MVME172

VME Embedded Controller

Programmer’s

Reference Guide

VME172A/PG2

Edition of February 1999

Notice

While reasonable efforts have been made to assure the accuracy of this document, Motorola, In c. assume s no l iabilit y result ing fro m any omis sions in this document, or from the use of the information obtained therein. Motorola reserves the right to revise this document and to ma ke c hanges from time to ti me in the content hereof without ob li ga ti on of Motorola to notify any person of such revision or changes.

No part of this material may be reprod uced or copied in any ta ngible medium, or stored in a retrieval system, or transmitted in any form, or by any means, radio, electronic, mechanical, photocopying, recording or facsimile, or otherwise, without the prior written permission of Motorola, Inc.

It is possibl e tha t th is pu bli cation may c ontai n refer ence t o, or info rmatio n a bout Motoro la products (machines and programs), programming, or services that are not announced in your country. Such refere nces or informat ion must not be construed to mean that Moto rola intends to announce such Motorola products, programming, or services in your country.

Restricted Rights Legend

If the documentation contained herein is supplied, directly or indirectly, to the U.S. Government, the following notice shall apply unless otherwise agreed to in writing by Motorola, Inc.

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013.

Motorola, Inc.

Computer Group

2900 South Diablo Way

Tempe, Arizona 85282

Preface

This manual provides board level information and detailed ASIC chip information including register bit descriptions for the MVME172 Embedded Controller. The information contained in this manual applies to the following MVME172 models:

MVME172-303 MVME172-213 MVME172-313 MVME172-413 MVME172-513 MVME172-223 MVME172-323 MVME172-233 MVME172-333 MVME172-433 MVME172-243 MVME172-343 MVME172-253 MVME172-353 MVME172-453 MVME172-263 MVME172-363

MVME172-373

This manual is intended for anyone who wants to program these boards in order to design OEM systems, supply addi ti onal capability to an exi st ing compatible system, o r wor k i n a lab environment for experimental purposes.

A basic knowledge of computers and digital logic is assumed. To use this manual, you should be familiar with the publications listed in Related

Documentation below.

Manual Terminology

Throughout this man ual, a conven tion is used whi ch precedes data and addr ess parameter s by a character identifying the numeric format as follows:

$ dollar specifies a hexadecimal character % percent specifies a binary number & ampersand specifies a decimal number

For example, “12” is the decimal number twelve, and “$12” is the decimal number eighteen.

Unless otherwise specified, all address references are in hexadecimal. An asterisk (*) f ollowing the signal name for s ignals which are level significant deno tes that

the signal is true or valid when the signal is low. An asterisk (*) f ollowing the signal name for s ignals which are edge significant deno tes that

the actions initiated by that signal occur on high to low transition.

In this manual, assertion and negation are used to specify forcing a signal to a particular state. In particular, assertion and assert refer to a signal that i s acti ve or t rue; ne gation and negate indicate a sign al that i s inact ive or false . Thes e terms a re u sed inde pendent ly of t he voltage level (high or low) that they represent.

Data and address sizes are defined as follows:

❏ A byte is ei ght b it s, numbered 0 through 7, with bit 0 bei ng the least significant. ❏ A word is 16 bits, number ed 0 t hr ough 1 5, wit h bi t 0 be in g the lea st si gni fi can t. ❏ A longword is 32 bits, numbered 0 through 31, with bit 0 being the least

significant.

The terms contr ol bit, s tatus bit, true, and false are used ex tensi vely i n thi s document . The term control bit is used to describe a bit in a register that can be set and cleared under software control. The term true is used to indicate that a bit is in the state that enables the function it controls. The term false is used to i ndicate that the bit is in the state that disable s the function it controls. I n all table s, the term s 0 and 1 are us ed to desc ribe the act ual value that should be wri tten to the bit, or the value that i t yi elds whe n read . The te rm st atus b it is used to describe a bit in a register that reflects a specific condition. The status bit can be read by software to determine operational or exception conditions.

Recent Updates

This edition of the MVME172 VME Embedded Controller Progr ammer’s Reference Guide incorporates the following changes:

❏ The ‘‘MVME172 Version Regis ter‘ ‘ sect ion has an impr oved des cript ion of the

function of bit V6.

❏ The ‘‘PROM Access Time Cont rol Reg ist er ’’ and ‘‘Flash Access Time Control

❏ In accordance wit h recent MCG prac tice, the ‘ ‘Related Document ation’’ sec tion

has been moved from the front of the document to a separate appendix.

The computer programs stored in the Read Only Memory of this device contain material copyrighted by Motorola Inc., first published 1990, and may be used only under a license such as the Licens e for Computer Pro grams (Article 14) contained in M otorola’s T erms and Conditions of Sale, Rev. 1/79.

This equipment generat es, uses, and can radiate electro- magnet ic

WARNING

Motorola and the Motorola symbol are registered trademarks of Motorola, Inc. All other product s ment io ned in this document are trademarks or regist ered trademarks of

their respective holders.

energy. It may cause or be susceptible to electro-magnetic interference (EMI) if not i nstalled and used in a cabinet wi th adequate EMI protection.

Printed in the United States of America

February 1999

Place holder

Contents

CHAPTER 1 Board Description and Memory Maps

Introduction................................................................................................................1-1

Overview....................................................................................................................1-1

Requirements .............................................................................................................1-4

Block Diagrams .........................................................................................................1-5

Functional Description...............................................................................................1-5

No-VMEbus-Interface Option............................................................................1-5

VMEbus Interface and VMEchip2.....................................................................1-9

Memory Maps................................... .........................................................................1-9

Local Bus Memory Map.....................................................................................1-9

Normal Address Range................................................................................1-9

Detailed I/O Memory Maps.......................................................................1-21

BBRAM/TOD Clock Memory Map..........................................................1-40

Interrupt Acknowledge Map......................................................................1-46

VMEbus Memory Map............................... ..... ...... ...........................................1-46

VMEbus Accesses to the Local Bus..........................................................1-47

VMEbus Short I/O Memory Map..............................................................1-47

Software Support Considerations ............................................................................1-47

Interrupts...........................................................................................................1-47

Cache Coherency..............................................................................................1-48

Sources of Local BERR*..................................................................................1-48

Local Bus Time-out...................................................................................1-48

VMEbus Access Time-out........................ ...... ...... .....................................1-49

VMEbus BERR* ........................... ...... ..... .................................................1-49

Local DRAM Parity Error.........................................................................1-49

VMEchip2 .................................................................................................1-49

Bus Error Processing.................................................................................1-49

Description of Error Conditions on the MVME172.........................................1-50

MPU Parity Error.......................................................................................1-50

MPU Off-board Error................................................................................1-51

MPU TEA - Cause Unidentified ...............................................................1-51

MPU Local Bus Time-out.........................................................................1-51

DMAC VMEbus Error ..............................................................................1-52

DMAC Parity Error...................................................................................1-52

DMAC Off-board Error................. ............................................................1-53

DMAC LTO Error.....................................................................................1-53

vii

DMAC TEA - Cause Unidentified............................................................1-54

LAN Parity Error.......................................................................................1-54

LAN Off-Board Error ...............................................................................1-55

LAN LTO Error ........................................................................................1-55

SCSI Parity Error ......................................................................................1-56

SCSI Off-Board Error...............................................................................1-56

SCSI LTO Error........................................................................................1-56

Example of the Proper Use of Bus Timers.......................................................1-57

MVME172 MC68060 Indivisible Cycles........................................................1-58

Illegal Access to IP Modules from External VMEbus Masters .......................1-59

CHAPTER 2 VMEchip2

Introduction ...............................................................................................................2-1

Summary of Major Features...............................................................................2-1

Functional Blocks......................................................................................................2-4

Local Bus to VMEbus Interface.........................................................................2-4

Local Bus to VMEbus Requester................................................................2-7

VMEbus to Local Bus Interface...................................... ..... ..............................2- 9

Local Bus to VMEbus DMA Controller..........................................................2-10

No Address Increment DMA Transfers....................................................2-12

DMAC VMEbus Requester ..................................... ..... ............................2-1 3

Tick and Watchdog Timers.................................. .............................................2-14

Prescaler.......... ...... ....................................................................................2-1 4

Tick Timers...............................................................................................2-15

Watchdog Timer........................................................................................2-15

VMEbus Interrupter ....................................... ..... ...... .......................................2-16

VMEbus System Controller ........................... ..... ...... .......................................2-17

Arbiter............. ...... ....................................................................................2-17

IACK Daisy-Chain Driver ........................................................................2-17

Bus Timer..................................................................................................2-17

Reset Driver ..............................................................................................2-18

Local Bus Interrupter and Interrupt Handler....................................................2-18

Global Control and Status Registers ................................................................2-20

LCSR Programming Model.....................................................................................2-20

Programming the VMEbus Slave Map Decoders............................................2-26

VMEbus Slave Ending Address Register 1 .............................................2-28

VMEbus Slave Starting Address Register 1 ............................................2-28

VMEbus Slave Ending Address Register 2 .............................................2-29

VMEbus Slave Starting Address Register 2 ............................................2-29

VMEbus Slave Address Translation Address Offset Register 1 ..............2-29

viii

VMEbus Slave Address Translation Select Register 1 ............................2-30

VMEbus Slave Address Translation Address Offset Register 2...............2-31

VMEbus Slave Address Translation Select Register 2 ............................2-31

VMEbus Slave Write Post and Snoop Control Register 2 ........................2-32

VMEbus Slave Address Modifier Select Register 2 .................................2-33

VMEbus Slave Write Post and Snoop Control Register 1 ........................2-35

VMEbus Slave Address Modifier Select Register 1 .................................2-36

Programming the Local Bus to VMEbus Map Decoders.................................2-37

Local Bus Slave (VMEbus Master) Ending Address Register 1...............2-39

Local Bus Slave (VMEbus Master) Starting Address Register 1..............2-40

Local Bus Slave (VMEbus Master) Ending Address Register 2...............2-40

Local Bus Slave (VMEbus Master) Starting Address Register 2..............2-40

Local Bus Slave (VMEbus Master) Ending Address Register 3 ..............2-41

Local Bus Slave (VMEbus Master) Starting Address Register 3 .............2-41

Local Bus Slave (VMEbus Master) Ending Address Register 4 ..............2-41

Local Bus Slave (VMEbus Master) Starting Address Register 4 .............2-42

Local Bus Slave (VMEbus Master)

Address Translation Address Register 4 ..........................................2-42

Local Bus Slave (VMEbus Master)

Address Translation Select Register 4 ..............................................2-42

Local Bus Slave (VMEbus Master) Attribute Register 4 .........................2-43

Local Bus Slave (VMEbus Master) Attribute Register 3 .........................2-44

Local Bus Slave (VMEbus Master) Attribute Register 2 .........................2-45

Local Bus Slave (VMEbus Master) Attribute Register 1 .........................2-46

VMEbus Slave GCSR Group Address Register .......................................2-47

VMEbus Slave GCSR Board Address Register .......................................2-48

Local Bus to VMEbus Enable Control Register .......................................2-49

Local Bus to VMEbus I/O Control Register ............................................2-50

ROM Control Register ............................. .................................................2-51

Programming the VMEchip2 DMA Controller................................................2-52

DMAC Registers ........................... ...... ......................................................2-53

PROM Decoder, SRAM and DMA Control Register ..............................2-54

Local Bus to VMEbus Requester Control Register ..................................2-55

DMAC Control Register 1 (bits 0-7) ........................................................2-56

DMAC Control Register 2 (bits 8-15) ......................................................2-57

DMAC Control Register 2 (bits 0-7) ........................................................2-59

DMAC Local Bus Address Counter................................ ...... ..... ...............2-60

DMAC VMEbus Address Counter ...........................................................2-60

DMAC Byte Counter .......................... ..... ...... ...........................................2-61

Table Address Counter .............................................................................2-61

VMEbus Interrupter Control Register ................................................... ...2-61

VMEbus Interrupter Vector Register ........................................ ...............2-63

MPU Status and DMA Interrupt Count Register .....................................2-63

DMAC Status Register ............... ..............................................................2-64

Programming the Tick and Watchdog Timers..................................................2-65

VMEbus Arbiter Time-out Control Register ...........................................2-65

DMAC Ton/Toff Timers

and VMEbus Global Time-out Control Register ..............................2-66

VME Access, Local Bus, and Watchdog Time-out Control Register ......2-67

Prescaler Control Register ........................................................................2-68

Tick Timer 1 Compare Register ...............................................................2-69

Tick Timer 1 Counter ...............................................................................2-69

Tick Timer 2 Compare Register ...............................................................2-70

Tick Timer 2 Counter ...............................................................................2-70

Board Control Register ............................................................................2-71

Watchdog Timer Control Register ...........................................................2-72

Tick Timer 2 Control Register .................................................................2-73

Tick Timer 1 Control Register .................................................................2-74

Prescaler Counter .....................................................................................2-74

Programming the Local Bus Interrupter...........................................................2-75

Local Bus Interrupter Status Register (bits 24-31) ..................................2-78

Local Bus Interrupter Status Register (bits 16-23) ..................................2-79

Local Bus Interrupter Status Register (bits 8-15) ....................................2-80

Local Bus Interrupter Status Register (bits 0-7) ......................................2-81

Local Bus Interrupter Enable Register (bits 24-31) .................................2-82

Local Bus Interrupter Enable Register (bits 16-23) .................................2-83

Local Bus Interrupter Enable Register (bits 8-15) ...................................2-84

Local Bus Interrupter Enable Register (bits 0-7) .....................................2-85

Software Interrupt Set Register (bits 8-15) ..............................................2-86

Interrupt Clear Register (bits 24-31) ........................................................2-86

Interrupt Clear Register (bits 16-23) ........................................................2-87

Interrupt Clear Register (bits 8-15) ..........................................................2-88

Interrupt Level Register 1 (bits 24-31) .....................................................2-88

Interrupt Level Register 1 (bits 16-23) .....................................................2-89

Interrupt Level Register 1 (bits 8-15) .......................................................2-89

Interrupt Level Register 1 (bits 0-7) .........................................................2-90

Interrupt Level Register 2 (bits 24-31) .....................................................2-90

Interrupt Level Register 2 (bits 16-23) .....................................................2-91

Interrupt Level Register 2 (bits 8-15) .......................................................2-91

Interrupt Level Register 2 (bits 0-7) .........................................................2-92

Interrupt Level Register 3 (bits 24-31) .....................................................2-92

Interrupt Level Register 3 (bits 16-23) .....................................................2-93

Interrupt Level Register 3 (bits 8-15) .......................................................2-93

Interrupt Level Register 3 (bits 0-7) .........................................................2-94

Interrupt Level Register 4 (bits 24-31) .....................................................2-94

Interrupt Level Register 4 (bits 16-23) .....................................................2-95

Interrupt Level Register 4 (bits 8-15) .......................................................2-95

Interrupt Level Register 4 (bits 0-7) .........................................................2-96

Vector Base Register ................................................................................2-96

I/O Control Register 1 ..............................................................................2-97

I/O Control Register 2 ..............................................................................2-98

I/O Control Register 3 ..............................................................................2-98

Miscellaneous Control Register ................................................................2-99

GCSR Programming Model...................................................................................2-101

Programming the GCSR.................................................................................2-103

VMEchip2 Revision Register .................................................................2-105

VMEchip2 ID Register............................................................................2-105

VMEchip2 LM/SIG Register ..................................................................2-105

VMEchip2 Board Status/Control Register .............................................2-107

General Purpose Register 0 ....................................................................2-108

General Purpose Register 1 ....................................................................2-108

General Purpose Register 2 ....................................................................2-109

General Purpose Register 3 ....................................................................2-109

General Purpose Register 4 ....................................................................2-110

General Purpose Register 5 ....................................................................2-110

CHAPTER 3 MC2 Chip

Introduction................................................................................................................3-1

Summary of Major Features...............................................................................3-1

Functional Description...............................................................................................3-2

MC2 Chip Initialization......................................................................................3-2

Flash and PROM Interface .................................................................................3-2

BBRAM Interface................ ...... .........................................................................3-3

82596CA LAN Interface ....................................................................................3-3

MPU Port and MPU Channel Attention......................................................3-3

MC68060-Bus Master Support for 82596CA .............................................3-4

LANC Bus Error............................................. .............................................3-4

LANC Interrupt .............................................. ...... .......................................3-5

53C710 SCSI Controller Interface.................................... ..................................3-5

SRAM Memory Controller.................................................................................3-5

NON-ECC DRAM Memory Controller .............................................................3-5

Z85230 SCC Interface........................................................................................3-6

Tick Timers........................................... ...... ........................................................3-7

Watchdog Timer..................................................................................................3-8

Local Bus Timer.................................................................................................3-8

Memory Map of the MC2 Chip Registers.................................................................3-8

Programming Model................................................................................................3-10

MC2 Chip ID Register .....................................................................................3-11

MC2 Chip Revision Register ...........................................................................3-11

General Control Register .................................................................................3-12

Interrupt Vector Base Register .........................................................................3-13

Programming the Tick Timers..........................................................................3-15

Tick Timer 1 and 2 Compare and Counter Registers................................3-15

LSB Prescaler Count Register...................................................................3-17

Prescaler Clock Adjust Register................................................................3-18

Tick Timer 1 and 2 Control Registers.......................................................3-18

Tick Timer Interrupt Control Registers.....................................................3-20

DRAM Parity Error Interrupt Control Register ............................................... 3-22

SCC Interrupt Control Register........................................................................3-23

Tick Timer 3 and 4 Control Registers..............................................................3-24

DRAM and SRAM Memory Controller Registers........................... ................3-25

DRAM Space Base Address Register.......................................................3-25

SRAM Space Base Address Register........................................................3-26

DRAM Space Size Register............................... ...... ..... ............................3-26

DRAM/SRAM Options Register ..............................................................3-27

SRAM Space Size Register.......................................................................3-29

LANC Error Status Register...................................... ...... .................................3-30

82596CA LANC Interrupt Control Register....................................................3-31

LANC Bus Error Interrupt Control Register....................................................3-32

SCSI Error Status Register...............................................................................3-33

General Purpose Inputs Register............................... ...... .................................3-33

MVME172 Version Register............................................................................3-35

SCSI Interrupt Control Register.......................................................................3-36

Tick Timer 3 and 4 Compare and Counter Registers.......................................3-37

Bus Clock Register...........................................................................................3-38

PROM Access Time Control Register .............................................................3-39

Flash Access Time Control Register................................................................3-40

ABORT Switch Interrupt Control Register......................................................3-41

RESET Switch Control Register......................................................................3-42

Watchdog Timer Control Register....................................................................3-43

Access and Watchdog Time Base Select Register............................................3-44

DRAM Control Register ........................................... ...... ..... ............................3-45

MPU Status Register........................................................................................3-46

32-bit Prescaler Count Register........................................................................3-48

xii

CHAPTER 4 IP2 Chip

Introduction................................................................................................................4-1

Summary of Major Features...............................................................................4-1

Functional Description...............................................................................................4-2

General Description............................................................................................4-2

Cache Coherency................................................................................................4-2

Local Bus to IndustryPack DMA Controllers.....................................................4-3

Clocking Environments and Performance..........................................................4-5

Programmable Clock..........................................................................................4-7

Error Reporting..................................... ..............................................................4-7

Error Reporting as a Local Bus Slave .............................................. ...........4-7

Error Reporting as a Local Bus Master .......................................................4-7

IndustryPack Error Reporting......................................................................4-8

Interrupts.............................................................................................................4-8

Overall Memory Map ......................................................... .......................................4-9

Programming Model................................................................................................4-10

Chip ID Register...............................................................................................4-17

Chip Revision Register.....................................................................................4-17

Vector Base Register.........................................................................................4-18

IP_a, IP_b, IP_c, IP_d Memory Base Address Registers.................................4-19

IP_a or Double Size IP_ab Memory Base Address Registers ..................4-20

IP_b Memory Base Address Registers......................................................4-20

IP_c or Double Size IP_cd Memory Base Address Registers...................4-21

IP_d Memory Base Address Registers......................................................4-21

IP_a, IP_b, IP_c, IP_d Memory Size Registers................................................4-21

IP_a, IP_b, IP_c, and IP_d; IRQ0 and IRQ1 Interrupt Control Registers........4-23

IP_a, IP_b, IP_c, and IP_d; General Control Registers....................................4-24

IP Clock Register..............................................................................................4-28

DMA Arbitration Control Register...................................................................4-29

IP RESET Register ..........................................................................................4-30

Programming the DMA Controllers.................................................................4-31

DMA Enable Function...............................................................................4-33

DMA Control and Status Register Set Definition .....................................4-33

Programming the Programmable Clock....................................................4-43

Local Bus to IndustryPack Addressing....................................................................4-46

8-Bit Memory Space.........................................................................................4-46

16-Bit Memory Space.......................................................................................4-47

32-Bit Memory Space.......................................................................................4-48

IP_a I/O Space..................................................................................................4-49

IP_ab I/O Space................................................................................................4-50

IP_a ID Space ...................................................................................................4-51

xiii

IP to Local Bus Data Routing..................................................................................4-52

Memory Space Accesses..................................................................................4-52

I/O and ID Space Accesses ..............................................................................4-54

CHAPTER 5 MCECC

Introduction ...............................................................................................................5-1

Features......................................................................................................................5-1

Functional Description ..............................................................................................5-2

General Description............................................................................................5-2

Performance........................................................................................................5-2

Cache Coherency................................................................................................5-3

ECC....................................................................................................................5-4

Cycle Types.................................................................................................5-4

Error Reporting ........................... ...... ..........................................................5-5

Single Bit Error (Cycle Type = Burst Read or Non-Burst Read) ...............5-5

Double Bit Error (Cycle Type = Burst Read or Non-Burst Read)..............5-5

Triple (or Greater) Bit Error

(Cycle Type = Burst Read or Non-Burst Read)..................................5-6

Cycle Type = Burst Write...........................................................................5-6

Single Bit Error (Cycle Type = Non-Burst Write)......................................5-6

Double Bit Error (Cycle Type = Non-Burst Write)....................................5-6

Triple (or Greater) Bit Error (Cycle Type = Non-Burst Write)..................5-6

Single Bit Error (Cycle Type = Scrub) .......................................................5-6

Double Bit Error (Cycle Type = Scrub)......................................................5-7

Triple (or Greater) Bit Error (Cycle Type = Scrub)....................................5-7

Error Logging........................................... ..........................................................5-7

Scrub................................................................................................................... 5-7

Refresh................................ ..... ...... ..................................................................... 5-8

Arbitration.......................................... ...... ..........................................................5-8

Chip Defaults......................................................................................................5-8

Programming Model..................................................................................................5-9

Chip ID Register...............................................................................................5-14

Chip Revision Register.....................................................................................5-14

Memory Configuration Register ..................................... .................................5-15

Dummy Register 0............................................................................................ 5-16

Dummy Register 1............................................................................................ 5-17

Base Address Register...................................................................................... 5-17

DRAM Control Register ........................................... ...... ..... ............................5-18

BCLK Frequency Register...............................................................................5-20

Data Control Register.......................................................................................5-21

xiv

Scrub Control Register......................................................................................5-23

Scrub Period Register Bits 15-8........................................................................5-24

Scrub Period Register Bits 7-0..........................................................................5-24

Chip Prescaler Counter.....................................................................................5-25

Scrub Time On/Time Off Register....................................................................5-25

Scrub Prescaler Counter (Bits 21-16)...............................................................5-27

Scrub Prescaler Counter (Bits 15-8).................................................................5-28

Scrub Prescaler Counter (Bits 7-0)...................................................................5-28

Scrub Timer Counter (Bits 15-8)......................................................................5-28

Scrub Timer Counter (Bits 7-0)........................................................................5-29

Scrub Address Counter (Bits 26-24).................................................................5-29

Scrub Address Counter (Bits 23-16).................................................................5-30

Scrub Address Counter (Bits 15-8)...................................................................5-30

Scrub Address Counter (Bits 7-4).....................................................................5-31

Error Logger Register.................................................. ..... ................................5-31

Error Address (Bits 31-24) ...............................................................................5-32

Error Address (Bits 23-16) ...............................................................................5-33

Error Address Bits (15-8).................................................................................5-33

Error Address Bits (7-4)...................................................................................5-33

Error Syndrome Register................................. .................................................5-34

Defaults Register 1............................................................................................5-34

Defaults Register 2............................................................................................5-36

Initialization......................................................................................................5-37

Syndrome Decode....................................................................................................5-39

APPENDIX A Related Documentation

Motorola Computer Group Documents....................................................................A-1

Literature Updates..............................................................................................A-2

Manufacturers’ Documents.......................................................................................A-2

APPENDIX B Using Interrupts on the MVME172

Introduction...............................................................................................................B-1

VMEchip2 Tick Timer 1 Periodic In terrupt Example ..............................................B-1

INDEX

FIGURES

Figure 1-1. 200/300-Series MVME172 Block Diagram ........................................... 1-6

Figure 1-2. 400/500-Series MVME172 Block Diagram........................................... 1-7

Figure 2-1. VMEchip2 Block Diagram.....................................................................2-5

TABLES

Table 1-1. MVME172 Features Summary.................................................................1 -3

Table 1-2. Redundant Functions in the VMEchip2 and MC2 Chip .........................1-8

Table 1-3. 200/300-Series MVME172 Local Bus Memory Map............................1-10

Table 1-4. 400/500-Series MVME172 Local Bus Memory Map............................1-12

Table 1-5. 200/300-Series MVME172 Local I/O Devices Memory Map...............1-14

Table 1-6. 400/500-Series MVME172 Local I/O Devices Memory Map...............1-18

Table 1-7. VMEchip2 Memory Map (Sheet 1 of 3) ................................................1-22

Table 1-8. MC2 Chip Register Map ........................................................................ 1-27

Table 1-9. IP2 Chip Overall Memory Map..............................................................1-28

Table 1-10. IP2 Chip Memory Map - Contro l and Status Registers .......................1-29

Table 1-11. MCECC Internal Register Memory Map ............................................1-35

Table 1-12. Z85230 SCC Register Addresses .........................................................1-37

Table 1-13. 82596CA Ethernet LAN Memory Map................................................1-38

Table 1-14. 53C710 SCSI Memory Map ...............................................................1-39

Table 1-15. MK48T58 BBRAM/TOD Clock Memory Map...................................1-40

Table 1-16. BBRAM Configuration Area Memory Map ............................ ...... .....1-41

Table 1-17. TOD Clock Memory Map....................................................................1-42

Table 2-1. VMEchip2 Memory Map - LCSR Summary (Sheet 1 of 2)..................2-22

Table 2-2. DMAC Command Table Format............................................................2-53

Table 2-3. Local Bus Interrupter Summary ............................................................2-76

Table 2-4. VMEchip2 Memory Map (GCSR Summary) ......................................2-104

Table 3-1. DRAM Performance.................................................................................3 -6

Table 3-2. MC2 Chip Register Map .........................................................................3-9

Table 3-3. Interrupt Vector Base Register Encoding and Priority...........................3-14

Table 3-4. DRAM Size Control Bit Encoding.........................................................3-27

Table 3-5. DRAM Size Control Bit Encoding.........................................................3-28

Table 3-6. SRAM Size Control Bit Encoding .........................................................3-28

Table 3-7. SRAM Size Control Bit Encoding .........................................................3-29

Table 4-1. IP2 Chip Clock Cycles .............................................................................4-6

Table 4-2. IP2 Chip Overall Memory Map ...............................................................4-9

Table 4-3. IP2 Chip Memory Map - Control and Status Registers .........................4-11

xvi

Table 5-1. MCECC Specifications.............................................................................5-3

Table 5-2. MCECC Internal Register Memory Map, Part 1....................................5-10

Table 5-3. MCECC Internal Register Memory Map, Part 2 ...................................5-12

Table A-1. Motorola Computer Group Documents..................................................A-1

Table A-2. Manufacturers’ Documents ....................................................................A-2

xvii

xviii

1Board Description

Introduction

This manual provides programming information for the MVME172 Embedded Controller . Extensive programming information is prov ided for the Application-Specific Integrated Circuit (ASIC) devices used on the board. Reference information is included for the Large Scale Integration (LSI) devices used on the board and so urces for a dditiona l informati on are provided.

This chapter briefly describes the board level hardware features of the MVME172 Embedded Controller. The chapter begins with a board level overview and feat ur es list. Memory maps are next, and th e c hapter closes with some general software considerations such as cache coherency, interrupts, and bus errors.

and Memory Maps

All programmable registers in the MVME172 that reside in ASICs are covered in the chapt ers on th ose ASICs. Cha pter 2 c overs t he VMEchip2, Chapter 3 covers the MC2 chi p, and Chapter 4 covers the IP2 chip. Chapt er 5 covers the MCECC chip, used only on 200/300-Series MVME172. Appendix A describes using interrupts. For those interested in programmable register bit definitions and less interested in hardware functionality, focus on Chapters 2, 3, 4, and 5. In some cases, however, Chapter 1 gives rela ted background information.

Overview

The MVME172 is based on the MC68060 or MC68LC060 microprocessor. The MVME172 is available in various versions with the features listed in Table 1-1 on page 1-3. A “No VMEbus” option is also

available. The I/O connection for the 200/300-Se ries MVME172 is provided through

four RJ-45 front panel connectors.

1-1

Board Description and Memory Maps

The I/O connection f or t he 400/500-Series serial ports is prov ide d by t wo DB-25 front panel I/O connecto rs. The I/O i s connected t o the VMEbus P2 connector. The main board is con nected through a P2 transi tion board and cables to transition boards. The Series 400/500 MVME172 supports the transition boards MVME712-12, MVME712-13, MVME712M, MVME712A, MVME712AM, and MVME712B (referred to in this manual as MVME712x, unless separately specified). These transition boards provide configuration headers, serial port drivers and industry standard connectors for the I/O devices. The MVME712 series transition boards were designed to support the MVME167 boards, but can be used on the MVME172 by following some special precautions. (Refer to the section on the Serial Communications Interface in the MVME172 installation and use manual furnished with your 400/500-Series MVME172, for more information.)

The VMEbus interface is pr ovided by an ASIC call ed the VMEchip2. The VMEchip2 includes two tick timers , a watchdog timer, programmable map decoders for the master and slave interfac es, and a VMEbus to/fr om local bus DMA controller, a VMEbus t o/from local bus non-DMA pr ogrammed access interface, a VMEbus interrupter, a VMEbus system cont roller, a VMEbus interrupt handler, and a VMEbus requester.

Processor-to-VMEbus t ransfers can be D8, D16, or D32. VMEchip2 DMA transfers to the VMEbus, howev er, can be D16, D32, D16/BLT, D32/BLT, or D64/MBLT.

The MC2 ch ip ASIC provides four tick timers, the interface to the LAN chip, SCSI chip, s erial port c hip, BBRAM, the pro grammable interf ace for the DRAM and/or SRAM mezzanine board, and Flash write enable.

The IndustryPack Interface Controller (IP2 chip) ASIC provides control and status information, including DMA control, for up to four single size IndustryPacks (IPs) or up to two double size IPs that can be plugged into the MVME172 main module.

1-2 Computer Group Literature Center Web Site

The MCECC chip Memory Controller ASIC on the 200/300-Series MVME172 provides the programmable interface for the ECC-protected 16 MB DRAM mezzanine board.

Table 1-1. MVME172 Features Summary

Feature 200/300-Series 400/500-Series

Overview

Processor 6

0 MHz 32-bit MC68060 microprocessor, or 64 MHz 32-bit

MC68LC060 microprocessor

DRAM 4MB, 8 MB, or 16 MB of shared

DRAM with parity protection on a mezzanine module, or up to 64 MB of ECC-protected DRAM

SRAM 128 K

B of SRAM with battery

4MB, 8 MB, or 16 MB of shared DRAM with no protection

512KB of SRAM with battery backup

backup

PROM/ EPROM Sockets

Flash One Intel 28F016SA 2M x 8 Flash memory device (2MB Flash memo ry

NVRAM and TOD

Timers Four 32-bit Tick Timers and Watchdog Timer (in the MC2 Chip ASIC) for

Two JEDEC standard 32- pin DIP PROM sockets

total) with write protection (optional) 8K by 8 Non-Volatile RAM (NVRAM) and Time-of-Day (TOD) clock with

battery backup

periodic interrupts Two 32-bit Tick Timers and Watchdog Timer in the VMEchip2 ASIC) for

periodic interrupts

ne JEDEC standard 32-pin

PLCC EPROM socket (EPROMs may

be shipped separately)

Software Interrupts

I/O Four serial ports, both EIA-232-D RJ-45Tw

http://www.mcg.mot.com/literature 1-3

Eight software interrupts (for MVME172 versions that have the VMEchip2)

Serial port controller Optional Small Computer Systems Interface (SCSI) bus interface with 32-bit

local bus burst Direct Memory Access (DMA) (NCR 53C710 controller) Optional LAN Ethernet transceiver interface with 32- bit lo cal b us DMA (Inter

82596CA controller)

o serial ports; one EIA-232-D

DCE, one EIA-232-D DCE/DTE or EIA-530 DCE/DTE or EIA-42 DCE/DTE or EIA-485

s (Zilog Z85230)

Board Description and Memory Maps

Table 1-1. MVME172 Features Summary

Feature 200/300-Series 400/500-Series

Two MVIP IndustryPack

interfaces with DMA

VMEbus interface (boards may be special ordered without the VMEbus interface)

Switches Two pushbutton switch e s Light-Emitting

Diodes (LEDs)

VMEbus system controller functions VMEbus interface to local bus (A24/A32, D8/D16/D32 (D8/D16/D32/D64 BLT) (BLT = Block Transfer) Local bus to VMEbus interface (A16/A24/A32, D8/D16/D32) VMEbus interrupter VMEbus interrupt handler Global CSR for interprocessor communications DMA for fast local memory - VMEbus transfers (A16/A24/A32, D16/D32

(D16/D32/D64 BLT)

Four LEDs: FAIL, RUN, SCON,

FUSES (LAN power)

Four MVIP IndustryPack

interfaces with DMA

(ABORT and RESET)

Eight LEDs: FAIL, STAT, RUN,

SCON, LAN, FUSE (LAN power), SCSI, and VME

Requirements

These boards are d esigned to confo rm to the requirement s of the foll owing documents:

❏ VMEbus Specification (IEEE 1014-87) ❏ EIA-232-D Serial Interface Specification, EIA ❏ SCSI Specification, ANSI ❏ IndustryPack Specification, GreenSpring

1-4 Computer Group Literature Center Web Site

Block Diagrams

Figure 1-2 on page 1-7 is a general block diagram of the 200/300-Series

MVME172. Figure 1-2 on page 1-7 is a general block diagram of the 400/500-Series MVME172.

Functional Description

This section covers only a few specific features of the MVME172. A complete functional description of the major blocks of the MVME172

Embedded Controller is provided in your MVME172 installation and use manual.

No-VMEbus-Interface Option

Block Diagrams

The MVME172 can be operated as an embedded controller without the VMEbus interface. For this option, the VMEchip2 and the VMEbus buffers are not popul ated. Als o, the bus gra nt daisy chain and the interr upt acknowledge daisy chain have zero-ohm bypass resistors installed.

To support this feature, certa in logic in the VMEchi p2 has been dupl icated in the MC2 chip. Table 1-2 on page 1-8 defines the location of the redundant logic. This logic is inhibited in the MC2 chip if the VMEchip2 is present. The enables for these functions are controll ed by software and MC2 chip hardware initialization.

Note that an MVME 172 ordered wi thout the VMEbu s interf ace is shippe d with Flash memory blank (the factory uses the VMEbus to program the Flash memory with debugger code). To use the 172Bug package, MVME172Bug, in such models, be sure that the General Purpose Readable Jumpers Header is configured for the EPROM memory map. Refer to Chapters 3 and 4 of your MVME172 install atio n and use manual for further details.

http://www.mcg.mot.com/literature 1-5

Board Description and Memory Maps

21009702

2MB

Flash

Optional

4 Serial Ports

Optional

RJ-45 Front

Panel

SCSI

Ethernet

EIA-232

Transceivers

Connector

Peripherals

Panel SCSI

68-pin Front

Panel

Connector

Transceiver

DB-15 Front

Serial

Dual 85230

I/O Controllers

MC2 chip

Sockets

EPROM

Two 32 -pin

SCSI

53C710

Coprocessor

Ethernet

Controller

i82596CA

M48T58

Battery Backed

8KB RAM/Clock

4,8,16,32,64MB

4,8,16MB Parit y

w/Battery

128KB SRAM

Memory Array

ECC DRAM

Memory Array

Configuration Dependent

Array

DRAM Memory

A32/D32

I/O

IndustryPack

Optional

VMEbus

A32/24:D64/32/16/08

Figure 1-1. 200/300-Series MVME172 Block Diagram

1-6 Computer Group Literature Center Web Site

2 Channels

Master/Slave

IP2

Interface

IndustryPack

MPU

Optional

MC68LC060

VMEbus

Interface

VMEchip2

MC68060

Optional

Functional Description

2038 9706

2MB

Flash

Via P2 and

2 Serial Ports

Transition Module

DB-25 Front Panel

SCSI

Peripherals

Optional

Ethernet

Transceiver

Via P2 and

connections are

Transition Modules

Via P2 and

connections are

Transition Modules

EIA-232

Transceivers

Serial

Dual 85230

I/O Controller s

MC2 chip

Socket

1 PLCC

SCSI

53C710

Coprocessor

Ethernet

Controller

i82596CA

A32/D32

M48T58

Battery Backed

8KB RAM/Clock

4,8,16MB Parity

w/Battery

512KB SRAM

Memory Array

Array

DRAM Memory

Configuration Dependent

I/O

4 Channels

IndustryPack

Optional

VMEbus

Master/Slave

A32/24:D64/32/16/08

Figure 1-2. 400/500-Series MVME172 Block Diagram

http://www.mcg.mot.com/literature 1-7

IP2

Interface

IndustryPack

MPU

Optional

MC68LC060

VMEbus

Interface

VMEchip2

MC68060

Board Description and Memory Maps

Table 1-2. Redundant Functions in the VMEchip2 and MC2 Chip

VMEchip2 MC2 Chip

Address Bit # Address Bit #

$FFF40060 28 - 24 $FFF42044 28 - 24 1,5 $FFF40060 22 -

19,17,16

$FFF4004C 13 - 8 $FFF42044 13 - 8 3,5

$FFF40048 7 $FFF42048 8 4 $FFF40048 9 $FFF42048 9 4,5 $FFF40048 10 $FFF42048 10 4,5 $FFF40048 11 $FFF42048 11 4,5 $FFF40064 31 - 0 $FFF4204C 31 - 0 8

$FF800000-$FFBFFFFF 31 - 0 $FF800000-

$FFE00000-$FFEFFFFF 3 1 - 0 Programmable 31 - 0 7

$FFF42044 22 -

19,17,16

$FFF42040 6 - 0 6

31 - 0 7

$FFBFFFFF

Notes

2,5

Notes 1. RESET switch control.

2. Watchdog timer control.

3. Access and watchdog timer parameters.

4. MPU TEA (bus error) status

5. Bit numbering for VMEchip2 and MC2 chip has a one-toone correspondence.

ABORT switch interrupt control. Implemented also in the

6. VMEchip2, but with a diff erent bit or ganiza tion ( refe r to the VMEchip2 description i n Ch apter 2). In the MVME172, the

ABORT switch is wired to the MC2 chip, not the VMEchip2.

7. The SRAM and PROM decoder in the VMEchip2 (ver sion

2) must be disab led by software before any accesses are made to these address spaces.

8. 32-bit prescaler. The prescaler can also be accessed at $FFF40064 when the optional VMEbus is not enabled.

1-8 Computer Group Literature Center Web Site

VMEbus Interface and VMEchip2

The local bus to VMEbus inte rface an d the VMEbus t o loca l bus int erface are provided by the VMEchip2. The VMEchip2 can also provide the VMEbus system controll er functions. Refer to the VMEchi p2 in Chapter 2 for detailed programming information.

Memory Maps

Note that th e inputs to the VMEchip2 which are located at $FFF40088 bits 7-0 are not used. The MC2 chip ASIC at lo cation $FFF42043. The GPI inputs are integra ted into the MC2 chip ASIC at location $FFF4202C bits 23-16.

Memory Maps

There are two points of view for memory maps: 1) the mapping of all resources as view ed by local bus masters (local bus memory map), a nd 2) the mapping of onboard resources as viewed by VMEbus masters (VMEbus memory map).

The memory and I/O map s which are des cribed in the foll owing tab les are correct for all local bus masters. There is some address translation capability in the VMEchip2 . This allows multiple MVME172 modules on the same VMEbus with diff erent virtual local bus maps as viewed by different VMEbus masters.

ABORT switch logic in the VMEchip2 is not used. The GPI

ABORT switch interrupt is integrated into the

Local Bus Memory Map

The local bus memory ma p is split into different address spaces by the transfer type (TT) signals. The local resources respond to the normal access and interrupt acknowledge codes.

Normal Address Range

The memory map of devices that respond to the normal address range is shown in the following tabl es. The normal addre ss range is define d by the Transfer Type (TT) si gna ls on the local bus. On the MVME172, Transfer Types 0, 1, and 2 define the normal address range. Table 1-2 is the entire

http://www.mcg.mot.com/literature 1-9

Board Description and Memory Maps

map from $00000000 to $FFFFFFFF. Many areas of the map are user-programmable, an d suggested us es are shown in th e table. The ca che inhibit function is programmable in the MC68xx060 MMU. The onboard I/O space must be marked cache inhibit and serialized in its page table.

Table 1-3 on page 1-10 further defines the map for the local I/O devices

for the 200/300-Series MVME172, and Table 1-4 on page 1-12 further defines the map for the local I/O devices for the 400/500-Series MVME172.

Table 1-3. 200/300-Series MVME172 Local Bus Memory Map

Address Range Devices Accessed

Programmable DRAM on parity

mezzanine

Programmable DRAM on ECC

mezzanine Programmable Onboard SRAM D32 128KB N 2 Programmable VMEbus A32/A24 D32-D16 -- ? 4 Programmable IP_a memory D32-D8 64KB-8MB ? 2, 4 Programmable IP_b memory D32-D8 64KB-8MB ? 2, 4 $FF800000-$FF9FFFFF Flash/EPROM D32 2MB N 1, 5 $FFA00000-$FFBFFFFF EPROM/Flash D32 2MB N 5 $FFC00000-$FF DFF F FF Not decoded D32 2MB N $FFE00000-$F FE1FFFF Onboard

SRAM default

Port

Width

D32 4MB-16MB N 2

D32 4MB-64MB N 2

D32 128KB N

Size

Software

Cache

Inhibit

Notes

$FFE80000-$FFEFFFFF Not decoded -- 512KB N 6 $FFF00000-$FFFEFFFF Local I/O devices

$FFFF0000-$FFFFFFFF VMEbus A16 D32/D16 64KB ? 2, 4

1-10 Computer Group Literature Center Web Site

D32-D8 878KB Y 3

(see next table)

Memory Maps

Notes 1. Devices mapped at $FFF80000- $FFF9FFFF also appear at

$00000000- $001FFFFF when the ROM0 bit in the MC2 chip EPROM control register is high (ROM0=1). ROM0 is set to 1 after ea ch reset. The ROM0 bit must be cl eared before other resources (DRAM or SRAM) can be mapped in this range ($00000000 - $001FFFFF).

The EPROM/Flash memory map is also controlled by the EPROM size and by control bit V11 in the MC2 chip ASIC. Refer to t he EPROM/Flash configuration tables in your MVME172 installation manual for further details.

2. This area is user-programmable. The DRAM and SRAM decoder is programmed in the MC2 chip, the local-toVMEbus decoders are programmed in the VMEchip2, and the IP memory space is programm ed in the IP2.

3. Size is approximate.

4. Cache inhibit depends on the devices in the area mapped.

5. The EPROM and Flash are dynamica lly sized by the MC2 chip ASIC from an 8- bit p rivate b us t o the 32-bit MPU local bus.

6. These areas are not decoded unless one of the programmable deco ders is initia lized t o decod e this s pace. If they are not decod ed and the local ti mer is enabled , an access to this address range will generate a local bus time-out.

http://www.mcg.mot.com/literature 1-11

Board Description and Memory Maps

Table 1-4. 400/500-Series MVME172 Local Bus Memory Map

Address Range

Programmable DRAM on board D32 4MB-16 MB N 2 Programmable SRAM D32 128KB-2MB N 2 Programmable VMEbus

Programmable IP_a Memory D32-D8 64KB-8MB ? 2, 4 Programmable IP_b Memory D32-D8 64KB-8MB ? 2, 4 Programmable IP_c Memory D32-D8 64KB-8MB ? 2, 4 Programmable IP_d Memory D32-D8 64KB-8MB ? 2, 4 $FF800000 - $FF9FFF FF Flash/PROM D32 2MB N 1, 5 $FFA00000 - $FFBFFFFF PROM/Flash D32 2MB N 6 $FFC00000 - $FFCFFFFF Not decoded -- 1MB N 7 $FFD00000 - $FFDFFFFF Not decoded -- 1MB N 7 $FFE00000 - $FFE7FFFF SRAM default D32 512KB N --

Devices

Accessed

A32/A24

Port

Width

D32/D16 -- ? 4

Size

Software

Cache

Inhibit

Note(s)

$FFE80000 - $FFEFFFFF Not decoded -- 512KB N 7 $FFF00000 - $FFFEFFFF Local I/O D32-D8 878KB Y 3 $FFFF0000 - $FFFFFFFF VMEbus A16 D32/D16 64KB ? 2, 4

Notes 1. Reset enables the decoder for this space of the memory

map so that it will decode address spaces $FF800000-$FF9FFFFF and $00000000-$003FFFFF. The decode at 0 must be disabled in the MC2 chip bef ore DRAM is enabled. DRAM is enabled with the DRAM Control

1-12 Computer Group Literature Center Web Site

Memory Maps

Register at address $FFF42048, bit 24. PROM/Flash is disabled at the low address space with PROM Control Register at address $FFF42040, bit 20.

2. This area is user-programmable. The DRAM and SRAM decoder is programmed in the MC2 chip, the local-to-VMEbus decoders are programmed in the VMEchip2, and the IP memory space is programmed in the IP2 chip.

3. Size is approximate.

4. Cache inhibit depends on devices in area mapped.

5. The PROM and Flash are sized by the MC2 chip ASIC from an 8-bit private bus to the 32-bit MPU local bus. Because the device size is less than the allocated memory map size for some entries, the device contents repeat for those entries.

If jumper GPI3 is installed, the Flash device is accessed. If GPI3 is not installed, the PROM is accessed.

6. The Flash and PROM are sized by the MC2 chip ASIC from an 8-bit private bus to the 32-bit MPU local bus. Because the device size is less than the allocated memory map size for some entries, the device contents repeat for those entries.

If jumper GPI3 is in stalled, the PROM is accessed. If GPI 3 is not installed, the Flash device is accessed.

7. These areas are not decoded unless one of the programmable decoders are initialized to decode this space. If they are not decoded, an access to this address range will generate a local bus time- out. The local bus timer must be enabled.

http://www.mcg.mot.com/literature 1-13

Board Description and Memory Maps

Table 1-5 below and Table 1-6 on page 1-18 describe the "Local I/O

Devices" portion of the local bus main memory ma p for the 200/300-Series and 400/500-Series MVME172, respectively.

Table 1-5. 200/300-Series MVME172 Local I/O Devices Memory Map

Address Range Devices Accessed Port

Width

$FFF00000 - $FFF3FFFF Reserved - - 256K

$FFF40000 - $ FFF400FF VMEchip2 (LCSR) D32 256B 1, 3 $FFF40100 - $FFF401FF VMEchip2 (GCSR) D32-D8 256B 1, 3 $FFF40200 - $FFF40FFF Reserved - - 3.5KB 4, 5 $FFF41000 - $FFF41FFF Reserved - - 4KB 4 $FFF42000 - $ FFF42FFF MC2 chip D32-D8 4KB 1 $FFF43000 - $FFF430FF MCECC #1 D8 256B 1, 8 $FFF43100 - $FFF431FF MCECC #2 D8 256B 1, 8 $FFF43200 - $FFF43FFF MCECCs (repeated) - - 3.5KB 1, 5, 8 $FFF44000 - $FFF44FFF Reserved - - 8KB 4 $FFF45000 - $FFF45800 SCC #1 (Z85230) D8 2KB 1, 2 $FFF45801 - $FFF45FFF SCC #2 (Z85230) D8 2KB 1, 2

Size Notes

$FFF46000 - $FFF46FFF LAN (82596CA) D32 4KB 1, 6 $FFF47000 - $FFF47FFF SCSI (53C710) D32-D8 4KB 1 $FFF48000 - $FFF57FFF Reserved - - 64KB 4 $FFF58000 - $FFF5807F IP2 IP_a I/O D16 128B 1 $FFF58080 - $FFF580FF IP2 IP_a ID D16 128B 1 $FFF58100 - $FFF5817F IP2 IP_b I/O D16 128B 1 $FFF58180 - $FFF581FF IP2 IP_b ID Read D16 128B 1 $FFF58200 - $FFF5827F IP2 IP_c I/O D16 128B 7

1-14 Computer Group Literature Center Web Site

Memory Maps

Table 1-5. 200/300-Series MVME172 Local I/O Devices Memory Map

(Continued)

Address Range Devices Accessed Port

Width

$FFF58280 - $FFF582FF IP2 IP_c ID D16 128B 7 $FFF58300 - $FFF583 7F IP2 IP_d I/O D16 128B 7 $FFF58380 - $FFF583FF IP2 IP_d ID Read D16 128B 7 $FFF58400 - $FFF584 FF IP2 IP_ab I/O D32-D16 256B 1 $FFF58500 - $FFF585 FF IP2 IP_cd I/O D32-D16 256B 7 $FFF58600 - $FFF586FF IP2 IP_ab I/O Repeated D32-D16 256B 1 $FFF58700 - $FFF587FF IP2 IP_cd I/O Repeated D32-D16 256B 7 $FFF58800 - $FFF5887F Reserved - - 128B 1 $FFF58880 - $FFF588FF Reserved - - 128B 1 $FFF58900 - $FFF5897F Reserved - - 128B 1 $FFF58980 - $FFF589FF Reserved - - 128B 1 $FFF58A00 - $FFF58A7F Reserved - - 128B 1

Size Notes

$FFF58A80 - $FFF58AFF Reserved - - 128B 1 $FFF58B00 - $FFF58B7F Reserved - - 128B 1 $FFF58B80 - $FFF58BFF Reserved - - 128B 1 $FFF58C00 - $FFF58CFF Reserved - - 256B 1 $FFF58D00 - $FFF58DFF Reserved - - 256B 1 $FFF58E00 - $FFF58EFF Reserved - - 256B 1 $FFF58F00 - $FFF58FFF Reserved - - 256B 1 $FFFBC000 - $FFFBC01F IP2 Registers D32-D8 2KB 1

http://www.mcg.mot.com/literature 1-15

Board Description and Memory Maps

Table 1-5. 200/300-Series MVME172 Local I/O Devices Memory Map

(Continued)

Address Range Devices Accessed Port

Width

$FFFBC800 - $FFFBC81F Reserved - - 2KB 1 $FFFBD000 - $FFFBFFFF Reserved - - 12KB 4 $FFFC0000 - $FFFCFFFF M48T58 (BBRAM, TOD Clock) D32-D8 64KB 1, 9 $FFFD0000 - $FFFEFFFF Reserved - - 128K

Size Notes

1-16 Computer Group Literature Center Web Site

Memory Maps

Notes 1. For a complete descripti on of the regi ster bits , refer to the

data sheet f or the specific chip. For a more detailed memory map, refer to the following detailed peripheral device memory maps.

2. The SCC is an 8-bit device locate d on an MC2 chip private data bus. Byte access is required.

3. Writes to the LCSR in the VMEchip2 must be 32 bits. LCSR writes of 8 or 16 bits terminate with a TEA signal. Writes to the GCSR may be 8, 16 or 32 bits. Reads to the LCSR and GCSR may be 8, 16 or 32 bits. Byte reads should be used to read the interrupt vector.

4. This area does not return an acknowledge signal. If the local bus timer is enabled, the access times out and is terminated by a TEA signal.

5. Size is approximate.

6. Port commands to t he 82596CA must be wri tten as two 16bit writes: upper word first and lower word second.

7. Not used.

8. To use this area, the ECC mezzanine board must be installed. If it is not installed, no acknowledge signal is returned; if the local bus timer is enabled, the access times out and is terminated by a TEA signal.

9.Repeats on 8KB boundaries.

http://www.mcg.mot.com/literature 1-17

Board Description and Memory Maps

Table 1-6. 400/500-Series MVME172 Local I/O Devices Memory Map

Address Range Device

Port

Width

Size Note(s)

$FFF00000 - $FFF3FFFF Reserved -- 256KB 4 $FFF40000 - $FFF400FF VMEchip2 (LCSR) D32 256B 1, 3 $FFF40100 - $FFF401FF VMEchip2 (GCSR) registers D32-D8 256B 1, 3 $FFF40200 - $FFF40FFF Reserved -- 3.5KB 4, 5 $FFF41000 - $FFF41FFF Reserved -- 4KB 4 $FFF42000 - $FFF42FFF M C2 chip D32-D8 4KB 1 $FFF43000 - $FFF44FFF Reserved -- 8KB 4 $FFF45000 - $FFF45FFF SCC (Z85230) D8 4KB 1, 2 $FFF46000 - $FFF46FFF LAN (82596CA) D32 4KB 1, 6 $FFF47000 - $FFF47FFF SCSI (53C710) D32-D8 4KB 1 $FFF48000 - $FFF57FFF Reserved -- 64KB 4 $FFF58000 - $FFF5807F IP2 chip IP_a I/O D16 128B 1 $FFF58080 - $FFF580FF IP2 chip IP_a ID D16 128B 1 $FFF58100 - $FFF5817F IP2 chip IP_b I/O D16 128B 1 $FFF58180 - $FFF581FF IP2 chip IP_b ID Read D16 128B 1 $FFF58200 - $FFF5827F IP2 chip IP_c I/O D16 128B 1 $FFF58280 - $FFF582FF IP2 chip IP_c ID D16 128B 1 $FFF58300 - $FFF5837F IP2 chip IP_d I/O D16 128B 1 $FFF58380 - $FFF583FF IP2 chip IP_d ID Read D16 128B 1 $FFF58400 - $FFF584FF IP2 chip IP_ab I/O D32-D16 256B 1 $FFF58500 - $FFF585FF IP2 chip IP_cd I/O D32-D16 256B 1 $FFF58600 - $FFF586FF IP2 chip IP_ab I/O repeated D32-D16 256B 1 $FFF58700 - $FFF587FF IP2 chip IP_cd I/O repeated D32-D16 256B 1 $FFF58800 - $FFF5887F Reserved -- 128B 1 $FFF58880 - $FFF588FF Reserved -- 128B 1 $FFF58900 - $FFF5897F Reserved -- 128B 1

1-18 Computer Group Literature Center Web Site

Memory Maps

Table 1-6. 400/500-Series MVME172 Local I/O Devices Memory Map

(Continued)

Address Range Device

$FFF58980 - $FFF589FF Reserved -- 128B 1 $FFF58A00 - $FFF58A7F Reserved -- 128B 1 $FFF58A80 - $FFF58AFF Reserved -- 128B 1 $FFF58B00 - $FFF58B7F Reserved -- 128B 1 $FFF58B80 - $FFF58BFF Reserved -- 128B 1 $FFF58C00 - $FFF58CFF Reserved -- 256B 1 $FFF58D00 - $FFF58DFF Reserved -- 256B 1 $FFF58E00 - $FFF58EFF Reserved -- 256B 1 $FFF58F00 - $FFF58FFF Reserved -- 256B 1 $FFFBC000 - $FFFBC01F IP2 chip registers D32-D8 2KB 1 $FFFBC800 - $FFFBC81F Reserved -- 2KB 1 $FFFBD000 -

$FFFBFFFF $FFFC0000 - $FFFC7FFF MK48T58

Reserved -- 12KB 4

(BBRAM, TOD clock)

Port

Width

D32-D8 32KB 1

Size Note(s)

$FFFC8000 - $FFFCBFFF MK48T58 D32-D8 16KB 1, 7 $FFFCC000 - $FFFCFFFF MK48T58 D32-D8 16KB 1, 7 $FFFD0000 - $FFFEFFFF Reserved -- 128KB 4

http://www.mcg.mot.com/literature 1-19

Board Description and Memory Maps

Notes 1. For a complete descripti on of the regi ster bits , refer to the

data sheet f or the specific chip. For a more detailed memory map, refer to the following detailed peripheral device memory maps.

2. The SCC is an 8-bit device locate d on an MC2 chip private data bus. Byte access is required.

The data register of the Zilog Z85230 device which is interfaced by the MC2 chip ASIC cannot be accessed. The Zilog Z85230 has an indirect access mode to the data registers which is functional and must be used.

4. This area does not return an acknowledge signal. If the local bus timer is enabled, the access times out and is terminated by a TEA signal.

5. Size is approximate.

6. Port commands to the 82596CA must be written as two 16-bit writes: upper word first and lower word second.

7. Refer to th e Flash and PROM Int erface section i n the MC2 chip description in Chapter 3.

1-20 Computer Group Literature Center Web Site

Detailed I/O Memory Maps

Tables 1-7 through 1-17 give the detailed memory maps for:

VMEchip2 Table 1-7 MC2 chip Table 1-8 IP2 chip Table 1-9 IP2 chip Control and Status Registers Table 1-10 MCECC chip Table 1-11 Z85230 SCC Register addresses Table 1-12 82596CA Ethernet LAN chip Table 1-13 53C710 SCSI chip Table 1-14 MK48T58 BBRAM/TOD clock Table 1-15

Memory Maps

BBRAM configuration area Table 1-16 TOD clock Table 1-17

Note Manufacturers’ errata sheets for the various chips are

available by contacting your local Motorola sales representative. A non-disc losure a greement ma y be requi red.

http://www.mcg.mot.com/literature 1-21

Board Description and Memory Maps

Table 1-7. VMEchip2 Memory Map (Sheet 1 of 3)

VMEchip2 LCSR Base Address = $FFF40000 OFFSET:

16171819202122232425262728293031

SLAVE ADDRESS TRANSLATION ADDRESS 1

SLAVE ADDRESS TRANSLATION ADDRESS 2

ADDER

SLAVE ENDING ADDRESS 1

SLAVE ENDING ADDRESS 2

SNP

WP2SUP2USR2A322A24

BLK

BLK2PRGM2DATA

D64

16171819202122232425262728293031

MASTER ENDING ADDRESS 1

MASTER ENDING ADDRESS 2

MASTER ENDING ADDRESS 3

MASTER ENDING ADDRESS 4

MASTER ADDRESS TRANSLATION ADDRESS 4

MAST

D16

MAST

GCSR GROUP SELECT

MAST

D16

GCSR

BOARD SELECT

MASTER AM 3MASTER AM 4

MAST

16171819202122232425262728293031

WAIT RMW

ROM

ZERO

DMA TB

SNP MODE

SRAM

SPEED

TICK

2/1

TICK

IRQ 1

CLR

IRQ

STAT

VMEBUS

INTERRUPT

LEVEL

VMEBUS INTERRUPT VECTOR

DMA CONTROLLER

This sheet continues on facing page.

1-22 Computer Group Literature Center Web Site

SLAVE STARTING ADDRESS 1

SLAVE STARTING ADDRESS 2

SLAVE ADDRESS TRANSLATION SELECT 1

SLAVE ADDRESS TRANSLATION SELECT 2

ADDER

SNP

WP1SUP1USR1A321A24

MASTER STARTING ADDRESS 1

MASTER STARTING ADDRESS 2

MASTER STARTING ADDRESS 3

MASTER STARTING ADDRESS 4

Memory Maps

0123456789101112131415

BLK

BLK1PRGM1DATA

D64

0123456789101112131415

MAST

D16

EN IO2ENIO2

ARB

ROBN

DMA

TBL

INT

MAST

DHB

DMA LB

SNP MODE

IO2 S/U

MAST

DWB

MASTER AM 2 MASTER AM 1

IO2

IO1ENIO1

P/D

MST FAIR

DMA

INC

VME

LOCAL BUS ADDRESS COUNTER

VMEBUS ADDRESS COUNTER

BYTE COUNTER

TABLE ADDRESS COUNTER

DMA TABLE

INTERRUPT COUNT

MPU

CLR

STAT

MASTER ADDRESS TRANSLATION SELECT 4

MAST

D16

MST

RWD DMA

INC

MPU

LBE

ERR

IO1 WP EN

MASTER VMEBUS

DMA

WRT

MPU

LPE

ERR

IO1 S/U

DMA

D16

MPU

LOB

ERR

DMA

HALT

DMA

D64 BLK

MPU

LTO

ERR

ROM SIZE

DMAENDMA

DMA

DMA ERR

BLK

LBE

ROM BANK B

TBL

DMA

LPE

ERR

SPEED

DMA FAIR

DMA

LOB ERR

DMA

DMA LTO ERR

RELM

ROM BANK A

DMA

TBL

ERR

SPEED

DMA

VMEBUS

DMA

DMA VME ERR

1360 9403

0123456789101112131415

DMA

DONE

This sheet begins on facing page.

http://www.mcg.mot.com/literature 1-23

Board Description and Memory Maps

Table 1-7. VMEchip2 Memory Map (Sheet 2 of 3)

VMEchip2 LCSR Base Address = $FFF40000 OFFSET:

ARB

BGTO

DMA

TIME OFF

DMA

TIME ON

16171819202122232425262728293031

VME

GLOBAL

TIMER

TICK TIMER 1

SCON BRD

FAIL

IRQ

CLR

IRQ

VECTOR BASE

SYS FAIL

SYS FAIL IRQ

IRQ

CLR IRQ

AC FAIL

IRQ LEVEL

VME IACK

IRQ LEVEL

SW7

IRQ LEVEL

SPARE

IRQ LEVEL

FAIL

STAT

MWP

BERR

IRQ

EN IRQ

CLR

IRQ

PURS

STAT

IRQ

CLR

IRQ

CLR

BRD

PURS

FAIL

STA T

OUT

IRQ1E

TIC2

IRQ

CLR

IRQ

ABORT

IRQ LEVEL

DMA

IRQ LEVEL

SW6

IRQ LEVEL

VME IRQ 7 IRQ LEVEL

VECTOR BAS E

RST

TIC1

IRQ

CLR

IRQ

SYS RSTWDCLR

VME

DMA

IACK

IRQ

CLR

IRQ

MST

SYS

IRQ

FAIL

LEVEL

IRQ

CLR IRQ

CLR

CNT

SIG3

IRQ

CLR IRQ

SYS FAIL

IRQ LEVEL

SIG 3

IRQ LEVEL

SW5

IRQ LEVEL

VME IRQ 6 IRQ LEVEL

FAIL

LEVEL

STA T

SIG2

IRQ

CLR

IRQ

ABORT

LEVEL

TO BF EN

SIG1

IRQ

CLR IRQ

TICK TIMER 1

TICK TIMER 2

SRST

RST

LRST

ENWDEN

SIG0

LM1

IRQ

CLR

IRQ

MST WP ERROR

IRQ LEVEL

SIG 2

IRQ LEVEL

SW4

IRQ LEVEL

VME IRQ 5 IRQ LEVEL

GPIOEN

EN 17

PRE

16171819202122232425262728293031

LM0

IRQ

CLR

IRQ

1-24 Computer Group Literature Center Web Site

This sheet continues on facing page.

VME

ACCESS

TIMER

LOCAL

BUS

TIMER

COMPARE REGISTER

COUNTER

COMPARE REGISTER

COUNTER

OVERFLOW COUNTER 2

TIME OUT

SELECT

CLR OVF

COC

Memory Maps

0123456789101112131415

PRESCALER

CLOCK ADJUST

TIC

COC

TIC

OVERFLOW

COUNTER 1

CLR OVF

SCALER

SW7

IRQ

SET

IRQ

CLR

IRQ

SW6

IRQ

SET IRQ

CLR IRQ

P ERROR

IRQ LEVEL

VME IRQ 4 IRQ LEVEL

GPIOO

SW5

IRQ

SET IRQ

CLR IRQ

SIG 1

SW3

SW4

IRQ

SET IRQ

CLR IRQ

SW3

IRQ

SET IRQ

CLR IRQ

SW2

SW1

SW0

IRQ

SET

IRQ

CLR

IRQ

IRQ1E

IRQ LEVEL

SIG 0

IRQ LEVEL

SW2

IRQ LEVEL

VMEB IRQ 3

IRQ LEVEL

GPIOI GPI

IRQ

SET IRQ

CLR IRQ

SPARE VME

IRQ

IRQ7

IRQ

REV

EROM

VME

IRQ6

IRQ

TIC TIMER 2

IRQ LEVEL

LM 1

IRQ LEVEL

SW1

IRQ LEVEL

VME IRQ 2 IRQ LEVEL

DIS

SRAM

VME

IRQ5

IRQ

DIS

MST

VME

0123456789101112131415

VME

IRQ4

IRQ3

IRQ

BBSY

IRQ

TIC TIMER 1

IRQ LEVEL

VME IRQ 1 IRQ LEVEL

DIS

BSYTENINT

IRQ2

IRQ

LM 0

SW0

VME IRQ1

IRQ

DIS

BGN

1361 9403

This sheet begins on facing page.

http://www.mcg.mot.com/literature 1-25

Board Description and Memory Maps

Table 1-7. VMEchip2 Memory Map (Sheet 3 of 3)

VMEchip2 GCSR Base Address = $FFF40100

Offsets Bit Numbers

VME

-bus

Local Bus

1514131211109876543210

0 0 Chip Revision Chip ID 24

LM3LM2LM1LM0SIG3SIG2SIG1SIG0RSTISF BF SCONSYS

4 8 General Purpose Control and Status Register 0 6 C General Purpose Control and Status Register 1 8 10 General Purpose Control and Status Register 2

A 14 General Purpose Control and Status Register 3

C 18 General Purpose Control and Status Register 4 E 1C General Purpose Control and Status Register 5

XXX

1-26 Computer Group Literature Center Web Site

1Board Description and Memory Maps 0Memory Maps

Table 1-8. MC2 Chip Register Map

MC2 Chip Base Address = $FFF42000

Offset D31-D24 D23-D16 D15-D8 D7-D0

Memory Maps

$00 MC2 chip ID MC2 chip

Revision $04 Tick Timer 1 Compare Register $08 Tick Timer 1 Counter Register

$0C Tick Timer 2 Compare R egister

$10 Tick Timer 2 Counter Register $14 LSB Prescaler

Count Register

$18 Tick Timer 4

Interrupt Control

$1C DRAM Parity Error

Interrupt Control $20 DRAM Space Base Address Register SRAM Space Base Address Register $24 DRAM Space

Size

$28 LANC Error Status Reserved LANC Interrupt

$2C SCSI Error Status General Purpose

Prescaler

Clock Adjus t

Tick Timer 3

Interrupt Control

SCC Interrupt

Control

DRAM/SRAM

Options

Inputs

General

Control

Tick Timer 2

Control

Tick Timer 2

Interrupt Control

Tick Timer 4

Control

SRAM Space

Size

Control

MVME172 Version SCSI Interrupt

Interrupt Vector

Base Register

Tick Timer 1

Control

Tick Timer 1

Interrupt Control

Tick Timer 3

Control

Reserved

LANC Bus Error Interrupt Control

Control $30 Tick Timer 3 Compare Register $34 Tick Timer 3 Counter Register $38 Tick Timer 4 Compare Register

$3C Tick Timer 4 Counter Register

$40 Bus Clock EPROM Access

Time Control

$44

$48 DRAM Control Reserved MPU Status Reserved

$4C 32-bit Prescaler Count Register

http://www.mcg.mot.com/literature 1-27

RESET Switch

Control

Watchdog Timer

Control

Flash Parameter

Control

Access &

Watchdog Time

Base Select

ABORT Switch

Interrupt Control

Reserved

Board Description and Memory Maps

The following memory ma p ta bl e includes all devices selected by t he IP2 chip map decoder.

Table 1-9. IP2 Chip Overall Memory Map

Address Range Selected Device Port Width Size

Programmable IP_a/IP_ab Memory Space D32-D8 64KB-16MB Programmable IP_b Memory Space D16-D8 64KB-8MB Programmable IP_c/IP_cd Memory Space D32-D8 64KB-16MB Programmable IP_d Memory Space D16-D8 64KB-8MB

$FFF58000-$FFF5807F IP_a I/O Space D16 128B $FFF58080-$FFF580BF IP_a ID Space D16 64B $FFF580C0-$FFF580FF IP_a ID Space Repeated D16 64B

$FFF58100-$FFF5817F IP_b I/O Space D16 128B $FFF58180-$FFF581BF IP_b ID Space D16 64B $FFF581C0-$FFF581FF IP_b ID Space Repeated D16 64B

$FFF58200-$FFF5827F IP_c I/O Space D16 128B $FFF58280-$FFF582BF IP_c ID Space D16 64B $FFF582C0-$FFF582FF IP_c ID Space Repeated D16 64B

$FFF58300-$FFF5837F IP_d I/O Space D16 128B $FFF58380-$FFF583BF IP_d ID Space D16 64B $FFF583C0-$FFF583FF IP_d ID Space Repeated D16 64B

$FFF58400-$FFF584FF IP_ab I/O Space D32-D16 256B

$FFF58500-$FFF585FF IP_cd I/O Space D32-D16 256B

$FFF58600-$FFF586FF IP_ab I/O Space Repeated D32-D16 256B

$FFF58700-$FFF587FF IP_cd I/O Space Repeated D32-D16 256B

$FFFBC000-$FFFBC083 Control/Status Registers D32-D8 32B

A summary of the IP 2 chip CSR registers i s shown in Table 1 -10. The CSR registers can be accessed as bytes, words, or longwords. They should not be accessed as lines. They are shown in the table as bytes.

1-28 Computer Group Literature Center Web Site

Memory Maps

Table 1-10. IP2 Chip M emory Map - Control and Status Registers

IP2 Chip Base Address = $FFFBC000

Offset

$00CHIP ID00100011 $01 CHIP

$02RESERVED00000000 $03 VEC T O R BA S E IV7 IV6 IV5 IV4 IV3 IV2 IV1 IV0

$04 IP_a MEM

$05 IP_a MEM

$06 IP_b MEM

$07 IP_b MEM

$08 IP_c MEM

$09 IP_c MEM

$0A IP_d MEM

$0B IP_d MEM

$0C IP_a MEM

$0D IP_b MEM

$0E IP_c MEM

$0F IP_d MEM

$10 IP_a INT0

$11 IP_a INT1

$12 I P_b INT 0

$13 I P_b INT 1

$14 IP_c INT0

$15 IP_c INT1

$16 I P_d INT 0

$17 I P_d INT 1

Name

REVISION

BASE UPPER

BASE LOWER

BASE UPPER

BASE LOWER

BASE UPPER

BASE LOWER

BASE UPPER

BASE LOWER

SIZE

CONTROL

D7 D6 D5 D4 D3 D2 D1 D0

00000001

a_BASE31 a_BASE30 a_BASE29 a_BASE28 a_BASE27 a_BASE26 a_BASE25 a_BASE24

a_BASE23 a_BASE22 a_BASE21 a_BASE20 a_BASE19 a_BASE18 a_BASE17 a_BASE16

b_BASE31 b_BASE30 b_BASE29 b_BASE28 b_BASE27 b_BASE26 b_BASE25 b_BASE24

b_BASE23 b_BASE22 b_BASE21 b_BASE20 b_BASE19 b_BASE18 b_BASE17 b_BASE16

c_BASE31 c_BASE30 c_BASE29 c_BASE28 c_BASE27 c_BASE26 c_BASE25 c_BASE24

c_BASE23 c_BASE22 c_BASE21 c_BASE20 c_BASE19 c_BASE18 c_BASE17 c_BASE16

d_BASE31 d_BASE30 d_BASE29 d_BASE28 d_BASE27 d_BASE26 d_BASE25 d_BASE24

d_BASE23 d_BASE22 d_BASE21 d_BASE20 d_BASE19 d_BASE18 d_BASE17 d_BASE16

a_SIZE23 a_SIZE22 a_SIZE21 a_SI ZE20 a_SIZE19 a_SIZE18 a_SIZE17 a_SIZE16

b_SIZE23 b_SIZE22 b_SIZE21 b_SIZE20 b_SIZE19 b_SIZE18 b_SIZE17 b_SIZE16

c_cSIZE23 c_SIZE22 c_SIZE21 c_SIZE20 c_SIZE19 c_SIZE18 c_SIZE17 c_SIZE16

d_SIZE23 d_SIZE22 d_SIZE21 d_SIZE20 d_SIZE19 d_SIZE18 d_SIZE17 d_SIZE16

a0_PLT Y a0_E/L* a0_INT a0_IEN a0_ICLR a0_IL2 a0_IL1 a0_IL0

a1_PLT Y a1_E/L* a1_INT a1_IEN a1_ICLR a1_IL2 a1_IL1 a1_IL0

b0_PLTY b0_E/L* b0_INT b0_IEN b0_ICLR b0_IL2 b0_IL 1 b0_IL0

b1_PLTY b1_E/L* b1_INT b1_IEN b1_ICLR b1_IL2 b1_IL 1 b1_IL0

c0_PLT Y c0__E/L* c0__INT c0__IEN c0__ICLR c0__IL2 c0__IL1 c0__IL0

c1_PLT Y c1__E/L* c1__INT c1__IEN c1__ICLR c1__IL2 c1__IL1 c1__IL0

d0_PLTY d0__E/L* d0__INT d0__IEN d0__ICLR d0__IL2 d0__IL1 d0__IL0

d1_PLTY d1__E/L* d1__INT d1__IEN d1__ICLR d1__IL2 d1__IL1 d1__IL0

http://www.mcg.mot.com/literature 1-29

Board Description and Memory Maps

Table 1-10. IP2 Chip Mem ory Map - Control and Status Registers

(Continued)

Offset

$18 IP_a

$19 IP_b

$1A IP_c

$1B IP_d

$1CRESERVED00000000

$1DIP CLOCK0000000IP32

$1E DMA

$1FIP RESET0000000RES

Name

GENERAL CONTROL

ARBITRATION

CONTROL

D7 D6 D5 D4 D3 D2 D1 D0

a_ERR 0 a_RT1 a_RT0 a_WIDTH1 a_WIDTH0 a_BTD a_MEN

b_ERR 0 b_RT1 b_RT0 b_WIDTH1 b_WIDTH0 b_BTD b_MEN

c_ERR 0 c_RT1 c_RT0 c_WIDTH1 c_WIDTH0 c_BTD c_MEN

d_ERR 0 d_RT1 d_RT0 d_WIDTH1 d_WIDTH0 d_BTD d_MEN

00000ROTATPRI1PRI0

1-30 Computer Group Literature Center Web Site

Memory Maps

Table 1-10. IP2 Chip Mem ory Map - Control and Status Registers

(Continued)

Offset

$20 DMA_a

$21 DMA_a INT

$22DMA ENABLE0000000DEN $23RESERVED00000000

$24 DMA_a CON-

$25 DMA_a

$26RESERVED00000000 $27RESERVED00000000

$28 DMA_a LB

$29 DMA_a LB

$2A DMA_a LB

$2B DMA_a LB

$2C DMA_a IP

$2D DMA_a IP

$2E DMA_a IP

$2F DMA_a IP

$30 DMA_a BYTE

$31 DMA_a BYTE

$32 DMA_a BYTE

$33 DMA_a BYTE

$34 DMA_a TBL

$35 DMA_a TBL

$36 DMA_a TBL

$37 DMA_a TBL

Name

STATUS

CTRL

TROL 1

CONTROL 2

ADDR

CNT

ADDR

D7 D6 D5 D4 D3 D2 D1 D0

DMAC for IndustryPack a, request 0. This register set is referred to as DMACa in the text.

0 DLBE 0 IPEND CHANI TBL IPTO DONE

0 0 DINT DIEN DICLR DI L2 DIL1 DIL0

DHALT 0 DTBL ADMA WIDTH1 WIDTH0 0 XXX

INTE 0 DMAEI DMAEO ENTO TOIP 0 0

LBA31 LBA30 LBA29 LBA28 LBA27 LBA26 LBA25 LBA24

LBA23 LBA22 LBA21 LBA20 LBA19 LBA18 LBA17 LBA16

LBA15 LBA14 LBA13 LBA12 LBA1 1 LBA10 LBA9 LBA8

LBA7 LBA6 LBA5 LBA4 LBA3 LBA2 LBA1 LBA0

00000000

IP A23 IPA22 IPA21 IPA20 IPA19 IPA18 IPA17 IPA16

IPA15 IPA14 IPA13 IP A12 IPA11 IPA10 IPA9 IPA8

IPA7 IPA6 IPA5 IPA4 IPA3 IPA2 IPA1 IPA0

00000000

BCNT23 BCNT22 BCNT21 BCNT20 BCNT19 BCNT18 BCNT17 BCNT16

BCNT15 BCNT14 BCNT13 BCNT12 BCNT11 BCNT10 BCNT9 BCN8

BCNT7 BCNT6 BCNT5 BCNT4 BCNT3 BCNT2 BCNT1 BCNT0

TA31 T A30 TA29 TA28 TA27 TA26 T A25 TA24

TA23 T A22 TA21 TA20 TA19 TA18 T A17 TA16

TA15 T A14 TA13 TA12 TA11 TA10 TA9 TA8

TA7 TA6 TA5 TA4 TA3 TA2 TA1 TA0

http://www.mcg.mot.com/literature 1-31

Board Description and Memory Maps

Table 1-10. IP2 Chip Mem ory Map - Control and Status Registers

(Continued)

Offset

$38 DMA_b

$39 DMA_b INT

$3aDMA ENABLE0000000DEN $3bRESERVED00000000

$3c DMA_b CON-

$3d DMA_b CON-

$3eRESERVED00000000 $3fRESERVED00000000

$40 DMA_b LB

$41 DMA_b LB

$42 DMA_b LB

$43 DMA_b LB

$44 DMA_b IP

$45 DMA_b IP

$46 DMA_b IP

$47 DMA_b IP

$48 DMA_b BYTE

$49 DMA_b BYTE

$4a DMA_b BYTE

$4b DMA_b BYTE

$4c DMA_b TBL

$4d DMA_b T BL

$4e DMA_b TBL

$4f DMA_b TBL

Name

DMAC for IndustryPack b, request 0 or for IndustryPack a, request 1. This register set is referred to as DMACb in the text.

STATUS

CTRL

TROL 1

TROL 2

ADDR

CNT

ADDR

D7 D6 D5 D4 D3 D2 D1 D0

0 DLBE 0 IPEND CHANI TBL IPTO DONE

0 0 DINT DIEN DICLR DIL2 DIL1 DIL0

DHALT 0 DTBL ADMA WIDTH1 WIDTH0 A_CH1 XXX

INTE 0 DMAEI DMAEO ENTO TOIP 0 0

LBA31 LBA30 LBA29 LBA28 LBA27 LBA26 LBA25 LBA24

LBA23 LBA22 LBA21 LBA20 LBA19 LBA18 LBA17 LBA16

LBA15 LBA14 LBA13 LBA12 LBA11 LBA10 LBA9 LBA8

LBA7 LBA6 LBA5 LBA4 LBA3 LBA2 LBA1 LBA0

00000000

IP A23 IPA22 IPA21 IPA20 IPA19 IPA18 IPA17 IPA16

IPA15 IPA14 IPA13 IP A12 IPA11 IPA10 IPA9 IP A8

IPA7 IPA6 IPA5 IPA4 IPA3 IPA2 IPA1 IPA0

00000000

BCNT23 BCNT22 BCNT21 BCNT20 BCNT19 BCNT18 BCNT17 BCNT16

BCNT15 BCNT14 BCNT13 BCNT12 BCNT11 BCNT10 BCNT9 BCN8

BCNT7 BCNT6 BCNT5 BCNT4 BCNT3 BCNT2 BCNT1 BCNT0

TA31 TA30 TA29 TA28 TA27 TA26 TA25 TA24

TA23 TA22 TA21 TA20 TA19 TA18 TA17 TA16

TA15 TA14 TA13 TA12 TA11 TA10 TA9 TA8

TA7 TA6 TA5 TA4 TA3 TA2 TA1 TA0

1-32 Computer Group Literature Center Web Site

Memory Maps

Table 1-10. IP2 Chip Mem ory Map - Control and Status Registers

(Continued)

Offset

$50 DMA_c

$51 DMA_c INT

$52DMA ENABLE0000000DEN $53RESERVED00000000

$54 DMA_c CON-

$55 DMA_c CON-

$56RESERVED00000000 $57RESERVED00000000

$58 DMA_c LB

$59 DMA_c LB

$5A DMA_c LB

$5B DMA_c LB

$5C DMA_c IP

$5D DMA_c IP

$5E DMA_c IP

$5F DMA_c IP

60 DMA_c BYTE

$61 DMA_c BYTE

$62 DMA_c BYTE

$63 DMA_c BYTE

$64 DMA_c TBL

$65 DMA_c TBL

$66 DMA_c TBL

$67 DMA_c TBL

Name

STATUS

CTRL

TROL 1

TROL 2

ADDR

CNT

ADDR

D7 D6 D5 D4 D3 D2 D1 D0

DMAC for IndustryPack c, request 0. This register set is referred to as DMACc in the text.

0 DLBE 0 IPEND CHANI TBL IPTO DONE

0 0 DINT DIEN DICLR DI L2 DIL1 DIL0

DHALT 0 DTBL ADMA WIDTH1 WIDTH0 0 XXX

INTE 0 DMAEI DMAEO ENTO TOIP 0 0

LBA31 LBA30 LBA29 LBA28 LBA27 LBA26 LBA25 LBA24

LBA23 LBA22 LBA21 LBA20 LBA19 LBA18 LBA17 LBA16

LBA15 LBA14 LBA13 LBA12 LBA1 1 LBA10 LBA9 LBA8

LBA7 LBA6 LBA5 LBA4 LBA3 LBA2 LBA1 LBA0

00000000

IP A23 IPA22 IPA21 IPA20 IPA19 IPA18 IPA17 IPA16

IPA15 IPA14 IPA13 IP A12 IPA11 IPA10 IPA9 IPA8

IPA7 IPA6 IPA5 IPA4 IPA3 IPA2 IPA1 IPA0

00000000

BCNT23 BCNT22 BCNT21 BCNT20 BCNT19 BCNT18 BCNT17 BCNT16

BCNT15 BCNT14 BCNT13 BCNT12 BCNT11 BCNT10 BCNT9 BCN8

BCNT7 BCNT6 BCNT5 BCNT4 BCNT3 BCNT2 BCNT1 BCNT0

TA31 T A30 TA29 TA28 TA27 TA26 T A25 TA24

TA23 T A22 TA21 TA20 TA19 TA18 T A17 TA16

TA15 T A14 TA13 TA12 TA11 TA10 TA9 TA8

TA7 TA6 TA5 TA4 TA3 TA2 TA1 TA0

http://www.mcg.mot.com/literature 1-33

Board Description and Memory Maps

Table 1-10. IP2 Chip Mem ory Map - Control and Status Registers

(Continued)

Offset

DMAC for IndustryPack d, request 0 or for IndustryPack c, request 1, and for PACER CLOCK. This register set, not including the Pacer

$68 $69 DMA_d INT

$6aDMA ENABLE0000000DEN $6bRESERVED00000000

$6c DMA_d CON-

$6d DMA_d CON-

$6eRESERVED00000000 $6fRESERVED00000000

$70 DMA_d LB

$71 DMA_d LB

$72 DMA_d LB

$73 DMA_d LB

$74 DMA_d IP

$75 DMA_d IP

$76 DMA_d IP

$77 DMA_d IP

$78 DMA_d BYTE

$79 DMA_d BYTE

$7a DMA_d BYTE

$7b DMA_d BYTE

$7c DMA_d TBL

$7d DMA_d T BL

$7e DMA_d TBL

$7f DMA_d TBL

Name

DMA_d

STATUS

CTRL

TROL 1

TROL 2

ADDR

CNT

ADDR

D7 D6 D5 D4 D3 D2 D1 D0

Clock, is referred to as DMACd in the text. 0 DLBE 0 IPEND CHANI TBL IPTO DONE 0 0 DINT DIEN DICLR DIL2 DIL1 DIL0

DHALT 0 DTBL ADMA WIDTH1 WIDTH0 C_CH1 XXX

INTE 0 DMAEI DMAEO ENTO TOIP 0 0

LBA31 LBA30 LBA29 LBA28 LBA27 LBA26 LBA25 LBA24

LBA23 LBA22 LBA21 LBA20 LBA19 LBA18 LBA17 LBA16

LBA15 LBA14 LBA13 LBA12 LBA11 LBA10 LBA9 LBA8

LBA7 LBA6 LBA5 LBA4 LBA3 LBA2 LBA1 LBA0

00000000

IP A23 IPA22 IPA21 IPA20 IPA19 IPA18 IPA17 IPA16

IPA15 IPA14 IPA13 IP A12 IPA11 IPA10 IPA9 IP A8

IPA7 IPA6 IPA5 IPA4 IPA3 IPA2 IPA1 IPA0

00000000

BCNT23 BCNT22 BCNT21 BCNT20 BCNT19 BCNT18 BCNT17 BCNT16

BCNT15 BCNT14 BCNT13 BCNT12 BCNT11 BCNT10 BCNT9 BCN8

BCNT7 BCNT6 BCNT5 BCNT4 BCNT3 BCNT2 BCNT1 BCNT0

TA31 TA30 TA29 TA28 TA27 TA26 TA25 TA24

TA23 TA22 TA21 TA20 TA19 TA18 TA17 TA16

TA15 TA14 TA13 TA12 TA11 TA10 TA9 TA8

TA7 TA6 TA5 TA4 TA3 TA2 TA1 TA0

1-34 Computer Group Literature Center Web Site

Memory Maps

Table 1-10. IP2 Chip Mem ory Map - Control and Status Registers

(Continued)

Offset

$80 PACER INT

$81 PACER GEN

$82 PACER

$83 PACER

Name

CONTROL

TIMER

D7 D6 D5 D4 D3 D2 D1 D0

0 IRE INT IEN ICLR IL2 IL1 IL0

PLTY PLS 0 EN CLR PS2 PS1 PS0

T15 T14 T13 T12 T11 T10 T9 T8

T7 T6 T5 T4 T3 T2 T1 T0

The following MCECC memory map applies only to the 200/300-Series MVME172 boards.

Table 1-11. MCECC Internal Register Memory Map

MCECC Base Address = $FFF43000 (1st); $FFF43100 (2nd)

Offset

Name

D31 D30 D29 D28 D27 D26 D25 D24

$00 CHIP ID CID7 CID6 CID5 CI D4 CID3 CID2 CID1 CID0

$04 $08

CHIP REVISION MEM CONFIG

REV7 REV6 REV5 REV4 REV3 REV2 REV1 REV0

FSTRD

0 MSIZ2 MSIZ1 MSIZ0 $0CDUMMY 000000 000 $10DUMMY 100000 000 $14 $18

BASE ADDRESS DRAM CONTRL

BAD31 BAD30 BAD29 BAD28 BAD27 BAD26 BAD25 BAD24 BAD23 BAD22 RWB5 SWAIT RWB3

NCEIEN

NCEBEN

RAMEN

$1C BCLK FREQ BCK7 BCK6 BCK5 BC K4 BCK3 BCK2 BC K1 BCK 0 $20 $24 $28 $2C $30 $34 $38 $3C

DATA CONTRL SCRUB CNTRL SCRUB PERIOD SBPD15 SCRUB PERIOD CHIP PRESCALE

SCRUB TIME ON/OFF

SCRUB PRESCALE SCRUB PRESCALE

0 0 DERC ZFILL

RACODE RADATA

SBPD

7 SBPD6 SBPD5 SBPD4 SBPD3 SBPD2 SBPD1 SBPD0

CPS7 CPS6 CPS5 CPS4 CPS3 CPS2 CPS1 CPS0

SRDIS

SPS

15 SPS14 SPS13 SPS12 SPS11 SPS10 SPS9 SPS8

HITDIS SCRB

SBPD1

4 SBPD13 SBPD12 SBPD11 SBPD10 SBPD9 SBPD8

STON2 SPS21

STON SPS2

RWCKB

SCRBEN

1 STON0

000 0

STOFF2

SBEIEN

STOFF

IDIS

1 STOFF0

0 SPS19 SPS18 SPS17 SPS16

http://www.mcg.mot.com/literature 1-35

Board Description and Memory Maps

Table 1-11. MCECC Internal Register Memory Map (Continued)

MCECC Base Address = $FFF43000 (1st); $FFF43100 (2nd)

Offset

$40 $44 $48

$4C

$50 $54 $58

$5C

$60 $64 $68

$6C

$70 $74 $78

Name

SCRUB PRESCALE SCRUB TIMER SCRUB TIMER

SCRUB ADDR CNTRL

ERROR LOGGER ERROR ADDRESS ERROR ADDRESS ERROR ADDRESS ERROR ADDRESS

ERROR SYNDROME

DEFAULTS1 DEFAULTS2

D31 D30 D29 D28 D27 D26 D25 D24

SPS

7 SPS6 SPS5 SPS4 SPS3 SPS2 SPS1 SPS0 ST15 ST14 ST13 ST12 ST11 ST10 ST9 ST8 ST7 ST6 ST5 ST4 ST3 ST2 ST1 ST0 00000 SAC26SAC25SAC24

SAC23 SAC22 SAC21 SAC20 SAC19 SAC18 SAC17 SAC16 SAC15 SAC14 SAC13 SAC12 SAC11 SAC 10 SAC9 SAC8 SAC7 SAC6 SAC5 SAC4 0 0 0 0

ERRLOG

ERD ESCRB ERA EALT

MBE SBE

EA31 EA30 EA29 EA28 EA27 EA26 EA25 EA24 EA23 EA22 EA21 EA20 EA19 EA18 EA17 EA16 EA15 EA14 EA13 EA12 EA11 EA10 EA9 EA8 EA7 EA6 EA5 EA4 0 0 0 0 S7 S6 S5 S4 S3 S2 S1 S0

WRHDIS STATCOL

FRC_OPN XY_FLIP REFDIS TVECT NOCACHE RESST2

FSTRD SELI1

SELI

RSIZ2

RSIZ

1 RSIZ0

RESST1 RESST0

1-36 Computer Group Literature Center Web Site

Table 1-12. Z85230 SCC Register Addresses

SCC Z85230 SCC Register Address

Memory Maps

SCC #1

(All MVME172

modules)

SCC #2

(200/300-Series

MVME172

only)

Note A bug in MVME172s that have MC2 chip revisi on $01 does

Port B Control $FFF45001

Port B Data $FFF45003

Port A Control $FFF45005

Port A Data $FFF45007

Port B Control $FFF45801

Port B Data $FFF45803

Port A Control $FFF45805

Port A Data $FFF45807

not allow the data regis ters to be accessed dir ectly. You must access them indirectly via the SCC chip. The software must send a command to the control register that tells it that the next thing read or written to the control register will go to the data register. The fol lowing two macros are examples:

dev_addr is a pointer to the base address of the SCC. SCCR0 is the offset to the SCC control register #0.

#define READ_SCC(VAR_NAME)\

dev_addr[SCCR0] = 0x08;\ (VAR_NAME) = dev_addr[SCCR0]

#define WRITE_SCC(VAR_NAME)\

dev_addr[SCCR0] = 0x08;\ dev_addr[SCCR0] = (VAR_NAME)

http://www.mcg.mot.com/literature 1-37

Board Description and Memory Maps

Table 1-13. 82596CA Ethernet LAN Memory Map

82596CA Ethernet LAN

Directly Accessible Registers

Address

D31 ... D16 D15 ... D0

$FFF46000 Upper Command Word Lower Command Word $FFF46004 MPU Channel Attention (CA)

Data Bits

Notes 1. Refer to the MPU Port and MPU Channel Attention

registers in Chapter 3.

2. After reset you must write the System Configuration Pointer to the command registers prior to writing to the MPU Channel Attention register. Writes to the System Configuration Pointer must be upper word first, lower word second.

1-38 Computer Group Literature Center Web Site

Table 1-14. 53C710 SCSI Memory Map

Base Address is $FFF47000

Memory Maps

Big Endian

Mode

53C710 Register Address Map

SCRIPTs Mode and Little Endia n Mode

00 SIEN SDID SCNTL1 SCNTL0 00 04 SOCL SODL SXFER SCID 04 08 SBCL SBDL SIDL SFBR 08

0C SSTAT 2 SSTAT1 SSTAT0 DSTAT 0C

10 DSA 10 14 CTEST3 CTEST2 CTEST1 CTEST0 14 18 CTEST7 CTEST6 CTEST5 CTEST4 18

1C TEMP 1C

20 LCRC CTEST8 ISTAT DFIFO 20 24 DC MD DBC 24 28 DNAD 28

2C DSP 2C

30 DSPS 30 34 SCRATCH 34 38 DC NTL DWT DIEN DMO DE 38

3C ADDER 3C

Note Accesses may be 8-bit or 32-bit, but not 16-bit.

http://www.mcg.mot.com/literature 1-39

Board Description and Memory Maps

BBRAM/TOD Clock Memory Map

The MK48T58 BBRAM (also called Non-Volatile RAM or NVRAM) is divided into six areas as shown in Table 1-15. The first five areas are defined by softwar e, while the si xth ar ea, the time-o f-day ( TOD) cloc k, is defined by the chi p har d war e. The fi rst area is reserved for user data. The second area is used by Mot orola n etworki ng sof tware. Th e thir d area may be used by a n operat ing syst em. The fou rth are a is us ed by t he MVME172 board debugger (M VME172Bug). The fifth a rea, detailed in Table 1-16, is the configuration area. The sixth area, the TOD clock, detailed in Table

1-17, is defined by the chip hardware.

Table 1-15. MK48T58 BBRAM/TOD Clock Memory Map

Address Range Description Size (Bytes)

$FFFC0000 - $FFFC0FFF User Area 4096 $FFFC1000 - $FFFC10FF Networking Area 256

$FFFC1100 - $FFFC16F7 Op erating System Area 1528 $FFFC16F8 - $FFFC1EF7 Debugger Area 2048 $FFFC1EF8 - $FFFC1FF7 Configuration Area 256 $FFFC1FF8 - $FFFC1FFF TOD Clock 8

1-40 Computer Group Literature Center Web Site

1Board Description and Memory Maps 0Memory Maps

Memory Maps

Table 1-16. BBRAM Configuration Area Memory Map

Address Range Description Size (Bytes)

$FFFC1EF8 - $FFFC1EFB Version 4

$FFFC1EFC - $FFFC1F07 Serial Number 12

$FFFC1F08 - $FFFC1F17 Board ID 16 $FFFC1F18 - $FFFC1F27 PWA 16 $FFFC1F28 - $FFFC1F2B Speed 4 $FFFC1F2C - $FFFC1F31 Ethernet Address 6 $FFFC1F32 - $FFFC1F33 Reserved 2 $FFFC1F34 - $FFFC1F35 Local SCSI ID 2

$FFFC1F36 - $FFFC1F 3D Memory Mezz. PWB 8

$FFFC1F3E - $FFFC1F45 Memory Mezz. Serial Number 8 $FFFC1F46 - $FFFC1F4D Static Mezz. PWB 8 $FFFC1F4E - $FFFC1F4D Static Mezz. Serial 8 $FFFC1F56 - $FFFC1F5D ECC1 Mezz. PWB 8 $FFFC1F5E - $FFFC1F5D ECC1 Mezz Serial 8

$FFFC1F66 - $FFFC1F65 ECC2 Mezz. PWB 8

$FFFC1F6E - $FFFC1F75 ECC2 Mezz. Serial 8 $FFFC1F76 - $FFFC1F7D Ser. Port 2 Pers. PWB 8

$FFFC1F7E - $FFFC1F85 Ser. Port 2 Pers. Serial No. 8 $FFFC1F86 - $FFFC1F8D IP_a Board ID 8

$FFFC1F8E - $FFFC1F95 IP_a Board Serial Number 8 $FFFC1F96 - $FFFC1F9D IP_a Board PWB 8 $FFFC1F9E - $FFFC1FA5 IP_b Board ID 8

$FFFC1FA6 - $FFFC1FAD IP_b Board Serial Number 8 $FFFC1FAE - $FFFC1FB5 IP_b Board PWB 8 $FFFC1FB6 - $FFFC1FBD IP_c Board ID 8 $FFFC1FBE - $FFFC1FC5 IP_c Board Serial Number 8 $FFFC1FC6 - $FFFC1FCD IP_c Board PWB 8 4FFFC1FCE - $FFFC1FD5 IP_d Board ID 8

http://www.mcg.mot.com/literature 1-41

Board Description and Memory Maps

Table 1-16. BBRAM Configuration Area Memory Map (Continued)

Address Range Description Size (Bytes)

$FFFC1FD6 - $FFFC1FDD IP_d Board Serial Number 8

4FFFC1FDE - $FFFC1FE5 IP_d Board PWB 8

$FFFC1FE6 - $FFFC1FF6 Reserved 65

$FFFC1FF7 Checksum 1

Note IP_c and IP_d are not used on 200/300-Series MVME172

modules.

Table 1-17. TOD Clock Memory Map

Address

D7 D6 D5 D4 D3 D2 D1 D0

$FFFC1FF8 W R S Calibration Control

$FFFC1FF9ST-------------- Seconds 00 $FFFC1FFA x -- -- -- -- -- -- -- Minutes 00 $FFFC1FFBxx------------ Hour 00 $FFFC1FFC x FT x x x -- -- -- Day 01 $FFFC1FFDx x------------ Date 01

$FFFC1FFE x x x -- -- -- -- -- Month 01

$FFFC1FFF---------------- Year 00

Data Bits

Function

Notes W = Write Bit

R = Read Bit S = Signbit ST = Stop Bit FT = Frequency Test x = Must be set to 0

1-42 Computer Group Literature Center Web Site

Memory Maps

The data structure of the configuration bytes starts at $FFFC1EF8 and is as follows.

struct brdi_cnfg {

char version[4]; char serial[12]; char id[16]; char pwa[16]; char speed[4]; char ethernet[6]; char fill[2]; char lscsiid[2]; char pmem_pwb[8]; char pmem_serial[8]; char smem_pwb [8] ; char smem_serial [8]; char ecc1mem_pwb [8]; char ecc1mem_serial [8]; char ecc2mem_pwb [8] ; char ecc2mem_srial [8]; char port2_pwb[8]; char port2_serial[8]; char ipa_brdid[8]; char ipa_serial[8]; char ipa_pwb[8]; char ipb_brdid[8]; char ipb_serial[8]; char ipb_pwb[8]; char ipc_brdid[8]; char ipc_serial[8]; char ipc_pwb[8]; char ipd_brdid[8]; char ipd_serial[8]; char ipd_pwb[8]; char reserved[17]; char cksum[1];

}

The fields are defined as follows:

1. Four bytes are reserved for the revision or version of this structure. This revision is stored in ASCII format, with the first two bytes being the major version numbers and the last two bytes being the

http://www.mcg.mot.com/literature 1-43

Board Description and Memory Maps

minor version numb ers. For example, i f the versi on of this str ucture is 1.0, this field contains:

0100

2. Twelve bytes are reserved for the serial number of the board in ASCII format. For example, this field could contain:

000000470476

3. Sixteen bytes are reserved for the board ID in ASCII format. For example, for an MVME172 boar d wit h MC6806 0, SCSI, Ethernet, 4MB DRAM, and 512KB SRAM, this field contains:

MVME172-

(The 12 characters are followed by four blanks.)

xxx

4. Sixteen bytes are reserved for the printed wiring assembly (PWA) number assigned to this board in ASCII format. This includes the

01-W prefix. This is for the main logic board if more than one board

is required for a set. Additional boards in a set are defined by a structure for that set. For example, for an MVME172 board with MC68060, SCSI, Ethernet, 4MB DRAM, and 512KB SRAM, at revision A, the PWA field contains:

01-W318xB01A

(The 12 characters are followed by four blanks.)

5. Four bytes contain the speed of the board in MHz. The first two bytes are the whole number of MHz and the second two bytes are fractions of MHz. For example, for a 60.00 MHz board, this fiel d contains:

6000

6. Six bytes are reserved fo r the Ethernet address. The addre ss is stored in hexadecimal format. (Refer to the detailed description earlier in this chapter.) If the board does not support Ethernet, this field is filled with zeros.

7. These two bytes are reserved.

8. Two bytes are reserved for the local SCSI ID. The SCSI ID is stored in ASCII format.

1-44 Computer Group Literature Center Web Site

Memory Maps

9. Eight bytes are reserved for the printed wiring boar d (PWB) number assigned to the memory mezzanin e board in ASCII format. This does not include the

01-W prefix. F or example, for a 4MB

mezzanine at revisi on A, the PWB field contains:

3992B03A

10. Eight bytes are reserved for the serial number assigned to the memory mezzanine board in ASCII format.

11. Eight bytes are reserved for the printed wiring boar d (PWB) number assigned to the serial port 2 personality board in ASCII format.

Static Memory Mezzanine pwb identifier in ascii Static Memory Mezzanine serial number in ascii ECC1 Memory Mezzanine pwb ide ntifier in ascii ECC1 Memory Mezzanine serial number in ascii ECC2 Memory Mezzanine pwb ide ntifier in ascii ECC2 Memory Mezzanine serial number in ascii

12. Eight bytes are res erved f or th e ser ial numbe r assi gned to the seria l port 2 personality board in ASCII format.

13. Eight bytes are reser ved for the bo ard identifi er, in ASCII, assig ned to the optional first IndustryPack a.

14. Eight bytes are reserve d for the serial number, in ASCII, a ssigned to the optional first IndustryPack a.

15. Eight bytes are reserved for the printed wiring boar d (PWB) number assigned to the optional first IndustryPack a.

16. Eight bytes are reser ved for the bo ard identifi er, in ASCII, assig ned to the optional second IndustryPack b.

17. Eight bytes are reserve d for the serial number, in ASCII, a ssigned to the optional second IndustryPack b.

18. Eight bytes are reserved for the printed wiring boar d (PWB) number assigned to the optional second IndustryPack b.

19. Eight bytes are reser ved for the bo ard identifi er, in ASCII, assig ned to the optional third Indus tryPack c.

http://www.mcg.mot.com/literature 1-45

Board Description and Memory Maps

20. Eight bytes are reserve d for the serial number, in ASCII, assigned to the optional third Ind ust ryPack c.

21. Eight bytes are reserved for the printed wiring boar d (PWB) number assigned to the optional third IndustryPack c.

22. Eight bytes are reser ved for the bo ard identifi er, in ASCII, assig ned to the optional fourth IndustryPack d.

23. Eight bytes are reserve d for the serial number, in ASCII, assigned to the optional fourth IndustryPack d.

24. Eight bytes are reserved for the printed wiring boar d (PWB) number assigned to the optional fourth IndustryPack d.

25. Growth space (65 bytes) is reserved. This pads the structure to an even 256 bytes.

26. The final one byte of t he area is re served for a checks um (as defined in the Debugging Package for Motorola 68K CISC CPUs User’s Manual) for security and data integrity of the configuration area of the NVRAM. This data is stored in hexadecimal format.

Interrupt Acknowledge Map

The local bus distinguishes interrupt acknowledge cycles from other cycles by placing the binary value %11 on TT1-TT0. It also specifies the level that is being acknowledged using TM2-TM0. The interrupt handler selects which device within that level is being acknowledged.

VMEbus Memory Map

This section describes the mapping of local resources as viewed by VMEbus masters. Default addresses for the slave, master, and GCSR address decoders are provided by the ENV command.

1-46 Computer Group Literature Center Web Site

Software Support Considerations

VMEbus Accesses to the Local Bus

The VMEchip2 includes a user-programmable map decoder for the VMEbus to local bus interface. The map decoder allows you to program the starting and endin g address and the modifiers t he MVME172 responds to.

VMEbus Short I/O Memory Map

The VMEchip2 includes a us er-programmable map decoder for the GCSR. The GCSR map decoder allows you t o program the st arting add ress of the GCSR in the VMEbus short I/O space.

Software Support Considerations

The MVME172 is a complex board that interfaces to the VMEbus and SCSI bus. These multiple bus int erfaces raise the is sue of cache coherency and support of indivi sible cycles. There are al so many sources of bus erro r. First, let us consider how interrupts are handled.

Interrupts

The MC68060 uses hardware-vectored interrupts. Most interrupt sources are level and base vector programmable. Interrupt

vectors from the MC2 chip and the VMEchip2 have two sections, a base value which can be set by the processor, usually the upper four bits, and the lower b its which are set according to the particular interrupt source. There is an onboard dais y cha in of int er ru pt sources, with interrupts from the MC2 chip having the highest priority, those from the IP2 chip having the next highest pri ority, and interrupt sources from the VMEchip 2 having the lowest priority. Refer to Appendix A for an example of interrupt usage.

The MC2 chip, IP2 chip, and VMEchip2 ASICs are used to implement the multilevel MC680x0 interrupt ar chitectu re. A PLD i s used to c ombine the individual IPLx signals from each ASIC.

http://www.mcg.mot.com/literature 1-47

Board Description and Memory Maps

Cache Coherency

The MC68060 has the abi li ty t o watch local bus cycles executed by other local bus masters such as the SCSI DMA controller, the LAN, the VMEchip2 DMA controller, the VMEbus to local bus controller, and the IP DMA controller.

When snooping is enabled, the MPU can invalidate cache entries as required by the current cycle. The MPU cannot watch VMEbus cycles which do not access t he local bus on the MVME172. Software must ensure that data shared by multiple pro cessors is kept in memory that is not cached. The software must also ma rk al l onboa rd and off- boar d I/ O areas as cache inhibited and serialized.

Sources of Local BERR*

A TEA* signal (indicating a bus error) is returned to the local bus master when a local bus time-out occurs, a DRAM parity error occurs and parity checking is enabl ed, or a VME bu s err or occ urs dur ing a VMEbus acc ess .

Note The 400/500-Serie s MVME172 models do not contain parity

The devices on the MV ME172 that are able to assert a local bus error are described below.

Local Bus Time-out

A Local Bu s Time-out occurs whenever a local bus cycle does not complete within the programmed time (VMEbus bound cycles are not timed by the local bus timer). If the system is configured properly, this should only happen if s oft war e ac cesses a nonexistent location within the onboard address range.

DRAM.

1-48 Computer Group Literature Center Web Site

VMEbus Access Time-out

A VMEbus Access Time-out occurs whenever a VMEbus bound transfer does not receiv e a VMEbus bu s grant wit hin the pro grammed time. Thi s is usually caused by another bus master holding the bus for an excessive period of time.

VMEbus BERR*

A VMEbus BERR* occurs when the BERR* signal lin e is a sserted on the VMEbus while a local bus master is accessing the VMEbus. VMEbus BERR* should occur only if : an initialization routine samples to see if a device is present on the VMEbus and it is not, software accesses a nonexistent device within the VMEbus range, incorrect configuration information causes the VMEchip2 to incorrectly access a device on the VMEbus (such as driving LWORD* low to a 16-bit board), a hardware error occurs on the VMEbus, or a VMEbus slave reports an access error (such as parity error).

Software Support Considerations

Local DRAM Parity Error

Note The 400/500-Serie s MVME172 models do not contain parity

DRAM.

When parity checking is enabled, the current bus master receives a bus error if it is accessing the local DRAM and a parity error occurs.

VMEchip2

An 8- or 16-bit write to the LCSR in the VMEchip2 causes a local BERR*.

Bus Error Processing

Because differ ent cond itions can cause bus error excepti ons, the softwar e must be able to distinguish the source. To aid in this, status registers are provided for every lo cal bus master. The next section des cribes the various causes of bus error and the associated status registers.

http://www.mcg.mot.com/literature 1-49

Board Description and Memory Maps

Generally, the bus error ha ndler can int errogate t he status bi ts and procee d with the result. Howe ver , an i nt err upt can happen during the execution of the bus error handler (before an instruction ca n wri te to the status register to raise the interrupt mask). If the interrupt service routine causes a second bus error, the status that indicates the source of the first bus error may be lost. The software must be written to deal with this.

Description of Error Conditions on the MVME172

This section list the various error conditions that are reported by the MVME172 hardware. A subsection heading identifies each type of error condition. A sta ndard format gives a description of the error, i ndicates how notification of the error condition is made, indicates which status register(s) have information about the error, and concludes with some comments pertaining to each particular error.

MPU Parity Error

Note The 400/500_Series MVME172 models do not contain parity

Description: A DRAM parity error.

MPU Notification: TEA is asserted during an MPU DRAM access.

Status: Bit 9 of the MPU Status and DMA Interrupt Count Register in the VMEchip2 at address $FFF40048.

Comments: After memory has been initia lized, this error normally indicates a hardware problem.

DRAM.

1-50 Computer Group Literature Center Web Site

MPU Off-board Error

Description: An error occurred while the MPU was attempting to access an off-board resource.

MPU Notification: TEA is asserted during off-board access.

Status: Bit 8 of the MPU Status and DMA Interrupt Count Register. Address $FFF40048.

Comments: This can be caused by a VMEbus time-out, a VMEbus BERR, or an MVME172 VMEbus acces s time-out. The la tter is the t ime from when th e VMEbus has been requested to when it is granted.

Software Support Considerations

MPU TEA - Cause Unidentified

Description: An error occurred while the MPU was attempting an access.

MPU Notification: TEA is asserted during an MPU access.

Status: Bit 10 of the MPU Status and DMA Interrupt Count Register at address $FFF40048 in the VMEchip2.

Comments: No status was given as to the cause of the TEA assertion.

MPU Local Bus Time-out

Description: An error occurred while the MPU was attempting to access a local resource.

MPU Notification: TEA is asserted during the MPU access.

http://www.mcg.mot.com/literature 1-51

Board Description and Memory Maps

Status: Bit 7 of the MPU Status and DMA Interrupt Count Register, (actually in the DMAC Status Register) at address $FFF40048.

Comments: The local bus timer timed out. This usually indicates the MPU tried to read or write an address at which there was no resource. Otherwise, it indicates a hardware problem.

DMAC VMEbus Error

Description: The DMAC experienced a VMEbus error during an attempted transfer.

MPU Notification: DMAC interrupt (when enabled).

Status: The VME bit is set in the DMAC Status Register (ad dress $FFF40048 bit

1). Comments:

This indicates the DMAC atte mpted to acce ss a VMEbus a ddress at which there was no resource or the VMEbus slave returned a BERR signal.

DMAC Parity Error

Note The 400/500-Serie s MVME172 models do not contain parity

Description: Parity error while th e DMAC was reading DRAM.

MPU Notification: DMAC interrupt (when enabled).

Status: The DLPE bit is set in the DMAC Status Registe r (address $FFF4004 8 bit

5).

DRAM.

1-52 Computer Group Literature Center Web Site

Comments: If the TBL bit is set (address $FFF 40048 bit 2) the er ror occurre d during a command table access, otherwise the error occurred during a data access.

DMAC Off-board Error

Description: Error encountered while the local bus side of the DMAC was attempting to go to the VMEbus.

MPU Notification: DMAC interrupt (when enabled).

Status: The DLOB bit is set in t he DMAC Status Register (address $FFF40048 bit

4). Comments:

This is normally cause d by a p rogrammin g error. The loca l bus addre ss of the DMAC should not be pro grammed with a lo cal bus address that maps to the VMEb us. If the TBL bit is set (address $FFF40048 bit 2) the error occurred during a command table access, otherwise the error occurred during a data access.

Software Support Considerations

DMAC LTO Error

Description: A local bus time-out (LTO) occurred while the DMAC was local bus master.

MPU Notification: DMAC interrupt (when enabled).

Status: The DLTO bit is set in the DMAC Status Register (address $FFF40048 bit 3).

http://www.mcg.mot.com/literature 1-53

Board Description and Memory Maps

Comments: This indicates the DMAC attempted to access a local bus addre ss at which there was no resour ce. If the TBL bit is set (address $FFF40 048 bit 2) the error occurred during a command table access, otherwise the error occurred during a data access.

DMAC TEA - Cause Unidentified

Description: An error occurred while the DMAC was local bus master and additional status was not provided.

MPU Notification: DMAC interrupt (when enabled).

Status: The DLBE bit is set in the DMAC Statu s Register (add ress $FFF40048 b it

6). Comments:

An 8- or 16-bit write to the LCSR in the VMEchip2 causes this error. If the TBL bit is set (address $FFF40048 bit 2) the error occurred during a command table access, otherwise the error occurred during a data access.

LAN Parity Error

Note The 400/500-Serie s MVME172 models do not contain parity

Description: Parity error while th e LANCE was reading DRAM MPU.

Notification: MC2 chip Interrupt (LAN ERROR IRQ).

Status: MC2 chip LAN Error Status Register ($FFF42028).

DRAM.

1-54 Computer Group Literature Center Web Site

Comments: The LANCE has no ability to respond to TEA so the error interrupt and status are pro vided in the MC2 chip. Cont rol for the int errupt is in the MC2 chip LAN Error Interrupt Control Register ($FFF4202B).

LAN Off-Board Error

Description: Error encountered while the LANCE was attempting to go to the VMEbus.

MPU Notification: MC2 chip Interrupt (LAN ERROR IRQ).

Status: MC2 chip LAN Error Status Register ($FFF42028).

Software Support Considerations

LAN LTO Error

Description: Local Bus Time-out occurred while the LANCE was local bus master.

MPU Notification: MC2 chip Interrupt (LAN ERROR IRQ).

Status: MC2 chip LAN Error Status Register ($FFF42028).

http://www.mcg.mot.com/literature 1-55

Board Description and Memory Maps

SCSI Parity Error

Note The 400/500-Serie s MVME172 models do not contain parity

DRAM.

Description: Parity error detected while the 53C710 was reading DRAM.

MPU Notification: 53C710 Interrupt.

Status: 53C710 DMA Status Register 53C710 DMA Interrupt Status Register MC2 chip SCSI Error Status Register ($FFF4202C).

Comments: 53C710 interrupt enables are controlled in the 53C710 and in the MC2 chip SCSI Interrupt Control Register ($FFF4202F).

SCSI Off-Board Error

Description: Error encounter ed while th e 53C710 was attemptin g to go to the VMEbus.

MPU Notification: 53C710 Interrupt.

Status: 53C710 DMA Status Register 53C710 DMA Interrupt Status Register MC2 chip SCSI Error Status Register ($FFF4202C).

Comments: 53C710 interrupt enables are controlled in the 53C710 and in the MC2 chip SCSI Interrupt Control Register ($FFF4202F).

SCSI LTO Error

Description: Local Bus Time-out occurred while the 53C710 was local bus master.

1-56 Computer Group Literature Center Web Site

Software Support Considerations

MPU Notification: 53C710 Interrupt.

Status: 53C710 DMA Status Register 53C710 DMA Interrupt Status Register MC2 chip SCSI Error Status Register ($FFF4202C).

Comments: 53C710 interrupt enables are controlled in the 53C710 and in the MC2 chip SCSI Interrupt Control Register ($FFF4202F).

Example of the Proper Use of Bus Timers

In this example, the use of the bus timers is ill ustrated by describing the sequence of events when the MPU on one MVME172 accesses the local bus memory on another MVME172 using the VMEbus. In this scenario there are three bus timers involved. These are the local bus timer, the VMEbus access timer, and the Gl obal VMEbus t imer. The l ocal bus t imer measures the time an access to an onboard resource takes. The VMEbus timer measures the time fr om when the VMEbus req uest has bee n initiated to when a VMEbus grant has been obtained. The global bus timer measures the time from when a VMEbus cycle begins to when it completes. Normally these timers should be set to quite different values.

An example of one MVME172 accessing another MVME172 illustrates the use of these ti mers.

When the processor or another local bus master initiates an access to the VMEbus, it first waits until any other local bus masters get off the local bus. Then it begins its cycle and the local bus timer starts counting. It continues to count until an address decode of the VMEbus address space is detected and then terminates. This is normally a very short period of time. In fact all local bus non-error bus accesses are normally very short, such as the time to access onboa rd memory. Therefore , it is recommended this timer be set to a small value, such as 256 µsec.

The next timer to take over when one MVME172 accesses another is the VMEbus access timer. This measures t he time between whe n the VMEbus has been address decoded and hence a VMEbus request has been made,

http://www.mcg.mot.com/literature 1-57

Board Description and Memory Maps

and when VMEbus mastership has been granted. Because we have found in the past that some VME sys tems can become very busy, we recommend this time-out be set at a large value, such as 32 msec.

Once the VM Ebus has been g ranted, a third timer takes over. This is the global VMEbus timer. This timer starts when a transfer actually begins (DS0 or DS1 goes active) and ends when that transfer completes (DS0 or DS1 goes inactive). This time should be longer than any expected legitimate transfer time on the bus. We normally set it to 256 µsec. This timer can also be disabled for debug purposes. Before an MVME172 access to another MVME172 can complete, however, the VMEchip2 on the accessed MVM E172 must decode a slave access and request the local bus of the second MVME172. When the local bus is granted (any in-process onboard transfers have completed) then the local bus timer of the accessed MVME172 starts. Normally, this is also set to 256 µsec. When the me m ory has the data available, a transfer acknowl edge signal (TA) is given. This t ranslates int o a DTACK signal on the VMEbus which is then transla ted into a TA signal to the first reque sting proce ssor, and the transfer is complete. If the VMEbus global timer expires on a legitimate transfer, the VMEbus to local bus controller in the VMEchip2 may become

confused and the VMEchip2 may misbehave; therefore, the bus timers’ values must be set correctly. The correct settings depend on the system configuration.

MVME172 MC68060 Indivisible Cycles

The MC68060 performs operations that require indivisible read-modify-write (RMW) memory accesses. These RMW sequences occur when the MMU modifie s table entri es or when the MPU e xecute s a TAS, CAS, or CAS2 instruction. TAS cy cles are always single-address RMW operations, while the CAS, CAS2, and MMU operations can be multiple-address RMW cycles. The VMEbus does not support multiple-address RMW cycles and there is no defined protocol for supporting multiple -address RMW cycles which start onboard and then access off-board resources. The MVME172 does not fully support all RMW operations in all possible cases.

1-58 Computer Group Literature Center Web Site

Software Support Considerations

The MVME172 makes the following assumptions and supports a limited subset of RMW instructions. The MVME172 supports single-address RMW cycles caused by TAS and CAS instructions. Because it is not possible to tell if the MC68060 is executing a single- or multiple-address read-modify-write cycle, software should only execute single-address RMW instructions. Multiple-address RMW cycles caused by CAS or CAS2 instructions are not guaranteed indivisible and may cause illegal VMEbus cycles. Lock cycles caused by MMU table walks do not cause illegal VMEbus cycles, and they are not guaranteed indivisible.

Illegal Access to IP Modules from External VMEbus Masters

When a device other than the local MVME172 is operating as VMEbus master, access by that device to the local IP modules is subject to restrictions.

Access to the IndustryPack memory space is supported in all cases. As a result of the difference in data width between the VMEbus and the IP modules (D32 versus D16), however, access to the IndustryPack I/O, ID, and Interrupt Acknowledge space is not supported for single IP modules. This applies to IndustryPacks a, b, c, and d.

http://www.mcg.mot.com/literature 1-59

Board Description and Memory Maps

1-60 Computer Group Literature Center Web Site

Introduction

This chapter describes the VMEchip2 ASIC, local bus to VMEbus interface chip.

The VMEchip2 interfaces the local bus to the VMEbus. In addition to the VMEbus defined functions, the VMEchip2 includes a local bus to VMEbus DMA controller, VME board support features, and Global Control and Status Regi ster s (GCSR) for int erpro cessor communicat ions.

Summary of Major Features

❏ Local Bus to VMEbus Interface:

– Programmable local bus map decoder.

2VMEchip2

– Programmable short, standard, and extended VMEbus

addressing. – Programmable AM codes. – Programmable 16-bit and 32-bit VMEbus data width. – S oftware-enabled write posting mode. – Write post buffer (one cache line or one four-byte). – Automatically performs dynamic bus sizing for VMEbus cyc les. – Software-configured VMEbus access tim ers. – Local bus to VMEbus Requester:

Software-enabl ed fair request mode;

Software-configured release modes:

Release-When-Done (RWD), and Release-On-Request (ROR); and

Software-configured BR0*-BR3* request levels.

2-1

VMEchip2

❏ VMEbus Bus to Local Bus Interface:

– Programmable VMEbus map decoder. – Programmable AM decoder. – Programmable local bus snoop enable. – Simple VMEbus to local bus address translation. – 8-bit, 16-bit and 32-bit VMEbus data width. – 8-bit, 16-bit and 32-bit block transfer. – Standard and extended VMEbus addressing. – S oftware-enabled write posting mode. – Write post buffer (17 four-bytes in BLT mode, two four-by tes in

non-BLT mode).

– An eight four-byte read ahead buffer (BLT mode only).

❏ 32-bit Local to VMEbus DMA Controller:

– Programmable 16-bit, 32-bit, and 64-bit VMEbus data width. – Programmable short, standard, and extended VMEbus

addressing. – Programmable AM code. – Programmable local bus snoop enable. – A 16 four-byte FIFO data buffer. – Supports up to 4 GB of data per DMA request. – Automatically adjusts transfer size to optimize bus utilization. – DMA complete interrupt. – DMAC command chaining is supported by a singly-l inked list of

DMA commands. – VMEbus DMA controller requester:

Software-enabl ed fair request modes;

Software-configured release modes:

Release-On-Request (ROR), an d

Release-On-End-Of-Data (ROEOD); Software-configured BR0-BR3 request levels; and Software enabled bus-tenure timer.

2-2 Computer Group Literature Center Web Site

Introduction

❏ VMEbus Interrupter:

– S oftware-configured IRQ1-IRQ7 interrupt req uest level. – 8-bit software-p rogrammed status/ID register.

❏ VMEbus System Controller:

– Arbiter with software-configured arbitration modes:

Priority (PRI), Round-Robin-Select (RRS), and

Single-level (SGL). – Programmable arbitration timer. – IACK daisy-chain driver. – Programmable bus timer. – SYSRESET logic.

❏ Global Control Status Register Set:

– F our location monitors. – G lobal control of locally detected failures. – G lobal control of local reset.

– Four global attention interrupt bits. – A chip ID and revision register. – Four 16-bit dual-ported general purpose registers.

❏ Interrupt Handler:

– All interrupts are level-programmable. – A ll interrupts are maskable. – All interrupts provide a unique vector. – Software and external interrupts.

❏ Watchdog timer. ❏ Two 32-bit tick timers.

http://www.mcg.mot.com/literature 2-3

VMEchip2

Functional Blocks

The following sections provide an overview of the functions provided by the VMEc hip2. See Figure 2-1 for a block diagram of the VMEchip 2. A detailed programming model for the local control and status registers (LCSR) is provided in the following section. A detailed programming model for the glob al control and status r egisters (GCSR) is provided in the next section.

Local Bus to VMEbus Interface

The local bus to VMEbus interface allows local bus masters access to global resources on the VMEbus. This interface i ncludes a local bus slave , a write post buffer, and a VMEbus master.

Using programmable map decoders wit h programmabl e attribut e bits, the local bus to VMEbus in terface can be configur ed to provid e the fol lowing VMEbus ca pabilities:

Addressing capabilities: A16, A24, A32 Data transfer capabilities: D08 , D 16, D32

The local bus slave includes six local bus map decoders for accessing the VMEbus. The first four map decoders are gener al purpo se progra mmable decoders, while t he other two ar e fixed and ar e dedicated for I/O decoding.

The first four map de code rs compare local bus address lines A31 through A16 with a 16-bit sta rt a ddress and a 16-bi t en d a ddress . When an addre ss in the sele cted range is detected, a VMEbus select is generated to the VMEbus master. Each map decoder also has eight attribute bits and an enable bit. Th e a tt ri but e b it s a re fo r VM Ebus AM co des, D16 enable, and write post (WP) enable.

The fourth map decoder also includes a 16-bit alternate address register and a 16-bit alternate address select register. This allows any or all of the upper 16 address bits from the local bus to be replaced by bits from the alternate addr ess register. The feature allows the local bus master to acc ess any VMEbus address.

2-4 Computer Group Literature Center Web Site

Functional Blocks

DATA

CONTROL

ADDRESS

1344 9403

VMEBUS TO LOCAL BUS INTERFACE

VMEBUS MASTER

FIFO

LOCAL BUS MASTER

DATA

ADDRESS

CONTROL

DATA

CONTROL

DATA

16 ENTRY BY 4 BYTES

CONTROL

DMA CONTROL

DATA

GCSR

DATA

DMA CONTROLLER

CONTROL

ADDRESS

GLOBAL CONTROL / STATUS REGISTER

DATA

CONTROL CONTROL

DATA

CONTROL

DATA

CONTROL

ADDRESS

CONTROL

CONTROL CONTROL

DATA

CONTROL

ADDRESS

VMEBUS SLAVE

FIFO

DATA

ADDRESS

CONTROL

DATA

CONTROL

ADDRESS

CONTROL

DATA

ADDRESS

CONTROL

16 ENTRY BY 4 BYTES

DATA

ADDRESS

CONTROL

DATA

CONTROL

ADDRESS

CONTROL

DATADATA

CONTROL

ADDRESS

4 ENTRY BY 4 BYTES

LOCAL BUS TO VMEBUS INTERFACE

CONTROL CONTROL

DATA

CONTROL

ADDRESS

CONTROL

DATA

CONTROL

ADDRESS

DATA

CONTROL CONTROL

DATA

ADDRESS

CONTROL

LOCAL BUS MASTER

DATA

CONTROL

ADDRESS

DATA

ADDRESS

LOCAL BUS LOCAL BUS SLAVE FIFO VMEBUS MASTER VMEBUS

CONTROL

Figure 2-1. VMEchip2 Block Diagram

http://www.mcg.mot.com/literature 2-5

VMEchip2

Using the four programmable map decoders, separate VMEbus maps can be created, each with its own attributes. For example, one map can be configured as A32, D32 with write posting enabled while a second map can be A24, D16 with write posting disabled.

The first I/O map decoder decodes local bus addresses $FFFF0000 thr ough $FFFFFFFF as the short I/O A16/D16 or A16/D32 area, and the other provides an A24/D16 space at $F0000000 to $F0FFFFFF and a n A32/D16 space at $F1000000 to $FF7FFFFF.

Supervisor/non-pri vileged and program/data space is determined by attribute bits. Write posting may be enabled or disabled for each decoder I/O space and this map decoder may be enabled or disabled.

When writ e posting is ena bled, the VMEc hip2 stores the local bus add ress and data and t hen acknowled ges the l ocal bus mas ter. The l ocal bus i s then free to perform other oper ations while the VMEbus master requests the VMEbus and performs the requested operation.

The write post buffer stores one byte, two-byte, four-byte, or one cache line (four four-bytes). Write posting should only be enabled when bus errors are not expected . If a bus error is returned on a write posted cycle, the local pr ocessor is i nterrupted, if the interr upt is enabl ed. The address of the error is not saved. Normal memory never returns a bus err or on a write cycle. However, some VMEbus ECC memory cards perform a readmodify-write operation and therefore may return a bus error if there is an error on the r ead po rtion of a r ead-modi fy-wr ite. Write postin g shoul d not be enabled when this type of memory card is used. Also, memory should not be sized using write operations if write posting is enabled. I/O areas that have holes should not be write posted if software may access nonexistent memory. Using the programmable map decoders, write posting

can be enabled for “s afe” areas and disable d for areas which are not “s afe”. Block transfer is not supported because the MC68060 block transfer

capability is not compatible with the VMEbus. The VMEbus master supports dynamic bus sizing. When a local device

initiates a quad -byte acce ss to a VMEbus sl ave tha t only h as the D1 6 data transfer capability, the chip executes two double-byte cycles on the VMEbus, acknowledging the local device after all requested four-bytes

2-6 Computer Group Literature Center Web Site

Functional Blocks

have been accessed. This enhances the portability of software because it allows software to run on the system regardless of the physical organization of global memory.

Using the local bus map decoder attribute register, the AM code that the master places on the VMEbus can be programmed un der software control.

The VMEchip2 includes a softwar e-controlled VMEb us access timer, and it starts ti cking when the chip i s request ed to do a VMEbus dat a transfer or an interrupt acknowl edge cycl e. The timer sto ps ticki ng once th e chip has started the dat a transfer o n the VMEbus. If the data tr ansfer does not begin before the timer times out, the timer drives the local bus error signal, and sets the appropriate status bit in the Local Control and Status Register (LCSR). Using control bits in the LCSR, the timer can be disabled, or it can be en abled to drive the local bus error signal after 64 µs, 1 ms, or 32 ms.

The VMEchip2 includes a software-controlled VMEbus write post timer, and it starts ticking when a data transfer to the VMEbus is writ e posted. The timer stops ticking once the chip has started the data transfer on the VMEbus. If this does not happen before the timer times out, the chip aborts the write post ed c ycl e and send an interrupt to the loc al b us interrupter. If the write post bus error interrupt is enabled in the local bus interrupter, the local processor is interrupted to indi cate a write post time-out has occurred. The write post timer has the same timing as the VMEbus access timer.

Local Bus to VMEbus Requester

The requester provides all the signals necessary to allow the local bus to VMEbus master to request and be granted use of the VMEbus. The chip connects to all signals that a VMEbus requester is required to drive and monitor.

Requiring no externa l jumpers, the chip provide s the means for software to program the re quester to request th e bus on a ny one of the four bus r equest levels, automatically establishing the bus grant daisy-chains for the three inactive levels.

http://www.mcg.mot.com/literature 2-7

VMEchip2

The requester requests the bus if any of the following conditions occur:

1. The local bus master initiates either a data transfer cycle or an interrupt acknowledge cycle to the VMEbus.

2. The chip is requested to acq uire contro l of the VMEbus as signale d by the DWB input signal pin.

3. The chip is requested to acq uire contro l of the VMEbus as signale d by the DWB control bit in the LCSR.

The local bus to VMEbus requester in the VMEchip2 implements a fair mode. By setting the LVFAIR bit, the requester refrains from requesting the VMEbus until it detects its assigned request line in its negated state.

The local bus t o VMEbus requ ester at tempts to relea se the VMEbus when the requested d ata transfe r operation i s complete, the DWB pin is neg ated, the DWB bit in th e LCSR is negated an d the bus is not bei ng held by a loc k cycle. The requester releases the bus as follows:

1. When the chip is configured in the release-when-done (RWD) mode, the request er r el eases the bus when the above c ondi ti ons a re satisfied.

2. When the chip is configured in the rele ase-on-requ est (ROR) mode, the requester releases the bus when the above conditions are satisfied and there is a bus request pending on one of the VMEbus request lines.

To minimize the timing overhead of the arbitration process, the local bus to VMEbus requester in the VMEchip2 executes an early release of the VMEbus. If it is about to release the bus and it is executing a VMEbus cycle, the requester releases BBSY before its ass ociated master compl etes the cycle. This allows the arbiter to arbitrate any pending requests, and grant the bus to the ne xt r equester, at the same time that the active master completes its cycle.

2-8 Computer Group Literature Center Web Site

Functional Blocks

VMEbus to Local Bus Interface

The VMEbus to local bus interface allows an off-board VMEbus master access to onboard re sources. The VMEbus to local bus interface includes the VMEbus slave, write post buffer, and local bus master.

Adhering to th e IEEE 1014-87 VMEbus St andard, the slave can withstand address-only cycles, as well as address pipelining, and respond to unaligned transfers. Using programmable map decoders, it can be configured to provide the following VMEbus capabilities:

Addressing capabilities: A24, A32 Data transfer capabilities: D08 (EO), D16, D32, D8/BLT,

The slave can be prog rammed to perform write posting opera ti ons. When in this mod e, the chip latches incoming data and addressing infor mation into a stagi ng FIFO and t hen a cknowle dges the VMEbus wr ite tran sfer by asserting DTACK. The chip then requests control of the local bus and independently a ccesses the local reso urce after it has been gr anted the local bus. The write-post ing pipeline is two deep in the non-blo ck transfer mode and 16 deep in the block transfer mode.

D16/BLT, D32/BLT, D64/BLT (BLT = block transfer)

To significantly improve the access time of the slave when it responds to a VMEbus block read cycle, the VMEchip2 contai ns a 16 four-byte deep read-ahead pipeli ne. When responding to a block read cycle, the chip performs block read cycles on the local bus to keep the FIFO buffer full. Data for su bsequent transfers is then retrieved from the on chip buffer, significant ly improving the response time of the slave in the block tra nsfer mode.

The VMEchip2 includes an onchip map decoder that allows software to configure the global addressing range of onboard resources. The decoder allows the local address range to be partitioned into two separate banks, each with its own start and end address (in increments of 64KB), as well as set each bank’s address mo difier co des and write post enable and snoop enable.

http://www.mcg.mot.com/literature 2-9

VMEchip2

Each map decoder includes an alternate address register and an alternate address select register. These registers allow any or all of the upper 16 VMEbus address line s to be replace d by signal s from the alte rnate addres s register. This allows the address of local resources to be different from their VMEbus address.

The alternat e address regi ster also pr ovides the uppe r eight bits of the local address when the VMEbus slave cycle is A24.

The local bus master requests the local bus and executes cycles as required. To reduce local bus loading and improve performanc e i t a lway s attempts to transf er data using a b urst tr ansfer a s define d by the MC680 60.

When snooping is enabled, the local bus master requests the cache controller in the MC68060 to monitor the local bus addresses.

Local Bus to VMEbus DMA Controller

The DMA Con troller (DMAC) operates in conjun ction with the local bus master, the VMEbus master, and a 16 four-byte FIFO buffer. The DMA controller has a 32-bit local address counter, 32-bit table address counter, a 32-bit VMEbus address counter, a 32-bit byte counter, and control and status registers. The Local Control and Status Register (LCSR) provides software with the ability to control the operational modes of the DMAC. Software can program the DMAC to transfer up to 4GB of data in the course of a singl e DMA operation. The DMAC supports tra nsfers from any local bus address to an y VMEbus addr ess. The t ransf ers may be fr om one byte to 4GB in length.

To optimize local bus use, the DMAC automatically adjusts the size of individual data transfers until 32-bit transfers can be executed. Based on the address of the first byte, the DMAC transfers a single-byte, a double-byte, or a mixt ure of both, and then con tinues to execute quad- byte block transfer cycles. When the DMAC is set for 64-bit transfers, the octal-byte transfers takes place. Based on the address of the last byte, the DMAC transfers a single-byte, a double- byte, or a mixture of both to end the transfer.

2-10 Computer Group Literature Center Web Site

Functional Blocks

Using control register bits in the LCSR, the DMAC can be configured to provide the following VMEbus capabilities:

Addressing capabilities: A16, A24, A32 Data transfer capabilities: D16 , D 32, D16/BLT, D32/BLT,

D64/BLT (BLT = block transfer)

Using the DMA AM control register, the address modifier code that the VMEbus DMA controller places on the VMEbus can be programmed under software cont rol. In addition, the DMAC can be programmed to execute block-transfer cycles over the VMEbus.

Complying with the VMEbus specification, the DMAC automatically terminates bloc k-transfer cycl es whenever a 2 56-byte (D32/BLT) or 2-KB (D64/BLT) boundary is crossed. It does so by momentarily releasing AS and then, in accordance with its bus release/bus request configuration, initiating a new block-transfer cycle.

To optimize VMEbus use, the DMAC automatically adjusts the size of individual data transfers until 64-bit transfers (D64/BLT mode), 32-bit transfers (D32 mode) or 16-bit transfers (D16 mode) can be executed. Based on the address of the first byte, the DMAC transfers single-byte, double-byte, or a mixture of both, and then continues to execute transfer cycles based on the programmed data width. Based on the address of the last byte, the DMAC transfers single-byte, double-byte, or a mixture of both to end the transfer.

To optimize local b us use when the VMEbu s is operating in the D16 mode, the data FIFO conv erts D1 6 VMEbus t ransf ers t o D32 loca l bus t ransf ers. The FIFO also aligns data if the source and destination addresses are not aligned so the local bus and VMEbus can operate at their maximum data transfer sizes.

To allow other boards access to the VMEbus, the DMAC has bus tenure timers to limit the time the DMAC spends on the VMEbus and to ensure a minimum time off the VMEbus. Since the loca l bus is generally faster t han the VMEbus, other local bus masters may use the local bus while the DMAC is waiting for the VMEbus.

http://www.mcg.mot.com/literature 2-11

VMEchip2

The DMAC also supports command chaining through the use of a singlylinked list built in local memory. Each entry in the list includes a VMEbus address, a local bus addr ess, a byt e count, a co ntrol word, and a poin ter to the next entry. When the c ommand chai ning mo de is ena bled, t he DMAC reads and executes commands from the list in local memory until all commands are execu t ed.

The DMAC can be programmed to send an interrupt request to the local bus interrupt er when any specific t able entry has complete d. In addition the DMAC always sends an interrupt request at the normal completion of a request o r when an error is detected. If the DMAC interrupt is enabled in the DMAC, the local bus is interrupted.

To allow increased flexibility in managing the bus tenure to op t imize bus usage as required by the system configuration, the chip contains control bits that allow the DMAC time on and off the bus to be programmed. Using these control bits, soft ware can inst ruct the DMA Co ntroller t o acquire th e bus, maintain mastership for a specific amount of time, and then, after relinquishing it, refrain from requesting it for another specific amount of time.

No Address Increment DMA T ransfers

During normal memory-to-memory DMA transfers, the DMA controller is programmed to incr ement the local bu s and VMEbus a ddress. Thi s allows a block of data to be transferre d betwe en VMEbus memory and loc al bus memory. In some applications, it may be desirable to transfer a block of data from local bus memory to a single VMEbus address. This single VMEbus address may be a FIFO or similar type device which can accept a large amount of data but only appears at single VMEbus address. The DMA controller provides support for these devices by allowing transfers without incrementing the VMEbus address. The DM A controller also allows DMA transfers without incrementing the local bus address, however the MVME172 does not have any onboard devices that benefit from not incrementing the local bus address.

The transfer mode on t he VMEbus may be D16, D16/BLT, D32, D32/BLT or D64/BLT. When the no increment address mo de is selected, some of the VMEbus address li nes and local bus ad dress lines co ntinue to incr ement in some modes. This is re quired to support t he various port size s and to allow

2-12 Computer Group Literature Center Web Site

Functional Blocks

transfers which are not an even byte count or star t at an odd address, with respect to the port size. A 16-bit device should respond with VA<1> high or low. Devices on the local bus should respond to any combination of LA<3..2>. This is re quired to support the burst mode on the MC68 060 bus.

Normally when the non-increment mode is used, the starting address and byte count would be aligned to th e port size. For example, a DM A transfer to a 16-bit FIFO would start on a 16-bit boundar y and would have an even number of 16-b it t ransfer s. If t he star ting ad dress is not aligned or the byte count is odd, the DMA controller will increment the lower address lines. This is re quired because the lower order address li nes are used to define the size of the transfer and the byte lanes.

The VMEbus uses VA<2..1>, LWORD*, and DS<1..0>* to define the transfer size a nd byte lanes. I f the VMEbus port size is D32, then VA<1 >, LWORD* and DS<1..0>* are used to define the transfer size and byte lanes. During D16 transfers, the VMEbus address line VA<1> toggles. If the VMEbus port size is D64, then VA<2..1>, LWORD* and DS<1..0>* are used to define the transfer size and byte lanes. Local bus address LA<3..0> and SIZ<1..0> are us ed to define the tr ansfer size and byte lanes on local bus. During local bus transfers, LA<3..2> count.

The DMA controller internally increments the VMEbus address counter and if the transfer mode is BLT, the DMA controller generates a new address strobe (AS*) when a block boundary is crossed.

DMAC VMEbus Requester

The chip contains an independent VMEbus requester associated with the DMA Controller. This allows flexibility in instituting different bus tenure policies for the single-transfer oriented master, and the block-transfer oriented DMA controller. The DMAC requester provides all the signals necessary to allow the onchip DMA Controller to request and be granted use of the VMEbus.

Requiring no externa l jumpers, the chip provide s the means for software to program the DMAC requeste r to request the bus on any one of the four bus request level s, automatically esta blishing the bus gran t daisy-chains for t he three inactive levels.

http://www.mcg.mot.com/literature 2-13

VMEchip2

The DMAC requester requests the bus as required to transfer data to or from the FIFO buffer.

The requester implements a fair mode. By setting the DFAIR bi t, the requester refrains from requesting the bus until it detects its assigned request line in its negated state.

The requester rele ases the bus when requested to by the DMA controller. The DMAC always releases the VMEbus when the FI FO is full ( VMEbus to local bus) or empty (local bus to VMEbus). The DMAC can also be programmed to release the VMEbus when another VMEbus master requests the bus, when the time on time r has expi red, or when the time on timer has expired and another VMEbus master is requesting the bus. To minimize the timing overhead of the arbitration process, the DMAC requester executes an early release of the bus. If it is about to release the bus and it is executing a VMEbus cycle, the requester releases BBSY before its associat ed VMEbus master completes th e cycle. This allows the arbiter to arbitrate any pending requests, and grant the bus to the next requester, at the same time that the DMAC completes its cycle.

Tick and Watchdog Timers

The VMEchip2 has two 32-bit tick timers and a watchdog t imer . The tick timers run on a 1 MHz clock which is der ived fr om the loca l bus clo ck by the prescaler.

Prescaler

The prescaler is used to derive the various clocks required by the tick timers, VME access timers, reset timer, bus arbitration timer, local bus timer, and VMEbus timer. The prescaler divides the local bus clock to produce the constant-frequency clocks required. Software is required to load the appropriate constant, depending upon the local bus clock, following reset to ensure proper operation of the prescaler.

2-14 Computer Group Literature Center Web Site

Functional Blocks

Tick Timer s

The VMEchip2 include s two general purpose t ick timers. These timers can be used to generate interrupts at various rates or the counters can be read at various times for interval timing. The time rs have a resolution of 1 µs and when free running, they roll over every 71.6 minutes.

Each tick timer has a 32-bit counter, a 32-bit compare register, a 4-bit overflow register, an enable bit, an overflow clear bit, and a clear-on-compare enable bit. The counter is readable and writable at any time and when enabled in the free run mode, it increments every 1µs. When the counte r i s e n abl ed in the clear-on-compare mode, it in cre m ent s every 1µs until the counter value matches the value in the compare register. When a match occurs, the counter is cleared. When a match occurs, in either mode, an interrupt is sent to the local bus interrupter and the overflow counter is incremented. An interrupt to the local bu s is only generated if the tick timer interrupt is enabled by the local bus interrupter. The overflow counter c an be cleared by writing a one to the overflow c lear bit.

Tick timer one or two can be programmed to generate a pulse on the VMEbus IRQ1 interrupt line at the tick timer period. This pr ovides a broadcast interrupt function which allows several VME boards to receive an interrupt at the same time. In certain applications, this interrupt can be used to synchronize multiple processors. This interrupt is not acknowledged on the VMEbus. This mode is intended for specific applications and is not defined in the VMEbus specification.

Watchdog T imer

The watchdog timer has a 4-bit counter, four clock select bits, an enable bit, a local r eset enable bit, a SYSRESET enable bit, a board fail enab le bit, counter reset bit, WDTO status bit, and WDTO status reset bit.

When enabled, the counter increments at a rate determined by the clock select bits. If the counter is not reset by software, the counter reaches its terminal count. When this occurs, the WDTO status bit is set; and if the local or SYSRESET funct ion is e nab led, t he se lecte d res et i s gene rated ; if the board fail function is enabled, the board fail signal is generated.

http://www.mcg.mot.com/literature 2-15

VMEchip2

VMEbus Interrupter

The interrupter provides all the signals necessary to allow software to request interrupt service from a VMEbus interrupt handler. The chip connects to all signals that a VMEbus interrupter is required to drive and monitor.

Requiring no externa l jumpers, the chip provide s the means for software to program the interrupter to request an interrupt on any one of the seven interrupt requ est lin es. In addit ion, the chi p contro ls the prop agation of the acknowledge on the IACK daisy-chain.

The interrupter operates in the release-on-acknowledge (ROAK) mode. An 8-bit control r egister pr ovides sof tware wit h the means to dynamica lly program the status/ID information. Upon reset, this register is initialized to a status/ID of $0 F (the uninitialize d vector in the 68K-b ased environment).

The VMEbus interrupter has an additional feature not defined in the VMEbus specification . The VMEchi p2 s upports a broadcast mode on the IRQ1 signal line. When this feature is used, the normal IRQ1 interrupt to the local bus interrupter should be disabled and the edge-sensitive IRQ1 interrupt to the local bus interrupter should be enabled. All boards in the system which are not participating in the broadcast interrupt function should not drive or respond to any signals on the IRQ1 signal line.

There are two ways to broadcast an IRQ1 interrupt. The VMEbus interrupter in the VMEchip2 may be programmed to generate a level one interrupt. This interrupt must be cleared using the interrupt clear bit in the control register because the interrupt is never acknowledged on the VMEbus. The VMEchip2 allows the output of one of the tick timers to be connected to the IRQ1 interrupt signal line on the VMEbus. When this function is enabled, a pulse appears on the IRQ1 signal line at the programmed interrupt rate of the tick timer.

2-16 Computer Group Literature Center Web Site

Functional Blocks

VMEbus System Controller

With the exception of the optional SERCLK Driver and the Power Monitor, the chip includes all the functions that a VMEbus System Controller must provide. The System Controller is enabled/disabled with the aid of an external jumper (the only jumper required in a VMEchip2 based VMEbus interface).

Arbiter

The arbitration al gor it hm use d by th e chip arbiter is selected by software. All three arbitration modes defined in the VMEbus Specification are supported: Priority (PRI), Round-Robin-Select (RRS), as well as Single (SGL). When operating in the PRI mode, the arbiter asserts the BCLR line whenever it det ects a req uest for t he bus who se level i s higher t hat the o ne being serviced.

The chip includes an arbitration timer, preventing a bus lockup when no requester assumes control of the bus after the arbiter has issued a grant. Using a control bit, this timer can be enabled or disabled. When enabled, it assumes control of th e bus by driving the BBSY signal after 256 µsecs, releasing i t after satis fying th e requir ements of the VMEbu s spec ificat ion, and then re-arbitrating any pending bus requests.

IACK Daisy-Chain Driver

Complying with the latest revision of the VMEbus specification, the System Controller includes an IACK Daisy-Chain Driver, ensuring that the timing requirements of the IACK daisy-chain are satisfied.

Bus Timer

The Bus Timer is enabled/disabled by software to terminate a VMEbus cycle by asserting BERR if any of the VMEbus data strobes is maint ained in its asserted state for longer than the programmed time-out period. The time-out period can be set to 8, 64, or 256 secs. The bus timer terminates an unresponded VMEbu s cycle only if both it a nd the system control ler are enabled.

http://www.mcg.mot.com/literature 2-17

VMEchip2

Reset Driver

In addition to the VMEbus timer, the chip contains a local bus timer. This timer asserts the local TEA when the local bus cycle mainta ined in its asserted state for longer that the programmed time-out pe riod. This timer can be enabled or disabled under sof tware control. The time-out period can be programmed for 8, 64, or 256 secs.

The chip includes both a global and a local reset driver. When the chip operates as the VMEbus system controller, the reset driver provides a global system reset by asserting the VMEbus signal SYSRESET. A SYSRESET may be generated by the

RESET switch, a power up reset, a

watch dog time-out, or by a c ontrol bi t in the LCSR. SYSRESET remains asserted for at least 200 msec, as required by the VMEbus specification.

Similarly, the chip provides an input signa l and a control bit to initiate a local reset operation.

The local reset dr iver is enabled even when the chip is not the system controller. A local reset may be generated by the

RESET switch, a power

up reset, a watch dog time-out, a VME bus SYSRESET, or a co ntrol bit in the GCSR.

Local Bus Interrupter and Interrupt Handler

There are 31 interrupt sources in the VMEchip2: VMEbus ACFAIL,

ABORT switch, VMEbus SYSFAIL, write post bus error, external input,

VMEbus IRQ1 edge-sensitive, VMEchip2 VMEbus interrupter acknowledge, tick t imer 2-1, DMAC done, GCSR SIG3-0, GCSR location monitor 1-0, softwa re interrupts 7-0, and VMEbus IRQ7- 1. Each of the 3 1 interrupts can be enabled to generate a local bus interrupt at any level. For example, VMEbus IRQ5 can be programmed to generate a level 2 local bus interrupt.

The VMEbus AC fail interrupter is an edge-sensitive interrupter connected to the VMEbus ACFAIL signal line. This interrupter is filtered to remove the ACFAIL glitch which is related to the BBSY glitch.

The SYS fail interrupter is an edge-sensitive interrupter connected to the VMEbus SYSFAIL signal line.

2-18 Computer Group Literature Center Web Site

Functional Blocks

The write post bus error interrupter is an edge-sensitive interrupter connected to the local bus to VMEbus write post bus error signal line.

The VMEbus IRQ1 edge-sensitive interrupter is an edge-sensitive interrupter conne cted to t he VMEbus IRQ1 signal line. Thi s interrup ter is used when one of the tick timers is connected to the IRQ1 signal line. When this interrupt is acknowledged, the vector is provided by the VMEchip2 and a VMEbus i nt er rup t acknowledge is not generated. When this interrupt is enabled, the VMEbus IRQ1 level-sensitive interrupter should be disabled.

The VMEchip2 VMEbus interrupter acknowledge interrupter is an edgesensitive inter rupter conn ected to the ackn owledge outpu t of the VMEbus interrupter. An interrupt is generated wh en an interrupt on the VMEbus from VMEchip2 is acknowledged by a VMEbus interrupt handler.

The tick timer interr upters are edg e-sensit ive interru pters connect ed to the output of the tick timers.

The DMAC interrupter is an edge-sensitive interrupter connected to the DMAC.

The GCSR SIG3-0 interrupters are edge-sensitive interrupters connected to the output of the signal bits in the GCSR.

The location monit or interrupters are edge-s ensitive interrupters connected to the location monitor bits in the GCSR.

The software 7-0 interrupters can be set by software to generate interrupts. The VMEbus IRQ7-1 interrupters are level-sensitive interrupters

connected to the VMEbus IRQ7-1 signal lines. The interrupt hand ler provides all logic neces sary to identify and handle all

local interrupts as well as VMEbus interru pts. When a local interrupt is acknowledged, a unique vector is provided by the chip. Edge-sensitive interrupters are not cleared during the interr upt acknowledge cycle and must by reset by software as required. If the interrupt source is the VMEbus, the interrupt handler instructs the VMEbus master to execute a VMEbus IACK cycle to obtain the vector from the VMEbus interrupter. The chip connects to all signals th at a VMEbus handle r is required to drive

http://www.mcg.mot.com/literature 2-19

VMEchip2

and monitor. On the local bus, the interrupt handler is designed to comply with the interrupt handli ng sign ali ng protocol of the MC68060 microprocessor.

Global Control and Status Registers

The VMEchip2 includ es a set of register s that are accessible from both th e VMEbus and the local bus. These registers are provided to aid in interprocessor communications over the VMEbus. These registers are fully described in a later section.

LCSR Programming Model

This section defines the programming model for the Local Control and Status Registers ( LCSR) in the VMEchip2. The loc al bus map decoder for the LCSR is incl uded in the VMEchip2. The base address of the LCSR is $FFF40000 and the registers are 32-bits wide. Byte, two-byte, and four-byte read ope rations are per mitted: however , byte and two-byte wr ite operations are not permitted. Byte and two-byte write operations return a TEA signal to the local bus. Read-modi fy-write oper ations should be us ed to modify a byte or a two-byte of a register.

Each register definition includes a table with 5 lines:

❏ Line 1 is the base address of the register and the number of bits

defined in the table.

❏ Line 2 shows the bits defined by this table. ❏ Line 3 defines the name of the register or the name of the bits in the

2-20 Computer Group Literature Center Web Site

LCSR Programming Model

❏ Line 4 defines the operations pos sible on the regis ter bits as foll ows:

R This bit is a read-only status bit. R/W This bit is readable and writable. W/AC This bit can be set and it is automatically cleared. This bit can

also be read.

C Writing a one to this bit clears this bit or another bit. This bit

reads zero.

S Writing a one to this bit sets this bit or another bit. This bit reads

zero.

❏ Line 5 defines the state of the bit following a reset as follows:

P The bit is affected by powerup reset. S The bit is affected by SYSRESET. L The bit is affected by local reset. X The bit is not affected by reset.

A summary of the LCSR is shown in Table 2-1.

http://www.mcg.mot.com/literature 2-21

VMEchip2

Table 2-1. VMEchip2 Memory Map - LCSR Summary (Sheet 1 of 2)

VMEchip2 LCSR Base Address = $FFF40000 OFFSET:

SLAVE ENDING ADDRESS 1

SLAVE ENDING ADDRESS 2

SNP

WP2SUP2USR2A322A24

MASTER ENDING ADDRESS 1

MASTER ENDING ADDRESS 2

MASTER ENDING ADDRESS 3

MASTER ENDING ADDRESS 4

MAST

D16

GCSR

BOARD SELECT

WAIT

RMW

ROM

ZERO

MASTER AM 3MASTER AM 4

BLK D64

MAST

DMA TB

SNP MODE

MAST

BLK2PRGM2DATA

SLAVE ADDRESS TRANSLATION ADDRESS 1

SLAVE ADDRESS TRANSLATION ADDRESS 2

ADDER

MASTER ADDRESS TRANSLATION ADDRESS 4

MAST

D16

GCSR GROUP SELECT

MAST

SRAM

SPEED

16171819202122232425262728293031

MAST

16171819202122232425262728293031

TICK

2/1

TICK

IRQ 1

CLR

IRQ

STAT

VMEBUS

INTERRUPT

LEVEL

VMEBUS INTERRUPT VECTOR

DMA CONTROLLER

This sheet continues on facing page.

2-22 Computer Group Literature Center Web Site

Motorola MVME172-223, MVME172-213, MVME172-313, MVME172-413, MVME172-323 Programmer's Reference Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
