Motorola 99FT5014 User Manual

PROFESSIONAL DIGITAL TWO-WAY RADIO
MOTOTRBO™ XPR™ 755 0/XPR™ 7580
COLOR DISPLAY PORTABLE
USER GUIDE
This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola Solutions, Inc.
Address: 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A. Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: XPR 7550 / XPR 7580
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Declaration of Conformity
English
i
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
ii
English
Contents
This User Guide contains all the information you need to use the MOTOTRBO XPR Series Digital Portable Radios.
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . i
Important Safety Information . . . . . . . . . . . . . . . . . ix
Product Safety and RF Exposure Compliance . . .ix
Software Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Computer Software Copyrights . . . . . . . . . . . . . . . . x
Handling Precautions . . . . . . . . . . . . . . . . . . . . . . . xi
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . 1
What Your Dealer/System Administrator
Can Tell You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Preparing Your Radio for Use . . . . . . . . . . . . . . . . . . 2
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . 2
Attaching the Battery . . . . . . . . . . . . . . . . . . . . . . . . . 3
Attaching the Antenna . . . . . . . . . . . . . . . . . . . . . . . . 3
Attaching the Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . 4
Attaching the Universal Connector Cover (Dust Cover)
4
Powering Up the Radio . . . . . . . . . . . . . . . . . . . . . . . 5
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . 5
Identifying Radio Controls . . . . . . . . . . . . . . . . . . . . 6
Radio Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Programmable Buttons . . . . . . . . . . . . . . . . . . . . . . . 7
Assignable Radio Functions . . . . . . . . . . . . . . . . . 7
Assignable Settings or Utility Functions . . . . . . . . . 9
Using the 4-Way Navigation Button . . . . . . . . . . . . 10
Accessing the Programmed Functions . . . . . . . . . . 10
Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Push-To-Talk (PTT) Button . . . . . . . . . . . . . . . . . . . 12
Switching Between Conventional Analog and Digital
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IP Site Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Capacity Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Linked Capacity Plus . . . . . . . . . . . . . . . . . . . . . . . 14
Identifying Status Indicators . . . . . . . . . . . . . . . . . . 16
Display Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Call Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Advanced Menu Icons . . . . . . . . . . . . . . . . . . . . . . 18
Mini Notice Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Sent Item Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Bluetooth Device Icons . . . . . . . . . . . . . . . . . . . . . . 20
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Indicator Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Audio Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Contents
iii
English
Making and Receiving Calls . . . . . . . . . . . . . . . . . . 22
Selecting a Zone . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Selecting a Channel . . . . . . . . . . . . . . . . . . . . . . . . 23
Receiving and Responding to a Radio Call . . . . . . 24
Receiving and Responding to a Group Call . . . . 24
Receiving and Responding to a Private Call . . . 25
Receiving an All Call . . . . . . . . . . . . . . . . . . . . . . 26
Receiving and Responding to a Selective Call . . 26
Receiving and Responding to a Phone Call . . . . 27
Phone Call as a Private Call . . . . . . . . . . . . . . 27
Phone Call as a Group Call . . . . . . . . . . . . . . . 27
Phone Call as an All Call . . . . . . . . . . . . . . . . . 28
Making a Radio Call . . . . . . . . . . . . . . . . . . . . . . . . 28
Making a Call with the Channel Selector Knob . . 29
Making a Group Call . . . . . . . . . . . . . . . . . . . . 29
Making a Private Call . . . . . . . . . . . . . . . . . . . 30
Making an All Call . . . . . . . . . . . . . . . . . . . . . . 31
Making a Selective Call . . . . . . . . . . . . . . . . . 31
Making a Phone Call with the One Touch Access
Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Making a Group, Private or All Call with the
Programmable Number Key . . . . . . . . . . . . . . . 33
Making a Phone Call with the Programmable Phone
Contents
Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Making a Call with the Programmable Manual Dial
Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
iv
Making a Private Call . . . . . . . . . . . . . . . . . . . . 35
Making a Phone Call . . . . . . . . . . . . . . . . . . . . 36
Stopping a Radio Call . . . . . . . . . . . . . . . . . . . . . . 38
Talkaround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Monitoring Features . . . . . . . . . . . . . . . . . . . . . . . . 39
Monitoring a Channel . . . . . . . . . . . . . . . . . . . . . 39
Permanent Monitor . . . . . . . . . . . . . . . . . . . . . . . 39
Advanced Features . . . . . . . . . . . . . . . . . . . . . . . . . 40
Radio Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Sending a Radio Check . . . . . . . . . . . . . . . . . . . 40
Remote Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Initiating Remote Monitor . . . . . . . . . . . . . . . . . . 42
Stopping Remote Monitor . . . . . . . . . . . . . . . . . . 43
Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Viewing an Entry in the Scan List . . . . . . . . . . . . 43
Viewing an Entry in the Scan List by Alias Search 44
Editing the Scan List . . . . . . . . . . . . . . . . . . . . . . 44
Adding a New Entry to the Scan List . . . . . . . . 44
Deleting an Entry from the Scan List . . . . . . . . 45
Setting and Editing Priority for an Entry in the Scan
List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Starting and Stopping Scan . . . . . . . . . . . . . . . . 47
Responding to a Transmission During a Scan . . 48
Deleting a Nuisance Channel . . . . . . . . . . . . . . . 48
English
Restoring a Nuisance Channel . . . . . . . . . . . . . . 48
Vote Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Contacts Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Making a Group Call from Contacts . . . . . . . . . . . 50
Making a Private Call from Contacts . . . . . . . . . 50
Making a Phone Call from Contacts . . . . . . . . . . 51
Making a Call by Alias Search . . . . . . . . . . . . . . 53
Assigning an Entry to a Programmable
Number Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Removing the Association between Entry and
Programmable Number Key . . . . . . . . . . . . . . . . 55
Setting Default Contact . . . . . . . . . . . . . . . . . . . . 55
Adding a New Contact . . . . . . . . . . . . . . . . . . . . . 55
Call Indicator Settings . . . . . . . . . . . . . . . . . . . . . . . 56
Activating or Deactivating Call Ringers for Call Alert
56
Activating or Deactivating Call Ringers for Private
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Activating or Deactivating Call Ringers for Selective
Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Activating or Deactivating Call Ringers for Text
Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Activating or Deactivating Call Ringers for Telemetry
Status with Text . . . . . . . . . . . . . . . . . . . . . . . . . 58
Assigning Ring Styles . . . . . . . . . . . . . . . . . . . . . 58
Escalating Alarm Tone Volume . . . . . . . . . . . . . . 59
Call Log Features . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . 59
Storing an Alias or ID from a Call List . . . . . . . . . 60
Deleting a Call from a Call List . . . . . . . . . . . . . . 60
Viewing Details from a Call List . . . . . . . . . . . . . . 60
Call Alert Operation . . . . . . . . . . . . . . . . . . . . . . . . . 61
Receiving and Responding to a Call Alert . . . . . . 61
Making a Call Alert from the Contacts List . . . . . . 61
Making a Call Alert with the One Touch Access Button 62
Emergency Operation . . . . . . . . . . . . . . . . . . . . . . . 62
Receiving an Emergency Alarm . . . . . . . . . . . . . 63
Responding to an Emergency Alarm . . . . . . . . . . 63
Sending an Emergency Alarm . . . . . . . . . . . . . . . 64
Sending an Emergency Alarm with Call . . . . . . . 64
Sending an Emergency Alarm with Voice to Follow 65
Reinitiating an Emergency Mode . . . . . . . . . . . . . 67
Exiting Emergency Mode . . . . . . . . . . . . . . . . . . . 67
Text Message Features . . . . . . . . . . . . . . . . . . . . . 68
Writing and Sending a Text Message . . . . . . . . . 68
Sending a Quick Text Message . . . . . . . . . . . . . . 69
Sending a Quick Text Message with the One Touch
Access Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Accessing the Drafts Folder . . . . . . . . . . . . . . . . . 70
Viewing a Saved Text Message . . . . . . . . . . . . 70
Contents
v
English
vi
Editing and Sending a Saved Text Message . . 71
Deleting a Saved Text Message from Drafts . . 71
Managing Fail-to-Send Text Messages . . . . . . . 72
Resending a Text Message . . . . . . . . . . . . . . . 72
Forwarding a Text Message . . . . . . . . . . . . . . 72
Editing a Text Message . . . . . . . . . . . . . . . . . . 73
Managing Sent Text Messages . . . . . . . . . . . . . 73
Viewing a Sent Text Message . . . . . . . . . . . . . 74
Sending a Sent Text Message . . . . . . . . . . . . . 74
Deleting All Sent Text Messages from Sent Items
75
Receiving a Text Message . . . . . . . . . . . . . . . . . 76
Reading a Text Message . . . . . . . . . . . . . . . . . . 76
Managing Received Text Messages . . . . . . . . . . 76
Viewing a Text Message from the Inbox . . . . . 77
Viewing a Telemetry Status Text Message from the
Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Replying to a Text Message from the Inbox . . 77
Deleting a Text Message from the Inbox . . . . . 78
Deleting All Text Messages from the Inbox . . . 79
Analog Message Encode . . . . . . . . . . . . . . . . . . . 79
Sending MDC Message Encode to Dispatcher . . 79
Analog Status Update . . . . . . . . . . . . . . . . . . . . . . 80
Contents
Sending Status Update to Predefined Contact . . 80
Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Dual Tone Multi Frequency (DTMF) . . . . . . . . . . . . 81
Multi-Site Controls . . . . . . . . . . . . . . . . . . . . . . . . . 82
Starting an Automatic Site Search . . . . . . . . . . . 82
Stopping an Automatic Site Search . . . . . . . . . . 83
Starting a Manual Site Search . . . . . . . . . . . . . . 83
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Radio Disable . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Radio Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Lone Worker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Password Lock Features . . . . . . . . . . . . . . . . . . . . 86
Accessing the Radio from Password . . . . . . . . . 86
Unlocking the Radio from Locked State . . . . . . . 87
Turning the Password Lock On or Off . . . . . . . . . 87
Changing the Password . . . . . . . . . . . . . . . . . . . 88
Bluetooth Operation . . . . . . . . . . . . . . . . . . . . . . . . 89
Turning Bluetooth On or Off . . . . . . . . . . . . . . . . 89
Finding and Connecting to a Bluetooth Device . . 89
Finding and Connecting From a Bluetooth Device
(Discoverable Mode) . . . . . . . . . . . . . . . . . . . . . . 90
Disconnecting from a Bluetooth Device . . . . . . . 91
Switching Audio Route . . . . . . . . . . . . . . . . . . . . 91
Viewing Device Details . . . . . . . . . . . . . . . . . . . . 91
Editing Device Name . . . . . . . . . . . . . . . . . . . . . 92
Deleting Device Name . . . . . . . . . . . . . . . . . . . . 92
BT Mic Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Notification List . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
English
Accessing the Notification List . . . . . . . . . . . . . . . 93
Auto-Range Transponder System (ARTS) . . . . . . . 94
Over-the-Air Programming (OTAP) . . . . . . . . . . . . . 94
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Turning the Radio Tones/Alerts On or Off . . . . . . 95
Turning Keypad Tones On or Off . . . . . . . . . . . . . 95
Setting the Tone Alert Volume Offset Level . . . . 96
Turning the Talk Permit Tone On or Off . . . . . . . 96
Turning the Power Up Tone On or Off . . . . . . . . . 96
Setting the Power Level . . . . . . . . . . . . . . . . . . . . 97
Changing the Display Mode . . . . . . . . . . . . . . . . . 97
Adjusting the Display Brightness . . . . . . . . . . . . . 98
Controlling the Display Backlight . . . . . . . . . . . . . 98
Setting the Squelch Level . . . . . . . . . . . . . . . . . . 99
Turning the Introduction Screen On or Off . . . . . . 99
Locking and Unlocking the Keypad . . . . . . . . . . 100
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Setting the Text Message Alert Tone . . . . . . . . 100
Turning the LED Indicator On or Off . . . . . . . . . 101
Turning the Voice Operating Transmission (VOX)
Feature On or Off . . . . . . . . . . . . . . . . . . . . . . . . 101
Turning the Option Board Feature(s) On or Off . 102
Identifying Cable Type . . . . . . . . . . . . . . . . . . . . 102
Voice Announcement . . . . . . . . . . . . . . . . . . . . . 103
Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . 103
Menu Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Analog Mic AGC (Mic AGC-A) . . . . . . . . . . . . . . 104
Digital Mic AGC (Mic AGC-D) . . . . . . . . . . . . . . 104
Intelligent Audio . . . . . . . . . . . . . . . . . . . . . . . . . 105
Turning the Acoustic Feedback Suppressor Feature
On or Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Turning the Microphone Dynamic Distortion Control
Feature On or Off . . . . . . . . . . . . . . . . . . . . . . . . 106
GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Text Entry Configuration . . . . . . . . . . . . . . . . . . 107
Word Correct . . . . . . . . . . . . . . . . . . . . . . . . . 107
Word Predict . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Sentence Cap . . . . . . . . . . . . . . . . . . . . . . . . . 108
Viewing Custom Words . . . . . . . . . . . . . . . . . 108
Editing Custom Word . . . . . . . . . . . . . . . . . . . 109
Adding Custom Words . . . . . . . . . . . . . . . . . . 109
Deleting a Custom Word . . . . . . . . . . . . . . . . 110
Deleting All Custom Words . . . . . . . . . . . . . . . 110
Accessing General Radio Information . . . . . . . . 111
Accessing the Battery Information . . . . . . . . . 111
Checking the Radio Alias and ID . . . . . . . . . . 111
Checking the Firmware Version and Codeplug Ver-
sion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Checking the GPS Information . . . . . . . . . . . . 112
Software Update . . . . . . . . . . . . . . . . . . . . . . . 113
Site Information . . . . . . . . . . . . . . . . . . . . . . . 113
RSSI Values . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Contents
vii
English
Front Panel Configuration (FPC) . . . . . . . . . . . . . 114
Entering FPC Mode . . . . . . . . . . . . . . . . . . . . . 114
Editing FPC Mode Parameters . . . . . . . . . . . . . 114
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Carry Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Headsets and Headset Accessories . . . . . . . . . . 116
Earbuds and Earpieces . . . . . . . . . . . . . . . . . . . . 117
Remote Speaker Microphones . . . . . . . . . . . . . . . 117
Surveillance Accessories . . . . . . . . . . . . . . . . . . . 118
Miscellaneous Accessories . . . . . . . . . . . . . . . . . 118
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Appendix: Maritime Radio Use in the VHF Frequency
Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Special Channel Assignments . . . . . . . . . . . . . . . 121
Emergency Channel . . . . . . . . . . . . . . . . . . . . . 121
Non-Commercial Call Channel . . . . . . . . . . . . . 122
Operating Frequency Requirements . . . . . . . . . . 122
Declaration of Compliance for the Use of Distress and
Contents
Safety Frequencies . . . . . . . . . . . . . . . . . . . . . . . 124
Technical Parameters for Interfacing External Data
Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
viii
Batteries and Chargers Warranty . . . . . . . . . . . . 125
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 126
English

Important Safety Information

Product Safety and RF Exposure Compliance

Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio.
ATTENTION!
This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements.
Before using this product, read the RF energy awareness information and operating instructions in the Regulatory Compliance and Product Safety section of your Quick Reference Guide enclosed with your radio (Motorola Publication part number 68009503001) to ensure compliance with RF energy exposure limits.
For a list of Motorola-approved antennas, batteries, and other accessories, visit the following website:
http://www.motorolasolutions.com
Any modification to this device, not expressly authorized by Motorola, may void the user’s authority to operate this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
This radio transmitter has been approved by Industry Canada to operate with Motorola-approved antenna with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Important Safety Information
English
ix

Software Version

All the features described in the following sections are supported by the radio's software version R02.06.10.
See Checking the Firmware Version and Codeplug Version on page 112 to determine your radio's software version.
Check with your dealer or system administrator for more details of all the features supported.

Computer Software Copyrights

The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied,
Software Version
reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola
x
products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product.
TM
The AMBE+2 this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc.
This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human-readable form.
U.S. Pat. Nos. #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166.
voice coding Technology embodied in
English

Handling Precautions

The MOTOTRBO Series Digital Portable radio meets IP57 specifications, allowing the radio to withstand adverse field conditions such as being submersed in water.
If the radio has been submersed in water, shake the
radio well to remove any water that may be trapped inside the speaker grille and microphone port. Trapped water could cause decreased audio performance.
If the radio’s battery contact area has been exposed to
water, clean and dry battery contacts on both the radio and the battery before attaching the battery to the radio. The residual water could short-circuit the radio.
If the radio has been submersed in a corrosive
substance (e.g. saltwater), rinse the radio and battery in fresh water then dry the radio and battery.
To clean the exterior surfaces of the radio, use a diluted
solution of mild dishwashing detergent and fresh water (i.e. one teaspoon of detergent to one gallon of water).
Never poke the vent (hole) located on the radio chassis
below the battery contact. This vent allows for pressure equalization in the radio. Doing so may create a leak path into the radio and the radio’s submersibility may be lost.
Never obstruct or cover the vent, even with a label.
Ensure that no oily substances come in contact with the
vent.
The radio with antenna attached properly is designed to
be submersible to a maximum depth of 1 meter (3.28 feet) and a maximum submersion time of 30 minutes. Exceeding either maximum limit or use without antenna may result in damage to the radio.
When cleaning the radio, do not use a high pressure jet
spray on the radio as this will exceed the 1 meter depth pressure and may cause water to leak into the radio.
Do not disassemble the radio. This could damage radio seals and result in leak paths into the radio. Radio maintenance should only be done in service depot that is equipped to test and replace the seal on the radio.
Handling Precautions
English
xi

Notes

Notes
xii
English

Getting Started

Take a moment to review the following:
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . page 1
What Your Dealer/System Administrator
Can Tell You. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 1

How to Use This Guide

This User Guide covers the basic operation of the MOTOTRBO Portables.
However, your dealer or system administrator may have customized your radio for your specific needs. Check with your dealer or system administrator for more information.
Throughout this publication, the icons below are used to indicate features supported in either the conventional Analog mode or conventional Digital mode:
Indicates a conventional Analog Mode-Only feature.
Indicates a conventional Digital Mode-Only feature.
For features that are available in both conventional Analog and Digital modes, no icon is shown.
For features that are available in a conventional multi-site mode, see IP Site Connect on page 13 for more information.
Selected features are also available on the single-site trunking mode, Capacity Plus. See Capacity Plus on page 14 for more information.
Selected features are also available in the multi-site trunking mode, Linked Capacity Plus. See Linked Capacity Plus on page 14 for more information.
What Your Dealer/System Administrator
Can Tell You
You can consult your dealer or system administrator about the following:
Is your radio programmed with any preset conventional
channels?
Which buttons have been programmed to access other
features?
What optional accessories may suit your needs?
What are the best radio usage practices for effective
communication?
What maintenance procedures will help promote longer radio
life?
Getting Started
1
English

Preparing Your Radio for Use

Assemble your radio by following these steps:
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
Attaching the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Attaching the Antenna. . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Attaching the Belt Clip. . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Attaching the Universal Connector
Cover (Dust Cover) . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Powering Up the Radio . . . . . . . . . . . . . . . . . . . . . . . . . page 5
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
Preparing Your Radio for Use

Charging the Battery

For best performance, your radio is powered by a Motorola-approved Nickel Metal-Hydride (NiMH) or Lithium-Ion (Li-lon) battery. To avoid damage and comply with warranty terms, charge the battery using a Motorola charger exactly as described in the charger user guide. It is recommended your radio remains powered off while charging.
Charge a new battery 14 to 16 hours before initial use for best performance.
IMPORTANT: ALWAYS charge your IMPRES battery with an
IMPRES charger for optimized battery life and valuable battery data. IMPRES batteries charged exclusively with IMPRES chargers receive a 6-month capacity warranty extension over the standard Motorola Premium battery warranty duration.
2
English

Attaching the Battery

Attaching the Antenna

Align the battery with the rails on the back of the radio. Press
the battery firmly, and slide upward until the latch snaps into
place. Slide battery latch into lock position.
To remove the battery, turn the radio off. Move the battery latch into unlock position and hold, and slide the battery down and off the rails.
Battery Latch
With the radio turned off, set the antenna in its receptacle and turn clockwise.
To remove the antenna, turn the antenna counterclockwise.
If antenna needs to be replaced, ensure that only MOTOTRBO antennas are used. Neglecting this will damage your radio. See Antennas on page 115 for a list of available antennas.
Preparing Your Radio for Use
3
English

Attaching the Belt Clip

Attaching the Universal Connector Cover
(Dust Cover)
Align the grooves on the clip with those on the battery and press downward until you hear a click.
To remove the clip, press the belt clip tab away from the battery. Using a key may be helpful. Then slide the clip upward and away from the radio.
Preparing Your Radio for Use
4
The universal connector is located on the antenna side of the radio. It is used to connect MOTOTRBO accessories to the radio.
Insert the hooked end of the
Universal Connector
To remove the universal connector cover, press down on the cover and turn the thumbscrew counterclockwise.
Replace the dust cover when the universal connector is not in use.
cover into the slots above the universal connector. Press downward on the cover to seat the lower tab properly into the RF connector.
Turn the thumbscrew clockwise to secure the connector cover to the radio.
English

Powering Up the Radio

Rotate the On/Off/Volume
Control Knob clockwise
until you hear a click. You
see MOTOTRBO (TM) on the
radio’s display momentarily,
followed by a welcome
message or welcome
image.
The LED lights up solid
green and the Home screen
lights up if the backlight
setting is set to turn on
automatically.
NOTE: The Home screen does not light up during a power up if
the LED indicator is disabled (see Turning the LED Indicator On or Off on page 101).
A brief tone sounds, indicating that the power up test is
successful.
NOTE: There is no power up tone if the radio tones/alerts
function is disabled (see Turning the Radio Tones/ Alerts On or Off on page 95).
LED
To turn off the radio, rotate this knob counterclockwise until you hear a click. You see a brief display.
Powering Down
on the radio’s

Adjusting the Volume

To increase the volume, turn the On/Off/Volume Control Knob clockwise.
To decrease the volume, turn this knob counterclockwise.
NOTE: Your radio can be
programmed to have a minimum volume offset where the volume level cannot be turned past the programmed minimum volume. Check with your dealer or system administrator for more information.
Preparing Your Radio for Use
If your radio does not power up, check your battery. Make sure
that it is charged and properly attached. If your radio still does
not power up, contact your dealer.
5
English

Identifying Radio Controls

Radio Controls

Take a moment to review the following:
Radio Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
Programmable Buttons . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Using the 4-Way Navigation Button . . . . . . . . . . . . . . page 10
Accessing the Programmed Functions . . . . . . . . . . . . page 10
Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 11
Push-To-Talk (PTT) Button . . . . . . . . . . . . . . . . . . . . . page 12
Switching Between Conventional Analog and
Digital Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 13
IP Site Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 13
Capacity Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 14
Linked Capacity Plus. . . . . . . . . . . . . . . . . . . . . . . . . . page 14
Identifying Radio Controls
6
1
2
3
4
5
6
7
8
9
Channel Selector Knob*
1
On/Off/Volume Control Knob
2
LED Indicator
3
19
18
17
16
15 14
13
12
11
10
English
Side Button 1**
4
Push-to-Talk (PTT) Button
5
Side Button 2**
6
Side Button 3**
7
Front Button P1**
8
Menu/OK Button
9
4-Way Navigation Button
10
Keypad
11
Back/Home Button
12
Front Button P2**
13
Display
14
Microphone
15
Speaker
16
Universal Connector for Accessories
17
Emergency Button**
18
Antenna
19
* Display radios have a continuous-rotary Channel Selector Knob ** These buttons are programmable.

Programmable Buttons

Your dealer can program the programmable buttons as shortcuts to radio functions or preset channels/groups depending on the duration of a button press:
Short press Pressing and releasing rapidly.
Long press Pressing and holding for the programmed
duration.
Hold down Keeping the button pressed.
NOTE: The programmed duration of a button press is
applicable for all assignable radio/utility functions or settings. See Emergency Operation on page 62 for more information on the programmed duration of the
Emergency button.

Assignable Radio Functions

Bluetooth® Audio Switch – Toggles audio routing between
internal radio speaker and external Bluetooth-enabled accessory.
Contacts – Provides direct access to the contacts list.
Call Alert – Provides direct access to the contacts list for you to
select a contact to whom a Call Alert can be sent.
Call Forwarding – Toggles Call Forwarding on or off.
Call Log – Selects the call log list.
Identifying Radio Controls
7
English
Voice Announcement for Channel – Plays zone and channel
announcement voice messages for the current channel. This function is unavailable when Voice Announcement is disabled.
Emergency – Depending on the programming, initiates or cancels an emergency alarm or call.
Intelligent Audio On/Off – Toggles Intelligent Audio on or off.
Manual Dial Depending on the programming, initiates a
Private or Phone call by keying in any subscriber ID or phone number.
Manual Site Roam*
– Starts the manual site search.
Mic AGC On/OffToggles the internal microphone automatic gain control (AGC) on or off. Not applicable during a Bluetooth session.
Monitor – Monitors a selected channel for activity.
Notifications – Provides direct access to the Notifications List.
Nuisance Channel Delete*
– Temporarily removes an unwanted channel, except for the Selected Channel, from the scan list. The Selected Channel refers to the user’s selected zone/channel combination from which scan is initiated.
One Touch Access Directly initiates a predefined Private, Phone or Group Call, a Call Alert or a Quick Text message.
Identifying Radio Controls
* Not applicable in Capacity Plus
8
Not applicable in Linked Capacity Plus
Option Board Feature – Toggles option board feature(s) on or off for option board-enabled channels.
Permanent Monitor*
– Monitors a selected channel for all
radio traffic until function is disabled.
Phone – Provides direct access to the Phone Contacts list.
Privacy Toggles privacy on or off.
Radio Alias and ID – Provides radio alias and ID.
Radio Check Determines if a radio is active in a system.
Radio Enable Allows a target radio to be remotely
enabled.
Radio Disable Allows a target radio to be remotely disabled.
Remote Monitor Turns on the microphone of a target radio without it giving any indicators.
Repeater/Talkaround*
– Toggles between using a repeater
and communicating directly with another radio.
Scan*‡ – Toggles scan on or off.
Site Info* – Displays current Linked Capacity Plus site name
and ID. Plays site announcement voice messages for the current site (this function is unavailable when Voice Announcement is disabled).
English
Site Lock On/Off* – Toggles the automatic site roam on or
off.
Status – Selects the status list menu.
Telemetry Control Controls the Output Pin on a local or
remote radio.
Text Message – Selects the text message menu.
Transmit Interrupt Remote Dekey Stops the
transmission of a remote monitored radio without giving any indicators, or an ongoing interruptible call to free the channel.
Voice Announcement On/Off – Toggles Voice Announcement on or off.
Voice Operating Transmission (VOX) – Toggles VOX on or off.
Zone – Allows selection from a list of zones.
* Not applicable in Capacity Plus
Not applicable in Linked Capacity Plus

Assignable Settings or Utility Functions

All Tones/Alerts – Toggles all tones and alerts on or off.
Backlight On/Off – Toggles display backlight on or off.
Backlight Brightness – Adjusts the brightness level.
Display Mode – Toggles the day/night display mode on or off.
Keypad Lock – Toggles keypad between locked and unlocked.
Power Level – Toggles transmit power level between high and
low.
Squelch Toggles squelch level between tight and normal.
Identifying Radio Controls
9
English

Using the 4-Way Navigation Button

Accessing the Programmed Functions

You can use the 4-way navigation button, e, to scroll through
options, increase/decrease values, and navigate vertically.
Category
Menu Vertical Navigation
Lists Vertical Navigation
View Details Vertical Navigation Previous/Next Item
You can use the 4-way navigation button,
alias, or free form text editor.
Editor Category
Number
Alias
Free Form Text
Numeric Values Increase/Decrease
^ or v< or >
e, as a number,
^ or v< or >
Left: Delete last digit
Move cursor one
character left/right
Move cursor up/
down
Move cursor one
character left/right
Right: –
Identifying Radio Controls
You can access various radio functions through one of the following ways:
A short or long press of the
relevant programmable buttons.
OR
ced
Use the 4-way navigation button as follows:
1 To access the menu, press the c button. Press the
appropriate direction of the functions.
e to access the menu
2 To select a function or enter a sub-menu, press the c
button.
3 To go back one menu level, or to return to the previous
screen, press the return to the Home screen.
NOTE: Your radio automatically exits the menu after a period
of inactivity and returns to your Home screen.
d button. Long press the d button to
10
English

Using the Keypad

You can use the 3 x 4 alphanumeric keypad to access your radio’s features. You can use the keypad to enter subscriber aliases or IDs, and text messages. Many characters require that you press a key multiple times. The table below shows the number of times a key needs to be pressed to generate the required character.
Number of Times Key is Pressed
Key1 2345678910111213
1
2 3 4 5 6 7 8 9
0 * #
1.,?!@&‘%-:*#
ABC2
DEF3
GHI4
JKL5
MNO6
PQRS7
TUV8
WXYZ9
0
* or del
# or space
NOTE: Press to enter “0” and long press to activate the CAPS lock. Another long press to turn off the CAPS lock.
NOTE: Press during text entry to delete the character. Press during numeric entry to enter a “*”.
NOTE: Press during text entry to insert a space. Press during numeric entry to enter a “#”. Long press to change text entry
method.
Identifying Radio Controls
English
11

Push-To-Talk (PTT) Button

The PTT button on the side of the radio serves two basic purposes:
If the Talk Permit Tone (see Turning the Talk Permit Tone On
or Off on page 96) or the PTT Sidetone is enabled, wait
until the short alert tone ends before talking.
During a call, if the Channel Free Indication feature is enabled on your radio (programmed by your dealer), you
hear a short alert tone the moment the target radio (the radio that is receiving your call) releases the PTT button, indicating the channel is free for you to respond.
PTT Button
While a call is in progress, the PTT button allows the radio to
transmit to other radios in the call.
Press and hold down PTT button to talk. Release the PTT button to listen.
The microphone is activated when the PTT button is pressed.
Identifying Radio Controls
While a call is not in progress, the PTT button is used to make
a new call (see Making a Radio Call on page 28).
12
English
You will also hear a continuous talk prohibit tone, if your call is interrupted, indicating that you should release the
PTT button, for example when the radio receives an Emergency Call.
Switching Between Conventional Analog
and Digital Mode
Each channel in your radio can be configured as a conventional analog or conventional digital channel. Use the Channel Selector Knob to switch between an analog or a digital channel.
Channel Selector Knob
When switching from digital to analog mode, certain features are unavailable. Icons for the digital features (such as Messages) reflect this change by appearing ‘grayed out’. Disabled features are hidden in the menu.
Your radio also has features available in both analog and digital mode. However, the minor differences in the way each feature works does NOT affect the performance of your radio.
NOTE: Your radio also switches between digital and analog
modes during a dual mode scan (see Scan on page 47).

IP Site Connect

This feature allows your radio to extend conventional communication beyond the reach of a single site, by connecting to different available sites which are connected via an Internet Protocol (IP) network.
When the radio moves out of range from one site and into the range of another, it connects to the new site's repeater to send or receive calls/data transmissions. Depending on your settings, this is done automatically or manually.
If the radio is set to do this automatically, it scans through all available sites when the signal from the current site is weak or when the radio is unable to detect any signal from the current site. It then locks on to the repeater with the strongest Received Signal Strength Indicator (RSSI) value.
In a manual site search, the radio searches for the next site in the roam list that is currently in range (but which may not have the strongest signal) and locks on to it.
NOTE: Each channel can only have either Scan or Roam
enabled, not both at the same time.
Channels with this feature enabled can be added to a particular roam list. The radio searches the channel(s) in the roam list during the automatic roam operation to locate the best site.
A roam list supports a maximum of 16 channels (including the Selected Channel).
Identifying Radio Controls
13
English
NOTE: You cannot manually add or delete an entry to the roam
list. Check with your dealer or system administrator for more information.

Capacity Plus

Capacity Plus is a single-site trunking configuration of the MOTOTRBO radio system, which uses a pool of channels to support hundreds of users and up to 254 Groups. This feature allows your radio to efficiently utilize the available number of programmed channels while in Repeater Mode.
Icons of features not applicable to Capacity Plus are not available in the menu. You hear a negative indicator tone if you try to access a feature not applicable to Capacity Plus via a programmable button press.
Your radio also has features that are available in conventional digital mode, IP Site Connect, Capacity Plus and Linked Capacity Plus. However, the minor differences in the way each feature works does NOT affect the performance of your radio.
Check with your dealer or system administrator for more information on this configuration.
Identifying Radio Controls
14

Linked Capacity Plus

Linked Capacity Plus is a multi-site multi-channel trunking configuration of the MOTOTRBO radio system, combining the best of both Capacity Plus and IP Site Connect configurations.
Linked Capacity Plus allows your radio to extend trunking communication beyond the reach of a single site, by connecting to different available sites which are connected via an Internet Protocol (IP) network. It also provides an increase in capacity by efficiently utilizing the combined available number of programmed channels supported by each of the available sites.
When the radio moves out of range from one site and into the range of another, it connects to the new site's repeater to send or receive calls/data transmissions. Depending on your settings, this is done automatically or manually.
If the radio is set to do this automatically, it scans through all available sites when the signal from the current site is weak or when the radio is unable to detect any signal from the current site. It then locks on to the repeater with the strongest Received Signal Strength Indicator (RSSI) value.
In a manual site search, the radio searches for the next site in the roam list that is currently in range (but which may not have the strongest signal) and locks on to it.
Any channel with Linked Capacity Plus enabled can be added to a particular roam list. The radio searches these channels during the automatic roam operation to locate the best site.
English
NOTE: You cannot manually add or delete an entry to the roam
list. Check with your dealer or system administrator for more information.
Similar to Capacity Plus, icons of features not applicable to Linked Capacity Plus are not available in the menu. You hear a negative indicator tone if you try to access a feature not applicable to Linked Capacity Plus via a programmable button press.
Check with your dealer or system administrator for more information on this configuration.
Identifying Radio Controls
English
15

Identifying Status Indicators

Your radio indicates its operational status through the following:
Display Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 16
Call Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 18
Advanced Menu Icons. . . . . . . . . . . . . . . . . . . . . . . . . page 18
Mini Notice Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 19
Sent Item Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 19
Bluetooth Device Icons . . . . . . . . . . . . . . . . . . . . . . . . page 20
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 20
Audio Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21
Indicator Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21
Identifying Status Indicators
16

Display Icons

The 132 x 90 pixels, 256 colors, liquid crystal display (LCD) of your radio shows radio status, text entries, and menu entries.
The following are icons that appear on the status bar at the top of the radio’s display. Icons are displayed on the status bar, arranged left-to-right, in order of appearance/usage and are channel specific.
Received Signal Strength Indicator (RSSI)
The number of bars displayed represents the radio signal strength. Four bars indicate the strongest signal. This icon is only displayed while receiving.
Battery
The number of bars (0 – 4) shown indicates the charge remaining in the battery.
Blinks when the battery is low.
Bluetooth
The Bluetooth feature is enabled but there is no remote Bluetooth device connected.
Bluetooth Connected
The Bluetooth feature is enabled. The icon stays lit when one or more remote Bluetooth devices are connected.
Bluetooth Discoverable
The Bluetooth feature is enabled and radio is in discoverable mode.
English
Loading...
