APPLICANT MOTOROLA INC. FCC ID: IHDP56KZ1

INSTRUCTION MANUAL

A representative version of the user's manual follows:

Exhibit 8

FOCUS ON WHAT MATTERS.

MOTOROLA ZEPPELIN™ with MOTOBLUR™

Congratulations

MOTOROLA ZEPPELIN with MOTOBLUR

MOTOROLA ZEPPELIN with MOTOBLUR is the first touch tablet with social skills.

• Streamlined Messaging: Sync messages, feeds and

updates from your office to today’s most popular social sites.

• Contacts Connected: Contact updates are delivered

automatically without your raising a finger.

• More Web: The enhanced browser lets you see

more of the Web, while pinch-and-zoom and front-nav-pad features give you more control of it.

• Music Connectivity: The music player directly

connects online for instant music, such as Internet radio; Widgets and applications let you share preferences and see lyrics.

Caution: Before assembling, charging or using your

phone for the first time, please read the Safety, Regulatory, & Legal Information provided with your

phone. Once your phone is up and running, press Menu >

regulatory

Settings

to read the full information.

About phone

Safety &

More information

On your phone—>

On any phone—Call 1-800-734-5870.

On your computer—Go to

www.motorola.com/support/MB501

After you create a MOTOBLUR account, you can also log in and find help with MOTOBLUR: www.motorola.com/mymotoblur

So, whether you want to talk, read, watch, or play, we can help.

My Account

1Congratulations

Your phone

Trevor Gilley

Black turtleneck and a beret, and he thought I was serious?

5 min ago

298 minutes away from cake.

15 min ago

Browser

Vanessa Eskridge

Ultra secret double-agent party agenda

London

Partly Sunny

11:35

Market

Power Key

Press to put the display to sleep, or hold to turn off.

OMTP 3.5mm Headset Jack

Home Key

Back Key

Microphone

Key

Micro USB

Connector

Charge or

connect to PC.

Notification

LED

On=Charged

Flashing=

Charging or

notification

Volume Keys

To u chscreen

Camera Key

Menu Key

If you use a wired headset with built-in microphone, you'll need to use an OMTP (Open Mobile Terminal Platform) compliant headset such as the Motorola OH15. Look for the OMTP logo shown here, or go to www.motorola.com/wired for additional information.

11:35

Enter message here

Delete

Return

Space

Symbols

Shift

When you turn your phone, the home screen adjusts for you.

To open the display keypad, touch a text field, or press and hold Menu

To close the keypad, press Back

Tip: To change the Notification LED, press Menu >

Settings

Display & security

Notification LED

. To change your home screen, see “Set up & manage your home screen” on page 7.

arket

2 Your phone

Note: Your phone might look a little different.

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

MOTOBLUR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

myFaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Contacts & Mobile Backup . . . . . . . . . . . . . . . . . . . 21

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Voicemail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Personalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Camera & video recorder . . . . . . . . . . . . . . . . . . . . 31

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Web browsing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Android Market™ . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Voice Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Bluetooth® wireless . . . . . . . . . . . . . . . . . . . . . . . . 47

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 58

Let’s go

let’s get you up and running

Assemble & charge

1 cover off 2 SIM in

3 battery in 4 microSD in

5 cover on 6 charg e u p

(already done)

3Contents

Caution: Please read the battery use and safety text in

MOTOBLUR ID:

Enter email address

Your name:

e.g. John Smith

Password:

Password

NextBack

Creating your

MOTOBLUR account...

acebook

tter

FMPi

the Safety, Regulatory & Legal guide provided with your phone.

Tip: To save battery life, see “Battery tips” on page 13.

Set up & go

Create or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on page 14. Registration is secure, and should only take a few minutes:

1 Turn on.

2 Select a language.

Tip: For product support, you

can touch and dial 611.

Emergency Call

3 Register or log in.

If you have not created a MOTOBLUR account, you’ll need to register: Enter your name, your current email address (where MOTOBLUR can send account information), and a new

Tip: Touch a text field to

open the touchscreen

MOTOBLUR account password.

keypad.

4 Add your accounts. To add an account,

touch it and enter the

ace

ast

Photobucke

cas

user name or email and password that you set up on that account.

Tip: For more, or to

add accounts anytime, go to “Add accounts” on page 15.

4 Let’s go

After you sign in, your phone imports your contacts from your T-Mobile

Mobile Backup

account, or your SIM card if you haven’t used

Backup

. To see your contacts, touch

Mobile

Contacts

Tip: To manually import contacts from a SIM card,

Contacts

touch

Settings

Import from SIM card

, then press Menu >

. TouchOK to confirm.

Turn it on & off

To turn on your phone, press Power (on the right side).

To turn off your phone, press and hold Power , then touch

off

in the menu that opens.

Power

Wi-Fi connect

If you want to use a Wi-Fi network for even faster Internet access, press Menu >

Wireless controls

Wi-Fi settings

search for and connect to wireless networks. There’s more in “Wi-Fi” on page 48.

Settings

. Touch

Wi-Fi

Cool content & more

Browse and download thousands of the coolest apps on the planet from Android. On top of that, you get a full HTML browser, so you can surf in style.

Download new apps with “Android Market™” on page 44. Download music with “Get music online” on

card installed—you can load it up with photos, videos, and music from your computer using “Copy files to your card” on page 50.

Note: Do not remove your memory card while your

phone is using it or writing files on it.

Security

Your contacts are backed-up on MOTOBLUR, so don’t worry. Even if you lose your phone, MOTOBLUR can help you find it or wipe it. And when you get your next MOTOBLUR product, your stored info makes it a snap to set up with just a username and password.

Of course, it doesn't stop there. There are plenty of ways to protect your phone and your information, in “Security” on page 54.

5Let’s go

page 36. Your phone comes with a microSD memory

Basics

Trevor Gilley

Black turtleneck and a beret, and he thought I was serious?

5 min ago

298 minutes away from cake.

15 min ago

Browser

Vanessa Eskridge

Ultra secret double-agent party agenda

London

Partly Sunny

11:35

Market

Status Indicators

Your Online Status

Tap to change your status.

Shortcuts

Tap to open.

Open the main menu.

Widgets

Tap to open, or tap & hold to move or delete.

Flick left or right to open more panels of widgets.

Notifications

Flick this bar down to see details.

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in one place. It’s what you see when you turn on the phone or press Home from a menu. It’s basically like this:

Search

To search, use a Search widget on your home screen or press Search .

Type, then touch the icon for

Google Search

Tip: In your app menu or

hold Menu to open the touchscreen keypad, then type an entry name to find it.

a text search.

Touch the icon, then speak for a voice search.

Contacts

, you can press and

6 Basics

Phone status & notifications

At the top of the screen, icons on the left notify you about new messages or events (flick the bar down for details). Icons on the right tell you about phone status:

Bluetooth® active network (full signal)

GPS active network (roaming)

Wi-Fi active GPRS (fast data)

downloading EDGE (faster data)

vibrate 3G (fastest data)

silent flight mode

11:35

mute call battery (charging)

speakerphone active battery (full charge)

Google™ sync

alarm set

active

Tip: To see today’s date, touch and hold the status

indicators.

Set up & manage your home screen

On your home screen, shortcuts are icons that open your favorite apps, Web bookmarks, contacts, Gmail labels, or music playlists. Widgets show you news, weather, messages, and other updates.

Flick the home screen left or right to open other panels of shortcuts and widgets.

• To open something, touch it. Press Home to

return to the home screen.

To change a widget’s settings, open it and then press Menu >

You can find details about the settings for

Happenings

(“Set up messaging” on page 25), on page 35), or on page 15).

Setup

(“Add accounts” on page 15),

Social Status

Music

(“Update your status”

Messages

(“Music”

• To add something or change your wallpaper, touch

and hold an empty spot until you see the

Home screen

menu.

Add to

Tip: You can add shortcuts to your favorite contacts

and apps, or add a folder to organize your shortcuts.

• To move or delete something, touch and hold it

until you feel a vibration, then drag it to another spot, another panel, or the trash at the bottom of the screen.

Touch tips

Here are some tips on how to navigate around your phone.

Touch

To choose an icon or option, touch it. Try it: In the home screen, touch the icon for

Contacts

7Basics

Touch & hold

To open special options, touch and hold an icon or other item. Try it: In the home screen, touch

Contacts

, then touch and hold a contact to open options.

Drag

To scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, touch

Contacts

your

Contacts

, then drag

list up or

down.

Tip: When you drag or flick

a list, a scroll bar appears on the right. Drag the scroll

Contacts

Alex Pico

View contact

Call

Send Text Message

Delete contact

Contacts

Alex Pico

Dan Smith

Kate Shunney

Keith Zang

Luke Carmody

Mariana Bukvic

StatusHistory A-Z

bar to move the list to a letter A - Z.

Flick

To scroll through a list or move quickly, flick across the touchscreen (drag quickly and release).

8 Basics

Tip: When you flick a long list, touch the screen to stop

it from scrolling.

Key tips

Menu, home, search, & back

Press Home to close any menu or app and return to the home screen. Press and hold Home to show the last few apps you used, then touch an app to

Menu Key

Search Key

open it. In the home screen, press Home to open or close the app menu.

Press Menu to open menu options, or Back to go back.

Press Search to open a Web search.

Back

Key

Home

Key

TinyTouch pad

Sauce Vin Blanc Albufera Allemande Bercy Poulette Aurora Hungarian Sauce ravigote Normandy Suprême Venetian

Bercy

Volume

Keys

You can use the TinyTouch pad to select small items in the display (like a small link on a Web page), or control a game without blocking your view. Just flick across the pad to scroll or move, and press the pad to select.

Sleep & wake up

To save your battery, prevent accidental touches, or when you want to wipe smudges off your touchscreen, put the touchscreen to sleep by pressing Power . To wake up the touchscreen, just press Power , Menu , Search , Home , or Back .

To change how long your phone waits before the screen goes to sleep automatically, press Menu >

Settings

Tip: To make the screen lock when it goes to sleep,

use “Screen lock” on page 54.

Display & security

Screen timeout

Power key menu

Press and hold Power to open the menu where you can turn off the phone ( features (

Airplane mode, Bluetooth, Wi-Fi

Power off

), or turn off

, or

GPS

Adjust volume

Press the volume keys to change the ring volume (in the home screen), or the earpiece volume (during a call).

Spin the screen

In many apps, the touchscreen can spin to stay right-side up when you rotate your phone:

Find it: Menu >

Display & security

Settings

Orientation

App menu

The app menu shows you all of your applications. To open it from the home screen, just touch the

app tab or press Home . To close it, touch the tab or press Home again.

Tip: To find an app in the menu, press and hold

Menu to open the touchscreen keypad, then type the app name.

9Basics

Recent apps

Press and hold Home to see the last few apps you used, then touch the app you want. Press Home to return to the home screen.

Text entry

think computer keyboard, now think smaller

Touchscreen keypad

To open the touchscreen keypad, touch a text field or press and hold Menu . To close it, press Back .

Text Entry

Send

Touch to open the touchscreen keypad.

Delete

Smiley

10 Text entry

Shift

Numbers/Symbols

Touch once for numbers, and again for symbols.

Space

Copy, cut, & paste

Let’s meet at Michael’s

Select Menu

Let’s meet at Michael’s

Cut Copy Menu

Let’s meet at Michael’s

Cut Copy Menu

Select Line

Select all

Let’s meet at Michael’s

After you enter text, you can touch it to copy, cut, or paste:

1 Touch a word to open the

menu.

Tip: You can drag the text

editing menu to move it.

Select

Cut

(to select the

Select all

Copy

2 Touch

word), or touch

Select Line

3 Touch

4 Now, go to another

message or text field. Touch and hold the text field, then touch

Text entry settings

When you enter text, your phone automatically corrects or suggests words. To change these settings, press Menu >

• To edit your word suggestion dictionary, touch

dictionary

Paste

Settings

Locale & text

, then:

User

• To change the language and the style for your

touchscreen keypad, touch

Select locale

• To change the sounds, corrections, and other

settings for your touchscreen keypad, touch

keyboard

Android

• To change the automatic correction settings,

Device keyboard

touch

11Text entry

Tips & tricks

a few handy hints

To .. .

Return to the home

screen

Open option

menus

See recent apps Press and hold Home .

See recently dialed numbers

Sleep/wake your

phone

Set lock screen Press Menu >

Tu rn ringer on/off In the home screen, press

Google™ search Press Search .

Google™ search by

voice

Tu rn airplane mode on/off

12 Tips & tricks

Press Home .

Touch and hold an item, or press Menu , to see all of your options.

Dialer

Touch

Recent

To sleep, press Power . To wake, press Menu .

Display & security lock

Settings

Screen

and hold a volume key.

Press and hold Search .

Press and hold Power >

Airplane mode

To...

Tu rn Bluetooth® on/off

Press and hold Power >

Bluetooth

Tu rn Wi-Fi on/off Press and hold Power >

Wi-Fi

Tu rn GPS on/off Press and hold Power >

GPS

Zoom in to select a

Press > link.

link on a web page

Go to the top of a

list

Go to the bottom of

a list

Scroll list up one

screen

Scroll list down

one screen

Open the

touchscreen

Press Alternate > Scroll up.

Press Alternate > Scroll down.

Press Shift > Scroll up.

Press Shift > Scroll down.

Touch a text field, or press and hold Menu .

keypad

Battery tips

Your phone is like a small computer, giving you a lot of information and apps, at 3G speed, with a touch display! Depending on what you use, that can take a lot of power.

To start getting the most out of your battery, press Menu >

Battery Profile

constant data transfer and battery use,

Mode

when your battery is low, or want to set and wireless connections during off-peak hours.

To save even more battery life between charges, you could reduce:

• recording or watching videos, listening to music, or

taking pictures.

• widgets that stream information to your home

screen, like news or weather (“Set up & manage your home screen” on page 7).

• unused online accounts that you registered with

MOTOBLUR (“Remove accounts” on page 15).

• GPS, Wi-Fi, and Bluetooth® use: Press and hold

Power to open the Power key menu, then touch items to turn them off or on.

Settings

. Choose

Battery Profile Options

Battery Manager

Performance Mode

for

Battery Saver

Smart Mode

if you

that limit your data

• Email updates: Touch

Messaging settings Every hour

• Google™ app updates: Menu >

Google Synchronization

• network speed: Menu >

controls

Only

Mobile networks

Messaging

Background data

> Menu >

Get new email

Settings

Select network

Wireless

• network searching: If you are out of coverage, to

keep your phone from looking for networks, press and hold Power to open the Power key menu, then touch

Airplane mode

• display brightness: Menu >

& security

Brightness

• display timeout delay: Menu >

Display & security

> (dimmer setting).

Screen timeout

Settings

> (shorter

Display

setting).

13Tips & tricks

MOTOBLUR

Your MOTOBLUR account

The first time you turned on your phone, you registered for a MOTOBLUR account that manages your messages, contacts, and more (“Set up & go” on page 4). You can log into this account from a computer to upload contacts, reset your password, get help, or even locate your phone: www.motorola.com/mymotoblur

What is MOTOBLUR?

Only MOTOBLUR syncs contacts, posts, feeds, messages, e-mails, photos and much more—from sources like Facebook, Twitter, MySpace, Gmail™, your work e-mail, Picasa, Photobucket—and automatically serves it up just the way you want it. No opening and closing apps and menus, it’s all front and center on your home screen and integrated throughout the entire phone so you can communicate anyway you like.

14 MOTOBLUR

Social networking

my life, your life

About social networking

Every friend-feed, status update, wall post, bulletin and photo upload from today’s most popular social sites is automatically fed to the Happenings widget. Flick through your latest updates and fire back a response on ZEPPELIN’s touchscreen keypad—no apps to open and no menus to dig through, just instant social gratification.

View accounts & update status

Note: Your network or other factors might affect the

speed of widget updates.

View accounts

After you add a social networking account, you can see and respond to friends’ updates with the widget on your home screen. If you don’t see one, set one up in “Set up & manage your home screen” on page 7.

When you touch the update, you can touch to open the full update, then touch the social network’s icon to open its Web site.

Happenings

widget to open an

Update your status

After you add a social networking account, you can update and see your current status in a

Social Status

widget on your home screen.

To update your status, just touch your

Social Status

widget and enter text. If you have more than one account, you can use the pull-down menu to limit which accounts are updated. If you don’t see a

Status

widget, flick your home screen left or right to

Social

check all panels.

Social Status

To add a

1 Touch and hold an empty spot on your home screen

to open the

Widgets

2 Touch

widget:

Add to home screen

Social Status

menu.

. The widget appears in the empty spot, and will show your status the next time your phone updates from the network.

Add accounts

Note: You can add your

or other accounts to your phone. If you don’t have accounts, you can visit their Web sites to set them up.

Find it: >

To sign into your account, use the user name or email and password that you set up on that account (the same as on your computer).

Facebook, MySpace, Twitter

Accounts

Add account

When you sign into social networking accounts, you’ll see your friends and contacts in your your status and updates can appear in

Happenings

and

widgets.

Contacts

list, and

Social Status

Twitter and MySpace messages will always appear

as “read” on your phone, but your phone notifies you when you receive a new message. MySpace marks your messages as “read” online.

For email accounts, see “Set up messaging” on

page 25.

Tip: To download updates faster, use “Wi-Fi” on

page 48.

Remove accounts

Find it: >

Touch and hold an account, then touch to edit it, or touch with its contacts and messages).

Note: You can’t remove your MOTOBLUR or Google™

accounts.

Accounts

Delete account

Open account

to remove it (along

15Social networking

Calls

Alex Pico

Mobile (555) 555-2505

Just found $100 on the street! Drinks on me tonight!

End call

SpeakerMute

Active call ( 00:12 )

Call Timer

Mute

Mute or unmute the call.

End Call

Hang up.

Speakerphone

Turn the speakerphone on or off.

Dial Pad

Open a dial pad, to enter numbers during a call.

it’s good to talk

Quick start: Calls

Find it:

Dialer

123

GHI

16 Calls

Recent Frequent

ABC DEF

JKL

TUVPQRS WXY

Call

Dialer

Speed Dial List

Touch to open and press

Spd Dial

to add or edit.

Delete

Touch to delete a digit you entered.

Frequent Call List

Touch to open, then touch an

entry to call.

MNO

Recent Calls

Touch to open, then touch an entry to call.

Open Your Contacts

Voice Dial

Call

Enter a phone number and touch here to call it.

During a call, press Menu to choose

call

, or

Use Bluetooth

, or to wake up the touchscreen

Hold, New

if it’s dark.

Tip: You can press Home or Back to hide the

Dialer

active call display. To reopen it, touch

Make calls

To make a call, touch

Call

then touch

Dialer

, enter a number,

Tip: To enter the international dialing code, touch and

Slide to Answer

Press Power/Lock button to ignore

End call

SpeakerMute

hold . To add a pause or wait after numbers, press Menu .

Answer calls

To answer a call, drag the right (when your phone is unlocked,

Answer

button).

Answer

is just a touch

End calls

Touch

End call

Note: When you hold your phone

to your ear, the display goes dark

End call

to avoid accidental touches. When you move your phone away from your ear, the display lights up again.

Tip: You can press Home or Back to hide the

active call display. To reopen it, touch

Dialer

Use keypad while on a call

To enter numbers during a call, touch and then touch the dial pad.

Use speed dial

Find it:

Dialer

Spd Dial

• To call a number, touch it.

• To add, edit, or clear entries, press Menu .

Access recent calls

Find it:

• To call a number, touch it.

• To send a text message, create a contact, view a

contact, add the call to speed dial, or other options, touch and hold an entry.

• To filter the list, touch the view name (like

SpeakerMute

at the top.

• To clear the list, press Menu .

Dialer

Recent

All calls

)

Access frequent calls

Find it:

• To call a number, touch it.

• To send a text message, view a contact, add the call

to speed dial, or other options, touch and hold an entry.

Dialer

Frequent

Call forwarding & waiting

You can forward calls all the time, or only when your phone is busy, unanswered, or unreachable (not on the network):

17Calls

Find it: Menu >

Call

forwarding

Settings

Call settings

Call

When you’re on a call and a second call comes in,

waiting

lets you answer it by touching

can turn off

Call waiting

, to send second calls straight

Answer

. You

to your voicemail:

Find it: Menu >

Additional call settings

Call waiting

Call settings

Settings

Restrict outgoing calls

To restrict your phone so that it can only dial a few numbers:

Find it: Menu >

dialing number

• To turn fixed dialing on, touch

Call settings

FDN disabled

Fixed

Settings

• To add or delete the allowed numbers,

Manage FDN list

touch

Find your phone number

Find it: Menu >

Phone number

Settings

About phone

Status

Your caller ID

To hide your number from the people you call, press Menu >

Additional call settings

18 Calls

Settings

Call settings

Caller ID

Call

Use the speakerphone

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

During a call:

Speaker

• To use the speakerphone, touch

• To use a Bluetooth® device, press Menu >

Bluetooth

Use

Mute & hold

During a call:

Mute

• To mute the current call, touch

• To put a call on hold, press Menu >

Hold

Make conference calls

To start a conference call, call the first number. After they answer, press Menu > next number. When the next number answers,

Join

press Menu >

New call

and call the

Use voice dial

Find it:

Say a number, or a name from

Contacts

your

Dialer

TTY mode

Your phone can use an optional teletypewriter (TTY) device, for people who are hard of hearing or have a speech impairment.

1 Plug the TTY device into the phone’s headset

connector.

Settings

2 Press Menu >

Support

and choose a TTY setting.

Call settings

TTY

Emergency calls

Note: Your service provider programs one or more

emergency phone numbers (such as 911 or 112) that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

1 Touch

touch

2 Enter the emergency number.

3 Touch

Note: Your mobile device can use AGPS satellite

signals to help emergency services find you (see “GPS & AGPS” in the Safety, Regulatory & Legal Information booklet).

Dialer

Emergency Call

Call

to call the emergency number.

(if your phone is locked,

myFaves

talk to your five favorite people

Add myFaves contacts

Find it: >

1 Rotate an unassigned circle to the front, and touch

it.

Create new

2 Touch

3 Touch a contact or type a name and phone number.

Add contact

4 Touch

Edit myFaves contacts

You can change a myFaves contact’s time. You can the contact’s calendar month (you’ll see an error if the number change isn’t allowed).

Find it: >

1 Rotate the contact to the front.

2 Press Menu >

3 Type a new name and phone number.

Save contact

4 Touch

Replace myFaves contacts

Find it: >

myFaves

From contacts

myFaves

Edit contact

myFaves

Name

Phone Number

at any

once per

19myFaves

1 Touch the contact’s circle.

2 Press Menu >

Create new

3 Touch

Replace Contact

Get from phonebook

choose the new contact.

Save

4 Touch

Move myFaves contacts

Find it: >

order

1 Rotate the contact to the location.

2 Press Home to save and exit.

myFaves

> Menu >

Change

Call myFaves contacts

Find it: >

1 Touch the contact.

Call

2 Touch

myFaves

Send email messages

Find it: >

1 Touch the contact.

Send email

2 Touch

Note: Make sure you have an email address saved

for this contact.

3 Enter your subject and message.

20 myFaves

myFaves

4 Touch

Send

Send text messages

Find it: >

1 Touch the contact.

Send message

2 Touch

3 Enter your message.

Send

4 Touch

myFaves

Send IM messages

Find it: >

1 Touch the contact.

Send IM

2 Touch

Note: Make sure you have an IM name saved for

this contact.

3 If required, log into your IM application.

4 Enter your message.

Send

5 Touch

myFaves

View activity log

Find it: >

1 Touch the contact.

Activity log

2 Touch

myFaves

Download new icons

Contacts

StatusHistory A-Z

Alex Pico

Mariana Bukvic

Luke Carmody

Dan Smith

Keith Zang

Kate Shunney

Group

Press Menu to choose which group to show (like All, Favorites, or Facebook).

Create Contacts

Views

Touch a list view, or flick the display right or left to show:

History - recently used A-Z - list without status Status - list with status

Contacts List

Touch to view contact information. Touch & hold to edit, delete, and more.

Find it: >

T-Mobile Downloads

Browser

> Menu >

myFaves icons

Bookmarks

Contacts & Mobile Backup

contacts like you’ve never had before

Quick start: Contacts

Find it:

Contacts

Tip: To search the list, press and hold Menu to

open a touchscreen keypad, then type a name. When you flick or drag this list, a scroll bar appears on the right. Drag the scroll bar to move the list faster.

21Contacts & Mobile Backup

About Mobile Backup

Mobile Backup stores your contacts on a secure T-Mobile server, that you can access through MobileLife on my.t-mobile.com.

Mobile Backup gives you peace of mind, knowing your important information will not be lost if their phone is damaged, lost, or stolen, and allows you to avoid the hassle of manually re-entering contacts into a new phone if you upgrade.

Find it: >

Mobile Backup

About MOTOBLUR

When you change one of your automatically updates your MOTOBLUR account online. Also, your phone updates your MOTOBLUR account whenever you change a friend in your social networking accounts.

So, you don’t have to do anything to synchronize your

Contacts

with your other accounts! MOTOBLUR takes

care of it for you.

Contacts

, your phone

Contacts

and

Access contacts

Only MOTOBLUR threads all of your contacts’ information together in a whole new way. Friends photos, status and contact details are automatically updated as they change it on their profiles. In contacts view, MOTOBLUR lets you view all your latest

22 Contacts & Mobile Backup

conversations, emails or texts with them, tweet them a message, comment on photos or even post on their Facebook wall.

Find it:

• To filter the contacts by group (

Contacts

All, Facebook

, and so

on) touch the filter name at the top.

Tip: To change which account provides the pictures

Contacts

for your

Accounts

• To change the list view, touch

A-Z

used),

, from the home screen >

> Menu >

Picture Source

History

(list without status), or

(recently

Status

(list with

status) at the bottom.

• To find a contact, just type the name.

Touch a contact to open their details. To start a call or message, just touch their phone number or other info. You can touch

History, Info

, or

Happenings

the bottom of the screen to see more.

Tip: You can touch a contact’s address to see it on a

Edit

map. To add an address, press Menu >

Create new contacts

Find it:

Contacts

> Menu >

Add contact

Touch a text field to enter the name and details.

Adam Aaronson

Phone

First Last

Add contact

Mobile

Emails

Touch Mobile to choose a different type for this entry.

+ adds another entry.

- removes this entry.

To see more details, flick up.

When you’re finished, press Menu >

Where are contacts saved? Your phone saves new

contacts in its memory, your MOTOBLUR account, and other accounts you select: In touch Menu > get updated. New contacts won’t be on your SIM card, but they will download to any new MOTOBLUR phone when you log into your MOTOBLUR account.

Contacts

Settings

to choose which accounts

Save

Edit contact information

Find it:

1 Touch the contact to open their details.

2 Press Menu >

address, and other details that will be saved on your phone and your MOTOBLUR account.

Where are contacts edited or deleted? Your phone

edits the contacts in its memory, and also updates your MOTOBLUR account. Your changes won’t affect your SIM card.

Contacts

Edit

. You can set a ringer,

Call contacts

Find it:

1 Touch the contact to open their details.

2 Touch their phone number to call them.

Send text messages to contacts

Find it:

1 Touch the contact to open their details.

2 Touch

them.

Contacts

Send Text Message

to open a message to

Link contacts

You might have two maybe a Facebook friend who is also stored on your

Contacts

for the same person,

23Contacts & Mobile Backup

SIM card, or one friend with two email addresses. To combine these two contacts:

Find it:

Contacts

Touch a contact to open it, then press Menu >

Link contact

and touch the second entry. Your

MOTOBLUR account remembers this connection.

Import contacts from SIM

Note: You might have already done this during “Set up

& go” on page 4.

If you need to import the contacts from your SIM card,

Contacts

touch press Menu >

Import from SIM card

, then

Settings

My details

Find it:

details

To edit details, touch them.

Contacts

> Menu >

View my

Groups

You can put your (like “friends,” “family,” or “work”). Then, you can find contacts faster by showing one group at a time.

24 Contacts & Mobile Backup

Contacts

into groups that you create

To create a group in your

Add group

. Enter a group name, then touch

Contacts

members.

To show only one group in your

Contacts

at the top of your screen and choose the

group name.

, press Menu >

Add

Contacts

, touch

to add

Messaging

8:34 PM

Alex Pico

Some guys have all the luck - me... Right now, you’re busy flexing...

Sep 25

Keith Zang

Job It’s only a freelance gig, but it pays...

Sep 25

Kate Shunney

I have so much energy today, I have no IDEA why.

Universal Inbox (4)

Sep 25

Seth Rementer

The cinnamon bun place is right next to the store. It’s like 8 hours...

Create Message

Touch to create a new message, and see a list of your drafts (indicated by the number).

Message List

Touch to open a message. Touch & hold to move, delete, and more.

Check for Messages Now

Message Type

Message Status

Icons indicate: unread urgent has attachments

sometimes it’s best 2 text, or IM, or email . . .

Quick start: Messaging

Find it: >

Tip: To see more messages, flick or drag up.

Set up messaging

To add email accounts, >

account

Messaging

Universal Inbox

Accounts

Add

•

Corporate Sync

is for Microsoft® Exchange server work email accounts, described in “Synchronize with Microsoft® Office Outlook” on page 51.

is for most personal email accounts. For

•

account details, contact the account provider.

Note: While you are using a Wi-Fi network, you

cannot access

Yahoo Mail

accounts. You can still use your browser to see these accounts at mail.yahoo.com

To change your settings, >

Messaging

Menu , then touch:

Manage accounts

•

to change your user name or

password (or server settings, for email).

Edit Universal Inbox

•

show messages in the

Messaging Settings

•

to choose which accounts

Universal Inbox

to set the notification for each account type (along with other preferences, for email).

To get Gmail™ in your Messages widget and

Universal Inbox

account: >

Manage accounts

touch enter your Gmail™ details. If you added your

, you’ll need to add it as an

Messaging

> Menu , then

Add account

and

Google

account too, turn off its email sync to avoid duplicate email notices: >

Accounts

account, and touch the checkmark to turn off

, touch your Google™

Gmail

25Messaging

Tip: For social network accounts, see “Add accounts”

Messaging

on page 15.

Read messages

All your emails, social site messages, and texts are delivered straight to the universal inbox. Catch a glimpse of your latest messages through the live widget, or dive into any account you like, right from one spot.

Find it: >

Messaging

Universal Inbox

To open a message and all of its replies, touch it. Then, you can touch and hold a message or reply to forward it.

Universal Inbox

Note:

shows all of your messages together—text, email, and social networking messages. To show only one type of message, touch a message account type instead of

Universal Inbox

Send messages

Find it: >

Messaging

Tip: To forward a message, touch it to open the

conversation, then touch and hold the message or reply you want to forward.

Format text in emails

When you create an email, you can format your message. To select text for formatting, press and hold Shift , then press Scroll .

New gmail message

To:

Subject:

Font

Send Discard

Bold, Italic, or Underline

Bullet FontSmiley

Choose a message type. Then, enter the recipient and message. In text messages and emails, press Menu to insert pictures or attach other files.

26 Messaging

To change your email signature and default text style,

Settings

Messaging

> Menu >

Font and signature

Messaging

Delete messages

Find it: >

Messaging

Universal Inbox

Touch and hold a message, then touch

Delete

Reply to messages

Find it: >

1 Touch the message to open it.

To forward a text message, touch and hold a message in the conversation, then touch

message

For email, touch to choose a reply or forward option.

2 Enter your response in the text

box at the bottom of the screen.

Messaging

Universal Inbox

Forward

Add attachments

To send a picture or other file in a message, open a new message and press Menu >

Attach Files

When you open a message with an attachment, touch the file name to download it. Then, touch the name again to open it. Some file formats can be converted to HTML for faster viewing, and your phone will show a button that says

Get HTML version

Tip: To send and receive large attachments faster, use

a Wi-Fi connection, in “Wi-Fi” on page 48.

Insert...

To send and receive instant messages, you can use an instant messaging app or your browser.

Find it:

1 Touch the name of your IM provider.

2 Enter your screen name and password.

3 Touch

When you’re signed in, you’ll see a list of your chats and friends. Press Menu to add contacts, create groups, and see other options.

Sign out

To sign out, press Menu >

If you don’t see the name of your IM provider, you can

Browser

use your Web browser. >

Menu >

, then enter your provider’s Web site.

Once you’re there, follow the link to sign in.

Note: Your IM options depend on your IM provider.

Audio postcards

Audio postcards are a great way to show (and tell) your whole crowd what you’re up to—take a photo and add a personalized voice message before sending.

Find it: >

1 Press Menu >

2 Touch the postcard frame you want.

Audio postcard

Choose Frame

27Messaging

3 Center the image you want in the frame, then press

Camera on the side of your phone.

4 Touch

Add Voice

. Touch to start recording, and

to stop.

Send

5 Touch

6 Enter recipients, then touch

Send

to send the

postcard.

28 Voicemail

Voicemail

never miss a message

Access and listen to voicemail

When you have a new voicemail, shows at the top of your screen. To hear the voicemail, touch

If you need to change your voicemail number, in the home screen press Menu >

settings

Send voicemail

To send a voicemail message to another T-Mobile subscriber:

1 Access your voicemail: Touch

touch and hold .

2 Follow the audio prompts to enter the recipient’s

number and record your message.

Visual voicemail

Visual voicemail lets you see and edit a list of your voicemail messages, from your phone display.

Find it: >

Voicemail

Dialer

, then touch and hold .

Voicemails

Settings

Dialer

Call

, then

Personalization

add your personal touch

Ringtones & sounds

Ringtones

To change your ringtone and notifications, press Menu >

To set vibrate for messages, > Menu >

, or

Social Messaging

To change your ringtone to silent from the home screen, press and hold the down volume key.

Tip: To use a song as a ringtone, press >

Music

then touch

Sounds

featur es

set volume for media and videos

Menu >

volume

play tones when using dial pad

Menu >

touch tones

Settings> Sound & ringtones

Messaging Settings

Text Messaging

Songs

, touch and hold the song name,

Use as phone ringtone

Settings

Sound & ringtones

Settings

Sound & ringtones

Messaging

Media

Audible

features

play sound on screen selection

Settings

Menu >

selection

Wallpapers

Find it: Press Menu >

Display settings

Sound & ringtones

Wallpaper

Audible

features

notification LED

Blinks to tell you that a notification has been received. Menu >

Notification LED

Display & security

Settings

set display brightness

Menu >

Brightness

Display & security

Settings

set orientation

Menu >

Orientation

Display & security

Settings

set animation

Settings

Menu >

Animation

Display & security

29Personalization

Widgets

Create widgets

1 Find an empty spot on your home screen where you

want to add a widget. You can flick left or right to open other panels on your home screen.

2 Touch and hold the empty spot until you see the

Add to Home screen

Widgets

3 Touch

4 Touch the type of widget. If necessary, enter the

widget settings.

Set up widgets

You can customize some widgets. Touch a widget to open it, then press Menu :

Happenings

•

accounts appear in this widget, or manage your accounts (the same as “Add accounts” on page 15).

Music

: Set this widget to an artist, album, song,

•

playlist, or just press Menu > There’s more in “Music” on page 35.

News

: Change the widget name, choose how long it

•

shows new stories, or choose a news source. To choose a source, touch , then choose preset

Bundles

Channels

URL for a

30 Personalization

Webpage

menu.

: Update your status, choose which

Party shuffle

, or choose

or an

RSS feed

Custom

to enter a

•

Messages

: Change the widget name or choose how long it shows new messages. To add email accounts, “Set up messaging” on page 25.

Weather

•

: Change temperature units or add

locations. To add locations, touch , enter a city,

and touch

. When you open the weather

widget, flick left to see other locations you added.

Note: Some apps have custom widget types that you

can add and set up after you install the app.

Shortcuts

To use a quick launch shortcut, press Search and the assigned key, like Search and B to launch the browser.

Folders

On your home screen, you can add a folder to help organize your favorite shortcuts or other items.

1 Find an empty spot on your home screen where you

want to add a folder. You can flick left or right to open other panels on your home screen.

2 Touch and hold the empty spot until you see the

Add to Home screen

Folders

3 Touch

4 Touch the type of folder you want to add. If you

New folder

choose

menu.

, you will be able to touch and

drag shortcuts from your home screen to drop into

245

5MP

New York, New York 10006 United States

Autofocus Box

Touch the thumbnail to open your

last photo.

the folder.

Date & time

Set the date, time, time zone, and formats:

Settings

Find it: Menu >

Date & time

Language & region

Set your menu language and region:

Settings

Find it: Menu >

locale

Locale & text

Select

Camera & video recorder

see it, capture it, share it!

Camera

Tak e p i c t u r e s

Find it: Press Camera

Note: Photos are stored on your microSD memory

Picture Resolution

card.

To take the photo, lightly press Camera halfway until the autofocus box turns green, then press all the way to take the photo.

is 3MP, unless you change it.

31Camera & video recorder

After you take a photo, touch the thumbnail:

All Pictures (10/43) 2010-07-12 12.00.00

201

20099

432

)

2010-0

My Pictures AllPictures

Picture Dates

Tap on the left to open the date list, then drag the dates to find pictures.

Categories

Tap at the top to open, then tap a category.

Gallery

• To see all your photos, touch

• To set the photo as a wallpaper, contact photo, or

social network profile photo, touch

Set as

• To send the photo in a message or post it online,

touch

. For more info on sharing your photos,

see “Send and share” on page 35.

• To delete the photo and return to the viewfinder,

Delete

touch

Picture options

In the viewfinder, press Menu >

Settings

the camera menu:

options

Store location in

Save the details of where the photo was taken.

pictures

Picture Resolution

Color Effects

Reset Settings

32 Camera & video recorder

Set the resolution of your photo.

Choose your color settings, like

None, Negative

Undo all of your camera setting changes.

, or

B/W

to open

options

Advanced settings

Set the

Picture Quality

photo, or choose your

Balance

light settings, like

Daylight

, or

Cloudy

of your

White

Auto

View pictures

Find it: >

ctures (10/43

ll P

Picture Gallery

7-12 12.00.

Play a slideshow

Press >

Picture Gallery

, touch a picture, then touch to start a slideshow. To stop the slideshow, touch the display. To return to the gallery, press Back .

Delete pictures

0:00

Touch the thumbnail to open your last recording.

Find it: >

Touch and hold a photo, then touch

Picture Gallery

Delete

Edit pictures

Find it: >

• To crop a photo, press Menu >

Picture Gallery

> picture

Edit

. Touch the crop tool to show arrows. Drag to the size you want and then touch the save icon.

• To set the photo as a contact picture, social network

profile picture, or wallpaper, press Menu >

Set as

• To open file details, press Menu >

Picture Info

Tip: To copy photos to/from a computer, go to “Copy

files to your card” on page 50.

Video recorder

Record videos

Find it: >

Tip: To send your video in a message, set the video

quality to

Settings

Low (for MMS messages)

To r e cord the video, press Camera . To stop the

video recording, press Camera again. After you record a video, touch the thumbnail:

• To see all your videos, touch

• To play the video, touch

Camcorder

Video quality

: Press Menu >

Gallery

Play

33Camera & video recorder

• To send the video in a message or post it online,

1:14

3:45

Video ControlsProgress Bar

touch

. For more info on sharing your photos,

see “Send and share” on page 35.

Delete

• To delete the video, touch

Video options

In the viewfinder, press Menu >

Settings

to open

the camera menu:

options

Video quality

Color Effects

Advanced settings

Choose your color settings, like

(for MMS messages) card)

High (for SD

Choose your color settings, like

None, Negative

Choose your settings, like

Cloudy

Auto, Daylight

, or

B/W

White Balance

light

, or

Low

Play back videos

Find it: >

Video Gallery

Delete videos

Find it: >

Video Gallery

Touch and hold a video, then touch

Edit videos

Find it: >

Video Gallery

Touch and hold a video, then touch

Video Info

, or other options.

> video

Delete

Edit, Rename

34 Camera & video recorder

Send and share

Music Artist

Album Title

Song Title

1:14 3:45

Artists Albums

Songs Playlists

Music

Music ControlsCategories

Touch a category, then

touch a song or playlist.

Send via email

Find it: >

Picture Gallery

Touch and hold a photo or video, then touch

Send via picture messaging

Find it: >

Picture Gallery

Touch and hold a photo or video, then touch

Text Messaging

Upload to Picasa™ or YouTube™

Find it: >

1 Touch and hold a photo or video, then touch

2 Choose how you want to share—depending on the

photo or video, options can include

Picasa, Social sharing

Tip: With

than one social network at the same time.

Social sharing

Picture Gallery

, or

, you can post a photo to more

YouTube

MySpace

Video Gallery

Music

when music is what you need . . .

Access the music player

Touch, touch, play—instant music. Just open your music library, then select what you want to play.

Find it: >

Tip: When a song is playing, you can add it to a playlist

by pressing Menu >

Music

Add to playlist

35Music

Download music

Your music is stored on your memory card. Your phone supports removable microSD memory cards up to 32 GB capacity. To make sure your memory card is installed, go to “Assemble & charge” on page 3.

Tip: To see the available memory on your memory

card, press Menu >

Note: Your phone has an OMTP 3.5mm headset jack

for wired stereo listening. You can go wireless with Bluetooth® stereo headphones or speakers (see “Bluetooth® wireless” on page 47).

Get music online

Download songs from the Internet directly to your phone’s memory card.

1 Press >

2 Find the song you want, then touch

3 Enter your account details and touch

Get music from a computer

You will need:

• a Microsoft® Windows® PC or

Apple® Macintosh®

• a USB data cable

36 Music

Settings

Amazon MP3

SD card & storage

Buy

• music files in one of these formats: MP3, M4A,

AAC, ACC+, MIDI, WAV, and OGG Vorbis

Note: Your phone does not support any DRM

protected files.

Rip a CD

Not literally. If you’re new to digital music transfer, this means transferring music from a music CD to your computer.

To rip a music CD on your computer, you can use Microsoft® Windows® Media Player. You can download Windows Media Player from www.microsoft.com

1 On your computer, open Windows Media Player.

2 Insert a music CD into the computer’s CD

ROM drive.

Note: Make sure you change the format to MP3 in

“Rip > Format > Rip Settings”.

3 In the Windows Media Player window, click on the

“Rip” tab.

4 Highlight the songs you want to import, and click

“Start Rip“.

The songs are imported to the Windows Media Player Library.

Transfer using Windows Media Player

Transfer music files from a computer to your memory card.

Note: Copyright—do you have the right? Always follow

the rules (see “Content Copyright” in the Safety, Regulatory & Legal Information booklet).

1 With a memory card inserted, and your phone

showing the home screen, connect a Motorola micro USB data cable to your phone and your computer. Your phone should show in the status bar.

Note: Your phone supports Microsoft® Windows®

XP, Windows Vista®, and Apple® Macintosh®. Other operating systems may not be compatible.

2 Touch

USB Drive

to connect your memory card to your computer. You can’t use the files on your memory card while it is connected.

3 On your computer, open Windows Media Player.

4 On the “Sync” tab, select “More Options”. Under

“Device”, select your phone.

5 Select “Properties”, check the “Create folder

hierarchy on device” box, and click “OK”.

6 Drag your music files over to the “Sync List” and

press “Start Sync”.

Transfer using USB

Transfer music files from a computer to your memory card.

1 With a memor y card inserted, and your phone

showing the home screen, connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.

Note: Your phone supports Microsoft® Windows®

XP, Windows Vista®, and Apple® Macintosh®. Other operating systems may not be compatible.

2 Touch

USB Drive

to connect your memory card to your computer. You can’t use the files on your memory card while it is connected.

3 On your computer, find “Removable Device” (your

memory card) in the “My Computer” window.

4 Drag and drop your music to a folder on your

memory card.

Tip: To help manage your music, create a “Music”

folder on your memory card.

5 When you’re done, use the “Safely Remove

Hardware” feature to finish.

37Music

Play music

Music Artist

Album Title

Song Title

1:14 3:45

Open Playlist

Shuffle On/Off

Repeat Off/All /Current

Artist

Album

Song Title

Music Controls

Total Song Time

Progress Bar

Music library

Open your music library, then select what you want to play.

Find it: >

Music

Artists Albums

Songs Playlists

Music Artist

Song Title

Your music is stored by artists, albums, songs, and playlists. Touch a category, then touch the song or playlist you want to play. Press Menu >

shuffle

to randomly play all your songs, or touch

to look for a song.

38 Music

Music

Categories

Touch to list songs or playlists.

Last Played

Touch to play again.

Party

Music player

Just touch a song or playlist to get going.

Music player controls

controls

play/pause Touch / .

previous/next Touch / .

fast forward/rewind Touch & hold / .

controls

view playlist Touch .

shuffle Touch .

repeat Touch .

volume Press the side volume keys.

Library

Party

Add to

Use as

Delete

view library Press Menu >

turn shuffle on/off Press Menu >

shuffle

add to playlist Press Menu >

playlist

use as ringtone Press Menu >

ringtone

delete Press Menu >

Hide, wake, turn off

Press Home to use another app. Your music continues to play.

When you see in the status bar a song is playing, flick down to see details. Touch the song to return to the music controls.

To turn off your music touch .

Playlists

To add a song from the music library to a playlist, touch and hold the song then touch an existing playlist, or touch playlist.

To add a song to the playlist you're playing, press Menu >

Add to playlist

To edit, delete and rename playlists, touch and hold the playlist in the music library.

Add to playlist

New

to create a new

. Choose

in the music player.

39Music

Web browsing

www.google.com: Google

Android | Official Website

Official site for the development of the open source project. Provides a directory of applications and links to download the source ..

www.android.com/ - Options

More from www.android.com »

Android Market

News results for android Verizon Droid Success Limited by Android Market -

7 hours ago The idon't ad campaign pits the Android-based Droid head-to-head against the formidable iphone. Based on preliminary predictions ..

PC World - 1778 related articles »

Android | Official Website

Official site for the development of the open source project. Provides a directory of applications and links to download the source ..

www.android.com/ - Options

More from www.android.com »

Android Market

Browse and search for applications on Android Market and publish your own.

www.android.com/market/ - Options

More from www.android.com »

Google Projects for Android

Official website. Provides a project documentation and links to download the Android SDK.

code.google.com/android/ - Options

More from www.android.com »

Android (operating system) - Wikipedia, the free encyclopedia

This article is about the mobile operating system. For the type of robot,

see Android. For other uses, see Android (disambiguation). ...

en.wikipedia.org/wiki/Android/ - Options

More from www.android.com »

Magnify

Open a magnifying window

that you can drag.

Zoom In/Out

source/android.com/ - Options

Android Community - Tracking the Android Platform

application developer sreern

you don’t need a computer, surf the web with your phone

Access the Internet

Find it: >

www.google.com: Google

Web

Images

Local

My Location: Off - Turn On

View Google in: Mobile

New window

Note: If you can’t connect, contact your service

provider.

To go to a Web site or search, just press Menu >

, then enter the URL or the words to search.

40 Web browsing

News more

Google Search

Exit

Refresh

Browser

12:00 PM

Classic

Bookmarks

The page is loading.

Connection

Over the air: Mobile Network: , , Wi-Fi:

Links

Touch to open.

Web Address

To go to a URL, press > Go.

Drag or flick to scroll.

Press to open a menu where you can open a Web page, your bookmarks, a new window, and more.

Web touch tips

Zoom & magnify

In Web pages, when you scroll (drag or flick), zoom icons appear at the bottom of your screen.

Select links

When you touch a link, your phone outlines it. If you touch and hold the link, your phone shows options, like

Bookmark link

Tip: To help select links, use the “TinyTouch pad” on

page 9.

Open in new window

Access web2go

web2go is your destination—on your phone or the Web—for the latest features and services, games, wallpaper, 411 and information, Web and applications, music and sounds, special values, and more. A single location that hosts all of this content all the time, web2go is free to browse so you can always find the latest additions.

You can access web2go through your phone, or through your personal Web portal at My T-Mobile.

Add a bookmark

To bookmark the current page in your browser, press Menu >

Bookmarks

Add bookmark...

Clear browser cache

To clear any files that your browser stored from sites you visited, press Menu >

cache

Settings

Clear

Copy and paste text

To copy text on the current Web page, press Menu

> over the text. When you lift up your finger, the highlighted text is copied to your clipboard.

Select text

. Then, touch and drag your finger

Search within a page

To search for a word or phrase on the current Web page, press Menu >

Find on page

View browser history

To see the Web pages you’ve visited, press Menu

Bookmarks

Most visited

, then choose your full

History

or just the

Adjust browser options

To see your browser options, press Menu >

Settings

Use a Wi-Fi network

Your phone uses the mobile phone network (over the air) to automatically connect to the Web.

Note: Your service provider may charge to surf the

Web or download data.

To use a wireless network, press Menu >

Wireless controls

Wi-Fi settings

touch networks. Touch a network to connect. There’s more in “Wi-Fi” on page 48.

. Touch

Wi-Fi

to search for nearby wireless

to turn it on, then

Settings

41Web browsing

Download apps

Warnin g: Apps downloaded from the Web can be

from unknown sources. To protect your phone and personal data, only download apps from sources you trust, like “Android Market™” on page 44.

Note: All apps downloaded are stored in your phone

memory.

To download apps:

1 If you want to download apps from any Web page,

press Menu >

Unknown sources

2 To launch the browser, press >

3 Find the app you want to download and touch the

download link.

Manage your downloads

To view files or applications you have downloaded, press > To clear your download history, press Menu >

Clear list

. To cancel, press Menu >

downloads

42 YouTube™

Settings

Browser

> >

Applications

Downloads

Cancel all

Browser

Yo u Tu be ™

go and create your own classic

Quick start: YouTube

Find it: >

Featured

Categories

Touch a video to play.

Press to open a menu where you can search, upload, edit your account, and more.

Note: If you don’t have a YouTube account, visit

www.youtube.com

to find out more. To create an

account or sign in, go to “Your account” on page 43.

Watch YouTube videos

See popular video categories, like Featured, Most viewed, and Top rated. Touch a category, then touch the video to start playing it. To see more video categories, press Menu >

Categories

Search for YouTube videos

Find it: >

Enter text, then touch history, press Menu >

history

YouTube

> Menu >

.To clear your search

Settings

Clear search

Share videos

Send someone a link to a video that you are watching.

1 Press Menu >

Tip: Just touch and hold a video to open the

menu.

2 Address and complete your email, then touch

Send

Your account

YouTube

Find it: >

account

1 To create your YouTube account, touch the “Don’t

> Menu >

have a YouTube account? Click here to create one” link.

If you already have a YouTube account, enter your username, password and touch

2 For a new account, enter a username, and complete

I accept

the fields, then touch

Upload videos

Find it: >

1 Touch the video you want to upload. You can change

YouTube

> Menu >

the video title, description, set the access, and add tags.

Upload

2 Touch

Upload

43YouTube™

Android Market™

get the app you want

Locations

where you are, where you’re going

About Android Market™

Find it: >

Get all the fun games and cool apps you want! Android Market provides access to applications developed by developers worldwide, so you can find the app you want. If you need help or have questions about Android Market, press Menu >

Market

Help

Browse & install apps

Scroll to and touch the app you want to install. Then,

Install

touch

(if app is free) or

Buy

Manage & restore apps

Find it: Menu >

applications

Touch an app in the list, then touch you downloaded),

To reinstall any downloaded items, press >

Market

are listed and available for download.

44 Android Market™

Settings

Clear cache

My downloads

Applications

Uninstall

Manage

(for apps

, or other options.

. Previously installed apps

Google Maps™

Quick start: Google Maps

Where am I? What's around here? Don't worry—let Google Maps help you explore your surroundings and find what you're looking for.

N Rush St

Google Maps

E Ohio St

E Grand Ave

N Micigan Ave

E S WaterSt

N Micigan Ave

Randolph

St Metra

N New St

N Park St

rD submuloC N

Map View

Drag or flick to scroll. Touch to show zoom.

E Randolph St

Press to open a menu where you can search, get directions, find your location, and more.

Find it: >

Ontario St

E Ontario St

N Wabash Ave

Grand Red

N Dearborn St

N Clark St

44 West Street

Wacker Dr

E Wacker Pl

State/Lake

W Lake St W Lake St

Lake

Randolph/

Wabash

Washington-Blue

Search Directions Map mode

My Location Join Latitude

Google Maps opens by default in “Map mode.”

Te le Na v ®

Note: The free trial of TeleNav GPS Navigator

automatically expires after 14 days. To continue use of the TeleNav GPS Navigator after expiration of the free 14 day trial, you must sign up for regular service. TeleNav is a registered trademark and TeleNav GPS Navigator is a trademark of TeleNav, Inc.

Find it: >

1 Read the agreement and touch

2 Enter your first and last name, and your e-mail

address.

3 Read the warning and touch

The first time you launch TeleNav:

• You cant take a brief tour. If you skip it, you can

take it later under

• TeleNav downloads the pictures and sounds it

will need. You’ll see a message while it downloads. Let the download complete before you do anything else with your phone.

Tip: For more help, go to www.telenav.com

Find a location

Find it: >

TeleNav

to continue.

Tools & More

to continue.

Product Tour

You can search for types of places, or a specific search location.

Get directions

TeleNav

Find it: >

Drive To

Follow the prompts to enter an address, or choose one of the addresses you’ve saved.

Latitude

Join Latitude

See where your friends and family are on Google Maps™. Plan to meet up, check that your parents got home safely, or just stay in touch.

Don’t worry, your location is not shared unless you agree to it. You need to join Latitude, and then invite your friends to view your location or accept their invitations. When using Google Maps (in any mode

except in Street View), press Menu >

Latitude

. Read the privacy policy and if you agree with

it, touch

Allow & share

Add and remove friends

Find it: >

Latitude

To add friends:

1 Press Menu >

Google Maps

Add friends

> Menu >

Join

45Locations

2 Touch

Select from Contacts

address

, then touch a contact and

Add via email

Add friends

If your friends already use Latitude, they’ll receive an email request and a notification. If they have not yet joined Latitude, they’ll receive an email request that invites them to sign in to Latitude with their Google™ account.

To remove friends:

1 Press Menu >

Latitude

to show your friend’s

list, then touch a friend in your list.

Remove

2 Touch

Share location

When you receive a request to share location details you can choose to:

Accept and share back

•

—see your friend’s location,

and your friend can see yours.

Accept, but hide my location

•

—see your friend's

location, but they can't see yours.

Don't accept

•

—location information is not shared

between you and your friend.

Hide location

Latitude

Press Menu >

to show your friend’s list.

Touch your contact name, then press Menu >

Privacy

Hide your location

46 Locations

Tip: To hide your location from all apps, from the home

screen press and hold Power to open the power

GPS

menu. Then, turn off

Disable latitude

Press Menu > Touch Menu >

Latitude

to show your friend’s list.

Privacy

Turn off Latitude

Voice Search

just tell me what you want

Bluetooth® wireless

lose the wires

Use search

Google™ voice: Press and hold Search , then say

a term to search the Web.

Other ways to search:

•Google™ text: Press Search , then type the

search term.

•Contacts: Just type a contact’s name in the home

screen.

• Apps: to open the app menu, then type the

app name.

SafeSearch

Your phone has a search filter that’s set to to remove explicit images. To change it:

1 Press and hold the Search , then say the search

term.

2 In the search results window, press Menu >

Settings

3 Touch

4 Touch

SafeSearch

Off, Moderate

, or

Strict

Moderate

Turn Bluetooth power on or off

Find it: Press and hold Power >

Note: To extend battery life, turn Bluetooth power

off when not in use.

Bluetooth

Connect to new Bluetooth® devices

Note: This feature requires an optional accessory.

To connect with a new device, you need to pair with it. You only need to do this once for each device—to connect again, just turn on the device.

1 Make sure the device you are pairing with is in

discoverable mode.

Note: Refer to the guide that came with the device

for details.

Settings

2 Press Menu >

Bluetooth settings

Bluetooth

3 Touch

to turn on and scan. If Bluetooth

power is already on, touch

Wireless controls

Scan for devices

4 Touch a device to connect.

5 If necessary, touch

0000

(like

) to connect to the device. When the

, or enter the device passkey

47Voice Search

device is connected, the Bluetooth indicator appears in the status bar.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Reconnect devices

To automatically reconnect your phone with a paired device, simply turn on the device.

To manually reconnect your phone with a paired device, touch the device name in the

devices

list.

Bluetooth

Disconnect Bluetooth® devices

To automatically disconnect your phone from a paired device, simply turn off the device.

To manually disconnect your phone from a paired device, touch the device name in the devices list, then press Menu >

Disconnect

Edit properties

Press Menu >

Bluetooth settings

touch

48 Wi-Fi

Settings

Device name

Wireless controls

. Enter a name and

Wi-Fi

home, office, or hotspot

Quick start: Wi-Fi

Find it: Menu >

Wi-Fi settings

Note: Your phone's Wi-Fi features and power levels

are not allowed for outdoor operation in France. To avoid unlawful interference with radio signals, do not use the Wi-Fi features in France unless you are indoors.

Use a wireless network for fast Internet access and to download data.

Wi-Fi settings

Wi-Fi

Network notification

Notify me when an open network is available

Wi-Fi networks

Your network

Add Wi-Fi network

Settings

Wireless controls

Turn on & scan.

Connect.

Turn Wi-Fi on or off

Find it: Press and hold Power >

Note: To extend battery life, turn off Wi-Fi power when

not in use.

Wi-Fi

Search & connect

To find networks in your range:

1 Press Menu >

Wi-Fi settings

Wi-Fi

2 Touch

on, press Menu >

Settings

Wireless controls

to turn on and scan. If Wi-Fi is already

Scan

. Your phone lists the

networks it finds within range.

Tip: To see your phone’s MAC address or other

Wi-Fi details, press Menu >

Advanced

3 Touch a network to connect.

4 If necessary, enter

Wireless password

Network SSID, Security

, and touch

Connect

, and

. When your phone is connected to the network, the wireless indicator appears in the status bar.

Tip: When you are in range and Wi-Fi is on, you will

automatically reconnect to available networks you’ve connected to before.

Delete networks

To delete networks you have used:

1 Press Menu >

Wi-Fi settings

Settings

Wireless controls

2 Touch and hold the network in your list.

3 Touch

Forget network

49Wi-Fi

Memory card

store more

Install memory card

Your phone comes with a microSD memory card installed, but if you need to install a different one:

1 cover off 2 microSD in

3 cover on

Note: Do not remove your memory card while your

phone is using it or writing files on it. You need the memory card installed for some features on your phone, like

Before you remove or format your memory card you need to unmount it. Press Menu >

card & storage

50 Memory card

Camera

Unmount SD card

Settings

To format your memory card, touch

Format SD card

Warnin g: All data on your memory card will be

deleted.

View available memory

To see the available memory on your memory card, press Menu >

Settings

SD card & storage

Copy files to your card

Note: This feature requires an optional accessory.

You can connect your phone to a computer and transfer your pictures, videos, music, ringtones, and more, from your computer to your phone’s memory card.

1 With a memor y card

inserted, and your phone showing the home screen, connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.

Note: Make sure to connect the phone to a high

power USB port. Typically, these are located directly on your computer.

2 Touch

USB Drive

to connect your memory card to your PC. You can’t use the files on your memory card while it is connected.

3 On your computer, use the “My Computer”

window to find “Removable Disk”.

4 Click on the “Removable Disk” icon to access the

memory card.

5 Drag and drop your pictures, videos, music,

ringtones, and more, to your phone folder. To help manage your files, you can create more folders in your phone folder.

6 When you’re done, use the “Safely Remove

Hardware” feature to finish.

View files from your phone

Find it: >

Touch a file or folder to open it, and touch a file to open it.

Quickoffice

Memory card

Delete files

Find it: >

Touch a file or folder to open, then touch and hold a file to choose

Delete

Quickoffice

Memory card

Management

stay in control

Google™ data synchronization

Find it: Menu >

synchronization

The Google apps on your phone give you access to the same personal information (emails, events, and contacts) that you have on a computer using Gmail™, Google Calendar™, and Contacts. It’s easy to synchronize the Google apps information you want to keep up-to-date.

Select apps to synchronize

1 Touch

Background data

Tip: To save battery power, do not touch

Background data

2 Touch the apps you want to synchronize, like

Calendar

, or

Synchronize with Microsoft® Office Outlook

If you use Microsoft Office Outlook on your work computer, your phone can synchronize emails, events, and contacts with your Microsoft Exchange server.

Settings

Contacts

and

Google

Auto-sync

Gmail

51Management

Find it: >

Alarm

7:00am

Wake Up

8:30am Tuesday

9:00am Tue, Fri

Alarm Clock

January 2009

Sun

Mon Tue Wed Thu Sat

282930 31 123

456 8910

11 12 13 15 16 17

18 19 20 22 23 24

25 26 27 29 30 31

123 567

Fri

Sync

1 Enter details from your IT administrator (the server

Accounts

Add account

address is the same URL you use to access your company’s email using the Web on your computer).

Tip: You might need to enter your domain name

with your user name (like domain/username)

Note: Some work accounts might require you to

add a password lock to your phone, for security. Some small businesses use private certificates that are not supported by

Corporate Sync

. To stop an account from showing the contacts you create on your phone, touch

Settings

contacts

2 Touch

, then uncheck the account under

Contacts

, press Menu

Alarm clock

Find it: >

52 Management

Alarm Clock

Corporate

New

To turn on an alarm, touch the check b ox .

When an alarm sounds, drag

Dismiss

to turn it off or

Snooze

delay.

To add an alarm, press Menu

Add alarm

, then enter alarm

details.

To set a snooze period, touch the alarm, then press Menu >

Snooze time

Calendar

Find it: >

Your calendar events can be viewed in different ways: Press Menu >

Agenda, Week

highlight an event in the day and week views, more details appear.

The calendar on your phone can be synchronized with your Google Calendar™.

, or

Calendar

Month

Day

. When you

Add calendar events

From any calendar view, press Menu > Enter event details and touch

Save

New event

Manage calendar events

To edit an event, press Menu > event details, then when you’re done, touch

To delete an event, press Menu >

To go to today, press Menu >

Edit event

Delete event

Today

. Edit

Save

Calculator

Find it: >

Your calculator has two views: basic and advanced. To change your views, press Menu >

Basic panel

Clear history

Calculator

Advanced panel

. To clear history, press Menu >

Quickoffice

Use

Quickoffice

to view recent documents and files

on your memory card.

Find it: >

Quickoffice

Airplane mode

Use airplane mode to turn off all of your wireless connections—useful when flying. Press and hold Power >

Airplane mode

Update my phone

To keep your phone current, software updates may be available. Press Menu >

System updates

isn’t, touch

to see if your phone is up to date. If it

Update

About phone

Settings

53Management

Security

help keep your phone safe

Screen lock

Set your phone to display a lock screen, and prevent accidental key presses, press Menu >

Display & security

Screen lock

. You can also set a

security lock to prevent others from using your phone.

To set your security level, press Menu >

Display & security type

Pattern lock

•

Passcode lock

•

Security lock

- draw a pattern to unlock.

- enter a code to unlock.

Note: You can make emergency calls on a locked

phone (“Emergency calls” on page 19). A locked phone still rings, but you need to unlock it to

answer.

54 Security

Security lock

Settings

Lock pattern

To set the lock pattern, press

Settings

Menu >

security

Security lock type

Security lock

Display &

Pattern lock

Draw an unlock pattern

Follow the instructions to draw your lock pattern.

When prompted, draw the pattern to unlock the phone.

Passcode lock

Settings

Enter

To set the passcode, press Menu >

Display & security

Passcode lock

Enter a passcode, then touch

Security lock

Security lock type

Enter

. Enter the

passcode again to confirm it, and touch

When prompted, enter the passcode to unlock the phone.

Personalize your lock screen

To change your timeout, press Menu >

Display & security

Screen timeout

Settings

. If you don't touch the screen or press any keys for this amount of time, the screen locks automatically. To unlock, see “Lock & unlock” on page 55.

To change your lock screen picture, press Menu >

Wallpaper

Lock & unlock

To lock the screen/phone:

• Press Power .

• Let the screen time out (don’t press anything).

• Switch the power off.

To unlock the screen/phone:

• Press Menu or switch the phone on to display

the lock screen.

• Press Menu to unlock—if you've set a lock

pattern or passcode, you'll be asked to enter it.

Forgot your pattern or passcode?

In the passcode unlock screen, press Menu >

Forgot passcode?

to unlock your phone with your MOTOBLUR email address and MOTOBLUR password.

In the pattern unlock screen, after you enter an incorrect pattern five times, you can

Forgot passcode?

touch

to unlock your phone with your MOTOBLUR email address and MOTOBLUR password.

Tip: You can also reset your password at

www.motorola.com/mymotoblur

Lock SIM

Enable SIM PIN

To lock your SIM (the next time you power up the phone you will need to enter your SIM PIN), press Menu >

SIM card lock

code.

Caution: If you enter an incorrect PIN code three

times, your phone locks your SIM card and asks for your PIN unlock code, contact your service provider.

Change SIM PIN

To change your SIM PIN, press Menu >

Display & security SIM PIN

PUK code

To unlock your SIM PIN, you need to enter your PIN unlock code (PUK code) when prompted.

Note: Your PUK code is provided by your service

provider.

Settings

Lock SIM card

Set up SIM card lock

Display & security

. Enter your SIM PIN

Settings

Change

Set up

55Security

Reset & clear

To reset your phone to factory settings and erase all the data on your phone, press Menu >

SD card & storage

Factory data reset

Warnin g: All downloaded apps and user data on your

phone will be deleted. Data on your memory card will not be deleted.

Settings

Reset phone

Locate and wipe lost phone

Don't you just hate it when your life is on your phone and it all goes wrong—lose it, break it, reset it, or even worse—stolen! Relax, MOTOBLUR can help find your phone, clear it (if you need to) and best of all, restore all your stuff.

Track your phone

To locate your phone:

1 Log into your MOTOBLUR account:

www.motorola.com/mymotoblur

2 On the phone profile page, follow the link to locate

your phone.

MOTOBLUR locates your phone using GPS and AGPS.

Remote clear

To wipe your phone data:

56 Security

1 Log into your MOTOBLUR account:

www.motorola.com/mymotoblur

2 On the phone profile page, follow the link to delete

data.

Warnin g: All downloaded apps and user data on

your phone will be deleted. Data on your memory card will not be deleted.

Restore your phone

If you lose your phone, you can log into your MOTOBLUR account from a computer to locate your phone or clear the data on it: www.motorola.com/mymotoblur

Note: If you recover your phone after a remote clear,

you need to complete a factory reset: Hold the Camera key and press Power to turn on your phone. When you see a blue screen, press Press Alternate +L and Alternate +W. Now, press Power and log into MOTOBLUR.

If you get your next MOTOBLUR product, just log into your existing MOTOBLUR account on your phone to recover all your stuff automatically.

To recover your Android Market apps, see “Manage & restore apps” on page 44.

Troubleshooting

Crash recovery

In the unlikely event that your phone stops responding to touches and key presses, try a quick reset. Remove the back cover and battery (“Assemble & charge” on page 3), then replace and turn on your phone as usual.

Service & repairs

If you have questions or need assistance, go to www.motorola.com/support from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada)

, where you can select

57Troubleshooting

Safety, Regulatory & Legal

032375o

Battery Use & Safety

Important: Handle and store batteries properly to avoid injury or damage.

Most battery issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to

change the form of your battery.

• Don’t let the phone or battery come in contact with water.

into the phone’s circuits, leading to corrosion. If the phone and/or battery get wet, have them checked by your service provider or contact Motorola, even if they appear to be working properly.*

• Don’t allow the battery to touch metal objects.

jewelry, stay in prolonged contact with the battery contact points, the battery could become very hot.

• Don’t place your battery near a heat source.

phone or the battery. High temperatures can cause the battery to swell, leak, or malfunction. Therefore:

•

not

dry a wet or damp battery with an appliance or heat source, such as a

hair dryer or microwave oven.

•

Avoid leaving your phone in your car in high temperatures.*

DOs

• Do avoid dropping the battery or phone.

a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your phone or battery

has been damaged from dropping or high temperatures.

* Note:

If the product guide expressly states that your damage from exposure to certain rugged conditions, such as water immersion, rain, dust, high and low temperatures, shock, or other conditions, do stated limits, and ensure the stated precautions are taken. Always make sure that

Excessive heat can damage the

Dropping these items, especially on

Water can get

If metal objects, such as

phone

is designed to resist

not

exceed the

the battery compartment is closed and secure to avoid direct exposure of the battery to any of these conditions.

Important: Use Motorola Original products for quality assurance and safeguards.

To aid consumers in identifying authentic Motorola batteries from non-original or counterfeit batteries (tha t may not have adequate safety protection), Motorola provides holograms on its batteries. Consumers should confirm that any battery they purchase has a “Motorola Original” hologram.

Motorola recommends you always use Motorola-branded batteries and chargers.

Motorola mobile devices are designed to work with Motorola batteries.

If you see a message on your display such as

Unable to Charge

•

Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and retry charging it;

•

If the message remains, contact a Motorola authorized service center.

Important:

Motorola’s warranty does not cover damage to the phone caused by

non-Motorola batteries and/or chargers.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

Proper and safe battery disposal and recycling:

only important for safety, it benefits the environment. Consumers may recycle their used batteries in many retail or service provider locations. Additional information on proper disposal and recycling may be found on the Web:

•

www.motorola.com/recycling

•

www.rbrc.org/call2recycle/

Disposal:

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center or national recycling organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

Battery Charging

Notes for charging your phone’s battery:

, take the following steps:

Invalid Battery

(in English only)

Proper battery disposal is not

•

When charging your battery, keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.

Specific Absorption Rate (IEEE)

SAR (IEEE)

Your model wireless phone meets the governmental requirements for exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is designed and manufactured to not exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed for the safety of all persons, regardless of age or health, and to account for any variations in measurements. The exposure standard for mobile device s employs a unit of measurement known as the Specific Absorption Rate (SAR). The IEEE SAR limit set by the FCC and by the Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over one gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC and by Industry Canada with the mobile device transmitting at its highest certified power level in all tested frequencies. Although the SAR is determined at the highe st certified power level, the actual SAR level of the mobile device while operating can be below the maximum value. This is because the mobile device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output. Before a mobile device is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed

the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) submitted to the FCC and available for review by Industry Canada. The highest SAR value for this mobile device when tested for use at the ear is 1.20 W body,

as described in this guide, is 0.93 W/k

ts data transmission mode (body-worn use) is 0.38 W

in i

urements can differ, depending upon available accessories and regulatory

meas requirements. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product. While there may be differences between the SAR levels of various mobile devices and at various positions, they meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site: http://www.phonefacts.net or the Canadian Wireless Telecommunications Association (CWTA) Web site: http://www.cwta.ca

/kg, and when worn on the

g. The SAR value for this mobile device

/kg. Body-worn

European Union Directives Conformance Statement

EU Conformance

[Only Indoor Use Allowed In France]

Hereby, Motorola declares that this product is in compliance with:

•

The essential requirements and other relevant provisions of Directive 1999/5/EC

•

All other relevant EU Directives

The above gives an example of a typical Product Approval Number.

0168

Product Approval Number

You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at Product Approval Number from your product’s label in the “Search” bar on the Web site.

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you

www.motorola.com/rtte

. To find your DoC, enter the

are uncertain about your right to copy any material, please contact your legal advisor.

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA The Motorola website regarding Motorola's use of open source. Motorola has created the portal for interaction with the software community-at-large. To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please press Menu Key > >

Legal information >Open source licenses

Motorola device may include self-contained applications that present supplemental notices for open source packages used in those applications.

GPS & AGPS

Your mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device. Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges,

opensource.motorola.com

Settings >About Phone

also contains information

website to serve as a

. In addition, this

and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details.

Your Location

Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS technology in your mobile device to tell the emergency responders your approximate location. AGPS has limitations and

•

Always tell the emergency responder your location to the best of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

might not work in your area

. Therefore:

Performance Tips

•

Go outside and away from underground locations, covered vehicles, structures with metal or concrete roofs, tall buildings, and foliage. Indoor performance might improve if you move closer to windows, but some window sun shielding films can block satellite signals.

•

Move away from radios, entertainment equipment, and other electronic devices.

Navigation

Motorola strives to provide complete and accurate mapping information, directions, and other navigational data, using a combination of governmental and private location information sources. These sources may contain inaccurate or incomplete data. In some countries, complete information may not be available. Therefore, you should visually confirm that the navigational instructions are consistent with what

you see. All drivers should pay attention to road conditions, closures, traffic, and all other factors that may impact driving. Always obey posted road signs.

Safety & General Information

Safety Information

This section contains important information on the safe and efficient operation of your mobile device. Read this information before using your mobile device.

Exposure to Radio Frequency (RF) Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits. Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions.

Product Operation

When placing or receiving a phone call, hold your mobile device just like you would a landline phone. If you wear the mobile device on your body, always place the mobile device in a Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola, keep the mobile device and its antenna at least 2.5 centimeters (1 inch) from your body when transmitting. Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our Web site at:

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy

compatibility. In some circumstances, your mobile device may cause interference

032374o

032376o

032375o

with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so. In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator, consult your physician before using this mobile device. Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place. Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your mobile device with your implantable medical device, consult your healthcare provider.

Driving Precautions

Using a mobile device while driving may cause distraction. End a call if you can’t concentrate on driving. Input information about your destination and route prior to your drive. Do not input data or engage in text messaging while driving. Keep your eyes on the road while driving. Listen to the audible turn-by-turn directions, if available. Also, using a mobile device or accessory may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products. Responsible driving practices can be found at (in English only).

www.motorola.com/callsmart

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and can include fueling areas, such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders. When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Do not throw your battery or mobile device in the trash.

Do not let your battery, charger, or mobile device get wet.

Symbol Definition

Listening at full volume to music or voice through a headset may damage your hearing.

Batteries & Chargers

Caution:

Improper treatment or use of batteries may present a danger of fire, explosion, leakage, or other hazard. For more information, see “Battery Use & Safety.”

Keep Your Mobile Device & Its Accessories Away From Small Children

These products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing ligh ts, such as when playing video games . These may occur even if a per son has never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your mobile device. Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes,

leave the lights on in the room, take a 15-minute break every hour, and stop use if you are tired.

Caution About High Volume Usage

Warning:

Exposure to loud noise from any source for extended periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected. To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears, or muffled speech, you s hould stop listening to the device through your headset or headphones and have your hearing checked. For more information about hearing, see our Web site at direct.motorola.com/hellomoto/nss/AcousticSafety.asp only).

(in English

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician. [Nov0109]

Industry Canada Notice to Users

Industry Cana da Notice

Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interferenc e that may cause undesired operation of the device. See RSS-GEN 7.1.5.

FCC Notice to Users

FCC Notice

The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID:xxxxxx on the product label.

Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21. This device complies with part 15 of the FCC Rules. Operation is subject to the following two c onditions: (1) This devic e may not cause harmful interfer ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3). This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Use & Care

To care for your Motorola phone, please keep it away from:

liquids of any kind

Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture. If it does get wet, don’t try to accelerate drying with the use of an oven or dryer, as this may damage the phone.

extreme heat or cold

Avoid temperatures below 0°C/32°F or above 45°C/113°F.

microwaves

Don’t try to dry your phone in a microwave oven.

dust and dirt

Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.

cleaning solutions

To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

shock and vibration

Don’t drop your phone.

Motorola Limited Warranty for the United States and Canada

Warra nty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its mobile telephones (“Products”), Motorola-branded or certified accessories sold for use with these Products (“Accessories”), and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories, and Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and Accessories

defined above, unless otherwise provided for below.

Decorative Accessories and Cases.

Decorative covers, bezels, PhoneWrap™ covers and cases.

Monaural Headsets.

and boom headsets that transmit mono sound through a wired connection.

Products and Accessories that are Repaired or Replaced.

Exclusions (Products and Accessories)

Normal Wear and Tear.

due to normal wear and tear are excluded from coverage.

Batteries.

Only batteries whose fully charged capacity falls below 80% of their

rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Defects or damage that result from: (a) improper operation,

One (1) year

the first consumer purchaser of the product unless otherwise provided for below.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

Ear buds

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

returned to the consumer, whichever is longer.

Periodic maintenance, repair and replacement of parts

from the date of purchase by

for the

from the date

Use of Non-Motorola Products and Accessories.

from the use of non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification.

service, testing, adjustment, instal lation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.

Products or Accessories with (a) serial numbers or date tags

Defects, damages, or the failure of Products,

Defects or damage that res ult

Defects or damages resulting from

Software

Products Covered Length of Coverage

Applies only to physical defects in the

Software.

media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

Exclusions (Software)

Software Embodied in Physical Media.

will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media.

physical media (e.g. software that is downloaded from the Internet), is provided “as is” and without warranty.

Ninety (90) days

the date of purchase.

No warranty is made that the software

Software that is not embodied in

from

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does no t conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, wi ll be reinstalled. To avoid losing such data, software, and applications, please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information

USA All Products, Accessories, and Software:

Canada All Products:

TTY

You will receive instructions on how to ship the Products, Accessories or Software, at your expense, t o a Motorola Authorized Repair Center. To obtain service, you must include: (a) a c opy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

1-888-390-6456

1-800-461-4575

1-800-734-5870

What Other Limitations are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO

EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Hearing Aid Compatibility with Mobile Phones

Hearing Aid Compat ibili ty

Some Motorola phones are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies. When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate. The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in finding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for this mobile phone, use only the original equipment battery model. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the

phone with your hearing device is the best way to evaluate it for your personal

032376o

needs.

M-Ratings:

Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings:

Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.) Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.

Information from the World Health Organization

WHO Information

Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using handsfree devices to keep mobile phones away from your head and body. Source: WHO Fact Sheet 193 Further information:

Product Registration

Registration

Online Product Registration: www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage. Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status.

http://www.who.int/peh-emf

Thank you for choosing a Motorola product.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Caring for the Environment by Recycling

Recycling Info rmation

This symbol on a Motorola product means the product should not be disposed of with household waste.

Disposal of your Mobile Device & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste. Do not dispose of your battery or mobile device in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling

Disposal of your Mobile Device Packaging & Product Guide

Product packaging and pr oduct guides should only be dis posed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

California Perchlorate Label

Perchlorate Label

Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label: Perchlorate Material – special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate There is no special handling required by consumers.

Privacy & Data Security

Privacy & Data Se curity

Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

• Monitor access

others may have unmonitored access. Lock your device’s keypad where this feature is available.

• Keep software up to date

releases a patch or software fix for your mobile device that updates the device’s security, install it as soon as possible.

• Secure personal information

information in various locations including your SIM card, memory card, and phone memory. Be sure to remove or clear all personal information before you recycle, return, or give away your device. You can also backup your personal data to transfer to a new device.

Note:

go to

• Online accounts

(such as MOTOBLUR). Go to your account for information on how to manage the account, and how to use security features such as remote wipe and device location (where available).

• Location-based information

information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that

—Keep your mobile device with you and do not leave it where

—If Motorola or a software/application vendor

—Your mobile device can store personal

For information on how to backup or wipe data from your mobile device,

www.motorola.com/support

—Some mobile devices provide a Motorola online account

—Location-based information includes

require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

• Other information your device may transmit

testing and other diagnostic (including location-based) information, and other non-personal information to Motorola or other third-party servers. This

information is used to help improve products and services offered by Motorola. If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at privacy@motorola.com

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas—for example, handsfree use only. Go to (in English only) for more information.

Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your mobile device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as speed

dial and redial.

taking your attention off the road.

• When available, use a handsfree device.

an additional layer of convenience to your mobile device with

one of the many Motorola Original handsfree accessories

available today.

• Position your mobile device within easy reach.

access your mobile device without removing your eyes from the road. If you

receive an incoming call at an inconvenient time, if possible, let your voicemail

answer it for you.

, or contact your service provider.

Drive Safe, Call Smart

If available, these features help you to place your call without

—Your device may also transmit

www.motorola.com/callsmart

If possible, add

Be able to

• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

sleet, snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

“to do” list or going through your address book takes attention away from your primary responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your car is not moving or before pulling into traffic.

moving, dial only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be distracting.

suspend conversations that can divert your attention away from the road.

• Use your mobile device to call for help.

number in the case of fire, traffic accident, or medical emergencies (wherever wireless phone service is available).

• Use your mobile device to help others in emergencies.

accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number (wherever wireless phone service is available), as you would want others to do for you.

• Call roadside assistance or a special non-emergency wireless assistance number when necessary.

posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number (wherever wireless phone service is available).

Make people you are talking with aware you are driving and

If you must make a call while

Dial 911 or other local emergency

If you see a broken-down vehicle

Rain,

Jotting down a

If you see an auto

Motorola, Inc. Consumer Advocacy Office 600 N US Hwy 45 Libertyville, IL 60048 www.hellomoto.com

Note:

Do not ship your phone to the above address. If you need to return your phone for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at: 1-800-734-5870 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Microsoft, Windows, Windows Me, and Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries. Google, YouTube, Picasa, Gmail, and the Google logo are trademarks of Google, Inc. is a Certification Mark of the Wireless Fidelity Alliance, Inc. All other product or service names are the property of their respective owners. © 2010 Motorola, Inc. All rights reserved.

Caution:

Changes or modifica tions made in the radio phone, not expressly approved

by Motorola, will void the user’s authority to operate the equipment.

Bluetooth ID: B016118

MOTOROLA ZEPPELIN with MOTOBLUR (MB501) Manual Number: TBD-A

Motorola P56KZ1 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Congratulations

Your phone

Contents

Let’s go

Assemble & charge

Set up & go

Turn it on & off

Wi-Fi connect

Cool content & more

Security

Basics

Quick start: Home screen

Search

Phone status & notifications

Set up & manage your home screen

Touch tips

Key tips

Adjust volume

Spin the screen

App menu

Text entry

Touchscreen keypad

Text entry settings

Tips & tricks

Battery tips

MOTOBLUR

Your MOTOBLUR account

What is MOTOBLUR?

Social networking

About social networking

View accounts & update status

Add accounts

Remove accounts

Calls

Quick start: Calls

Make calls

Answer calls

End calls

Use keypad while on a call

Use speed dial

Access recent calls

Access frequent calls

Call forwarding & waiting

Restrict outgoing calls

Find your phone number

Your caller ID

Use the speakerphone

Mute & hold

Make conference calls

Use voice dial

TTY mode

Emergency calls

myFaves

Add myFaves contacts

Edit myFaves contacts

Replace myFaves contacts

Move myFaves contacts

Call myFaves contacts

Send email messages

Send text messages

Send IM messages

View activity log

Download new icons

Contacts & Mobile Backup

Quick start: Contacts

About Mobile Backup

About MOTOBLUR

Access contacts

Create new contacts

Edit contact information

Call contacts

Send text messages to contacts

Link contacts

Import contacts from SIM

My details

Groups
