Motorline professional ROLLING, ROLLING SP, ROLLING 120, ROLLING120SP, ROLLING 160 User Manual
...
ROLLING | ROLLING SP
USER'S AND INSTALLER'S MANUAL
EN
v2.1
REV. 11/2014
00. CONTENT 01. SAFETY INSTRUCTIONS
INDEX
01. SAFETY INSTRUCTIONS
STANDARDS TO FOLLOW
02. THE AUTOMATISM
TECHNICAL SPECIFICATIONS
INSTALLATION INSTRUCTIONS
INSTALLATION OF THE ELECTROBRAKE
GEAR MOTOR WITH SAFETY DEVICE
1B
2A
2B
4B
5A
STANDARDS TO FOLLOW
ATTENTION:
• To ensure the safety of people, it is important that you read all the following
instructions. Incorrect installation or incorrect use of the product can cause physical
injury and material damage.
• Keep these instructions in a safe place for future reference.
• This product was designed and produced strictly for the use indicated in this manual.
Any other use, not expressly indicated here, could compromise the good condition/
operation of the product and/or be a source of danger.
• ELECTROCELOS SA is not responsible for the improper use of the product, or other use
than that for which it was designed.
• ELECTROCELOS SA is not responsible if safety standards were not taken into account
when installing the equipment, or for any deformation that may occur to it.
• ELECTROCELOS SA is not responsible for the safety and proper operation when using
components not sold by them.
• Do not make any modifications to the operator components and / or their accessories.
• Before installation unplug the automatism from the source of power.
• The installer must inform the client how to handle the product in case of emergency
and provide this manual to user.
• Keep remote controls away from children, to prevent the automated system from being activated involuntarily.
• The customer shall not, under any circumstances, attempt to repair or tune the operator. Must call qualified technician only.
• Connect the automatism to a 230V plug with ground wire.
• Operator for indoor use.
• Do not install the gearmotor in presence of fumes or inflammable gas.
• The mechanical parts must conform to the provisions of standard EN 12604 and EN 12605.
• The installation must conform to standards EN 12453 and EN 12445.
• The main power supply of the automated system must be fitted with an all-pole switch
with contact opening distance of 3mm. Use of a 6 A thermal breaker with all-pole circuit
break is recommended.
• The safety devices (photocells , etc.) protect any danger areas against mechanical movement risks, such as crushing, dragging, and shearing.
• Use of at least one indicator-light is recommended for every system, as well as a warning
sign, in addition to the safety devices.
• Do not command more than one gearmotor with each button.
