MOTOROLA

Order this document

by MC68HC11KTS/D

SEMICONDUCTOR

TECHNICAL DATA

M68HC11 K Series

Technical Summary

8-Bit Microcontroller

The M68HC11 K-series microcontroller units (MCUs) are high-performance derivatives of the MC68HC11F1 and have several additional features. The MC68HC11K0, MC68HC11K1, MC68HC11K3, MC68HC11K4 and MC68HC711K4 comprise the series. These MCUs, with a nonmultiplexed expanded bus, are characterized by high speed and low power consumption. Their fully static design allows operation at frequencies from 4 MHz to dc.

This document contains information concerning standard, custom-ROM, and extended-voltage devices. Standard devices include those with disabled ROM (MC68HC11K1), disabled EEPROM (MC68HC11K3), disabled ROM and EEPROM (MC68HC11K0), or EPROM replacing ROM (MC68HC711K4). Custom-ROM devices have a ROM array that is programmed at the factory to customer specifications. Extended-voltage devices are guaranteed to operate over a much greater voltage range (3.0 Vdc to 5.5 Vdc) at lower frequencies than the standard devices. Refer to the device ordering information tables for details concerning these differences.

1 Features

• M68HC11 CPU

• Power Saving STOP and WAIT Modes

• 768 Bytes RAM (All Saved During Standby)

• 24 Kbytes ROM or EPROM

• 640 Bytes Electrically Erasable Programmable Read Only Memory (EEPROM)

• Optional Security Feature Protects Memory Contents

• On-Chip Memory Mapping Logic Allows Expansion to Over 1 Mbyte of Address Space

• PROG Mode Allows Use of Standard EPROM Programmer (27C256 Footprint)

• Nonmultiplexed Address and Data Buses

• Four Programmable Chip Selects with Clock Stretching (Expanded Modes)

• Enhanced 16-Bit Timer with Four-Stage Programmable Prescaler — Three Input Capture (IC) Channels — Four Output Compare (OC) Channels — One Additional Channel, Selectable as Fourth IC or Fifth OC

• 8-Bit Pulse Accumulator

• Four 8-Bit or Two 16-Bit Pulse Width Modulation (PWM) Timer Channels

• Real-Time Interrupt Circuit

• Computer Operating Properly (COP) Watchdog

• Clock Monitor

• Enhanced Asynchronous Nonreturn to Zero (NRZ) Serial Communications Interface (SCI)

• Enhanced Synchronous Serial Peripheral Interface (SPI)

• Eight-Channel 8-Bit Analog-to-Digital (A/D) Converter

• Seven Bidirectional Input/Output (I/O) Ports (54 Pins)

• One Fixed Input-Only Port (8 Pins)

• Available in 84-Pin Plastic Leaded Chip Carrier (PLCC), 84-Pin Windowed Ceramic Leaded Chip

Carrier (CLCC), and 80-Pin Quad Flat Pack (QFP)

This document contains information on a new product. Speciﬁcations and information herein are subject to change without notice.

Table 1 Standard Device Ordering Information

Package Temperature CONFIG Description Frequency MC Order Number

84-Pin PLCC –40 ° to + 85 ° C $DF BUFFALO ROM 4 MHz MC68HC11K4BCFN4

–40 ° to + 85 ° C $DD No ROM 2 MHz MC68HC11K1CFN2

3 MHz MC68HC11K1CFN3 4 MHz MC68HC11K1CFN4

–40 ° to + 105 ° C $DD No ROM 2 MHz MC68HC11K1VFN2

3 MHz MC68HC11K1VFN3 4 MHz MC68HC11K1VFN4

–40 ° to + 125 ° C $DD No ROM 2 MHz MC68HC11K1MFN2

3 MHz MC68HC11K1MFN3 4 MHz MC68HC11K1MFN4

–40 ° to + 85 ° C $DC No ROM, No EEPROM 2 MHz MC68HC11K0CFN2

3 MHz MC68HC11K0CFN3 4 MHz MC68HC11K0CFN4

–40 ° to + 105 ° C $DC No ROM, No EEPROM 2 MHz MC68HC11K0VFN2

3 MHz MC68HC11K0VFN3 4 MHz MC68HC11K0VFN4

–40 ° to + 125 ° C $DC No ROM, No EEPROM 2 MHz MC68HC11K0MFN2

3 MHz MC68HC11K0MFN3 4 MHz MC68HC11K0MFN4

–40 ° to + 85 ° C $DF OTPROM 2 MHz MC68HC711K4CFN2

3 MHz MC68HC711K4CFN3 4 MHz MC68HC711K4CFN4

–40 ° to + 105 ° C $DF OTPROM 2 MHz MC68HC711K4VFN2

3 MHz MC68HC711K4VFN3 4 MHz MC68HC711K4VFN4

–40 ° to + 125 ° C $DF OTPROM 2 MHz MC68HC711K4MFN2

3 MHz MC68HC711K4MFN3 4 MHz MC68HC711K4MFN4

80-Pin QFP

(14 mm X 14

mm)

–40 ° to + 85 ° C $DF BUFFALO ROM 4 MHz MC68HC11K4BCFU4 –40 ° to + 85 ° C $DD No ROM 2 MHz MC68HC11K1CFU2

3 MHz MC68HC11K1CFU3 4 MHz MC68HC11K1CFU4

–40 ° to + 105 ° C $DD No ROM 2 MHz MC68HC11K1VFU2

3 MHz MC68HC11K1VFU3 4 MHz MC68HC11K1VFU4

–40 ° to + 85 ° C $DC No ROM, No EEPROM 2 MHz MC68HC11K0CFU2

3 MHz MC68HC11K0CFU3 4 MHz MC68HC11K0CFU4

–40 ° to + 105 ° C $DC No ROM, No EEPROM 2 MHz MC68HC11K0VFU2

3 MHz MC68HC11K0VFU3 4 MHz MC68HC11K0VFU4

MOTOROLA M68HC11 K Series 2 MC68HC11KTS/D

Table 1 Standard Device Ordering Information (Continued)

Package Temperature CONFIG Description Frequency MC Order Number

84-Pin CLCC

(Windowed)

–40 ° to + 85 ° C $DF EPROM 2 MHz MC68HC711K4CFS2

3 MHz MC68HC711K4CFS3 4 MHz MC68HC711K4CFS4

–40 ° to + 105 ° C $DF EPROM 2 MHz MC68HC711K4VFS2

3 MHz MC68HC711K4VFS3 4 MHz MC68HC711K4VFS4

–40 ° to + 125 ° C $DF EPROM 2 MHz MC68HC711K4MFS2

3 MHz MC68HC711K4MFS3 4 MHz MC68HC711K4MFS4

Table 2 Extended Voltage (3.0 Vdc to 5.5 Vdc) Device Ordering Information

Package Temperature Description Frequency MC Order Number

84-Pin PLCC –20 ° to + 70 ° C Custom ROM 1 MHz MC68L11K4FN1

3 MHz MC68L11K4FN3

No ROM 1 MHz MC68L11K1FN1

3 MHz MC68L11K1FN3

No ROM, No EEPROM 1 MHz MC68L11K0FN1

3 MHz MC68L11K0FN3

Custom ROM, No EEPROM 1 MHz MC68L11K3FN1

3 MHz MC68L11K3FN3

80-Pin QFP –20 ° to + 70 ° C Custom ROM 1 MHz MC68L11K4FU1

3 MHz MC68L11K4FU3

No ROM 1 MHz MC68L11K1FU1

3 MHz MC68L11K1FU3

No ROM, No EEPROM 1 MHz MC68L11K0FU1

3 MHz MC68L11K0FU3

Custom ROM, No EEPROM 1 MHz MC68L11K3FU1

3 MHz MC68L11K3FU3

M68HC11 K Series MOTOROLA MC68HC11KTS/D 3

Table 3 Custom ROM Device Ordering Information

Package Temperature Description Frequency MC Order Number

84-Pin PLCC –40 ° to + 85 ° C Custom ROM 2 MHz MC68HC11K4CFN2

3 MHz MC68HC11K4CFN3 4 MHz MC68HC11K4CFN4

–40 ° to + 105 ° C Custom ROM 2 MHz MC68HC11K4VFN2

3 MHz MC68HC11K4VFN3 4 MHz MC68HC11K4VFN4

–40 ° to + 125 ° C Custom ROM 2 MHz MC68HC11K4MFN2

3 MHz MC68HC11K4MFN3 4 MHz MC68HC11K4MFN4

–40 ° to + 85 ° C Custom ROM, No EEPROM 2 MHz MC68HC11K3CFN2

3 MHz MC68HC11K3CFN3 4 MHz MC68HC11K3CFN4

–40 ° to + 105 ° C Custom ROM, No EEPROM 2 MHz MC68HC11K3VFN2

3 MHz MC68HC11K3VFN3 4 MHz MC68HC11K3VFN4

–40 ° to + 125 ° C Custom ROM, No EEPROM 2 MHz MC68HC11K3MFN2

3 MHz MC68HC11K3MFN3 4 MHz MC68HC11K3MFN4

80-Pin QFP –40 ° to + 85 ° C Custom ROM 2 MHz MC68HC11K4CFU2

3 MHz MC68HC11K4CFU3 4 MHz MC68HC11K4CFU4

–40 ° to + 105 ° C Custom ROM 2 MHz MC68HC11K4VFU2

3 MHz MC68HC11K4VFU3 4 MHz MC68HC11K4VFU4

–40 ° to + 85 ° C Custom ROM, No EEPROM 2 MHz MC68HC11K3CFU2

3 MHz MC68HC11K3CFU3 4 MHz MC68HC11K3CFU4

–40 ° to + 105 ° C Custom ROM, No EEPROM 2 MHz MC68HC11K3VFU2

3 MHz MC68HC11K3VFU3 4 MHz MC68HC11K3VFU4

MOTOROLA M68HC11 K Series 4 MC68HC11KTS/D

PH0/PW1 PH1/PW2 PH2/PW3 PH3/PW4

PH4/CSIO PH5/CSGP1 PH6/CSGP2

PH7/CSPROG

TEST16

XIRQ

PPE

TEST15

TEST14

PG7/R/W

PG6 PG5/XA18 28 PG4/XA17 PG3/XA16 PG2/XA15 PG1/XA14

PB1/ADDR9

PB3/ADDR11

PB2/ADDR10

PB0/ADDR8

11 12 13 14 15 16 17 18 19

22 23 24

25 26

29 30 31 32

33343536373839

PB6/ADDR14

PB4/ADDR12

PB5/ADDR13

654

PB7/ADDR15

PA0/IC3

PA2/IC1

PA1/IC2

838281

MC68HC11K SERIES

4041424344

PA3/OC5/IC4/OC1

PA4/OC4/OC1

PA5/OC3/OC1

PA6/OC2/OC1

PA7/PAI/OC1

787776

464748

505152

PD4/SCK

PD5/SS

PD3/MOSI

PD2/MISO

PD1/TxD

PD0/RxD

MODA/LIR

MODB/V

RESET

XTAL

EXTAL

XOUT

VDD

VSS

PC7/DATA7

PC6/DATA6

PC5/DATA5

PC4/DATA4

59 58 PC3/DATA3

PC2/DATA2

PC1/DATA1

PC0/DATA0

IRQ

STBY

PG0/XA13

1. Pins 20, 22, and 25 are used only during factory testing and should not be connected to external circuitry. applies only to devices with EPROM.

2. V

PPE

PE6/AN6

PE7/AN7

PE5/AN5

PE4/AN4

PE2/AN2

PE3/AN3

PE1/AN1

PE0/AN0

PF7/ADDR7

PF6/ADDR6

PF5/ADDR5

PF4/ADDR4

PF3/ADDR3

PF2/ADDR2

PF1/ADDR1

PF0/ADDR0

Figure 1 Pin Assignments for 84-Pin PLCC/CLCC

M68HC11 K Series MOTOROLA MC68HC11KTS/D 5

STBY

PD3/MOSI

PD4/SCK

PD5/SS

PA7/PAI/OC1 PA6/OC2/OC1 PA5/OC3/OC1 PA4/OC4/OC1

PA3/OC5/IC4/OC1

PA2/IC1 PA1/IC2 PA0/IC3

PB7/ADDR15 PB6/ADDR14 PB5/ADDR13

PB4/ADDR12 PB3/ADDR11 PB2/ADDR10

PB1/ADDR9

PD0/RxD

PD2/MISO

PD1/TxD

80 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

21222324252627

MODA/LIR

RESET

77767574737071

XTALEEXTAL

MODB/V

MC68HC11K SERIES

282930

VSSPC7/DATA7

313233

PC6/DATA6

PC5/DATA5

PC4/DATA4

686766

343536

PC1/DATA1

PC3/DATA3

PC2/DATA2

636261

383940

PC0/DATA0

IRQ

60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 PE5/AN5 43 42 41

PF0/ADDR0 PF1/ADDR1 PF2/ADDR2 PF3/ADDR3 PF4/ADDR4 PF5/ADDR5 PF6/ADDR6 PF7/ADDR7 AV

VRL PE0/AN0

PE1/AN1 PE2/AN2 PE3/AN3 PE4/AN4

PE6/AN6 PE7/AN7 AV

PG6

PG7/R/W

PG5/XA18

PG4/XA17

PG3/XA16

PG2/XA15

PG1/XA14

PG0/XA13

PH0/PW1

PH1/PW2

PB0/ADDR8

PH3/PW4

PH2/PW3

PH4/CSIO

PH5/CSGP1

XIRQ

PH6/CSGP2

PH7/CSPROG

Figure 2 Pin Assignments for 80-Pin 14 mm X 14 mm TQFP

MOTOROLA M68HC11 K Series 6 MC68HC11KTS/D

XTAL

EXTAL

*XOUT

MODA/

LIR

MODB/ V

STBY

PA7

PA6 PA5 PA4 PA3 PA2 PA1 PA0

PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0

PF7 PF6 PF5 PF4 PF3 PF2 PF1 PF0

PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0

PORT E

PORT H

PORT D

PORT G

IRQ XIRQ/V RESET

RL PE7 PE6 PE5 PE4 PE3 PE2 PE1 PE0

DD V

PH7 PH6 PH5 PH4

PH3 PH2 PH1 PH0

PD5 PD4 PD3 PD2

PD1 PD0

PG7 PG6 PG5 PG4 PG3 PG2 PG1 PG0

PPE

INTERRUPT

LOGIC

A/D

CONVERTER

AN7 AN6 AN5 AN4 AN3 AN2 AN1 AN0

CHIP

SELECTS

CSPROG

CSGP2 CSGP1

CSIO

PW4 PW3

PWM

PW2 PW1

SCK

SPI

MOSI MISO

TxD

SCI

RxD

MEMORY

EXPANSION

XA18 XA17 XA16 XA15 XA14 XA13

PORT H DDR

PORT D DDR

PORT G DDR

PORT A

PORT A DDR

PORT B

PORT B DDRPORT F DDR

PORT F

PORT C

PORT C DDR

PAI/OC1

ACCUMULATOR

OC2/OC1 OC3/OC1 OC4/OC1 OC5/IC4/OC1 IC1 IC2 IC3

ADDR15 ADDR14 ADDR13 ADDR12 ADDR11 ADDR10 ADDR9 ADDR8

ADDR7 ADDR6 ADDR5 ADDR4 ADDR3 ADDR2 ADDR1 ADDR0

DATA7 DATA6 DATA5 DATA4 DATA3 DATA2 DATA1 DATA0

R/W

PULSE

ADDRESS BUSDATA BUS

TIMER

SYSTEM

CPU

MODE

CONTROL

COP

PERIODIC

INTERRUPT

BYTES

768

RAM

CLOCK

LOGIC

KBYTES

ROM/ EPROM (K3, K4)

KBYTES

ROM/ EPROM (K0, K1)

OSCILLATOR

640

BYTES

EEPROM

(K1, K4)

KBYTES

EEPROM

(K0, K3)

*XOUT pin omitted on 80-pin QFP.

Figure 3 M68HC11 K-Series Block Diagram

M68HC11 K Series MOTOROLA MC68HC11KTS/D 7

Section Page

1 Features 2 Operating Modes

2.1 Single-Chip Operating Mode .....................................................................................................11

2.2 Expanded Operating Mode .......................................................................................................11

2.3 Bootstrap Mode .........................................................................................................................11

2.4 Special Test Mode .....................................................................................................................11

2.5 Mode Selection ..........................................................................................................................11

3 On-Chip Memory

3.1 Memory Map and Register Block ..............................................................................................14

3.2 RAM ..........................................................................................................................................17

3.3 ROM/EPROM ............................................................................................................................18

3.4 EEPROM ...................................................................................................................................22

3.5 Configuration Control Register (CONFIG) .................................................................................24

3.6 Security Feature ........................................................................................................................25

4 Memory Expansion and Chip Selects

4.1 Memory Expansion ....................................................................................................................27

4.2 Overlap Guidelines ....................................................................................................................30

4.3 Chip Selects ..............................................................................................................................30

4.3.1 Program Chip Select (CSPROG) ...................................................................................31

4.3.2 I/O Chip Select (CSIO) ...................................................................................................31

4.3.3 General-Purpose Chip Selects (CSGP1, CSGP2) .........................................................32

4.3.4 Chip Select Priorities ......................................................................................................32

4.3.5 Chip Select Control Registers ........................................................................................32

4.3.6 Examples of Memory Expansion Using Chip Selects .....................................................35

5 Resets and Interrupts 6 Parallel Input/Output 7 Serial Communications Interface 8 Serial Peripheral Interface 9 Analog-to-Digital Converter 10 Main Timer

10.1 Real-Time Interrupt ...................................................................................................................70

11 Pulse Accumulator 12 Pulse-Width Modulation Timer

12.1 PWM Boundary Cases ..............................................................................................................78

38 42 49 56 60

MOTOROLA M68HC11 K Series 8 MC68HC11KTS/D

REGISTER INDEX

CFORC Timer Compare Force $000B 66 CONFIG System Configuration Register $003F 25 COPRST Arm/Reset COP Timer Circuitry $003A 40 CSCSTR Chip Select Clock Stretch $005A 33 CSCTL Chip Select Control $005B 32

DDRA Data Direction Register for Port A $0001 42 DDRB Data Direction Register for Port B $0002 43 DDRF Data Direction Register for Port F $0003 46 DDRG Data Direction Register for Port G $007F 47 DDRH Data Direction Register for Port H $007D 46

EPROG EPROM Programming Control $002B 19

GPCS1A General-Purpose Chip Select 1 Address $005C 33 GPCS1C General-Purpose Chip Select 1 Control $005D 34 GPCS2A General-Purpose Chip Select 2 Address $005E 34 GPCS2C General-Purpose Chip Select 2 Control $005F 34

HPRIO Highest Priority I-Bit Interrupt and Miscellaneous $003C 11, 40

INIT RAM and Register Mapping $003D 18 INIT2 EEPROM Mapping $0037 24

MMSIZ Memory Mapping Size $0056 28 MMWBR Memory Mapping Window Base $0057 29

OC1D Output Compare 1 Data $000D 66 OC1M Output Compare 1 Mask $000C 66 OPT2 System Configuration Options 2 $0038 12, 44, 59 OPTION System Configuration Options $0039 39

PACNT Pulse Accumulator Counter $0027 73 PACTL Pulse Accumulator Control $0026 73 PGAR Port G Assignment $002D 28, 47 PORTA Port A Data $0000 42 PORTB Port B Data $0004 43 PORTC Port C Data $0006 43 PORTE Port E Data $000A 46 PORTF Port F Data $0005 46 PORTG Port G Data $007E 47 PORTH Port H Data $007C 46 PPAR Port Pull-Up Assignment $002C 48 PPROG EEPROM Programming Control $003B 22 PWCLK Pulse-Width Modulation Clock Select $0060 62, 76

M68HC11 K Series MOTOROLA MC68HC11KTS/D 9

PWCNT[4:1] Pulse-Width Modulation Timer Counter 1 to 4 $0064–$0067 77 PWDTY[4:1] Pulse-Width Modulation Timer Duty Cycle 1 to 4 $006C–$006F 78 PWEN Pulse-Width Modulation Timer Enable $0063 77 PWPER[4:1] Pulse-Width Modulation Timer Period 1 to 4 $0068–$006B 78 PWPOL Pulse-Width Modulation Timer Polarity $0061 62, 76 PWSCAL Pulse-Width Modulation Timer Prescaler $0062 63, 77

SCBDH/L SCI Baud Rate Control High/Low $0070, $0071 52 SCCR1 SCI Control 1 $0072 45, 52 SCCR2 SCI Control 2 $0073 53 SCSR1 SCI Status Register 1 $0074 54 SCSR2 SCI Status Register 2 $0075 55 SPCR Serial Peripheral Control $0028 45 SPCR Serial Peripheral Control Register $0028 57 SPDR SPI Data $002A 58 SPSR Serial Peripheral Status Register $0029 58

TCNT Timer Count $000E, $000F 66 TCTL2 Timer Control 2 $0021 67 TFLG2 Timer Interrupt Flag 2 $0025 69, 72 TI4/O5 Timer Input Capture 4/Output Compare 5 $001E–$001F 67 TMSK1 Timer Interrupt Mask 1 $0022 68 TMSK2 Timer Interrupt Mask 2 $0024 68, 72 TOC1–TOC4 Timer Output Compare $0016–$001D 67

MOTOROLA M68HC11 K Series 10 MC68HC11KTS/D

2 Operating Modes

The M68HC11 K-series MCUs have four modes of operation that directly affect the address space. These modes are described as follows.

2.1 Single-Chip Operating Mode

In single-chip operating mode, the M68HC11 K-series MCUs are stand-alone microcontrollers with no external address or data bus. Addressing range is 64 Kbytes and is limited to on-chip resources. Refer to the memory map diagram.

2.2 Expanded Operating Mode

In expanded operating mode, the MCU has a 64 Kbyte address range and, using the expansion bus, can access external resources within the 64 Kbyte space. This space includes the same on-chip memory addresses used for single-chip mode, in addition to addressing capabilities for external peripheral and memory devices. Addressing beyond 64 Kbytes is available only in expanded mode using the onchip, register-based memory mapping logic. The additional address lines for memory expansion (XA[18:13]) are implemented as alternate functions of port G. The expansion bus (external address and data buses) is made up of ports B, C, and F, and the R/W order address bits are output on the port B pins, low order address bits on the port F pins, and the data bus on port C. Refer to the memory map diagram.

2.3 Bootstrap Mode

Bootstrap mode allows special-purpose programs to be loaded into internal RAM. The MCU contains 448 bytes of bootstrap ROM which is enabled and present in the memory map only when the device is in bootstrap mode. The bootstrap ROM contains a program which initializes the SCI and allows the user to download up to 768 bytes of code into on-chip RAM. After a four-character delay, or after receiving the character for address $037F, control passes to the loaded program at $0080. Refer to the memory map diagram. Refer also to Application Note

M68HC11 Bootstrap Mode

signal. In expanded operating mode, high

(AN1060/D).

2.4 Special Test Mode

Special test mode is used primarily for factory testing. In this operating mode, ROM/EPROM is removed from the address space and interrupt vectors are accessed externally at $BFC0–$BFFF.

2.5 Mode Selection

Operating modes are selected by a combination of logic levels applied to two input pins (MODA and MODB) during reset. The logic level present (at the rising edge of reset) on these inputs is reflected in bits in the HPRIO register. After reset, the operating mode may be changed according to the table contained in the description of the HPRIO register.

The functions of two features that are enabled by bits in OPT2 register are dependent upon the operating mode. LIR driven is enabled with the LIRDV bit. Internal read visibility/not E is enabled with the IRVNE bit. Refer to the OPT2 register description that follows HPRIO.

HPRIO —Highest Priority I-Bit Interrupt and Miscellaneous $003C

Bit 7 654321Bit 0

RBOOT* SMOD* MDA* PSEL4 PSEL3 PSEL2 PSEL1 PSEL0

RESET: 0 0 0 0 0 1 1 0 Single Chip

00100110Expanded 11000110Bootstrap 01100110Special Test

*The reset values of RBOOT, SMOD, and MDA depend on the mode selected at power up.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 11

RBOOT — Read Bootstrap ROM/EPROM

Valid only when SMOD is set (bootstrap or special test mode). Can only be written in special modes.

0 = Bootstrap ROM disabled and not in map 1 = Bootstrap ROM enabled and in map at $BE00–$BFFF

SMOD and MDA —Special Mode Select and Mode Select A

These two bits can be read at any time. They can be written anytime in special modes. MDA can only be written once in normal modes. SMOD cannot be set once it has been cleared.

Inputs Latched at Reset

MODB MODA Mode SMOD MDA

1 0 Single Chip 0 0 1 1 Expanded 0 1 0 0 Bootstrap 1 0 0 1 Special Test 1 1

PSEL[4:0] —Priority Select Bits [4:0]

Refer to 5 Resets and Interrupts.

OPT2 — System Configuration Options 2 $0038

Bit 7 654321Bit 0

LIRDV CWOM — IRVNE* LSBF SPR2 XDV1 XDV0

RESET: 0 0 0 — 0 0 0 0

*Can be written only once in normal modes. Can be written anytime in special modes.

LIRDV —LIR Driven

In single-chip and bootstrap modes, this bit has no meaning or effect. The LIR pin is normally configured for wired-OR operation (only pulls low). In order to detect consecutive instructions in a high-speed application, this signal can be made to drive high for a short time to prevent false triggering.

0 = LIR not driven high out of reset 1 = LIR driven high for one quarter cycle to reduce transition time

CWOM —Port C Wired-OR Mode

Refer to 6 Parallel Input/Output.

Bit 5 —Not implemented

Always read zero

IRVNE —Internal Read Visibility/Not E

IRVNE can be written only once in normal modes (SMOD = 0). In special modes IRVNE can be written any time. In special test mode, IRVNE is reset to one. In all other modes, IRVNE is reset to zero. In expanded modes this bit determines whether IRV is on or off.

0 = No internal read visibility on external bus 1 = Data from internal reads is driven out the external data bus.

In single-chip modes this bit determines whether the E clock drives out from the chip.

0 = E is driven out from the chip. 1 = E pin is driven low. Refer to the following table.

Mode IRVNE Out

of Reset

Single Chip 0 On Off E Once Expanded 0 On Off IRV Once Boot 0 On Off E Anytime Special Test 1 On On IRV Anytime

E Clock Out

of Reset

IRV Out of

Reset

IRVNE

Affects Only

IRVNE Can

Be Written

MOTOROLA M68HC11 K Series 12 MC68HC11KTS/D

LSBF —LSB First Enable

Refer to 8 Serial Peripheral Interface.

SPR2 —SPI Clock Rate Select

Refer to 8 Serial Peripheral Interface.

XDV[1:0] —XOUT Clock Divide Select

Controls the frequency of the clock driven out of the XOUT pin

XDV [1:0]

0 0 1 8 MHz 12 MHz 16 MHz 0 1 4 2 MHz 3 MHz 4 MHz 1 0 6 1.3 MHz 2 MHz 2.7 MHz 1 1 8 1 MHz 1.5 MHz 2 MHz

XOUT = EXTAL

Divided By

Frequency at

EXTAL = 8 MHz

Frequency at

EXTAL = 12 MHz

Frequency at

EXTAL = 16 MHz

M68HC11 K Series MOTOROLA MC68HC11KTS/D 13

3 On-Chip Memory

In general, K-series MCUs have 768 bytes RAM, 640 bytes EEPROM, and 24 Kbytes ROM/EPROM. Some devices in the series have portions of their memory resources disabled. Some have ROM and some have EPROM replacing ROM. The following paragraphs describe the memory systems of devices in the series.

3.1 Memory Map and Register Block

The INIT, INIT2, and CONFIG registers control the presence and location of the registers, RAM, EEPROM, and ROM/EPROM in the 64 Kbyte CPU address space. The 128-byte register block originates at $0000 after reset and can be placed at any 4 Kbyte boundary ($x000) after reset by writing an appropriate value to the INIT register. Refer to Figure 4.

$0000

EXT

$1000

EXT

$A000

$FFFF

SINGLE

CHIP

NOTE: ROM/EPROM can be enabled in special test mode by setting ROMON bit in the config register after reset.

EXPANDED

BOOTSTRAP

EXT

SPECIAL

TEST

128-BYTE REGISTER BLOCK

x000

(CAN BE REMAPPED TO ANY

x07F

4K PAGE BY THE INIT REGISTER)

x080

768 BYTES RAM (CAN BE REMAPPED TO ANY 4K PAGE BY THE INIT REGISTER)

x37F

xD00

RESERVED (SPECIAL TEST MODE ONLY)

xD7F

640 BYTES EEPROM

xD80

(CAN BE REMAPPED TO ANY 4K PAGE BY THE INIT2 REGISTER)

xFFF

A000

24 KBYTES ROM/EPROM (CAN BE REMAPPED TO $2000–$7FFF OR $A000–$FFFF BY THE CONFIG REGISTER)

FFFF

BOOT ROM

BE00

(ONLY PRESENT IN BOOTSTRAP MODE)

SPECIAL MODE

BFC0

INTERRUPT

BFFF

VECTORS

FFC0

NORMAL MODE INTERRUPT

FFFF

VECTORS

Figure 4 Memory Map

MOTOROLA M68HC11 K Series 14 MC6HC11KTS/D

INIT = $00

INIT = $10

INIT = $04

REG @ $0000 RAM @ $0080

$0000

BLOCK

$007F

$0080

RAM

$02FF

$0300

RAM

$037F

REG @ $0000 RAM @ $1000

$0000

BLOCK

$007F

$1000

RAM

$107F

$1080

RAM

$12FF

Figure 5 RAM and Register Mapping

REG @ $4000

RAM @ $0000

$0000

RAM

A $007F $0080

RAM

$02FF

$4000

BLOCK

$407F

Table 4 M68HC11 K Series Register and Control Bit Assignments

(Can be remapped to any 4-Kbyte boundary)

Bit 7 654321Bit 0 $0000 PA7 PA6 PA5 PA4 PA3 PA2 PA1 PA0 PORTA $0001 DDA7 DDA6 DDA5 DDA4 DDA3 DDA2 DDA1 DDA0 DDRA $0002 DDB7 DDB6 DDB5 DDB4 DDB3 DDB2 DDB1 DDB0 DDRB $0003 DDF7 DDF6 DDF5 DDF4 DDF3 DDF2 DDF1 DDF0 DDRF $0004 PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0 PORTB $0005 PF7 PF6 PF5 PF4 PF3 PF2 PF1 PF0 PORTF $0006 PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0 PORTC $0007 DDC7 DDC6 DDC5 DDC4 DDC3 DDC2 DDC1 DDC0 DDRC $0008 0 0 PD5 PD4 PD3 PD2 PD1 PD0 PORTD $0009 0 0 DDD5 DDD4 DDD3 DDD2 DDD1 DDD0 DDRD

$000A PE7 PE6 PE5 PE4 PE3 PE2 PE1 PE0 PORTE $000B FOC1 FOC2 FOC3 FOC4 FOC5 0 0 0 CFORC $000C OC1M7 OC1M6 OC1M5 OC1M4 OC1M3 0 0 0 OC1M $000D OC1D7 OC1D6 OC1D5 OC1D4 OC1D3 0 0 0 OC1D $000E Bit 15 14 13 12 11 10 9 Bit 8 TCNT (High) $000F Bit 7 654321Bit 0 TCNT (Low)

$0010 Bit 15 14 13 12 11 10 9 Bit 8 TIC1 (High) $0011 Bit 7 654321Bit 0 TIC1 (Low) $0012 Bit 15 14 13 12 11 10 9 Bit 8 TIC2 (High) $0013 Bit 7 654321Bit 0 TIC2 (Low) $0014 Bit 15 14 13 12 11 10 9 Bit 8 TIC3 (High)

M68HC11 K Series MOTOROLA MC6HC11KTS/D 15

Table 4 M68HC11 K Series Register and Control Bit Assignments (Continued)

(Can be remapped to any 4-Kbyte boundary)

Bit 7 654321Bit 0 $0015 Bit 7 654321Bit 0 TIC3 (Low) $0016 Bit 15 14 13 12 11 10 9 Bit 8 TOC1(High) $0017 Bit 7 654321Bit 0 TOC1 (Low) $0018 Bit 15 14 13 12 11 10 9 Bit 8 TOC2 (High) $0019 Bit 7 654321Bit 0 TOC2 (Low)

$001A Bit 15 14 13 12 11 10 9 Bit 8 TOC3 (High) $001B Bit 7 654321Bit 0 TOC3 (Low) $001C Bit 15 14 13 12 11 10 9 Bit 8 TOC4 (High) $001D Bit 7 654321Bit 0 TOC4 (Low) $001E Bit 15 14 13 12 11 10 9 Bit 8 TI4/O5 (High) $001F Bit 7 654321Bit 0 TI4/O5 (Low)

$0020 OM2 OL2 OM3 OL3 OM4 OL4 OM5 OL5 TCTL1 $0021 EDG4B EDG4A EDG1B EDG1A EDG2B EDG2A EDG3B EDG3A TCTL2 $0022 OC1I OC2I OC3I OC4I I4/O5I IC1I IC2I IC3I TMSK1 $0023 OC1F OC2F OC3F OC4F I4/O5F IC1F IC2F IC3F TFLG1 $0024 TOI RTII PAOVI PAII 0 0 PR1 PR0 TMSK2 $0025 TOF RTIF PAOVF PAIF 0000TFLG2 $0026 0 PAEN PAMOD PEDGE 0 I4/O5 RTR1 RTR0 PACTL $0027 Bit 7 654321Bit 0 PACNT $0028 SPIE SPE DWOM MSTR CPOL CPHA SPR1 SPR0 SPCR $0029 SPIF WCOL 0 MODF 0 0 0 Bit 0 SPSR

$002A Bit 7 654321Bit 0 SPDR $002B MBE 0 ELAT EXCOL EXROW T1 T0 EPGM EPROG* $002C 0000HPPUE GPPUE FPPUE BPPUE PPAR $002D 0 0 PGAR5 PGAR4 PGAR3 PGAR2 PGAR1 PGAR0 PGAR $002E Reserved $002F Reserved

$0030 CCF 0 SCAN MULT CD CC CB CA ADCTL $0031 Bit 7 654321Bit 0 ADR1 $0032 Bit 7 654321Bit 0 ADR2 $0033 Bit 7 654321Bit 0 ADR3 $0034 Bit 7 654321Bit 0 ADR4 $0035 BULKP LVPEN BPRT4 PTCON BPRT3 BPRT2 BPRT1 BPRT0 BPROT $0036 Reserved $0037 EE3 EE2 EE1 EE0 0000INIT2 $0038 LIRDV CWOM 0 IRVNE LSBF SPR2 XDV1 XDV0 OPT2 $0039 ADPU CSEL IRQE DLY CME FCME CR1 CR0 OPTION

$003A Bit 7 654321Bit 0 COPRST $003B ODD EVEN LVPI BYTE ROW ERASE EELAT EEPGM PPROG $003C RBOOT SMOD MDA PSEL4 PSEL3 PSEL2 PSEL1 PSEL0 HPRIO $003D RAM3 RAM2 RAM1 RAM0 REG3 REG2 REG1 REG0 INIT $003E TILOP 0 OCCR CBYP DISR FCM FCOP 0 TEST1 $003F ROMAD 1 CLKX PAREN NOSEC NOCOP ROMON EEON CONFIG $0040 Reserved

to $0055 Reserved $0056 MXGS2 MXGS1 W2SZ1 W2SZ0 0 0 W1SZ1 W1SZ0 MMSIZ $0057 W2A15 W2A14 W2A13 0 W1A15 W1A14 W1A13 0 MMWBR

MOTOROLA M68HC11 K Series 16 MC6HC11KTS/D

Table 4 M68HC11 K Series Register and Control Bit Assignments (Continued)

(Can be remapped to any 4-Kbyte boundary)

Bit 7 654321Bit 0 $0058 0 X1A18 X1A17 X1A16 X1A15 X1A14 X1A13 0 MM1CR $0059 0 X2A18 X2A17 X2A16 X2A15 X2A14 X2A13 0 MM2CR

$005A IOSA IOSB GP1SA GP1SB GP2SA GP2SB PCSA PCSB CSCSTR $005B IOEN IOPL IOCSA IOSZ GCSPR PCSEN PCSZA PCSZB CSCTL $005C G1A18 G1A17 G1A16 G1A15 G1A14 G1A13 G1A12 G1A11 GPCS1A $005D G1DG2 G1DPC G1POL G1AV G1SZA G1SZB G1SZC G1SZD GPCS1C $005E G2A18 G2A17 G2A16 G2A15 G2A14 G2A13 G2A12 G2A11 GPCS2A $005F 0 G2DPC G2POL G2AV G2SZA G2SZB G2SZC G2SZD GPCS2C

$0060 CON34 CON12 PCKA2 PCKA1 0 PCKB3 PCKB2 PCKB1 PWCLK $0061 PCLK4 PCLK3 PCLK2 PCLK1 PPOL4 PPOL3 PPOL2 PPOL1 PWPOL $0062 Bit 7 654321Bit 0 PWSCAL $0063 TPWSL DISCP 0 0 PWEN4 PWEN3 PWEN2 PWEN1 PWEN $0064 Bit 7 654321Bit 0 PWCNT1 $0065 Bit 7 654321Bit 0 PWCNT2 $0066 Bit 7 654321Bit 0 PWCNT3 $0067 Bit 7 654321Bit 0 PWCNT4 $0068 Bit 7 654321Bit 0 PWPER1 $0069 Bit 7 654321Bit 0 PWPER2

$006A Bit 7 654321Bit 0 PWPER3 $006B Bit 7 654321Bit 0 PWPER4 $006C Bit 7 654321Bit 0 PWDTY1 $006D Bit 7 654321Bit 0 PWDTY2 $006E Bit 7 654321Bit 0 PWDTY3 $006F Bit 7 654321Bit 0 PWDTY4 $0070 BTST BSPL 0 SBR12 SBR11 SBR10 SBR9 SBR8 SCBDH $0071 SBR7 SBR6 SBR5 SBR4 SBR3 SBR2 SBR1 SBR0 SCBDL $0072 LOOPS WOMS 0 M WAKE ILT PE PT SCCR1 $0073 TIE TCIE RIE ILIE TE RE RWU SBK SCCR2 $0074 TDRE TC RDRF IDLE OR NF FE PF SCSR1 $0075 0000000RAFSCSR2 $0076 R8 T8 000000SCDRH $0077 R7/T7 R6/T6 R5/T5 R4/T4 R3/T3 R2/T2 R1/T1 R0/T0 SCDRL $0078 Reserved

to $007B Reserved $007C PH7 PH6 PH5 PH4 PH3 PH2 PH1 PH0 PORTH $007D DDH7 DDH6 DDH5 DDH4 DDH3 DDH2 DDH1 DDH0 DDRH $007E PG7 PG6 PG5 PG4 PG3 PG2 PG1 PG0 PORTG $007F DDG7 DDG6 DDG5 DDG4 DDG3 DDG2 DDG1 DDG0 DDRG

*MC68HC711K4 only.

3.2 RAM

All members of the M68HC11 K series have 768 bytes of static RAM. The RAM can be mapped to any 4-Kbyte boundary. Upon reset, the RAM is mapped at $0080–$037F. The registers are also mapped to this 4-Kbyte boundary. In previous versions of the M68HC11 devices the register block being mapped to the same boundary would cause the portion of RAM overlapped by the register block to be lost. However, a new RAM remapping feature has been added which automatically allows all of the RAM to be accessible even if the register block overlaps the RAM. Because the registers are located in the same

M68HC11 K Series MOTOROLA MC6HC11KTS/D 17

4-Kbyte boundary after reset, 128 bytes of the RAM are located at $0300 to $037F. Remapping is accomplished by writing appropriate values to the INIT register. Refer to the register and RAM mapping examples following the memory map diagram.

When power is removed from the MCU, RAM contents may be preserved using the MODB/V A power source (2.0 Vdc –V

) applied to this pin protects all 768 bytes of RAM.

INIT — RAM and Register Mapping $003D

Bit 7 654321Bit 0

RAM3 RAM2 RAM1 RAM0 REG3 REG2 REG1 REG0

RESET: 0000000 0

Can be written only once in first 64 cycles out of reset in normal modes or at any time in special mode.

RAM[3:0] —Internal RAM Map Position

These bits determine the upper four bits of the RAM address. At reset RAM is mapped to $0000. Normally the RAM would be mapped at $0000–$02FF (768 bytes). However, the register block overlaps the first 128 bytes of RAM, causing them to be remapped to $0300–$037F. Refer to Figure 4 and Fig- ure 5.

REG[3:0] —128-Byte Register Block Map Position

These bits determine the upper four bits of the register block starting address. At reset registers are mapped to $0000 and overlap the first 128 bytes of RAM, causing them to be remapped to $0300– $037F. Refer to Figure 4 and Figure 5.

3.3 ROM/EPROM

Standard devices have 24 kbytes of EPROM (OTPROM in a non-windowed package). Custom ROM devices have a 24-Kbyte ROM array that is mask programmed at the factory to customer specifications. The MC68HC11K0, MC68HC11K1, MC68L11K0, and MC68L11K1 have no ROM/EPROM. Refer to the ordering information tables.

STBY

pin.

The ROMAD and ROMON control bits in the CONFIG register control the position and presence of ROM/EPROM in the memory map. The ROM/EPROM can be mapped at $2000–$7FFF or $A000– $FFFF. If it is mapped to $A000–$FFFF, vector space is included. In single-chip mode the ROM/ EPROM is forced to $A000–$FFFF (ROMAD = 1) and enabled (ROMON = 1), regardless of the value in the CONFIG register. This ensures that there will be ROM/EPROM at the vector space. In special test mode, the ROMON bit is forced to zero so that the ROM/EPROM is removed from the memory map. Refer to Figure 4.

Programming EPROM requires an external 12.25 volt nominal power supply (V plied to the XIRQ

pin. Three methods are used to program and verify EPROM/OTPROM.

PPE

) that must be ap-

PPE

Normal EPROM/OTPROM programming can be accomplished in any operating mode. Normal programming is accomplished using the EPROM/OTPROM programming register (EPROG). The EPROG register enables the EPROM programming voltage, controls the latching of data to be programmed, and selects single- or multiple-byte programming.

To program the EPROM, complete the following steps using the EPROG register:

1. Set the ELAT bit in EPROG register. EELAT bit in PPROG must be cleared as it negates the function of the ELAT bit.

2. Write data to the desired address.

3. Turn on programming voltage to the EPROM array by setting the EPGM bit in EPROG register.

4. Delay for 2 ms or more, as appropriate.

5. Clear the EPGM bit in EPROG to turn off the programming voltage.

MOTOROLA M68HC11 K Series 18 MC6HC11KTS/D

6. Clear the EPROG register to reconfigure the EPROM address and data buses for normal operation.

In EPROM emulation mode (PROG mode), the EPROM/OTPROM is programmed as a stand-alone EPROM by adapting the MCU footprint to the 27C256-type EPROM and using an appropriate EPROM programmer. To put the MCU in PROG mode, pull the following pins low: MODA/LIR, MODB/V

RESET

, PA[2:0]. Refer to Figure 6.

STBY

In the third method, the EPROM is programmed by software while in the special test or bootstrap modes. User-developed software can be uploaded through the SCI, or a ROM resident EPROM programming utility can be used. To use the resident utility, bootload a three-byte program consisting of a single jump instruction to $BF00. $BF00 is the starting address of a resident EPROM programming utility. The utility program sets the X and Y index registers to default values, then receives programming data from an external host and programs it into EPROM. The value in IX determines programming delay time. The value in IY is a pointer to the first address in EPROM to be programmed (default = $A000).

When the utility program is ready to receive programming data, it sends the host the $FF character. Then it waits. When the host sees the $FF character, the EPROM programming data is sent, starting with the first location in the EPROM array. After the last byte to be programmed is sent and the corresponding verification data is returned, the programming operation is terminated by resetting the MCU.

Although the external 12.25 V programming voltage must be applied to the XIRQ/V EPROM programming, it should be equal to V should equal V

during normal operation also. The XIRQ/V

before verifying the data that was just programmed. It

pin has a high voltage detect circuit

PPE

pin during

PPE

that inhibits assertion of the ELAT bit when programming voltage is at low levels.

CAUTION

If the MCU is used in any operating mode while high voltage (12.25 V nominal) is present on the XIRQ

pin, the IRQ/CE pin must be pulled high to avoid acci-

PPE

dental programming or corruption of EPROM contents. After programming an EPROM location, IRQ

pin must also be pulled high before the address and data

are changed to program the next location.

EPROG — EPROM Programming Control $002B

Bit 7 654321Bit 0

MBE — ELAT EXCOL EXROW — — EPGM

RESET: 0000000 0

MBE —Multiple-Byte Programming Enable

0 = EPROM array configured for normal programming

1 = Program two bytes with the same data When multiple-byte programming is enabled, address bit 5 is considered a don't care so that bytes with address bit 5 = 0 and address bit 5 = 1 both get programmed. MBE can be read in any mode and always reads zero in normal modes. MBE can only be written in special modes.

Bit 6 —Not implemented

Always reads zero

ELAT —EPROM Latch Control

ELAT can be read any time. ELAT can be written any time except when EPGM = 1, then the write to ELAT will be disabled. When ELAT = 1, writes to EPROM cause address and data to be latched and the EPROM cannot be read.

0 = EPROM address and data bus configured for normal reads

1 = EPROM address and data bus configured for programming

M68HC11 K Series MOTOROLA MC6HC11KTS/D 19

EXCOL —Select Extra Columns

0 = User array selected

1 = User array is disabled and extra columns are accessed at bits [7:0]. Addresses use bits [11:5]

and bits [4:0] are don't care. EXCOL can only be read in special modes and always returns zero in normal modes. EXCOL can be written in special modes only.

EXROW —Select Extra Rows

0 = User array selected

1 = User array is disabled and two extra rows are available. Addresses use bits [5:0] and bits [11:6]

are don't care. EXROW can only be read in special modes and always returns zero in normal modes. EXROW can be written in special modes only.

Bits [2:1] —Not implemented

Always read zero

EPGM —EPROM Programming Voltage Enable

EPGM can be read any time and can only be written when ELAT = 1.

0 = Programming voltage to EPROM array disconnected

1 = Programming voltage to EPROM array connected

MOTOROLA M68HC11 K Series 20 MC6HC11KTS/D

EPROM MODE PIN CONNECTIONS

MCU PIN FUNCTIONS

EPROM

PIN FUNCTIONS

NOTE 4

NOTE 1

ADDR0 ADDR1 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 ADDR8 ADDR9 ADDR10 ADDR11 ADDR12 ADDR13 ADDR14

GND PA0/IC3 GND PA1/IC2 GND PA2/IC1

GND GND PA4/OC4/OC1 GND PA5/OC3/OC1 GND PA6/OC2/OC1 GND PA7/PAI/OC1 GND PG0/XA13 GND PG1/XA14 GND PG2/XA15 GND PG3/XA16 GND PG4/XA17 GND PG5/XA18 GND PG6 GND PG7/R/W GND PD0/RxD GND PD1/TxD GND GND GND GND

PF0/ADDR0

PF1/ADDR1 PF2/ADDR2 PF3/ADDR3 PF4/ADDR4 PF5/ADDR5 PF6/ADDR6 PF7/ADDR7 PB0/ADDR8 PB1/ADDR9

PB2/ADDR10

PB3/ADDR11 PB4/ADDR12 PB5/ADDR13 PB6/ADDR14

PA3/IC4/OC5/OC1

PD2/MISO PD3/MOSI

PD4/SCK

PD5/SS

ADDR0

ADDR1 ADDR2

ADDR3

ADDR4 ADDR5

ADDR6 ADDR7 ADDR8 ADDR9

ADDR10 ADDR11 ADDR12

ADDR13

ADDR14

INTERNAL

24 KBYTE

EPROM

MC68HC711K4

O0 O1 O2 O3 O4 O5 O6 O7

OE CE V V V

PP CC SS

PC0/DATA0 PC1/DATA1 PC2/DATA2 PC3/DATA3 PC4/DATA4 PC5/DATA5 PC6/DATA6 PC7/DATA7

PB7/ADDR15 IRQ XIRQ/V

PPE

PE0/AN0 PE1/AN1 PE2/AN2 PE3/AN3 PE4/AN4 PE5/AN5 PE6/AN6 PE7/AN7

PH1/PW2 PH2/PW3 PH3/PW4 PH4/CSIO PH5/CSGP1 PH6/CSGP2 PH7/CSPROG

EXTAL

XTAL XOUT E TESTxx (3)

MODA/LIR MODB/V

STBY

RESET

O0 O1 O2 O3 O4 O5 O6 O7

OE CE

UNUSED

INPUTS

GNDPH0/PW1 GND GND GND GND GND GND GND

GND GND

GND

UNUSED

OUTPUTS

GND GND GND

NOTE 2

NOTE 1

NOTE 3

NOTE 4

NOTES:

1. Unused Inputs – grounding is recommended.

2. Unused Inputs – these pins may be left unterminated.

3. Unused Outputs – these pins should be left unconnected.

4. Grounding these six pins configures the MC68HC711K4 for EPROM emulation mode.

Figure 6 Pin Assignments of the MC68HC711K4 MCU in PROG Mode

M68HC11 K Series MOTOROLA MC6HC11KTS/D 21

3.4 EEPROM

The 640-byte EEPROM is initially located at $0D80 after reset, assuming EEPROM is enabled in the memory map by the EEON bit in the CONFIG register. EEPROM can be placed at any 4-Kbyte boundary ($xD80) by writing appropriate values to the INIT2 register. Note that EEPROM can be mapped so that it contains the vector space. Refer to Figure 4. The MC68HC11K0, MC68HC11K3, MC68L11K0, and MC68L11K3 have no EEPROM. Refer to the ordering information tables.

Programming and erasing the EEPROM is controlled by the PPROG register, and dependent upon the block protect (BPROT) register value. An on-chip charge pump develops the high voltage required for programming and erasing. When the frequency of the E clock is less than 1 MHz, select the internal clock source to drive the EEPROM charge pump by writing one to the CSEL bit in the OPTION register.

The CONFIG register consists of a single EEPROM byte. Although the byte is not included in the 640byte EEPROM array, programming the CONFIG register requires the same procedure as any byte in the array. The erased state of bits in the CONFIG register is logic one. Refer to the CONFIG register description that follows this section.

The erased state of an EEPROM byte is $FF (all ones). To erase the EEPROM, ensure that the proper bits of the BPROT register are cleared, then complete

the following steps using the PPROG register:

1. Set the ERASE, EELAT, and appropriate BYTE and ROW bits in PPROG register.

2. Write to the appropriate EEPROM address with any data. Row erase only requires a write to any location in the row. Bulk erase is done by writing to any location in the array.

3. Set the ERASE, EELAT, EEPGM, and appropriate BYTE and ROW bits in PPROG register.

4. Delay for 10 ms or more, as appropriate.

5. Clear the EEPGM bit in PPROG to turn off the programming voltage.

6. Clear the PPROG register to reconfigure the EEPROM address and data buses for normal operation.

To program the EEPROM, ensure the proper bits of the BPROT register are cleared and use the PPROG register to complete the following steps:

1. Set the EELAT bit in PPROG register.

2. Write data to the desired address.

3. Set EEPGM bit in PPROG.

4. Delay for 10 ms or more, as appropriate.

5. Clear the EEPGM bit in PPROG to turn off the programming voltage.

6. Clear the PPROG register to reconfigure the EEPROM address and data buses for normal operation.

CAUTION

Since it is possible to perform other operations while the EEPROM programming/ erase operation is in progress, it is common to start the operation and then return to the main program until the 10 ms is completed. When the EELAT bit is set at the beginning of a program/erase operation, the EEPROM is electronically removed from the memory map; thus, it is not accessible during the program/erase cycle. Care must be taken to ensure that EEPROM resources will not be needed by any routines in the code during the 10 ms program/erase time.

PPROG —EEPROM Programming Control $003B

Bit 7 654321Bit 0

ODD EVEN LVPI BYTE ROW ERASE EELAT EEPGM

RESET: 0000000 0

MOTOROLA M68HC11 K Series 22 MC6HC11KTS/D

ODD —Program Odd Rows in Half of EEPROM (TEST) EVEN —Program Even Rows in Half of EEPROM (TEST) LVPI —Low Voltage Programming Inhibit

LVPI can be read at any time and writes to LVPI have no meaning nor effect. LVPI is set if LVPEN bit in BPROT register equals one and the LVPI circuit detects that VDD has fallen below a safe operating

voltage. Once set, LVPI is cleared when V

returns to a safe operating voltage or if LVPEN bit in

BPROT register is cleared. If LVPEN equals zero, then LVPI is always zero and has no meaning nor effect.

0 = EEPROM programming enabled 1 = EEPROM programming disabled

BYTE —Byte/Other EEPROM Erase Mode

0 = Row or bulk erase mode used 1 = Erase only one byte of EEPROM

ROW —Row/All EEPROM Erase Mode (only valid when BYTE = 0)

0 = All 640 bytes of EEPROM erased 1 = Erase only one 16-byte row of EEPROM

BYTE ROW Action

0 0 Bulk Erase (All 640 Bytes) 0 1 Row Erase (16 Bytes) 1 0 Byte Erase 1 1 Byte Erase

ERASE —Erase/Normal Control for EEPROM

0 = Normal read or program mode 1 = Erase mode

EELAT —EEPROM Latch Control

0 = EEPROM address and data bus configured for normal reads 1 = EEPROM address and data bus configured for programming or erasing

EEPGM —EEPROM Program Command

0 = Program or erase voltage switched off to EEPROM array 1 = Program or erase voltage switched on to EEPROM array

BPROT — Block Protect $0035

Bit 7 654321Bit 0

BULKP LVPEN BPRT4 PTCON BPRT3 BPRT2 BPRT1 BPRT0

RESET: 1111111 1

NOTE

Block protect register bits can be written to zero (protection disabled) only once within 64 cycles of a reset in normal modes, or at any time in special modes. Block protect register bits can be written to one (protection enabled) at any time.

BULKP —Bulk Erase of EEPROM Protect

0 = EEPROM can be bulk erased normally 1 = EEPROM cannot be bulk or row erased

M68HC11 K Series MOTOROLA MC6HC11KTS/D 23

LVPEN —Low Voltage Programming Protect Enable

If LVPEN = 1, programming of the EEPROM is enabled unless the LVPI circuit detects that VDD has fallen below a safe operating voltage, thus setting the low voltage programming inhibit bit in PPROG

0 = Low voltage programming protect for EEPROM disabled 1 = Low voltage programming protect for EEPROM enabled

BPRT4 —Block Protect Bit for Upper 128 Bytes of EEPROM

Refer to description for BPRT[3:0].

PTCON —Protect for CONFIG

0 = CONFIG register can be programmed or erased normally 1 = CONFIG register cannot be programmed or erased

BPRT[3:0] —Block Protect Bits for EEPROM

0 = Protection disabled 1 = Protection enabled

Bit Name Block Protected Block Size

BPRT4 $xF80–$xFFF 128 Bytes BPRT3 $xE60–$xF7F 288 Bytes BPRT2 $xDE0–$xE5F 128 Bytes BPRT1 $xDA0–$xDDF 64 Bytes BPRT0 $xD80–$xD9F 32 Bytes

INIT2 —EEPROM Mapping $0037

Bit 7 654321Bit 0 EE3 EE2 EE1 EE0 0 0 0 0

RESET: 0000000 0

INIT2 can be written only once in normal modes, any time in special modes.

EE[3:0] —EEPROM Map Position

EEPROM is at $xD80–$xFFF, where x is the hexadecimal digit represented by EE[3:0].

Bits [3:0] —Not implemented

Always read zero

3.5 Configuration Control Register (CONFIG)

The CONFIG register is used to define several system functions. Although the CONFIG register is an address within the register block, it is actually an EEPROM byte with the address of $x03F. CONFIG is made up of EEPROM cells and static latches. The operation of the MCU is controlled directly by these latches and not the actual EEPROM byte. When programming the CONFIG register, the EEPROM byte is being accessed. When the CONFIG register is being read, the static latches are being accessed.

The CONFIG register can be read at any time. The value read is the one latched from the EEPROM cells during the last reset sequence. A new value programmed into this register cannot be read until a subsequent reset occurs. Unused bits always read as ones.

In normal modes (SMOD = 0), CONFIG bits can only be written using the EEPROM programming sequence, and are neither readable nor active until latched via the next reset. In special modes (SMOD =

1), CONFIG bits can be written at any time.

MOTOROLA M68HC11 K Series 24 MC6HC11KTS/D

CONFIG —System Configuration Register $003F

Bit 7 654321Bit 0

ROMAD 1 CLKX PAREN NOSEC NOCOP ROMON EEON

RESET: — 1 — ———— —

ROMAD —ROM/EPROM Mapping Control

In single-chip mode ROMAD is forced to one out of reset.

0 = ROM/EPROM located at $2000–$7FFF 1 = ROM/EPROM located at $A000–$FFFF

Bit 6 —Not implemented

Always reads one

CLKX —XOUT Clock Enable

0 = XOUT pin disabled 1 = Buffered XTAL signal (four times E frequency) driven out on the XOUT pin

PAREN —Pull-Up Assignment Register Enable

0 = Pull-ups always disabled regardless of state of bits in PPAR 1 = Pull-ups either enabled or disabled through PPAR

NOSEC —Security Disable

NOSEC is invalid unless the security mask option is specified before the MCU is manufactured. If security mask option is omitted NOSEC always reads one. Refer to 3.6 Security Feature.

0 = Security enabled 1 = Security disabled

NOCOP —COP System Disable

Resets to programmed value

0 = COP enabled (forces reset on timeout) 1 = COP disabled (does not force reset on timeout)

ROMON —ROM/EPROM Enable

In single-chip mode, ROMON is forced to one out of reset. In special test mode, ROMON is forced to zero out of reset.

0 = ROM/EPROM removed from memory map 1 = ROM/EPROM present in memory map

EEON —EEPROM Enable

0 = EEPROM disabled from memory map 1 = EEPROM present in memory map with location depending on value specified in EE[3:0] in INIT2

3.6 Security Feature

The security feature protects memory contents from unauthorized access. Although many devices in the M68HC11 family support the security feature, an enhancement has been added to the MC68S11K4 that protects the contents of EPROM/OTPROM.

The security feature affects how the MCU behaves in certain modes. When the optional security feature has been specified prior to manufacture and enabled via the NOSEC bit in CONFIG, the MCU is restricted to operation in single-chip modes only. When the NOSEC bit equals zero, the MCU ignores the state of the MODA pin during reset. This allows the MCU to be operated in single-chip and bootstrap modes only. These modes of operation do not allow external visibility of the internal address and data buses. Although the security feature can easily be disabled when in bootstrap mode, the bootloader firmware residing in bootstrap ROM checks to see if the NOSEC bit is clear. If NOSEC is clear (security enabled), the bootloader program performs the following:

M68HC11 K Series MOTOROLA MC6HC11KTS/D 25

• Output $FF on SCI transmitter.

• Erase EEPROM array.

• Verify that EEPROM has been erased. If it has not, repeat erase procedure.

• Write $FF to every location in RAM.

• Check EPROM for data. If data is present, stay in loop. Otherwise proceed.

• Erase the CONFIG register.

• Continue executing bootloader routine.

Notice that the bootloader routine checks the EPROM to see if it contains any data. The presence of data causes the routine to stay in a loop. At this time, devices with the security enhancement are only available as one-time-programmable (OTP) MCUs in non-windowed packages. Once they have been programmed and secured, they will not function in bootstrap mode.

For more information refer to

M68HC11 Reference Manual

(M68HC11RM/AD).

MOTOROLA M68HC11 K Series 26 MC6HC11KTS/D

4 Memory Expansion and Chip Selects

Two additional on-chip blocks are provided with the M68HC11 K-series MCUs. The first block implements additional address lines that become active only when required by the CPU. The second block provides chip-select signals that simplify the interface to external peripheral devices. Both of these blocks are fully programmable by values written to associated control registers.

4.1 Memory Expansion

New to the M68HC11 family of microcontrollers is the ability of the M68HC11 K-series MCUs to extend the address range of the M68HC11 CPU beyond the physical 64 Kbyte limit of the 16 CPU address lines. The following is a brief description of how the extended addressing is achieved. For a more detailed discussion refer to application note

Memory expansion is achieved by manipulating the CPU address lines such that, even though the CPU cannot distinguish more than 64 Kbytes of physical memory, up to 1 Mbyte can be accessed through a paged memory scheme. Additional address lines XA[18:13] are provided as alternate functions of port G pins. Bits in the port G assignment register (PGAR) define which port G pins are to be used for memory expansion address lines and which are to be used for general-purpose I/O.

In order to access expanded memory, the user must first allocate a range of the 64 Kbyte address space to be used for the window(s) through which external expanded memory is viewed by the CPU. The size and placement of the window(s) depend upon values written to the MMSIZ and MMWBR registers, respectively. Which bank or page of the expanded memory that is present in the window(s) at a given time is dependent upon values written to the MM1CR and MM2CR registers.

Using the MC68HC11K4 Memory Mapping Logic

(AN452/D).

Up to two windows can be designated and each can be programmed to 0 (disabled), 8, 16, or 32 Kbytes. The base address for each window must be an integer multiple of the window size. When the window size is 32 Kbytes, the base address can be at $0000, $4000, or $8000.

If the windows are defined in such a way that they overlap, bank window 1 has priority and the part of window 2 that is not overlapped by bank window 1 remains active. If a window is defined such that it overlaps any internal registers, RAM, or EEPROM, the portion of the registers, RAM, or EEPROM that is overlapped is repeated in all banks associated with that window. However, if ROM/EPROM is enabled and overlapped by a window, the ROM/EPROM is present only in banks with XA[18:16] = 0:0:0.

Expanded memory is addressed by using a combination of the CPU's normal address lines ADDR[15:0] and the expansion address lines XA[18:13]. Window size and the number of banks associated with the window determine exactly which address lines are used. The additional address lines (XA[18:13]) determine which bank is present in a window at a given time. The lower three expansion address lines (XA[15:13]) are used only when needed by the CPU and replace the CPU's equivalent address lines (ADDR[15:13]). The following tables show which address lines are used for various configurations of expanded memory.

Five registers control operation of the memory expansion function. MM1CR and MM2CR registers indicate which bank of a window is active. Each contains the value to be output when the CPU selects addresses within the memory expansion window. PGAR selects which pins are used for I/O or memory expansion address lines, defining which extended address lines are used. The MMWBR register defines the starting address of each of the two windows within the CPU 64-Kbyte address range. The MMSIZ register sets the size of the windows in use and selects whether the on-board general-purpose chip selects are active for CPU addresses or for expansion addresses.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 27

Table 5 CPU Address and Address Expansion Signals

Number of Banks Window Size

8 Kbytes 16 Kbytes 32 Kbytes 32 Kbytes

(Window Based at

$4000)

2 ADDR[12:0] ADDR[13:0] ADDR[14:0] ADDR[13:0]

XA13 XA14 XA15 XA[15:14]

4 ADDR[12:0] ADDR[13:0] ADDR[14:0] ADDR[13:0]

XA[14:13] XA[15:14] XA[16:15] XA[16:14]

8 ADDR[12:0] ADDR[13:0] ADDR[14:0] ADDR[13:0]

XA[15:13] XA[16:14] XA[17:15] XA[17:14]

16 ADDR[12:0] ADDR[13:0] ADDR[14:0] ADDR[13:0]

XA[16:13] XA[17:14] XA[18:15] XA[18:14]

32 ADDR[12:0] ADDR[13:0] — —

XA[17:13] XA[18:14] — —

64 ADDR[12:0] — — —

XA[18:13] — — —

PGAR — Port G Assignment $002D

Bit 7 654321Bit 0

— — PGAR5 PGAR4 PGAR3 PGAR2 PGAR1 PGAR0

RESET: 0000000 0

Bits [7:6] — Not implemented

Always read zero

PGAR[5:0] —Port G Pin Assignment Bits [5:0]

0 = Corresponding port G pin is general-purpose I/O 1 = Corresponding port G pin is address line, XA[18:13]

NOTE

A special case exists for expansion address lines XA[15:13] that overlap the CPU address lines ADDR[15:13]. If these lines are selected as expansion address lines in PGAR, but are not used in either window, the corresponding CPU address line is output on the appropriate port G pin.

MMSIZ — Memory Mapping Size $0056

Bit 7 654321Bit 0

MXGS2 MXGS1 W2SZ1 W2SZ0 — — W1SZ1 W1SZ0

RESET: 0000000 0

MXGS[2:1] — Memory Expansion Select for General-Purpose Chip Select 2 or 1

0 = General-purpose chip select 2 or 1 based on 64 Kbyte CPU address 1 = General-purpose chip select 2 or 1 based on expansion address

W2SZ[1:0] — Window 2 Size

These bits select the size of memory expansion window 2. Refer to the table following W1SZ[1:0].

Bits [3:2] — Not implemented

Always read zero

MOTOROLA M68HC11 K Series 28 MC68HC11KTS/D

W1SZ[1:0] —Window 1 Size

These bits select the size of memory expansion window 1.

WxSZ[1:0] Window Size

0 0 Window disabled 0 1 8 K —Window can have up to 64 8-Kbyte banks 1 0 16 K —Window can have up to 32 16-Kbyte banks 1 1 32 K —Window can have up to 16 32-Kbyte banks

MMWBR — Memory Mapping Window Base $0057

Bit 7 654321Bit 0

$0057 W2A15 W2A14 W2A13 — W1A15 W1A14 W1A13 —

RESET: 0000000 0

W2A[15:13] —Window 2 Base Address

Selects the three most significant bit (MSB) of the base address for memory mapping window 2. Refer to the table following W1A[15:13].

Bit 4 —Not implemented

Always reads zero

W1A[15:13] —Window Base 1 Address

Selects the three MSB of the base address for memory mapping window 1. Refer to the following table for additional information.

MSB Bits Window Base Address

WxA[15:13] 8 K 16 K 32 K

0 0 0 $0000 $0000 $0000 0 0 1 $2000 $0000 $0000 0 1 0 $4000 $4000 $4000 0 1 1 $6000 $4000 $4000 1 0 0 $8000 $8000 $8000 1 0 1 $A000 $8000 $8000 1 1 0 $C000 $C000 $8000 1 1 1 $E000 $C000 $8000

Bit 0 —Not implemented

Always reads zero

NOTE

A special case exists when the bank size is 32 Kbytes and the window base address is $4000. The XA14 signal connected to the ADDR14 pin of the memory device automatically drives an inverted CPU ADDR14 signal onto the XA14 pin when the window is active. The effect occurs while the CPU address is in the $4000– $BFFF range, the XA pins and external physical memory range is $0000–$7FFF.

MM1CR–MM2CR —Memory Mapping Window 1 and 2 Control $0058–$0059

Bit 7 654321Bit 0 $0058 — X1A18 X1A17 X1A16 X1A15 X1A14 X1A13 — MM1CR $0059 — X2A18 X2A17 X2A16 X2A15 X2A14 X2A13 — MM2CR

RESET: 00000000

M68HC11 K Series MOTOROLA MC68HC11KTS/D 29

Bit 7 — Not implemented

Always reads zero

MM1CR — Memory Mapping Window 1 Control Register

When a 64 Kbyte CPU address falls within window 1, the value in MM1CR is driven out from the corresponding expansion address lines to enable the specified bank in the window.

MM2CR — Memory Mapping Window 2 Control Register

When a 64 Kbyte CPU address falls within window 2, the value in MM2CR is driven out from the corresponding expansion address lines to enable the specified bank in the window.

Bit 0 — Not implemented

Always reads zero

4.2 Overlap Guidelines

• On-chip registers, RAM, and EEPROM are higher priority than expansion windows. If a window overlaps RAM, registers, or EEPROM, they appear in all banks at their CPU address.

• If a window overlaps on-chip ROM/EPROM, the ROM/EPROM appears only in banks with XA[18:16] = 0:0:0.

• Window 1 is higher priority than window 2, therefore any overlapped portion of window 2 is inaccessible.

4.3 Chip Selects

M68HC11 K-series MCUs have four software configured chip selects that are enabled in expanded modes. The chip select for I/O (CSIO) is used for I/O expansion. The program chip select (CSPROG is used with an external memory that contains the reset vectors and program. The two general-purpose chip selects, CSGP1 and CSGP2, are used to enable external devices. These external devices can be in the 64 Kbyte memory space or in the expanded memory space. Chip select signals are a shared function of port H. When an MCU pin is not used for chip select functions it can be used for general-purpose I/O. The following table contains a summary of the attributes of each chip select that can be controlled by user software.

)

MOTOROLA M68HC11 K Series 30 MC68HC11KTS/D

CSIO Enable IOEN in CSCTL —1 = On, off at reset (0)

Valid IOCSA in CSCTL —1 = Address valid, 0 = E valid Polarity IOPL in CSCTL —1 = Active high, 0 = Active low Size IOSZ in CSCTL —1 = 4K ($1000–$1FFF), 0 = 8K ($0000–$1FFF) Start Address Fixed (see Size) Stretch IO1SA:IO1SB in CSCSTR —0, 1, 2, or 3 E clocks

CSPROG Enable PSCEN in CSCTL —1 = On, ON

Valid Fixed (Address valid) Polarity Fixed (Active low)

CSGP1, CSGP2

Size PCSZA:PCSZB in CSCTL — 0:0 = 64K ($0000–$FFFF)

Start Address Fixed (see Size) Stretch PCSA:PCSB in CSCSTR —0, 1, 2, or 3 E clocks Priority GCSPR in CSCTL — 1 = CSGPx above CSPROG

Enable Set size to 0K to disable Valid GxPOL in GPCS1C (GPCS2C) —1 = Address valid, 0 = E valid Polarity GxAV in GPCS1C (GPCS2C) —1 = Active high, 0 = Active low Size Refer to GPCS1C (GPCS2C) —2K to 512K in nine steps, 0K = dis-

Start Address Refer to GPCS1A (GPCS2A) Stretch Refer to CSCSTR —0, 1, 2, or 3 E clocks Other G1DG2 in GPCS1C allows CSGP1 and CSGP2 to be connected to

0:1 = 32K ($8000–$FFFF)

0 = CSPROG above CSGPx

able, can also follow memory expansion window 1 or window 2

an internal OR gate and driven out the CSGP2 pin. G1DPC in GPCS1C allows CSGP1 and CSPROG

an internal OR gate and driven out the CSPROG

at reset

1:0 = 16K ($C000–$FFFF) 1:1 = 8K ($E000–$FFFF)

to be connected to

pin.

G2DPC in GPCS2C allows CSGP2 and CSPROG an internal OR gate and driven out the CSPROG

MXGS2 in MMSIZ allows CSGP2 to follow either 64K CPU addresses or 512K expansion addresses.

MXGS1 in MMSIZ allows CSGP1 to follow either 64K CPU addresses or 512K expansion addresses.

to be connected to

pin.

4.3.1 Program Chip Select (CSPROG)

The program chip select (CSPROG) is active in the range of memory where the main program exists. CSPROG is enabled out of reset in all modes. After reset in normal mode, the PCS stretch select bit is set to provide one cycle of stretch so that slow memory devices can be used.

4.3.2 I/O Chip Select (CSIO)

The I/O chip select (CSIO) is programmable for a four Kbyte size located at addresses $1000 to $1FFF or eight Kbyte size located at addresses $0000 to $1FFF. Polarity of the active state is programmable for active high or active low. Clock stretching can be set from zero to three cycles.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 31

4.3.3 General-Purpose Chip Selects (CSGP1, CSGP2)

The general-purpose chip selects are the most flexible and programmable and have the most control bits. Polarity of active state, E valid or address valid, size, and starting address are all programmable. Clock stretching can be set from zero to three cycles. Each chip select can be programmed to become active whenever the CPU address enters a memory expansion window regardless of the actual bank selected. This is known as following a window.

Each general purpose chip select can be configured to drive the program chip select. CSGP1 can be configured to drive CSGP2 or the program chip select. Using one chip select to drive another allows the same device to cover the address space defined by both chip selects. The two chip selects are connected to an internal OR gate. The output of the OR gate is then driven onto the pin corresponding to the driven chip select. For example, this is useful when the same external device is used with both bank windows but the windows are opened independently. In cases where one chip select drives another, determine the priority from the following table.

Condition Priority

GPCS1 drives GPCS2 GPCS1

GPCS1 drives PCS GPCS1 GPCS2 drives PCS GPCS2

GPCS1 and GPCS2 drive PCS GPCS1

4.3.4 Chip Select Priorities

To minimize chip select conflicts (with one another or with internal memory and registers), the priority is determined by the GCSPR bit in the CSCTL register. Refer to the following table.

GCSPR = 0 GCSPR = 1

On-Chip Registers On-Chip Registers

On-Chip RAM On-Chip RAM

Bootloader ROM Bootloader ROM

On-Chip EEPROM On-Chip EEPROM

On-Chip ROM/EPROM On-Chip ROM/EPROM

I/O Chip Select I/O Chip Select

Program Chip Select GP Chip Select 1

GP Chip Select 1 GP Chip Select 2 GP Chip Select 2 Program Chip Select

4.3.5 Chip Select Control Registers

There are six chip select control registers. Chip select functions are enabled by control bits in CSCTL register. Chip selects are configured by bits in CSCSTR, IOEN, IOPL, IOCSA, and IOSZ registers.

CSCTL — Chip Select Control $005B

Bit 7 654321Bit 0

IOEN IOPL IOCSA IOSZ GCSPR PCSEN PCSZA PCSZB

RESET: 0000010 0

IOEN —I/O Chip Select Enable

0 = CSIO disabled 1 = CSIO enabled

IOPL —I/O Chip Select Polarity Select

0 = CSIO active low 1 = CSIO active high

MOTOROLA M68HC11 K Series 32 MC68HC11KTS/D

IOCSA —I/O Chip Select Address Valid

0 = Valid during E-clock high time 1 = Valid during address valid time

IOSZ —I/O Chip Select Size Select

0 = $1000–$1FFF (4 Kbyte) 1 = $0000–$1FFF (8 Kbyte)

GCSPR —General-Purpose Chip Select Priority

0 = Program chip select has priority over general-purpose chip selects 1 = General-purpose chip selects have priority over program chip select

PCSEN —Program Chip Select Enable

0 = CSPROG disabled 1 = CSPROG

enabled

PCSZA, PCSZB —Program Chip Select Size (A or B)

PCSZA PCSZB Size (Bytes) Address Range

0 0 64 K $0000–$FFFF 0 1 32 K $8000–$FFFF 1 0 16 K $C000–$FFFF 1 1 8 K $E000–$FFFF

CSCSTR —Chip Select Clock Stretch $005A

Bit 7 654321Bit 0

IOSA IOSB GP1SA GP1SB GP2SA GP2SB PCSA PCSB

RESET: 00000001Normal Modes

00000000Special Modes

IOSA, IOSB —CSIO Stretch Select GP1SA, GP1SB —CSGP1 Stretch Select GP2SA, GP2SB —CSGP2 Stretch Select PCSA, PCSB —CSPROG Stretch Select

Bit [A:B] Clock Stretch

0 0 None 0 1 1 Cycle 1 0 2 Cycles 1 1 3 Cycles

GPCS1A —General-Purpose Chip Select 1 Address $005C

Bit 7 654321Bit 0

G1A18 G1A17 G1A16 G1A15 G1A14 G1A13 G1A12 G1A11

RESET: 0000000 0

G1A[18:11] —General-Purpose Chip Select 1 Address

Selects the starting address of general-purpose chip select 1 range. Refer to the G1SZA–G1SZD table.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 33

GPCS1C —General-Purpose Chip Select 1 Control $005D

Bit 7 654321Bit 0

G1DG2 G1DPC G1POL G1AV G1SZA G1SZB G1SZC G1SZD

RESET: 0000000 0

G1DG2 —General-Purpose Chip Select 1 Drives General-Purpose Chip Select 2

0 = CSGP1 does not affect CSGP2 1 = CSGP1 and CSGP2 are connected to an OR gate and driven out CSGP2

G1DPC —General-Purpose Chip Select 1 Drives Program Chip Select

0 = CSGP1 does not affect CSPROG 1 = CSGP1 and CSPROG are connected to an OR gate and driven out CSPROG

G1POL —General-Purpose Chip Select 1 Polarity Select

0 = CSGP1 active low 1 = CSGP1 active high

G1AV —General-Purpose Chip Select 1 Address Valid Select

0 = CSGP1 active during E high time 1 = CSGP1 active during address valid time

G1SZA–G1SZD —General-Purpose Chip Select 1 Size

G1SZx Valid Bits Valid Bits

ABCDSize (Bytes) (MXGS1 = 0) (MXGS1 = 1)

0000 Disabled None None 0001 2 K ADDR[15:11] G1A[18:11] 0010 4 K ADDR[15:12] G1A[18:12] 0011 8 K ADDR[15:13] G1A[18:13] 0100 16 K ADDR[15:14] G1A[18:14] 0101 32 K ADDR15 G1A[18:15] 0110 64 K None G1A[18:16] 0111 128 K None G1A[18:17] 1000 256 K None G1A18 1001 512 K None None 1010Follow Window 1 None None 1011Follow Window 2 None None

1100–1111 Default to 512 K None None

GPCS2A —General-Purpose Chip Select 2 Address $005E

Bit 7 654321Bit 0

G2A18 G2A17 G2A16 G2A15 G2A14 G2A13 G2A12 G2A11

RESET: 0000000 0

G2A[18:11] —General-Purpose Chip Select 2 Address

Selects the Starting Address of General-Purpose Chip Select 2 Range. Refer to G2SZA–G2SZD table.

GPCS2C —General-Purpose Chip Select 2 Control $005F

Bit 7 654321Bit 0

— G2DPC G2POL G2AV G2SZA G2SZB G2SZC G2SZD

RESET: 0000000 0

MOTOROLA M68HC11 K Series 34 MC68HC11KTS/D

Bit 7 — Not implemented

Always reads zero

G2DPC — General-Purpose Chip Select 2 Drives Program Chip Select

0 = CSGP2 does not affect CSPROG 1 = CSGP2 and CSPROG are connected to an OR gate and driven out CSPROG

G2POL — General-Purpose Chip Select 2 Polarity Select

0 = CSGP2 active low 1 = CSGP2 active high

G2AV — General-Purpose Chip Select 2 Address Valid Select

0 = Active during E high time 1 = Active during address valid time

G2SZA–G2SZD — General-Purpose Chip Select 2 Size

G2SZx Valid Bits Valid Bits

ABCDSize (Bytes) (MXGS2 = 0) (MXGS2 = 1)

0000 Disabled None None 0001 2 K ADDR[15:11] G2A[18:11] 0010 4 K ADDR[15:12] G2A[18:12] 0011 8 K ADDR[15:13] G2A[18:13] 0100 16 K ADDR[15:14] G2A[18:14] 0101 32 K ADDR15 G2A[18:15] 0110 64 K None G2A[18:16] 0111 128 K None G2A[18:17] 1000 256 K None G2A18 1001 512 K None None 1010Follow Window 1 None None 1011Follow Window 2 None None

1100–1111 Default to 512 K None None

4.3.6 Examples of Memory Expansion Using Chip Selects

On the following two pages are examples of memory expansion schemes that use chip select signals to simplify the interface to the external memory devices. Although schematics are not provided, careful study of the memory map diagram for each example will reveal the simplicity with which an expanded system can be created. Both examples require a minimum of external circuitry as well as very little program code.

This example is a system consisting of the MCU and a single 27C512-type memory device. This system uses one chip select and has one window containing eight banks of eight Kbytes each. In this example, a total of 64 Kbytes is added to the address range of the MCU. Three of the expansion address lines (XA[15:13]) are used. Register values particular to this example are given below the diagram.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 35

$0000

$1000

$00000

$02000

$04000

$06000

WINDOW 1

$08000

$0A000

$0C000

$0E000

$4000

$6000

$A000

$FFFF

CHIP SELECT 1

INTERNAL

EPROM

BANK 0 BANK 1 BANK 2 BANK 3 BANK 4 BANK 5

XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]=

0:0:0 0:0:1 0:1:0 0:1:1 1:0:0 1:0:1 1:1:0 1:1:1

$01FFF

$03FFF

$05FFF

PGAR = $07

MMWBR = $04

MMSIZ = $41

CSCTL = $00

GPCS1A = $00 GPSC1C = $06 GPCS2A = $00 GPCS2C = $00

$07FFF

XA[15:13] WINDOW 1 @ $4000, WINDOW 2 DISABLED WINDOW 1 = 8 KBYTES, WINDOW 2 DISABLED

NO I/O OR PROGRAM CHIP SELECTS GEN. PURPOSE CHIP SELECT 1 FROM $00000 64 KBYTE RANGE (8 X 8K) N/A GEN. PURPOSE CHIP SELECT 2 DISABLED

$09FFF

$0BFFF

BANK 6

$0DFFF

BANK 7

$0FFFF

Figure 7 Memory Expansion Example 1

This example is a system consisting of the MCU, a single 27C512-type memory device as in the previous example, and two 6226-type memory devices as well. This system uses two chip selects and has two windows. For purposes of explanation, the setup of the first window is identical to the previous example. In addition, a second window consisting of 16 banks of 16 Kbytes each uses the second chip select signal. Window 1 contains 64 Kbytes of expanded memory pages, window 2 contains a total of 256 Kbytes of expanded memory. A total of five expansion address lines are used. Register values particular to this example are given below the diagram.

MOTOROLA M68HC11 K Series 36 MC68HC11KTS/D

WINDOW 1

$0000

$1000

$4000

$6000

$8000

$A000

$C000

$FFFF

EE/REG/RAM

CHIP SELECT 1

CHIP SELECT 2

INTERNAL

EPROM

MMWBR = $84

PGAR = $1F

MMSIZ = $E1

$00000

BANK 0 BANK 1 BANK 2 BANK 3 BANK 4 BANK 5

XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]= XA[15:13]=

0:0:0 0:0:1 0:1:0 0:1:1 1:0:0 1:0:1 1:1:0 1:1:1

$01FFF

$00000

BANK 0 BANK 1 BANK 2 BANK 3 BANK 4 BANK 15

XA[17:14]= XA[17:14]= XA[17:14]= XA[17:14]= XA[17:14]= XA[17:14]=

0:0:0:0 0:0:0:1 0:0:1:0 0:0:1:1 0:1:0:0 1:1:1:1

$03FFF

XA[17:13] WINDOW 1 @ $4000, WINDOW 2 @ $8000 WINDOW 1 = 8 KBYTES, WINDOW 2 = 16 KBYTES

$02000

$03FFF

$04000

$07FFF

$04000

$05FFF

$08000

$0BFFF

CSCTL = $00

GPCS1A = $00

GPSC1C = $06

GPCS2A = $00

GPCS2C = $08

$06000

$07FFF

$0C000

$09FFF

WINDOW 2

$08000

$10000

$0A000

$0BFFF

• • • • • • •

$0FFFF

$13FFF

NO I/O OR PROGRAM CHIP SELECTS GEN. PURPOSE CHIP SELECT 1 FROM $00000 64 KBYTE RANGE (8 X 8K) GEN. PURPOSE CHIP SELECT 2 FROM $00000 256 KBYTE RANGE (16 X 16K)

$0C000

BANK 6

$0DFFF

$0E000

BANK 7

$0FFFF

$3C000

$3FFFF

Figure 8 Memory Expansion Example 2

M68HC11 K Series MOTOROLA MC68HC11KTS/D 37

5 Resets and Interrupts

All M68HC11 MCUs have three reset vectors and 18 interrupt vectors. The reset vectors are as follows:

• RESET, or Power-On Reset

• Clock Monitor Fail

• COP Failure

The 18 interrupt vectors service 22 interrupt sources (three nonmaskable, 19 maskable). The three nonmaskable interrupt sources are as follows:

• XIRQ Pin (X-Bit Interrupt)

• Illegal Opcode Trap

• Software Interrupt

On-chip peripheral systems generate maskable interrupts, which are recognized only if the global interrupt mask bit (I) in the condition code register (CCR) is clear. Maskable interrupts are prioritized according to a default arrangement; however, any one source can be elevated to the highest maskable priority position by a software-accessible control register (HPRIO). The HPRIO register can be written at any time, provided bit I in the CCR is set.

Nineteen interrupt sources in the M68HC11 K series devices are subject to masking by the global interrupt mask bit (bit I in the CCR). In addition to the global bit I, all of these sources, except the external interrupt (IRQ M68HC11 devices have separate interrupt vectors; therefore, there is usually no need for software to poll control registers to determine the cause of an interrupt.

) pin, are controlled by local enable bits in control registers. Most interrupt sources in

For some interrupt sources, such as the SCI interrupts, the flags are automatically cleared during the normal course of responding to the interrupt requests. For example, the RDRF flag in the SCI system is cleared by the automatic clearing mechanism invoked by a read of the SCI status register while RDRF is set, followed by a read of the SCI data register. The normal response to an RDRF interrupt request would be to read the SCI status register to check for receive errors, then to read the received data from the SCI data register. These two steps satisfy the automatic clearing mechanism without requiring any special instructions.

Refer to the following table for a list of interrupt and reset vector assignments.

MOTOROLA M68HC11 K Series 38 MC68HC11KTS/D

Vector Address Interrupt Source CCR Mask

Bit

FFC0, C1 —FFD4, D5 Reserved — — —

FFD6, D7 SCI Serial System I

• SCI Receive Data Register Full RIE 19

• SCI Receiver Overrun RIE 20

• SCI Transmit Data Register Empty TIE 21

• SCI Transmit Complete TCIE 22

• SCI Idle Line Detect ILIE 23

FFD8, D9 SPI Serial Transfer Complete I SPIE 18 FFDA, DB Pulse Accumulator Input Edge I PAII 17

FFDC, DD Pulse Accumulator Overflow I PAOVI 16

FFDE, DF Timer Overflow I TOI 15

FFE0, E1 Timer Input Capture 4/Output Compare 5 I I4/O5I 14 FFE2, E3 Timer Output Compare 4 I OC4I 13 FFE4, E5 Timer Output Compare 3 I OC3I 12 FFE6, E7 Timer Output Compare 2 I OC2I 11 FFE8, E9 Timer Output Compare 1 I OC1I 10

FFEA, EB Timer Input Capture 3 I IC3I 9

FFEC, ED Timer Input Capture 2 I IC2I 8

FFEE, EF Timer Input Capture 1 I IC1I 7

FFF0, F1 Real Time Interrupt I RTII 6 FFF2, F3 IRQ FFF4, F5 XIRQ FFF6, F7 Software Interrupt None None *

FFF8, F9 Illegal Opcode Trap None None * FFFA, FB COP Failure None NOCOP 3 FFFC, FD Clock Monitor Fail None CME 2

FFFE, FF RESET None None 1

I None 5

Pin X None 4

Local Mask Priority

(1 = High)

*Same level as an instruction

OPTION —System Configuration Options $0039

Bit 7 654321Bit 0

ADPU CSEL IRQE* DLY* CME FCME* CR1* CR0*

RESET: 0001000 0

*Can be written only once in first 64 cycles out of reset in normal modes, or at any time in special modes.

ADPU —A/D Converter Power up

Refer to 9 Analog-to-Digital Converter.

CSEL —Clock Select

Refer to 9 Analog-to-Digital Converter.

IRQE —IRQ Select Edge Sensitive Only

0 = Low level recognition 1 = Falling edge recognition

DLY —Enable Oscillator Start-Up Delay on Exit from STOP

0 = No stabilization delay on exit from STOP 1 = Stabilization delay enabled on exit from STOP

M68HC11 K Series MOTOROLA MC68HC11KTS/D 39

CME —Clock Monitor Enable

0 = Clock monitor disabled; slow clocks can be used 1 = Slow or stopped clocks cause clock failure reset

FCME —Force Clock Monitor Enable

0 = Clock monitor follows the state of the CME bit 1 = Clock monitor circuit is enabled until next reset

CR[1:0] —COP Timer Rate Select

Refer to NOCOP bit in CONFIG register.

Table 6 COP Timer Rate Select (Timeout Period Length)

CR[1:0] Rate

Selected

0 0 0 1 1 0 1 1

E = 2.0 MHz 3.0 MHz 4.0 MHz

XTAL = 8.0 MHz

Timeout

–0 ms, +16.4 ms

16.384 ms 10.923 ms 8.192 ms

65.536 ms 43.691 ms 32.768 ms

262.14 ms 174.76 ms 131.07 ms

1.049 sec 699.05 ms 524.29 ms

XTAL = 12.0 MHz

Timeout

–0 ms, +10.9 ms

XTAL = 16.0 MHz

Timeout

–0 ms, +8.2 ms

COPRST —Arm/Reset COP Timer Circuitry $003A

Bit 7 654321Bit 0

76543210

RESET: 0000000 0

Write $55 (%01010101) to COPRST to arm COP watchdog clearing mechanism. Write $AA (%10101010) to COPRST to reset COP watchdog. Refer to NOCOP bit in CONFIG register.

HPRIO —Highest Priority I-Bit Interrupt and Miscellaneous $003C

Bit 7 654321Bit 0

RBOOT* SMOD* MDA* PSEL4 PSEL3 PSEL2 PSEL1 PSEL0

RESET: — — — 0011 0

*RBOOT, SMOD, and MDA reset depend on power-up initialization mode and can only be written in special mode.

RBOOT —Read Bootstrap ROM

Refer to 2 Operating Modes.

SMOD —Special Mode Select

Refer to 2 Operating Modes.

MDA —Mode Select A

Refer to 2 Operating Modes.

MOTOROLA M68HC11 K Series 40 MC68HC11KTS/D

PSEL[4:0] —Priority Select Bit 4 through Bit 0

Can be written only while the I-bit in the CCR is set (interrupts disabled). These bits select one interrupt source to be elevated above all other I-bit related sources.

PSELx

43210 Interrupt Source Promoted

0 0 0 X X Reserved (Default to IRQ 00100Reserved (Default to IRQ 00101Reserved (Default to IRQ 00110IRQ 00111Real-Time Interrupt 01000Timer Input Capture 1 01001Timer Input Capture 2 01010Timer Input Capture 3 01011Timer Output Compare 1 01100Timer Output Compare 2 01101Timer Output Compare 3 01110Timer Output Compare 4 01111Timer Output Compare 5/Input Capture 4 10000Timer Overflow 10001Pulse Accumulator Overflow 10010Pulse Accumulator Input Edge 10011SPI Serial Transfer Complete 10100SCI Serial System 10101Reserved (Default to IRQ 10110Reserved (Default to IRQ 10111Reserved (Default to IRQ 1 1 X X X Reserved (Default to IRQ

) ) )

) ) ) )

M68HC11 K Series MOTOROLA MC68HC11KTS/D 41

6 Parallel Input/Output

M68HC11 K-series MCUs have up to 62 input/output lines, depending on the operating mode. To enhance the I/O functions, the data bus of this microcontroller is nonmultiplexed. The following table is a summary of the configuration and features of each port.

Port Input Pins Output Pins Bidirectional Pins Shared Functions

Port A — — 8 Timer

Port B — — 8 High Order Address Port C — — 8 Data Bus Port D — — 6 SCI and SPI

Port E 8 — — A/D Converter

Port F — — 8 Low Order Address Port G — — 8 Memory Expansion Port H — — 8 PWM, Chip Select

NOTE

Port pin function is mode dependent. Do not confuse pin function with the electrical state of the pin at reset. Port pins are either driven to a specified logic level or are configured as high impedance inputs. I/O pins configured as high-impedance inputs have port data that is indeterminate. The contents of the corresponding latches are dependent upon the electrical state of the pins during reset. In port descriptions, an "I" indicates this condition. Port pins that are driven to a known logic level during reset are shown with a value of either one or zero. Some control bits are unaffected by reset. Reset states for these bits are indicated with a "U".

PORTA —Port A Data $0000

Bit 7 654321Bit 0 PA7 PA6 PA5 PA4 PA3 PA2 PA1 PA0

RESET: IIIIIII I

Alt. Pin

Func.: PAI OC2 OC3 OC4 IC4/OC5 IC1 IC2 IC3

And/or: OC1 OC1 OC1 OC1 OC1 — — —

NOTE

To enable PA3 as fourth input capture, set the I4/O5 bit in the PACTL register. Otherwise, PA3 is configured as a fifth output compare out of reset, with bit I4/O5 being cleared. If the DDA3 bit is set (configuring PA3 as an output), and IC4 is enabled, writes to PA3 cause edges on the pin to result in input captures. Writing to TI4/O5 has no effect when the TI4/O5 register is acting as IC4. PA7 drives the pulse accumulator input but also can be configured for general-purpose I/O or output compare. Note that even when PA7 is configured as an output, the pin still drives the pulse accumulator input.

DDRA —Data Direction Register for Port A $0001

Bit 7 654321Bit 0

DDA7 DDA6 DDA5 DDA4 DDA3 DDA2 DDA1 DDA0

RESET: 0000000 0

DDA[7:0] —Data Direction for Port A

0 = Corresponding pin configured for input 1 = Corresponding pin configured for output

MOTOROLA M68HC11 K Series 42 MC68HC11KTS/D

PORTB —Port B Data $0004

Bit 7 654321Bit 0 PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0

S. Chip or

Boot: PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0

RESET: IIIIIII I

Expan. or

Test: ADDR15 ADDR14 ADDR13 ADDR12 ADDR11 ADDR10 ADDR9 ADDR8

Reset state is mode dependent. In single-chip or bootstrap modes, port B pins are high-impedance inputs with selectable internal pull-up resistors. In expanded or test modes, port B pins are high order address outputs and PORTB is not in the memory map.

DDRB —Data Direction Register for Port B $0002

Bit 7 654321Bit 0

DDB7 DDB6 DDB5 DDB4 DDB3 DDB2 DDB1 DDB0

RESET: 0000000 0

DDB[7:0] —Data Direction for Port B

0 = Corresponding pin configured for input 1 = Corresponding pin configured for output

PORTC —Port C Data $0006

Bit 7 654321Bit 0 PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0

S. Chip or

Boot: PC7 PC6 PC5 PC4 PC3 PC2 PC1 PC0

RESET: 0000000 0

Expan. or

Test: DATA7 DATA6 DATA5 DATA4 DATA3 DATA2 DATA1 DATA0

Reset state is mode dependent. In single-chip or bootstrap modes, port C pins are high-impedance inputs with selectable internal pull-up resistors. In expanded or test modes, port C pins are data bus inputs and outputs and PORTC is not in the memory map. Refer to CWOM bit in OPT2 register description that follows.

DDRC —Data Direction Register for Port C $0007

Bit 7 654321Bit 0

DDC7 DDC6 DDC5 DDC4 DDC3 DDC2 DDC1 DDC0

RESET: 0000000 0

DDC[7:0] —Data Direction for Port C. Refer to CWOM bit in OPT2 register description that follows.

0 = Corresponding pin configured for input 1 = Corresponding pin configured for output

M68HC11 K Series MOTOROLA MC68HC11KTS/D 43

OPT2 —System Configuration Options 2 $0038

Bit 7 654321Bit 0

LIRDV CWOM — IRVNE LSBF SPR2 XDV1 XDV0

RESET: 0 0 0 — 0 0 0 0

LIRDV—LIR Driven

Refer to 2 Operating Modes.

CWOM —Port C Wired-OR Mode

0 = Port C operates normally. 1 = Port C outputs are open-drain.

Bit 5 —Not implemented

Always read zero

IRVNE —Internal Read Visibility/Not E

Refer to 2 Operating Modes.

LSBF —SPI LSB First Enable

Refer to 8 Serial Peripheral Interface.

SPR2 —SPI Clock (SCK) Rate Select

Refer to 8 Serial Peripheral Interface.

XDV[1:0] —XOUT Clock Divide Select

Refer to 2 Operating Modes.

PORTD —Port D Data $0008

Bit 7 654321Bit 0

— — PD5 PD4 PD3 PD2 PD1 PD0

RESET: 0 0 IIIII I

Alt. Pin

Func.: — — SS

SCK MOSI MISO TxD RxD

DDRD —Data Direction Register for Port D $0009

Bit 7 654321Bit 0

— — DDD5 DDD4 DDD3 DDD2 DDD1 DDD0

RESET: 0000000 0

Bits [7:6] — Not implemented

Always read zero

DDD[5:0] — Data Direction for Port D

0 = Corresponding pin configured for input 1 = Corresponding pin configured for output

NOTE

When the SPI system is in slave mode, DDD5 has no meaning nor effect. When the SPI system is in master mode, DDD5 determines whether bit 5 of PORTD is an error detect input (DDD5 = 0) or a general-purpose output (DDD5 = 1). If the SPI system is enabled and expects any of bits [4:2] to be an input that bit will be an input regardless of the state of the associated DDR bit. If any of bits [4:2] are expected to be outputs that bit will be an output only if the associated DDR bit is set.

MOTOROLA M68HC11 K Series 44 MC68HC11KTS/D

SPCR —Serial Peripheral Control $0028

Bit 7 654321Bit 0

SPIE SPE DWOM MSTR CPOL CPHA SPR1 SPR0

RESET: 00100000Boot Mode

00000000Other Modes

SPIE —SPI Interrupt Enable

Refer to 8 Serial Peripheral Interface.

SPE —SPI System Enable

Refer to 8 Serial Peripheral Interface.

DWOM —Port D Wired-OR Mode Option for SPI Pins PD[5:2] (See also WOMS bit in SCCR1)

0 = PD[5:2] are normal CMOS outputs 1 = PD[5:2] are open-drain outputs

MSTR —Master/Slave Mode Select

Refer to 8 Serial Peripheral Interface.

CPOL —Clock Polarity

Refer to 8 Serial Peripheral Interface.

CPHA —Clock Phase

Refer to 8 Serial Peripheral Interface.

SPR[1:0] —SPI Clock Rate Selects

Refer to 8 Serial Peripheral Interface.

SCCR1 —SCI Control 1 $0072

Bit 7 654321Bit 0

LOOPS WOMS — M WAKE ILT PE PT

RESET: 01000000Boot Mode

00000000Other Modes

LOOPS —SCI LOOP Mode Enable

Refer to 7 Serial Communications Interface.

WOMS —Port D Wired-OR Mode Option for SPI Pins PD[5:2] (See also DWOM bit in SPCR.)

0 = TxD and RxD operate normally 1 = TxD and RxD are open drains if operating as an output

Bit 5 —Not implemented

Always reads zero

M —Mode (Select Character Format)

Refer to 7 Serial Communications Interface.

WAKE —Wakeup by Address Mark/Idle

Refer to 7 Serial Communications Interface.

ILT —Idle Line Type

Refer to 7 Serial Communications Interface.

PE —Parity Enable

Refer to 7 Serial Communications Interface.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 45

PT —Parity Type

Refer to 7 Serial Communications Interface.

PORTE —Port E Data $000A

Bit 7 654321Bit 0 PE7 PE6 PE5 PE4 PE3 PE2 PE1 PE0

RESET: IIIIIIII

Alt. Pin

Func.: AN7 AN6 AN5 AN4 AN3 AN2 AN1 AN0

DDRF —Data Direction Register for Port F $0003

Bit 7 654321Bit 0

DDF7 DDF6 DDF5 DDF4 DDF3 DDF2 DDF1 DDF0

RESET: 0000000 0

DDF[7:0] —Data Direction for Port F

0 = Corresponding pin configured for input 1 = Corresponding pin configured for output

PORTF —Port F Data $0005

Bit 7 654321Bit 0

PF7 PF6 PF5 PF4 PF3 PF2 PF1 PF0

S. Chip or

Boot: PF7 PF6 PF5 PF4 PF3 PF2 PF1 PF0

RESET: IIIIIII I

Expan. or

Test: ADDR7 ADDR6 ADDR5 ADDR4 ADDR3 ADDR2 ADDR1 ADDR0

Reset state is mode dependent. In single-chip or bootstrap modes, port F is high-impedance input with selectable internal pull-up resistors. In expanded or test modes, port F pins are low order address outputs and PORTF is not in the memory map.

PORTH —Port H Data $007C

Bit 7 654321Bit 0 PH7 PH6 PH5 PH4 PH3 PH2 PH1 PH0

RESET: IIIIIII I

Alt. Pin

Func.:

CSPROG

CSGP2 CSGP1 CSIO PW4 PW3 PW2 PW1

Port H pins reset to high-impedance inputs with selectable internal pull-up resistors. In expanded and special test modes, reset also causes PH7 to be configured as CSPROG

DDRH —Data Direction Register for Port H $007D

Bit 7 654321Bit 0

DDH7 DDH6 DDH5 DDH4 DDH3 DDH2 DDH1 DDH0

RESET: 0000000 0

DDH[7:0] —Data Direction for Port H

0 = Bits set to zero to configure corresponding I/O pin for input only 1 = Bits set to one to configure corresponding I/O pin for output

MOTOROLA M68HC11 K Series 46 MC68HC11KTS/D

NOTE

In expanded and special test modes, chip-select circuitry forces the I/O state to be an output for each port H pin associated with an enabled chip select. In any mode, PWM circuitry forces the I/O state to be an output for each port H line associated with an enabled pulse width modulator channel. In these cases, data direction bits are not changed and have no effect on these lines. DDRH reverts to controlling the I/O state of a pin when the associated function is disabled. Refer to 4.3 Memory Expansion and Chip Selects and 12 Pulse-Width Modulation Timer for further information.

PORTG —Port G Data $007E

Bit 7 654321Bit 0 PG7 PG6 PG5 PG4 PG3 PG2 PG1 PG0

RESET: IIIIIII I

Alt. Pin

Func.: R/W

— XA18 XA17 XA16 XA15 XA14 XA13

Port G pins reset to high-impedance inputs with selectable internal pull-up resistors. In expanded and special test modes PG7 becomes R/W

. Refer to PGAR register description.

DDRG —Data Direction Register for Port G $007F

Bit 7 654321Bit 0

DDG7 DDG6 DDG5 DDG4 DDG3 DDG2 DDG1 DDG0

RESET: 0000000 0

DDG[7:0] —Data Direction for Port G

0 = Configure corresponding I/O pin for input only

1 = Configure corresponding I/O pin for output In expanded and test modes, bit 7 is configured for R/W, forcing the state of this pin to be an output although the DDRG value remains zero. Refer to PGAR register description.

PGAR — Port G Assignment $002D

Bit 7 654321Bit 0

$002D — — PGAR5 PGAR4 PGAR3 PGAR2 PGAR1 PGAR0

RESET: 0000000 0

Bits [7:6] —Not implemented

Always read zero

PGAR[5:0] —Port G Pin Assignment Bits [5:0]

0 = Corresponding port G pin is general-purpose I/O

1 = Corresponding port G pin is memory expansion address line (XA[18:13])

NOTE

Each PGAR bit forces the I/O state to be an output for each port G pin associated with an enabled expansion address line. In this case, data direction bits are not changed and have no effect on these lines. DDRG reverts to controlling the I/O state of a pin when the associated function is disabled. Refer to 4.1 Memory Ex- pansion for further information.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 47

PPAR —Port Pull-Up Assignment $002C

Bit 7 654321Bit 0

————HPPUE GPPUE FPPUE BPPUE

RESET: 0000111 1

Bits [7:4] —Not implemented

Always read zero

xPPUE —Port x Pin Pull-Up Enable

Valid only when PAREN = 1. Refer to PAREN bit in the CONFIG register description.

0 = Port x pin on-chip pull-up devices disabled

1 = Port x pin on-chip pull-up devices enabled

NOTE

FPPUE and BPPUE have no effect in expanded mode because port F and port B are address outputs.

MOTOROLA M68HC11 K Series 48 MC68HC11KTS/D

7 Serial Communications Interface

The SCI, a universal asynchronous receiver transmitter (UART) serial communications interface, is one of two independent serial I/O subsystems in M68HC11 K-series MCUs. Rearranging registers and control bits used in previous M68HC11 family devices has enhanced the existing SCI system and added new features, which include the following:

• A 13-bit modulus prescaler that allows greater baud rate control

• A new idle mode detect, independent of preceding serial data

• A receiver active flag

• Hardware parity for both transmitter and receiver

The enhanced baud rate generator is shown in the following diagram. Refer to Table 7 for standard values.

EXTAL

13-BIT COUNTER

RESET

13-BIT COMPARE

SCBDH/L SCI BAUD CONTROL

Figure 9 SCI Baud Generator Circuit Diagram

INTERNAL

PHASE 2 CLOCK

÷ 2

SYNCH

÷ 16

RECEIVER BAUD RATE CLOCK

TRANSMITTER BAUD RATE CLOCK

M68HC11 K Series MOTOROLA MC68HC11KTS/D 49

TRANSMITTER

BAUD RATE

CLOCK

SCDR Tx BUFFER

10 (11) - BIT Tx SHIFT REGISTER

H(8)76543210L

(WRITE ONLY)

DDD1

PIN BUFFER

AND CONTROL

PD1 TxD

SIZE 8/9

TRANSFER Tx BUFFER

WAKE

SCCR1 SCI CONTROL 1

SHIFT ENABLE

JAM ENABLE

PREAMBLE—JAM 1s

TRANSMITTER

CONTROL LOGIC

TDRE

SCSR INTERRUPT STATUS

TDRE TIE

TC TCIE

BREAK—JAM 0s

IDLE

RDRF

DIRECTION (OUT)

FORCE PIN

SBK

RWU

ILIE

RIE

TCIE

TIE

SCCR2 SCI CONTROL 2

SCI Rx

REQUESTS

SCI INTERRUPT

REQUEST

INTERNAL DATA BUS

Figure 10 SCI Transmitter Block Diagram

MOTOROLA M68HC11 K Series 50 MC68HC11KTS/D

RECEIVER

BAUD RATE

CLOCK

PD0/ RxD

DDD0

PIN BUFFER

AND CONTROL

DATA

RECOVERY

÷16

10 (11) - BIT

Rx SHIFT REGISTER

STOP

(8)76543210

START

SCSR2 SCI STATUS 2

WOMS

LOOPS

SCCR1 SCI CONTROL 1

WAKE

ILT

DISABLE DRIVER

WAKE-UP

RAF

LOGIC

RDRF RIE

PARITY

DETECT

TDRE

IDLE

RDRF

SCSR1 SCI STATUS 1

MSB ALL ONES

RWU

R8 T8 – – – – – –

SCDRH Tx/Rx DATA HIGH

7 6 5 4 3 2 1 0

SCDRL Tx/Rx DATA LOW

$x076

$x077

(READ-ONLY)

IDLE ILIE

OR RIE

SCI Tx

REQUESTS

SCI INTERRUPT

REQUEST

TIE

TCIE

SCCR2 SCI CONTROL 2

RIE

ILIE

RWU

SBK

INTERNAL

DATA BUS

Figure 11 SCI Receiver Block Diagram

M68HC11 K Series MOTOROLA MC68HC11KTS/D 51

SCBDH/L —SCI Baud Rate Control High/Low $0070, $0071

Bit 7 654321Bit 0

$0070 BTST BSPL — SBR12 SBR11 SBR10 SBR9 SBR8 High

RESET: 00000000

$0071 SBR7 SBR6 SBR5 SBR4 SBR3 SBR2 SBR1 SBR0 Low

RESET: 00000100

BTST —Baud Register Test (TEST)

Factory test only

BSPL —Baud Rate Counter Split (TEST)

Factory test only

Bit 5 —Not implemented

Always reads zero

SBR[12:0] —SCI Baud Rate Selects

Use the following formula to calculate SCI baud rate. Refer to the table of baud rate control values for example rates.

SCI baud rate = EXTAL ÷[16 ∗ (2 ∗ BR)] Where BR is the contents of SCBDH/L (BR = 1, 2, 3 ... 8191). BR = 0 disables the baud rate generator.

Table 7 SCI Baud Rate Control Values

Target Crystal Frequency (EXTAL)

Baud 8 MHz 12 MHz 16 MHz

Rate Dec Value Hex Value Dec Value Hex Value Dec Value Hex Value

110 2272 $08E0 3409 $0D51 4545 $11C1 150 1666 $0682 2500 $09C4 3333 $0D05 300 833 $0341 1250 $04E2 1666 $0682

600 416 $01A0 625 $0271 833 $0341 1200 208 $00D0 312 $0138 416 $01A0 2400 104 $0068 156 $009C 208 $00D0 4800 52 $0034 78 $004E 104 $0068 9600 26 $001A 39 $0027 52 $0034

19.2 K 13 $000D 20 $0014 26 $001A

38.4 K ————13$000D

SCCR1 —SCI Control 1 $0072

Bit 7 654321Bit 0

LOOPS WOMS — M WAKE ILT PE PT

RESET: 01000000Bootstrap

00000000Other Modes

Mode

MOTOROLA M68HC11 K Series 52 MC68HC11KTS/D

LOOPS —SCI LOOP Mode Enable

0 = SCI transmit and receive operate normally 1 = SCI transmit and receive are disconnected from TxD and RxD pins, and transmitter output is

fed back into the receiver input

WOMS —Wired-OR Mode Option for PD[1:0] (See also DWOM bit in SPCR.)

0 = TxD and RxD operate normally 1 = TxD and RxD are open drains if operating as an output

Bit 5 —Not implemented

Always reads zero

M —Mode (Select Character Format)

0 = Start bit, 8 data bits, 1 stop bit 1 = Start bit, 9 data bits, 1 stop bit

WAKE —Wakeup by Address Mark/Idle

0 = Wakeup by IDLE line recognition 1 = Wakeup by address mark (most significant data bit set)

ILT —Idle Line Type

0 = Short (SCI counts consecutive ones after start bit) 1 = Long (SCI counts ones only after stop bit)

PE —Parity Enable

0 = Parity disabled 1 = Parity enabled

PT —Parity Type

0 = Parity even (even number of ones causes parity bit to be zero, odd number of ones causes par-

ity bit to be one)

1 = Parity odd (odd number of ones causes parity bit to be zero, even number of ones causes parity

bit to be one)

SCCR2 —SCI Control 2 $0073

Bit 7 654321Bit 0

TIE TCIE RIE ILIE TE RE RWU SBK

RESET: 0000000 0

TIE —Transmit Interrupt Enable

0 = TDRE interrupts disabled 1 = SCI interrupt requested when TDRE status flag is set

TCIE —Transmit Complete Interrupt Enable

0 = TC interrupts disabled 1 = SCI interrupt requested when TC status flag is set

RIE —Receiver Interrupt Enable

0 = RDRF and OR interrupts disabled 1 = SCI interrupt requested when RDRF flag or the OR status flag is set

ILIE —Idle Line Interrupt Enable

0 = IDLE interrupts disabled 1 = SCI interrupt requested when IDLE status flag is set

TE —Transmitter Enable

0 = Transmitter disabled 1 = Transmitter enabled

M68HC11 K Series MOTOROLA MC68HC11KTS/D 53

RE —Receiver Enable

0 = Receiver disabled 1 = Receiver enabled

RWU —Receiver Wakeup Control

0 = Normal SCI receiver 1 = Wakeup enabled and receiver interrupts inhibited

SBK —Send Break

0 = Break generator off 1 = Break codes generated as long as SBK = 1

SCSR1 —SCI Status Register 1 $0074

Bit 7 654321Bit 0

TDRE TC RDRF IDLE OR NF FE PF

RESET: 1100000 0

TDRE —Transmit Data Register Empty Flag

This flag is set when SCDR is empty. Clear the TDRE flag by reading SCSR1 and then writing to SCDR.

0 = SCDR busy 1 = SCDR empty

TC —Transmit Complete Flag

This flag is set when the transmitter is idle (no data, preamble, or break transmission in progress). Clear the TC flag by reading SCSR1 and then writing to SCDR.

0 = Transmitter busy 1 = Transmitter idle

RDRF —Receive Data Register Full Flag

RDRF is set if a received character is ready to be read from SCDR. Clear the RDRF flag by reading SCSR1 and then reading SCDR.

0 = SCDR empty 1 = SCDR full

IDLE —Idle Line Detected Flag

This flag is set if the RxD line is idle. Once cleared, IDLE is not set again until the RxD line has been active and becomes idle again. The IDLE flag is inhibited when RWU = 1. Clear IDLE by reading SCSR1 and then reading SCDR.

0 = RxD line is active 1 = RxD line is idle

OR —Overrun Error Flag

OR is set if a new character is received before a previously received character is read from SCDR. Clear the OR flag by reading SCSR1 and then reading SCDR.

0 = No overrun 1 = Overrun detected

NF —Noise Error Flag

NF is set if majority sample logic detects anything other than a unanimous decision. Clear NF by reading SCSR1 and then reading SCDR.

0 = Unanimous decision 1 = Noise detected

FE —Framing Error

FE is set when a zero is detected where a stop bit was expected. Clear the FE flag by reading SCSR1 and then reading SCDR.

0 = Stop bit detected 1 = Zero detected

MOTOROLA M68HC11 K Series 54 MC68HC11KTS/D

PF —Parity Error Flag

PF is set if received data has incorrect parity. Clear PF by reading SCSR1 and then reading SCDR.

0 = Parity correct 1 = Incorrect parity detected

SCSR2 —SCI Status Register 2 $0075

Bit 7 654321Bit 0

———————RAF

RESET: 0000000 0

Bits [7:1] —Not implemented

Always read zero

RAF —Receiver Active Flag (Read Only)

0 = A character is not being received 1 = A character is being received

SCDRH, SCDRL —SCI Data Register High/Low $0076, $0077

Bit 7 654321Bit 0

$0076 R8 T8 ——————SCDRH

$0077 R7/T7 R6/T6 R5/T5 R4/T4 R3/T3 R2/T2 R1/T1 R0/T0 SCDRL

(High)

(Low)

R8 —Receiver Bit 8

Ninth serial data bit received when SCI is configured for nine-data-bit operation.

T8 —Transmitter Bit 8

Ninth serial data bit transmitted when SCI is configured for nine-data-bit operation.

Bits [5:0] —Not implemented

Always read zero

R/T[7:0] —Receiver/Transmitter Data Bits [7:0]

SCI data is double buffered in both directions.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 55

8 Serial Peripheral Interface

The SPI allows the MCU to communicate synchronously with peripheral devices and other microprocessors. Data rates can be as high as 2 Mbits per second when configured as a master and 4 Mbits per second when configured as a slave (assuming 4 MHz bus speed).

Two control bits in OPT2 allow the transfer of data either MSB or LSB first and select an additional divide by four stage to be inserted before the SPI baud rate clock divider.

INTERNAL

MCU CLOCK

DIVIDER

÷2 ÷4 ÷16 ÷32 ÷8 ÷16 ÷64 ÷128

SELECT

SPR1

SPR0

SPR2

LSBF

OPTIONS REGISTER 2

SPI CONTROL

SPI CLOCK (MASTER)

MSTR SPE SPIE

MSB

8-BIT SHIFT REGISTER

READ DATA BUFFER

LSBF

LSB

CLOCK

LOGIC

CLOCK

S M

M S

CONTROL

LOGIC

S M

MSTR

SPE

DWOM

MISO/

PD2

MOSI/

PD3

SCK/

PD4

SS PD5

SPIE

SPE

DWOM

MSTR

CPHA

CPOL

SPR1

SPIF

WCOL

MODF

SPSR SPI STATUS REGISTER

SPI INTERRUPT

REQUEST

SPCR SPI CONTROL REGISTER

INTERNAL

DATA BUS

SPR0

Figure 12 SPI Block Diagram

MOTOROLA M68HC11 K Series 56 MC68HC11KTS/D

SPCR —Serial Peripheral Control Register $0028

Bit 7 654321Bit 0

SPIE SPE DWOM MSTR CPOL CPHA SPR1 SPR0

RESET: 000001UU

SPIE —Serial Peripheral Interrupt Enable

0 = SPI interrupts disabled 1 = SPI interrupts enabled

SPE —Serial Peripheral System Enable

0 = SPI off 1 = SPI on

DWOM —Port D Wired-OR Mode Option for SPI Pins PD[5:2] (See also WOMS bit in SCCR1.)

0 = Normal CMOS outputs 1 = Open-drain outputs

MSTR —Master Mode Select

0 = Slave mode 1 = Master mode

CPOL, CPHA —Clock Polarity, Clock Phase

Refer to the following figure, SPI Transfer Format.

SCK CYCLE #

(FOR REFERENCE)

SCK (CPOL = 0)

SCK (CPOL = 1)

SAMPLE INPUT

(CPHA = 0)

DATA OUT

SAMPLE INPUT

DATA OUT(CPHA = 1)

SS (TO SLAVE)

23456781

MSB654321LSB

654321 LSBMSB

Figure 13 SPI Transfer Format

NOTE

This figure shows transmission order when LSBF = 0 default. If LSBF = 1, data is transferred in reverse order (LSB first).

M68HC11 K Series MOTOROLA MC68HC11KTS/D 57

SPR[2:0] —SPI Clock Rate Selects (SPR2 is located in OPT2 register)

Table 8 SPI Clock Rate Selects

SPR[2:0] Divide

E Clock By

0 0 0 2 1.0 MHz 3.0 MHz 4.0 MHz 0 0 1 4 500 kHz 750 kHz 1.0 MHz 0 1 0 16 125 kHz 187.5 kHz 250 kHz 0 1 1 32 62.5 kHz 93.75 kHz 125 kHz 1 0 0 8 250 kHz 375 kHz 500 kHz 1 0 1 16 125 kHz 187.5 kHz 250 kHz 1 1 0 64 31.25 kHz 46.875 kHz 62.5 kHz 1 1 1 128 15.625 kHz 23.438 kHz 31.25 kHz

Frequency at

E = 2 MHz (Baud)

Frequency at

E = 3 MHz (Baud)

Frequency at

E = 4 MHz (Baud)

SPSR —Serial Peripheral Status Register $0029

Bit 7 654321Bit 0

SPIF WCOL — MODF ————

RESET: 00000000

SPIF —SPI Transfer Complete Flag

This flag is set when an SPI transfer is complete (after eight SCK cycles in a data transfer). Clear this flag by reading SPSR, then access SPDR.

0 = No SPI transfer complete or SPI transfer still in progress 1 = SPI transfer complete

WCOL —Write Collision Error Flag

This flag is set if the MCU tries to write data into SPDR while an SPI data transfer is in progress. Clear this flag by reading SPSR, then access SPDR.

0 = No write collision error 1 = SPDR written while SPI transfer in progress

Bit 5 —Not implemented

Always reads zero

MODF —Mode Fault (Mode fault terminates SPI operation)

Set when SS

is pulled low while MSTR = 1. Cleared by SPSR read followed by SPCR write. 0 = No mode fault error 1 = SS pulled low in master mode

Bits [3:0] —Not implemented

Always read zero

SPDR —SPI Data $002A

Bit 7 654321Bit 0 Bit 7 654321Bit 0

SPI is double buffered in, single buffered out.

MOTOROLA M68HC11 K Series 58 MC68HC11KTS/D

OPT2 —System Configuration Options 2 $0038

Bit 7 654321Bit 0

LIRDV CWOM — IRVNE LSBF SPR2 XDV1 XDV0

RESET: 0 0 0 — 0 0 0 0

LIRDV—LIR Driven

Refer to 2 Operating Modes.

CWOM —Port C Wired-OR Mode

Refer to 6 Parallel Input/Output.

Bit 5 —Not implemented

Always read zero

IRVNE —Internal Read Visibility/Not E

Refer to 2 Operating Modes.

LSBF —SPI LSB First Enable

0 = SPI data transferred MSB first 1 = SPI data transferred LSB first

SPR2 —SPI Clock (SCK) Rate Select

Adds a divide by four prescaler to SPI clock chain. Refer to SPCR register.

XDV[1:0] —XOUT Clock Divide Select

Refer to 2 Operating Modes.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 59

9 Analog-to-Digital Converter

The analog-to-digital (A/D) converter system uses an all-capacitive charge-redistribution technique to convert analog signals to digital values. The A/D converter system contained in M68HC11 K-series MCUs is an 8-channel,8-bit, multiplexed-input, successive-approximation converter. It does not require external sample and hold circuits.

The clock source for the A/D converter’s charge pump, like the clock source for the EEPROM charge pump, is selected with the CSEL bit in the OPTION register. When the E clock is slower than 1 MHz, the CSEL bit must be set to ensure that the successive approximation sequence for the A/D converter will be completed before any charge loss occurs. In the case of the EEPROM, it is the efficiency of the charge pump that is affected.

PE0/ AN0

PE1/ AN1

PE2/ AN2

PE3/ AN3

PE4/ AN4

PE5/ AN5

PE6/ AN6

PE7/ AN7

ANALOG

MUX

8-BIT CAPACITIVE DAC

WITH SAMPLE AND HOLD

SUCCESSIVE APPROXIMATION

RESULT

RESULT REGISTER INTERFACE

MULT

SCAN

CCF

ADCTL A/D CONTROL

INTERNAL DATA BUS

ADDR 3 A/D RESULT 3

ADDR 4 A/D RESULT 4ADDR 2 A/D RESULT 2ADDR 1 A/D RESULT 1

Figure 14 A/D Converter Block Diagram

The A/D converter can operate in single or multiple conversion modes. Multiple conversions are performed in sequences of four. Sequences can be performed on a single channel or an a group of channels.

Dedicated lines V

and VRL provide the reference supply voltage inputs.

MOTOROLA M68HC11 K Series 60 MC68HC11KTS/D

A multiplexer allows the single A/D converter to select one of 16 analog input signals. The A/D converter control logic implements automatic conversion sequences on a selected channel

four times or on four channels once each. A write to the ADCTL register initiates conversions and, if made while a conversion is in progress, a write to ADCTL also halts that conversion operation, sets CCF, and proceeds to the next instruction.

When the SCAN bit is zero, four requested conversions are performed, once each, to fill the four result registers. When SCAN is one, conversions continue in a round-robin fashion with the result registers being updated as new data becomes available. When the MULT bit is zero, the A/D converter system is configured to perform conversions on each channel in the group of four channels specified by the CD and CC channel select bits.

E CLOCK

WRITE

ADCTL

12 E CYCLES

SAMPLE ANALOG INPUT

CONVERT FIRST

CHANNEL

AND UPDATE ADDR1

MSB

CYCLES

CONVERT SECOND

CHANNEL

AND UPDATE ADDR2

BIT 6

BIT 5

BIT 4

CYC

SUCCESSIVE APPROXIMATION SEQUENCE

CONVERT THIRD

CHANNEL

AND UPDATE ADDR3

CYC

BIT 3

CYC

BIT 2

CYC

Figure 15 Timing Diagram for a Sequence of Four A/D Conversions

ANALOG

INPUT

PROTECTION

DEVICE

< 2 pF

+ ~ 20 V

– ~ 0.7 V

DIFFUSION AND POLY COUPLER

≤ 4 kΩ

400 nA

JUNCTION

LEAKAGE

BIT 1

LSB

CYC

CONVERT FOURTH

CHANNEL

AND UPDATE ADDR4

20 pF

DAC

CAPACITANCE

CYC

END

SET CCF

FLAG

REPEAT

SEQUENCE

SCAN = 1

1289664320

CYCLES

* This analog switch is closed only during the 12-cycle sample time.

Figure 16 Electrical Model of an Analog Input Pin (Sample Mode)

M68HC11 K Series MOTOROLA MC68HC11KTS/D 61

ADCTL —A/D Control/Status $0030

Bit 7 654321Bit 0

CCF — SCAN MULT CD CC CB CA

RESET: 0000000 0

CCF — Conversions Complete Flag

0 = Write to ADCTL is complete 1 = A/D conversion cycle is complete

Bit 6 — Not implemented

Always reads zero

SCAN —Continuous Scan Control

0 = Do four conversions and stop 1 = Convert four channels in selected group continuously

MULT —Multiple Channel/Single Channel Control

0 = Convert single channel selected 1 = Convert four channels in selected group

CD:CA —Channel Select D through A

Table 9 A/D Converter Channel Assignments

Channel Select Control Bits Channel Signal Result in ADRx if

CD CC CB CA

0 0 0 0

1 1 1 1

*Used for factory testing

0 0 0 0

1 1 1 1

0 0 0 0

1 1 1 1

0 0 1 1

0 1 0 1

AN0 AN1 AN2 AN3

AN4 AN5 AN6 AN7

Reserved Reserved Reserved Reserved

)/2*

Reserved*

MULT = 1

ADR1 ADR2 ADR3 ADR4

— — — —

ADR1 ADR2 ADR3 ADR4

ADR[4:1] —A/D Results $0031 – $0034

$0031 Bit 7 654321Bit 0 ADR1 $0032 Bit 7 654321Bit 0 ADR2 $0033 Bit 7 654321Bit 0 ADR3 $0034 Bit 7 654321Bit 0 ADR4

MOTOROLA M68HC11 K Series 62 MC68HC11KTS/D

OPTION —System Configuration Options $0039

Bit 7 654321Bit 0

ADPU CSEL IRQE* DLY* CME FCME* CR1* CR0*

RESET: 0001000 0

ADPU —A/D Converter Power-Up

0 = A/D converter powered down 1 = A/D converter powered up

CSEL — Clock Select

0 = A/D and EEPROM use system E clock 1 = A/D and EEPROM use internal RC clock source

IRQE —IRQ Select Edge Sensitive Only

Refer to 5 Resets and Interrupts

DLY —Enable Oscillator Startup Delay on Exit from Stop

Refer to 5 Resets and Interrupts

CME —Clock Monitor Enable

Refer to 5 Resets and Interrupts

FCME —Force Clock Monitor Enable

Refer to 5 Resets and Interrupts

CR[1:0] —COP Timer Rate Select

Refer to 10 Main Timer

M68HC11 K Series MOTOROLA MC68HC11KTS/D 63

10 Main Timer

The timing system is based on a free-running 16-bit counter with a four-stage programmable prescaler. A timer overflow function allows software to extend the timing capability of the system beyond the 16bit range of the counter.

The timer has three channels for input capture, four channels for output compare, and one channel that can be configured as a fourth input capture or a fifth output compare. In addition, the timing system includes pulse accumulator and real-time interrupt (RTI) functions, as well as a clock monitor function, which can be used to detect clock failures that are not detected by the COP.

Refer to 11 Pulse Accumulator and 10.1 Real-Time Interrupt for further information about these functions. Refer to the following table for a summary of the crystal-related frequencies and periods.

Table 10 Timer Summary

Control Bits Common System Frequencies Definition

8.0 MHz 12.0 MHz 16.0 MHz XTAL

2.0 MHz 3.0 MHz 4.0 MHz E

PR[1:0] Main Timer Count Rates (Period Length)

0 0

1 count —

overflow —

0 1

1 count —

overflow —

1 0

1 count —

overflow —

1 1

1 count —

overflow —

RTR[1:0] Periodic (RTI) Interrupt Rates (Period Length)

0 0 0 1 1 0 1 1

CR[1:0] COP Watchdog Timeout Rates (Period Length)

0 0 0 1 1 0 1 1

Timeout Tolerance

(–0 ms/+...) 16.4 ms 10.9 ms 8.192 ms

500 ns

32.768 ms

2.0 µs

131.07 ms

4.0 µs

262.14 ms

8.0 µs

524.29 ms

4.096 ms

8.192 ms

16.384 ms

32.768 ms

16.384 ms

65.536 ms

262.14 ms

1.049 s

333 ns

21.845 ms

1.333 µs

87.381 ms

2.667 µs

174.76 ms

5.333 µs

349.52 ms

2.731 ms

5.461 ms

10.923 ms

21.845 ms

10.923 ms

43.691 ms

174.76 ms

699.05 ms

250 ns

16.384 ms

1.0 µs

65.536 ms

2.0 µs

131.07 ms

4.0 µs

262.14 ms

2.048 ms

4.096 ms

8.192 ms

16.384 ms

8.192 ms

32.768 ms

131.07 ms

524.28 ms

1/E

4/E

8/E

16/E

/E /E /E /E

MOTOROLA M68HC11 K Series 64 MC68HC11KTS/D

MCU

ECLK

16-BIT COMPARATOR

TOC1 (HI) TOC1 (LO)

16-BIT COMPARATOR

TOC2 (HI) TOC2 (LO)

16-BIT COMPARATOR

TOC3 (HI) TOC3 (LO)

16-BIT COMPARATOR

TOC4 (HI) TOC4 (LO)

16-BIT TIMER BUS

16-BIT COMPARATOR

TI4/O5 (HI)

TIC1 (HI)

PRESCALER–DIVIDE BY

1, 4, 8, OR 16

PR1 PR0

16-BIT TIMER BUS

TI4/O5 (LO)

16-BIT LATCH CLK

TIC1 (LO)

TCNT (HI)

16-BIT FREE-RUNNING

TFLG1

I4/O5

OC1F

OC2F

OC3F

OC4F

OC5

I4/O5F

IC4

IC1F

TCNT (LO)

COUNTER

TAPS FOR RTI, COP

WATCHDOG AND

PULSE ACCUMULATOR

CFORC

FOC1

FOC2

FOC3

FOC4

FOC5

FORCE

OUTPUT

COMPARE

TOI TOF

TMSK1

OC1I

OC2I

OC3I

OC4I

I4/O5I

IC1I

INTERRUPT REQUESTS

(FURTHER QUALIFIED

BY I-BIT IN CCR)

BIT-7

BIT-6

BIT-5

BIT-4

BIT-3

BIT-2

PULSE

ACCUMULATOR

FUNCTIONS

PA7/

OC1/

PAI

PA6/

OC2/

OC1

PA5/

OC3/

OC1

PA4/

OC4/

OC1

PA3

OC5/

IC4/ OC1

PA2/

IC1

16-BIT LATCH CLK

TIC2 (HI)

16-BIT LATCH CLK

TIC3 (HI)

TIC2 (LO)

TIC3 (LO)

IC2F

IC3F

STATUS

FLAGS

IC2I

IC3I

INTERRUPT

ENABLES

BIT-1

BIT-0

PORT A

CONTROL

PA1/

IC2

PA0/

IC3

Figure 17 Timer Block Diagram

M68HC11 K Series MOTOROLA MC68HC11KTS/D 65

CFORC —Timer Compare Force $000B

Bit 7 654321Bit 0

FOC1 FOC2 FOC3 FOC4 FOC5 — — —

RESET: 0000000 0

FOC[5:1] —Force Output Compare

Write ones to force compare(s)

0 = Not affected 1 = Output x action occurs

Bits [2:0] —Not implemented

Always read zero

OC1M —Output Compare 1 Mask $000C

Bit 7 654321Bit 0

OC1M7 OC1M6 OC1M5 OC1M4 OC1M3 — — —

RESET: 0000000 0

Set bit(s) to enable OC1 to control corresponding pin(s) of port A

Bits [2:0] —Not implemented

Always read zero

OC1D —Output Compare 1 Data $000D

Bit 7 654321Bit 0

OC1D7 OC1D6 OC1D5 OC1D4 OC1D3 — — —

RESET: 0000000 0

If OC1Mx is set, data in OC1Dx is output to port A bit x on successful OC1 compares.

Bits [2:0] —Not implemented

Always read zero

TCNT —Timer Count $000E, $000F

$000E Bit 15 14 13 12 11 10 9 Bit 8 High TCNT $000F Bit 7 654321Bit 0 Low

TCNT resets to $0000. In normal modes, TCNT is read only.

TIC1–TIC3 —Timer Input Capture $0010–$0015

$0010 Bit 15 14 13 12 11 10 9 Bit 8 High TIC1 $0011 Bit 7 654321Bit 0 Low $0012 Bit 15 14 13 12 11 10 9 Bit 8 High TIC2 $0013 Bit 7 654321Bit 0 Low $0014 Bit 15 14 13 12 11 10 9 Bit 8 High TIC3 $0015 Bit 7 654321Bit 0 Low

TICx not affected by reset

MOTOROLA M68HC11 K Series 66 MC68HC11KTS/D

TOC1–TOC4 —Timer Output Compare $0016–$001D

$0016 Bit 15 14 13 12 11 10 9 Bit 8 High TOC1 $0017 Bit 7 654321Bit 0 Low $0018 Bit 15 14 13 12 11 10 9 Bit 8 High TOC2 $0019 Bit 7 654321Bit 0 Low $001A Bit 15 14 13 12 11 10 9 Bit 8 High TOC3 $001B Bit 7 654321Bit 0 Low $001C Bit 15 14 13 12 11 10 9 Bit 8 High TOC4 $001D Bit 7 654321Bit 0 Low

All TOCx register pairs reset to ones ($FFFF).

TI4/O5 —Timer Input Capture 4/Output Compare 5 $001E–$001F

$001E Bit 15 14 13 12 11 10 9 Bit 8 High $001F Bit 7 654321Bit 0 Low

This is a shared register and is either input capture 4 or output compare 5 depending on the state of bit I4/O5 in PACTL. Writes to TI4/O5 have no effect when this register is configured as input capture 4. The TI4/O5 register pair resets to ones ($FFFF).

TCTL1 —Timer Control 1 $0020

Bit 7 654321Bit 0

OM2 OL2 OM3 OL3 OM4 OL4 OM5 OL5

RESET: 0000000 0

OM[5:2] —Output Mode OL[5:2] —Output Level

OMx OLx Action Taken on Successful Compare

0 0 Timer disconnected from output pin logic 0 1 Toggle OCx output line 1 0 Clear OCx output line to zero 1 1 Set OCx output line to one

TCTL2 —Timer Control 2 $0021

Bit 7 654321Bit 0

EDG4B EDG4A EDG1B EDG1A EDG2B EDG2A EDG3B EDG3A

RESET: 00000000

Table 11 Timer Control Configuration

EDGxB EDGxA Configuration

0 0 Capture disabled 0 1 Capture on rising edges only 1 0 Capture on falling edges only 1 1 Capture on any edge

M68HC11 K Series MOTOROLA MC68HC11KTS/D 67

TMSK1 —Timer Interrupt Mask 1 $0022

Bit 7 654321Bit 0

OC1I OC2I OC3I OC4I I4/O5I IC1I IC2I IC3I

RESET: 00000000

OC1I–OC4I —Output Compare x Interrupt Enable

If the OCxF flag bit is set while the OCxI enable bit is set, a hardware interrupt sequence is requested.

I4/O5I —Input Capture 4 or Output Compare 5 Interrupt Enable

When I4/O5 in PACTL is one, I4/O5I is the input capture 4 interrupt bit. When I4/O5 in PACTL is zero, I4/O5I is the output compare 5 interrupt control bit.

IC1I–IC3I —Input Capture x Interrupt Enable

If the ICxF flag bit is set while the ICxI enable bit is set, a hardware interrupt sequence is requested.

TFLG1 —Timer Interrupt Flag 1 $0023

Bit 7 654321Bit 0

OC1F OC2F OC3F OC4F I4/O5F IC1F IC2F IC3F

RESET: 0000000 0

Clear flags by writing a one to the corresponding bit position(s).

OC1F–OC5F —Output Compare x Flag

Set each time the counter matches output compare x value

I4/O5F —Input Capture 4/Output Compare 5 Flag

Set by IC4 or OC5, depending on which function was enabled by I4/O5 of PACTL

IC1F–IC3F —Input Capture x Flag

Set each time a selected active edge is detected on the ICx input line

NOTE

Control bits in TMSK1 correspond bit for bit with flag bits in TFLG1. Ones in TMSK1 enable the corresponding interrupt sources.

TMSK2 —Timer Interrupt Mask 2 $0024

Bit 7 654321Bit 0

TOI RTII PAOVI PAII — — PR1 PR0

RESET: 0000000 0

TOI —Timer Overflow Interrupt Enable

0 = Timer overflow interrupt disabled 1 = Timer overflow interrupt enabled

RTII —Real-Time Interrupt Enable

0 = RTIF interrupts disabled 1 = Interrupt requested when RTIF is set to one.

PAOVI —Pulse Accumulator Overflow Interrupt Enable

Refer to 11 Pulse Accumulator.

PAII —Pulse Accumulator Interrupt Enable

Refer to 11 Pulse Accumulator.

MOTOROLA M68HC11 K Series 68 MC68HC11KTS/D

NOTE

Control bits [7:4] in TMSK2 correspond bit for bit with flag bits [7:4] in TFLG2. Ones in TMSK2 enable the corresponding interrupt sources.

Bits [3:2] —Not implemented

Always read zero

PR[1:0] —Timer Prescaler Select

In normal modes, PR1 and PR0 can only be written once, and the write must occur within 64 cycles after reset. Refer to Table 10 for specific timing values.

PR[1:0] Prescaler

0 0 1 0 1 4 1 0 8 1 1 16

TFLG2 —Timer Interrupt Flag 2 $0025

Bit 7 654321Bit 0 TOF RTIF PAOVF PAIF — — — —

RESET: 0000000 0

Clear flags by writing a one to the corresponding bit position(s).

TOF —Timer Overflow Flag

Set when TCNT changes from $FFFF to $0000

RTIF —Real-Time (Periodic) Interrupt Flag

0 = No RTI interrupt 1 = RTI interrupt request pending

PAOVF —Pulse Accumulator Overflow Flag

Refer to 11 Pulse Accumulator.

PAIF —Pulse Accumulator Input Edge Flag

Refer to 11 Pulse Accumulator.

Bits [3:0] —Not implemented

Always read zero

PACTL —Pulse Accumulator Control $0026

Bit 7 654321Bit 0

— PAEN PAMOD PEDGE — I4/O5 RTR1 RTR0

RESET: 0000000 0

Bit 7 —Not implemented

Always read zero

PAEN —Pulse Accumulator System Enable

Refer to 11 Pulse Accumulator.

PAMOD —Pulse Accumulator Mode

Refer to 11 Pulse Accumulator.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 69

PEDGE —Pulse Accumulator Edge Control

Refer to 11 Pulse Accumulator.

Bit 3 —Not implemented

Always reads zero

I4/O5 —Input Capture 4/Output Compare 5

Configure TI4/O5 for input capture or output compare

0 = OC5 enabled 1 = IC4 enabled

RTR[1:0] —Real-Time Interrupt (RTI) Rate

Refer to 10.1 Real-Time Interrupt.

10.1 Real-Time Interrupt

These rates are a function of the MCU oscillator frequency and the value of the software-accessible control bits, RTR1 and RTR0. These bits determine the rate at which interrupts are requested by the

RTI system. The RTI system is driven by an E divided by 2

rate clock compensated so that it is independent of the timer prescaler. The RTR1 and RTR0 control bits select an additional division factor. RTI is set to its fastest rate by default out of reset and can be changed at any time.

Table 12 Real-Time Interrupt Rates (Period Length)

Period Length Period Length

RTR[1:0] Selected E = 2.0 MHz E = 3.0 MHz E = 4.0 MHz

0 0 0 1 1 0 1 1

2 2 2 2

13 ÷

14 ÷ 15 ÷ 16 ÷

Ε Ε Ε

4.096 ms 2.731 ms 2.048 ms

8.192 ms 5.461 ms 4.096 ms

16.384 ms 10.923 ms 8.192 ms

32.768 ms 21.845 ms 16.383 ms

Table 13 Real-Time Interrupt Rates (Frequency)

Frequency

RTR[1:0] Rate Selected E = 2.0 MHz E = 3.0 MHz E = 4.0 MHz

0 0 0 1 1 0 1 1

E ÷2 E ÷2 E ÷2 E ÷2

13 14 15 16

244.141 Hz 366.211 Hz 488.281 Hz

122.070 Hz 183.105 Hz 244.141 Hz

61.035 Hz 91.553 Hz 122.070 Hz

30.518 Hz 45.776 Hz 61.035 Hz

MOTOROLA M68HC11 K Series 70 MC68HC11KTS/D

11 Pulse Accumulator

M68HC11 K-series MCUs have an 8-bit counter that can be configured as a simple event counter or for gated time accumulation. The counter can be read or written at any time.

The port A bit 7 I/O pin can be configured to act as a clock in event counting mode, or as a gate signal to enable a free-running clock (E divided by 64) to the 8-bit counter in gated time accumulation mode.

Common XTAL Frequencies

8.0 MHz 12.0 MHz 16.0 MHz

CPU Clock (E) 2.0 MHz 3.0 MHz 4.0 MHz

Cycle Time (1/E) 500 ns 333 ns 250 ns

Pulse Accumulator (Gated Mode)

1 Count —

Overflow —

E ÷ 64 CLOCK

(FROM MAIN TIMER)

/E)

PAOVI

PAII

TMSK2 INT ENABLES

32.0 µs 21.33 µs 16.0 µs

8.192 ms 5.461 ms 4.096 ms

PAOVI PAOVF

INTERRUPT

PAII PAIF

PAIF

PAOVF

TFLG2 INTERRUPT STATUS

REQUESTS

PA7/

PAI/

OC1

MAIN TIMER

FROM

OC1

FROM

DDRA7

PAI EDGE PAEN

INPUT BUFFER

AND

EDGE DETECTOR

OUTPUT BUFFER

DATA BUS

PEDGE

PAEN

PAMOD

PACTL CONTROL

2:1

MUX

CLOCK

PAEN

INTERNAL DATA BUS

Figure 18 Pulse Accumulator System Block Diagram

DISABLE FLAG SETTING

OVERFLOW

PACNT 8-BIT COUNTER

ENABLE

M68HC11 K Series MOTOROLA MC68HC11KTS/D 71

TMSK2 —Timer Interrupt Mask 2 $0024

Bit 7 654321Bit 0

TOI RTII PAOVI PAII — — PR1 PR0

RESET: 0000000 0

TOI —Timer Overflow Interrupt Enable

Refer to 10 Main Timer.

RTII —Real-Time Interrupt Enable

Refer to 10 Main Timer.

PAOVI —Pulse Accumulator Overflow Interrupt Enable

0 = Pulse accumulator overflow interrupt disabled 1 = Pulse accumulator overflow interrupt enabled

PAII —Pulse Accumulator Input Interrupt Enable

0 = Pulse accumulator input interrupt disabled 1 = Pulse accumulator input interrupt enabled if PAIF bit in TFLG2 register is set

Bits [3:2] —Not implemented

Always read zero

PR[1:0] —Timer Prescaler Select

Refer to 10 Main Timer.

NOTE

Control bits [7:4] in TMSK2 correspond bit for bit with flag bits [7:4] in TFLG2. Ones in TMSK2 enable the corresponding interrupt sources.

TFLG2 —Timer Interrupt Flag 2 $0025

Bit 7 654321Bit 0 TOF RTIF PAOVF PAIF — — — —

RESET: 0000000 0

Clear flags by writing a one to the corresponding bit position(s).

TOF —Timer Overflow Enable

Refer to 10 Main Timer.

RTIF —Real-Time Interrupt Flag

Refer to 10 Main Timer.

PAOVF —Pulse Accumulator Overflow Flag

Set when PACNT changes from $FF to $00

PAIF —Pulse Accumulator Input Edge Flag

Set each time a selected active edge is detected on the PAI input line

Bits [3:0] —Not implemented

Always read zero

MOTOROLA M68HC11 K Series 72 MC68HC11KTS/D

PACTL —Pulse Accumulator Control $0026

Bit 7 654321Bit 0

— PAEN PAMOD PEDGE — I4/O5 RTR1 RTR0

RESET: 0000000 0

Bit 7 —Not implemented

Always reads zero

PAEN —Pulse Accumulator System Enable

0 = Pulse accumulator disabled 1 = Pulse accumulator enabled

PAMOD —Pulse Accumulator Mode

0 = Event counter 1 = Gated time accumulation

PEDGE —Pulse Accumulator Edge Control

0 = In event mode, falling edges increment counter. In gated accumulation mode, high level enables

accumulator and falling edge sets PAIF.

1 = In event mode, rising edges increment counter. In gated accumulation mode, low level enables

accumulator and rising edge sets PAIF.

I4/O5 —Input Capture 4/Output Compare 5

Refer to 10 Main Timer.

RTR[1:0] —Real-Time Interrupt Rate

Refer to 10 Main Timer.

PACNT —Pulse Accumulator Counter $0027

Bit 7 654321Bit 0 Bit 7 654321Bit 0

Can be read and written.

M68HC11 K Series MOTOROLA MC68HC11KTS/D 73

12 Pulse-Width Modulation Timer

M68HC11 K-series MCUs contains a PWM timer that is composed of a four-channel 8-bit modulator. Each of the modulators can create independent continuous waveforms with software-selectable duty rates from 0% to 100%.

The PWM provides up to four pulse-width modulated waveforms on port H pins. Each channel has its own counter. Pairs of counters can be concatenated to create 16-bit PWM outputs based on 16-bit counts. Three clock sources (A, B, and S) and a flexible clock select scheme give the PWM system a wide range of frequencies.

Four control registers configure the PWM outputs —PWCLK, PWPOL, PWSCAL, and PWEN. The PWCLK register selects the prescale value for the PWM clock sources and enables the 16-bit PWM functions. The PWPOL register determines each channel's polarity and selects the clock source for each channel. The PWSCAL register derives a user-scaled clock based on the A clock source, and the PWEN register enables the PWM channels.

Each channel has a separate 8-bit counter, period register, and duty cycle register. The period and duty cycle registers are double buffered so that if they are changed while the channel is enabled, the change does not take effect until the counter rolls over or the channel is disabled. A new period or duty cycle can be forced into effect immediately by writing to the period or duty cycle register and then writing to the counter.

With channels configured for 8-bit mode and E = 4 MHz, PWM signals of 40 kHz (1% duty cycle resolution) to less than 10 Hz (approximately 0.4% duty cycle resolution) can be produced. By configuring the channels for 16-bit mode with E = 4 MHz, PWM periods greater than one minute are possible.

In 16-bit mode, duty cycle resolution of almost 15 parts per million can be achieved (at a PWM frequency of about 60 Hz). In the same system, a PWM frequency of 1 kHz corresponds to a duty cycle resolution of 0.025%.

MOTOROLA M68HC11 K Series 74 MC68HC11TS/D

MCU

E CLOCK

PCKB1 PCKB2 PCKB3

÷ 1 ÷ 2 ÷ 4

÷ 8 ÷ 16 ÷ 32 ÷ 64

÷ 128

SELECT

PCLK3 PCLK4

SELECT

PCKA1 PCKA2

CLOCK B

CLOCK

SELECT

CNT3 CNT4

8-BIT COMPARE

PWSCAL

RESET

8-BIT COUNTER

PWEN3 PWEN4 CON34

PCLK1 PCLK2

CLOCK S

÷ 2

CLOCK A

CLOCK

SELECT

CNT1 CNT2

PWEN1 PWEN2 CON12

PWCNT1 PWCNT2

RESET

8-BIT COMPARE

PWDTY1

PWCNT3 PWCNT4

RESET

8-BIT COMPARE

PWDTY3

RESET

8-BIT COMPARE

PWPER2PWPER1

8-BIT COMPARE

PWDTY2

PWPER4PWPER3

PWDTY4

CARRY

16-BIT

PWM

CONTROL

CON34

16-BIT

PWM

CONTROL

CON12

SRQ

PPOL1

PPOL2

PPOL3

PPOL4

MUX

BIT 0

BIT 1

PORT H

CONTROL

BIT 2

BIT 3

PH0/ PW1

PH1/ PW2

PH2/ PW3

PH3/ PW4

PWM

OUTPUT

PWDTY

PWPER

Figure 19 Pulse-Width Modulation Block Diagram

M68HC11 K Series MOTOROLA MC68HC11TS/D 75

PWCLK —Pulse-Width Modulation Clock Select $0060

Bit 7 654321Bit 0

CON34 CON12 PCKA2 PCKA1 — PCKB3 PCKB2 PCKB1

RESET: 0000000 0

CON34 —Concatenate Channels 3 and 4

Channel 3 is high-order byte, and channel 4 is the low-order byte. The resulting output is available on port H, pin 3. Clock source is determined by PCLK4.

0 = Channels 3 and 4 are separate 8-bit PWMs. 1 = Channels 3 and 4 are concatenated to create one 16-bit PWM channel.

CON12 —Concatenate Channels One and Two

Channel 1 is high-order byte, and channel 2 is the low-order byte. The resulting output is available on port H, pin 1. Clock source is determined by PCLK2.

0 = Channels 1 and 2 are separate 8-bit PWMs. 1 = Channels 1 and 2 are concatenated to create one 16-bit PWM channel.

PCKA[2:1] —Prescaler for Clock A (See also PWSCAL register)

Determines the rate of clock A

PCKA[2:1] Value of Clock A

0 0 E 0 1 E/2 1 0 E/4 1 1 E/8

Bit 3 —Not implemented

Always reads zero

PCKB[3:1] —Prescaler for Clock B

Determines the rate for clock B

PCKB[3:1] Value of Clock B

0 0 0 E 0 0 1 E/2 0 1 0 E/4 0 1 1 E/8 1 0 0 E/16 1 0 1 E/32 1 1 0 E/64 1 1 1 E/128

PWPOL —Pulse-Width Modulation Timer Polarity $0061

Bit 7 654321Bit 0

PCLK4 PCLK3 PCLK2 PCLK1 PPOL4 PPOL3 PPOL2 PPOL1

RESET: 0000000 0

PCLK4 —Pulse-Width Channel 4 Clock Select

0 = Clock B is source 1 = Clock S is source

MOTOROLA M68HC11 K Series 76 MC68HC11TS/D

PCLK3 —Pulse-Width Channel 3 Clock Select

0 = Clock B is source 1 = Clock S is source

PCLK2 —Pulse-Width Channel 2 Clock Select

0 = Clock A is source 1 = Clock S is source

PCLK1 —Pulse-Width Channel 1 Clock Select

0 = Clock A is source 1 = Clock S is source

PPOL[4:1] —Pulse-Width Channel x Polarity

0 = PWM channel x output is low at the beginning of the clock cycle and goes high when duty count

is reached

1 = PWM channel x output is high at the beginning of the clock cycle and goes low when duty count

is reached

PWSCAL —Pulse-Width Modulation Timer Prescaler $0062

Bit 7 654321Bit 0

76543210

RESET: 0000000 0

Scaled clock S is generated by dividing clock A by the value in PWSCAL, then dividing the result by 2. If PWSCAL = $00, divide clock A by 256, then divide the result by 2.

PWEN —Pulse-Width Modulation Timer Enable $0063

Bit 7 654321Bit 0

TPWSL DISCP — — PWEN4 PWEN3 PWEN2 PWEN1

RESET: 0000000 0

TPWSL —PWM Scaled Clock Test Bit (TEST)

Factory test only

DISCP —Disable Compare Scaled E Clock (TEST)

Factory test only

Bits [5:4] —Not implemented

Always read zero

PWEN[4:1] —Pulse-Width Channel 4–1

0 = Channel disabled 1 = Channel enabled

PWCNT1–PWCNT4 —Pulse-Width Modulation Timer Counter 1 to 4 $0064–$0067

$0064 Bit 7 654321Bit 0 PWCNT1 $0065 Bit 7 654321Bit 0 PWCNT2 $0066 Bit 7 654321Bit 0 PWCNT3 $0067 Bit 7 654321Bit 0 PWCNT4

RESET: 00000000

PWCNT1–PWCNT4

Begins count using whichever clock was selected

M68HC11 K Series MOTOROLA MC68HC11TS/D 77

PWPER1–PWPER4 —Pulse-Width Modulation Timer Period 1 to 4 $0068–$006B

$0068 Bit 7 654321Bit 0 PWPER1 $0069 Bit 7 654321Bit 0 PWPER2 $006A Bit 7 654321Bit 0 PWPER3 $006B Bit 7 654321Bit 0 PWPER4

RESET: 11111111

PWPER1–PWPER4

Determines period of associated PWM channel

PWDTY1–4 —Pulse-Width Modulation Timer Duty Cycle 1 to 4 $006C–$006F

Bit 7 654321Bit 0 $006C Bit 7 654321Bit 0 PWDTY1 $006D Bit 7 654321Bit 0 PWDTY2 $006E Bit 7 654321Bit 0 PWDTY3 $006F Bit 7 654321Bit 0 PWDTY4

RESET: 11111111

PWDTY1–4

Determines duty cycle of associated PWM channel

12.1 PWM Boundary Cases

Certain values written to PWM control registers, counters, etc. can cause outputs that are not what the user might expect. These are referred to as boundary cases. Boundary cases occur when the user specifies a value that is either a maximum or a minimum. This value combined with other conditions causes unexpected behavior of the PWM system.

The following conditions always cause the corresponding output to be high: PWDTYx = $00, PWPERx > $00, and PPOLx = 0 PWDTYx ≥PWPERx, and PPOLx = 1 PWPERx = $00 and PPOLx = 1 The following conditions always cause the corresponding output to be low: PWDTYx = $00, PWPERx > $00, and PPOLx = 1 PWDTYx ≥PWPERx, and PPOLx = 0 PWPERx = $00 and PPOLx = 0

MOTOROLA M68HC11 K Series 78 MC68HC11TS/D

M68HC11 K Series MOTOROLA MC68HC11KTS/D 79

Motorola reserves the right to make changes without further notice to any products herein. Motorola makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does Motorola assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. "Typical" parameters which may be provided in Motorola data sheets and/or specifications can and do vary in different applications. All operating parameters, including "Typicals" must be validated for each customer application by customer's technical experts. Motorola does not convey any license under its patent rights nor the rights of others. Motorola products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the Motorola product could create a situation where personal injury or death may occur. Should Buyer purchase or use Motorola products for any such unintended or unauthorized application, Buyer shall indemnify and hold Motorola and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that Motorola was negligent regarding the design or manufacture of the part. MCUinit, MCUasm, MCUdebug, and RTEK are trademarks of Motorola, Inc. Motorola and the Motorola logo are registered trademarks of Motorola, Inc. Motorola, Inc. is an Equal Opportunity/Affirmative Action Employer.

How to reach us:

USA/EUROPE/Locations Not Listed: Motorola Literature Distribution;

P.O. Box 5405, Denver Colorado 80217. 1-800-441-2447, (303) 675-2140

Mfax™: RMFAX0@email.sps.mot.com - TOUCHTONE (602) 244-6609 INTERNET: http://Design-NET.com JAPAN: Nippon Motorola Ltd.; Tatsumi-SPD-JLDC,

6F Seibu-Butsuryu-Center, 3-14-2 Tatsumi Koto-Ku, Tokyo 135, Japan. 81-3-3521-8315 ASIA PACIFIC: Motorola Semiconductors H.K. Ltd.; 8B Tai Ping Industrial Park, 51 Ting Kok Road, Tai Po, N.T., Hong Kong. 852-26629298 Mfax is a trademark of Motorola, Inc.

MC68HC11KTS/D

Motorola MC68L11K0FN1, MC68L11K3FN1, MC68L11K3FU1, MC68L11K3FU3, MC68L11K4FN3 Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Features

Table 3 Custom ROM Device Ordering Information

Figure 1 Pin Assignments for 84-Pin PLCC/CLCC

Figure 3 M68HC11 K-Series Block Diagram

TABLE OF CONTENTS

REGISTER INDEX

2 Operating Modes

2.1 Single-Chip Operating Mode

2.2 Expanded Operating Mode

2.3 Bootstrap Mode

2.4 Special Test Mode

2.5 Mode Selection

3 On-Chip Memory

3.1 Memory Map and Register Block

Figure 4 Memory Map

Figure 5 RAM and Register Mapping

3.2 RAM

3.3 ROM/EPROM

3.4 EEPROM

3.5 Configuration Control Register (CONFIG)

3.6 Security Feature

4 Memory Expansion and Chip Selects

4.1 Memory Expansion

Table 5 CPU Address and Address Expansion Signals

4.2 Overlap Guidelines

4.3 Chip Selects

4.3.1 Program Chip Select (CSPROG)

4.3.2 I/O Chip Select (CSIO)

4.3.3 General-Purpose Chip Selects (CSGP1, CSGP2)

4.3.4 Chip Select Priorities

4.3.5 Chip Select Control Registers

Figure 7 Memory Expansion Example 1

Figure 8 Memory Expansion Example 2

5 Resets and Interrupts

6 Parallel Input/Output

7 Serial Communications Interface

Figure 9 SCI Baud Generator Circuit Diagram

Figure 10 SCI Transmitter Block Diagram

Figure 11 SCI Receiver Block Diagram

Table 7 SCI Baud Rate Control Values

8 Serial Peripheral Interface

Figure 12 SPI Block Diagram

Figure 13 SPI Transfer Format

Table 8 SPI Clock Rate Selects

9 Analog-to-Digital Converter

Figure 14 A/D Converter Block Diagram

Table 9 A/D Converter Channel Assignments

10 Main Timer

Table 10 Timer Summary

Figure 17 Timer Block Diagram

Table 11 Timer Control Configuration

10.1 Real-Time Interrupt

Table 13 Real-Time Interrupt Rates (Frequency)

11 Pulse Accumulator

Figure 18 Pulse Accumulator System Block Diagram

12 Pulse-Width Modulation Timer

Figure 19 Pulse-Width Modulation Block Diagram

12.1 PWM Boundary Cases
