MC68328

MC68328V

Product Brief

Integrated Portable System Processor—DragonBall

As the portable consumer market grows in full speed, the system requirements are becoming more rigorous
than ever. Minimum components, small board space, low power consumption, and low system cost are several
minimum criteria to a successful product. To address these needs, Motorola designed a new processor
MC68328 DragonBall

nc...

I

cost-effective performance to satisfy the extensive requirements of today’s portable consumer market.
The MC68328 (shown in Figure 1) is the first integrated processor of the 68K Family to include a LCD controller,

which demonstrates Motorola’s focus on the portable market. With addition to the LCD controller, MC68328
provides key features that are suitable for many portable applications. Modules like RTC, PWM, Timers, Master
SPI, Slave SPI, UART, and the System Integration Module (SIM28) facilitate the system engineer with more
flexibility and resources to design efficient and innovative products.

TM

. By providing 3.3V, fully static operation in an efficient package, the MC68328 delivers

ΤΜ

cale Semiconductor,

Frees

8-/16-Bit

68000 BUS

INTERFACE

CLOCK

SYNTHESIZER

AND

POWER

CONTROL

PCMCIA 1.0

SUPPORT

PROCESSOR

CONTROL

AND

PORTC

SYSTEM

INTEGRATION

MODULE

(SIM28)

RTC

INTERRUPT

CONTROLLER

68EC000 HCMOS

STATIC

CORE

DYNAMIC BUS SIZING EXTENSION

68EC000 INTERNAL BUS

LCD

CONTROL

MODULE

MASTER

SPI

PWM

MODULE

SLAVE

SPI

DUAL
16-BIT
TIMER

MODULE

UART

WITH

INFRA-RED

SUPPORT

Figure 1. MC68328 Block Diagram

This document contains information on a product under development. Motorola reserves the right to change or discontinue this product without notice.

MOTOROLA, 1995

For More Information On This Product,

Go to: www.freescale.com

nc...

I

cale Semiconductor,

Frees

Freescale Semiconductor, Inc.

KEY FEATURES

The primary features of the MC68328 are as follows:

• Static 68EC000 Core Processor—Identical to MC68EC000 Microprocessor
—Full Compatibility With MC68000 And MC68EC000

—32-Bit both External and Internal Address Bus capable of addressing 4GB Space
—16-Bit On-Chip Data Bus For MC68000 Bus Operations
—Static Design Allows Processor Clock To Be Stopped Providing Dramatic Power Savings
—2.7 MIPS Performance At 16.67-MHz Processor Clock

• External M68000 Bus Interface with Dynamic Bus Sizing for 8-bit and 16-bit Data Ports

• System Integration Module (SIM28), Incorporating Many Functions Typically Relegated to External Array
Logic, such as:

—System Configuration, Programmable Address Mapping
—Glueless Interface to SRAM, EPROM, FLASH Memory
—Sixteen Programmable Peripheral Chip Selects With Wait State Generation Logic
—Interrupt Controller with 13 flexible inputs
—Programmable Interrupt Vector Response For On-Chip Peripheral Modules
—Hardware Watchdog Timer
—Software Watchdog Timer
—Low-Power Mode Control
—Up to 78-Bit Individually Programmable Parallel I/O Ports
—PCMCIA 1.0 Support

• UART
—Support IrDA Physical Layer Protocol

—8 Bytes FIFO on Rx and Tx

• Two Separated Serial Peripheral Interface Ports (Master and Slave)
—Support For External POCSAG Decoder (Slave)

—Support for Digitizer from A/D Input or EEPROM (Master)

• Dual Channel 16-Bit General Purpose Counter/timer
—Multimode Operation, Independent Capture/Compare Registers

—Automatic Interrupt Generation
—240-ns Resolution At 16.67-MHz System Clock
—Each Timer Has An Input And An Output Pin for Capture and Compare

• Pulse Width Modulation Output For Sound Generation
—Programmable Frame rate

—16 Bit programmable
—Supports Motor Control

• Real Time Clock
—24 Hour Time

—One Programmable Alarm

• Power Management
—5 V or 3.3 V Operation

—Fully Static HCMOS Technology
—Programmable Clock Synthesizer for Full Frequency Control
—Low Power Stop Capabilities
—Modules Can Be Individually Shut-down
—Lowest Power Mode Control (Shut Down CPU and Peripherals)
