MICROWAVE OVEN

Installation & User Instructions – Please keep for future reference

800W

CLOCK/ PRE-SET

MICROWAVE

Speed Defrost

Vegetable

Meat

Potato

Soup

DEFROST BY W.T.

GRILL/ COMBI

Porridge

400/8493

Auto Reheat

Fish

Pasta

Pizza

IMPORTANT

• WARNING: if the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person;

• WARNING: it is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy;

• WARNING: liquids and other food must not be heated in a sealed container since they are liable to explode;

• WARNING: only allow children to use the oven without supervision when adequate instruction have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

• WARNING: accessible parts may become hot during use. Young children should be kept away.

CAREFULLY RETAIN THESE INSTRUCTIONS

Contents

Safety Information

2-6

Materials you can use in microwave oven 7

Materials to avoid using in the microwave oven 7 Utensils 7

Setting Up your Oven 8

Oven components and accessories 8 Turntable installation 8 Microwave cooking principle Microwave Food Packaging Symbols

Accessories included 9

Installation 10-11

Please Note Electrical connection 10

Earthing installation

Operating your microwave oven

Clock Setting Microwave Cooking

Grilling Cooking

Combination cooking

Defrist Multi-stage Cookking Speed Microwave Cooking

Pre-set Function Microwave auto function

Checking information-power / time Lock-out Function for Children Warming up , heating

Cleaning your microwave oven

Troubleshooting and maintenance

12-17

12 13

13 14

18 19

Questions and Answers 22

Technical Specifications

Guarantee

23 24

CLOCK/

DEFROST BY W.T.

PRE-SET

GRILL/

MICROWAVE

COMBI

Speed

Auto

Defrost

Reheat

Fish

Vegetable

Pasta

Meat

Pizza

Potato

Porridge

Soup

800W

Safety Information

Important – Please read these instructions fully before installation

IMPORTANT SAFETY INSTRUTIONS

READ CAREFULLY AND KEEP FOR FUTURE

REFERENCE

1. The temperature of accessible surfaces may get hot when the appliance is operating especially the metal top area and the warming rack if any.

2. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

3. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

4. Keep the appliance and its cord out of reach of children less than 8 years.

5. Children should be supervised to ensure that they do not play with the appliance.

Safety Information

Important – Please read these instructions fully before installation

6. The appliance is not intended to be operated by means of an external timer or separate remotecontrol system.

7. The appliance is intended to be used in household and similar applications such as :

- staff kitchen areas in shops, offices and other working environment;

- by clients in hotels, motels and other residential type environments;

- farm houses;

- bed and breakfast type environments.

8. WARNING : If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

9. WARNING : It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

10. WARNING : Liquids and other foods must not be heated in sealed containers since they are liable to explode.

11. A minimum clearance of 12inches (30cm) must be left above the top of the oven.

Safety Information

Important – Please read these instructions fully before installation

12. Only use utensils that are suitable for use in microwave ovens.

13. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.

14. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle and flames.

15. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.

16. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.

17. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.

18. The oven should be cleaned regularly and any food deposits removed.

19. When cleaning door and oven surfaces use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth.

Safety Information

Important – Please read these instructions fully before installation

20. Failure to maintain the oven in a clean condition could lead to deterioration of the surface which could adversely affect the life of the appliance and possibly result in a hazardous situation.

21. The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.

22. The rear surface of appliances shall be placed against a wall.

23. WARNING : The appliance and its accessible parts become hot during use. Care must be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.

24. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.

2 . Do not use steam cleaners inside the cavity. 5

Safety Information

–

Important

1. The oven must be placed on a level surface.

2. The turntable and turntable ring assembly must always be used in the oven during cooking. Place the cookware gently on the turntable and handle it carefully to avoid possible breakage.

3. Incorrect use of dish for browning food may cause turntable to break.

4. Use only the specified bag size when using pre-prepared popcorn.

5. The oven has several built-in safety switches to ensure that the power remains off when the door is open. Do not tamper with these switches.

6. Do not operate the microwave oven when empty. Operating the oven with no food or food that is extremely low in moisture can cause fire, charring or sparking.

7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause the turntable to break.

8. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature should be carefully checked before consumption, in order to avoid burns.

9. Do not heat narrow-necked containers, such as syrup or sauce bottles.

10. Do not attempt to deep-fry in your microwave oven.

11. Do not attempt home canning in this microwave oven as it is impossible to be sure all contents of the jar have reached boiling temperature.

12. This appliance is intended to be used in household

13. Caution : Stir the liquid prior to and during heating / reheating, let liquid stand for at least 10 seconds after cooking and always take care when adding ingredients to hot liquids. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.

14. Check the food in the microwave oven frequently to avoid burning due to overheating.

15. Failure to maintain the oven in a clean condition could lead to deterioration of the surface which could adversely affect the life of the appliance and possibly result in a hazardous situation.

16. Stand at arm's length when opening the door to avoid scalding when steam or hot air is released.

17. ALWAYS allow an appropriate standing time after the oven has switched off according to the food being cooked to allow heat to distribute evenly throughout the food.

18. Use oven gloves when removing any cookware from oven to reduce chance of being burned or scalded.

19. Read and follow the specific: "precautions for avoiding possible exposure to excessive microwave energy".

20. As with most cooking appliances, close supervision

is necessary to reduce the risk of a fire in the oven cavity .

If a fire should start or smoke is observed: a. Keep the oven door closed. b. Turn the oven off and unplug the appliance.

21. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.

22. Do not overcook food. Regularly observe the oven if paper, plastic, or other combustible materials are used in the oven.

23. Do not use the oven cavity for storage purposes. Do not store items such as bread, cookies, paper products, etc. inside the oven.

24. Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.

25. This oven must be earthed. Connect only to properly earthed outlet. See "earthing installation".

26. Install or locate this oven in accordance with installation instructions provided. The microwave oven is intended to be used freestanding. The appliance m ust not b e placed in a cabinet.

Please read these instructions fully before installation

and not in application such as :

- staff kitchen areas in shops, offices and other residential environments;

- farm houses;

-by clients in hotels, motels and other residential environments;

- bed and breakfast type environments.

27. Use this appliance only for its intended uses as described in the manual.

containing oil and water as

This oven is specifically It is not designed for

28. Never allow children to use the oven without supervision unless adequate instructions have been given so that the children are able to use the oven in a safe way and understand the hazards of improper use.

29. If the supply cord or plug is damaged, or if the oven is not working properly or has been dropped it must be replaced or

30. This appliance should be serviced only by qualified service technicians. Contact the nearest authorised service facility for examination, repair or adjustment.

31. Do not cover or block any vents on the oven.

32. Do not store or use this appliance outdoors.

33. Do not use this oven near water wet basement or near a swimming pool.

34. Do not immerse cord or plug in water.

35. Keep cord away from heated surfaces.

36. Do not let cord hang over edge of table or counter.

37. When cleaning door and oven surfaces use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth.

38.

39. Do not attempt to repair the oven yourself, please consult an authorised service agent.

40. Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to try an override or tamper with the safety interlocks.

41. Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the, (1) door (i.e. door is not bent or dented), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

42. Utensils should be checked to ensure that they are suitable for use in microwave ovens.

43. The symbol on the product or on its packaging indicates that this product may not be treated as

household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is

disposed of correctly, you will help prevent potential negative consequences for the environment and human health,which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

44. The lamp holder must be serviced by an authorised service agent.

45. The oven should be cleaned regularly and any food deposits removed.

46. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface,

47. Do not use steam cleaners inside the cavity.

48. During use the appliance becomes hot. Care should be

taken to avoid touching heating elements inside the

49. The product is classified as a Group 2, Class B, ISM

appliance. Group 2 includes all ISM (Industrial, Scientific or Medical) appliances in which radio frequencies are generated intentionally and/or used in the form of electromagnetic radiation to treat materials, together with electroerosion equipment. Class B includes equipment for domestic use or on premises directly connected to low voltage electricity supply for supplying buildings for residential use.

50. This appliance complies with EC directive 2004/108/EC

on electromagnetic compatibility and Europea regulation no.1935/2004 of 27/10/2004 on food contact materials.

repaired by the manufacturer or its service

agent or a

similarly qualified person in order to

a hazard.

The microwave is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar items may lead to risk of injury,ignition or fire.

the glass.

Take care when heating mixtures

foaming or spitting may occur.

designed to heat or cook food.

industrial or laboratory use.

avoid

, near a kitchen sink, in a

which may result in shattering of

oven.

MATERIALS YOU CAN USE IN MICROWAVE OVEN

Utensils

Aluminium foil

Arcing can occur if foil is too close to oven walls.

Browning dish

Dinnerware

Glass jars

Glassware

Oven cooking bags

Paper plates and cups

Paper towels

Parchment paper

Plastic

Plastic wrap

Thermometers Wax paper

Utensils Remarks Aluminium tray Food carton with metal handle Metal or metal-trimmed utensils Metal twist ties Paper bags Plastic foam

Wood

Remarks Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry

to prevent overcooking. The foil should be a least 1 inch

(2.5cm) away from oven walls.

Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage cause the turntable to break.

Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes. Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant

and may break. Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or

chipped dishes. Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to

escape. Use for short-term cooking/warming only. Do not leave oven unattended while cooking. Use to cover food for reheating and absorbing fat. Use with supervision for short-term cooking

only. Use as a cover to prevent splattering or as a wrap during steaming. Microwave-safe only. Follow the manufacturer's instructions. Should be labelled "Microwave Safe".

Some plastic containers soften as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package.

Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.

Microwave-safe only (meat and sugar thermometers). Use as a cover to prevent splattering and retain moisture.

TERIALS TO AVOID USING IN THE MICROWAVE OVEN

May cause arcing. Transfer food into microwave-safe dish. May cause arcing. Transfer food into microwave-safe dish. Metal shields the food from microwave energy. Metal trim may cause arcing. May cause arcing and could cause a fire in the oven. May cause a fire in the oven. Expanded polystyrene may melt or contaminate the liquid inside when exposed to high

temperature. Wood will dry out when used in the microwave oven and may split or crack.

UTENSILS

CAUTION Personal Injury Hazard Tightly-closed containers could explode. Closed containers should be opened and plastic pouches pierced before cooking. See above for further instructions "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question by following the procedure below. Utensil test:

1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.

2. Cook on maximum power for 1 minute.

3. Carefully feel the utensil. If the utensil is warm, do not use if for microwave cooking.

4. Do not exceed 1 minute cooking time.

Setting Up Your Oven

OVEN COMPONENTS AND ACCESSORIES

fig.1

CLOCK/ PRE-SET

MICROWAVE

Speed Defrost

Vegetable

Meat

Potato

Soup

DEFROST BY W.T.

GRILL/ COMBI

Auto Reheat

Fish

Pasta

Pizza

Porridge

TURNTABLE INSTALLATION

Warning : Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.

fig. 2

Setting Up Your Oven

Microwave cooking principles

1. The microwaves generated by the magnetron are evenly distributed through the food as the glass turntable revolves. This ensures that the food is cooked uniformly.

2. The microwaves are absorbed by the food up to a depth of approximately 1 inch (2.5cm). Cooking continues as the heat is dissipated through the food.

3. Cooking times will vary according to the recipe and the density , weight and water content of the food. The cooking time will also vary according to the temperature at the start of cooking, i.e. depending on whether the food is frozen or not.

Microwave Food packaging Symbols

Microwave Symbols: On the front of your oven there is a microwave symbol, as shown below. This symbol has been introduced for your benefit when cooking or reheating packaged food. Packaged food is also increasingly using a microwave symbol similar to the one below. When you see this symbol on food packaging the cooking instructions are based on either IEC Power Output Rating, on the Reheating Categories A,B,C,D or E.

A , B, C, D or E

MORE HEATING TIME

LESS HEATING TIME

800W

Accessories included

Turntable Ring Assembly

Microwave Oven Recipe Book

Microwave Oven Recipe

Recipe Book - Please keep for future reference

Recipe - Please keep for future reference

IMPORTANT

• Please read the Cooking Tips and Cooking Care before you start.

• Check with your Microwave Rating and adjust cooking times accordingly.

Recipe

lass Tray

MICROWAVE OV EN

Installation & User Instructions – Please keep for future reference

IMPORTANT

• WARNING: if the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person;

• WARNING: liquids and other food must not be heated in a sealed container since they are liable to explode;

• WARNING: accessible parts may become hot during use. Young children should be kept away.

CAREFULLY RETAIN THESE INSTRUCTIONS

XXXXXX

CLOCK/

DEFROST BY W.T.

PRE-SET

GRILL/

MICROWAVE

COMBI

Speed

Auto

Defrost

Reheat

Fish

Vegetable

Pasta

Meat

Pizza

Potato

Porridge

Soup

800W

Issue 1 – 05/10/09

Instruction

Installation

Please Note Electrical connection

The oven is fitted with a plug and

must be only connected to a

properly installed earthed socket.

In accordance with the appropriate regulations,

be installed and

cable must only be replaced by a

qualified electrician.

no longer accessible following

installation and all-pole isolating

switch must

installation side with a contact gap

of at least 3mm.

Select a level surface that provide

enough open space for the intake

and/or outlet vents.

The rear surface of appliance shall be placed against a wall.

(1) The minimum installation height is 85cm.

(2) Leave a minimum clearance of 12 inches (30cm) above the oven. (3) Do not remove the legs from the bottom of the oven.

(4) Blocking the intake and/or outlet openings can damage the oven.

( ) Place the oven as far away from

radios and TV as possible.

Operation of microwave oven may

cause interference to your radio or TV

reception.

2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be void.

the socket must only

the connecting

If the plug is

be present on the

30cm

20cm

min85cm

Installation

EARTHING INSTALLATION

DANGER

Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard Improper earthing can result in electric shock. Do not plug into an outlet until appliance is properly installed and earthed. Three pin earthed plug

This appliance must be earthed. In the event of an electrical short circuit,grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a earthing

plug. The plug must be plugged into an outlet

that is properly installed and earthed. Consult a qualified electrician or serviceman if the earthing

instructions are not completely understood or if doubt exists as to whether the appliance is

necessary to use an extension cord, use only a 3-wire extension cord that has a 3 pin earthing plug, and a 3-slot socket which will

1. A short power-supply cord is provided to reduce the risks

resulting from becoming entangled in or tripping over a longer cord.

2. If an extension cord is used:

a. The marked electrical rating of the extension cord should be

at least as great as the electrical rating of the appliance.

b. The extension cord must be earthed, a 3-wire cord.

c. The extension cord should be arranged so that it will not

drape over the worktop or tabletop where it can be pulled on

by children or tripped over accidentally.

Properly polarised and earthed outlet.

properly earthed. If it is

accept the plug.

Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13 A plug complying with BS1363. lf this plug is unsuitable or needs to be replaced, please note

the following: Important: The wires in the mains lead are coloured in

accordance with the following code: GREEN / YELLOW – EARTH, BLUE – NEUTRAL, BROWN – LIVE For UK use only Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter

(E) or

by the earth symbol or coloured GREEN or

GREEN/YELLOW. The BLUE wire is the NEUTRAL and must be connected to the terminal marked with the letter (N) or coloured BLACK. The BROWN wire is the LIVE and must be connected to the terminal marked with the letter(L) or coloured RED. Always ensure that the plug cord grip is fastened correctly. If a 13A (BS 1363) fused plug is used it must be fitted with a 13A fuse conforming to BS1362 and be ASTA approved. If in doubt contact a qualified electrician.

OPERATING YOUR MICROWAVE OVEN

1 . CLOCK SETTING

Your microwave oven is equipped with a clock. You must set the clock when you first install your oven or after a power failure.

1) Press " ", "00:00" will be displayed and it is a 24 hours clock.

CLOCK/ PRE-SET

2) Press number buttons to set the hour and minute.

3) Finally, press " " and the time will be set.

CLOCK/ PRE-SET

For example: Set the time to 12:12pm.

1) Press " ";

CLOCK/ PRE-SET

2) Press "1", "2", "1", "2" to input the hour and minute and it displays "12:12";

3) Press " " and the time will be set.

CLOCK/ PRE-SET

Note: 1) ":" will flash when time has been set.

2) During the process of clock setting, if you press " ", the oven will go back to the previous status automatically.

4 . COMBINATION COOKING

2 . MICROWAVE COOKING

1) Press " " once to select the microwave cooking, continue to press " "

MICROWAVE

to select the required microwave power until the required power setting is reached.

2) Input the cooking time by pressing on the number buttons.

3) Press " " to start cooking.

Example: Setting cooking time of 20 minutes on power 80%.

1) Press " " twice to microwave power 80%.

MICROWAVE

2) Press "2", "0", "0", "0" to set the cooking time to 20 minutes.

3) Press " " to start cooking.

4) When the cooking is finished, the oven will beep 5 times.

OPERATING YOUR MICROWAVE OVEN

Microwave power chart

No. of time to press

on " " button

MICROWAVE

Microwave

power level

100%

Display

P100

Always remember that cooking instructions are intended only as a guide. If you have followed the instructions and the food is still not piping not throughout, simply return it to the oven and cook it until it is.

80%

50%

30%

10%

P 80

P 50

P 30

P 10

3. Grill Cooking

This function allows food to be cooked and grilled for browning at the same time.

(1) Press the " " button once to choose the grill function, the LED will display "G-1" .

(2) Set the cooking time, the maximum cooking time is 99 minutes and 99 seconds. Example: Set 12 minutes 50 seconds, press "1", "2", "5", "0" in order.

GRILL/ COMBI

(3) Press " " to start cooking.

4. Combination cooking (microwave + grill)

(1) Press the " " button twice or thrice to choose C1 or C2.

GRILL/ COMBI

Function Display

Microwave Power

Grill Power

Combi.1 C-1 55% 45%

Combi.2 C-2 36% 64%

(2) Set the cooking time, the maximum cooking time is 99 minutes and 99 seconds. Example: Set 12 minutes 50 seconds, press "1", "2", "5", "0" in order.

(3) Press " " to start cooking.

OPERATING YOUR MICROWAVE OVEN

4 . COMBINATION COOKING

5. DEFROST

This function help you to heat up the food under the microwave cooking.

A. Defrost By Weight

Example: Defrost beef of 500g:

(1) Press " ", LED will display "dEF1".

DEFROST BY W.T.

(2) Press "5", "0", "0" in order, "g" will light, the range of defrosting weight is 100g-2000g. (3) Press " " to start defrosting.

B. Speedy Defrost

Example: Defrost beef of 500g

(1) Press "

Speed Defrost

", LED will display "dEF2".

(2) Press "5" "0" "0" in order, "g" will light, the range of defrosting weight is 100g-1200g. (3) Press " " to start defrosting.

6 . MULTI-STAGE COOKING

This microwave can be set up to 2 stages cooking. Example: cook with 100% microwave power for 10 minutes + 50% microwave power for 5 minutes. The steps are as following:

1) Press " " once to choose 100% microwave power;

2) Press "1", "0", "0", "0" to set the cooking time of 10 minutes;

MICROWAVE

3) Press " " three times to choose 50% microwave power;

MICROWAVE

4) Press "5", "0", "0" to set cooking time of 5 minutes;

5) Press " " to start cooking. Note : (1) If one of the stages is defrosting, the defrost cooking will be started at the 1st

stage automatically. (2) The buzzer will ring once after each stage and the next stage will begin.

OPERATING YOUR MICROWAVE OVEN

SPEEDY MICROWAVE COOKING

In standby, press " " to start cooking with 100% microwave power for 30 seconds. If the remaining cooking time is less than one minute and 30 seconds, each press on " " button will increase 30 seconds. If the remaning cooking time is more than one minute and 30 seconds, each press on " " button will increase 1 minute. The maximum cooking time is 12 minutes.

Example : Set 3 minutes speedy cooking:

1) Press " " once to start cooking, LED will display "0:30".

2) Press "

8 .

Please ensure the clock has been set. If the clock is not yet set, please follow the section of "Clock Setting" to set the clock. The pre-set function cannot be activated if the clock is not set. Example: set cooking time at 12:12

1) Set cooking procedure; To cook the food with 80% microwave power for 15 minutes. a. Press " " twice to choose 80% microwave power and it displays "P80"; b. Press "1", "5", "0", "0" to set the cooking time to 15 minutes; c. Be careful do not press " " to start the cooking;

" again for 4 times, the cooking time will be 3 minutes.

PRE-SET FUNCTION

MICROWAVE

2) Press " " and current time will display;

CLOCK/ PRE-SET

3) Press "1", "2", "1", "2" to set pre-set cooking time at 12:12.

4) Press " " to confirm the setting and the cooking will start at 12:12. When the set time arrives, the buzzer sounds twice and cooking begins.

Note:

1) After the pre-set has been set, press " ", it will display the start time for the pre-set cooking.

CLOCK/ PRE-SET

2) Press " " twice to cancel the preset function.

OPERATING YOUR MICROWAVE OVEN

. MICROWAVE AUTO FUNCTION

This auto function has nine pre-programmed cooking. You do not need to set either cooking times or the power level. The table below shows the time taken to cook weight of food.

1). In standby states, select auto setting by pressing number buttons "1 to 9". It will display A-1 to A-9 respectively.

2). Continue to press the same number button to select the weight. i.e. portion / gram.

3). Press " " to start cooking

4). When the cooking is finished, the oven will beep 5 times.

OPERATING YOUR MICROWAVE OVEN

Auto menu Chart

A-1

Auto Reheat

A-2

Vegetable

A-3

Fish

A-4

Meat

A-5

Pasta

A-6

Potato

A-7

Pizza

A-8

Soup

A-9

Porridge

Weight(g)

150 250 350 400 150 350 500 150 250 350 400 450 150 300 450 600

50(with cold water 450g)

100(with cold water 800g)

150(with cold water 1200g)

1 portion (230g) 2 portion (460g) 3 portion (690g)

1 portion (80g) 2 portion (160g) 3 portion (240g)

500 750

1000

550

1100

Press Times

Once Twice Thrice

4 times

Once Twice Thrice

4 times 5 times

Once Twice Thrice

4 times

Once Twice Thrice

Once Twice

Display

150 250 350 400 150 350 500 150 250 350 400 450 150 300 450 600

50 100 150

1 2 3 1 2

3 500 750

1000

550

1100

Power

100%

80%

100%

80%

100%

80%

100%/50%

OPERATING YOUR MICROWAVE OVEN

10. Checking information-power / time

(1) In one stage cooking state, press " ", the current microwave power will be displayed for 3 seconds. After three seconds, the oven will turn back to the former state;

(2) In pre-set state, press " " to inquire the time for delay start cooking. The

CLOCK/ PRE-SET

MICROWAVE

pre-set time will flash for 2-3 seconds, then the oven will turn back to the clock display.

(3) In cooking state, press " " to inquire the current time. The current

CLOCK/ PRE-SET

time will flash for 2-3 seconds, then the oven will turn back to former states.

11. Lock-out Function for Children

Lock: In waiting state, press " " for 3 seconds, there will be a long beep denoting entering into the children-lock state and LED will display " ".

Lock quitting: In locked state, press " " for 3 seconds, there will be a long "beep" denoting that the lock is released.

WARMING UP, HEATING

Times stated are approximate and can vary depending on the quality, size of the chopped pieces, storage temperature and moisture content of the foodstuff. It is advisable to set a shorter cooking time at first, and then if necessary continue the cooking process, until the food is cooked to your satisfaction.

Foodstuff Quantity Output Level Time (Mins) Remarks Liquids

Milk, 1 cup 150g P100 (=100%)

Water/Coffee/Milk 1 cup 150g P100 (=100%)

Water 500g P100 (=100%)

One-course meals/ 450g P100 (=100%) Cover. Ready -to-serve meals Soups 250g P100 (=100%) Stir. Stews 500g P100 (=100%) Stir between times.

Meat / Poultry

Roast 250g P100 (=100%) Rissoles/Meatballs 500g P100 (=100%) 1/2 Chicken 450g P100 (=100%) Lightly brush with oil.

Vegetables

Portion x 1 150g P100 (=100%) Cover, stir. Portions x 2 300g P100 (=100%) Cover, stir.

Side Dishes

Noodles 150g P100 (=100%) Dampen slightly beforehand, cover, stir. Rice 150g P100 (=100%) Dampen slightly beforehand, cover, stir. Potatoes 500g P100 (=100%) Cover. Baby Food approx, 200g P100 (=100%) Stir well, check the temperature.

Meat

Beef, P ork in one piece 500g P 80 (= Cover, turn halfway through cooking, leave to stand. Lightly smoked pork loin 500g P 80 (=

Meatloaf P100 (=100%) Sausages 200g P 80 (= Pierce skin with fork.

Poultry

Chicken 1000g P100 (=100%) Cover, turn once, leave to stand for 5 minutes. Pieces of Chicken 250g P 80 (=80%)

Fish

Fresh fish 300g P 80 (= Cover, turn once, leave to stand for 3 minutes. Fillet of fish 300g P 80 (= 0%) Cover, turn once, leave to stand for 3 minutes. Frozen fish 400g P100 (=100%) Cover, leave to stand for 3 minutes.

Vegetables, fresh

Cauliflower, broccoli, fennel 150g P100 (=100%) Chop vegetables into small pieces, cook with liquid,

French beans 500g P100 (=100%) Potatoes, boiled potatoes 500g P100 (=100%) Jacket potatoes 500g P100 (=100%) Prick the jacket for boiling potatoes. Carrots 500g P100 (=100%) Vegetables, deep frozen Take note of details on the packaging. Leaf spinach 300g P100 (=100%) Cover, add some liquid, stir in between times, leave to

Peas 300g P100 (=100%) Leeks 200g P100 (=100%) Carrots 200g P100 (=100%) Brussel sprouts 250g P100 (=100%) Spinach 150g P100 (=100%)+

Deserts

Pudding/Flummery 500g P100 (=100%)

80%) 80%) 80%)

80%) 8

P 30 (= 30 %)

0.5 - 1

2. - 1

3 - 5

4 - 6 1 - 2

3 - 5 2 - 3

3 - 4 3 - 4

1 - 2 2 - 4

1 - 2 1 - 2 3 - 4

1 - 2 11 - 14 12 - 15

12 - 15

2 - 3

20 - 25

4 - 5 5 - 7

4 - 5

8 - 10

10 - 12

8 - 10 10 - 12

7 - 9 10 - 12

6 - 8

3 - 4 20 - 22

6 - 8

Caution: Stir the liquid prior to and during heating/ reheating, let liquid stand for at least 10 seconds after cooking and always take care when adding ingredients to hot liquids.

for 3-5 minutes.

(3-5 tablespoons), stir in between times leave to stand for 3-5 minutes, add spices, (salt before serving).

stand for 3 - 3 minutes.

CLEANINGYOURMICROWAVEOVEN

Attention

Your microwave oven should be cleaned regularly to prevent grease and food particles from building up on the inside surface. The accumulated grease / food particles may cause a fire hazard. It is important to clean the interior of your microwave oven after each use. To clean the oven interior, use a mild detergent solution, such as washing-up liquid, with warm water on a soft cloth. It is suggested to place half a lemon in a bowl and add 300ml water inside the oven. Then heat it on 100% microwave power setting for 10 minutes. Wipe the oven clean with a soft, dry cloth.

IMPORTANT:

ALWAYS switch off oven and unplug from power supply. ALWAYS use a branded cleaning spray, and for stubborn spots inside the oven, spray a small amount of cleaner onto a damp cloth. DO NOT SPRAY DIRECTLY INSIDE THE OVEN. Removable Parts

1. The turntable may be cleaned at the sink. Be careful not to chip or scratch the edges as this may cause the turntable to break during use.

2. The turntable roller rest should be cleaned regularly.

3. Do not immerse the turntable glass in cold water. Special Care For best performance and safety, the inner door panel and the oven front frame should be free of food residue. To prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation openings.

Troubleshooting and maintenance

NORMAL CONDITION

Microwave oven interfering with TV reception.

Radio and TV reception may be interfered with when microwave oven is in operation. It is similar to the interference of small electrical appliances such as food mixers, vacuum cleaners and electric fans. This is normal.

Oven light dim.

In low power microwave cooking, oven light may become dim. This is normal.

Steam accumulating on door, hot air out of vents.

In cooking, steam may come out of food. Most will come out from vents but some may condense on cool places such as the oven door. This is normal.

Oven started accidentally with no food in.

Although starting the oven with no food in it should be avoided, it does no damage to the oven provided it is only operated empty for a very short time. It is advised that a glass or microwave safe container of water is always left in the oven to absorb any heat should the oven be turned on accidentally.

MAINTENANCE

Troubleshooting

Check for problems by using the chart below. If the microwave oven still does not work properly, contact the nearest authorised service centre.

PROBLEM

Oven will not start

Arcing or sparking

a. Plug not secure in power socket, or not switched on. b. Door is open. c.

Wrong operation is set.

a. Materials which should be avoided in microwave oven are used. b. The oven is operated when empty. c. Spilled food remains in the cavity.

POSSIBLE CAUSE

Unevenly cooked food

Overcooked food

Undercooked food

Incomplete defrosting

Noise comes from turntable when oven is turned on

Oven light does not glow

a. Materials which should be avoided in microwave oven are used. b. Food is not defrosted completely. c. Power setting for cooking time is incorrect. d. Food is not turned or stirred.

Power setting for cooking time is incorrect.

a. Materials to be avoided in microwave oven are used. b. Food is not defrosted completely. c. Oven ventilation ports are restricted. d. Power setting for cooking time is incorrect.

a. Materials to be avoided in microwave oven are used. b. Power setting for cooking time is incorrect. c. Food is not turned or stirred.

a. Food residue exists between the turntable roller rest and cavity bottom.

a. The light bulb has burned out, a new bulb must be fitted by a qualified service engineer. b. START has not been pressed.

Questions and Answers

Troubleshooting

Q: When the oven is plugged into a wall outlet for the first time, it does not work properly. What's wrong? A: The microcomputer used in the oven control may temporarily become scrambled and fail to function as programmed. Unplug the oven from the wall outlet and then plug it back in. The microcomputer will then reset for proper functioning. Q: Why is there noise coming from the oven when using a lower power level? A: When cooking with power other than 100%, the oven automatically switches on and off to obtain the correct power output. The clicking noise can be heard when the oven switches on and off . This is normal Q: Why is there steam coming out of the air exhaust vent? A: Steam is produced during cooking. The microwave oven has been made to vent this steam. Q: What is wrong when the oven light will not glow? A: There may be several reasons why the oven light will not glow. The light bulb has burned out or ST ART has not been pressed. Q: Why do eggs sometimes burst? A: The egg yolk may burst because of steam build-up inside the membrane. Pierce the membrane with a toothpick before cooking it. Never microwave eggs in the the shell as they may explode. Q: How is boiling over avoided? A: Use a larger utensil than usual for cooking. If you open the oven door or touch STOP/CLEAR, the food will stop boiling.

IMPORTANT NOTES

1. Before first using this oven please read this instruction manual and keep it carefully.

2. Do not attempt to repair the oven yourself, please consult an authorised expert.

3. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature should be carefully checked before consumption, in order to avoid burns.

4. Check the oven and the cable regularly for damage. If there is any kind of damage, the oven should not be used. Warning: a. It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy . b. Never allow children to use the oven without supervision unless adequate instructions have been given so that the children are able to use the oven in a safe way and understand the hazards of improper use. c. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. NOTE

•

Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave

energy. It is important not to try and override or tamper with the safety interlocks.

•

Carefully clean door seals and sealing surfaces.

•

Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to

the, (1) door (i.e. door is not bent or dented), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

•

Utensils should be checked to ensure that they are suitable for use in microwave ovens.

•

When heating food in plastic or paper containers, check the oven frequently to avoid any possibility of ignition.

•

Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the contai ner.

•

If smoke is observed, switch off or unplug the appliance immediately and keep the door closed in order to stifle any flames.

•

Eggs in their shells and whole hard-boiled eggs should not be heated in microwave ovens since they may explode.

•

If the door or door seals are damaged the oven must not be operated until it has been repaired by a trained person.

•

Liquids or other foods must not be heated in sealed containers since they are liable to explode.

•

Warning: Children should only use this oven under adult supervision.

•

When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.

•

The temperature of accessible surfaces may be high when the appliance is operating. The surfaces are liable to get hot during use.

Keep cord away from heated surface, and do not cover any events on the oven.

•

Children should be supervised to ensure that they do not play with the appliance.

•

The appliances are not intended to be operated by means of an external timer or separate remote-control system. BULB REPLACEMENT If the interior light bulb fails, it can be easily replaced by a qualified service engineer . Do not attempt to remove the outercasing, as this will expose live components. Please consult a qualified service engineer .

Technical Specifications

Model

Power Source: Microwave Power Consumption:

Maximum Output:

Grill Power Consumption:

Oven Capacity: Turntable Diameter: External Dimensions (L x W x H): Net Weight:

EG820CFD(F)-PM

230-240V~50Hz 1200-12 0

Watt 750-800

Watt 950-1000

Watt

20 litres

255

Ø mm

439.5mm x 330mm x 258.2mm

10.7

Approx. Kg

We apologise for any inconvenience caused by any minor inconsistencies in these instructions, which may occur as a result of product improvements and development.

Guarantee

This product is guaranteed against manufacturing defects for a period of

This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced,

refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.

The guarantee is subject to the following provisions: y The guarantee does not cover accidental damage, misuse, cabinet parts, knobs or

consumable items.

y The product must be correctly installed and operated in accordance with the instructions

contained in this manual.

y It must be used solely for domestic purpose.

y The guarantee will be rendered invalided if the product is re-sold or has been damaged by

inexpert repair.

y Specifications are subject to change without notice. y The manufacturer disclaims any liability for the incidental or consequential damages. y The guarantee is in addition to, and does not diminish your statutory or legal rights. y In the event of a problem with the product within the guarantee period call the Customer

Helpline on

0870 600 8990

PRODUCT GUARANTEE

Year

Guarantor: Argos Ltd

489 - 499 Avebury Boulevard

Central Milton Keynes

MK9 2NW

PN:261800315130

Morphy Richards EG820CFD F -PM Instruction manual

Specifications and Main Features

Frequently Asked Questions

User Manual
