MOTOROLA MMSF3P03HD User Manual
1
Motorola TMOS Power MOSFET Transistor Device Data
Medium Power Surface Mount Products
MiniMOS devices are an advanced series of power MOSFETs
which utilize Motorola’s High Cell Density HDTMOS process.
These miniature surface mount MOSFET s feature ultra low R
DS(on)
and true logic level performance. They are capable of withstanding
high energy in the avalanche and commutation modes and the
drain–to–source diode has a very low reverse recovery time.
MiniMOS devices are designed for use in low voltage, high speed
switching applications where power efficiency is important. Typical
applications are dc–dc converters, and power management in
portable a nd battery p owered p roducts such as computers,
printers, cellular and cordless phones. They can also be used for
low voltage motor controls in mass storage products such as disk
drives and t ape drives. T he avalanche e nergy i s specified t o
eliminate the guesswork in designs where inductive loads are
switched and offer additional safety margin against unexpected
voltage transients.
• Ultra Low R
DS(on)
Provides Higher Efficiency and Extends Battery Life
• Logic Level Gate Drive — Can Be Driven by Logic ICs
• Miniature SO–8 Surface Mount Package — Saves Board Space
• Diode Is Characterized for Use In Bridge Circuits
• Diode Exhibits High Speed, With Soft Recovery
• I
DSS
Specified at Elevated Temperature
• Avalanche Energy Specified
• Mounting Information for SO–8 Package Provided
MAXIMUM RATINGS
(TJ = 25°C unless otherwise noted)
(1)
Rating
Symbol Value Unit
Drain–to–Source Voltage V
DSS
30 Vdc
Drain–to–Gate Voltage (RGS = 1.0 MΩ) V
DGR
30 Vdc
Gate–to–Source Voltage — Continuous V
GS
± 20 Vdc
Drain Current — Continuous @ TA = 25°C
Drain Current — Continuous @ TA = 100°C
Drain Current — Single Pulse (tp ≤ 10 µs)
I
D
I
D
I
DM
4.6
3.0
50
Adc
Apk
Total Power Dissipation @ TA = 25°C
(2)
P
D
2.5 Watts
Operating and Storage Temperature Range – 55 to 150 °C
Single Pulse Drain–to–Source Avalanche Energy — Starting TJ = 25°C
(VDD = 20 Vdc, VGS = 5.0 Vdc, IL = 9.0 Apk, L = 14 mH, RG = 25 Ω)
E
AS
567 mJ
Thermal Resistance — Junction to Ambient
(2)
R
θJA
50 °C/W
Maximum Lead Temperature for Soldering Purposes, 1/8″ from case for 10 seconds T
L
260 °C
DEVICE MARKING
S3P03
(1) Negative signs for P–Channel device omitted for clarity .
(2) Mounted on 2” square FR4 board (1” sq. 2 oz. Cu 0.06” thick single sided), 10 sec. max.
ORDERING INFORMATION
Device Reel Size Tape Width Quantity
MMSF3P03HDR2 13″ 12 mm embossed tape 2500 units
Designer’s Data for “Worst Case” Conditions — The Designer’s Data Sheet permits the design of most circuits entirely from the information presented. SOA Limit
curves — representing boundaries on device characteristics — are given to facilitate “worst case” design.
Designer’s, HDTMOS and MiniMOS are trademarks of Motorola, Inc. TMOS is a registered trademark of Motorola, Inc.
Thermal Clad is a trademark of the Bergquist Company.
Order this document
by MMSF3P03HD/D
SEMICONDUCTOR TECHNICAL DATA
Motorola, Inc. 1996
D
S
G
CASE 751–05, Style 13
SO–8
SINGLE TMOS POWER FET
3.0 AMPERES
30 VOLTS
R
DS(on)
= 0.1 OHM
Motorola Preferred Device
N–C
1
2
3
4
8
7
6
5
Top View
Source
Source
Gate
Drain
Drain
Drain
Drain
Preferred devices are Motorola recommended choices for future use and best overall value.
REV 5
