CP185 Series
Two-Way Portable Radio
User’s Guide
Computer Software Copyrights . . . . . . . . ii
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Radio Overview . . . . . . . . . . . . . . . . . . . . . . 1
LED Colors . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LCD Display and Icons . . . . . . . . . . . . . . . . . 4
Programmable Buttons. . . . . . . . . . . . . . . . . . 5
Getting Started . . . . . . . . . . . . . . . . . . . . . . . 7
Attaching and Removing the Antenna . . . . . 7
Attaching and Removing the Battery . . . . . . 8
Attaching and Removing the Belt Clip . . . . 9
Charging the Battery . . . . . . . . . . . . . . . . . . 10
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Deleting a Nuisance Scan Channel . . . . . . . 12
Voice Operated Transmit (VOX) . . . . . . . . 13
Voice Inversion Scrambling . . . . . . . . . . . 14
Front Panel Programming Mode . . . . . . . .15
Entering Front Panel Programming
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Exiting Front Panel Programming Mode . . . .15
Assessing Front Panel Programming
Mode Parameters . . . . . . . . . . . . . . . . . . . .15
TPL and DPL Frequencies and Codes . . . . .21
TPL Frequency . . . . . . . . . . . . . . . . . . . . . . 21
DPL Codes . . . . . . . . . . . . . . . . . . . . . . . . . 23
Motorola Limited Warranty for the United
States and Canada . . . . . . . . . . . . . . . . . . .26
Accessories . . . . . . . . . . . . . . . . . . . . . . . .31
CONTENTS
i
English

COMPUTER SOFTWARE COPYRIGHTS

The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola.
COPYRIGHTS
COMPUTER SOFTWARE
Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product.
English
ii

SAFETY

C a u t i o n
PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE
Before using this product, read the operating instructions for safe usage
!
This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before
using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C98_) to ensure compliance with RF energy exposure limits.
contained in the Product Safety and RF Exposure booklet enclosed with your radio
ATTENTION!
.
SAFETY
iii
English
Notes:
SAFETY
English
iv

RADIO OVERVIEW

r
1 Channel Selector Knob
2 On/Off and Volume Knob
3 LED Indicator
4 Speaker
5 Microphone
6 Liquid Crystal Display (LCD)
7 Push-to-Talk (PTT) Button
CP185
RADIO OVERVIEW
9 Accessory Connecto 10 Programming Port
11 Front Left/Right Buttons
12 Front Programmable Buttons
8 Side Programmable Buttons
1
English
English

1. Channel Selector Knob

Used to select channels in normal radio operation mode.

2. On/Off and Volume Knob

Turn the ON/OFF/Volume Control knob clockwise to turn the radio ON. Turn the ON/OFF/Volume Control knob counterclockwise to turn the radio OFF. Turn this knob clockwise to increase the volume.
RADIO OVERVIEW
Turn this knob counterclockwise to decrease the volume

7. Push-to-Talk (PTT) Button

Press and speak to microphone to send message. Release and listen to receive messages. Note: If a channel is programmed with the Busy Channel
Lockout feature, you can only transmit on that channel if it is free.

8. Side Programmable Buttons

.
Refer to "Programmable Buttons" on page 5 for more details.

3. LED Indicator

Indicates radio transmit, receive, scan and monitor status. Refer to "LED Colors" on page 3 for more information.

4. Speaker

You will hear received messages through the speaker.

5. Microphone

Speak into the microphone when sending messages.

6. Liquid Crystal Display (LCD)

An 8 character single line display with up to 9 radio status icons. Refer to "LCD Display and Icons" on page 4 for more details.
English
2

9. Accessory Connector

2.5 mm audio in and 3.5 mm audio out port are used to connect compatible accessories to the radio.

10. Programming Port

2.5 mm audio in (lower port) used by dealer to program the radio.

11. Front Left/Right Buttons

Used to navigate menu, sub-menu or parameter selections in front panel programming mode.

12. Front Programmable Buttons

Refer to "Programmable Buttons" on page 5 for more details.
English

LED COLORS

LED Color State Indication
Green
Amber Illuminated Monitor activated.
Red Normal Blinking Radio is transmitting in normal
Illuminated Radio is transmitting in normal
mode. Radio is transmitting in scrambling mode.
Normal Blinking Radio is receiving in normal
mode. Channel is busy. Radio passed self test during powering up.
Permanent Sticky Monitor activated.
Normal Blinking Radio is in active scan mode.
Radio is receiving in scrambling mode.
mode while battery is low. Radio is transmitting in scrambling mode while battery is low.
Fast Blinking Radio failed self test during
powering up.
RADIO OVERVIEW
3
English
English

LCD Display and Icons

Displays selected channel, programming parameters, status messages and any error or information messages.
LCD
Indicator
RADIO OVERVIEW
Description Function
Signal Strength Indicator
Power Level Indicator
Talkaround Indicator
Shows the signal strength. More bars indicate a stronger signal received by radio.
“L” illuminates to indicate radio is configured to transmit in low power; “H” illuminates when radio transmits in high power.
Illuminates when radio is not transmitting through the repeater.
LCD
Indicator
Description Function
Programming Mode Indicator
Keypad Lock Indicator
Battery Level Indicator
Voice Inversion Scrambling Indicator
Illuminates when radio is in Programming Mode.
Illuminates when keypad is locked.
Shows remaining charge in battery based on how many bars (1 – 3) are displayed. Blinks when the battery is low.
Illuminates when scrambling is on.
English
Monitor Indicator
Scan Indicator Blinks without dot, when normal
Illuminates when monitoring a selected channel.
scan is activated. Illuminates without dot, when there is some activity on a non­priority channel. Illuminates with dot blinking, to indicate that there is some activity on the priority channel.
4
English

Programmable Buttons

The programmable buttons consist of:
Side Programmable Button 1
Side Programmable Button 2
Front Programmable Button 1
Front Programmable Button 2
Front Programmable Button 3
The following functions can be assigned as short press (press and release) or long press (press and hold for more than 1
second).
Button Function
Backlight Toggles backlight display between ON and OFF.
Channel Alias Toggles display between Channel Number and
Channel Alias.
Button Function
Keypad Lock Locks or unlocks all buttons except PTT, Side
Programmable Button 1, Side Programmable Button 2, Channel Selector Knob and ON/OFF/ Volume Knob.
Monitor Monitors the channel for any activity as long as
Nuisance Channel Delete
TPL/DPL Enable
Power Level Selects required power level: High or Low.
Prime Channel Quick move to the selected Prime Channel.
Reverse Burst Select the Reverse Burst Type: None, 180 or
Scan Starts or stops channel scan.
Squelch Level Selects desired squelch level: Normal or Tight.
Sticky Monitor Toggles the permanent monitor function until the
Talkaround/ Repeater Mode
Unassigned No function is programmed to this button.
Scrambling Code Select
the button is pressed.
Removes unwanted channel(s) temporarily from scan list during scan.
Enables or disables radio from requiring matching TPL/DPL to unsquelch.
240.
button is pressed again.
Allows the user to toggle between repeater and talkaround mode operations.
Select the scrambling code: 3.29kHz or 3.39kHz
RADIO OVERVIEW
5
English
English
Button Function
Scrambling Enable/Disable
Vol ume Set A programmable button used to control the
VOX Enables or disables VOX feature for the selected
RADIO OVERVIEW
Enables or disables scrambling feature for the selected channel.
audio level. The button emits a continuous tone to indicate the current volume level. To change volume level, turn the volume knob to the desired level while pressing the programmable button.
channel.
The default functions assigned to your radio are described in the table below.
Press
Typ e
Short Press
Long Press
Side
Button 1
Unassign Unassign Monitor Scan Power
Unassign Unassign Sticky
Side
Button 2
Front
Button
1
Monitor
Front
Button 2
Nuisance
Channel
Delete
Front
Button 3
Level
Unassign
If your dealer has re-programmed your radio’s programmable buttons, you may want to write down the new functions in the
table below.
English
Press
Typ e
Short Press
Long Press
6
Side
Button 1
Side
Button 2
Front
Button 1
Front
Button 2
Front
Button
3
English

GETTING STARTED

Attaching and Removing the Antenna

To Attach Antenna
1. Fasten the antenna to the radio by placing the threaded end of the antenna into the Antenna Connector.
2. Rotate the antenna clockwise until tight.
Threaded End
of Antenna
CP185
Antenna Connector
To Remove Antenna
1. Turn the antenna in a counter-clockwise direction until it disengages from the radio.
7
GETTING STARTED
English

Attaching and Removing the Battery To Attach Battery

GETTING STARTED
Grooves
1. Fit the battery slots with the grooves on the radio.
2. Slide the battery upwards until a click is heard.
To Remove Battery
1. Slide the battery latch away from the radio.
2. Slide the battery downwards.
3. Pull the battery away from the radio.
Battery Latch
Battery Slots
English
8

Attaching and Removing the Belt Clip

Release Tab
To Attach Belt Clip
1. Align mounting rails of the belt clip with the grooves of the radio.
Mounting Grooves
2. Slide the belt clip downwards until it clicks into place.
To Remove Belt Clip
1. Safely insert a flat tool between the release tab and the back surface of the radio.
2. Lift the release tab.
GETTING STARTED
3. Slide the belt clip upwards.
9
English

Charging the Battery

CP185
GETTING STARTED
1. Make sure radio is OFF.
2. Plug the power supply into an electric outlet.
3. Connect the power supply output cord connector into the rear of the Desktop Changing Tray.,
5. Turn the radio OFF before charging the battery. Insert a battery, or a radio with a battery into the charger’s pocket by:
a) Aligning the groove on each side of the battery with the corresponding raised rail on each side of the charger pocket OR b) Pressing the battery towards the rear of the pocket OR c) Sliding the battery into the charger pocket, ensuring complete contact between the charger and battery contacts.
6. The charger’s LED color will indicate the battery charging status. (See “Charging Status” on page 11).
Refer to picture below for the battery insert visual guide line.
Battery insert visual guide line
4. The LED on the charger blinks green once to indicate charger is turned ON.
English
10
LED Color Charging Status
Solid Red Charging
Blinking Red Battery Fault
Solid Green Charge Complete
Blinking Green Trickle Charging
Single Green Blink Power On
Blinking Yellow Waiting to Charge
Note: To get maximum use from a new battery, charge it
overnight (12 to 16 hours) before using the battery for the first time. The typical time needed to completely charge the discharged battery is estimated within 2.5 to 5 hours depending on its cell chemistry. Once the charger LED
turns solid green, the charging process is done.
GETTING STARTED
11
English

SCAN

Scan allows you to monitor multiple channels and receive calls that are transmitted on them.
If your radio has switched to a non-priority channel during priority scan, it still checks for activity on the priority channel. If activity is detected there, the radio switches to the priority channel.
Two types of scan are supported: Normal Scan and Priority Scan. Normal Scan searches all channels sequentially in the radio’s scan list, whereas Priority Scan allocates 50% of the scanning time to the Priority Channel (the first channel in the designated scan list).
Start
Start
Ch. 1
Ch. 2
Home
Ch. 2
Ch. 3
Normal Scan
Ch. 16
Ch. 1
Ch. 4
Ch. 15
Ch. 3
Priority Scan
Ch. 1
Home
SCAN
During scan, when activity is detected that meets the
Channel 1 Prioritized
Ch. 1
Ch. 16
unsquelch condition, the radio stops scanning and switches to that channel; the G indicator is illuminated, and the channel number is displayed. When no activity is detected for a pre-set time, the radio resumes scanning.
Ch. 14
Ch. 1
The radio transmits on the Home Channel, if PTT is pressed during scanning. If the radio stops scanning, and changes to a particular channel, all transmit and receive activity is performed on that channel.
• Press the Scan button to begin channel scanning. The G
indicator blinks to indicate that the radio is scanning. The LCD Screen shows the Home Channel where the scan began.
• Press Scan button to stop scanning.

Deleting a Nuisance Scan Channel

A channel with unwanted activity is called a Nuisance Channel. You can remove a Nuisance Channel from the scan list temporarily. To remove a Nuisance Channel
• Press the Nuisance Channel Delete programmable button, when your radio stops on a Nuisance Channel. A high­pitched tone is heard.
You cannot remove the Home or Priority Channel from the scan list. If attempted, a low-pitched tone is heard, and no action is taken.
To reinstate the deleted channel(s) into the scan list, restart scan, or simply turn off your radio and turn it on again.
English
12

VOICE OPERATED TRANSMIT (VOX)

When the VOX headset/microphone is connected, your radio may be used in hands-free operation.
To start the VOX feature:

1. Connect the VOX headset to the accessory connector of the radio. Make sure the radio is turned OFF before connecting the VOX accessory.

2. Turn the radio ON.

To disable the VOX feature:

1. Press the PTT button on the radio. This allows you to use the VOX headset, but you must press the radio PTT to transmit.

To re-enable the VOX feature:

1. Turn the radio OFF, and turn it ON again, with the headset connected to the accessory connector, or

2. Change channel with the VOX headset connected.

To adjust the VOX sensitivity level, see “ACCESORY (Accessory)” on page 17 of this user guide.
VOICE OPERATED TRANSMIT (VOX)
13
English

VOICE INVERSION SCRAMBLING

Your radio has the Voice Inversion Scrambling feature which gives you an extra layer of privacy. This scrambling function is implemented via a frequency inversion in analog mode using two standard codes (3.29 KHz and 3.39 KHz).
To Enable and Disable the Scrambling Mode
Configure one of the programmable buttons for Scrambling Mode. Press this button to enable or disable the function. You can also configure this function via the Front Panel Programming Mode ("Front Panel Programming Mode" Menu on page 15).
To Change the Scrambling Code
Configure one of the programmable buttons for Scrambling Code. Press this button to toggle between the two codes. You can also configure this function via the Front Panel Programming Mode ("Front Panel Programming Mode" Menu on page 15).
VOICE INVERSION SCRAMBLING
English
14

FRONT PANEL PROGRAMMING MODE

Assessing Front Panel Programming Mode Parameters

This mode allows you to change the feature parameters to enhance the use of your radio.
Note: This feature is only supported by certain models.

Entering Front Panel Programming Mode

If your radio is turned ON, turn it OFF. Press and hold the side programmable button 1, and turn your radio ON. A tone is heard, indicating that your radio is in Programming Mode. The
indicator illuminates and the “BCKLIGHT” is displayed on
the radio LCD.

Exiting Front Panel Programming Mode

Turn the radio OFF to exit Programming Mode.
Press the or to scroll through the parameters for each menu or sub-menu item, or
Press the PTT button to select menu or sub-menu item, or
Press side programmable button 1 to return to previous menu
level or to exit the selection parameter without change.
PROGRAMMING MODE
FRONT PANEL
15
English
Main Menu
1st Level
Sub-Menu
2nd Level
Sub-Menu
Setting Remarks
BCKLIGHT (Backlight)
BATTERY SAVER
(Battery Saver)
TYPE (Battery Type)
AUTO TOGGLE
OFF NORMAL ENHANCED
NIMH (Nickel Metal Hydride) LI-ION (Lithium-Ion) H LI-ION (High Capacity Lithium- Ion)
Selecting AUTO causes the backlight to automatically extinguish, if there is no keypress for more than 5 seconds. Pressing the Backlight button again prolongs illumination time. Selecting TOGGLE allows the Backlight button toggle to control the ON/OFF status of the backlight.
Helps to extend the battery life. When enabled, it turns off radio receiver circuitry periodically when no activity is detected. NORMAL – turns off the receiver less frequently. ENHANCED – turns off the receiver for a longer duration to maximize battery saving.
Selects the type of battery that the radio uses.
FRONT PANEL
PROGRAMMING MODE
English
16
Main Menu
1st Level
Sub-Menu
2nd Level
Sub-Menu
Setting Remarks
ACCESORY (Accessory)
TONE VOL (Alert Tone Volume)
SPK GAIN (External Speaker Gain)
MIC GAIN (External Microphone Gain)
+2 +1 0
-1
-2
+2 +1 0
-1
-2
ON OFF
Allows you to adjust the external speaker loudness when accessories are connected to radio. +2 will set the external speaker gain to maximum level and -2 will set the external speaker gain to minimum level.
Allows you to adjust the external microphone sensitivity when accessories are connected to radio. +2 will set the external microphone sensitivity to maximum level and -2 will set the external microphone sensitivity to minimum level.
Selects the alert tone volume preference. Select OFF, if quiet operation is required. Select ON, if working in a noisy environment.
PROGRAMMING MODE
FRONT PANEL
17
English
Main
Menu
CHANNEL
FRONT PANEL
1st Level
Sub-Menu
RX PL (Receive TPL/ DPL)
TX PL (Transmit TPL/ DPL)
SQUELCH (Squelch Level)
TIME OUT (Time Out Timer)
2nd Level
Sub-Menu
CH-001 … CH-099
CH-001 … CH-099
CH-001... CH-099
Settings Remarks
CSQ (Carrier Squelch) TPL 067.0… TPL 254.1 TPL1 TPL2 TPL3 DPL 023… DPL 754
CSQ (Carrier Squelch) TPL 067.0… TPL 254.1 DPL 023… DPL 754 TPL1 TPL2 TPL3
NORMAL TIGHT
OFF 010 020 ... 590 600
This is the TPL or DPL code that the channel will use to unsquelch the received signal. CSQ indicates that radio operates in carrier squelch mode. Press Left Arrow Button or Right Arrow Button to select the desired TPL/DPL.
This is the TPL or DPL code that the channel will use to transmit. CSQ indicates that radio operates in carrier squelch mode. Press Left Arrow Button or Right Arrow Button to select the desired TPL/ DPL.
NORMAL squelch level allows the radio to receive weak signals. TIGHT squelch level allows the radio to receive strong signals and eliminates unwanted noise.
This determines the maximum duration (in seconds) that the radio can transmit continuously.
PROGRAMMING MODE
English
18
Main
Menu
CHANNEL (Cont’d)
SCAN LIST 1
(*) Applicable to Keypad Models only.
1st Level
Sub-Menu
PRIME CH (Prime Channel)
(Scan List 1)
LIST SEL (Scan List Select)
SCAN TYP (Scan Type Select)
PRIORITY (Priority Channel Select)
2nd Level
Sub-Menu
01-XXX 02-XXX … 15-XXX 16-XXX
CH-001 … CH-099
CH-001 … CH-099
LIST1 (Scan List 1)
Settings Remarks
OFF
001... 099
_ _ _ 001 … 099
LIST1 (Scan List 1) Allows you to set the scan list for a selected channel.
NORMAL PRIORITY
_ _ _ ... XXX
The channel that you wish to spend most of your time monitoring. The radio will always switch back to the Prime Channel if it is idle for more than the preprogrammed hang-time in other channels. .
Allows you to set scan list 1 members. “XXX “denotes the selected scan
list member. "_ _ _" shows that no scan list member is selected.
User can use the button or the button to scroll the
valid channel list and press PTT to set the selection.
Allows you to set scan type either Normal Scan or Priority Scan for a selected channel.
Allows you to set priority channel for scan list 1. XXX denotes the selected priority channel. "_ _ _" shows that no priority channel is selected. User can also use the button or the button to scroll the valid channel list and press PTT to set the selection.
PROGRAMMING MODE
FRONT PANEL
19
English
Notes:
FRONT PANEL
PROGRAMMING MODE
English
20

TPL AND DPL FREQUENCIES AND CODES

The following information in the tables are to guide the user to select the appropriate TPL (Tone Private Line) or DPL (Digital Private Line) codes so that they can expand usage of the frequency.

TPL Frequency

Table 1: TPL Frequency
TPL Freq (Hz)
67.0 XZ 001
69.3 WZ 002
71.9 XA 003
74.4 WA 004
77.0 XB 005
79.7 WB 006
82.5 YZ 007
85.4 YA 008
88.5 YB 009
91.5 ZZ 010
94.8 ZA 011
Equivalent PL
Code
Motorola Code
Table 1: TPL Frequency
TPL Freq (Hz)
97.4 ZB 012
100.0 1Z 013
103.5 1A 014
107.2 1B 015
110.9 2Z 016
114.8 2A 017
118.8 2B 018
123.0 3Z 019
127.3 3A 020
131.8 3B 021
136.5 4Z 022
141.3 4A 023
146.2 4B 024
151.4 5Z 025
156.7 5A 026
162.2 5B 027
167.9 6Z 028
173.8 6A 029
179.9 6B 030
Equivalent PL
Code
TPL AND DPL FREQUENCIES
Motorola Code
AND CODES
21
English
Table 1: TPL Frequency
TPL Freq (Hz)
186.2 7Z 031
192.8 7A 032
203.5 M1 033
AND CODES
TPL AND DPL FREQUENCIES
206.5 8Z 034
210.7 M2 035
218.1 M3 036
225.7 M4 037
229.1 9Z 038
233.6* M5 039
241.8 M6 040
250.3 M7 041
254.1* 0Z 042
TPL1*
TPL2*
TPL 3*
Equivalent PL
Code
Motorola Code
Note: The TPL Frequencies marked with an asterisk (*) are
not part of the 39 standard EIA/TIA-603 CTCSS Code Frequency.
TPL1
TPL2
TPL3
English
22

DPL Codes

Table 2: DPL Codes
TPL AND DPL FREQUENCIES
Table 2: DPL Codes
DPL Code Motorola Code
023 043
025 044
026 045
031 046
032 047
043 048
047 049
051 050
054 051
065 052
071 053
072 054
073 055
074 056
114 057
115 058
116 059
DPL Code Motorola Code
125 060
131 061
132 062
134 063
143 064
152 065
155 066
156 067
162 068
165 069
172 070
174 071
205 072
223 073
226 074
243 075
244 076
245 077
AND CODES
23
English
Table 2: DPL Codes
Table 2: DPL Codes
DPL Code Motorola Code
AND CODES
TPL AND DPL FREQUENCIES
251 078
261 079
263 080
265 081
271 082
306 083
311 084
315 085
331 086
343 087
346 088
351 089
364 090
365 091
371 092
411 093
412 094
413 095
DPL Code Motorola Code
423 096
431 097
432 098
445 099
464 100
465 101
466 102
503 103
506 104
516 105
525(*) 106
532 107
546 108
565 109
606 110
612 111
624 112
627 113
English
24
Table 2: DPL Codes
DPL Code Motorola Code
TPL AND DPL FREQUENCIES
631 114
632 115
645(*) 116
654 117
662 118
664 119
703 120
712 121
723 122
731 123
732 124
734 125
743 126
754 127
Note: The codes marked with an asterisk (*) are not part
of the 83 standard EIA/TIA-603 codes.
AND CODES
25
English
WARRANTY
MOTOROLA LIMITED WARRANTY FOR
THE UNITED STATES AND CANADA
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its telephones, pagers, and consumer and business two-way radios (excluding commercial, government or industrial radios) that operate via Family Radio Service or General Mobile Radio Service, Motorola-branded or certified accessories sold for use with these Products (“Accessories”) and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below.
This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories and Software purchased by consumers in the United States, which are accompanied by this written warranty.
Products and Accessories
Products
Covered
Products and Accessories as defined
above, unless otherwise provided for below.
Decorative Accessories and Cases.
Decorative covers, bezels, PhoneWrap™ covers and cases.
Business Two-way Radio Accessories
Products and Accessories that are Repaired or Replaced.
Length of Coverage
One (1) year from the date of
purchase by the first consumer purchaser of the product unless otherwise provided for below.
Limited lifetime warranty for the lifetime of ownership by the first consumer purchaser of the product.
One (1) year from the date of purchase by the first consumer purchaser of the product.
The balance of the original warranty or for ninety (90) days
from the date returned to the consumer, whichever is longer.
English
26
Exclusions
Normal Wear and Tear. Periodic maintenance, repair
and replacement of parts due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty. Abuse & Misuse. Defects or damage that result from: (a) improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories. Defects or damage that result from the use of Non­Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded form coverage.
WARRANTY
27
English
WARRANTY
Communication Services. Defects, damages, or the
failure of Products, Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.
Software
Products Covered Length of Coverage
Software. Applies
only to physical defects in the media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).
Ninety (90) days from the date of purchase.
Exclusions
Software Embodied in Physical Media. No warranty
is made that the software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media. Software that is not embodied in physical media (e.g. software that is downloaded from the internet), is provided “as is” and without warranty.
WHO IS COVERED?
This warranty extends only to the first consumer purchaser, and is not transferable.
HOW TO OBTAIN WARRANTY SERVICE OR OTHER INFORMATION?
Contact your Motorola point of purchase.
English
28
SOFTWARE COPYRIGHT NOTICE
The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law.
Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.
PATENT NOTICE
This product is covered by one or more of the following United States patents.
5896277 5894292 5864752 5699006 5742484 D408396 D399821 D387758 D389158 5894592 5893027 5789098 5734975 5861850 D395882 D383745 D389827 D389139 5929825 5926514 5953640 6071640 D413022 D416252 D416893 D433001
EXPORT LAW ASSURANCES
This product is controlled under the export regulations of the United States of America. The Governments of the United States of America may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce.
WARRANTY
29
English
WARRANTY
Notes:
English
30

ACCESSORIES

BATTERIES
The following accessories parts are compatible with model number CP185.
ANTENNAS
Motorola Part
Number
NAD6502_R VHF Heliflex Antenna, 146 – 174 Mhz
PMAD4049_ VHF Helical Antenna, 146 – 174 MHz
NAE6483_R UHF Whip Antenna, 403 – 520 MHz
(16.5 cm)
NAE6522_R UHF Stubby Antenna, 438 – 470 MHz
(7.5 cm)
PMAE4016_ UHF Whip Antenna, 403 – 520 MHz
Description
Motorola Part
Number
PMNN4080_ Li-Ion High Capacity – 2150mAh: 14hrs
talktime @ 5-5-90 at High Power
PMNN4081_ Li-Ion – 1500mAh: 10hrs talktime @
5-5-90 at High Power
PMNN4082_ NiMH – 1300mAh: 8hrs talktime @
5-5-90 at High Power
Description
ACCESSORIES
31
English
CHARGERS AND POWER ADAPTERS
Motorola Part
Number
PMLN5228_ Tri-Chem Single Unit Charger Base
PMLN5398_ Single Unit Charger Base with US 2-Pin
Switch Mode Power Supply
2571586S14 110V, 10.8W Linear Power Supply with
North America / Latin America country plug
EPNN9288_ 90 – 264V, Switch Mode Power Supply
with North America /Latin America country plug
Description
ACCESSORIES
AUDIO ACCESSORIES
Motorola Part
Number
MAG ONE Branded
PMLN4442_ Earbud with In-Line Microphone / PTT /
VOX Switch (MagOne)
PMLN4443_ Ear Receiver with In-Line Microphone /
PTT / VOX Switch (MagOne)
PMLN4444_ Earset with Boom Microphone and In-Line
PTT/VOX Switch (MagOne)
PMLN4445_ Ultra-Light Headset with Boom Microphone
and In-Line PTT/VOX Switch (MagOne)
PMMN4008_ Remote Speaker Microphone (MagOne)
MOTOROLA Branded
HMN9013_ Lightweight Single Muff Adjustable
Headset with Swivel Boom Microphone
HMN9754_ 2-Piece Surveillance Kit, with Microphone
and PTT Combined, Beige (2-wire – Rubber Eartip Style)
PMLN4606_ 2-wire earpiece with clear acoustic tube
(consisting of PMLN4605 & PMLN4294)
PMLN4620_ Receive Only D-Style Earpiece (for
PMMN4013 Remote Speaker Microphone)
PMLN5001_ D-Style Earpiece with Microphone / PTT
PMLN5003_ Retail Temple Transducer Headset
Description
English
32
AUDIO ACCESSORIES
Motorola Part
Number
MOTOROLA Branded
PMMN4001_ Earset with Microphone and PTT
PMMN4013_ Remote Speaker Microphone with Ear
Jack
PMMN4029_ Remote Speaker Microphone with IP57
Rating
RLN6230_ High Noise Kit, Black (Includes Foam
Earplugs with Acoustic Tube)
RLN6231_ High Noise Kit, Beige (Includes Foam
Earplugs with Acoustic Tube)
RLN6232_ Low Noise Kit, Black (Includes Rubber Tip
with Acoustic Tube)
RLN6241_ Low Noise Kit, Beige (Includes Rubber Tip
with Acoustic Tube)
RLN6242_ Quick Disconnect Acoustic Tube
RLN4941_ Receive Only Earpiece with Translucent
Tube (for PMMN4013 Remote Speaker Microphone)
WADN4190_ Receive Only Flexible Earpiece (for
PMMN4013 Remote Speaker Microphone)
AARLN4885_ Receive Only Earbud (for PMMN4013
Remote Speaker Microphone)
Description
MISCELLANEOUS
Motorola Part
Number
HLN9844_ Spring Action Belt Clip (2 inch)
PMLN5334_ Protective Leather Case
Note: Certain accessories may be or may not be available at the
time of purchase. For latest information on accessories, contact your Motorola point of purchase or visit: http://www.motorola.com/governmentandenterprise.
Description
ACCESSORIES
33
English

Notes:

ACCESSORIES
English
34
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © 2008 by Motorola, Inc. All rights reserved.
*6878080A01*
6878080A01-A
Loading...
