MVME2300SC

VME Processor Module

Installation and Use

V2300SCA/IH2

Edition of Ma rch 2001

© Copyright 2001 Motorola, Inc.

All rights reserved.

Printed in the United States of America.

Motorola

PowerPC

®

and the Motorola logo are registered trademarks of Motorola, Inc.

®

is a registered trademark of International Business Machines Corporation and

is used by Motorola with permission.

All other products mentioned in this document are trademarks or registered trademarks of
their respective holders.

Safety Summary

The following general safety precautions must be observed during all phases of operation, service, and repair of this
equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual could result
in personal injury or damage to the equipment.

The safety precautions listed below represent warnings of certain dangers of which Motorola is aware. You, as the user
of the product, should follow these warnings and all other safety precautions necessary for the safe operation of the
equipment in your operating environment.

Ground the Instrument.

To minimize shock hazard, the equipment chassis and enclosure must be connected to an electrical ground. If the
equipment is supplied with a three-conductor AC power cable, the power cable must be plugged into an approved
three-contact electrical outlet, with the grounding wire (green/yellow) reliably connected to an electrical ground
(safety ground) at the power outlet. The power jack and mating plug of the power cable meet International
Electrotechnical Commission (IEC) safety standards and local electrical regulatory codes.

Do Not Operate in an Explosive Atmosphere.

Do not operate the equipment in any explosive atmosphere such as in the presence of flammable gases or fumes.
Operation of any electrical equipment in such an environment could result in an explosion and cause injury or damage.

Keep Away From Live Circuits Inside the Equipment.

Operating personnel must not remove equipment covers. Only Factory Authorized Service Personnel or other
qualified service personnel may remove equipment covers for internal subassembly or component replacement or any
internal adjustment. Service personnel should not replace components with power cable connected. Under certain
conditions, dangerous voltages may exist even with the power cable removed. To avoid injuries, such personnel should
always disconnect power and discharge circuits before touching components.

Use Caution When Exposing or Handling a CRT.

Breakage of a Cathode-Ray Tube (CRT) causes a high-velocity scattering of glass fragments (implosion). To prevent
CRT implosion, do not handle the CRT and avoid rough handling or jarring of the equipment. Handling of a CRT
should be done only by qualified service personnel using approved safety mask and gloves.

Do Not Substitute Parts or Modify Equipment.

Do not install substitute parts or perform any unauthorized modification of the equipment. Contact your local
Motorola representative for service and repair to ensure that all safety features are maintained.

Observe Warnings in Manual.

Warnings, such as the example below, precede potentially dangerous procedures throughout this manual. Instructions
contained in the warnings must be followed. You should also employ all other safety precautions which you deem
necessary for the operation of the equipment in your operating environment.

To prevent serious injury or death from dangerous voltages, use extreme
caution when handling, testing, and adjusting this equipment and its

Warning

components.

Flammability

All Motorola PWBs (printed wiring boards) are manufactured with a flammability rating
of 94V-0 by UL-recognized manufacturers.

EMI Caution

This equipment generates, uses and can radiate electromagnetic energy. It

!

Caution

This product contains a lithium battery to power the clock and calendar circuitry.

!

Caution

may cause or be susceptible to electromagnetic interference (EMI) if not
installed and used with adequate EMI protection.

Lithium Battery Caution

Danger of explosion if battery is replaced incorrectly. Replace battery only
with the same or equivalent type recommended by the equipment
manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.

!

Attention

!

Vorsicht

Il y a danger d’explosion s’il y a remplacement incorrect de la batterie.
Remplacer uniquement avec une batterie du même type ou d’un type
équivalent recommandé par le constructeur. Mettre au rebut les batteries
usagées conformément aux instructions du fabricant.

Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur
durch denselben oder einen vom Hersteller empfohlenen Typ. Entsorgung
gebrauchter Batterien nach Angaben des Herstellers.

CE Notice (European Community)

Motorola Computer Group products with the CE marking comply with the EMC Directive
(89/336/EEC). Compliance with this directive implies conformity to the following
European Norms:

EN55022 “Limits and Methods of Measurement of Radio Interference Characteristics
of Information Technology Equipment”; this product tested to Equipment Class B

EN50082-1:1997 “Electromagnetic Compatibility—Generic Immunity Standard, Part

1. Residential, Commercial and Light Industry”

System products also fulfill EN60950 (product safety) which is essentially the requirement
for the Low Voltage Directive (73/23/EEC).

Board products are tested in a representative system to show compliance with the above
mentioned requirements. A proper installation in a CE-marked system will maintain the
required EMC/safety performance.

In accordance with European Community directives, a “Declaration of Conformity” has
been made and is on file within the European Union. The “Declaration of Conformity” is
available on request. Please contact your sales representative.

Notice

While reasonable efforts have been made to assure the accuracy of this document,
Motorola, Inc. assumes no liability resulting from any omissions in this document, or from
the use of the information obtained therein. Motorola reserves the right to revise this
document and to make changes from time to time in the content hereof without obligation
of Motorola to notify any person of such revision or changes.

Electronic versions of this material may be read online, downloaded for personal use, or
referenced in another document as a URL to the Motorola Computer Group website. The
text itself may not be published commercially in print or electronic form, edited, translated,
or otherwise altered without the permission of Motorola, Inc.

It is possible that this publication may contain reference to or information about Motorola
products (machines and programs), programming, or services that are not available in your
country. Such references or information must not be construed to mean that Motorola
intends to announce such Motorola products, programming, or services in your country.

Limited and Restricted Rights Legend

If the documentation contained herein is supplied, directly or indirectly, to the U.S.
Government, the following notice shall apply unless otherwise agreed to in writing by
Motorola, Inc.

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in
subparagraph (b)(3) of the Rights in Technical Data clause at DFARS 252.227-7013 (Nov.

1995) and of the Rights in Noncommercial Computer Software and Documentation clause
at DFARS 252.227-7014 (Jun. 1995).

Motorola, Inc.
Computer Group
2900 South Diablo Way
Tempe, Arizona 85282

Contents

About this Manual

Summary of Changes.................................................................................................xvi

Overview of Contents ................................................................................................xvi

Comments and Suggestions ......................................................................................xvii

Conventions Used in This Manual...........................................................................xviii

CHAPTER 1 Hardware Preparation and Installation

Getting Started ...........................................................................................................1-1

Overview of Installation Procedure....................................................................1-1

Equipment Required ...........................................................................................1-3

Guidelines for Unpacking...................................................................................1-4

ESD Precautions .................................................................................................1-4

Preparing the Board ...................................................................................................1-5

MVME2300SC ...................................................................................................1-6

Flash Bank Selection (J8)............................................................................1-8

VMEbus System Controller (J9) .................................................................1-9

General-Purpose Readable Jumpers (J10)...................................................1-9

PMCs ................................................................................................................1-10

PMCspan...........................................................................................................1-10

Installing the Hardware............................................................................................1-11

PMC Modules...................................................................................................1-11

Primary PMCspan Module ...............................................................................1-13

Secondary PMCspan Module ...........................................................................1-16

MVME2300SC .................................................................................................1-18

System Console Terminal .................................................................................1-20

Installation Considerations ...............................................................................1-21

CHAPTER 2 Startup and Operation

Introduction................................................................................................................2-1

Switches and LEDs.............................................................................................2-1

Initial Conditions .......................................................................................................2-2

Applying Power .........................................................................................................2-3

Pre-Startup Checklist .................................................................................................2-4

Bringing up the Board................................................................................................2-5

vii

Autoboot.............................................................................................................2-7

ROMboot............................................................................................................ 2-8

Network Boot .....................................................................................................2-9

Restarting the System ................................................................................................ 2-9

Reset .................................................................................................................2-10

Abort................................................................................................................. 2-11

Break ................................................................................................................ 2-11

Diagnostic Facilities ................................................................................................ 2-11

CHAPTER 3 PPCBug Firmware

Overview ...................................................................................................................3-1

PPCBug Basics..........................................................................................................3-1

PPCBug Implementation ...........................................................................................3-2

Memory Requirements....................................................................................... 3-3

Using PPCBug...........................................................................................................3-3

Debugger Commands ................................................................................................ 3-4

Diagnostic Tests.................................................................................................. 3-8

Modifying the Environment ......................................................................................3-9

CNFG - Configure Board Information Block ..................................................3-10

ENV - Set Environment ...................................................................................3-11

Configuring the PPCBug Parameters........................................................ 3-12

Configuring the VMEbus Interface...........................................................3-21

CHAPTER 4 Functional Description

Introduction ...............................................................................................................4-1

Summary of Features................................................................................................. 4-1

General Description...................................................................................................4-3

MPC604 Processor............................................................................................. 4-3

I/O Implementation ............................................................................................ 4-4

ASICs .................................................................................................................4-5

DRAM Memory .................................................................................................4-5

DRAM Latency........................................................................................... 4-7

Flash Memory.....................................................................................................4-9

Flash Latency ............................................................................................4-10

Ethernet Interface ............................................................................................. 4-11

PCI Mezzanine Card (PMC) Interface ............................................................. 4-12

PMC Slot 1 (Single-Width PMC) .............................................................4-13

PMC Slot 2 (Single-Width PMC) .............................................................4-13

PMC Slots 1 and 2 (Double-Width PMC) ................................................4-14

viii

PCI Expansion ...........................................................................................4-14

VMEbus Interface.............................................................................................4-14

Asynchronous Debug Port................................................................................4-15

PCI/ISA Bridge (PIB) Controller .....................................................................4-15

Real-Time Clock/NVRAM/Timer Function.....................................................4-16

PCI Host Bridge................................................................................................4-17

Interrupt Controller (MPIC)..............................................................................4-17

Programmable Timers.......................................................................................4-17

Interval Timers ..........................................................................................4-18

16/32-Bit Timers........................................................................................4-18

Connectors ........................................................................................................4-19

Status Indicators ........................................................................................4-20

10/100 BASET Port...................................................................................4-20

DEBUG Port..............................................................................................4-20

CHAPTER 5 Pin Assignments

Connector Pin Assignments.......................................................................................5-1

VMEbus Connectors (P1, P2).............................................................................5-1

Serial Port Connector - DEBUG (J2) .................................................................5-4

Ethernet Connector - 10BASET (J3)..................................................................5-4

CPU Debug Connector - J1 ................................................................................5-5

PCI Expansion Connector - J6..........................................................................5-10

PCI Mezzanine Card Connectors - J11 through J14.........................................5-12

PCI Mezzanine Card Connectors - J21 through J24.........................................5-15

APPENDIX A Specifications

Board Specifications .................................................................................................A-1

Cooling Requirements ..............................................................................................A-3

EMC Regulatory Compliance...................................................................................A-4

APPENDIX B Troubleshooting

Solving Startup Problems .........................................................................................B-1

APPENDIX C Related Documentation

Motorola Computer Group Documents ....................................................................C-1

Manufacturers’ Documents....................................................................................... C-2

Related Specifications............................................................................................... C-5

ix

Glossary

Index

x

List of Figures

Figure 1-1. MVME2300SC Layout ...........................................................................1-7

Figure 1-2. General-Purpose Software-Readable Header........................................1-10

Figure 1-3. Typical Single-width PMC Module Placement on MVME2300SC .....1-12

Figure 1-4. PMCspan-002 Installation on an MVME2300SC.................................1-15

Figure 1-5. PMCspan-010 Installation on a PMCspan-002/MVME2300SC ..........1-17

Figure 2-1. MVME2300SC/Firmware System Startup .............................................2-3

Figure 4-1. MVME2300SC Block Diagram..............................................................4-6

Figure 4-2. Memory Block Diagram .........................................................................4-7

xi

xii

List of T ables

Table 1-1. Startup Overview ......................................................................................1-1

Table 1-2. MVME2300SC Jumper Settings ..............................................................1-6

Table 2-1. MVME2300SC Front Panel Controls.......................................................2-1

Table 3-1. Debugger Commands ...............................................................................3-4

Table 3-2. Diagnostic Test Groups.............................................................................3-8

Table 4-1. MVME2300SC Features...........................................................................4-1

Table 4-2. Power Requirements .................................................................................4-4

Table 4-3. PPC604-Bus-to-DRAM Timing — 60ns Page Devices ...........................4-7

Table 4-4. PPC604-to-DRAM Timing — 50ns EDO Devices ..................................4-8

Table 4-5. PowerPC604-Bus-to-Flash Timing — Bank B (16-bit Port)..................4-11

Table 5-1. VMEbus Connector P1 Pin Assignments.................................................5-2

Table 5-2. VMEbus Connector P2 Pin Assignment...................................................5-3

Table 5-3. DEBUG (J2) Connector Pin Assignments................................................5-4

Table 5-4. 10/100 BASET (J3) Connector Pin Assignments.....................................5-4

Table 5-5. CPU Debug (J1) Connector Pin Assignments..........................................5-5

Table 5-6. J6 - PCI Expansion Connector (J6) Pin Assignments.............................5-10

Table 5-7. J11 - J12 PMC1 Connector Pin Assignments.........................................5-13

Table 5-8. J13 - J14 PMC1 Connector Pin Assignments.........................................5-14

Table 5-9. J21 and J22 PMC2 Connector Pin Assignments ....................................5-16

Table 5-10. J23 and J24 PMC2 Connector Pin Assignments ..................................5-17

Table A-1. MVME2300SC Specifications ..............................................................A-1

Table B-1. Troubleshooting MVME2300SC Modules ............................................B-1

xiii

xiv

About This Manual

MVME2300SC VME Processor Module Installation and Use provides

information you will need to install and use your MVME2300SC VME
processor module. It includes instructions for hardware preparation and
installation; a board-level hardware overview; and firmware-related
general information and startup instructions.

The MVME2300SC VME processor module is based on an MPC604
PowerPC microprocessor, and features dual PCI Mezzanine Card (PMC)
slots with front panel and/or P2 I/O. As of the publication date, the
information presented in this manual applies to the following
MVME2300SC models:

Model Processor Memory

MVME2306SC-1

MVME2307SC-1 64MB ECC DRAM

The MVME2300SC VME processor module is compatible with optional
double-width or single-width PCI Mezzanine Cards (PMCs), and with the
PMCspan PCI expansion mezzanine module. By utilizing the two onboard
PMC slots and stacking PMCspan(s), the MVME2300SC provides support
for up to six PMCs.

MPC604
@ 300 MHz

32MB ECC DRAM

The information in this manual applies principally to the MVME2300SC
module. The PMCspan and PMC modules are described briefly here but
are documented in detail in separate publications, furnished with those
products. Refer to the individual product documentation for complete
preparation and installation instructions. These manuals are listed in

Appendix C, Related Documentation.

This manual is intended for anyone who designs OEM systems, adds
capability to an existing compatible system, or works in a lab environment
for experimental purposes. A basic knowledge of computers and digital
logic is assumed. To use this manual, you may also wish to become

familiar with the publications listed in the Related Documentation section

in Appendix C.

xv

Summary of Changes

This is the third edition of MVME2300SC Installation and Use. It

supersedes the April 1999 edition and incorporates the following updates.

Date Description of Change

April 1999 Tables C-8 and C-10 were updated to supply corrected pinout information for

PMC connectors J14 and J24.

March 2001 In the descriptions of the general-purpose software-readable header (J10) in

Chapter 1 and 2, information on bit 1 (SRH1) has been updated to correctly
reflect the functionality of that bit.

In addition, the contents of the manual were reorganized in line with present
Computer Group practice for board manuals.

Overview of Contents

Chapter 1, Hardware Preparation and Installation, provides unpacking

instructions, hardware preparation guidelines, and installation instructions
for the MVME2300SC VME processor module.

Chapter 2, Startup and Operation, provides information on powering up

the MVME2300SC VME processor module after its installation in a
system and describes the functionality of the switches, status indicators,
and I/O ports.

xvi

Chapter 3, PPCBug Firmware, describes the basics of PPCBug and its

architecture, describes the monitor (interactive command portion of the
firmware) in detail, and gives information on using the debugger and
special commands.

Chapter 4, Functional Description, describes the MVME2300SC VME

processor module on a block diagram level.

Chapter 5, Pin Assignments, summarizes the pin assignments for the

various groups of interconnect signals on the MVME2300SC.

Appendix A, Specifications, lists the general specifications for the

MVME2300SC VME processor module. Subsequent sections of the
appendix detail cooling requirements and EMC regulatory compliance.

Appendix B, Troubleshooting, includes simple troubleshooting steps to

follow in the event that you have difficulty with your MVME2300SC
VME processor module.

Appendix C, Related Documentation, lists all documentation related to the

MVME2300SC.

Comments and Suggestions

Motorola welcomes and appreciates your comments on its documentation.
We want to know what you think about our manuals and how we can make
them better. Mail comments to:

Motorola Computer Group
Reader Comments DW164
2900 S. Diablo Way
Tempe, Arizona 85282

You can also submit comments to the following e-mail address:

n all your correspondence, please list your name, position, and company.

I
Be sure to include the title and part number of the manual and tell how you
used it. Then tell us your feelings about its strengths and weaknesses and
any recommendations for improvements.

xvii

Conventions Used in This Manual

The following typographical conventions are used in this document:

bold

is used for user input that you type just as it appears; it is also used for
commands, options and arguments to commands, and names of
programs, directories and files.

italic

is used for names of variables to which you assign values. Italic is also
used for comments in screen displays and examples, and to introduce
new terms.

courier

is used for system output (for example, screen displays, reports),
examples, and system prompts.

<Enter>, <Return> or <CR>

<CR> represents the carriage return or Enter key.

CTRL

xviii

represents the Control key. Execute control characters by pressing the

Ctrl key and the letter simultaneously, for example, Ctrl-d.

A character precedes a data or address parameter to specify the numeric
format, as follows:

$ Specifies a hexadecimal character
0x Specifies a hexadecimal number
% Specifies a binary number
& Specifies a decimal number

An asterisk (∗) following a signal name for signals that are level signifi cant
denotes that the signal is true or valid when the signal is low. An asterisk
(∗) following a signal name for signals that are edge significant denotes

that the actions initiated by that signal occur on high to low transition.

1Hardware Preparation and

Installation

Getting Started

This chapter provides unpacking instructions, hardware preparation
guidelines, and installation instructions for the MVME2300SC VME
processor module. The section below supplies an overview of the
preparation and startup process.

Overview of Installation Procedure

The following table lists the things you will need to do to use this board
and tells where to find the information you need to perform each step. Be
sure to read this entire chapter, including all Cautions and Warnings,
before you begin.

Table 1-1. Startup Overview

What you need to do ... Refer to ... On

page ...

Unpack the hardware. Guidelines for Unpacking 1-4

Configure jumpers on
the MVME2300SC
module.

Prepare the PMCs. Preparing the Board, PMCs 1-10

Prepare the PMCspan
module(s), if necessary.

Install the PMCs on the
MVME2300SC module.

Preparing the Board, MVME2300SC 1-6

For additional information on PMCs, refer to the PMC
manuals provided with those cards.

Preparing the Board, PMCspan 1-10

For more information on PMCspan expansion modules,

refer to the PMCspan PMC Adapter Carrier Module

Installation and Use manual, listed in Appendix C,
Related Documentation.

Installing the Hardware, PMC Modules 1-11

For additional information on PMCs, refer to the PMC

manuals provided with those cards.

1

1-1

1

Hardware Preparation and Installation

Table 1-1. Startup Overview (Continued)

What you need to do ... Refer to ... On

page ...

Install the primary
PMCspan module (if
used).

Install the secondary
PMCspan module (if
used).

Install and connect the
MVME2300SC module.

Connect a console
terminal, if necessary.

Connect any other
optional devices or
equipment you will be
using.

Power up the system. Startup and Operation 2-1

Note that the debugger
firmware initializes the
MVME2300SC.

Initialize the system
clock.

Installing the Hardware, Primary PMCspan Module 1-13

For additional information on PMCspan modules, refer

to the PMCspan PMC Adapter Carrier Module

Installatio n an d Us e manual, listed in Appendix C,
Related Documentation.

Installing the Hardware, Secondary PMCspan Module 1-16

For additional information on PMCspan modules, refer

to the PMCspan PMC Adapter Carrier Module

Installatio n an d Us e manual, listed in Appendix C,
Related Documentation.

Installing the Hardware, MVME2300SC 1-18

Installing the Hardware, System Console Terminal 1-20
Installation Considerations 1-21
Connector Pin Assignments 5-1

For more information on optional devices and
equipment, refer to the documentation provided with
that equipment.

Troubleshooting B-1
PPCBug Firmware, Using PPCBug 3-3
You may also wish to obtain the PPCBug Diagnostics

Manual, listed in Appendix C, Related
Documentation.

PPCBug Firmware, Debugger Commands 3-4

1-2 Computer Group Literature Center Web Site

Getting Started

Table 1-1. Startup Overview (Continued)

What you need to do ... Refer to ... On

Examine and/or change
environmental
parameters.

Program the
MVME2300SC module
and PMCs as needed for
your applications.

ENV - Set Environment 3-11
You may also wish to obtain the PPCBug Firmware

Package User’s Manual, listed in Appendix C, Related
Document atio n.

MVME2300 Series VME Processor Module
Programmer’s Reference Guide, listed in Appendix C,
Related Documentation

For additional information on PMCs, refer to the PMC
manuals provided with those cards.

Equipment Required

The following equipment is necessary to complete an MVME2300SC
system:

1

page ...

1-3

❏ VME system enclosure

❏ System console terminal

❏ Operating system (and / or application software)

❏ Disk drives (and / or other I/O) and controllers

1

Hardware Preparation and Installation

Guidelines for Unpacking

Note If the shipping carton is damaged upon receipt, request that the

carrier’s agent be present during the unpacking and inspection of
the equipment.

Unpack the equipment from the shipping carton. Refer to the packing list
and verify that all items are present. Save the packing material for storing
and reshipping of equipment.

!

Caution

Avoid touching areas of integrated circuitry; static discharge can damage
circuits.

ESD Precautions

This section applies to all hardware installations you may perform that
involve the MVME2300SC board.

Motorola strongly recommends the use of an antistatic wrist strap and a
conductive foam pad when you install or upgrade the board. Electronic
components can be extremely sensitive to ESD. After removing the board
from the chassis or from its protective wrapper, place the board flat on a
grounded, static-free surface, component side up. Do not slide the board
over any surface.

If no ESD station is available, you can avoid damage resulting from ESD
by wearing an antistatic wrist strap (available at electronics stores). Place
the strap around your wrist and attach the grounding end (usually a piece
of copper foil or an alligator clip) to an electrical ground. An electrical
ground can be a piece of metal that literally runs into the ground (such as
an unpainted metal pipe) or a metal part of a grounded electrical appliance.
An appliance is grounded if it has a three-prong plug and is plugged into a
three-prong grounded outlet. You cannot use the chassis in which you are
installing the MVME2300SC itself as a ground, because the enclosure is
unplugged while you work on it.

1-4 Computer Group Literature Center Web Site

Turn the system’s power off before you perform these procedures. Failure

!

Warning

to turn the power off before opening the enclosure can result in personal
injury or damage to the equipment. Hazardous voltage, current, and energy
levels are present in the chassis. Hazardous voltages may be present on
power switch terminals even when the power switch is off. Never operate
the system with the cover removed. Always replace the cover before
powering up the system.

Preparing the Board

To produce the desired configuration and ensure proper operation of the
MVME2300SC, you may need to reconfigure hardware to some extent
before installing the module.

Most options on the MVME2300SC are under software control: By setting
bits in control registers after installing the module in a system, you can
modify its configuration. (The MVME2300SC registers are briefly

described in Chapter 3 under ENV – Set Environment, with additional
information in the MVME2300 Series VME Processor Module

Programmer's Reference Guide as listed in Appendix C, Related
Documentation.)

Preparing the Board

1

1-5

Some options, though, are not software-programmable. Such options are
either set by configuration switches or are controlled through physical
installation or removal of header jumpers or interface modules on the
MVME2300SC or its associated modules.

1

Hardware Preparation and Installation

MVME2300SC

Figure 1-1 illustrates the placement of the jumper headers, connectors, and

various other components on the MVME2300SC. Manually configurable
jumper headers on the MVME2300SC are listed in the following table
(with default settings enclosed in brackets).

Table 1-2. MVME2300SC Jumper Settings

Jumper Function Settings

J8 Flash bank selection

[1-2]

2-3

Flash bank A enabled (4MB, soldered).
Flash bank B enabled (1MB, sockets).

J9

J10

VMEbus system
controller selection

General-purpose
readable jumper
configuration

No jumper

1-2

[2-3]

3-4 empty

[3-4]

System controller.
Not system controller.
Automatic system controller.

Firmware defaults (in Flash) selected.
NVRAM selected.
Other headers are user-definable. Factory
configuration has all jumpers installed.

Notes Items in brackets are factory default settings.

J5 and J7 are for factory use only.

MVME2300SC boards are tested and shipped with the jumper

configurations summarized in Table 1-2. The factory-installed debug

monitor, the PPCBug firmware, operates with those factory settings.

1-6 Computer Group Literature Center Web Site

Preparing the Board

1

DEBUG

ABT

RST

10/100 BASET

PCI MEZZANINE CARD PCI MEZZANINE CARD

BFL

CPU

SCON

FUS

189 190

BATTERY

DEBUG

PORT

J2

DS

SWITCH

1

ABORT

S1 S2

J3

SWITCH

PORT

RESET

ETHERNET

DS

2

DS

3

DS

4

XU2

FLASH SOCKETS

XU1

J1

12

PMC 2 PMC1

1

1

264

J21

63

63

1

1

264

J23

63

63

1

1

264

J11

A1B1C1

264

A32

B32

C32

J22

264

J24

A1B1C1

264

J12

P1

2386 9810

1-7

J5

1

3

1

3

8

J9

J8

J7

1

3

1

J10

21

113 114

16 15

Figure 1-1. MVME2300SC Layout

63

63

1

1

J13

63

J6

264

264

J14

63

12

C32

B32

A32

VME BUS

P2

1

Hardware Preparation and Installation

Flash Bank Selection (J8)

The MVME2300SC VMEmodule has provision for 1MB of 8-bit Flash
memory for the on-board firmware (or for customer-specific applications)
in two 32-pin PLCC sockets that constitute Flash bank B.

In addition, the MVME2300SC accommodates 4MB of firmware resident
on four soldered-in devices (Flash bank A) specifically for customer use.
Bank A consists of four 16-bit Smart Voltage SMT devices populated with
8Mbit Flash devices (for a total of 4 MB).

Both banks contain the on-board firmware, PPCBug. The setting of a
jumper header (J8 on the MVME2300SC) determines whether the board
fetches its reset vector from bank A or from bank B. To enable Flash bank
A, place a jumper across header J8 pins 1-2. To enable Flash bank B, place
a jumper across header J8 pins 2-3. The factory configuration uses Flash
bank B.

J8

1
2

3

Flash Bank A Enabled (2MB/4MB, Soldered)

J8

1
2

3

Flash Bank B Enabled (1MB, Sockets)

(factory configuration)

1-8 Computer Group Literature Center Web Site

VMEbus System Controller (J9)

The MVME2300SC is factory-configured in ‘‘automatic’’ system

controller mode (i.e., a jumper is installed across pins 2 and 3 of header J9).
This means that at system power-up or reset, the MVME2300SC
determines whether it is system controller by its position on the bus; if it
occupies slot 1 on the VME system, it configures itself as the system
controller.

Remove the jumper from J9 if you intend to operate the MVME2300SC as
system controller in all cases.

Install the jumper across pins 1 and 2 if the MVME2300SC is not to
operate as system controller under any circumstances.

Preparing the Board

1

J9

1
2

3

Automatic System Controller

(factory configuration)

System Controller Enabled

General-Purpose Readable Jumpers (J10)

Header J10 provides eight software-readable jumpers. These jumpers can
be read as a register at ISA I/O address $801 (hexadecimal). Bit 0 is
associated with header pins 1-2; bit 7 is associated with pins 15-16. The bit
values are read as a

0 when a jumper is installed, or as a 1 when the jumper

is removed.

The PowerPC firmware, PPCBug, reserves all bits, SRH0 to SRH7. The
MVME2300SC is shipped from the factory with J10 set to all
on all pins), as shown below and in Figure 1-2.

J9

1
2

3

System Controller Disabled

J9

1
2

3

0s (jumpers

1-9

1

Hardware Preparation and Installation

PMCs

PPCBug INSTALLED

Reserved for future use

Reserved for future use

Reserved for future use

Reserved for future use

Reserved for future use

Reserved for future use

Reserved for future use

16Bit 7 (SRH7)

Reserved for future use

Bit 0 (SRH0)

Bit 1 (SRH1)

Bit 2 (SRH2)

Bit 3 (SRH3)

Bit 4 (SRH4)

Bit 5 (SRH5)

Bit 6 (SRH6)

J10

12

15

Figure 1-2. General-Purpose Software-Readable Header

For a discussion of any configurable items on the PMCs (PCI Mezzanine
Cards) that you are using, refer to the user’s manual for the PMCs in
question.

PMCspan

You will need to use an additional slot in the VME chassis for each
PMCspan expansion module you plan to use. Before installing a PMCspan
module on the MVME2300SC, you must first install the selected PMCs on

the PMCspan module. Refer to the PMCspan PMC Adapter Carrier
Module Installation and Use manual for instructions.

1-10 Computer Group Literature Center Web Site

Installing the Hardware

This section covers:

❏ Installation of PMCs and PMCspan modules on the MVME2300SC

❏ Installation of the assembly in a VME chassis

❏ System considerations relevant to the installation

PMC Modules

PCI mezzanine card (PMC) modules mount on top of the MVME2300SC,
and/or on a PMCspan module. Refer to Figure 1-3 and perform the
following steps to install a PMC on your MVME2300SC module. This
procedure assumes that you have read the user’s manual that came with
your PMCs.

1. Perform an operating system shutdown. Turn the AC or DC power
off and remove the AC cord or DC power lines from the system.
Remove chassis or system cover(s) as necessary for access to the
VME card cage.

Installing the Hardware

1

Caution

Warning

Caution

1-11

Inserting or removing modules with power applied may result

!

!

!

in damage to module components.

Dangerous voltages, capable of causing death, are present in
this equipment. Use extreme caution when handling, testing,
and adjusting.

2. If the MVME2300SC has already been installed in a VMEbus card
slot, carefully remove it. Lay the MVME2300SC flat, with
connectors P1 and P2 facing you.

Avoid touching areas of integrated circuitry; static discharge
can damage these circuits.

1

Hardware Preparation and Installation

3. Remove the PCI filler plate from the selected PMC slot in the front
panel of the MVME2300SC. If you are installing a double-width
PMC, remove the filler plates from both PMC slots.

4. Slide the front panel(s) of the PMC module into the front panel
opening(s) from behind and place the PMC module on top of the
MVME2300SC.

The PMC front panel should fit snugly and the four connectors on
the underside of the module should connect smoothly with the
corresponding connectors (J11/12/13/14 or J21/22/23/24 for a
single-width PMC, all eight for a double-width PMC) on the
MVME2300SC.

2387 9810

Figure 1-3. Typical Single-width PMC Module Placement on MVME2300SC

5. Insert the four short Phillips screws through the holes at the front
and rear corners of the PMC module, into the standoffs on the
MVME2300SC. Tighten the screws.

6. If you are installing two single-width PMCs, repeat the above
procedure for the second PMC.

1-12 Computer Group Literature Center Web Site

Primary PM Cspan Module

To install a PMCspan-002 PCI expansion module on your
MVME2300SC, refer to Figure 1-4 and perform the following steps. This
procedure assumes that you have read the user’s manual that was furnished
with the PMCspan module, and that you have installed the selected PMCs
on the PMCspan according to the instructions given in the PMCspan and
PMC manuals.

1. Perform an operating system shutdown. Turn the AC or DC power
off and remove the AC cord or DC power lines from the system.
Remove chassis or system cover(s) as necessary for access to the
VME card cage.

Inserting or removing modules with power applied may result

!

Caution

!

Warning

in damage to module components.

Dangerous voltages, capable of causing death, are present in
this equipment. Use extreme caution when handling, testing,
and adjusting.

Installing the Hardware

1

Caution

1-13

2. If the MVME2300SC has already been installed in the chassis,
carefully remove it from the VMEbus card slot and lay it flat, with
connectors P1 and P2 facing you.

Avoid touching areas of integrated circuitry; static discharge

!

can damage these circuits.

3. Attach the four standoffs to the MVME2300SC module. For each
standoff:

– Insert the threaded end into the standoff hole at each corner of

the VME processor module.

– Thread the locking nuts onto the standoff tips.

– Tighten the nuts with a box-end wrench or a pair of needle nose

pliers.

1

Hardware Preparation and Installation

4. Place the PMCspan on top of the MVME2300SC module. Align the
mounting holes in each corner to the standoffs, and align PMCspan
connector P4 with MVME2300SC connector J6.

5. Gently press the PMCspan and MVME2300SC together, making
sure that P4 is fully seated into J6.

6. Insert the four short Phillips screws through the holes at the corners
of the PMCspan and into the standoffs on the MVME2300SC
module. Tighten the screws.

Note The screws have two different head diameters. Use the

screws with the smaller heads on the standoffs next to
VMEbus connectors P1 and P2.

1-14 Computer Group Literature Center Web Site

P4

Installing the Hardware

SCREWS WITH SMALLER

HEADS HERE

1

1-15

J6

2388 9810

Figure 1-4. PMCspan-002 Installation on an MVME2300SC

1

Hardware Preparation and Installation

Secondar y PMCspan Module

The PMCspan-010 PCI expansion module mounts on top of a PMCspan­002 PCI expansion module. To install a PMCspan-010 on your
MVME2300SC, refer to Figure 1-5 and perform the following steps. This
procedure assumes that you have read the user’s manual that was furnished
with the PMCspan, and that you have installed the selected PMCs on the
PMCspan according to the instructions given in the PMCspan and PMC
manuals.

1. Perform an operating system shutdown. Turn the AC or DC power
off and remove the AC cord or DC power lines from the system.
Remove chassis or system cover(s) as necessary for access to the
VME card cage.

Inserting or removing modules with power applied may result

!

Caution

!

Warning

in damage to module components.

Dangerous voltages, capable of causing death, are present in
this equipment. Use extreme caution when handling, testing,
and adjusting.

2. If the Primary PMC Carrier Module/MVME2300SC assembly is
already installed in the VME chassis, carefully remove the two­board assembly from the VMEbus card slots and lay it flat, with the
P1 and P2 connectors facing you.

Avoid touching areas of integrated circuitry; static discharge

!

Caution

1-16 Computer Group Literature Center Web Site

can damage these circuits.

3. Remove the four short Phillips screws from the standoffs in each
corner of the primary PCI expansion module, PMCspan-002.

4. Attach the four standoffs to the PMCspan-002.

5. Place the PMCspan-010 on top of the PMCspan-002. Align the
mounting holes in each corner to the standoffs, and align PMCspan­010 connector P3 with PMCspan-002 connector J3.

Installing the Hardware

SCREWS WITH SMALLER

HEADS HERE

P3

1

J3

Figure 1-5. PMCspan-010 Installation on a PMCspan-002/MVME2300SC

1-17

2065 9708

1

Hardware Preparation and Installation

6. Gently press the two PMCspan modules together, making sure that
P3 is fully seated in J3.

7. Insert the four short Phillips screws through the holes at the corners
of PMCspan-010 and into the standoffs on the primary PMCspan-

002. Tighten the screws.

Note The screws have two different head diameters. Use the

screws with the smaller heads on the standoffs next to
VMEbus connectors P1 and P2.

MVME2300SC

Before installing the MVME2300SC into your VME chassis, ensure that
the jumpers on the MVME2300SC J7, J8, J9, and J10 headers are
configured, as previously described. This procedure assumes that you have
already installed the PMCspan module(s) if desired, and any PMCs that
you have selected.

Proceed as follows to install the MVME2300SC in the VME chassis:

1. Attach an ESD strap to your wrist. Attach the other end of the ESD

strap to an electrical ground (refer to Installation Preliminaries).

The ESD strap must be secured to your wrist and to ground
throughout the procedure.

a. Ensure that the AC or DC power is switched off and remove the

AC cord or DC power lines from the system.

!

Caution

!

Warning

1-18 Computer Group Literature Center Web Site

Inserting or removing modules while power is applied could result in
damage to module components.

Dangerous voltages, capable of causing death, are present in this
equipment. Use extreme caution when handling, testing, and adjusting.

2. Remove chassis or system cover(s) as instructed in the user’s
manual for the equipment.

3. Remove the filler panel from the card slot where you are going to
install the MVME2300SC. If you have installed one or more

!

Caution

Installing the Hardware

1

PMCspan PCI expansion modules onto your MVME2300SC, you
will need to remove filler panels from one additional card slot for
each PMCspan module, above the card slot for the MVME2300SC.

– If you intend to use the MVME2300SC as system controller, it

must occupy the leftmost card slot (slot 1). The system controller
must be in slot 1 to correctly initiate the bus-grant daisy-chain
and to ensure proper operation of the IACK daisy-chain driver.

– If you do not intend to use the MVME2300SC as system

controller, it can occupy any unused card slot.

Avoid touching areas of integrated circuitry; static discharge
can damage these circuits.

4. Slide the MVME2300SC (together with the PMCspan modules if
used) into the selected card slot(s). Be sure the module or modules
is/are seated properly in the P1 and P2 connectors on the backplane.
Do not damage or bend connector pins.

1-19

5. Secure the MVME2300SC (and PMCspan modules if used) in the
chassis with the screws provided, making good contact with the
transverse mounting rails to minimize RF emissions.

Note Some VME backplanes (e.g., those used in Motorola "Modular

Chassis" systems) have an autojumpering feature for automatic
propagation of the IACK and BG signals. Step 6 does not apply
to such backplane designs.

6. On the chassis backplane, remove the
(IACK) and
slot occupied by the MVME2300SC.

Note For slots occupied by PMCspan modules (if used), the IACK

and BG jumpers may be left in or taken out as you wish. The
P1 connector on PMCspan modules passes those signals
through.

BUS GRANT (BG) jumpers from the header for the card

INTERRUPT ACKNOWLEDGE

1

Hardware Preparation and Installation

7. If you intend to use PPCBug interactively, connect the terminal that
is to be used as the PPCBug system console to the
the front panel of the MVME2300SC.

In normal operation, the host CPU controls MVME2300SC
operation via the VMEbus Universe registers.

8. Replace the chassis or system cover(s), cable peripherals to the
panel connectors as appropriate, reconnect the system to the AC or
DC power source, and turn the equipment power on.

DEBUG port on

9. The MVME2300SC’s green
confidence tests is run, and the debugger prompt
appears.

System Console Terminal

To ready the system console terminal for use:

1. Confirm that jumpers were installed on all bits on header J10 of the
MVME2300SC board as shown in Figure 1-2. This is necessary
when the PPCBug firmware is used.

2. Connect the terminal via a cable to the DB9
See Table 5-3 for pin signal assignments. Set the terminal up as
follows:

– Eight bits per character

– One stop bit per character

– Parity disabled (no parity)

– Baud rate of 9600 baud

9600 baud is the power-up default for the serial port on the
MVME2300SC. After power-up you can reset the baud rate if you wish,

using the PPCBug firmware’s PF (Port Format) command via the

command line interface. Whatever the baud rate, some type of hardware
handshaking — either XON/XOFF or via the RTS/CTS line — is desirable
if the system supports it.

CPU LED indicates activity as a set of

PPC1-Bug>

DEBUG connector, J2.

1-20 Computer Group Literature Center Web Site

Installation Considerations

The MVME2300SC draws power from VMEbus backplane connectors P1
and P2. P2 is also used for the upper 16 bits of data in 32-bit transfers, and
for the upper 8 address lines in extended addressing mode. The
MVME2300SC may not function properly without its main board
connected to VMEbus backplane connectors P1 and P2.

In addition, the MVME2300SC routes 32 pins of I/O from PMC slot 1 and
32 pins of I/O from PMC slot 2 to a set of 32 shared pins on P2. This I/O
scheme gives both PMC slots access (via P2) to an SCSA (Signal
Computing System Architecture) backplane bus, if the system supports
one.

Whether the MVME2300SC operates as a VMEbus master or as a
VMEbus slave, it is configured for 32 bits of address and 32 bits of data
(A32/D32). However, it handles A16 or A24 devices in the address ranges
indicated in Chapter 4. D8 and/or D16 devices in the system must be
handled by the PowerPC processor software. For elaboration, refer to the
memory maps in Chapter 4.

The MVME2300SC contains shared onboard DRAM whose base address
is software-selectable. Both the onboard processor and off-board VMEbus
devices see this local DRAM at base physical address $00000000, as
programmed by the PPCBug firmware. This may be changed via software

to any other base address. Refer to the MVME2300SC Programmer’s
Reference Guide for more information.

If the MVME2300SC tries to access off-board resources in a nonexistent
location and is not system controller, and if the system does not have a
global bus timeout, the MVME2300SC waits indefinitely for the VMEbus
cycle to complete. This will cause the system to lock up. There is only one
situation in which the system might lack this global bus timeout: when the
MVME2300SC is not the system controller and there is no global bus
timeout elsewhere in the system.

Multiple MVME2300SC boards may be installed in a single VME chassis.
Each must have a unique Universe address, selected as described in the

‘‘VMEbus Interface’’ chapter of the Universe User Manual. In general,

hardware multiprocessor features are supported.

Other MPUs on the VMEbus can interrupt, disable, communicate with,
and determine the operational status of the processor(s). One register of the
Universe set includes four bits that function as location monitors to allow

Installing the Hardware

1

1-21

1

Hardware Preparation and Installation

one MVME2300SC processor to broadcast a signal to any other
MVME2300 series processors. All eight registers are accessible from any
local processor as well as from the VMEbus.

1-22 Computer Group Literature Center Web Site

2Startup and Operation

Introduction

This chapter provides information on powering up the MVME2300SC
VME processor module after its installation in a system, and describes the
functionality of the switches, status indicators, and I/O ports on the front
panels of the MVME2300SC and PMCspan modules.

For programming information, consult the MVME2300 Series VME
Processor Module Programmer’s Reference Guide as listed in Appendix
C, Related Documentation.

Switches and L EDs

There are two switches (ABT and RST) and four LED (light-emitting diode)
status indicators (
front panel.

2

BFL, CPU, SCON and FUS) located on the MVME2300SC

Table 2-1. MVME2300SC Front Panel Controls

Control/Indicator Function

Abort Switch (

Reset Switch (RST) Resets all onboard devices. Also asserts the HRESET∗ line in the

ABT) Sends an interrupt signal to the processor. The interrupt is normally used

to abort program execution and return control to the debugger firmware
located in the MVME2300SC Flash memory.

The interrupter connected to the ABT switch is an edge-sensitive
circuit, filtered to remove switch bounce.

MPC604 and drives a

system controller. SYSRESET∗ signals may be generated by the

Reset switch, a power-up reset, a watchdog timeout, or by a
control bit in the Miscellaneous Control Register (MISC_CTL) in
the Universe ASIC. For further details, refer to Chapter 4,

Functional Description.

SYSRESET∗ signal if the MVME2300SC is

2-1

Startup and Operation

2

Table 2-1. MVME2300SC Front Panel Controls

Control/Indicator Function

BFL LED (yellow) Board failure. Lights when the BRDFAIL∗ signal line is active.
CPU LED (green) CPU activity. Lights when the DBB∗ (Data Bus Busy) signal line on

the processor bus is active.

SCON LED (green) System controller. Lights when the MVME2300SC is functioning as

VMEbus system controller.

FUS LED (green) Fuse OK. Indicates that +5Vdc and +12Vdc power is available on the

. (–12Vdc is not fused.)

board

Initial Conditions

After you have verified that all necessary hardware preparation has been
done, that all connections have been made correctly, and that the
installation is complete, you can power up the system. Applying power to
the system (as well as resetting it) triggers an initialization of the
MVME2300SC’s MPU, hardware, and firmware along with the rest of the
system.

The Flash-resident firmware initializes the devices on the MVME2300SC
board in preparation for booting the operating system. The firmware is
shipped from the factory with a set of defaults appropriate to the board. In
most cases there is no need to modify the firmware configuration before
you boot the operating system. For specifics in this regard, refer to Chapter
3 and to the user documentation for the PPCBug firmware.

2-2 Computer Group Literature Center Web Site

Applying Power

Applying Power

When you power up (or when you reset) the system, the firmware executes
some self-checks and proceeds to the hardware initialization. The system
startup flows in a predetermined sequence, following the hierarchy
inherent in the processor and the MVME2300SC hardware. The figure
below charts the flow of the basic initialization sequence that takes place
during system startup.

STARTUP

INITIALIZATION

POST

Power-up/reset initialization

Initialization of devices on the MVME2300SC
module/system

Power-On Self-Test diagnostics

2

2-3

BOOTING

MONITOR

Firmware-configured boot mechanism,
if so configured. Default is no boot.

Interactive, command-driven on-line
debugger, when terminal connected.

Figure 2-1. MVME2300SC/Firmware System Startup

Startup and Operation

2

Pre-Startup Checklist

Before you power up the MVME2300SC system, be sure that the
following conditions exist:

1. Jumpers and/or configuration switches on the MVME2300SC VME
processor module and associated equipment are set as required for
your particular application.

2. The MVME2300SC board is installed and cabled up as appropriate
for your particular chassis or system, as outlined in Chapter 1.

3. The terminal that you plan to use as the system console is connected
to the console port (serial port 1) on the MVME2300SC module.

4. The terminal is set up as follows:

– Eight bits per character

– One stop bit per character

– Parity disabled (no parity protection)

– Baud rate 9600 baud (the default baud rate of many serial ports

at power-up)

5. Any other device that you wish to use, such as a host computer
system and/or peripheral equipment, is cabled to the appropriate
connectors.

After you complete the checks listed above, you are ready to power up the
system.

2-4 Computer Group Literature Center Web Site

Bringing up the Board

Bringing up the Board

The MVME2300SC comes with PPCBug firmware installed. For the
firmware to operate properly with the board, you must follow the steps
below.

!

Caution

Inserting or removing boards with power applied may damage board
components.

Turn all equipment power OFF. Refer to Prepari ng the Board on page 1-5

and verify that jumpers and switches are configured as necessary for your
particular application.

1. Header J8 determines whether the on-board firmware, PPCBug,
initializes from Flash memory bank A (4MB, soldered) or from
Flash bank B (1MB, socketed). The factory configuration has the
jumper installed on J8 pins 1-2, enabling Flash bank B. Verify that
this setting is appropriate for your application.

2. Verify that header J9 is configured as appropriate for the desired
system controller functionality (always system controller, never
system controller, or self-regulating) on the MVME2300SC.

2

2-5

3. Configuration header J10 on the MVME2300SC contains eight
software-readable jumper segments, which all affect the operation
of the firmware. They are read as a register at ISA I/O address $801.

(The MVME2300 Series VME Processor Module Programmer’s
Reference Guide supplies information on register accesses.) The bit
values are read as a 0 when a jumper is installed on the
corresponding header segment, or as a 1 when the jumper is

removed from that segment.

The default configuration for the board has J10 set to all
installed on all pins). The PPCBug firmware reserves/defines all
bits, SRH0 to SRH7.

4. Verify that the settings of any configuration switches or jumpers
that are present on the PMCs you have installed are appropriate for
your application.

0s (jumpers

Startup and Operation

2

details concerning the installation of the MVME2300SC and the
implementation of the SCbus.

6. Confirm that the terminal to be used as the PPCBug system console

5. Refer to the setup procedure for your particular chassis or system for

is connected to the DB9

DEBUG connector, J2, on the front panel of

the MVME2300SC. (Other connection options may exist, but they
depend on the nature of your overall system configuration.) The
console terminal should be set up as follows:

– Eight bits per character

– One stop bit per character

– Parity disabled (no parity)

– Baud rate 9600 baud (the power-up default)

After power-up, you can reconfigure the baud rate of the debug port

by using the PPCBug Port Format (PF) command.

Note Whatever the baud rate, some form of hardware handshaking —

either XON/XOFF or via the RTS/CST line — is desirable if the
system supports it. If you get garbled messages and missing
characters, you should check the terminal to make sure that
handshaking is enabled.

7. Verify that the remaining equipment in your system is installed and
configured as appropriate.

8. Power up the system. PPCBug executes some self-checks and
displays the debugger prompt

PPC-Bug> if the firmware is in Board

mode.

However, if the ENV command has placed PPCBug in System

mode, the system performs a self-test and tries to autoboot. Refer to

the ENV and MENU command descriptions (Modifying the

Environment on page 3-9).

If the confidence test fails, the test is aborted when the first fault is
encountered. If possible, an appropriate message is displayed, and
control then returns to the menu.

2-6 Computer Group Literature Center Web Site

Bringing up the Board

Autoboot

9. Before using the MVME2300SC after the initial installation, set the
date and time using the following command line structure:

PPC-Bug> SET [mmddyyhhmm]|[<+/-CAL>;C]

For example, the following command line starts the real-time clock
and sets the date and time to 10:37 a.m., November 7, 2001:

PPC-Bug> SET 1107011037

The board’s self-tests and operating systems require that the real­time clock be running.

Autoboot is a software routine included in the PPCBug Flash/EPROM to
provide an independent mechanism for booting operating systems. The
autoboot routine automatically scans for controllers and devices in a
specified sequence until a valid bootable device containing a boot media is
found or the list is exhausted. If a valid bootable device is found, a boot
from that device is started. The controller scanning sequence goes from the
lowest controller Logical Unit Number (LUN) detected to the highest LUN
detected.

At power-up, Autoboot is enabled and (provided that the drive and
controller numbers encountered are valid) the following message is
displayed upon the system console:

2

2-7

Autoboot in progress... To abort hit <BREAK>

A delay follows this message so that you can abort the Autoboot process if
you wish. Then the actual I/O begins: the program designated within the
volume ID of the media specified is loaded into RAM and control passes
to it. If you want to gain control without Autoboot during this time,
however, you can press the <BREAK> key or use the

ABORT or RESET

switches on the front panel.

The Autoboot process is controlled by parameters contained in the ENV

command. These parameters allow the selection of specific boot devices

and files, and allow programming of the Boot delay. Refer to the ENV

command description in Chapter 3 for more details.

Startup and Operation

2

!

Caution

Although you can use streaming tape to autoboot, the same power supply
must be connected to the tape drive, the controller, and the
MVME2300SC. At power-up, the tape controller will position the
streaming tape to the load point where the volume ID can correctly be read
and used.

However, if the MVME2300SC loses power but the controller does not,
and the tape happens to be at load point, the necessary command sequences
(Attach and Rewind) cannot be given to the controller and the autoboot
will not succeed.

ROMboot

The ROMboot function is configured/enabled via the ENV command

(refer to Chapter 3) and is executed at power-up (optionally also at reset).

You can also execute the ROMboot function via the RB command,

assuming there is valid code in the memory devices (or optionally
elsewhere on the board or VMEbus) to support it. If ROMboot code is
installed, a user-written routine is given control (if the routine meets the
format requirements).

One use of ROMboot might be resetting the SYSFAIL∗ line on an
unintelligent controller module. The NORB command disables the

function.

For a user’s ROMboot module to gain control through the ROMboot
linkage, four conditions must exist:

❏ Power has just been applied (but the ENV command can change this

to also respond to any reset).

❏ Your routine is located within the MVME2300SC Flash memory

map (but the ENV command can change this to any other portion of

the onboard memory, or even offboard VMEbus memory).

❏ The ASCII string "BOOT" is found in the specified memory range.

❏ Your routine passes a checksum test, which ensures that this routine

was really intended to receive control at powerup.

2-8 Computer Group Literature Center Web Site

Restarting the System

Network Boot

Network Auto Boot is a software routine in the PPCBug firmware which
provides a mechanism for booting an operating system using a network
(local Ethernet interface) as the boot device. The Network Auto Boot
routine automatically scans for controllers and devices in a specified
sequence until a valid bootable device containing boot media is found or
until the list is exhausted. If a valid bootable device is found, a boot from
that device is started. The controller scanning sequence goes from the
lowest controller Logical Unit Number (LUN) detected to the highest LUN
detected.

At power-up, Network Boot is enabled and (provided that the drive and
controller numbers encountered are valid) the following message is
displayed upon the system console:

Network Boot in progress... To abort hit <BREAK>

After this message, there is a delay to let you abort the Auto Boot process
if you wish. Then the actual I/O is begun: the program designated within
the volume ID of the media specified is loaded into RAM and control
passes to it. If you want to gain control without Network Boot during this
time, however, you can press the <BREAK> key or use the software

ABORT or RESET switches.

2

Network Auto Boot is controlled by parameters contained in the NIOT
and ENV commands. These parameters allow the selection of specific

boot devices, systems, and files, and allow programming of the Boot delay.

Refer to the ENV command description in Chapter 3 for more details.

Restarting the System

You can initialize the system to a known state in three different ways:
Reset, Abort, and Break. Each method has characteristics which make it
more suitable than the others in certain situations.

A special debugger function is accessible during resets. This feature
instructs the debugger to use the default setup/operation parameters in
ROM instead of your own setup/operation parameters in NVRAM. To
activate this function, you press the

2-9

RESET and ABORT switches at the

Startup and Operation

2

same time. This feature can be helpful in the event that your
setup/operation parameters are corrupted or do not meet a sanity check.

Refer to the ENV command description in Chapter 3 for the ROM

defaults.

Reset

Powering up the MVME2300SC initiates a system reset. You can also
initiate a reset by pressing and quickly releasing the
MVME2300SC front panel, or reset the board in software.

For details on resetting the MVME2300SC board through software, refer

to the MVME2300 Series VME Processor Module Programmer’s
Reference Guide.

Both “cold” and “warm” reset modes are available. By default, PPCBug is

in “cold” mode. During cold resets, a total system initialization takes place,

as if the MVME2300SC had just been powered up. All static variables
(including disk device and controller parameters) are restored to their
default states. The breakpoint table and offset registers are cleared. The
target registers are invalidated. Input and output character queues are
cleared. Onboard devices (timer, serial ports, etc.) are reset, and the two
serial ports are reconfigured to their default state.

RESET switch on the

During warm resets, the PPCBug variables and tables are preserved, as

well as the target state registers and breakpoints.

Note that when the MVME2300SC comes up in a cold reset, PPCBug runs

in Board mode. Using the Environment (ENV) or MENU commands can

make PPCBug run in System mode. Refer to Chapter 3 for specifics.

You will need to reset your system if the processor ever halts, or if the
PPCBug environment is ever lost (vector table is destroyed, stack
corrupted, etc.).

2-10 Computer Group Literature Center Web Site

Diagnostic Facilities

Abort

Break

Aborts are invoked by pressing and releasing the ABORT switch on the
MVME2300SC front panel. When you invoke an abort while executing a
user program (running target code), a snapshot of the processor state is
stored in the target registers. This characteristic makes aborts most
appropriate for terminating user programs that are being debugged.

If a program gets caught in a loop, for instance, aborts should be used to
regain control. The target PC, register contents, etc., help to pinpoint the
malfunction.

Pressing and releasing the
which may interrupt the processor if enabled. The target registers,
reflecting the machine state at the time the
displayed on the screen. Any breakpoints installed in your code are
removed and the breakpoint table remains intact. Control returns to the
debugger.

Pressing and releasing the <BREAK> key on the terminal keyboard
generates a ‘‘power break’’. Breaks do not produce interrupts. The only
time that breaks are recognized is while characters are being sent or
received by the console port. A break removes any breakpoints in your
code and keeps the breakpoint table intact. If the function was entered
using SYSCALL, Break also takes a snapshot of the machine state. This
machine state is then accessible to you for diagnostic purposes.

ABORT switch generates a local board condition

ABORT switch was pressed, are

2

In many cases, you may wish to terminate a debugger command before its
completion (for example, during the display of a large block of memory).
Break allows you to terminate the command.

Diagnostic Facilities

The PPCBug package includes a set of hardware diagnostics for testing
and troubleshooting the MVME2300SC. To use the diagnostics, switch
directories to the diagnostic directory.

2-11

Startup and Operation

2

directory with the debugger command Switch Directories (SD). The

diagnostic prompt

PPC-Diag> appears. Refer to the PPCBug Diagnostics

Manual for complete descriptions of the diagnostic routines available and

instructions on how to invoke them. Note that some diagnostics depend on
restart defaults that are set up only in a particular restart mode. The
documentation for such diagnostics includes restart information.

If you are in the debugger directory, you can switch to the diagnostic

2-12 Computer Group Literature Center Web Site

Overview

The PPCBug firmware is the layer of software just above the hardware.
The firmware supplies the appropriate initialization for devices on the
MVME2300SC board upon power-up or reset.

This chapter describes the basics of PPCBug and its architecture, describes
the monitor (interactive command portion of the firmware) in detail, and
gives information on using the debugger and special commands. A list of
PPCBug commands appears at the end of the chapter.

For full user information about PPCbug, refer to the PPCBug Firmware
Package User’s Manual and the PPCBug Diagnostics Manual, listed
under Related Documentation.

PPCBug Basics

3PPCBug Firmware

3

The PowerPC debug firmware, PPCBug, is a powerful evaluation and
debugging tool for systems built around the Motorola PowerPC
microcomputers. Facilities are available for loading and executing user
programs under complete operator control for system evaluation. PPCBug
provides a high degree of functionality, user friendliness, portability, and
ease of maintenance.

PPCBug includes:

❏ Commands for display and modification of memory

❏ Breakpoint and tracing capabilities

❏ A powerful assembler/disassembler useful for patching programs

❏ A “self-test at power-up” feature which verifies the integrity of the

system

3-1

PPCBug Firmware

PPCBug consists of three parts:

❏ A command-driven, user-interactive software debugger, described

in the PPCBug Firmware Package User’s Manual. It is hereafter

3

referred to as “the debugger” or “PPCBug”.

❏ A command-driven diagnostics package for the MVME2300SC

hardware, hereafter referred to as “the diagnostics.” The diagnostics

package is described in the PPCBug Diagnostics Manual.

❏ A user interface or debug/diagnostics monitor that accepts

commands from the system console terminal.

When using PPCBug, you operate out of either the debugger directory or
the diagnostic directory.

❏ If you are in the debugger directory, the debugger prompt PPC1-

Bug> is displayed and you have all of the debugger commands at

your disposal.

❏ If you are in the diagnostic directory, the diagnostic prompt PPC1-

Diag> is displayed and you have all of the diagnostic commands at

your disposal as well as all of the debugger commands.

Because PPCBug is command-driven, it performs its various operations in
response to user commands entered at the keyboard. When you enter a
command, PPCBug executes the command and the prompt reappears.
However, if you enter a command that causes execution of user target code

(for example, GO), then control may or may not return to PPCBug,

depending on the outcome of the user program.

PPCBug Implementation

Physically, PPCBug is contained in two socketed 32-pin PLCC Flash
devices that together provide 1MB of storage. The executable code is
checksummed at every power-on or reset firmware entry, and the result
(which includes a precalculated checksum contained in the Flash devices),
is verified against the expected checksum.

3-2 Computer Group Literature Center Web Site

Memory Requirements

PPCBug requires a maximum of 512KB of read/write memory (i.e.,
DRAM). The debugger allocates this space from the top of memory. For
example, a system containing 64MB ($04000000) of read/write memory
will place the PPCBug memory page at locations $03F80000 to
$03FFFFFF.

Using PPCBug

PPCBug is command-driven; it performs its various operations in response
to commands that you enter at the keyboard. When the PPC1-Bug prompt
appears on the screen, the debugger is ready to accept debugger
commands. When the PPC1-Diag prompt appears on the screen, the
debugger is ready to accept diagnostics commands.

To switch from one mode to the other, enter SD (Switch Directories). To

examine the commands in the directory that you are currently in, use the

Help command (HE).

Using PPCBug

3

3-3

What you key in is stored in an internal buffer. Execution begins only after
you press the Return or Enter key. This allows you to correct entry errors,

if necessary, with the control characters described in the PPCBug
Firmware Package User’s Manual, Chapter 1.

After the debugger executes the command you have entered, the prompt
reappears. However, if the command causes execution of user target code

(for example GO), then control may or may not return to the debugger,

depending on what the user program does.

For example, if a breakpoint has been specified, then control returns to the
debugger when the breakpoint is encountered during execution of the user
program. Alternatively, the user program could return to the debugger by
means of the System Call Handler routine RETURN (described in the

PPCBug Firmware Package User’s Manual, Chapter 5). For more about
this, refer to the GD, GO, and GT command descriptions in the PPCBug
Firmware Package User’s Manual, Chapter 3.

PPCBug Firmware

A debugger command is made up of the following parts:

❏ The command name, either uppercase or lowercase (e.g., MD or

md).

3

❏ Any required arguments, as specified by the command.

❏ At least one space before the first argument. Precede all other

arguments with either a space or comma.

❏ One or more options. Precede an option or a string of options with

a semicolon (;). If no option is entered, the command’s default

option conditions are used.

Debugger Commands

The PPCBug debugger commands are summarized in the following table.

The commands are described in detail in the PPCBug Firmware Package

User’s Manual.

Note You can list all the available debugger commands by entering the

Help (HE) command alone. You can view the syntax for a
particular command by entering HE and the command

mnemonic, as listed below.

Table 3-1. Debugger Commands

Command Description

AS One Line Assembler

BC Block of Memory Compare

BF Block of Memory Fill

BI Block of Memory Initialize

BM Block of Memory Move

BR Breakpoint Insert

NOBR Breakpoint Delete

BS Block of Memory Search

3-4 Computer Group Literature Center Web Site

Table 3-1. Debugger Commands (Continued)

Command Description

BV Block of Memory Verify

CM Concurrent Mode

NOCM No Concurrent Mode

CNFG Configure Board Information Block

CS Checksum

CSAR PCI Configuration Space READ Access

CSAW PCI Configuration Space WRITE Access

DC Data Conversion

DMA Block of Memory Move

DS One Line Disassembler

DU Dump S-Records

ECHO Echo String

ENV Set Environment

FORK Fork Idle MPU at Address

FORKWR Fork Idle MPU with Registers

GD Go Direct (Ignore Breakpoints)

GEVBOOT Global Environment Variable Boot

GEVDEL Global Environment Variable Delete

GEVDUMP Global Environment Variable(s) Dump

GEVEDIT Global Environment Variable Edit

GEVINIT Global Environment Variable Initialization

GEVSHOW Global Environment Variable(s) Display

GN Go to Next Instruction

GO Go Execute User Program

GT Go to Temporary Breakpoint

HE Help

IDLE Idle Master MPU

IOC I/O Control for Disk

IOI I/O Inquiry

Debugger Commands

3

3-5

PPCBug Firmware

Table 3-1. Debugger Commands (Continued)

Command Description

3

IOP I/O Physical (Direct Disk Access)

IOT I/O Teach for Configuring Disk Controller

IRD Idle MPU Register Display

IRM Idle MPU Register Modify

IRS Idle MPU Register Set

LO Load S-Records from Host

MA Macro Define/Display

NOMA Macro Delete

MAE Macro Edit

MAL Enable Macro Listing

NOMAL Disable Macro Listing

MAR Load Macros

MAW Save Macros

MD, MDS Memory Display

MENU System Menu

MM Memory Modify

MMD Memory Map Diagnostic

MS Memory Set

MW Memory Write

NAB Automatic Network Boot

NAP Nap MPU

NBH Network Boot Operating System, Halt

NBO Network Boot Operating System

NIOC Network I/O Control

NIOP Network I/O Physical

NIOT Network I/O Teach (Configuration)

NPING Network Ping

OF Offset Registers Display/Modify

PA Printer Attach

3-6 Computer Group Literature Center Web Site

Table 3-1. Debugger Commands (Continued)

Command Description

NOPA Printer Detach

PBOOT Bootstrap Operating System

PF Port Format

NOPF Port Detach

PFLASH Program FLASH Memory

PS Put RTC into Power Save Mode

RB ROMboot Enable

NORB ROMboot Disable

RD Register Display

REMOTE Remote

RESET Cold/Warm Reset

RL Read Loop

RM Register Modify

RS Register Set

RUN MPU Execution/Status

SD Switch Directories

SET Set Time and Date

SROM SROM Examine/Modify

SYM Symbol Table Attach

NOSYM Symbol Table Detach

SYMS Symbol Table Display/Search

T Trace

TA Terminal Attach

TIME Display Time and Date

TM Transparent Mode

TT Trace to Temporary Breakpoint

VE Verify S-Records Against Memory

VER Revision/Version Display

WL Write Loop

Debugger Commands

3

3-7

PPCBug Firmware

Although a command to allow the erasing and reprogramming of Flash

!

Caution

3

memory is available to you, keep in mind that reprogramming any portion
of Flash memory will erase everything currently contained in Flash,
including the PPCBug debugger.

Note, however, that Flash bank A and Flash bank B both contain the
PPCBug debugger.

Diagnostic Tests

The PPCBug hardware diagnostics are intended for testing and
troubleshooting the MVME2300SC module.

In order to use the diagnostics, you must switch to the diagnostic directory.

You may switch between directories by using the SD (Switch Directories)

command. You may view a list of the commands in the directory that you

are currently in by using the HE (Help) command.

If you are in the debugger directory, the debugger prompt

PPC1-Bug>

displays, and all of the debugger commands are available. Diagnostics
commands cannot be entered at the

If you are in the diagnostic directory, the diagnostic prompt

PPC1-Bug> prompt.

PPC1-Diag>

displays, and all of the debugger and diagnostic commands are available.

PPCBug’s diagnostic test groups are listed in Table 3-2. Note that not all

tests are performed on the MVME2300SC. Using the HE command, you

can list the diagnostic routines available in each test group. Refer to the

PPCBug Diagnostics Manual for complete descriptions of the diagnostic

routines and instructions on how to invoke them.

Table 3-2. Diagnostic Test Groups

Command Description

CL1283 Parallel Interface (CL1283) Tests*

DEC DEC21x43 Ethernet Controller Tests

ISABRDGE PCI/ISA Bridge Tests

KBD8730x PC8730x Keyboard/Mouse Tests*

L2CACHE Level 2 Cache Tests*

3-8 Computer Group Literature Center Web Site

Modifying the Environment

Table 3-2. Diagnostic Test Groups (Continued)

Command Description

NCR NCR 53C8xx SCSI-2 I/O Processor Tests*

PAR8730x Parallel Interface (PC8730x) Test*

UART Serial Input/Output Tests

PCIBUS PCI/PMC Generic Tests

RAM Local RAM Tests

RTC M48Txxx Timekeeping Tests

SCC Serial Communications Controller

(Z85C230) Tests*

VGA543x Video Diagnostics Tests*

VME2 VMEchip2 VME Interface ASIC Tests*

Z8536 Z8536 Counter/Timer Tests*

Notes You may enter command names in either uppercase or lowercase

characters.

3

Some diagnostics depend on restart defaults that are set up only
in a particular restart mode. Refer to the documentation on a
particular diagnostic for the correct mode.

Test Sets marked with an asterisk (*) are not available on the
MVME2300SC.

Modifying the Environment

You can use the factory-installed debug monitor, PPCBug, to modify
certain parameters contained in the MVME2300SC’s Non-Volatile RAM
(NVRAM), also known as Battery Backed-Up RAM (BBRAM).

❏ The Board Information Block in NVRAM contains various entries

that define operating parameters of the board hardware. Use the

PPCBug command CNFG to change those parameters.

3-9

PPCBug Firmware

❏ Use the PPCBug command ENV to change configurable PPCBug

parameters in NVRAM.

The CNFG and ENV commands are both described in the PPCBug

3

Firmware Package User’s Manual. Refer to that manual for general

information about their use and capabilities.

The following paragraphs present supplementary information on CNFG
and ENV that is specific to the PPCBug firmware, along with the
parameters that you can modify with the ENV command.

CNFG - Configure Board Information Block

Use this command to display and configure the Board Information Block
which resides within the NVRAM. The board information block contains
various elements that correspond to specific operational parameters of the
MVME2300SC board.

The board structure for MVME2300SCs resembles that shown in the
following example:

PPC-Bug>cnfg
Board (PWA) Serial Number = "MOT00
Board Identifier = "MVME2307SC"
Artwork (PWA) Identifier = "01-W3430FxxB"
MPU Clock Speed = "300"
Ethernet Address = 0001AF26A464
Local SCSI Identifier = "07"
System Serial Number = "
System Identifier = "Motorola MVME2300SC"
License Identifier = "
PPC-Bug>

nnnnnnn

nnnnnnnn

"

"

xxxxxxx

"

The parameters that are quoted are left-justified character (ASCII) strings
padded with space characters, and the quotes (") are displayed to indicate
the size of the string. Parameters that are not quoted are considered data
strings, and data strings are right-justified. The data strings are padded
with zeros if the length is not met.

3-10 Computer Group Literature Center Web Site

Modifying the Environment

The Board Information Block is factory-configured before shipment.
There is no need to modify block parameters unless the NVRAM is
corrupted.

Refer to the MVME2300 Series VME Processor Module Programmer’s
Reference Guide for the actual location and other information about the
Board Information Block. Refer to the PPCBug Firmware Package User's
Manual for a CNFG description and examples.

ENV - Set Environment

Use the ENV command to view and/or configure interactively all PPCBug

operational parameters that are kept in Non-Volatile RAM (NVRAM).

Refer to the PPCBug Firmware Package User's Manual for a description
of the use of ENV. Additional information on registers in the Universe
ASIC that affect these parameters is contained in your MVME2300 Series
VME Processor Module Programmer’s Reference Guide.

Listed and described below are the parameters that you can configure

using ENV. The default values shown are those that were in effect when

this document was published.

Note In the event of difficulty with the MVME2300SC, you may wish

to use env;d <CR> to restore the factory defaults as a

troubleshooting aid (see Appendix B).

3

3-11

PPCBug Firmware

Configuring the PPCBug Parameters

The parameters that can be configured using ENV are:

3

Bug or System environment [B/S] = B?

B

Bug is the mode where no system type of support is
displayed. However, system-related items are still
available. (Default)

S

System is the standard mode of operation, and is the
default mode if NVRAM should fail. System mode is
defined in the PPCBug Firmware Package User’s
Manual.

Field Service Menu Enable [Y/N] = N?

Y
N

Remote Start Method Switch [G/M/B/N] = B?

Display the field service menu.

Do not display the field service menu. (Default)

The Remote Start Method Switch is used when the MVME2300SC is
cross-loaded from another VME-based CPU, to start execution of the
cross-loaded program.

G

M

Use the Global Control and Status Register to pass
and start execution of the cross-loaded program. This

selection is not applicable to the MVME2300SC
boards.

Use the Multiprocessor Control Register (MPCR) in
shared RAM to pass and start execution of the cross­loaded program.

B

Use both the GCSR and the MPCR methods to pass
and start execution of the cross-loaded program.
(Default)

N

Do not use any Remote Start Method.

3-12 Computer Group Literature Center Web Site

Modifying the Environment

Probe System for Supported I/O Controllers [Y/N] = Y?

Y

Accesses will be made to the appropriate system
buses (e.g., VMEbus, local MPU bus) to determine
the presence of supported controllers. (Default)

N

Accesses will not be made to the VMEbus to
determine the presence of supported controllers.

Auto-Initialize of NVRAM Header Enable [Y/N] = Y?

Y

NVRAM (PReP partition) header space will be
initialized automatically during board initialization,
but only if the PReP partition fails a sanity check.
(Default)

N

NVRAM header space will not be initialized
automatically during board initialization.

Network PReP-Boot Mode Enable [Y/N] = N?

Y

Enable PReP-style network booting (same boot image
from a network interface as from a mass storage
device).

N

Negate VMEbus SYSFAIL* Always [Y/N] = N?

Do not enable PReP-style network booting. (Default)

3

3-13

Y

Negate the VMEbus SYSFAIL∗ signal during board
initialization.

N

Negate the VMEbus SYSFAIL∗ signal after
successful completion or entrance into the bug
command monitor. (Default)

SCSI Bus Reset on Debugger Startup [Y/N] = N?

Y
N

Local SCSI bus is reset on debugger setup.

Local SCSI bus is not reset on debugger setup.
(Default)

PPCBug Firmware

Primary SCSI Bus Negotiations Type [A/S/N] = A?

A

3

Primary SCSI Data Bus Width [W/N] = N?

Secondary SCSI identifier = 07?

S
N

W
N

Asynchronous SCSI bus negotiation. (Default)

Synchronous SCSI bus negotiation.

None.

Wide SCSI (16-bit bus).

Narrow SCSI (8-bit bus). (Default)

Select the identifier. (Default = 07.)

NVRAM Bootlist (GEV.fw-boot-path) Boot Enable [Y/N] = N?

Y

Give boot priority to devices defined in the fw-boot­path global environment variable (GEV).

N

Do not give boot priority to devices listed in the fw­boot-path GEV. (Default)

Note When enabled, the GEV (Global Environment Variable) boot

takes priority over all other boots, including Autoboot and
Network Boot.

NVRAM Bootlist (GEV.fw-boot-path) Boot at power-up only [Y/N] = N?

Y

Give boot priority to devices defined in the fw-boot­path GEV at power-up reset only.

N

Give power-up boot priority to devices listed in the
fw-boot-path GEV at any reset. (Default)

NVRAM Bootlist (GEV.fw-boot-path) Boot Abort Delay = 5?

The time in seconds that a boot from the NVRAM boot list will delay
before starting the boot. The purpose for the delay is to allow you the
option of stopping the boot by use of the

BREAK key. The time value

is from 0-255 seconds. (Default = 5 seconds)

3-14 Computer Group Literature Center Web Site

Auto Boot Enable [Y/N] = N?

Modifying the Environment

Y
N

Auto Boot at power-up only [Y/N] = N?

Y
N

Auto Boot Scan Enable [Y/N] = Y?

Y

N

Auto Boot Scan Device Type List = FDISK/CDROM/TAPE/HDISK?

The Autoboot function is enabled.

The Autoboot function is disabled. (Default)

Autoboot is attempted at power-up reset only.

Autoboot is attempted at any reset. (Default)

If Autoboot is enabled, the Autoboot process attempts
to boot from devices specified in the scan list (e.g.,

FDISK/CDROM/TAPE/HDISK). (Default)

If Autoboot is enabled, the Autoboot process uses the
Controller LUN and Device LUN to boot.

This is the listing of boot devices displayed if the Autoboot Scan
option is enabled. If you modify the list, follow the format shown
above (uppercase letters, using forward slash as separator).

Auto Boot Controller LUN = 00?

Refer to the PPCBug Firmware Package User’s Manual for a listing

of disk/tape controller modules currently supported by PPCBug.
(Default = $00)

3

3-15

Auto Boot Device LUN = 00?

Refer to the PPCBug Firmware Package User’s Manual for a listing

of disk/tape devices currently supported by PPCBug.
(Default = $00)

Auto Boot Partition Number = 00?

Which disk “partition” is to be booted, as specified in the PowerPC
Reference Platform (PRP) specification. If set to zero, the firmware
will search the partitions in order (1, 2, 3, 4) until it finds the first

PPCBug Firmware

“bootable” partition. That is then the partition that will be booted.
Other acceptable values are 1, 2, 3, or 4. In these four cases, the
partition specified will be booted without searching.

3

Auto Boot Abort Delay = 7?

The time in seconds that the Autoboot sequence will delay before
starting the boot. The purpose for the delay is to allow you the option
of stopping the boot by use of the

BREAK key. The time value is from

0-255 seconds. (Default = 7 seconds)

Auto Boot Default String [NULL for an empty string] = ?

You may specify a string (filename) which is passed on to the code
being booted. The maximum length of this string is 16 characters.
(Default = null string)

ROM Boot Enable [Y/N] = N?

Y
N

ROM Boot at power-up only [Y/N] = Y?

Y
N

ROM Boot Enable search of VMEbus [Y/N] = N?

The ROMboot function is enabled.

The ROMboot function is disabled. (Default)

ROMboot is attempted at power-up only. (Default)

ROMboot is attempted at any reset.

Y

N

ROM Boot Abort Delay = 5?

VMEbus address space, in addition to the usual areas
of memory, will be searched for a ROMboot module.

VMEbus address space will not be accessed by
ROMboot. (Default)

The time in seconds that the ROMboot sequence will delay before
starting the boot. The purpose for the delay is to allow you the option
of stopping the boot by use of the

BREAK key. The time value is from

0-255 seconds. (Default = 5 seconds)

3-16 Computer Group Literature Center Web Site

Modifying the Environment

ROM Boot Direct Starting Address = FFF00000?

The first location tested when PPCBug searches for a ROMboot
module. (Default = $FFF00000)

ROM Boot Direct Ending Address = FFFFFFFC?

The last location tested when PPCBug searches for a ROMboot
module. (Default = $FFFFFFFC)

Network Auto Boot Enable [Y/N] = N?

3

Y

N

Network Auto Boot at power-up only [Y/N] = N?

Y
N

Network Auto Boot Controller LUN = 00?

The Network Auto Boot (NETboot) function is
enabled.

The NETboot function is disabled. (Default)

NETboot is attempted at power-up reset only.

NETboot is attempted at any reset. (Default)

Refer to the PPCBug Firmware Package User’s Manual for a listing

of network controller modules currently supported by PPCBug.
(Default = $00)

Network Auto Boot Device LUN = 00?

Refer to the PPCBug Firmware Package User’s Manual for a listing

of network controller modules currently supported by PPCBug.
(Default = $00)

Network Auto Boot Abort Delay = 5?

The time in seconds that the NETboot sequence will delay before
starting the boot. The purpose for the delay is to allow you the option
of stopping the boot by use of the

BREAK key. The time value is from

0-255 seconds. (Default = 5 seconds)

3-17

PPCBug Firmware

Network Auto Boot Configuration Parameters Offset (NVRAM) =
00001000?

The address where the network interface configuration parameters are

3

to be saved/retained in NVRAM; these parameters are the necessary
parameters to perform an unattended network boot. A typical offset
might be $1000, but this value is application-specific. (Default =
$00001000)

If you use the NIOT debugger command, these parameters need to be

!

Caution

saved somewhere in the offset range $00001000 through $000016F7. The

NIOT parameters do not exceed 128 bytes in size. The setting of this ENV

pointer determines their location. If you have used the same space for your
own program information or commands, they will be overwritten and lost.

You can relocate the network interface configuration parameters in this

space by using the ENV command to change the Network Auto Boot

Configuration Parameters Offset from its default of $00001000 to the
value you need to be clear of your data within NVRAM.

Memory Size Enable [Y/N] = Y?

Y

N

Memory Size Starting Address = 00000000?

Memory will be sized for Self Test diagnostics.
(Default)

Memory will not be sized for Self Test diagnostics.

The default Starting Address is $00000000.

Memory Size Ending Address = 04000000?

The default Ending Address is the calculated size of local memory. If
the memory start is changed from $00000000, this value will also need
to be adjusted.

3-18 Computer Group Literature Center Web Site

Modifying the Environment

DRAM Speed in NANO Seconds = 50?

The default setting for this parameter will vary depending on the speed
of the DRAM memory parts installed on the board. The default is set
to the slowest speed found on the available banks of DRAM memory.

ROM First Access Length (0 - 31) = 10?

This is the value programmed into the“ROMFAL” field (Memory
Control Configuration Register 8: bits 23-27) to indicate the number
of clock cycles used in accessing the ROM. The lowest allowable
ROMFAL setting is $00; the highest allowable is $1F. The value to
enter depends on processor speed; refer to Chapter 1 or Appendix A
for appropriate values. The default value varies according to the
system’s bus clock speed.

Note ROM First Access Length is not applicable to the

MVME2300SC. The configured value is ignored by PPCBug.

3

3-19

ROM Next Access Length (0 - 15) = 0?

The value programmed into the“ROMNAL” field (Memory Control
Configuration Register 8: bits 28-31) to represent wait states in access
time for nibble (or burst) mode ROM accesses. The lowest allowable
ROMNAL setting is $0; the highest allowable is $F. The value to enter
depends on processor speed; refer to Chapter 1 or Appendix A for
appropriate values. The default value varies according to the system’s
bus clock speed.

Note ROM Next Access Length is not applicable to the

MVME2300SC. The configured value is ignored by PPCBug.

PPCBug Firmware

DRAM Parity Enable [On-Detection/Always/Never - O/A/N] = O?

O

3

A
N

DRAM parity is enabled upon detection. (Default)

DRAM parity is always enabled.

DRAM parity is never enabled.

Note This parameter (above) also applies to enabling ECC for DRAM.

L2 Cache Parity Enable [On-Detection/Always/Never - O/A/N] = O?

O
A
N

PCI Interrupts Route Control Registers (PIRQ0/1/2/3) = 0A0B0E0F?

L2 Cache parity is enabled upon detection. (Default)

L2 Cache parity is always enabled.

L2 Cache parity is never enabled.

Initializes the PIRQx (PCI Interrupts) route control registers in the IBC
(PCI/ISA bus bridge controller). The ENV parameter is a 32-bit value

that is divided by 4 to yield the values for route control registers
PIRQ0/1/2/3. The default is determined by system type. For details on
PCI/ISA interrupt assignments and for suggested values to enter for

this parameter, refer to the 8259 Interrupts section of Chapter 5 in the

MVME2300 Series VME Pr oc essor Module Programmer’s Reference
Guide.

Note LED/Serial Startup Diagnostic Codes: these codes can be

displayed at key points in the initialization of the hardware
devices. Should the debugger fail to come up to a prompt, the last
code displayed will indicate how far the initialization sequence

had progressed before stalling. The codes are enabled by an ENV

parameter:

Serial Startup Code Master Enable [Y/N]=N?

A line feed can be inserted after each code is displayed to prevent it
from being overwritten by the next code. This is also enabled by an

ENV parameter:

3-20 Computer Group Literature Center Web Site

Serial Startup Code LF Enable [Y/N]=N?

The list of LED/serial codes is included in the section on MPU,
Hardware, and Firmware Initialization in Chapter 1 of the PPCBug

Firmware Package User’s Manual.

Configuring the VMEbus Interface

ENV asks the following series of questions to set up the VMEbus interface

for the MVME2300SC modules. To perform this configuration, you
should have a working knowledge of the Universe ASIC as described in

your MVME2300 Series VME Processor Module Programmer’s
Reference Guide.

VME3PCI Master Master Enable [Y/N] = Y?

Modifying the Environment

3

Y
N

PCI Slave Image 0 Control = 00000000?

Set up and enable the VMEbus Interface. (Default)

Do not set up or enable the VMEbus Interface.

The configured value is written into the LSI0_CTL register of the
Universe chip.

PCI Slave Image 0 Base Address Register = 00000000?

The configured value is written into the LSI0_BS register of the
Universe chip.

PCI Slave Image 0 Bound Address Register = 00000000?

The configured value is written into the LSI0_BD register of the
Universe chip.

PCI Slave Image 0 Translation Offset = 00000000?

The configured value is written into the LSI0_TO register of the
Universe chip.

3-21

PPCBug Firmware

PCI Slave Image 1 Control = C0820000?

The configured value is written into the LSI1_CTL register of the
Universe chip.

3

PCI Slave Image 1 Base Address Register = 01000000?

The configured value is written into the LSI1_BS register of the
Universe chip.

PCI Slave Image 1 Bound Address Register = 20000000?

The configured value is written into the LSI1_BD register of the
Universe chip.

PCI Slave Image 1 Translation Offset = 00000000?

The configured value is written into the LSI1_TO register of the
Universe chip.

PCI Slave Image 2 Control = C0410000?

The configured value is written into the LSI2_CTL register of the
Universe chip.

PCI Slave Image 2 Base Address Register = 20000000?

The configured value is written into the LSI2_BS register of the
Universe chip.

PCI Slave Image 2 Bound Address Register = 22000000?

The configured value is written into the LSI2_BD register of the
Universe chip.

PCI Slave Image 2 Translation Offset = D0000000?

The configured value is written into the LSI2_TO register of the
Universe chip.

PCI Slave Image 3 Control = C0400000?

The configured value is written into the LSI3_CTL register of the
Universe chip.

PCI Slave Image 3 Base Address Register = 2FFF0000?

The configured value is written into the LSI3_BS register of the
Universe chip.

3-22 Computer Group Literature Center Web Site

Modifying the Environment

PCI Slave Image 3 Bound Address Register = 30000000?

The configured value is written into the LSI3_BD register of the
Universe chip.

PCI Slave Image 3 Translation Offset = D0000000?

The configured value is written into the LSI3_TO register of the
Universe chip.

VMEbus Slave Image 0 Control = E0F20000?

The configured value is written into the VSI0_CTL register of the
Universe chip.

VMEbus Slave Image 0 Base Address Register = 00000000?

The configured value is written into the VSI0_BS register of the
Universe chip.

VMEbus Slave Image 0 Bound Address Register = (Local DRAM Size)?

The configured value is written into the VSI0_BD register of the
Universe chip. The value is the same as the Memory Size number
already displayed.

3

3-23

VMEbus Slave Image 0 Translation Offset = 80000000?

The configured value is written into the VSI0_TO register of the
Universe chip.

VMEbus Slave Image 1 Control = 00000000?

The configured value is written into the VSI1_CTL register of the
Universe chip.

VMEbus Slave Image 1 Base Address Register = 00000000?

The configured value is written into the VSI1_BS register of the
Universe chip.

VMEbus Slave Image 1 Bound Address Register = 00000000?

The configured value is written into the VSI1_BD register of the
Universe chip.

PPCBug Firmware

VMEbus Slave Image 1 Translation Offset = 00000000?

The configured value is written into the VSI1_TO register of the
Universe chip.

3

VMEbus Slave Image 2 Control = 00000000?

The configured value is written into the VSI2_CTL register of the
Universe chip.

VMEbus Slave Image 2 Base Address Register = 00000000?

The configured value is written into the VSI2_BS register of the
Universe chip.

VMEbus Slave Image 2 Bound Address Register = 00000000?

The configured value is written into the VSI2_BD register of the
Universe chip.

VMEbus Slave Image 2 Translation Offset = 00000000?

The configured value is written into the VSI2_TO register of the
Universe chip.

VMEbus Slave Image 3 Control = 00000000?

The configured value is written into the VSI3_CTL register of the
Universe chip.

VMEbus Slave Image 3 Base Address Register = 00000000?

The configured value is written into the VSI3_BS register of the
Universe chip.

VMEbus Slave Image 3 Bound Address Register = 00000000?

The configured value is written into the VSI3_BD register of the
Universe chip.

VMEbus Slave Image 3 Translation Offset = 00000000?

The configured value is written into the VSI3_TO register of the
Universe chip.

PCI Miscellaneous Register = 10000000?

The configured value is written into the LMISC register of the
Universe chip.

3-24 Computer Group Literature Center Web Site

Modifying the Environment

Special PCI Slave Image Register = 00000000?

The configured value is written into the SLSI register of the Universe
chip.

Master Control Register = 80C00000?

The configured value is written into the MAST_CTL register of the
Universe chip.

Miscellaneous Control Register = 52060000?

The configured value is written into the MISC_CTL register of the
Universe chip.

User AM Codes = 00000000?

The configured value is written into the USER_AM register of the
Universe chip.

3

3-25

PPCBug Firmware

3

3-26 Computer Group Literature Center Web Site

4Functional Description

Introduction

This chapter describes the MVME2300SC VME processor module on a

block diagram level. The Summary of Features provides an overview of

the MVME2300SC, followed by a detailed description of several blocks of
circuitry. Figure 4-1 shows a block diagram of the overall board
architecture.

Detailed descriptions of other MVME2300SC blocks, including
programmable registers in the ASICs and peripheral chips, can be found in

the MVME2300 Series VME Processor Module Programmer’ s Refere nce
Guide (part number V2300A/PG). Refer to that manual for a functional

description of the MVME2300SC in greater depth.

Summary of Features

4

The following table summarizes the features of the MVME2300SC VME
processor module.

Table 4-1. MVME2300SC Features

Feature Description

Microprocessor 300 MHZ MPC604 PowerPC

Form factor 6U VMEbus

ECC DRAM Two-way interleaved, ECC-protected 32MB or 64MB

Bank B: Two 32-pin PLCC sockets populated with 1MB 8-bit Flash

Flash memory

Real-time clock

Switches Reset

devices

Bank A: Four 16-bit Smart Voltage SMT devices populated with 8Mbit
Flash devices (4MB)

8KB NVRAM with RTC, battery backup, and watchdog function (SGS­Thomson M48T559)

(RST) and Abort (ABT)

®

processor

4-1

Functional Description

Table 4-1. MVME2300SC Features (Continued)

Feature Description

Status LEDs Four: Board Fail (BFL), CPU, System Controller (SCON), Fuses (FUS)

One 16-bit timer in W83C553 PCI/ISA bridge; four 32-bit timers in

Timers

4

Interrupts

VME I/O VMEbus P2 connector

Serial I/O

Ethernet I/O

PCI interface

SCSA I/O

VMEbus interface

Raven (MPIC) device

Watchdog timer provided in SGS-Thomson M48T559

Software interrupt handling via Raven (PCI/MPU bridge) and Winbond
(PCI/ISA bridge) controllers

One asynchronous debug port via DB9 connector on front panel,
also via P2 and transition module

10Base-T/100Base-TX connections via RJ45 connector on front panel;
AUI connections via P2 and transition module

Two IEEE P1386.1 PCI Mezzanine Card (PMC) slots for one double­width or two single-width PMCs

Front panel and/or VMEbus P2 I/O on both PMC slots

One 114-pin Mictor connector for optional PMCspan expansion module

Connections from both PMC slots to SCSA backplane TDM bus (if
present in system) via

VMEbus system controller functions

VMEbus-to-local-bus interface (A24/A32, D8/D16/D32/block transfer
[D8/D16/D32/D64])

Local-bus-to-VMEbus interface (A16/A24/A32, D8/D16/D32)

VMEbus interrupter

VMEbus interrupt handler

Global Control/Status Register (GCSR) for interprocessor
communications

DMA for fast local memory/VMEbus transfers (A16/A24/A32,
D16/D32/D64)

shared pins on P2 connector

4-2 Computer Group Literature Center Web Site

General Description

General Description

The MVME2300SC is a VME processor module equipped with a
PowerPC

As described in the Features section, the MVME2300SC offers many

standard features desirable in a computer system — among them Ethernet
and debug ports, Boot ROM, Flash memory, DRAM, and an interface for
two PCI Mezzanine Cards (PMCs) — all contained in a one-slot VME
package. Its flexible mezzanine architecture allows relatively easy
upgrades of the I/O.

There are four standard buses on the MVME2300SC:

In addition, the MVME2300SC supplies connectivity from both PMC
slots to an SCSA (Signal Computing System Architecture) backplane
TDM bus, if the system supports one, via shared pins on VME connector
P2.

As shown in Figure 4-1, a Raven PCI Bridge ASIC provides the interface
from the Processor Bus to PCI. A W83C553 PCI/ISA Bridge (PIB)
Controller device performs the bridge function between PCI and ISA. The
Universe ASIC device provides the interface between the PCI Local Bus
and the VMEbus. A Falcon chipset is the ECC memory controller.

®

604 microprocessor.

PowerPC Processor Bus ISA Bus
PCI Local Bus VMEbus

4

The Peripheral Component Interface (PCI) local bus is a key feature. In
addition to the on-board local bus peripherals, the PCI bus supports an
industry-standard mezzanine interface, IEEE P1386.1 PMC (PCI
Mezzanine Card).

MPC604 Processor

The MVME2300SC is built with a PowerPC 604 processor chip. It can be
ordered with 32MB or 64MB of ECC DRAM, and up to 5MB of Flash
memory.

The PowerPC 604 is a 64-bit processor with 32 KB on-chip caches (32KB
data cache and 32KB instruction cache).

4-3

Functional Description

The Raven bridge controller ASIC provides the bridge between the
PowerPC microprocessor bus and the PCI local bus. Electrically, the
Raven chip is a 64-bit PCI connection. Four programmable map decoders
in each direction provide flexible addressing between the PowerPC
microprocessor bus and the PCI local bus.

4

The power requirements for the MVME2300SC are shown in Table 4-2.

Table 4-2. Power Requirements

Configuration +5V Power +12V and –12V Power

300MHz PowerPC 604 4.5A typical

5.5A maximum

PMC-dependent
(Refer to Appendix B)

I/O Implementation

The MVME2300SC offers many standard features desirable in a computer
system — among them Ethernet and debug ports, Boot ROM, Flash
memory, DRAM, and an interface for two PCI Mezzanine Cards (PMCs)
— all contained in a one-slot VME package. Its flexible mezzanine
architecture allows relatively easy I/O upgrades.

There are four standard buses on the MVME2300SC:

PowerPC Processor Bus ISA Bus
PCI Local Bus VMEbus

In addition, the MVME2300SC supplies connectivity from both PMC
slots to an SCSA (Signal Computing System Architecture) backplane
TDM bus, if the system supports one, via shared pins on VME connector
P2.

As shown in Figure 4-1, a Raven PCI Bridge ASIC provides the interface
from the Processor Bus to PCI. A W83C553 PCI/ISA Bridge (PIB)
Controller device performs the bridge function between PCI and ISA. The
Universe ASIC device provides the interface between the PCI Local Bus
and the VMEbus. A Falcon chipset is the ECC memory controller.

4-4 Computer Group Literature Center Web Site

General Description

The Peripheral Component Interface (PCI ) local bus is a key feature. In
addition to the on-board local bus peripherals, the PCI bus supports an
industry-standard mezzanine interface, IEEE P1386.1 PMC (PCI
Mezzanine Card).

ASICs

The following ASICs are used on the MVME2300SC:

❏ Universe ASIC (VMEbus interface). Provides the PCI-bus-to-

❏ Raven ASIC. Provides the bridge function between the MPC604

The block diagram in Figure 4-1 on page 4-6 illustrates the
MVME2300SC’s overall architecture.

DRAM Memory

Current models of the MVME2300SC have either 32MB or 64MB of
DRAM.

The DRAM blocks are controlled by the Falcon chipset, which performs
two-way interleaving and provides single- and double-bit error correction.
ECC is calculated over a span of 72 bits.

4

VMEbus interface, the VMEbus-to-PCI-bus interface, and the
DMA controller functions of the local VMEbus.

Processor-to-VMEbus transfers are D8, D16, or D32. VMEchip2
DMA transfers to the VMEbus, however, are D16, D32, D16/BLT,
D32/BLT, or D64/MBLT.

processor bus and the PCI Local Bus. It provides 32-bit addressing
and 64-bit data.

4-5

There are one or two blocks of DRAMs that provide 32MB or 64MB of
ECC DRAM. The DRAM blocks consists of 9 devices each. Either 1Mx16
(Page) 50-pin TSOPII DRAM or 4Mx16 (EDO) 50-pin TSOPII DRAM
are used to provide 32/64MB. When populated, these blocks appears as
Block A and Block B to the Falcon chipset.

Refer to the MVME2300 Series VME Processor Module Programmer’s
Reference Guide for additional information and programming details.

Functional Description

Debug Connector

DRAM

16/32/64/128M

FLASH

1M to 5M

Clock

Generator

Bus

4

Processor

MPC604

System

Registers

PIB & MPIC

Raven ASIC

33MHz 32/64-bit PCI

2,64-bit PMC Slot

Ethernet

RJ45

10/100TX

Micro D-9

Serial port

TL16C550

Slot2

PMC Front IO

Slot1

PMC Front IO

UART

AUI

Front Panel

66MHz PPC604 Processor

PIB

W83c553

ISA Bus

Local Bus

Registers

RTC/NVRAM/WD

Memory Controller

ISA

M48T559

Falcon Chipset

VME Bridge

Universe

Buffers

PCI Expansion

VME P1VME P2

2389 9810

Figure 4-1. MVME2300SC Block Diagram

4-6 Computer Group Literature Center Web Site

General Description

The block diagram for the memory interface is shown in the following
figure.

Memory Controll er

Falcon to 128M

4

Data

DRAM Latency

The ECC memory access latency times for 60ns, fast page DRAMs are
shown in the following table.

Table 4-3. PPC604-Bus-to-DRAM Timing — 60ns Page Devices

Access Type

4-Beat Read after Idle
(Quad-word aligned)

ECC DRAM

16M to 128M

Buffers

Flash

1M to 5M

Figure 4-2. Memory Block Diagram

Clock Periods Required for:

1st Beat 2nd Beat 3rd Beat 4th Beat

912113

Buffers

Address & Control

Buffers

2390 9810

Total

Clocks

4-Beat Read after Idle
(Quad-word misaligned)

4-Beat Read after 4-Beat Read
(Quad-word aligned)

4-7

931114

7/3

1

1 2 1 11/7

Functional Description

Table 4-3. PPC604-Bus-to-DRAM Timing — 60ns Page Devices (Continued)

Access Type

1st Beat 2nd Beat 3rd Beat 4th Beat

4-Beat Read after 4-Beat Read

4

(misaligned)

4-Beat Write after Idle 4 1 1 1 7

4-Beat Write after 4-Beat Write
(Quad-word aligned)

1-Beat Read after Idle 9 - - - 9

1-Beat Read after 1-Beat Read 8/6

1-Beat Write after Idle 4 - - - 4

1-Beat Write after 1-Beat Write 12/10

Clock Periods Required for:

1

31111/7

6/2

7/3

1

1

1

11110/6

---8/6

---12/10

Total

Clocks

Notes 1. These numbers assume that the PowerPC 604 bus master

is doing address pipelining with TS∗ occurring at the
minimum time after AACK∗ is asserted. Also the two

numbers shown in the 1st beat column are for page miss/page
hit.

2. In some cases, the numbers shown are averages and
specific instances may be longer or shorter.

If all blocks of DRAMs are 50ns, EDO devices then the latency times for
the ECC memory would be as follows:

Table 4-4. PPC604-to-DRAM Timing — 50ns EDO Devices

Clock Periods Required for:

Access Type

4-Beat Read after Idle
(Quad-word aligned)

4-8 Computer Group Literature Center Web Site

1st Beat 2nd Beat 3rd Beat 4th Beat

81 1111

Total

Clocks

General Description

Table 4-4. PPC604-to-DRAM Timing — 50ns EDO Devices (Continued)

Access Type

1st Beat 2nd Beat 3rd Beat 4th Beat

4-Beat Read after Idle
(Quad-word misaligned)

4-Beat Read after 4-Beat Read
(Quad-word aligned)

4-Beat Read after 4-Beat Read
(misaligned)

4-Beat Write after Idle 4 1 1 1 7

4-Beat Write after 4-Beat Write
(Quad-word aligned)

1-Beat Read after Idle 8 - - - 8

1-Beat Read after 1-Beat Read 7/5

1-Beat Write after Idle 4 - - - 4

1-Beat Write after 1-Beat Write 9/7

Clock Periods Required for:

82 1112

1

5/2

1

2118/6

4/2

1

4/3

1

1

1 1 1 8/5

1117/6

---7/5

---9/7

Total

Clocks

Notes 1. These numbers assume that the PowerPC 604 bus master

is doing address pipelining with TS∗ occurring at the
minimum time after AACK∗ is asserted. Also the two

numbers shown in the 1st beat column are for page miss/page
hit.

4

Flash Memory

The MVME2300SC base board has provision for up to 5MB of Flash
memory.

4-9

2. In some cases, the numbers shown are averages and
specific instances may be longer or shorter.

Functional Description

Bank B consists of 1MB of 8-bit Flash memory in two 32-pin PLCC 8-bit
sockets.

Bank A consists of four 16-bit Smart Voltage SMT devices populated with
8Mbit Flash devices (for a total of 4MB). Only 32-bit writes are supported
for this bank of Flash. Both banks contain the on-board firmware,

4

PPCBug. The address of the reset vector, 0xFFF00100, is jumper­selectable. A jumper must be installed either between J8 pins 1 and 2 for
Bank A, or between J8 pins 2 and 3 for Bank B (the factory configuration).
The Falcon chipset maps 0xFFF00100 to Bank A or B depending on the
jumper setting.

The onboard monitor/debugger, PPCBug, resides in the Flash chips.
PPCBug provides functionality for:

❏ Booting the system
❏ Initializing after a reset
❏ Displaying and modifying configuration variables
❏ Running self-tests and diagnostics
❏ Updating firmware ROM

Under normal operation, the Flash devices are in “read-only” mode, their
contents are pre-defined, and they are protected against inadvertent writes
due to loss of power. For programming purposes, however, programming
voltage is always supplied to the devices and the Flash contents may be
modified by executing the proper program command sequence. Refer to

the PFLASH command in the PPCbug Debugging Package User’s
Manual for further device-specific information on modifying Flash

contents.

Flash Latency

There is one 16-bit port bank of Flash on the MVME2300SC. The access
times for this bank are shown in the following table.

4-10 Computer Group Literature Center Web Site

General Description

Table 4-5. PowerPC604-Bus-to-Flash Ti ming — Bank B (16-bit Port)

Clock Periods Required for:

Access type

1st Beat

4-Beat Read 68 64 64 64 260

4-Beat Write N/A N/A N/A N/A N/A

1-Beat Read (2 bytes to 8 bytes) 68 - - - 68

1-Beat Read (1 byte) 20 - - - 20

1-Beat Write 19 - - - 19

2nd

Beat

3rd

Beat

4th

Beat

Ethernet Interface

The MVME2300SC module uses Digital Equipment’s DECchip 21143
PCI Fast Ethernet LAN controller to implement an Ethernet interface that
supports 10Base-T/100Base-TX connections, via an RJ45 connector on
the front panel. Ethernet AUI signals are routed to the P2 connector. The
balanced differential transceiver lines are coupled via on-board
transformers.

Every MVME2300SC is assigned an Ethernet station address. The address

is $0001AF2xxxxx, where xxxxx is the unique 5-nibble number assigned to
the board (i.e., every board has a different value for xxxxx).

Total

Clocks

4

4-11

Each MVME2300SC displays its Ethernet station address on a label
attached to the base board in the PMC connector keepout area just behind
the front panel. In addition, the six bytes including the Ethernet station
address are stored in the NVRAM (BBRAM) configuration area specified

by boot ROM. That is, the value 0001AF2xxx xx is stored in NVRAM. The

MVME2300SC debugger, PPCBug, has the capability to retrieve the

Ethernet station address via the CNFG command.

Functional Description

Note The unique Ethernet address is set at the factory and should

not be changed. Any attempt to change this address may
create node or bus contention and thereby render the board
inoperable.

If the data in NVRAM is lost, use the number on the label in the PMC

4

connector keepout area to restore it.

For the pin assignments of the 10Base-T/100Base-TX connector, refer to
Chapter 5.

At the physical layer, the Ethernet interface bandwidth is 10Mbit/second
for 10Base T. For the 100Base TX, it is 100Mbit/second. Refer to the
description of the NVRAM/RTC and Watchdog Timer registers in the

MVME2300 Series VME Processor Module Programmer’s Reference
Guide for detailed programming information.

PCI Mezzanine Card (PMC) Interface

A key feature of the MVME2300SC family is the PCI bus. In addition to
the on-board local bus devices (Ethernet, etc.), the PCI bus supports an
industry-standard mezzanine interface, IEEE P1386.1 PCI Mezzanine
Card (PMC).

PMC modules offer a variety of possibilities for I/O expansion such as
FDDI (Fiber Distributed Data Interface), ATM (Asynchronous Transfer
Mode), graphics, Ethernet, or SCSI ports. For a complete listing of
available PMCs, go to the GroupIPC World Wide Web site at URL
The MVME2300SC supports PMC
front panel and rear P2 I/O. There is also provision for stacking one or two
PMC carrier boards, or PMCspan PCI expansion modules, on the
MVME2300SC for additional expansion.

The MVME2300SC supports two PMC slots. Two sets of four 64-pin
connectors on the base board (J11 - J14, and J21 - J24) interface with 32­bit/64-bit IEEE P1386.1 PMC-compatible mezzanines to add any
desirable function.

4-12 Computer Group Literature Center Web Site

General Description

Refer to Chapter 5 for the pin assignments of the PMC connectors. For
detailed programming information, refer to the PCI bus descriptions in the

MVME2300 Series VME Processor Module Programmer’s Reference
Guide and to the user documentation for the PMC modules you intend to

use.

PMC Slot 1 (Single-Width PMC)

PMC slot 1 has the following characteristics:

Mezzanine Type PCI Mezzanine Card (PMC)
Mezzanine Size
PMC Connectors J11 to J14 (32/64-Bit PCI with front and rear I/O)

Signaling Voltage V

For P2 I/O configurations, pins 1 through 32 of J14 are routed to row C and
row A of P2.

PMC Slot 2 (Single-Width PMC)

PMC slot 2 has the following characteristics:

Mezzanine Type PCI Mezzanine Card (PMC)
Mezzanine Size
PMC Connectors J21 to J24 (32/64-Bit PCI with front and rear I/O)

Signaling Voltage V

S1B: Single width, standard depth (75mm x 150mm)
with front panel

= 5.0Vdc

io

S1B: Single width, standard depth (75mm x 150mm)
with front panel

= 5.0Vdc

io

4

4-13

For P2 I/O configurations, pins 1 through 32 of J24 (as with J14) are routed
to row C and row A of P2.

Functional Description

PMC Slots 1 and 2 (Double-Width PMC)

PMC slots 1 and 2 with a double-width PMC have the following
characteristics:

Mezzanine Type PCI Mezzanine Card (PMC)

4

Mezzanine Size

PMC Connectors
Signaling Voltage V

Double width, standard depth (150mm x 150 mm)
with front panel

J11 to J14 and J21 to J24 (32/64-Bit PCI) with front
and rear I/O

= 5.0Vdc

io

PCI Expansion

The PMCspan expansion module connector, J6, is a 114-pin Mictor
connector. It is located near P2 on the primary side of the MVME2300SC.
Its interrupt lines are routed to the Raven MPIC.

VMEbus Interface

The VMEbus interface is implemented with the CA91C042 Universe
ASIC. The Universe chip interfaces the 32/64-bit PCI local bus to the
VMEbus.

The Universe ASIC provides:

❏ The PCI-bus-to-VMEbus interface

❏ The VMEbus-to-PCI-bus interface

❏ The DMA controller functions of the local VMEbus

The Universe chip includes Universe Control and Status Registers
(UCSRs) for interprocessor communications. It can provide the VMEbus
system controller functions as well. For detailed programming

information, refer to the Universe User’s Manual and to the discussions in
the MVME2300 Series VME Processor Module Programmer's Reference
Guide.

4-14 Computer Group Literature Center Web Site

Maximum performance is achieved with D64 Multiplexed Block
Transfers (MBLT). The on-chip DMA channel should be used to move
large blocks of data to/from the VMEbus. The Universe should be able to
reach 50MB/second in 64-bit MBLT mode.

The MVME2300SC interfaces to the VMEbus via the P1 and P2
backplane connectors, which use three-row 96-pin connectors as specified
in the VMEbus standard. It also draws +5V, +12V, and –12V power from
the VMEbus backplane through these two connectors. 3.3V and 2.5V
supplies are regulated onboard from the +5 power.

Asynchronous Debug Port

A Texas Instruments TL16C550 Universal Asynchronous
Receiver/Transmitter (UART) provides the asynchronous debug port.
TTL-level signals for the port are routed through appropriate EIA-232-D
drivers and receivers to a DB9 connector on the front panel, and to the P2
backplane connector. The external signals are ESD protected.

This serial port can support 19.2 KBaud I/O. For detailed programming

information, refer to the MVME2300 Series VME Processor Module
Programmer’s Reference Guide and to the vendor documentation for the

UART device.

General Description

4

PCI/ISA Bridge (PIB) Controller

The MVME2300SC uses a Winbond W83C553 PCI/ISA Bridge (PIB)
Controller to supply the interface between the PCI local bus and the ISA
system I/O bus (diagrammed in Figure 4-1).

The PIB controller provides the following functions:

❏ PCI bus arbitration for:

– ISA (Industry Standard Architecture) bus DMA (not functional

on the MVME2300SC)

– The PHB (PCI Host Bridge) MPU/local bus interface function,

implemented by the Raven ASIC

– All on-board PCI devices

4-15

Functional Description

– The PMC slot

❏ ISA bus arbitration for DMA devices

❏ ISA interrupt mapping for four PCI interrupts

❏ Interrupt controller functionality to support 14 ISA interrupts

4

❏ Edge/level control for ISA interrupts

❏ Seven independently programmable DMA channels

❏ One 16-bit timer

❏ Three interval counters/timers

Accesses to the configuration space for the PIB controller are performed
by way of the CONADD and CONDAT (Configuration Address and Data)
registers in the Raven bridge controller ASIC. The registers are located at
offsets $CF8 and $CFC, respectively, from the PCI I/O base address.

Real-Time Clock/NVRAM/Timer Function

The MVME2300SC employs an SGS-Thomson surface-mount M48T559
RAM and clock chip to provide 8KB of non-volatile static RAM, a real­time clock, and a watchdog timer function. This chip supplies a clock,
oscillator, crystal, power failure detection, memory write protection, 8KB
of NVRAM, and a battery in a package consisting of two parts:

❏ A 28-pin 330mil SO device containing the real-time clock, the

oscillator, power failure detection circuitry, timer logic, 8KB of
static RAM, and gold-plated sockets for a battery

❏ A SNAPHAT battery housing a crystal along with the battery

The SNAPHAT battery package is mounted on top of the M48T559
device. The battery housing is keyed to prevent reverse insertion.

The clock furnishes seconds, minutes, hours, day, date, month, and year in
BCD 24-hour format. Corrections for 28-, 29- (leap year), and 30-day
months are made automatically. The clock generates no interrupts.
Although the M48T559 is an 8-bit device, 8-, 16-, and 32-bit accesses from

the ISA bus to the M48T559 are supported. Refer to the MVME2300 Seri es

4-16 Computer Group Literature Center Web Site

VME Processor Module Programmer’s Reference Guide and to the

M48T559 data sheet for detailed programming and battery life
information.

PCI Host Bridge

General Description

The Raven ASIC provides the bridge function between the MPC604
processor bus and the PCI Local Bus. It provides 32-bit addressing and 64­bit data. 64-bit addressing (dual address cycle) is not supported. The Raven
supports various PowerPC processor external bus frequencies up to
66MHz and PCI frequencies up to 33MHz.

There are four programmable map decoders for each direction to provide
flexible address mappings between the MPC and the PCI Local Bus. Refer

to the MVME2300 Series VME Processor Module Programmer’s
Reference Guide for additional information and programming details.

Interrupt Controller (MPIC)

The Raven ASIC provides an MPIC Interrupt Controller to handle various
interrupt sources. The interrupt sources are:

❏ Four MPIC timer interrupts

❏ Processor 0 self-interrupt

❏ Memory Error interrupt from the Falcon chipset

❏ Interrupts from all PCI devices

❏ Two software interrupts

4

❏ ISA interrupts (actually handled as a single 8259 interrupt at INT0)

Programmable Timers

Among the resources available to the local processor are a number of
programmable timers. Timers are incorporated into the PCI/ISA Bridge
(PIB) controller and the Raven device (diagrammed in Figure 4-1). They
can be programmed to generate periodic interrupts to the processor.

4-17

Functional Description

Interval Timers

The PIB controller has three built-in counters that are equivalent to those
found in an 82C54 programmable interval timer. The counters are grouped
into one timer unit, Timer 1, in the PIB controller. Each counter output has
a specific function:

4

❏ Counter 0 is associated with interrupt request line IRQ0. It can be

used for system timing functions, such as a timer interrupt for a
time-of-day function.

❏ Counter 1 generates a refresh request signal for ISA memory. This

timer is not used in the MVME2300SC.

❏ Counter 2 provides the tone for the speaker output function on the

PIB controller (the

SPEAKER_OUT signal which can be cabled to an

external speaker via the remote reset connector). This function is not
used on the MVME2300SC.

The interval timers use the OSC clock input as their clock source. The
MVME2300SC drives the OSC pin with a 14.31818MHz clock source.

16/32-Bit Timers

The MVME2300SC has one 16-bit timer and four 32-bit timers. The 16­bit timer is provided by the PIB. Raven device provides the four 32-bit
timers that may be used for system timing or for generation of periodic
interrupts. For information on programming these timers, refer to the data

sheet for the W83C553 PIB controller and to the MVME2300 Series VME
Processor Module Programmer’s Reference Guide.

4-18 Computer Group Literature Center Web Site

Connectors

General Description

The MVME2300SC interfaces to the VMEbus via P1 and P2, which are
implemented with the three-row 96-pin connectors specified in the IEEE
P1014-1987 VMEbus specification. The board also draws +5V, +12V, and

−12V power from the VMEbus backplane through these two connectors.

(The 3.3V supply is regulated on-board from the +5V power.)

Front panel connectors on the MVME2300SC include an RJ45 connector
for the Ethernet 10BaseT/100BaseTX interface, and a 9-pin DB9
connector for the asynchronous serial debug port.

The MVME2300SC is equipped with two IEEE 1386.1 PCI Mezzanine
Card (PMC) slots. The PMC slots are 64-bit capable and support both
front and rear I/O. Pins 1-32 of PMC slot 1 connector J14 are routed to
rows C and A of the 3-row P2 connector. Pins 1-32 of PMC slot 2
connector J24 are likewise routed to rows C and A of connector P2.

Additional PCI expansion is supported with a 114-pin Mictor connector
(J6). This connection permits the stacking of one or two PMCspan dual­PMC carrier boards on the MVME2300SC for increased I/O capability.
Each PMCspan board that you add requires an additional VME slot.

4

4-19

Pin assignments for the connectors on the MVME2300SC are listed in
Chapter 5.

Functional Description

Status Indicators

The MVME2300SC front panel has four LED (light-emitting
diode) status indicators:

❏ BFL (DS1, yellow). Board failure; lights when the

BRDFAIL

∗ signal line is active.

4

❏ CPU (DS2, green). CPU activity; lights when the DBB∗

(Data Bus Busy) signal line on the processor bus is
active.

❏ SCON (DS3, green). System controller; lights when the

DEBUG

ABT

RST

10/100 BASET

BFL

CPU

SCON

FUS

MVME2300SC is functioning as VMEbus system
controller.

❏ FUS (DS4, green). Fuses OK; indicates that +5Vdc and

+12Vdc power is available on the board (

−12Vdc is not

PCI MEZZANINE CARD PCI MEZZANINE CARD

fused). The fuses are resettable polyswitches.

10/100 BASET Port

The RJ45 port labeled

10/100 BASET on the MVME2300SC

front panel supplies the Ethernet LAN 10BaseT/100BaseTX
interface, implemented with a DEC 21143 controller chip.

Note Ethernet AUI signals are routed to the P2

connector.

DEBUG Port

The DB9 port labeled

DEBUG on the front panel of the

MVME2300SC supplies the serial communications interface,
implemented via a TL16C550 UART controller chip from
Texas Instruments. It is asynchronous only. This serial port is
configured for EIA-232-D DTE.

The serial I/O signals are also available via P2 and a transition
module.

4-20 Computer Group Literature Center Web Site

5Pin Assignments

Connector Pin Assignments

This chapter summarizes the pin assignments for the following groups of
interconnect signals on the MVME2300SC:

Connector Location Table

VMEbus connector P1 Table 5-1

VMEbus connector, P2 I/O P2 Table 5-2

Debug serial port, DB9 DEBUG (J2) Table 5 -3

Ethernet port, RJ45 10/100 BASET (J3) Ta ble 5 - 4

CPU debug connector J1 Ta ble 5 - 5

PCI expansion connector J18 Tab le 5-6

PMC connectors,

Slot 1

PMC connectors,

Slot 2

64-bit PCI extension and P2 I/O J13, J14 Tabl e 5-8

64-bit PCI extension and P2 I/O J23, J24 Table 5-10

32-bit PCI J11, J12 Tabl e 5-7

32-bit PCI J21, J22 Table 5-9

5

The tables in this chapter furnish pin assignments only. For detailed
descriptions of the interconnect signals, consult the support information
for the MVME2300SC (available through your Motorola sales office).

VMEbus Connectors (P1, P2)

Two three-row 96-pin DIN type connectors, P1 and P2, supply the
interface between the base board and the VMEbus. P1 provides power and
VME signals for 24-bit addressing and 16-bit data. Its pin assignments are
set by the IEEE P1014-1987 VMEbus Specification. P2 rows A and C
provide power and interface signals for the transition module and SCSA
backplane, if present. P2 Row C supplies the base board with power, with
the upper 8 VMEbus address lines, and with an additional 16 VMEbus data
lines. The pin assignments are listed in the following two tables.

5-1

Pin Assignments

Table 5-1. VMEbus Connector P1 Pin Assignments

Row A Row B Row C

1 VD0 VBBSY∗ VD8 1
2 VD1 VBCLR∗ VD9 2
3 VD2 VACFAIL∗ VD10 3
4 VD3 VBGIN0∗ VD11 4
5 VD4 VBGOUT0∗ VD12 5

5

6 VD5 VBGIN1∗ VD13 6
7 VD6 VBGOUT1∗ VD14 7
8 VD7 VBGIN2∗ VD15 8

9 GND VBGOUT2∗ GND 9
10 VSYSCLK VBGIN3∗ VSYSFAIL∗ 10
11 GND VBGOUT3∗ VBERR∗ 11
12 VDS1∗ VBR0∗ VSYSRESET∗ 12
13 VDS0∗ VBR1∗ VLWORD∗ 13
14 VWRITE∗ VBR2∗ VAM 5 1 4
15 GND VBR3∗ VA23 15
16 VDTACK∗ VA M 0 VA2 2 1 6

17 GND VAM1 VA21 17
18 VAS∗ VA M 2 VA2 0 1 8

19 GND VAM3 VA19 19
20 VIACK∗ GND VA18 20
21 VIACKIN∗ Not Used VA17 21
22 VIACKOUT∗ Not Used VA16 22

23 VAM4 GND VA15 23
24 VA7 VIRQ7∗ VA14 24
25 VA6 VIRQ6∗ VA13 25
26 VA5 VIRQ5∗ VA12 26
27 VA4 VIRQ4∗ VA 1 1 27
28 VA3 VIRQ3∗ VA10 28
29 VA2 VIRQ2∗ VA 9 2 9
30 VA1 VIRQ1∗ VA 8 3 0

31 –12V Not Used +12V 31

32 +5V +5V +5V 32

5-2 Computer Group Literature Center Web Site
