3PC Oversized Rocker Set
155426
Please keep this instruction manual for future reference
Assembly Instructions
& User’s Manual
Customer Serv ice: (888) 922-2336
7:00 am to 12:00 am CST (daily)
Live Chat at: www.acad e my.com
Email: customerserv ice@a ca demy.com
----------------------OR--------------------
(877) 579-1550 8:30am t o 5:30pm Monday thru Friday, EST
(Made in China)
Table of Contents
Warnings………………………………………………………………..…2
Parts List……………………………………………………………….. …3
Assembly Instructions…………………………………..……………. .4 -8
Care and Maintenance……………………………………………...…...9
Warranty Information………………..……......... ........ ........ ........ ...... ..10
Page 1 of 10
Note: Before beginning assembly of product, make sure all
parts are present. Compare parts with package content list
and contents on next page. If any part is missing or
damaged do not attem pt to assemble the unit. Contact
customer service for replacement parts .
Sku:113243199
Style#: 155426
Warnings
Page 2 of 10
• Weight Limit Chair: 400 Lb
• Weight Limit Table: 50 Lb
• Children should not open or close items in this set
• To avoid injuries, use care when folding chairs and table
Parts List
A Table Qty: 1
B Chair Qty: 2
Page 3 of 10
Assembly Instructions
Step 1:
Remove the packaging material carefull y, place the
table onto soft surface.
Step 2:
Hold the table top and unfold the table accordi ng to
the right figure.
Page 4 of 10
Assembly Instructions
Step 3:
Assembly finished.
Step 4:
Remove the packaging material car efully, place the
chair onto soft space.
Page 5 of 10
Assembly Instructions
Step 5:
Unfasten hook on the side of the chair.
Fixing the chair l eg and pull the backrest ac cor di ng
to the right figure.
Step 6:
Fully unfolded the chair, press the loc k butt on to
secure the front leg from moving. Assembly
finished.
Page 6 of 10
Assembly Instructions
Step 7:
Step on the rear tube, pull up t he l ock button
before folding the rocker
Step 8:
Folding the chair ac cor di ng to the figure until it is
fully folded.
Page 7 of 10
Assembly Instructions
Step 9:
Secure the chair with the lock as illustrated.
Page 8 of 10
Care and Maintenance
Page 9 of 10
This patio set should be cleaned on a regular basis to
promote safe use and prolong product life.
Wipe the frame with a smooth damp cloth and air dr y.
Do not use abrasive cleaners as they may damage or
scratch the surf ac e pai nt. Do not leave this product in severe
weather conditions for extended periods. For extended life,
the patio set should be stored indoors or covered during
prolonged periods of non-use. Storing in a dry l oc ation will
help prevent rust.
Warranty Information
Page 10 of 10
This product has been manufactured under t he highest
standards of quality and workmanship. We warrant to the
original consumer purchaser that all aspects of this product will
be free of defects in m aterial and workmanship for one year
from the date of purchase. A r eplacement for any defectiv e
part will be supplied free of charge for installation by the
consumer. Defects or damage caused by the use of other than
genuine parts are not c overed by this warranty. This warranty
shall be effective from the dat e of purchase as shown in the
purchaser receipt.
This warranty is valid for the original consumer purchaser only
and excludes industrial, commercial or business use of the
product, product damage due to shipment or failure which
results from alteration, product abuse, or product misuse,
whether performed by a contractor , servi c e company , or
consumer. We will not be responsible for labor charges and/or
damage incurred in installation, r epair or replacement nor f or
incidental or cons equential damage.
