Morphy Richards Bagless Vacuum Cleaner User Manual

www.morphyrichards.com

Cyclonic bagless vacuum cleaner

Please read and keep these instructions

getting the best from your new cleaner...

If your cleaner isn’t picking up as well as it should, please check

• Dust canister

It is important to regularly empty the canister even if it does not appear full.

• Filters

It is important that the pleated filter is shaken clean each time the dust canister is emptied to allow air through the appliance. Wash the canister filters regularly in warm water and allow to air dry. A spare pleated filter is included.

• Blockages

Check the hose, tubes and tools for blockages

• Belt

Check and replace damaged or broken belt

• Height adjustment

The height adjustment only comes into effect when the handle is released by the handle release pedal

È.

VC73360MUK-CyclonicBaglessRev3 3/11/05 4:41 pm Page 1

Important safety instructions

The use of any electrical appliance requires

the following of common sense safety rules.

Primarily there is danger of personal injury and secondly danger of damage to the appliance and property. These are indicated in the instructions text by the following two conventions:

WARNING: Danger of personal injury

IMPORTANT: Damage to the appliance

In addition we offer the following essential safety advice.

Location

• Do not use or keep this product outside

when it is raining.

• Do not store the appliance near hot ovens or

heating appliances.

Mains lead

• Do not allow the mains lead to become

strained or run this appliance over it.

• If the electrical cable becomes damaged the

complete cable assembly must be replaced. Do not attempt this task yourself, contact Morphy Richards using the helpline number.

Children

• Children do not understand the dangers

associated with operating electrical appliances. Never allow children to use this appliance.

Other safety considerations

• Never use in the presence of explosive

liquids or vapours.

• Never pick up inflammable or poisonous

liquids such as petrol, copier toner, or other volatile substances. Never pick up acids, asbestos or asbestos dust.

• Never use the appliance without the filters

installed.

• Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or liquids.

• Never modify the cleaner in any way.

• Always disconnect the appliance from the

mains supply after use or prior to cleaning or emptying.

• The appliance should never be left running unsupervised.

• Repairs to electrical appliances are only to be undertaken by trained personnel. Unprofessional repairs can be dangerous for users.

• Use only genuine Morphy Richards spare parts and accessories

• Never over-extend the hose such that the cleaner is pulled over. If the cleaner is knocked over, switch off before attempting to upright.

• Never pick the cleaner up by the floor nozzle when connected to the mains, use the carrying handle.

• WARNING: Keep loose clothing, hair, fingers etc. away from the floor nozzle whenever the cleaner is connected to the mains.

• Disconnect from the mains supply before attempting to clear blockages, clear the brush or replace the belt.

Electrical requirements

Check that the voltage on the rating plate of your appliance corresponds with your house electricity supply which must be A.C. (Alternating Current).

If the socket outlets in your home are not suitable for the plug supplied with this appliance, the plug should be removed and the appropriate one fitted.

WARNING: The plug removed from the mains lead, if severed, must be destroyed as a plug with bared flexible cord is hazardous if engaged into a live socket outlet.

Should the fuse in the 13 amp plug require replacement, a BS1362 13 amp fuse must be fitted.

VC73360MUK-CyclonicBaglessRev3 3/11/05 4:41 pm Page 2

Features

⁄ Vari power slider (certain models only) ¤ Front cover release ‹ Removable front cover › Exhaust filter grille ﬁ Carpet height adjustment knob ﬂ Floor nozzle with powered brush ‡ Upper handle

· Flexible hose ‚ Cord storage with quick release cleat „ On/Off switch ‰ Carrying handle Â Nested extension tubes (2) Ê Crevice nozzle Á Furniture brush Ë Hose clip slot È Handle release pedal

Í Hose connector Î Dust canister release (shown page 5) Ï Dust canister lid Ì Pleated circular filter Ó Dust canister Ô Central mesh filter  Canister handle Ò Motor protection filter (shown page 6) Ú Exhaust filter (page 6) Û Belt cover (shown page 7) Ù Brush bar (page 7) ı Motor shaft (shown page 7) ˆ Brush bar end caps (shown page 7) ˜ Hose clip ¯ Turbo nozzle (certain models only) ˘ Belt guard (shown page 7)

Accessories included

Extension tubes

Crevice tool

Furniture brush

‡

ﬁ

›

ﬂ

‹

‚

‰

„

⁄



VC73360MUK-CyclonicBaglessRev3 3/11/05 4:41 pm Page 3
