1 WELCOME

Navigation Key

Move through menus.

Left Soft Key

Call/Answer Key

Make & answer calls.

Home Key ALT Key

Microphone

Message/Display Off Key Space Key Center Key

Select menu items.

Right Soft Key Power/End Key

Turn phone on & off, and end calls.

Back Key

Enter Key Caps Key Speakerphone/Voice Recognition Key Camera Key Thumb Wheel Undo/Back Key Infrared Port Memory Card Door Mini USB Port

Charge & connect phone accessories.

2.5mm Headset Jack Camera Lens Battery Door Release Speakers Camera Flash

678

WELCOME

Introducing your new QWERTY keyboard for entering text, and use it with Bluetooth

PAGE 1 WELCOME

MOTO

Q™ Amp’d Edition CDMA wireless phone! You can check and write e-mail, use the

Enabled headsets. Here’s a quick anatomy lesson.

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

www.hellomoto.com

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States for hearing impaired)

1-800-461-4575 (Canada)

Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. All other product or service names are the property of their respective owners.

CAUTION: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment.

Manual Number: 6809509A43-B

PAGE 2 WELCOME

CONTENTS MOTO Q, AMP’D EDITION USER GUIDE

1 WELCOME . . . . . . . . . . . . . . . . . . . . . . . 1

2 GETTING STARTED . . . . . . . . . . . . . . . . 5

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . 5

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Battery Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . 6

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . 6

Turning Your Phone On & Off . . . . . . . . . . . . . . . 7

Activing Your Phone . . . . . . . . . . . . . . . . . . . . . . 7

Using the Thumb Wheel . . . . . . . . . . . . . . . . . . . 7

Carrying Your Phone . . . . . . . . . . . . . . . . . . . . . . 7

Viewing Your Phone Number . . . . . . . . . . . . . . . 7

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . 7

Setting Up Voicemail . . . . . . . . . . . . . . . . . . . . . . 7

Transferring Your Number . . . . . . . . . . . . . . . . . . 8

Using the Infrared Port . . . . . . . . . . . . . . . . . . . . 8

Inserting a Memory Card . . . . . . . . . . . . . . . . . . . 8

Getting Software Updates . . . . . . . . . . . . . . . . . . 9

Upgrading Amp’d Live . . . . . . . . . . . . . . . . . . . . . 9

Additional Information . . . . . . . . . . . . . . . . . . . . 9

3 HIGHLIGHT FEATURES . . . . . . . . . . . . 10

Amp’d Live™ . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Synchronizing Your Phone . . . . . . . . . . . . . . . . . 16

E-mailing & Messaging . . . . . . . . . . . . . . . . . . . 18

Enjoy Your Music . . . . . . . . . . . . . . . . . . . . . . . 22

Taking & Sending a Photo . . . . . . . . . . . . . . . . . 24

Recording & Playing Video Clips . . . . . . . . . . . . 25

Copying Media Files . . . . . . . . . . . . . . . . . . . . . 26

Using the Media Player . . . . . . . . . . . . . . . . . . . 27

Adjusting Audio . . . . . . . . . . . . . . . . . . . . . . . . 27

Browsing the Web . . . . . . . . . . . . . . . . . . . . . . . 28

Using Bluetooth Wireless . . . . . . . . . . . . . . . . . . 28

Using a Modem-Link . . . . . . . . . . . . . . . . . . . . . 30

4 LEARNING TO USE YOUR PHONE . . . 33

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . 33

Using the Thumb Wheel . . . . . . . . . . . . . . . . . . 34

Using the Menus . . . . . . . . . . . . . . . . . . . . . . . . 34

Opening a Program . . . . . . . . . . . . . . . . . . . . . . 35

Using the File Manager . . . . . . . . . . . . . . . . . . . 35

Using the Task Manager . . . . . . . . . . . . . . . . . . 36

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . 37

Using the Handsfree Speaker . . . . . . . . . . . . . . . 37

Using Voice Commands . . . . . . . . . . . . . . . . . . . 38

Switching to Airplane Mode . . . . . . . . . . . . . . . . 38

Locking & Unlocking Your Phone . . . . . . . . . . . . 39

Automatically Locking Your Phone . . . . . . . . . . . 39

Locking & Unlocking the Keypad . . . . . . . . . . . . 39

5 SETTING UP YOUR PHONE . . . . . . . . . 40

Using Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Setting Time & Date . . . . . . . . . . . . . . . . . . . . . . 40

Personalizing the Home Screen . . . . . . . . . . . . . 41

Setting the Backlight . . . . . . . . . . . . . . . . . . . . . 41

Selecting Answer Options . . . . . . . . . . . . . . . . . 41

Installing Third Party Applications . . . . . . . . . . . . 42

6 CALLING FEATURES . . . . . . . . . . . . . . 43

Turning off a Call Alert . . . . . . . . . . . . . . . . . . . 43

Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . 43

Using Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Viewing Missed Calls . . . . . . . . . . . . . . . . . . . . . 43

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Dialing Emergency Calls . . . . . . . . . . . . . . . . . . 44

Dialing International Calls . . . . . . . . . . . . . . . . . 44

Calling with Speed Dial . . . . . . . . . . . . . . . . . . . 44

Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . 45

Using Three-Way Calling . . . . . . . . . . . . . . . . . . 45

7 PHONE FEATURES . . . . . . . . . . . . . . . 46

Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . 47

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Personalizing . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Call Times & Costs . . . . . . . . . . . . . . . . . . . . . . . 51

Handsfree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Network Connections . . . . . . . . . . . . . . . . . . . . 52

PAGE 3 CONTENTS MOTO Q, AMP’D EDITION USER GUIDE

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Phone Information . . . . . . . . . . . . . . . . . . . . . . 54

Fun & Games . . . . . . . . . . . . . . . . . . . . . . . . . . 55

8 SERVICE AND REPAIRS . . . . . . . . . . . . 56

9 SPECIFIC ABSORBTION RATE DATA . . 57

10 MICROSOFT EULA . . . . . . . . . . . . . . . 58

PAGE 4 CONTENTS MOTO Q, AMP’D EDITION USER GUIDE

Navigation

and Center

Select Key

Left Soft Key

Right Soft Key

Undo/Back Key

Home Key

Power Key

Call/Answer Key

GETTING STARTED

2 GETTING STARTED

Caution:

Before using the phone for the first time, read the important safety and legal information in the separate legal guide included in the box.

About This Guide

This guide shows how to locate a menu feature. Press the left and right soft keys to select screen menus and options. Use the highlight menu features. Press the select items.

Press

Start > Call History > [Incoming Call]

This example shows that, from the main or home screen of the phone, you press the left soft key to open the Start menu and then use the thumb wheel to scroll to

I Call History

incoming (

Optional Features

This label identifies an optional network or subscriptiondependent feature that may not be offered by all service providers in all geographical areas. Contact your service provider for more information.

Optional Accessories

This label identifies a feature that requires an optional Motorola Original

Navigation

key (S) to scroll and

then highlight and select an

) call.

™

accessory.

Select

key (s) to

Getting Help

For in-device help while using your phone, press

Start > Help and QuickStart (1

For more ways to get help, see “Additional Information” on page 9.

Battery Tips

Battery life depends on the network, signal strength, temperature, features, and accessories you use.

•

Always use Motorola Original batteries and battery chargers. The warranty does not cover damage caused by non-Motorola batteries and/or chargers.

•

New batteries or batteries stored for a long time may take more time to charge.

•

When charging your battery, keep it near room

temperature.

•

When storing your battery, keep it uncharged in a cool, dark, dry place.

•

Never expose batteries to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

•

It is normal for batteries to gradually wear down and require longer charging times. If you notice a change in your battery life, it is probably time to purchase a new battery.

•

Contact your local recycling center for proper battery

disposal.

Warning:

they may explode.

Never dispose of batteries in a fire because

PAGE 5 ABOUT THIS GUIDE GETTING STARTED

GETTING STARTED

Installing the Battery

Your phone uses only Motorola Original batteries and accessories.

Press the battery door latch.

Lift the battery door up and remove it.

Insert the battery as shown.

Charging the Battery

New batteries are not fully charged. You can charge your battery by connecting the power supply to your phone's mini-USB port and plugging it into a wall outlet. Your phone displays a full battery icon or

Charge Complete

when finished.

Your battery will perform best after you have fully charged it and completely drained it (by using it) a few times.

Tip:

You can safely leave the charger connected to your phone after charging is complete. This will the battery.

Notes

•

If your battery is completely drained, you cannot charge it by using the USB cable plugged into the computer (this connection only maintains the current battery level). Use a wall charger or car charger to recharge the battery. Some computer USB ports provide a higher current than others and will provide more rapid charging.

not

damage

•

The mini-USB port does not support headphones. You

Replace the

battery door.

must use 2.5mm headphones or a Bluetooth stereo

headset.

PAGE 6 INSTALLING THE BATTERY GETTING STARTED

Turning Your Phone On & Off

Answering a Call

To turn on your phone, press and hold

until the display

turns on.

To turn off your phone, press

and hold

for three seconds.

Activing Your Phone

Before you use your phone, you must activate it.

Turn your phone on.

Dial *22890 and press N.

Using the Thumb Wheel

To display a list of options on the home screen, use the thumb wheel to scroll through the menu.

Carrying Your Phone

Carry your phone in an approved holster or case so that you do not damage it by placing it in your pocket, purse, or bag.

Viewing Your Phone Number

When your phone rings and/or vibrates, press N or

(left soft key) to answer. To “hang up,”

press

•

If you are busy when a call comes in, press send the call directly to voicemail.

•

If you are on a call and receive another call, you can choose to answer the second call, the first call is put on hold and the second is active. If you choose call is sent to voicemail.

•

To switch between the two active calls, press N.

Answer

the second call or

Wait

Ignore

Wait

. If you

, the second

Setting Up Voicemail

To set up your new voicemail, press and hold the 7 key or dial *86. If you hear your recorded greeting, press #. Use the voice prompts to set up your account.

To access your voicemail box, press and hold the 7 key or dial *86. If you are calling from another phone, dial your cell phone number. When you hear your recorded greeting, press the # key.

To view your phone number, press

More... My Telephone Number

More... > More... > Phone Settings >

Start > Settings >

Making a Call

From the home screen, enter a phone number and press

to make a call.

To learn how to use voice dialing, see page 38.

PAGE 7 TURNING YOUR PHONE ON & OFF GETTING STARTED

Transferring Your Number

Note:

Make sure you have already activated your phone

by dialing *22890.

To transfer your number from another phone, contact the Amp’d Customer Care Center at 1-866-811-0091. Before you call, have this information ready:

•

The ESN from your old mobile phone which is located behind the battery.

•

Your account number from your previous service

provider.

The transfer process may take up to 24 hours.

Using the Infrared Port

Use the infrared port to synchronize and exchange files with a computer or other infrared capable device. For more information about synchronizing your phone, see “Synchronizing Your Phone” on page 16.

You can use Bluetooth or USB cable to transfer data. For Bluetooth transfer information, see page 28. For data transfer using USB cable and ActiveSync

, see page 16.

Inserting a Memory Card

A memory card is included with your phone. You can use the removable miniSD memory card to store multimedia content (such as music, pictures, videos).

Caution

phone is using or writing files on it.

To insert a miniSD memory card:

: Do not remove your memory card while your

Open the memory slot cover by putting your fingernail on bottom ridge of infrared port and scraping the rubber cover downward.

Insert memory card with the contacts facing down, into the exposed memory slot. Make sure the card clicks into

place.

Place memory card cover back in place and push to

close.

PAGE 8 TRANSFERRING YOUR NUMBER GETTING STARTED

Caution:

Don’t bend or scratch your memory card.

Keep it away from static electricity, water, and dirt.

Tip:

Move media files (pictures, videos, music) to a memory card as often as possible to save storage space on your phone.

Getting Software Updates

Additional Information

Motorola Software Update is an easy and convenient way to update your phone to the latest available software. Access the tool and check for updates at http://www.hellomoto.com/update.

Upgrading Amp’d Live

Press the center select key (s) to enter Amp’d Live.

Scroll to

Amp’d

Select

follow the prompts.

Tips & Upgrades

Live

Buy Now

—you will not be charged—and

and select

New

Need additional assistance or more documentation?

MOTO Q Support Website

www.motorola.com/support/Q

Motorola Customer Support Center

You can also contact the Motorola Customer Support Center at 1-800-657-7576 (United States and Canada) or 1-888-390-6456 (TTY/TDD United States for hearing impaired).

Amp’d Mobile Downloads

For additional handset information and downloads, visit: www.ampd.com

Microsoft® Windows Mobile Websites

• Windows Smartphone Support—

www.microsoft.com/windowsmobile/smartphone/ default.mspx

• Virtual Private Network and ActiveSync —

http://download.microsoft.com/download/1/c/5/ 1c541c3d-c8c7-4899-81fd-1b8e9bac09ed/ readme.doc.

PAGE 9 GETTING SOFTWARE UPDATES GETTING STARTED

HIGHLIGHT FEATURES

3 HIGHLIGHT FEATURES

You can do much more with your phone than make and receive calls!

Amp’d Live™

Amp’d Live is a whole new world of mobile entertainment. In addition to hot phone features like messaging and photo and video camera, you can now:

•

watch your favorite videos and TV clips

•

play your favorite 3D multiplayer games

•

download your favorite music, the hottest ring tones, wallpapers, and more

How to Start

Ready to get started? Just select the Amp’d Live icon from the home screen or press your phone.

What Can You Do?

The Amp’d Live menu is set up by topic, so finding the things you like couldn’t be easier.

What’s Hot

Just like the real world, the Amp’d Live world is dynamic. New music videos, songs, ring tones, and other cool stuff are released all the time. Think of the new-release and hottest-picks corner of Amp’d Live. Check it often to stay up-to-date.

What’s Hot

• Daily Video

must-see flicks.

• Hot Bundles

for hot ring tones and wallpapers.

• Artist Features

from your favorite artists.

you’ll find:

—Catch new video releases and other

—Get specially selected combinations

—Check here for new releases

Start > Amp’d Live

What’s Hot

• Cutting-Edge Gear

for your phone (coming soon).

• Sizzling Apps

Synchronizing Your Phone

You can synchronize the information on your phone with the information on your computer either over the air (OTA) or by using a cable.

Synchronizing Over the Air

To sync your phone over the air, you must sync it directly with a Microsoft Information Server or Microsoft Exchange Server 2003. For more information, see page 9 and the MOTO Q Support website at: http://www.motorola.com/support/Q or contact your system administrator.

Note:

If you are out of network coverage, and your phone tries to sync three times without finding a network, your synchronization settings automatically revert to manual synchronization. To set your synchronization schedule back to the desired frequency, reset the (On the Home screen, press

Menu > Schedule

Schedule

option in the ActiveSync settings.

Start > ActiveSync >

Synchronizing With a Computer

Note:

For information about connections (Bluetooth, VPN, or web browser), see page

You can use Microsoft ActiveSync version 4.1 or later to synchronize information between your phone and computer. ActiveSync compares your phone’s contact information, calendar appointments, e-mail messages, and media files to those on your computer and then updates to the most recent information.

52.

Installing & Setting Up ActiveSync

To synchronize your phone with a computer, you must install Microsoft ActiveSync software on your computer. If you do not have a CD-ROM, you can download the latest ActiveSync software from the Microsoft Windows Mobile website

http://www.microsoft.com/windowsmobile.

Caution:

Before installing the software, check the requirements for your computer and operating system with the CD-ROM sleeve or Microsoft Mobile Phone website: http://www.microsoft.com/windowsmobile.

1. Install ActiveSync on your computer.

2. After setup completes, connect your phone to

the

computer.

The phone drivers are installed on your computer and then the Sync Setup Wizard automatically starts.

3. Follow the instructions on the screen to complete

the wizard.

Note:

You can configure an Exchange Server connection to synchronize directly with Exchange Server and Outlook e-mail clients. The Sync Setup Wizard will prompt you for the name of the Exchange Server, your user name, password, and domain name. If you don’t have this information available, contact your system administrator or see Additional Information on page and the MOTO Q Support website:

http://www.motorola.com/support/Q.

When you finish the wizard, ActiveSync automatically starts to synchronize with your phone. After synchronization completes, you can disconnect your phone from your computer.

Note:

You may need to restart your computer.

PAGE 16 SYNCHRONIZING YOUR PHONE HIGHLIGHT FEATURES

Synchronizing Via a Cable Connection

After you install ActiveSync on your computer, you can connect your phone and sync.

1. Turn on the phone.

2. Connect your phone to your computer using a USB

cable.

Note:

For more information, see the ActiveSync Help on your computer, the Microsoft Web Site for ActiveSync or the MOTO Q Support web site at http://www.motorola.com/support/Q.

Synchronizing Via Bluetooth

After you install ActiveSync on your computer, you can connect your phone and sync via Bluetooth.

Note:

To use this feature, your computer must be equipped with Bluetooth or a Bluetooth computer adaptor accessory.

1. On your computer, use the ActiveSync online help to

configure Bluetooth to support ActiveSync.

2. Turn on your phone.

3. On your phone, verify that Bluetooth is turned on

(Press

Start > Bluetooth > Bluetooth Manager >

Settings

4. Press

5. Select

. Toggle

Start > ActiveSync

Status

Bluetooth On

Menu > Connect via Bluetooth

. Ensure that

the phone and computer are within close range.

6. If this is the first time you have connected to this computer via Bluetooth, you must complete the Bluetooth wizard on the phone and set up a Bluetooth partnership with the computer before synchronizing.

7. Select

8. When finished, select

Tip:

Bluetooth (see page

Sync

Menu >

Disconnect

Bluetooth

To preserve battery power on your phone, turn off

28).

Synchronizing Via Infrared

After you install ActiveSync on your computer, you can connect your phone and sync via infrared (IR).

Note:

To use this feature, your computer must have IR

capability.

1. On your computer, use

the ActiveSync online help to set up your computer to receive IR signals.

2. Turn on your phone.

3. On your phone, verify that IR is turned on (Press

Start > Settings > Connections > Beam and select Receive incoming beams

4. Line up the IR port on your phone and computer so

that they are unobstructed and within close range.

5. Press

6. Select

7. Select

Start > ActiveSync

Menu > Connect via IR

Sync

PAGE 17 SYNCHRONIZING YOUR PHONE HIGHLIGHT FEATURES

E-mailing & Messaging

You can set up e-mail with Microsoft Exchange Server

2003. Contact your system administrator to set this up or see page “Setting Up Exchange Server E-mail” on page 19 or the MOTO Q Support website: http://www.motorola.com/support/Q.

Setting Up E-mail

You can set up e-mail on your phone either automatically or manually. If you have a Hotmail or Pocket MSN account, see “Setting Up Hotmail E-mail” on page 19.

Setting Up Automatic E-mail

Some e-mail providers support automatic e-mail set up. Have your e-mail address, username, and password ready and:

1. Press

2. Select

3. At

4. At

5. Select

If the account sets up successfully, you will be prompted to send and receive e-mail. If not, you must click see the next section.

Start > Messaging > Outlook E-mail

Menu > Options > New Account

Your name

mail

messages.

E-mail address

this

account.

, enter your display name for e-

, enter the e-mail address for

Attempt to obtain e-mail settings from

the Internet

and select

Manually Setting Up E-mail

If you tried to set up your account automatically and were prompted for detailed e-mail settings, call your email (internet) service provider for additional information. To perform the setup, you need the following information:

•

Domain name

•

Server type (POP3 or IMAP4)

•

Account name

•

Incoming mail server (POP3 or IMAP4)

•

Secure Sockets Layer (SSL) connection requirements

•

Outgoing mail server (SMTP)

1. Press

2. Select

3. At

4. At

5. Select

Start > Messaging > Outlook E-mail

Menu > Options > New Account

Your name

mail

messages.

E-mail address

this

account.

, enter your display name for e-

, enter the e-mail address for

6. Enter the information from the e-mail (Internet)

service provider as appropriate until setup is complete, and click

Caution:

If you save your password and then lose your

Finish

phone, anyone who finds your phone can gain access to your e-mail.

PAGE 18 E-MAILING & MESSAGING HIGHLIGHT FEATURES

Setting Up Exchange Server E-mail

If you do not have specific Exchange Server information, contact your system administrator to set up your phone, otherwise, use these steps:

1. Press

2. Press

3. At

Start > ActiveSync

Menu > Configure Server

Server Address

, enter the exchange server

address. (You might need to check if this server requires an encrypted (SSL) connection.)

4. Press

5. At

User Name

, enter your user name for the

e-mail account.

6. At

Password

, enter the password for the account.

7. If you want to save your password, so you don’t have to enter it again, select the check box to

Save Password

Caution:

If you save your password, anyone who finds

your phone can read your e-mail.

8. Select

9. At

10. Press

Domain

(if

necessary).

, enter the server's domain name

11. Choose the data to synchronize. You can select Contacts, Calendar, E-mail, and Tasks.

12. Press

13. Press

Finish

Sync

to synchronize your phone with the

Exchange server.

This device uses the enhanced version of Microsoft Windows Mobile 2005 known as Mobile Security Feature Pack (MSFP).

This enhanced version supports a type of over-the-air communication with your corporate e-mail servers known as “IP-PUSH’.

IP-PUSH will keep your Moto Q and corporate mailbox synchronized at all times with absolutely minimal delays. It will do this for e-mail, calendar entries, contacts, and tasks.

To benefit from the enhanced capabilities of IP-PUSH you will need to consult your corporate IT staff. IP-PUSH may require some set-up and adjustments to your corporate technical infrastructure. Another name for MSFP is Adaptation Kit Update-2 (AKU2).

Setting Up Hotmail E-mail

If you use the Hotmail or MSN e-mail services, have your e-mail address, and password ready and:

1. Press

2. Select

3. At

4. At

5. Select

Start > Pocket MSN

MSN Hotmail

E-mail address

your

account.

Password

, enter the e-mail address for

, enter the password for the account.

If the Hotmail account sets up correctly, your e-mail files and account folders will be synchronized with your phone.

Tip:

After you set up your Hotmail e-mail account, you

won’t need to do it again.

Note:

If you don’t have all of the information for these steps, contact your company’s system administrator to set up your phone or the MOTO Q Support website at: http://www.motorola.com/support/Q.

PAGE 19 E-MAILING & MESSAGING HIGHLIGHT FEATURES

Operator Hosted E-mail

If you have Operator Hosted E-mail, contact your operator, or access their web site to get information about their hosted e-mail solution and its compatibility with Windows Mobile

Receiving & Reading Messages

5.0 enabled devices.

When you receive a message, your phone plays an alert and displays indicator

New Message

with a message

To check your e-mail:

1. Press

Start > Messaging

Message Options

Use these quick steps from the Inbox with a message selected or when viewing a message:

Message Option Steps

Delete

Forward

Press

Menu > Delete

Press

Menu > Reply or

Reply All

and press

Press

. Enter the message

Send

Menu > Forward

the message and press

. Enter

Send.

2. Select the account to send and receive messages and

press

Menu > Send/Receive

The phone connects to your Internet e-mail server and sends and receives your messages.

To stop this process, press

Stop Send/Receive

Menu >

Tips:

•

If you do not see a list of messages, press

Folders > Inbox

press

À.

•

To open the next message in the list from within an

. To return to the Folder list,

open message, press the navigation key

Menu >

to the right; to open the previous message in the list, press the navigation key

•

You can send, read, and receive PDF, Microsoft

to the left.

Word, Excel, and PowerPoint files via e-mail. Use ActiveSync to transfer these files to your computer for editing.

Create a contact card

Sending a Message

Press

Menu > Save to

Contacts

You can send SMS text messages and e-mail messages that contain pictures, animations, sounds, videos, PDFs, compressed files, word processing and spreadsheet files:

To send a message:

Press

Start > Messaging > Text Messages or

E-

mail Account.

2. Press

3. For e-mail, in To, Cc, and/or

New

Bcc

, enter e-mail addresses. Insert a semicolon (;) between multiple numbers or addresses.

For text messages, enter contact telephone number.

You can quickly enter phone numbers or e-mail addresses from your contact cards. In

Enter (Á

) and select a recipient from the list. Then

select the recipient's phone number or

, press

e-mail address.

PAGE 20 E-MAILING & MESSAGING HIGHLIGHT FEATURES

4. Use the keypad to compose a message.

5. Press

Send

In an e-mail you can insert a picture, voice note or file in the message, on the message area press

Insert


Voice Note

File

If you select to insert a voice note into the message, you will also need to record it. Press

Record

and start speaking into the phone's microphone. When finished speaking, press

To set the priority for an e-mail message, press

Message Options

To cancel a message, press

Stop

and then

Done

Menu > Cancel Message

Using Global Address Look Up

You can view a global address list (GAL) on the Exchange Server on your phone. This means you can find a contact’s phone number or e-mail without having to store the information directly to your phone.

Note:

You can view GAL information only during a data transfer session; the entire GAL cannot be stored for viewing offline.

GAL Lookup can be found from Contacts and Contact Chooser. Contact Chooser is found in Messaging, Phone, Calendar and Speed Dial.

Here’s how to use GAL to search for a contact:

1. Press

2. In the contact list, press

3. Scroll through the list of entries displayed. When you

Start

Contacts

locate your contact, press the to make a call.

Find Online

Call/Answer

key (N)

Note:

You can also send a message, SMS or e-mail to a contact that you have found by using GAL. In a new message or e-mail, press

Menu > Find Online

. When you locate the contact to send a message, highlight and select it. The e-mail information is populated into the

To:

Field.

Messaging Quick Reference

Make sure you have an e-mail provider and the following account information: ISP settings, protocols, user ID, password, and sending and receiving host information. Otherwise, these features might not work.

Option Description

Send a text message

Create and send e-mail

Start

Messaging

Text Messages

Start

Messaging > Outlook E-

mail

> E-mail Account

New

You must set up your e-mail before you can send a message (see page 18).

To add a picture, voice note, or file in an e-mail message, in the

message area, press

Insert

Picture or Voice Note

or File

You can save a draft of a message to finish and send later. Press

Save to Drafts

. A draft of the message is stored in the Drafts folder of the account you are in.

Although the entire GAL cannot be stored on your phone, after the contact is found, you can add the single contact to your contact list.

PAGE 21 E-MAILING & MESSAGING HIGHLIGHT FEATURES

Enjoy Your Music

After you download a song or start a music subscription, use the Media Player to play your music.

You can select any of the following methods to play your music:

Pick Songs

1. Go to

2. Select

3. Select the method you want to use to play your

My Stuff

Music

songs (see the following table).

Option Description

Shuffle Play all songs on your phone in random sequence.

Artist Display an alphabetical list of artists whose songs are on your phone. You

can select the artist you want to hear. After you select the artist, you can play all songs by that artist, a specific album, or a single song.

Album Display an alphabetical list of the albums on your phone. Just select the

album you want to hear. You can then play all songs on the album or a specific song.

Song Display an alphabetical list of all songs on your phone. Select the songs you

want to play.

Playlist Display all playlists on your phone. Select a playlist, then play all songs on

that playlist or only a specific song.

PAGE 22 ENJOY YOUR MUSIC HIGHLIGHT FEATURES

Playing Songs

After you select the songs you want to play, use the Media Player to control playback.

Option Description

Play/Pause Press the center select key s to play a song.

While a song is playing, press playing it.

Stop Press S up to turn off the song. The next time you play the song, it will

start at the beginning.

Next Press S right to skip ahead to the next song.

Restart Press S left to restart a song from the beginning.

to pause it. Press s again to continue

Previous Press S left

twice

to skip back to the previous song.

Fast Forward Press and hold S right to fast-forward the song.

Rewind Press and hold S left to scroll backwards in the song.

Volume Press your phone’s volume keys (on the side of the phone) up and down to

adjust volume levels.

PAGE 23 ENJOY YOUR MUSIC HIGHLIGHT FEATURES

Taking & Sending a Photo

Thumbnails

Pictures & Videos

877

1.0x


AREA

Press and hold the

Camera

for two seconds to see the camera viewfinder:

To adjust picture settings (

brightness resolution, zoom white balance

and

1. Point the camera lens at the photo subject.

2. Press the

3. Press

key (e)

mode

flash

) in the camera viewfinder press

Camera

key (

) to take a photo. The picture is automatically

key (e) again or the center select

saved and displays in the view finder.

to see the camera options.

Option Description

Delete

delete the photo and return to the active viewfinder,

Send

Outlook

send the photo

your send option

E-mail

Properties

view image properties, such as the file name

Options

Note:

Pictures are automatically stored in your phone. To view them: Press the picture to view and press

Tip:

To view pictures in a folder other than the default pictures folder, including on a storage card, press >

Pictures & Videos

view picture options

Start

Pictures & Videos

View

Folders

. Select

Start

, and select the

folder that contains stored pictures.

Taking a Self Portrait

1. Press and hold the

the

camera.

2. Press

3. Press the

Menu > Mode > Timer

Camera

second

delay.

4. Aim the camera lens at yourself.

The phone makes a shutter sound and takes the

picture.

Camera

key (e) to activate

key (e) to start the five

Bluetooth

Beam

Use as Home

send via Bluetooth

send the picture via infrared port

use the picture as the home screen

Screen

Edit

PAGE 24 TAKING & SENDING A PHOTO HIGHLIGHT FEATURES

edit the picture

Setting Picture Options

00:05 43:20

Stop

Pictures & Videos

Pause

VIDEO

AREA

Remaining recording time Current recording length

In the picture viewfinder press open the

Picture Options Menu

include the following options:

Option Description General

Determine default picture sizes for email and rotating picture settings.

Slide Show Camera

Select default slide show settings. Select default locations to store

pictures, filename prefixes, and image compression.

Video

Determine audio settings and time limits for video files.

Options

. This menu can

Recording & Playing Video Clips

1. Point the camera lens at the photo subject.

2. Press the

(

Camera

key (e) or the center select key

) to begin recording a video. The video displays in

the viewfinder.

3. Press

press

Stop

to end recording the video altogether, or

Pause

to pause recording and

Resume

continue recording.

Videos are automatically stored in your phone. To view them: Press the video to view and press select

key (s).

Tip

: To view videos in a folder other than the default

Start

Pictures & Videos

Play

or the center

video folder, including on a storage card, press

Pictures & Videos

Folder

, and then select

the folder that contains the stored videos.

. Select

Start

Recording a Video Clip

Press

Tip:

and press

Setting Video Options

Camera (e) > Menu > Video.

To adjust video settings (

white balance

PAGE 25 RECORDING & PLAYING VIDEO CLIPS HIGHLIGHT FEATURES

) in the video viewfinder,

still, brightness, quality

In the video viewfinder press the Options Menu. This menu can include the following options:

Option Description Camera

Video

Note: General

available in this menu, however these settings are

specific to picture files only.

Options

to open

Select default save locations, video filename prefixes, and image compression.

Determine audio and time limit settings for video files.

and

Slideshow

options are also

00:00 70%

Now Playing

Windows Media

Playing a Video Clip

Press

Start

Pictures & Videos

video clip >

Play

The video clip displays in the Windows Media screen.

Tip:

To pl ay video in full screen, press

Full

Screen

. Not all videos play in full screen mode. Only those videos that were captures in the correct

resolution.

If a call comes in while watching a video, the video pauses and a call alert appears. You can choose to answer the call or ignore it. To continue watching the movie, select the

Play

button.

Setting Video Playback Options

In the video playback window press open the

Video Playback Menu

include the following options:

Option Description Playback

Determines how the time counter is displayed, whether to pause playback while using another program, and whether to resume playback after a phone call.

Video

Options for displaying in full screen and when to scale to fit window.

Network

Selects default network settings for streaming media.

Library

Determines if the player starts on the Library screen.

Options

. This menu can

Option Description Skins

Determine Windows Media Player skin theme.

Buttons

Set playback button mapping.

Copying Media Files

You can copy media files from your computer to your phone.

Note:

You must have installed ActiveSync on your

computer, as described on page

1. Connect the phone to your computer.

2. In ActiveSync on your computer, click double-click

My Windows Mobile

3. On your computer, find the files you would like to copy to your device and paste the files into the

Windows Mobile

folder.

4. Resync your phone and computer and then view the picture or video on your phone from

Pictures & Videos

16.

Explore

device.

Start

and

PAGE 26 COPYING MEDIA FILES HIGHLIGHT FEATURES

Using the Media Player

Windows Media Player Mobile version 10.2 or later for Smartphone is available on your to phone to play digital audio and video files that are stored on your phone or on the Web.

By default, Windows Media Player Mobile can play the following types of files: Windows Media Audio (WMA), Windows Media Video (WMV), and Motion Picture Experts Group-2 Audio Layer-3 (MP3).

Press

Start

Windows Media

Tip:

Do you want to play a song or video on the Internet or network? Use the Open URL command. From the Library screen press

Open URL

(if you need

to get to the Library screen, in Windows Media, press

Library

). For more information about

downloading or copying video files, see page

26.

Setting Video Controls

You can set up keys on your phone to control the media player.

1. From the media player screen, press the

Right Soft Key

and select

Options

00:00 70%

Play or pause a music or video file.

Skip to the previous or next file.

Increase or decrease the volume.

Switch to full screen video playback.

Fast forward or rewind.

Now Playing

Press

Enter (Á

Press the navigation key (S) left or right.

Press the navigation key (S) up or down.

If you need to turn the sound off, press #.

Press 0.

Press and hold the navigation key (

) left or right.

2. Select

Buttons

3. Scroll to the media player action you want to assign

a button or key press.

4. Press the

Assign, Reset

Menu Right Soft Key

, or

None

and choose,

5. After you have assigned key presses to the medial

player controls, press the

setup.

and

Done

to complete

Adjusting Audio

Your phone allows you to adjust surround sound, bass, and clarity levels for the phone speakers as well as your headset.

From the home screen, press

Audio Enhancement

Note:

When you adjust the headset audio, make sure you wear your headset while adjusting the level. You can also set the speaker size for your particular headset.

Start

Accessories

PAGE 27 USING THE MEDIA PLAYER HIGHLIGHT FEATURES

Browsing the Web

You can use Internet Explorer Mobile to search and view the web.

Start

Press

Note:

Go to a

Internet Explorer

Not all web file formats are supported.

web page.

Go to a link in a web page.

Press

Address Bar

Enter the address and press

Use the navigation key to highlight the link and then

press the center select key (

Change connection options.

Show/hide pictures.

Add a web address to your Favorites.

Press

Tools

Options

Press

Show Pictures

Connections

View

Open the web page and press

Add to Favorites

Using Bluetooth Wireless

Your phone supports Bluetooth wireless

linking

called

bonding

). You can pair your phone with a Bluetooth headset or car kit, or pair your phone with a computer to exchange and synchronize files.

Note:

The use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these

products.

pairing

(also

Turning Bluetooth Power On or Off

With Bluetooth pairs with the handsfree device you have used before. Just turn on the device or move it near the phone.

To turn Bluetooth on: Press

Bluetooth Manager Bluetooth ON

The Bluetooth indicator

Note:

To extend battery life, set Bluetooth

OFF

when not in use. Your phone will not pair with devices until you set Bluetooth pair your phone with the devices again.

Power On

, your phone automatically

Start > Bluetooth

Settings

then toggle

appears in the home screen.

Status

Power

back to ON and

Pairing With a Headset Or Handsfree Device

Before you pair your phone with a device, make sure your phone’s Bluetooth power is and

ready

pairing

bonding

your phone with multiple devices, but use it with only one headset device at a time.

Your phone lists the devices it finds within range.

1. Press

Start

Hands-free

Bluetooth > Bluetooth Manager

2. Put the device (handsfree headset, stereo headset,

keyboard, etc.) in pairing mode.

3. Press

Add

. The phone prompts you to verify your

device is ready. Press

4. Select the device from the list.

5. If prompted, enter the device passkey (such as 0000)

and press the

and the device is on

mode. You can pair

key.

PAGE 28 BROWSING THE WEB HIGHLIGHT FEATURES

When the devices are paired, an icon appears on the home screen in the Bluetooth Task Tray.

Tip:

For specific information about the Bluetooth device you are using with your phone, refer to the instructions that came with it.

Sending Objects to Another Device

You can use Bluetooth pairing to send Outlook e-mail, contacts, tasks, calendar items, audio, ring tones, pictures, video, and voice notes from your phone to a computer or other device.

1. Press

Start > Bluetooth

BT Send Object

2. Select the object type and object you want to send.

To select an item, press the center select key (s).

3. Press

Send

4. Select the name of the device to send the file.

5. To cancel sending an item, press

Cancel

Using Advanced Bluetooth Features

Features Description

Make phone visible to other devices

Connect to recognized device

Allow

a Bluetooth device to

discover your phone:

Start > Bluetooth >

Press

Bluetooth Manager > Settings > Allow other Bluetooth devices to see this phone

Press

Bluetooth Manager Hands-free

Start

Bluetooth

device name

Using Your Phone as a Computer Remote

You can use Bluetooth and your phone as a remote control for your computer. For example, want to watch a video on your computer and use your phone as a remote control? Use computer Remote and control when the video plays, stops, or pauses.

1. On your computer, turn Bluetooth on.

2. On your phone, press

computer Remote

3. Press the

Add Left Soft Key

Start > Bluetooth

4. On the your computer, launch the Bluetooth devices applet from the Control Panel and click

Add

5. After the computer finds the phone, select it and press

Finish

Your computer Remote is now connected.

To determine which program on your computer to control, on your phone, press the

left soft key

and select a program.

Drop pairing with devices

Send object to device

Edit device properties/ change device name

Press

Start

Bluetooth Bluetooth Manager Hands-free Disconnect

Press

BT Send Object

Press

> device name >

Start > Bluetooth

Start

Bluetooth > Bluetooth Manager Hands-free Menu Nickname

device name

Properties >

To change the Bluetooth name of your phone, press

Start > Bluetooth Bluetooth Manager Settings

and enter the name

My Bluetooth name

PAGE 29 USING BLUETOOTH WIRELESS HIGHLIGHT FEATURES

Using a Modem-Link

Note:

You must have Multiple Network Access Identifier (MNAI) software on your phone and MNAI service enabled in your account for dial up networking functionality to work on your phone. Call your phone service provider for more information regarding account

You can use your phone as a modem to dial in to a network. You can do this using Bluetooth or using a USB cable.

When your phone is a modem, e-mail, web browsing, ActiveSync, and text messaging services will be suspended until the modem-link is deactivated.

Using Bluetooth

To use Bluetooth to modem-link to a network:

Note:

capabilities for modem-link to work via Bluetooth.

1. To make sure other Bluetooth devices can find your

2. On your computer, launch the Bluetooth devices

Note:

locate the Bluetooth window and setup of dial-up networking. Please refer to your computer operating help system for more information.

services.

You must have a computer that has Bluetooth

phone, you must first turn on Bluetooth. To do this on your phone, press

Bluetooth Manager Status

Bluetooth ON

page

28 for more information.

Start > Bluetooth

Settings

then toggle

. See Bluetooth Wireless on

applet from the task bar.

Not all computers have the same procedure to

3. On your computer, in the Bluetooth window menu bar, select the "Connections" menu, "Dial-up Networking" and then "Find devices."

4. The computer finds your phone and displays the dial up networking window.

Now you can use your phone as a modem to connect to a service provider or network.

Using a Cable

To use a USB cable with your phone to connect with modem-link to a network, first you must install networking drivers onto your computer. Before starting the set up:

•

DO NOT connect your data cable to your phone and computer.

•

Note your phone’s ESN number (located behind the battery in the phone)

•

Contact your service provided for your account user

name

1. Place the provided Companion CD into the CD Drive on your computer. The Companion CD Installation wizard window automatically displays.

2. On your computer, click "Applications" and then "Dial-Up Networking Software."

3. Follow the prompts as directed to install the drivers onto your computer.

Then you need to enable modem-link on your phone and install phone drivers:

4. On your phone, press

Modem-link

Start > Accessories

Activate > OK.

PAGE 30 USING A MODEM-LINK HIGHLIGHT FEATURES

5. Using the USB data cable, connect the phone to your

computer.

6. When a window displays prompting for the device driver, select "Install the software automatically" and press "Next."

The driver is installed on your computer and ready for setting up a network connection.

Note:

If you do not have the Companion CD, or want the latest version of the device and computer drivers, go to http://www.motorola.com/support/Q and click "User Support Dial-up Networking."

Not all computers have the same procedure to setup of dial-up networking. Please refer to your computer operating help system for more information.

To establish a new network connection, on your computer:

1. Click "Start," "Settings," and then "Control Panel."

2. Double-click "Network Connections" and then "New

Network Connection Wizard."

3. Follow the prompts to connect to the Internet using

a modem:

At... Enter or select... Network

Connect to the Internet

Connection Type Getting Ready Set up My

Connection Manually

Internet Connection

Connect using a dialup modem

Select a Device Smartphone wireless USB

Modem

(Deselect any

other modems)

Connection Name

Typ e a connection name (which can be any name).

At... Enter or select... Number to Dial #777

Connection

Anyone's Use

Availability User Name

Get this information from your service provider.

Password

Get this information from your service provider.

Notes:

•

If you do not plan to use your phone as the default Internet connection, then do

the default Internet connection

•

If Microsoft Windows firewall is not enabled, do

not

check

Turn on Internet connection firewall

for this connection

•

Your computer proxy server settings may also need

not

check

to be deactivated for modem link to access the Internet. (Open your web browser, select

Internet Options > Connections Proxy Server this connections

> Deselect

Use a proxy server for

Settings

Make this

Tools

PAGE 31 USING A MODEM-LINK HIGHLIGHT FEATURES

Disconnecting Modem-Link

To disconnect modem-link, you’ll need to perform steps on your computer and your phone. On your computer:

1. Go to task bar and right click on the Network

Connection icon.

2. Select "Disconnect."

Your computer disconnects the modem-link.

Start > Accessories

Press

activate

OK.

Modem-link de-activates on your phone.

Note:

After you are no longer using modem link, you may need to reactivate your computer’s proxy settings. Check with your internet provider.

Modem-link

De-

PAGE 32 USING A MODEM-LINK HIGHLIGHT FEATURES

Start

Home Service

Text Messages (0) No upcoming appointments.

Profile: Normal

12:00 PM 12/31/07

Contacts

Navigation

and Center

Select Key

Left Soft Key

Right Soft Key

ALT Key

Caps Key

Enter Key

Undo/Back Key

Home Key

Space

Key

Messages

Key

Camera

Key

Voice Recognition Key

LEARNING TO USE YOUR PHONE

4 LEARNING TO USE YOUR PHONE

See page 1 for a basic phone diagram.

Using the Display

The

home screen

To dial a number from the home screen, press number keys and

Note:

Your home screen might look different.

Soft Key Labels

Press the navigation key use the thumb wheel to navigate basic menu items or text in the home screen.

Press the home key (

appears when you turn on the phone.

show the current soft key functions.

up, down, left, or right or

) to return to the home screen.

Status indicators appear at the top of the home screen:

Description

Roam Indicator

phone is seeking or using a network

outside your home network. Other

– Shows when your

indicators can include:

•/ EvDO network

•+ roaming unavailable

Bluetooth Indicator

– Shows connection

status.

C BMessage Indicators

– Shows when you receive new messages. Indicators can include:

•C new e-mail or text message

•B voicemail message

Signal Strength Indicator

– Vertical bars show the strength of the network connection. You can’t make or receive calls when no vertical bars are displayed.

Battery Level Indicator

– Vertical bars show the battery charge level. Recharge the battery when your phone shows one or two bars.

PAGE 33 USING THE DISPLAY LEARNING TO USE YOUR PHONE

Description

Amp’d Live

Profile: Normal

Contacts

#QJ0

My Stuff

amp’d mobile

01/27/2007 10:29 AM

Scroll up, down,

left, or right.

Press center to

select

highlighted

menu feature.

Access

the main

menu.

Exit menu without making changes.

Return to previous menu.

Profile Indicator –

Shows the profile (ring style) setting. When the profile is normal, outdoor, or automatic no indicator is displayed.

•< meeting

•

(no icon)

car

•Q silent

•% speakerphone

•

(no icon)

•

(no icon) normal

•

(no icon) outdoor

•

(no icon) automatic

Note:

You cannot change to speakerphone

headset

mode from the Profiles menu.

Location/Data Indicator

phone can send location information

When in a data session (data is currently being

– Shows when your

transferred to the phone), the data indicator (

) is displayed. If double arrows (M) are displayed, your phone is ready and capable of a data transfer session.

Location and Data Indicators do not appear on the screen simultaneously.

or not

Using the Thumb Wheel

You can use the thumb wheel to scroll through menu items and lists. Press the thumb wheel to select the highlighted item in a list or menu.

Tip:

Use the

Back

button (the button below the thumb wheel) to undo the current action or return to the previous screen.

Using the Menus

From the home screen, press main menu.

Start

to open the

PAGE 34 USING THE THUMB WHEEL LEARNING TO USE YOUR PHONE

Use the navigation key

up, down, left, or right or

thumb wheel to see more menu items.

The following menu icons may be available in the main menu.

Icon Description

Amp’d Live

My Stuff

Internet Explorer

Windows Media

Messaging

ActiveSync

Settings

Voic e Notes

Accessories

Help and QuickStart

Pocket MSN

Voice Recognition

System Tools

Ta sk s

Calendar

Contacts

Call History

Games

Pictures & Videos

File Manager

Media Center

Speed Dial

Bluetooth

Some features require you to select an option from a list:

Profiles

A Normal 9

B Silent C Meeting D Outdoor E Automatic F Headset G More...

Done Menu

•

Scroll up or down to highlight the option you want.

•

In a numbered list, press a number key to highlight

Edit

Select Cancel

Reset to default

an option.

•

In an alphabetized list, use the keyboard and press the first letter of the desired item and the phone will highlight the closest matching list option.

•

When an option has a list of possible settings, noted by an arrow displayed next to the option, scroll left or right to select the setting.

•

When an option has a list of possible numeric values, press a number key to set the value.

•

Press

for additional items for option.

Opening a Program

From the home screen, press programs. Use the thumb wheel or navigation key ( to scroll to a program. Press the thumb wheel or center select key (

) to open the program.

Start

to access the list of

Using the File Manager

You can use File Manager to sort, view, copy, and move files on your phone. Files you might want to use in file manager include text, pictures, music, and video files.

Press

Start

File Manager

)

PAGE 35 OPENING A PROGRAM LEARNING TO USE YOUR PHONE

Using the Task Manager

Press

to open the

sub-menu.

Flashing cursor

indicates insertion point.

Press to switch entry modes. For indicator

descriptions, see the following section.

Send

Text Messages To :

0/160

Want to see what programs are running (active) on your phone? Use the Task Manager to see the programs, or stop a specific program from running.

Press

Start > System Tools > Task Manager

Tip:

Need to stop running program? In

select the program and press

Task Manager

Kill

If you want to remove a program from your phone entirely, from the home screen, press

Remove Programs

Start > Settings

Entering Text

Use the keypad to enter text and numbers. The status indicator at the top right of the display screen shows the your current entry mode.

Press the

ALT

key (=) in a text entry screen to select an

input mode:

Input Modes

primary key entry

Secondary key entry. In this mode the next key pressed will be the secondary character. After next key is pressed, the device will return to primary key entry mode.

Secondary key lock. In this mode all subsequent key presses will be secondary keys until the pressed again.

Changing to Uppercase, Lowercase, or Caps

Lock

Your phone has a QWERTY keypad like a computer keyboard. You can use it to type e-mail and text messages and enter contact information. Press

to change to uppercase,

lowercase, or caps lock.

ALT

key (=) is

PAGE 36 USING THE TASK MANAGER LEARNING TO USE YOUR PHONE

Entering Text & Numbers

Enter text and numbers by using the keypad. When you select a field that requires text or numbers, the phone automatically selects the correct input mode. To switch modes, press the indicator at the top of the screen shows you which mode you are using. To start a new line, press

ALT

Enter (Á

key (=). An

Using the Undo/Back Key

To return to the previous screen or menu, press the key (see graphic) or press the keypad.

To backspace and delete a single character in any input mode, press the

To backspace and delete an entire text or numeric field in any input mode, press and hold the

Back

Undo/Back

key (À).

Back

key (À).

Using iTAP®

iTAP lets you enter words using one keypress per letter. The iTAP software combines your key presses into common words, and predicts each word as you enter it. This feature is integrated into your phone’s software and is automatically set. If you want to turn off this setting press

Start

Settings

uncheck

If you want a different word (such as continue pressing keypad keys to enter the remaining characters.

Text Prediction

Text Input Settings

Progress

and

Using Numeric Mode

To enter numbers, press the

ALT

or number mode.

If a field permits a numeric entry only, like a phone number, the input mode automatically defaults to secondary key entry mode.

Alt

key (=), to switch to

Using Symbol Mode

To enter a symbol, press the

Caps

key (Â). The Symbol page appears. Press the center

select key (

) or thumb wheel to select a symbol.

ALT

key (=) and then the

Adjusting the Volume

Press and hold the thumb wheel to adjust earphone, speaker, or headset volume.

•

Need to change profiles on the fly? On the home screen, scroll to and select

Profile

. Choose

from

Normal, Silent

Meeting

•

Want to turn off a sound? Press

Settings

select the sound you want to associate with that

Tip:

You can eliminate the ringer volume instantly when a call comes in—just use the thumb wheel to turn the ringer off.

item.

and others.

Sounds

Start

. Highlight the desired item and

Using the Handsfree Speaker

Note:

Using wireless phones while driving may cause distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations.

You can use your phone’s handsfree speaker on calls without holding the phone to your ear.

During a call, press the

or press

. Your phone displays

Spkrphone On

off or end the call.

Note:

phone is connected to a car kit or headset.

The handsfree speaker won’t work when your

Voice

key

Speakerphone

until you turn it

PAGE 37 ADJUSTING THE VOLUME LEARNING TO USE YOUR PHONE

Using Voice Commands

You can use voice commands to make calls, and to open and use some phone applications.

Note:

Not all phone languages support voice

recognition and voice commands.

Opening Applications

To use voice commands:

1. Press and hold the voice key for two seconds.

Your phone prompts you to say a command.

2. Say one of the following commands:

•

“Call <contact name or phone number>.”

•

“Send text <contact name>.”

•

“Look up <contact name>.”

•

“Open <program name>.”

Your phone responds to the request.

Tip:

Speak numbers at a normal speed and volume, pronouncing each digit distinctly. Avoid pausing between digits.

Notes:

•

Your phone may ask you to repeat a name or number. If the name/number isn’t valid, the phone doesn’t make the call.

•

If the phone does not recognize the name or number, the display shows a list of names/numbers, asks, “Did you say in the list. Say “Yes” to call the highlighted number, or “No” to go to the next list item.

To select the name or number manually, scroll to the name/number on the list and press the

...,” and highlights the first item

Select

key.

Switching to Airplane Mode

You can put your phone in airplane mode to safely access your address book, games, camera, and music in areas where cellular network access is prohibited (i.e. during airline flights and in hospitals).

1. To turn airplane mode on or off, press and hold the Home key (

2. Highlight and select Wireless Manager.

3. Scroll to When the is turned off.

Tip:

You can also user Bluetooth. Press and hold the Home key ( List displays. Highlight and select Wireless Manager. Scroll to When the button turns to the lighter color, it is turned

off.

). The Quick List appears.

Phone

Bluetooth

and press the center select key (s).

button turns to the lighter color, it

Wireless Manager

to turn off

). The Quick

and press the center select key (s).

PAGE 38 USING VOICE COMMANDS LEARNING TO USE YOUR PHONE

Locking & Unlocking Your Phone

Note:

You can make emergency calls on a locked

phone (see page

You can manually lock your phone to keep others from using it.

Press and hold the Home key (Y). The Quick List

opens.

Highlight and select

Check the and select the amount of time for the phone to be inactive before automatically locking.

Choose either a simple password (4-digit number) or strong numeric (a hard-to-guess numeric PIN) password type.

Enter and confirm your password. Press the (

) to switch to numeric mode.

Note:

Passwords can be numbers only—no letters.

Press

44).

Device Lock

Prompt if device unused for

Done

check box,

ALT

key

Automatically Locking Your Phone

To set your phone so that it automatically locks after a specified time, use auto phone lock:

Press

Start > Settings > More... > Security > Device

Lock > Prompt if device unused for

and select the

number of minutes.

Locking & Unlocking the Keypad

To lock the keypad

then the space bar.

Press and hold the Home key (Y). When the Quick List appears, highlight and select

Note:

After the keypad is locked, the left soft key label

changes to

Unlock

To unlock the phone keypad

the unlock screen appears, press the * key.

, press the Home key (Y) and

Key Lock

, press

Unlock

. When

To unlock the phone, press screen appears, enter your password and press

Warning: Do not forget your password

your password, you can reset your phone, but

Unlock

. When the unlock

Done

. Without

you will

lose your personalized settings and all content stored in phone memory

hold the the

Note:

center key s

phone.

A locked phone still rings or vibrates for

incoming calls or messages, and you

unlock it to answer a call

PAGE 39 LOCKING & UNLOCKING YOUR PHONE LEARNING TO USE YOUR PHONE

. To perform a hard reset,

for five seconds while turning on

do not need to

SETTING UP YOUR PHONE

5 SETTING UP YOUR PHONE

Using Profiles

Each profile uses a different set of sounds, ring styles, earpiece volume settings, or vibrations for incoming calls and other events. For example, the Outdoor profile volume is much louder than the Normal profile.

Here are the profiles you can choose:

Profiles

Normal Silent Meeting Outdoor Automatic Headset Car Speakerphone

To choose your profile:

On the home screen, scroll and select

Profile:

style name

The ring style profile’s indicator displays at the top of your home screen.

Note:

The ring style profile indicators do not display in all home screen settings and will not display if the home screen is set to Windows simple or Large Font.

Changing Ring Tones in a Profile

You can change the ring tones for incoming calls and other events. Your changes are saved in the current ring style profile.

Press

Start

Settings

Note:

Changes made to the alert settings will have no effect when using the

1. Scroll and highlight the sound you want to change,

then press the navigation key ( change it.

Sounds

Silent

profile.

) right or left to

profile

2. Press the

Note:

Done

key to save the sound setting.

If you download a sound file for a ring tone, it does not automatically save in the Sounds location. To move your sound file, press

Documents

. Highlight the sound file you want to copy to the Sound location, press and select

Application Data

Start

File Manager > My

Menu > File

Sounds

Copy to

. If the sound file is not located in the My Documents folder, go to the folder where the sound file is stored and copy it to the Sounds folder.

Setting Time & Date

Your service provider usually sets the time and date on your phone. But, if you decide to change it manually:

Start

Press

and Time

1. In

Settings

Time Zone

your time zone.

2. In

Date

, edit the month, day,

or year.

To change the month, day, and year, press the (

) to enter numeric

entry mode.

3. In

Time

, edit the hour, minute, and second.

The change the hour, minute, and second press the

Alt

key (=) to enter numeric entry mode.

4. Press

Done

You can specify the date and time style by changing the regional settings. Press

Regional Settings

Clock & Alarm

Date

, use the navigation key (S) to select

Alt

key

to save the clock and date settings.

Start

Settings

More...

PAGE 40 USING PROFILES SETTING UP YOUR PHONE

Personalizing the Home Screen

Set a photo, picture, or animation as a wallpaper (background) image or change your layout and color scheme on your home screen.

Press

Start

Settings

Options

Home Screen Layout

Color Scheme

Background Image

Time out

Changing Background Image

Want to copy an image from your PC to your phone to use as a background image?

Note:

You must have ActiveSync on your PC installed as

described on page

1. Connect the phone to your PC.

2. On your PC, copy the image file you want. The file format must be .gif, .jpg, or .bmp.

3. In ActiveSync on your PC, click Explore and doubleclick My Windows Mobile device.

4. Double-click Application Data, double-click Home, and paste the image into that folder.

Home Screen

Select a layout for the Home Screen.

Select a color scheme for the display.

Select a picture for your wallpaper image, or

None

for no wallpaper.

Select the time interval before the display will go inactive or

Never

16.

Note:

If you download a picture file for a wallpaper, it does not automatically save in the Pictures folder. To move your picture file, press

My Documents

. Highlight the picture file you want to

copy to the My Pictures location, press

Copy to

and select

My Documents

Start

File Manager

Menu > File

My Pictures

. If the picture file is not located in the My Documents folder, go to the folder where the sound file is stored and copy it to the My Pictures folder.

Setting the Backlight

To save battery life, your you’re not using your phone. The backlight turns back on when you press a key. To set how long your phone waits before the backlight turns off:

Press

Start > Settings

Management

Backlight time out on AC

To save battery life, the you’re not using your phone. The display turns back on when press a key. To set how long your phone waits before the display turns off:

Press

Start > Settings

Management

backlight

More...

turns off when

Power

Backlight time out on battery

display

can turn off when

More...

Power

Display Time out

and

Selecting Answer Options

You can use additional, alternative methods to answer an incoming call. To activate or deactivate an answer option, press >

Any key answer

When selected, you can put the first call on hold and answer the second call by pressing between calls, press

To postpone answering the call, press sent to voicemail.

Start

Settings

Swap

Call Options

Answer

Ignore

. To switch

. The call is

PAGE 41 PERSONALIZING THE HOME SCREEN SETTING UP YOUR PHONE

Installing Third Party Applications

Third-party applications, or add-on programs, include email, to mobile office and productivity software. These products can typically be downloaded and installed immediately. Both commercial and free applications are available on the Internet that are compatible with the MOTO Q. For more information see the Applications Catalog on the MOTO Q Support website at: www.motorola.com/support/Q.

PAGE 42 INSTALLING THIRD PARTY APPLICATIONS SETTING UP YOUR PHONE

CALLING FEATURES

6 CALLING FEATURES

To make and answer calls, see page 7.

Turning off a Call Alert

You can use the thumb wheel to turn off the ringer before answering the call.

Viewing Recent Calls

Your phone keeps a list of incoming and outgoing calls, even for calls that didn’t connect. The most recent calls are listed first. The oldest calls are deleted as new calls are added.

1. Press

2. Highlight a call.

Start > Call History

•

To call the number, press N.

•

To see call details (like time and date), press the

center select key

•

To see

Menu Options

, press

from the Call

History screen. This menu includes:

Options

Find Contact

Find this phone number in your Contacts.

Send Text Message

E-mail

Send a text message to this phone number

Send an e-mail message to this Contact.

Save to

Save this number to a Contact.

Contacts

Filter

Filter all calls in the Call History list. Filtering calls allows you to group calls in a specific matter. For example, if you filter the list for all Missed Calls, all the incoming phone calls that you did not answer will be listed first.

Using Redial

1. Press N

from the home screen to see the dialed

calls list.

2. Highlight the entry you want to call, then

f you hear a

Number Busy

busy signal

and you see

, press N or the

RETRY

press N.

Call Failed,

key to redial the number. When the call goes through, your phone rings or vibrates one time, displays

Redial Successful

, and

connects the call.

Viewing Missed Calls

Your phone keeps a record of your unanswered calls.

1. Press

2. Press

Start > Call History

Filter > Missed Calls

View Timers

View the call times for this call and all calls.

Delete/ Delete List

Delete this call from the Call History.

PAGE 43 Turning off a Call Alert CALLING FEATURES

Using Caller ID

Calling line identification

(caller ID) shows the phone

number for an incoming call on your home screen.

Your phone shows the caller’s name and picture when they’re stored in your phonebook, or

Incoming Call

when caller ID information isn’t available.

You can set your phone to play a distinctive ring for specific entries in your phonebook (see page 48).

Dialing Emergency Calls

Your service provider programs one or more emergency phone numbers, such as 911 or 112, that you can call under any circumstances, even when your phone and keypad are locked.

Note:

Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

1. Dial the emergency number.

2. Press N.

Dialing International Calls

If your phone service includes international dialing, press and hold code (indicated by dial the country code and phone number.

to insert your local international access

). Then, press the keypad keys to

Calling with Speed Dial

You can use speed dialing in two ways: quick access for up to 98 phone numbers and shortcuts to features found in the Start menu including e-mail, calendar, and Bluetooth Manager.

To access speed dial entries, press and hold the singledigit speed dial number for one second. If the speed dial is two digits, press the first digit, then press and hold the second digit. The phone dials the phone number, opens a new e-mail message, or goes to the Web page.

Phone Numbers

You can set the speed dial to call the entries in your phone’s contact list:

1. Press

2. Scroll to the desired contact and press the center

3. Select the phone number, e-mail address, or web for

4. Press

5. In the

6. Press

Note:

To delete a speed dial, press [

entry

Start

select key (

Contacts

which to create the speed dial.

Add to Speed Dial.

Keypad Assignment

, select the speed dial

number to use.

Done

Speed dial 1 is reserved for calling your voicemail.

Start

] >

Menu > Delete

Speed dial

PAGE 44 Using Caller ID CALLING FEATURES

Menu Shortcuts

You can set a shortcut speed dial to open an application on your phone:

1. Press

2. Scroll to the icon of the application you want a

3. In the

Start

shortcut for and press

Keypad Assignment

number to use.

Add to Speed Dial

, select the speed dial

Using Three-Way Calling

While connected to a call:

1. Place your current call on hold by pressing N.

2. Enter the number of the other person you wish to connect to a three-way call and press

3. After you are connected to the other phone, you can press

to connect both calls.

4. Press

Note:

[

entry

Using Voicemail

Done

To delete a shortcut, press

] >

Menu > Delete

Start

Speed dial

Your network stores the voicemail messages you receive. To listen to your messages, call your voicemail number.

Note:

Your service provider may include additional

information about using this feature.

When you displays the voicemail message indicator

New Voicemail

check

Press and hold the

Note:

receive

a voicemail message, your phone

and

voicemail messages:

key.

If you want to store a p (pause), w (wait), or n (number) character in your voicemail number, create a contact and when entering the voicemail number press

to insert these special characters.Then, you can

use the entry to call your voicemail.

PAGE 45 Using Voicemail CALLING FEATURES

PHONE FEATURES

7 PHONE FEATURES

Menu Map

Contents of the Main Menu

(

From the home screen, press the

Internet Explorer

Explore Windows Mobile MSN Mobile WindowsMedia.com

Ta s ks

Windows Media

My Music My Videos My TV My Playlists Now Playing

Calendar

Messaging

Text Messages Outlook E-mail MMS

Contacts

ActiveSync

Call History

Settings

(see Contents of the Settings Menu)

Games

Bubble Breaker Solitaire

Voice Notes

Start Left Soft Key.)

Pictures & Videos

Accessories

Audio Enhancement Calculator Download Agent

File Manager

Help and QuickStart

Media Center

Images Videos Audio

Pocket MSN

MSN Messenger MSN Hotmail Compose Hotmai MSN Mobile Home

Speed Dial

Voicemail

Voice Recognition

Bluetooth

Bluetooth Manager BT PC Remote BT Send Object

System Tools

Master Reset Memory Manager Task Manager

Contents of the Settings Menu

Call Options

Sounds

Ring tone Reminders New e-mail New voice message New instant message Alarm clock Exclamation Question Warnings Keypad control

Profiles

Normal Silent Meeting Outdoor Automatic Headset Car Speakerphone

Home Screen

Home screen layout Color scheme Background image Time out

Clock & Alarm

Date and Time Alarm

Connections

Beam Proxy VPN USB to PC

Security

Device Lock Certificates

Remove Programs

Power Management

Main battery Backlight timeout on battery Backlight timeout on AC Display time out

Accessibility

System font size Multipress time out Confirmation time out In-call alert volume

Regional Settings

Language Locale Short date style Long date style Time format Positive number Negative number Positive currency Negative currency

Owner Information

Name Telephone number E-mail address Notes

About

Error Reporting

Phone Settings

Phone Information Alerts Network My Telephone Number DTMF Voice privacy

TTY Settings

Unread Message Alert

Text Input Settings

Language Dictionary

This is the standard main menu layout. Menu organization and feature names may vary on your phone. Not all features may be available on your phone. If desired menu item does not appear on your screen, use the navigation key, thumb wheel, or press the

PAGE 46 MENU MAP PHONE FEATURES

More Left

soft key.

Calling Features

Feature Description

Speed dial

TTY calls

Make call from hyperlink phone number

Make call from the contact list

Speed dial a contact by pressing and holding the speed dial number. If the speed dial is two digits, press the first digit, and press and hold the second digit.

If you forget Aunt Mildred’s speed dial number, press

Start > Contacts

, and find

her entry.

Set up your phone for use with an optional TTY device:

Press

Start > Settings

TTY Settings

TTY does not work from mobile phone to mobile phone.

You can quickly dial a phone number from an e-mail or text message that contains a hyperlink phone number. A hyperlink phone number is underlined in the same manner as a Web site address.

From a message containing a hyperlink phone number, select the phone number and press the

Call/Answer

key (N).

You can quickly dial a phone number from the contact list.

Press

Start > Contacts

Tip:

If you have a long list of contacts, you can use a shortcut to find the contact

. Select the contact and press the

Call/Answer

key (N).

you want. Enter the first few letters of the contact's name. The phone searches through the contact list and displays the name.

PAGE 47 CALLING FEATURES PHONE FEATURES

Contacts

Feature Description

Add new entry

Edit contact

Dial number

Search for contact

Set ringer ID for a contact

Set picture ID for contact

Press

Start > Contacts

New

Enter information for the new contact.

If someone who isn't in your list of contacts calls you or sends you a message, you can create a contact from Call History, or from the message by clicking

Save to Contacts

Press

Start

Contacts

Contact Name

and then

Edit

Call a number stored in the phonebook:

Start > Contacts

Press

Contact Name

> N.

The contact’s default number is dialed.

To call a phone number other than the default, click the contact, scroll to the number you want to dial, and press the

Call/Answer

key (N).

Enter the first few letters of the contact's name. The phone searches through the contact list and displays the name.

To easily identify who is calling you by the ring tone, you can assign a custom ring tone to each contact.

Press

Start

Contacts

Tone

Press

Start

Contacts

Tip:

If you want to instantly take a picture with the camera for this contact, press

the

Camera

key (e) and take a picture.

Want to remove a picture ID? Press

Edit > Remove Picture

Contact Name

Start

and then

Contacts

Edit > Custom Ring

Edit > Picture

> Contact Name

> Menu

Voice dial

To use voice dialing:

Press

PAGE 48 CONTACTS PHONE FEATURES

Start > Voice Recognition

Feature Description

Set category for contact

Set category view

Send contact to another device

Press

Start

Contacts

Contact Name

and then

Edit > Categories

Categories are shared between your appointments, contacts, and tasks. A category will remain in the list of shared categories as long as it is assigned to at least one appointment, contact, or task.

Press

Start

Contacts and then

Filter

Use a Bluetooth connection or Infrared connection to send a contact to another phone, computer, or device:

Press

Start

Contacts

Contact Name

and then

Beam Contact

Status information displays, indicating the name of the device to which the phone is beaming, and whether the beaming process is pending, finished, or was unsuccessful.

For more about Bluetooth connections, see page 28.

Note:

Remember you must have an active Bluetooth connection.

PAGE 49 CONTACTS PHONE FEATURES

Personalizing

Feature Description

Language

Ring volume

Accessibility

Sounds

Alarm

Press

Start

Settings

Note:

You must turn your phone off and on again for the changes to take effect.

More...

Regional Settings

If you want to specify a language for reading e-mail, while reading a message press

Languages

Press

Start

Highlight the desired profile, and press

Under

Ring Volume

Settings> Profiles

Edit

, press the navigation key (S) left or right to adjust the volume

for that profile.

Tip:

You can turn off the ringer volume instantly when an incoming call comes in—

just use the thumb wheel.

You can set system font size, multipress timeout, confirmation timeout, and incall alerts:

Start

Press

Settings

More...

Accessibility

Change the default sounds for ring tone, reminders, new messages, alarm clock, or keypad controls.

Press

Start

Settings > Sounds

Note:

Changes made to the alert settings will have no effect when using the

Silent

profile.

Press

Start > Settings

Need to change or set the alarm alert style? Press

Clock & Alarm

Alarm

Start > Settings

Sounds

Alarm Clock

Owner information

Entering and displaying owner information are best practices; they allow someone to return the phone to you in case it is lost:

Press

Master reset

Reset all options except

Press

PAGE 50 PERSONALIZING PHONE FEATURES

Start

Settings

System Tools > Master Reset

More... > Owner Information

unlock

code, security code, and lifetime timer:

Call Times & Costs

Network connection time

the moment you end the call by pressing

Note:

The amount of network connection time you track on your timer may not equal the amount of time for which

you are billed by your service provider. For billing information, contact your service provider.

Feature Description

is the elapsed time from the moment you connect to your service provider's network to

. This time includes busy signals and ringing.

Call times

Reset call timers

The default reminder time for tasks and calendar items is 15 minutes. To change this default:

Press

Start > Call History

Reset all call timers to zero (0), except for the Lifetime calls timer.

Press

Start > Call History

Reset Timers

and then

View Timers

and then

Handsfree

Note:

The use of wireless phones while driving may cause distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.

Feature Description

External speakerphone

Auto answer

headset)

(car kit or

Activate a connected external speakerphone during a call:

Press the

Note: Menu > Speakerphone On.

Change to the headset profile to automatically answer calls when connected to a car kit or headset:

Press

Note:

Voice

key or press

With a Bluetooth headset press

Start

Settings

Edit the profile (see page 40) and enable the

Profiles

Speakerphone On

Headset

Handsfree Off

Auto-answer in

and then press

option.

PAGE 51 CALL TIMES & COSTS PHONE FEATURES

Network Connections

Feature Description

Create proxy, Virtual Private Network (VPN), or dial-up network

Beam

Every network connection is different. You should gather all of the relevant information or network settings you need before starting this process:

Press

Start

Settings

Note:

For more information about this feature, see page 9.

Connections

VPN

To allow your phone to receive data beamed from other devices (via Bluetooth or Infrared):

Press

Start

Settings

Connections

Beam

PAGE 52 NETWORK CONNECTIONS PHONE FEATURES

Calendar

Feature Description

Add new calendar event

View calendar event

Calendar event reminder

Send calendar event to another device

Calculator

Press

Start

Calendar

Note:

To schedule an all-day event, under

and then

New Appointment

End time

, select

All day event

All-day events do not occupy blocks of time in Calendar; instead, they appear in banners at the top of the calendar.

To quickly view today's agenda, on the home screen, scroll and press the center select key (

To view previous or approaching dates, scroll left or right, or click

Go to Date

) on an upcoming appointment (if one is present).

The default reminder time for tasks and calendar items is 15 minutes. To change this default:

Press

Start

Calendar

and then

Options

Set Reminders

Use a Bluetooth connection to send a calendar event to another phone, computer, or device:

From the calendar item, press

Send via Bluetooth

If using Bluetooth, select the device to which you want to send the item.

If using infrared, press

Beam Appointment

and align the infrared (IR)

> ports at close range until the target device name appears, and then select the device to which you want to send the item.

For more about Bluetooth connections, see page 28.

Press

Start > Accessories

Calculator

Respond to a meeting request

You can receive and respond to Outlook meeting requests on your phone in a similar manner as you do in Outlook on your PC

Press

and then

PAGE 53 CALENDAR PHONE FEATURES

Start

Messaging >Outlook E-mail >E-mail Account

Decline,Tentative

Meeting Request

Security

Feature Description

Manage certificates

Enable or disable Internet access certificates stored on your phone:

Press

Start

Note:

Certificates are used to verify the identity and security of Web sites when you

download files or share information.

Phone Information

Feature Description

Software version

Memory & storage

To view your phone software version:

Press

Start

To view your available and total memory capabilities of your phone and memory card use Memory Manager.

Press

Start

Settings

System Tools

More...

Security

More...

Memory Manager

Certificate

About

PAGE 54 SECURITY PHONE FEATURES

Fun & Games

Feature Description

Manage pictures

Manage sounds

Manage video clips

Start web-browser

Download objects from web page

Disconnect web sessions

Play games on your phone

Press

Start

Pictures & Videos

Manage ring tones and music that you have downloaded or composed:

Press

Start

Windows Media

For more information about Windows Media, see page 27.

Press

Start

Pictures & Videos

For more information about Windows Media, see page 27.

Press

Start

Internet Explorer

For more information about Internet Explorer Mobile, see page 28.

Download a picture, sound, or phone theme from a Web page:

Highlight the file, press the

Note:

Normal airtime and/or service provider usage charges apply.

Press the

Press

End Session

Start

Games

key.

Select

key, press the

Store

key.

PAGE 55 FUN & GAMES PHONE FEATURES

SERVICE AND REPAIRS

8 SERVICE AND REPAIRS

If you have questions or need assistance, we’re here to help. Go to www.motorola.com/consumer/support, where you can select from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

PAGE 56 SERVICE AND REPAIRS

SPECIFIC ABSORBTION RATE

9 SPECIFIC ABSORBTION RATE DATA

The model wireless phone meets the government’s requirements for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC

and by the Canadian regulatory authorities is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC and by Industry Canada with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) reported to the FCC and available for review by Industry Canada. See the printed

Information

for SAR values.

While there may be differences between the SAR levels of various phones and at various positions, they all meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications

& Internet Association (CTIA) Web site: http:// www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web site: http://www.cwta.ca

1 In the United States and Canada, the SAR limit for

mobile phones used by the public is 1.6 kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

2 The SAR information includes the Motorola testing

protocol, assessment procedure, and measurement uncertainty range for this product.

guide or http://www.motorola.com/rfhealth

Important Safety and Legal

watts/kg (W/

PAGE 57 SPECIFIC ABSORBTION RATE

MICROSOFT EULA

10 MICROSOFT EULA

Microsoft License

You have acquired a device ("DEVICE") that includes software licensed by Motorola, Inc. ("Motorola") from one or more third-party licensors ("Licensor"), for use in connection with wireless network services provided under separate agreement between you and a wireless telecommunications provider ("Mobile Operator"). Those installed software products provided by Licensor, as well as associated media, printed materials, and "online" or electronic documentation ("SOFTWARE") are protected by international intellectual property laws and treaties. SOFTWARE includes software already installed on the DEVICE ("DEVICE Software") and Licensor software contained on any CD-ROM disk accompanying the DEVICE ("Desktop Software").

IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT ("EULA"), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT MOTOROLA FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT).

1. GRANT OF SOFTWARE LICENSE. This EULA grants you the following license:

1.1. DEVICE Software. You may use the DEVICE Software as installed on the DEVICE (including as installed on removable media installed in the DEVICE). All or certain portions of the DEVICE Software may be inoperable if a proper account is not established or maintained with an appropriate Mobile Operator, or if the Mobile Operator's network facilities are not

operating or configured to operate with the DEVICE software.

1.2. Desktop Software. If Desktop Software is included with your DEVICE, you may install and use the Desktop Software on one (1) or more computers to exchange information with one (1) or more computing devices that contain a compatible version of the DEVICE Software. For other software component(s) contained in the Desktop Software, you may install and use such components only in accordance with the terms of the printed or online end user license agreement(s) provided with such component(s). In the absence of an end user license agreement for particular component(s) of the Desktop Software, you may install and use only one (1) copy of such component(s) on the DEVICE or a single computer with which you use the DEVICE.

1.3. Back-up Copy. If Motorola has not included a backup copy of the DEVICE Software with the DEVICE, you may make a single back-up copy of the DEVICE Software. You may use the back-up copy solely for archival purposes.

1.4. Microsoft Windows® 2003. If Microsoft Outlook® 2002 is included with your Device, the following terms apply to your use of Microsoft Outlook

2002: (i) regardless of the information contained in "Software Installation and Use" section of the online EULA you may install one (1) copy of Microsoft Outlook

2002 on one (1) computer to use, exchange data, share data, access and interact with the DEVICE, and (ii) the EULA for Microsoft Outlook

2002 is between Motorola and the end user - not between the PC manufacturer and end user.

2. Speech/Handwriting Recognition. If the Software includes speech and or handwriting recognition component(s), you should understand that speech and handwriting recognition are inherently statistical

PAGE 58 MICROSOFT EULA

processes; that recognition errors are inherent in the processes; that it is your responsibility to provide for handling such errors and to monitor the recognition processes and correct any errors. Motorola, its affiliates, subsidiaries, or suppliers shall not be liable for any damages arising out of errors in the speech and handwriting recognition processes.

3. Limitations on Reverse Engineering, Decompilation and Disassembly. You may not reverse engineer, decompile, or disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.

4. Single DEVICE. The Device Software is licensed with the DEVICE as a single integrated product. The DEVICE Software may only be used as part of the DEVICE, notwithstanding any installation of the DEVICE Software on removable media.

5. Single EULA. The package for the DEVICE may contain multiple versions of this EULA, such as multiple translations and/or multiple media versions (e.g., in the user documentation and in the software). Even if you receive multiple versions of the EULA, you are licensed to use only one (1) copy of the DEVICE Software.

6. Rental. You may not rent or lease the SOFTWARE.

7. Software Transfer. You may not permanently transfer any of your rights under this EULA with regard to the DEVICE Software or Desktop Software, except as permitted by the applicable Mobile Operator. In the event that the Mobile Operator permits such transfer, you may permanently transfer all of your rights under this EULA only as part of a sale or transfer of the DEVICE, provided you retain no copies, you transfer all of the SOFTWARE (including all component parts, the media and printed materials, any upgrades or backup copies, this EULA and, if applicable, the Certificate(s) of Authenticity), and the recipient agrees to the terms of this EULA. If the Software is an upgrade, any transfer must include all prior versions of the SOFTWARE.

8. Termination. Without prejudice to any other rights, Motorola, Licensor and their affiliates and subsidiaries may terminate this EULA if you fail to comply with the terms and conditions of this EULA. In such event, you must destroy all copies of the SOFTWARE and all of its component parts.

9. Security Updates. The SOFTWARE may include digital rights management technology. If SOFTWARE does contain digital rights management technology, content providers are using the digital rights management technology ("Licensor DRM") contained in the SOFTWARE to protect the integrity of their content ("Secure Content") so that their intellectual property, including copyright, in such content is not misappropriated. Owners of such Secure Content ("Secure Content Owners") may, from time to time, request Licensor, or its subsidiaries or affiliates to provide security related updates to the Licensor DRM components of the SOFTWARE ("Security Updates") that may affect your ability to copy, display and/or play Secure Content through Licensor software or third party applications that utilize Licesnor DRM. You therefore agree that, if you elect to download a license from the Internet which enables your use of Secure Content, Licensor, its subsidiaries or affiliates may, in conjunction with such license, also download onto your DEVICE such Security Updates that a Secure Content Owner has requested that Licensor, its subsidiaries or affiliates, to distribute. Licensor, its subsidiaries or affiliates will not retrieve any personally identifiable information, or any other information, from your DEVICE by downloading such Security Updates.

10. Consent to Use of Data. You agree that Licensor, its subsidiaries and affiliates may collect and use technical information gathered in any manner as part of product support services related to the SOFTWARE.. Licensor, its subsidiaries and affiliates may use this information solely to improve their products or to provide customized services or technologies to you. Licensor, its affiliates

PAGE 59 MICROSOFT EULA

and subsidiaries may disclose this information to others, but not in a form that personally identifies you.

11. Internet Gaming/Update Features. If the SOFTWARE provides, and you choose to utilize, the Internet gaming or update features within the SOFTWARE, it is necessary to use certain computer system, hardware, and software information to implement the features. By using these features, you explicitly authorize Licensor, its subsidiaries and affiliates, and/or their designated agent to use this information solely to improve their products or to provide customized services or technologies to you. Licensor, its subsidiaries and affiliates may disclose this information to others, but not in a form that personally identifies you.

12. Internet-Based Services Components. The SOFTWARE may contain components that enable and facilitate the use of certain Internet-based services. You acknowledge and agree that Licensor, its affiliates and subsidiaries may automatically check the version of the SOFTWARE and/or its components that you are utilizing and my provide upgrades or supplements to the SOFTWARE that may be automatically downloaded to your Device.

13. Links to Third Party Sites. The SOFTWARE may provide you with the ability to link to third party sites through the use of the SOFTWARE. The third party sites are NOT under the control of Motorola, Licensor, or their affiliates or subsidiaries. Neither Motorola, Licensor, nor their affiliates or subsidiaries are responsible for (i) the contents of any third party sites, any links contained in third sites, or any changes or updates to third party sites, or (ii) webcasting or any other form of transmission received from any third party sites. If the SOFTWARE provides links to third party sites, those links are provided to you only as a convenience, and the inclusion of any link does not imply an endorsement of the third party site by Motorola, Licensor, or their affiliates or subsidiaries.

14. Additional Software/Services. The SOFTWARE may permit Motorola, Licensor, their affiliates or subsidiaries to provide or make available to you SOFTWARE updates, supplements, add-on components, or Internet-based services components of the SOFTWARE after the date you obtain your initial copy of the SOFTWARE ("Supplemental Components").

14.1. If Motorola, or its subsidiaries or affiliates, provides or makes available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply.

14.2. If Licensor, or its affiliates or subsidiaries, make available Supplemental Components, and no other EULA terms are provided, then the terms of this EULA shall apply, except that the Licensor, or its affiliates or subsidiaries providing the Supplemental Component(s) shall be the licensor of the Supplemental Component(s).

14.3. Motorola, Licensor, and their affiliates and subsidiaries reserve the right to discontinue any Internetbased services provided to you or made available to you through the use of the SOFTWARE.

15. UPGRADES AND RECOVERY MEDIA.

15.1. DEVICE Software. If the DEVICE Software is provided by Motorola, its subsidiaries or affiliates, separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other means, and is labeled "For Upgrade Purposes Only" or "For Recovery Purposes Only", you may install one copy of such DEVICE Software on the DEVICE as a replacement copy for the existing DEVICE Software and use it in accordance with the Grant of Software License section of this EULA.

15.2. Desktop Software. If any Desktop Software component(s) is provided by Motorola, its subsidiaries or affiliates, separate from the DEVICE on CD ROM disk(s) or via web download or other means, and labeled "For Upgrade Purposes Only" or "For Recovery Purposes

PAGE 60 MICROSOFT EULA

Only", you may (i) install and use one copy of such component(s) on the computer(s) you use to exchange data with the DEVICE as a replacement copy for the existing Desktop Software component(s).

16. COPYRIGHT. All title and intellectual property rights in and to the SOFTWARE (including but not limited to any images, photographs, animations, video, audio, music, text and "applets", incorporated into the SOFTWARE), the accompanying printed materials, and any copies of the SOFTWARE, are owned by Motorola, Licensor, and/or their affiliates, subsidiaries, or suppliers. You may not copy the printed materials accompanying the SOFTWARE. All title and intellectual property rights in and to the content which may be accessed through use of the SOFTWARE is the property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This EULA grants you no rights to use such content. All rights not specifically granted under this EULA are reserved by Motorola, Licensor, their affiliates, subsidiaries, and suppliers.

17. EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is subject to U.S. export jurisdiction. You agree to comply with all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as enduser, end-use and destination restrictions issued by U.S. and other governments.

18. PRODUCT SUPPORT. Product support for the SOFTWARE is NOT provided by Licensor, its parent corporation, or their affiliates or subsidiaries.

19. NO LIABILITY FOR CERTAIN DAMAGES. EXCEPT AS PROHIBITED BY LAW, MOTOROLA, LICENSOR, AND THEIR AFFILIATES AND SUBSIDIARIES, SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE SOFTWARE. THIS LIMITATION

SHALL APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE.

20. FOR APPLICABLE LIMITED WARRANTIES AND SPECIAL PROVISIONS PERTAINING TO YOUR PARTICULAR JURISDICTION, PLEASE REFER TO YOUR WARRANTY BOOKLET INCLUDED WITH THIS PACKAGE OR PROVIDED WITH THE SOFTWARE PRINTED MATERIALS.

PAGE 61 MICROSOFT EULA

INDEX

SETTING UP YOUR PHONE

accessibility 50 accessories 5, 51 accessory connector port 1 ActiveSync 16 airplane mode 38 alarm 50 alert

set

turn off 27, 28, 37, 43 Amp’d Live 10 Amp’d Mobile 10 animation 55 answer a call 41 answering a call 7 audio enhancement 27 auto-lock, phone 39 automatic e-mail setup 18

background 41 backlight 41 battery

charging

extending battery life 5

installing 6 battery indicator 33 battery life, extending 28, 41 Bluetooth connection 49, 53 Bluetooth remote 29 Bluetooth wireless 28 bonding (See Bluetooth wireless) browser

disconnect 55

calculator 53 calendar 53 call

answer

answering 7 dialing 7 make 48 making 7

receiving 7 call timers 51 caller ID 44, 48 camera 24, 25 cancel message 21 car kit 51 certificate management 54 codes 39 contacts 44, 47, 48 copy files 26, 29

daily news 12 date, 40 datebook 53 delete program 36 dial a phone number 48 dialed calls 43 dialing a number 7 digit dial (voice) 38 display 33, 41 download files 26

PAGE 62 INDEX

INDEX

e-mail 18, 21 e-mail address 48 e-mail setup 18 emergency number 44 end key 1 enter

numbers

text 36 Excel 20 exchange server 19

file manager 35 filter 43 5-way navigation key 1

games 12, 55 global access look up 21

handsfree 51 handsfree speaker 37 headset 51 headset jack 1 help 15 home screen 33, 41 hyperlink, phone number 47

Incoming Call message 44 incoming call, answering 7 international access code 44 ISP 21

joystick 1

key

end

5-way navigation 1 left soft key 1 menu 1 power 1 right soft key 1 send 1 voice 1 volume control 1

language 50 left soft key

functions linking (See Bluetooth wireless) lock, phone Low Battery message 33 lowercase 36

PAGE 63 INDEX

INDEX

make a call 48 make call 47 making a call 7 manual e-mail setup 18 master reset 50 media player 50, 55

buttons 27

controls 27 menu 34 menu icons 33, 35 menu indicator 33 menu key 1 menu shortcuts 45 message indicator 33 message options 20 message reminders 50 messages 18, 21

e-mail 18

text 18 Microsoft Word 20 missed call 43 Missed Calls message 43 mode, airplane 38 modem 30 multimedia message 18 music 22, 55

name dial 38 navigation key 5 netowrking 30 network settings 52

number. See phone number numbers numeric entry mode 37

object exchange 29 open

program open program 35 operator hosted e-mail 18 optional accessory, defined 5 optional feature, defined 5 options

message

video 25 over the air (OTA) 16 owner information 50

pairing (See Bluetooth wireless) PC remote PDF 20 personalize 50 phone 39

phone number 7, 48 phonebook 47 photo 24, 55 picture 55 picture ID 44, 48 playing music 22 power key 1 PowerPoint 20

open to answer 7

news 12

PAGE 64 INDEX

priority 21

INDEX

profile 40 program, open 35

ratings 13 received calls 43 recent calls 43 redial 43 reminders 50 remote control 29 remove program 36 return a call 43 right soft key, functions 1 ring style indicator 34 ring style, setting 40 ring tone 55 ring tones 10, 11 ringer ID 44, 48 ringer volume 50 roam indicator 33

security

lock

send and receive messages 20 send key 1 shortcuts 45 smart key 37 soft keys 1, 33 software update 9 sounds 50, 55 speakerphone 51 speed dial 44, 47 sports 11 Start menu 5 store your number 7

symbol entry mode 37 sync (cable) 17 sync (infrared) 17 synch (Bluetooth) 17 synchronize 16 synchronizing with computer 16

task manager 36 telephone number. See phone number text

text entry 36 third party applications 42 thumb wheel 34 time, setting 40 timers 43, 51 TTY calls 47 turning on, phone 7 TV 11

unlock

phone

unlock code 39 uppercase 36

video 55

controls 27

playing clips 26 video clips 25 video options 25 videos 10

voice commands 38

PAGE 65 INDEX

INDEX

voice key

illustration voice recognition 38 voicemail 44, 45 voicemail message indicator 45 volume 37, 50 volume keys 1

wallpaper 11, 41 web 55 web browser 55

disconnect 55 web page 55 web, phone number 47

your phone number 7

PAGE 66 INDEX

ampd.com

Moto Q User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 WELCOME

CONTENTS

2 GETTING STARTED

About This Guide

Getting Help

Battery Tips

Installing the Battery

Charging the Battery

Turning Your Phone On & Off

Answering a Call

Activing Your Phone

Using the Thumb Wheel

Carrying Your Phone

Viewing Your Phone Number

Setting Up Voicemail

Making a Call

Transferring Your Number

Using the Infrared Port

Inserting a Memory Card

Getting Software Updates

Additional Information

Upgrading Amp’d Live

3 HIGHLIGHT FEATURES

Amp’d Live™

Synchronizing Your Phone

E-mailing & Messaging

Enjoy Your Music

Taking & Sending a Photo

Recording & Playing Video Clips

Copying Media Files

Using the Media Player

Adjusting Audio

Browsing the Web

Using Bluetooth Wireless

Using a Modem-Link

4 LEARNING TO USE YOUR PHONE

Using the Display

Using the Thumb Wheel

Using the Menus

Opening a Program

Using the File Manager

Using the Task Manager

Entering Text

Adjusting the Volume

Using the Handsfree Speaker

Using Voice Commands

Switching to Airplane Mode

Locking & Unlocking Your Phone

Automatically Locking Your Phone

Locking & Unlocking the Keypad

5 SETTING UP YOUR PHONE

Using Profiles

Setting Time & Date

Personalizing the Home Screen

Setting the Backlight

Selecting Answer Options

Installing Third Party Applications

6 CALLING FEATURES

Turning off a Call Alert

Viewing Recent Calls

Using Redial

Viewing Missed Calls

Using Caller ID

Dialing Emergency Calls

Dialing International Calls

Calling with Speed Dial

Using Three-Way Calling

Using Voicemail

7 PHONE FEATURES

Menu Map

Calling Features

Contacts

Personalizing

Call Times & Costs

Handsfree

Network Connections
