Morton Machine BTP-3 User Manual

Download
Page 1
M a n u f a c t u r e r o f Q u a l i t y T o o lin g C o m p o n e n t s
Page 2
STAINLESS STEEL COMPONENTS
HAND WHEELS
ADJUSTABLE
HANDLES
Largest selection of stainless steel parts in the industry
SPRING PLUNGERS
Pages 8-14
Pages 51-77
THUMB SCREWS
HAND KNOBS
& HANDLES
Pages 15-33
Pages 86-96
Pages 34-43
LEVELING MOUNTS
Pages 44-48
WASHERS
Pages 110-115
CLAMPING
COMPONENTS
Pages 98-129
Page 3
C a t a l o g 2 4
Manufacturing Quality Tooling Components for Over 60 Years!
Quality system certified to ISO9001:2008 standards
135 Gearhart Street
Millersburg, PA 17061
800-441-2751 Fax: 717-692-2120
[email protected]
k
Manufactured on the
latest CNC equipment
Experienced engineers and machinists
w w w . m o r t o n m a c h i n e . c o m
Morton components are
used by OEM’s all
around the world
Page 4
j
I n f o r m a t i o n
j
FFICE
O
ales office is located at 125 Gearhart
S
Street, Millersburg, Pa.
FACTORYjProduction facility is located at 527
est Main Street, Elizabethville, Pa.
W
BUSINESS HOURSjOffice hours are Monday
through Friday 8:00 am - 5:00 pm EST
PRICESjFor prices please refer to Morton's latest
price schedule. For distributor discounts inquire with a Morton salesperson. All prices are subject to change without prior notice.
DELIVERYjMorton offers same day shipment on
items from stock when the orders are placed before 1:30 pm EST. If an item is back-ordered, please check with a Morton salesperson for the expected delivery date.
MINIMUMjMinimum invoice $25.00 on all
shipments.
TERMSjNet 30 days for companies with
approved credit. Credit card payment on orders until open credit has been established.
ORDER ONLINEjOrders may be placed at
www.mortonmachine.com
CADjCAD models along with 2D sales
drawings are available for download/insertion at www.mortonmachine.com
FREIGHTjAll shipments are FOB Millersburg, PA.
Freight charges are billed at actual costs. Depending on weight, parts are shipped UPS or common carrier unless customer specifies special instructions.
SPECIALSjMorton can modify its standard parts
to meet special requirements. Fax your drawings and specifications to Morton's quote department. Specials are non-returnable.
SPECIFICATIONSjPlease refer to each catalog
drawing for part specifications. If tolerances are not shown, inquire with a Morton salesperson.
WARRANTYjSince the conditions of end use are
beyond the control of Morton, performance of the product cannot be guaranteed. Liability is limited to the replacement of the product within six months of purchase.
RETURNSjStandards can be returned within
three months from the date of purchase less a 15% restocking fee. Call to request an RGA number prior to sending back product.
PATENTS & TRADEMARKS
j
U.S. Patent 5.898.974 U.S. Patent 4.693.656 U.S. Patent 5.533.232 Canada Patent 1.219.151 Button Thread M-T
SAFETYjPlease refer to recommended load
capacities on all lifting devices. Machine tools can pose many safety hazards. Observe all appropriate safety precautions.
QUALITYjQuality system is certified and main-
tained to ISO 9001: 2008. Certification number 84311-IS1 NSF.
TOOLING COMPONENT
MANUFACTURERS ASSOCIATION
INTERNATIONAL
j
2
CERTIFICATIONjMaterial certification charge on
selected items. Please specify certification requests when placing order. RoHS compliant statements avail­able upon request.
CATALOGSjContact Morton or your local distrib-
utor to receive additional catalogs or price lists.
w w w . m o r t o n m a c h i n e . c o m
Page 5
A l p h a b e t i c a l I n d e x
k
Acorn Nuts........................................................101
djustable Clamping Levers..........................34-43
A
Aluminum Handwheels ....................................8-9
alanced Handles ..............................................14
B
Ball Clamping Screws ..................................82-84
Ball Detents........................................................66
Ball Handles ......................................................12
Ball Knobs..........................................................33
Ball Plungers ................................................51-54
Ball Plungers - Hex Drive ..............................53-54
Ball Plungers - Metric....................................51-54
Ball Plungers - Nylon Nose............................51-53
Ball Plungers - Press Fit................................62-64
Ball Plunger Wrenches ......................................66
Bar Knobs ..........................................................30
Brass Knobs ......................................................33
Brass Thumb Screws ........................................91
Bullet Nose Liners..............................................79
Bullet Nose Pins ................................................78
Button Jig Feet ..................................................85
Button Thread Levers ........................................43
Button Thread Nuts ..................................107-109
Button - Rest ................................................80-81
C Washers..................................................113-115
Cams................................................................121
Cast Iron Hand Knob Screws ........................17-18
Cast Iron Handwheels..........................................8
Clamp Assemblies - Hook ................................129
Clamp Rests ....................................................129
Clamp Straps ............................................124-128
Clamps - Fixture........................................124-128
Clamping Handles..............................................13
Clamping Levers ..........................................34-43
Check Nuts ......................................................105
Chrome Plated Clamping Levers........................42
Collar Nuts ................................................100-101
Construction Balls ............................................80
Control Knobs ....................................................24
Coupling Nuts ..................................................105
Crank Handles ..............................................12-14
Detents ..............................................................66
Domed Knobs ....................................................15
Double Cams....................................................121
Dowel Locating Pins ..........................................78
Dowel Liners ......................................................79
Equalizing Nuts ................................................105
Equalizing Washers ..........................................112
Extension Nuts ................................................105
Eye Bolts ..................................................120-123
Fender Washers................................................111
Fixture Studs..............................................116-117
Flange Nuts ..............................................100-101
Flat Washers..............................................110-111
Fold-Away Handles ............................................10
Forged Eye Bolts ......................................122-123
ear Handles ....................................................19
G
Glides ................................................................48
uide Blocks......................................................85
G
Half Turn Screws................................................96
Hand Knob Screws........................................17-19
Hand Knobs..................................................22-23
Handles ........................................................10-12
Handles - Adjustable ....................................34-43
Handles - Pull ....................................................32
Handles - Gear Lever..........................................19
Handles - Revolving ............................................11
Handwheels ....................................................8-10
Hex Nuts ..........................................................102
Indexing Plungers..........................................76-77
Jam Nuts..........................................................102
Jig Latch Bolt....................................................121
Keys - Fixture......................................................85
Knurled Head Screws ..................................94-95
Knurled Knobs ..............................................16-17
Knurled Nuts ............................................104-105
Latch Bolts ......................................................121
Leveling Mounts............................................44-49
Locking Plungers ..........................................67-68
Machine Mounts ..........................................44-49
Miniature Hand Knobs ......................................31
Nose Clamps......................................................84
Nuts ..........................................................100-109
Nylon Handwheels..............................................10
Nylon Thumb Screws ........................................93
Panel Screws......................................................93
Pins....................................................................78
Plunger Wrenches..............................................66
Press Fit Plungers ........................................62-65
Pull Handles ......................................................32
Pull Ring Plungers ........................................68-69
Quarter Turn Screws ..........................................96
Quick Change Hand Knobs................................25
Quill Stops........................................................107
Rest Buttons..................................................80-81
Rest Pads ..........................................................81
Retractable Handles ..........................................10
Retractable Plungers ....................................67-77
Revolving Handles ........................................10-11
Rotary T-Nuts ..................................................103
Safety Clamping Levers......................................40
Set-Up Studs..............................................116-117
Shoulder Screws ..........................................98-99
Speed Handles ............................................12, 14
Spherical Collar Nuts........................................101
Spherical Washers............................................112
Spring Plungers ............................................56-65
Spring Plungers - Retractable........................70-77
Spring Plungers - Hex Drive ..........................56-61
Spring Plungers - Metric................................55-59
pring Plungers - Mounts ..................................66
S
Spring Plungers - Press Fit............................62-65
pring Plungers - Pull Ring............................68-69
S
Spring Plungers - Short ................................59-61
Spring Plunger - Wrenches ................................66
Stainless Steel - Collar Nuts ............................100
Stainless Steel - Clamping Levers ................36, 41
Stainless Steel - Clamps............................126-127
Stainless Steel - Thumb Screws ....................86-96
Stainless Steel - Washers ..........................110-115
Star Knobs ....................................................22-30
Steel Balls ..........................................................33
Steel Clamping Handles ....................................13
Step Blocks......................................................128
Step Clamps ....................................................128
Studs..........................................................116-117
Swing Bolts ......................................................121
Swing C Washers..............................................113
Swivel Nuts ......................................................101
Swivel Screws................................................82-84
Threaded Adapters........................................74-75
Through Hole Hand Knobs............................24-25
Thumb Screws..............................................86-96
T-Knobs ........................................................20-21
Toe Clamps......................................................125
Toggle Pads ..................................................96-97
Toggle Screws ..............................................96-97
Tooling Balls ......................................................80
T-Slot Bolts ................................................118-119
T-Slot Nuts........................................................103
Washers ....................................................110-115
Washers - C................................................113-115
Washers - Equalizing ........................................112
Washers - Fender..............................................111
Washers - Spherical..........................................112
Washers - Square..............................................115
Wrenches - Spring Plungers ..............................66
“Made to print” specials available
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
k
3
Page 6
j
T a b l e o f C o n t e n t s
andwheels
H
page 8-10
rank Handles
C
page 12
Knurled Knobs
page 16
Fold-Away Handles
page 10
all Handles
B
page 12
Knurled Knobs
page 17
Handles
page 11
lamping Handles
C
page 13
Hand Knob Screws
page 18-19
Revolving Handles
page 11
alanced Handles
B
page 14
Hand Knob Screws
page 19
Metric Handles
page 11
luminum Domed Knobs
A
page 15
Gear Handles
page 19
T-Knobs
page 20
Through Hole Hand Knobs
page 24
Hand Knobs
page 28-30
j
4
T-Knobs
page 21
Hand Knobs
page 25
Bar Knobs
page 30
Hand Knobs
page 22-23
Quick-Change Knobs
page 25
Miniature Hand Knobs
page 31
Stainless Hand Knobs
page 23
Hand Knobs
page 26-27
Pull Handles
page 32
Control Knobs
page 24
Metric Star Knobs
page 27
Ball Knobs
page 33
w w w . m o r t o n m a c h i n e . c o m
Page 7
T a b l e o f C o n t e n t s
k
djustable Clamping Levers
A
page 34-43
hrome Plated Levers
C
page 42
Fixed-Base Mounts
page 49
Adjustable Clamping Levers
page 34-43
utton Thread Levers
B
page 43
Ball Plungers
page 51-55
Economy Clamping Levers
page 38-39
eveling Mounts
L
page 44-47
Spring Plungers
page 55-61
Safety Clamping Levers
page 40
eveling Mounts
L
page 44-48
Press Fit Plungers
page 62-65
Stainless Steel Levers
page 41
ndustrial Glides
I
page 48
Press Fit Plungers
page 62-65
Spring Plunger Mounts
page 66
Retractable Plungers
page 70-73
Bullet Nose Liners
page 79
Plunger Wrenches
page 66
Threaded Adapters
page 74-75
Tooling Balls
page 80
Ball Plunger Detents
page 66
Indexing Plungers
page 76-77
Rest Buttons
page 80-81
Locking Plungers
Bullet Nose Pins
Rest Buttons
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
page 67
page 78
page 81
Pull Ring Plungers
page 68-69
Bullet Nose Pins
page 78
Rest Pads
page 81
k
5
Page 8
j
T a b l e o f C o n t e n t s
all Clamping Screws
B
page 82-84
humb Screws
T
page 86
Thumb Screws
page 90
Nose Clamps
page 84
humb Screws
T
page 87
Brass Thumb Screws
page 91
Fixture Keys
page 85
humb Screws
T
page 88
Brass Thumb Screws
page 91
Guide Blocks
page 85
humb Screws
T
page 89
Plastic Thumb Screws
page 92
Button Jig Feet
page 85
humb Screws
T
page 90
Plastic Thumb Screws
page 92
Panel Screws
page 93
Half Turn Screws
page 96
Slotted Shoulder Screws
page 98
j
6
Nylon Thumb Screws
page 93
Toggle Screws
page 96
Shoulder Screws
page 99
Adjusting Screws
page 94-95
Toggle Screws
page 96
Spherical Head Screws
page 99
Knurled Screws
page 94
Toggle Pads
page 97
Collar Nuts
page 100
Quarter Turn Screws
page 96
Shoulder Screws
page 98
Spherical Collar Nuts
page 101
w w w . m o r t o n m a c h i n e . c o m
Page 9
T a b l e o f C o n t e n t s
k
corn Nuts
A
page 101
nurled Nuts
K
page 104
Knurled Head Nuts
page 106
Swivel Nuts
page 101
pherical Seat Nut
S
page 104
Equalizing Nuts
page 106
Hex Nuts
page 102
nurled Nuts
K
page 105
Nylon Finger Nuts
page 106
T-Slot Nuts
page 103
xtension Nuts
E
page 105
Quill Stops
page 107
Rotary T-Nuts
page 103
qualizing Nuts
E
page 105
Button Thread Nuts
page 108-109
Flat Washers
page 110-111
Square Washers
page 115
Forged Eye Bolts
page 122-123
Large OD Washers
page 111
T-Slot Bolts
page 118-119
Clamp Straps
page 124-128
Spherical Washers
page 112
Eye Bolts
page 120
Step Blocks
page 128
Swing C Washer
page 113
Swing Bolts
page 121
Hook Clamps
page 129
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
C Washers
page 114-115
Double Cams
page 121
Clamp Rests
page 129
k
7
Page 10
j
H a n d w h e e l s
Handwheels
(standard type)
Cast Iron / Aluminum
j Additional charge for installing handles
j Machined handwheels include faced
hub that is true with rim
j Bore, keyway, and set screw prices are available upon request
j Material is cast grey iron and 319 cast aluminum
Blank Casting Only Machined Only Machined, Polished & Painted Optional
Cast Iron Aluminum Cast Iron Aluminum Cast Iron Aluminum Handle Weight (lbs.)
PART # PART # PART # PART # PART # PART # A B C D J Cast Iron Aluminum
HW-4 HW-4A HW-4M HW-4AM HW-4F HW-4AF 4 1-1/4 5/8 1-1/8 H-20 1.7 .6­HW-5 HW-5A HW-5M HW-5AM HW-5F HW-5AF 5 1-1/2 5/8 1-1/8 H-30 2.2 .8 HW-6 HW-6A HW-6M HW-6AM HW-6F HW-6AF 6 1-5/8 3/4 1-1/4 H-30 3.4 1.3 HW-8 HW-8A HW-8M HW-8AM HW-8F HW-8AF 8 1-7/8 7/8 1-3/8 H-40 6.0 2.3 HW-9 - HW-9M - HW-9F -927/8 1-3/4 H-40 7.2 ­HW-10 HW-10A HW-10M HW-10AM HW-10F HW-10AF 10 2-1/4 1 2-1/4 H-40 11 5
- HW-12A - HW-12AM - HW-12AF 12 3 1-1/4 3 H-50 21 8
- HW-14A - HW-14AM - HW-14AF 14 3 1-1/4 3-1/2 H-50 25 9
Handwheels
(offset type)
Aluminum
j Additional charge for installing handles
j Bore, keyway, and set screw prices are
available upon request
j Machined handwheels include faced hub that is true with rim
Blank Machined Machined, Polished
Casting Only Only & Painted Optional
Aluminum Aluminum Aluminum Handle Weight (lbs.)
PART # PART # PART # A B C D J Aluminum
OHW-4A OHW-4AM OHW-4AF 4 1-1/4 5/8 1-11/16 H-20 .7 OHW-5A OHW-5AM OHW-5AF 5 1-1/2 5/8 1-13/16 H-30 .8 OHW-6A OHW-6AM OHW-6AF 6 1-5/8 3/4 2 H-30 1.3 OHW-8A OHW-8AM OHW-8AF 8 1-7/8 7/8 2-3/16 H-40 2.4 OHW-9A OHW-9AM OHW-9AF 927/8 2-3/4 H-40 3.0 OHW-10A OHW-10AM OHW-10AF 10 2-1/4 1 3-1/4 H-40 5
j
8
w w w . m o r t o n m a c h i n e . c o m
Page 11
j Black powder coated cast aluminum
j Installed manual fold-away handle
j Through bore
H a n d w h e e l s
k
Black Powder Coated Aluminum Handwheels
with fold-away handle
PART # ABCE F GH
Bore
HW-50A 4.00 1.25 .375 1.77 .812 .750 2.20 HW-50B 4.00 1.25 .500 1.77 .812 .750 2.20 HW-51A 5.00 1.31 .375 1.93 .875 .750 2.56 HW-51B 5.00 1.31 .500 1.93 .875 .750 2.56 HW-52A 6.00 1.44 .500 2.05 1.00 .750 2.56 HW-52B 6.00 1.44 .625 2.05 1.00 .750 2.56 HW-53A 8.00 1.94 .500 2.74 1.38 .937 3.15 HW-53B 8.00 1.94 .625 2.74 1.38 .937 3.15 HW-54A 10.00 1.94 .625 2.80 1.38 .937 3.15 HW-54B 10.00 1.94 .750 2.80 1.38 .937 3.15
j Made from cast aluminum
j High quality machined and polished finish
j Available with or without revolving plastic handle
j Through bore
Two-Spoke Aluminum Handwheels
Without handle With handle
PART # PART # DABC E
HW-30 HW-30H 4.92 .47 .59 1.22 1.30 HW-31 HW-31H 6.30 .55 .71 1.42 1.54 HW-32 HW-32H 7.87 .71 .80 1.65 1.77 HW-33 HW-33H 9.84 .87 .91 1.89 2.01
j Made from cast aluminum
j High quality machined and polished rim
j Solid web design has no hazardous openings
j Available with or without revolving black plastic handle
j Through bore
Without handle With handle
PART # PART # DABC E
HW-20 HW-20H 3.94 .39 .55 1.10 1.18 HW-21 HW-21H 4.92 .47 .59 1.22 1.30 HW-22 HW-22H 6.30 .55 .71 1.42 1.54 HW-23 HW-23H 7.87 .71 .80 1.65 1.77 HW-24 HW-24H 9.84 .87 .91 1.89 2.01
Solid Web Aluminum Handwheels
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
k
9
Page 12
j
H a n d w h e e l s
Nylon Handwheels
j Molded with high strength plastic nylon 6N resin
j Available with or without revolving handle
j Three spoke offset design
j Steel core allows for custom machining and
increased strength
j Through bore
Without Handle With Handle Bore Handle
PART # PART # DA BCFHLJThread
PHW-40 PHW-60 3.15 .98 .94 1.18 .39 .55 1.57 3/16 M6 x 1.0 PHW-41 PHW-61 3.94 1.10 1.10 1.26 .39 .55 1.73 3/16 M6 x 1.0 PHW-42 PHW-62 4.92 1.18 1.10 1.38 .39 .55 1.89 3/16 M8 x 1.25 PHW-43 PHW-63 6.30 1.38 1.38 1.97 .59 .79 2.48 13/32 M10 x 1.5 PHW-44 PHW-64 7.87 1.38 1.38 1.97 .59 .79 2.48 13/32 M10 x 1.5 PHW-49 PHW-69 9.84 1.77 2.13 2.32 .59 1.02 2.48 13/32 M10 x 1.75
Stainless Steel Handwheels
Fold-Away Handles
j 300 series stainless steel
j Excellent machined finish
j Stainless steel handle included
j Offset dish design
j No bore hole
PART # AB C D EGL
SHW-3 3" .39 1.10 .87 .67 .24 1.49 SHW-4 4" .47 1.25 1.02 .71 .31 1.57 SHW-6 6" .75 1.50 1.50 .87 .39 2.50
j Plastic handle
j Inch and metric sizes available
j Fold-away handle design...pull handle upward and it snaps into an
upright position.
j Steel stud
j Fold-away design eliminates a projecting handle that sometimes
causes safety hazards
j
10
PART # Thread A B CDE
FH-60 3/8-16 .51 .83 2.56 .91 .75 FH-70 1/2-13 .55 .87 3.15 1.02 .83 FH-80 5/8-11 .79 .94 3.54 1.10 .91 FH-10 M8 x 1.25 .51 .83 2.56 .91 .75 FH-20 M8 x 1.25 .51 .87 3.15 1.02 .83 FH-30 M10 x 1.50 .55 .87 3.15 1.02 .83 FH-40 M12 x 1.75 .79 .94 3.54 1.10 .91
w w w . m o r t o n m a c h i n e . c o m
Page 13
j Machine steel, high polished finish
j Solid or revolving handle
Excellent handle for fixturing or when used with
j
cast iron and aluminum handwheels.
Solid Revolving
Part # Part # ABCL
H-10 1-29/32 7/16 1/4 1-15/32 H-20 2-5/32 7/16 5/16 1-23/32
H-1 2-5/8 9/16 5/16 2-1/16
H-30 2-11/16 9/16 3/8 2-1/8
H-2 3-25/32 3/4 3/8 3-1/32
H-40 3-15/16 11/16 7/16 3-1/4
H-3 4-1/32 3/4 7/16 3-9/32
H-50 5 15/16 1/2 4-1/16
H-4 5-1/8 15/16 1/2 4-3/16
H a n d l e s
Handles
k
j Revolving handle
j Handle available in polished steel or black
thermoplastic
j Steel screw with black oxide finish
Steel Plastic
PART # PART # XABCDE
HA-6 HP-6 M6 x 1.0 16mm 50mm 11mm 5.5mm 3mm HA-8 HP-8 M8 x 1.25 20 64 13 64 HA-10 HP-10 M10 x 1.5 25 80 14 85 HA-12 HP-12 M12 x 1.75 32 100 21 10.5 6
j Thermoplastic handle
j Spindle made from steel
j Revolving handle
j Metric thread
Metric Revolving Handles
Handles
plastic, revolving
PART # B P A CD S
RH-60 M6 x 1.0 1.97 .51 .71 .83 .12 RH-61 M8 x 1.25 2.56 .55 .75 .91 .16 RH-62 M10 x 1.5 3.15 .63 .87 1.02 .20
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
11
k
Page 14
j
H a n d l e s
Crank Handles
Ball Handles
Crank handle with revolving handle
Crank handle with foldable
revolving handle
j Aluminum die-cast crank body
j Black painted finish
j Available with black plastic revolving handle or fold-away handles
j Available with round bore or square broach
ITH PLASTIC REVOLVING HANDLE
ored Broached
B
ART # PART # ALB C D EF GH
P
CH-2031 CH-2131 5/16 1.20 0.68 0.55 0.94 0.34 0.37 0.56 -
CH-2037 CH-2137 3/8 2.52 0.79 0.75 1.22 0.43 0.47 0.70 1/16 CH-2038 CH-2138 3/8 3.15 0.95 0.91 1.97 0.55 0.55 0.85 1/16 CH-2050 CH-2150 1/2 3.94 1.10 1.06 2.50 0.67 0.59 0.93 3/32 CH-2062 CH-2162 5/8 4.92 1.34 1.26 3.25 0.87 0.71 1.12 3/32 CH-2075 CH-2175 3/4 6.30 1.50 1.38 3.25 1.02 0.71 1.12 3/32
Bored Broached
PART # PART # ALB C D EF GH
CH-2085 CH-2185 1/2 3.94 1.10 1.06 2.00 0.67 1.22 0.88 3/32 CH-2086 CH-2186 5/8 4.92 1.34 1.26 2.50 0.87 1.49 0.94 3/32 CH-2087 CH-2187 3/4 6.30 1.50 1.38 3.15 1.02 1.49 1.00 3/32
W
WITH PLASTIC FOLDING HANDLE
j
12
j Cast grey iron, zinc-plated finish
j Available as a blank casting, with a tapped hole, or a reamed hole
j Bottom face of hub is machined square with the hole
j Spherical face is available to fit bottom half of spherical washer
PART # A B CDEF GR T of Hub
BH-100 1-1/8 4-3/4 1-3/8 2-1/4 3/4 1/2 3/8 Blank Casting
BH-101 1-1/8 4-3/4 1-3/8 2-1/4 3/4 1/2 3/8 .499 Flat Face BH-104 1-1/8 4-3/4 1-3/8 2-1/4 3/4 1/2 3/8 3/8-16 Flat Face BH-102 1-1/8 4-3/4 1-3/8 2-1/4 3/4 1/2 3/8 1/2-13 Flat Face BH-103 1-1/8 4-3/4 1-3/8 2-1/4 3/4 1/2 3/8 1/2-13 SP-2 Radius BH-200 1-3/8 6 1-5/8 2-1/2 7/8 9/16 7/16 Blank Casting BH-204 1-3/8 6 1-5/8 2-1/2 7/8 9/16 7/16 .624 Flat Face BH-205 1-3/8 6 1-5/8 2-1/2 7/8 9/16 7/16 5/8-11 Flat Face BH-206 1-3/8 6 1-5/8 2-1/2 7/8 9/16 7/16 5/8-11 SP-3 Radius BH-300 1-5/8 8 1-3/4 2-15/16 1 5/8 1/2 Blank Casting BH-307 1-5/8 8 1-3/4 2-15/16 1 5/8 1/2 .749 Flat Face BH-308 1-5/8 8 1-3/4 2-15/16 1 5/8 1/2 3/4-10 Flat Face BH-309 1-5/8 8 1-3/4 2-15/16 1 5/8 1/2 3/4-10 SP-4 Radius
Ream Tapped Bottom Face
Condition of
w w w . m o r t o n m a c h i n e . c o m
Page 15
j Available in 3 styles....
ingle side offset, Double side offset,
S Double side straight
j Low carbon steel, black oxide finish
j Solid steel hub on select sizes allows
for custom machining
j Black plastic balls
jDouble straight design can be adjusted for additional leverage by loosening the set screw
and sliding the handle to one side.
jDouble straight design can be adjusted for additional leverage by loosening the set screw and sliding the handle to one side.
STYLE
PART # TABC D E FGHJ
CH-13 x Blank 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 -­CH-1350 x 1/2-13 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 - 3/4 CH-1362 x 5/8-11 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 - 1” CH-1375 x 3/4-10 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 - 1”
DOUBLE
STRAIGHT
H a n d l e s
k
Steel Clamping Handles
Double Straight Design
STYLE
PART # TABC D EFGHJ
CH-14 x Blank 4” 2” 7/8 1-1/2 1” 1/4 3/4 30˚ ­CH-1425 x 1/4-20 4” 2” 7/8 1-1/2 1” 1/4 3/4 30˚ 1/2 CH-1437 x 3/8-16 4” 2” 7/8 1-1/2 1” 1/4 3/4 30˚ 1/2 CH-15 x Blank 6” 3” 1-1/8 1-3/4 1-1/16 3/8 1” 30˚ ­CH-1537 x 3/8-16 6” 3” 1-1/8 1-3/4 1-1/16 3/8 1” 30˚ 1/2 CH-1550 x 1/2-13 6” 3” 1-1/8 1-3/4 1-1/16 3/8 1” 30˚ 3/4 CH-16 x Blank 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 30˚ ­CH-1662 x 5/8-11 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 30˚ 1” CH-1675 x 3/4-10 8” 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 30˚ 1”
PART # TABC D E F GH J
CH-17 x Blank - 2” 7/8 1-1/2 1” 1/4 3/4 30˚ ­CH-1725 x 1/4-20 - 2” 7/8 1-1/2 1” 1/4 3/4 30˚ 1/2 CH-1737 x 3/8-16 - 2” 7/8 1-1/2 1” 1/4 3/4 30˚ 1/2 CH-18 x Blank - 3” 1-1/8 1-3/4 1-1/16 3/8 1” 30˚ ­CH-1837 x 3/8-16 - 3” 1-1/8 1-3/4 1-1/16 3/8 1” 30˚ 1/2 CH-1850 x 1/2-13 - 3” 1-1/8 1-3/4 1-1/16 3/8 1” 30˚ 3/4 CH-19 x Blank - 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 30˚ ­CH-1962 x 5/8-11 - 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 30˚ 1” CH-1975 x 3/4-10 - 4” 1-3/8 2-1/4 1-1/4 1/2 1-3/8 30˚ 1”
DOUBLE OFFSET
STYLE
SINGLE
OFFSET
Double Offset Design
Single Offset Design
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
13
k
Page 16
j
H a n d l e s
Balanced Crank Handles
Balanced Double Crank Handles
Polished chrome appearance
j
j Fixed handle
j Cross drilled hole for easy installation
ART # A B C DH L
P
CH-3001 2 5/16 1/8 13/16 7/16 2 CH-3002 2-1/2 5/16 1/8 1 9/16 2-1/2 CH-3003 3-1/8 3/8 5/32 1-1/4 11/16 3-1/4 CH-3004 4 3/8 5/32 1-1/4 11/16 3-1/4 CH-3005 5 1/2 3/16 1-1/2 7/8 4 CH-3006 6-1/8 1/2 3/16 1-1/2 7/8 4
Balanced Crank Handles
j Double fixed handle design
j Chrome plated steel
j Cross drilled hole for easy installation
PART # A B C HL
CH-3021 2 5/16 1/8 7/16 2 CH-3022 2-1/2 5/16 1/8 9/16 2-1/2 CH-3023 3-1/4 3/8 5/32 11/16 3-1/4
j Available with fixed or revolving handle
j Polished chrome appearance
j Cross drilled hole for easy installation
j
14
Revolving Fixed
PART # PART # A B C DHL1 L2
CH-3052 CH-3062 2-1/2 5/16 1/8 1 9/16 2-3/4 2-9/16 CH-3053 CH-3063 3-1/8 3/8 5/32 1-1/4 11/16 3-1/2 3-1/4 CH-3054 CH-3064 4 3/8 5/32 1-1/4 11/16 3-1/2 3-1/4 CH-3055 CH-3065 5 1/2 3/16 1-1/2 7/8 4-3/16 3-15/16
w w w . m o r t o n m a c h i n e . c o m
Page 17
j Made from 6061-T6 aluminum
Large palm-grip design
j
j Diamond knurl
j Comfort design and finish
PART # Thread D A F C Thread Depth H
AK-101 1/4-20 1 1/4 7/16 5/8 1/2 15/16 AK-102 5/16-18 1 1/4 7/16 5/8 1/2 15/16 AK-103 5/16-18 2 5/16 1/2 1 1/2 1-3/16 AK-104 3/8-16 2 5/16 1/2 1 1/2 1-3/16 AK-105 3/8-16 2-1/4 3/8 5/8 1-1/4 1 1-3/8 AK-106 1/2-13 2-1/4 3/8 5/8 1-1/4 1 1-3/8 AK-107 1/2-13 3 3/8 3/4 1-1/2 1 1-5/8 AK-108 5/8-11 3 3/8 3/4 1-1/2 1 1-5/8 AK-109 5/8-11 3-1/2 1/2 3/4 211-7/8 AK-110 3/4-10 3-1/2 1/2 3/4 211-7/8
D o m e d K n o b s
k
Aluminum Domed Knurled Knobs
Aluminum Domed Knurled Knob Assemblies
j Knobs made 6061-T6 aluminum
j Carbon steel screw, black oxide finish
j Large palm-grip design
j Steel screw held in place with roll pin
j Comfort design and finish
PART # Thread Thread Lgth D A FCL
AK-2517 1/4-20 1-3/4 1 1/4 7/16 5/8 2-11/16 AK-2530 1/4-20 311/4 7/16 5/8 3-15/16 AK-3117 5/16-18 1-3/4 1 1/4 7/16 5/8 2-11/16 AK-3130 5/16-18 311/4 7/16 5/8 3-15/16 AK-3717 3/8-16 1-3/4 2 5/16 1/2 1 2-15/16 AK-3730 3/8-16 325/16 1/2 1 4-3/16 AK-5017 1/2-13 1-3/4 2-1/4 3/8 5/8 1-1/4 3-1/8 AK-5030 1/2-13 3 2-1/4 3/8 5/8 1-1/4 4-3/8 AK-6217 5/8-11 1-3/4 3 3/8 3/4 1-1/2 3-3/8 AK-6230 5/8-11 333/8 3/4 1-1/2 4-5/8 AK-7517 3/4-10 1-3/4 3-1/2 1/2 3/4 2 3-5/8 AK-7530 3/4-10 3 3-1/2 1/2 3/4 2 4-7/8
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
15
k
Page 18
j
K n u r l e d K n o b s
Knurled Knobs
with reamed hole
j Available in carbon steel with black oxide finish and 303 stainless
teel
s
j Reamed hole
j Diamond knurl
Steel Stainless Steel Reamed Hole
PART # PART # EA BCD
KK-10 KK-10SS 3/16 3/4 5/8 1/2 1/4 KK-11 KK-11SS 1/4 3/4 5/8 1/2 1/4 KK-12 KK-12SS 1/4 1 3/4 5/8 1/4 KK-13 KK-13SS 5/16 1 3/4 5/8 1/4 KK-14 KK-14SS 5/16 1-1/2 1 3/4 5/16 KK-15 KK-15SS 3/8 1-1/2 1 3/4 5/16 KK-16 KK-16SS 3/8 2 1-1/8 1 3/8 KK-17 KK-17SS 1/2 2 1-1/8 1 3/8 KK-18 - 1/2 2-1/2 1-1/2 1-1/2 9/16 KK-19 - 5/8 2-1/2 1-1/2 1-1/2 9/16 KK-20 - 5/8 3 1-3/4 1-3/4 5/8 KK-21 - 3/4 3 1-3/4 1-3/4 5/8
Knurled Knobs
with tapped hole
j Available in carbon steel with black oxide finish and 303 stainless steel
j Tapped hole
j Knurled head
j Diamond knurl
j Metric knobs have through hole thread
Steel Stainless Steel
PART # PART # Thread T ABCD
KK-30 KK-30SS #10-24 3/4 5/8 1/2 1/4 KK-31 KK-31SS 1/4-20 3/4 5/8 1/2 1/4 KK-32 KK-32SS 1/4-20 1 3/4 5/8 1/4 KK-33 KK-33SS 5/16-18 1 3/4 5/8 1/4 KK-34 KK-34SS 5/16-18 1-1/2 1 3/4 5/16 KK-35 KK-35SS 3/8-16 1-1/2 1 3/4 5/16 KK-36 KK-36SS 3/8-16 2 1-1/8 1 3/8 KK-37 KK-37SS 1/2-13 2 1-1/8 1 3/8 KK-38 - 1/2-13 2-1/2 1-1/2 1-1/2 9/16 KK-39 - 5/8-11 2-1/2 1-1/2 1-1/2 9/16 KK-40 - 5/8-11 3 1-3/4 1-3/4 5/8 KK-41 - 3/4-10 3 1-3/4 1-3/4 5/8
PART # Thread A B C D
KK-70 M3 x .5 12mm 6mm 7.5mm 2.5mm KK-71 M4 x .7 16 8 9.5 3.5 KK-72 M5 x .8 20 10 11.5 4 KK-73 M6 x 1.0 24 12 16 5 KK-74 M8 x 1.25 30 16 18 6 KK-75 M10 x 1.5 36 20 23 8
INCH THREAD
METRIC THREAD (THRU-HOLE)
j
16
w w w . m o r t o n m a c h i n e . c o m
Page 19
j Black oxide finish
j Stud is drilled and pinned in place
j Knurled head
j Machined from low carbon 12L14 steel
NCH STUD
tud
ART # Thread EAB C D
P
KKS-50 #10-24 1/2 3/4 5/8 1/2 1/4 KKS-51 #10-24 1 3/4 5/8 1/2 1/4 KKS-52 1/4-20 3/4 3/4 5/8 1/2 1/4 KKS-53 1/4-20 1-1/4 3/4 5/8 1/2 1/4 KKS-54 1/4-20 1-3/4 1 3/4 5/8 1/4 KKS-55 5/16-18 1-3/4 1 3/4 5/8 1/4 KKS-56 5/16-18 313/4 5/8 1/4 KKS-57 5/16-18 1-3/4 1-1/2 1 3/4 5/16 KKS-58 5/16-18 3 1-1/2 1 3/4 5/16 KKS-59 3/8-16 1-3/4 1-1/2 1 3/4 5/16 KKS-60 3/8-16 3 1-1/2 1 3/4 5/16 KKS-61 3/8-16 1-3/4 2 1-1/8 1 3/8 KKS-62 3/8-16 321-1/8 1 3/8 KKS-63 1/2-13 1-3/4 2 1-1/8 1 3/8 KKS-64 1/2-13 1-3/4 2-1/2 1-1/2 1-1/2 9/16 KKS-65 1/2-13 3 2-1/2 1-1/2 1-1/2 9/16 KKS-66 5/8-11 1-3/4 2-1/2 1-1/2 1-1/2 9/16
S
I
K n u r l e d K n o b s
Knurled Knobs
with studs
k
j Cast iron hand knob, zinc-plated finish
j Steel screw with black oxide finish
j Knurled hand knob
PART # Thread EAB C D
SKS-2517 1/4-20 1-3/4 1-1/2 7/8 5/8 3/8 SKS-2530 1/4-20 3 1-1/2 7/8 5/8 3/8 SKS-3117 5/16-18 1-3/4 2 7/8 3/4 3/8 SKS-3130 5/16-18 327/8 3/4 3/8 SKS-3717 3/8-16 1-3/4 2 7/8 3/4 3/8 SKS-3730 3/8-16 327/8 3/4 3/8 SKS-5017 1/2-13 1-3/4 2-1/2 1-1/2 1-1/8 1/2 SKS-5030 1/2-13 3 2-1/2 1-1/2 1-1/8 1/2 SKS-6217 5/8-11 1-3/4 2-1/2 1-1/2 1-1/8 1/2 SKS-6230 5/8-11 3 2-1/2 1-1/2 1-1/8 1/2
Stud
Cast Iron Hand Knob Screws
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
17
k
Page 20
j
H a n d K n o b S c r e w s
Hand Knob Screws
D
C
B
ast Iron Aluminum Thread
C
ART # PART # A B C D
P
HKS-2510 HKS-2510A 1/4-20 1 1-1/2 7/8 HKS-2515 HKS-2515A 1/4-20 1-1/2 1-1/2 7/8 HKS-2517 HKS-2517A 1/4-20 1-3/4 1-1/2 7/8 HKS-2520 HKS-2520A 1/4-20 2 1-1/2 7/8 HKS-2530 HKS-2530A 1/4-20 3 1-1/2 7/8 HKS-3117 HKS-3117A 5/16-18 1-3/4 21 HKS-3125 HKS-3125A 5/16-18 2-1/2 21 HKS-3130 HKS-3130A 5/16-18 321 HKS-3712 HKS-3712A 3/8-16 1-1/4 21 HKS-3717 HKS-3717A 3/8-16 1-3/4 21 HKS-3720 HKS-3720A 3/8-16 221 HKS-3725 HKS-3725A 3/8-16 2-1/2 21 HKS-3730 HKS-3730A 3/8-16 321 HKS-5015 HKS-5015A 1/2-13 1-1/2 2-1/2 1-1/2 HKS-5017 HKS-5017A 1/2-13 1-3/4 2-1/2 1-1/2 HKS-5020 HKS-5020A 1/2-13 2 2-1/2 1-1/2 HKS-5025 HKS-5025A 1/2-13 2-1/2 2-1/2 1-1/2 HKS-5030 HKS-5030A 1/2-13 3 2-1/2 1-1/2 HKS-6217 HKS-6217A 5/8-11 1-3/4 2-1/2 1-1/2 HKS-6225 HKS-6225A 5/8-11 2-1/2 2-1/2 1-1/2 HKS-6230 HKS-6230A 5/8-11 3 2-1/2 1-1/2 HKS-6235 HKS-6235A 5/8-11 3-1/2 2-1/2 1-1/2
j Hand knob available in cast iron or aluminum
j Steel screw with black oxide finish
j Screw is pressed and held in place with a spring pin
Stainless Steel Hand Knob Screws
D
C
B
Aluminum Thread
PART # A B C D
HKS-825A 1/4-28 1-3/4 1-1/2 7/8 HKS-831A 5/16-24 1-3/4 2 7/8 HKS-837A 3/8-24 1-3/4 2 7/8 HKS-850A 1/2-20 1-3/4 2-1/2 1-1/2 HKS-862A 5/8-11 1-3/4 2-1/2 1-1/2
Fine Thread
j Aluminum hand knob
j 303 stainless steel screw
j Screw is pressed and held in place by a roll pin
PART # A B C D
HKS-2517A-SS 1/4-20 1-3/4 1-1/2 7/8 HKS-2530A-SS 1/4-20 3 1-1/2 7/8 HKS-3117A-SS 5/16-18 1-3/4 21 HKS-3130A-SS 5/16-18 321 HKS-3717A-SS 3/8-16 1-3/4 21 HKS-3730A-SS 3/8-16 321 HKS-5017A-SS 1/2-13 1-3/4 2-1/2 1-1/2 HKS-5030A-SS 1/2-13 3 2-1/2 1-1/2 HKS-6217A-SS 5/8-11 1-3/4 2-1/2 1-1/2 HKS-6230A-SS 5/8-11 3 2-1/2 1-1/2
Thread
j
18
w w w . m o r t o n m a c h i n e . c o m
Page 21
j Metric sizes
j 4 prong cast iron hand knob
j Heat treated steel screw, black oxide finish
j Dog point screw
j Screw is pressed and held in place with a spring pin
ART # ABCDTip Dia. Tip Length
P
HKS-92 M6 x 1.0 26mm 38mm 22mm 4.5mm 3mm HKS-93 M6 x 1.0 38 38 22 4.5 3 HKS-94 M8 x 1.25 44.5 38 22 6 4.5 HKS-95 M10 x 1.5 38 51 25 7 4.5 HKS-96 M10 x 1.5 51 51 25 7 4.5 HKS-97 M12 x 1.75 38 63.5 38 10 6.5 HKS-98 M12 x 1.75 63.5 63.5 38 10 6.5
H a n d K n o b s S c r e w s
k
Metric Hand Knob Screws
j Available in steel shaft with black oxide finish or stainless steel shaft
j Black plastic ball
j Inch and metric sizes available
j Gear lever shaft available without the plastic ball upon request
Steel Stainless Steel
PART # PART # Thread ABCD
GL-05 GL-05SS #10-32 3/4 1/4 1-1/2 3/8 GL-10 GL-10SS #10-32 3/4 1/4 3 3/8 GL-15 GL-15SS 1/4-20 3/4 1/4 2-1/2 3/8 GL-20 GL-20SS 1/4-20 3/4 1/4 3-1/2 3/8 GL-30 GL-30SS 1/4-20 1” 3/8 6 1/2 GL-35 GL-35SS 5/16-18 1” 3/8 2-1/2 1/2 GL-38 GL-38SS 5/16-18 1” 3/8 4 1/2 GL-40 GL-40SS 5/16-18 1” 3/8 6 1/2 GL-45 GL-45SS 3/8-16 1-3/8 1/2 2-1/2 1/2 GL-48 GL-48SS 3/8-16 1-3/8 1/2 4 1/2 GL-50 GL-50SS 3/8-16 1-3/8 1/2 8 1/2 GL-55 GL-55SS 1/2-13 1-7/8 5/8 6 5/8 GL-58 GL-58SS 1/2-13 1-7/8 5/8 8 5/8 GL-60 GL-60SS 1/2-13 1-7/8 5/8 10 5/8
Steel Steel Stainless
PART # PART # Thread ABCD
GL-63 GL-63SS M6 x 1.0 19mm 6.5mm 76mm 9.5mm GL-83 GL-83SS M8 x 1.25 25.5 9.5 152 12.5 GL-103 GL-103SS M10 x 1.5 35 12.5 203 12.5 GL-123 GL-123SS M12 x 1.75 47.5 16 254 16
INCH
METRIC
Gear Lever Handles
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
19
k
Page 22
j
T - K n o b s
Plastic T-Knobs
Black thermoplastic knob
j
Bushing insert made from brass
j
j Inch and metric sizes
RASS INSERT
B
NCH - INTERNAL THREAD
ART # X Thread Thread Depth HDE
P
3735AC 1/4-20 0.39 0.71 1.38 0.59 3745AC 1/4-20 0.63 0.94 1.77 0.79 3735AD 5/16-18 0.39 0.71 1.38 0.59 3745AD 5/16-18 0.63 0.94 1.77 0.79 3745AE 3/8-16 0.63 0.94 1.77 0.79
PART # X Thread Thread Depth HDE
373504 M4 x .7 10mm 18mm 35mm 15.5mm 373505 M5 x .8 10 18 35 15.5 373506 M6 x 1.0 10 24 45 20 374506 M6 x 1.0 16 24 45 20 374508 M8 x 1.25 16 24 45 20
I
BRASS INSERT
METRIC - INTERNAL THREAD
Plastic T-Knobs
with screws
j Black thermoplastic knob
j
Screws made from zinc-plated steel or stainless steel
j Inch and metric sizes
ZINC PLATED STEEL
PART # X Thread Thread Lgth HD E
3735AC015 3735AC028 3735AD015 3735AD028 3735AD040 3745AE016 3745AE029 3745AE048
PART # X Thread Thread Lgth HDE
373505015 373505030 373506015 373506030 374506015 374506030 374508015 M8 x 1.25 15 24 45 20 374508030
PART # X Thread Thread Lgth HDE
373505015SS M5 x .8 15mm 18mm 35mm 15.5mm 373506015SS M6 x 1.0 15 18 35 15.5 373506030SS M6 x 1.0 30 18 35 15.5 373508015SS M8 x 1.25 15 18 35 15.5 373508030SS M8 x 1.25 30 18 35 15.5 374508040SS M8 x 1.25 40 24 45 20 374510020SS M10 x 1.5 20 24 45 20 374510050SS M10 x 1.5 50 24 45 20
INCH - EXTERNAL THREAD
1/4-20 0.59 0.71 1.38 0.59 1/4-20 1.10 0.71 1.38 0.59 5/16-18 0.59 0.71 1.38 0.59 5/16-18 1.10 0.71 1.38 0.59 5/16-18 1.58 0.71 1.38 0.59 3/8-16 0.63 0.94 1.77 0.79 3/8-16 1.14 0.94 1.77 0.79 3/8-16 1.88 0.94 1.77 0.79
ZINC PLATED STEEL
METRIC - EXTERNAL THREAD
M5 x .8 15mm 18mm 35mm 15.5mm M5 x .8 30 18 35 15.5 M6 x 1.0 15 18 35 15.5 M6 x 1.0 30 18 35 15.5 M6 x 1.0 15 24 45 20 M6 x 1.0 30 24 45 20
M8 x 1.25 30 24 45 20
STAINLESS STEEL
METRIC - EXTERNAL THREAD
j
20
w w w . m o r t o n m a c h i n e . c o m
Page 23
j 304 cast stainless steel
j
Internal thread or blank casting
T - K n o b s
k
Stainless Steel T-Knobs
ART # X Thread Thread Depth HD E
P
TK-100 Blank Blank .71 1.375 .59 TK-101 #10-32 .500 .71 1.375 .59 TK-102 #10-24 .500 .71 1.375 .59 TK-103 1/4-20 .500 .71 1.375 .59 TK-104 5/16-18 .500 .71 1.375 .59 TK-105 Blank Blank .94 1.770 .79 TK-106 5/16-18 .625 .94 1.770 .79 TK-107 3/8-16 .625 .94 1.770 .79
ART # X Thread Thread Depth HDE
P
TK-110 M5 x .8 12mm 18mm 35mm 15.5mm TK-111 M6 x 1.0 12 18 35 15.5 TK-112 M8 x 1.25 12 18 35 15.5 TK-113 M10 x 1.5 16 24 45 20 TK-114 M12 x 1.75 16 24 45 20
Inch
Metric
Stainless Steel T-Knobs
stainless steel screw
j 304 cast stainless steel
j
303 stainless steel screw
j
Screw is pressed and held in place by a roll pin
PART # X Thread Thread Length HD E
TK-301 #10-32 5/8 .71 1-3/8 .59 TK-302 #10-32 1 .71 1-3/8 .59 TK-303 #10-24 5/8 .71 1-3/8 .59 TK-304 #10-24 1 .71 1-3/8 .59 TK-305 1/4-20 3/4 .71 1-3/8 .59 TK-306 1/4-20 1-1/4 .71 1-3/8 .59 TK-307 1/4-20 1-3/4 .71 1-3/8 .59 TK-308 5/16-18 3/4 .94 1-3/4 .79 TK-309 5/16-18 1-1/4 .94 1-3/4 .79 TK-310 5/16-18 1-3/4 .94 1-3/4 .79 TK-311 3/8-16 1 .94 1-3/4 .79 TK-312 3/8-16 1-3/4 .94 1-3/4 .79 TK-313 3/8-16 2-1/4 .94 1-3/4 .79
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
21
k
Page 24
j
H a n d K n o b s
Hand Knobs
j Available in cast iron with zinc plating or cast aluminum
j Sizes 200 through 621 have 4 prongs
j Sizes 722 through 829 have 5 prongs
j Blind hole (tapped and reamed hole are not through)
Cast Iron Aluminum Ream Tapped
PART # PART # A B C DR T
HK-307 HK-307A 1-1/2 5/8 7/8 3/8 5/16-18 HK-308 HK-308A 1-1/2 5/8 7/8 3/8 .3115 HK-309 HK-309A 1-1/2 5/8 7/8 3/8 Blank HK-410 HK-410A 2 3/4 1 3/8 3/8-16 HK-411 HK-411A 2 3/4 1 3/8 .3115 HK-412 HK-412A 2 3/4 1 3/8 .374 HK-413 HK-413A 2 3/4 1 3/8 Blank HK-616 HK-616A 2-1/2 1-1/8 1-1/2 1/2 1/2-13 HK-617 HK-617A 2-1/2 1-1/8 1-1/2 1/2 .499 HK-618 HK-618A 2-1/2 1-1/8 1-1/2 1/2 5/8-11 HK-619 HK-619A 2-1/2 1-1/8 1-1/2 1/2 .624 HK-620 HK-620A 2-1/2 1-1/8 1-1/2 1/2 .374 HK-621 HK-621A 2-1/2 1-1/8 1-1/2 1/2 Blank
- HK-826A 3 1-1/4 1-3/4 1/2 3/4-10
- HK-827A 3 1-1/2 1-3/4 1/2 .624
- HK-828A 3 1-1/2 1-3/4 1/2 .749
- HK-829A 3 1-1/2 1-3/4 1/2 Blank
Hand Knobs
j Cast iron hand knob with zinc plate finish
j Straight knurl design
j Available as a “blank” casting, blind thread, or tap through design
PART # Design Thread Thread Depth A B C D
SK-150 Blank Casting --1-1/2 7/8 5/8 3/8 SK-151 Blind Thread 1/4-20 7/16 1-1/2 7/8 5/8 3/8 SK-152 Tap Through 1/4-20 Tap Through 1-1/2 7/8 5/8 3/8 SK-153 Blind Thread 5/16-18 7/16 1-1/2 7/8 5/8 3/8 SK-154 Tap Through 5/16-18 Tap Through 1-1/2 7/8 5/8 3/8 SK-200 Blank Casting --27/8 3/4 3/8 SK-201 Blind Thread 5/16-18 9/16 2 7/8 3/4 3/8 SK-202 Tap Through 5/16-18 Tap Through 2 7/8 3/4 3/8 SK-203 Blind Thread 3/8-16 9/16 2 7/8 3/4 3/8 SK-204 Tap Through 3/8-16 Tap Through 2 7/8 3/4 3/8 SK-250 Blank Casting --2-1/2 1-1/2 1-1/8 1/2 SK-251 Blind Thread 1/2-13 3/4 2-1/2 1-1/2 1-1/8 1/2 SK-252 Tap Through 1/2-13 Tap Through 2-1/2 1-1/2 1-1/8 1/2 SK-253 Blind Thread 5/8-11 3/4 2-1/2 1-1/2 1-1/8 1/2 SK-254 Tap Through 5/8-11 Tap Through 2-1/2 1-1/2 1-1/8 1/2
j
22
w w w . m o r t o n m a c h i n e . c o m
Page 25
j Stainless steel
j Heavy duty solid hand knob
j Polished finish
j Available in blank form, reamed or tapped hole
ART # AB C D E Depth J
P
HK-1120SS 2 1.02 .78 .34 Blank .40 HK-1121SS 2 1.02 .78 .34 1/4 Ream .68 .40 HK-1122SS 2 1.02 .78 .34 1/4-20 .68 .40 HK-1123SS 2 1.02 .78 .34 5/16 Ream .68 .40 HK-1124SS 2 1.02 .78 .34 5/16-18 .68 .40 HK-1125SS 2 1.02 .78 .34 3/8 Ream .68 .40 HK-1126SS 2 1.02 .78 .34 3/8-16 .68 .40 HK-1130SS 3 1.50 1.14 .50 Blank .47 HK-1131SS 3 1.50 1.14 .50 3/8 Ream 1.00 .47 HK-1132SS 3 1.50 1.14 .50 3/8-16 1.00 .47 HK-1133SS 3 1.50 1.14 .50 1/2 Ream 1.00 .47 HK-1134SS 3 1.50 1.14 .50 1/2-13 1.00 .47 HK-1135SS 3 1.50 1.14 .50 5/8 Ream 1.00 .47 HK-1136SS 3 1.50 1.14 .50 5/8-11 1.00 .47
H a n d K n o b s
k
Stainless Steel Hand Knobs
j Hand knobs are made from forged aluminum
j Polished finish
j High tensile strength
j Available in two styles (blind or through hole)
Blind Tapped Hole (Form E)
PART # X Thread DABCF
764006E M6 x 1.0 40mm 15mm 25mm 12.5mm 15mm 764008E M8 x 1.25 40 15 25 12.5 15 765008E M8 x 1.25 50 19 32 16 18 765010E M10 x 1.5 50 19 32 16 18 766010E M10 x 1.5 60 21 40 20 22 766012E M12 x 1.75 60 21 40 20 22
Tapped Through Hole (Form D)
PART # X Thread DAB CH
764008D M8 x 1.25 40mm 15mm 25mm 12.5mm 15mm 765010D M10 x 1.5 50 19 32 16 20 766012D M12 x 1.75 60 21 40 20 26
Aluminum Hand Knobs
Metric
Form E
Form D
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
23
k
Page 26
j
H a n d K n o b s
Precision Control Knobs
j Available in aluminum or 303 stainless steel
j Optional handle design
j Knurled rim design
ITH HANDLE
luminum Stainless Steel Reamed
A
ART # PART # Dia. AB C D E G
P
CK-201 CK-301 3/8 2 1-1/8 13/16 9/16 7/8 1-9/32 CK-202 CK-302 Solid 2 1-1/8 13/16 9/16 - 1-15/16 CK-203 CK-303 5/8 3 1-1/4 1-1/4 9/16 7/8 1-9/32 CK-204 CK-304 Solid 3 1-1/4 1-1/4 9/16 - 1-15/16
luminum Stainless Steel Thread
A
ART # PART # Size Reamed AB CDE
P
CK-210 CK-310 - 1/4 1 13/16 1/2 3/8 5/8 CK-211 CK-311 - Solid Hub 1 13/16 1/2 3/8 ­CK-212 CK-312 1/4-20 -113/16 1/2 3/8 5/8 CK-213 CK-313 5/16-18 -113/16 1/2 3/8 5/8 CK-214 CK-314 - 3/8 2 1-1/8 13/16 9/16 7/8 CK-215 CK-315 - Solid Hub 2 1-1/8 13/16 9/16 ­CK-216 CK-316 3/8-16 -21-1/8 13/16 9/16 7/8 CK-217 CK-317 1/2-13 -21-1/8 13/16 9/16 7/8 CK-218 CK-318 - 5/8 3 1-1/4 1-1/4 11/16 7/8 CK-219 CK-319 - Solid Hub 3 1-1/4 1-1/4 11/16 ­CK-220 CK-320 5/8-11 -31-1/4 1-1/4 11/16 7/8 CK-221 CK-321 3/4-10 -31-1/4 1-1/4 11/16 7/8
W
ITHOUT HANDLE
W
Stainless Steel Hand Knobs
Metric
Through Hole Plastic Hand Knobs
j Made from 303 stainless bar stock
j Shot blast finish
j Two styles in metric (blind or through hole)
Tapped Through Hole (Form D)
PART # X Thread DABCH
564008D M8 x 1.25 40mm 18mm 26.5mm 11mm 13mm 565010D M10 x 1.5 50 21 29 12 16 566012D M12 x 1.75 60 25 33 12 20
Blind Tapped Hole (Form E)
PART # X Thread DABCF
564006E M6 x 1.0 40mm 18mm 26.5mm 11mm 12mm 564008E M8 x 1.25 40 18 26.5 11 12 565008E M8 x 1.25 50 21 29 12 15
565010E M10 x 1.5 50 21 29 12 15 566010E M10 x 1.5 60 25 33 12 18 566012E M12 x 1.75 60 25 33 12 18
j Available in inch and metric sizes
j Handle made from glass-fiber reinforced polyamide
j Black matte finish
j Bushing from steel, zinc-plated finish
j
24
PART # X Thread AB C DE
7132AC 1/4-20 .43 1.26 .55 .79 .39 7140AD 5/16-18 .51 1.57 .71 .98 .51 7150AE 3/8-16 .59 1.98 .86 1.26 .67 7163AF 1/2-13 .79 2.48 1.02 1.57 .82
PART # X Thread ABCDE
713206 M6 x 1.0 11mm 32mm 14mm 20mm 10mm 714008 M8 x 1.25 13 40 18 25 13 715010 M10 x 1.5 15 50 22 32 17 716312 M12 x 1.75 20 63 26 40 21
INCH
METRIC
w w w . m o r t o n m a c h i n e . c o m
Page 27
Black phenolic knob with brass insert
j
j Tapped through hole
j Four prong design
PART # AB C D Tapped Hole
HK-1250 1-1/4 5/8 7/8 1/2 1/4-20 HK-1251 1-1/4 5/8 7/8 1/2 5/16-18 HK-1751 1-3/4 13/16 1’’ 1/2 5/16-18 HK-1752 1-3/4 13/16 1’’ 1/2 3/8-16 HK-2252 2-1/4 1’’ 1-1/8 9/16 3/8-16 HK-2253 2-1/4 1’’ 1-1/8 9/16 1/2-13
H a n d K n o b s
k
Plastic Hand Knobs
j Easy to use...slide knob along length of stud and tilt the handle to engage the threads
j Steel knob, black oxide finish
j A great time saver!
j Four prong design
PART # Thread Size ABCD
QK-10 1/4-20 1-1/8 9/16 5/8 5/16 QK-11 5/16-18 1-1/2 11/16 7/8 3/8 QK-12 3/8-16 2" 13/16 1" 1/2 QK-13 1/2-13 2-1/2 1" 1-1/8 9/16 QK-14 5/8-11 3" 1-1/4 1-1/4 5/8 QK-15 3/4-10 3" 1-1/4 1-1/4 5/8
PART # Thread Size ABCD
QK-20 M6 x 1.0 30mm 14mm 16mm 8mm QK-21 M8 x 1.25 38 17 22 10 QK-22 M10 x 1.5 50 21 25 13 QK-23 M12 x 1.75 64 25 30 14 QK-24 M16 x 2.0 76 32 32 16
INCH
METRIC
Quick-Change Knobs
Metric Quick-Change Knobs
j Black thermoplastic knob
j Steel bushing with zinc-plated finish
j Easy to use...slide knob along length of stud and
tilt the handle to engage the threads.
j A great time saver!
PART # X Thread DBC
254008 M8 x 1.25 40mm 26mm 13mm 255010 M10 x 1.5 50 34 17 256312 M12 x 1.75 63 42 21
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
25
k
Page 28
j
H a n d K n o b s
Plastic Hand Knobs
j Black thermoplastic hand knob
Thread bushing is made from steel with zinc-plated finish
j
j Additional sizes available upon request
Plastic Hand Knobs
with steel screws
PART # X Thread Thread Depth DA BC
2425AC 1/4-20 .35 .98 .47 .63 .32 2432AC 1/4-20 .35 1.26 .55 .79 .39 2440AD 5/16-18 .55 1.57 .71 .98 .51 2450AD 5/16-18 .55 1.97 .87 1.26 .67 2450AE 3/8-16 .83 1.97 .87 1.26 .67 2463AE 3/8-16 .91 2.48 1.02 1.57 .83 2463AF 1/2-13 .91 2.48 1.02 1.57 .83
PART # X Thread Thread Depth DA BC
PHK-151 M5 x .8 8.5mm 25mm 12mm 16mm 8mm PHK-152 M6 x 1.0 9 32 14 20 10 PHK-153 M8 x 1.25 14 40 18 25 13 PHK-154 M10 x 1.5 21 50 22 32 17 PHK-155 M12 x 1.75 23 63 26 40 21
INTERNAL THREAD
INTERNAL METRIC THREAD
j Black thermoplastic hand knob
j Steel screw with zinc-plated finish
j Additional sizes available upon request
j
26
PART # X Thread LDABC
2425AC015 1/4-20 0.59 0.98 0.47 0.63 0.32 2425AC022 1/4-20 0.88 0.98 0.47 0.63 0.32 2425AC028 1/4-20 1.10 0.98 0.47 0.63 0.32 2425AC034 1/4-20 1.34 0.98 0.47 0.63 0.32 2440AD017 5/16-18 0.67 1.57 0.71 0.98 0.51 2440AD024 5/16-18 0.94 1.57 0.71 0.98 0.51 2440AD030 5/16-18 1.18 1.57 0.71 0.98 0.51 2450AE018 3/8-16 0.71 1.97 0.87 1.26 0.67 2450AE030 3/8-16 1.18 1.97 0.87 1.26 0.67 2450AE043 3/8-16 1.70 1.97 0.87 1.26 0.67 2463AF025 1/2-13 0.98 2.48 1.02 1.57 0.83 2463AF046 1/2-13 1.82 2.48 1.02 1.57 0.83
PART # X Thread LDABC
PHK-251 M5 x .8 15mm 25mm 12mm 16mm 8mm PHK-2515 M5 x .8 25 25 12 16 8 PHK-252 M6 x 1.0 21 32 14 20 10 PHK-2525 M6 x 1.0 31 32 14 20 10 PHK-253 M8 x 1.25 25 40 18 25 13 PHK-2535 M8 x 1.25 40 40 18 25 13 PHK-254 M10 x 1.5 30 50 22 32 17 PHK-2545 M10 x 1.5 50 50 22 32 17 PHK-255 M12 x 1.75 40 63 26 40 21 PHK-2555 M12 x 1.75 60 63 26 40 21
INCH - EXTERNAL THREAD
METRIC - EXTERNAL THREAD
w w w . m o r t o n m a c h i n e . c o m
Page 29
j Black thermoplastic hand knob
j Stainless steel screw
j Additional sizes available upon request.
H a n d K n o b s
k
Plastic Hand Knobs
tainless steel screw
s
PART # X Thread LDABC
2425AC015SS 1/4-20 0.59 0.98 0.47 0.63 0.32 2425AC028SS 1/4-20 1.10 0.98 0.47 0.63 0.32 2425AC034SS 1/4-20 1.34 0.98 0.47 0.63 0.32 2440AD017SS 5/16-18 0.67 1.57 0.71 0.98 0.51 2440AD024SS 5/16-18 0.94 1.57 0.71 0.98 0.51 2440AD036SS 5/16-18 1.42 1.57 0.71 0.98 0.51 2450AE018SS 3/8-16 0.71 1.97 0.87 1.26 0.67 2450AE030SS 3/8-16 1.18 1.97 0.87 1.26 0.67 2450AE043SS 3/8-16 1.70 1.97 0.87 1.26 0.67 2463AF020SS 1/2-13 0.79 2.48 1.02 1.57 0.83 2463AF046SS 1/2-13 1.81 2.48 1.02 1.57 0.83
ART # X Thread LDABC
P
PHK-252SS M6 x 1.0 21 32 14 20 10 PHK-2525SS M6 x 1.0 31 32 14 20 10 PHK-2528SS M8 x 1.25 20 40 18 25 13 PHK-2535SS M8 x 1.25 40 40 18 25 13 PHK-254SS M10 x 1.5 30 50 22 32 17 PHK-2548SS M10 x 1.5 50 50 22 32 17 PHK-255SS M12 x 1.75 44 63 26 40 21
INCH SCREW SIZES
METRIC SCREW SIZES
Metric Star Knobs
j Black Duroplastic FS31
j Extra smooth finish
j Thread bushing is made from steel with zinc-plated finish
j Steel screw with zinc-plated finish
j
Additional sizes available upon request
PART #
PHK-351 M5 x .8 25mm 11mm 17mm 9mm 10.5mm PHK-352 M6 x 1.0 32 14 21 10 12 PHK-353 M8 x 1.25 40 18 26 14 14 PHK-354 M10 x 1.5 50 22 32 18 18 PHK-355 M12 x 1.75 63 26 42 25 22
PART #
PHK-4515 M5 x .8 15mm 25mm 11mm 17mm 9mm PHK-4620 M6 x 1.0 20 32 14 21 10 PHK-4630 M6 x 1.0 30 32 14 21 10 PHK-4820 M8 x 1.25 20 40 18 26 14 PHK-4830 M8 x 1.25 30 40 18 26 14 PHK-41025 M10 x 1.5 25 50 22 32 18 PHK-41035 M10 x 1.5 35 50 22 32 18 PHK-41240 M12 x 1.75 40 63 26 42 25 PHK-41260 M12 x 1.75 60 63 26 42 25
X Thread
X Thread
INTERNAL METRIC THREAD
DA B C F
EXTERNAL METRIC THREAD
LDABC
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
27
k
Page 30
j
H a n d K n o b s
Plastic Hand Knobs
through hole
Plastic Hand Knobs
blind hole
j Phenolic hand knob
j Brass insert
j Four arm design
ART # Thread Depth ABC D
P
HK-1525 1/4-20 3/8 1-1/2 1 5/8 1/2 HK-1531 5/16-18 1/2 1-1/2 1 5/8 1/2 HK-2031 5/16-18 1/2 217/8 1/2 HK-2037 3/8-16 1/2 217/8 1/2 HK-2050 1/2-13 5/8 217/8 1/2
Plastic Hand Knobs
with stud
j Phenolic hand knob
j Zinc-plated insert
j Four arm design
PART # Thread Depth ABC D
HK-3125 1/4-20 3/8 1-1/2 1 5/8 1/2 HK-3131 5/16-18 1/2 1-1/2 1 5/8 1/2 HK-3137 3/8-16 1/2 217/8 1/2 HK-3150 1/2-13 5/8 217/8 1/2
j Phenolic hand knob
j Steel, zinc plated stud
j Four arm design
j
28
PART # Thread Thread Lgth ABC D
HK-4251 1/4-20 1 1-1/2 1 5/8 1/2 HK-4311 5/16-18 1 1-1/2 1 5/8 1/2 HK-4371 3/8-16 12 17/8 1/2 HK-4375 3/8-16 1-1/2 217/8 1/2 HK-4507 1/2-13 3/4 217/8 1/2
w w w . m o r t o n m a c h i n e . c o m
Page 31
j Glass filled nylon
j Brass insert
j Three arm design
PART # Thread Depth ABCD
HK-8101 #8-32 3/8 1-5/32 3/4 1/2 1/4 HK-8102 #10-32 3/8 1-5/32 3/4 1/2 1/4 HK-8103 1/4-20 1/2 1-5/32 3/4 1/2 1/4 HK-8104 5/16-18 1/2 1-5/32 3/4 1/2 1/4
H a n d K n o b s
k
Plastic Hand Knobs
Plastic Hand Knobs
with stud
j Glass filled nylon
j Steel, zinc plated stud
j Three arm design
PART #
HK-8121 #8-32 3/8 1-5/32 3/4 1/2 1/4 HK-8122 #10-32 3/8 1-5/32 3/4 1/2 1/4 HK-8123 1/4-20 1/2 1-5/32 3/4 1/2 1/4 HK-8124 1/4-20 3/4 1-5/32 3/4 1/2 1/4 HK-8125 1/4-20 1 1-5/32 3/4 1/2 1/4 HK-8126 5/16-18 5/8 1-5/32 3/4 1/2 1/4 HK-8127 5/16-18 1 1-5/32 3/4 1/2 1/4
Thread Thread Length
ABCD
j Phenolic hand knob
j Brass insert
j Knurled rim
Plastic Hand Knobs
PART # X Thread Depth AB CD
HK-6032 #10-32 5/16 1 1/2 5/8 1/8 HK-6125 1/4-20 3/8 1 3/4 5/8 1/8 HK-6131 5/16-18 1/2 1-1/4 3/4 3/4 17/64 HK-6137 3/8-16 1/2 1-1/4 3/4 3/4 17/64
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
29
k
Page 32
j
H a n d K n o b s
Heavy Duty Plastic Hand Knobs
j Phenolic hand knob
j Brass insert
j Rugged design, excellent for high torque applications
PART # Thread Depth ABCD
HK-5032 #8-32 3/8 3/4 11/16 1/2 3/8 HK-5125 1/4-20 3/8 1” 7/8 3/4 7/16 HK-5131 5/16-18 1/2 1-3/16 13/16 13/16 3/8 HK-5137 3/8-16 1/2 1-5/8 7/8 1-5/32 9/32 HK-5250 1/2-13 5/8 2-1/2 1-1/2 1-1/4 21/32
Bar Knobs
j Phenolic hand knob
j Zinc-plated steel hex nut within through hole knob
j Brass threaded insert
PART # Thread Depth ABCD
TK-125 1/4-20 Hex Nut 2 1-1/8 3/4 1/2 TK-131 5/16-18 Hex Nut 2 1-1/8 3/4 1/2 TK-137 3/8-16 Hex Nut 2 1-1/8 3/4 1/2
THRU-HOLE
j
30
PART # Thread Depth ABCD
TK-225 1/4-20 1/2 2-1/2 1-1/8 3/4 1/2 TK-231 5/16-18 1/2 2-1/2 1-1/8 3/4 1/2 TK-237 3/8-16 1/2 2-1/2 1-1/8 3/4 1/2 TK-250 1/2-13 5/8 3-1/2 1-1/8 15/16 1/4
BLIND HOLE
w w w . m o r t o n m a c h i n e . c o m
Page 33
j Phenolic hand knob
j Brass insert
PART # Thread Depth ABC D
HK-7101 #6-32 1/4 1/2 1/2 3/8 5/32 HK-7102 #8-32 1/4 5/8 9/16 7/16 3/8 HK-7103 #10-24 5/16 5/8 9/16 7/16 3/8 HK-7104 #10-32 5/16 5/8 9/16 7/16 3/8
H a n d K n o b s
k
Miniature Hand Knobs
Miniature Hand Knobs
with stud
j Phenolic hand knob
j Steel, zinc-plated stud
PART #
HK-7121 #8-32 3/8 5/8 1/4 7/16 1/16 HK-7122 #8-32 1/2 5/8 1/4 7/16 1/16 HK-7123 #10-32 1/2 11/16 9/16 5/8 5/16 HK-7124 #10-32 3/4 13/16 1/2 7/16 1/4 HK-7125 #10-24 5/8 13/16 1/2 7/16 1/4
Thread Thread Length
ABCD
j Phenolic hand knob
j Brass insert
Push/Pull Knobs
PART # Thread Depth ABC
HK-7701 #6-32 1/4 11/16 3/4 3/8 HK-7702 #8-32 1/4 11/16 3/4 3/8 HK-7703 #8-32 3/8 11/16 3/4 3/8 HK-7704 #10-32 5/16 11/16 3/4 3/8 HK-7705 1/4-20 3/8 7/8 7/8 1/2
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
31
k
Page 34
j
H a n d l e s
Pull Handles
aluminum
j Natural matte finish
j Aluminum offers high stability...available without tapped
holes upon request
Pull Handles
aluminum
PART # X B L A H RT
PH-20 M6 x 1.0 20mm 100mm 13mm 47mm 13mm 10mm PH-21 M6 x 1.0 20 128 13 51 13 10 PH-22 M8 x 1.25 26 128 17 55 17 12 PH-23 M8 x 1.25 26 160 17 57 17 12 PH-24 M8 x 1.25 26 192 17 57 17 12 PH-25 M8 x 1.25 26 300 17 57 17 12
ALUMINUM
j
32
j Available in natural matte finish or plastic coated aluminum
j Allows assembly from the front of the handle
Black Finish Matte Finish
PART # PART # b l1 l2 adh1 h2 r
PH-30 PH-40 26mm 116mm 130mm 17mm 6.3mm 53mm 17mm 17mm PH-31 PH-41 26 132 146 17 6.3 55 17 17 PH-32 PH-42 26 164 178 17 6.3 57 17 17 PH-33 PH-43 26 196 210 17 6.3 57 17 17
w w w . m o r t o n m a c h i n e . c o m
Page 35
j Black thermoplastic ball knob
j High polished finish
j Internal thread
B a l l K n o b s
k
Plastic Ball Knobs
PART # X Thread Depth ABC
PB-5 #10-32 5/16 25/32 47/64 3/8 PB-9 1/4-20 7/16 1 29/32 1/2 PB-10 5/16-18 7/16 1 29/32 1/2 PB-11 3/8-16 1/2 1-3/8 1-3/16 5/8 PB-13 1/2-13 5/8 1-7/8 1-1/2 3/4 PB-15 1/2-13 3/4 2 1-27/32 1-1/16
PART # X Thread AB C
PB-20 M4 x .7 16mm 8mm 8mm PB-21 M5 x .8 20 10.5 12 PB-22 M6 x 1.0 25 13.5 15 PB-23 M8 x 1.25 32 16 16 PB-24 M10 x 1.5 36 21 18 PB-25 M12 x 1.75 40 25 22
INCH
METRIC
Steel and Brass Ball Knobs
j Machined from bar stock
j High polished decorative finish
PART # X Thread AB
STEEL BALL KNOBS
SK-31 #10-24 3/4 3/8 SK-32 #10-32 3/4 3/8 SK-35 1/4-20 1 1/2 SK-39 1/4-20 1-3/8 5/8 SK-37 5/16-18 1 1/2 SK-42 5/16-18 1-3/8 5/8 SK-44 3/8-16 1-3/8 5/8 SK-49 3/8-16 1-7/8 3/4 SK-47 1/2-13 1-3/8 5/8 SK-52 1/2-13 1-7/8 3/4 SK-54 5/8-11 1-7/8 3/4
PART # X Thread AB
BK-31 #10-24 3/4 3/8 BK-32 #10-32 3/4 3/8 BK-35 1/4-20 1 1/2 BK-39 1/4-20 1-3/8 5/8 BK-37 5/16-18 1 1/2 BK-42 5/16-18 1-3/8 5/8 BK-44 3/8-16 1-3/8 5/8 BK-49 3/8-16 1-7/8 3/4 BK-47 1/2-13 1-3/8 5/8 BK-52 1/2-13 1-7/8 3/4 BK-54 5/8-11 1-7/8 3/4
BRASS BALL KNOBS
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
33
k
Page 36
j
C l a m p i n g L e v e r s
Adjustable Clamping Levers
plastic handle / die-cast zinc handle
LIFT AND ROTATE
HANDLE 360°
U.S. PATENT
5,533,232
j Black thermoplastic handle with metal insert
j Zinc die-cast handle with black finish
j Orange handles available
All steel parts ensure durability
j
j Internal thread with black oxide finish
lastic Die-Cast
P Handle Handle Thread Thread
ART # PART # X Depth B C D E F
P
AH-101 MH-101 #10-24 .32 .55 .95 1.65 1.30 .39 AH-102 MH-102 #10-32 .32 .55 .95 1.65 1.30 .39 AH-103 MH-103 1/4-20 .32 .55 .95 1.65 1.30 .39 AH-104 MH-104 1/4-20 .40 .71 1.22 2.56 1.77 .53 AH-105 MH-105 5/16-18 .40 .71 1.22 2.56 1.77 .53 AH-106 MH-106 5/16-18 .55 .86 1.41 3.07 2.12 .63 AH-107 MH-107 3/8-16 .55 .86 1.41 3.07 2.12 .63 AH-108 MH-108 3/8-16 .67 .98 1.69 3.62 2.52 .75 AH-109 MH-109 1/2-13 .67 .98 1.69 3.62 2.52 .75
- MH-112 1/2-13 .90 1.18 1.98 4.25 2.95 .91
- MH-113 5/8-11 .90 1.18 1.98 4.25 2.95 .91
Adjustable Clamping Levers
plastic handle with stud / die-cast zinc handle with stud
LIFT AND ROTATE
HANDLE 360°
U.S. PATENT
5,533,232
j Black thermoplastic handle with metal insert
j Zinc die-cast handle with black finish
j Steel parts give increased stability and rigidity
j Orange handles available
j External steel stud with black oxide finish
j Additional thread lengths available upon request
Plastic Die-Cast Handle Handle
PART # PART # X Thread LB C D EF
AH-301 MH-301 #10-24 .63 .55 .95 1.65 1.30 .39 AH-302 MH-302 #10-32 .63 .55 .95 1.65 1.30 .39 AH-3027 MH-3027 #10-32 1.25 .55 .95 1.65 1.30 .39 AH-303 MH-303 1/4-20 .78 .55 .95 1.65 1.30 .39 AH-3032 MH-3032 1/4-20 .98 .55 .95 1.65 1.30 .39 AH-3034 MH-3034 1/4-20 1.25 .55 .95 1.65 1.30 .39 AH-3038 MH-3038 1/4-20 1.57 .55 .95 1.65 1.30 .39 AH-3036 MH-3036 1/4-20 1.78 .55 .95 1.65 1.30 .39 AH-3035 MH-3035 1/4-20 .98 .71 1.22 2.56 1.77 .53 AH-3037 MH-3037 5/16-18 .78 .71 1.22 2.56 1.77 .53 AH-3039 MH-3039 5/16-18 1.26 .71 1.22 2.56 1.77 .53 AH-304 MH-304 5/16-18 1.57 .71 1.22 2.56 1.77 .53 AH-3043 MH-3043 5/16-18 1.97 .71 1.22 2.56 1.77 .53 AH-3045 MH-3045 5/16-18 2.48 .71 1.22 2.56 1.77 .53 AH-3047 MH-3047 3/8-16 .78 .71 1.22 2.56 1.77 .53 AH-3048 MH-3048 3/8-16 1.25 .71 1.22 2.56 1.77 .53 AH-305 MH-305 3/8-16 1.57 .71 1.22 2.56 1.77 .53 AH-3053 MH-3053 5/16-18 1.97 .86 1.41 3.07 2.12 .63 AH-3056 MH-3056 3/8-16 .98 .86 1.41 3.07 2.12 .63 AH-3058 MH-3058 3/8-16 1.26 .86 1.41 3.07 2.12 .63 AH-306 MH-306 3/8-16 1.57 .86 1.41 3.07 2.12 .63 AH-307 MH-307 3/8-16 1.97 .86 1.41 3.07 2.12 .63 AH-3079 MH-3079 3/8-16 2.48 .86 1.41 3.07 2.12 .63 AH-3075 MH-3075 3/8-16 1.57 .98 1.69 3.62 2.52 .75 AH-3078 MH-3078 3/8-16 1.97 .98 1.69 3.62 2.52 .75 AH-308 MH-308 1/2-13 1.25 .98 1.69 3.62 2.52 .75 AH-3085 MH-3085 1/2-13 1.57 .98 1.69 3.62 2.52 .75 AH-309 MH-309 1/2-13 1.97 .98 1.69 3.62 2.52 .75 AH-310 MH-310 1/2-13 2.48 .98 1.69 3.62 2.52 .75
- MH-321 1/2-13 1.57 1.18 1.98 4.25 2.95 .91
- MH-322 1/2-13 2.48 1.18 1.98 4.25 2.95 .91
- MH-324 5/8-11 1.57 1.18 1.98 4.25 2.95 .91
- MH-325 5/8-11 2.48 1.18 1.98 4.25 2.95 .91
j
34
w w w . m o r t o n m a c h i n e . c o m
Page 37
C l a m p i n g L e v e r s
k
Black thermoplastic handle with metal insert
j
j Zinc die-cast handle with black finish
j Orange handles available
j All steel parts ensure durability
j Internal metric thread with black oxide finish
lastic Die-Cast
P
andle Handle Thread Thread
H
PART # PART # X Depth B C D E F
AH-201 MH-201 M4 x .7 8mm 14mm 24mm 42mm 33mm 10mm AH-202 MH-202 M5 x .8 8 14 24 42 33 10 AH-203 MH-203 M6 x 1.0 8 14 24 42 33 10 AH-204 MH-204 M6 x 1.0 10 18 31 65 45 13.5 AH-205 MH-205 M8 x 1.25 10 18 31 65 45 13.5 AH-206 MH-206 M8 x 1.25 14 22 36 78 54 16 AH-207 MH-207 M10 x 1.50 14 22 36 78 54 16 AH-208 MH-208 M10 x 1.50 17 25 43 92 64 19 AH-209 MH-209 M12 x 1.75 17 25 43 92 64 19
- MH-210 M12 x 1.75 23 30 50 108 75 23
- MH-211 M16 x 2.0 23 30 50 108 75 23
Metric Adjustable Clamping Levers
Metric Adjustable Clamping Levers
Plastic Die-Cast
Handle Handle
PART # PART # X Thread LB C D EF
AH-401 MH-401 M5 x .8 12mm 14mm 24mm 42mm 33mm 10mm AH-402 MH-402 M5 x .8 16 14 24 42 33 10 AH-403 MH-403 M5 x .8 20 14 24 42 33 10 AH-4035 MH-4035 M5 x .8 40 14 24 42 33 10 AH-404 MH-404 M6 x 1.0 16 14 24 42 33 10 AH-405 MH-405 M6 x 1.0 20 14 24 42 33 10 AH-406 MH-406 M6 x 1.0 25 14 24 42 33 10 AH-407 MH-407 M6 x 1.0 32 14 24 42 33 10 AH-408 MH-408 M6 x 1.0 40 14 24 42 33 10 AH-409 MH-409 M8 x 1.25 20 18 31 65 45 13.5 AH-410 MH-410 M8 x 1.25 25 18 31 65 45 13.5 AH-411 MH-411 M8 x 1.25 32 18 31 65 45 13.5 AH-412 MH-412 M8 x 1.25 40 18 31 65 45 13.5 AH-413 MH-413 M8 x 1.25 50 18 31 65 45 13.5 AH-414 MH-414 M8 x 1.25 63 18 31 65 45 13.5 AH-415 MH-415 M10 x 1.50 20 18 31 65 45 13.5 AH-416 MH-416 M10 x 1.50 32 18 31 65 45 13.5 AH-417 MH-417 M10 x 1.50 40 18 31 65 45 13.5 AH-418 MH-418 M10 x 1.50 50 18 31 65 45 13.5 AH-419 MH-419 M10 x 1.50 20 22 36 78 54 16 AH-4195 MH-4195 M10 x 1.50 25 22 36 78 54 16 AH-420 MH-420 M10 x 1.50 32 22 36 78 54 16 AH-421 MH-421 M10 x 1.50 40 22 36 78 54 16 AH-422 MH-422 M10 x 1.50 50 22 36 78 54 16 AH-423 MH-423 M10 x 1.50 63 22 36 78 54 16
- MH-4233 M10 x 1.50 32 25 43 92 64 19
- MH-4234 M10 x 1.50 40 25 43 92 64 19
- MH-4235 M10 x 1.50 50 25 43 92 64 19
- MH-4236 M10 x 1.50 63 25 43 92 64 19 AH-424 MH-424 M12 x 1.75 32 25 43 92 64 19 AH-425 MH-425 M12 x 1.75 40 25 43 92 64 19 AH-426 MH-426 M12 x 1.75 50 25 43 92 64 19 AH-427 MH-427 M12 x 1.75 63 25 43 92 64 19
- MH-4275 M12 x 1.75 40 30 50 108 75 23
- MH-428 M12 x 1.75 63 30 50 108 75 23
plastic handle with stud / die-cast zinc handle with stud
plastic handle / die-cast zinc handle
LIFT AND ROTATE
ANDLE 360°
H
U.S. PATENT
5,533,232
LIFT AND ROTATE
HANDLE 360°
U.S. PATENT
5,533,232
j Black thermoplastic handle with metal insert
j Zinc die-cast handle with black finish
j Orange handles available
j Steel parts give increased stability and rigidity
j External steel stud with black oxide finish
j Additional thread lengths available upon request
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
35
k
Page 38
j
C l a m p i n g L e v e r s
Stainless Steel Adjustable Clamping Levers
j Zinc die-cast handle with black finish
j All internal components made from stainless steel
LIFT AND ROTATE
ANDLE 360°
H
PART # X Thread B C D E F
MH-101SS #10-24 .55 .95 1.65 1.30 .39 MH-102SS #10-32 .55 .95 1.65 1.30 .39 MH-103SS 1/4-20 .55 .95 1.65 1.30 .39 MH-104SS 1/4-20 .71 1.22 2.56 1.77 .53 MH-105SS 5/16-18 .71 1.22 2.56 1.77 .53 MH-106SS 5/16-18 .86 1.41 3.07 2.12 .63 MH-107SS 3/8-16 .86 1.41 3.07 2.12 .63 MH-108SS 3/8-16 .98 1.69 3.62 2.52 .75 MH-109SS 1/2-13 .98 1.69 3.62 2.52 .75
Stainless Steel Adjustable Clamping Levers
with stud
j Zinc die-cast handle with black finish
j Stud made from stainless steel
j All internal components made from stainless steel
PART # X Thread LB C D EF
MH-301SS #10-24 .63 .55 .95 1.65 1.30 .39 MH-302SS #10-32 .63 .55 .95 1.65 1.30 .39
LIFT AND ROTATE
HANDLE 360°
MH-3027SS #10-32 1.25 .55 .95 1.65 1.30 .39 MH-303SS 1/4-20 .78 .55 .95 1.65 1.30 .39 MH-3032SS 1/4-20 .98 .55 .95 1.65 1.30 .39 MH-3034SS 1/4-20 1.25 .55 .95 1.65 1.30 .39 MH-3038SS 1/4-20 1.57 .55 .95 1.65 1.30 .39 MH-3036SS 1/4-20 1.78 .55 .95 1.65 1.30 .39 MH-3035SS 1/4-20 .98 .71 1.22 2.56 1.77 .53 MH-3037SS 5/16-18 .78 .71 1.22 2.56 1.77 .53 MH-304SS 5/16-18 1.57 .71 1.22 2.56 1.77 .53 MH-3043SS 5/16-18 1.97 .71 1.22 2.56 1.77 .53 MH-3045SS 5/16-18 2.48 .71 1.22 2.56 1.77 .53 MH-3047SS 3/8-16 .78 .71 1.22 2.56 1.77 .53 MH-3048SS 3/8-16 1.25 .71 1.22 2.56 1.77 .53 MH-305SS 3/8-16 1.57 .71 1.22 2.56 1.77 .53 MH-3053SS 5/16-18 1.97 .86 1.41 3.07 2.12 .63 MH-306SS 3/8-16 1.57 .86 1.41 3.07 2.12 .63 MH-307SS 3/8-16 1.97 .86 1.41 3.07 2.12 .63 MH-3075SS 3/8-16 1.57 .98 1.69 3.62 2.52 .75 MH-3078SS 3/8-16 1.97 .98 1.69 3.62 2.52 .75 MH-308SS 1/2-13 1.25 .98 1.69 3.62 2.52 .75 MH-3085SS 1/2-13 1.57 .98 1.69 3.62 2.52 .75 MH-309SS 1/2-13 1.97 .98 1.69 3.62 2.52 .75
j
36
w w w . m o r t o n m a c h i n e . c o m
Page 39
j Zinc die-cast handle with black finish
j All internal components made from stainless steel
C l a m p i n g L e v e r s
k
Stainless Steel Adjustable Clamping Levers
metric
LIFT AND ROTATE
HANDLE 360°
PART # X Thread Depth B C D E F
Thread
MH-202SS M5 x .8 8mm 14mm 24mm 42mm 33mm 10mm MH-203SS M6 x .10 8 14 24 42 33 10 MH-205SS M8 x 1.25 10 18 31 65 45 13.5 MH-207SS M10 x 1.50 14 22 36 78 54 16 MH-208SS M10 x 1.50 17 25 43 92 64 19 MH-209SS M12 x 1.75 17 25 43 92 64 19
Stainless Steel Adjustable Clamping Levers
j Zinc die-cast handle with black finish
j Stud made from stainless steel
j All internal components made from stainless steel
metric with stud
PART # X Thread LB C D EF
MH-4035SS M5 x .8 40mm 14mm 24mm 42mm 33mm 10mm MH-405SS M6 x 1.0 20 14 24 42 33 10 MH-406SS M6 x 1.0 25 14 24 42 33 10 MH-407SS M6 x 1.0 32 14 24 42 33 10 MH-408SS M6 x 1.0 40 14 24 42 33 10 MH-409SS M8 x 1.25 20 18 31 65 45 13.5 MH-410SS M8 x 1.25 25 18 31 65 45 13.5 MH-411SS M8 x 1.25 32 18 31 65 45 13.5 MH-412SS M8 x 1.25 40 18 31 65 45 13.5 MH-413SS M8 x 1.25 50 18 31 65 45 13.5 MH-414SS M8 x 1.25 63 18 31 65 45 13.5 MH-4195SS M10 x 1.50 25 22 36 78 54 16 MH-420SS M10 x 1.50 32 22 36 78 54 16 MH-421SS M10 x 1.50 40 22 36 78 54 16 MH-422SS M10 x 1.50 50 22 36 78 54 16 MH-4236SS M10 x 1.50 63 25 43 92 64 19 MH-424SS M12 x 1.75 32 25 43 92 64 19 MH-425SS M12 x 1.75 40 25 43 92 64 19 MH-426SS M12 x 1.75 50 25 43 92 64 19
LIFT AND ROTATE
HANDLE 360°
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
37
k
Page 40
j
C l a m p i n g L e v e r s
Economy Adjustable Clamping Levers
j Internal thread
j Excellent pricing...quality low cost solution
IFT AND ROTATE
L
HANDLE 360°
j Handle made from glass-fiber reinforced polyamide
j Bushing made from zinc-plated steel
j Resistant to oils, solvents, and other chemicals
PART #
AH-811 #10-24 .29 .63 1.04 1.18 1.28 .47 AH-812 #10-32 .29 .63 1.04 1.18 1.28 .47 AH-813 1/4-20 .29 .63 1.04 1.18 1.28 .47 AH-801 #10-24 .29 .63 1.04 1.65 1.38 .47 AH-802 #10-32 .29 .63 1.04 1.65 1.38 .47 AH-803 1/4-20 .29 .63 1.04 1.65 1.38 .47 AH-804 1/4-20 .45 .79 1.42 2.56 1.97 .59 AH-805 5/16-18 .45 .79 1.42 2.56 1.97 .59 AH-806 5/16-18 .56 .98 1.81 3.15 2.48 .79 AH-807 3/8-16 .56 .98 1.81 3.15 2.48 .79 AH-808 1/2-13 .56 .98 1.81 3.15 2.48 .79
Economy Adjustable Clamping Levers
with Stud
j Zinc-plated steel stud
j Excellent pricing...quality low cost solution
LIFT AND ROTATE
HANDLE 360°
j Handle made from glass-fiber reinforced polyamide
j Resistant to oils, solvents, and other chemicals
PART # X Thread L B C D E F
AH-840 #10-32 .39 .63 1.04 1.18 1.28 .47 AH-841 #10-32 .79 .63 1.04 1.18 1.28 .47 AH-842 1/4-20 .59 .63 1.04 1.18 1.28 .47 AH-843 1/4-20 .79 .63 1.04 1.18 1.28 .47 AH-844 1/4-20 1.18 .63 1.04 1.18 1.28 .47 AH-820 #10-32 .39 .63 1.04 1.65 1.38 .47 AH-821 #10-32 .79 .63 1.04 1.65 1.38 .47 AH-822 1/4-20 .59 .63 1.04 1.65 1.38 .47 AH-823 1/4-20 .79 .63 1.04 1.65 1.38 .47 AH-824 1/4-20 1.18 .63 1.04 1.65 1.38 .47 AH-825 5/16-18 .59 .79 1.42 2.56 1.97 .59 AH-826 5/16-18 .79 .79 1.42 2.56 1.97 .59 AH-827 5/16-18 1.18 .79 1.42 2.56 1.97 .59 AH-828 5/16-18 1.57 .79 1.42 2.56 1.97 .59 AH-829 3/8-16 .79 .98 1.81 3.15 2.48 .79 AH-830 3/8-16 1.18 .98 1.81 3.15 2.48 .79 AH-831 3/8-16 1.57 .98 1.81 3.15 2.48 .79 AH-832 3/8-16 1.97 .98 1.81 3.15 2.48 .79 AH-833 1/2-13 1.18 .98 1.81 3.15 2.48 .79 AH-834 1/2-13 1.97 .98 1.81 3.15 2.48 .79
X Thread Thread Depth
B C D E F
j
38
w w w . m o r t o n m a c h i n e . c o m
Page 41
j Internal thread
j Excellent pricing...quality low cost solution
j Handle made from glass-fiber reinforced polyamide
j Bushing made from zinc-plated steel
j Resistant to oils, solvents, and other chemicals
C l a m p i n g L e v e r s
k
Economy Adjustable Clamping Levers
metric
LIFT AND ROTATE
HANDLE 360°
PART #
AH-911 M4 x .7 7.5mm 16mm 26.5mm 30mm 32.4mm 12mm AH-912 M5 x .8 7.5 16 26.5 30 32.4 12 AH-913 M6 x 1.0 7.5 16 26.5 30 32.4 12 AH-901 M4 x .7 7.5 16 26.5 42 35 12 AH-902 M5 x .8 7.5 16 26.5 42 35 12 AH-903 M6 x 1.0 7.5 16 26.5 42 35 12 AH-904 M6 x 1.0 11.5 20 36 65 50 15 AH-905 M8 x 1.25 11.5 20 36 65 50 15 AH-906 M8 x 1.25 14 25 46 80 63 20 AH-907 M10 x 1.50 14 25 46 80 63 20 AH-908 M12 x 1.75 14 25 46 80 63 20
j Zinc-plated steel stud
X Thread Thread Depth
B C D E F
Economy Adjustable Clamping Levers
j Excellent pricing...quality low cost solution
j Handle made from glass-fiber reinforced polyamide
j Resistant to oils, solvents, and other chemicals
PART # X Thread L B C D E F
AH-949 M4 x .7 10mm 16mm 26.5mm 30mm 32.4mm 12mm AH-940 M5 x .8 10 16 26.5 30 32.4 12 AH-941 M5 x .8 20 16 26.5 30 32.4 12 AH-943 M6 x 1.0 10 16 26.5 30 32.4 12 AH-944 M6 x 1.0 15 16 26.5 30 32.4 12 AH-945 M6 x 1.0 20 16 26.5 30 32.4 12 AH-919 M4 x .7 10 16 26.5 42 35 12 AH-920 M5 x .8 10 16 26.5 42 35 12 AH-921 M5 x .8 20 16 26.5 42 35 12 AH-922 M5 x .8 30 16 26.5 42 35 12 AH-923 M6 x 1.0 10 16 26.5 42 35 12 AH-924 M6 x 1.0 15 16 26.5 42 35 12 AH-925 M6 x 1.0 20 16 26.5 42 35 12 AH-926 M6 x 1.0 25 16 26.5 42 35 12 AH-927 M6 x 1.0 30 16 26.5 42 35 12 AH-928 M8 x 1.25 15 20 36 65 50 15 AH-929 M8 x 1.25 20 20 36 65 50 15 AH-930 M8 x 1.25 25 20 36 65 50 15 AH-931 M8 x 1.25 30 20 36 65 50 15 AH-932 M8 x 1.25 40 20 36 65 50 15 AH-933 M10 x 1.50 20 25 46 80 63 20 AH-934 M10 x 1.50 30 25 46 80 63 20 AH-935 M10 x 1.50 40 25 46 80 63 20 AH-936 M10 x 1.50 50 25 46 80 63 20 AH-937 M12 x 1.75 30 25 46 80 63 20 AH-938 M12 x 1.75 40 25 46 80 63 20 AH-939 M12 x 1.75 50 25 46 80 63 20
LIFT AND ROTATE
HANDLE 360°
metric with stud
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
39
k
Page 42
j
C l a m p i n g L e v e r s
Safety Clamping Levers
ush Down
P
to Engage
➞
j Handle made from glass-fiber reinforced polyamide
j Bushing made from zinc-plated steel
j Resistant to oils, solvents, and other chemicals
Morton Safety Clamping Levers are used on applications where mis­taken releasing or repositioning of the clamp lever could lead to an accident. The lever in its rest position is not connected to the internal spindle and it can spin freely. The clamp lever engages only after pushing the handle down.
NCH
M
I
ETRIC
PART # X Thread A C D E
SH-801 #10-24 .35 1.04 1.65 1.38 SH-802 #10-32 .35 1.04 1.65 1.38 SH-803 1/4-20 .35 1.04 1.65 1.38 SH-804 1/4-20 .47 1.42 2.56 1.97 SH-805 5/16-18 .47 1.42 2.56 1.97 SH-807 3/8-16 .67 1.81 3.15 2.48 SH-808 1/2-13 .67 1.81 3.15 2.48
ART # X Thread A C D E
P
SH-902 M5 x .8 9mm 26.5mm 42mm 35mm SH-903 M6 x 1.0 9 26.5 42 35 SH-904 M6 x 1.0 12 36 65 50 SH-905 M8 x 1.25 12 36 65 50 SH-907 M10 x 1.50 17 46 80 63 SH-908 M12 x 1.75 17 46 80 63
Safety Clamping Levers
with stud
Push Down
to Engage
➞
Morton Safety Clamping Levers are used on applications where mis­taken releasing or repositioning of the clamp lever could lead to an accident. The lever in its rest position is not connected to the internal spindle and it can spin freely. The clamp lever engages only after pushing the handle down.
j Handle made from glass-fiber reinforced polyamide
j Screw made from zinc-plated steel
j Resistant to oils, solvents, and other chemicals
PART # X Thread L C D E
SH-820 #10-32 .39 1.04 1.65 1.38 SH-821 #10-32 .79 1.04 1.65 1.38 SH-822 1/4-20 .59 1.04 1.65 1.38 SH-823 1/4-20 .79 1.04 1.65 1.38 SH-824 1/4-20 1.18 1.04 1.65 1.38 SH-825 5/16-18 .59 1.42 2.56 1.97 SH-826 5/16-18 .79 1.42 2.56 1.97 SH-827 5/16-18 1.18 1.42 2.56 1.97 SH-828 5/16-18 1.57 1.42 2.56 1.97 SH-829 3/8-16 .79 1.81 3.15 2.48 SH-830 3/8-16 1.18 1.81 3.15 2.48 SH-831 3/8-16 1.57 1.81 3.15 2.48 SH-832 3/8-16 1.97 1.81 3.15 2.48 SH-833 1/2-13 1.18 1.81 3.15 2.48 SH-834 1/2-13 1.97 1.81 3.15 2.48
PART # X Thread L C D E
SH-923 M6 x 1.0 10mm 26.5mm 42mm 35mm SH-925 M6 x 1.0 20 26.5 42 35 SH-928 M8 x 1.25 15 36 65 50 SH-929 M8 x 1.25 20 36 65 50 SH-931 M8 x 1.25 30 36 65 50 SH-933 M10 x 1.50 20 46 80 63 SH-934 M10 x 1.50 30 46 80 63 SH-935 M10 x 1.50 40 46 80 63 SH-937 M12 x 1.75 30 46 80 63 SH-938 M12 x 1.75 40 46 80 63
INCH
METRIC
j
40
w w w . m o r t o n m a c h i n e . c o m
Page 43
Stainless Steel Adjustable Clamping Levers
Handle material: 303 stainless steel
j
j Component material: 303 stainless steel
j Internal thread
j Ball handle design
ART # A B D E FHJL
P
SSH-101 #10-24 .35 .53 .39 .15 1.30 .95 1.57 SSH-102 #10-32 .35 .53 .39 .15 1.30 .95 1.57 SSH-103 1/4-20 .35 .53 .39 .15 1.30 .95 1.57 SSH-104 1/4-20 .47 .71 .53 .25 1.81 1.14 2.56 SSH-105 5/16-18 .47 .71 .53 .25 1.81 1.14 2.56 SSH-106 5/16-18 .55 .84 .62 .39 2.28 1.47 3.15 SSH-107 3/8-16 .55 .84 .62 .39 2.28 1.47 3.15 SSH-108 3/8-16 .67 1.00 .75 .39 2.63 1.68 3.74 SSH-109 1/2-13 .67 1.00 .75 .39 2.63 1.68 3.74
LIFT AND ROTATE
HANDLE 360°
C l a m p i n g L e v e r s
ball handle design
k
Stainless Steel Adjustable Clamping Levers
j Handle material: 303 stainless steel
j Component material: 303 stainless steel
j External thread
j Ball handle design
LIFT AND ROTATE
PART # X Thread Length EFH JL
SSH-301 #10-32 .59 .39 .15 1.30 .95 1.57 SSH-302 #10-32 .78 .39 .15 1.30 .95 1.57 SSH-303 #10-32 1.18 .39 .15 1.30 .95 1.57 SSH-304 #10-24 .59 .39 .15 1.30 .95 1.57 SSH-305 #10-24 .78 .39 .15 1.30 .95 1.57 SSH-306 #10-24 1.18 .39 .15 1.30 .95 1.57 SSH-307 1/4-20 .59 .39 .15 1.30 .95 1.57 SSH-308 1/4-20 .78 .39 .15 1.30 .95 1.57 SSH-309 1/4-20 1.18 .39 .15 1.30 .95 1.57 SSH-310 1/4-20 1.57 .39 .15 1.30 .95 1.57 SSH-311 1/4-20 1.77 .39 .15 1.30 .95 1.57 SSH-312 5/16-18 .78 .53 .25 1.81 1.14 2.56 SSH-313 5/16-18 1.18 .53 .25 1.81 1.14 2.56 SSH-314 5/16-18 1.57 .53 .25 1.81 1.14 2.56 SSH-315 5/16-18 1.96 .53 .25 1.81 1.14 2.56 SSH-316 5/16-18 2.36 .53 .25 1.81 1.14 2.56 SSH-317 3/8-16 .78 .62 .39 2.28 1.47 3.15 SSH-318 3/8-16 1.18 .62 .39 2.28 1.47 3.15 SSH-319 3/8-16 1.57 .62 .39 2.28 1.47 3.15 SSH-320 3/8-16 1.96 .62 .39 2.28 1.47 3.15 SSH-321 3/8-16 2.36 .62 .39 2.28 1.47 3.15 SSH-322 1/2-13 .78 .75 .39 2.63 1.68 3.74 SSH-323 1/2-13 1.18 .75 .39 2.63 1.68 3.74 SSH-324 1/2-13 1.57 .75 .39 2.63 1.68 3.74 SSH-325 1/2-13 1.96 .75 .39 2.63 1.68 3.74 SSH-326 1/2-13 2.36 .75 .39 2.63 1.68 3.74
ball handle design with stud
HANDLE 360°
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
41
k
Page 44
j
C l a m p i n g L e v e r s
Chrome Plated Adjustable Clamping Levers
Die-cast handle with chrome plated finish
j
j Internal parts have black oxide finish
j Used on applications where appearance is as important as
LIFT AND ROTATE
HANDLE 360°
PART # X Thread Thread Depth B C DEF
MHC-101 #10-24 .32 .52 .97 1.75 1.38 .39 MHC-103 1/4-20 .32 .52 .97 1.75 1.38 .39 MHC-104 1/4-20 .44 .71 1.22 2.44 1.83 .53 MHC-105 5/16-18 .44 .71 1.22 2.44 1.83 .53 MHC-106 5/16-18 .50 .83 1.52 3.03 2.20 .63 MHC-107 3/8-16 .50 .83 1.52 3.03 2.20 .63 MHC-108 3/8-16 .62 .94 1.67 3.58 2.50 .75 MHC-109 1/2-13 .62 .94 1.67 3.58 2.50 .75 MHC-112 1/2-13 .87 1.19 2.00 4.17 3.00 .91 MHC-113 5/8-11 .87 1.19 2.00 4.17 3.00 .91
function
Chrome Plated Adjustable Clamping Levers
with stud
LIFT AND ROTATE
HANDLE 360°
PART # X Thread L BCD EF
MHC-301 1/4-20 1/2 .52 .97 1.75 1.38 .39 MHC-302 1/4-20 3/4 .52 .97 1.75 1.38 .39 MHC-303 1/4-20 1 .52 .97 1.75 1.38 .39 MHC-304 1/4-20 1-1/2 .52 .97 1.75 1.38 .39 MHC-305 5/16-18 3/4 .71 1.22 2.44 1.83 .53 MHC-306 5/16-18 1 .71 1.22 2.44 1.83 .53 MHC-307 5/16-18 1-1/2 .71 1.22 2.44 1.83 .53 MHC-308 5/16-18 2 .71 1.22 2.44 1.83 .53 MHC-309 3/8-16 3/4 .83 1.52 3.03 2.20 .63 MHC-310 3/8-16 1 .83 1.52 3.03 2.20 .63 MHC-311 3/8-16 1-1/2 .83 1.52 3.03 2.20 .63 MHC-312 3/8-16 2 .83 1.52 3.03 2.20 .63 MHC-313 1/2-13 1 .94 1.67 3.58 2.50 .75 MHC-314 1/2-13 1-1/2 .94 1.67 3.58 2.50 .75 MHC-315 1/2-13 2 .94 1.67 3.58 2.50 .75 MHC-316 1/2-13 2-1/2 .94 1.67 3.58 2.50 .75 MHC-317 5/8-11 1-1/2 1.19 2.00 4.17 3.00 .91 MHC-318 5/8-11 2 1.19 2.00 4.17 3.00 .91 MHC-319 5/8-11 2-1/2 1.19 2.00 4.17 3.00 .91 MHC-320 5/8-11 3 1.19 2.00 4.17 3.00 .91
j Die-cast handle with chrome plated finish
j Internal parts have black oxide finish
j Used on applications where appearance is as important as
function
j
42
w w w . m o r t o n m a c h i n e . c o m
Page 45
j Handles available in die-cast zinc or plastic
j Internal thread mechanism made from carbon steel
j Inch and metric sizes available
j Great for repetitive tightening operations
j Torque and load ratings shown below
C l a m p i n g L e v e r s
Button Thread Clamping Levers
U.S. PATENT
5,898,974
k
Die-Cast Plastic
Handle Handle Thread BC DE
MH-725 AH-725 1/4-20 .813 1.00 2.56 1.77 MH-731 AH-731 5/16-18 .938 1.125 3.07 2.17 MH-737 AH-737 3/8-16 .938 1.125 3.07 2.17 MH-750 AH-750 1/2-13 1.25 1.500 4.25 2.95 MH-762 AH-762 5/8-11 1.25 1.500 4.25 2.95
Die-Cast Plastic
Handle Handle Thread BC DE
MH-706 AH-706 M6 x 1.0 21mm 26mm 65mm 45mm MH-708 AH-708 M8 x 1.25 23.5 29 78 55 MH-710 AH-710 M10 x 1.50 23.5 29 78 55 MH-712 AH-712 M12 x 1.75 32 38 108 75 MH-716 AH-716 M16 x 2.0 32 38 108 75
INCH SIZES
METRIC SIZES
Button Thread
Torque Testing Results
Hex Nuts, Collar Nuts, Knurled Nuts, Clamping Handles
1/4"-20 M6 x 1.0 95 in-lbs. 5/16"-18 M8 x 1.25 149 in-lbs. 3/8"-16 M10 x 1.50 234 in-lbs. 1/2"-13 M12 x 1.75 456 in-lbs. 5/8"-11 M16 x 2.00 660 in-lbs.
Button Thread
Load Rating Test Results
Hex Nuts, Collar Nuts, Knurled Nuts, Clamping Handles
Inch Metric
1/4"-20 2075 lbs. M6 x 1.0 940 kg. 5/16"-18 6440 lbs. M8 x 1.25 2925 kg. 3/8"-16 8612 lbs. M10 x 1.50 3915 kg. 1/2"-13 8812 lbs. M12 x 1.75 4005 kg. 5/8"-11 9006 lbs. M16 x 2.0 4095 kg.
As Easy As 1-2-3...
1. Push button
2. Slide handle to new position
3. Release button and threads engage for clamping
A Great Time Saver!
The through hole clamping lever allows for quick clamping on long thread lengths. Simply press the button and the threads are disengaged to allow easy movement up or down the screw. Release the button and the threads engage to allow for normal clamping. Available in inch and metric sizes with plas­tic or die-cast handle.
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
43
k
Page 46
j
L e v e l i n g M o u n t s
Leveling Mounts
j 10 degree swivel in all directions to keep machine tools, racks, assembly lines, and other equipment level.
j Available in steel or stainless steel
j Do not exceed load requirements
j Hardened ball insures proper seating
Steel Stainless Steel Thread Load
PART # PART # XBCDPounds
LM-100 LM-100SS #10-32 3/4 17/32 3/8 700 LM-101 LM-101SS 1/4-20 1 45/64 1/2 1000 LM-1015 LM-1015SS 5/16-18 1-1/4 7/8 5/8 2500 LM-102 LM-102SS 3/8-16 1-1/4 7/8 5/8 3750 LM-103 LM-103SS 1/2-13 1-7/8 1-1/8 3/4 5000 LM-104 LM-104SS 5/8-11 2-1/2 1-1/4 7/8 6000 LM-105 LM-105SS 3/4-10 3 1-1/2 1-1/16 7400 LM-1055 LM-1055SS 7/8-9 4 1-7/8 1-3/8 15000 LM-106 LM-106SS 1-8 4 1-7/8 1-3/8 20000 LM-107 LM-107SS 1-1/4-7 6 2-3/4 1-7/8 43000
Steel Stainless Steel Thread Load
PART # PART # XBCDKilos
LM-200 LM-200SS M6 x 1.0 19mm 14mm 10mm 310 LM-201 LM-201SS M8 x 1.25 26 18 13 450 LM-202 LM-202SS M10 x 1.5 32 22 16 1700 LM-203 LM-203SS M12 x 1.75 48 29 19 2250 LM-204 LM-204SS M16 x 2.0 64 32 22 2720 LM-205 LM-205SS M20 x 2.5 76 38 27 3350 LM-206 LM-206SS M24 x 3.0 101 48 35 9070 LM-207 LM-207SS M30 x 3.5 152 70 48 18700
INCH
METRIC
Leveling Mounts with Bolts
j 10 degree swivel in all directions to keep machine tools, racks, assembly lines, and other equipment level
j Steel ball hardened for proper seating
j Jam nut included
j Available in inch and metric sizes
j Available in steel or stainless steel
Steel Stainless Steel Thread Load
PART # PART # XE B C DPounds
LM-300 LM-300SS #10-32 1 3/4 1-17/32 3/8 700 LM-3005 LM-3005SS #10-32 2 3/4 2-1/2 3/8 700 LM-301 LM-301SS 1/4-20 1-1/4 1 1-61/64 1/2 1000 LM-3015 LM-3015SS 1/4-20 2-1/2 1 3-3/16 1/2 1000 LM-3017 LM-3017SS 5/16-18 2 1-1/4 2-7/8 5/8 2500 LM-3018 LM-3018SS 5/16-18 4 1-1/4 4-7/8 5/8 2500 LM-302 LM-302SS 3/8-16 2 1-1/4 2-7/8 5/8 3750 LM-3025 LM-3025SS 3/8-16 4 1-1/4 4-7/8 5/8 3750 LM-303 LM-303SS 1/2-13 2 1-7/8 3-1/8 3/4 5000 LM-3035 LM-3035SS 1/2-13 4 1-7/8 5-1/8 3/4 5000 LM-304 LM-304SS 5/8-11 2 2-1/2 3-1/4 7/8 6000 LM-3045 LM-3045SS 5/8-11 4 2-1/2 5-1/4 7/8 6000 LM-305 LM-305SS 3/4-10 23 3-1/2 1-1/16 7400 LM-3055 LM-3055SS 3/4-10 43 5-1/2 1-1/16 7400 LM-3058 LM-3058SS 7/8-9 44 5-7/8 1-3/8 15000 LM-306 LM-306SS 1-8 3-1/2 4 5-3/8 1-3/8 20000 LM-307 LM-307SS 1-8 4-1/4 4 6-1/8 1-3/8 20000 LM-3075 LM-3075SS 1-8 64 7-7/8 1-3/8 20000 LM-308 LM-308SS 1-1/4-7 46 6-3/4 1-7/8 43000 LM-309 LM-309SS 1-1/4-7 66 8-3/4 1-7/8 43000
Steel Stainless Steel Thread Load
PART # PART # XEBCKilos
LM-400 LM-400SS M6 x 1.0 25mm 19mm 39mm 317 LM-401 LM-401SS M8 x 1.25 31 26 50 453 LM-402 LM-402SS M10 x 1.5 51 32 73 1701 LM-403 LM-403SS M12 x 1.75 51 48 79 2268 LM-404 LM-404SS M16 x 2.0 51 64 83 2721 LM-405 LM-405SS M20 x 2.5 51 76 89 3357 LM-406 LM-406SS M24 x 3.0 88 101 136 9072 LM-407 LM-407SS M24 x 3.0 108 101 149 9072 LM-408 LM-408SS M30 x 3.5 102 152 171 18730 LM-409 LM-409SS M30 x 3.5 152 152 222 18730
INCH
METRIC
j
44
w w w . m o r t o n m a c h i n e . c o m
Page 47
j Designed for high precision and computerized machinery
j Do not exceed load capacity
j 10 degree swivel in all directions to keep machinery level on uneven surfaces
j Additional load standards available upon request
j Patent M9600727.3 (Germany)
j Other Foreign Patents D2053583, D2053584
j Anti-Vibe
ART # X Thread BCDPounds
P
LM-150 3/8-16 1-1/4 1-1/2 5/8 100 LM-151 1/2-13 1-7/8 1-3/4 3/4 240 LM-152 5/8-11 2-1/2 1-7/8 7/8 440 LM-153 3/4-10 3 2-1/8 1-1/16 650 LM-154 1-8 4 2-1/2 1-3/8 1180 LM-155 1-1/4-7 6 2-7/8 1-7/8 2710
PART # X Thread BC DKilos
LM-250 M10 x 1.5 32mm 38mm 16mm 45 LM-251 M12 x 1.75 48 44 19 109 LM-252 M16 x 2.0 64 48 22 200 LM-253 M20 x 2.5 76 54 27 295 LM-254 M24 x 3.0 102 64 35 535
®
NCH
I
METRIC
oad
L
Load
L e v e l i n g M o u n t s
k
Anti-Vibration Leveling Mounts
INCH
PART # X Thread EBCPounds
LM-350 3/8-16 2 1-1/4 3-1/2 100 LM-351 1/2-13 2 1-7/8 3-3/4 240 LM-352 5/8-11 2 2-1/2 3-7/8 440 LM-353 3/4-10 234-1/8 650 LM-354 1-8 3-1/2 461180 LM-355 1-8 4-1/4 4 6-1/8 535 LM-356 1-1/4-7 46 6-7/8 2710 LM-357 1-1/4-7 66 8-3/4 1230
METRIC
PART # X Thread EBCKilos
LM-450 M10 x 1.5 51mm 32mm 89mm 45 LM-451 M12 x 1.75 51 48 95 109 LM-452 M16 x 2.0 51 64 99 200 LM-453 M20 x 2.5 51 76 105 295 LM-454 M24 x 3.0 90 102 154 535 LM-455 M24 x 3.0 108 102 154 535 LM-456 M30 x 3.5 102 152 171 1230 LM-457 M30 x 3.5 152 152 222 1230
Load
Load
Anti-Vibration Leveling Mounts
with bolts
j Designed for high precision and computerized machinery
j Do not exceed load capacity
j 10 degree swivel in all directions to keep machinery level on uneven
surfaces
j Additional load standards available upon request
j Jam nut included
j Anti-Vibe
®
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
45
k
Page 48
j
L e v e l i n g M o u n t s
Delrin®Leveling Mounts
10 degree swivel in any direction to keep machine tools, racks,
j
assembly lines, and other equipment level.
j Hardened ball insures proper seating
Available in inch and metric sizes
j
j Also available in stainless steel within the Delrin
NCH
teel Stainless Steel Load
S
ART # PART # X Thread BCDPounds
P
DLM-100 DLM-100SS #10-32 3/4 17/32 3/8 150 DLM-101 DLM-101SS 1/4-20 1 45/64 1/2 200 DLM-1015 DLM-1015SS 5/16-18 1-1/4 7/8 5/8 250 DLM-102 DLM-102SS 3/8-16 1-1/4 7/8 5/8 300 DLM-103 DLM-103SS 1/2-13 1-7/8 1-1/8 3/4 700 DLM-104 DLM-104SS 5/8-11 2-1/2 1-1/4 7/8 1200 DLM-105 DLM-105SS 3/4-10 3 1-1/2 1-1/16 1800 DLM-1055 DLM-1055SS 7/8-9 4 1-7/8 1-3/8 1700 DLM-106 DLM-106SS 1-8 4 1-7/8 1-3/8 2000 DLM-107 DLM-107SS 1-1/4-7 6 2-7/8 1-7/8 3200
PART # X Thread BCDKilos
DLM-200 M6 x 1.0 19mm 14mm 10mm 68 DLM-201 M8 x 1.25 26 18 13 91 DLM-202 M10 x 1.5 32 22 16 136 DLM-203 M12 x 1.75 48 29 19 317 DLM-204 M16 x 2.0 64 32 22 544 DLM-205 M20 x 2.5 76 38 27 816 DLM-206 M24 x 3.0 101 48 35 907 DLM-207 M30 x 3.5 152 70 48 1800
I
METRIC
®
base
Load
Delrin®Leveling Mounts
with bolts
j 10 degree swivel in any direction to keep machine tools, racks, assembly lines, and other equipment level
j Hardened ball insures proper seating
j Available in inch and metric sizes
j Jam nut included
j New stainless steel bolt sizes
Steel Stainless Steel Load
PART # PART # X Thread EBCPounds
DLM-300 DLM-300SS #10-32 1 3/4 1-17/32 150 DLM-3005 DLM-3005SS #10-32 2 3/4 2-1/2 150 DLM-301 DLM-301SS 1/4-20 1-1/4 1 1-15/16 200 DLM-3015 DLM-3015SS 1/4-20 2-1/2 1 3-3/16 200 DLM-3017 DLM-3017SS 5/16-18 2 1-1/4 2-7/8 250 DLM-3018 DLM-3018SS 5/16-18 4 1-1/4 4-7/8 250 DLM-302 DLM-302SS 3/8-16 2 1-1/4 2-7/8 300 DLM-3025 DLM-3025SS 3/8-16 4 1-1/4 4-7/8 300 DLM-303 DLM-303SS 1/2-13 2 1-7/8 3-1/8 700 DLM-3035 DLM-3035SS 1/2-13 4 1-7/8 5-1/8 700 DLM-304 DLM-304SS 5/8-11 2 2-1/2 3-1/4 1200 DLM-3045 DLM-3045SS 5/8-11 4 2-1/2 5-1/4 1200 DLM-305 DLM-305SS 3/4-10 23 3-1/2 1800 DLM-3055 DLM-3055SS 3/4-10 43 5-1/2 1800 DLM-3057 DLM-3057SS 7/8-9 44 5-7/8 1700 DLM-306 DLM-306SS 1-8 3-1/2 4 5-3/8 2000 DLM-307 DLM-307SS 1-8 4-1/4 4 6-1/8 2000 DLM-3075 DLM-3075SS 1-8 64 7-7/8 2000 DLM-308 DLM-308SS 1-1/4-7 46 6-3/4 3200 DLM-309 DLM-309SS 1-1/4-7 66 8-3/4 3200
PART # X Thread EBCKilos
DLM-400 M6 x 1.0 25mm 19mm 39mm 68 DLM-401 M8 x 1.25 31 26 50 91 DLM-402 M10 x 1.5 51 32 73 136 DLM-403 M12 x 1.75 51 48 79 317 DLM-404 M16 x 2.0 51 64 83 544 DLM-405 M20 x 2.5 51 76 89 816 DLM-406 M24 x 3.0 88 101 136 907 DLM-407 M24 x 3.0 108 101 150 907 DLM-408 M30 x 3.5 102 152 171 1800 DLM-409 M30 x 3.5 152 152 222 1800
INCH
METRIC
Load
j
46
w w w . m o r t o n m a c h i n e . c o m
Page 49
L e v e l i n g M o u n t s
k
Nylon base is water and corrosion resistant
j
j 15 degree swivel in any direction to keep machine tools, racks assembly
lines, and other equipment level
j Lag holes
j Inch and metric sizes available
j Steel and stainless steel components available
j Patent pending (Polymount)
NCH
teel Stainless Steel Thread Load
S
ART # PART # XA BPounds
P
LM-120 LM-120SS 3/8-16 2 1-5/8 4000 LM-121 LM-121SS 1/2-13 2 1-5/8 4000 LM-122 LM-122SS 5/8-11 2 1-5/8 4000 LM-123 LM-123SS 3/8-16 3 1-5/8 5000 LM-124 LM-124SS 1/2-13 3 1-5/8 5000 LM-125 LM-125SS 5/8-11 3 1-5/8 5000 LM-126 LM-126SS 3/4-10 3 1-5/8 5000
Steel Stainless Steel Thread Load
PART # PART # XABKilos
LM-220 LM-220SS M10 x 1.5 50mm 41mm 1815 LM-221 LM-221SS M12 x 1.75 50 41 1815 LM-222 LM-222SS M16 x 2.0 50 41 1815 LM-223 LM-223SS M10 x 1.5 80 41 2268 LM-224 LM-224SS M12 x 1.75 80 41 2268 LM-225 LM-225SS M16 x 2.0 80 41 2268 LM-226 LM-226SS M20 x 2.5 80 41 2268
I
METRIC
Nylon Leveling Mounts
j Nylon base is water and corrosion resistant
j 15 degree swivel in any direction to keep machine tools, racks, assembly
lines, and other equipment level
j Lag holes j Inch and metric sizes available
j Steel and stainless steel components available
j Jam nut included j Patent pending (Polymount)
Steel Stainless Steel Thread Load
PART # PART # XBACPounds
LM-320 LM-320SS 3/8-16 424-7/8 4000 LM-321 LM-321SS 3/8-16 626-7/8 4000 LM-322 LM-322SS 3/8-16 828-7/8 4000 LM-323 LM-323SS 1/2-13 424-7/8 4000 LM-324 LM-324SS 1/2-13 626-7/8 4000 LM-325 LM-325SS 1/2-13 828-7/8 4000 LM-326 LM-326SS 5/8-11 424-7/8 4000 LM-327 LM-327SS 5/8-11 626-7/8 4000 LM-328 LM-328SS 5/8-11 828-7/8 4000 LM-329 LM-329SS 3/8-16 434-7/8 5000 LM-330 LM-330SS 3/8-16 636-7/8 5000 LM-331 LM-331SS 3/8-16 838-7/8 5000 LM-332 LM-332SS 1/2-13 4 3 4-7/8 5000 LM-333 LM-333SS 1/2-13 636-7/8 5000 LM-334 LM-334SS 1/2-13 838-7/8 5000 LM-335 LM-335SS 5/8-11 434-7/8 5000 LM-336 LM-336SS 5/8-11 636-7/8 5000 LM-337 LM-337SS 5/8-11 838-7/8 5000 LM-338 LM-338SS 3/4-10 434-7/8 5000 LM-339 LM-339SS 3/4-10 636-7/8 5000 LM-340 LM-340SS 3/4-10 838-7/8 5000
Nylon Leveling Mounts
with bolts
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
47
k
Page 50
j
L e v e l i n g M o u n t s
Nylon Leveling Mounts
metric with bolts
j Nylon base is water and corrosion resistant
j 15 degree swivel in any direction to keep machine tools,
racks, assembly lines, and other equipment level
j Lag holes
j Inch and metric sizes available
j Steel and stainless steel components available
j Jam nut included
j Patent pending (Polymount)
Industrial Glides
Steel Stainless Steel Load
PART # PART # X Thread BACKilos
LM-420 LM-420SS M10 x 1.5 102mm 50mm 123mm 1815 LM-421 LM-421SS M10 x 1.5 152 50 175 1815 LM-422 LM-422SS M10 x 1.5 203 50 225 1815 LM-423 LM-423SS M12 x 1.75 102 50 123 1815 LM-424 LM-424SS M12 x 1.75 152 50 175 1815 LM-425 LM-425SS M12 x 1.75 203 50 225 1815 LM-426 LM-426SS M16 x 2.0 102 50 123 1815 LM-427 LM-427SS M16 x 2.0 152 50 175 1815 LM-428 LM-428SS M16 x 2.0 203 50 225 1815 LM-429 LM-429SS M10 x 1.5 102 80 123 2268 LM-430 LM-430SS M10 x 1.5 152 80 175 2268 LM-431 LM-431SS M10 x 1.5 203 80 225 2268 LM-432 LM-432SS M12 x 1.75 102 80 123 2268 LM-433 LM-433SS M12 x 1.75 152 80 175 2268 LM-434 LM-434SS M12 x 1.75 203 80 225 2268 LM-435 LM-435SS M16 x 2.0 102 80 123 2268 LM-436 LM-436SS M16 x 2.0 152 80 175 2268 LM-437 LM-437SS M16 x 2.0 203 80 225 2268 LM-438 LM-438SS M20 x 2.5 102 80 123 2268 LM-439 LM-439SS M20 x 2.5 152 80 175 2268 LM-440 LM-440SS M20 x 2.5 203 80 225 2268
METRIC
j Steel with nickel plated finish
j Nylon base pad provides non-abrasive surface
j Excellent for leveling light duty machines, cabinets, and office furniture
j Economical leveling solution
PART # X Thread AB
GR-01 #10-24 1-1/2 1-1/4 GR-02 1/4-20 1-1/2 1-1/4 GR-03 5/16-18 1-1/2 1-1/4 GR-04 5/16-18 22 GR-05 3/8-16 22 GR-06 3/8-16 2 2-13/32 GR-07 3/8-16 4 2-13/32 GR-08 1/2-13 2 2-13/32 GR-09 1/2-13 4 2-13/32 GR-10 1/2-13 2 2-3/4 GR-11 1/2-13 4 2-3/4 GR-12 5/8-11 2 2-3/4 GR-13 5/8-11 4 2-3/4 GR-14 1/2-13 4 3-3/16 GR-15 1/2-13 6 3-3/16 GR-16 5/8-11 4 3-3/16 GR-17 5/8-11 6 3-3/16
INCH
PART # X Thread AB
MGR-01 M6 x 1.0 38mm 31mm MGR-02 M8 x 1.25 38 31 MGR-03 M8 x 1.25 38 52 MGR-04 M10 x 1.50 51 52 MGR-05 M10 x 1.50 51 61 MGR-06 M10 x 1.50 102 61 MGR-07 M12 x 1.75 51 61 MGR-08 M12 x 1.75 102 61 MGR-09 M12 x 1.75 51 71 MGR-10 M12 x 1.75 102 71 MGR-11 M16 x 2.0 51 71 MGR-12 M16 x 2.0 102 71 MGR-13 M12 x 1.75 102 81 MGR-14 M12 x 1.75 152 81 MGR-15 M16 x 2.0 102 81 MGR-16 M16 x 2.0 152 81
METRIC
j
48
w w w . m o r t o n m a c h i n e . c o m
Page 51
j Inch and metric sizes available
j Non-slip black plastic base
Steel screw, zinc-plated finish
j
Mounts let you isolate height on all types of machinery
j
and equipment
NCH
ART # XLA B
P
7832AC020 1/4-20 3/4 1-1/4 9/16 7832AC030 1/4-20 1-3/16 1-1/4 9/16 7832AC040 1/4-20 1-1/2 1-1/4 9/16 7832AD020 5/16-18 3/4 1-1/4 9/16 7832AD030 5/16-18 1-3/16 1-1/4 9/16 7832AD040 5/16-18 1-1/2 1-1/4 9/16 7832AE030 3/8-16 1-3/16 1-1/4 9/16 7832AE040 3/8-16 1-1/2 1-1/4 9/16
I
L e v e l i n g M o u n t s
k
Fixed-Base Leveling Mounts
PART # XLA B
783206020 M6 x 1.0 20mm 32mm 14.5mm 783206030 M6 x 1.0 30 32 14.5 783206040 M6 x 1.0 40 32 14.5 783208020 M8 x 1.25 19 32 14.5 783208030 M8 x 1.25 30 32 14.5 783208040 M8 x 1.25 40 32 14.5 783210030 M10 x 1.5 30 32 14.5 783210040 M10 x 1.5 40 32 14.5
METRIC
h
Common applications for adjustable handles.
h
Tooling components are used for a variety of fixture applications.
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
49
k
Page 52
j
S p r i n g L o a d e d D e v i c e s
k
Spring Plunger
k
Ball Plunger
SPRING PLUNGERS
Ball Plungers are a compact solution that allows a controlled end pressure on repetitive applications. Ball plungers are assembled from three components ... a threaded body, internal spring, and a hardened ball. They are available in various mate­rials, spring pressures, and nose materials to meet your specif­ic applications.
k
Press-Fit Spring Plunger
k
Press-Fit Ball Plunger
k
Hand Retractable Plunger
Spring Plungers typically offer a longer thread length than ball plungers, but they are also spring loaded. Spring plungers consist of a threaded body, internal spring, and a nose pin. The nose pin allows pressure to be applied over a longer travel length. The nose pin can be fully retracted into the threaded body.
Locking Element: A nylon pellet provides resistance to vibra­tion and helps to secure the plunger in a fixed position.
j
50
k
Pull Ring Plunger
k
Locking Plunger
w w w . m o r t o n m a c h i n e . c o m
Page 53
teel Body Stainless Body End Pressures Pounds Ball Dia.
S
ART # PART # Start Full ABCD
P
MBP-190 MBP-188SS .12 .5 #4-48 3/16 .020 .062 MBP-191 MBP-189SS .25 .75 #5-40 1/4 .020 .062 MBP-192 MBP-190SS .5 1.0 #6-40 5/16 .023 .078 MBP-193 MBP-191SS .5 1.25 #8-36 11/32 .025 .093 MBP-194 MBP-192SS .5 1.25 #8-32 11/32 .025 .093 MBP-170 MBP-170SS 0.5 1.5 #10-32 33/64 .025 .093 MBP-171 MBP-171SS 1.5 3.0 #10-32 33/64 .025 .093 MBP-172 MBP-172SS 2.0 5.0 #10-32 33/64 .025 .093 MBP-173 MBP-173SS 2.0 4.0 1/4-20 17/32 .035 .125 MBP-174 MBP-174SS 3.0 7.0 1/4-20 17/32 .035 .125 MBP-175 MBP-175SS 4.0 12.0 1/4-20 17/32 .035 .125 MBP-176 MBP-176SS 2.0 4.5 5/16-18 37/64 .040 .156 MBP-177 MBP-177SS 4.0 9.0 5/16-18 37/64 .040 .156 MBP-178 MBP-178SS 6.0 17.0 5/16-18 37/64 .040 .156 MBP-179 MBP-179SS 2.5 5.0 3/8-16 5/8 .048 .187 MBP-180 MBP-180SS 5.0 10.0 3/8-16 5/8 .048 .187 MBP-181 MBP-181SS 6.0 21.0 3/8-16 5/8 .048 .187 MBP-182 MBP-182SS 3.0 6.0 1/2-13 3/4 .072 .281 MBP-183 MBP-183SS 6.0 12.0 1/2-13 3/4 .072 .281 MBP-184 MBP-184SS 6.0 30.0 1/2-13 3/4 .072 .281 MBP-185 MBP-185SS 4.5 9.0 5/8-11 63/64 .096 .375 MBP-186 MBP-186SS 9.0 18.0 5/8-11 63/64 .096 .375 MBP-187 MBP-187SS 7.0 50.0 5/8-11 63/64 .096 .375
B a l l P l u n g e r s
k
Nylon Nose Ball Plungers
j Bodies available in steel with black oxide finish and 303 stainless steel
j Nylon ball nose
j All plungers equipped with nylon pellet for positive
holding. If you require plungers without the nylon lock­ing element, please specify when ordering.
j Ideal for locating or positioning applications
j Bodies are steel with zinc-plated finish and stainless steel, nylon
ball noses
j All plungers equipped with nylon pellet for positive holding. If you require plungers without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
Steel Stainless Steel End Pressures Newtons Ball Dia.
PART # PART # Start Full ABCD
MBP-200 MBP-200SS .53 2.2 M3 x 0.5 4.7mm 0.51mm 1.57mm MBP-201 MBP-201SS 2.2 5.6 M4 x 0.7 9.00 0.60 2.36 MBP-202 MBP-202SS 2.2 6.7 M5 x 0.8 13.00 0.60 2.36 MBP-203 MBP-203SS 6.7 13.3 M5 x 0.8 13.00 0.60 2.36 MBP-204 MBP-204SS 8.9 22.2 M5 x 0.8 13.00 0.60 2.36 MBP-205 MBP-205SS 8.9 17.8 M6 x 1.0 13.50 0.90 3.20 MBP-206 MBP-206SS 13.3 31.1 M6 x 1.0 13.50 0.90 3.20 MBP-207 MBP-207SS 17.8 53.3 M6 x 1.0 13.50 0.90 3.20 MBP-208 MBP-208SS 8.9 20 M8 x 1.25 15.00 1.00 3.96 MBP-209 MBP-209SS 17.8 40 M8 x 1.25 15.00 1.00 3.96 MBP-210 MBP-210SS 26.7 75 M8 x 1.25 15.00 1.00 3.96 MBP-211 MBP-211SS 11.1 22.2 M10 x 1.5 16.00 1.20 4.75 MBP-212 MBP-212SS 22.2 44.5 M10 x 1.5 16.00 1.20 4.75 MBP-213 MBP-213SS 26.7 93 M10 x 1.5 16.00 1.20 4.75 MBP-214 MBP-214SS 13.3 26.7 M12 x 1.75 19.00 2.00 7.14 MBP-215 MBP-215SS 26.7 53 M12 x 1.75 19.00 2.00 7.14 MBP-216 MBP-216SS 26.7 133 M12 x 1.75 19.00 2.00 7.14 MBP-217 MBP-217SS 20 40 M16 x 2.00 25.00 2.50 9.52 MBP-218 MBP-218SS 40 80 M16 x 2.00 25.00 2.50 9.52 MBP-219 MBP-219SS 31 222 M16 x 2.00 25.00 2.50 9.52
Nylon Nose Ball Plungers
metric
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
51
k
Page 54
j
B a l l P l u n g e r s
Steel Ball Plungers
j Bodies available in steel with black oxide finish and 303 stainless steel
j Stainless steel ball nose
j All plungers equipped with nylon pellet for positive
holding. If you require plungers without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
teel Stainless Steel End Pressures Pounds Ball Dia.
S
ART # PART # Start Full ABCD
P
MBP-100 MBP-090SS .12 .5 #4-48 3/16 .020 .062 MBP-101 MBP-091SS .25 .75 #5-40 1/4 .020 .062 MBP-102 MBP-092SS .5 1.0 #6-40 5/16 .023 .078 MBP-103 MBP-093SS .5 1.25 #8-36 11/32 .025 .093 MBP-104 MBP-094SS .5 1.25 #8-32 11/32 .025 .093 MBP-106 MPB-106SS .5 1.5 #10-32 33/64 .025 .093 MBP-105 MBP-105SS 1.5 3.0 #10-32 33/64 .025 .093 MBP-107 MBP-107SS 2.0 5.0 #10-32 33/64 .025 .093 MBP-111 MBP-111SS 2.0 4.0 1/4-20 17/32 .035 .125 MBP-110 MBP-110SS 3.0 7.0 1/4-20 17/32 .035 .125 MBP-112 MBP-112SS 4.0 12.0 1/4-20 17/32 .035 .125 MBP-116 MBP-116SS 2.0 4.5 5/16-18 37/64 .040 .156 MBP-115 MBP-115SS 4.0 9.0 5/16-18 37/64 .040 .156 MBP-117 MBP-117SS 6.0 17.0 5/16-18 37/64 .040 .156 MBP-121 MBP-121SS 2.5 5.0 3/8-16 5/8 .048 .187 MBP-120 MBP-120SS 5.0 10.0 3/8-16 5/8 .048 .187 MBP-122 MBP-122SS 6.0 21.0 3/8-16 5/8 .048 .187 MBP-126 MBP-126SS 3.0 6.0 1/2-13 3/4 .072 .281 MBP-125 MBP-125SS 6.0 12.0 1/2-13 3/4 .072 .281 MBP-127 MBP-127SS 6.0 30.0 1/2-13 3/4 .072 .281 MBP-131 MBP-131SS 4.5 9.0 5/8-11 63/64 .096 .375 MBP-130 MBP-130SS 9.0 18.0 5/8-11 63/64 .096 .375 MBP-132 MBP-132SS 7.0 50.0 5/8-11 63/64 .096 .375
Steel Ball Plungers
metric
j Steel body, stainless steel ball nose, zinc-plated finish
j All plungers equipped with nylon pellet for positive holding. If you require plungers
without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
Steel Stainless Steel End Pressures Newtons Ball Dia.
PART # PART # Start Full ABCD
MBP-149 MBP-149SS .53 2.2 M3 x 0.5 4.7mm .51mm 1.57mm MBP-150 MPB-150SS 2.2 5.6 M4 x 0.7 9.00 0.60 2.36 MBP-151 MBP-151SS 2.2 6.7 M5 x 0.8 13.00 0.60 2.36 MBP-152 MBP-152SS 6.7 13.3 M5 x 0.8 13.00 0.60 2.36 MBP-153 MBP-153SS 8.9 22.2 M5 x 0.8 13.00 0.60 2.36 MBP-154 MBP-154SS 8.9 17.8 M6 x 1.0 13.50 0.90 3.20 MBP-155 MBP-155SS 13.3 31.1 M6 x 1.0 13.50 0.90 3.20 MBP-156 MBP-156SS 17.8 53.3 M6 x 1.0 13.50 0.90 3.20 MBP-157 MBP-157SS 8.9 20 M8 x 1.25 15.00 1.00 3.96 MBP-158 MBP-158SS 17.8 40 M8 x 1.25 15.00 1.00 3.96 MBP-159 MBP-159SS 26.7 75 M8 x 1.25 15.00 1.00 3.96 MBP-160 MBP-160SS 11.1 22.2 M10 x 1.5 16.00 1.20 4.75 MBP-161 MBP-161SS 22.2 44.5 M10 x 1.5 16.00 1.20 4.75 MBP-162 MBP-162SS 26.7 93 M10 x 1.5 16.00 1.20 4.75 MBP-163 MBP-163SS 13.3 27 M12 x 1.75 19.00 2.00 7.14 MBP-164 MBP-164SS 26.7 54 M12 x 1.75 19.00 2.00 7.14 MBP-165 MBP-165SS 26.7 133 M12 x 1.75 19.00 2.00 7.14 MBP-166 MBP-166SS 20 40 M16 x 2.0 25.00 2.50 9.52 MBP-167 MBP-167SS 40 80 M16 x 2.0 25.00 2.50 9.52 MBP-168 MBP-168SS 31 222 M16 x 2.0 25.00 2.50 9.52
j
52
w w w . m o r t o n m a c h i n e . c o m
Page 55
B a l l P l u n g e r s
k
j Hex drive
j Bodies available in steel with black oxide finish and 303 stainless steel
j Stainless steel ball nose
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
STAINLESS STEEL BALL NOSE
teel Body Stainless Body End Pressure Pounds Ball Dia. Hex Dia.
S
PART # PART # Start Full ABCDE
MBP-306 MBP-306SS 0.5 1.5 #10-32 9/16 .025 .093 5/64 MBP-305 MBP-305SS 1.5 3.0 #10-32 9/16 .025 .093 5/64 MBP-307 MBP-307SS 2.0 5.0 #10-32 9/16 .025 .093 5/64 MBP-311 MBP-311SS 2.0 4.0 1/4-20 43/64 .035 .125 5/64 MBP-310 MBP-310SS 3.0 7.0 1/4-20 43/64 .035 .125 5/64 MBP-312 MBP-312SS 4.0 12.0 1/4-20 43/64 .035 .125 5/64 MBP-316 MBP-316SS 2.0 4.5 5/16-18 23/32 .040 .156 3/32 MBP-315 MBP-315SS 4.0 9.0 5/16-18 23/32 .040 .156 3/32 MBP-317 MBP-317SS 6.0 17.0 5/16-18 23/32 .040 .156 3/32 MBP-321 MBP-321SS 2.5 5.0 3/8-16 13/16 .048 .187 5/32 MBP-320 MBP-320SS 5.0 10.0 3/8-16 13/16 .048 .187 5/32 MBP-322 MBP-322SS 6.0 21.0 3/8-16 13/16 .048 .187 5/32 MBP-326 MBP-326SS 3.0 6.0 1/2-13 1-3/64 .072 .281 7/32 MBP-325 MBP-325SS 6.0 12.0 1/2-13 1-3/64 .072 .281 7/32 MBP-327 MBP-327SS 6.0 30.0 1/2-13 1-3/64 .072 .281 7/32 MBP-331 MBP-331SS 4.5 9.0 5/8-11 1-15/64 .096 .375 1/4 MBP-330 MBP-330SS 9.0 18.0 5/8-11 1-15/64 .096 .375 1/4 MBP-332 MBP-332SS 7.0 50.0 5/8-11 1-15/64 .096 .375 1/4
Ball Plungers
hex drive
j Hex drive
j Bodies available in steel with black oxide finish and 303 stainless steel
j Nylon ball nose
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
NYLON BALL NOSE
Steel Body Stainless Body End Pressure Pounds Ball Dia. Hex Dia.
PART # PART # Start Full ABCDE
MBP-370 MBP-370SS 0.5 1.5 #10-32 9/16 .025 .093 5/64 MBP-371 MBP-371SS 1.5 3.0 #10-32 9/16 .025 .093 5/64 MBP-372 MBP-372SS 2.0 5.0 # 10-32 9/16 .025 .093 5/64 MBP-373 MBP-373SS 2.0 4.0 1/4-20 43/64 .035 .125 5/64 MBP-374 MBP-374SS 3.0 7.0 1/4-20 43/64 .035 .125 5/64 MBP-375 MBP-375SS 4.0 12.0 1/4-20 43/64 .035 .125 5/64 MBP-376 MBP-376SS 2.0 4.5 5/16-18 23/32 .040 .156 3/32 MBP-377 MBP-377SS 4.0 9.0 5/16-18 23/32 .040 .156 3/32 MBP-378 MBP-378SS 6.0 17.0 5/16-18 23/32 .040 .156 3/32 MBP-379 MBP-379SS 2.5 5.0 3/8-16 13/16 .048 .187 5/32 MBP-380 MBP-380SS 5.0 10.0 3/8-16 13/16 .048 .187 5/32 MBP-381 MBP-381SS 6.0 21.0 3/8-16 13/16 .048 .187 5/32 MBP-382 MBP-382SS 3.0 6.0 1/2-13 1-3/64 .072 .281 7/32 MBP-383 MBP-383SS 6.0 12.0 1/2-13 1-3/64 .072 .281 7/32 MBP-384 MBP-384SS 6.0 30.0 1/2-13 1-3/64 .072 .281 7/32 MBP-385 MBP-385SS 4.5 9.0 5/8-11 1-15/64 .096 .375 1/4 MBP-386 MBP-386SS 9.0 18.0 5/8-11 1-15/64 .096 .375 1/4 MBP-387 MBP-387SS 7.0 50.0 5/8-11 1-15/64 .096 .375 1/4
Ball Plungers
hex drive
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
53
k
Page 56
j
B a l l P l u n g e r s
Metric Ball Plungers
hex drive
j Available in steel and stainless steel body, hardened stainless steel ball
j Spring pressure shown in newtons (N)
j No locking element
j Socket design (ws)
Steel Stainless Steel Initial Final Ball Dia.
PART # PART # Pressure Pressure ABCDWS
MBP-247 MBP-247SS 3 4.5 M3 x .5 8mm .4mm 1.5mm 1.5mm MBP-248 MBP-248SS 8 14 M4 x .7 12 .8 2.5 2.0 MBP-249 MBP-249SS 8 14 M5 x .8 14 .9 3 2.5 MBP-250 MBP-250SS 11 18 M6 x 1.0 15 1 3.5 3 MBP-251 MBP-251SS 18 31 M8 x 1.25 18 1.5 4.5 4 MBP-252 MBP-252SS 24 45 M10 x 1.5 23 265 MBP-253 MBP-253SS 26 49 M12 x 1.75 26 2.5 86 MBP-254 MBP-254SS 41 86 M16 x 2.0 33 3.5 10 8 MBP-255 MBP-255SS 66 111 M20 x 2.5 43 4.5 12 10 MBP-256 MBP-256SS 81 151 M24 x 3.0 48 5.5 15 12
Metric Ball Plungers
j Available in steel and stainless steel body, hardened stainless steel ball
j Spring pressure shown in newtons (N)
j No locking element
j Screwdriver slot
Steel Stainless Steel Initial Final Ball Dia.
PART # PART # Pressure Pressure ABCD
40103 40203 23M3 x .5 7mm .5mm 1.5mm 40104 40204 6 12 M4 x .7 9 .8 2.5 40105 40205 7 13 M5 x .8 12 .9 3 40106 40206 9 15 M6 x 1.0 14 1 3.5 40108 40208 20 35 M8 x 1.25 16 1.5 5 40110 40210 25 45 M10 x 1.5 19 26 40112 40212 35 60 M12 x 1.75 22 2.5 8 40116 40216 65 110 M16 x 2.0 24 3.5 10 40120 40220 90 140 M20 x 2.5 30 4.5 12 40124 40224 125 180 M24 x 3.0 34 5.5 15
j
54
w w w . m o r t o n m a c h i n e . c o m
Page 57
B a l l P l u n g e r s
k
Delrin®Body Ball Plungers
PART # Start Full ABC D
MBP-270 2.0 4.0 1/4-20 17/32 .035 .125 MBP-271 3.0 7.0 1/4-20 17/32 .035 .125 MBP-272 4.0 12.0 1/4-20 17/32 .035 .125 MBP-273 2.0 4.5 5/16-18 37/64 .040 .156 MBP-274 4.0 9.0 5/16-18 37/64 .040 .156 MBP-275 6.0 17.0 5/16-18 37/64 .040 .156 MBP-276 2.5 5.0 3/8-16 5/8 .048 .187 MBP-277 5.0 10.0 3/8-16 5/8 .048 .187 MBP-278 6.0 21.0 3/8-16 5/8 .048 .187
P
MBP-280 2.0 4.0 1/4-20 17/32 .035 .125 MBP-281 3.0 7.0 1/4-20 17/32 .035 .125 MBP-282 4.0 12.0 1/4-20 17/32 .035 .125 MBP-283 2.0 4.5 5/16-18 37/64 .040 .156 MBP-284 4.0 9.0 5/16-18 37/64 .040 .156 MBP-285 6.0 17.0 5/16-18 37/64 .040 .156 MBP-286 2.5 5.0 3/8-16 5/8 .048 .187 MBP-287 5.0 10.0 3/8-16 5/8 .048 .187 MBP-288 6.0 21.0 3/8-16 5/8 .048 .187
PART # Start Full AB C D
MSP-160 6.5 21.0 M4 x .7 11.0mm 1.32mm 1.77mm MSP-161 7.5 28.0 M5 x .8 12.0 1.65 2.36 MSP-162 13.5 46.5 M6 x 1.0 13.5 1.98 3.02 MSP-163 16.5 69.0 M8 x 1.25 14.0 2.14 3.42 MSP-164 20.0 82.0 M10 x 1.5 16.0 2.80 4.72 MSP-165 22.0 125.5 M12 x 1.75 19.0 3.83 6.29
PART # Start Full AB C D
MSP-170 6.5 21.0 M4 x .7 11.0mm 1.32mm 1.77mm MSP-171 7.5 28.0 M5 x .8 12.0 1.65 2.36 MSP-172 13.5 46.5 M6 x 1.0 13.5 1.98 3.02 MSP-173 16.5 69.0 M8 x 1.25 14.0 2.14 3.42 MSP-174 20.0 82.0 M10 x 1.5 16.0 2.80 4.72 MSP-175 22.0 125.5 M12 x 1.75 19.0 3.83 6.29
PART # Start Full AB C D
MSP-180 2.0 6.5 M4 x .7 11.0mm 1.32mm 1.77mm MSP-181 3.5 11.0 M5 x .8 12.0 1.65 2.36 MSP-182 4.5 15.5 M6 x 1.0 13.5 1.98 3.02 MSP-183 6.5 18.0 M8 x 1.25 14.0 2.14 3.42 MSP-184 6.5 22.0 M10 x 1.5 16.0 2.80 4.72 MSP-185 8.0 24.5 M12 x 1.75 19.0 3.83 6.29
PART # Start Full AB C D
MSP-190 2.0 6.5 M4 x .7 11.0mm 1.32mm 1.77mm MSP-191 3.5 11.0 M5 x .8 12.0 1.65 2.36 MSP-192 4.5 15.5 M6 x 1.0 13.5 1.98 3.02 MSP-193 6.5 18.0 M8 x 1.25 14.0 2.14 3.42 MSP-194 6.5 22.0 M10 x 1.5 16.0 2.80 4.72 MSP-195 8.0 24.5 M12 x 1.75 19.0 3.83 6.29
End Pressures Pounds
E
ART # Start Full ABC D
End Pressures Newtons
End Pressures Newtons
End Pressures Newtons
End Pressures Newtons
STAINLESS STEEL BALL
ELRIN
nd Pressures Pounds
D
HEAVY SPRING PRESSURE
BROWN NYLON NOSE
LIGHT SPRING PRESSURE
WHITE NYLON NOSE
®
ALL
B
STEEL NOSE
STEEL NOSE
+.000 -.050
+.000 -.050
+.000 -.050
+.000 -.050
j Bodies are made from Delrin
®
j Available with stainless steel ball or Delrin®ball
j Delrin®is a lightweight, non-marring material
j High temperature rating of 180˚F
Metric Short Spring Plungers
Slotted Drive
j All dimensions are shown in millimeters
j Steel bodies are made from carbon steel with black oxide finish.
j All plungers equipped with nylon pellet for positive holding. If
you require plungers without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
55
k
Page 58
j
S p r i n g P l u n g e r s
Spring Plungers
heavy pressure
j Steel body, black oxide finish
j All plungers equipped with nylon pellet for positive
holding. If you require plungers without the nylon lock­ing element, please specify when ordering.
j New phenolic nose available
j Ideal for locating or positioning applications
Steel Nose End Pressures Pounds +.000 -.002
PART # Start 1/2 Full ABCD
MSP-1 1.5 3.0 4.5 #6-32 17/32 .062 .046 MSP-2 1.0 1.3 1.6 #6-32 3/8 .062 .046 MSP-3 2.7 5.0 7.3 #8-32 5/8 .093 .070 MSP-4 2.9 7.0 11.1 #10-32 3/4 .125 .093 MSP-5 3.0 8.0 13.0 1/4-20 1" .187 .119 MSP-6 3.0 8.0 13.0 1/4-28 1" .187 .119 MSP-7 2.0 5.5 9.0 1/4-20 3/4 .125 .119 MSP-8 3.0 9.0 15.0 5/16-18 1" .187 .135 MSP-9 5.5 10.0 14.5 3/8-16 1-1/8 .187 .186 MSP-10 6.6 12.0 17.4 1/2-13 1-1/4 .250 .248 MSP-11 10.5 18.0 25.5 5/8-11 1-1/2 .312 .310 MSP-12 6.7 22.0 37.3 3/4-10 1-3/4 .312 .374 MSP-13 16.0 42.0 68.0 1"-8 2-13/32 .500 .499
Phenolic Nose Delrin Nose End Pressures Pounds +.000 -.002
PART # PART # Start 1/2 Full ABCD
MSP-141 MSP-41 2.7 5.0 7.3 #8-32 5/8 .093 .070 MSP-142 MSP-42 2.9 7.0 11.1 #10-32 3/4 .125 .093 MSP-143 MSP-43 3.0 8.0 13.0 1/4-20 1" .187 .119 MSP-1435 MSP-435 3.0 8.0 13.0 1/4-28 1" .187 .119 MSP-144 MSP-44 3.0 9.0 15.0 5/16-18 1" .187 .135 MSP-145 MSP-45 5.5 10.0 14.5 3/8-16 1-1/8 .187 .186 MSP-146 MSP-46 6.6 12.0 17.4 1/2-13 1-1/4 .250 .248 MSP-147 MSP-47 10.5 18.0 25.5 5/8-11 1-1/2 .312 .310
Brown
HEAT TREATED BLACK OXIDE STEEL NOSE
Spring Plungers
light pressure
j Steel body, black oxide finish
j All plungers equipped with nylon pellet for positive
holding. If you require plungers without the nylon lock­ing element, please specify when ordering.
j New phenolic nose available
j Ideal for locating or positioning applications
Steel Nose End Pressures Pounds +.000 -.002
PART # Start 1/2 Full ABCD
MSP-21 0.5 1.0 1.5 #6-32 17/32 .062 .046 MSP-22 0.7 1.5 2.3 #8-32 5/8 .093 .070 MSP-23 1.3 2.0 2.7 #10-32 3/4 .125 .093 MSP-24 1.0 2.5 4.0 1/4-20 1" .187 .119 MSP-25 1.0 2.5 4.0 1/4-28 1" .187 .119 MSP-26 1.5 3.0 4.5 5/16-18 1" .187 .135 MSP-27 2.8 5.0 7.2 3/8-16 1-1/8 .187 .186 MSP-28 2.7 6.0 9.3 1/2-13 1-1/4 .250 .248 MSP-29 3.5 7.0 10.5 5/8-11 1-1/2 .312 .310 MSP-30 4.0 10.0 16.0 3/4-10 1-3/4 .312 .374 MSP-31 4.0 17.5 31.0 1"-8 2-13/32 .500 .499
Phenolic Nose Delrin Nose End Pressures Pounds +.000 -.002
PART # PART # Start 1/2 Full ABCD
MSP-151 MSP-51 0.7 1.5 2.3 #8-32 5/8 .093 .070 MSP-152 MSP-52 1.3 2.0 2.7 #10-32 3/4 .125 .093 MSP-153 MSP-53 1.0 2.5 4.0 1/4-20 1" .187 .119 MSP-1535 MSP-538 1.0 2.5 4.0 1/4-28 1" .187 .119 MSP-154 MSP-54 1.5 3.0 4.5 5/16-18 1" .187 .135 MSP-155 MSP-55 2.8 5.0 7.2 3/8-16 1-1/8 .187 .186 MSP-156 MSP-56 2.7 6.0 9.3 1/2-13 1-1/4 .250 .248 MSP-157 MSP-57 3.5 7.0 10.5 5/8-11 1-1/2 .312 .310
White
HEAT TREATED ZINC PLATED STEEL NOSE
j
56
w w w . m o r t o n m a c h i n e . c o m
Page 59
j All plungers equipped with nylon pellet for positive holding. If you require plungers without the nylon locking element, please specify when ordering.
j Bodies are stainless steel ... check spreadsheet for nose material
j Ideal for locating or positioning applications
Heavy Spring Pressures
TAINLESS NOSE
ART # Start 1/2 Full ABCD
P
MSP-1SS 1.5 3.0 4.5 #6-32 17/32 .062 .046 MSP-2SS 1.0 1.3 1.6 #6-32 3/8 .062 .046 MSP-3SS 2.7 5.0 7.3 #8-32 5/8 .093 .070 MSP-4SS 2.9 7.0 11.1 #10-32 3/4 .125 .093 MSP-5SS 3.0 8.0 13.0 1/4-20 1" .187 .119 MSP-6SS 3.0 8.0 13.0 1/4-28 1" .187 .119 MSP-7SS 2.0 5.5 9.0 1/4-20 3/4 .125 .119 MSP-8SS 3.0 9.0 15.0 5/16-18 1" .187 .135 MSP-9SS 5.5 10.0 14.5 3/8-16 1-1/8 .187 .186 MSP-10SS 6.6 12.0 17.4 1/2-13 1-1/4 .250 .248
MSP-11SS 2.7 5.0 7.3 #8-32 5/8 .093 .070 MSP-12SS 2.9 7.0 11.1 #10-32 3/4 .125 .093 MSP-13SS 3.0 8.0 13.0 1/4-20 1" .187 .119 MSP-14SS 3.0 8.0 13.0 1/4-28 1" .187 .119 MSP-15SS 3.0 9.0 15.0 5/16-18 1" .187 .135 MSP-16SS 5.5 10.0 14.5 3/8-16 1-1/8 .187 .186 MSP-17SS 6.6 12.0 17.4 1/2-13 1-1/4 .250 .248
End Pressures Pounds +.000 -.002
S
BROWN NYLON NOSE
S p r i n g P l u n g e r s
k
Stainless Steel Spring Plungers
Light Spring Pressures
PART # Start 1/2 Full ABCD
End Pressures Pounds +.000 -.002
MSP-21SS 0.5 1.0 1.5 #6-32 17/32 .062 .046 MSP-22SS 0.7 2.0 2.3 #8-32 5/8 .093 .070 MSP-23SS 1.3 2.5 2.7 #10-32 3/4 .125 .093 MSP-24SS 1.0 3.0 4.0 1/4-20 1" .187 .119 MSP-25SS 1.0 2.5 4.0 1/4-28 1" .187 .119 MSP-26SS 1.5 3.0 4.5 5/16-18 1" .187 .135 MSP-27SS 2.8 5.0 7.2 3/8-16 1-1/8 .187 .186
MSP-28SS 2.7 6.0 9.3 1/2-13 1-1/4 .250 .248
MSP-29SS 0.7 1.5 2.3 #8-32 5/8 .093 .070 MSP-30SS 1.3 2.0 2.7 #10-32 3/4 .125 .093 MSP-31SS 1.0 2.5 4.0 1/4-20 1" .187 .119 MSP-32SS 1.0 2.5 4.0 1/4-28 1" .187 .119 MSP-33SS 1.5 3.0 4.5 5/16-18 1" .187 .135 MSP-34SS 2.8 5.0 7.2 3/8-16 1-1/8 .187 .186 MSP-35SS 2.7 6.0 9.3 1/2-13 1-1/4 .250 .248
STAINLESS NOSE
WHITE NYLON NOSE
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
57
k
Page 60
j
S p r i n g P l u n g e r s
Metric Spring Plungers
j Steel bodies, black oxide finish
®
j Available in hardened steel nose, or white Delrin
nose
j Spring pressure shown in newtons (N)
teel Nose Delrin Nose Initial Final
S
PART # PART # Pressure Pressure ABCDHex
41103 -24M3 x .5 12mm 1mm 1mm .7mm 41104 41204 5 15 M4 x .7 15 1.5 1.5 1.3 41105 41205 7 20 M5 x .8 18 2.3 2.4 1.5 41106 41206 7 20 M6 x 1.0 20 2.5 2.7 2 41108 41208 9 35 M8 x 1.25 22 3 3.5 2.5 41110 41210 9 35 M10 x 1.5 22 343 41112 41212 15 55 M12 x 1.75 28 464 41116 41216 45 100 M16 x 2.0 32 5 7.5 5 41120 - 70 140 M20 x 2.5 40 7 10 6 41124 - 80 180 M24 x 3.0 52 10 12 8
Metric Spring Plungers
j All dimensions are shown in millimeters
j Steel bodies are made from carbon steel with black oxide
finish
j Stainless bodies are made from 303 stainless steel
j All plungers equipped with nylon pellet for positive holding.
If you require plungers without the nylon locking element, please specify when ordering.
j Ideal for locating or positioning applications
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start Full ABCD
MSP-80 MSP-80SS 13.5 58 M 6 X 1.0 25.00mm 5.00mm 3.00mm MSP-81 MSP-81SS 13.5 67 M 8 X 1.25 25.00 5.00 3.40 MSP-82 MSP-82SS 24.5 65 M 10 X 1.5 29.00 5.00 4.70 MSP-83 MSP-83SS 29.5 78 M 12 X 1.75 32.00 6.00 6.30
Steel Body Stainless Body
MSP-84 MSP-84SS 13.5 58 M6 x 1.0 25.00 5.00 3.00 MSP-85 MSP-85SS 13.5 67 M8 x 1.25 25.00 5.00 3.40 MSP-86 MSP-86SS 24.5 65 M10 x 1.5 29.00 5.00 4.70 MSP-87 MSP-87SS 29.5 78 M12 x 1.75 32.00 6.00 6.30
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start Full ABCD
MSP-90 MSP-90SS 4.5 18 M6 x 1.0 25.00 5.00 3.00 MSP-91 MSP-91SS 6.5 20 M8 x 1.25 25.00 5.00 3.40 MSP-92 MSP-92SS 12.5 32 M10 x 1.5 29.00 5.00 4.70 MSP-93 MSP-93SS 12 42 M12 x 1.75 32.00 6.00 6.30
Steel Body Stainless Body
MSP-94 MSP-94SS 4.5 18 M6 x 1.0 25.00 5.00 3.00 MSP-95 MSP-95SS 6.5 20 M8 x 1.25 25.00 5.00 3.40 MSP-96 MSP-96SS 12.5 32 M10 x 1.5 29.00 5.00 4.70 MSP-97 MSP-97SS 12 42 M12 x 1.75 32.00 6.00 6.30
HEAVY SPRING PRESSURE
End Pressue Newtons
BROWN NYLON NOSE
LIGHT SPRING PRESSURE
End Pressue Newtons
WHITE NYLON NOSE
Class 6G ISO ±.025
Class 6G ISO ±.025
j
58
w w w . m o r t o n m a c h i n e . c o m
Page 61
j Steel bodies are made from carbon steel with black oxide finish
j Stainless bodies are made from 303 stainless steel
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon element, please specify when ordering.
j Extended nose travel length. Ideal for positioning applications.
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start Full ABCD
MSP-250 MSP-250SS 1.0 3.25 #8-32 7/16 .093 .070 MSP-251 MSP-251SS 1.0 3.25 #8-36 7/16 .093 .070 MSP-252 MSP-252SS 1.25 4.25 #10-32 15/32 .125 .093 MSP-253 MSP-253SS 2.0 7.0 1/4-20 17/32 .187 .119 MSP-254 MSP-254SS 2.5 10.5 5/16-18 9/16 .187 .135 MSP-255 MSP-255SS 3.0 12.5 3/8-16 5/8 .187 .186 MSP-256 MSP-256SS 3.5 19.0 1/2-13 3/4 .250 .248 MSP-257 - 4.5 33.5 5/8-11 1-1/16 .312 .310
teel Body Stainless Body
S
ART # PART # Start Full ABCD
P
MSP-260 MSP-260SS 1.0 3.25 #8-32 7/16 .093 .070 MSP-261 MSP-261SS 1.0 3.25 #8-36 7/16 .093 .070 MSP-262 MSP-262SS 1.25 4.25 #10-32 15/32 .125 .093 MSP-263 MSP-263SS 2.0 7.0 1/4-20 17/32 .187 .119 MSP-264 MSP-264SS 2.5 10.5 5/16-18 9/16 .187 .135 MSP-265 MSP-265SS 3.0 12.5 3/8-16 5/8 .187 .186 MSP-266 MSP-266SS 3.5 19.0 1/2-13 3/4 .250 .248 MSP-267 - 4.5 33.5 5/8-11 1-1/16 .312 .310
End Pressue Pounds
ROWN NYLON NOSE
B
nd Pressue Pounds
E
S p r i n g P l u n g e r s
k
Short Spring Plungers
extended nose, slotted drive
Slotted Drive
j Steel bodies are made from carbon steel with black oxide finish
j Stainless bodies are made from 303 stainless steel
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon element, please specify when ordering.
j Extended nose travel length. Ideal for positioning applications.
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start Full ABCDE
MSP-350 MSP-360SS 0.5 1.25 #6-32 7/16 .062 .046 3/64 MSP-351 MSP-351SS 1.0 3.25 #8-32 1/2 .093 .070 5/64 MSP-352 MSP-352SS 1.0 3.25 #8-36 1/2 .093 .070 5/64 MSP-353 MSP-353SS 1.25 4.25 #10-32 9/16 .125 .093 3/32 MSP-354 MSP-354SS 2.0 7.0 1/4-20 5/8 .187 .119 1/8 MSP-355 MSP-355SS 2.0 9.0 5/16-18 23/32 .187 .135 5/32 MSP-356 MSP-356SS 3.0 12.5 3/8-16 29/32 .187 .186 3/16 MSP-357 MSP-357SS 3.5 19.0 1/2-13 1-3/64 .250 .248 1/4 MSP-358 MSP-358SS 4.5 33.5 5/8-11 1-3/8 .312 .310 5/16
Steel Body Stainless Body
PART # PART # Start Full ABCDE
MSP-360 MSP-360SS 0.5 1.25 #6-32 7/16 .062 .046 3/64 MSP-361 MSP-361SS 1.0 3.25 #8-32 1/2 .093 .070 5/64 MSP-362 MSP-362SS 1.0 3.25 #8-36 1/2 .093 .070 5/64 MSP-363 MSP-363SS 1.25 4.25 #10-32 9/16 .125 .093 3/32 MSP-364 MSP-364SS 2.0 7.0 1/4-20 5/8 .187 .119 1/8 MSP-365 MSP-365SS 2.0 9.0 5/16-18 23/32 .187 .135 5/32 MSP-366 MSP-366SS 3.0 12.5 3/8-16 29/32 .187 .186 3/16 MSP-367 MSP-367SS 3.5 19.0 1/2-13 1-3/64 .250 .248 1/4 MSP-368 MSP-368SS 4.5 33.5 5/8-11 1-3/8 .312 .310 5/16
End Pressue Pounds Hex Drive
End Pressue Pounds Hex Drive
BROWN NYLON NOSE
Short Spring Plungers
extended nose, hex drive
Hex Drive
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
59
k
Page 62
j
S p r i n g P l u n g e r s
Short Spring Plungers
heavy pressure, slotted drive
Slotted Drive
j Steel bodies are made from carbon steel with black oxide finish
j Stainless bodies are made from 303 stainless steel
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon element, please specify when ordering.
j Ideal for locating or positioning applications
teel Body Stainless Body
S
teel Nose Stainless Nose
S
ART # PART # Start 1/2 Full ABCD
P
MSP-201 MSP-40SS 1.5 3.1 4.75 #8-32 7/16 .052 .070 MSP-202 MSP-41SS 1.5 3.1 4.75 #8-36 7/16 .052 .070 MSP-203 MSP-42SS 1.75 4.0 6.25 #10-32 15/32 .065 .093 MSP-204 MSP-43SS 3.0 6.75 10.5 1/4-20 17/32 .078 .119 MSP-205 MSP-44SS 3.75 9.6 15.5 5/16-18 9/16 .084 .135 MSP-206 MSP-45SS 4.5 11.5 18.5 3/8-16 5/8 .110 .186 MSP-207 MSP-46SS 5.0 16.5 28.0 1/2-13 3/4 .151 .248 MSP-208 - 7.0 28.5 50.0 5/8-11 1-1/16 .215 .310
Steel Body Stainless Body
PART # PART # Start 1/2 Full ABCD
MSP-210 MSP-47SS 1.5 3.1 4.75 #8-32 7/16 .052 .070 MSP-211 MSP-48SS 1.5 3.1 4.75 #8-36 7/16 .052 .070 MSP-212 MSP-49SS 1.75 4.0 6.25 #10-32 15/32 .065 .093 MSP-213 MSP-50SS 3.0 6.75 10.5 1/4-20 17/32 .078 .119 MSP-214 MSP-51SS 3.75 9.6 15.5 5/16-18 9/16 .084 .135 MSP-215 MSP-52SS 4.5 11.5 18.5 3/8-16 5/8 .110 .186 MSP-216 MSP-53SS 5.0 16.5 28.0 1/2-13 3/4 .151 .248 MSP-217 - 7.0 28.5 50.0 5/8-11 1-1/16 .215 .310
nd Pressue Pounds
E
BROWN NYLON NOSE
End Pressue Pounds
.000 -.002
+
+.000 -.002
Short Spring Plungers
light pressure, slotted drive
Slotted Drive
j Steel bodies are made from carbon steel with black oxide finish
j Stainless bodies are made from 303 stainless steel
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon element, please specify when ordering.
j Ideal for locating or positioning applications
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start 1/2 Full ABCD
MSP-220 MSP-60SS .5 1.0 1.5 #8-32 7/16 .052 .070 MSP-221 MSP-61SS .5 1.0 1.5 #8-36 7/16 .052 .070 MSP-222 MSP-62SS .75 1.62 2.5 #10-32 15/32 .065 .093 MSP-223 MSP-63SS 1.0 2.25 3.5 1/4-20 17/32 .078 .119 MSP-224 MSP-64SS 1.5 2.75 4.0 5/16-18 9/16 .084 .135 MSP-225 MSP-65SS 1.5 3.25 5.0 3/8-16 5/8 .110 .186 MSP-226 MSP-66SS 1.75 3.62 5.5 1/2-13 3/4 .151 .248 MSP-227 - 2.0 5.25 8.5 5/8-11 1-1/16 .215 .310
Steel Body Stainless Body
PART # PART # Start 1/2 Full ABCD
MSP-230 MSP-67SS .5 1.0 1.5 #8-32 7/16 .052 .070 MSP-231 MSP-68SS .5 1.0 1.5 #8-36 7/16 .052 .070 MSP-232 MSP-69SS .75 1.62 2.5 #10-32 15/32 .065 .093 MSP-233 MSP-70SS 1.0 2.25 3.5 1/4-20 17/32 .078 .119 MSP-234 MSP-71SS 1.5 2.75 4.0 5/16-18 9/16 .084 .135 MSP-235 MSP-72SS 1.5 3.25 5.0 3/8-16 5/8 .110 .186 MSP-236 MSP-73SS 1.75 3.62 5.5 1/2-13 3/4 .151 .248 MSP-237 - 2.0 5.25 8.5 5/8-11 1-1/16 .215 .310
End Pressue Pounds
End Pressue Pounds
WHITE NYLON NOSE
+.000 -.002
+.000 -.002
j
60
w w w . m o r t o n m a c h i n e . c o m
Page 63
j Steel bodies are made from carbon steel with black oxide finish
j Stainless bodies are made from 303 stainless steel
All plungers equipped with nylon pellet for positive holding. If you require
j
plungers without the nylon element, please specify when ordering.
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start Full ABCDE
MSP-301 MSP-301SS 1.5 4.75 #8-32 1/2 .052 .070 5/64 MSP-302 MSP-302SS 1.5 4.75 #8-36 1/2 .052 .070 5/64 MSP-303 MSP-303SS 1.75 6.25 #10-32 9/16 .065 .093 3/32 MSP-304 MSP-304SS 3.0 10.5 1/4-20 5/8 .078 .119 1/8 MSP-305 MSP-305SS 3.75 15.5 5/16-18 23/32 .084 .135 5/32 MSP-306 MSP-306SS 4.5 18.5 3/8-16 29/32 .110 .186 3/16 MSP-307 MSP-307SS 5.0 28.0 1/2-13 1-3/64 .151 .248 1/4 MSP-308 MSP-308SS 7.0 50.0 5/8-11 1-3/8 .215 .310 5/16
End Pressure Pounds Hex Dia.
S p r i n g P l u n g e r s
k
Short Spring Plungers
heavy pressure, hex drive
ROWN NYLON NOSE
teel Body Stainless Body
S
ART # PART # Start Full ABCDE
P
MSP-311 MSP-311SS 1.5 4.75 #8-32 1/2 .052 .070 5/64 MSP-312 MSP-312SS 1.5 4.75 #8-36 1/2 .052 .070 5/64 MSP-313 MSP-313SS 1.75 6.25 #10-32 9/16 .065 .093 3/32 MSP-314 MSP-314SS 3.0 10.5 1/4-20 5/8 .078 .119 1/8 MSP-315 MSP-315SS 3.75 15.5 5/16-18 23/32 .084 .135 5/32 MSP-316 MSP-316SS 4.5 18.5 3/8-16 29/32 .110 .186 3/16 MSP-317 MSP-317SS 5.0 28.0 1/2-13 1-3/64 .151 .248 1/4 MSP-318 MSP-318SS 7.0 50.0 5/8-11 1-3/8 .215 .310 5/16
nd Pressure Pounds Hex Dia.
E
B
j Steel bodies are made from carbon steel with black oxide finish
j Stainless bodies are made from 303 stainless steel
j All plungers equipped with nylon pellet for positive holding. If you require
plungers without the nylon element, please specify when ordering.
Steel Body Stainless Body Steel Nose Stainless Nose
PART # PART # Start Full ABCDE
MSP-321 MSP-321SS 0.5 1.5 #8-32 1/2 .052 .070 5/64 MSP-322 MSP-322SS 0.5 1.5 #8-36 1/2 .052 .070 5/64 MSP-323 MSP-323SS 0.75 2.5 #10-32 9/16 .065 .093 3/32 MSP-324 MSP-324SS 1.0 3.5 1/4-20 5/8 .078 .119 1/8 MSP-325 MSP-325SS 1.5 4.0 5/16-18 23/32 .084 .135 5/32 MSP-326 MSP-326SS 1.5 5.0 3/8-16 29/32 .110 .186 3/16 MSP-327 MSP-327SS 1.75 5.5 1/2-13 1-3/64 .151 .248 1/4 MSP-328 MSP-328SS 2.0 8.5 5/8-11 1-3/8 .215 .310 5/16
Steel Body Stainless Body
PART # PART # Start Full ABCDE
MSP-331 MSP-331SS 0.5 1.5 #8-32 1/2 .052 .070 5/64 MSP-332 MSP-332SS 0.5 1.5 #8-36 1/2 .052 .070 5/64 MSP-333 MSP-333SS 0.75 2.5 #10-32 9/16 .065 .093 3/32 MSP-334 MSP-334SS 1.0 3.5 1/4-20 5/8 .078 .119 1/8 MSP-335 MSP-335SS 1.5 4.0 5/16-18 23/32 .084 .135 5/32 MSP-336 MSP-336SS 1.5 5.0 3/8-16 29/32 .110 .186 3/16 MSP-337 MSP-337SS 1.75 5.5 1/2-13 1-3/64 .151 .248 1/4 MSP-338 MSP-338SS 2.0 8.5 5/8-11 1-3/8 .215 .310 5/16
End Pressure Pounds Hex Dia.
End Pressure Pounds Hex Dia.
WHITE NYLON NOSE
Hex Drive
Short Spring Plungers
light pressure, hex drive
Hex Drive
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
61
k
Page 64
j
P r e s s F i t P l u n g e r s
Press Fit Spring Plungers
j Available in steel or stainless steel bodies
j Nose available in steel, stainless steel, or Delrin
j Excellent solution when used in wood, soft plastic,
or aluminum
®
TEEL NOSE / STAINLESS STEEL NOSE - HEAVY PRESSURE
S
teel Stainless Steel Pounds -.002
S
ART # PART # Start Full AB CDEF
P
MSP-501 MSP-501SS 12.125 .252 .062 .070 .187 .032 MSP-507 MSP-507SS 1.25 3.25 .157 .330 .078 .093 .215 .035 MSP-502 MSP-502SS 1.5 4.5 .188 .405 .094 .121 .250 .035 MSP-503 MSP-503SS 2.5 6 .250 .481 .125 .168 .312 .044 MSP-504 MSP-504SS 4 10 .312 .643 .151 .186 .375 .045 MSP-505 MSP-505SS 5 14 .375 .785 .187 .234 .500 .078 MSP-506 MSP-506SS 8 18 .500 1.130 .250 .332 .688 .088
MSP-511 MSP-511SS .5 1 .125 .252 .062 .070 .187 .032 MSP-517 MSP-517SS .75 2 .157 .330 .078 .093 .215 .035 MSP-512 MSP-512SS .75 2.5 .188 .405 .094 .121 .250 .035 MSP-513 MSP-513SS 1.5 3 .250 .481 .125 .168 .312 .044 MSP-514 MSP-514SS 25.312 .643 .151 .186 .375 .045 MSP-515 MSP-515SS 2.5 7 .375 .785 .187 .234 .500 .078 MSP-516 MSP-516SS 49.500 1.130 .250 .332 .688 .088
Steel Stainless Steel Pounds -.002
PART # PART # Start Full AB CDEF
MSP-520 MSP-520SS 12.125 .252 .062 .070 .187 .032 MSP-527 MSP-527SS 1.25 3.25 .157 .330 .078 .093 .215 .035 MSP-521 MSP-521SS 1.5 4.5 .188 .405 .094 .121 .250 .035 MSP-522 MSP-522SS 2.5 6 .250 .481 .125 .168 .312 .044 MSP-523 MSP-523SS 4 10 .312 .643 .151 .186 .375 .045 MSP-524 MSP-524SS 5 14 .375 .785 .187 .234 .500 .078 MSP-525 MSP-525SS 8 18 .500 1.130 .250 .332 .688 .088
MSP-530 MSP-530SS .5 1 .125 .252 .062 .070 .187 .032 MSP-537 MSP-537SS .75 2 .157 .330 .078 .093 .215 .035 MSP-531 MSP-531SS .75 2.5 .188 .405 .094 .121 .250 .035 MSP-532 MSP-532SS 1.5 3 .250 .481 .125 .168 .312 .044 MSP-533 MSP-533SS 25.312 .643 .151 .186 .375 .045 MSP-534 MSP-534SS 2.5 7 .375 .785 .187 .234 .500 .078 MSP-535 MSP-535SS 49.500 1.130 .250 .332 .688 .088
STEEL NOSE / STAINLESS STEEL NOSE - LIGHT PRESSURE
nd Pressure +.001
E
BROWN DELRIN®NOSE - HEAVY PRESSURE
End Pressure +.001
WHITE DELRIN®NOSE - LIGHT PRESSURE
Press Fit Ball Plungers
metric
j Small, lightweight plungers excellent in light duty applications
j Stainless steel ball available in Delrin stainless steel body
j Stainless steel spring
j Pressure in (N) newtons
j d1 tolerance = +0.01-0mm
®
body or
STAINLESS STEEL BODY AND BALL
PART # d1Pressure Pressure ABCDE
42104 4mm 253mm 4.6mm 5mm 1mm 1.0mm 42105 54 7 4 5.6 611.4 42106 66 12 5 6.5 711.8 42108 86 12 6.5 8.5 912.4 42110 10 8.5 19 8.5 11 13 1.7 3.3 42112 12 12 27 10 13 16 2.3 4.0
PART # d1Pressure Pressure ABCDE
42404 4mm 2.5 6 2.5mm 4.5mm 5mm 1mm .8mm 42405 5 3.0 6.5 3.5 5.5 611 42406 6 5.5 11.5 4.5 6.5 711.6 42408 8 7.0 12.5 6 8.5 911.9
PART # d1Pressure Pressure ABCDE
42204 4mm 3.5 7 3mm 4.6mm 5mm 1mm .9mm 42205 55 9 4 5.6 611 42206 68 14 5 6.5 711.5 42208 89 17 6.5 8.5 911.8 42210 10 12 23 8 11 13 1.5 2.4 42212 12 13 25 10 13 16 1.5 3.3
PART # d1Pressure Pressure ABCDE
42304 4 3.5 734.6 51.9 42305 55 9 4 5.6 611 42306 68 14 5 6.5 711.5 42308 89 17 6.5 8.5 911.8 42310 10 12 23 8 11 13.5 1.5 2.4 42312 12 13 25 10 13 16 1.5 3.3
Initial Final
BRASS BODY, STAINLESS STEEL BALL
Initial Final
DELRIN®BODY, STAINLESS STEEL BALL
Initial Final
DELRIN®BODY, DELRIN®BALL
Initial Final
j
62
w w w . m o r t o n m a c h i n e . c o m
Page 65
STAINLESS STEEL BALL NOSES
Steel Stainless Steel Pounds -.000 Ball Dia.
PART # PART # Start Full AB CDEF
PFP-125H PFP-125HSS 25.125 .252 .035 .093 .187 .032 PFP-157H PFP-157HSS 3 7.5 .157 .330 .046 .125 .215 .035 PFP-188H PFP-188HSS 4 10 .188 .405 .058 .156 .250 .035 PFP-250H PFP-250HSS 6 13 .250 .481 .070 .187 .312 .044 PFP-312H PFP-312HSS 8 16 .312 .643 .090 .250 .375 .045 PFP-375H PFP-375HSS 10 18 .375 .785 .110 .312 .500 .078 PFP-500H PFP-500HSS 12 23 .500 1.130 .161 .437 .688 .088
PFP-125 PFP-125SS .75 2.5 .125 .252 .035 .093 .187 .032 PFP-157 PFP-157SS 1.5 3.5 .157 .330 .046 .125 .215 .035 PFP-188 PFP-188SS 25.188 .405 .058 .156 .250 .035 PFP-250 PFP-250SS 37.250 .481 .070 .187 .312 .044 PFP-312 PFP-312SS 4 10 .312 .643 .090 .250 .375 .045 PFP-375 PFP-375SS 5 14 .375 .785 .110 .312 .500 .078 PFP-500 PFP-500SS 8 18 .500 1.130 .161 .437 .688 .088
PFP-125L PFP-125LSS .5 1 .125 .252 .035 .093 .187 .032 PFP-157L PFP-157LSS .75 2 .157 .330 .046 .125 .215 .035 PFP-188L PFP-188LSS 1 2.5 .188 .405 .058 .156 .250 .035 PFP-250L PFP-250LSS 1.5 3.5 .250 .481 .070 .187 .312 .044 PFP-312L PFP-312LSS 25.312 .643 .090 .250 .375 .045 PFP-375L PFP-375LSS 2.5 7 .375 .785 .110 .312 .500 .078 PFP-500L PFP-500LSS 49 .500 1.130 .161 .437 .688 .088
Steel Stainless Steel Pounds -.000 Ball Dia.
PART # PART # Start Full AB CDEF
PFP-12H PFP-12HSS 25.125 .252 .035 .093 .187 .032 PFP-15H PFP-15HSS 3 7.5 .157 .330 .046 .125 .215 .035 PFP-18H PFP-18HSS 4 10 .188 .405 .058 .156 .250 .035 PFP-25H PFP-25HSS 6 13 .250 .481 .070 .187 .312 .044 PFP-31H PFP-31HSS 8 16 .312 .643 .090 .250 .375 .045 PFP-37H PFP-37HSS 10 18 .375 .785 .110 .312 .500 .078 PFP-50H PFP-50HSS 12 23 .500 1.130 .161 .437 .688 .088
PFP-12 PFP-12SS .75 2.5 .125 .252 .035 .093 .187 .032 PFP-15 PFP-15SS 1.5 3.5 .157 .330 .046 .125 .215 .035 PFP-18 PFP-18SS 25.188 .405 .058 .156 .250 .035 PFP-25 PFP-25SS 37.250 .481 .070 .187 .312 .044 PFP-31 PFP-31SS 4 10 .312 .643 .090 .250 .375 .045 PFP-37 PFP-37SS 5 14 .375 .785 .110 .312 .500 .078 PFP-50 PFP-50SS 8 18 .500 1.130 .161 .437 .688 .088
PFP-12L PFP-12LSS .5 1 .125 .252 .035 .093 .187 .032 PFP-15L PFP-15LSS .75 2 .157 .330 .046 .125 .215 .035 PFP-18L PFP-18LSS 1 2.5 .188 .405 .058 .156 .250 .035 PFP-25L PFP-25LSS 1.5 3.5 .250 .481 .070 .187 .312 .044 PFP-31L PFP-31LSS 25.312 .643 .090 .250 .375 .045 PFP-37L PFP-37LSS 2.5 7 .375 .785 .110 .312 .500 .078 PFP-50L PFP-50LSS 49.500 1.130 .161 .437 .688 .088
End Pressure +.002
End Pressure +.002
HEAVY PRESSURE
MEDIUM PRESSURE
LIGHT PRESSURE
NYLON BALL NOSES
HEAVY PRESSURE
MEDIUM PRESSURE
LIGHT PRESSURE
P r e s s F i t P l u n g e r s
Press Fit Ball Plungers
j Available with stainless steel ball nose or nylon ball nose
j Steel plungers made from 12L14
j Stainless steel plungers made from
303 stainless
j Excellent solution when used in wood, soft plastic, or aluminum
k
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
63
k
Page 66
j
P r e s s F i t P l u n g e r s
Press-Thru™Ball Plungers
tainless ball
s
j Tolerance “A” +.001 +.002
j Steel bodies made from C12L14 with black oxide finish
j Stainless steel bodies made from 303 stainless steel
j Ball material: 440 stainless steel
*Patent pending
IGHT PRESSURE
L
nd Pressure +.001
teel Stainless Steel Pounds +.002
S
ART # PART # Start Full AB C D
P
MBP-400 MBP-400SS 0.5 1.0 .125 .284 .035 .093 MBP-406 MBP-406SS 0.75 2.0 .157 .365 .046 .125 MBP-401 MBP-401SS 1.0 2.5 .188 .440 .058 .156 MBP-402 MBP-402SS 1.5 3.5 .250 .525 .070 .187 MBP-403 MBP-403SS 2.0 5.0 .312 .688 .090 .250 MBP-404 MBP-404SS 2.5 7.0 .375 .864 .110 .312 MBP-405 MBP-405SS 4.0 9.0 .500 1.218 .161 .437
MBP-407 MBP-407SS 0.75 2.5 .125 .284 .035 .093 MBP-413 MBP-413SS 1.5 3.5 .157 .365 .046 .125 MBP-408 MBP-408SS 2.0 5.0 .188 .440 .058 .156 MBP-409 MBP-409SS 3.0 7.0 .250 .525 .070 .187 MBP-410 MBP-410SS 4.0 10.0 .312 .688 .090 .250 MBP-411 MBP-411SS 5.0 14.0 .375 .864 .110 .312 MBP-412 MBP-412SS 8.0 18.00 .500 1.218 .161 .437
MBP-414 MBP-414SS 2.0 5.0 .125 .284 .035 .093 MBP-420 MBP-420SS 3.0 7.5 .157 .365 .046 .125 MBP-415 MBP-415SS 4.0 10.0 .188 .440 .058 .156 MBP-416 MBP-416SS 6.0 13.0 .250 .525 .070 .187 MBP-417 MBP-417SS 8.0 16.0 .312 .688 .090 .250 MBP-418 MBP-418SS 10.0 18.0 .375 .864 .110 .312 MBP-419 MBP-419SS 12.0 23.0 .500 1.218 .161 .437
E
MEDIUM PRESSURE
HEAVY PRESSURE
Press-Thru™Ball Plungers
Delrin®ball
j Tolerance “A” +.001 +.002
j Steel bodies made from C12L14 with black oxide finish
j Stainless steel bodies made from 303 stainless steel
j Ball material: Delrin
®
*Patent pending
LIGHT PRESSURE
Steel Stainless Steel Pounds +.002
PART # PART # Start Full AB CD
MBP-421 MBP-421SS 0.5 1.0 .125 .284 .035 .093 MBP-427 MBP-427SS 0.75 2.0 .157 .365 .046 .125 MBP-422 MBP-422SS 1.0 2.5 .188 .440 .058 .156 MBP-423 MBP-423SS 1.5 3.5 .250 .525 .070 .187 MBP-424 MBP-424SS 2.0 5.0 .312 .688 .090 .250 MBP-425 MBP-425SS 2.5 7.0 .375 .864 .110 .312 MBP-426 MBP-426SS 4.0 9.0 .500 1.218 .161 .437
MBP-428 MBP-428SS 0.75 2.5 .125 .284 .035 .093 MBP-434 MBP-434SS 1.5 3.5 .157 .365 .046 .125 MBP-429 MBP-429SS 2.0 5.0 .188 .440 .058 .156 MBP-430 MBP-430SS 3.0 7.0 .250 .525 .070 .187 MBP-431 MBP-431SS 4.0 10.0 .312 .688 .090 .250 MBP-432 MBP-432SS 5.0 14.0 .375 .864 .110 .312 MBP-433 MBP-433SS 8.0 18.00 .500 1.218 .161 .437
MBP-435 MBP-435SS 2.0 5.0 .125 .284 .035 .093 MBP-441 MBP-441SS 3.0 7.5 .157 .365 .046 .125 MBP-436 MBP-436SS 4.0 10.0 .188 .440 .058 .156 MBP-437 MBP-437SS 6.0 13.0 .250 .525 .070 .187 MBP-438 MBP-438SS 8.0 16.0 .312 .688 .090 .250 MBP-439 MBP-439SS 10.0 18.0 .375 .864 .110 .312 MBP-440 MBP-440SS 12.0 23.0 .500 1.218 .161 .437
End Pressure +.001
MEDIUM PRESSURE
HEAVY PRESSURE
j
64
w w w . m o r t o n m a c h i n e . c o m
Page 67
P r e s s F i t P l u n g e r s
k
j Tolerance “A” +.001 +.002
j Steel bodies made from C12L14 with black oxide finish
j Stainless steel bodies made from 303 stainless steel
j Nose material listed above each grid
EAVY PRESSURE
H
HEAT TREATED STEEL NOSE / STAINLESS STEEL NOSE
Steel Stainless Steel Pounds +.002
PART # PART # Start Full AB CD
MSP-401 MSP-401SS 1.0 2.0 .125 .284 .062 .070 MSP-407 MSP-407SS 1.25 3.25 .157 .365 .078 .093 MSP-402 MSP-402SS 1.5 4.5 .188 .440 .094 .121 MSP-403 MSP-403SS 2.5 6.0 .250 .525 .125 .168 MSP-404 MSP-404SS 4.0 10.0 .312 .688 .151 .186 MSP-405 MSP-405SS 5.0 14.0 .375 .864 .187 .234 MSP-406 MSP-406SS 8.0 18.0 .500 1.218 .250 .332
MSP-408 MSP-408SS 1.0 2.0 .125 .284 .062 .070 MSP-414 MSP-414SS 1.25 3.25 .157 .365 .078 .093 MSP-409 MSP-409SS 1.5 4.5 .188 .440 .094 .121 MSP-410 MSP-410SS 2.5 6.0 .250 .525 .125 .168 MSP-411 MSP-411SS 4.0 10.0 .312 .688 .151 .186 MSP-412 MSP-412SS 5.0 14.0 .375 .864 .187 .234 MSP-413 MSP-413SS 8.0 18.0 .500 1.218 .250 .332
End Pressure +.001
BROWN DELRIN™NOSE
*Patent pending
Press-Thru™Spring Plungers
LIGHT PRESSURE
HEAT TREATED STEEL NOSE / STAINLESS STEEL NOSE
MSP-415 MSP-415SS 0.50 1.0 .125 .284 .062 .070 MSP-421 MSP-421SS 0.75 2.0 .157 .365 .078 .093 MSP-416 MSP-416SS 0.75 2.5 .188 .440 .094 .121 MSP-417 MSP-417SS 1.5 3.0 .250 .525 .125 .168 MSP-418 MSP-418SS 2.0 5.0 .312 .688 .151 .186 MSP-419 MSP-419SS 2.5 7.0 .375 .864 .187 .234 MSP-420 MSP-420SS 4.0 9.0 .500 1.218 .250 .332
WHITE DELRIN™NOSE
MSP-422 MSP-422SS 0.50 1.0 .125 .284 .062 .070 MSP-428 MSP-428SS 0.75 2.0 .157 .365 .078 .093 MSP-423 MSP-423SS 0.75 2.5 .188 .440 .094 .121 MSP-424 MSP-424SS 1.5 3.0 .250 .525 .125 .168 MSP-425 MSP-425SS 2.0 5.0 .312 .688 .151 .186 MSP-426 MSP-426SS 2.5 7.0 .375 .864 .187 .234 MSP-427 MSP-427SS 4.0 9.0 .500 1.218 .250 .332
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
65
k
Page 68
j
P l u n g e r A c c e s s o r i e s
Spring Plunger Mounts
j Used as a mounting bracket for spring loaded devices
j Made from steel, zinc-plated finish
PART # Size Length Length Height Thickness Dia.
Thread Overall Front to Back Overall Base Hole
SPM-1 #8-32 .690 .500 .250 .090 1/8 SPM-2 #10-32 .690 .500 .270 .130 1/8 SPM-3 1/4-20 .880 .690 .410 .190 9/64 SPM-4 5/16-18 .940 .630 .410 .188 9/64 SPM-5 3/8-16 1.130 .750 .470 .219 5/32 SPM-6 1/2-13 1.500 1.00 .630 .250 13/64 SPM-7 5/8-11 1.880 1.25 .800 .312 17/64
Ball & Spring Plunger Wrenches
j Used in installing or removing plungers. Spring damage can result when using a screwdriver on the nose end of plunger.
j Wrenches work on all inch and metric sizes
j Wrenches engage the front of the part without damaging the plunger or internal spring
For Plungers
PART # with Thread Sizes
WR-10 #6 WR-11 #8 and M4 WR-12 #10 and M5 WR-13 1/4 and M6 WR-14 5/16 and M8 WR-15 3/8 and M10 WR-16 1/2 and M12 WR-17 5/8 WR-18 3/4 WR-19 1"
Ball Plunger Detents
j
66
j 440C stainless steel hardened and ground
j Used as a mating detent for ball plungers
j “B” tolerance: + .002/- .0000
PART # Ball Dia. A B C
For Use With
DT-1 .062 1/8 .1075 .056 DT-15 .078 1/8 .1175 .051 DT-2 .094 3/16 .1614 .069 DT-3 .125 1/4 .2034 .111 DT-4 .156 5/16 .2559 .139 DT-5 .188 3/8 .3284 .164 DT-6 .281 1/2 .4378 .241 DT-7 .375 5/8 .5472 .330
w w w . m o r t o n m a c h i n e . c o m
Page 69
j Available in zinc-plated steel or stainless steel
j Includes nylon patch for positive holding
j Plunger can be completely withdrawn into the thread and locked into place
STANDARD LENGTH
L o c k i n g P l u n g e r s
Locking Plungers
k
Steel Stainless Steel End Pressures -.002
PART # PART # Start Full ABCDEFGHI
LP-10 LP-10SS .5 2.5 1/4-20 .156 3/8 5/8 1-5/8 1/4 5/8 3/32 1/2 LP-14 LP-14SS .75 3.0 5/16-18 .186 1/2 7/8 2-1/8 5/16 3/4 7/64 9/16 LP-11 LP-11SS .75 3.75 3/8-16 .250 9/16 1-1/16 2-9/16 3/8 15/16 9/64 11/16 LP-12 LP-12SS 1.0 5.0 1/2-13 .312 3/4 1-1/8 2-7/8 1/2 1-1/4 3/16 3/4 LP-13 LP-13SS 1.0 5.0 5/8-11 .375 1 1-3/4 4 5/8 1-5/16 3/16 1-1/16
SHORT LENGTH
teel Stainless Steel End Pressures -.002
S
ART # PART # Start Full ABCDEFGHI
P
LP-20 LP-20SS .125 .50 1/4-20 .156 3/16 7/16 15/16 1/4 17/32 3/32 1/4 LP-24 LP-24SS .25 1.0 5/16-18 .186 1/4 1/2 7/8 5/16 5/8 7/64 5/16 LP-21 LP-21SS .25 1.25 3/8-16 .250 5/16 5/8 1-7/16 3/8 3/4 9/64 3/8 LP-22 LP-22SS .50 2.0 1/2-13 .312 13/32 7/8 1-29/32 1/2 1 3/16 1/2 LP-23 LP-23SS .75 2.5 5/8-11 .375 1/2 1-1/8 2-3/8 5/8 1-3/16 3/16 5/8
+.001
.001
+
j Available in zinc plated steel and stainless steel
j Delrin®nose prevents marring of aluminum, brass or other soft materials
j Plunger can be completely retracted into the thread and locked into place
j Includes nylon patch for positive holding
Locking Plungers
Delrin®nose
STANDARD LENGTH
+.001
Steel Stainless Steel End Pressures -.002
PART # PART # Start Full ABCDEFGJ
LP-50 LP-50SS 0.5 2.5 1/4-20 .156 3/8 5/8 1-1/4 1/4 5/8 1/2 LP-54 LP-54SS 0.75 3.0 5/16-18 .186 1/2 7/8 1-5/8 5/16 3/4 9/16 LP-51 LP-51SS 0.75 3.75 3/8-16 .250 9/16 1-1/16 2” 3/8 15/16 11/16 LP-52 LP-52SS 1.0 5.0 1/2-13 .312 3/4 1-1/8 2-1/8 1/2 1-1/4 3/4 LP-53 LP-53SS 1.0 5.0 5/8-11 .375 1” 1-3/4 3” 5/8 1-5/16 1-1/16
SHORT LENGTH
+.001
Steel Stainless Steel End Pressures -.002
PART # PART # Start Full ABCDEFGJ
LP-60 LP-60SS .125 0.5 1/4-20 .156 3/16 7/16 3/4 1/4 9/16 1/4 LP-64 LP-64SS .25 1.0 5/16-18 .250 1/4 1/2 7/8 5/16 5/8 5/16 LP-61 LP-61SS .25 1.25 3/8-16 .250 5/16 5/8 1-1/8 3/8 3/4 3/8 LP-62 LP-62SS .5 2.0 1/2-13 .312 13/32 7/8 1-1/2 1/2 1” 1/2 LP-63 LP-63SS .75 2.5 5/8-11 .375 1/2 1-1/8 1-7/8 5/8 1-3/16 5/8
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
67
k
Page 70
j
P u l l R i n g P l u n g e r s
Pull Ring Plungers
tandard length
s
j Available in zinc-plated steel or stainless steel
j Used in machining applications as positioners, loading pins, indexing devices
j Standard length plunger retracts and locks completely into the body of the plunger
j Includes nylon patch for positive holding
TEEL AND STAINLESS STEEL NOSE
S
teel Stainless Steel End Pressures -.002
S
ART # PART # Start Full ABC DEFG
P
PRP-10 PRP-10SS 1.0 2.5 1/4-20 1 1/4 53/64 5/16 .156 1-9/64 PRP-11 PRP-11SS 2.0 4.0 3/8-16 1-1/4 3/8 1-1/4 7/16 .250 1-11/16 PRP-12 PRP-12SS 2.5 5.0 1/2-13 1-3/8 1/2 1-7/16 9/16 .312 2 PRP-13 PRP-13SS 3.0 6.0 5/8-11 1-1/4 .55 2-1/4 1-1/8 5/16 3.35 PRP-14 PRP-14SS 5.0 10.0 3/4-10 1-3/8 .65 2-5/8 1-7/16 7/16 4-1/16 PRP-15 PRP-15SS 8.0 20 1''-8 1-3/8 .90 3-1/4 1-3/8 11/16 4-5/8
+
.001
Pull Ring Plunger
standard length, Delrin®nose
j Available in zinc-plated steel or stainless steel
j Radiused Delrin®nose
j Delrin®prevents marring of aluminum, brass or other soft materials
j Includes nylon patch locking element
j Plunger can be withdrawn completely into body and locked in a fully retracted position
Steel Stainless Steel End Pressures (lbs.) -.002
PART # PART # Start Full ABC D E FG
PRP-60 PRP-60SS 1.0 2.5 1/4-20 1'' 1/4 13/16 5/16 .156 1-1/8 PRP-61 PRP-61SS 2.0 4.0 3/8-16 1-1/4 3/8 1-1/4 7/16 .250 1-11/16 PRP-62 PRP-62SS 2.5 5.0 1/2-13 1-3/8 1/2 1-7/16 9/16 .312 2''
+.001
j
68
w w w . m o r t o n m a c h i n e . c o m
Page 71
P u l l R i n g P l u n g e r s
j Available in zinc-plated steel or stainless steel
j Used in machining applications as positioners, loading pins, indexing devices
j Non-locking plunger
j Includes nylon patch for positive holding
.001
teel Stainless Steel End Pressures -.002 Ring
S
ART # PART # Start Full ABC D E FG HOD
P
PRP-20 PRP-20SS .50 2.00 1/4-20 7/16 3/16 .156 1/4 1/32 5/32 9/32 3/4 PRP-24 PRP-24SS .75 2.75 5/16-18 17/32 1/4 .186 5/16 3/32 3/16 23/64 3/4 PRP-21 PRP-21SS .75 3.00 3/8-16 5/8 9/32 .250 3/8 1/8 3/16 7/16 3/4 PRP-22 PRP-22SS 1.00 4.00 1/2-13 13/16 3/8 .312 1/2 5/32 1/4 9/16 1 PRP-23 PRP-23SS 1.25 5.00 5/8-11 1 7/16 .375 5/8 5/32 5/16 11/16 1 PRP-25 PRP-25SS 1.50 6.00 3/4-10 1-3/16 1/2 .437 3/4 1/4 5/16 1 1-1/8 PRP-26 PRP-26SS 1.75 7.00 1”-8 1-5/16 5/8 .500 1” 1/4 7/16 1-1/4 1-1/8
+
k
Pull Ring Plungers
short length
j Available in zinc-plated steel or stainless steel
j Radiused Delrin®nose
j Delrin®prevents marring of aluminum, brass or other soft materials
j Non-locking plunger
Steel Stainless Steel End Pressures (lbs.) -.002 Ring
PART # PART # Start Full ABC D EFG HOD
PRP-50 PRP-50SS 0.50 2.0 1/4-20 7/16 3/16 .156 1/4 1/32 5/32 9/32 3/4 PRP-54 PRP-54SS 0.75 2.75 5/16-18 17/32 1/4 .186 5/16 3/32 3/16 23/64 3/4 PRP-51 PRP-51SS 0.75 3.0 3/8-16 5/8 9/32 .250 3/8 1/8 3/16 7/16 3/4 PRP-52 PRP-52SS 1.0 4.0 1/2-13 13/16 3/8 .312 1/2 5/32 1/4 9/16 1” PRP-53 PRP-53SS 1.25 5.0 5/8-11 1” 7/16 .375 5/8 5/32 5/16 11/16 1”
+.001
Pull Ring Plunger
short length, Delrin®nose
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
69
k
Page 72
j
H a n d R e t r a c t a b l e P l u n g e r s
Hand Retractable Plungers
ocking design
l
j Available in zinc-plated steel or stainless steel
j All plungers include nylon locking element
j Available in heavy or light pressure
j Metric and inch sizes available
j Plunger can be withdrawn completely into the body and locked in a fully
retracted position
j To engage the plunger, simply turn the head to line up with the slot in body
INCH SIZES
HEAVY PRESSURE
Steel Stainless Steel Pounds -.002
PART # PART # Start Full AB CDE F
HRP-05 HRP-05SS 1 3.5 #10-32 13/32 3/32 .104 3/16 3/8 HRP-10 HRP-10SS 151/4-20 1/2 1/8 .124 1/4 1/2 HRP-20 HRP-20SS 1-1/2 6 5/16-18 5/8 3/16 .155 15/64 5/8 HRP-30 HRP-30SS 1-1/2 8 3/8-16 3/4 7/32 .186 1/4 3/4 HRP-40 HRP-40SS 2-1/2 10 1/2-13 7/8 1/4 .249 3/8 1" HRP-42 HRP-42SS 5 10 5/8-11 1” 5/16 .311 13/32 1-1/8 HRP-43 HRP-43SS 1.5 16 3/4-10 1-1/4 7/16 .375 1/2 1-1/2
End Pressure +.001
Steel Stainless Steel Pounds -.002
PART # PART # Start Full AB CDE F
HRP-50 HRP-50SS .5 2.0 #10-32 13/32 3/32 .104 3/16 3/8 HRP-60 HRP-60SS .5 2.5 1/4-20 1/2 1/8 .124 1/4 1/2 HRP-70 HRP-70SS .75 3.0 5/16-18 5/8 3/16 .155 15/64 5/8 HRP-80 HRP-80SS .75 4.0 3/8-16 3/4 7/32 .186 1/4 3/4 HRP-90 HRP-90SS 1.25 5.0 1/2-13 7/8 1/4 .249 3/8 1" HRP-92 HRP-92SS 3 6.0 5/8-11 1” 5/16 .311 13/32 1-1/8
METRIC SIZES
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-105 HRP-105SS 4.5 15.5 M5 x .8 10.3mm 2.4mm 2mm 4.7mm 9.5mm HRP-110 HRP-110SS 4.5 22 M6 x 1.0 12.5 3.17 3 6.3 12.7 HRP-120 HRP-120SS 6.5 26.5 M8 x 1.25 16 4.75 4 7.0 15.8 HRP-130 HRP-130SS 6.5 35.5 M10 x 1.5 19 5.50 5 7.9 19 HRP-140 HRP-140SS 11 45 M12 x 1.75 22 6.35 6 9.4 25.4 HRP-145 HRP-145SS 22 45 M16 x 2.0 25.4 7.92 8 10.3 28.6
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-150 HRP-150SS 29M5 x .8 10.3mm 2.4mm 2mm 4.7mm 9.5mm HRP-160 HRP-160SS 2 11 M6 x 1.0 12.5 3.17 3 6.3 12.7 HRP-170 HRP-170SS 3 13 M8 x 1.25 16 4.75 4 7.0 15.8 HRP-180 HRP-180SS 3 18 M10 x 1.5 19 5.50 5 7.9 19 HRP-190 HRP-190SS 5.5 22 M12 x 1.75 22 6.35 6 9.4 25.4 HRP-195 HRP-195SS 12 26.5 M16 x 2.0 25.4 7.92 8 10.3 28.6
End Pressure +.001
End Pressure
End Pressure
LIGHT PRESSURE
HEAVY PRESSURE
LIGHT PRESSURE
j
70
w w w . m o r t o n m a c h i n e . c o m
Page 73
j Inch and metric sizes
j Available in zinc plated steel or stainless steel
j Non-locking design
j All plungers include nylon locking element
INCH SIZES
H a n d R e t r a c t a b l e P l u n g e r s
Hand Retractable Plungers
non-locking design
k
Steel Stainless Steel Pounds -.002
PART # PART # Start Full ABCDEF
HRP-400 HRP-400SS 1.0 3.5 #10-32 13/32 3/32 .104 3/16 3/8 HRP-401 HRP-401SS 1.0 5.0 1/4-20 1/2 1/8 .124 1/4 1/2 HRP-402 HRP-402SS 1.5 6.0 5/16-18 5/8 3/16 .155 9/32 5/8 HRP-403 HRP-403SS 1.5 8.0 3/8-16 3/4 7/32 .186 5/16 3/4 HRP-404 HRP-404SS 2.5 10.0 1/2-13 7/8 1/4 .249 3/8 1 HRP-405 HRP-405SS 5.0 10.0 5/8-11 1” 5/16 .311 13/32 1-1/8 HRP-406 HRP-406SS 1.5 16.0 3/4-10 1-1/4 7/16 .375 1/2 1-1/2
Steel Stainless Steel Pounds -.002
PART # PART # Start Full ABCDEF
HRP-410 HRP-410SS 0.5 2.0 #10-32 13/32 3/32 .104 3/16 3/8 HRP-411 HRP-411SS 0.5 2.5 1/4-20 1/2 1/8 .124 1/4 1/2 HRP-412 HRP-412SS 0.75 3.0 5/16-18 5/8 3/16 .155 9/32 5/8 HRP-413 HRP-413SS 0.75 4.0 3/8-16 3/4 7/32 .186 5/16 3/4 HRP-414 HRP-414SS 1.25 5.0 1/2-13 7/8 1/4 .249 3/8 1” HRP-415 HRP-415SS 3.0 6.0 5/8-11 1” 5/16 .311 13/32 1-1/8
METRIC SIZES
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-420 HRP-420SS 4.5 15.5 M5 x .8 10.3mm 2.36mm 2mm 4.7mm 9.5mm HRP-421 HRP-421SS 4.5 22 M6 x 1.0 12.7 3.17 3 6.3 12.7 HRP-422 HRP-422SS 6.5 26.5 M8 x 1.25 15.8 4.75 4 7.0 15.8 HRP-423 HRP-423SS 6.5 35.5 M10 x 1.5 19.0 5.50 5 7.9 19.0 HRP-424 HRP-424SS 11 44.5 M12 x 1.75 22.2 6.35 6 9.4 25.4 HRP-425 HRP-425SS 22 44.5 M16 x 2.0 25.4 7.92 8 10.3 28.6
End Pressure +.001
End Pressure +.001
End Pressure
HEAVY PRESSURE
LIGHT PRESSURE
HEAVY PRESSURE
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-430 HRP-430SS 29M5 x .8 10.3mm 2.36mm 2mm 4.7mm 9.5mm HRP-431 HRP-431SS 2 11 M6 x 1.0 12.7 3.17 3 6.3 12.7 HRP-432 HRP-432SS 3 13 M8 x 1.25 15.8 4.75 4 7.0 15.8 HRP-433 HRP-433SS 3 18 M10 x 1.5 19.0 5.50 5 7.9 19.0 HRP-434 HRP-434SS 5.5 22 M12 x 1.75 22.2 6.35 6 9.4 25.4 HRP-435 HRP-435SS 13 26.5 M16 x 2.0 25.4 7.92 8 10.3 28.6
End Pressure
LIGHT PRESSURE
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
71
k
Page 74
j
H a n d R e t r a c t a b l e P l u n g e r s
Hand Retractable Plungers
locking design, Delrin®nose
j Inch and metric sizes
j Available in zinc-plated steel or stainless steel
j Radiused Delrin®nose that can be fully retracted and locked in position
j Available in heavy or light pressure
j Includes nylon pellet for positive holding
NCH SIZES
I
Steel Stainless Steel Pounds -.002
PART # PART # Start Full ABCDEF
HRP-301 HRP-301SS 1.0 5.0 1/4-20 1/2 1/8 .144 1/4 1/2 HRP-302 HRP-302SS 1.5 6.0 5/16-18 5/8 3/16 .179 9/32 5/8 HRP-303 HRP-303SS 1.5 8.0 3/8-16 3/4 7/32 .216 5/16 3/4 HRP-304 HRP-304SS 2.5 10.0 1/2-13 7/8 1/4 .310 3/8 1” HRP-305 HRP-305SS 5.0 10.0 5/8-11 1” 5/16 .373 13/32 1-1/8
Steel Stainless Steel Pounds -.002
PART # PART # Start Full ABCDEF
HRP-309 HRP-309SS 0.5 2.5 1/4-20 1/2 1/8 .144 1/4 1/2 HRP-310 HRP-310SS 0.75 3.0 5/16-18 5/8 3/16 .179 9/32 5/8 HRP-311 HRP-311SS 0.75 4.0 3/8-16 3/4 7/32 .216 5/16 3/4 HRP-312 HRP-312SS 1.25 5.0 1/2-13 7/8 1/4 .310 3/8 1” HRP-313 HRP-313SS 3.0 6.0 5/8-11 1” 5/16 .373 13/32 1-1/8
METRIC SIZES
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-321 HRP-321SS 4.5 22 M6 x 1.0 12.7mm 3.17mm 3.65mm 6.3mm 12.7mm HRP-322 HRP-322SS 6.5 26.5 M8 x 1.25 15.8 4.75 4.54 7.0 15.8 HRP-323 HRP-323SS 6.5 35.5 M10 x 1.5 19.0 5.50 5.48 7.9 19.0 HRP-324 HRP-324SS 11 44.5 M12 x 1.75 22.2 6.35 7.87 9.4 25.4 HRP-325 HRP-325SS 22 44.5 M16 x 2.0 25.4 7.92 9.47 10.3 28.6
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-331 HRP-331SS 2 11 M6 x 1.0 12.7mm 3.17mm 3.65mm 6.3mm 12.7mm HRP-332 HRP-332SS 3 13 M8 x 1.25 15.8 4.75 4.54 7.0 15.8 HRP-333 HRP-333SS 3 18 M10 x 1.5 19.0 5.50 5.48 7.9 19.0 HRP-334 HRP-334SS 5.5 22 M12 x 1.75 22.2 6.35 7.87 9.4 25.4 HRP-335 HRP-335SS 13 26.5 M16 x 2.0 25.4 7.92 9.47 10.3 28.6
End Pressure +.001
End Pressure +.001
End Pressure
End Pressure
HEAVY PRESSURE
LIGHT PRESSURE
HEAVY PRESSURE
LIGHT PRESSURE
j
72
w w w . m o r t o n m a c h i n e . c o m
Page 75
j Inch and metric sizes
j Available in zinc-plated steel or stainless steel
j Non-locking design
j Radiused Delrin®nose
j Available in light or heavy pressure
j Includes nylon pellet for positive holding
H a n d R e t r a c t a b l e P l u n g e r s
Hand Retractable Plungers
non-locking design, Delrin®nose
k
INCH SIZES
Steel Stainless Steel Pounds -.002
PART # PART # Start Full ABCDEF
HRP-340 HRP-340SS 1.0 5.0 1/4-20 1/2 1/8 .144 1/4 1/2 HRP-341 HRP-341SS 1.5 6.0 5/16-18 5/8 3/16 .179 9/32 5/8 HRP-342 HRP-342SS 1.5 8.0 3/8-16 3/4 7/32 .216 5/16 3/4 HRP-343 HRP-343SS 2.5 10.0 1/2-13 7/8 1/4 .310 3/8 1” HRP-344 HRP-344SS 5.0 10.0 5/8-11 1” 5/16 .373 13/32 1-1/8
Steel Stainless Steel Pounds -.002
PART # PART # Start Full ABCDEF
HRP-345 HRP-345SS 0.5 2.5 1/4-20 1/2 1/8 .144 1/4 1/2 HRP-346 HRP-346SS 0.75 3.0 5/16-18 5/8 3/16 .179 9/32 5/8 HRP-347 HRP-347SS 0.75 4.0 3/8-16 3/4 7/32 .216 5/16 3/4 HRP-348 HRP-348SS 1.25 5.0 1/2-13 7/8 1/4 .310 3/8 1” HRP-349 HRP-349SS 3.0 6.0 5/8-11 1” 5/16 .373 13/32 1-1/8
METRIC SIZES
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-351 HRP-351SS 4.5 22 M6 x 1.0 12.7mm 3.17mm 3.65mm 6.3mm 12.7mm HRP-352 HRP-352SS 6.5 26.5 M8 x 1.25 15.8 4.75 4.54 7.0 15.8 HRP-353 HRP-353SS 6.5 35.55 M10 x 1.50 19.0 5.50 5.48 7.9 19.0 HRP-354 HRP-354SS 11 44.5 M12 x 1.75 22.2 6.35 7.87 9.4 25.4 HRP-355 HRP-355SS 22 44.5 M16 x 2.0 25.4 7.92 9.47 10.3 28.6
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-361 HRP-361SS 2 11 M6 x 1.0 12.7mm 3.17mm 3.65mm 6.3mm 12.7mm HRP-362 HRP-362SS 3 13 M8 x 1.25 15.8 4.75 4.54 7.0 15.8 HRP-363 HRP-363SS 3 18 M10 x 1.50 19.0 5.50 5.48 7.9 19.0 HRP-364 HRP-364SS 5.5 22 M12 x 1.75 22.2 6.35 7.87 9.4 25.4 HRP-365 HRP-365SS 13 26.5 M16 x 2.0 25.4 7.92 9.47 10.3 28.6
End Pressure +.001
End Pressure +.001
End Pressure
End Pressure
HEAVY PRESSURE
LIGHT PRESSURE
HEAVY PRESSURE
LIGHT PRESSURE
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
73
k
Page 76
j
H a n d R e t r a c t a b l e P l u n g e r s
Hand Retractable Plungers
threaded adapter/locking
Locking Design
(Plunger nose can be retracted and locked in the retracted position)
j Inch and metric sizes
j Available in zinc-plated steel or stainless steel
j Just add your own knob to customize the adapter to create a hand
retractable plunger that meets your own requirements. See photos at the
ottom of this page.
b
j All plungers include nylon pellet locking element
INCH SIZES
EAVY PRESSURE
H
nd Pressure
teel Stainless Steel Pounds
S
ART # PART # Start Full AB CDEF
P
HRP-500 HRP-500SS 1.0 3.0 #10-32 13/32 3/32 .104 #10-32 15/64 HRP-501 HRP-501SS 1.0 5.0 1/4-20 1/2 1/8 .124 #10-32 15/64 HRP-502 HRP-502SS 1.5 6.0 5/16-18 5/8 3/16 .155 1/4-20 11/32 HRP-503 HRP-503SS 1.5 8.0 3/8-16 3/4 7/32 .186 5/16-18 13/32 HRP-504 HRP-504SS 2.5 10.0 1/2-13 7/8 1/4 .249 3/8-16 7/16 HRP-505 HRP-505SS 5.0 10.0 5/8-11 1” 5/16 .311 1/2-13 7/16
teel Stainless Steel Pounds
S
ART # PART # Start Full AB CDEF
P
HRP-510 HRP-510SS 0.5 1.5 #10-32 13/32 3/32 .104 #10-32 15/64 HRP-511 HRP-511SS 0.5 2.5 1/4-20 1/2 1/8 .124 #10-32 15/64 HRP-512 HRP-512SS 0.75 3.0 5/16-18 5/8 3/16 .155 1/4-20 11/32 HRP-513 HRP-513SS 0.75 4.0 3/8-16 3/4 7/32 .186 5/16-18 13/32 HRP-514 HRP-514SS 1.25 5.0 1/2-13 7/8 1/4 .249 3/8-16 7/16 HRP-515 HRP-515SS 3.0 6.0 5/8-11 1” 5/16 .311 1/2-13 7/16
E
nd Pressure
E
LIGHT PRESSURE
k
Just add your
own knob.
j
METRIC SIZES
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-550 HRP-550SS 4.5 15.5 M5 x .8 10.3mm 2.36mm 2mm 10-32 5.9mm HRP-551 HRP-551SS 4.5 22 M6 x 1.0 12.7 3.17 3 10-32 5.9 HRP-552 HRP-552SS 6.5 26.5 M8 x 1.25 15.8 4.75 4 1/4-20 8.7 HRP-553 HRP-553SS 6.5 35.5 M10 x 1.50 19 5.5 5 5/16-18 10.3 HRP-554 HRP-554SS 11 44.5 M12 x 1.75 22.2 6.35 6 3/8-16 11.1 HRP-555 HRP-555SS 22 44.5 M16 x 2.0 25.4 7.92 8 1/2-13 11.1
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-560 HRP-560SS 29 M5 x .8 10.3mm 2.36mm 2mm 10-32 5.9mm HRP-561 HRP-561SS 2 11 M6 x 1.0 12.7 3.17 3 10-32 5.9 HRP-562 HRP-562SS 3 13 M8 x 1.25 15.8 4.75 4 1/4-20 8.7 HRP-563 HRP-563SS 3 18 M10 x 1.50 19 5.5 5 5/16-18 10.3 HRP-564 HRP-564SS 5.5 22 M12 x 1.75 22.2 6.35 6 3/8-16 11.1 HRP--565 HRP-565SS 13 26.5 M16 x 2.0 25.4 7.92 8 1/2-13 11.1
End Pressure
End Pressure
HEAVY PRESSURE
LIGHT PRESSURE
j
74
w w w . m o r t o n m a c h i n e . c o m
Page 77
H a n d R e t r a c t a b l e P l u n g e r s
j Inch and metric sizes
j Available in zinc-plated steel or stainless steel
j Just add your own knob to customize the adapter to create a hand retractable
plunger that meets your requirements. See photos at the bottom of page 72.
j All plungers include nylon pellet locking element
NCH SIZES
I
k
Hand Retractable Plungers
threaded adapter/non-locking
Steel Stainless Steel Pounds
PART # PART # Start Full ABCDEF
HRP-520 HRP-520SS 1.0 3.0 #10-32 13/32 3/32 .104 #10-32 15/64 HRP-521 HRP-521SS 1.0 5.0 1/4-20 1/2 1/8 .124 #10-32 15/64 HRP-522 HRP-522SS 1.5 6.0 5/16-18 5/8 3/16 .155 1/4-20 11/32 HRP-523 HRP-523SS 1.5 8.0 3/8-16 3/4 7/32 .186 5/16-18 13/32 HRP-524 HRP-524SS 2.5 10.0 1/2-13 7/8 1/4 .249 3/8-16 7/16 HRP-525 HRP-525SS 5.0 10.0 5/8-11 1” 5/16 .311 1/2-13 7/16
Steel Stainless Steel Pounds
PART # PART # Start Full ABCDEF
HRP-530 HRP-530SS 0.5 1.5 #10-32 13/32 3/32 .104 #10-32 15/64 HRP-531 HRP-531SS 0.5 2.5 1/4-20 1/2 1/8 .124 #10-32 15/64 HRP-532 HRP-532SS 0.75 3.0 5/16-18 5/8 3/16 .155 1/4-20 11/32 HRP-533 HRP-533SS 0.75 4.0 3/8-16 3/4 7/32 .186 5/16-18 13/32 HRP-534 HRP-534SS 1.25 5.0 1/2-13 7/8 1/4 .249 3/8-16 7/16 HRP-535 HRP-535SS 3.0 6.0 5/8-11 1” 5/16 .311 1/2-13 7/16
METRIC SIZES
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-570 HRP-570SS 4.5 15.5 M5 x .8 10.3mm 2.36mm 2mm 10-32 5.9mm HRP-571 HRP-571SS 4.5 22 M6 x1.0 12.7 3.17 3 10-32 5.9 HRP-572 HRP-572SS 6.5 26.5 M8 x 1.25 15.8 4.75 4 1/4-20 8.7 HRP-573 HRP-573SS 6.5 35.5 M10 x 1.50 19 5.5 5 5/16-18 10.3 HRP-574 HRP-574SS 11 44.5 M12 x 1.75 22.2 6.35 6 3/8-16 11.1 HRP-575 HRP-575SS 22 44.5 M16 x 2.0 25.4 7.92 8 1/2-13 11.1
Steel Stainless Steel Newtons
PART # PART # Start Full ABCDEF
HRP-580 HRP-580SS 29 M5 x .8 10.3mm 2.36mm 2mm 10-32 5.9mm HRP-581 HRP-581SS 2 11 M6 x 1.0 12.7 3.17 3 10-32 5.9 HRP-582 HRP-582SS 3 13 M8 x 1.25 15.8 4.75 4 1/4-20 8.7 HRP-583 HRP-583SS 3 18 M10 x 1.50 19 5.5 5 5/16-18 10.3 HRP-584 HRP-584SS 5.5 22 M12 x 1.75 22.2 6.35 6 3/8-16 11.1 HRP--585 HRP-585SS 13 26.5 M16 x 2.0 25.4 7.92 8 1/2-13 11.1
End Pressure
End Pressure
End Pressure
End Pressure
HEAVY PRESSURE
LIGHT PRESSURE
HEAVY PRESSURE
LIGHT PRESSURE
Non-Locking Design
(Plunger nose cannot be retracted and locked without manually pulling back and holding in the retracted position)
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
75
k
Page 78
j
I n d e x i n g P l u n g e r s
Indexing Plungers
metric
j Black matte plastic knob
j Steel parts with black oxide finish
j Plunger is hardened and precision ground
j Type A: Non-locking, without locking nut
j Type B: Non-locking, with locking nut
j Type C: Locking, without locking nut
j Type D: Locking, with locking nut
Type A Type B Type C Type D
ART # PART # PART # PART # Size d
P
d
1
2
d
e
3
3005A 3005B 3005C 3005D 5 M10 x 1 21 13,8 44 5 17 5 15 49 12 3006A 3006B 3006C 3006D 6 M12 x 1.5 25 16,2 53 6 20 6 17 59 14 3008A 3008B 3008C 3008D 8 M16 x 1.5 31 21,9 67 8 26 8 23 73.5 19 3010A 3010B --10 M20 x 1.5 31 25,4 78 10 33 10 30 - 22 3037A 3037B 3037C 3037D .20 3/8-24 .83 .54 1.73 .20 .67 .20 .59 -­3050A 3050B 3050C 3050D .24 1/2-13 .98 .64 2.09 .24 .79 .24 .67 -­3062A 3062B 3062C 3062D .31 5/8-11 1.22 .86 2.64 .31 1.02 .31 .91 --
l
1l2
in. l
m
l
l
3
4
l6m
5
Stainless Steel Indexing Plungers
metric
in. SW
j Black matte plastic knob
j Stainless steel parts
j Plunger is precision ground and nitrated
j Type A: Non-locking, without locking nut
j Type B: Non-locking, with locking nut
j Type C: Locking, without locking nut
j Type D: Locking, with locking nut
Type A Type B Type C Type D
PART # PART # PART # PART # Size d
3005ASS 3005BSS 3005CSS 3005DSS 5 M10 x 1 21 13,8 44 5 17 5 15 49 12 3006ASS 3006BSS 3006CSS 3006DSS 6 M12 x 1.5 25 16,2 53 6 20 6 17 59 14 3008ASS 3008BSS 3008CSS 3008DSS 8 M16 x 1.5 31 21,9 67 8 26 8 23 73.5 19 3010ASS 3010BSS --10 M20 x 1.5 31 25,4 78 10 33 10 30 - 22
j
76
d
1
2
d
el1l2min. l
3
l
3
l
4
5
w w w . m o r t o n m a c h i n e . c o m
l6min. SW
Page 79
j Black matte plastic knob
j Available in steel with black oxide finish and
stainless steel
j Plunger is hardened and precision ground
j Type A: Without locking nut
j Type B: With locking nut
ype A Type B Type A Type B
T
teel Steel Stainless Steel Stainless Steel
S
ART # PART # Part # PART # d
P
1
5905A 5905B 5905SS 5905BSS 5 M10 x 1 21 44 5 22 5906A 5906B 5906SS 5906BSS 6 M12 x 1.5 25 53 6 26 5908A 5908B 5908SS 5908BSS 8 M16 x 1.5 31 67 8 34 5910A 5910B 5910SS 5910BSS 10 M20 x 1.5 31 78 10 43
d
2
d
l
3
l
1
2
I n d e x i n g P l u n g e r s
Indexing Plungers
metric without collar
l
3
k
j Black matte plastic knob
j Available with or without knob
j Steel parts, black oxide finish
j Type A: With knob
j Type B: Without knob
Type A Type B
PART # PART # d
5805A 5805G 5 12 M5 44 5 22 6 5806A 5806G 6 14 M6 53 6 26 10 5808A 5808G 8 18 M8 67 8 34 12
d
1
d
2
l
4
l
1
2
Indexing Plungers
metric without threads
l
l
3
4
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
77
k
Page 80
j
L o c a t i n g P i n s
Bullet Nose Dowels
Bullet Nose Pins
j Material: 1144 steel
j Hardness: HRC 61-65
j Black oxide finish
j Tolerances: A = +.0000 / -.0005
B = +.003 / -.003
PART # ABCDEF G
P-1025 .2499 .2516 .280 .500 .125 .907 .125 P-1031 .3124 .3141 .344 .500 .157 .939 .156 P-1037 .3749 .3766 .407 .500 .187 1.032 .187 P-1050 .4999 .5017 .532 .500 .187 1.094 .250
j Material: 1144 steel
j Hardness: HRC 61-65
j Black oxide finish
j Tolerances: A = +.0000 / -.0005
B = +.003 / -.003
Bullet Nose Pins
relieved
PART # ABCDEFG
P-2025 .2499 .4078 3/8 21/32 7/32 9/16 1/16 P-2031 .3124 .5017 3/8 23/32 9/32 5/8 1/16 P-2037 .3748 .6267 1/2 7/8 5/16 3/4 1/16 P-2050 .4998 .7518 1/2 31/32 13/32 7/8 1/16 P-2075 .7498 1.0018 3/4 1-7/16 9/16 1-1/8 1/8 P-2100 .9998 1.3771 3/4 1-5/8 3/4 1-1/2 1/8
j Material: 1144 steel
j Hardness: HRC 61-65
j Black oxide finish
j Tolerances: A = +.0000 / -.0005
B = +.003 / -.003
PART # ABCDEFG
P-3025 .2499 .4078 3/8 21/32 7/32 9/16 1/16 P-3031 .3124 .5017 3/8 23/32 9/32 5/8 1/16 P-3037 .3748 .6267 1/2 7/8 5/16 3/4 1/16 P-3050 .4998 .7518 1/2 31/32 13/32 7/8 1/16 P-3075 .7498 1.0018 3/4 1-7/16 9/16 1-1/8 1/8 P-3100 .9998 1.3771 3/4 1-5/8 3/4 1-1/2 1/8
j
78
w w w . m o r t o n m a c h i n e . c o m
Page 81
j Application: Bullet nose pins are frequently used in aligning fixtures together by mating the pins within the liners at a precise location.
j Material: 1144 steel
j Hardness: HRC 61-65
j Black oxide finish
j Tolerances: ID (A) = +.0004 / -.0000
OD (B) = +.0000 / -.0005
L i n e r s
k
Bullet Nose Dowel Liners
PART # A D B C
PL-1025 .2501 .5017 3/8 5/8 PL-1031 .3126 .5017 3/8 5/8 PL-1037 .3751 .6267 1/2 3/4 PL-1050 .5001 .7518 5/8 7/8
j Material: 1144 steel
j Hardness: HRC 61-65
j Black oxide finish
j Tolerances: ID (A) = +.0004 / -.0000
OD (B) = +.0000 / -.0005
Bullet Nose Pin Liners
PART # ABCDG
PL-2025 .2501 .4078 9/16 7/16 1/16 PL-2031 .3126 .5017 5/8 7/16 1/16 PL-2037 .3751 .6267 3/4 1/2 1/16 PL-2050 .5001 .7518 7/8 1/2 1/16 PL-2075 .7502 1.0018 1-1/8 1/2 1/8 PL-2100 1.0002 1.3771 1-1/2 11/16 1/8
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
79
k
Page 82
j
T o o l i n g B a l l s
Tooling Balls
Tooling Balls
with shoulder
j Ball and shank are concentric within 0.0002 T.I.R.
j
When ordering, please specify either slip fit or
press fit
j Press fit + .0003 - .0000 shank “P”
j Slip fit + .0000 - .0004 shank “S”
j Rc 55-60
j Used as precise reference points in critical
machining applications
j Ball and shank are concentric within
0.0002 T.I.R.
j When ordering, please specify either slip fit or press fit
j Press fit + .0003 - .0000 shank
j Slip fit + .0000 - .0004 shank
j Rc 55-60
j Used as precise reference points in
critical machining applications
1448-4P .2500 .1250 .56 .200 1448-4S .2500 .1250 .56 .200 1448-6P .3750 .1875 .75 .300 1448-6S .3750 .1875 .75 .300 1448-8P .5000 .2500 .94 .400 1448-8S .5000 .2500 .94 .400 1448-12P .5000 .2500 1.375 .500 1448-12S .5000 .2500 1.375 .500 1448-14P .5000 .3125 1.500 .500 1448-14S .5000 .3125 1.500 .500 1448-10P .7500 .3750 1.25 .500 1448-10S .7500 .3750 1.25 .500
ART # AB C
P
1224-4P .2500 .1250 .5625 1224-4S .2500 .1250 .5625 1224-6P .3750 .1875 .750 1224-6S .3750 .1875 .750 1224-8P .5000 .2500 .9375 1224-8S .5000 .2500 .9375 1224-10P .5000 .2500 1.500 1224-10S .5000 .2500 1.500 1224-12P .5000 .3125 1.500 1224-12S .5000 .3125 1.500 1224-14P .5000 .3750 1.500 1224-14S .5000 .3750 1.500
PART # AB CD
Hex Head Rest Buttons
j
80
j Case hardened steel, black oxide finish
j “B” dimension…+.012-.003
j Head thickness can be held to
+.0005-.0000 if required. Prices available upon request.
PART # AB C D
SRB-3725 3/8 1/4 3/8 1/4-20 SRB-3737 3/8 3/8 3/8 1/4-20 SRB-3750 3/8 1/2 3/8 1/4-20 SRB-3775 3/8 3/4 3/8 1/4-20 SRB-3710 3/8 1" 3/8 1/4-20 SRB-5025 1/2 1/4 1/2 3/8-16 SRB-5037 1/2 3/8 1/2 3/8-16 SRB-5050 1/2 1/2 1/2 3/8-16 SRB-5075 1/2 3/4 1/2 3/8-16 SRB-5010 1/2 1" 1/2 3/8-16 SRB-6225 5/8 1/4 5/8 1/2-13 SRB-6237 5/8 3/8 5/8 1/2-13 SRB-6250 5/8 1/2 5/8 1/2-13 SRB-6262 5/8 5/8 5/8 1/2-13 SRB-6275 5/8 3/4 5/8 1/2-13 SRB-6210 5/8 1" 5/8 1/2-13
Hex Thread
w w w . m o r t o n m a c h i n e . c o m
Page 83
.0000 +.001
+
.0005 -.000
ART # AB CD
P
RB-1881 .1885 3/8 .250 3/8 RB-1882 .1885 3/8 .375 3/8 RB-1883 .1885 3/8 .500 3/8 RB-141 .2510 1/2 .250 1/2 RB-142 .2510 1/2 .375 1/2 RB-143 .2510 1/2 .500 1/2 RB-381 .3760 5/8 .250 5/8 RB-382 .3760 5/8 .375 5/8 RB-1 .3760 11/16 .4375 11/16 RB-383 .3760 5/8 .500 5/8 RB-384 .3760 5/8 .625 5/8 RB-385 .3760 5/8 .750 5/8 RB-2 .3805 11/16 .375 11/16 RB-5001 .5010 5/8 .375 7/8 RB-3 .5010 13/16 .4375 7/8 RB-5003 .5010 5/8 .500 7/8 RB-5004 .5010 5/8 .625 7/8 RB-5005 .5010 5/8 .750 7/8 RB-4 .5055 13/16 .4375 7/8 RB-6251 .6260 3/4 .375 1 RB-5 .6260 15/16 .4375 1-1/16 RB-6253 .6260 3/4 .500 1 RB-6254 .6260 3/4 .625 1 RB-6255 .6260 3/4 .750 1 RB-6 .6305 15/16 .4375 1-1/16 RB-7501 .7515 7/8 .375 1-1/4 RB-7502 .7515 7/8 .4375 1-1/4 RB-7503 .7515 7/8 .500 1-1/4 RB-7 .7515 7/8 .625 1-1/4 RB-8 1.0010 1-1/4 .750 1-5/8
-
j Press fit design
j Case hardened carbon steel
j Black oxide finish
j Precision ground
R e s t B u t t o n s
Rest Buttons
k
j Machined from 416 stainless steel
j Press fit design
j Rest buttons are magnetic
PART # AB C D E
2375 1/2 1/4 3/16 3/8 1/4 2376 5/8 1/4 3/16 3/8 3/8 2377 3/4 1/4 3/16 3/8 1/2 2503 9/16 5/16 1/4 1/2 1/4 2504 11/16 5/16 1/4 1/2 3/8 2505 13/16 5/16 5/16 1/2 1/2 2506 1-1/16 5/16 5/16 1/2 3/4 2507 1-5/16 5/16 5/16 1/2 1
j Case hardened, black oxide finish
j RP-10 has 2 holes
j RP-20 has 4 holes 1" apart
j “D” dimension…+.005-.005
j Holes designed for 3/8" socket head shoulder screw
PART # ABCD
RP-10 2-3/8 1" 1" 1-5/8 RP-20 3-3/8 2" 2" 2-5/8
Stainless Steel Rest Buttons
Rest Pads
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
81
k
Page 84
j
B a l l S e t S c r e w s
Ball Set Screws
rolling ball design
Steel Ball Set Screws
j Screw: heat treated steel, black oxide finish
j Ball: ball bearing steel, hardened
Stainless Steel Ball Set Screws
j Screw: 18-8 Series stainless steel
j Ball: hardened stainless steel
olling
R
Ball
Steel Stainless Steel
PART # PART # M (Thread) L d1 SBC
9530 9530SS 1/4-20 .500 .157 .051 .125 .120 9531 9531SS 1/4-20 .750 .157 .051 .125 .120 9532 9532SS 5/16-18 .750 .216 .061 .157 .151 9533 9533SS 5/16-18 1.000 .216 .061 .157 .151 9534 9534SS 3/8-16 .750 .275 .071 .196 .182 9535 9535SS 3/8-16 1.000 .275 .071 .196 .182 9536 9536SS 1/2-13 1.000 .334 .122 .250 .245 9537 9537SS 1/2-13 1.500 .334 .122 .250 .245 9538 9538SS 5/8-11 1.000 .472 .142 .315 .307 9539 9539SS 5/8-11 1.500 .472 .142 .315 .307
Ball Set Screws
flat tip design
Steel Ball Set Screws
j Screw: heat treated steel, black oxide finish
j Ball: ball bearing steel, hardened
Stainless Steel Ball Set Screws
j Screw: 18-8 Series stainless steel
j Ball: hardened stainless steel
Flat
Swivel
Tip
Steel Stainless Steel
PART # PART # M (Thread) L d2 S1 BC
9510 9510SS 1/4-20 .500 .120 .023 .125 .120 9511 9511SS 1/4-20 .750 .120 .023 .125 .120 9512 9512SS 5/16-18 .750 .147 .032 .157 .151 9513 9513SS 5/16-18 1.000 .147 .032 .157 .151 9514 9514SS 3/8-16 .750 .192 .032 .196 .182 9515 9515SS 3/8-16 1.000 .192 .032 .196 .182 9516 9516SS 1/2-13 1.000 .290 .038 .250 .245 9517 9517SS 1/2-13 1.500 .290 .038 .250 .245 9518 9518SS 5/8-11 1.000 .372 .051 .315 .307 9519 9519SS 5/8-11 1.500 .372 .051 .315 .307
j
82
w w w . m o r t o n m a c h i n e . c o m
Page 85
B a l l C l a m p i n g S c r e w s
olling
R
Ball
Steel Stainless Steel
PART # PART # M (Thread) L d1 SABECL1
9829 9829SS 1/4-20 .500 .157 .051 .375 .187 .250 .120 .059 9830 9830SS 1/4-20 .750 .157 .051 .375 .187 .250 .120 .059 9831 9831SS 1/4-20 1.000 .157 .051 .375 .187 .250 .120 .059 9832 9832SS 5/16-18 .750 .216 .061 .468 .250 .312 .151 .059 9841 9841SS 5/16-18 1.000 .216 .061 .468 .250 .312 .151 .059 9833 9833SS 5/16-18 1.250 .216 .061 .468 .250 .312 .151 .059 9842 9842SS 3/8-16 .750 .275 .071 .562 .312 .375 .182 .078 9834 9834SS 3/8-16 1.000 .275 .071 .562 .312 .375 .182 .078 9835 9835SS 3/8-16 1.500 .275 .071 .562 .312 .375 .182 .078 9836 9836SS 1/2-13 1.000 .334 .122 .750 .375 .500 .245 .137 9837 9837SS 1/2-13 1.500 .334 .122 .750 .375 .500 .245 .137 9843 9843SS 5/8-11 1.000 .472 .142 .937 .500 .625 .307 .157 9838 9838SS 5/8-11 1.500 .472 .142 .937 .500 .625 .307 .157 9839 9839SS 5/8-11 2.000 .472 .142 .937 .500 .625 .307 .157
k
Ball Clamping Screws
rolling ball design
Steel Ball Clamping Screws
j Screw: heat treated steel, black oxide finish
j Ball: ball bearing steel, hardened
Stainless Steel Ball Clamping Screws
j Screw: 18-8 Series stainless steel
j Ball: hardened stainless steel
Flat
Swivel
Tip
Steel Stainless Steel
PART # PART # M (Thread) L d2 S1 ABECL1
9809 9809SS 1/4-20 .500 .120 .023 .375 .187 .250 .120 .059 9810 9810SS 1/4-20 .750 .120 .023 .375 .187 .250 .120 .059 9811 9811SS 1/4-20 1.000 .120 .023 .375 .187 .250 .120 .059 9812 9812SS 5/16-18 .750 .147 .032 .468 .250 .312 .151 .059 9821 9821SS 5/16-18 1.000 .147 .032 .468 .250 .312 .151 .059 9813 9813SS 5/16-18 1.250 .147 .032 .468 .250 .312 .151 .059 9822 9822SS 3/8-16 .750 .192 .032 .562 .312 .375 .182 .078 9814 9814SS 3/8-16 1.000 .192 .032 .562 .312 .375 .182 .078 9815 9815SS 3/8-16 1.500 .192 .032 .562 .312 .375 .182 .078 9816 9816SS 1/2-13 1.000 .290 .038 .750 .375 .500 .245 .137 9817 9817SS 1/2-13 1.500 .290 .038 .750 .375 .500 .245 .137 9823 9823SS 5/8-11 1.000 .372 .051 .937 .500 .625 .307 .157 9818 9818SS 5/8-11 1.500 .372 .051 .937 .500 .625 .307 .157 9819 9819SS 5/8-11 2.000 .372 .051 .937 .500 .625 .307 .157
Ball Clamping Screws
flat tip design
Steel Ball Set Screws
j Screw: heat treated steel, black oxide finish
j Ball: ball bearing steel, hardened
Stainless Steel Ball Set Screws
j Screw: 18-8 Series stainless steel
j Ball: hardened stainless steel
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
83
k
Page 86
j
B a l l C l a m p i n g S c r e w s
Ball Clamping Screws
metric
j
Rolling Ball Design
j
Flat Tip Design
Steel Ball Set Screws
j Screw: heat treated steel, black oxide finish
Ball: ball bearing steel, hardened
j
OLLING BALL DESIGN
R
FLAT TIP DESIGN
Rolling
all
B
Flat
Swivel
Tip
teel Stainless Steel
S
ART # PART # M (Thread) L d1 SBC
P
470610A 470610AN M6 x 1.0 10mm 4mm .8mm 3mm 3mm 470620A 470620AN M6 x 1.0 20 4 .8 33 470810A 470810AN M8 x 1.25 10 5.5 1.2 44 470820A 470820AN M8 x 1.25 20 5.5 1.2 44 471012A 471012AN M10 x 1.50 12 7 1.7 55 471020A 471020AN M10 x 1.50 20 7 1.7 55 471216A 471216AN M12 x 1.75 16 8.5 266 471620A 471620AN M16 x 2.0 20 12 3.3 88
Steel Stainless Steel
PART # PART # M (Thread) L d1 SBC
470610B 470610BN M6 x 1.0 10mm 4mm .8mm 3mm 3mm 470620B 470620BN M6 x 1.0 20 4 .8 33 470810B 470810BN M8 x 1.25 10 5.5 1.2 44 470820B 470820BN M8 x 1.25 20 5.5 1.2 44 471012B 471012BN M10 x 1.50 12 7 1.7 55 471020B 471020BN M10 x 1.50 20 7 1.7 55 471216B 471216BN M12 x 1.75 16 8.5 266 471620B 471620BN M16 x 2.0 20 12 3.3 88
Stainless Steel Ball Set Screws
j Screw: 18-8 Series stainless steel
j Ball: hardened stainless steel
Nose Clamps
metric
j Available with brass or plastic nose pad to prevent marks or damage to contact surface.
j Steel screw with black oxide finish
PART # XLABC
BP-0410 M4 x .7 10mm 2.5mm .5mm 2mm BP-0416 M4 x .7 16 2.5 .5 2 BP-0512 M5 x .8 10 3 .5 2.5 BP-0520 M5 x .8 20 3 .5 2.5 BP-0620 M6 x 1.0 20 4 1.0 3 BP-0632 M6 x 1.0 32 4 1.0 3 BP-0820 M8 x 1.25 20 6 1.5 4 BP-0840 M8 x 1.25 50 6 1.5 4 BP-1020 M10 x 1.5 20 82 5 BP-1040 M10 x 1.5 50 82 5 BP-1225 M12 x 1.75 25 10 26 BP-1250 M12 x 1.75 50 10 26
BRASS NOSE
PART # XLABC
PP-0410 M4 x .7 10mm 2mm 1mm 2mm PP-0416 M4 x .7 16 21 2 PP-0512 M5 x .8 12 31 2.5 PP-0520 M5 x .8 20 31 2.5 PP-0620 M6 x 1.0 20 3.5 1.3 3 PP-0632 M6 x 1.0 32 3.5 1.3 3 PP-0820 M8 x 1.25 20 5 1.6 4 PP-0840 M8 x 1.25 40 5 1.6 4 PP-1020 M10 x 1.5 20 6.5 1.9 5 PP-1040 M10 x 1.5 40 6.5 1.9 5 PP-1225 M12 x 1.75 25 8 2.1 6 PP-1250 M12 x 1.75 50 8 2.1 6
PLASTIC NOSE
j
84
w w w . m o r t o n m a c h i n e . c o m
Page 87
F i x t u r e K e y s
k
j Case hardened, black oxide finish
j Precision ground
j “A” dimension…+.000-.001
PART # ABCDE
K-10 .500 1/4 3/4 1/2 1/4 K-15 .5625 9/32 3/4 1/2 1/4 K-20 .625 5/16 3/4 1/2 5/16 K-30 .6875 11/32 1 1/2 5/16 K-40 .750 3/8 1-1/4 1/2 5/16 K-50 .8125 13/32 1-1/4 1/2 5/16
j Case hardened, black oxide finish
j Precision ground
For Screw
j “B” dimension...+.000-.001
j “C” dimension...+.000-.001
j “A” dimension...+.000-.001
ART # ABCDE
P
SK-5 .4375 .5625 .5625 1/2 10-24 SK-10 .500 .625 .625 1/2 1/4 SK-15 .5625 .6875 .6875 1/2 1/4 SK-20 .625 .750 .750 1/2 5/16 SK-30 .6875 .8125 .8125 1/2 5/16
Plain Fixture Keys
Fixture Step Keys
j Case hardened, black oxide finish
j Machined from low carbon steel
PART # ABCDEFGH J
GB-1 3/16 13/16 3/4 7/16 3/16 7/16 3/16 5/16 #5 Fil Hd GB-2 1/4 1-1/8 1 5/8 1/4 5/8 5/16 1/2 #10 Fil Hd GB-3 5/16 1-1/2 1-3/8 7/8 5/16 7/8 3/8 5/8 1/4-20 Fil Hd GB-4 3/8 1-5/8 1-1/2 1 3/8 7/8 3/8 5/8 1/4-20 Fil Hd GB-5 1/2 1-5/8 1-1/2 1 3/8 7/8 3/8 5/8 1/4-20 Fil Hd
Screw Size
j Case hardened, black oxide finish
j Precision ground
j “A” dimension...+.001-.000
PART # AB C
BJF-250 .250 5/8 #10-Flat BJF-375 .375 5/8 #10-Flat BJF-500 .500 5/8 #10-Flat BJF-625 .625 5/8 #10-Flat BJF-750 .750 5/8 #10-Flat BJF-875 .875 5/8 #10-Flat BJF-1000 1.000 5/8 #10-Flat BJF-3750 .375 7/8 5/16 BJF-5000 .500 7/8 5/16 BJF-6250 .625 7/8 5/16 BJF-7500 .750 7/8 5/16 BJF-8750 .875 7/8 5/16
PART # ABC
BJF-10000 1.000 7/8 5/16 BJF-11250 1.125 7/8 5/16 BJF-7501 .750 1-1/4 3/8 BJF-8751 .875 1-1/4 3/8 BJF-10001 1.000 1-1/4 3/8 BJF-15000 1.500 1-1/4 3/8 BJF-20000 2.000 1-1/4 3/8 BJF-75 .750 1-3/8 1/2 BJF-100 1.000 1-3/8 1/2 BJF-1250 1.250 1-3/8 1/2 BJF-1750 1.750 1-5/8 1/2 BJF-2250 2.250 1-5/8 1/2
Guide Blocks
Button Jig Feet
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
85
k
Page 88
j
T h u m b S c r e w s
Precision Thumb Screws
with shoulder
j Precision thumb screw for a wide variety of applications
j 303 stainless steel or carbon steel with black oxide finish
j Diamond knurl
j Shoulder provides an excellent bearing surface
j Inch and metric sizes available
Steel Stainless Steel Thread
PART # PART # ADB C E F
3101 4101 #4-40 1/4 3/8 1/4 3/16 3/32 3102 4102 #4-40 3/8 3/8 1/4 3/16 3/32 3251 4251 #4-40 7/16 3/8 1/4 3/16 3/32
- 4075 #4-40 1/2 3/8 1/4 3/16 3/32 3252 4252 #6-32 3/8 7/16 3/8 5/16 3/32 3202 4202 #6-32 7/16 7/16 3/8 5/16 3/32 3253 4253 #6-32 1/2 7/16 3/8 5/16 3/32 3204 4204 #6-32 9/16 7/16 3/8 5/16 3/32 3205 4205 #8-32 5/16 7/16 3/8 5/16 3/32 3206 4206 #8-32 3/8 7/16 3/8 5/16 3/32 3207 4207 #8-32 7/16 7/16 3/8 5/16 3/32 3208 4208 #8-32 1/2 7/16 3/8 5/16 3/32 3209 4209 #8-32 9/16 7/16 3/8 5/16 3/32 3301 4301 #8-32 5/16 1/2 3/8 5/16 3/32 3302 4302 #8-32 3/8 1/2 3/8 5/16 3/32 3303 4303 #8-32 7/16 1/2 3/8 5/16 3/32 3304 4304 #8-32 1/2 1/2 3/8 5/16 3/32 3305 4305 #8-32 5/8 1/2 3/8 5/16 3/32 3401 4401 #10-32 5/16 1/2 3/8 5/16 3/32 3402 4402 #10-32 3/8 1/2 3/8 5/16 3/32 3403 4403 #10-32 7/16 1/2 3/8 5/16 3/32 3404 4404 #10-32 1/2 1/2 3/8 5/16 3/32 3405 4405 #10-32 9/16 1/2 3/8 5/16 3/32 3406 4406 #10-32 5/8 1/2 3/8 5/16 3/32 3076 4076 #10-32 3/4 1/2 3/8 5/16 3/32 3407 4407 1/4-20 1/2 1/2 3/8 3/8 1/8 3408 4408 1/4-20 5/8 1/2 3/8 3/8 1/8 3409 4409 1/4-20 3/4 1/2 3/8 3/8 1/8 3412 - 1/4-20 1'' 1/2 3/8 3/8 1/8
INCH
j
86
Stainless Steel Thread
PART # ADBCEF
4601 M3 x .5 8mm 9.5mm 6.4mm 7.9mm 2.3mm 4602 M3 x .5 11 9.5 6.4 7.9 2.3 4603 M3 x .6 9 9.5 6.4 7.9 2.3 4604 M3 x .6 13 9.5 6.4 7.9 2.3 4605 M4 x .7 9 11.1 9.5 7.9 2.3 4606 M4 x .7 13 11.1 9.5 7.9 2.3 4607 M5 x .8 9 11.1 9.5 7.9 2.3 4608 M5 x .8 16 11.1 9.5 7.9 2.3 4609 M6 x 1.0 9 12.7 9.5 9.5 3.2 4610 M6 x 1.0 13 12.7 9.5 9.5 3.2 4611 M6 x 1.0 19 12.7 9.5 9.5 3.2
METRIC
w w w . m o r t o n m a c h i n e . c o m
Page 89
T h u m b S c r e w s
k
j 303 stainless steel
j Diamond knurl
j Inch and metric sizes available
NCH
ART # A D B C
P
4113 #4-40 5/16 5/16 3/16 4114 #4-40 3/8 5/16 3/16 4119 #4-40 1/2 5/16 3/16 4525 #6-32 5/16 5/16 3/16 4124 #6-32 3/8 5/16 3/16 4127 #6-32 1/2 5/16 3/16 4526 #6-32 5/8 5/16 3/16 4128 #6-32 3/8 3/8 3/16 4218 #8-32 3/8 3/8 3/16 4222 #8-32 1/2 3/8 3/16 4224 #8-32 5/8 3/8 3/16 4226 #8-32 3/4 3/8 3/16 4312 #10-24 3/4 3/8 3/16 4318 #10-24 3/4 1/2 3/16 4324 #10-24 3/4 3/4 3/16 4358 #10-32 3/8 7/16 3/16 4460 #10-32 1/2 3/8 3/16 4361 #10-32 1/2 7/16 3/16 4362 #10-32 5/8 7/16 3/16 4363 #10-32 3/4 7/16 3/16 4364 #10-32 3/4 1/2 3/16 4372 #10-32 3/4 3/4 3/16 4368 #10-32 1-1/4 1/2 3/16 4376 #10-32 1-1/4 3/4 3/16 4527 1/4-20 1/2 3/4 3/16 4528 1/4-20 5/8 3/4 3/16 4412 1/4-20 3/4 3/4 3/16 4414 1/4-20 1 3/4 3/16 4416 1/4-20 1-1/4 3/4 3/16 4418 1/4-20 1-1/2 3/4 3/16 4420 1/4-20 2 3/4 3/16 4428 1/4-20 21 3/16
I
Stainless Steel Thumb Screws
PART # Thread D BC
4111 M3 x .5 8mm 8mm 5mm 4115 M3 x .5 98 5 41195 M3 x .5 11 85 4123 M3 x .5 13 85 41275 M3.5 x .6 88 5 4131 M3.5 x .6 98 5 4135 M3.5 x .6 11 85 4139 M3.5 x .6 13 85 4143 M4 x .7 9 9.5 5 4147 M4 x .7 11 9.5 5 4151 M4 x .7 13 9.5 5 4155 M4 x .7 14 9.5 5 4159 M4 x .7 16 9.5 5 4163 M5 x .8 9 11.5 5 4167 M5 x .8 11 11.5 5 4171 M5 x .8 13 11.5 5 4175 M5 x .8 14 11.5 5 4179 M5 x .8 16 11.5 5 4183 M6 x 1.0 13 13 6 4187 M6 x 1.0 14 13 6 4191 M6 x 1.0 16 13 6 4195 M6 x 1.0 18 13 6 4199 M6 x 1.0 19 13 6
METRIC
j Precision thumb screw used in a variety of electronic component applications
j Available in 303 stainless steel and 360 brass
j Diamond knurl
j Washer face shoulder design
Stainless Steel Brass
PART # PART # THREAD DABC
4800 5800 #4-40 5/16 3/8 3/16 5/8 4801 5801 #4-40 3/8 3/8 3/16 11/16 4802 5802 #4-40 7/16 3/8 3/16 3/4 4803 5803 #6-32 3/8 3/8 3/16 11/16 4804 5804 #6-32 7/16 3/8 3/16 3/4 4805 5805 #6-32 1/2 3/8 3/16 13/16 4806 5806 #8-32 3/8 7/16 3/16 11/16 4807 5807 #8-32 1/2 7/16 3/16 13/16 4808 5808 #8-32 5/8 7/16 3/16 15/16 4809 5809 #10-32 3/8 7/16 3/16 11/16 4810 5810 #10-32 1/2 7/16 3/16 13/16 4811 5811 #10-32 5/8 7/16 3/16 15/16 4812 5812 1/4-20 3/8 1/2 1/4 3/4 4813 5813 1/4-20 1/2 1/2 1/4 7/8 4814 5814 1/4-20 5/8 1/2 1/4 1 4815 5815 1/4-20 3/4 1/2 1/4 1-1/8
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
Thumb Screws
with washer face
k
87
Page 90
j
T h u m b S c r e w s
Precision Stainless Steel Thumb Screws
ETRIC
ART # A D B C
P
4501 M3.5 x .6 19mm 4.8mm 9.5mm 4502 M3.5 x .6 25 4.8 9.5 4503 M3.5 x .6 31 4.8 9.5 4504 M4 x .7 19 4.8 9.5 4505 M4 x .7 25 4.8 9.5 4506 M4 x .7 31 4.8 9.5 4507 M5 x .8 19 6.4 12.7 4508 M5 x .8 25 6.4 12.7 4509 M5 x .8 31 6.4 12.7 4510 M6 x 1.0 19 8 12.7 4511 M6 x 1.0 25 8 12.7 4512 M6 x 1.0 31 8 12.7
M
j Made from 303 stainless steel
Diamond knurl on head
j
j Longer head length than standard thumb screw
Inch and metric sizes available
j
NCH
ART # A D B C
P
4520 #4-40 5/8 3/16 3/8 4118 #4-40 1" 3/16 3/8 4521 #6-32 3/8 3/16 3/8 4522 #6-32 5/8 3/16 3/8 4120 #6-32 3/4 3/16 3/8 4122 #6-32 1" 3/16 3/8 4125 #6-32 1-1/4 3/16 3/8 4523 #8-32 3/8 3/16 3/8 4219 #8-32 1/2 3/16 3/8 4220 #8-32 3/4 3/16 3/8 4228 #8-32 1" 3/16 3/8 4231 #8-32 1-1/4 3/16 3/8 4310 #10-24 1/2 1/4 1/2 4311 #10-24 3/4 1/4 1/2 4326 #10-24 1" 1/4 1/2 4327 #10-24 1-1/4 1/4 1/2 4359 #10-32 1/2 1/4 1/2 4360 #10-32 3/4 1/4 1/2 4374 #10-32 1" 1/4 1/2 4375 #10-32 1-1/4 1/4 1/2 4410 1/4-20 1/2 5/16 1/2 4411 1/4-20 3/4 5/16 1/2 4413 1/4-20 1" 5/16 1/2 4524 1/4-20 1-1/4 5/16 1/2 4436 1/4-20 1-1/2 5/16 1/2 4417 5/16-18 1/2 3/8 5/8 4438 5/16-18 1 3/8 5/8 4419 5/16-18 1-1/2 3/8 5/8
I
Long Style Thumb Screws
j Available in carbon steel (black oxide finish), or 300 series stainless steel
j Long style thread, diamond knurl head
Steel Stainless Steel
PART # PART # A Thread BCD
4064 - #10-32 1/2 3/16 5/8 4065 - #10-32 3/4 3/16 5/8 4066 - #10-32 1” 3/16 3/8 4010 4010-SS #10-32 1-1/2 3/16 5/8 4011 4011-SS #10-32 2 3/16 5/8 4012 4012-SS #10-24 1-1/2 3/16 5/8 4013 4013-SS #10-24 2 3/16 5/8 4067 - 1/4-20 1/2 7/32 11/16 4068 - 1/4-20 3/4 7/32 11/16 4069 - 1/4-20 1” 7/32 11/16 4014 4014-SS 1/4-20 1-1/2 7/32 11/16 4015 4015-SS 1/4-20 2-1/2 7/32 11/16 4031 4031-SS 5/16-18 1 1/4 3/4 4032 4032-SS 5/16-18 1-1/2 1/4 3/4 4016 4016-SS 5/16-18 1-3/4 1/4 3/4 4017 4017-SS 5/16-18 2-1/4 1/4 3/4 4018 4018-SS 5/16-18 3 1/4 3/4 4041 4041-SS 3/8-16 1 5/16 7/8 4042 4042-SS 3/8-16 1-1/2 5/16 7/8 4019 4019-SS 3/8-16 2 5/16 7/8 4020 4020-SS 3/8-16 2-1/2 5/16 7/8 4021 4021-SS 3/8-16 3 5/16 7/8 4051 4051-SS 1/2-13 1-1/2 3/8 1 4052 4052-SS 1/2-13 2 3/8 1 4053 4053-SS 1/2-13 2-1/2 3/8 1 4022 4022-SS 1/2-13 3 3/8 1
j
88
w w w . m o r t o n m a c h i n e . c o m
Page 91
NCH
teel Stainless Steel
S
ART # PART # Thread Thread Lgth d
P
KK-2531 KK-2531SS 1/4-20 5/16 1 1/2 5/8 1/4 KK-2537 KK-2537SS 1/4-20 3/8 1 1/2 5/8 1/4 KK-2550 KK-2550SS 1/4-20 1/2 1 1/2 5/8 1/4 KK-2562 KK-2562SS 1/4-20 5/8 1 1/2 5/8 1/4 KK-2575 KK-2575SS 1/4-20 3/4 1 1/2 5/8 1/4 KK-2510 KK-2510SS 1/4-20 111/2 5/8 1/4 KK-2512 KK-2512SS 1/4-20 1-1/4 1 1/2 5/8 1/4 KK-3150 KK-3150SS 5/16-18 1/2 1-1/4 5/8 3/4 1/4 KK-3162 KK-3162SS 5/16-18 5/8 1-1/4 5/8 3/4 1/4 KK-3175 KK-3175SS 5/16-18 3/4 1-1/4 5/8 3/4 1/4 KK-3110 KK-3110SS 5/16-18 1 1-1/4 5/8 3/4 1/4 KK-3112 KK-3112SS 5/16-18 1-1/4 1-1/4 5/8 3/4 1/4 KK-3115 KK-3115SS 5/16-18 1-1/2 1-1/4 5/8 3/4 1/4 KK-3762 KK-3762SS 3/8-16 5/8 1-3/8 3/4 1 5/16 KK-3775 KK-3775SS 3/8-16 3/4 1-3/8 3/4 1 5/16 KK-3710 KK-3710SS 3/8-16 1 1-3/8 3/4 1 5/16 KK-3712 KK-3712SS 3/8-16 1-1/4 1-3/8 3/4 1 5/16 KK-3715 KK-3715SS 3/8-16 1-1/2 1-3/8 3/4 1 5/16 KK-5010 KK-5010SS 1/2-13 1 1-3/8 7/8 1 5/16 KK-5015 KK-5015SS 1/2-13 1-1/2 1-3/8 7/8 1 5/16 KK-5020 KK-5020SS 1/2-13 2 1-3/8 7/8 1 5/16
I
2
d
3
k
h
K n u r l e d T h u m b S c r e w s
Knurled Thumb Screws
k
Steel Stainless Steel
PART # PART # Thread Thread Lgth d
361203006 M3 x .5 6mm 12mm 6mm 7.5mm 2.5mm 361203010 M3 x .5 10 12 6 7.5 2.5 361203012 M3 x .5 12 12 6 7.5 2.5 361203016 M3 x .5 16 12 6 7.5 3.0 361604005 M4 x .7 5 16 8 9.5 3.5 361604008 361604008SS M4 x .7 8 16 8 9.5 3.5 361604010 361604010SS M4 x .7 10 16 8 9.5 3.5 361604012 361604012SS M4 x .7 12 16 8 9.5 3.5 361604016 361604016SS M4 x .7 16 16 8 9.5 3.5 361604020 M4 x .7 20 16 8 9.5 3.5 361604025 M4 x .7 25 16 8 9.5 3.5 362005006 M5 x .8 6 20 10 11.5 4 362005008 M5 x .8 8 20 10 11.5 4 362005010 362005010SS M5 x .8 10 20 10 11.5 4 362005012 362005012SS M5 x .8 12 20 10 11.5 4 362005016 362005016SS M5 x .8 16 20 10 11.5 4 362005020 362005020SS M5 x .8 20 20 10 11.5 4 362406008 M6 x 1.0 8 24 12 16 5 362406010 M6 x 1.0 10 24 12 16 5 362406012 362406012SS M6 x 1.0 12 24 12 16 5 362406016 362406016SS M6 x 1.0 16 24 12 16 5 362406020 362406020SS M6 x 1.0 20 24 12 16 5 362406025 M6 x 1.0 25 24 12 16 5
362406030SS M6 x 1.0 30 24 12 16 5 363008012 M8 x 1.25 12 30 16 18 6 363008016 363008016SS M8 x 1.25 16 30 16 18 6 363008020 363008020SS M8 x 1.25 20 30 16 18 6 363008025 M8 x 1.25 25 30 16 18 6 363008030 363008030SS M8 x 1.25 30 30 16 18 6 363008040 M8 x 1.25 40 30 16 18 6 363610016 M10 x 1.5 16 36 20 23 8 363610020 M10 x 1.5 20 36 20 23 8 363610025 M10 x 1.5 25 36 20 23 8 363610030 M10 x 1.5 30 36 20 23 8 363610040 M10 x 1.5 40 36 20 23 8
METRIC
d
2
hk
3
j Inch and metric sizes available
j Available in steel and stainless steel
j Solid one piece construction
j Straight knurl
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
89
k
Page 92
j
T h u m b S c r e w s
Thumb Screws
metric
j Carbon steel, black oxide finish
j Straight knurl
j Large head diameter
teel
S
ART # X Thread D BC
P
521203006 M3 x .5 6mm 12mm 2.5mm 521203010 M3 x .5 10 12 2.5 521203016 M3 x .5 16 12 2.5 521604008 M4 x .7 8 16 3.5 521604010 M4 x .7 10 16 3.5 521604012 M4 x .7 12 16 3.5 521604016 M4 x .7 16 16 3.5 521604020 M4 x .7 20 16 3.5 522005010 M5 x .8 10 20 4 522005012 M5 x. 8 12 20 4 522005016 M5 x .8 16 20 4 522005020 M5 x .8 20 20 4 522406012 M6 x 1.0 12 24 5 522406016 M6 x 1.0 16 24 5 522406020 M6 x 1.0 20 24 5 522406030 M6 x 1.0 30 24 5 522406040 M6 x 1.0 40 24 5 523008016 M8 x 1.25 16 30 6 523008020 M8 x 1.25 20 30 6 523008025 M8 x 1.25 25 30 6 523008030 M8 x 1.25 30 30 6 523008040 M8 x 1.25 40 30 6 523610020 M10 x 1.5 20 36 8 523610025 M10 x 1.5 25 36 8 523610030 M10 x 1.5 30 36 8 523610040 M10 x 1.5 40 36 8
Hex Head Thumb Screws
j Available in carbon steel (black oxide finish), or 300 series stainless steel
j Hex head allows the opportunity for increased torque
Steel Stainless Steel
PART # PART # Thread A BC
HTS-11 HTS-11SS #4-40 1/2 5/16 1/4 HTS-12 HTS-12SS #4-40 1/2 3/8 1/4 HTS-13 HTS-13SS #6-32 1/2 5/16 1/4 HTS-14 HTS-14SS #6-32 1/2 3/8 1/4 HTS-15 HTS-15SS #8-32 1/2 3/8 1/4 HTS-16 HTS-16SS #8-32 5/8 3/8 1/4 HTS-17 HTS-17SS #8-32 3/4 3/8 1/4 HTS-18 HTS-18SS #10-24 1/2 3/8 1/4 HTS-19 HTS-19SS #10-24 5/8 3/8 1/4 HTS-20 HTS-20SS #10-24 3/4 1/2 3/8 HTS-21 HTS-21SS #10-32 1/2 3/8 1/4 HTS-22 HTS-22SS #10-32 5/8 3/8 1/4 HTS-23 HTS-23SS #10-32 5/8 1/2 3/8 HTS-24 HTS-24SS #10-32 3/4 1/2 3/8 HTS-25 HTS-25SS 1/4-20 5/8 1/2 3/8 HTS-26 HTS-26SS 1/4-20 3/4 1/2 3/8 HTS-27 HTS-27SS 1/4-20 3/4 5/8 7/16 HTS-28 HTS-28SS 1/4-20 1 5/8 7/16 HTS-29 HTS-29SS 1/4-20 1-1/4 5/8 7/16
j
90
w w w . m o r t o n m a c h i n e . c o m
Page 93
j Free machining brass
j Diamond knurl
j Precision machined finish
PART # Thread D B C
5160 #4-40 .312 .312 .187 5161 #4-40 .375 .312 .187 5162 #6-32 .375 .312 .187 5163 #6-32 .500 .312 .187 5164 #8-32 .375 .375 .187# 5165 #8-32 .500 .375 .187 5166 #10-24 .500 .375 .187 5167 #10-24 .625 .375 .187 5168 #10-32 .500 .375 .187 5169 #10-32 .625 .375 .187 5170 1/4-20 .750 .500 .187 5171 1/4-20 1.000 .500 .187
T h u m b S c r e w s
k
Brass Knurled Head Thumb Screws
j Free machining brass
j Diamond knurl
j Precision machined finish
j Shoulder provides an excellent bearing surface
PART # Thread DB CE F
5180 #4-40 .250 .375 .250 .187 .094 5181 #4-40 .375 .375 .250 .187 .094 5182 #6-32 .437 .437 .375 .312 .094 5183 #6-32 .562 .437 .375 .312 .094 5184 #8-32 .375 .500 .375 .312 .094 5185 #8-32 .500 .500 .375 .312 .094 5186 #8-32 .625 .500 .375 .312 .094 5187 #10-32 .375 .500 .375 .312 .094 5188 #10-32 .500 .500 .375 .312 .094 5189 #10-32 .625 .500 .375 .312 .094 5190 1/4-20 .500 .625 .500 .437 .125 5191 1/4-20 .625 .625 .500 .437 .125 5192 1/4-20 .750 .625 .500 .437 .125
Brass Knurled Head Thumb Screws
with shoulder
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
91
k
Page 94
j
T h u m b S c r e w s
Plastic Head Thumb Screws
XTERNAL
E
THREAD
j Black plastic knurled knob
j Zinc-plated steel screw
NCH - EXTERNAL THREAD
ART # XLBCDEF
P
TS-301 #10-32 .39 .25 .47 .75 .55 .32 TS-302 #10-32 .78 .25 .47 .75 .55 .32 TS-303 #10-24 .59 .25 .47 .75 .55 .32 TS-304 #10-24 .78 .25 .47 .75 .55 .32 TS-305 1/4-20 .78 .43 .55 .94 .64 .37 TS-306 1/4-20 1.18 .43 .55 .94 .64 .37 TS-307 5/16-18 .78 .51 .63 1.18 .76 .43 TS-308 5/16-18 1.18 .51 .63 1.18 .76 .43 TS-309 5/16-18 1.57 .51 .63 1.18 .76 .43 TS-310 3/8-16 .78 .59 .71 1.42 .88 .49 TS-311 3/8-16 1.18 .59 .71 1.42 .88 .49 TS-312 3/8-16 1.90 .59 .71 1.42 .88 .49
PART # XLBCDEF
TS-420 M4 x .7 20mm 9mm 12mm 20mm 14mm 8mm TS-515 M5 x.8 15 9 12 20 14 8 TS-620 M6 x 1.0 20 11 14 25 16.5 9.5 TS-630 M6 x 1.0 30 11 14 25 16.5 9.5 TS-820 M8 x 1.25 20 13 16 30 19.5 11 TS-830 M8 x 1.25 30 13 16 30 19.5 11 TS-840 M8 x 1.25 40 13 16 30 19.5 11
I
METRIC - EXTERNAL THREAD
Plastic Head Thumb Knobs
INTERNAL
THREAD
j Black plastic knurled knob
j Thread insert made from brass
PART # XABCDEF
TS-100 #10-32 .35 .25 .47 .75 .55 .32 TS-101 #10-24 .35 .25 .47 .75 .55 .32 TS-102 1/4-20 .41 .43 .55 .94 .64 .37 TS-103 5/16-18 .45 .51 .63 1.18 .76 .43 TS-104 3/8-16 .55 .59 .71 1.42 .88 .49
PART # XABCDEF
TS-04 M4 x .7 9mm 9mm 12mm 20mm 14mm 8mm TS-05 M5 x .8 9912 20 14 8 TS-06 M6 x 1.0 10.5 11 14 25 16.5 9.5 TS-08 M8 x 1.25 11.5 13 16 30 19.5 11 TS-10 M10 x 1.5 14 15 18 35 22.5 12.5
INCH - INTERNAL THREAD
METRIC - INTERNAL THREAD
j
92
w w w . m o r t o n m a c h i n e . c o m
Page 95
Available in carbon steel with black oxide finish or 300 series
j
stainless steel
j Extra large head with straight knurl
One piece construction
j
Steel Stainless Steel
PART # PART # Thread CA B
- PS-90SS #6-32 1/2 3/8 5/16
- PS-91SS #6-32 3/4 3/8 5/16
- PS-92SS #8-32 1/2 1/2 3/8
- PS-93SS #8-32 3/4 1/2 3/8
- PS-94SS #10-32 1/2 1/2 3/8
- PS-95SS #10-32 3/4 1/2 3/8 PS-10 PS-10SS 1/4-20 1/2 5/8 1/2 PS-20 PS-20SS 1/4-20 3/4 5/8 1/2 PS-25 PS-25SS 1/4-20 1'' 5/8 1/2 PS-15 PS-15SS 1/4-20 1-1/4 5/8 1/2 PS-30 PS-30SS 5/16-18 3/4 3/4 9/16 PS-40 PS-40SS 5/16-18 1" 3/4 9/16
- PS-45SS 5/16-18 1-1/4 3/4 9/16 PS-50 PS-50SS 3/8-16 3/4 7/8 11/16 PS-60 PS-60SS 3/8-16 1" 7/8 11/16
- PS-65SS 3/8-16 1-1/2 7/8 11/16 PS-70 PS-70SS 1/2-13 3/4 1" 13/16 PS-80 PS-80SS 1/2-13 1" 1" 13/16
- PS-85SS 1/2-13 1-1/2 1'' 13/16
T h u m b S c r e w s
k
Large Panel Screws
j Machined from Nylatron
j High strength and rigidity
j Superior heat resistance
j Diamond knurl on head
PART # A Thread D B C
4701 #6-32 3/8 3/8 1/8 4702 #6-32 1/2 3/8 1/8 4703 #8-32 3/8 3/8 3/16 4704 #8-32 1/2 3/8 3/16 4705 #8-32 3/4 3/8 3/16 4706 #10-24 1/2 3/8 3/16 4707 #10-24 3/4 1/2 3/16 4708 #10-24 3/4 3/4 3/16 4709 #10-32 1/2 3/8 3/16 4710 #10-32 3/4 1/2 3/16 4711 #10-32 3/4 3/4 3/16 4712 #10-32 1” 3/4 3/16 4713 1/4-20 3/4 1/2 3/16 4714 1/4-20 3/4 3/4 3/16 4715 1/4-20 1” 3/4 3/16 4716 1/4-20 1-1/4 3/4 3/16 4717 5/16-18 1” 3/4 1/4 4718 5/16-18 1-1/4 3/4 1/4
Nylon Thumb Screws
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
93
k
Page 96
j
K n u r l e d H e a d S c r e w s
Knurled Head Adjusting Screws
j
Available in carbon steel (black oxide finish) or 300 series stainless steel
j Two piece construction
j Straight knurl
j Screws not fully threaded, thread length is the “L” dimension
Low Carbon Steel Stainless Steel Thread
PART # PART # ALB C D
- KHS0-4SS #10-32 3/4 1 5/16 3/4
- KHS0-3SS #10-32 1-1/4 1-1/2 5/16 3/4
- KHS0-5SS #10-32 1-3/4 2 5/16 3/4 KHS0-1 KHS0-1SS #10-24 1-1/16 1-1/4 5/16 3/4 KHS0-2 KHS0-2SS #10-24 1-7/16 1-5/8 5/16 3/4 KHS0 KHS0SS #10-24 1-13/16 2 5/16 3/4 KHS1-0 KHS1-0SS 1/4-20 3/4 1 5/16 1 KHS1-1 KHS1-1SS 1/4-20 1-1/4 1-1/2 5/16 1 KHS1-2 KHS1-2SS 1/4-20 1-3/4 2 5/16 1 KHS1 KHS1SS 1/4-20 2-1/4 2-1/2 5/16 1 KHS2-0 KHS2-0SS 5/16-18 7/8 1 3/8 1-1/8 KHS2-1 KHS2-1SS 5/16-18 1-3/16 1-1/2 3/8 1-1/8 KHS2-3 KHS2-3SS 5/16-18 1-7/16 1-3/4 3/8 1-1/8 KHS2-2 KHS2-2SS 5/16-18 1-15/16 2-1/4 3/8 1-1/8 KHS2-4 KHS2-4SS 5/16-18 2-7/16 2-3/4 3/8 1-1/8 KHS2 KHS2SS 5/16-18 2-11/16 3 3/8 1-1/8 KHS3-0 KHS3-0SS 3/8-16 1-1/8 1-1/2 7/16 1-1/4 KHS3-1 KHS3-1SS 3/8-16 1-5/8 2 7/16 1-1/4 KHS3-2 KHS3-2SS 3/8-16 2-1/8 2-1/2 7/16 1-1/4 KHS3 KHS3SS 3/8-16 2-3/8 3 7/16 1-1/4 KHS3-3 KHS3-3SS 3/8-16 3-1/8 3-1/2 7/16 1-1/4 KHS3-4 KHS3-4SS 3/8-16 3-5/8 4 7/16 1-1/4 KHS4-1 KHS4-1SS 1/2-13 2 2-1/2 1/2 1-1/4 KHS4-0 KHS4-0SS 1/2-13 2-1/4 2-3/4 1/2 1-1/4 KHS4-2 KHS4-2SS 1/2-13 2-1/2 3 1/2 1-1/4 KHS4 KHS4SS 1/2-13 3 3-1/2 1/2 1-1/4
Stainless Steel Knurled Head Screws
j Machined from 303 stainless steel
j One piece construction
j Oversized head, straight knurl
j Screws are not fully threaded. Thread length is the ‘B’ dimension.
PART # E Thread AB C D
8251 #4-40 1 7/16 1/2 1/4 8252 #4-40 1-1/4 5/8 1/2 1/4 82505 #4-40 1-1/2 3/4 1/2 1/4 8253 #4-40 1/2 5/16 1/8 3/8 8254 #4-40 5/8 7/16 1/8 3/8 8255 #6-32 1 7/16 1/2 1/4 8256 #6-32 1-1/4 5/8 1/2 1/4 8257 #6-32 1-1/2 13/16 1/2 1/4 8258 #6-32 1/2 5/16 1/8 3/8 8259 #6-32 5/8 3/8 1/8 3/8 8260 #8-32 1 7/16 1/2 1/4 8261 #8-32 1-1/4 5/8 1/2 1/4 8262 #8-32 1-1/2 13/16 1/2 1/4 8263 #8-32 1/2 5/16 1/8 3/8 8264 #8-32 5/8 3/8 1/8 3/8 8266 #10-24 15/16 5/8 3/16 3/8 8267 #10-24 1-3/16 13/16 3/16 3/8 8268 #10-24 1-7/16 1 3/16 3/8 8269 #10-24 15/16 5/8 3/16 1/2 8270 #10-24 1-3/16 13/16 3/16 1/2 8271 #10-24 1-7/16 1 3/16 1/2 8273 #10-24 15/16 5/8 3/16 3/4 8274 #10-24 1-3/16 13/16 3/16 3/4 8275 #10-24 1-7/16 1 3/16 3/4 8276 #10-24 1-11/16 1-1/4 3/16 3/4 8277 #10-32 11/16 7/16 3/16 3/8 8280 #10-32 1-7/16 1 3/16 3/8 8281 #10-32 15/16 5/8 3/16 1/2 8282 #10-32 1-3/16 13/16 3/16 1/2 8283 #10-32 1-7/16 1 3/16 1/2 8284 #10-32 1-11/16 1-1/4 3/16 1/2 8285 #10-32 15/16 5/8 3/16 3/4 8286 #10-32 1-3/16 13/16 3/16 3/4 8287 #10-32 1-7/16 1 3/16 3/4 8289 1/4-20 15/16 5/8 3/16 3/4 8290 1/4-20 1-3/16 13/16 3/16 3/4 8291 1/4-20 1-7/16 1 3/16 3/4 8292 1/4-20 1-11/16 1-1/4 3/16 3/4 8299 1/4-20 1-13/16 1-3/8 3/16 3/4 8293 1/4-20 2-3/16 1-5/8 3/16 3/4 8294 1/4-20 15/16 5/8 3/16 1 8295 1/4-20 1-3/16 13/16 3/16 1 8296 1/4-20 1-7/16 1 3/16 1 8297 1/4-20 1-11/16 1-1/4 3/16 1 8298 1/4-20 2-3/16 1-5/8 3/16 1
j
94
w w w . m o r t o n m a c h i n e . c o m
Page 97
j Carbon steel, black oxide finish
j Two-piece construction
j Straight knurl
hread
ART # A B CDTip Dia. Tip Lgth.
P
KHS-80 M4 x .7 38mm 6mm 19mm 2mm 3mm KHS-81 M4 x .7 51 6 19 23 KHS-82 M6 x 1.0 38 8 25 53 KHS-83 M6 x 1.0 51 8 25 53 KHS-84 M6 x 1.0 64 8 25 53 KHS-85 M8 x 1.25 38 9.5 29 65 KHS-86 M8 x 1.25 51 9.5 29 65 KHS-87 M8 x 1.25 64 9.5 29 65 KHS-88 M10 x 1.5 51 11 32 75 KHS-89 M10 x 1.5 64 11 32 75 KHS-90 M10 x 1.5 76 11 32 75 KHS-91 M12 x 1.75 76 13 32 10 6
T
K n u r l e d H e a d S c r e w s
k
Knurled Head Adjusting Screws
metric
Stainless Steel Knurled Head Adjusting Screws
j 300 series stainless steel
j Two-piece construction
j Straight knurl
PART # A B DCTip Dia. Tip Lgth.
KHS-51SS M4 x .7 32mm 19mm 8mm 2mm 3mm KHS-52SS M4 x .7 41 19 823 KHS-53SS M4 x .7 51 19 823 KHS-54SS M6 x 1.0 25 25 843 KHS-55SS M6 x 1.0 38 25 843 KHS-56SS M6 x 1.0 51 25 843 KHS-57SS M6 x 1.0 64 25 843 KHS-58SS M8 x 1.25 25 29 9.5 64 KHS-59SS M8 x 1.25 38 29 9.5 64 KHS-60SS M8 x 1.25 44 29 9.5 64 KHS-61SS M8 x 1.25 57 29 9.5 64 KHS-62SS M8 x 1.25 70 29 9.5 64 KHS-63SS M8 x 1.25 76 29 9.5 64 KHS-64SS M10 x 1.5 38 32 11 74 KHS-65SS M10 x 1.5 51 32 11 74 KHS-66SS M10 x 1.5 64 32 11 74 KHS-67SS M10 x 1.5 76 32 11 74 KHS-68SS M10 x 1.5 89 32 11 74 KHS-69SS M10 x 1.5 102 32 11 74 KHS-70SS M12 x 1.75 64 32 13 10 6 KHS-71SS M12 x 1.75 70 32 13 10 6 KHS-72SS M12 x 1.75 76 32 13 10 6 KHS-73SS M12 x 1.75 89 32 13 10 6
Thread
metric
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
95
k
Page 98
j
L o c a t i n g S c r e w s
Quarter Turn Screws
D
C
B
A
Half Turn Screws
j Available hardened or unhardened black oxide finish, carbon steel
Not hardened Hardened
Low Carbon Low Carbon Stainless
Steel Steel Steel Thread
PART # PART # PART # AB CD
QT-0 QT-10 QT-0SS #10-32 1/2 1'' 1-1/2 QT-1 QT-11 QT-1SS 1/4-20 3/4 1-1/4 1-7/8 QT-2 QT-12 QT-2SS 5/16-18 1" 1-1/2 2-1/4 QT-3 QT-13 QT-3SS 3/8-16 1" 1-1/2 2-1/2 QT-4 QT-14 QT-4SS 1/2-13 1-1/4 1-3/4 2-3/4
Long Style
LQT-0 LQT10 – #10-32 1/2 1-1/2 2'' LQT-1 LQT-11 – 1/4-20 3/4 1-3/4 2-3/8 LQT-2 LQT-12 – 5/16-18 1'' 2 2-3/4 LQT-3 LQT-13 – 3/8-16 1'' 2 3'' LQT-4 LQT-14 – 1/2-13 1-1/4 2-1/4 3-1/4
Knurled Head Toggle Screws
j Carbon steel, black oxide finish
j Applications include using as locking tool for leaf and jig plates
PART # ABCDEF
HTS-510 #10-32 1'' 3/16 1-11/16 3/4 3/16 HTS-525 1/4-20 1-1/4 3/16 2'' 3/4 1/4 HTS-531 5/16-18 1-1/4 3/16 2-1/16 1'' 5/16 HTS-537 3/8-16 1-3/4 1/4 2-11/16 1-1/16 3/8 HTS-550 1/2-13 1-3/4 1/4 2-3/4 1-1/4 1/2
Thread
j Heat treated steel, black oxide finish
j Three piece construction
j Pad swivels to allow for uniform clamping pressure
PART # ABCDE
KHT-10 1/4-20 1-1/2 5/16 1" .185 KHT-11 1/4-20 2'' 5/16 1" .185 KHT-12 5/16-18 1-1/2 3/8 1-1/8 .245 KHT-13 5/16-18 2" 3/8 1-1/8 .245 KHT-14 5/16-18 2-1/2 3/8 1-1/8 .245 KHT-15 3/8-16 1-1/2 7/16 1-1/4 .297 KHT-17 3/8-16 2-1/2 7/16 1-1/4 .297 KHT-18 3/8-16 3" 7/16 1-1/4 .297 KHT-20 1/2-13 2" 1/2 1-1/4 .405 KHT-22 1/2-13 3" 1/2 1-1/4 .405
Thread
j
96
w w w . m o r t o n m a c h i n e . c o m
Page 99
j Heat treated steel, black oxide finish
Pad swivels 8˚ in any direction for clamping on uneven surfaces
j
j Hex socket for clamping in confined area
hread
ART # ABCD H
P
HST-2507 1/4-20 3/4 3/16 .185 1/8 HST-2510 1/4-20 1 3/16 .185 1/8 HST-3115 5/16-18 1-1/2 15/64 .240 5/32 HST-3707 3/8-16 3/4 9/32 .293 3/16 HST-3715 3/8-16 1-1/2 9/32 .293 3/16 HST-3720 3/8-16 2 9/32 .293 3/16 HST-5020 1/2-13 2 3/8 .400 1/4 HST-5025 1/2-13 2-1/2 3/8 .400 1/4 HST-6220 5/8-11 2 7/16 .506 5/16 HST-6230 5/8-11 3 7/16 .506 5/16
T
T o g g l e P a d s
k
Hex Socket Toggle Screws
j Zinc-plated steel
j Available with steel pad or Delrin®pad
j 10 degree swivel
j Do not exceed load rating
j Metric sizes have black oxide finish
Steel Pad Delrin Pad Thread Steel Lbs. Delrin Lbs.
PART # PART # XBC ELoad Load
BTP-1 BTP-10 1/4-20 1/2 5/8 5/16 3900 360 BTP-2 BTP-20 5/16-18 9/16 3/4 3/8 5900 360 BTP-3 BTP-30 3/8-16 5/8 13/16 3/8 6400 570 BTP-4 BTP-40 1/2-13 3/4 15/16 7/16 7000 570 BTP-5 BTP-50 5/8-11 7/8 1 7/16 10000 1000 BTP-6 BTP-60 3/4-10 1-1/16 1-11/32 5/8 13500 1300 BTP-7 BTP-70 1-8 1-3/8 1-53/64 13/16 18750 1570
METRIC
PART # XBCE
BTP-208 M8 x 1.25 16mm 19mm 9mm BTP-210 M10 x 1.5 20 22 11 BTP-212 M12 x 1.75 24 25 12 BTP-216 M16 x 2.0 30 34 16
Thread
INCH
Toggle Pads
j Stainless steel
Stainless Steel Toggle Pads
j Available with stainless steel or Delrin®pad
j10 degree swivel
j Do not exceed load rating
Stainless Pad Delrin Pad Thread Stainless Delrin
PART # PART # XBCELoad Load
BTP-1SS BTP-10SS 1/4-20 1/2 5/8 5/16 5000 360 BTP-2SS BTP-20SS 5/16-18 9/16 3/4 3/8 7600 360 BTP-3SS BTP-30SS 3/8-16 5/8 13/16 3/8 8250 570 BTP-4SS BTP-40SS 1/2-13 3/4 15/16 7/16 9000 570 BTP-5SS BTP-50SS 5/8-11 7/8 1 7/16 12900 1000 BTP-6SS BTP-60SS 3/4-10 1-1/16 1-11/32 5/8 17400 1300 BTP-7SS BTP-70SS 1-8 1-3/8 1-53/64 13/16 24200 1570
p h o n e 8 0 0 - 4 4 1 - 2 7 5 1 / f a x 7 1 7 - 6 9 2 - 2 1 2 0
97
k
Page 100
j
S h o u l d e r S c r e w s
Socket Head Shoulder Screws
j Available in heat treated carbon steel or stainless steel
j Black oxide finish
j “C” dimension...+.005-.000
j “A” dimension...+.000-.001
ow Carbon Stainless
L
teel Steel
S
ART # PART # A B C DEF
P
SHS-1 SHS-1SS .250 #10-24 1/4 3/16 3/8 3/8 SHS-2 SHS-2SS .250 #10-24 3/8 3/16 3/8 3/8 SHS-3 SHS-3SS .250 #10-24 1/2 3/16 3/8 3/8 SHS-4 SHS-4SS .250 #10-24 5/8 3/16 3/8 3/8 SHS-5 SHS-5SS .250 #10-24 3/4 3/16 3/8 3/8 SHS-6 SHS-6SS .250 #10-24 1 3/16 3/8 3/8 SHS-7 SHS-7SS .312 1/4-20 1/4 7/32 7/16 7/16 SHS-8 SHS-8SS .312 1/4-20 3/8 7/32 7/16 7/16 SHS-9 SHS-9SS .312 1/4-20 1/2 7/32 7/16 7/16 SHS-10 SHS-10SS .312 1/4-20 5/8 7/32 7/16 7/16 SHS-11 SHS-11SS .312 1/4-20 3/4 7/32 7/16 7/16 SHS-12 SHS-12SS .312 1/4-20 1 7/32 7/16 7/16 SHS-13 SHS-13SS .375 5/16-18 1/4 1/4 9/16 1/2 SHS-14 SHS-14SS .375 5/16-18 3/8 1/4 9/16 1/2 SHS-15 SHS-15SS .375 5/16-18 1/2 1/4 9/16 1/2 SHS-16 SHS-16SS .375 5/16-18 5/8 1/4 9/16 1/2 SHS-17 SHS-17SS .375 5/16-18 3/4 1/4 9/16 1/2 SHS-18 SHS-18SS .375 5/16-18 1 1/4 9/16 1/2 SHS-19 SHS-19SS .500 3/8-16 3/8 5/16 3/4 5/8 SHS-20 SHS-20SS .500 3/8-16 1/2 5/16 3/4 5/8 SHS-21 SHS-21SS .500 3/8-16 5/8 5/16 3/4 5/8 SHS-22 SHS-22SS .500 3/8-16 3/4 5/16 3/4 5/8 SHS-23 SHS-23SS .500 3/8-16 1 5/16 3/4 5/8 SHS-24 SHS-24SS .625 1/2-13 1/2 3/8 7/8 3/4 SHS-25 SHS-25SS .625 1/2-13 5/8 3/8 7/8 3/4 SHS-26 SHS-26SS .625 1/2-13 3/4 3/8 7/8 3/4 SHS-27 SHS-27SS .625 1/2-13 1 3/8 7/8 3/4
Slotted Shoulder Screws
j Available in heat treated carbon steel or stainless steel
j Black oxide finish
j “A” dimension…+.005 -.000
j “E” dimension…+.000 -.001
Low Carbon Stainless
Steel Steel
PART # PART # A B C DEF
SS-1 SS-1SS .252 3/16 3/8 1/4-20 .374 5/8 SS-2 SS-2SS .314 3/16 3/8 1/4-20 .374 5/8 SS-3 SS-3SS .377 1/4 1/2 5/16-18 .499 3/4 SS-4 SS-4SS .502 1/4 5/8 3/8-16 .499 3/4 SS-5 SS-5SS .627 1/4 5/8 3/8-16 .499 3/4 SS-6 SS-6SS .752 1/4 5/8 3/8-16 .499 3/4
j
98
w w w . m o r t o n m a c h i n e . c o m
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
