Page 1
RN40420MUK Rev1
* Register online for your 3 year guarantee. See the back of this instruction book for details. (UK and Ireland customers only)
Steam Iron
www.facebook.com/morphyrichardsuk
www.twitter.com/loveyourmorphy
www.morphyrichards.co.uk/blog
For competitions, product hints and tips
and more join us at
*
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 1
Please read and keep these instructions for future use
Page 2
2
Important safety instructions
•
This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience or knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
•
Keep the iron and its cord out of reach of children
less than 8 years of age at all times.
•
The iron must not be left unattended while it is
connected to the supply mains.
•
The plug must be removed from the socket before
being filled with water.
•
The iron must be used and rested on a stable
surface.
•
When placing the iron on its heel, ensure that the
surface on which the heel is placed is stable.
•
The iron is not to be used if it has been dropped, if
there are visible signs of damage or it is leaking.
•
The filling aperture must not be opened during use.
• WARNING: Burns can occur from touching hot
metal, hot water or steam.
• WARNING: To avoid electric shock, do not
immerse appliance in water / liquid.
Electrical requirements and mains cable
• Check that the voltage on the rating plate of your
appliance corresponds with your house electricity
supply which must be A.C. (Alternating current).
• Do not operate with a damaged supply cord or
grommet, it must be replaced by the manufacturer,
its service agent or similarly qualified person in order
to avoid a hazard.
• Do not let the mains lead come into contact with the
hot soleplate of the iron.
• Should the fuse in the 13 amp plug require
changing, a 13 amp BS1362 fuse must be fitted.
• WARNING: This appliance must be earthed.
PLEASE READ ALL INSTRUCTIONS AND KEEP
FOR REFERENCE
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 2
Page 3
3
(1) Filling hole with cap
(2) Water spray button
(3) Steam boost button
(4) Variable steam switch
(5) Spray nozzle
(6) Soleplate
(7) Self clean button
(8) Temperature dial
(9) Temperature indicator
light
(10) Water tank
(11) Filling beaker
Steam iron overview
Heat setting markings on the temperature dial of all Morphy Richards irons match those of the International
Textile Care Labelling Code
Temperature guide
Symbol
(120°C Max) Cool (160°C Max) Warm (210°C Max) Hot MAX setting
Control dial
positions
Do not iron
• •• •••
Fabric Nylon, Acetates,
synthetic fabrics
Wool, Polyester
mixtures
Cotton, Linen
Rayon, Rayon
mixtures
Ironing Iron on wrong side,
if moisture
required, use
damp cloth
(not Acetate)
Fabrics requiring
this setting usually
require steam
pressing.
Steam level setting
(see step 3 of
‘Using the iron for
steam ironing’ on
page 4)
No steam
(see ‘Dry ironing’
on page 5)
Low Medium / High High
With water in tank
Without water in tank
Steam/spray/ shot of steam
Dry and spray
Dry ironing
Remove any protective cover from the soleplate (6).
Before use
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 3
1
2
5
6
4
3
9
10
7
8
11
Page 4
4
For stubborn creases, use the water spray
button (2). You may need to press this a few
times to prime the pump.
Vary the steam output using
the variable steam switch (4).
Only use the steam facility on
heavy fabrics (midway
between 2 and 3-dot, to MAX).
Plug in the iron and switch on at the mains.
Set the temperature dial (8) to the temperature
required (see ‘Temperature Guide’ on page 3).
Begin with cool fabrics and work up to higher
settings. An iron heats up quicker than it cools
down so you will save time and energy.
Your iron is fitted with a temperature indicator
light (9) which will switch on and off whilst you
are ironing.
The temperature indicator light will illuminate
until the required temperature is reached, then it
will turn off.
Make sure the iron is not plugged in. Set the
variable steam switch (4) to ‘ ’. Fill the water
tank (10) via the filling hole (1).
IN HARD WATER AREAS, WE RECOMMEND
A MIX OF 50% TAP WATER AND 50%
DISTILLED OR DEMINERALISED WATER.
Never use battery topping up fluid or water
containing any substances like starch, sugar,
fragrant additives or defrosted water from a
refrigerator.
2
3
Steam boost
Press
(3)
for an extra steam boost for stubborn
creases / heavy fabrics.
NOTE: If you need to use the steam boost whilst
dry ironing, check the temperature dial
(8)
is set
within the steam range.
NOTE: For optimum steam quality, do not operate
the shot more than three times in succession
.
Using the iron for steam ironing
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 4
1
2
3
4
5
Page 5
5
Dry ironing
Your iron can be used for dry ironing. Set the
variable steam switch
(4)
to ‘ ’ and set the
temperature dial
(8)
as desired (see page 3).
You won’t need water in the tank unless using the
water spray or steam boost features
.
Vertical steam
Vertical steam is useful for removing creases
from hanging clothes, curtains, etc. Hold the iron
between 1cm and 2cm away from the item and
press the steam boost button
(3).
Anti-drip system
This prevents water escaping from the soleplate
(6)
when the iron is too cold.
During use, the anti-drip system may emit a loud
click, particularly during heat-up or whilst cooling
down. This is perfectly normal and indicates that
the system is functioning correctly
.
Life long anti-scale system (certain
models only)
This system reduces scale deposits and helps
prolong the life of the iron
.
Features of your iron
3
To clean a stainless steel soleplate
We recommend using a generally available gentle
chrome, silver or stainless steel cleaner. Always
follow the manufacturer’s instructions.
To clean a coated soleplate
Do not use scouring powder or solution as this
could cause damage to the coating.
To clean either soleplate type
If any man-made fibres fuse to the soleplate (6),
set the iron at the 3-dot position for a stainless
steel soleplate, or MAX position for a coated
soleplate, and pass it over a clean piece of cotton
to draw the deposit off the surface.
To clean the exterior
Allow the unit to cool and wipe over with a damp
cloth and mild detergent, then wipe dry.
When you have finished ironing, unplug and
empty all water from your iron and set the steam
switch at the ‘ ’ position. When cool, store the
iron on its heel with the cord wrapped loosely
around the heel.
Maintenance Emptying and storing
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 5
3
Page 6
6
Y
our iron has a built in cleaning system designed
to keep the water valve, steam chamber and
steam vents clear of lint and loose mineral
deposits.
1 Half fill the iron with water.
2 Place the iron on its heel.
3 Move the variable steam switch
(4)
to the ‘ ’
position.
4 Connect to a mains supply outlet.
5 Set the temperature dial
(8)
to ‘MAX’. See step 2
of ‘Using your iron for steam ironing’ on page 4.
6
The temperature indicator light (9) will illuminate
until the required temperature is reached, then it
will turn off. Wait for one more cycle - the
temperature indicator light illuminates and
switches off.
7 Disconnect the iron from the mains supply outlet.
8 Whilst the iron is still very hot, hold the iron
horizontally over a sink.
9
Press and hold down the self clean button
(7)
.
WARNING: Steam and boiling hot water will
drain from the holes in the soleplate. This
washes away the scale and minerals that have
built up inside the steam chamber.
10
Gently move the iron back and forth until the
water tank is empty.
11
When cleaning is complete, release the self clean
button
(7)
.
12
Rest your steam iron back on its heel and allow to
fully cool down.
13
Wipe the soleplate
(6)
with a cold, damp cloth.
After this cleaning operation, empty out any
remaining water.
WARNING: Keep hands and body away from
the hot water.
WARNING: Do not attempt to descale the
soleplate with descaling products.
Helpline
If you are having a problem with your appliance,
please call our Helpline, as we are more likely to
be able to help than the store you purchased the
item from. Please have the product name, model
number and serial number to hand when you call
to help us deal with your enquiry quicker.
UK Helpline: 0844 871 0960
IRE Helpline: 1800 409 119
Spares: 0844 873 0726
Talk to us
If you have any questions or comments, or want
some great tips to help you get the most out of
your products, join us online:
Blog: www.morphyrichards.co.uk/blog
Facebook: www.facebook.com/morphyrichardsuk
Twitter: www.twitter.com/loveyourmorphy
Website: www.morphyrichards.com
Contact us
Self clean
7
9
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 6
Page 7
7
Notes
Please attach your receipt to this page. This will be needed if you have any issues with the appliance.
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 7
Page 8
RN40420MUK Rev1 12/11
The After Sales Division
Morphy Richards Ltd
Mexborough,
South Yorkshire,
England, S64 8AJ
Your standard 1 year guarantee is extended for an
additional 2 years when you register the product within 28
days of purchase with Morphy Richards. If you do not
register the product with Morphy Richards within 28 days,
your product is guaranteed for 1 year. To validate your 3
year guarantee register with us online at
www.morphyrichards.co.uk
Or call our customer registration line
UK 0844 871 0962
IRE 1800 409 119
N.B. Each qualifying product needs to be registered with
Morphy Richards individually.
Please note that the 3 year guarantee is only available in
the UK and Ireland. Please refer to the 1 year guarantee
for more information.
It is important to retain the retailer’s receipt as proof of
purchase. Staple your receipt to this back cover for future
reference.
Please quote the following information if the product
develops a fault. These numbers can be found on the base
of the product.
Model no.
Serial no.
All Morphy Richards products are individually tested before
leaving the factory. In the unlikely event of any appliance
proving to be faulty within 28 days of purchase, it should
be returned to the place of purchase for it to be replaced.
If the fault develops after 28 days and within 12 months of
original purchase, you should contact the Helpline number
quoting Model number and Serial number on the product,
or write to Morphy Richards at the address shown.
You may be asked to return a copy of proof of purchase.
Subject to the exclusions set out below (see Exclusions),
the faulty appliance will then be repaired or replaced as
appropriate and dispatched usually within 7 working days
of receipt.
If, for any reason, this item is replaced or repaired during
the 1 year guarantee period, the guarantee on the new
item will be calculated from original purchase date.
Therefore it is vital to retain your original till receipt or
invoice to indicate the date of initial purchase.
To qualify for the 1 year guarantee, the appliance must
have been used according to the instructions supplied.
For example, water should be emptied after each use.
Morphy Richards shall not be liable to replace or repair the
goods under the terms of the guarantee where:
1 The fault has been caused or is attributable to accidental
use, misuse, negligent use or used contrary to the
manufacturer’s recommendations or where the fault has
been caused by power surges or damage caused in
transit.
2 The appliance has been used on a voltage supply other
than that stamped on the products.
3 Repairs have been attempted by persons other than our
service staff (or authorised dealer).
4 The appliance has been used for hire purposes or non
domestic use.
5 The appliance is second hand.
6 Morphy Richards reserves the right not to carry out any
type of servicing under the guarantee at its discretion
7 Plastic filters for all Morphy Richards kettles and coffee
makers are not covered by the guarantee.
8 Batteries and damage from leakage are not covered by
the guarantee.
• This guarantee does not confer any rights other than those
expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is offered
as an additional benefit and does not affect your statutory
rights as a consumer. Morphy Richards products are
intended for household use only. See usage limitations
within the location safety instructions.
Morphy Richards has a policy of continuous improvement
in product quality and design. The company, therefore
reserves the right to change the specification of
its models at any time.
For electrical products sold within the
European Community. At the end of the
electrical products useful life, it should not be
disposed of with household waste.
Please recycle where facilities exist. Check with
your Local Authority or retailer for
recycling advice in your country
Exclusions
Registering your 3 year
guarantee
Your 1 year guarantee
Disclaimer
IF YOU ARE HAVING A PROBLEM
WITH ONE OF OUR PRODUCTS,
CALL OUR HELPLINE:
UK: 0844 871 0960
EIRE: 1800 409 119
SPARES: 0844 873 0726
RN40420 MUK Rev1 1-colour_Layout 1 24/02/2012 10:38 Page 8
Loading...
