Your two year guarantee
It is important to retain the retailers
receipt as proof of purchase. Staple your
receipt to this back cover for future reference.
Please quote the following information if the
product develops a fault. These numbers can
be found on the base of the product.
Model no. Serial no.
All Morphy richards products are individually
tested before leaving the factory. In the unlikely
event of any appliance proving to be faulty
within 28 days of purchase it should be returned
to the place of purchase for it to be replaced.
If the fault develops after 28 days and within
24 months of original purchase, you should
contact the Helpline number quoting Model
number and Serial number on the product, or
write to Morphy richards at the address shown.
You will be asked to return the product (in
secure, adequate packaging) to the address
below along with a copy of proof of purchase.
Subject to the exclusions set out below (1-5) the
faulty appliance will then be repaired or
replaced and dispatched usually within 7
working days of receipt.
If you suspect a fault, follow the simple
checks detailed below before returning the
appliance or calling the helpline.
• Check the filters for blockages.
• Check the tools / tubes for blockages.
• Check the plug is firmly in the socket and the
supply is switched on.
• Make sure the socket is working by trying
another appliance.
• Check the fuse in the plug.
If for any reason this item is replaced during
the 2 year guarantee period, the guarantee on
the new item will be calculated from original
purchase date. Therefore it is vital to retain your
original till receipt or invoice to indicate the date
of initial purchase.
To qualify for the 2 year guarantee the
appliance must have been used according to
the manufacturers instructions. For example, the
filter must be cleaned regularly.
EXCLUSIONS
Morphy richards shall not be liable to replace
or repair the goods under the terms of the
guarantee where:
1 The fault has been caused or is attributable
to accidental use, misuse, negligent use or
used contrary to the manufacturers
recommendations or where the fault has
been caused by power surges or damage
caused in transit.
2 The appliance has been used on a voltage
supply other than that stamped on the
products.
3 Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4 Where the appliance has been used for hire
purposes or non domestic use.
5 The guarantee excludes consumables such
as filters.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is offered as an
additional benefit and does not affect your
statutory rights as a consumer.
• This guarantee is valid in the UK and Ireland
only.
Morphy richards products are intended for
household use only.
Morphy richards has a policy of continuous
improvement in product quality and design.
The company, therefore reserves the right
to change the specification of its models at
any time.
The After Sales Division
Morphy richards Ltd, Mexborough
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK 0870 060 2604
Republic of Ireland 1800 409119
VC71050M Rev 2
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 1
Cyclonic vacuum cleaner
Please read and keep these instructions
www.morphyrichards.co.uk
getting the best from your
new cleaner...
If your cleaner is not picking up as well as it
should, please check
• Filters
It is important to clean the motor protection filter every time you
empty the dust container, otherwise the performance of the
cleaner will be impaired. See page 5 - Cleaning the filter. A spare
is provided.
• Blockages
Check the nozzle, tubes and hose for blockages.
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 2
Important safety
instructions
The use of any electrical appliance
requires the following common sense safety
rules.
Primarily there is danger of injury or
death and secondly the danger of damage
to the appliance. These are indicated in the
text by the following two conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance! In
addition we offer the following safety advice.
Location
• Do not use or keep this product outside
when it is raining.
• Do not store the appliance near hot
ovens or heating appliances.
Mains lead
• Do not allow the mains lead to become
strained or run this appliance over it.
• If the electrical cable becomes damaged
the complete cable assembly must be
replaced. Do not attempt this task
yourself, contact Morphy Richards using
the replacement parts number on the
front of this leaflet.
Children
• Children do not understand the dangers
associated with operating electrical
appliances. Never allow children to use
this appliance.
Personal safety
• The plug must be removed from the wall
socket before cleaning or maintaining
the appliance.
• Never modify the cleaner in any way.
• Never use in the presence of explosive
liquids or vapours.
• Never pick up inflammable or poisonous
liquids such as petrol, copier toner or
other volatile substances. Never pick up
acids, asbestos or asbestos dust.
• Repairs to electrical appliances are only
to be undertaken by trained personnel.
Unprofessional repairs can be
dangerous for users.
• Use only genuine Morphy Richards
spare parts and accessories.
• The appliance must never be left running
when unsupervised.
• This vacuum cleaner is intended for
domestic use only. Misuse or use for
commercial or any other purpose will
render the guarantee invalid.
Product safety
• Never use the appliance without the
filters being installed.
• Never use the appliance to vacuum hot
ashes, broken glass, sharp objects or
liquids.
• To protect against fire, electric shock and
personal injury do not immerse cord,
plug or cleaner in water or other liquid.
Electrical requirements
Check that the voltage on the rating
plate corresponds with your house
electricity supply which must be A.C.
(alternating current).
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance the plug should be removed and
the appropriate one fitted.
If you cut off the plug and let go of the
cable it will rewind into the machine.
Therefore you must pull out a length of
cable and secure it before cutting off the
plug and refitting a new one.
IMPORTANT: The plug removed from
the mains lead, if severed, must be
destroyed as a plug with a bared flexible
cord is hazardous if engaged into a live
socket outlet.
Should the fuse in the 13 amp plug
require changing a 13 amp BS1362 fuse
must be fitted.
2
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 3
Features
⁄ Hose inlet
¤ Cable rewind pedal
‹ Carrying handle
› On/off power foot pedal
fi Variable power switch
fl Dust container release button
‡ Pleated, washable motor protection filter
· Dust collection container
‚ Tool storage drawer
„ Parking slot
‰ Exhaust filter cover
 Airflow regulator
⁄
¤
‹
›
fi
fl
‡
‚
Ê
‰
Á
3
„
Â
Illustration
Accessories you should have
Ê Hose handle
Á Flexible hose
Ë Telescopic tube (length adjustable)
È Filter cleaning brush
Í Crevice tool
Î Upholstery nozzle
Ï Clip on brush (attaches to Î)
Ì Wheeled floor nozzle
Ó Stair cleaning stretch hose
(not shown)
Note: È,Í,Î and Ï are stored in
the tool storage drawer ‚.
Ë
È
A
·
Í
Î
Ï
Ì
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 4
Quick start
1 Assemble the nozzle, telescopic tube
and hose as shown A.
2 Pull out the mains cable to it’s full length
and plug into the mains supply.
3 Switch on by pressing the foot pedal ›.
Accessories
1 Fit the hose to the cleaner by inserting
the hose end into the hose inlet ⁄.
When removing, squeeze the clips either
side and pull.
2 Attach the telescopic tube to the handle
end of the hose. Extend to the required
length by pressing down the slider
release and pulling out the tube B.
The hose handle features an airflow
regulator  which allows suction to be
reduced as required.
3 Attach the wheeled floor nozzle Ì to the
tube.
The crevice tool Í (for awkward places,
behind radiators etc) and the upholstery
nozzle Î with clip on brush Ï (for curtains
and upholstery) are stored in the tool
drawer ‚. The crevice tool is used for hard
surfaces, pelmets, delicate objects etc C.
Stair cleaning hose Ó
An additional stretch hose is also
provided for use on stairs. Fit the hose to
the cleaner by inserting the hose end into
the hose inlet. When removing squeeze the
clips either side and pull.
WARNING: For safety, always leave
the cleaner at the bottom of the stairs
and clean upwards.
Controls
Power
The on/off control is operated by the foot
pedal ›.
Variable power
A sliding switch fi varies the suction
power as required. For example, maximum
suction can be used for cleaning carpets,
hard floors etc. and reduced suction for
cleaning upholstery and curtains.
Suction can also be controlled using the
airflow regulator on the handle Â. Closed
for maximum suction, open for reduced
suction.
Automatic cable rewind
After use, unplug and press the cable
rewind button ¤ to retract the cable.
WARNING: When using the cable
rewind, always hold the plug as the cable
will rewind quickly.
4
B
C
Î
Í
Ï
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 5
5
Dust disposal
To obtain the best results from your
cleaner empty the dust container regularly,
otherwise the airflow and cleaning power
will be reduced.
1 Remove the dust container from the
product by pressing the dust container
release button fl and pulling the dust
container away from the product. D
2 Holding the dust container over a
dustbin press the dust release button as
shown E, the bottom of the dust
container will drop down to release the
dirt.
3 Close the bottom of the dust container
by pressing the base upwards until it
clicks into place.
4 Push the dust container back onto the
product to refit.
Cleaning the motor
protection filter
1 Remove the dust container from the
product by pressing the dust container
release button fl and pulling the
container away from the product. After
emptying any dirt into the dustbin as
detailed in E.
2 Remove the motor protection filter ‡
from the top of the dust container by
pushing the filter release switch to
release the filter and lift the filter out of
the container from the top.F. The filter
can be gently knocked against the side
of the dustbin to remove excess dust.
Use the filter cleaning brush È to
remove dirt from between the pleats.
3 To re-fit the filter, drop the cartridge into
the hole in the top of the dust container.
Ensure the top of the filter is located
under the lug and push the filter release
switch to allow the filter to drop into
place. The filter release switch will then
automatically flick back when released to
lock the filter in place.
The filter should be regularly washed in
cold water and left to air dry before
inserting back into the machine.
IMPORTANT: Do not use detergents to
clean the filter. The filter must be thoroughly
dry before the machine is used.
A spare filter is provided.
IMPORTANT: The dust container will not
lock back onto the machine unless the filter
is fitted correctly
D
E
F
Filter
release
switch
locating
lug
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 6
6
Cleaning the exhaust
filter
The exhaust filter ‰ is located at the side
of the cleaner. To remove, push the catch
and pull the cover away. G Take out the filter.
Wash regularly in warm water, but do not use
detergent. Allow to dry naturally and ensure it
is totally dry before replacing it.
IMPORTANT
• All filters should be checked regularly for
signs of damage, preferably after each
cleaning task. The filters must be replaced
immediately if they become damaged.
• Always disconnect the cleaner from the
mains when checking filters.
• Always make sure all filters are fitted
before use. Failure to do so may result in
damage to your product.
Storage position
When finished you can store the tubes
and accessories by locating the tube storage
clip into the slot on the side of the cleaner as
shown H.
G
H
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 7
Care and maintenance
Your cleaner is manufactured to withstand
normal day-to-day use, but an occasional
wipe over with a damp cloth will help
maintain its good looks. Abrasive cleaners
should not be used.
Purchasing filters
Use original Morphy Richards spares &
consumables. These can be purchased by
telephoning the Morphy Richards
replacement parts line.
Helpline
If you have any difficulty with your
appliance do not hesitate to call us. We are
likely to be more help than the store from
where it was bought.
Please have the following information
ready to enable our staff to help you.
• Name of product
• Model number as shown on the underside
of the appliance.
7
Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 8
Loading...
