If you received your Sprint PCS Phone
purchased it at a Sprint PCS Center, your phone may already be
activated. If so, it simply needs to be unlocked before you begin
using it. See the next page for help unlocking your phone.
Activating Your Phone
If your phone isn’t pre-activated, the fastest way to get activated
is to call from your new Sprint PCS Phone.
in the mail or
Charge
1.
Battery
Turn ON
2.
Phone
Call
3.
Sprint PCS
Fully charge your battery. See page 14 for
help installing and charging batteries.
Press ¡ to turn the phone ON.
Press «, ¤, ª while in a Sprint PCS
Service Area. You will be connected to a
Sprint PCS Customer Advocate who will
guide you through the activation process.
In Southern California, call 1-888-PCS-6699
from any phone other than your
Sprint PCS Phone.
You can also reach Sprint PCS Customer Care from any other
phone by calling 1-888-715-4588 (in Southern California, call
1-888-PCS-6699).
Please turn the page for more important information.
1
First Things First
What you should know before you call:
•
This call typically takes about 30 minutes, but may take
longer at peak times.
•
Your Sprint PCS Phone will be ready for use about an hour
after the call is completed.
What you should have handy:
•
Your new Sprint PCS Phone
•
The original packaging for your new phone
•
Your billing address
•
Your Social Security number or Tax ID number
•
Your driver’s license number
•
Pen and paper to write down your new Sprint PCS
Phone Number
During this call, a Sprint PCS Customer Advocate will help you
select your Sprint PCS Service Plan and will request billing
information. Once you’ve made all your selections, they’ll guide
you through the activation process.
2
First Things First
Unlocking Your Phone
Just follow these simple steps to unlock your phone:
Turn ON
1.
Phone
Enter Code
2.
Press ¡ to turn the phone ON.
Enter your four-digit code.
If you don’t remember your code, try using the last four digits of
your Sprint PCS Phone Number or the last four digits of your
Social Security number or Tax ID number. If that doesn’t work,
take your phone to the nearest Sprint PCS Center for assistance.
One More Important Detail
Our services are provided to you under certain terms and
conditions – all of which are listed in the brochure included
in the box your phone came in. Please take a moment to
read them.
Only Sprint PCS built a 100% digital, 100% PCS nationwide
network from the ground up for a new level of clarity. We’ve built
our network to give you what we believe you really want from a
wireless phone: clear sound, private conversations and timesaving features. But Sprint Personal Communication Services
™
also has the potential to do something more far-reaching–
simplify your life. Our advanced technology is designed to grow
with your communications needs so that one day you will be
™
able to rely entirely on your Sprint PCS Phone
to stay in touch.
This guide will introduce you to our technology and the Digital
®
phone, through easy-to-follow instructions. For
StarTAC
additional help, just stop by any Sprint PCS Center or call Sprint
PCS Customer Care.
Sprint PCS Customer Care
Sprint PCS Customer Advocates will answer 24 hours a day and
will be happy to assist you.
•
Calling with your new Sprint PCS Phone:
Press «, ¤,
In Southern California,
«, fl
press
•
Calling from any other phone:
Call 1-888-211-4PCS (4727).
In Southern California,
call 1-800-455-4551.
ª
.
,
⁄, ⁄, ª
.
Thank you for choosing Sprint PCS!
6
Guide Overview
We’ve designed this guide to take you step-by-step through each
feature of your new Sprint PCS Phone. We’ll show you what key
to press and what happens when you press it. Follow along,
chapter-by-chapter, and you’ll find it’s as easy as 1-2-3.
Getting Started
Once the box is open, this section will show you where to begin.
We will explain what came with your new phone and show you
how to use the battery. Turn to page 12 to get started.
The Basics
What do all those buttons and lights mean? How do I make my
first phone call? In this section, we’ll answer those questions and
teach you everything necessary to start using your Sprint PCS
Phone. Begin learning “The Basics” on page 24.
Using Memory
Read “Using Memory,” beginning on page 40, and we will
explain how to make the most of your new phone’s internal
Phone Book. You will save time with dialing shortcuts and
memory features that make it easy to place quick calls.
Using Messaging
This Sprint PCS Phone supports optional messaging services,
like Caller ID, which allows you to see who is calling before you
answer. It can even receive alphanumeric messages just like a
pager and tell you when you have voicemail.
begin “Using Messaging.”
The Works
When you are ready to learn the advanced features of your new
phone, turn to page 60 for “The Works.” We will explain
everything from navigating the menu system to electronically
locking your phone.
Let us show you what your Sprint PCS Phone can do!
May not be available with some Service Plans.
*
*
Turn to page 52 to
7
Exposure
to Radio
Frequency
Signals
Antenna
Care
Phone
Operation
Safety Information
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for hand-held
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies:
ANSI C95.1 (1992)
•
NCRP Report 86 (1986)*
•
ICNIRP (1996)*
•
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. For example, over
120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available
body of research to develop the ANSI Standard (C95.1).
The design of your phone complies with the FCC guidelines (and
those standards).
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could
damage the phone and may violate FCC regulations.
Normal Position:
Hold the phone as you would any other telephone, with the antenna
pointed up and over your shoulder.
Tips on Efficient Operation:
For your phone to operate most efficiently:
•
Extend your antenna fully.
•
Do not touch the antenna unnecessarily when the phone is in use.
Contact with the antenna affects call quality and may cause the
phone to operate at a higher power level than otherwise needed.
*
American National Standards Institute; National Council on Radiation Protection
*
and Measurements; International Commission on Non-Ionizing Radiation Protection
8
Safety Information
Caution:
All batteries can cause property damage, injury or burns if
a conductive material, such as jewelry, keys or beaded chains,
touches exposed terminals. The material may complete an electrical
circuit and become quite hot. To protect against such unwanted
current drain, exercise care in handling any charged battery,
particularly when placing it inside your pocket, purse or other
container with metal objects. When the battery is detached from the
phone: your battery is packed with a protective cover; please use this
cover for storing your battery when not in use.
Check the laws and regulations on the use of wireless telephones in
the areas where you drive. Always obey them. Also, if using your
phone while driving, please:
•
Give full attention to driving–driving safely is your first responsibility;
•
Use hands-free operation, if available;
•
Pull off the road and park before making or answering a call if
driving conditions so require.
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against
the RF signals from your phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and recommendations
of Wireless Technology Research.
Persons with pacemakers:
•
Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
•
Should not carry the phone in a breast pocket;
•
Should use the ear opposite the pacemaker to minimize the potential for interference.
•
If you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
Batteries
Driving
Electronic
Devices
9
Aircraft
Safety Information
Hearing Aids
Some digital wireless phones may interfere with some hearing aids.
In the event of such interference, you may want to consult your
hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to external
RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer
or its representative regarding your vehicle. You should also consult
the manufacturer of any equipment that has been added to your
vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
FCC regulations prohibit using your phone while in the air. Switch
OFF your phone before boarding an aircraft.
10
Safety Information
To avoid interfering with blasting operations, turn your phone OFF
when in a “blasting area” or in areas posted: “Turn off two-way
radio.” Obey all signs and instructions.
Turn your phone OFF when in any area with a potentially explosive
atmosphere, and obey all signs and instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily injury or
even death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gasoline
stations; below deck on boats; fuel or chemical transfer or storage
facilities; areas where fuel odors are present, i.e. if a gas/propane
leak occurs in a car or home; areas where the air contains
chemicals or particles, such as grain, dust, or metal powders; and
any other area where you would normally be advised to turn off
your vehicle engine.
Blasting
Areas
Potentially
Explosive
Atmospheres
An air bag inflates with great force. DO NOT place objects, including
both installed or portable wireless equipment, in the area over the
air bag or in the air bag deployment area. If in-vehicle wireless
equipment is improperly installed and the air bag inflates, serious
injury could result.
Your Sprint PCS Phone is designed for excellent durability under
normal use conditions. Protect your Sprint PCS Phone from water
damage that could result from spills or excessive exposure to rain.
Never submerge your phone.
Cleaning of this product should only be done with a damp cloth.
The use of chemical cleaners may harm the finish and integrity of
the radio housing and is not recommended.
Vehicles
Equipped
with Air
Bags
Equipment
Care
Cleaning
the Phone
11
Getting Started
Package Content Options
This Sprint PCS Phone™ comes equipped with a standard battery
and an AC Adapter Charger to get you up and running. An
exciting line of accessory options, now smaller and lighter than
ever, can customize your wireless package for maximum
performance and portability.
12
07/07/98
Digital
def
33
menu
abc
22
11
mute
lock
mno
66
batt
jkl
55
ghi
44
vib
wxyz
99
v
tu
88
pqrs
77
opr
00
TALK
STO CLR
RCL
FCNEND
Sprint PCS Phone
Auxiliary Battery
with Battery Cover
Slim Battery with
Battery Cover
Extra Capacity Battery
with Battery Cover
Package Content Options
Holster
Cigarette Lighter
Adapter
AC Adapter
Charger
Getting Started
Headset
Dual-Slot Desktop Charging Base
(AC Adapter Charger required)
Your phone and accessories may not look exactly as pictured.
13
Introduction to Batteries
Each battery is shipped in an uncharged state with a protective
cover on it. Before you can use your Sprint PCS Phone, you will
need to remove the cover from the battery and charge it.
Battery Covers
It is a good idea to save the protective cover to store and carry the
battery when not in use. The cover prevents objects from
touching the battery terminals, thereby reducing the risk of
injury or damage from a short circuit.
Removing the Main Battery Cover
14
1.
2.
Press In
Latch
Remove
Battery
Press in the release latch.
Rotate the batter upward and lift it out of
the cover.
2.
1.
Attaching the Main Battery Cover
1.
2.
Lower
Side
Click
Latch
Lower the side, opposite the release latch,
into the cover.
Drop the side with the release latch down
until the latch clicks.
1.
Release Latch
2.
Introduction to Batteries
Removing the Auxiliary Battery Cover
Getting Started
Dislodge
1.
Cover
Hold the auxiliary battery securely with one
hand. With your other hand’s thumb, push up
on the bottom of the cover.
2.
Remove
Battery
Continue to push up until the cover slides free
of the pins on the bottom of the battery and
swing the cover outward.
2.
1.
Attaching the Auxiliary Battery Cover
1.
2.
Insert
Point
Secure
Cover
Slide the cover’s narrow end into the small
grooved hook on the top of the auxiliary battery.
Push the cover firmly so the base slides past
the pins on the auxiliary battery, and release.
1.
Hook
Pins
2.
15
Installing Batteries
Main Battery Installation
To install a battery:
Tip:
If you have a
charged auxiliary
battery attached
to your phone,
you can remove
and change your
main battery at
any time – even
during a call.
1.
2.
Insert
Toe
Snap
Heel
Place the side of the battery opposite the
release latch into the compartment.
1.
Press the side with the release latch down
until you hear it click into place.
Main Battery Removal
To remove a battery:
1.
2.
Turn OFF
Phone
Remove
Battery
If another battery is not attached, press and
¡ to turn your phone OFF.
hold
Pull the release latch back toward the battery
and lift the battery out.
2.
Release Latch
16
Installing Batteries
Auxiliary Battery Installation
The auxiliary battery clips onto the back of your phone.
Place
1.
Hook
Pull
2.
Battery
Down
Release
3.
Battery
Auxiliary Battery Removal
To remove the auxiliary battery:
Pull
1.
Battery
Down
Remove
2.
Battery
Place the hook located on the narrow end of
the battery into the slot on the back of the
phone.
Pull the battery down and slide the battery
pegs over the bottom of the phone.
Once the battery clears the bottom of the
phone, release it. Make sure that the pegs fit
securely into place.
1.
2.
3.
Pull the battery down until the pegs come
free, and pull the base away from the phone.
Lift the battery’s hook out of the slot on the
back of the phone.
2.
1.
Getting Started
Tip:
If you have a
charged main
battery attached
to your phone,
you can remove
and change your
auxiliary battery
at any time – even
during a call.
17
Charging Batteries
77
pq
Using the Internal Charger
There is a battery charger built right into your phone. To make
use of the internal charger, you will need one of the two
available adapters, either an AC Adapter Charger or a cigarette
lighter adapter.
Keep in mind: When the internal charger is in use and the
phone is ON, you can still place and receive calls. However,
talking on the phone requires energy, so your phone may not
charge while the call is in progress.
*
18
1.
Attach
Adapter
to Phone
Plug the AC Adapter Charger or cigarette
lighter adapter into the accessory connector
on the bottom of your phone as shown, with
the release tab facing up.
2.
Plug In
Adapter
Plug the adapter into the appropriate
power source.
opr
00
TALK
STO CLR
RCL
FCNEND
PUSH
Keep in mind: In some cars, the ignition must be ON to use
the cigarette lighter.
Check with your local Sprint PCS Center for availability of the adapters.
*
Charging Batteries
The Battery Indicator
In the upper right corner of your Sprint PCS Phone’s display,
there is a battery indicator filled with three segments. The more
segments you see, the greater the charge.
• The border of the battery icon will flash during charging.
• When both batteries are fully charged, the battery icon will
stop flashing and become solid.
Getting Started
High
Battery Storage and Disposal
Low
To prolong the life of batteries, avoid exposing them to
temperatures below -10°C (14°F) or above 45°C (113°F). It is a
good idea to take your phone with you when you leave your car.
Never dispose of batteries in fire.
Caution: To prevent injuries or burns, do not allow metal
objects to contact or short circuit the battery terminals.
Expert Performance (E•P®)Charging System
The E•P system enables your phone’s built-in charger to
communicate with installed batteries and tailor its charging
cycle to optimize performance. If you see
Invalid Battery
when you power up the phone, the built-in charger is not able to
communicate with the battery and cannot charge it. There are
several possible reasons for this message. The most likely one is
that the battery is not a Motorola original and it does not have
the appropriate E•P technology. We recommend that you use
only Motorola original batteries and accessories and that you
store your batteries in their protective covers when not in use.
19
Charging Batteries
Using the Dual-Slot Desktop Charging Base
The Dual-Slot Desktop Charging Base’s front pocket can charge
batteries while they are attached to your Sprint PCS Phone, and
the rear pocket can charge batteries separately.
If you have a Dual-Slot Desktop Charging Base:
20
1.
Attach
Adapter
Plug the AC Adapter Charger into the back
of the charging base, with the release tab
facing up.
Plug In
2.
Adapter
Insert
3.
Phone
Insert
&
Battery
Front Pocket
Plug the other end of the AC Adapter Charger
into a wall socket.
Insert the phone into the front pocket with a
main and/or auxiliary battery attached.
If you like, insert a main or auxiliary battery
into the rear pocket.
H
S
U
P
Rear Pocket
Note: If two or three batteries are loaded in the charging base,
the batteries will charge one at a time. The main battery
attached to the phone will charge first, the attached auxiliary
second, and the battery in the rear pocket last.
Charging Batteries
Dual-Slot Desktop Charging Base Indicators
The three LED indicators on the left front of the Dual-Slot
Desktop Charging Base let you know the current state of any
charging batteries. The first light provides information on the
main battery attached to the phone, the second on the attached
auxiliary battery, and the third on any battery loaded in the rear
pocket.
• Red means the battery is charging.
• Flashing yellow means the battery is waiting to be charged.
• Green means the battery is charged within 90% of its capacity
and can be used. An additional hour of charging will bring
your battery up to 100% capacity.
• Flashing red means the battery is damaged and cannot be
charged.
Dual-Slot Desktop Charging Base Times
The time it takes for your battery to obtain a full charge is
affected by a variety of factors, including:
• Temperature Batteries should be at or near room tempera-
ture when charging. To prolong battery life and charge
capacity, avoid exposing your batteries to temperatures below
-10°C (14°F) or above 45°C (113°F). It is a good idea to take
your phone with you when you leave your car.
• Inactivity New batteries, or batteries that have been stored
for long periods of time, may not charge properly. In these
instances, the battery requires an overnight charge.
• Extended Usage Over extended periods of time, batteries
gradually wear down and require longer charging times.
This is normal. If you charge your battery regularly and
notice a decrease in talk time or an increase in charging
time, then it is probably time to purchase a new battery.
Getting Started
21
Sprint PCS Phone Overview
Function Keys
¡
Turns your Sprint PCS Phone ON and OFF.
ø
Opens messaging menus.
Acts as a “shift” key to access the secondary
ƒ
functions of other keys.
‰
Recalls phone numbers from memory.
¬
Stores phone numbers into memory.
Ç
Clears characters from the screen.
º
Ends phone calls and exits the menu.
ª
Places or answers calls.
Can be used to scroll through memory entries
«
»
and menu features.
Alphanumeric Display Displays your input from the keypad,
information recalled from memory, and other messages.
Microphone Positioned for convenient conversation.
Retractable Antenna Extend for best performance.
Earpiece Ultra-compact phone speaker.
Headset Jack Provides the connection for an optional headset.
Accessory Connector Provides the connection for an
external power supply.
qq
qq
Volume Keys Represented in this manual by
keys adjust keypad, earpiece and ringer volume. They also scroll
up and down through memory locations and menu features.
and ZZZZ, these
22
Using the Smart Button
Easily recognized in this User’s Guide by AAAA and in your Sprint
PCS Phone’s display by
variety of functions at your fingertip.
The Smart Button
Use the Smart Button’s fingertip convenience for:
Opening the Quick Menu
Press AAAA when your phone is idle to display a menu containing
shortcuts to your phone’s most popular features. See page 38.
Opening Your Phone Book
Press AAAA twice to open the Phone Book with your names and
numbers. Turn to page 44 in “Using Memory” to learn more.
Entering the Menu System
Press ƒ then press AA
See page 60 for information on navigating the menu system.
Selecting Items in the Menu
The primary use of the Smart Button is to select. Whenever the
phone offers you a choice, such as setting a ringer style, press
to select. You will see:
Turning Features ON and OFF
Press AAAA to toggle ON and OFF many menu features, like the call
timers (pg. 70). You will see:
Placing and Ending Calls
Press & hold AAAA to place a call when the number you want to
call is on the display. Press & hold
page 30 for information on placing and ending calls.
§ – the handy Smart Button puts a
07/07/98
menu
22
11
lock
AA
to enter your phone’s menu system.
Press § to Select.
Press § to Toggle.
AA
AA
again to end a call. See
Digital
33
defabc
mute
mno
66
AA
AA
Getting Started
23
The Basics
The next few pages will introduce you to the basic features of
your Sprint PCS Phone. In the chapters that follow, we will
explain every one of your phone’s features, including storing
names and numbers, using the call timers, locking the phone,
and more.
Turning Your
Sprint PCS Phone On
Follow these steps to turn your phone ON:
24
Extend
1.
Antenna
Open
2.
Phone
Turn ON
3.
Phone
What you will see:
Extend the antenna completely for best
performance.
Open the phone to expose the keypad.
Press ¡ once to turn the phone ON.
Each time you turn your phone ON, it performs a short self-test
to make sure it is operational and then it scans for service. While
the phone scans, the display reads:
Turning Your
Sprint PCS Phone On
CDMA Digital
When your phone finds the Sprint PCS Network, you will see the
time and date, the icon, and either
personalizable banner (if programmed).
Standby Mode
To conserve energy, your phone enters standby mode and turns
off the backlight when you have not touched a key for a few
seconds. The backlight will come back on as soon you press a
key or open the phone. If you like, you can choose how long the
backlight remains ON. See page 98.
Turning Your Phone OFF
Sprint PCS or the
07/07/98
Basics
Turn OFF
Phone
Press and hold ¡ to turn the phone OFF.
25
Strong
Weak
High
Low
Reading the Indicators
231
4
10
56789
Signal Strength (1)
Displays the strength of the connection between your phone and
the digital network.
Clock (2)
When your phone is on the Sprint PCS Network, the display
shows the current time and date. Wherever you are, you will have
the correct local time. You can set your clock for 12- or 24-hour
format. See page 99 for more information.
Battery Level (3)
The three bar segments on the phone’s Battery Level Indicator
show the amount of charge remaining in your battery. The more
bar segments you see, the higher the charge. If your battery is
low, the phone alerts you in three ways:
• No bar segments on the indicator will be highlighted.
• Low Battery will appear on your display.
• A hi-lo tone will sound periodically.
If you ignore these warnings, the phone will automatically turn
itself OFF when the battery is exhausted. At this point, you
should charge the battery or insert a new battery.
Digital (4)
Indicates you are receiving a digital signal.
26
Reading the Indicators
In Use (5)
Appears when a call is in progress.
Roam (6)
Lights up when your phone accesses a digital wireless
service outside of the Sprint PCS Network. When you leave a
Sprint PCS Service Area, your phone attempts to roam (seeks
another PCS/CDMA wireless system).
No Service (7)
Appears when calls cannot be placed or received from your
location.
Caller ID/Message (8)
Appears when you receive a Caller ID, alphanumeric page, or
text message. It will disappear after you have viewed the Caller
ID or read the Message.
Voicemail (9)
Indicates that you have received a voicemail message in
your voicemail box. It will disappear after you have listened
to the message.
When you select one of the VibraCall
page 79), the following indicators appear in the display:
VibraCall On (10)
Indicates that your phone’s ringer is turned OFF and the
VibraCall Alert is ON.
Silent Mode (10)
Indicates that all of your phone’s tones are silenced and the
VibraCall Alert is ON.
Vibrate Then Ring (10)
Indicates that both the ringer and VibraCall Alert are ON.
®
Alert combinations (see
Basics
27
Reading the Indicators
Detailed Battery Level Reading
Press ƒ then press ›.
The bar graph in the display represents the battery level. The
higher the graph, the closer the battery is to full charge.
Full ChargeLow Charge
If you are using an auxiliary battery with the main battery, the
display will indicate which one is in use.
Important:
cigarette lighter adapter for example–you will see:
If the phone is being powered externally–from the
28
Reading the Indicators
Service Light
The Service Light is on top of your Sprint PCS Phone and lights
up when your phone is ON. The color it flashes depends on your
phone’s current state of service. Please read the chart below to
learn how to understand your phone’s state of service at a
glance.
Service Light
Basics
Red & Green,
alternating
Green, flashing
Red, flashing
Yellow, flashing slow
Yellow, flashing fast
If you would like to increase your phone’s standby-time,
Note:
Incoming call or message
In Service: Sprint PCS system
No Service
Roaming
Roaming: non-home type system
you can turn the Service Light OFF. See page 99.
29
Loading...
+ 89 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
