Motorola

iDEN

Digital Multi-Service Data-Capable Phone

®
i30sx Phone User’s Guide
Preliminary
@NNTN4196A@
NNTN4196A

Table of Contents

Introduction .......................................................................................... 5
Driving Safety Tips .........................................................................................6
Getting Started......................................................................................9
i30sx Phone Features.....................................................................................10
Battery...........................................................................................................10
Turning Your i30sx Phone On/Off ...............................................................14
Security Features of the i30sx Phone ............................................................15
Keypad Lock .................................................................................................21
Status of Your i30sx Phone...........................................................................24
My Information .............................................................................................25
Using T9® Text Input ...................................................................................26
Display Essentials ............................................................................... 31
Display Screen Elements...............................................................................31
Call Information Icons...................................................................................34
Navigating Menus and Lists..........................................................................35
Main Menu Options.......................................................................................36
Phonebook...........................................................................................39
Accessing Phonebook with an i2000, i2000plus, or GSM Phone.................40
Phonebook Entries and Speed Dial Numbers................................................40
Phonebook Icons ...........................................................................................40
Voice Names .................................................................................................41
Accessing Your Phonebook ..........................................................................41
About PhonebookEntries..............................................................................42
Pause Digit Entry...........................................................................................49
Plus Dialing...................................................................................................51
Digital Cellular.................................................................................... 53
Making Phone Calls ......................................................................................53
Emergency Calling ........................................................................................58
i
Receiving a Phone Call.................................................................................58
Ending a Phone Call......................................................................................58
Recent Calls...................................................................................................58
Call Timers....................................................................................................62
Call Waiting ..................................................................................................63
Call Hold .......................................................................................................65
Three-Way Calling ........................................................................................66
Call Forwarding.............................................................................................68
Messages.............................................................................................. 73
Message Center .............................................................................................73
Voice Mail.....................................................................................................74
Using Voice Mail ..........................................................................................75
Text and Numeric Messaging........................................................................76
Net Mail.........................................................................................................78
Using Your Phone as a Modem.....................................................................79
Private Calls........................................................................................ 81
Private Call....................................................................................................81
Call Alerts......................................................................................................83
Group Call .....................................................................................................87
Memo ...................................................................................................91
Adding a New Memo ....................................................................................91
Viewing a Memo...........................................................................................91
Editing a Memo.............................................................................................92
Deleting a Memo ...........................................................................................92
Customizing the i30sx phone ............................................................. 93
Settings..........................................................................................................93
Accessories......................................................................................... 111
Carrying Solutions.......................................................................................111
Batteries.......................................................................................................114
Travel Chargers ...........................................................................................115
ii
Data Accessories .........................................................................................117
Other Important Information ......................................................... 123
Understanding Status Messages ..................................................................123
Safety and General Information ..................................................... 125
RF Operational Characteristics ...................................................................125
Accessory Safety Information.....................................................................133
Limited Warranty Motorola Communication Products...............................135
Limited WarrantyMotorola Communication Products (International) ......139
Patent and Trademark Information..............................................................143
iii
DECLARATION OF CONFORMITY
Per FCC CFR 47 part 2 Section 2.1077(a)
Responsible party name: Motorola Inc. Address: 8000 West Sunrise Boulevard,
Phone number: 1 (800) 453-0920
Hereby declares that the product:
Product name: i30sx Model Number: H56XAH6RR5AN
Conforms to the following regulation:
FCC Part15, subpart B Class B Computer peripheral
Date: December 17, 2001
Note: This equipment has beentested and found to complywith the limits for a Class B digital device, pursuantto part 15 of the FCC Rules. These limits are designed toprovide reasonable protection against harmful interference in a residential installation. Thisequipment generates, usesand can radiate radio frequency energy and, if notinstalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will notoccur in a particular installation. If this equipment does cause harmful interference toradio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one ormore of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into anoutlet on a circuit different from that to which thereceiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Plantation, FL 33328 USA
iv

Introduction

ongratulations on purchasing your Motorola iDEN i30sx Phone
C
• Phonebook— Your consolidated Phonebook holds up to 250 entries and
• SIM Card — Yourphone’s SIM card holds all entriesstored in your
• Messages — The Message Centerallows you to manage and access your
• Private and GroupCalls — You can use your phone as a two-way radio
• Fax and Data Transfer — for circuitdata faxes and file transfers..
• Speakerphone — You canenjoy hands-free communication at thetouch of
For morei nformation on theseand other featuresof the i30sx phone,review this User’s Guide. There is a Table of Contents in the front of the guide and an Index in the back of the guide to assist you in finding the specific information you want.
multi-service, data-capable, digital,portable phone. Your i30sx
phone
offers:
allows you to store multiple contact numbers foreach person, offeringyou various ways to communicate with your business and personal contacts.
Phonebook. In addition, you have a PIN (PersonalIdentification Number) to keep your information safe and secure.
Voice Mail, Text Messagesand NetMailallfromthe same inbox.
to communicate directly withbusiness and personalcontacts in your iDEN service area.
a button. And Speakerphone is especially great for conference calls.
NOTE:Some features of your i30sxphone are available only in the
iDEN service area, and are indicated as such in this guide.
NOTE:This guide describes the features of the i30sx phone as they
were set up by Motorola. However, your carrier or your organization may have changed or added features. For more information, check with your carrier or your organization.
5

Driving Safety Tips

“Safety is your most important call!” Your Motorola wireless telephone gives you the powerfulability to
communicate by voice — almostanywhere, anytime, wherever wireless phone serviceis available and safe conditions allow. But an important responsibility accompanies that benefits of wireless phones, one that every user must uphold.
Whendriving a car,driving is yourfirst responsibility.Ifyou find itnecessary to use yourwireless phone whilebehind the wheel of a car,practice goodcommon sense and remember the following tips:
1. Get to know your Motorola wireless phone and its features such as speed dial and redial.Ifavailable, these features help you to place your call with­out taking your attention off the road.
2. When available, use a hands-free device. If possible,add an additional layer of convenience to your wireless phone with one of the many Motor­ola Original hands-free accessories available today.
3. Positionyourwireless phone within easy reach. Be able to access your wireless phone without removing your eyes from the road. If you receive an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.
4. Let the person you are speaking w ith know you are driving; if necessary, suspend the callin heavy traffic or hazardous weather conditions. Rain, sleet,snow, ice, and even heavy traffic can be hazardous.
5. If youreceive an incomingcall at an inconvenient time do nottakenotes or look up phone numbers whiledriving. Jotting down a “to do” list or going through your address book takes attention away from your primary respon­sibility — driving safely.
6. Dialsensibly andassess thetraffic; ifpossible,place callswhen you arenot moving or before pulling into traffic. Try to plan calls when your car will be stationary. If you need to make a call while moving,dialonly a few numbers,check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that may be distract­ing. Make people you are talkingwith aware you are driving and suspend conversations which have the potential to divert your attention away from the road.
8. Use your wirelessphone to call for help. Dial9-1-1orother local emer­gency numberin the case of fire, traffic accident or medicalemergencies.
1
6
Driving Safety Tips
9. Use your wirelessphone to help others in emergencies. If you see an auto accident, crime in progress or other seriousemergency where lives are in danger,call 9-1-1 or other local emergency number, as you would want
others to do for you.
*
10. Call roadside assistance or a special non-emergency wirelessassistance number when necessary. If you see a broken-down vehicle posing no seri­oushazard,abrokentrafficsignal,aminortrafficaccidentwherenoone appearsinjured, oravehicle you knowtobe stolen, callroadside assistance
or other specialnon-emergency wireless number.
1
1. Wherever wireless phone service is available.
7
8

Getting Started

This section includes:
i30sx Phone Features Page 10 Battery Page 10 Turning Your i30sx Phone On/Off Page 14 Turning Your i30sx Phone On/Off Page 14 SecurityFeatures of the i30sx Phone Page 15 Statusof Your i30sx Phone Page 24 My Information Page 25 Using T9® Text Input Page 26
9
i30sx Phone Features
Lanyard Hook
Antenna
Earpiece
Display
Option Key
Menu K ey
Send Key
AlphaNumeric Keypad
Power On/Off Microphone
BOTTOM VIEW
SIDE VIEW
TOP VIEW
VolumeControl Buttons
Push-To-Talk Button (PTT)

Battery

Headset Jack
4-WayNavigation Key
Photosensor
End/Home Key
Punctuation Key
Back Key/PauseDialing
SpeakerKey
Next Word Key/International Plus Dialing
StatusLight
OptionKey
FRONT VIEW
Accessory Connector
Battery
Your i30sx phone comeswith a Lithium Ion battery. After attachingthe battery, you must charge it beforeyouuse it for the first time. See “Charging Lithium Ion Batteries” on page 114 for the charging times for your phone’s battery. The firsttimeyou chargeyour phone’s battery, charge for 30 minutes more than the time shownon page 114. Aftertheinitial charging, the batterycan be chargedin thetimeshownonpage114.
Instructions for Attaching and Detachingthebattery may be found on page 15.
10
Attaching the Battery
1
Holding the phone face down,insert the battery into the phone in a forward and downward motion. A securing click will be heard.
Detaching the Battery
1
Ensure the phone is powered off before attemptingtodetach the battery.
2
Press the battery release button and slide the battery away from the antenna.
3
Remove the battery by pushingthe battery toward the antenna and liftingit out of the phone.
Battery
11
Charging the Battery
1
With your phone’s keypadfacing up, plug the charger’s accessory connector into the left side of the accessory connectoron the bottom of the phone.
In Process
2
Plug the charger into an electrical outlet.
NOTE:Your phone’s screen backlight will remain lit while the battery is
charging.
12
Battery
Battery Charging Status
The batterystrength indicatoriconfound on your phone’s display screenshows the charge amount remaining in the battery.Refer to Battery Charging, Table 1.
Table 1: Battery Charging
When Using Phone
Icon Display
Battery Strength
NOTE:A short, chirp-like sound indicates a low battery. This indicates
abcd
Low Battery
that you have approximately fiveminutes of talktime remaining.
11% - 40% 41% - 70% Fully Charged
(90% -100%)
When Charging Battery
Icon Display
Battery Strength
NOTE:During the charging process, the battery icon will be flashing. In
efgh
1flashingbar 1flashingbar,
Low Battery
addition, when the battery is fully charged, the battery icon will show a fully charged battery.
1 continuous bar
31% - 60% 61% - 90% FullyCharged
1 flashing bar, 2 continuous bars
3 continuous bars
(90% -100%)
13
Turning Your i30sx Phon e On/Off
A
To power the phone on:
1
For optimal signalstrength, extend the antenna.
2
Press and hold p near the bottom of the phone until the status light glows red and a tone briefly sounds.
3
If the Enter SIM PIN Code screen displays,enter your SIM PIN.(For more information see “SIM Card Personal Identification Number (PIN)” on page 15.)
NOTE:The default SIM card PIN is 0000. It is recommended that you
change your PIN to prevent fraudulent use of the SIM card (see “Changing the PIN” on page 16).
4
Press B under OK.
As your phone connects to the network, youwillseeawelcomemessageanda connecting message. When the Ready screen appears on the display, you are readytouseyouri30sx phone!
To power the phone off:
1
Press and hold p near the bottomof t he phone until you seethemessage Powering Off.
2
Push down the antenna.
14
Security Features of the i30sx Phone
Security Features of the i30sx Phone
SIM Card
Your phonecomes with a built-in level of security protectionthrough the use of the SIM (Subscriber Identity Module) card. The SIM card stores all your Phonebookinformation. Sincethis information isstored on the SIM card, not in your phone itself,you can remove the information by removing the SIM card.
The SIM card is located in the SIM Card Holder on the back of the phone, underneath the battery. You can verify that the SIMcard is in placeby removing the batteryand viewing the SIM card through the SIM card cover.
See “Removing/Inserting the SIM Card” on page 20 for information on locating the SIM card. If there is no SIM card in your phone, notify your sales representative.
NOTE:Except formaking emergency calls, your phonewill not
function without the SIMcard.
SIM Card Personal Identification Number (PIN)
To prevent unauthorized use of your phone, your SIM card is protected by a PIN. Each time the phone is powered on, you must enter your PIN. You can change or disableyour PIN if desired.
NOTE:Disabling your PIN enables anyone to use your phone. If you
disable your PIN, you must still keep the SIM card in the phone to make calls.
Entering the PIN
Depending on yourservice provider, your phone may or may not require you to enter a SIM PIN whenyou firstuseyourphone.
If your phone is set to requireyoutoenter a PIN, your default SIM card PIN is: 0000. It is recommended that you change your PIN to preventfraudulent use of the SIM card (see “Changing the PIN” on page 16).
P
15
Incorrectly enteringyour PINthree times causes the SIM card to be blocked. To unblock your SIM card, you must c ontact
!
C a u t i o n
1
From the Enter SIM PIN screen,enteryour four- to eight-digit PIN. An asterisk appears for each character entered.
NOTE:Other than emergency dialing, you will be unable to use any
of the phone functions, including receiving phone calls, until you enter the PIN.
2
Press B under OK.
If you enter an incorrect PIN, the message SIM PIN incorrect:Tryagain appearson your phone’sscreen. After three consecutive incorrect attempts,t he SIM cardisblocked. The phonedoesnotallow you to attempttoenter your PIN again, even afterpowering the phone off and back on. If this happens, see “Unblocking the PIN” on page 17.
Changing the PIN
1
At the Ready screen, press m and then press R to scroll to Settings.
your service pr ovider. For more information,see “Unblocking the PIN” on page 17.
2
Press B under SELECT. The Settingsscreen displays.
16
B
Security Features of the i30sx Phone
3
Press R to scroll to Security.PressB under SELECT to access the Security screen.
C
4
At the Security screen, press R to scroll to New Passwords.PressB under SELECT to access the New Passwordsscreen.
5
At the NewPasswords screen,press R to scroll to SIM PIN and press B under SELECT.
6
At the Enter Old SIM PIN Code screen, enter the current SIM PIN and press B under OK.
NOTE:The default SIM is 0000.
7
At the Enter New SIM PIN Code screen, enterthe new 4- to 8-digit SIM PIN and press B under OK.
8
At the Re-enterNe w SIM PIN Code screen, re-enter the new SIM PIN to confirm, and press B under OK.
Unblocking the PIN
If you forget your PIN and unsuccessfully enter it three times,access to your phone will be blocked.
NOTE:Before you begin, obtain the PIN Unblocking Key (PUK) code
from your service provider, then read and understand the PIN unblocking sequence. When entering the key press sequence, each key press must occur within 5 seconds of the prior key press.
17
If you unsuccessfully enter the PUK code ten times, the SIM card is permanently blocked and must be replaced. If this
!
C a u t i o n
To unblock the PIN:
1
Press **05e.
2
Enter the PUK code.
3
Press e.
4
Enter a new 4- to 8-digit SIM PIN and press e.
5
Re-enter your SIM PIN and presse. If you entered the codes properly, theSIM Unlockedscreen displays.
Disabling/Enabling the PIN Requirement
When the PIN requirement is enabled, you are prompted to enteryourPIN each time you turn on your phone. Until a valid PIN is entered,you can use thephone only to make emergencycalls.
After the PIN is accepted, the phone registers on the network and the Ready screen displays.
WhenthePIN requirementis disabled,the phone can be used without entering a PIN.
happens, all data will be lost. You will get a message to contact your service provider. If the SIM card is blocked, the i30sx phone only allows outgoing Emergency calls.
P
18
Security Features of the i30sx Phone
If you disable the PIN requirement, you remove protection of personal data on your SIM card. Anyonecan then use your phone
!
C a u t i o n
1
At the Ready screen, press mand then press R to scroll to Settings.
2
Press B under SELECT. The Settingsscreen displays.
3
Press R to scroll to Security.PressB under SELECT to access the Security screen.
and access your personal data.
B C
4
At the Security screen, pressR to scroll to SIM PIN.PressB under SELECT to access the SIM PIN screen.
5
Press R to scroll to On or Off. On enables the SIM PIN requirement; Off disables the SIM PIN requirement.PressB under SELECT.
6
At the Verify SIM PIN Code screen,enter the current SIM PIN and press B under OK.
19
Removing/Inserting the SIM Card
Do not touch thegold-colored areas of the SIM card.
!
C a u t i o n
1
With phonepoweredoff, remove the battery cover. See “Detachingthe Battery” on page 11.
2
With the back of the phone exposedandf acing up, locate the SIM cover and gently push it to the right. Lift the coverup.
3
To insert the SIM card, very carefully placeit in its holder with the gold contactsidefacing down.
To close theSIMcard cover,push it down andslide forward.
To avoid loss or damage, do not remove your SIM card from your phone unless absolutely necessary.
20

Keypad Lock

4
To remove the SIM card, slide the SIM card cover back andlift up (as in step 2). Very carefully lift the SIM out of its holder. Do not t ouch the
gold-colored areas of the SIM card.
NOTE: Protect the SIM card as you would any delicate object. When
the SIM card is not in the phone, you should store it in something protective, such as a mailing envelope.
Keypad Lock
The i30sx phone includesa Keypad Lock feature that enables you to quickly lock the phone’s keypad to avoid inadvertently pressing keys or placing calls. Once Keypad Lock is activated, you can only perform the following tasks:
• turn your phone on and off
• unlockthekeypad
• receive incoming calls, messages, and alerts.
NOTE:Emergency calls cannot be placed while Keypad Lock is
activated.
Beforelocking your phone’s keypad, you may want to readthisentire sectionto learnhowtorespondtoincomingcalls,messages,andalerts.
Activating Keypad Lock
From the Ready screen,press m*.The message KeypadLocked displayson your phone.
D
Wheneverakeyis pressed while in Keypad Lock mode,the unlock instructions display briefly.
21
Receiving Incoming Calls
When you receive an incoming phone call (see “Receiving a Phone Call” on page 58), KeypadLock is temporarily disabled.
1
Press B under YES or press e to answer the call. When you end the call, the Recent Calls list appears. Press
reactivate Keypad Lock and return to theReady screen. Or,
A underNOorpresss t o send the call to Voice Mail and
Press reactivate Keypad Lock.
s or press A under EXIT to
Receiving Private Calls
When you receive an incoming Private call, Talkgroup call, or call alert (see “Private Call” on page 81), Keypad Lock is temporarily disabled.
1
Press and holdthe Push-To-Talk(PTT) button on the side of the phone. Begin talking after the phone emitsa chirping sound. Release the PTT buttonto listen.
2
When you end the call, the Recent Calls list appears.Press e or press A under EXIT to reactivate Keypad Lock and return to the Ready
screen.
Receiving New Voice Mail
When you receive new Voice Mail (see “VoiceMail” on page 74), Keypad Lock is temporarily disabled.
1
WhenNew VoiceMail Message displays, press A under EXIT to returnto theReady screenandreactivate Keypad Lock.
Or, Press B under CALL to access Voice Mail.
2
Once you have finished, press s to exitVoice Mail. The Recent Calls list displays. Press s to reactivate Keypad Lock and return to the Ready screen.
22
Keypad Lock
Receiving New Text Messages
When you receive new Text Messages (see “Text and Numeric Messaging” on page 76), KeypadLock is temporarily disabled.
1
WhenNew Text Message displays, press A under EXIT to return to the Ready screen and reactivate Keypad Lock.
Or, Press B under READ to read the message. Press B under SAVE or
DELETE. Once you have finished, press s or press A under EXIT to reactivateKeypadLockreturntotheReady screen.
Receiving New Net Mail
When you receive new Net Mail, Keypad Lock is temporarily disabled.
1
When New Browser Message displays,press A under EXIT to return to the Ready screen and reactivate Keypad Lock.
Or, Press B under GOTO. Pr ess A under View. Press A under OK or
Reply. Once you have finished, press s until you reactivate Keypad Lock return to the Rea dy screen.
23
Deactivating Keypad Lock
From the Ready screen, press m*. The message Keypad Unlocked displaysbriefly.
E
Status of Your i30sx Phone
Your i30sx phone has a status light that displaysatthe top of the phone. The statuslighti ndicates the status of your connection.
Status Light Indicator
Solid Red Signing on to the network. Please wait.
Flashing Red No service or out of coverage area.
Flashing Green
Solid Green In use
24
i30sx Phone Status
Inservice/Readytouse.
.

My Information

My Information
You can select My Info from the main menu to display or edit the following:
• Name — enter your name in this field.
• PrivateID — your Private ID is displayed in this field.YourPrivate ID is
the number that others use to contactyou using Private calls.
• Phone Numbers of Lines 1 and 2 — your phone’snumbers are displayed in these fields. You can edit the phone numbers displayed on the My Information screen, but this does not changeyourphonenumbers.
• IP Addresses — these fieldsdisplay the IP addresses you use to access the Internetwith your phone.
• CircuitDataNumber (Ckt) — your circuit data number is in this field.
Viewing/Editing My Information
1
From the Ready screen, pressm.
2
Press S to scroll to My Info.PressB under SELECT. The My Information screen displays.
3
Use S to scroll through the fields.
4
Toedit the displayedinformation, press B under CHANGE. Edit information as desired, and press B under OK to save the changes.
To return to the Ready screen, press A under EXIT.
25

Using T 9®Text Input

Your i30sx phone has embedded software, called T9®Text Input, thatmakes typing on a phone keypad much like typingon a computer keyboard: it eliminates the traditional “multi-tap” method of text entry. As you type, you pressonly one key perletter. T9 Text Inputmatches your keystrokes to wordsin its linguistic database of approximately 60,000 words and proper names. You may also store additional words you frequently use in your own user database, which is incorporated into the T9 database.
T9 Text Input is available when you are typing information into your Phonebook and Datebook.
T9 TextInputEntry Modes
Four text entry modes are availablein T9 Text Input: Alpha, Word, Symbols, and Numeric. When you are using T9 Text Input, an icon in the top right corner of your phone’s display screen (next to the battery strengthindicator icon) indicates the T9 Text Input entry mode you are using:
Icon T9 Entry Mode
Name
w Alpha Standard “multi-tap” keypad
# Word Entering words and
! Symbols Entering punctuation and
, Numeric Entering keypad numbers.
When you are using Phonebook or Datebook, you select your text entry mode from a menu availablewhenever the phone is displaying a screen that requires you to enter text (for example, the Name: screen or Title: screen).
Used For...
text entry.
punctuation with one key­press per character.
symbols such as “@” or “?”.
26
Using T9® Text Input
To choose a text entry mode:
1
From any screen thatrequires text input, press m to access the Entry Method menu.
A check mark appears next to the currenttextentry mode. When you access a screen that requires text input,the default text entry mode is Alpha.
2
Press S to scroll to the T9 Text Input text entry modeyou want to use.
3
Press B under SELECT.
The phone returns to the text entry screen. The text entry mode you selectedisnow active.
Choosing a Language
To change the language of the T9 Text Input database:
1
From any screen thatr equires text input, pressm to access the Entry Method menu.
2
Press S to scroll to Languages.
3
Press B under SELECT.
4
Press S to scroll to the language you want T9 Text Input to use.
5
Press B under SELECT.
Using Alpha Mode
To enter text while in Alpha text entry mode to enter letters, numbers, and symbols:
• Press any button on the alphanumeric keypad to enter the letters, numbers, and symbols on that key.
• Press and hold a key to capitalize a letter, or press # to activateand deactivate Caps Lock.
27
• Pause briefly to leave the currently displayed character in place and move on to the next place in the text entry field.
• Press P to create a space in the text entry field.
• Press A under DELETE to deleteone character. Pressand holdA under
DELETE to delete an entire entry.
Using Word Mode
In Word mode, T9 Text Input analyzestheletters on the keypad button you press and arranges them to create words. As you type, T9 Text Input matches your keystrokes to words in its database and will displaythe mostcommonly used matching word.
Special Key Functions
Some of your phone’s keys assume different functions while in T9 Text Input Word mode .
Backspace and Erase
Press A under DELETE once to backspace or to erase a single character.Press and hold A under DELETEto erase the entire textentry field.
Space
Press R once to accept a word and insert a space when entering text.
Next Word in Database
Press 0 to display more words in the database that matchthe keystroke sequence you entered.
Shift and Caps Lock
Press # to make the next letter typed uppercase (Shift), to make allsubsequent letters types uppercase (Caps Lock), or to go back to lowercase letters.
These icons appear in the top row of your display screen:
• $ for Shift to uppercase
• x for Caps Lock
When neither of these icons appear, letterstyped are lowercase.
NOTE:T9 Text Input automatically makes the first letter of a sentence
uppercase.
28
Using T9® Text Input
Punctuation
In Word mode, T9 Text Input uses Smart Punctuation to quickly apply basic rules of grammar to insert the correct punctuation within a word and at the end of a sentence.
Press 1 to insert punctuation. One of eight basic punctuationsymbols will be inserted(.,-’ @:?;).
Press 0 to changetheinserted punctuation symbol to anotherof the eight basic punctuation symbols.
Press R to accept the punctuationand continue typing.
NOTE:Additional punctuation symbols are available in Symbols mode.
EnteringaWord
To enter a word using Word mode:
1
Choose Word as your text entry mode.
2
Type a word by using one key-press per desired letter.
For example, to type “test” press 8378.
NOTE: The displayed word may change as you type it. Do not try to
correct the word as you go. Type to the end of the word before editing.
3
If the word that appearsisnotthedesired word, press 0 to change the word on the display to the next most likely word in the database.
Repeat until the desired word appears. If the desired worddoesnotappear, you can add it to the database of
words usingtheinstructions in “Adding Words to the User Database” on page 30.
29
Adding Words to the User Database
To add words to the T9 database:
1
Change from Word text entry mode to Alpha text entry mode.
2
Type the word using Alpha text entry mode.
3
Return to Word text entry mode.
4
Press R to add a space.
The word you typed in Alpha text entry mode is now in the database.
NOTE: You cannot store alphanumeric combinations, such as Y2K.
Using Numeric Mode
To use Numeric text entry mode, chooseNumeric as your text entry mode and press the number buttonsonyourkeypad to enter numbers.
Using Symbols Mode
To use Symbols text entry mode:
1
Choose Symbols as your text entry mode.
A row of 32 symbols appears along the bottom of your phone’sdisplay screen,justabove the display option and menu icon. (Press T to view the completerow.)
2
Press T to highlight the symbol you want to enter into the text entry field.
3
Press B under SELECT to enter the symbol.
30

Display Essentials

Your i30sx phone’s display screen tells you what you need to know as you use your phone.
This section includes:
DisplayScreen Elements Page 31 NavigatingMenus and Lists Page 35 Main Menu Options Page 36

Display Screen Elements

Any time your phone is powered on, the displayscreen provides you with information and options.
The Ready Screen
The Ready screen displays any time the phone is poweredon, but not engagedin some activity.
The Ready screenconsist of elements commontomanyofthescreensyour phone displays:
• statusicons
• text displayarea
• menu icon
• displayoptions
USER TIP:You can always access the Readyscreen by pressinge.
\
Status
Status
Status icon
icon
icon rows
rows
rows Text
Text
Text display
display
display area
area
area
Menu
Menu
Menu icon
icon
icon Display
Display
Display options
options
options
Status Icons
Statusicons provide you with information aboutyour phone and its functions. These icons are context sensitive;meaning, the icons that appear depend on the task you are performing.
31
Statusicons appear inthetwo rows at thetopof the displayscreen. Some appear at all times.Others appear onlywhen your phone is engaged incertain activities or when you have activated certain features.
Icon Indicates...
abcd
efgd
opqr s
01
GHI JKL
c Phone In Use — phone is connected on an
h PrivateIn Use — number beingcalled is a
% Talkgroup In Use — phone is active on a
Y Packet Data Ready — phone is ready to
Z Packet Data Activity — phone is
BatteryStrengthicons — remaining battery charge. More bars on the battery indicate a greater charge. See the table on page 13 for detailed information about the meaning of each battery strength icon.
Signal Strength icons — strength of the network signal.Morebarsnexttothe antenna indicate a stronger signal.
Active Line icons — currently active phone line;0 indicatesLine 1 isactive; 1 indicates Line 2 is active.
Call Forward icons — phone is set to forward calls. See “Call Forwarding” on page 68 for more information.
active call.
Private ID.
talkgroup call.
receive data through a data cable.
transmitting data.
32
] Mobile IP — phone is ready to access the
Internet.
Display Screen Elements
{ Secure Data — phone is accessing the
} Non-secureData — phone is accessing
l Roaming — phone is searching for
. Text Message — you have one or more
y Voice Mail — you have one or more Voice
B
u
-[\* Ring/Vibe icons — you have customized
w#,! $x
Internetusinga secure connection.
the Internetusinga non-secure connection.
network connections outside your local area.
Text Messages or Net Mail messages.
Mailmessages. FaxMail—you have oneormore FaxMail
messages. Speaker Off — phone’s speaker is off.
the way in which the phone is set to notify you when you receivecalls and other types of messages. See “RingStyle and Notification Type” on page 95 for more information.
T9 Text Input icons — youareusingT9 Text Input to enter text.See“Using T9® Text Input” on page 26 for more information.
The icon of the main menu feature currently in use always appears in the top left of the status icon rows. For a list of the main menu icons, see “Main Menu Options” on page 36.
Text Display A rea
The text displayareashows menu options, messages, names,phone numbers, and other information.
33

Call In formation Icons

Each of the following icons appear on the leftside of the text display areaofthe one-linescreen or the full-sized screen,providing you with information about your phones line or lines.
Icon Indicates...
D In Call - phone is in an active call. E Incoming Call - phone is receiving an
X Outgoing Call - phone is placing an
z On Hold - phone has a call on hold.
? End Call - phone has ended the active call.
incoming all (not active).
outgoing (not active).
Menu Icon
This menu icon m appears on any screen from which a menu can be accessed. To access a menu, press the menu key on your keypad. This key has the menu icon printed on it.
Menus are contextsensitive. The menu that appears depends on the screen you access it from and the items on the menu apply to the task you are currently performing.
Pressing
m or Q from the Ready screen accesses the main menu.
Display Options
Two displayoptions appear at the bottom of most screens.Theseoptions enable you to perform a wide variety of actions, including changing, saving and viewing information, running programs, and canceling previousactions. You
activate a display option by pressing the
NOTE:Throughout the User’s Guide,the option keys C and D will
be represented by
A.
A below it.
34

Navigating Menus and Lists

The Ready screen display options provide quick access to two main menu features. By default, the Phonebook (PHBK)andMessages(MESG)display optionsappear on the Ready screen. You can control which displayoptions appearon the Ready screenusing thephone’s Personalize feature in the Settings menu (see “Changing Ready Screen Options” on page 100).
The display optionsonscreens other than the Ready screen cannot be customized.
Navigating Menus and Lists
The i30sx phone is menu driven. By navigating menus, you access submenus which lead to all of thefunctions and featuresthat are builtintoyour phone. Use the menus to store calls,manage your Phonebook and Datebook, changeyour phone settings, browse the Internet, and more.
Some features include lists of names, numbers, or other information. These list items can be accessedthesame way menu options are.
To access the items in a menu or list,scroll throughusing the four-way navigation key near the center of your keypad. Scroll down by pressing the lower portion of the navigation key R. Scroll up by pressing the upper portion of the navigation key Q. Holding down the appropriate part of the navigation key speeds up scrolling. If you continue scrolling afteryouhavereached the bottom or top of a menu or list, you “wrap-around” to the opposite end.
If more items appear in a menu or list than can be displayed in the text area, a down arrow or up arrow appears in the left side of the screen indicating that more options may be accessedbyscrolling up or down.
Down arrow Up arrow
B
S
35

Main Menu Options

By default, the main menu options appear in the order determined by your service provider. You can change the order in whichthey appear by using the Personalize feature (see “Reordering Main Menu” on page 99)
To access the main menu, press
Menu Item Use to ...
7 Browser Browse the Web.
m or Q from the Ready screen:
m Settings Customize your phone: Ring/Vibe, In Call
b Phonebook Storeand retrieve a list of storedentries for
R Messages Receive, store, access and manage Voice
; Call Forward Settingsforforwarding calls in various
O Memo Input and store numbers to access later. z Call Timers Displaytheduration of phonecalls, private
j Recent Calls Accessa list ofthelast 20 sent, received,or
U My Info Viewthe name, PrivateID, phone numbers
: CallAlert Storereceived call alerts to respond to at
Setup,Security,Initial Setup, PhoneSetup, Voice Volume, and Talkgroup Settings.
calling,editing, viewing, and deleting.
Mail, FaxMail, Text Messages, and Net Mail.
situations.
or group calls,circuit data use, and Kilobytessentand received.
missedcalls. Calls can be made from this list.
for lines 1 and 2, IP address, and circuit data number of your phone.
your convenience.
36
Main Menu Options
To choose the highlighted Main Menu selection, press B under SELECT. To exittheMainMenu and return to the Ready screen, press A under EXIT or
s.
press
37
38

Phonebook

The Phonebook allows you to store up to 250 frequently used names and numbers.
When youstore informationinyour Phonebook, it issavedon your SIM card.If you move your SIM card to another i30sx phone,i85s phone ori50sx phone, you can access information in your Phonebook from that phone.
NOTE:If you use a different SIM card in your phone, some information
stored in the phone will be lost. See “Removing/Inserting the SIM Card” on page 20.
This section includes:
AccessingPhonebook with an i2000, i2000plus, or GSM Phone
Phonebook Entries and Speed DialNumbers Page 40 Phonebook Icons Page 40 Voice Na mes Page 41 AccessingYour Phonebook Page 41 About Phonebook Entries Page 42 Viewing Phonebook Entries Page 42 Sorting Phonebook Entries Page 43 Adding Phonebook Entries Page 44 Editing Phonebook Entries Page 49 Deleting Phonebook Entries Page 49 Pause Digit Entry Page 49 Plus Dialing Page 51
Page 40
39

Accessing Phonebook with an i2000, i2000plus, or GSM Phone

If you plan to use the information stored in your Phonebookwithan i2000, i2000plus, or any other GSM phone, you must purchaseCompanionPro. Go to
www.motorola.com\iden or your service provider’swebsiteformore information.
You can use CompanionProto make the Phonebook information saved to your i30sx phone’s SIM card accessible in this type of phone.

Phonebook Entries and Speed Dial Numbers

Your Phonebookcanstore multiple phone numbers to a single name. For example,you canentersomeone’s name into your Phonebook once and then add that person’s home, office, mobilephoneand fax numbers to the name.
Each number storedinyourPhonebook is automatically assigned a Speed Dial number thatcorresponds to its location in your Phonebook. Each phonenumber uses one Speed Dial location, even if it is assigned to the same name as other phone numbers.The phone number stored in location 1 is assigned Speed Dial number 1, thephone number stored inlocation 2 is assignedSpeedDialnumber 2, and so forth, to location250.

Phonebook Icons

Icons that appear to the right of entries in your Phonebookconvey information about those entries.
When you enter a phone number in your Phonebook, you can designatethe phone number’stypeusinganyof the following icons:
40
W Mobile h Private
+ Work
Q Main L Home b Pager
K Fax n Talkgroup

Voice Names

|
Z Other
NOTE:The Mobile icon automatically appears to the right of the first
number assigned to a name unless you choose another icon.
For more informationonentering numbers into your Phonebook, see “Adding Phonebook Entries” on page 44.
The “picker” arrows appearing around the number type icon indicates multiple phone numbersstored under one name:
ef pickers
The Voice Name icon appearingtothe left of one of the phone number type icons indicates that a voice name is associated with the Phonebookentry:
p Voi ce Na me
IP (Internet Protocol Address)
Voice Names
A voicename is an audiorecordingyoum ake by speakinginto your i30sxphone that you assign to a number in your Phonebook. You can then dialthe number by speaking the words you recorded into the phone. See step 6 of “Adding Phonebook Entries” on page 44 for more informationon creating a voice name.

Accessing Your Phonebook

If PHBK is one of your display options:
From the Readyscreen, press A under PHBK.
41
If PHBK is not one of your display options:
1
From the Ready screen, press m.
2
Press R to scroll to Phonebook.
3
Press B under SELECT.
USER TIP:You can also access the Phonebook by pressing m while
This brings you to the Phonebook screen. From thisscreen, you can view, sort, add, edit, and delete Phonebook entries, check Phonebook capacity, or make calls.
your phone is on a phone call or private call.

About Phonebook Entries

Each Phonebook entry may contain the following information:
• The name associated with the entry.Typically, this is the name of the person whosenumber you are storing in the Phonebook.
• The type of number to be stored: Mobile, Private, Work, Main, Home, Pager, Fax, Other, or Talkgroup. If you don’t choose a type, the number is assignedtypeMobile, unless a Mobile number has already been assigned to the name.
• The number to be stored. Every Phonebook entry must contain a phone number. This number may be any type of phone number, Private ID, or Talkgroup number.
• A Speed Dial number. Youmay accept the default Speed Dial number or assign a different one.
• A voice name audio recording for voice-activateddialing.
Viewing Phonebook Entries
Names with more than one numberassigned to them appear with ef surrounding the icon to the right of the name. For example, if you had stored a home and work number for Joe Smith, the entry for Joe Smith’s home phone number would looklike this:
Joe Smith eLf
Whenthenameishighlighted,pressT to scroll to the icons representingeach of the numbers assigned to thatname.
42
About Phonebook Entries
To view any of the phone numbers assigned to a name:
1
From the Phonebook screen, press S to scroll to the name associated with the phone numberyou want to see.
2
Press T to view the icons representingthephonenumbers assigned to that name.
3
When the icon representing the number you want to view is displayed, press B under VIEW.
If there is a Private ID or a Talkgroup number stored for the person, press m.ThenpressR to scroll to View and press B under SELECT.
4
Press S to view the other numbers stored for thisname.
Sorting Phonebook Entries
You can sort your Phonebook entries by:
• Name — thenameyouenteredfortheentry.
• Speed No. — the Speed Dial location of the entry.
• Voice Name — all entries with voice names appear at the top of the list.
NOTE:Private and group calls cannot be made from the Phonebook
when sorted by Speed Dial location.
To sort your Phonebook list:
1
From the Main Screenscreen, press m and scroll down R to view the PhonebookMenu screen.
2
Press R to scroll to Sort By.
}
43
3
Press B under SELECT.
4
Press R to scroll to the desired sorting method: Name, Speed No.,or Voice Name.
5
Press B under SELECT.
Checking Phonebook Capacity
Your Phonebookcanstore up t o 250 separate numbers. To see how many entriesare stored in your Phonebook:
1
From the Phonebook screen, press m to view the Phonebook Menu screen.
2
Press R to scroll to Capacity.
3
Press B under SELECT. The Capacity screen shows how many storagespaces in you
Phonebook are in use and how many are empty.
Adding Phonebook Entries
Using the following instructions, you will enter the information in the order the items appearon the Phonebook Entry Details screen. However, youcan enter this information in any order by pressing S to scroll through the items on the Entry Details screen.
YoucanleaveanyitemblankorunchangedbypressingS to scroll past it on the Entry Detailsscreen. Only a number is required for a valid Phonebook entry.
After you have entered a phone number and any other information you wish to include, you can press A under DONE to save the Phonebook entry.
44
About Phonebook Entries
To cancel a Phonebook entry at any time, press s to return to the Ready screen.Toadd a Phonebook entry:
1
Access the Entry Detailsscreen: From the Main Screen screen, press m.
Then press R to scroll to Phonebook. Press B under SELECT
To add a [New Entry],pressB under SELECT.
2
If you want to assign a name to your Phonebook entry:
With the Name: field highlighted, press B under CHANGE.
From the Name:screen, enter the name using the alphanumeric keypad.
See “Using T9® Text Input” on page 26 for information about entering text into this field.
When you are finished, press B under OK.
H I
The Entry Details screen returns with the Type: field highlighted.
3
If you want to assign a number type other than Mobile to your Phonebook entry:
With the Type: field highlighted, press B under CHANGE.
From the Type Editor screen, press R to scroll to the type of number you want to assign to the Phonebookentry.
Press B under SELECT. The Entry Details screen returns with the No.:field highlighted.
J
45
4
Assign a number to your Phonebook entry:
With the No.: field highlighted, press B under CHANGE.
Type the number using the alphanumeric keypad. For phone numbers, use the 10-digit format.
To delete a digit, press A under DELETE.
See “Pause Digit Entry” on page 49 and “Plus Dialing” on page 51 for information on using these featureswhen storing phone numbers in your Phonebook.
NOTE:The number can be up to 20 characters long.
When you are finished, press B under OK. The Entry Details screen returns with the Speed No. field highlighted.
5
The default Speed Dialnumber assigned to the Phonebook entry is displayed in the Speed No.: field. This is always the next available Speed Dial location.
If you want to assign the phone number to a differentSpeed Dial location:
With the Speed No.: field highlighted, press B under CHANGE.
K
L
Press A under DELETE to delete the current Speed Dial number.
Type the new Speed Dial number using the alphanumeric keypad. When you are finished, press B under OK.
46
About Phonebook Entries
U
6
If you want to assign a voice name to the number:
With the Voice Name: field highlighted, press B under RECORD.
Asdirected bythe screenprompts,say and repeat the name you want to assignto the number. Speak clearly into the microphone.
An ) icon appears in the Voice Name: field indicating that the voice name has been recorded.
USER TIP:For best results, record in a quiet environment.
7
If you want to store more numbers to the name associated with this Phonebook entry:
Press R to scroll to MORE at the bottom of the Entry Details screenand then press B under SELECT.
AnewType: field appears for the additional number.
Enterthe information fortheadditional number using step 3 through step 7.
M
NOTE:Each name in your Phonebook may have up to seven phone
numbers one Private ID associated with it.
8
Whenyouhave enteredallthe information you wanted in this Phonebook entry, press A under DONE.
N
47
Storing Numbers Fast
Your phone gives you two ways to store numbers quickly: from the Ready screen and fromtheRecent Calls list.
To store a number from the Ready screen:
1
From the Ready screen, use the alphanumeric keypad to enter the number you want to store.
2
Press m to access the Dialing Menu screen.
3
With Store Numberhighlighted, press B under SELECT. This displays the Entry Details screen with theNo:fieldfilledinwith
the number you typed.
4
If you want to addmore information to the Phonebookentry, followthe applicable instructions in “Adding Phonebook Entries” on page 44.
5
Press A under DONE.
To store a number from the Recent Calls list:
1
From the Recent Calls screen, press R to scrolltothenumber you want to store.
2
Press B under STORE.
Or, press Store.Press
This displays the Entry Details screen with theNo:fieldfilledinwith thenumberoftherecentcall.
3
If you want to addmore information to the Phonebookentry, followthe applicable instructions in “Adding Phonebook Entries” on page 44.
4
Press A under DONE.
m to access the Rec. Calls Menu.PressS to scroll to
B under SELECT.
48

Pause Digit Entry

Editing Phonebook Entries
1
From the Phonebook screen, press R to scroll to the entry you want to edit.
2
Press m to view the Phonebook Menu.
3
Press R to scroll to Edit.
4
Press B under SELECT. The Entry Details screen displays.
5
Followthe applicable instructions in“Adding Phonebook Entries” on page 44 to edit the various fields.
Deleting Phonebook Entries
1
From the Phonebook screen, press R to scroll to the entry you want to delete.
2
Press m to view the Phonebook Menu.
3
Press R to scroll to Delete Record or Del ete Number. Delete Record deletes the name and all numbers associated with that
name. Delete Number deletes the number associated with the icon that is
currently displayed in the Phonebook list for the name. The name and all the other numbers will remain.
4
Press B under SELECT. A warning screendisplays requiring you to confirm the deletion.
Pause Digit Entry
Whenstoring a number, youcan program yourphone so that itwillnot only dial a number but also pause before entering another series of numbers such as a personal identificationnumber (PIN) or password. This featureis particularly usefulforaccessing automated services such as voice mail and banking systems from your i30sx phone.
49
Here’s how it works.Let’s say you have a company voice mail account thatyou frequently check while traveling.And,to accessthataccount you must do the following:
• Dial your work number
• Press # while the voice mail greeting is being played
• Enter your PIN to accessyourmessages
You can program your phone to enter all of the above information for you. All you have to do is separate each entry with a pause. If you were to programyour phone to automatically input the above information, the stored data would look likethis17035551234P#P1234.Inthis example, thefirst eleven digitsr epresent the number that mustbe dialedtoaccessyour voice mail.The P representsa 3 second pause. The # interrupts yourgreeting. The second P represents another 3 second pause. The last four digitsrepresent your PIN.
You can use this feature not only to enter PINs and passwords but also to have the phone automatically select menu options (i.e., press 1 to hear messages).
To create a three-second pause, follow the steps below:
Pressandhold * for two seconds.The pause symbol (P) will appear on the display screen.
NOTE:You can enter up to 20 characters in a single entry, stored or
dialed.
NOTE:If you use a system that will not let you enter an option until the
automated message has played in its entirety, you can program your phone to pause for more than 3 seconds. For example, performing the above step twice will program two pauses and cause your phone to wait 6 seconds before entering the next set of numbers.
50

Plus Dialing

Plus Dialing
This feature enables you to place an international call from most countries— without entering the local international access code. Use Plus Dialingforall Phonebook entries if you plan to travel outside the United States. Begin by following the instructions for “Adding Phonebook Entries” on page 44. Before you type the phone number to be stored:
1
Press and hold 0 for two seconds. A “0” appears, then changes to a “+”.
NOTE:The network translates the “+” into the appropriate
international access code needed to placethe call.
2
Enter the countrycode, city code, or area code, and phone number.
3
Follow the rest of the instructionsfor“Adding Phonebook Entries” on page 44.
51
52

Digital Cellular

The i30sx phone enablesyou to make and receive domestic and international phone calls,makeemergency calls, and be notified of a missed call.
This section includes:
Making Phone Calls Page 53 Emergency Calling Page 58 Receiving a Phone Call Page 58 Ending a Phone Call Page 58 Recent Calls Page 58 Call Waiting Page 63 Hands-FreeSpeakerPhone Page 61 Call Timers Page 63 Call Hold Page 65 Three-Way Calling Page 66 Call Forwarding Page 68

Making Phone Calls

Your i30sx phone provides the following features for making phone calls:
• Direct Dial
• Phonebook
• RecentCalls
• Speed Dial
• Turbo Dial
• Last Number Redial
• TTY - your phone supports TTY devices and communications.
®
53
Using Direct Dial
1
From the Readyscreen, use the keypad to enter the 10-digit phone number you want to call.
2
Press e to place the call.
3
Press s to end the call.
NOTE:See “Plus Dialing” on page 51 for information on making
international calls.
If you make a mistake:
• To clear one digit, press A under DELETE.
• To clear all digits, press and hold A under DELETE.
• To cancel, press s.
Making Calls from the Phonebook
After you have entered phone numbers into your Phonebook, you can use these numbers to make phone calls.For information on entering numbers into your Phonebook, see “Adding Phonebook Entries” on page 44.
To make calls from the Phonebook:
1
From the Ready screen, if PHBK is one of your display options, press A under PHBK.
Or, From the Readyscreen, press m,thenpressR to scroll to
Phonebook.PressB under SELECT.
2
Press R to scroll through the names in your Phonebook.
Or, Use the alphanumeric keypad to enter the first letter of the name and
press R to scroll through the namesbeginning with thatletter. Stop when the name of the person you want to call is highlighted.
54
Making Phone Calls
3
If more than one number is stored for the person you want to call, ef appearsaround the icon to the right of the person’sname.
Press T to scroll through the icons representing the numbers stored for that person.
Or, Press B under VIEW to view all the numbers stored for this person.
Then press R to scroll to the number you want to call. Or, If there is a Private ID or a Talkgroup number stored for this person,
press m. When the PhonebookMenu appears, press S to scroll to View and press B under SELECT. Then press R to scroll to the number you want to call.
For more information on assigningmultiple numbers to one person, see “Adding Phonebook Entries” on page 44.
4
Press e to place the call.
5
Press s to end the call.
Making Calls from the Recent Calls List
Your phone stores the numbers of the last 20 calls you received or sent in the RecentCalls list.
1
From the Ready screen, press R.
Or, From the Readyscreen, press S to Re cent Calls is not the first item
on the list, press S to scroll to it. Press B under SELECT.
2
Press S to scroll the list received or sent recentcalls until you reach the desired call.
55
3
To view additional information about the call:
Press B under VIEW. Or, Press m to access the Rec. Calls Menu.ThenpressR to scroll to
View and press B under SELECT.
4
Press e to place the call.
5
Press s to end the call.
Using Speed Dial
Each phonenumber stored in your Phonebook is assignedaSpeed Dial number. You can use the Speed Dial number to quickly place a call.
1
From the Ready screen, enter the Speed Dial number assignedtothe phone numberyou want to call.
2
Press #.
3
Press e to place the call.
4
Press s to end the call.
Using Turbo Dial
Turbo Dial allows you to call the numbers in yourPhonebook associated with Speed Dial numbers1 through9 by pressing and holding the corresponding numerickeyonthekeypad.
Press and hold a number key (1 through 9).
NOTE:Turbo Dial cannot be accessed while the browser is active, nor
while Keypad Lock or SIM Lock is active.
56
Making Phone Calls
Last Number Redial
Press and hold e to redial the last number you called.
Placing International Phone Calls
When making an international call, you can either enter the international access code directly(011intheUnited States) or use Plus Dialing.
You can make international calls from your Phonebook if you have stored the numbers with Plus Dialing. See “Adding Phonebook Entries” on page 44 and “Plus Dialing” on page 51 for more information.
NOTE:Your service default is “International Calls Restricted.”
Therefore, you must call Customer Care to obtain international dialing access.
To make an international call using Plus Dialing:
1
Press and hold 0 for two seconds. A “0” appears, then changes to a “+”.
NOTE:The network translates the “+” into the appropriate
international access code needed to placethe call.
2
Enter the countrycode, city code, or area code, and phone number.
3
Press e to place the call.
4
Press s to end the call.
Making TTY Calls
NOTE:This feature may not be offered by your service provider.
You can use your phone to make calls using a TTY device. When you make TTY call, the call begins in the TTY mode you l ast selected.
You canchangethe TTY mode during a call.For more informationon choosing a TTY mode, see “Setting TTY Mode” on page 105.
To make a call using a TTY device:
57
1
Connect one end of a 2.5mm cable into the jack on the phone. (To locate the jack, see page 10.) Connect the other end of the cord into your TTY device.
2
Enter the phone number you wish to call and press e.

Emergency Calling

Your phone supports emergency calling. Emergency calls can be made even when the SIM card is blocked or not in the phone.
To place a call in an emergency, dial 911e. You will be connectedtothe nearest emergency dispatch center. If you are on an activecall,you must end it beforecalling 911.
NOTE: If you have enabled the Keypad Lock feature, you must unlock
the phone’s keypad before any call can be made, including 911 emergency calls.

Receiving a Phone Call

Incoming calls are indicated by a ring, vibrationor backlight illumination. Press e or any key on the keypad or press B under YES to answer the call.

Ending a Phone Call

Press s to hang up.

Recent Calls

The RecentCalls feature stores thenumbers of the20most recentcalls you have made and received,i ncluding private and talkgroupcalls. You can access RecentCallsto:
• view your recent calls
• store numbers to the Phonebook
• deleterecent calls
• call numbers on the Recent Callslist
58
Recent Calls
NOTE:The Recent Calls list displays briefly after you end a call.
Recent Calls Icons
If thenumber of the recentcall is stored in yourPhonebook, the nameassociated with the phone number appears on the Recent Calls list.
For privatecalls, group calls, and numbers stored in your Phonebook,an icon appearsto the right of the name of numberindicating the Phonebook type of the number used in the call. See “Phonebook Icons” on page 40 for more information about Phonebook types.
For phone calls, an icon appears to the left of the name or number indicating the type of call:
• N indicates an incoming call
• a indicates an outgoing call
• V indicates a missedcall.(Missed calls appear on your Recent Calls list
only if you have Caller ID.)
For private calls,an icon appearsto the left ofthe name or numberindicatingthe type of call:
• h indicatesa Private Call
• n indicates a Group Call
Viewing Recent Calls
To view your Recent Calls list:
1
From the Ready screen, press R.
Or, From the Readyscreen, press S to scroll to Recent Calls.PressB
under SELECT.
2
Press S to scroll the list ofrecent calls.
59
Getting Detailed Information About Recent Calls
To get more information about a recent call:
1
From the Recent Calls screen, press S to scrolltothecall you want more information on.
2
Press B under VIEW.
Or, Press m to access the Rec. Calls Menu.ThenpressR to scroll to
View and press B under SELECT.
The screen that appears displays information such as the name associated with the number of the recentcall, the number, the date, time, and duration of the call.
Storing a Recent Call Number to the Phonebook
To store a number from the Recent Calls list to the Phonebook:
1
From the Recent Calls screen, press S to scroll tothenumber you want to store.
2
Press B under STORE. This displays the Phonebook Entry Details screen with the No: field
filled in with the number of the recent call.
3
If you want to add more information to the Phonebook entry, follow applicable the instructions in “Adding Phonebook Entries” on page 44.
Calling From the Recent Calls List
See “Making Calls from the Recent Calls List” on page 55.
60
Deleting Recent Calls
To delete a recent call:
1
From the Recent Calls screen, press S to scroll to the call you want to delete.
2
Press m to access the Rec. Calls Menu.
3
Press R to scroll to Delete.
4
Press B under SELECT.
5
Press A under YES to confirm the deletion.
To delete allcalls on the Recent Calls list:
1
From the Recent Calls screen, press m to access the Rec. Calls Menu.
2
Press R to scroll to Delete All.
3
Press B under SELECT.
4
Press A under YES to confirm the deletion.
Recent Calls
Hands-Free Speakerphone
This featureprovides the convenience of a hands-freesolution, allowing you to hold impromptu meetings andplacesafer phone calls. Thespeakerphone option (SPKR) is available whenever you are on an active phone.
NOTE:During speakerphone operation, you may either speak or listen,
but you cannot do both at the same time.
To turn the speakerphone on:
While on an active call, press B under SPEAKER.
While speakerphone is on, Spkrphone On appears in the text display area.
61
To turn the speakerphone off:
Press B under SPEAKER.
Use the Mute feature to listento incoming audiowithout allowing sound from your phone’s microphone to be transmitted over the phone line.
To turn mute on:
Press B under MUTE.
While mute is on, UNMUTE appears as a display option. To turn mute off:
Press B under UNMUTE.

Call Time rs

Call Timers measure the duration of your phone calls, Private or Group calls, and circuitdatause,aswellas the numberof Kilobytes sent and received by your phone.
The Call Time rs menu displays the following options:
• Last Call — displays the duration of your most recentphonecall.
• PhoneReset— keepsa running total of yourphone call minutes, until you
reset it.
• Phone Lifetime — displays the total minutesofall your phonecalls.
• Prvt/Grp Reset — keeps a running total of all of your Private and Group
call minutes, until you reset it.
• Prvt/GrpLifetime — displays the total minutesof all your Privateand Groups calls.
• CircuitReset — keeps a running total of all of your circuit data use,until you reset it.
• Circuit Lifetime — displays the total minutesof all of your circuitdata use.
62

Call Waiting

• Kbytes Reset — keeps a runningtotal of the number of Kilobytes sent and receivedby your phone, until you reset it.
To view the Call Tim ers menu:
1
From the Ready screen, press m.
2
Press R to scroll to Call Timers.
3
Press B under SELECT.
To view or reset a Call Timers option:
1
From the Call Timersm enu, press S to scroll to the Call Timers option youwant to view or reset.
2
Press B under SELECT.
3
If the feature does not include an option to reset or you do not wish to reset the option,press A under DONE whe n you are finished viewing.
To reset a feature, press B under RESET. When the confirmation screen appears, press A under YES to confirm the reset.
NOTE:The values displayed by Call Timers are not intended for billing
purposes.
Call Waiting
Call Waiting allows you to receive a second call while you are talking on the phone. You can switchbetween calls so you never have to miss a call. By default, Call Waiting is always on unless you turn it off for a specific call.
63
If you’re on a call and you receive a second call, you will:
• Hear a tone; and
• See a message on your display informing
you of another incoming call.
e
Accepting Calls
Press B under YES. The first call is placed on hold.
Switching Between Calls
When you acceptasecond call while you are talkingon thephone, your display shows thename or number of each call. An iconappears to the left of each name or number indicating that the call is on hold z or active D.
Press B under SWITCH to switch between calls.
Z
Declining Calls
Press A under NO. If you subscribe to Voice Mail, thecallwill be forwarded to your Voice Mail box.
64

Call Hold

Ending the Active Call
Press
s.
Turning O ff Call Waiting
If you do not want to be interrupted during a call,you can turn Call Waiting off prior to making/receiving a call.
1
From the Ready screen, press m.PressR to scroll to Settings,and press B under SELECT.
2
Press R to scroll to In Call Setup and press B under SELECT.
3
Press R to scroll to Call Waiting and press B under CHANGE.
4
Press R to scroll to Off and press B under SELECT.
Call Waiting is now disabled for the next call. It will automatically reset to On when you hang up.
Call Hold
When you are on an active call, you can place the call on hold and make a second call.
To place an active call on hold:
1
Press m to access the Calls Menu.
2
Press R to scroll to Hold.
3
Press B under SELECT.
4
If you have not placed a second call, you can resume this callby pressing B under RESUME.
65
To place a second call while the first call is on hold:
1
Enter the second phone numberyou want to call. Or select the number from your Phonebook by pressing
2
Press e to place the second call.
To toggle betweenthe two calls:
Press B under SWITCH.
To end the active call:
Press s. The call on hold becomes active.
m and selecting Phonebook.

Three-Way Calling

Using Three-Way Calling, you can combine two ongoing phone calls into one conversation. While on an active call, you can make a second call and combine the two calls. When you placeor receivea phone call, the 3-WAY option appearsin the bottom right-hand corner of the display screen.
To make a three-way call:
1
Place or receive a phone call.
2
While on the call, press m to access the Call Menu.
3
Press R to scroll to 3Way.
4
Press B under SELECT. The first call will be placed on hold.
66
Three-Way Calling
5
Enter the second phone numberyou want to call and press e to place the secondcall.
Or, access the number from your Phonebook:
m andthenpressR to scroll to Phonebook.
Press
Press
B under SELECT.
To place the call, see “Making Calls from the Phonebook” on page 54.
6
After you reach the second individual, press m.
7
Press S to scroll to 3Way.
8
Press B under SELECT. Both calls will appear on your display.
67

Call Forwarding

CallForwarding forwardscalls to the numberyou designate.The followingCall Forwarding options are available:
• Off — No calls areforwarded.
• All Calls — When this option is turned on, all calls will be sent
automatically to a number you specify.
• Detailed — Choosing thisoption enables you to forward calls you missed to different numbers, or to Voice Mail,depending on why you missed each call:
• Busy — your phone is engaged in other activities.
• No Answer — you do not answer. The phone willring4 times before
forwarding the call.
• Unreachable — your phone is out of coverageorpowered off.
You can forward Line 1 and Line 2 independently. When your phone is set to forward all calls, one of the following icons appears
on the top row of your display screen to indicatethecall forwarding option you have chosen:
Icon Indicates...
68
G Line1i s active;calls from Line1are being
forwarded.
H Line1i s active;calls from Line2are being
forwarded.
I Line 1 is active; calls from Line 1 and Line
2 are being forwarded.
J Line2i s active;calls from Line1are being
forwarded.
K Line1i s active;calls from Line2are being
forwarded.
L Line 2 is active; calls from Line 1 and Line
2 are being forwarded.
Call Forwarding
NOTE:Call Forwarding must be set to Detailed with the Voice Mail
access number to receive Voice Mail messages. This is the default setting.
TurningOnCallForwarding
1
Press m then press R to scroll to Call Forward.
2
Press B under SELECT.
3
At the Call Forward screen, the Forward field is highlighted. Press B under CHANGE.
W
4
Press S to scroll to All Calls.
5
Press B under SELECT.
6
Press R to scroll to the To field and press B under CHANGE.
69
7
To activate a call forwardingnumber: If you have never used Call Forwarding before, the Forward screen
appears. To enter a call forwarding number, type the number on your phone’skeypadorpressB under SEARCH to select from numbers stored in your phone.Press B under OK.
Or, If you have used Call Forwarding before, the call forwarding number
youlastusedisdisplayed.PressB under CHANGE to access the Forward screen.
To forward your calls to this number, press B underOK. To forward your calls to a different number, press and hold A under
DELETE to erase the displayednumber. Type the new number on your phone’skeypadorpressB under SEARCH to select from numbers stored in your phone.Press B under OK.
Your calls will now be forwarded to the number that you selected.
Turning Off Call Forwarding
1
Press m then press R to scroll to Call Forward.
2
Press B under SELECT. The Call Forward screen displayswith the Forwardfield highlighted.
70
Call Forwarding
3
Press R to scroll to the To field and press B under CHANGE.
4
Press S to scroll to Off and press B under SELECT.
NOTE:You can use the Detailed setting to forward calls to other
numbers if desired. However, it is recommended that you leave Detailed set to the Voice Mail access number and use the All Calls setting if you wish to forward your calls to another number.
SettingCallForwardingtoVoiceMail
In mostcases, turning offCall Forwardingrestores your ability to receive Voice Mail messageswhenyou are unavailable (see “Turning Off Call Forwarding” on page 70). If you have completed those steps but are still not able to receive Voice Mail messages, you can reset Call ForwardingtoVoice Mail.
For you to receive Voice Mail messages, Call Forwarding must be set to Detailed with your Voice Mail access number:
1
Press m then press R to scroll to Call Forward.
2
Press B under SELECT.
The Call Forward screen displayswith the Forwardfield set to Detailed.
3
Press R to scroll to the If Busy field and press B under CHANGE.
71
4
The call forwarding number you last used is displayed. Press B under CHANGE. If this is your Voice Mail access number (the first six digits of your 10-digit phonenumberfollowed by 6245), go to step 7.
5
Press and hold A under DELETE to erase the displayed number.
6
Enter your Voice Mail access number.
Your Voice Mail accessnumber is the first six digitsof your 10-digit phone number, followed by 6245. (For example 7035556245.)
7
Press B under OK.
8
Repeat step 3 through step7 for the If No Answer field and the If Unreachable field.
9
When finished, press A under EXIT.
NOTE:You can use the Detailed setting to forward calls to other
numbers if desired. However, it is recommended that you leave Detailed set to the Voice Mail access number and use the All Calls setting if you wish to forward your calls to another number.
72

Messages

The main topics covered in this section are listed below:
MessageCenter Page 73 Voice Ma il Page 74 Text and Numeric Messaging Page 76 Alert FlagNotification Page 74 Net Mail Page 78 Using Your Phone as a Modem Page 79

Message Center

The Message Center enables you to access allmessaging services throughone screen.
To access the MessageCenter: If MESG is one of your display options:
From the Readyscreen, press B under MESG.
If MESG is not one of your display options:
1
From the Ready screen, press m.
2
Press R to scroll to Messages.
3
Press B under SELECT.
The Message Centerscreen displays the number of messagesyou have in each message service — Voicemail (Voice Mail), Text Msgs (Text and Numeric Messages), and NetMail (Net Mail).
73
To access any message service:
1
From the Message Centerscreen, press R to scroll to the message serviceyou want to access.
2
Press B under the display option on the right. This option varies depending on the messageservice selected.

Voice Mail

New Message Indicators
When you receive a new message:
• New VoiceMail Message will display on the screen.
f
• Your phonewill alert youevery 30 secondsuntil you pressB underCALL or A under EXIT.(Ifyou are on a call, your phone will alert you once during the call.)
Transferring Calls to Voice M ail
Press A under NO whileyourphoneis ringing to transferincoming calls directly to Voice Mail.
74

Using Voice Mail

Logging Into Voice Mail
1
From the Ready screen, press B under MESG to open up the Message Center screen.
2
Voicemail should be highlighted to indicate that it is selected. If it isn’t highlighted, press S to scroll to the Voicemail field.
The number of new messages and the total numberof messages are displayed.
Using Voice Mail
A
g
3
Press B under CALL to log into your Carrier’s Voice Mail System. Calling displays as you are connected to the network.
75

Text and Numeric Messaging

With Text and Numeric Messaging, your phone will:
• Allow numericmessages up to 20 characters in length and text (alpha) messagesupto140charactersinlength.
• Accept your messages even if you are unavailable, if your phone is turned off,or if you are busy on another call.
• Alertyouofa new text or numericmessage, even if youareon another call.
• Store a message if you are making a Private or Groupcall and deliver it
upon completion of the call.
• Store the message if you are outside of the coverage area and deliver it as soon as you are back in a coverage area.
• Attemptcontinuous delivery of messages until successful, for up to 7 days.
With Text and Numeric Messaging, your phone will:
• Refer to text and numeric messages as Text Messages.
• Stamp the message with the time and date the message was left.
• Storeupto16messagesatatime,thatwillremainuntilyoudeletethem.
NOTE:“Mail Waiting, Memory Full” displays when 16 message
registers are full. (Messages must be erased before you can receive others.)
• Allow for “Auto Call Back” of a phone number that is included withina message,by pressinge. Ifthe message contains two phonenumbers, Auto Call Back will dial the last number.
76
Text and Numeric Messaging
New Messages Indicators
When you receive a new message:
• New Text Message willdisplayonthescreen.
i
• Your phone will alert you every 30 seconds until you press B under READ or A under EXIT. (If you are on a call, your phone will alert you once during the call.)
Accessing New Messages
When you receive a message, you can view it immediately or later:
View a Message Immediately
1
Press B under READ. The message displays.
2
If the message fills more than one screen, use S to scroll throughthe rest of the message.
3
Press A under SAVE to save the message.
Or, Press B under DELETE to delete the message.
Viewing a Message Later
Press A under EXIT. The Ready screen to remind you that you have a stored message.
. icon will appearon the second lineofthe
77
Viewing Stored Mess ages
1
In the Message Center screen, press S to scrolldown to Text M sgs. The number of new messages and the total number of messages are displayed.
2
Press B under SELECT. The Text Msg Inbox screen appears.
3
Press S to scroll to the message you want toreadand press B under READ.
4
If the message fills more than one screen, use S to scroll throughthe rest of the message.
5
Press A under SAVE to save the message.
Or, Press B under DELETE to delete the message.

Net Mail

With Net Mail, you can send text and numericmessages in any of three ways:
• from your i30sx phone
• from a web site provided by your service provider
• from any email application
When you receive a new message:
• Words will display on your phone’sdisplay screenindicating thatyou have a Net Mail message. (The exactwords displayed are determined by your serviceprovider.)
• Your phone will alert you every 30 seconds until your press B to access the message or press A to exit the screen.
If you choose to exit the screen and view the message later, the appear on the second line of the Ready screen to remind you that you have a stored message.
You can view new or stored Net Mail messagesat any time by accessthe Message Center. For more information, see “Message Center” on page 73.
. icon will
78

Using Your Phone as a M odem

Using Your Phone as a Mode m
NOTE: Some features may be network dependent or subscription only,
and may not be available in all areas. Contact your service provider for more information.
You can use your i30sx phone as a modem for data transfer from your laptop, handheld device, or desktop computer.Thisis particularly useful when thereis no wired phone line (wall jack) available.
You simply attacha datacable(available separately) to your phone and your computer. From that point, your phone is your modem. This allows you to send or receive time-critical information such as email, a field service report, or files. In addition, you can alsosendor receive faxes.
This type of wireless connection uses one of two types of data connection: circuit-switched data and packet data.
• Circuit-switcheddata is typicallyused for sending and receiving faxesand for transferring large files.
• Packetdata is used for small file transfers such as email.
To use theseservices, you must install the iDEN Wireless DataServices software (available separately). For more information on setting up your computer and your i30sx phone for Packet and Circuit Data calls, see the Wireless Data Services User’s Guide and contact your carrier.
79
80

Private Calls

The main topics covered in this section are listed below:
Private Call Page 81 Call Alerts Page 83 Group Call Page 87

Private Call

There are several ways to reachan individual using Private calls. Whether you dial the person’s Private ID directly or store it in your Phonebookor Recent Callslist, you musthave the individual’sPrivate ID to use Private calls. To learn how to store names and numbers,see “Phonebook” on page 39.
USER TIP:To find out your own Private ID number, see “My
Making a Private Call from the Keypad
1
Enter the Private ID of the person you are trying to call.
2
Press and hold the Push-To-Talk button (PTT) button on the side of the phone. Begin talking after the phone emits a chirping sound.
3
Releasethe PTT button to listen.
Information” on page 25.
Making a Pr ivate C all from the Phoneboo k
If you have stored a person’s Private ID in your Phonebook, youcan use your Phonebook to make a Privatecallt o that person:
1
From the Ready screen, press m.
2
Press R to scroll to the Phonebook.PressB under SELECT.
81
3
From the Phonebook screen, press S to scroll throughthenames until the desiredname is highlighted.
4
Press and hold the PTT button on the side of the phone. Begin talking after the phone emits a chirping sound.
5
Releasethe PTT button to listen.
Making a Private Call from the Recent Call List
1
From the Ready screen, press m.
2
Press R to scroll to the Recent Calls.PressB under SELECT.
3
From theRecentCalls screen, press S to scrollthrough the namesand numbers until the desired name or Private ID number is highlighted.
4
Press and hold the PTT button on the side of the phone. Begin talking after the phone emits a chirping sound.
5
Releasethe PTT button to listen.
Receiving a Private Call
When youreceive a Privatecall, your phoneemits a chirping sound and Private in Use appears on the screen. The Private ID or the name of the caller (if stored
in your Phonebook) displays on the screen. To respond to a Private Call:
1
Wait for the caller tostopspeaking.
2
Press and hold the PTT button. Begin talking after the phone emits a chirpingsound.
3
Release the PTT button to listen.
82

Call Alerts

Storing Private IDs
For information store Private ID numbers to your Phonebook, see “Adding Phonebook Entries” on page 44.
For information on how to quickly store Private ID numbers, see “Storing NumbersFast” on page 48.
Call Alerts
You can send a call alert, which lets recipients know that you would like to talk with them. When you send an alert, the recipient will receive a series of beeps and your name or Private ID will appearon the display.
Placing a Call Alert from the Keypad
1
Enter the Private ID of the person you want to call.
2
Press B under ALERT. The ReadytoAlertscreen displays.
3
Pressandhold the PTTbutton untilAlert Successful displays.The alert sounds intermittently until the user of the phone answers, queues, or clears the alert.
Placing a Call Alert from the Phonebook
1
From the Ready screen, press m.
2
Press R to scroll down to Phonebook.PressB under SELECT.
3
From the Phonebook screen, pressS to scroll to the Phonebook entry for the person you want to alert.
83
4
Press B under ALERT. The Ready to Alert screen appears.
V
5
Pressandhold the PTTbutton untilAlert Successful displays.The alert sounds intermittently until the user of the phone answers, queues, or clears the alert.
Ready to Alert Screen
ReadytoAlertis used to confirm your request for the alert and to prompt you to push the PTT button:
• If youpress the PTTbutton, the callalert is sent,and the phone displays the RecentCalls screen.
• For callalerts placed fromthekeypad, pressing A under CANCELcauses the phone to return to the Dial screen with the previously entered number displayed.
• For call alerts placed from the Phonebook, pressing A under CANCEL causes the phone to return to the Phonebook screen.
• If you do nothing, the phone will revert to the Ready screen.
Receiving Call Alerts
Whenyoureceive a callalert, your phone emits a chirpand displaysthename or number of the caller. You can answer, queue, or clear the callalert:
• To answer a call alert, press the PTT button.
• To queue a call alert, press B under QUEUE.
• To clear the call alert, press A under CLEAR.
84
Call Alerts
Call Alert Queue
Call alert queuing enables you to save call alerts in a list, or queue. To store a call alert in the call alert queue, press B under QUEUE whenyou have received an incoming call alert.
Accessing the Call Alert Queue
1
From the Ready screen, press m.
2
Press R to scroll to Call Alert.
3
Press B under SELECT. The Call Alert Queue screen displays.
ViewingCall Alert Dateand Time
Tofindoutthedateandtimeacallalertwasreceived:
1
From the CallAlertQueue screen, press S to scroll to the desired call alert.
2
Press m to access Call Alert Menu.
3
Press R to scroll to View.
4
Press B under SELECT.
Sorting Call Alerts
To sort your call alertsby the ordertheywerereceived:
1
From the Call Alert Queue screen, press m to access Call Alert Menu.
2
Press S to scroll to Sort By.
3
Press B under SELECT.
85
4
Press S to scroll to Firston Top or Last on Top.
5
Press B under SELECT.
Responding to a Call Alert From the Queue
1
From the Call Alert Queue screen, press S to scroll to the call alert you want to respond to. You can respond by sending a call alert or placing a Private call.
2
To send a call alert, press B under ALERT and then press the PTT button.
Or, To place a Private call, press the PTT button. The call alert will be removed from the queue.
Deleting a Call Alert From the Queue
To delete a call alert from the queue:
1
From the Call Alert Queue screen, press S to scroll to the entry you want to delete.
2
Press m to access Call Alert Menu.
3
Press R to scroll to Delete.
4
Press B to SELECT.
5
Whenthe confirmation screenappears, pressB under YES todelete all call alerts.
86

Group Call

To delete all call alerts from the queue:
1
From the Call Alert Queue screen, press m to access Call Alert Menu.
2
Press R to scroll to Delete All.
3
Press B to SELECT.
4
When the confirmation screen appears, press B under YES to delete the entry.
Group Call
In a Group call, you can communicate instantly with a group of people that you have previously set up as a Talkgroup. Your sales representative must set up your Talkgroups by providing you with a Talkgroup number for each Talkgroup. After youhave the number,you can assigneach Talkgroupnumber a name and store it in your phone (see “Storinga Talkgroup” on page 87).
Talkgroups appear on your display as numbers or programmed names suchas SALES TEAM or Talkgrp 5. Your phone can store up to 30 Talkgroups. You can initiateor participate in Group calls for Talkgroups that have been created for you and that are stored in your Phonebook.
Storing a Talkgroup
1
From the Ready screen, press m.
2
Press R to scroll to Phonebook.
3
Press B under SELECT.
4
Press S to scroll to New Entry.
5
Press B under SELECT. The Entry Details screen displays.
6
Enter the information as you would any otherPhonebook entry. (See “Adding PhonebookEntries”onpage44.) When you getto Type,make sure that you select Talkgroup.
87
7
Enter the Talkgroup name or number.
8
When you have completed the Entry Details,pressA under DONE.
Making a Group Call from the Keypad
1
Press # and then enter the Talkgroup number of the group that you want to call.
2
Press and hold the PTT button on the side of the phone or press B under ALERT, and speak. The phones of individuals in the Talkgroup will emit a chirping sound to alert them thatsomeone is calling.
3
Releasethe PTT button to listen.
Making a Group Call from the Phonebook
1
From the Phonebook screen, press R to scroll to the name of the Talkgroup you want to call.
2
Press and hold the PTT button on the side of the phone or press B under ALERT, and speak. The phones of the people in the Talkgroup will emit a chirping sound to alert them thatsomeone is calling.
3
Releasethe PTT button to listen.
Making a Group Call from the Recent Calls List
1
From the Recent Calls screen, press R to scrollto thename of the Talkgroup you want to call.
2
Press and hold the PTT button on the side of the phone or press B under ALERT, and speak. The phones of individuals in the Talkgroup will emit a chirping sound to alert them thatsomeone is calling.
3
Releasethe PTT button to listen.
88
Group Call
Receiving a Group Call
When you receive an incomingGroupcall, your phone emits a chirp. To respond to a Group call:
1
Wait for the caller to finish speaking.
2
Press and hold the PTTbutton to talk. Release the PTT button to listen.
Group-Silent Programming
Group-Silent programming enablesyouto silence incoming Group alerts and communication.
Turning Group-Silen t On or Off
1
From the Ready screen, press m.
2
Press R to scroll to Settings.PressB under SELECT.
3
Press R to scroll to Tkgrp Settings.PressB under SELECT.
4
With the Silent field highlighted, press B under CHANGE.
5
Press S to scroll to On or Off.
6
Press B under SELECT.
89
90

Memo

The Memo application provides you with a place to store a numeric note (for example a phone number)in your i30sx phone.
This section includes:
Adding a New Memo Page 91 Viewing a Memo Page 91 Editing a Memo Page 92 Deleting a Memo Page 92

Adding a New Memo

1
From the Ready screen, press m.
2
Press R to scroll to Memo.
3
Press B under SELECT. The Memo screen displays.
4
Type your numeric memo using the phone’skeypad.
5
Press B under STORE.

Viewing a Memo

1
From the Ready screen, press m.
2
Press R to scroll to Memo.
3
Press B under SELECT.
4
To call this number, press e.
91

Editing a Memo

1
From the Ready screen, press m.
2
Press R to scroll to Memo.
3
Press B under SELECT.
4
Type the new number.
You can delete a digit by pressing A under DELETE. To all the digits, press and hold A under DELETE.
5
Press B under STORE.

Deleting a Memo

1
From the Ready screen, press m.
2
Press R to scroll to Memo.
3
Press B under SELECT.
4
Press and hold A under DELETE.
5
Press B under STORE.
92

Customizing the i30sx phone

You can customizeyour i30sx phonetofitthewayyouwanttouseit. This section includes:
Settings Page 93

Settings

The phone’s Settingsmenu enables you to control many of the phone’sfeatures and functions, including display properties, messagehandling, and security features.
To access the Settingsmenu:
1
From the Ready screen, press m.
2
Press S to scroll to Settings.
3
Press B under SELECT.
From the Settings screen, you can access these Settings options:
• Ring/Vibe — controls how your phone rings or vibrates (VibraCall when you receive calls and messages.
• Phone Setup — sets call-answering features, turns offnon-telephone features, chooses which phone line is used, and sets your network ID.
• In Call Setup — sets call timer, message notification, and call waiting features.
• Security— sets security features including phone lock,keypadlock, and SIM PIN.
• Personalize — controls whichfeatures are most accessiblewhen youturn on your phone.
• Initial Setup — sets a variety of display features including the language displayed, the screen contrast, time and date formats, current year, backlight, statuslight, and scrolling. Also turns auto redialonoroff and sets baud rate.
• VoiceVolume — sets the volume of your phone’s earpiece and speaker.
TM
)
93
• Tkgrp — sets certain Talkgroup options.
• Service Status — shows the status of your phone’sservices.
To access any of these options:
1
From the Settings screen, press R to scroll to the option you want to access.
2
Press B under SELECT.
Many of these options have otheroptions within them. Press S to scroll through the listsof options, and press A to select and modify optionsand the features, accordingto the instructions on yourphone’s screen.For some options, you can also press T to select sub-options.
In screens thatshow listsofoptions for a setting,a check mark to the left of the option indicates the current option for the setting.
Ring/Vibe
Ring/Vibe enablesyou to control howyourphonerings andvibrates VibraCall
®*
when you receivecalls and messages. You can set ring volume, choose ring styles, and use the vibrate alert featurewhichenables you to set your phone to alert you to calls and messages by vibrating.
Main Options
Ring/Vibe providesthese main options:
• Ringer Vol — sets ring volume.
• Keypad Vol— sets volume of sounds associated with keypad actions.
• Mail Vol — sets volume of TextMessage, Voice Mail, and Net Mail
notifications.
• Headset — choosing the HdsetOnly option preventssound from being
emittedfrom the phone’s speaker when the headset is beingused.
TM
• VibeAll (VibraCall
) — choosing On sets the phone to vibrate for all
calls,messages, and alerts; choosingOff enablesyou set the type of notification for each these features.
94
Settings
Ring Style and Notification Type
When you set VibeAll to On, your phone vibrates to notify you of all types of calls, messages, and alerts.
When you set VibeAll to Off, the following features displayafter VibeAll on the Ring/Vibrate screen, enabling you to set notification options for each:
• Line 1 — sets the ring style and type of notification for calls on Line 1.
• Line 2 — sets the ring style and type of notification for calls on Line 2.
• Pvt/Grp — sets type of notification for private and group calls.
• Call Alert — sets the ring style and type of notification for call alerts.
• Text Msgs — sets typeof notification for Text Messages.
• Reminder — sets type of notification for Datebook reminder alarms.
• Voicemail — sets type of notification for Voice Mail messages.
• Netmail — sets type of notification for Net Mail messages.
To set VibeAll to Off or On:
1
From the Ring/Vibrate screen, press S to scrollto the VibeAll:.
2
Press B under CHANGE.
3
Press S to scroll to Off or On.
4
Press B under SELECT.
The followingiconsappear on your display screen to indicate the options you have chosen:
Icon Indicates...
- Vibrate All - phone is set to vibrate when
you receive all types of calls,messages, and alerts; the VibeAll option is On.
[ Vibrate On - phone is set to vibrate when
you receive phone calls.
95
\ Vibrate Then Ring - phone is set to
vibrate and then ring when you receive phone calls.
* Silent - phone is set not to ring.
Ring Styles
When you set a ring style, you can choose from any of nine pre-set ring styles. To set a ring style:
1
From the Ring/Vibrate screen, ensure that VibeAll is set to Off.Then press S to scrollto any of the features thatallow you to set a ringer style: Line1, Line2,orCall Alert.
2
Press B under SELECT.
3
With the Style: field highlight, press B under CHANGE.
4
Press R to scroll to the ring style you want to assign to the feature.
5
To assign the ring style,press B under SELECT.
USER TIP:To hear thering style you have selected, press thevolume
button on the side of your phone.
Notification Types
When you set a notificationtype,you have these options:
• Ring — the phone rings to notify you.
• Vibe — the phone vibrates to notify you.
• Vibe/Ring — the phone vibrates and then rings to notify you. This option
is only availablefor calls on Line 1 and Line 2.
• Silent — the phone does not ring to notify you.
96
Settings
To set a notification type:
1
From the Ring/Vibrate screen, ensure that VibeAll is set to Off.Then press S to scrollto any of the features on the Ring/Vibrate screen after VibeAll.
2
Press B under SELECT.
3
With the Type: field highlighted, press B under CHANGE.
4
Press R to scroll to the notification type you want to assign to the feature.
5
To assign the notification type, press B under SELECT.
Phone Setup
Phone Setup sets some basic phone features. Access Phone Setup to set the following options:
• Line — enables you to choose Line 1 or Line 2 as the active line for
outgoing calls.
• AutoAns — sets your phone to automatically answer an incoming call
afteraspecified number of rings. When this featureisturned on, the phone answers byconnecting you to the caller; it does not send the call to Voice Mail, unlessyou are out of coverageor on the line.
• Any Key — when turned on, enablesyou to answer calls by pressingany
key on the alphanumeric keypad.
• Phone Only — when turned on, prevents your phone from making or
receiving Private calls or Group calls.
• Network ID — enables you to set the phone’snetworkIDsandtheir
roaming options.
In Call Setup
In Call Setup sets the in-call timer, message notification, and call-waiting features.
• The In Call Timer option turns the following features on and off:
• Display — the duration of each call displays on the phone’s screen.
97
• Minute Beep — an audible beep occurs every minute of an active
call.
• The Notifications option controls message notification during calls:
• Receive All — notifies you of all types of messages during calls.
• Msg Mail Only — notifiesyouof mail messages only; allother types
of message notifications are delayed until the call has ended.
• Delay All — delays notification of all messages until the call has
ended.
• Call Waiting — enables you to turn off call waiting for the next call. After
you hang up, call waiting is turned back on.
Security
Securityallows you to set security features:
• Phone Lock — sets an optional code that locks your phone.
• Keypad Lock — displaysinstructions for locking and unlockingyour
phone’skeypad.
• SIM PIN — enables and disablesyourphone’s SIM PIN requirement.
• New Passwords — enables you to change your phone’s security code,
phone unlock code,and SIM PIN.
• Master Reset — allows your service provider to reset your serviceinthe
event of a security or provisioning problem.
Using Phone Lock
The Phone Lock feature enables you to preventyourphone from being used unless an Unlock codeis typed into the keypad.
The Unlock code is required to enable the phone lock feature, to unlock the phone, and to set a new Unlock code. Contact your service provider for your default Unlock code.
Phone lock provides two options for locking the phone:
• Lock Now locks the phone immediately after you set the option.
• Auto Lock locks the phone the next time the phone is powered on.
98
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
