Motorola
Keylink
let’s get started
en
Attach the lanyard
Attach the lanyard, then hook the metal loop to a key ring or strap.
123
Caution: Before using your device, please read the safety, regulatory, and legal
information at the back of this guide and at www.motorola.com/motokeylinklegal.
For more help, visit www.motorola.com/support or contact the Motorola Customer
Support Center at: 1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD United
States for hearing impaired), or 1-800-461-4575 (Canada).
1en
Turn on Keylink
motorola connect
motorola connect
Long press the Power button to turn Keylink on or off.
Keylink beeps to let you know when it turns on.
Tip: To check if Keylink is on, quick press the Power button. The
status light flashes to confirm Keylink is turned on.
Pair Keylink with your phone
Keylink is a Bluetooth® Smart Device. Your phone needs
Android™ 4.3 or later to work with Keylink.
Download Motorola Connect: On your phone, download and install
the Motorola Connect app from Google Play™ Store or Apple
App Store™. Launch the app and follow the prompts to pair Keylink
with your phone.
Find your phone
Double press Keylink’s Power button to find your lost phone.
Keylink’s status light flashes and your phone rings.
To stop the phone from ringing, press Keylink’s Power button.
Note: Keylink can find your phone up to about 100 feet.
2 Tu rn on Ke yl in k en
Find your keys
On your phone, launch the Motorola Connect app and use the Ping feature to find your
lost Keylink device.
Keylink will beep when it’s within range of your phone.
Keep your phone unlocked
Do you use a PIN to lock your phone? Keylink minimizes the number of times you have
to unlock it.
On your phone, launch the Motorola Connect app and enable the trusted devices
feature for Keylink. Each time you connect, enter your PIN and your phone will stay
unlocked as long as you are connected.
Note: This feature works on Motorola phones with Trusted Device feature installed. If
you have corporate security policies installed, you may be prevented from using this
feature.
3en Find your keys
Replace the battery
123
Use a small screw driver Remove old battery &
insert new battery with
negative (-) terminal facing up.
Align and snap
on battery cover.
to pry o battery cover.
Keylink’s battery life is expected to be over one year with normal use. The Motorola
Connect app notifies you when you need to replace the battery.
Note: Keylink uses a standard size CR2032 lithium ion coin cell battery.
Keylink turns on automatically when the battery door is closed and beeps to let you
know the battery is installed correctly.
4 Replace the battery en
Safety, Regulatory, & Legal
0168
0168
Type
Name
Children
Children
Keep your product and its accessories away from small chil dren.
children. For example, a choking hazard may exist for small, detachable parts.
European Union Directives Conformance Statement
EU Conformance
The following CE compliance information is applicable to Motorola products that carry one of the following CE marks:
Hereby, Motorola declares that this product is in compliance with:
•
The essential requirements and other relevant provisions of Directive 1999/5/EC
•
All other relevant EU Directives
For products that support Wi-Fi 802.11a (as defined in your product information): Outside the United States, this device is
restricted to indoor use when operating in the 5.15 to 5.25 GHz (802.11a) Wi-Fi frequency band.
The following gives an example of a typical Type name:
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at
www.motorola.com/rtte
bar on the website.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo and/or FCC ID on the product label.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. See 47 CFR Sec. 15.105(b). These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
(in English only). To find your DoC, enter the Type name from your product’s label in the “Search”
These products are not toys and may be hazardous to small
5en Safety, Regulatory, & Legal
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. See 47 CFR Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the
user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
For products that support Wi-Fi 802.11a (as defined in product information): In the United States, do not use your device outdoors
while connected to an 802.11a Wi-Fi network. The FCC prohibits such outdoor use since frequencies 5.15-5.25 GHz can cause
interference with Mobile Satellite Services (MSS). Public Wi-Fi access points in this range are optimized for indoor use.
Industry Canada Notice to Users
Industry Canada Notice
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference and (2) This device must accept any interference, including interference that may
cause undesired operation of the device. See RSS-Gen, Section 7.1.3. This device complies with ICES-003 requirements for Class
B ITE (Information Technology Equipment).
Motorola Limited Warranty
Warran t y
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Mobility LLC warrants its mobile telephones (“Products”), Motorola-branded
or certified accessories sold for use with these Products (“Accessories”), and Motorola software contained on CD-ROMs or other
tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under
normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as
follows to new Motorola Products, Accessories, and Software purchased by consumers, which are accompanied by this written
warranty:
Products and Accessories
Products Covered Length of Coverage
Products and Accessories
otherwise provided for below.
CAN ICES-3 (B)/NMB-3(B)
as defined above, unless
One (1) year
from the date of purchase by the first consumer
purchaser of the product unless otherwise provided for below.
6 Safety, Regulatory, & Legal en
Products Covered Length of Coverage
Decorative Accessories and Cases.
covers, bezels, and cases.
Monaural Headsets.
transmit mono sound through a wired connection.
Products and Accessories that are Repaired or
Replace d.
Exclusions (Products and Accessories)
Normal Wear and Tear.
coverage.
Batteries.
by this limited warranty.
Abuse & Misuse.
as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain,
extreme humidity or heavy perspi ration, sand, dirt or the like, extreme heat, o r food; (c) use of the Prod ucts or Accessories for
commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the
fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification.
maintenance, alteration, or modification i n any way by someone other than Motorola, or its authorized service centers, are
excluded from coverage.
Altered Products.
(b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or
non-Motorola housings, or parts, are excluded from coverage.
Communication Services.
service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.
Ear buds and boom headsets that
Periodic maintenance, repair and replacement of parts due to normal wear and tear are excluded from
Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered
Defects or damage that result from: (a) improper operation, storage, misuse or abuse, accident or neglect, such
Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated;
Decorative
Defects or damages resulting from service, testing, adjustment, installation,
Defects, damages, or the failure of Products, Accessories or Software due to any communication
Limited lifetime warranty
consumer purchaser of the product.
Limited lifetime warranty
consumer purchaser of the product.
The balance of the original warranty or for ninety (90) days
from the date returned to the consumer, whichever is longer.
Defects or damage that result from the use of non-Motorola branded or
for the lifetime of ownership by the first
for the lifetime of ownership by the first
7en Safety, Regulatory, & Legal
Software
Products Covered Length of Coverage
Software.
Applies only to physical defects in the media that embodies
the copy of the software (e.g. CD-ROM).
Exclusions (Software)
Software Embodied in Physical Media.
combination with any hardware or software applicati ons provided by third parties, tha t the operation of the soft ware products will
be uninterrupted or error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
from the Internet), is provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that
does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products,
Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to
personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software, and applications, please create
a back up prior to requesting service.
How to Obtain Warranty Service or Other Information
Please contact Motorola using the contact details provided on the customer support website at
www.motorola.com/support
You will receive instructions on how and where to ship the Product for assessment. We will generally need: (i) proof of purchase;
(ii) a written description of the problem; (iii) the name of your mobile network service provider, if applicable; (iv)your address and
telephone number. We will only use this information for the purposes of processing your claim under this Limited Warranty.
You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized
Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase;
(b) a written description of the problem; (c)the name of your service provider, if applicable; (d) the name and location of the
installation facility (if applicable) and, most importantly; (e) your address and telephone number.
What Other Limitations are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE
THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO
EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDI NG NEGLIGENCE) FOR DAMAGES IN
8 Safety, Regulatory, & Legal en
No warranty is made that the software will meet your requirements or will work in
Software that is not embodied in physical media (e.g. software that is downloaded
.
Ninety (90) days
from the date of purchase.
EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT
OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE
FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or li mitation
on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary from state to st ate or from one jurisdiction to another.
Copyright & Trademarks
Motorola Mobility LLC
222 W. Merchand ise Mart Plaza
16th Floor
Chicago, IL 60654
www.motorola.com
Note:
Do not ship your product to the above address. If you need to return your product for re pairs, replacement, or warranty
service, please contact the Motorola Customer Support Center at:
1-800-734-5870 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. All other
product or service names are the property of their respective owners.
© 2014 Motorola Mobility LLC. All rights reserved.
Caution:
Motorola does not take responsibility for changes/modification to the transceiver.
Product ID: Motorola Keylink
Manual Number: 68017604001-A
9en Safety, Regulatory, & Legal
Loading...
