibrate alert,

IMI

Making a Call

There is a built-in antenna in the top of your phone. Do not block the antenna while you are on a call.

Press To

keypad keys dial the phone number

Tip:

If you make a mistake,

press

DELETE

the last digit, or press and hold

DELETE

digits.

Answering a Call

When you receive a call, your phone rings and/or vibrates and displays an incoming call message.

make the call end the call and “hang up” the

phone when you are finished

IMI

Built-in antenna

(-) to delete

(-) to clear all

Getting Started

To Answer a Call

Press N or

Press O (end key) when the call is done.

ANSWER

(+)

Note:

If the phone is locked, you must unlock it to answer

the call.

Viewing Your Phone Number

To view your phone number from the idle display, press

While you are on a call, press

Your phone number must be stored on your SIM card to use this feature. To store your phone number on the SIM card, see page 40. If you do not know your phone number, contact your service provider.

My Tel. Numbers

Getting Started

IMI

Learning to Use Your Phone

See page 1 for a basic phone diagram.

Using the Display

The idle display (shown below) is the standard display when you are not on a call or using the menu.

5| U; tf9 Y

12:00

MYMENU MESSAGE

Clock

(menu) indicator at the bottom center of the display

The indicates you can press the menu key ( main menu to see more features.

Labels at the bottom corners of the display show the current soft key functions. Press the left soft key ( right soft key ( left or right soft key label.

Menu Indicator Soft Key Labels

) to perform the function indicated by the

IMI

) to go to the

) or

Learning to Use Your Phone

At the top of the display are a number of status indicators:

➎

➋

Service Indicator

➊

Signal Strength Indicator

➑

Alert Type Indicator

➌

In Use Indicator

5| U; tf9 Y

➍

12:00

Roam Indicator

Text Entry Indicator (if applies)

➏

Message Indicator

➐

Battery

Level Indicator

MYMENU MESSAGE

➊

Signal Strength Indicator

phone’s connection with the network.

Shows the strength of your

Strong

You cannot make or answer calls when the “no signal” indicator is displayed.

is active. The indicator does not mean that you are in a

Learning to Use Your Phone

call; only that you are registered on the network via a GPRS connection.

➌

In Use Indicator

and when you have a secure ( connection.

5 4 3 2 1 0

➋

Service Indicator

GPRS connection ( transfer speeds, and your service provider may indicate when a GPRS packet data connection

IMI

Indicates when a call is in progress,

Indicates if you have a

). GPRS allows faster data

) or insecure (F)

No signal

➍

Roam Indicator

uses another network system outside your home network. When you leave your home

network area, your phone roams or seeks another network. Icons here can also indicate your text entry mode (alpha, numeric, symbol, etc.)

➎

Text Entry Indicator

whenever you are in a text editor (Tap, iTap, etc.). See “Entering Text” on page 28.

➏

Message Indicator

have an active Chat session, or when you

have a new voice or text message waiting.

➐

Battery Level Indicator

left in your battery. The more bars visible, the greater the charge.

Appears when your phone

Indicates your Text Entry Method

Indicates when you

Shows the amount of charge

Learning to Use Your Phone

High

Recharge your battery as soon as possible when you see the

Low Battery

battery alert.

Note:

indicator instead shows how much of the charging process is complete. See “Charging the Phone” on page 18.

➑

Alert Type Indicator

profile. The default alert setting is loud ring.

Y W

Low

IMI

warning message and hear the low

When you charge the phone, the battery level

Shows the current selected alert

=soft ring

= vibrate and ring

= loud ring

=vibrate

= silent

Using the 4-Way Navigation Key

Use the 4-way navigation key like a joystick to navigate the menu system, change feature

settings, and play games.

Tip:

Down and up are the primary movements within menus. Move left and right to change feature settings,

navigate the datebook, and edit text.

Navigation Key

Using Menus

From the idle display, press M to display the main menu.

Selecting a Menu Feature

From the idle display, select a menu feature as follows:

Find the Feature

Learning to Use Your Phone

This example shows that from the idle display, you must

press and select to scroll, and the left/right soft keys to select the functions listed in the bottom left and right corners of the display.

, scroll to and select

Dialed Calls

IMI

to see the dialed calls list. Use S

Recent Calls

Dialed Calls

Recent Calls

, then scroll to

Selecting a Feature Option

Some features require you to select an item from a list:

Press

BACK

(-) to display the previous screen.

Press

to open

the sub-menu.

•

Press S to scroll up or down to highlight an item.

•

In a numbered list, press a number key to highlight the item.

•

In an alphabetized list, press a key repeatedly to cycle through the letters on the key and highlight the closest matching list item.

•

When an item has a list of possible values, press S to the left or right to scroll and select a value.

•

When an item has a list of possible numeric values, press a number key to set the value.

Dialed Calls

10)John Smith

9)Mary Smith

BACK VIEW

Press

VIEW

for the highlighted item.

(+) to display details

Highlighted item

IMI

Learning to Use Your Phone

+ 71 hidden pages
