DAB micro system
Compact disc player
MW/FM/RDS/DAB digital tuner
Programmable clock functions
Instructions
Conventions used in text
BUTTON Small capitals for the name of a button
Function/Mode Function or mode names in italics
Model 29103
On/Standby
Remote sensor
Timer
Memory/Clock Adjust
X-bass indicator
Stand-by indicator
FM stereo indicator
FM Stereo/Mono
Play/Pause
Remain/Select
RDS mode
Stop
Earphones
4-line LCD
Function
(CD/Tuner/DAB/Aux)
Mode
X-bass
EQ
Skip-R/DN & Skip-F/UP
Mute
Intro/RDS search
DAB autosearch
Volume control
CD open/close
Repeat / Preset up / Setup
Random / Preset down / Info
Band
On/Standby
Remote sensor
Timer
Memory/Clock Adjust
X-bass indicator
Stand-by indicator
FM stereo indicator
FM Stereo/Mono
Play/Pause
Remain/Select
RDS mode
Stop
Earphones
4-line LCD
Function
(CD/Tuner/DAB/Aux)
Mode
X-bass
EQ
Skip-R/DN & Skip-F/UP
Mute
Intro/RDS search
DAB autosearch
Volume control
CD open/close
Repeat / Preset up / Setup
Random / Preset down / Info
Band
Auxiliary in jacks
DAB aerial stud
Optical output
FM aerial
Power switch
Tabs for speakers
AM aerial tabs
Standby
Function
Band
Mute
CD open/close
UP/F skip
Mode
Numeric buttons
Memory/Clock adjust
Timer
DN/R skip
Remain/select/
RDS mode
Intro/auto scan/
RDS search
X-Bass
Equalizer
Volume down
Volume up
Repeat/Setup/Preset UP
Info/Random/Preset DN
STOP
Play/pause
Sleep
9208 29103MUK 4 19/5/05 4:27 pm Page 2
Components
2
AM aerial tabs
9208 29103MUK 4 19/5/05 4:27 pm Page 3
Connect the speakers to main unit
1 Ensure the mains power is disconnected.
2 Connect the speaker wires between the main unit and the speakers.
Match the speaker wire to the appropriate terminal on the components:
(+) to (+) (colour), and (-) to (-) (black). (If the wires are reversed, the
sound will be distorted and will lack some tones.)
3 Hold down the terminal tab to
insert each wire. Release the tab
to lock the wire into the terminal.
Make sure the bare wire is fully
inserted and that the insulation
reaches right up to the tab leaving
no bare wire visible.
• To avoid short-circuiting the speakers, make sure the the stripped end
of each speaker wire does not touch another terminal or another wire.
Connecting the aerials
Plug the RF coax plug of the FM aerial lead into the external FM antenna
socket.
Assemble the MW loop aerial by bending the stand along the join and
continue to bend until the stand is at the bottom of the aerial. Clip into the
slot in the base of the aerial. Then connect the two wires from the MW
aerial to the external MW antenna terminals (in the same way the speakers
wires are connected).
Take out the DAB antenna and extend it to its full length.
Connect it to the DAB aerial stud by simply screwing it onto
the stud.
Connect to the wall socket
1 Plug the unit to a live wall outlet.
Backlight illumination in standby mode
Press any key (except ON/STANDBY) on the control panel or the remote
control (when unit in standby mode) and the backlight for the display
illuminates and remains on for 5 seconds for you to check the information
on the display.
Digital clock and timer operation
Setting the time and date (in standby mode only)
Auto synchronization with DAB signal
When the LCD display shows —:—:— in standby and the radio is switched
on in DAB mode, the clock will show the correct time and date obtained
from the DAB signal.
Manual synchronization with DAB signal
Switch on in DAB mode, long press TIMER to enable the clock
synchronisation function (the LCD will display clock sync) and the correct
time and date will be displayed.
Auto synchronization with FM (RDS) signal
When the LCD display shows —:—:— in standby and the radio is switched
on in FM (RDS) mode, the clock will show the correct time and date
obtained from the FM (RDS) signal.
Manual synchronization with FM (RDS) signal
Switch on in FM mode, long press TIMER to enable the clock
synchronisation function (the LCD will display clock sync) and the correct
time and date will be displayed. This will only work if the RDS signal is
being broadcast.
Manual adjustment
1 Press CLK/ADJ in standby mode (press twice if back light on).
2 The hour digits will flash, adjust the hour whilst the clock display is
flashing by pressing REW or FFWD. Press CLK/ADJ to confirm the hour
digits.
3 The minute digits flash. Adjust the minutes whilst the clock display is
flashing by pressing
when the minutes change from 59 to 00. Press CLK/ADJ to confirm the
minute digits.
4 Adjust the day/month/year following the above steps.
• If the time has been manually set the boom box will not update the
time from the FM or DAB signal unless manual sync is used.
Time and date may not update if station signal strength is low.
How to set the timer
Press MODE twice to activate Timer On setting mode.
1 Press
MEM/CLK ADJ the hour digits will start to flash, press SKIP/SEARCH
to adjust the hour, then press MEM/CLK ADJ to confirm.
REW or FFWD. The minutes don’t carry over to hours
3
9208 29103MUK 4 19/5/05 4:27 pm Page 4
2 Follow the same steps to adjust the minutes.
3 Press
4 Press MODE again to move to the timer source setting. Press the
5 After all the settings are done, press
The unit will wake to the set mode at the set time (when in stand by
mode).
MODE again to move to the Timer Off mode; follow the same
steps to set the hour and minutes.
MEM/CLK ADJ and use the SKIP UP and SKIP DOWN to select
CD/Tuner/DAB/Aux.
MODE to exit setting mode.
Sleep function
1 Press and hold SLEEP on the remote control when listening to a CD or a
radio broadcast.
2 The display changes
60 50 40 30 20 10 off with the mesage sleep
flashing.
3 After the sleep time has expired the unit will go into standby mode.
sleep time in a sequence: 90 80 70
CD operation
CD playback
1 Press FUNCTION to select CD playback mode.
2 Open the CD tray by pressing
3 Insert a disc onto the CD tray and close the tray.
4 The display shows the number of tracks and total playing time of the
CD.
5 Press
PLAY/PAUSE to begin CD playback; press again to pause playback.
CD playback controls
Stop button
Press this button to stop playing the disc during CD playback.
Skip/search button
Press UP-SKIP once to advance by one track or DN-SKIP once to jump back
to the beginning of the current track or press DN-SKIP continuously to jump
back to previous tracks during playback.
Press and hold these buttons for 2 seconds during CD playback to fast
forward or backward within the track.
Repeat but on
Press this button to select between repeat one and repeat all modes in CD
stop or play modes; once for repeat all mode, twice for repeat one and
three times to exit.
Random button
Press this button to enter random play mode when in CD stop or CD play
mode; then press PLAY/PAUSE to begin random playback; press again to
exit this mode.
Intro button
The intro function will play the first 10 seconds of every track. Press this
button to enter intro play mode in CD stop or CD play mode; press this
button again to exit this mode. In random playback, press this button to
enter random intro mode.
Remain button
Press this button continuously to display the elapsed time of the current
track; the remaining time of this track, the remaining time of whole disc,
and the elapsed time of the whole disc during normal playback.
OPEN/CLOSE.
4
9208 29103MUK 4 19/5/05 4:27 pm Page 5
Program playback
To program tracks:
1 Press
2 Press SKIP/SEARCH or numeric buttons to select the memory location to
3 Press
4 After programming is finished, press PLAY/PAUSE to enter program
5 Press stop twice to return to normal CD playback.
• A total of 60 tracks can be programmed depending on how many
MEMORY in CD stop mode.
store current track.
MEMORY again to save and move to next track.
playback.
tracks are on the CD.
MW/FM/RDS radio operation
Storing stations
• Press FUNCTION until LCD shows ‘Tuner information’.
• Press
• Press SKIP/SEARCH buttons to manually tune the frequency.
• Press and hold
To store the current radio station:
1 Press
2 Press PRESET UP/DOWN buttons or directly press the numeric buttons on
3 Press the
4 To recall the preset station frequency, press the PRESET UP/DOWN
A total of 20 station frequencies (10 stations per band) can be stored in
memory. The memory will be erased if the unit loses power.
RDS operation
When the radio stops at a radio station which supports RDS, the LCD
shows the frequency, radio name, program type and radio text step-by-step.
You can also select the displayed text by pressing RDS MODE. The display
toggles as follows: Frequency Station name Program type
Radio text back to Frequency.
If you want to enjoy a particular type of program, press
continuously, the LCD shows as follows: News Affairs Info
Sport Educate Drama Culture Science Varied Pop
M Rock M Easy M Light M Classics Other M
Weather Finance Children Social Religion Phone in
Travel Leisure Jazz Country Nation M Oldies Folk
M Document test Alarm back to News.
Use the SKIP/SEARCH buttons to select the particular program after
programming is done.
BAND to select between MW and FM.
SKIP/SEARCH buttons for 2 seconds to automatically
tune the radio frequency. When the tuning finds the first station
available, broadcasting starts immediately.
MEMORY.
the remote control to select a memory position.
MEMORY button again to store the current frequency.
buttons or the preset buttons on the remote control.
RDS SEARCH. Press
5
9208 29103MUK 4 19/5/05 4:27 pm Page 6
DAB (digital audio broadcasting)
DAB or Digital Audio Broadcasting represents a new age in broadcasting
technology and as with all new technologies it is significantly different to
traditional analogue FM/AM broadcast methods. The new system no
longer relies on the user tuning to a given frequency but allows the DAB
receiver to provide an active service list of all available radio
programmes/stations at the touch of one button.
IMPORTANT: Before using DAB for the first time please ensure the DAB
aerial is attached and fully extended.
1 Take end of DAB
antenna wire
Operation
1 Switch the main power switch on the rear of the unit to the ON position.
2 Press
3 Press
At this stage and in the unlikely event that the display shows ‘Poor
reception?’ this indicates the unit has been unable to locate any available
stations this may be due to:
• No DAB service in the local area;
• The unit needs relocating in order to get adequate reception. To help
6
STANDBY on the front of the unit or on the remote control to
switch the unit on, the standby indicator will extinguish.
FUNCTION until the DAB information appears, the LCD display will
illuminate and will show ‘Welcome to DAB Digital Radio’, solid blocks
will progress across the display from left to right. The ‘O’ in the top
right hand corner of the display will change as stations are found and
after around 10 seconds ‘now tuning’ will show in the display and the
first station on the service list will be tuned to.
with this process a tuning aid can be accessed by pressing the
button this will bring up a manual tuning aid which will show the
available signal strength for a given multiplex the incoming signal
should exceed the outline box shown in the display to ensure good
uninterrupted reception. Move the unit around in the location until an
2 Split end of DAB
antenna wire
3 Mount the ends
vertically for the
best reception
SELECT
adequate signal is received.
• In the event that the available signal is still not sufficient it may be
necessary to connect an external aerial to the socket on the rear of the
unit.
4 Assuming there is now a service list available the other stations on the
list can be located by using
SKIP/SEARCH to scroll through the list. To
listen to the station shown on the bottom line of the display press
SELECT.
Select and skip/search buttons
When navigating through the DAB functions using the integrated menu
system all the menu options will scroll across the display. Navigation is
easy using the SKIP/SEARCH buttons and then the SELECT button. If any
other button is pressed that has no function then the menu will exit.
• Pressing
SELECT whilst listening to a station will show the signal
strength of the received broadcast in the form of blocks moving from
left to right.
Display button
Pressing DISPLAY changes the information displayed on the bottom line of
the screen. Continue to press DISPLAY to scroll through the options
available as follows:
12:48 13-04-05
THE ARROW - ROCK
<SCROLLING TEXT>
X BASS ROCK
Or press
SELECT to show signal strength meter.
MUX
This provides a static display of the identification of the multiplex provider.
Channel +Freq.
This option shows the multiplex number and frequency of the current
tuned service. This option can only be viewed and is for information only,
no adjustment is available.
Bit rate/Audio status
This provides the bit rates of 128kbps, 192kbps and 256kbps; you may
also select mono or stereo audio output.
12:48 13-04-05
THE ARROW - ROCK
12A 223 93MHZ
X BASS ROCK
SIGNAL ERROR 8
THE ARROW - ROCK
MXR YORKSHIRE
128KBPS STEREO
9208 29103MUK 4 19/5/05 4:27 pm Page 7
SIG error rate
This option shows the digital bit error rate of the current tuned service.
This option can only be viewed and is for information only, no adjustment
is available. The lower the figure the better the quality of the received
broadcast.
Scrolling DLS text
This is text that accompanies a radio programme and can be used to
provide additional information such as the title of the song being played or
contact phone numbers or web site addresses etc. Not all stations
broadcast DLS text therefore this information may not be available on
some stations/broadcasts.
Programme type
This provides a static display of the type of material the station is
broadcasting and allows the easy identification of stations that are new or
unknown. Not all stations broadcast this information.
Date and time
Pressing MODE will provide a static display of the current time and date;
this is decoded from the incoming broadcast signal and therefore does not
ever need setting or adjusting.
Autotune button
Pressing AUTOTUNE will activate the autotune quickscan function. The
display will show a progress bar moving from left to right, this will add new
found stations to the initial service list. This feature is useful when the unit
is moved from one location to another.
• Stations that are not receivable in the current location will have a ‘?’ in
front of the service name in the list. To remove these see the section
Tidy stations later in this manual.
Press and hold
longer time.
AUTOTUNE to begin auto scan full coverage. This will take a
Setup button
Pressing this button will bring up a menu list. If you navigate using the
SKIP/SEARCH buttons the menu moves from one option per press to the
option that follows. Press SELECT to confirm when the desired option is
reached.
Station order
Selecting this option provides the following sub menus, navigate using the
SKIP/SEARCH buttons. The menu is cyclic and will continue to move one
option on each button press as follows: Fav Station Alphanumeric
Active Station Prune Stations Presets. Press SELECT to select the
required option.
Favourite station
DAB has a unique feature whereby it remembers every time you listen to a
station and stores this information. If this option is selected the service list
will be sorted in the favourite order, i.e. the most listened to station at the
top of the list to make it faster to find when the unit is switched on.
Alphanumeric
Selecting this option sorts the service list in alphanumeric order from
A to Z.
Prune stations
Selecting this option removes any stations from the list that are not
currently receivable (marked with a ‘?’ in front of the service name).
Presets
This menu option only becomes available once the favourite stations sort
has been used. The unit will automatically allocate the top 10 most
frequently listened to stations to presets 1 to 10, with preset 1 the most
listened to station, Preset 2 the second most listened to station etc.
Storing stations into the preset memory
With DAB using a service list with easy station identification it is not
essential to store DAB stations as presets, however if this is required then
proceed as follows.
1 Tune the to station to be stored in memory.
2 Press and hold
memory position the station is to be stored into.
3 After a couple of seconds ‘Preset x saved’ will show in the display
where x is the preset location number 1-10.
You can also store presets from the second line of the display, scroll
through the service list until the required station is located and follow
steps 2 and 3 above.
To review the preset numbers allocated to stations scroll through the
service list using the
been allocated to a station it will show on the right hand side of the
display i.e. ‘ Classic 3 ’ indicating Classic is stored in preset
location 3.
NUMBER on the remote control relating to the preset
SKIP/SEARCH buttons, where a preset number has
7
9208 29103MUK 4 19/5/05 4:27 pm Page 8
Recalling a preset station
Briefly press NUMBER on the remote control relating to the preset memory
position required.
Other DAB functions
Manual tune
Selecting this option brings up the multiplex number and frequency in the
display along with a signal strength meter and is useful in areas of poor
reception. The multiplexes can be scrolled through using the SKIP/SEARCH
buttons and are listed as follows: 5A 5B 5C 5D 12A
12B 12C 12D 13A 13B 13C 13D 13E 13F.
To check the signal strength for a multiplex press
required multiplex number is in the display and the unit will tune to that
multiplex and display the signal strength as a bar moving from left to right.
For correct reception the bar should pass the outline box shown in the
display.
To exit this menu at any stage press SETUP.
• Some Multiplexes will appear to have no signal when checked using
the above method this is normal and indicates that the selected
multiplex is not broadcasting in the area where the unit is being used. A
single multiplex can carry a large number of individual stations
therefore it is not necessary for all multiplexes to be used in all areas of
the country.
SELECT when the
Dynamic range control (DRC)
DRC enables the alteration of the dynamic range of the received audio
(dependent on broadcast material). The DRC level of a broadcast is set by
the broadcaster and transmitted with the service.
Changing the DRC value applies relative variance to the transmitted level.
When this option is selected the current DRC value is displayed on the top
line of the display and the available adjustment is displayed as a scroll
selection on the bottom line of the display, use the
view the available adjustment options.
DRC 0: DRC adjustment is switched off;
DRC1/2: DRC adjustment is set to 1/2 of that sent with the transmitted
service;
DRC 1: Applies the DRC scaling as sent with the transmitted service. This
SKIP/SEARCH buttons to
isthe default setting.
Software version
This option shows the version number of the software installed in the unit.
This option can only be viewed and is for information only, no adjustment
is available.
Factory reset
Press and hold SETUP, the reset menu will appear on the LCD asking you
to press SELECT to confirm. Press SELECT to reset the unit. This will revert
the unit to the initial start-up mode and will do a complete re-scan. Please
note if this mode is invoked then all the favourite and preset information
will be lost.
The radio will contain the following default settings:
• No stations in service list
• No presets allocated
• Service order is alphanumeric order
• DRC value is 1
• Display mode is scrolling DLS
8
9208 29103MUK 4 19/5/05 4:27 pm Page 9
Other functions
EQ button
Press EQ to toggle the equalizer effect of the system; the EQ effect will
change between: Flat Rock Classic Pop Jazz.
X-Bass button
Press this button to turn on or off the bass boost function.
Volume control wheel
Rotate to increase or decrease the volume level. The volume level can be
changed from 0 - 50.
Mute button
Press this button to turn mute on or off. In mute on mode, the sound is cut
off.
Mono/Stereo
Press this button to change between FM mono broadccasts and stereo
broadcasts.
External connection
The SPDIF socket is for connecting to other equipment enabled with this
interface (DAB and CD output only).
Auxiliary input operation
Any signal can be input through the auxiliary input jacks.
1 Press FUNCTION until ‘Aux’ appears in the LCD screen.
2 Insert the plugs of a commercially made audio cable into the AUX Input
jacks (right and left), and the other into the line-out jack of the signal
source (such as CD player, recorder, etc.).
3 Press
Adjust the
of this set. The volume control of the signal source will not work any more.
PLAY on the signal source to start playback.
VOLUME and choose the music style by selecting the EQ effects
9
9208 29103MUK 4 19/5/05 4:27 pm Page 10
Compact disc
Always use compact discs bearing the mark as shown.
Handling discs
When removing the disc from its storage case and loading it:
• Do not touch the reflective recorded surface.
• Do not stick paper or write anything on the surface.
• Do not bend the disc.
Storage
• Store the disc in its case.
• Do not expose discs to direct sunlight or high temperatures, high
humidity or dusty places.
Cleaning a disc
If there is a scratch, dirt or finger prints on the CD, it may cause tracking
errors. Before playing, clean the CD with a clean cloth. Wipe the CD from
the centre outwards. After playing, store the disc in its CD case.
• Never use benzene, thinners, record cleaner fluid or anti static spray.
• Be sure to close the CD door so the lens is not contaminated by dust.
Do not touch the lens.
Warning labels
WARNING : to reduce the risk of an electric
shock, do not expose this appliance to rain
or moisture.
ATTENTION: To reduce the risk of an electric shock, do not
remove the cover. There are no user serviceable parts inside
the unit. Refer any servicing to qualified personnel.
The lightning flash with arrowhead symbol within
the triangle is a warning sign alerting the user of
‘dangerous voltage’ inside the unit.
The exclamation point within the triangle is a
warning sign alerting the user of important
instructions accompanying the product.
To prevent fire or shock hazard do not expose this apparatus
to dripping or splashing.
Ventilation warning
The normal ventilation of the product shall not be impeded for intended
use.
Maintenance
Do not expose your cd micro system to extreme of temperatures. The
product should be kept in a warm environment free from dust and damp.
For external cleaning use only a soft, clean, damp cloth. Use of detergents
may damage the finish.
10
From the centre to
the edge
CORRECT
INCORRECT
9208 29103MUK 4 19/5/05 4:27 pm Page 11
Guarantee
Morphy Richards products are manufactured to internationally accepted
quality standards. In addition to your statutory rights, Morphy Richards
guarantee your product to be free from manufacturing and component
defects for a period of TWO YEARS from date of purchase.
If your product proves to be defective within 28 days of purchase, your
Morphy Richards dealer from whom the product was purchased will be
pleased to replace it free of charge.
Should your product develop a defect within the guarantee period but
after the replacement period, please return the product to the following
address, together with the proof of purchase, brief details of the
symptoms and your own name and address.
After Sales Division
Morphy Richards Limited
Mexborough
South Yorkshire
S64 8AJ
Your post office will provide a certificate of posting. The product will be
repaired and returned to you promptly.
11
9208 29103MUK 4 19/5/05 4:27 pm Page 12
Helpline
(8.30-5.00 Mon-Thur/ 8.30-4.00 Fri)
UK 0870 060 2614
Republic of Ireland 1800 409119
Replacement parts
0870 167 6645
Morphy Richards Ltd., Mexborough, South Yorkshire, S64 8AJ
www.morphyrichards.com
29103MUK Rev 1 5/05
Loading...
