Motorola E51 User Manual
E51 Series
Digital Expansion Handset
5.8 GHz
Model Family: MD7101
Users Guide
For a copy of a large-print version of this guide, or for
product-related questions, please visit us online:
www.motorola.com/cordless
Or contact us at:
1-800-353-2729 U.S.A.
1-800-461-4575 Canada
1-888-390-6456 TTY (Text Telephone)
Motorola reserves the right to revise this publication and to make changes in content from time to time
without obligation on the part of Motorola to provide notification of such revision or change.
MOTOROLA PROVIDES THIS GUIDE WITHOUT WARRANTY OF ANY KIND, EITHER IMPLIED OR
EXPRESS, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. Motorola may make improvements or changes in the
product(s) described in this manual at any time.
MOTOROLA and the Stylized M logo are registered in the U.S. Patent and Trademark Office. All other
product or service names are the property of their respective owners.
© Motorola, Inc. 2006
Table of Contents
FCC Information ...........................................................................................................v
FCC Compliance Class B Digital Device.................................................... v
FCC Declaration of Conformity.............................................................. vi
Canadian Compliance ......................................................................... vi
Federal Communications Commission (FCC) Part 68 Statement .................... vi
Industry Canada CS-03 Declaration of Conformity ..................................... viii
Important Safety Instructions .............................................................................ix
Welcome......................................................................................................................1
Handset Overview .................................................................................................2
Handset Charger Overview....................................................................................3
Getting Started .........................................................................................................4
Battery Safety Instructions.....................................................................................4
Installing the Battery ..............................................................................................5
Charging the Handset Battery................................................................................6
MD7101 User Guide
i
Installing the Base Unit ...............................................................................................7
Basic Operations ..........................................................................................................9
Handset Indicators.................................................................................................9
Base Unit LEDs...................................................................................................... 9
Making a Call .......................................................................................................10
Answering Calls ...................................................................................................11
Ending a Call ........................................................................................................11
Speakerphone Operation .....................................................................................11
Adjust Handset Volume .......................................................................................12
Temporary Ringer Adjustments...........................................................................13
Redial Function ....................................................................................................13
Deleting a Redial Listing ......................................................................................14
Mute Function .....................................................................................................14
Locate a Misplaced Handset ...............................................................................15
MD7101 User Guide
Phonebook Operations.............................................................................................. 16
Storing a New Entry............................................................................................. 17
ii
Reviewing/Dialing from the Phonebook...............................................................19
Editing a Phonebook Entry ...................................................................................20
Delete a Single Phonebook Entry.........................................................................20
Caller ID/Call Waiting ID .......................................................................................21
Reviewing Caller ID Records................................................................................22
Storing a Caller ID Entry in the Phonebook ..........................................................23
Dialing from the Caller ID Log ..............................................................................24
Deleting a Caller ID Record ..................................................................................24
Deleting All Caller ID Records ..............................................................................24
Ringer Volume......................................................................................................25
Ringer Tone..........................................................................................................25
Key Tone ..............................................................................................................26
Display Language .................................................................................................26
Dialing Method.....................................................................................................27
Message Waiting Indicator ..................................................................................27
Special Features .........................................................................................................28
MD7101 User Guide
iii
Intercom Calls......................................................................................................28
Call Transfer.........................................................................................................29
Conference Call ...................................................................................................30
In Case of Difficulty....................................................................................................31
Warranty .....................................................................................................................33
Technical Specifications............................................................................................38
MD7101 User Guide
iv
FCC Information
FCC Compliance Class B Digital Device
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Privacy of communications may not be ensured when using this telephone.
Caution: Changes or modifications not expressly approved by Motorola for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
MD7101 User Guide
v
FCC Declaration of Conformity
Motorola, Inc., Connected Home Solutions, 101 Tournament Drive, Horsham, PA 19044,
1-215-323-1000, declares that this cordless phone complies with 47 CFR Parts 2 and 15 of the FCC
Rules as Class B digital devices.
Canadian Compliance
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B
est conforme á la norme NMB-003 du Canada.
Federal Communications Commission (FCC) Part 68
Statement
This Motorola cordless phone complies with Part 68 of the FCC rules and the requirements adopted by
the Administrative Council for Terminal Attachments (ACTA). On the bottom of this equipment is a label
that contains, among other information, a product identifier in format US: AAAEQ##TXXXX. If requested,
this information must be provided to the telephone company.
The Ringer Equivalence Number (REN) is used to determine the number of devices that may be
connected to the telephone line. Excessive RENs on the telephone line may result in the devices not
ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not
exceed five (5.0). To be certain of the number of devices that may be connected to the line, as
determined by the total RENs, contact the telephone company.
MD7101 User Guide
vi
For products approved after July 23, 2001, the REN for this product is part of the product identifier that
has the format US: AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point
(e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label.
This equipment uses the following USOC jack: RJ11C. A plug and jack used to connect this equipment
to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this
product. It is designed to be connected to a compatible modular jack that is also compliant. See
installation instructions for details.
Connection to Party Line Service is subject to state tariffs. Contact the state public utility commission,
public service commission, or corporation commission for information. If this equipment causes harm to
the telephone network, the telephone company will notify you in advance that the temporary
discontinuance of services may be required. If advance notice is not practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint
with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that
could affect the operation of the equipment. If this happens, the telephone company will provide
advance notice in order for you to make necessary modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, for repair or warranty information, please contact
Motorola, Inc. at 1-877-466-8646. If the equipment is causing harm to the telephone network, the
telephone company may request that you disconnect the equipment from the network until the problem
is solved.
MD7101 User Guide
vii
This equipment is hearing aid compatible.
If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of the cordless phone does not disable your alarm equipment. If you have questions about
what will disable alarm equipment, consult your telephone company or a qualified installer.
CAUTION: To maintain compliance with the FCC's RF exposure guidelines, place the base unit at least
7.87 in (20 cm) from nearby persons.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when
used with the belt clip supplied or designated for this product. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
Industry Canada CS-03 Declaration of Conformity
This product meets the applicable Industry Canada technical specifications. The Ringer Equivalence
Number (REN) is an indication of the maximum number of devices allowed to be connected to a
telephone interface. The termination on an interface may consist of any combination of devices subject
only to the requirement that the sum of the RENs of all the devices does not exceed five.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment on and off, the user is encouraged to try to correct the
interference with one or more of the following measures: Reorient or relocate the receiving antenna
(that is, the antenna for the radio or television that is "receiving" the interference).Reorient or relocate
and increase the separation.
MD7101 User Guide
viii
Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bathtub, kitchen sink, or
swimming pool).
5. Do not place this product on an unstable surface, such as a table, shelf, or stand. The
product may fall, causing serious damage.
6. Slots and openings in the back or bottom of the base unit and handset are provided
for ventilation. To protect them from overheating, these openings must not be
blocked by placing the product on a soft surface such as a bed, sofa, or rug. This
product should never be placed near or over a radiator or heat register. This product
should not be placed in any area where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply in your home, consult
your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not install this product where the
cord may have anyone walking on it.
MD7101 User Guide
ix
9. Never push objects of any kind into this product through slots in the base or handset,
as they may touch dangerous voltage points or short out parts that could result in a
risk of fire or electric shock.
10. Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble this product, but take it to an
authorized service facility. Opening or removing parts of the base or handset other
than specified access doors may expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock when the product is subsequently
used.
12. Do not overload wall outlets and extension cords, as this can result in the risk of fire or
electric shock.
13. Unplug this product from the wall outlet and refer servicing to an authorized service
facility under the following conditions:
• When the power supply cord or plug is damaged or frayed.
• If liquid has been spilled onto the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions, as
improper adjustment of other controls may result in damage and often requires
extensive work by an authorized technician to restore the product to normal
MD7101 User Guide
operation.
• If the product has been dropped and the base and/or handset has been
damaged.
• If the product exhibits a distinct change in performance.
x
14. Avoid using a telephone (other than cordless) during an electrical storm. There is a
remote risk of electric shock from lightning.
15. Do not use the telephone to report a gas leak in the vicinity of the leak.
16. Only put the handset of your telephone next to your ear when it is in normal talk
mode.
MD7101 User Guide
xi
Welcome
Congratulations on your purchase of a Motorola MD7101 expansion handset. Check the
contents listing on the product packaging to ensure that your purchase includes each of the
items listed.
Product registration is an important step toward enjoying your new Motorola product.
Registering helps us facilitate warranty service and permits us to contact you should your
Motorola product require an update or other service. Registration is not required for
warranty coverage.
To register your product online, visit:
http://broadbandregistration.motorola.com
Product registration is not available in Canada.
Please retain your original dated sales receipt for your records. For warranty service of your
Motorola product, you will need to provide a copy of your dated sales receipt to confirm
warranty status.
MD7101 User Guide
1
Handset Overview
1. Earpiece
2. LCD display
3. Select/Menu
4. Caller ID/Scroll down
5. Headset jack (2.5 mm)
6. Phone On/Flash
7. Speakerphone
8. Temporary tone dialing key
9. Redial/Pause
10. Mute/Delete
11. Microphone
12. Intercom
13. Change number format
14. Phone Off/Cancel
15. Volume control
16. Phonebook/Scroll up
1
2
3
4
5
6
7
16
15
14
MD7101 User Guide
2
8
9
10
13
12
11
Loading...
