Page 1
Professional Radio
GP644
User Guide
6866542D03
Issue: April 2003
Page 2
9
10
6
1
7
2
8
3
4
5
Page 3
CONTENTS
RadioOverview .................... 3
Operation and Control Functions . . . . . . . . 3
Radio Controls . . . . . . . . . . . . . . . . . . . 3
Programmable Buttons . . . . . . . . . . . . . 4
Audio Signal Tones . . . . . . . . . . . . . . . . 5
GettingStarted..................... 7
Battery Information . . . . . . . . . . . . . . . . . . . 7
Battery Care and Tips . . . . . . . . . . . . . . 7
Recycling or Disposal of Batteries . . . . 8
Charging the Battery . . . . . . . . . . . . . . . 8
Accessory Information . . . . . . . . . . .... 9
Attaching the Battery . . . . . . . . . . . . . . . . . 9
Removing the Battery. . . . . . . . . . . . . . . . . 9
Attaching the Antenna . . . . . . . . . . . . . . . 10
Removing the Antenna. . . . . . . . . . . . . . . 10
RadioOperation................... 11
Turning the Radio On-Off. . . . . . . . . . . . . 11
Adjusting the Radio’s Volume . . . . . . . . . 11
Radio Registration . . . . . . . . . . . . . . . . . . 12
RadioCalls........................13
Making a Call . . . . . . . . . . . . . . . . . . . . . . . 13
Contact List . . . . . . . . . . . . . . . . . . . . . . . .13
User Absent. . . . . . . . . . . . . . . . . . . . . . . . 13
Dedicated Calls . . . . . . . . . . . . . . . . . . . . .14
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . 14
Cancelling a Call . . . . . . . . . . . . . . . . . . . .14
Receiving a Call. . . . . . . . . . . . . . . . . . . . .15
Receiving a Call on a OACSU System. . 15
Receiving a Call on a FOACSU System. 15
Missed Calls . . . . . . . . . . . . . . . . . . . . . . . 16
Call Diversion . . . . . . . . . . . . . . . . . . . . . . 17
Emergency Calls . . . . . . . . . . . . . . . . . . . .18
Personality........................19
MPT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Talkgroup. . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fixed and Dynamic Groups . . . . . . . . .20
Conventional Mode . . . . . . . . . . . . . . . . . .21
Personality Selection . . . . . . . . . . . . . . . . .22
CONTENTS
1
English
Page 4
CONTENTS
C
omputerSoftwareCopyright
The products described in this manual may include copyrighted computer
programmes stored in semiconductor memories or other media. Laws in the
United States of America and other countries preserve for Motorola Europe
and Motorola Inc. certain exclusive rights for copyrighted computer
programmes, including the right to copy or reproduce in any form the
copyrighted computer programme. Accordingly, any copyrighted computer
programmes contained in the products described in this manual may not be
copied or reproduced in any manner without the express written permission of
the holders of the rights. Furthermore, the purchase of these products shall not
be deemed to grant either directly or by implication, estoppel, or otherwise, any
licence under the copyrights, patents, or patent applications of the holders of
the rights, except for the normal non-exclusive royalty free licence to use that
arises by operation of the law in the sale of the product.
English
2
Page 5
RADIO OVERVIEW
This user guide covers the operation of the
GP644 Portable Radio.
Before using this radio, refer to the Product Safety
and RF Exposure booklet for Portable Two-way
Radios 6864117B25_ enclosed with your radio.
OPERATION AND CONTROL FUNCTIONS
Radio Controls
The numbers below refer to the illustrations on
the inside front cover.
1. Rotary Knob
Used as a multi-function scroll key and as a
channel selector in Conventional mode.
2. On-Off / Volume Knob
Used to turn the radio on or off, and to adjust
the radio’s volume.
3. Push to Talk Button (PTT)
Press and hold down this button to talk, release
it to listen.
4. Clear Button (Side Button 1)
Used to cancel a call, clear down at the end of
a call or Carrier Monitor (Conventional mode).
5. Side Button 2 (programmable)
Personality button, otherwise programmable.
6. Top Button (programmable)
Recommended as Emergency button.
7. LED Indicator
Green: Flashes to indicate NO SERVICE.
Red: On when radio is transmitting.
Red Flashing: When transmitting - battery low.
Green: On to indicate monitor mode active
(Conventional Mode).
Red Flashing: When receiving - channel busy
(Conventional Mode).
8. Microphone
9. Antenna
10. Accessory Connector
Connects headsets, remote speaker/microphones and other accessories. Replace
attached dust cap when not in use.
RADIO OVERVIEW
3
English
Page 6
Programmable Buttons
Several of your radio buttons can be
programmed (by your dealer) to activate the
radio features.
Feature Description
RADIO OVERVIEW
Dedicated Call/
Emergency
Personality
Missed Calls
The following table shows the features that can
be assigned to the Top button and Side Button 2.
To make a call to a pre-determined number. This can
be an emergency number, effectively activating an
Emergency Call.
To select one of two radio personalities, (e.g. MPT
trunking system or conventional system).
This will normally be Side Button 2.
To select the Missed Call list. This is a list of calls
received and stored by the radio when you were
unable to take the call.
English
4
Page 7
Audio Signal Tones (Normal Tones)
High pitched tone Low pitched tone
Tone Signal Description
Self test Power up.
Tone A Call clear indication.
Traffic channel
Tone B
Tone C1 System busy.
Tone C2 Unavailable.
Tone C3 Called party busy.
Tone C4 Invalid number.
Tone D
Tone F
Tone G
Tone H Invalid entry.
allocated or PTT/ Mic/
Loudspeaker enabled.
Call set up in progress,
wait for further
indications.
Transaction
confirmed, called unit
will call back.
Look at display for
call set up or
System information.
Tone Signal Description
Confidence tone when
Key click
Fail tone
Tone I Low battery warning.
Tone L1 1st Personality.
Tone L2 2nd Personality.
Tone M1 Talkgroup Confirmation.
Tone M2 Talkgroup unavailable.
Tone N1 Out of range alert.
Ring
tones
Standard/
English/French/
General
any key pressed or
speech limitation alert.
Hardware error or
Call timed out
(conventional mode).
Incoming call, press
PTT, then wait for
further indications.
RADIO OVERVIEW
5
English
Page 8
Audio Signal Tones (Alternative)
High to Low pitched tones
Tone Signal Description
Self test Power up.
Tone A Call clear indication.
RADIO OVERVIEW
Tone B
Tone C1 System busy.
Tone C2
Tone C3 Called party busy.
Tone C4 Invalid number.
Tone D
Tone F
Tone G
allocated or PTT/ Mic/
Loudspeaker enabled.
Call set up in progress,
confirmed, called unit
Look at display for
System information.
Traffic channel
Unavailable.
wait for further
indications.
Transaction
will call back.
call set up or
Tone Signal Description
Tone H Invalid entry.
Key click
Fail tone
Tone I Low battery warning.
Tone L1 1st Personality.
Tone L2 2nd Personality.
Tone M1 Talkgroup Confirmation.
Tone M2 Talkgroup unavailable.
Tone N1 Out of range alert.
Ring
tones
Standard/
English/French/
General
Confidence tone when
any key pressed or
Speech limitation alert.
Hardware error or
Call timed out
(conventional mode).
Incoming call, press
PTT, then wait for
further indications.
English
6
Page 9
GETTING STARTED
BATTERY INFORMATION
Battery Care and Tips
This product is powered by a nickel-metalhydride (NiMH) or lithium-ion rechargeable
battery.
The following battery tips will help you obtain the
highest performance and longest cycle life from
your Motorola rechargeable battery.
• Charge your new battery overnight (14-16 hrs)
before using it to obtain maximum battery
capacity and performance.
• Charging in non-Motorola equipment may lead
to battery damage and void the battery warranty.
• When charging a battery that is attached to the
radio, turn the radio off to ensure a full charge.
• The battery should be at about 25°C (room
temperature) whenever possible. Charging a
cold battery (below 10°C) may result in leakage
of electrolyte and ultimately, in failure of the
battery.
• Charging a hot battery (above 35°C) results in
reduced discharge capacity, affecting the
performance of the radio. Motorola rapid-rate
battery chargers contain a temperature-sensing
circuit to ensure that the battery is charged
within these temperature limits.
• New batteries can be stored up to two years
without significant cycle loss. Store new/unused
batteries in a cool dry area.
• Batteries which have been in storage should be
charged overnight.
• Do not return fully charged batteries to the
charger for an “extra boost”. This action will
significantly reduce cycle life.
• Do not leave your radio and battery in the
charger when not charging. Continuous charging
will shorten battery life. (Do not use your charger
as a radio stand.)
• For optimum battery life and operation use only
Motorola brand chargers. They were designed to
operate as an integrated energy system.
GETTING STARTED
7
English
Page 10
Recycling or Disposal of Batteries
Motorola endorses and encourages the recycling
of all re-chargeable batteries. Contact your local
Motorola dealer for further information.
Charging the Battery
If a battery is new, or its charge level is very low,
indicated by high pitched warning tones, you will
GETTING STARTED
need to charge the battery before you can use it
in your radio.
Note: Batteries are shipped uncharged from the
factory. New batteries could prematurely
indicate full charge, charge a new battery for
14-16 hrs before initial use.
Charger LED Status
Red Battery is charging
Green Battery is fully charged
Flashing Red * Battery is unchargeable
Flashing Yellow Charger is getting ready to charge
Flashing Green Battery is 90% charged
*
Battery is damaged. Please contact your dealer.
1. Place the radio with the battery attached, or the
battery alone, in the charger.
2. The charger’s LED indicates the charging
progress.
Battery chargers will charge only the Motorola
authorized batteries listed below; other
batteries will not charge
Part No. Description
.
English
JMNN4023
JMNN4024
JMNN4025
Lithium-Ion
Lithium-Ion High Capacity
NiMH Factory Mutual
8
Page 11
ACCESSORY INFORMATION
Attaching the Battery
Slots
GETTING STARTED
Removing the Battery
Battery
Latches
1. Fit the extensions at the bottom of the battery
into the slots at the bottom of the radio’s body.
2. Press the top part of the battery towards the
radio until you hear a click.
1. Turn off the radio, if it is turned on.
2. Slide the battery latches, on both sides of the
battery, downwards.
3. Pull the top part of the battery away from the
radio’s body, and remove the battery.
9
English
Page 12
Attaching the Antenna
GETTING STARTED
Removing the Antenna
1. Align the threaded end of the antenna with the
radio’s antenna connector.
2. Turn the antenna clockwise to fasten it.
English
10
1. Turn the antenna counterclockwise until you
can remove it.
Page 13
RADIO OPERATION
Turning The Radio On or Off
ON OFF
• To turn the radio on, turn the On-Off/Volume
Control knob clockwise.
• To turn the radio off, turn the On-Off/Volume
Control knob counterclockwise until you hear a
click.
Adjusting the Radio’s Volume
• Turn the On-Off/Volume Control knob to adjust
the volume level.
GETTING STARTED
11
English
Page 14
Radio Registration
When turned on, the radio enters a self test routine,
the self test tone will sound and the LED will light
green. If the radio fails the self test a continuous low
tone will sound until the radio is turned off .
Note: If the radio fails the self test routine, consult
your dealer.
When the self test is complete the radio will scan for
GETTING STARTED
system access with the LED on the top of the radio
flashing GREEN.
The radio personality will be the one last used prior
to the radio being switched off. To check the radio
personality or select a new personality refer to
PERSONALITY - Personality Selection.
When a system is acquired, the green LED will go
off.
English
12
Page 15
RADIO CALLS
Making a Call
The radio is capable of making a variety of
calls, including calls to individual radios,
groups of radios and calls to private and public
telephone systems.
Before you can make a call the radio must be
in the IDLE STATE, i.e. a personality has been
selected and no call is in progress.
The radio can make calls by using the Contact
List or Dedicated Calls.
Contact List
The contact list allows access to up to 16
preprogrammed numbers using the rotary
knob (1) when the radio is in the IDLE STATE.
Use the rotary knob to scroll through the list
and select the required number indicated on
base of the knob. Make the call by:
1 PTT button to make radio call.
The radio sends out its ID and sounds a tone.
2 After the call is set-up, press PTT button and
talk with your mouth 2.5-5 cm from microphone. Release PTT to listen.
3
When finished with call.
4 CLEAR BUTTON Tone A sounds
If a contact list number is selected but no call
request is sent, tone H sounds and the radio
reverts to the IDLE STATE.
User Absent
User Absent is a network feature which may be
enabled in your radio. With this feature
enabled, entry into the user absent mode is
automatic and any calls received when you are
away from your radio will be put into the
Missed Calls list automatically and the
message “Will call back” sent to the caller.
When you return to your radio, check whether
tone G sounds every 10 seconds which
indicates that your radio is in user absent
mode. Press any button to exit user absent
mode and return the radio to the idle state for
normal operation.
RADIO CALLS
13
English
Page 16
Dedicated Calls
Ending a Call
Dedicated calls can be made from a
preprogrammed Dedicated Call button. Press
the Dedicated Call button to make a call to a
commonly used pre- programmed number.
The call may also be programmed as an
Emergency call, Priority call or Status call.
RADIO CALLS
Always end a call by:
1 CLEAR BUTTON Tone A sounds
Cancelling a Call
At any time while setting up a call it may be
cancelled by
1 CLEAR BUTTON
:
Tone D or G
sounds
English
14
Page 17
Receiving A Call
There are two types of systems on which the
radio may be used, Off Air Call Set Up (OACSU)
and Full Off Air Call Set Up (FOACSU).
If you are in doubt about which system you are
operating on, please consult your dealer.
Receiving a call on an OACSU system
When the radio is called:
1 Tone D sounds LED flashes red. Call is
being set up
Receiving a call on an FOACSU system
When the radio is called:
1 Ringing tone sounds LED flashes red.
2 PTT button to accept call.
(Unless in talkgroup personality, when the
radio unmutes automatically for dynamic and
fixed group calls)
3 Tone D sounds LED flashes red. Call is
being set up
4 Tone B sounds
LED extinguished
RADIO CALLS
2 Tone B sounds
LED extinguished
Note: The system may have a limited call time and
the call may be terminated automatically if
this call time is exceeded.
15
English
Page 18
Missed Calls
If a call remains unanswered, the call will be
stored by the radio, provided that missed calls
has been programmed into your radio.
Only one call can be stored. If the same radio
calls more than once the call is only stored
once. When the call have been stored by the
RADIO CALLS
radio, any further calls received overwrite the
stored call.
When a call has been stored by the radio, tone
G will sound every ten seconds.
The Missed Call List is entered directly by
pressing the Missed Call button when the radio
is in the IDLE STATE.
You can call back to the number in the Missed
Call list by:
1 PTT button to make the call.
The radio sends out its ID and sounds a tone.
2 After the call is set-up, press PTT button and
talk with your mouth 2.5-5 cm from microphone. Release PTT to listen.
On a successful call set- up, the entry is
automatically deleted from the stack and the
radio returns to the IDLE STATE.
An unanswered call may be deleted from the
Missed Call list at any time by:
1
Press MISSED CALL button to enter list
2 Press CLEAR button to delete entry in list
Radio returns to IDLE STATE
Note: The calls in the Missed Call list are not
deleted when the radio is turned off. It is not
possible to call back status calls.
3 CLEAR BUTTON Tone A sounds
English
16
Page 19
Call Diversion
Incoming speech calls or status calls can be
diverted from your radio or to your radio.
Call diversion and cancellation may be
programmed into the Contact List. Please
contact your network manager or dealer for
further information.
RADIO CALLS
17
English
Page 20
Emergency Calls
An emergency call allows you the highest form
of priority calling and normally takes
precedence over all other calls.
Your radio can be programmed to give you a
one-button quick access to call a particular
radio or centre (predefined by your dealer) in
RADIO CALLS
emergency situations.
To initiate an emergency call:
Emergency can be stopped by one of the
following:
1 Switching the radio Off and On again.
2 Pressing the CLEAR button.
3 The emergency time duration is reached.
Note: The emergency time duration is
programmed into your radio by your dealer.
1 Press the Emergency button
English
18
Your radio may receive an emergency call
when:
Tone D or Ring Tone Ring Tone will sound
depending on your system
Page 21
PERSONALITY
The personalities described below are
programmed into your radio by your dealer and
are accessible via the personality button.
A radio personality contains data such as
frequencies, alert tones, permitted calls etc.
which determines the operation of your radio.
Your radio may be programmed with up to 2
different personalities, selected from MPT,
Talkgroup Select and Conventional.
MPT
This personality permits the radio to operate in
a trunked mode. Incoming and outgoing calls
are set up using a defined set of rules or
protocol between your radio and a controller in
a similar manner to your home telephone. Your
radio ‘registers’ onto an MPT trunked system
as described in GETTING STARTED - Radio
Registration.
PERSONALITY
19
English
Page 22
Talkgroup
Talkgroup is an MPT personality following the
same rules or protocol, but is primarily for
talkgroup calls. In talkgroup personality,
talkgroups are contained in a Talkgroup list,
similar to the Contact list, which is scrolled and
selected using the Rotary Knob (1).
PERSONALITY
On selection of a talkgroup, you may send and
receive calls as described below.
Fixed and Dynamic Groups
These groups form part of the Talkgroup
Personality, such that when this personality is
selected your talkgroup list shows only these
groups.
A fixed group is a group of users, the address
(number/alias) of which is preprogrammed into
your radio by your dealer.
A dynamic group is a group of users, the
address (number) of which is sent to your radio
‘over air’ at any time via the system controller.
Therefore at any time you may become a
member of a dynamic group, able to receive
calls and (depending on how your radio is
programmed) send calls to that group.
Incoming calls to fixed and dynamic group
numbers are detailed in Receiving a Call.
To make an outgoing call to a selected
talkgroup, press the PTT and speak after the
confidence tone.
Calls are cleared in the normal manner.
If the system is busy an engaged tone will be
heard, release the PTT and wait for the
confidence tone. You may then proceed with
the call by pressing the PTT.
English
20
Page 23
Conventional Mode
In the conventional mode your radio operates
as a standard two-way radio.
Select the personality number which
corresponds to Conventional mode as
described in Personality Selection.
Use the rotary knob (1) to select the desired
channel.
Prior to transmission always make sure that
the channel is free (red LED not flashing).
Press the PTT (4) to transmit, release to listen.
The red LED lights while the radio transmits
and flashes if the channel is busy.
Some channels may be monitored for activity
by pressing the Clear button (3).
In the conventional mode, the radio is
equipped with a time out timer. A speech
limitation alert tone will sound a few seconds
before the transmitter in your radio is switched
off. The call timed out tone will sound and
continue until the PTT is released.
PERSONALITY
21
English
Page 24
Personality Selection
To change the personality:
Your radio may be programmed with two
different personalities, known as Personality 1
and Personality 2.
The personalities programmed may be any of
MPT, Talkgroup or Conventional.
Check with your system manager or dealer for
PERSONALITY
the personalities in your radio.
To check the current personality:
1 Ensure radio is in IDLE STATE.
2
Press Personality button (5)
3 If Personality 1: Tone L1 sounds.
4 If Personality 2: Tone L2 sounds.
1 Ensure radio is in IDLE STATE.
2 Press Personality button (5) for longer than 3
seconds
3 If the current person-
ality is Personality 1:
4 At the end of the 3
second button press:
5 Repeat procedure to revert to Personality 1.
Tone L1 sounds.
Tone L2 sounds
indicating that the
personality has
changed to
Personality 2.
English
22
Loading...
