Motorola SCOUT1100 USER’S GUIDE

USER’S GUIDE

Model: SCOUT1100

DIGITAL VIDEO PET MONITOR with

OUTDOOR PET UNIT

USER’S GUIDE

The features described in this User's Guide are

subject to modifications without prior notice.

Welcome...

to your new Motorola Digital Video Pet Monitor with Outdoor Pet Unit!

Thank you for purchasing your new Digital Video Pet Monitor with Outdoor pet unit. If you have always wondered what your pet is up to when you are away, wonder no more. With the outdoor pet unit, you can also see what your pet(s) is doing in the backyard.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.

For product related questions, please call:

+49 (0) 1805 938 802 in Europe Email: motorola-mbp@tdm.de

This User's Guide provides you with all the information you need to get the most out of your product.

Before you can use your new Digital Video Pet Monitor, we recommend that you fully charge the battery of the digital video pet monitor by inserting it in the owner unit. This will allow it to continue to work even if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on page 7 before installation.

Got everything?

• 1 x Owner Unit

• 1 x Outdoor Pet Unit

• 1 x Rechargeable Ni-MH Battery Pack for the Owner Unit

• 1 x Power adapter for the Owner Unit

• 1 x Power adapter with connector for the Outdoor Pet Unit

• 4 x Mounting Screws and Dry Wall Plugs

• 1 x Tamper-proof Screw

• 1 x Metal Bracket

• 1 x Wrench Key In multi-camera packs, you will find one or more additional pet units with

power adapter units.

Overview of the Owner Unit

1. Display (LCD screen)

2. Up Key

3. Down Key

4. Left Key

5. Right Key

6. Menu Key

7. OK Key

8. Quick Scan key >>

9. Tal k K e y

Normal Mode: Tilt Up Menu Mode: Up

Normal Mode: Tilt Down Menu Mode: Down

Normal Mode: Pan Left Menu Mode: Left

Normal Mode: Pan Right Menu Mode: Right

Press to open the Menu options

Press to double the video pan and tilt speed. Press again to return to normal speed.

Press and hold to talk to your pet Note: applicable for Indoor Pet Unit only (not incl.)

10. Power Adapter / Battery LED BLUE when mains adapter power on. RED when battery low.

11. Unit ON/OFF LED (Green)

12. Audio Level LED (Green,

Orange, Red, Red) Note: applicable for Indoor Pet Unit Only (not. incl.)

13. Microphone

14. Power / Video ON-OFF key

Press and Hold to turn the unit ON/OFF Press once to turn ON and OFF the LCD display

15. Antenna Lift the antenna for optimal reception

16. Battery cover

17. Stand

18. Speaker

19. USB connector

Connection to AV output * AV Cable (Optional accessory, purchased separately)

20. Power Adapter Socket

Owner unit menu icons

Signal Level (5 Levels)

No RF Signal

Night Vision Mode (Screen changes to Black/White)

Battery Level Control (4 Levels)

Pan Left

Pan Right

Tilt Up

Tilt Down

Pan/Tilt at normal speed

Pan/Tilt at double speed

Volume Level Control (8 Levels)

Brightness Level Control (8 Levels)

Zoom Level Control (1X, 2X)

Alarm Setting (6h, 4h, 2h, OFF)

Cam Control (scan, view, add, del)

Overview of Outdoor Pet Unit

1. Camera Lens

2. Infared LEDs

3. Pair Key

4. Antenna

Important guidelines for installing your digital video pet monitor

• To use your Pet Units and Owner Unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions.

• Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Camera and Owner Unit may block the radio signal.

• The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches.

• Use of other 2.4GHz products, such as wireless networks (Wi-Fi routers), Bluetooth interference with this product, so keep the monitor at least 5ft (1.5m) away from these products, or turn them off if they appear to be causing interference.

• If the signal is weak, try moving the Monitor and/or the Pet Units to different positions in the rooms or outdoor area.

systems, or microwave ovens, may cause

Table of contents

1. Safety Instructions .........................................................................7

2. Getting Started..............................................................................12

2.1 Owner Unit Battery Installation.....................................................12

2.2 Owner Unit Power Supply ............................................................12

2.3 Outdoor Pet Unit Installation ........................................................13

2.3.1 Mounting the Outdoor Pet Unit ......................................14

2.4 Registration (Pairing)....................................................................17

2.5 View Video Through TV ...............................................................17

3. Using the Digital Video Pet Monitor............................................18

3.1 Setting up .....................................................................................18

3.2 Pan and Tilt ..................................................................................18

3.3 Night Vision Mode ........................................................................18

3.4 Video ON/OFF..............................................................................18

4. Owner Unit Menu Options............................................................19

4.1 Brightness ....................................................................................19

4.2 Zoom ............................................................................................19

4.3 Alarm ............................................................................................19

4.4 Camera Control............................................................................19

4.4.1 View a camera ...............................................................19

4.4.2 Delete a camera ............................................................20

4.4.3 Scan camera ..................................................................20

5. Disposal of The Device (environment) .......................................21

6. Cleaning.........................................................................................22

7. Help ................................................................................................23

8. General Information......................................................................25

6 Table of contents

1. Safety Instructions

WARNING:

STRANGULATION HAZARD - In case this unit is being used to monitor infants or children, keep the unit and adapter cord more than 1 metre from the cot and out of their reach. Never place camera or cords within a cot or near a bed. Secure the cord away from children's reach. Never use extension cords with AC Adapters. Only use the AC Adapters provided.

As with any electrical device, supervision of your pet's usage should be exercised until your pet is acclimated to the product. If your pet is prone to chewing, we strongly recommend you keep this and all other electrical devices out of its reach.

CAMERA SET UP & USE:

● Determine a location for the CAMERA that will provide the best view of your pet in its area of activity.

● Place the CAMERA on a flat surface, such as a dresser, desk or shelf.

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit.

This symbol indicates that there are important operating and maintenance (servicing) instructions in the literature accompanying the unit.

WARNING: VOLTAGES IN THIS UNIT ARE HAZARDOUS TO LIFE. DO NOT REMOVE COVERS. THERE ARE NO USER SERVICEABLE PARTS INSIDE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH THE WIDE BLADE OF THE PLUG TO THE WIDE SLOT

ENGLISH

Safety Instructions 7

WARNING

This digital video pet monitor is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User's Guide, safe to use. Therefore, always read the instructions in this User's Guide carefully before using the device.

• Adult assembly is required. Keep small parts away from children and pet(s) when assembling.

• This product is not a toy. Do not allow children or pet(s) to play with it.

• This digital video pet monitor is not a substitute for responsible supervision and interaction.

• Keep this User's Guide for future reference.

• Keep the cords out of reach of children and pet(s).

• Do not cover the digital video pet monitor with a towel or blanket.

• Never use extension cords with power adapters. Only use the power adapters provided.

• Test this monitor and all its functions so that you are familiar with it prior to actual use.

• Do not use the digital video pet monitor near water.

• Do not install the digital video pet monitor near a heat source.

• Only use the chargers and power adapters provided. Do not use other chargers or power adapters as this may damage the device and battery pack.

• Only insert a battery pack of the same type.

• Do not touch the plug contacts with sharp or metal objects.

CAUTION

There is a risk of explosion if battery is replaced by an incorrect type.

Please dispose of used batteries according to the instructions.

8 Safety Instructions

Important instructions:

• Read and Follow Instructions - Please read all the safety and operating instructions before operating the product. Follow all operating instructions.

• Retain Instructions - The safety and operating instructions should be retained for future reference.

• Heed Warnings - Comply with all warnings on the product and in the operating instructions.

• Polarisation - Do not defeat the safety purpose of the polarised or grounding-type plug. A polarised plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the supplied plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

• Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your location, consult your camera dealer or local power company. For products intended to operate from battery power, or other sources, please refer to the operating instructions

• Overloading - Do not overload wall outlets or extension cords as this can result in the risk of fire or electric shock. Overloaded AC outlets, extension cords, frayed power cords, damaged or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire hazard. Periodically examine the cord, and if its appearance indicates damage or deteriorated insulation, have it replaced by your service technician.

• Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

ENGLISH

Safety Instructions 9

• Surge Protectors - It is highly recommended that the camera equipment be connected to a surge protector. Doing so will protect the equipment from damage caused by power surges. Surge protectors should bear the UL listing mark or CSA certification mark.

• Uninterruptible Power Supplies (UPS) - Because this product is designed for continuous, 24/7 operation, it is recommended that you connect the product to an uninterruptible power supply. An uninterruptible power supply has an internal battery that will keep the product running in the event of a power outage. Uninterruptible power supplies should bear the UL listing mark or CSA certification mark. CAUTION: Maintain electrical safety. Power line operated equipment or accessories connected to this product should bear the UL listing mark or CSA certification mark on the accessory itself and should not be modified so as to defeat the safety features. This will help avoid any potential hazard from electrical shock or fire. If in doubt, contact qualified service personnel.

• Ventilation - Slots and openings on the case are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the camera equipment on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided and the product manufacturer's instructions have been followed.

• Attachments - Do not use attachments unless recommended by the product manufacturer, as they may cause a hazard.

• Water and Moisture - Do not use receivers or video monitors near water - for example, near a bath tub, sink or laundry tub, in a wet basement, near a swimming pool, etc.

• Heat - The product should be located away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

10 Safety Instructions
