Motorola 89419n User Manual

HZ800

Contents

Congratulations Your headset Charge it Basics Pair & connect Be clear Calls Talk time Status light Settings Problems? Safety, Regulatory & Legal

2 3 4 5 10 13 14 15 16 17 18 21

Congratulations

Your Motorola Finiti™ headset delivers the best sound in any condition and Without raising your voice. CrystalTalk™ dual microphones are used for everyday noise cancellation, and the stealth mode for windy or extreme conditions.

Some other cool features:

• Hear and reply to phone text messages with MotoSpeak™.

• Hear the caller’s name and use your voice to answer or ignore calls.

• Stream Bluetooth® music from your phone.

• Voice prompts to guide you on connections, battery level, and other functions.

• Simultaneous connect with two phones.

We’ve crammed all of the main features of your headset into this handy guide, and in a matter of minutes we’ll show you just how easy your headset is to use.

So go on, check it out.

more information

on the Web: www.motorola.com/support

Caution: Before using your headset for the rst time, please read the important Safety, Regulatory & Legal information at the back of this guide (page 21).

Your headset

the important parts

Button

MicroUSB

Charging

Warning:Do not apply pressure or squeeze the stealth mode sensor (sm all

rubber balloon), as it can damage the parts inside and will void the warranty.

Connector

Call

side view

Volume

Buttons

Loop

Status

Light

the

Stealth

Mode

Button

Ear

Power

Switch

Earpiece with the Stealth Mode Sensor

Earhook

Charge it

let’s get you up and running

Status Light

Red/Yellow - charging Green - fully charged

While your headset is charging, you won’t be able to use it.

Note: Your battery is designed to last the life of your product. It should only be removed by a recycling facility. Any attempt to remove or replace your battery will damage your headset.

Basics

a few essentials to get you started

Change ear tting

Your headset comes with multiple ear ttings.

Left

Right

Large

Medium

Ear

Spring

Ear

Loop

Choose your ear tting (loop or spring) so

your headset is comfortable.

Lift the current ear tting up and slide it off the headset

in an upward direction.

Ear

Loop

Small

Ear

Loop

Basics

Slide the new ear loop or spring downward onto the earpiece, then align and push the bottom onto the groove.

Wear it

Bend the ear loop or spring and insert the earpiece into your ear. Make sure the stealth mode sensor is in contact with your ear canal.

Place the ear loop or spring in the bend of your ear.

Groove

the Stealth mode sensor

Ear canal

Basics

Flex the earhook and loop it over your ear, and point the headset microphone towards your mouth.

Turn it on & off

Listen to music

Note: This feature is phone dependent.

Your heads et allows you to stream Bluetooth music from your phon e. Music playback is started and controlled from your phone.

Basics

While a call is active, music pauses. When the call ends, music resumes playing.

Enhanced call features

Tell headset to answer or ignore calls Use your voice to answer or ignore an incoming call:

• say “answer” to answer the call

• say “ignore” to ignore the call

Note: This feature does not work for second incoming calls.

Hear caller’s name

If your phone knows your caller’s name, then you hear “call from <name>” on an incoming call.

Basics

Clean your headset

Keep your headset clean and dry. High humidity or perspiration can make the ear

tting feel slippery. Remove the ear tting and wipe it with a soft cloth to remove

dirt and moisture.

Note: Be very careful when wiping near the stealth mode sensor.

Also check for any debris that may be blocking the small speaker port on the ear

tting.

Pair & connect

connect and go

Pair & connect with your phone

Turn off any Bluetooth® devices previously paired with your headset. Turn on the Bluetooth feature on your phone. Put the headset on your ear (see “Wear it” on page 6). Turn on your headset (see “Turn it on & off” on page 7). The status light becomes steadily lit in blue and you hear “ready to pair”. Follow the voice prompts to connect your phone to your headset. Note: When prompted for the passkey, enter 0000.

When your headset successfully pairs with your phone, you hear “pairing complete”.

For daily use, make sure your headset is turned on, and your phone’s Bluetooth feature is on. Your headset and phone connect automatically.

Pair & connect

Pair & connect a second phone

Turn off rst phone and any other Bluetooth devices previously paired

with your headset. Turn your headset off. Turn on the Bluetooth feature on your phone. Put the headset on your ear. Turn on your headset. The status light becomes steadily lit in blue and you hear “ready to pair”. Follow the voice prompts to connect your phone to your headset. Note: When prompted for the passkey, enter 0000.

When your headset successfully pairs with your phone, you hear “pairing complete”.

To connect to both phones, turn on the rst phone while the second phone

is connected. When you hear “<phone 1 name> connected”, your headset is connected to both phones.

Pair & connect

Test your call connection

Place the headset on your ear. On your phone, dial a phone number and press the Call/Send key.

If your phone and headset are successfully connected, you hear ringing on the headset.

Be clear

your voice, not all the noise

Always be heard during calls with the CrystalTalk dual microphones and the stealth mode sensor:

• CrystalTalk is always on to cancel out everyday background noise.

• The stealth mode can be turned on when noise and wind get really bad to shut out all background noise.

Turn on the stealth mode

Press the Stealth Mode button and listen for the “stealth mode on” or “stealth mode off” prompt.

Note: Make sure the stealth mode sensor is placed correctly and is in contact with the ear canal (see page 6). It is normal for the sound of your voice to be less “natural” in the stealth mode.

the Stealth Mode Button

Calls

it’s good to talk

Note: Some features are phone/network dependent.

To...

answer call

reject call

make a voice dial call

redial last call

mute or unmute a call

end a call

Answer second incoming call

Reject second incoming call turn on/off stealth mode

Tip: When connected to two phones, follow the voice prompts to perform functions such as voice dial, redial, and end call on the desired phone.

Say “answer” or press the Call button. Say “ignore” or press and hold a Volume button until you hear a tone. Press the Call button and you hear a tone.

Press and hold the Call button until you hear a tone.

Press both Volume buttons.

Press the Call button.

Press and hold a Volume button until you hear a tone. Press the stealth mode button.

Talk time

check your chat time

Press both Volume buttons while not on a call.

if light shows... and/or you hear…

red “battery level is low"

yellow “battery level is medium"

green “battery level is high”

To save battery power, turn off the headset when not using it.

your remaining talk time is..

less than 1.5 hours

between 1.5 to 3.5 hours

more than 3.5 hours

Status light

know your headset

If light shows...

three blue ashes

steady blue

rapid blue/purple ashes quick blue ash quick purple ash

slow blue pulse

slow blue ash slow green ash slow red ash

slow purple pulse steady red

quick red ash

Note: After 1 minute on a call or 20 minutes of inactivity, the light stops ashing to

conserve power, but the headset remains on.

your headset is...

powering on/off in pairing/connect mode connecting to your phone receiving or making a call on phone 1 receiving or making a call on phone 2 on a call in standby (not on a call—connected to one phone) in standby (not on a call—connected to two phones) idle (not connected to a phone) muting the call trying to connect to your phone in a low battery state

Settings

make some changes

Press and hold the Call button while turning on the headset to turn these features on/off:

• Reset to factory default Caution: This action erases all pairing information stored in your headset.

• Caller ID

• Voice prompts

• Multipoint (two phone) connections

Follow the voice prompts to make changes to these settings.

Problems?

we’ve got solutions

My headset will not enter pairing mode

Make sure that any devices previously paired with the headset are turned off. If the status light is not steadily lit in blue, turn off both the other device and headset, wait 10 seconds, then turn headset back on. Wait for the status light to become steadily lit in blue, indicating the headset is now in pairing mode.

My phone doesn't nd my headset when searching.

Make sure the status light on your headset is steadily lit in blue when your phone is searching for devices. If not, press and hold the Call button and both Volume buttons until you hear “ready to pair” and see the status light steadily lit in blue.

My headset worked before but now it's not working

Make sure your phone is on and the Bluetooth feature is turned on in your phone.

Problems?

If the Bluetooth feature was turned off or was turned on only temporarily, you may need to restart the Bluetooth feature and pair your phone and headset again (see “Pair & connect” on page 10).

The person you are talking to does not hear you

Try rotating the headset in your ear. Or, you can switch to another ear tting to provide a better t.

The person you are talking to does not hear you in stealth mode

Make sure the ear tting is clean and dry (see “Clean your headset” on page 9).

Support

we’re here to help

If you have questions or need assistance, contact us at 1-877-MOTOBLU, or

visi t us at www.motorola.com/Bl ueto othsupport or www.motorola.com/

bluetoothconnect.

Safety, Regulatory & Legal

Safety & General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR DEVICE.

Use & Safety for Battery-Powered Accessories

• Do not store or use your battery-powered accessory (such as a Bluetooth® headset or other device) in temperatures below -10°C (14°F) or above 60°C (140°F).

• Do not recharge your accessory in temperatures below 0°C (32°F) or above 45°C (113°F).

• Conditions inside a parked car can exceed this range. Do not store your accessory in a parked car.

• Do not store your accessory in direct sunlight.

• Storing your fully charged accessory in high-temperature conditions may permanently reduce the life of the internal battery.

• Battery life may temporarily shorten in low-temperature conditions.

Approved Accessories

Use of accessories not ap pro ved by Motorola, including bu t not limited to batteries,antennas, and convertible covers, may cause your mobile device to exceed RF energy exposure guidel ines and may void your mobile device ’s warranty. For a list of approved Motorola accessories, visit our Web site at: www.

motorola.com.

Driving Precautions

Responsible and safe driving is your primary responsibility when behind the wheel of a vehicle. Using a mobile device or accessory for a call or other application while driving may cause distraction. Using a mobile device or accessory may be prohibited or restricted in certain areas, always obey the laws and regulations on the use of these products.

While driving, NEVER:

• Type or read texts.

• Enter or review written data.

• Surf the web.

• Input navigation information.

• Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

• Keep your eyes on the road.

• Use a handsfree device if available or required by law in your area.

• Enter destination information into a navigation device before driving.

• Use voice activated features (such as voice dial) and speaking features (such asaudible directions), if available.

• Obey all local laws and regulations for the use of mobile devices and accessoriesin the vehicle.

• End your call or other task if you cannot concentrate on driving. Responsible driving practices can be found at www.motorola.com/callsmart (in English only).

Caution About High Volume Usage

Warning: Exposure to loud noise from any source for extended

periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected.To protect your hearing:

• Limit the amount of time you use headsets or headphones at high volume.

• Avoid turning up the volume to block out noisy surroundings.

• Turn the volume down if you can’t hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or

fullness in your ears, ringing in your ears, or mufed speech, you should stop

list enin g to the device through your headset or headphones and have your hearing checked. For more information about hearing, see our Web site at direct.motorola.com/

hellomoto/nss/AcousticSafety.asp (in English only).

Small Children

Keep your mobile device and its accessories away from small children.

These produc ts are not toys and may be haza rdo us to small childr en. For example:

• A choking hazard may exist for small, detachable parts.

• Improper use could result in loud sounds, possibly causing hearing injury.

• Improperly handled batteries could overheat and cause a burn.

Symbol Key

Your battery, charger, or mobile device may contain symbols, dened as follows:

Symbol Denition

032374o

Important safety information follows.

032376o

Do not dispose of your battery or mobile device in a re.

Do not dispose of your battery or product with your household waste. See “Recycling” for more information.

For indoor use only.

European Union Directives Conformance Statement

Hereby, Motorola declares that this product is in compliance with:

The above gives an example of a typical Product Approval Number.

You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/

EC (to R&TTE Directive) at www.motorola.com/rtte. To nd your DoC, enter the Product Approval Number from your product’s label in the “Search” bar on the Web site.

• The essential requirements and other relevant provisions of

Directive 1999/5/EC

0168

• All other relevant EU Directives

Product Approval Number

FCC Notice to Users

The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID:xxxxxx on the product label.

Motorola has not approved any changes or modications to this device by the user. Any changes or modications could void the user’s authority to operate the

equipment. See 47 CFR Sec. 15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation. See 47 CFR Sec. 15.19(3).

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmfu l in ter ference to radi o co mmu nications. How ever, the re is no

guarant ee that in terfere nce will not occur in a partic ular ins tallati on. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Industry Canada Notice to Users

Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See RSS-GEN

7.1.5. This Class B digital apparatus complies with Canadian ICES-003.
