XPR 4500 / XPR 4550

Mobile Radio

User’s Guide

6816817H01

MOTOROLA, the Stylized Logo and CommPort are registered in the U.S.

Patent & Trademark Office. All other product or service names are the

property of their respective owners.

Product Safety and RF Exposure Compliance

Before using this product, read the operating instructions for safe

usage contained in the Product Safety and RF Exposure booklet

Caution

enclosed with your radio.

ATTENTION!

This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C99) to ensure compliance with RF energy exposure limits.

Computer Software Copyrights

The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product.

Documentation Copyrights

No duplication or distribution of this document or any portion thereof shall take place without the express written permission of Motorola. No part of this manual may be reproduced, distributed, or transmitted in any form or by any means, electronic or mechanical, for any purpose without the express written permission of Motorola.

Disclaimer

The information in this document is carefully examined, and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies. Furthermore, Motorola reserves the right to make changes to any products herein to improve readability, function, or design. Motorola does not assume any liability arising out of the applications or use of any product or circuit described herein; nor does it cover any license under its patent rights, nor the rights of others.

MOTOROLA and the Stylized M Logo are registered in the U.S. Patent & Trademark Office. All other product or service names are the property of their respective owners.

XPR 4500 / XPR 4550 Mobile Radio i

Notations Used in This Manual

Throughout the text in this publication, you will notice the use of WARNINGS, CAUTIONS, and Notes. These notations are used to emphasize that safety hazards exist, and care that must be taken or observed.

WARNIN G

CAUTION

Note: Note: An operational procedure, practice, or other condition,

The following special notations identify certain items:

Example Description

Light button or

PHONE

WARNING: An operational procedure, practice, or other condition, which might result in injury or death if not carefully observed.

CAUTION: An operational procedure, practice, or other condition, which might result in damage to the equipment if not carefully observed.

which is essential to emphasize.

Buttons and keys are shown in bold print or as a key symbol.

Menu items (softkeys) are similar to the way they appear on the radio’s display.

Contents

Declaration of Conformity .................................................................. ii

Computer Software Copyrights .........................................................iii

Documentation Copyrights ................................................................iii

Disclaimer .........................................................................................iii

Notations Used in This Manual ........................................................ iv

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Using Your Radio: The Basics .......................................................... 1

Getting Started .................................................................................. 2

Identifying Your Radio ....................................................................... 3

Control Head .............................................................................. 3

Operating Your Control Head ............................................................ 3

Turning On the Radio ........................................................................ 4

Setting the Volume ..................................................................... 5

Adjusting the Display Brightness ................................................ 5

Using the navigation key ............................................................ 5

Trunked Modes or Conventional Channels ................................6

Field Programming ..................................................................... 6

Display Status ................................................................................... 7

Feature Control ................................................................................. 7

Alert Tones ........................................................................................ 7

Basic Operating Procedures . . . . . . . . . . . . . . . . . . . 11

Basic Functions ............................................................................... 11

Selecting the Zone or Mode ............................................................ 12

Selecting or Changing the Zone ............................................... 12

Selecting or Changing a Mode in the Current Zone ................. 13

Selecting or Changing to a Mode Not in the Current Zone ....... 13

Selecting the Home Mode ............................................................... 14

Transmitting (Conventional Modes Only) ........................................ 15

Transmitting (Trunked Modes Only) ................................................ 15

Selecting the Transmit Power Level ................................................ 16

Monitoring Conventional Mode Activity ........................................... 16

Adjusting the Squelch Level ............................................................ 17

General Radio Features . . . . . . . . . . . . . . . . . . . . . . . 18

Often-Used Features ....................................................................... 18

Emergency Call and Alarm ............................................................. 19

Emergency Call ........................................................................ 19

Initiating an Emergency Alarm .................................................. 20

Initiating an Emergency Call .....................................................20

Initiating an Emergency Call and Alarm ....................................21

Initiating a Silent Emergency Alarm ..........................................22

Special Considerations for Emergencies ..................................22

Scan Operation ................................................................................23

Turning On Scan .......................................................................24

Turning Scan On While Disregarding the Squelch Code (Conven-

tional Modes Only) .................................................................25

Viewing a Scan List ...................................................................26

Transmitting While Scan Is On .................................................27

Temporarily Deleting a Nuisance Mode with Scan On ..............28

Restoring a Nuisance Mode ......................................................28

Changing Mode Priorities While Scan Is On .............................29

Restoring Mode Priorities in a Scan List ...................................29

Programming a Scan List ..........................................................30

Hang Up Box (HUB) ..................................................................32

Optional External Alarms (Horn and Lights) ....................................32

Activating the External Alarm(s) ................................................32

Changing the Selected Alarms .................................................33

Receiving a Call While Alarms Are Turned On .........................34

Time-Out Timer ................................................................................35

Push-To-Talk Identification (PTT-ID) ................................................35

Telephone Interconnect List (Conventional and Trunking) ..............36

Answering a Phone Call ............................................................36

Initiating a Telephone Call from the List ....................................37

Unlimited Telephone Interconnect ...................................................38

Calling a Phone Number Not in the List ....................................38

Storing a Number in the List .....................................................39

Editing a Name in the List ........................................................40

Call Alert Page (Conventional and Trunking— Digital Modes Only) 43

Sending a Call Alert Page .........................................................44

Conventional Radio Features . . . . . . . . . . . . . . . . . . 47

Features Used in Conventional Operation ......................................47

Status Calls (Digital Modes Only) ....................................................48

Sending a Status Call ...............................................................48

Smart PTT .......................................................................................50

Conventional Talkgroup Calls ..........................................................50

Digital Modes Only ....................................................................50

Selecting a Conventional Talkgroup .........................................51

Conventional Talkaround ................................................................ 52

Talk Direct (Mobile-To-Mobile) ................................................. 52

Selective Calls (Digital Modes Only) ............................................... 52

Answering a Selective Call ....................................................... 53

Initiating a Selective Call .......................................................... 54

Viewing Your Unit ID Number ................................................... 56

Storing a Unit ID Number in the List ......................................... 57

Editing a Name in the List ......................................................... 58

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Antennas ......................................................................................... 63

Cables ............................................................................................. 64

Desktop ........................................................................................... 64

Microphones ................................................................................... 65

Miscellaneous ................................................................................. 65

Mounting Kits .................................................................................. 65

Speakers ......................................................................................... 66

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Commercial Warranty and Service . . . . . . . . . . . . . . 93

Limited Warranty ............................................................................. 93

Service ............................................................................................ 97

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

XPR 4500 / XPR 4550 Mobile Radio

viii

Introduction

Using Your Radio: The Basics

This chapter gives you the basic knowledge you need in order to use your radio. The following topics are covered:

• Getting Started (page 2)

• Identifying Your Radio (page 3)

• Operating Your Control Head (page 3)

• Turning On the Radio (page 5)

• Setting the Volume (page 6)

• Adjusting the Display Brightness (page 6)

• Display Status (page 8)

• Feature Control (page 8)

• Alert Tones (page 8)

XPR 4500 / XPR 4550 Mobile Radio

Introduction

Getting Started

The XPR 4500 / XPR 4550 Mobile Radio is among the most sophisticated two-way radios available. It can operate in the following frequency ranges:

VHF UHF

136-174 MHz 403-470 MHz

450-527 MHz

These channels provide maximum communications capability under varying operating conditions.

One of the newest in a long line of quality Motorola products, the XPR 4500 /

XPR 4550 Mobile Radio provides improved voice quality across more of your coverage area. The digital process called embedded signaling intermixes system signaling information with digital voice, resulting in improved system reliability and the capability of supporting a multitude of advanced features. Such features add up to better, more cost-effective two-way radio communications.

The XPR 4500 / XPR 4550 Mobile radio has two USB ports that can interface with external devices, such as laptop computers.

Introduction

Identifying Your Radio

The XPR 4500 / XPR 4550 Mobile Radio has two major components:

the radio unit installed in your vehicle and the control head that is used to activate various radio features. Keep the foldout page opened for reference as you read this manual. Your radio has the following control head:

Control Head

The control head has the rotary Volume knob, 4 programmable menu buttons, menu navigation buttons, menu button, home button, On/Off button, channel buttons and a 2-line dot matrix LCD display.

Note: A "CH MISMATCH" error upon turning on your radio, means

that either the Control Head has been connected to a legacy transceiver, or vice versa.

Operating Your Control Head

Your advanced control head is designed for ease of use and flexibility of feature control. Before operating the radio, familiarize yourself with the various controls, indicators, and alert tones.

• On/Off button: To turn the mobile radio On and Off.

• Rocker Up/Down button: To select the desired position/personality

from the radio.

• Programmable Buttons: Several of the radio’s buttons can be

programmed as short-cut buttons for many of the radio’s features, P1, P2, P3 and P4. 

XPR 4500 / XPR 4550 Mobile Radio

Introduction

Check with your dealer for a complete list of the functions your radio’s programmable buttons support.

• Left and Right navigation Buttons: For navigating through the radio menu.

• Back/Home button: Used to back up one level in the Menu hierarchy (short press); also used to exit the Menu Mode (long press).

• OK button: The “OK” button is used to make Menu selections.

• Menu button: To enter Menu mode.

• Volume Knob: Use to adjust the radio’s volume.  Turning the rotary volume knob counter-clockwise shall turn the radio volume to minimum. Turning the rotary volume knob clockwise shall turn the radio volume to maximum.

• Indicators

LED State Description

RED Illuminated Power ON

YELLOW Illuminated Permanent Monitor Mode

Receiving Private Call

Blinking Performing Scan

GREEN Illuminated Radio Transmitting

Blinking Power UP

Introduction

Turning On the Radio

Do the following:

• Turn the radio on with a short press of the power button in the upper left corner of the control unit.

After a short time, the red, green and yellow LED’s light up, indicating that the radio is powering up.

The radio first performs a selftest to determine its operational capability and then powers on

The display then shows XYZ 2345.

When the radio is fully powered on, the Zone and Channel text and menu items is displayed. The backlight will turn on to the last selected color and dim level.

Note: Pressing the power button anytime after the LED’s light up

will TURN OFF the radio.

The radio then performs a self check.

Note: If FAIL ##/## appears in the display, the radio will not

function until the condition has been corrected.



If ERROR ##/## appears, some non-critical data has been changed. If either of these displays appear, if the display goes blank, or if the unit appears to be locked up, refer to the “Troubleshooting” section.

XPR 4500 / XPR 4550 Mobile Radio

Introduction

Setting the Volume

Rotate the Vol u m e knob clockwise to increase the volume and counterclockwise to decrease the volume.

Adjusting the Display Brightness

The backlight allows the radio's display to be illuminated from the rear to allow you to see the display in any light condition.

Utilities

Select desired brightness from the following options and press the OK button:

•Low

• Medium

• High

o Radio Settings oBacklight

Using the navigation key

When accessing a feature on the radio, use the left or right toggles on the navigation key to access further options within the menu.



If you cannot locate a menu item, it may not be programmed, or it may not apply to the radio's current mode setting.

Introduction

Trunked Modes or Conventional Channels

Depending on how your radio is programmed, you can select conventional channels or trunked talkgroup. Conventional channels consist of a transmit and receive frequency pair, an associated squelch code pair, and a time-out timer value. See “Conventional Radio Features” on page 47.

Trunked modes consist of the system/announcement group/talkgroup combination and a time-out timer value. See “Trunking Operation” on page 61.

Field Programming

Other radio features may be slaved to the selected mode by field programming. This mode slaving means that the radio is preprogrammed to automatically give you the proper operation for each mode you select.

You may use the control head to program your own mode names. The names you assign are clearly shown in the alphanumeric display. You can see all the key operating information, including the mode selected or being scanned, and the on/off status of various features. The operating conditions are shown either by the display or by visual/ audio indicators, or by both.

XPR 4500 / XPR 4550 Mobile Radio

Introduction

Display Status

The control head display indicates your selected mode, or the currently active receive mode when scan is on.

Feature Control

You can turn the various radio features on or off, change modes, and adjust the volume.

To exit a feature, such as phone, press the HOME button.

Alert Tones

Tone Type Name Description

Two highpitched tones

Four highpitched tones every five seconds

Single, highpitched tone

Four highpitched tones

Sound similar to a telephone busy signal

Private Conversation™

Call Alert Indicate that a Call Alert page has been

Central Acknowledge

Mobile Unit Acknowledge

System Busy Indicates, when you press the

Indicate that a private call has been received.

received.

Indicates that a Call Alert, emergency alarm, reprogram request, or status/ message transmission has been received by the system’s central controller.

Indicate that a Call Alert page has been received by the intended unit, or the emergency alarm, reprogram request, or status/message transmission has been acknowledged by the intended dispatcher.

microphone push-to-talk (PTT) button, that you cannot transmit because all system radio channels are in use. Release the PTT button and wait for call back.

Tone Type Name Description

Introduction

A series of two short, high-pitched tones

A series of two short, high-pitched tones (same as automatic call back)

Continuous, low-pitched tone

Single, highpitched tone every nine seconds

Automatic Call Back

Talk Permit (optional)

Talk-Prohibit/ Out-of-Range

Failsoft In an unmuted receive condition,

Indicate that a channel is now available for your previously requested transmission.

Indicate, when you press the microphone PTT button, that the system is accepting your transmission.

Indicates, when you press the microphone PTT button, that either you are out of the range of the trunked radio system, or the system is out of service, or the channel is busy with the Smart PTT feature enabled.

indicates a trunked system central controller failure. The radio reverts from trunked operation to a system similar to conventional radio repeater operation. Other system users can be heard sharing the channel.

Continuous, low-pitched tone

Brief lowpitched tone

XPR 4500 / XPR 4550 Mobile Radio

Illegal Mode Indicates that you have entered a mode

Time-Out Timer Warning

where normal system traffic will be missed, or you are attempting something which is not permitted. Examples include: forgetting to exit the telephone interconnect mode after a call ends (fleet and subfleet calls cannot be received), attempting to transmit on a receive-only conventional mode, attempting to select a dynamic mode where no dynamic ID assignment has been made.

Indicates that your present transmission will soon be disabled.

Introduction

Tone Type Name Description

Single, short, high-pitched tone

Single, lowpitched tone

Unique chirping sound

Valid Key Indicates that you pressed a valid key, or

you entered a feature configuration state, or you are receiving or transmitting in the clear mode on secure models (with TX Clear Alert Tones enabled).

Invalid Key Indicates that you tried to make an

invalid key press, or that an emergency alarm, reprogram request, or status/ message was not acknowledged.

Dynamic Reprogramming

Indicates that a dynamic ID is assigned.

Basic Operating Procedures

Basic Functions

This chapter shows you how to access the radio’s basic functions and includes the following topics:

• Selecting the Zone or Mode (page 12)

• Selecting the Home Mode (page 14)

• Transmitting (Conventional Modes Only) (page 15)

• Transmitting (Trunked Modes Only) (page 15)

• Selecting the Transmit Level (page 16)

• Monitoring Conventional Mode Activity (page 16)

• Adjusting the Squelch Level (page 17)

XPR 4500 / XPR 4550 Mobile Radio

Basic Operating Procedures

Selecting the Zone or Mode

A zone is a grouping of modes. A mode is a group of characteristics such as transmit/receive frequencies, Private-Line™ codes, radio parameters, and an alphanumeric name.

Note: Your radio supports up to a maximum of 50 zones.

You can select or change zone via the programmable button or via the radio menu.

Selecting or Changing the Zone

MenuoZone

1 Press the main menu button and scroll to Zone.

2 Press the OK button to access the zone list.



The display shows the current zone and mode.

3 Press theor until the desired zone is displayed.

4 Press the OK button or PTT button to save the displayed

zone as the new home (default) zone. 

The zone name stops flashing once it is saved.

5 Press the PTT button to begin transmitting on the

displayed zone.

Basic Operating Procedures

Selecting or Changing a Mode in the Current Zone

To access a mode in the current zone, do the following:

1 Press MENU button.

2 Scroll to Zone Lists and press the OK button.



The display shows the current zone and mode.

3 Use the navigation keys until the desired channel in the

current zone is displayed.

4 Press the OK button or PTT button to save the displayed

channel as the new home (default) channel.



The channel name stops flashing once it is saved.

5 Press the PTT button to begin transmitting on the

displayed zone and mode.

Selecting or Changing to a Mode Not in the Current Zone

1 To access a mode that is not in the current zone, use the

navigation keys to move to the zone containing the mode.

Note: Analog and Digital channels can be mixed in each zone.

2 Do one of the following:

• Select a desired zone (page 12).

• Select a desired mode in the current zone (page 13).

Selecting the Home Mode

This feature must first be enabled by a qualified radio technician.

Press the HOME button to select the home mode contained within the home zone, from any other zone and mode in the radio.

XPR 4500 / XPR 4550 Mobile Radio

Basic Operating Procedures

Transmitting (Conventional Modes Only)

1 Lift the microphone off-hook, and listen for activity on that mode.

2 If you hear no activity, press and hold the microphone PTT

button.

Transmitting (Trunked Modes Only)

1 Select a desired zone and mode.

2 Lift the microphone off-hook, and press the microphone PTT

button to transmit. Speak clearly into the microphone.

3 Release the PTT button to receive.

Selecting the Transmit Power Level

You can select (toggle) the transmit power level via the programmable button.

Press the programmable button.



The display momentarily shows L at the power level icon is low power is selected or H to indicate high power level is selected.

Basic Operating Procedures

Monitoring Conventional Mode Activity

This feature allows you to monitor channel traffic on conventional channels by defeating the coded squelch. This feature must first be enabled by a qualified radio technician or system administrator.

Do one of the following:

Take the microphone off hook.  (This is the same as monitor on. You hear all channel traffic.)



1 Make sure you are in Home mode where the default zone and

mode are being displayed (page 14).

2 Press theor button to scroll to the MON softkey.

3 Pressing MON softkey momentarily toggles between MONITOR ON

and MONITOR OFF. MONITOR ON shown on the display indicates that the radio is monitoring.

4 Pressing MON softkey again turns monitor off and you don’t hear

all channel traffic.

XPR 4500 / XPR 4550 Mobile Radio

Basic Operating Procedures

Adjusting the Squelch Level

Your radio’s ability to transmit or receive signals varies as you move away from or close to your base station. You can adjust your radio’s squelch to improve its ability to receive transmissions.

Do the following:

1 Press the programmable button.

You can either chose tight or normal for your squelch setting.

Your squelch settings will be remembered upon power down, battery removal or change of channel.

General Radio Features

Often-Used Features

This chapter shows you how to access the most frequently used features. The following topics are covered:

• Emergency Call and Alarm (page 19)

• Scan Operation (page 23)

• Optional External Alarms (Horn and Lights) (page 32)

• Time-Out Timer (page 35)

• Push-To-Talk Identification (PTT-ID) (page 35)

• Telephone Interconnect List (Conventional and Trunking) (page 36)

• Unlimited Telephone Interconnect (page 38)

• Call Alert Page (Conventional and Trunking—Digital Modes Only)

(page 43)

General Radio Features

Emergency Call and Alarm

The emergency call and alarm features allow you to have priority channel access and/or send an emergency data transmission to the dispatcher in an emergency situation.

The desired type of emergency feature—alarm, call, call and alarm, or silent alarm—can be preprogrammed by a qualified radio technician.

The radio must be turned on to activate any emergency feature.

Emergency Call

Emergency call gives you priority access to a voice channel for all subsequent transmissions after you press the emergency button. The level of priority access is determined by the system manager.

SmartZone Emergency Call Receive Operation

A radio configured for SmartZone RECEIVED whenever it receives an emergency call. The display alternates with the selected-mode display as long as the radio is unmuted to the emergency call.

operation displays EMER

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Initiating an Emergency Alarm

The emergency alarm feature sends a data transmission to alert the dispatcher of your emergency condition and identify your unit ID.

Press the emergency button.



A tone sounds and the display alternates EMERGENCY with the current zone/channel.



For trunking modes, a high-pitched tone indicates that the alarm has been received by the trunked system’s central controller.

 A dispatcher acknowledgment ACK RECEIVED display follows. 

The radio automatically returns to normal operation. No further action is required.

Initiating an Emergency Call

1 Press the emergency button.



A tone sounds and the display alternates EMERGENCY with the current zone/channel.

2 Press the PTT button and announce your emergency.

3 After completing the emergency call, press and hold the

emergency button until a tone sounds. 

The alternating EMERGENCY display disappears, and the radio returns to normal operation.

General Radio Features

Initiating an Emergency Call and Alarm

If the radio has both emergency call and alarm features, it automatically proceeds to the call mode after the alarm is acknowledged.

1 Press the emergency button to activate the emergency call/

alarm feature.



The display begins alternating EMERGENCY with the current zone/channel.



For trunking modes, a high-pitched tone sounds, indicating that the alarm has been received by the trunked system’s central controller.



A dispatcher acknowledgment (four high-pitched tones) follows, accompanied by an ACK RCVD display.

2 Press the PTT button and announce your emergency.

3 To exit from the emergency state altogether, press and hold the

emergency button until a tone sounds. 

The alternating EMERGENCY display disappears, and the radio returns to normal operation.

Note: Turning the radio off also cancels the emergency state.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Initiating a Silent Emergency Alarm

1 Press the emergency button to activate the silent alarm feature.



During a silent emergency alarm, there are no display changes, and the receiver audio mutes so that no indication is given that an emergency alarm has been sent.

2 To exit the silent alarm mode, press and hold the emergency

button until a tone sounds.

Note: If silent emergency alarm is used with emergency call,

pressing the PTT button exits the silent mode and initiates the emergency call.

Special Considerations for Emergencies

• If you press the emergency button while in a mode that has no emergency capability, a low-pitched tone sounds.

• If the unit is out of the range of the system and/or the emergency alarm is not acknowledged, a tone sounds and the display shows NO ACKNOWLEDGE.

• If you press the emergency button, then change to a mode that has no emergency capability, a NO EMERGENCY display alternates with the mode name display, and a continuous low-pitched tone sounds until a valid emergency mode is selected or until the emergency is cancelled.

• When an emergency is active, changing to another mode where emergency is enabled (trunked or conventional) causes an emergency alarm and/or emergency call to be active on the new mode.

General Radio Features

Scan Operation

The scan feature allows you to monitor activity on different conventional or trunked modes by scanning a scan list of modes. The modes to be scanned in a scan list are programmed by a qualified radio technician. You can select the modes to be scanned in a scan list if operator-selectable scan is enabled.

There are three types of scan lists available:

• Conventional—Comprises up to 15 different conventional-only modes

• Trunked Priority Monitor—Comprises up to 15 modes that are all from the same trunked system

• Talkgroup Scan—Comprises up to 10 combined conventional modes and modes from one trunking system

The radio supports both priority and non-priority scanning. With priority scanning enabled, a scan list can have one mode assigned as the first-priority mode and a second as the second-priority mode.

The XPR 4500 / XPR 4550 Mobile Radio supports automatic scanning (autoscan), which can be programmed into the radio by a qualified radio technician. With this feature, the radio begins scanning whenever you select a mode to which a scan list is assigned.

Note: You cannot turn scan off on a mode that has autoscan

enabled.

If multiple scan types are enabled in the radio, the type of scan that is activated depends on the personality of the mode selected when the SCAN softkey is pressed. For all types of scan, the selected mode is, by default, a member of its own scan list.

Scan lists stay in memory when you turn scan off, turn the radio off, or disconnect the radio from the battery.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Turning On Scan

Do the following:

1 Press the  button to scroll to the SCAN softkey.

2 Press the button below SCAN.



The Scan indicator lights and a list of modes is scanned for activity. The text display area will indicate SCAN ON if scan is currently enabled or SCAN OFF if scan is just been turned off.



When a scanned mode becomes active, the display changes to show the active mode name, the appropriate priority indicator lights, and the radio unmutes.



The radio will not begin scanning again for a predetermined hang time after the call ends, giving you time to respond. The hang time is typically three seconds (by default), but can be changed by a qualified radio technician.

Note: A lit N PRI (non-priority) indicator means that the active

mode is a non-priority member of the scan list (for all scan types).



A solidly-lit PRI (priority) indicator means that the active mode is the priority 2 member of the scan list (Trunking Priority Monitor and Conventional scan types only).



A blinking PRI indicator means that the active mode is the priority 1 member of the scan list (Trunking Priority Monitor and Conventional scan types only).

General Radio Features

Turning Scan On While Disregarding the Squelch Code (Conventional Modes Only)

Do the following:

1 Press the  button to scroll to the MON softkey.

2 Press the button below MON.

3 The brief MONITOR ON display indicates that the radio is

disregarding the squelch code.

Note: While scanning for activity, you can still receive fleetwide,

system-wide, dynamic regrouping, incoming telephone interconnect and Private Conversation/Call Alert calls.



Respond to these types of calls as you would normally on the selected mode. However, when scanning different modes while in talkgroup scan, incoming Private Conversation/Call Alert calls may be missed.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Viewing a Scan List

1 Press and hold the SCAN softkey until the Scan indicator blinks

and a beep is heard. 

The radio suspends scanning while a scan list is being reviewed.

2 Press the  button to scroll to the VIEW softkey.

3 Press the button below VIEW.

4 Press the  button to scroll to the SCAN softkey.

5 Press the button below SCAN. The radio suspends

scanning while a scan list is being reviewed.

6 Press the  or button to scroll through the preprogrammed

scan list.

7 Those modes that are in the scan list are indicated by N PRI,

PRI or blinking PRI indicator (indicating the mode’s assigned

priority as previously described).

8 Press RCL softkey to review only modes that are already in the

scan list.

Press the HOME button momentarily to exit the scan list and resume scanning.

General Radio Features

Transmitting While Scan Is On

Radio Programmed for Talkback Scan

Press the microphone PTT button to transmit on the mode indicated by the display.



The radio does not begin scanning again for a predetermined hang time (programmable by a qualified radio technician) after you release the PTT button, allowing the other party to respond.



If the other party responds within the hang time, scanning does not resume until the full hang time expires after they have finished speaking, allowing the conversation to be completed.

Note: To transmit on the selected channel if another channel is

active, first turn scan off by pressing the SCAN softkey momentarily.

Radio Programmed for Non-Talkback Scan

In selected mode or fixed mode, press the microphone PTT button at any time to transmit on the selected mode or fixed mode.

Note: To make a Call Alert page, or Private Conversation call while

scanning, press either the PAGE or CALL softkey.  The call is entered on the selected mode and scanning is halted until the call is exited by pressing the HOME button or pressing either the PAGE or CALL softkey.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Temporarily Deleting a Nuisance Mode with Scan On

To temporarily delete a mode that you do not wish to hear (nuisance mode), press the NUIS softkey by searching for it with the help of  or .



You can delete undesired modes.

Note: Priority modes, the selected mode, and the designated

transmit mode cannot be deleted.

Restoring a Nuisance Mode

To restore the original scan list, do one of the following:

• Turn scan off, then on.

• Change modes.

• Turn off the radio, and then turn it back on.

Note: Nuisance mode delete can be disabled by the system

administrator.

General Radio Features

Changing Mode Priorities While Scan Is On

When active, this dynamic priority feature allows you to change the priority of a non-priority mode in the scan list to priority 2.

1 Press DYNP softkey to change the priority of a non-

priority channel in the scan list to priority 2.

2 Press the HOME button momentarily to exit the scan list

and resume scanning.

Note: You cannot alter the status of the priority 1 member.

Restoring Mode Priorities in a Scan List

To restore the original mode priorities in a scan list, do one of the following:

•Press RCL softkey.

• Turn scan off, then on.

• Change modes.

• Turn off the radio, and then turn it back on.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Programming a Scan List

To program a scan list, operator-selectable scan list members first must be enabled in the radio programming by a qualified radio technician.

Adding a Channel to the Scan List

1 Press the

2 Press the button below PROG.

3 Press the

4 Press the button below SCAN. The scan indicator blinks

and a good-key chirp is heard.

5 Press the

scan list.

Press the SEL softkey to add the channel.

Scroll through of the available priority choices, and press the SEL softkey to choose one.



The new channel becomes a member of the scan list assigned to the selected channel when scan list programming was entered.

Note: If a scan list is full, you will hear a bad-key chirp each time

Press the HOME button to exit scan list programming and return to normal scan operation.

 button to scroll to the PROG softkey.

 button to scroll to the SCAN softkey.

or button to scroll through the preprogrammed

you press SEL softkey, and the desired channel will not be assigned to the list.

Deleting a Channel from the Scan List

Do the following:

General Radio Features

1 Press the

2 Press the button below PROG.

3 Press the

4 Press button below SCAN. The scan indicator

blinks and a good-key chirp is heard.

5 Press the

channel to be deleted.

Press the SEL softkey momentarily to scroll through the available priority choices until the priority choice disappears.



This indicates that the channel is no longer a member of the scan list that was assigned to the selected channel.

Press the RCL softkey momentarily to scroll through just the scan list members.



Delete a channel from a scan list by pressing the DEL softkey.

 button to scroll to the PROG softkey.

 button to scroll to the SCAN softkey.

or button or Mode knob to locate the

Note: If you delete all members of a scan list, and scan is

subsequently turned on, you will hear a continuous lowpitched tone, and the display will change to EMPTY LIST 



You cannot delete the designated transmit mode, the selected mode, or the fixed scan list members. The selected mode, by default, is always scanned when scan is turned on, regardless of whether or not it is explicitly programmed as a scan list member.

Press the HOME button to exit scan list programming and return to normal scan operation.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Hang Up Box (HUB)

To temporarily suspend Scan Mode operation, remove the microphone from the Hang Up Box (HUB). You are allowed to use the microphone while scan is suspended. Priority Member scanning is not suspended, however. This feature applies to all Scan Lists and Scan Types. Scan is resumed once the microphone is returned to the holding clip and the preprogrammed hang time has elapsed.

Note: Priority Scan List members are continuously scanned only

when the Scan List, Designated Tx Member field is set to “Talkback” in the radio programming. Otherwise, all scan mode operation is suspended.

Optional External Alarms (Horn and Lights)

All control heads can be equipped for external alarms (horn and lights) that are activated when a Call Alert page, Private Conversation call, or phone call is received.

These features are useful when you must leave the vehicle, but need to receive any incoming messages.



The radio always powers up with the horn and lights feature enabled.

Activating the External Alarm(s)

Non-Permanent Horn and Lights

1 Press the H/L softkey momentarily.

If necessary use the within the menu.



The last selected alarm(s) are enabled, and the display alternately shows the enabled alarm(s), then the selected mode.

2 Press the H/L softkey a second time to turn off the alarm(s).

or buttons to access other options

General Radio Features

Permanent Horn and Lights

1 Press the H/L softkey momentarily.

 The last selected alarm(s) are enabled. 

The display briefly shows the enabled alarms, and then reverts back to the selected mode.

2 Press the H/L softkey a second time to turn off the alarm(s).

Changing the Selected Alarms

1 Press and hold the H/L softkey until a tone sounds and the

display indicates the currently selected alarm.

2 Press the appropriate softkey right below the menu to review

the choices until the display shows the desired alarm:

• H/L softkey - HORN/LITES ON (both horn and lights)

• LGTS softkey - LIGHTS ON

• HORN softkey - HORN ON

3 Press the H/L softkey to select the desired alarm and return to

normal operation.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Receiving a Call While Alarms Are Turned On

When a call is received, the vehicle’s horn sounds for four seconds, and/or the car lights turn on for 60 seconds. The time interval can be modified by a qualified radio technician.

The display alternates between the type of call received (CALL,

PAGE, or PHONE) and the selected mode name.

Turning Off Non-Rearmable External Alarm

1 To turn off the external alarm(s), press the PTT button or any

control-head button.

Note: Pressing the CALL, PAGE or PHON softkey will turn off the

external alarm(s) and place you directly in that feature.



The Vol u me knob and the DIM button have no effect on the state of the external alarm(s).

2 To rearm the horn and lights feature, press the H/L softkey

momentarily.

Turning Off Rearmable External Alarms

To turn off the external alarm(s), press the PTT button or any control head softkey or button other than the H/L softkey.



Pressing CALL, PAGE, or PHON softkey turns off the external alarm(s) and places you directly in that feature. When the external alarm(s) are turned off, they will be automatically rearmed.

Note: Pressing the H/L softkey turns off the external alarm(s) and

exits the horn and lights feature. To re-arm the feature, press the H/L softkey momentarily.



The Vol u m e knob and the DIM button have no effect on the state of the external alarms.

General Radio Features

Time-Out Timer

Your XPR 4500 / XPR 4550 Mobile Radio provides a time-out timer function that prevents locking up a repeater or channel by prolonged keying of the transmitter. You cannot transmit longer than the preset timer setting. If you attempt to do so, the radio automatically stops your transmission, and you hear a talk-prohibit tone.

Note: You will hear a brief, low-pitched, warning tone four seconds

before the transmission times out.

The timer is set for 60 seconds at the factory, but it can be reprogrammed by a qualified radio technician for between 15 and 465 seconds (7.75 minutes), in 15-second intervals, or it can be disabled entirely for each radio mode.

Push-To-Talk Identification (PTT-ID)

When you press the PTT button to send a message, your radio ID number is transmitted as part of each voice message. This PTT-ID number is then shown on the receiving radio’s display.

For the digital mode, the display shows up to eight right-justified digits.

Pressing the CALL softkey erases the PTT-ID from the display.

The display conditions of PTT-ID must be programmed by a qualified radio technician.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Telephone Interconnect List (Conventional and Trunking)

With any of the control heads, you can initiate and receive telephone calls if the system is properly equipped. All calls between the mobile operator and the land line are private, regardless of who initiates the call.

All control heads feature a phone list capability of up to 100 preprogrammed phone numbers. The radios can be programmed by a qualified radio technician so that a name can be assigned to each number in the list.

Answering a Phone Call

When a phone call is received, telephone-type ringing sounds and the display shows PHONE CALL.

1 Press the PHON softkey.

2 Press the PTT button to talk; release it to listen.

3 When the call is completed, press the HOME button or PHON

softkey to hang up and return to normal operation.

General Radio Features

Initiating a Telephone Call from the List

1 Press the PHON softkey momentarily to select the phone

function.  A valid-key chirp is heard. 

The display shows the last number dialed or a blank scratchpad appearing as a series of dashes.

2 Press the  or  button to locate the number you want to call.



The display first shows the name, and then the number.

3 Press the PTT button.



The display shows the number that is automatically dialed.

Note: If the number contains a programmed pause, the dialing

pauses briefly when the display shows P. After the brief pause, the rest of the numbers are dialed.



If you are out of range of the trunked system, the display shows NO PHONE, and a continuous low-pitched tone sounds. Press the PHON softkey to resume normal operation.



If the trunked phone interconnect is in use or the phone interconnect is out of service, a telephone-type busy tone sounds, and the display shows PHONE BUSY. Your number is automatically dialed when the phone interconnect becomes available. If you hang up, you lose your place in the queue.



If the display shows PHONE BUSY with a low-pitched tone rather than a telephone-type busy tone, the call is not queued. You must hang up and try again.

4 When your party answers, press the PTT button to talk, and

release it to listen.

5 When the call is completed, press the PHON softkey to hang up

and return to normal operation.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Unlimited Telephone Interconnect

Calling a Phone Number Not in the List

1 Press the  or  button to access the PHON feature. 



Press the softkey under the phone feature.

2 Enter the desired phone number from the optional keypad mic.



The display updates as the numbers are entered.

3 Press Enter on the keypad mic to make the call

4 When your party answers, press the PTT button to talk, and

release it to listen.

Note: If you are out of range of the trunked system, the display

shows NO PHONE, and a continuous low-pitched tone sounds. Press the HOME button or the PHON softkey to resume normal operation.



If your radio is programmed for live overdial, every digit pressed after the phone call is established is sent to the telephone system.



If your radio is programmed for buffer overdial, the digits pressed are entered into the radio’s memory, and they are all sent together when the PTT button is next pressed. You cannot send digits and talk on the same PTT button press. If you press the PTT button to send the digits, you must release the PTT button and press it again to transmit.

5 When the call is completed, press the HOME button or the PHON

softkey to hang up and return to normal operation.

General Radio Features

Storing a Number in the List

1 Press and hold the PHON softkey to select the phone

programming function.

2 Use the navigation keys,  or  to locate the number you want

to change.

3 Press the SEL softkey to edit the number in the display.

4 Enter the new phone number on the keypad.

Note: To backspace, press the # button twice or the Mode down

 button once. Enter a pause by pressing the * button, then

the # button.

5 Press the SEL softkey to store the new number.

6 Do one of the following:

• Press the HOME button to return to normal radio operation.



• Press the PHON softkey to return to normal phone operation.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Editing a Name in the List

1 Press and hold the PHON softkey to enter the phone ID list

programming. 

The Phon indicator flashes and a high-pitched tone sounds.

2 Use the navigation keys,  or  to locate the list member you

want to change.

Use the numbered keys to go immediately to the location of a member in the list. For example, press 2 to go to the second member in the list; press 1 and 0 to go to the tenth member in the list, and so on.

3 Change the characters or numbers using any of the numeric

keys (0 through 9) and special function keys (

*, #).

Note: The maximum number of characters permitted in a text line

is 14. If you try to add too many characters, you will hear a low-pitched tone.

To edit, do any or all of the following:

• To enter a character at the blinking cursor, refer to the table on page 42.



Press the key of the desired character the number of times shown in the table. For example, to enter the character C, press the 2 key three times.

• To leave a space in the text, press the Mode up switch to move the blinking cursor to the next character position, and then enter the character.

 rocker

General Radio Features

• To delete characters, press the Mode down  rocker switch

to move backwards over existing characters.



When the last character on the display has been erased, press the Mode down name-edit mode, without making any changes, and begin

the procedure again at step 2.

4 To save the changes, press and hold the SEL softkey.

Note: Press the SEL softkey momentarily to confirm changes to a

number in the list.

5 Repeat steps 2 through 4 until you have modified all the desired

names,

 OR 

Do one of the following:

• Press the HOME button to return to normal radio operation.



 rocker switch again to leave the

• Press the PHON softkey to return to normal phone operation.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Table 1: Entering Characters Using the Keypad

Number of times the key is pressed

Key

1 2 3 4 5 6 7 8 9

ABC2abc

DEF3def

GHI 4gh i

JKL5 j k l

MNO 6 m n o

PQRS7pqr s

TUV8 t u v

WXYZ9wxyz

*/+-

General Radio Features

Call Alert Page (Conventional and Trunking— Digital Modes Only)

The Call Alert feature allows a radio to selectively alert another radio, and to determine whether or not that radio received the alert. A Call Alert page can be initiated after an unsuccessful Private Conversation call or as a separate feature.

The Controller Head is capable of responding to a Call Alert initiated by another radio. It features a unique list of up to 100 preprogrammed ID numbers. A name can be assigned to each ID in the list for your convenience.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Sending a Call Alert Page

1 Press the PAGE softkey.

 The Page indicator lights and a valid-key chirp sounds. 

The display shows the last transmitted/received unit ID number.

2 Select a radio in one of the following ways:

• From the ID number list:

– Do nothing if you want to call the unit ID currently

displayed.



– Use the prestored list by using the navigation keys to

locate the name/ID you want to call.



– Enter, using the keypad or keypad mic, the ID of the

desired unit.

Note: Using the keypad to enter the ID of another unit can only be

accomplished from the first display shown when Page was entered. If the list has been entered, scroll to the first display.

3 Press the SEL softkey or the microphone PTT button.



The display changes to PLEASE WAIT.

General Radio Features

4 Choose one of the following:

• When the called radio acknowledges the page, four additional tones sound and the display changes to ACK

RCVD. 

The radio returns to normal operation.

• If you are out of the range of the system, a low-pitched tone sounds.

 Try again by pressing the PTT button or or the SEL softkey,  OR 

Press the HOME button or the PAGE softkey to return to normal operation.

• If, after six seconds, the called unit fails to acknowledge the alert, a low-pitched tone sounds and the display changes to

NO ACK.  Try again by pressing the PTT button or the SEL softkey,  OR 

Press the HOME button or the PAGE softkey to exit.

XPR 4500 / XPR 4550 Mobile Radio

General Radio Features

Notes

Conventional Radio Features

Features Used in Conventional Operation

This chapter shows you how to access features available in conventional operation. The following topics are covered:

• Status Calls (Digital Modes Only) (page 48)

• Smart PTT (page 50)

• Conventional Talkgroup Calls (page 50)

• Conventional Talkaround (page 52)

• Selective Calls (Digital Modes Only) (page 52)

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Status Calls (Digital Modes Only)

Radio status calls are used to inform the dispatcher of the present state of the mobile unit. For example, a status might be ENROUTE or AT SITE.

Status names are field programmable. Each radio can have up to 8 separate statuses.

Sending a Status Call

1 Press the STS softkey, and the display shows the last-

acknowledged status name.

2 Press the  or  button to review the list of status names, or

use the keypad mic to enter the number of the status you wish to send.

Note: If no button is pressed for a period of time, an inactivity

warning will sound.

3 The display shows the desired status name or number, press

the PTT button to send the transmission.



One of the following conditions occurs:

• The radio display shows PLEASE WAIT until the transmission is received and acknowledged.



When the dispatcher acknowledges the status, four highpitched tones sound, and the display shows ACK RECEIVED.



The radio then returns to normal dispatch operation.

• If the status is not acknowledged after approximately six seconds, the display alternates between NO ACKNOWLEDGE and the associated status name. A low-pitched tone also sounds continuously.

Conventional Radio Features

• If there is no acknowledgment, do one of the following:



Press the microphone PTT button to resend the status transmission.

 OR 

Press the HOME button to return to normal dispatch operation.

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Smart PTT

Smart PTT is a per-mode feature that gives the system manager better control of radio operations. When smart PTT is enabled in your radio, you will not be able to transmit on an active mode. If you try to transmit (press the PTT button) on a busy or active smart PTT channel, a continuous tone sounds until you release the PTT button, and the transmission is inhibited.

The yellow BUSY LED lights when the radio is receiving to indicate that the mode is busy.

Three radio-wide variations of smart PTT can be enabled on your radio:

Transmit Inhibit on Busy Mode with Carrier

Transmit Inhibit on Busy Mode with Wrong Squelch Code

Quick-Key Override You can override either of the two previous

You will not be able to transmit if any activity is detected on the mode.

You will not be able to transmit on an active mode that has a squelch code other than your own.

transmit-inhibit states by quick-keying the radio (two quick PTT button presses).

Conventional Talkgroup Calls

Digital Modes Only

This feature allows you to define talkgroups for your conventional system. Talkgroups, combined with selective squelch operation, allow groups of users to transparently share a conventional channel. Talkgroups can be slaved to a personality through programming, or you can select them.

Encryption keys are slaved to talkgroups. When conventional talkgroups are enabled, encryption keys are changed by changing the active talkgroup.

Conventional Radio Features

Selecting a Conventional Talkgroup

The Talkgroup Select feature allows you to manually select any one of the available talkgroups.

1 Press the TGRP softkey.

The display changes to show the last-selected talkgroup.

2 Rotate the Mode knob to choose a different talkgroup.

3 Press the SEL softkey to save the talkgroup.



The radio returns to the home display.

Note: To select the default talkgroup, press the SEL softkey while

the radio displays PRESET.



Selecting the PSET softkey causes the radio to return to its preprogrammed talkgroup.



To abort the talkgroup menu, press the HOME button or the PTT button:

– Pressing HOME exits the talkgroup select menu without

saving the selected talkgroup choice.

– Pressing the PTT button exits the menu without saving

the selected talkgroup and allows the radio to transmit.

Note: If the encryption key slaved to the new talkgroup is erased,

the display shows KEY FAIL and a momentary tone is generated. If the encryption key that is slaved to the new talkgroup is not allowed, the display shows ILLEGAL KEY and a momentary tone is generated.

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Conventional Talkaround

Talk Direct (Mobile-To-Mobile)

To talk directly to another unit without going through the conventional repeater system:

1 Press the DIR softkey momentarily.



The Dir indicator lights, indicating that the radio is now transmitting directly to another unit.

2 To return to repeater operation, press the DIR softkey again.



The Dir indicator goes out.

Note: A conventional personality can be configured to always

transmit on the direct mobile-to-mobile frequency. In this case, the Dir indicator is lit continuously while the mode is selected.

Selective Calls (Digital Modes Only)

The Selective Call feature not only allows you to carry on a conversation that is heard only by the two parties involved, but also enables you to determine whether the unit you are calling is in service.

The Control Head is capable of responding to a Selective Call initiated by another radio. It features a unique list of preprogrammed ID numbers. A name may be assigned to each ID in the list for your convenience.

Conventional Radio Features

Answering a Selective Call

When a Selective Call is received, two high-pitched tones sound and the display alternates between CALL RECEIVED and the home display.

1 Press the CALL softkey within 20 seconds of receiving the call.

(This time is programmable by a qualified radio technician.)



The display shows the ID number of the calling unit.

2 To respond to the call, press the PTT button and talk.



If 20 seconds pass before you press the CALL softkey, you will not respond privately to the call just received. Instead, when you press the CALL softkey, you enter the Selective Call state, as described in “Selective Calls (Digital Modes Only)” on page 52.



If the system is busy when you attempt to answer the call, a telephone-type busy tone sounds and your radio’s BUSY indicator lights. When a channel becomes available, you receive a call back, and your radio automatically keys up for three seconds so that you can begin talking.

Note: If you do not press the CALL softkey before pressing the

PTT button, your conversation will be heard by all members of the talk group.

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Initiating a Selective Call

To initiate a Selective Call, select a unit to call, then place the call.

1 Press the CALL softkey.



The Call indicator lights, and the display shows the last transmitted/received unit ID number.

2 Select a unit in one of the following ways:

• From the ID number list:

– Do nothing if you want to call the unit ID currently

displayed.



– Use the prestored list by using the navigation keys to

locate the name/ID you want to call.



– Enter, using the keypad, the ID of the desired unit.

Note: Using the keypad to enter the ID of another unit can only be

accomplished from the first display shown when CALL was entered. If the list has been entered, scroll to the first display.

3 Press the microphone PTT button.



A telephone-type ringing sounds if the unit you are calling is in service. The display shows PLEASE WAIT.

Conventional Radio Features

4 Choose one of the following conditions that applies to your

current call:

• If the receiving unit answers, identify yourself and begin your Selective Call.

• If, after a programmable time period, you are not connected, the display shows NO ACKNOWLEDGE and a momentary, lowpitched tone sounds.



Try again, or press the HOME button to return to normal operation.

• If you are out of the system’s range, a low-pitched tone sounds.



Try again, or press the HOME button to return to normal operation.

• If the system is busy when you attempt to make a call, the radio you are calling hears a telephone-type busy tone. When a channel becomes available, the called radio receives a call back and automatically keys up for three seconds so that conversation can begin.

5 To return to normal operation, press the HOME button.

Note: If you do not press HOME to hang up, your unit will remain in

the Selective Call state with the other unit. You will miss all subfleet traffic and incoming phone calls.

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Viewing Your Unit ID Number

1 Press the CALL softkey momentarily to select the Selective Call

feature. 

The Call indicator lights.

2 Do one of the following:

•Use the left navigation key to locate the MY ID display.



The display will alternate between MY ID and your ID number.

3 To return to normal operation, press the HOME button. .

Conventional Radio Features

Storing a Unit ID Number in the List

The Selective and Call Alert page features share the same prestored list of units’ IDs.

1 Press and hold the CALL softkey to review the Call ID list.



The Call indicator flashes and a high-pitched tone sounds.

2 Use the navigation keys to locate the list member you want to

change.

3 Press the NAME softkey to store a name 

 OR 

press the NUM softkey to store a number.

4 Use the keypad mic to update the entry.

5 When all the digits are entered, press the SAVE softkey to store

the new ID.

6 Repeat steps 2 through 5 until all the desired IDs have been

entered.

 OR 

Do one of the following:

• Press the HOME button to return to normal radio operation.



• Press PTT to exit the feature.

Note: The maximum number of characters permitted in a text line

is 14.

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Editing a Name in the List

The Selective Call and Call Alert page features share the same prestored list of unit IDs.

1 Press and hold the CALL or PAGE softkey to enter the Call ID list.



The Call indicator flashes and a high-pitched tone sounds.

2 Use the navigation keys to locate the list member you want to

change.  OR 

3 Press and hold the SEL button to select the name-editing

function.

4 Change the characters or numbers using any of the numeric

keys (0 through 9) and special function keys ( keyapd mic.

*, #) with the

Note: The maximum number of characters permitted in a text line

is 14. If you try to add too many characters, you will hear a low-pitched tone.

To edit, do any or all of the following:

• To enter a character at the blinking cursor, refer to the table on page 42.



Press the key of the desired character the number of times shown in the table. For example, to enter the character C, press the 2 key three times.

• To leave a space in the text, press the up  navigation key to move the blinking cursor to the next character position, and then enter the next character.

Conventional Radio Features

• To delete characters, press the down  navigation key to move backwards over existing characters.



When the last character on the display has been erased, press the down

 navigation key again to leave the name-

edit mode, without making any changes, and begin the procedure again at step 2.

5 To save the changes, press and hold the SEL softkey.

Note: Press the SEL softkey momentarily to confirm changes to a

number in the list.

6 Repeat steps 2 through 5 until you have modified all the desired

names.

 OR 

Do one of the following:

• Press the HOME button to return to normal radio operation.



• Press PTT to exit the feature.

XPR 4500 / XPR 4550 Mobile Radio

Conventional Radio Features

Notes

Troubleshooting

The following are suggestions to assist you in troubleshooting possible operating problems.

The cables that connect to the rear of the radio could have live voltage on some of their pins. Do not remove or reconnect these cables. Only a qualified radio technician should perform this task. Service performed by unauthorized personnel may cause the radio to transmit an emergency alarm even if the unit is turned off.

If your radio is locked up or the display shows FAIL 01/90, turn the radio off and then back on. If this does not correct the condition, take the radio to a qualified radio technician for service.

If radio operation is intermittent, check with other persons using the system for similar problems before taking the radio in for service. Similar problems indicate a system malfunction rather than a radio failure.

If symptoms persist or, if your unit exhibits other problems, contact a qualified radio technician.

CAUTION

XPR 4500 / XPR 4550 Mobile Radio

Troubleshooting

Accessories

Motorola provides the following approved accessories to improve the productivity of your XPR 4500 / XPR 4550 mobile two-way radio.

For a list of Motorola-approved antennas and other accessories, visit the following web site:

http://www.motorola.com/governmentandenterprise

Antennas

Part No. Description

HAE4002_ UHF 403- 430 MHz, 1/ 4 Wave Roof

Mount Mini U

HAE4003_ UHF 450- 470 MHz, 1/ 4 Wave Roof

Mount Mini U

HAE4010_ UHF 406- 420 MHz, 3.5dB Gain Roof

Mount Mini U

HAE4011_ UHF 450- 470 MHz, 3.5dB Gain Roof

Mount Mini U

RAE4004_RB UHF 445-470 MHz, 5.0dB Gain Roof

Mount Mini U

XPR 4500 / XPR 4550 Mobile Radio

Accessories

Cables

Part No. Description

RKN4135_ 15ft Speaker Cable (for Public Address

Speaker)

RKN4136_ Ignition Switch Cable

HKN4137_ Power Cable (to Battery) - 10 Ft.

HKN4192_ Power Cable (to Battery) - 20 Ft.

Desktop

Part No. Description

GLN7318_ Desktop Tray without Speaker

RSN4005_ Desktop Tray with Speaker

HPN4001_ Power Supply 14V 10 Amp 117/240 VAC

(25-60W)

GPN6145_ Switchmode Power Supply (CE Marked

for EMEA)

GKN6266_ Power Supply Cable (PS to desktop

mobile cable for GPN6145)

NTN7373_R US Linecord (3060665A04) - PS power

cable

NTN7374_R Euro Linecord (3060665A05) - PS

power cable

NTN7375_R UK Linecord (300212F02) - PS power

cable

NTN9246_ Argentina Linecord (3085801L01) - PS

power cable

HKN9088_ Adapter Cable for Control Station - 8

Foot

Microphones

Part No. Description

RMN5052_ Core Compact Mic

RMN5065_ Smart Keypad Mic

RMN5053_ Smart Heavy Duty Mic

RMN5050_ Core Desktop Mic

RMN5054_ Smart Visor Mic

Miscellaneous

Part No. Description

RLN5926_ Push Button PTT

RLN5929_ Emergency Footswitch

HLN9073_ Mic Hang Up Clip

HLN9414_ Mic Hang-up clip (no installation

required)

Accessories

HKN9557_ PL259/Mini-U Antenna Adapter - 8"

cable

Mounting Kits

Part No. Description

GLN7324_ Low Profile Mounting bracket

GLN7317_ High Profile Mounting bracket

RLN4779_ Key Lock Mt

RLN5933_ DIN Mount

XPR 4500 / XPR 4550 Mobile Radio

Accessories

Speakers

Part No. Description

RSN4002_ 13 Watt External Loudspeaker

RSN4003_ 7.5 Watt External Speaker

RSN4004_ 5 Watt External Speaker

HSN1000_ 6-Watt Public Address Speaker

(weather resistant)

Glossary

ACK Acknowledgment of communication.

Channel A group of characteristics, such as transmit/

receive frequency pairs, radio parameters, and encryption encoding.

Coded Squelch Tone Private-Line™ or Digital Private-Line.

Used on conventional channels to make sure you hear only the communication meant for you.

Control Channel In a trunking system, one of the channels that

is used to provide a continuous, two-way/data communications path between the central controller and all radios on the system.

Conventional Typically refers to radio-to-radio

communications, sometimes through a repeater. You share a frequency, or frequencies, with other users without the aid of a central controller to assign communication channels. Therefore, you should monitor each channel before transmitting to avoid interfering with another user who may be transmitting.

Cursor A visual tracking marker (a blinking line) that

indicates a location on the display.

Digital PrivateLine (DPL) Coded Squelch

Dispatcher An individual who has radio system

Failsoft A back-up system allowing you to

FCC Federal Communications Commission.

XPR 4500 / XPR 4550 Mobile Radio

A continuous, sub-audible data signal, transmitted with the carrier.

management duties.

communicate in a non-trunked, conventional mode should the trunked system fail.

Glossary

Hang Up Disconnect.

Home Display The first display information after the radio

completes its self test.

LCD Liquid-Crystal Display.

Mode A programmed combination of operating

parameters; for example, a channel or talkgroup.

Mode-Slaving Radio programmed to automatically give the

proper operation for a given mode you have selected.

Monitoring (Conventional Operation)

Press a programmed monitor button to listen to another user active on the channel. This way, you may be prevented from talking over someone else’s conversation.

Page A one-way alert, with audio and/or display

messages.

Push-To-Talk (PTT) button

The PTT button engages the transmitter and puts the radio in transmit (send) operation when pressed. Press this button to transmit; release it to receive.

Repeater A conventional radio feature, in which you talk

through a receive/transmit facility (repeater) that re-transmits received signals in order to improve communications range and coverage.

RF Radio Frequency. A part of the general

frequency spectrum between the audio and infrared light regions (about 10 kHz to 10,000,000 MHz).

RSSI Received Signal Strength Indicator.

XPR 4500 / XPR 4550 Mobile Radio

Glossary

Squelch The muting of audio circuits when received

signal levels fall below a pre-determined threshold. With carrier squelch, you hear all channel activity which exceeds the radio’s preset squelch level.

Standby An operating condition whereby the radio’s

speaker is muted but still continues to receive data.

Talkgroup An organization (or group) of radio users who

communicate with each other, using the same communication path.

Tone Private-Line (PL) Coded

A continuous sub-audible tone transmitted with the carrier.

Squelch

Trunking The automatic sharing of communications

paths between a large number of users (see Conventional). Allows radio users to share a smaller number of frequencies because a repeater, or communications path, is assigned to a talkgroup for the length of a conversation.

Zone A grouping of channels or talkgroups.

Index

Symbols

800 MHz frequencies ....................2

add scan list channel ..................30

adjust

display brightness .....................5

squelch level ...........................17

volume .......................................5

alarms

activate non-permanent ..........32

activate permanent ..................33

change selected ......................33

horn and lights .........................32

initiate

emergency ...........................20

emergency call and alarm ....21

silent emergency .................22

non-permanent horn 

and lights activation ..............32

non-rearmable external ...........34

optional external ......................32

permanent horn and lights

activation ................................33

rearmable external ..................34

receiving call when on .............34

alert tones .....................................7

answer

Enhanced Private Conversation

call .........................................53

phone call ................................36

automatic scanning .....................23

autoscan .....................................23

basic operation ...........................11

box, hang up (HUB) ....................32

button

PTT .........................................27

call

answer phone .........................36

conventional talkgroup ............ 50

emergency .............................. 19

Enhanced Private 

Conversation ........................ 54

initiate

emergency .......................... 20

Enhanced Private 

Conversation ...................... 54

from phone list ..................... 37

phone number not in list ......... 38

receiving when alarms 

turned on .............................. 34

Call Alert page

description ..............................43

placing ....................................44

selecting unit to call ................ 44

sending ...................................44

calls, status ................................. 48

change

mode ....................................... 12

mode in current zone .............. 13

mode not in current zone ........ 13

mode priorities ........................ 29

selected alarms ....................... 33

zone ........................................ 12

channels, conventional ................. 6

control head

operation ...................................3

status display ............................ 7

conventional

channel ..................................... 6

mode ....................................... 15

scan list ................................... 23

selecting talkgroup .................. 51

talkaround ...............................52

talkgroup calls ......................... 50

conventional mode, monitoring

activity ....................................... 16

current zone

change mode .......................... 13

select mode ............................13

XPR 4500 / XPR 4550 Mobile Radio

Index

delete

nuisance mode ........................28

scan list channel ......................31

display, brightness adjustment ......5

edit name in list ...........................40

embedded signaling ......................2

emergencies, special 

considerations ..........................22

emergency call

initiating ...................................20

trunking ....................................19

emergency call and alarm

description ...............................19

initiating ...................................21

Enhanced Private Conversation

answer a call ............................53

initiate call ................................54

select unit to call ......................54

entering keypad characters .........42

external alarms ............................32

activate non-permanent horn 

and lights ...............................32

activate permanent horn 

and lights ...............................33

non-rearmable .........................34

rearmable ................................34

frequency ranges

800 MHz ....................................2

glossary .......................................90

hang time ....................................24

hang up box (HUB) .....................32

Home

mode, selecting .......................14

horn and lights alarms ................32

HUB (hang up box) ..................... 32

identification, radio ........................ 3

indicator

N PRI (non-priority) ................. 24

PRI (priority) ............................24

scan ........................................ 24

initiate

emergency alarm .................... 20

emergency call and alarm ....... 21

Enhanced Private Conversation 

call ........................................54

phone call from list .................. 37

silent emergency alarm ........... 22

interconnect, unlimited telephone 38

introduction to radios ....................1

keypad

character selection sequence .42

entering characters .................42

list

edit name ................................40

phone, place call .....................37

scan ........................................ 23

store phone number ................ 39

telephone interconnect ............ 36

mode

changing .................................13

changing outside current zone 13

priorities, changing .................. 29

selecting .................................. 13

selecting Home .......................14

selecting outside current zone 13

selection .................................. 12

100

Index

slaving .......................................6

transmitting (conventional) ......15

transmitting (trunked) ..............15

trunked ......................................6

monitoring

conventional mode activity ......16

N PRI (non-priority) indicator ......24

non-priority scanning ...................23

non-rearmable external alarms ...34

non-talkback scan .......................27

nuisance mode

deleting ....................................28

restoring ..................................28

operation

basic ........................................11

control head ..............................3

scan .........................................23

operator-selectable scan .............23

phone numbers, preprogrammed 36

place phone call from list ............37

placing Call Alert page ................44

power level selection ...................16

powering on radio .....................4, 5

preprogrammed phone numbers 36

PRI (priority) indicator .................24

priority scanning ..........................23

programming scan list .................30

PTT button ..................................27

PTT-ID (Push-to-Talk 

identification) ............................35

Push-to-Talk 

identification (PTT-ID) ..............35

radio identification .........................3

rearmable external alarms ..........34

receive

call with alarms turned on ....... 34

restore

mode priorities ........................ 29

nuisance mode ....................... 28

scan

autoscan .................................23

indicator ..................................24

non-priority .............................. 23

non-talkback ........................... 27

operation .................................23

operator-selectable ................. 23

priority ..................................... 23

talkback ................................... 27

transmit while on ..................... 27

turning on ................................ 24

scan list

add a channel ......................... 30

conventional ............................23

delete a channel ..................... 31

modes ..................................... 23

programming ........................... 30

restore mode priorities ............ 29

talkgroup scan ........................ 23

trunked priority ........................ 23

viewing ....................................26

select

Call Alert page unit ................. 44

conventional talkgroup ............ 51

Home mode ............................ 14

mode ....................................... 12

mode in current zone .............. 13

mode not in current zone ........ 13

power level .............................. 16

volume level .............................. 5

zone ........................................ 12

send

Call Alert page ........................ 44

status call ................................ 48

service ........................................ 97

slaved programming ..................... 6

XPR 4500 / XPR 4550 Mobile Radio

Index

slaving, mode ................................6

smart PTT ...................................50

squelch, adjusting level ...............17

status calls

description ...............................48

sending ....................................48

status display, control head ...........7

store phone number in list ...........39

talk direct (mobile-to-mobile) .......52

talkback scan ..............................27

talkgroup scan list .......................23

telephone interconnect list ..........36

time-out timer ..............................35

tones, alert ....................................7

transmit

conventional modes .................15

trunked modes .........................15

with scan on ............................27

transmitting ..................................15

troubleshooting ...........................61

trunked

Call Alert page .........................43

mode ...................................6, 15

priority scan list ........................23

trunking

answer phone call ....................36

emergency call ........................19

initiating emergency call ..........20

status calls ...............................48

telephone interconnect list .......36

unlimited telephone 

interconnect ..........................38

turn on

radio ......................................4, 5

scan .........................................24

interconnect ..............................38

VHF frequency ..............................2

viewing scan list .......................... 26

volume, adjusting ..........................5

warranty ...................................... 93

zone selection ............................. 12

UHF frequencies ...........................2

units

troubleshooting ........................61

unlimited telephone

102

Commercial Warranty and Service

Limited Warranty

MOTOROLA COMMUNICATION PRODUCTS

I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG:

MOTOROLA INC. (“MOTOROLA”) warrants the MOTOROLA manufactured Communication Products listed below (“Product”) against defects in material and workmanship under normal use and service for a period of time from the date of purchase as scheduled below:

XPR 4500 / XPR 4550 Mobile Radio Two (2) Years

Product Accessories One (1) Year

Motorola, at its option, will at no charge either repair the Product (with new or reconditioned parts), replace it (with a new or reconditioned Product), or refund the purchase price of the Product during the warranty period provided it is returned in accordance with the terms of this warranty. Replaced parts or boards are warranted for the balance of the original applicable warranty period. All replaced parts of Product shall become the property of MOTOROLA.

This express limited warranty is extended by MOTOROLA to the original end user purchaser only and is not assignable or transferable to any other party. This is the complete warranty for the Product manufactured by MOTOROLA. MOTOROLA assumes no obligations or liability for additions or modifications to this warranty unless made in writing and signed by an officer of MOTOROLA. Unless made in a separate agreement between MOTOROLA and the original end user purchaser, MOTOROLA does not warrant the installation, maintenance or service of the Product.

MOTOROLA cannot be responsible in any way for any ancillary equipment not furnished by MOTOROLA which is attached to or used in connection with the Product, or for operation of the Product with any ancillary equipment, and all such equipment is expressly excluded from this warranty. Because each system which may use the Product is unique, MOTOROLA disclaims liability for range, coverage, or operation of the system as a whole under this warranty.

XPR 4500 / XPR 4550 Mobile Radio

Commercial Warranty and Service

II. GENERAL PROVISIONS:

This warranty sets forth the full extent of MOTOROLA'S responsibilities regarding the Product. Repair, replacement or refund of the purchase price, at MOTOROLA’s option, is the exclusive remedy. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL MOTOROLA BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME, INCONVENIENCE, COMMERCIAL LOSS, LOST PROFITS OR SAVINGS OR OTHER INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE SUCH PRODUCT, TO THE FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW.

III. STATE LAW RIGHTS:

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY.

This warranty gives specific legal rights, and there may be other rights which may vary from state to state.

IV. HOW TO GET WARRANTY SERVICE:

You must provide proof of purchase (bearing the date of purchase and Product item serial number) in order to receive warranty service and, also, deliver or send the Product item, transportation and insurance prepaid, to an authorized warranty service location. Warranty service will be provided by Motorola through one of its authorized warranty service locations. If you first contact the company which sold you the Product, it can facilitate your obtaining warranty service. You can also call Motorola at 1-888-567-7347 US/Canada.

Commercial Warranty and Service

V. WHAT THIS WARRANTY DOES NOT COVER:

A) Defects or damage resulting from use of the Product in other

than its normal and customary manner.

B) Defects or damage from misuse, accident, water, or neglect.

C) Defects or damage from improper testing, operation,

maintenance, installation, alteration, modification, or adjustment.

D) Breakage or damage to antennas unless caused directly by

defects in material workmanship.

E) A Product subjected to unauthorized Product modifications,

disassemblies or repairs (including, without limitation, the addition to the Product of non-Motorola supplied equipment) which adversely affect performance of the Product or interfere with Motorola's normal warranty inspection and testing of the Product to verify any warranty claim.

F) Product which has had the serial number removed or made

illegible.

G) Rechargeable batteries if:

• any of the seals on the battery enclosure of cells are broken or show evidence of tampering.

• the damage or defect is caused by charging or using the battery in equipment or service other than the Product for which it is specified.

H) Freight costs to the repair depot.

I) A Product which, due to illegal or unauthorized alteration of

the software/firmware in the Product, does not function in accordance with MOTOROLA’s published specifications or the FCC type acceptance labeling in effect for the Product at the time the Product was initially distributed from MOTOROLA.

XPR 4500 / XPR 4550 Mobile Radio

Commercial Warranty and Service

J) Scratches or other cosmetic damage to Product surfaces that

does not affect the operation of the Product.

K) Normal and customary wear and tear.

VI. PATENT AND SOFTWARE PROVISIONS:

MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a United States patent, and MOTOROLA will pay those costs and damages finally awarded against the end user purchaser in any such suit which are attributable to any such claim, but such defense and payments are conditioned on the following:

A) that MOTOROLA will be notified promptly in writing by such

purchaser of any notice of such claim;

B) that MOTOROLA will have sole control of the defense of such

suit and all negotiations for its settlement or compromise; and

C) should the Product or parts become, or in MOTOROLA’s

opinion be likely to become, the subject of a claim of infringement of a United States patent, that such purchaser will permit MOTOROLA, at its option and expense, either to procure for such purchaser the right to continue using the Product or parts or to replace or modify the same so that it becomes non-infringing or to grant such purchaser a credit for the Product or parts as depreciated and accept its return. The depreciation will be an equal amount per year over the lifetime of the Product or parts as established by MOTOROLA.

MOTOROLA will have no liability with respect to any claim of patent infringement which is based upon the combination of the Product or parts furnished hereunder with software, apparatus or devices not furnished by MOTOROLA, nor will MOTOROLA have any liability for the use of ancillary equipment or software not furnished by MOTOROLA which is attached to or used in connection with the

Commercial Warranty and Service

Product. The foregoing states the entire liability of MOTOROLA with respect to infringement of patents by the Product or any parts thereof.

Laws in the United States and other countries preserve for MOTOROLA certain exclusive rights for copyrighted MOTOROLA software such as the exclusive rights to reproduce in copies and distribute copies of such Motorola software. MOTOROLA software may be used in only the Product in which the software was originally embodied and such software in such Product may not be replaced, copied, distributed, modified in any way, or used to produce any derivative thereof. No other use including, without limitation, alteration, modification, reproduction, distribution, or reverse engineering of such MOTOROLA software or exercise of rights in such MOTOROLA software is permitted. No license is granted by implication, estoppel or otherwise under MOTOROLA patent rights or copyrights.

VII. GOVERNING LAW:

This Warranty is governed by the laws of the State of Illinois, USA.

Service

Proper repair and maintenance procedures will assure efficient operation and long life for this product. A Motorola maintenance agreement will provide expert service to keep this and all other communication equipment in perfect operating condition. A nationwide service organization is provided by Motorola to support maintenance services. Through its maintenance and installation program, Motorola makes available the finest service to those desiring reliable, continuous communications on a contract basis. For a contract service agreement, please contact your nearest Motorola service or sales representative, or an authorized Motorola dealer.

Express Service Plus (ESP) is an optional extended service coverage plan, which provides for the repair of this product for a period of three years from the date of shipment from the factory, or the date of delivery if purchased from an authorized Motorola two-way radio dealer. For more information about ESP, contact the Motorola Radio Support Center, 2204 Galvin Drive, Elgin, IL 60123, 1-800-227-6772.

XPR 4500 / XPR 4550 Mobile Radio

Commercial Warranty and Service

Notes

Transmitting (Conventional Modes)

operation.

1 Press Dir (Direct) softkey. The Dir indicator lights.

2 Press Dir softkey again to return to repeater

Activating Scan

1 Press Scan softkey to start a scan. If no activity

exists, the display shows your selected mode. When

a scanned channel or talkgroup becomes active, the

display shows the active mode name. The PRI and

scan list is being displayed and the scan indicator

blinks.

to program.

to add or remove the displayed mode from the scan

NPRI indicators show priority.

2 Press Scan softkey again to stop scanning.

Programming a Scan List

1 Press Prog softkey followed by Scan softkey until the

2 Use the navigation keys to select the mode you want

list.

3 Press the Sel softkey as indicated in the table below

4 Repeat the previous steps to continue editing the list.

5 Press Home button to exit.

Press Sel Mode Indicator

One time Non-Priority NPRI lit

Two times Second Priority PRI lit

Three times First Priority PRI blinks

Four times Delete from List No indicator

Selecting Scan Mode Priority

to designate up to two modes as priorities.

1 Press the Sel softkey as indicated in the table above

2 Press Home or Scan to end scan list selection.

BASIC OPERATION

Press the Pwr button once.

Turning the Radio On and Off

Setting the Volume and Squelch

1 Turn the Vol knob clockwise to increase volume or

counterclockwise to decrease volume as desired.

squelch.

Private-Line, press MON softkey to defeat the coded

operation.

3 Press MON softkey again to return to coded-squelch

2 On conventional modes with Private-Line or Digital

4 To adjust squelch level, hold MON softkey until a tone

sounds.

level or counterclockwise to decrease squelch level.

6 Press Home button to save the squelch level.

5 Rotate the Mode knob clockwise to increase squelch

ATT ENTION !

Before using this product, read the operating instructions

for safe usage contained in the Product Safety and RF

Exposure booklet enclosed with your radio.

XPR 4500 / XPR 4550 Mobile

Radio with Control Head

Quick Reference Card

Caution

Product Safety and RF Exposure Compliance

This radio is restricted to occupational use only to satisfy

FCC RF energy exposure requirements. Before using this

product, read the RF energy awareness information and

operating instructions in the Product Safety and RF

Exposure booklet enclosed with your radio (Motorola

Publication part number 6881095C99) to ensure

compliance with RF energy exposure limits.

Rotate the Mode knob to select the desired mode.ORPress Home button to access the preprogrammed

Changing Modes

Home mode.

1 Press and hold the microphone PTT button.

Transmitting

tones sound (or a talk-permit tone or ID sidetone

sounds), speak into the microphone in a normal voice.

transmission.

2 When the transmit light comes on solid and no alert

3 State your FCC call sign at the beginning of each

orto scroll to the desired zone.

display. The tone and display repeat every five

seconds.



ORTo send a Call Alert page following an Enhanced

Private Conversation attempt, follow the instructions

for sending a direct-entry Enhanced Private

Sending a Status Transmission

Conversation call.

acknowledged status or first status name.

1 Press Sts softkey. The display shows the last

Conversation to select a unit ID.

to the displayed ID,

1 Press the Page softkey.

Initiating a Call Alert Page

Alarm above) is displayed, the radio

Alarm and Call After ACK RECEIVED (see Non-Silent

Alarm Type Indications/Actions

has priority voice-channel access.

3 Press Sel or the PTT button to send a Call Alert page

2 Follow the instructions for initiating a Private

Press the PTT button and talk.After completing the call, press and

hold the emergency actuator until a

tone sounds to return to normal

operation.

Four tones sound and PAGE RCV flashes on the

Answering a Call Alert Page

display flashes the selected status/message name

3 Press the PTT button to send the transmission. The

2 Use the navigation keys to select other statuses.



ORInitiate an Enhanced Private Conversation call to the

caller.

1 Press the PTT button,

until the dispatcher acknowledges, at which time alert

tones sound and the display shows ACK RECEIVED.

The radio then returns to normal operation.

Sending a Direct-Entry Enhanced Private

Conversation Call

display changes to PLEASE WAIT, followed by

1 Press the PTT button. A single tone sounds and the

Selecting a Zone/Mode (Optional)

telephone-type ringing if the receiving unit is in

service.

key

1 Press the Zone softkey and then the arrow

identify yourself and proceed with your call.ORIf the called unit does not respond, press Sel or the

2 If the receiving unit answers, press the PTT button to

2 Rotate the Mode knob to select the mode.

Press the Home button.

Selecting a Home Zone/Home Mode

PTT button again to leave a Call Alert page message

and your ID.

A single tone followed by four tones sounds if the

called unit acknowledges the page.

Press the emergency actuator (Emer button,

Sending an Emergency Alarm or Call

footswitch, hidden pushbutton) to begin an

emergency transmission.

For conventional modes, a silent or non-silent

emergency alarm data transmission is sent.For trunked modes, emergency call (priority access

to a voice channel), silent or non-silent emergency

alarm, or emergency alarm and call are entered.Depending on your radio's programming, one of the



hold the emergency button to stop the

emergency condition and unmute the

radio.

zone/channel. When acknowledged,

four more tones sound and the display

shows ACK RECEIVED, then the radio

alternates between EMERGENCY and the

emergency sequences described in the table below

occur.

Alarm Type Indications/Actions

Non-Silent A tone sounds and the display

returns to normal operation.

changes take place during the alarm. Press the PTT button, or press and

Silent The audio is muted and no display

A tone sounds and the display

alternates between EMERGENCY and the

Call (Trunked

Modes only)

zone/channel.



Press the PTT button and talk.After completing the call, press and

hold the emergency actuator until a

tone sounds to return to normal

operation.

DISPLAY AND LIGHT INDICATORS

Selecting a Key Index

activity on it, or selected trunked

Display/Light Meaning

BUSY light on Displayed conventional mode has

1 Press and hold the SEC softkey until a tone sounds..

2 Use the navigation keys to scroll to INDX SEL.

system is currently busy. Wait for

callback.

3 Press Sel to enter the Index Selection Menu.

XMIT light on Indicates you are transmitting.

4 Use the navigation keys to select desired index.

mobile) operation.

Dir indicator lit Radio is in direct (mobile-to-

5 Press Sel to select index.

Display shows a mode in the scan

PRI, NPRI

6 Press Home or the PTT button to quit.

list with the indicated priority level.

Sel softkey to continue the dialing.

Unit being called with the

Enhanced Private Conversation or

Call Alert Page feature is not in

service, or emergency alarm or

status/message transmission is

not acknowledged by dispatcher.

Trunked phone interconnect is

busy.

Unit being called with Enhanced

Private Conversation or Call Alert

Page does not respond, but is

operational.

Radio is in emergency alarm or call

state.

A mode incapable of emergency

transmission has been selected.

Radio is out of range of the

trunking system.

indicators lit

P displayed Telephone dialing pause. Press

NO ACKNOWLEDGE

Erasing an Encryption Key

displayed

1 Press and hold the SEC softkey until a tone sounds.

PHONE BUSY

displayed

NO ANSWER

displayed

EMERGENCY

displayed

NO EMERGENCY

displayed

OUT OF RANGE

displayed

2 Use the navigation keys to scroll to ERASE KY.

3 Press Sel to enter the Key Erase Menu.

4 Use the navigation keys to select desired index.

5 Press Sel to select index.

6 Press Home or the PTT button to quit.

lights up.

Press and release the SEC softkey. The D indicator

Selecting Secure Mode

Selecting an Encryption Key

1 Press and hold the SEC softkey until a tone sounds.

2 Use the navigation keys to scroll to KEY SEL.

3 Press Sel to enter the Key Selection Menu.

4 Use the navigation keys to select desired key.

5 Press Sel to select key.

6 Press Home or the PTT button to quit.

ALERT TONES (Continued)

Channel is available

for previously

requested

Automatic Call

Back or Talk

Permit

Type of Tone Name Explanation

2 Short High-

Tones (after

requesting a

Feature button

pressed is not valid

in selected mode, or

Invalid Key

Alert

transmission.

System is accepting

your transmission.

Out of trunked radio

Talk Prohibit/

busy channel)

upon pressing

the PTT button)

Low-Pitched

a Call Alert or

emergency alarm

was not

acknowledged.

system range or

system is out of

service.

Out-of-Range

or Time-Out

Timer or Illegal

Tone (upon

pressing the

PTT button

Central controller

has received request

for Call Alert or

Central

Acknowledge

or Valid Key

Present transmission

will soon be disabled.

You have entered a

Mode

during Transmit)

(Operation

Error)

emergency alarm

transmission.

You pressed a valid

mode where normal

system traffic will be

missed, or you

key.

Dispatcher is

acknowledging your

Dispatcher or

Mobile Unit

attempted something

that is not allowed.

(See examples

below.)

emergency

transmission. Mobile

unit has received

Acknowledge

controller failure. The

radio reverts from

Failsoft System central

High-Pitched

Tone every 10

seconds in

your Call Alert.

The above two

acknowledge tones,

heard in tandem.

trunked operation to

unmuted receive

operation similar to a

condition

You have an

Private

conventional

repeater.Others may share

the channel.

incoming call. Press

Call, then the PTT

button, then talk.

Call Alert Page Call Alert page has

Conversation

Examples: Not exiting phone mode after a call (radio

cannot receive fleet or subfleet calls), transmitting in

been received.

receive-only conventional mode, trying to select a dynamic

System Busy All system radio

mode when no dynamic ID assignment has been made.

channels in use.

Release the PTT

button, and wait for

callback.

ALERT TONES

Type of Tone Name Explanation

1 Low-Pitched

Tone

1 High-Pitched

Tone

4 High-Pitched

Tones

5 High-Pitched

Tones

2 High-Pitched

Tones

4 High-Pitched

Tones every 6

seconds

Phone-Type

Busy Tone

(when pressing

the PTT button)

2006

6816817H01

Draft 2 - 8th of Mar 2006

Motorola 99FT4081, 99FT4080 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
