Motorola E310 User Manual

START HERE >

Welcome

Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola E310 CDMA wireless phone.

Left Soft Key

Perform functions

identified by left

display prompt.

Send Key

Send & answer calls,

view recently dialed

calls list

Jog Dial

Adjust earpiece &

ringer volume.

Clear Key

Delete text or go

back

Microphone

Accessory Connector Port

Insert charger & phone accessories.

Menu Key

Headset Jack

Insert headset accessory for handsfree use.

Right Soft Key

Perform functions identified by right display prompt.

Voice Key

Record voice notes, contact and shortcut names.

Power Key End Key

Turn phone on/off.

End calls and exit the menu system

5-Way Navigation Key

Scroll through menus & lists, set feature values & access main menu.

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)

www.motorola.com www.motorola.ca

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Manual number: 6809467A45-O Cover number: 8988485L61-O

(United States)

(Canada)

Safety and General Information Getting Started

What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Changing the Convertible Covers . . . . . . . . . . . . . . . . . 17

Attaching the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 18

Adjusting Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Changing the Ring Tone Volume. . . . . . . . . . . . . . . . . . 20

Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 20

Learning to Use Your Phone

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the 5-Way Navigation Key . . . . . . . . . . . . . . . . . . 25

Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Using the External Display . . . . . . . . . . . . . . . . . . . . . . 39

Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 39

Changing a Code or Password . . . . . . . . . . . . . . . . . . . 41

If You Forget a Code or Password. . . . . . . . . . . . . . . . . 41

Setting Up Your Phone

Storing Your Name and Phone Number . . . . . . . . . . . . 43

Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . 43

Setting a Alert Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . . . . . . . . 21

Setting Answer Options . . . . . . . . . . . . . . . . . . . . . . . . . 44

Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . . 44

Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . . 45

Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . 46

Setting Display Color . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Rhythm Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Hiding or Showing Location Information . . . . . . . . . . . . . 49

Calling Features

Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 51

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 53

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Calling an Emergency Number. . . . . . . . . . . . . . . . . . . . 53

Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 56

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Assigning a Speed Dial Number. . . . . . . . . . . . . . . . . . . 57

Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 58

Calling With 1-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . . 58

Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Muting the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Phone Features

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . 64

Specific Absorption Rate Data Consumer Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

. . . . . . . . . . . . . . . . . . . . 75

on Wireless Phones from the FDA Warranty Product Registration Export Law Assurances RF Energy Interference Index Wireless Phone Safety Tips

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

. . . . . . . . . . . . . . . . . . . . . . . . . . . 87

. . . . . . . . . . . . . . . . . . . . . . . . . 87

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

. . . . . . . . . . . . . . . . 77

. . . . . . . . . . . . . . . . . . . . . . 96

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR PHONE.

The information provided in this document supersedes the general safety information in user’s guides published prior to December 1, 2002.

Exposure To Radio Frequency (RF) Energy

Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.

Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

To assure optimal phone performance and make sure human exposure to RF energy is within the guidelines set forth in the relevant standards, always adhere to the following procedures.

External Antenna Care

Use only the supplied or Motorola-approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone.

Do NOT hold the external antenna when the phone is IN USE. Holding the external antenna affects call quality and may cause the phone to operate at a higher power level than needed. In addition, use of unauthorized antennas may result in non-compliance with the local regulatory requirements in your country.

Phone Operation

When placing or receiving a phone call, hold your phone as you would a wireline telephone.

Body-Worn Operation

To maintain compliance with RF energy exposure guidelines, if you wear a phone on your body when transmitting, always place the phone in a Motorola-supplied or approved clip, holder, holster, case, or body harness for this phone, if available. Use of accessories not approved by Motorola may exceed RF energy exposure guidelines. If you do not use one of the body-worn accessories approved or supplied by Motorola, and are not using the phone held in the normal use position, ensure the phone and its antenna are at least 1 inch (2.5 centimeters) from your body when transmitting.

Data Operation

When using any data feature of the phone, with or without an accessory cable, position the phone and its antenna at least 1 inch (2.5 centimeters) from your body.

Approved Accessories

Use of accessories not approved by Motorola, including but not limited to batteries and antenna, may cause your phone to exceed RF energy exposure guidelines. For a list of approved Motorola accessories, visit our website at

RF Energy Interference/Compatibility

Note:

interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your phone may cause interference.

Facilities

Turn off your phone in any facility where posted notices instruct you to do so. These facilities may include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

www.Motorola.com

Nearly every electronic device is susceptible to RF energy

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker.

Persons with pacemakers should:

•

ALWAYS keep the phone more than 6 inches (15 centimeters) from your pacemaker when the phone is turned ON.

•

NOT carry the phone in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the potential for interference.

•

Turn OFF the phone immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

Use While Driving

Check the laws and regulations on the use of phones in the area where you drive. Always obey them.

When using your phone while driving, please:

•

Give full attention to driving and to the road.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a call if driving conditions so require.

Responsible driving best practices may be found in the “Wireless Phone Safety Tips” at the end of this manual and at the Motorola website:

www.Motorola.com/callsmart

Operational Warnings

For Vehicles With an Air Bag

Do not place a phone in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive atmosphere, unless it is a phone type especially qualified for use in such areas and certified as “Intrinsically Safe.” Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death.

Note:

The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Areas with potentially explosive atmospheres are often but not always posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your phone when you are near electrical blasting caps, in a blasting area, or in

areas posted “Turn off electronic devices.” Obey all signs and instructions.

Batteries

Batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touch exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

and chargers.

Your battery or phone may contain symbols, defined as follows:

Symbol Definition

Important safety information will follow.

Your battery or phone should not be disposed of in a fire.

Your battery or phone may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Your battery or phone should not be thrown in the trash.

LiIon BATT

Your phone contains an internal lithium ion battery.

Use only Motorola original batteries

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to blinking lights, such as when watching television or playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your doctor before

playing video games on your phone or enabling a blinking-lights feature on your phone. (The blinking-light feature is not available on all products.)

Parents should monitor their children's use of video game or other features that incorporate blinking lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation.

To limit the likelihood of such symptoms, please take the following safety precautions:

•

Do not play or use a blinking-lights feature if you are tired or need sleep.

•

Take a minimum of a 15-minute break hourly.

•

Play in a room in which all lights are on.

•

Play at the farthest distance possible from the screen.

Repetitive Motion Injuries

When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow these instructions to avoid problems such as tendonitis, carpal tunnel syndrome, or other musculoskeletal disorders:

•

Take a minimum 15-minute break every hour of game playing.

•

If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.

•

If you continue to have sore hands, wrists, or arms during or after play, stop playing and see a doctor.

Getting Started

What’s in the Box?

Your digital wireless phone typically comes with a battery and a charger. You can purchase other accessory items to customize your phone for maximum performance and portability.

To purchase Motorola Original™ accessories, contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.

Getting Started

About This Guide

This guide introduces you to your Motorola wireless phone.

Note: A More Here reference guide for your phone is also available that describes your phone’s features in more detail.

To obtain the More Here guide for your phone, or another copy of this guide, see the Motorola Web site at:

http://motorola.com/consumer/manuals http://motorola.ca/consumer

or contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.

(U.S.A.)

(Canada)

Optional Features

This label identifies an optional network or subscription-dependent feature that may not be offered by all service providers in all geographical areas. Contact your service

provider for more information.

Optional Accessories

This label identifies a feature that requires an optional Motorola Original™ accessory.

Installing the Battery

You must install and charge the battery to use your phone.

Your phone is designed to be used only with Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use.

Action

Remove the battery from its protective clear plastic case.

If necessary, slide up the battery door release latch and lift the door off of the phone.

Release

Latch

Getting Started

Action

Insert the battery, printed arrow first,

Getting Started

under the tabs

the bottom of the battery compartment and push down.

Insert the tabs at the bottom of the battery door into the slot at the base of the phone, then push the door down until you hear a click locking the door in place.

Charging the Battery

New batteries are shipped partially charged. Before you can use your phone, install and charge the battery as

described below. Some batteries perform best after several full charge/discharge cycles.

Action

Plug the travel charger into your phone with the release tab facing up.

Plug the other end of the travel charger into the appropriate electrical outlet.

When your phone indicates press the release tab and remove the travel charger.

Release

Ta b

Charge Complete

Note:

When you charge the battery, the battery level indicator in the upper right corner of the display shows how much of the charging process is complete. At least 1 segment of the battery level indicator must be visible to ensure full phone functionality while charging.

Battery Use

Getting Started

Battery performance depends on many factors, including your wireless carrier’s network configuration; signal strength; the temperature at which you operate your phone; the features and/or settings you select and use; items attached to the phone’s accessory connector port; and your voice, data, and other application usage patterns.

Caution:

objects to contact or short-circuit the battery terminals.

•

Getting Started

•

battery type. Contact your local recycling center for proper disposal methods.

Warning:

may explode.

To prevent injuries or burns, do not allow metal

To maximize your battery’s performance:

•

Always use Motorola Original™ batteries and battery chargers. The phone warranty does not cover damage caused from using non-Motorola

batteries and/or battery chargers.

New batteries or batteries that have been stored for a long time may require a longer charge time.

Maintain the battery at or near room temperature when charging.

Do not expose batteries to temperatures below

-10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

When you do not intend to use a battery for a while, store it uncharged in a cool, dark, dry place, such as a refrigerator.

Batteries gradually wear down and require longer charging times. This is normal. If you charge your battery regularly and notice a decrease in talk time or an increase in charging time, then it is probably time to purchase a new battery.

The rechargeable batteries that power this phone must be disposed of properly and may need to be recycled. Refer to your battery’s label for

Never dispose of batteries in a fire because they

Changing the Convertible Covers

You can change the flip cover and the battery cover on your phone to personalize its appearance.

Removing a Flip Cover

Action

Grasp the sides of the flip cover and slide the cover toward the bottom of the phone, and then off the flip.

Notes:

•

Do not use tools to remove a flip cover. Using tools to remove a flip cover will damage the cosmetic appearance of the phone.

•

The flip cover is attached tightly to the phone, and considerable force is required to remove it.

Getting Started

Attaching a Flip Cover

Action

Slide the flip cover on to the flip engaging the channels on both sides of the flip.

Attaching the Camera

Getting Started

Insert the optional Motorola Original™ Digital Camera into the accessory connector port at the bottom of your phone.

Turning Your Phone On

Action

Open your phone.

Press and hold.

for 3 seconds

to turn on the phone.

Power

Key

If necessary, enter your 4-digit unlock code and press

(+) to unlock the phone.

The unlock code is originally set to 1234. Your service provider may change this number before you receive your phone.

Rhythm Lights

Your phone has a rhythm lights feature that illuminates the keyboard (for approximately 10 seconds) upon powerup, when a key is pressed, or when the flip is opened.

Adjusting

Jog Dial

Volume

Roll the jog dial up or down to:

•

increase or decrease earpiece volume during a call

•

increase or decrease the ringer volume setting when the idle display is visible (flip must be open)

Tip:

At the lowest volume setting, roll the volume jog dial down to switch to silent alert (vibrate or silent). Roll the jog dial up to reset ring alert.

•

turn off an incoming call alert

•

Change alert type with flip closed

Making a Call

Action

Press the keypad keys to dial the phone number.

Tip:

If you make a mistake, press clear the last digit, or press and hold to clear all digits.

Press N to make the call.

Press O to end the call and “hang up” the phone when you are finished.

CLEAR

Getting Started

(C)

Note:

You must dial the phone number from the idle

display (see page 21).

Answering a Call

When you receive a call, your phone rings and/or vibrates and displays an incoming call message.

Press To

ANSWER

Getting Started

Tip:

When the phone flip is active, open the phone to answer the call. (To activate, press >

In-Call Setup >Answer Options >Open to Answer

Note:

If the phone is locked, unlock it to answer the call.

(+)

answer the call

end the call and “hang up” the phone when you are finished

Changing the

Settings

Ring Tone

Jog Dial

Volume

With the phone flip open, roll the jog dial down to switch the alert for incoming calls and other events to silent alert (vibrate or silent). Roll the jog dial up to reset ring alert.

Viewing Your Phone Number

While you are on a call, press K #.

Learning to Use Your Phone

See page 1 for a basic phone diagram.

Using the Display

The idle display (shown below) is the standard display when you are not on a call or using the menu. You must be in the idle display to dial a phone number.

Datebook

Shortcuts

* Optional network/subscription dependent feature

Tip:

You can customize your menu order, icons to be displayed in the idle screen and soft keys. See Settings > Personalize > Main Menu and Settings > Personalize > Home Keys for icon assignment.

Press the 5-way navigation key ( down to select 1 of the 4 menu feature icons in the idle

#8?IM VQ5^

1:00pm 09/08/03

CONTACTS

Menu Indicator

Soft Key Labels

RECENT

Message Center

Brew*

) left, right, up, or

Learning to Use Your Phone

display. The center part of the 5-way navigation key is the “OK” key (

(menu) indicator at the bottom center of the display indicates you can press the menu key ( main menus to see additional features or menu items.

Labels at the bottom corners of the display show the current soft key functions. Press the left soft key (

right soft key ( the left or right soft key label.

Status indicators are at the top of the display:

➌

➋

➊

Learning to Use Your Phone

). Press K to select items in a list. The e

) to perform the function indicated by

In Use

Digital/ Analog Signal Indicator

Signal Strength

➍

Roam

1:00pm 09/08/03

CONTACTS

#8?

➎

Active Line

RECENT

) display to the

➏ Automatic

➐

➑

➒

) or

Location Information (ALI)

Battery Level

Ring Style Indicator

Message Waiting

➊

Signal Strength Indicator

strength of the network connection. You cannot make or receive calls when the

➋

Service Type Indicator

service your phone is receiving.

Vertical bars show the

(no signal) indicator displays.

Shows the type of

= digital service

= 13K digital

= packet data

service

➌

In Use Indicator

Other indicators can include:

= secure CSD

call

= secure packet

data transfer

;

= secure

application connection

➍

Roam Indicator

seeking or using another network outside your home network.

)

= 1X roam

= 2G roam

On text entry screens, shows text entry status information.

= symbol method

= caps lock on

Shows that a call is in progress.

= analog service

= 8K digital

= unsecure CSD

call

= unsecure packet

data transfer

= unsecure

application connection

Shows that your phone is

)

=1X home

= 2G home

= numeric method

= normal text entry

Learning to Use Your Phone

➎

Active Line Indicator

active phone line.

= line 1

Shows the current

= line 2

➏

ALI Indicator

dependent) Shows the status of the Automatic Location Information (ALI) feature.

= ALI on

On text entry screens, shows text entry status information.

= tap method = iTAP method

➐

Battery Level Indicator

battery charge level. Recharge the battery when you see

Low Battery

➑

Ring Style Indicator

= loud ring

=vibrate

= silent

➒

Message Waiting Indicator

you receive a text message. Other indicators can include.

=voicemail

message

Learning to Use Your Phone

= limited

character count (text entry screen)

and hear the low battery alert.

(indicator is carrier

= ALI off

Vertical bars show the

Shows the ring style setting.

= soft ring

= vibrate and ring

= voicemail and

Shows when

text message

Using the 5-Way Navigation

5-Way

Navigation

Key

Use the 5-way navigation key to navigate the menu system, change feature settings, and play games. The center part of the 5-way navigation key is the “OK” key (

), used to select items in a list. From the idle display,

press idle display.

Tip:

menus. Move left and right to change feature settings, navigate the datebook, and edit text.

to select 1 of the 4 menu feature icons in the

Down and up are your primary movements within

Learning to Use Your Phone

Using Menus

Setti

From the idle display, press e to go to the main menu.

Menu Key

Enter menu

system, or open

a sub-menu.

Left Soft Key

Perform left

function.

OK Key

(part of the 5-

way navigation

key) Select

feature option.

Send Key

Send & answer

calls, view

recently dialed

Learning to Use Your Phone

calls list

ngs

ïr

Exit Select

Current Selection

Right Soft Key

Perform right function.

5-Way Navigation Key

Scroll up,

left select feature options

down

, or

right &

Clear Key

Delete text or go back.

Press menu. Select The following icons represent features that may display in

to highlight a menu feature icon in the main

(?) to see additional menu features.

the main menu, depending on your service provider and service subscription options.

Icon

Feature

Voice Memos

Media Center

Settings

Brew*

Alert Styles

Shortcuts

* Optional network/subscription dependent feature

Tip:

You can set your phone to display the main menu as a

text-based list rather than graphic icons (see page 66).

Icon

Feature

More Contacts Datebook

Selecting a Menu Feature

Select a menu feature as follows:

Find the Feature

This example shows that from the idle display, press scroll to and select scroll to and select left/right soft keys to select the functions listed in the bottom left and right corners of the display.

Message Center

(?) from the main menu, then

Contacts

. Use S to scroll, and the

Learning to Use Your Phone

Selecting a Feature Option

Some features require you to select an item from a list:

V5^

Highlighted Item

Press

EXIT

(-)

to go back to

screen.

Press

•

Press S to scroll up or down to highlight the item you want.

•

In a numbered list, press a number key to highlight the item.

•

In an alphabetized list, press a key multiple times to cycle through the letters on the key and highlight the closest matching list item.

Learning to Use Your Phone

•

Press C to back out of screens.

SELECTEXIT

to open sub-menu.

Press

details of highlighted item.

SELECT

(+) to view

Entering Feature Information

Some features require you to enter information.

V5^

Highlighted

Press

scroll down to

other items.

CHANGECANCEL

Item

Press

CHANGE

enter or edit information.

(+) to

Press

CANCEL

making changes. when you enter or edit information.

(-) to exit without

DONE

(-) displays

•

Enter numbers or text with the keypad.

•

When an item has a list of possible values, press S to the left or right to scroll and select a value.

•

When an item has a list of possible numeric values, press a number key to set the value.

•

If you enter or edit information and do not want to save your changes, press

•

If you are entering or editing information, press and release

•

If you are entering or editing information, press and hold

to delete a character.

to delete all text in the editor.

to exit without saving.

Learning to Use Your Phone

Text Messaging

The message center lets you compose and send text messages.

Flashing cursor

indicates

insertion point.

Press

EXIT

When you enter text using the tap method (see page 31), the flashing cursor changes to a block cursor, and the soft key functions change:

(-) to exit without making changes.

PV5^

CREATEEXIT

Press open sub-menu.

Press

CREATE

insert quick note, picture, or sound.

(+) to

Learning to Use Your Phone

Flashing cursor

indicates

insertion point.

After

2 seconds,

block cursor

reverts to

flashing cursor

and moves to

next position.

Create

NEXTCANCEL

Press

CANCEL

message.

V5^

Press

to accept and store text.

(-) to cancel the

(+)

Entering Text

Multiple text entry methods make it easy for you to enter names, numbers, and messages on your phone.

Choosing an Entry Method

Most text entry screens let you enter letters, numbers, and/ or symbols as required. Press from a text entry screen to select a text method:

(or M >

Entry Setup)

iTap

Tap Method

Numeric Symbol Primary

Secondary

Note:

change it by selecting another method.

Tip:

A shortcut to to changing the text entry method is by pressing the # key.

Let the phone predict each word as you enter it (see page 34).

Enter letters, numbers, and symbols by

pressing a key 1 or more times. See the following section.

Enter numbers only.

Enter symbols only (see page 38).

Specify your preferred entry method

(

iTap

Specify an alternate entry method ( or

The text method you select remains active until you

Tap Method

iTap

Using Tap Method

This is the standard method for entering text on your phone.

Learning to Use Your Phone

Press M> select the

Learning to Use Your Phone

Entry Setup

Tap Method

Press To

a number key 1 or more times

number keys enter the remaining

3OK(+) store the text when you are

from any text entry screen and

menu option.

select a letter, number, or symbol shown in the “Character Chart” on page 34

characters

finished

General Text Entry Rules

Press a number key repeatedly to cycle through its characters (see the “Character Chart” on page 34).

Press a number

key as many

times as

necessary to

enter desired

character at

flashing cursor

location.

Press

down

to change letter in block cursor to uppercase or lowercase.

Press

left

Press & hold a

number key to

cycle between

text & numeric

entry modes.

•

If you do not press a key for 2 seconds, the character in the block cursor is accepted, and the cursor moves to the next position.

•

The first character of every sentence is capitalized. (Press

down to force the character to lowercase

while it is highlighted by the block cursor.)

to move flashing cursor to left or right in text message.

Learning to Use Your Phone

right

Character Chart

Use this chart as a guide for entering characters with the tap method.

space . 1 ? ! , @ _ & ~ : ; " -

( ) ' ¿ ¡ % £ $ ¥

a b c 2 ä å á à â ã

d e f 3

g h i 4 ï í î γ η

j k l 5 κ

m n o 6 ñ ö ø ó ò ô õ µ υ

p q r s 7

t u v 8

w x y z 9

+ - 0 x * / \ [ ] = > < # §

Note:

This chart may not reflect the exact character set available on your phone (for example, due to language requirements).

ë é è ê ε

ü ú ù û

ξ ψ

α β

Using iTAP™ Software Predictive Text Entry Method

Learning to Use Your Phone

iTAP™ software is a predictive text entry method that lets you enter a word using a single keypress per letter.

Press

select the

Entry Setup

iTAP

menu option.

from any text entry screen and

Note:

You can switch languages within a message in iTAP text method. Press language you want to use.

Entering Words

Action

Press a number key 1 time to enter the first letter of the word.

The letters associated with the key are shown at the bottom of the display.

Press number keys (1 per letter) to enter the rest of the word.

Alternative words and letter combinations are shown at the bottom of the display. The word choices are updated with each keypress.

Press S to scroll and highlight the word you want.

Press

SELECT

flashing cursor location.

A space is automatically inserted after the word.

Entry Setup

to select the

(+) to enter the word at the

Learning to Use Your Phone

For example, to spell the word “art,” press 2 7 8. The display shows:

Press

Flashing cursor

indicates

insertion point.

Create

Art

scroll & see additional word choices.

CANCEL

Entering Novel Words

You may enter a word that the iTAP software does not recognize. If the word you want does not display:

Learning to Use Your Phone

Press

(-) to

cancel

message.

Action

Press C 1 or more times to delete letters until you see a letter combination that matches the start of the word.

Press S left or right to highlight the letter or letter combination.

Continue to enter letters and highlight letter combinations to spell the word.

Art Apt Cpu Cru

NEXTCANCEL

Press

(+) to insert highlighted word.

Entering Punctuation

Press To

1 or 0

Using Capitalization

The first word of a sentence is automatically capitalized, with following words in lowercase.

Action

Press S up once to change the highlighted word or letters to uppercase.

Press

up twice to change the highlighted word or

letters to uppercase.

Press or letters to lowercase.

Entering Numbers

2 3

down once to change the highlighted word

Action

Enter the first digit and then highlight it to put the iTAP software in number entry method.

Press number keys to add digits to the number. Press

SELECT

flashing cursor location.

enter punctuation or other characters as shown in the “Character Chart” on page 34

(+) to enter the number at the

Learning to Use Your Phone

Deleting Letters and Words

Place the cursor to the right of the text you want to delete, and then do the following:

Action

Press clear (C) to delete 1 letter at a time. Hold clear (

) to delete the entire message.

Using Symbol Mode

Your phone provides an alternate way to enter symbol characters in a message. Press

any text entry screen and select the

Action

Press a number key 1 time to display its symbol options at the bottom of the screen (see the “Symbol Chart” below.

Press S, or press the number key multiple times, to highlight the symbol you want.

Press

SELECT

flashing cursor location.

Learning to Use Your Phone

Symbol Chart

Use this chart as a guide for entering characters in symbol method.

(+) to enter the symbol at the

Symbol

Entry Mode

menu option.

from

space . ? ! , @ _ & ~ : ; "

- ( ) ' ¿ ¡ % £ $ ¥

@ _ \

/ : ;

" & '

( ) [ ] { }

¿ ¡ ~

< > =

$ £ ¥

# % *

+ - x * / = > < # §

Note:

This chart may not reflect the exact character set

available on your phone.

Using the External Display

When the flip is closed, the external display shows the time, date, and phone status information. It also displays messages to notify you of incoming calls and other events. See pages 22–24 for descriptions of the status indicators that may appear in the external display.

Locking and Unlocking Your Phone

You can lock your phone manually or set the phone to lock automatically whenever you turn it off.

To use a locked phone, you must enter the unlock code. A locked phone still rings or vibrates for incoming calls or messages,

You can make emergency calls on your phone even when it is locked (see page 53).

but you must unlock it to answer

Learning to Use Your Phone

Locking Your Phone Manually

Find the Feature

Press To

keypad keys enter your unlock code

2OK(+) lock the phone

Settings >Security

Phone Lock

Lock Now

Unlocking Your Phone

Tip:

Your phone’s unlock code is originally set to 1234. Your service provider may reset the unlock code to the last 4 digits of your phone number.

At the

Enter Unlock Code

Press To

keypad keys enter your unlock code

2OK(+) unlock your phone

prompt:

Setting Your Phone to Lock Automatically

You can set your phone to lock every time you turn it off.

Learning to Use Your Phone

Find the Feature

Settings >Security

Phone Lock

Automatic Lock

Verify Unlock Code

Press To

keypad keys enter your unlock code

(+) activate automatic lock

Changing a Code or Password

Your phone’s 4-digit unlock code is originally set to 1234, and the 6-digit security password is originally set to

000000. Your service provider may reset these passwords before you receive your phone.

If your service provider has not reset these numbers, we recommend that you change them to prevent others from accessing your personal information. The unlock code must contain 4 digits, and the security password must contain 6 digits.

Learning to Use Your Phone

To change a code or password:

Find the Feature

Settings >Security

New Passwords

If You Forget a Code or Password

If you forget your security password, contact your service provider.

If you forget your unlock code, try entering 1234 or the last 4 digits of your phone number. If that does not work, at the

Enter Unlock Code

Press To

keypad keys enter your unlock code

3OK(+) submit your unlock code

prompt:

go to the unlock code bypass

screen

Learning to Use Your Phone

Setting Up Your Phone

Storing Your Name and Phone Number

To store or edit your name and phone number information on your phone:

Find the Feature

Settings

Phone Status

My Tel. Number

Setting the Time and Date

You must set the time and date format to use the datebook. The time and date are automatically set by the network.

Find the Feature

Settings

Initial Setup

Time and Date

Setting a Alert Style

Your phone rings or vibrates to notify you of an incoming call or other event. This ring or vibration is called an alert.

You can select 1 of 5 different alert styles:

= loud ring =vibrate = silent

=soft ring

= vibrate and ring

Setting Up Your Phone

The ring style indicator on the display shows the current ring style (see page 22).

To set a ring style:

Find the Feature

Press To

SELECT

(+) select the alert style

Alert Styles >Style

scroll to the alert style

Setting Answer Options

You can use different options to answer an incoming call.

Find the Feature

The

Answer Options

Multi-Key Open to Answer

answer by pressing any key

answer by opening the flip

Settings

In-Call Setup

Answer Options

menu includes:

Setting a Wallpaper Image

You can set a picture or animation as a wallpaper (background) image on your phone’s idle display.

Note:

When you set an animation as a wallpaper image,

only the first frame of the animation is displayed.

Setting Up Your Phone

Find the Feature

> > >

Settings Personalize Wallpaper

Press To

CHANGE

SELECT

CHANGE

SELECT

DONE

Note:

saver immediately after you take the photo.

(+) open the picture viewer

up or down

(+) select the image

(+) adjust the image layout

(+) confirm the layout setting

(-) save wallpaper settings

You can set a photo as wallpaper or as a screen

scroll to

scroll to a picture/animation

Scroll to wallpaper image.

scroll to

Center

the center of the display and, if necessary, shrinks the image to fill the display.

Tile

several small copies of the image.


(None)

to turn off the

Layout

Center

places the image in

fills the display with

Tile

Setting Up Your Phone

Setting a Screen Saver Image

You can set a picture or animation as a screen saver image. The image displays when the phone flip is open and no keypresses are detected for a specified time.

The screen saver image minimizes to fill the display, if necessary. An animation repeats for 1 minute, then the first frame of the animation displays.

Tip:

Turn off the screen saver to extend battery life.

Find the Feature

Press To

8 9

CHANGE

SELECT

CHANGE

CHANGE DONE

(+) open the picture viewer

up or down

(+) select the image

(+) set the delay interval

(+) confirm the delay setting

(-) save screen saver settings

Settings

Personalize Screen Saver

scroll to

scroll to a picture/animation

Scroll to screen saver image.

scroll to

scroll to the inactivity interval that triggers the screen saver


(None)

Delay

Setting Display Contrast

Setting Up Your Phone

Find the Feature

> > >

Settings Initial Setup Contrast

to turn off the

Setting Display Color

You can select the color palette that your phone uses to display indicators, highlights, and soft key labels.

Find the Feature

> > >

Settings Personalize Color Style

Adjusting the Backlight

You can set the amount of time that the display and keypad backlights remain on, or turn off backlights to extend battery life.

Find the Feature

> > >

Settings Initial Setup Backlight

Rhythm Lights

You can customize the response of your phone with the Rhythm Lights feature depending on the event. For example, your phone can be set to respond differently for an incoming call, voicemail, or incoming text message.

Find the Feature

Press To

CHANGE

(+) select On/Off

> > >

scroll to

Flip

Settings Personalize Rhythm Lights and

Fun Flip

Rhythm Light,or Fun

Setting Up Your Phone

Setting Ring Tones (Alert) Styles

Different alert styles can be selected.

Find the Feature

Press To

CHANGE

(+) select

scroll to

Ring Volume

Alert Styles

Style Detail

Setting Ring Tones (Alert) Details

Different alert details can be set.

Find the Feature

Press To

CHANGE

Alert Styles Detail Menu

The options as well as additional optins not listed here.

Option Description

Ring Volume Calls

Setting Up Your Phone

Alarms

Text Msgs

VoiceMail

(+) select the option

Alert Styles

scroll to Loud

scroll to the desired alert

includes the following

Adjusts the ring volume. Selecst a ring tone for incoming

calls. Selects a ring tone for alarms. Selects a ring tone for text

messages. Selects a ring tone for voice mail.

Detail

Note:

Alert Styles menu location may be carrier specific.

Turning On/Off the Fun Flip

The Fun Flip can be turned on or off for opening the flip and an incoming call.

Find the Feature

Press To

CHANGE

(+) select On/Off

scroll to

Personalize

Fun Flip

Hiding or Showing Location Information

Your phone uses the Automatic Location Information (ALI) feature to indicate to the network where physically located.

When ALI is set to displays the known location to provide useful information (for example, driving directions, or the location of the nearest bank). Your phone prompts you when the network or a service asks for your location. You can refuse to allow access to this information.

When ALI is set to (ALI off) indicator, and the phone does not send location information unless you call an emergency phone number (such as 911).

(ALI on) indicator. Services may use your

911 Only

Location On

, your phone displays the M

, your phone

Setting Up Your Phone

Find the Feature

Settings >Location

Press To

SELECT

(+) select the setting

To view or change the location transmission status of your phone during a call, press

scroll to

911 Only

Location

Location On

Setting Up Your Phone

Calling Features

For basic instructions on how to make and answer calls, see page 19.

Changing the Active Line

Change the active phone line to make and

receive calls from your other phone number.

Find the Feature

The active line indicator in the display shows the currently active phone line (see page 22).

Settings

Phone Status

Active Line

Redialing a Number

If you hear a normal busy signal:

Press To

hang up

redial the busy number

Using Automatic Redial

If the network is busy, you hear a fast busy signal, and your phone displays

Call Failed

Calling Features

With automatic redial, your phone automatically redials the number for 4 minutes. When the call goes through, your phone rings or vibrates 1 time, displays and then connects the call.

You must turn on automatic redial to use the feature. To turn automatic redial on or off:

Redial Successful

Find the Feature

When automatic redial is turned off, you can manually activate the feature to redial a phone number. When you hear a fast busy signal and see

Press To

RETRY

(+)

Settings

Initial Setup

Auto Redial

Call Failed

activate automatic redial

Calling Features

Using Caller ID

Calling line Identification (caller ID) displays the phone number for incoming calls in your phone’s external and internal displays.

If the caller’s name is stored in Contacts, the phone displays the caller’s name or a picture if you have assigned a picture to that entry. when caller ID information is not available.

Setting Up Picture Caller ID

The picture caller ID is shown only on the internal display.

Incoming Call

displays

Canceling an Incoming Call

While the phone is ringing or vibrating:

Press To

IGNORE

(-)

Depending on your phone settings and/or service subscription, the call may be forwarded to another number, or the caller may hear a busy signal.

cancel the incoming call

Turning Off a Call Alert

You can turn off your phone’s incoming call alert before answering the call.

Press To

jog dial turn off the alert

Calling an Emergency Number

Your service provider programs 1 or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked.

Note:

Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be

Calling Features

placed due to network, environmental, or interference issues.

Press To

keypad keys dial the emergency number

call the emergency number

Viewing Recent Calls

Your phone keeps a list of the calls you recently received and dialed, even if the calls did not connect. The lists are sorted from newest to oldest entries. The oldest entries are deleted as new ones are added.

Calling Features

Shortcut:

idle display.

Press N to display the dialed calls list from the

Find the Feature

Press To

SELECT

(+) select the list

scroll to

Dialed Calls

More >Recent Calls

Received Calls

Press To

scroll to an entry

Note: < indicates the call

connected.

call the entry’s number

Tip:

Press and hold N for 2 seconds to send the number as DTMF tones during a call.

VIEW

(+)

view entry details

open the perform other procedures

Last Calls Menu

The

Last Calls Menu

Option Description

Store

Create a contact entry with the

Delete Delete All Send Message

Add Digits

Add digits after the number.

can include the following options:

number in the Delete the entry. Delete all entries in the list.

Open a new text message with

the number in the

No.

field.

Calling Features

Option Description

Attach Number

Send Tones

Attach a number from the contact

or recent calls lists, after the highlighted number.

Send the number to the network

as DTMF tones.

Note:

This option displays only

during a call.

Returning an Unanswered Call

Your phone keeps a record of your unanswered calls, and displays:

•

the T (missed call) indicator

•

X Missed Calls

, where X is the number of missed calls

Calling Features

Press To

VIEW

(+) display the received calls list

Note:

Missed Call icons may be carrier specific.

select a call to return

make the call

Using the Notepad

The most recent set of digits entered on the keypad are stored in your phone’s notepad memory. This can be a phone number that you called, or a number that you

entered but did not call. To retrieve the number stored in the notepad:

Find the Feature

Press To

STORE

(+)

More >Recent Calls

Notepad

call the number

open the attach a number or insert a special character

create a contact entry with the number in the

Dialing Menu

No.

field

Attaching a Number

While dialing (with digits visible in the display):

Press To

Attach Number

Assigning a Speed Dial Number

attach a number from the contact or recent calls lists

Calling Features

You can assign a speed dial to a contacts entry. This allows you to call an entry by pressing one key.

Find the Feature

Contacts

Action

Press Mto open Contacts menu.

Scroll to Speed Dial Nos.

Press K.

Scroll to the speed dial number you want to assign (1 through 9).

Press

Calling With Speed Dial

Each entry you store in your contacts list can be assigned a unique speed dial number while you are setting up the contact entry. To speed dial a contact entry:

Press To

keypad keys enter the speed dial number

Calling Features

submit the number

for the entry you want to call

Note:

Some networks let you skip this step for speed dial numbers 1 through 99.

call the entry

Calling With 1-Touch Dial

To call contact entries 1 through 9, press and hold the 1-digit speed dial number for 1 second.

We recommend that you reserve contact entry 1 (speed dial number 1) for storing and dialing your voicemail phone number. Usually, your service provider has already done this for you. If necessary, see the More Here guide for information on how to store your voicemail number as a contact entry.

Using Voicemail

Voicemail messages that you receive are stored on the network. To listen to your messages, you must call your voicemail phone number.

Note:

Your service provider may include

additional information about using this feature.

Listening to Voicemail Messages

Calling Features

Find the Feature

The phone calls your voicemail phone number. If no voicemail phone number is stored, your phone prompts you to store one.

Shortcut:

voicemail phone number as contact entry number 1. If so, you can press and hold message(s).

Your service provider may also store your

Message Center

VoiceMail

to listen to your voicemail

Receiving a Voicemail Message

When you receive a voicemail message, your phone

displays the

New VoiceMail

Press To

CALL

The phone calls your voicemail phone number. If no voicemail phone number is stored, your phone prompts you to store one.

(voice message waiting) indicator and a

notification.

(+) call your voicemail

Storing Your Voicemail Phone Number

If necessary, use the following procedure to store your voicemail phone number on your phone. Usually, your service provider has already done this for you.

Calling Features

Find the Feature

Press To

keypad keys enter your voicemail number

2OK(+) store the number

Message Center

VoiceMail

Your service provider additionally may store your voicemail phone number as contact entry number 1, so you can use 1-touch dial to listen to your voicemail messages. If necessary, see the More Here guide for information on how to store your voicemail number as a contact entry.

Muting the Phone

To mute your phone during a call, press available) or

Mute

Using Call Waiting

When you are on a call, an alert tone sounds to indicate that you have received another call.

Press To

answer the new call

switch back to the first call

MUTE

(+) (if

Calling Features

Phone Features

Main Menu

This is the standard main menu layout.

organization and feature names may vary on your phone.

If you do not find a feature in the main menu,

select features may be available on your phone.

Phone Features

(?) to see additional menu features. Not all

Settings

(see next page)

Media Center

•Pictures

• Sounds

Alert Styles

•Style

• Soft Detail

• Rhythm and Lights

• Sounds

Brew*

Shortcuts

Voice Memos

Contacts

(go to following menu items)

* Your service provider may use a

Office Tools

•Calculator

• Datebook

Message Center

•VoiceMail

• Msg Inbox

•Drafts

• Templates

• Outbox

• Safebox

• Settings

Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times

different name for the Brew feature. Brew is a network dependent feature.

Settings Menu

•Personalize

• Main Menu

• Home Keys

• Color Style

• Ext. Lens Color

•Greeting

• Banner

• Rhythm Lights

• fUN fLIP

• Wallpaper

•Themes

• Screen Saver

• Speed Dial

• Initial Setup

• Time and Date

• Auto PIN Dial

• Auto Redial

• Backlight

• TTY Setup

• Scroll

• Animation

• Language

• Brightness

• Contrast

•DTMF

•Master Reset

• Master Clear

•Browser Setup

• Connection

• Incoming Call

• In-Call Setup

• In-Call Timer

• Answer Options

• Phone Status

•My Tel. Numbers

• Active Line

• Battery Meter

• Other Information

• Security

• Phone Lock

• Lock Side Keys

• Lock Application

• Restrict Calls

• New Passwords

•1xRTT Data

•Location

•More

•Network

• Car Settings

• Headset

Note:

The order of the menu

can be customized. See Settings > Personalize > Main Menu or Home Keys.

Shortcuts

Change ringer alert:

Open flip, press down volume key to decrease volume, then switch to silent alert. Press up volume key to reset ring alert and increase volume.

Go to dialed calls list:

Press N (in idle).

Exit menu system:

Press O.

Access Main Menu:

Press M.

Phone Features

Feature Quick Reference

You can do more with your phone than make and receive phone calls! For example, you can store frequently called numbers in the contact list for easy dialing, organize your meetings and other events in the datebook, browse the Web, download applications, send messages, and more.

This section helps you to locate features on your phone that are not described in this guide. For more detailed information, see the More Here guide.

Calling Features

Feature Description

3-Way Call

Restrict Calls

TTY Calls

Phone Features

During a call:

Dial third party’s number, press

to call, press N

again to connect. Restrict outgoing or

incoming calls:

Settings >Security

Restrict Calls

Set up your phone for use

with an optional TTY device:

Settings

Initial Setup >TTY Setup

Messages

Feature Description

Send Message

Insert Pictures & Ring Tones

Read Message

Store Pictures & Ring Tones

Send a text message:

More >Message Center

Create Message

While composing a message:

Insert

Read a new text message that you have received: Press

READ

Highlight a picture or ring tone in a message, then:

Store

Contacts

Feature Description

Create Entry

Create a new contact entry:

Contacts

Create New Contact

Phone Number

(+).

Email Address

Phone Features

Feature Description

Dial Number

Voice Dial Number

Call a number stored in the contact list:

Voice dial a number stored in the contacts list: Press and release the voice key, and say the entry’s name (within 2 seconds) Note: You must store a voice tag to use this feature.

Personalizing Features

Feature Description

Ring Alert

Ring Volume

Keypad Volume

Phone Features

Menu View

Reorder Menu Items

Change the ring alert for an event:

> event name Set ringer volume:

> Set keypad keypress volume:

Display the main menu as graphic

icons or as a text-based list:

> To reorder the main menu items:

Contacts

Ring Volume

Key Volume

Main Menu>View

Main Menu>Reorder

> entry to call

Alert Styles

Alert Styles >Loud Detail

Settings >Personalize

> Style

Detail

Feature Description

Themes

Soft Keys & Menu Icons

Shortcuts

Select different themes, (None, Fashion, Graffiti, or Tropical): >

Settings >Personalize >Themes

Change soft key labels and menu feature icons in the idle display:

Settings >Personalize

Home Keys

Create a shortcut to a menu item:

Highlight the menu item, then press and hold

Select a shortcut:

Shortcuts >New Shortcut

Menu Features

Feature Description

Language

Set menu language:

Settings >Initial Setup

Language

Phone Features

Feature Description

Master Reset

Master Clear

Reset all options except unlock code, security code, lifetime timer:

Settings >Initial Setup

Master Reset

Reset all options except unlock code, security code, and lifetime timer, and clear all user settings and entries:

Dialing Features

Feature Description

Auto PIN Dial

DTMF

Phone Features

Tone s

Caution:

media (ring tones/games).

This clears all downloaded

Settings >Initial Setup

Master Clear

Automatically dial an authenticating PIN code for outgoing calls:

Settings >Initial Setup

Auto PIN Dial

Activate DTMF tones:

Settings >Initial Setup >DTMF

Send DTMF tones during a call: Press number keys.

Send stored numbers as DTMF tones during a call: Highlight a number in the contacts or recent calls lists, then press >

Send Tones.

Call Monitoring

Network connection time

moment you connect to your service provider's network to the moment you end the call by pressing includes busy signals and ringing.

The amount of network connection time you track on your resettable timer may not equal the amount of time for which you are billed by your service provider. For billing information, contact your service provider.

Feature Description

Call Times

In-Call Timer

View call timers:

Call Times

Display time or cost information during a call:

In-Call Setup

In-Call Timer

is the elapsed time from the

More >Recent Calls

Settings

. This time

Handsfree Features

Note:

The use of wireless devices and their accessories

may be prohibited or restricted in certain areas. Always

Phone Features

obey the laws and regulations on the use of these products.

Feature Description

Speakerphone

Auto Answer

(car kit or headset)

Auto Handsfree

(car kit)

Power-Off Delay

(car kit)

Phone Features

Charger Time

(car kit)

Activate a connected external speakerphone during a call: Press

SPEAKER

available) or

Spkrphone On.

Automatically answer calls when connected to a car kit or headset:

Settings >More

Car Settings

Auto Answer

Automatically route calls to a car kit when connected:

Settings>More

Car Settings

Auto Handsfree

Set the phone to stay on for a specified time after the ignition is switched off:

Settings >More

Car Settings >Power-Off Delay

Charge the phone for a specified time after the ignition is switched off:

Settings >More

Car Settings >Charger Time

(+) (if

Headset

Data and Fax Calls

Feature Description

Send Data or Fax

Receive Data or Fax

Connect your phone to the device, then place the call through the device application.

Connect your phone to the device, then:

Settings >Connection

Incoming Call >Next Call

Data In Only

Reset normal voice operation:

Settings >Connection

Incoming Call >Next Call >Normal

FaxInOnly

Network Features

Feature Description

Network Settings

View network information and adjust network settings:

Settings >More

Network

Phone Features

Personal Organizer Features

Feature Description

Add Datebook Event

View Datebook Event

Event Reminder

Record Voice Memo

Play Voice Memo

Record Phone

Phone Features

Call

Add an event to the datebook:

More >Office Tools >Datebook

day

New Event

View or edit event details:

More >Office Tools > Datebook

> day > event name View event reminder:

Press VIEW

Dismiss event reminder:

Press BACK

Record a voice memo: Press and hold voice key, speak into the microphone, release voice key.

Voice Memos >New Voice Memo

Play back a recorded voice memo:

Voice Memos >New Voice Memo

During a call, press and hold voice key. The receiving caller’s voice is recorded.

Note:

Recording phone calls is subject to varying state and federal laws regarding privacy and recording of conversations.

(+)

(-)

Feature Description

Calculator

Currency Converter

Calculate numbers:

More >Office Tools

Calculator

Convert currency:

More >Office Tools

Calculator

Exchange Rate

Enter exchange rate, press OK(+), enter amount, select

Security

Feature Description

Lock Application

Lock phone applications:

Settings >Security

Lock Application

News and Entertainment

Feature Description

Launch MicroBrowser

Download Picture or Ring Tone from Web Page

Start a micro-browser session:

Launch Mobile Web

Home

Download an image or sound file from a Web page: Highlight the file, press

SELECT

(+), press

function.

STORE

(+)

Phone Features

Feature Description

Download Game or Application

Launch Game or Application

Picture Viewer

Sounds

Radio

Phone Features

Compose your own ring tones,

Use the optional Motorola

Download a Brew game or application:

Brew >Brew Shop

press

START

(-), select category, select application, select pricing option.

Note:

Your service provider may use a different name for the Brew feature.

Launch a Brew game or application:

Brew

> application

Manage pictures and animations:

Media Center

Pictures

manage ring tones that you have composed or downloaded:

Media Center >Sounds

Original™ FM Stereo Radio Headset accessory:

Media Center >Radio

Specific Absorption Rate Data

The model wireless phone meets the government’s requirements for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC and by the Canadian regulatory authorities is

1.6 W/kg. positions accepted by the FCC and by Industry Canada with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed the limit established by each government for safe exposure. The tests are performed in positions and locations (for example, at the ear and worn on the body) reported to the FCC and available for review by Industry Canada. The highest SAR value for this model phone when tested for use at the ear is 1.23 W/kg, and when worn

Tests for SAR are conducted using standard operating

on the body, as described in this user’s guide, is 0.74 W/kg. (Body-worn measurements differ among phone models, depending upon available accessories and regulatory requirements).

While there may be differences between the SAR levels of various phones and at various positions, they all meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site:

http://phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

2. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.

Consumer Information on Wireless Phones from the FDA

The U.S. Food and Drug Administration (FDA) provides consumer information on wireless phones at:

http://www.fda.gov/cellphones/qa.html

Following are safety-related questions and answers discussed at this web site.

Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radio frequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the stand-by mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

What is FDA's role concerning the safety of wireless phones?

Under the law, FDA does not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radio frequency energy (RF) at a level that is hazardous to the user. In such a

case, FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA regulatory actions, FDA has urged the wireless phone industry to take a number of steps, including the following:

•

Support needed research into possible biological effects of RF of the type emitted by wireless phones;

•

Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and

•

Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health.

FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:

•

National Institute for Occupational Safety and Health

•

Environmental Protection Agency

•

Federal Communications Commission

•

Occupational Safety and Health Administration

•

National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working group activities, as well.

FDA shares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. FCC relies on FDA and other health agencies for safety questions about wireless phones.

FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the primary subject of the safety questions discussed in this document.

What is FDA doing to find out more about the possible health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in

1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The Project has also helped develop a series of public information documents on EMF issues.

FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts to independent investigators. The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.

What steps can I take to reduce my exposure to radio frequency energy from my wireless phone?

If there is a risk from these products--and at this point we do not know that there is--it is probably very small. But if you are concerned about avoiding even potential risks, you can take a few simple steps to minimize your exposure to radio frequency energy (RF). Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure.

If you must conduct extended conversations by wireless phone every day, you could place more distance between your body and the source of the RF, since the exposure level drops off dramatically with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna

Again, the scientific data do not harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.

What about children using wireless phones?

The scientific evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radio frequency energy (RF), the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and increasing the distance between the user and the RF source will reduce RF exposure.

Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaflets containing such a recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by

demonstrate that wireless phones are

children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.

Do handsfree kits for wireless phones reduce risks from exposure to RF emissions?

Since there are no known risks from exposure to RF emissions from wireless phones, there is no reason to believe that handsfree kits reduce risks. Handsfree kits can be used with wireless phones for convenience and comfort. These systems reduce the absorption of RF energy in the head because the phone, which is the source of the RF emissions, will not be placed against the head. On the other hand, if the phone is mounted against the waist or other part of the body during use, then that part of the body will absorb more RF energy. Wireless phones marketed in the U.S. are required to meet safety requirements regardless of whether they are used against the head or against the body. Either configuration should result in compliance with the safety limit.

Do wireless phone accessories that claim to shield the head from RF radiation work?

Since there are no known risks from exposure to RF emissions from wireless phones, there is no reason to believe that accessories that claim to shield the head from those emissions reduce risks. Some products that claim to shield the user from RF absorption use special phone cases, while others involve nothing more than a metallic accessory attached to the phone. Studies have shown that these products generally do not work as advertised. Unlike “handsfree” kits, these so-called “shields” may interfere with proper operation of the phone. The phone may be forced to boost its power to compensate, leading to an increase in RF absorption. In February 2002, the Federal Trade Commission (FTC) charged two companies that sold devices that claimed to protect wireless phone users from radiation with making false and unsubstantiated claims. According to FTC, these defendants lacked a reasonable basis to substantiate their claim.

Motorola Limited Warranty for the United States and Canada

Warra nty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its telephones, pagers, messaging devices, and consumer and professional two-way radios (excluding commercial, government or industrial radios) that operate via Family Radio Service or General Mobile Radio Service, Motorola-branded or certified accessories sold for use with these Products (“Accessories”) and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories and Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and Accessories

defined above, unless otherwise provided for below.

Decorative Accessories and Cases

. Decorative covers, bezels, PhoneWrap™ covers and cases.

One (1) year

purchase by the first consumer purchaser of the product unless otherwise provided for below.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

from the date of

for the

Products Covered Length of Coverage

Monaural Headsets.

and boom headsets that transmit mono sound through a wired connection.

Consumer and Professional Two-Way Radio Accessories.

Products and Accessories that are Repaired or Replaced.

Exclusions

Normal Wear and Tear.

parts due to normal wear and tear are excluded from coverage.

Batteries.

their rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Only batteries whose fully charged capacity falls below 80% of

Ear buds

Periodic maintenance, repair and replacement of

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

Ninety (90) days

purchase by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

from the date returned to the consumer, whichever is longer.

for the

from the date of

Defects or damage that result from: (a) improper

Defects or damage

Unauthorized Service or Modification.

from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.

Software

Products Covered Length of Coverage

Software.

in the media that embodies the copy of the software (e.g., CD-ROM, or floppy disk).

Exclusions

Software Embodied in Physical Media.

software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media.

embodied in physical media (e.g. software that is downloaded from the internet), is provided “as is” and without warranty.

Products or Accessories with (a) serial numbers or

Defects, damages, or the failure of Products,

Applies only to physical defects

Defects or damages resulting

Ninety (90) days

the date of purchase.

No warranty is made that the

Software that is not

from

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software and applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information

USA

Phones

1-800-331-6456

Pagers

1-800-548-9954

Two-Way Radios

and Messaging Devices Canada All Products TTY

1-888-390-6456

For

Accessories

designated above for the product with which they are used.

You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

and

Software

1-800-461-4575

1-800-353-2729

, please call the telephone number

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF

THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted Motorola software such as the exclusive rights to reproduce and distribute copies of the Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.

Product Registration

Online Product Registration:

http://www.motorola.com/warranty

Product registration is an important step toward enjoying your new Motorola phone. Registering helps us facilitate warranty service, and permits us to contact you should your phone require an update or other service. Registration is for U.S. residents only and is not required for warranty coverage.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

Export Law Assurances

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

RF Energy Interference

This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Index

accessories 12, 13, 17, 64 accessory connector port 1 active line indicator 22, 23 alert

creating 74 defined 43 downloading 65, 73 setting 66

turning off 20, 53 ALI indicators 22, 24, 49 analog signal indicator 22 animation

downloading 65, 73

inserting in message 65

screen saver 45

viewing 74

wallpaper 44 answering a call 20, 44 application, locking and

unlocking 73 auto PIN dial 68 automatic location

information

indicators 24 sending 49

automatic redial 51

backlight 47 battery

car kit charger time 70 charging 14 extending battery life 15,

46, 47 installing 13 level indicator 15, 22, 24

block cursor 30, 33 Brew

applications 74

browse text mode 31

calculator 73 call

adding digits after phone

number 55 alert, setting 66 alert, turning off 20, 53 answer options 44 answering 20 call waiting 61 canceling 53 deleting 54 dialed calls list 54 dialing 19

emergency number 53 ending 19, 20 making 19 muting 61 received calls list 54 receiving 20 recent calls 54 restricting 64 speakerphone 70 storing 54 three-way call 64 timers 69 unanswered call 56

Call Failed

call waiting 61 caller ID 52, 56 calling line identification.

car kit

automatic answer 70 automatic hands-free 70 charger time 70

power-off delay 70 character chart 34 clock

illustration 21

setting 43 codes

changing 41

default 18, 40, 41

forgetting 41 color, setting 47

message 51

See caller ID

contact list

attaching two numbers

56, 57 dialing a number 66 one-touch dial 58 speed dial number 58 voice dialing 66

contact number

attaching two numbers

contrast, setting 46 convertible covers 17 cursor 29, 33 customizing the menu 66,

data call

receiving 71 sending 71

date, setting 43 datebook 72 deleting a call 54 dialed calls list 54 dialing a number 19 digital signal indicator 22 display

backlight 47 color 47 contrast 46 description 21 idle display, defined 21

language 67 menu icons, personalizing

DTMF tones

activating 68 sending 55, 56, 68

earpiece volume 19 emergency number 53 end key 1, 19, 20, 26 ending a call 19, 20

Enter Unlock Code

40, 42 event alert 66 external display 39

message

fax call

receiving 71

sending 71 flashing cursor 29, 33 flip

external display 39

open to answer 20, 44

replacing flip cover 17

screen saver 45 FM Stereo Radio Headset

4-way navigation key 1, 25,

games 74

hands-free use

automatic answer 70 automatic call routing 70 charger time 70 power-off delay 70 speakerphone, activating

headset

automatic answer 70 FM Stereo Radio Headset

74 headset jack 1 home keys, personalizing

idle display 21 in use indicator 22, 23

Incoming Call

incoming call, canceling 53 indicators

active line 22, 23 ALI 22, 24, 49 battery level 15, 22, 24 digital/analog signal 22 in use 22, 23 loud ring style 24, 43

message 52

message waiting 22, 24 missed call 56 ring style 22, 24, 43 roam 22, 23 signal strength 22 silent ring style 24, 43 soft ring style 24, 43 text entry mode 24 vibrate and ring style 24,

43 vibrate style 24, 43 voice message waiting

iTAP software 34

joystick 1, 26

key

end 1, 19, 20, 26 4-way navigation 1, 25,

26 left soft key 1, 22, 26, 67 menu 1, 26, 27 power 1, 18 right soft key 1, 22, 26,

67 send 1, 19, 20, 54 voice 1 volume control 1, 19

keypad

answering calls 44 backlight 47 volume, setting 66

language, setting 67 left soft key

functions 1, 22, 26 personalizing 67

location, sending to network

lock

application 73 phone 39

Low Battery

making a call 19 master clear 68 master reset 68 menu

entering text 29, 31 icons, changing in idle

icons, converting to text

icons, described 20, 22,

language, setting 67 lists 28 navigating 26 using features 28

message 24

display 67

66, 67

25, 58

view, changing 66, 67 menu key 1, 26, 27 message

menu feature icon 21

receiving 65

sending 65 message waiting indicator

22, 24

messages menu feature

icon 21 micro-browser, using 73 microphone 1 missed call indicator 56

Missed Calls

More Here guide 12 muting a call 61 my telephone number 20,

my tones 74

network settings 71 notepad 56 number

storing your number 43 viewing your number 20

numeric text mode 31

one-touch dial

using 58 voicemail number 59

message 56

optional accessory, defined

optional feature, defined 13

passwords. See codes phone

active line indicator 23 active line, changing 51 alert, setting 66 alert, turning off 20, 53 answer options 44 automatic location

information 49

clear stored information

68 codes 41 date, setting 43 flip 17, 20 keypad, answering calls

44 language, setting 67 location 49 locking 39 network settings 71 reset all options 68 security code 41 time, setting 43 turning on/off 18 unlock code 41 unlocking 18, 39, 40, 42

phone number

active line indicator 23 active line, changing 51 adding digits after 55 attaching two numbers

57 redialing 51 storing your number 43 viewing your number 20


downloading 65, 73 inserting in message 65 screen saver 45 viewing 74 wallpaper 44

PIN code, dialing

automatically 68 power key 1, 18 predictive text entry 34

radio 74 received calls list 54 recent calls 54 redial

automatic redial 51

busy number 51 reference guide 12 restricting calls 64 rhythm lights 47 right soft key

functions 1, 22, 26

personalizing 67

ring alert

setting 19, 66 turning off 20, 53

ring style

personalizing 66 setting 43

ring style indicators 22, 24,

ring tone

creating 74 downloading 65, 73 inserting in message 65

ringer volume, setting 19,

roam indicator 22, 23

screen saver 45 security code

changing 41 default 41

forgetting 41 send key 1, 19, 20, 54 shortcuts 63, 67 shortcuts icon 21 signal strength indicator 22 silent ring alert, setting 19,

soft keys

functions 22, 26

illustration 1

labels 21

personalizing 67

sound

downloading 65, 73 inserting in message 65

speakerphone, activating

speed dial

number, defined 58 using 58

standby time, increasing

46, 47 storing a call 54 symbol chart 38 symbol text entry 38

tap method text entry 31 telephone number

storing your number 43 viewing your number 20

text

block cursor 30, 33 browse mode 31 character chart 34 entering 31 flashing cursor 29, 33 iTAP software predictive

text entry 34 numeric mode 31 symbol chart 38 symbol mode 38 tap method 31

text entry mode indicator 24 three-way call 64 time, setting 43 timers 69 travel charger 15 TTY device 64

unlock

application 73 phone 39

unlock code

bypassing 41 changing 41 default 18, 40, 41 entering 18, 40, 41 forgetting 42

vibrate alert

setting 66

turning off 20, 53 vibrate ring alert, setting 43 voice dial 66 voice key

dialing a number 66

illustration 1 voice message waiting

indicator 60 voice notes 72 voicemail

dialing with one-touch dial

using 59

volume

earpiece 19 keypad 66 ringer 19, 66

volume keys 1, 19

wallpaper 44 warranty 82 Web browser icon 21 Web pages 73

U.S. patent Re. 34,976

Wireless Phone Safety

Tips

“Safety is your most important call!”

Your Motorola wireless telephone gives you

the powerful ability to communicate by voice—

almost anywhere, anytime, wherever wireless

phone service is available and safe conditions allow.

But an important responsibility accompanies the

benefits of wireless phones, one that every user

must uphold.

When driving a car, driving is your first

responsibility. If you find it necessary to use your

wireless phone while behind the wheel of a car,

practice good common sense and remember the

1 Get to know your Motorola wireless phone and its

features such as speed dial and redial.

these features help you to place your call without taking your attention off the road.

following tips:

If available,

✂

2 When available, use a handsfree device.

add an additional layer of convenience to your wireless phone with one of the many Motorola Original™ handsfree accessories available today.

3 Position your wireless phone within easy reach.

able to access your wireless phone without removing your eyes from the road. If you receive an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.

4 Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

snow, ice, and even heavy traffic can be hazardous.

5 If you receive an incoming call at an inconvenient

time do not take notes or look up phone numbers while driving.

through your address book takes attention away from your primary responsibility—driving safely.

6 Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before pulling into traffic.

be stationary. If you need to make a call while moving, dial only a few numbers, check the road and your mirrors, then continue.

7 Do not engage in stressful or emotional

conversations that may be distracting.

you are talking with aware you are driving and suspend conversations which have the potential to divert your attention away from the road.

Jotting down a “to do” list or going

Try to plan calls when your car will

If possible,

Rain, sleet,

Make people

8 Use your wireless phone to call for help.

other local emergency number in the case of fire, traffic accident or medical emergencies.*

9 Use your wireless phone to help others in

emergencies.

progress or other serious emergency where lives are in danger, call 9-1-1 or other local emergency number, as you would want others to do for you.*

10 Call roadside assistance or a special

non-emergency wireless assistance number when necessary.

serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.*

If you see an auto accident, crime in

If you see a broken-down vehicle posing no

Dial 9-1-1 or

✂

* Wherever wireless phone service is available.

Motorola E310 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Welcome

Contents

Safety and General Information

Getting Started

What’s in the Box?

About This Guide

Installing the Battery

Charging the Battery

Battery Use

Changing the Convertible Covers

Attaching the Camera

Turning Your Phone On

Making a Call

Answering a Call

Viewing Your Phone Number

Learning to Use Your Phone

Using the Display

Using Menus

Entering Text

Using the External Display

Locking and Unlocking Your Phone

Changing a Code or Password

If You Forget a Code or Password

Setting Up Your Phone

Storing Your Name and Phone Number

Setting the Time and Date

Setting a Alert Style

Setting Answer Options

Setting a Wallpaper Image

Setting a Screen Saver Image

Setting Display Contrast

Setting Display Color

Adjusting the Backlight

Rhythm Lights

Hiding or Showing Location Information

Calling Features

Changing the Active Line

Redialing a Number

Using Automatic Redial

Using Caller ID

Canceling an Incoming Call

Turning Off a Call Alert

Calling an Emergency Number

Viewing Recent Calls

Returning an Unanswered Call

Using the Notepad

Attaching a Number

Assigning a Speed Dial Number

Calling With Speed Dial

Using Voicemail

Muting the Phone

Using Call Waiting

Phone Features

Main Menu

Feature Quick Reference

Specific Absorption Rate Data

Consumer Information on Wireless Phones from the FDA

Product Registration

Export Law Assurances

RF Energy Interference

Index
