Morphy Richards VC720507MUK User Manual

VC720507MUK Rev1

* Register online for your 2 year guarantee. See back of this instruction book for details. (UK and Ireland customers only)

www.morphyrichards.co.uk/blog

For competitions, product hints and tips
and more join us at

www.facebook.com/morphyrichardsuk

@loveyourmorphy

Additional micro-fibre floor cloths may be
purchased in packs of two by calling our
UK helpline directly on:

0844 873 0726

IMPORTANT: To prevent limescale problems which would not be covered by
the guarantee, use only deionised, demineralised or distilled water (available
from most large supermarkets).

Upright and Portable Steam Cleaner

VC720507MUK Rev1_Instruction Book 09/01/2014 16:55 Page 1

Please read and keep these instructions for future use

2

Health and Safety

•

WARNING: Disconnect from the mains supply
before carrying out any routine maintenance.

•

This appliance can be used by persons with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards
involved.

•

Children shall not play with the appliance.

•

Keep the appliance out of reach of children when it is
energized or cooling down.

Personal safety

• WARNING: Never direct steam at
electrical components or fittings. If
in doubt about the suitability of
steam for cleaning an appliance,
contact the appliance manufacturer
for advice prior to cleaning.

• WARNING: Never touch the plug or
cable with wet hands.

• WARNING: Nozzles and tools will be
hot after use. Allow to cool before
attempting to remove.

• WARNING: Do not discharge
the steam towards
people or animals.
Danger of
scalding.

• WARNING: Do not use the appliance
without the filler cap in place.

•

To protect against fire, electric shock
and personal injury, do not immerse
cord, plug or cleaner in water or other
liquid.

• The plug should be removed from the

wall socket after use, before cleaning,
filling or changing the accessories, or
carrying out user maintenance.

Location

• Do not use or keep this product

outside.

• Do not store the appliance near hot

surfaces eg. ovens or heating
appliances.

Mains cable

• WARNING: A damaged or severed
mains cable fitted with a plug
should never be connected to the
mains supply. It must be destroyed,
as a damaged cable becomes
hazardous if connected to a power
socket.

•

If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent, or similarly qualified
person to avoid a hazard.

• Do not allow the mains lead to

become strained.

Product safety

• Never modify the steam cleaner in

any way.

• Never operate the steam cleaner

without water in the tank. Always
top-up with water during extended
periods of use.

• Never fill the steam cleaner’s tank

with anything other than deionised,
demineralised or distilled water.

• The appliance is not to be used if it

has been dropped, if there are visible
signs of damage or if it is leaking.

Other safety considerations

• IMPORTANT: Always test on an
inconspicuous area first. Never use
on materials that can not resist high
temperature, such as dralon, natural
fur etc.

•

Do not use any chemical detergents,
perfumes, alcohol or descaler etc in
water.

• Repairs to electrical appliances are

only to be undertaken by trained
personnel.

• Unprofessional repairs can be

dangerous for users.

• Use only genuine Morphy Richards

spare parts and accessories.

• The appliance must not be left

unattended while connected to the
supply mains.

• This steam cleaner is intended for

domestic use only. Misuse or use for
commercial or any other purpose will
render the guarantee invalid.

Electrical requirements

• Check that the voltage on the rating

plate of your appliance corresponds
with your house electricity supply
which must be A.C. (Alternating
Current).

• WARNING: This appliance must be
earthed.

•

Should the fuse in the mains plug
require changing, a 13 amp BS1362
fuse must be fitted.

The use of any electrical appliance requires the following common sense safety rules.

Please read these instructions carefully before using the product.

STEAM

VC720507MUK Rev1_Instruction Book 09/01/2014 16:55 Page 2

3

Health and safety .........................................................................

Electrical requirements ................................................................

Product overview / Features ........................................................

Operating the appliance ..............................................................

Dual functionality ..........................................................................

Upright steam cleaning: assembly ..............................................

Using in upright steam cleaning mode .......................................

Using the portable steam cleaner ...............................................

List of attachments for use on the portable steam cleaner .......

The water tank ..............................................................................

After use ........................................................................................

Storage .........................................................................................

Maintenance .................................................................................

Contact us ....................................................................................

Notes .............................................................................................

Guarantee .....................................................................................

Contents

2

2

4

5

5

5

6 & 7

8

9

10

10

10

10

11

11

12

VC720507MUK Rev1_Instruction Book 09/01/2014 16:55 Page 3

4

Features

(1) Handle
(2) Cord holder
(3) Upper cord storage hook

(rotatable)

(4) Power cord
(5) Handle dock
(6) Lower cord storage hook

(fixed)

(7) Upper shoulder strap hook
(8) Handle release button
(9) Water tank filler cap
(10) Portable steam cleaner
(11) Water gauge
(12) Steam level select button
(13) LED light button 1
(14) Vibrate button
(15) On/Off power button
(16) LED light button 2
(17) High steam level indicator
(18) Medium steam level

indicator

(19) Low steam level indicator
(20) Water tube with brass ball

weight attached

(21) Steam outlet
(22) Floorhead
(23) Floorhead release button
(24) Floorhead neck
(25) LED lights
(26) Lower shoulder strap hook
(27) Micro-fibre floor cloth
(28) Micro-fibre floor cloth

fastening strips

(29) Filler jug
(30) Fastening pads (on

underside of floorhead)

(31) Carpet glider
(32) Extension hose connector
(33) Extension hose
(34) Utility nozzle
(35) Squeegee attachment

(attaches to utility nozzle)

(36) Elasticated utility cloth

(attaches to utility nozzle)

(37) Shoulder strap
(38) Angled nozzle attachment
(39) 2x circular brass brush

attachment

(40) 4x circular nylon brush

attachment ­2x black / 2x lime green

(41) Accessory bag

Product overview

VC720507MUK Rev1_Instruction Book 09/01/2014 16:55 Page 4

5

21

22

29

MAX

450ml

300ml

MIN

150ml

30

32

33

34

35

36

1

2

3

4

6

9

1110

20

23

24

25

7

8

12

13

14

26

27

31

37

38

39

40

28

41

15

16

17

18

19
