Motorola L511BT, L515BT, L513BT, L512BT, L502BT User Manual

...

User’s Guide

L511BT / L512BT / L513BT / L514BT /

L515BT / L502BT

DECT 6.0 Digital Cordless Phone with

Bluetooth

Use only the adapter and telephone line cord provided

and Answering System

Warning

in the box.

Welcome...

to your new Motorola Phone!

Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.

For product related questions, please call:

US and Canada: 1-888-331-3383

On the Web: www.motorola.com

• 30 name and number phonebook.

• Answering machine with 15 minutes digital recording time.*

• Caller ID shows you who is calling and includes details of the last 30 callers in a calls list.**

• Register up to 5 handsets to a single base.

• Make internal calls, transfer external home calls, hold 3-way conversation between two internal callers and an external caller, including home call or cellular call.

*The recording time includes the pre-recorded voice menu and outgoing announcements.

**You must subscribe to your network provider's Caller ID or Call Waiting service for these features to work.

Please note that this equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made if emergency telephone call is necessary.

This ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR

label indicating it meets the latest energy efficiency guidelines.

This User’s Guide provides you with all the information you need to get the most from your phone.

Before you make your first call you will need to set up your phone. Follow the simple instructions in 'Getting Started', on the next few pages.

IMPORTANT

Only use the telephone line cord supplied.

This equipment is not designed to make emergency telephone calls during power failures. Alternative arrangements should be made for access to emergency services.

Got everything?

• Handset

• Base

• NiMH rechargeable battery pack

• Battery door

• Power adapter

• Telephone line cord

• User’s Guide

• Quick Start Guide

In multihandset packs, you will find one or more additional handsets, chargers with power adapter units, additional rechargeable battery packs and battery doors.

1. Getting started ................................................6

1.1 Connect the base ............................................... 7

1.2 Install and charge the handset battery pack ........ 7

1.3 Set the display language .................................... 8

1.4 Set date and time ............................................... 8

2. Getting to know your phone ..........................9

3. Using the phone............................................13

3.1 Introducing Bluetooth........................................ 13

3.2 Bluetooth Setup ................................................ 14

3.2.1 Setup Cellular ....................................... 14

3.2.2 Replace a paired device ....................... 14

3.2.3 Paired Devices ...................................... 15

3.3 Making a home call using your landline............ 15

3.4 Making a cellular call using your cordless

DECT handset.................................................. 16

3.5 Speed dial calling ............................................. 16

3.6 Answering a home call ..................................... 16

3.7 Answering a cellular call ................................... 16

3.8 Receiving a cellular call while on a home call .......17

3.9 Receiving a home call while on a cellular call ...... 17

3.10 Ending a call ..................................................... 17

3.11 Adjusting volume .............................................. 18

3.12 Muting a call ..................................................... 18

3.13 Dialing from the redial list ..................................18

3.14 Dialing from the calls list ....................................18

3.15 Adding an entry to the phonebook ....................18

3.16 Storing a phonebook entry as a

one touch number .............................................19

3.17 Dialing from the phonebook ..............................19

3.18 Caller ID ............................................................19

3.18.1 Calls List ................................................20

3.18.2 View the calls list ...................................20

3.18.3 Save a number from the calls list to

the phonebook .......................................20

3.18.4 Delete a calls list entry ...........................21

3.18.5 Delete entire calls list .............................21

3.19 Personal Settings ..............................................22

3.20 Intercom ............................................................23

3.20.1 Call another handset ..............................23

3.20.2 Transfer an external home call to

another handset .....................................23

3.20.3 Three-party conference call ...................24

3.21 Set the dial mode ..............................................24

3.22 Set the Flash Time ............................................24

3.23 Set the Area Code .............................................25

3.24 Registration .......................................................25

3.25 To reset all settings ...........................................25

3.26 Paging/Find handset ......................................... 26

3.27 Using your answering machine ......................... 26

3.27.1 Play messages ...................................... 26

3.27.2 Turn on or off the answer machine .........27

3.27.3 Set the announcement mode ................27

3.27.4 Set the number of rings .........................27

3.27.5 Announcement ......................................27

3.27.6 Record a memo ..................................... 28

3.27.7 Call screening on/off ..............................29

3.27.8 Delete all old messages ........................ 29

3.27.9 Remote access ...................................... 29

3.27.10Set the security code ............................. 30

4. Help................................................................ 31

5. General information ..................................... 33

1. Getting started

WARNING

Do not place your phone in the bathroom or other humid areas.

Location

When choosing a location for your new phone, here are some important guidelines you should consider:

• Avoid sources of noise and heat, such as motors, fluorescent lighting, microwave ovens, heating appliances and direct sunlight.

• Avoid areas of excessive dust, moisture, and low temperature.

• Avoid other cordless telephones or personal computers.

• Never install telephone wiring during a lightning storm.

• Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

• Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.

• Use caution when installing or modifying telephone lines.

6 Getting started

HANDSET RANGE

Optimal range is reached when there are no other electrical appliances working within the range area. Any obstruction between the base and handset will also reduce the range significantly.

SIGNAL STRENGTH

When out of range of the base, the screen shows

SEARCHING....

Move back within in range of the base. The handset will automatically re-connect to the base.

If you are on a call, the line will disconnect.

Setting up

IMPORTANT

The base must be plugged into an electrical outlet at all times. Do not connect the telephone line cord into a power outlet until the handset is fully charged. Only use adapter and telephone line cord supplied with the product.

WHICH POWER ADAPTER

The power adapter with the smaller pin is for the base unit and the power adapter with the larger pin is for the charger unit (only for multi-handset packs).

1.1 Connect the base

1.2 Install and charge the handset battery pack

Plug the power adapter with the smaller round pin plug and telephone line cord into the base. The power adapter with the larger round pin is for the charger (only in multi-handset packs).

Plug the other end of the power adapter and telephone line cord into a power outlet.

Use only the provided power adapter.

Getting started 7

Slide off the battery compartment cover to remove it. Place the supplied rechargeable battery pack in the battery compartment, with the battery connector plugged in, as shown.

Slide the battery compartment cover back on.

Put the handset on the base to charge for at least 24 hours. Once charged, the (battery icon) will indicate that the handset is fully charged.

IMPORTANT

Use only the rechargeable battery pack provided with the product.

1.3 Set the display language

Press MENU and then VOL+ or REDIAL/VOL- to select

SETUP HS

. Repeat to select Repeat to select language.

Press MENU to save.

LANGUAGE

Press MENU and then edit the time in 12hr format. Press VOL+ or REDIAL/VOL- to toggle

Press MENU to save the settings.

Your phone is now ready for use.

AM/PM

settings.

1.4 Set date and time

Press MENU to select to your network's Caller ID service, date and time is automatically set when a call is received.

Repeat to edit the year and date.

Press VOL+ or REDIAL/VOL- to move between the input fields

8 Getting started

YEAR

and

DATE & TIME

DATE

. If you're a subscriber

2. Getting to know your phone

Overview of your handset

Get acquainted with the following 14 buttons on your handset and their multi-function tasks.

1 Menu / Select

a) In idle mode: Press to access menu list. b) In menu/editing mode: Press to confirm and save the

settings.

c) During a home call: Press to transfer a call to a second

handset.

d) In calls list entry: Press to save the entry to the

phonebook.

e) In phonebook entry: Press to go to phonebook editing

mode.

2 Scroll up / Volume up

a) In menu mode: Press to scroll up. b) In editing mode: Press to move cursor to the left. c) During a call: Press to increase volume. d) Calls list/phonebook/redial list entry: Press to scroll up

the list.

e) In answering machine mode: Press to increase volume.

3 Right / Calls list

a) In idle mode/during a call: Press to access calls list. b) In editing mode: Press to move the cursor to the right.

4 Scroll down / Volume down / Redial list

a) In idle/pre-dial mode: Press to access redial list. b) In menu mode: Press to scroll down.

Getting to know your phone 9

c) In editing mode: Press to move cursor to the right. d) During a call: Press to decrease volume. e) Calls list/phonebook/redial list entry: Press to scroll

down the list.

f) In answering machine mode: Press to decrease

volume.

5 Talk off / Back

a) In menu/editing mode/phonebook entry: Press to exit

to previous level.

b) In pre-dial mode/calls list/redial list entry/answering

machine mode: Press to exit to idle.

c) During ringing: Press to silent the incoming ringer

temporarily.

d) During a call: Press to end a call, either home call or

cellular call.

6 Alphanumeric keypad

a) In idle/pre-dial/editing mode/during a call: Press to

enter characters/numbers. Press and hold to activate speed dial.

7 # / Pause / ABC / Format

a) In idle/pre-dial/number editing mode/during a call:

Press to insert a #, press and hold to insert a space.

b) In name editing mode: Toggle ABC/abc. c) In calls list entry: Press to toggle between 7, 10 and 11

digit formats when returning calls from Caller ID list.

d) In phonebook list entry: If the number is more than 15

digits, press to view the next page of remaining digits.

8Cellular

a) In idle mode: Press to make a cellular call. b) During an incoming cellular call: Press to answer the

cellular call.

9 Microphone 10 Speaker

a) In idle/menu/pre-dial mode/during a call: Press to turn

on/off the speakerphone.

b) Call List/phonebook/redial list entry: Press to make a

call with speakerphone.

c) During ringing: Press to answer a call with the

speakerphone.

d) In answering machine mode: Press to toggle the

message playback via the earpiece or speakerphone.

11 * / Tone

a) In idle/pre-dial/editing mode: Press to insert a *. b) During a call: Press to switch from pulse to tone dialing

temporarily if pulse mode was selected before. After the call has ended, the dial mode will change back to pulse.

c) In phonbook list entry: If the number is more than 15

digits, press to view the previous page of remaining digits.

10 Getting to know your phone

12 Talk on/ Flash

a) In idle/menu/pre-dial mode: Press to make a call. b) Call List/phonebook/redial list entry: Press to make a

call to the selected entry.

c) During an incoming call: Press to answer the call. d) During a home call: Press flash to switch to another call.

13 Left/ Phonebook

a) In idle mode/during a call: Press to access the

phonebook.

b) In editing mode: Press to move the cursor to the left.

14 Answering Machine/ Mute/ Clear/ X

a) In idle mode: Press to play the message in answering

machine.

b) In pre-dial/editing mode: Press to delete one character/

digit. Long press to delete all characters/digits.

c) During a call: Press to mute/unmute the call. d) In calls list/phonebook entry: Press to delete the entry. e) In answering machine mode: Press to delete the

current message playback.

Handset LCD display

Display icons

On when speakerphone is turned on. On when the answering machine is turned on.

Flashes when a new message is received.

Indicates that a new call has been received.

Off after all new calls have been reviewed.

Indicates that the ringer volume is off.

If a voice mail service is being used, this icon in dicates

that there is a new voice mail message. The icon is of f after all new voice mails have been reviewed. (For home line only)

Getting to know your phone 11

On when a call is muted.

Full battery power level.

2/3 battery power level.

1/3 battery power level.

Flashes when low battery level is detected, needs

charging.

Animation in motion. Battery is charging.

In idle mode, the current time is displayed.

In Caller ID mode, the time of call is displayed.

On when the Home line is in use.

Flashes when the Home line is put on hold. Off when the Home line is idle.

On when the Cellular line is in use.

Flashes when the Cellular line is put on hold. Off when the Cellular line is idle.

On when a Bluetooth device is

Off when Bluetooth feature is disabled.

12 Getting to know your phone

connected.

/ On when Bluetooth device or is connected with

the telephone base. Off When Bluetooth device(s) is (are) disconnected from the telephone base.

In idle mode the current date is displayed.

In Caller ID mode, the date of the call is displayed.

Overview of the base

1FIND

Press to find/page all registered handsets. Press the button again, or any key on the handset, to turn off page signal.

HOME

3. Using the phone

3.1 Introducing Bluetooth

Your new telephone system with Bluetooth wireless technology has the following features:

• Pairing a Bluetooth enabled mobile phone with the telephone base. Two Bluetooth devices can be paired up and connected.

• Connecting a Bluetooth enabled mobile phone to make and receive connected but only one of them can be used at a time.

• Making and receiving calls using your Bluetooth enabled mobile phone plan while benefiting from the ease and comfort of your home telephone system.

Glossary of terms

Below are some terms used in this User's Guide to help you become familiar with using your Bluetooth devices and your new telephone system.

Bluetooth mobile phone

mobile telephone.

CELLULAR

through your Bluetooth enabled mobile telephone.

Using the phone 13

CELLULAR

calls. Two mobile phones can be

- Refers to a Bluetooth enabled

line - The communications service provided

line - Your conventional telephone land line.

Pairing

- This refers to the process of two Bluetooth devices registering device information with each other. The telephone base must be paired with a Bluetooth enabled mobile phone before the Bluetooth device can be used.

IMPORTANT INFORMATION

• Refer to your mobile phone user's guide for more

information about its Bluetooth function.

• Make sure that your Bluetooth enabled mobile phone is

between one to twelve feet away from the telephone base in order to maintain a clear and consistent connection between your Bluetooth mobile phone, telephone base and cell tower.

• Make sure that your Bluetooth enabled mobile phone has

sufficient signal strength. You may need to move the Bluetooth enabled mobile phone and telephone base to a location where the cellular signal may be stronger.

• Charge your Bluetooth mobile phone while it is

connected to the telephone base because your mobile phone's battery will discharge faster while it is connected wirelessly to the telephone base.

+ 30 hidden pages
