Grind and brew coffee maker
Please read and keep these instructions
www.morphyrichards.co.uk
getting the best from
your new coffee maker
• Safety first
Caution must be used when handling hot water, coffee or steam.
• Run water through your machine before first use
It is important to run water through your coffee maker in order to
rinse the machine. You can also run water through to warm your
coffee machine.
• Descale as appropriate for the hardness of the
water in your area
It is important to descale as the performance of your coffee
maker may be impaired by limescale and other impurities in the
water supply.
•Full flavour
When using coffee beans ensure the beans are bought fresh and
stored in an air tight container. The automatic grind and brew is
pre-set for a medium grind to ensure optimum flavour.
Helpline
& order line
for replacement parts
UK 08450 777700
Eire 1800 409119
Important safety
instructions
The use of any electrical appliance
requires the following common sense safety
rules.
Primarily there is danger of injury or
death and secondly the danger of damage
to the appliance. These are indicated in the
text by the following two conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance! In
addition we offer the following safety advice.
Location
• Remove all the packaging and retain for
future reference.
•Ensure the coffee maker is used on a
firm, flat surface.
• Do not use the coffee maker outdoors or
in a bathroom.
• Do not place the coffee maker on a
highly polished wooden surface as
damage may occur to the surface.
• Do not place the coffee maker on or near
hot surfaces such as a hot plate or
radiant rings or near a naked flame.
•WARNING: Do not place the coffee
maker onto a metal tray or metal surface
whilst in use.
Children
• Children do not understand the dangers
associated with operating electrical
appliances. Never allow children to use
this appliance.
Other safety considerations
• Disconnect the coffee maker from the
mains supply when filling, cleaning or
not in use.
•Keep the outside of the coffee maker
area clean and dry at all times.
• Do not touch hot surfaces. Always use
handles or knobs.
• Do not immerse the coffee maker itself in
water and always ensure the electrical
connections are kept dry.
• Do not operate any applaince with a
damaged cord or plug or after the
appliance malfunctions or has been
damaged in any manner. Ring the
helpline number for advice on
examination and repair.
• The use of attachments or tools not
recommended or sold by Morphy
Richards may cause fire, electric shock
or injury.
•Do not use abrasive cleaners on the
outside of the coffee maker, they may
scratch the surface. Clean only with a
soft damp cloth.
• Do not use the coffee maker for anything
other than its intended purpose.
Product safety
• Never use warm or hot water to fill the
water reservoir.
• Do not overfill the water reservoir.
Treating scalds
• Run cold water over the affected area
immediately. Do not stop to remove
clothing, get medical help quickly.
Personal safety
• Avoid touching moving parts. Keep
hands, hair, clothing as well as
utensils away from the coffee maker
during operation. NEVER put your
fingers in the grinding section.
Auto shut off
• The coffee maker is fitted with an auto
shut off feature which switches off the
warming plate after 2 hours, to prevent
the coffee from becoming stewed. The
coffee will remain hot for some time. If
allowed to cool, do not reheat, discard
the remaining coffee and repeat the
process if more coffee is required.
2
Features
⁄ Reservoir lid
¤ Water gauge
‹ Jug lid
› Handle
fi Warming plate
fl Cord Storage
‡ Jug
· Control panel
‚ Lid release button
„ Grinder lid
‰ Filter basket cover/bean hopper
 Sieve
Ê Permanent filter
Á Grinder/filter basket
Ë Finger grips
È Water reservoir
Í Filter holder
Î Measuring spoon
Electrical requirements
Check that the voltage on the rating
plate of your appliance corresponds with
your house electricity supply which must be
A.C. (Alternating current).
For appliances with fitted plug.
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance the plug should be removed and
the appropriate one fitted.
IMP0RTANT : THE PLUG REMOVED
FROM THE MAINS LEAD, IF SEVERED,
MUST BE DESTROYED AS A PLUG WITH A
BARED FLEXIBLE CORD IS HAZARDOUS
IF ENGAGED INTO A LIVE SOCKET
OUTLET.
Should the fuse in the 13 amp plug
require changing a 13 amp BS1362 fuse
must be fitted.
WARNING: THIS APPLIANCE MUST
BE EARTHED.
⁄
¤
‹
›
fi
fl
‡
·
‚
‰
Â
Ê
„
Á
Ë
È
Í
Î
3
Coffee maker display
Hour set
Minutes set
Clock display
Displays the time of day, program setting
when the program button is pressed.
Flavour setting with LED indicator
Press to improve the extraction and flavour
when making fewer than 5 cups of coffee.
Program setting
Press to set for programmed brewing.
Auto button
Sets the machine to grind and brew or brew
at a preset time.
Notes for making
coffee
1 Between uses, the coffee basket
assembly should be cleaned and
thoroughly dried.
2 When making coffee using pre-ground
coffee, 10 cups of coffee can be made.
However, when using the fresh coffee
beans you will only be able to make 8
cups of coffee maximum (due to the
space taken up by the husks in the
coffee container) to maintain the coffee
strength and brew.
Beans = 10 scoops max
(grind and brew)
Preground (just brew) = 12 scoops max
3To make stronger coffee it is necessary
to use less water as the coffee amount
cannot be increased.
Using your coffee
maker for the first time
Before using your coffee maker for the
first time clean thoroughly by operating
two or three times with the maximum
volume of fresh water but without using
coffee.
GRIND
BREW
AUTO
HOUR MIN
PROG
FLAVOUR+
Flavour LED
Flavour
Display
Hour
Minute
Program
Auto
On/off grind
and brew
Brew LED
Grind LED
Auto LED
4
Using fresh coffee
beans
1 Remove the glass jug ‡ from the hot
plate.
2 Fill the glass jug with the required
amount of cold water, (8 cups maximum)
and close the jug lid. Both the jug and
water level indicators are marked in
cups. Do not exceed the maximum level.
3 Lift up the reservoir lid ⁄ by pressing
the release button and pour the contents
of the glass jug into the water reservoir
È. The water gauge window ¤
indicates the amount of water needed.
4 Replace the glass jug on the warming
plate fi.
5 Place the permanent filter Ê or a paper
filter in the grinder/filter basket Á.
When using the fresh coffee beans you
will only be able to make 8 cups of
coffee maximum.
To make fewer than 7 cups of coffee, use
about 1
1
/
2
measuring scoops of whole
beans per cup.
Note: One measuring scoop is
approximately equal to one tablespoon.
IMPORTANT: Do not fill above the max.
line of the grinder/filter basket.
6 Replace the filter basket cover/bean
hopper ‰.
7Put the beans into the filter basket/bean
hopper ‰ and replace the grinder lid „.
Close the reservoir lid ⁄ and press
down to lock.
Note :Ensure the lid is locked otherwise
the non drip valve will not open, causing
the filter to flood. The grind and brew will
not operate if the cover of the unit is
open more than 1cm or the filter basket
cover/bean hopper are left out.
8 Ensure the glass jug is positioned on the
warming plate and that the filter has
been placed in the filter basket. Plug into
the electrical socket. The clock display
will flash ‘0:00’ until the clock has been
set. This will not interfere with the
operation of the coffee maker.
9 Once the water and coffee are in place,
press the on/off button. The grind LED
indicator will light.
Note: If you are brewing fewer than 5
cups we recommend that you use the
flavour + programme to ensure full
coffee flavour. To use the flavour +
programme set up the coffee machine as
outlined in steps 1-9. Press the flavour
button, coffee will brew into the machine,
serve as required.
10 After less than 1 minute the light for
grind will go off and the brew light will
show to indicate the machine is brewing.
11 When the coffee has been made, serve
as required. The anti-drip valve will
prevent any remaining coffee dripping
onto the hotplate. Ensure that the jug is
replaced on the hotplate after serving.
While the coffee machine is switched on
the hotplate will keep the coffee warm.
12 Switch off the coffee maker when the jug
is empty or the coffee is no longer
required. WARNING THE COFFEE
MAKER AND HOT PLATE ARE HOT AND
REMAIN HOT FOR SOME TIME AFTER
SWITCHING OFF.
13 Remove the grinder lid, filter basket
cover/bean hopper, permanent filter and
grinder filter/basket. Note: it is normal for
a small quantity of coffee husks to
remain in the grinder after use. Empty
used coffee grounds, wash immediately
and dry thoroughly.
Refilling
Switch off the coffee maker and allow 3
minutes to cool before refilling with cold
water for another brew.
5
Using preground coffee
1 Remove the glass jug ‡ from the hot
plate.
2 Fill the glass jug with the required amount
of cold water, (10 cups maximum) and
close the jug lid. Both the jug and water
level indicators are marked in cups. Do
not exceed the maximum level.
3 Lift up the reservoir lid ⁄ by pressing the
release button and pour the contents of
the glass jug into the water reservoir È.
The water gauge window ¤ indicates the
amount of water needed.
4 Replace the glass jug on the warming
plate fi.
5 Place the permanent filter Ê in the
grinder/filter basket Á a paper filter could
be used instead.
When making coffee using pre-ground
coffee, 10 cups of coffee can be made.
Note: One measuring scoop is
approximately equal to one tablespoon.
IMPORTANT: Do not fill above the max.
line of the grinder/filter basket.
6 Spoon the required amount of pre-ground
coffee into the filter we suggest 1
measuring scoop per cup although a
maximum of 12 scoops can be used
depending upon personal taste.
7 Replace the filter basket cover/bean
hopper ‰ and the grinder lid „.Close the
reservoir lid ⁄ and press to lock.
Note:Ensure the lid is locked otherwise
the non drip valve will not open, causing
the filter to flood. The grind and brew will
not operate if the cover of the unit is open
more than 1cm or filter basket cover/bean
hopper are left out.
8 Ensure the glass jug is positioned on the
warming plate and that a filter has been
placed in the filter basket. Plug into the
electrical socket. The clock display will
flash ‘0:00’ until the clock has been set.
This will not interfere with the operation of
the coffee maker.
9 Once the water and coffee are in place,
press the on/off button twice.
Note: If you are brewing fewer than 5 cups
we recommend that you use the flavour +
programme to ensure full coffee flavour.
To use the flavour + programme set up
the coffee machine as outlined in steps
1-9. Press the flavour button coffee will
brew into the machine, serve as required.
10 The brew light will show to indicate the
machine is brewing.
11 When the coffee has been made, serve as
required. The anti-drip valve will prevent
any remaining coffee dripping onto the
hotplate. Ensure that the jug is replaced
on the hotplate after serving. While the
coffee machine is switched on the
hotplate will keep the coffee warm.
12 Switch off the coffee maker when the jug
is empty or the coffee is no longer
required. WARNING THE COFFEE MAKER
AND HOT PLATE ARE HOT AND REMAIN
HOT FOR SOME TIME AFTER
SWITCHING OFF.
13 Remove the grinder lid, filter basket
cover/bean hopper, permanent filter and
grinder filter/basket. Empty used coffee
grounds, wash immediately and dry
thoroughly.
Refilling
Switch off the coffee maker and allow 3
minutes to cool before refilling with cold
water for another brew.
6
HOUR MIN PROG
HOUR MIN
PROG
The display panel
The 0:00 digits will flash when you plug the unit into
the mains until you set the time. (see below).
The time display uses the 24 hr format.
How to set the clock
Press HOUR until the current hour is shown.
Press MIN until the current minutes past the hour are
shown.
The display will stop flashing as soon as the hour or
minute is pressed.
To advance the digits faster, press and hold the hour or
minute buttons.
i
i
i
Full flavour
The automatic grind & brew coffee maker
delivers the freshest coffee. It grinds the
beans before brewing the coffee.
Ensure the beans are bought fresh and
are stored in an air tight container.
The automatic grind and brew is pre-set
for a medium grind to ensure optimum
flavour.
Program operation
1 The display uses the 24 hour clock.
Setting the clock
7
Hold down the ‘PROG’ button. (The word BREW will be shown in
the display whilst the programmed brew time is being set).
Press HOUR until the desired hour for brewing is shown.
Press MIN until the desired minutes past the hour for brewing are
shown.
Release the program button.
IMPORTANT. This function is for use with WHOLE beans only.
The coffee and water must be in place before switching the unit
to AUTO. (Refer to the section called ‘Using fresh coffee beans’
for setting up the machine).
You can make sure the programmed time for automatic brew is
correct by pressing PROG
.
Press AUTO (the AUTO light flashes).
Press ON/OFF once (the auto light stops flashing and the GRIND
light comes on).
The unit will now GRIND AND BREW at the pre-set time.
The programmed time cannot be altered when the unit is in the
AUTO mode. If you need to alter the programmed brew time, you
must first of all cancel the AUTO function by pressing AUTO (the
lights will go off on the display). Then alter the program as
described above.
i
i
i
GRIND
BREW
AUTO
HOUR MIN
PROG
ON/OFF
GRIND
BREWAUTO
FLAVOUR+
HOUR MIN
PROG
ON/OFF
AUTO
FLAVOUR+
GRIND
BREW
AUTO
HOUR MIN
PROG
BREW
ON/OFF
FLAVOUR+
Setting the timer using coffee beans
to brew at a pre-set time
8
GRIND
BREW
AUTO
HOUR MIN
PROG
ON/OFF
GRIND
BREW
AUTO
HOUR MIN
PROG
ON/OFF
AUTO
FLAVOUR+
FLAVOUR+
GRIND
BREW
AUTO
HOUR MIN
PROG
BREW
ON/OFF
FLAVOUR+
Hold down the ‘PROG’ button. (The word BREW will be shown in
the display whilst the programmed brew time is being set).
Press HOUR until the desired hour for brewing is shown.
Press MIN until the desired minutes past the hour for brewing are
shown.
Release the program button.
IMPORTANT. This function is for use with PRE-GROUND beans
only. The coffee and water must be in place before switching the
unit to AUTO. (Refer to the section called ‘using pre-ground
coffee’ for setting up the machine).
You can make sure the programmed time for automatic brew is
correct by pressing PROG
.
Press AUTO (the AUTO light flashes).
Press ON/OFF twice (the auto light stops flashing and the BREW
light comes on).
The unit will now BREW at the pre-set time.
The programmed time cannot be altered when the unit is in the
AUTO mode. If you need to alter the programmed brew time, you
must first of all cancel the AUTO function by pressing AUTO (the
lights will go off on the display). Then alter the program as
described above.
i
i
i
Setting the timer using pre-ground coffee to brew
at a pre-set time
9
Troubleshooting guide
GRIND
BREWAUTO
FLAVOUR+
GRIND
BREWAUTO
FLAVOUR+
GRIND
BREWAUTO
FLAVOUR+
GRIND
BREWAUTO
FLAVOUR+
GRIND
BREWAUTO
FLAVOUR+
BREW light on = BREW function
GRIND light on = GRIND and BREW function
Auto light flashes = GRIND or GRIND and BREW not yet
chosen in automatic brewing set-up
AUTO and GRIND light on = automatic GRIND and BREW
program activated.
AUTO and BREW light on = automatic BREW program
activated.
0:00 flashing in display = time not set
The word BREW is shown in display = program time is
being set (prog. button is pressed).
The words AUTO and BREW are shown in the display =
program time cannot be set whilst AUTO function is active.
Press AUTO to cancel the programmed brew and amend
the program as described in the sections, ‘setting the timer
using preground coffee to brew at a pre-set time’ or setting
the timer using coffee beans to brew at a pre-set time’.
Program is set to brew automatically at the preset time
BREW
BREW
AUTO
AUTO
10
Descaling
• If you live in a hard water area, we
recommend that your coffee maker is
descaled at regular intervals, e.g. every
2-3 months. In areas of moderately hard
water you should descale every 6
months.
• If the water filters through more slowly
than usual, it is a sign that descaling is
necessary.
•We recommend you use proprietary
liquid descaler which is especially made
for coffee makers and plastic kettles.
Follow the instructions on the bottle or
sachet, and then operate the coffee
maker with just water 3 times before
making coffee.
• Do not use kettle descaler unless the
packet specifically states it it suitable for
coffee makers.
Note: The permanent mesh filter should
not be used during descaling.
Cleaning care
• Unplug the coffee maker and allow to
cool.
• Do not immerse the coffee maker in
liquid.
• Rinse the water reservoir occasionally
with cold water. Do not use a cloth as
any residue or lint may be left behind to
clog the coffee maker.
•Discard used coffee and remove the
permanent filter and wash. Extended
soaking helps to remove coffee stains
from the mesh.
•Wash the glass jug, jug lid, permanent
filter, grinder lid, spoon, grinder/filter
basket and filter basket cover/bean
hopper in warm soapy water. Rinse and
dry all parts thoroughly.
•Wipe all external surfaces including the
warming plate with a damp cloth and dry
thoroughly.
• Care must be taken to ensure that nondrip valve situated on the bottom of the
filter holder is not damaged during
cleaning.
Never use harsh or abrasive cleaners.
Not suitable for cleaning in a dishwasher.
11
Your two year guarantee
It is important to retain the retailers receipt
as proof of purchase. Staple your receipt to
this back cover for future reference.
Please quote the following information if
the product develops a fault. These numbers
can be found on the base of the product.
Model no. Serial no.
All Morphy Richards products are
individually tested before leaving the factory.
In the unlikely event of any appliance proving
to be faulty within 28 days of purchase it
should be returned to the place of purchase
for it to be replaced.
If the fault develops after 28 days and
within 24 months of original purchase, you
should contact the Helpline number quoting
Model number and Serial number on the
product, or write to Morphy Richards at the
address shown.
You will be asked to return the product (in
secure, adequate packaging) to the address
below along with a copy of proof of
purchase.
Subject to the exclusions set out below (see
Exclusions) the faulty appliance will then be
repaired or replaced and dispatched usually
within 7 working days of receipt.
If for any reason this item is replaced
during the 2 year guarantee period, the
guarantee on the new item will be calculated
from original purchase date. Therefore it is
vital to retain your original till receipt or
invoice to indicate the date of initial
purchase.
To qualify for the 2 year guarantee the
appliance must have been used according to
the manufacturers instructions. For example
kettles should have been regularly descaled.
EXCLUSIONS
Morphy Richards shall not be liable to
replace or repair the goods under the terms
of the guarantee where:
1 The fault has been caused or is
attributable to accidental use, misuse,
negligent use or used contrary to the
manufacturers recommendations or where
the fault has been caused by power
surges or damage caused in transit.
2 The appliance has been used on a voltage
supply other than that stamped on the
products.
3 Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4 Where the appliance has been used for
hire purposes or non domestic use.
5 Morphy Richards are not liable to carry
out any type of servicing work, under the
guarantee.
6 Plastic filters for all Morphy Richards
kettles and coffee makers are not covered
by the guarantee.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is offered as
an additional benefit and does not affect your
statutory rights as a consumer.
• This guarantee is valid in the UK and
Ireland only.
Morphy Richards products are intended for
household use only.
Morphy Richards has a policy of continuous
improvement in product quality and design.
The company, therefore reserves the right
to change the specification of its models at
any time.
The After Sales Division
Morphy Richards Ltd, Mexborough
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK (local rate) 08450 777700
Republic of Ireland 1800 409119
447/8015/12 Rev 1
Loading...
