Morphy Richards 501020 Instruction manual

1

F

P501020 MUK Rev 1

Please read and keep these instructions for future use

GUARANT EE

2

YEAR

* Register online for your 2 year guarantee. See the back of this instruction book for details (UK and Ireland customers only).

www.facebook.com/morphyrichardsuk

@loveyourmorphy

www.morphyrichards.co.uk/blog

For competitions, product hints and tips
and more join us at

Download the Morphy Richards

Cook & Create app for recipe ideas

Soup Maker

501020 Rev 1.qxp_Layout 1 26/08/2016 09:53 Page 1

2

In addition, we offer the following safety advice.

Location

• Always locate your appliance away from the edge of a

worktop.

• Ensure that the appliance is used on a firm, flat surface.

• Do not use the appliance outdoors, or near water.

Mains Cable

• The mains cable should reach from the socket to the base

unit without straining the connections.

• Do not let the mains cable hang over the edge of a

worktop where a child could reach it.

• Do not let the cable run across an open space e.g.

between a low socket and table.

• Do not let the cable run across a cooker or toaster or other

hot area which might damage the cable.

Personal Safety

• WARNING: To protect against fire, electric shock and

personal injury, do not immerse cord, plug and appliance
in water or any other liquid.

•

WARNING: Misuse of appliance could cause personal injury.

• WARNING: Avoid contact with moving parts.

• Extreme caution must be observed when moving an

appliance with hot contents.

• Do not use product with wet or moist hands.

• Unplug the appliance from the outlet when not in use and

before cleaning.

Treating Scalds

• Run cold water over the affected area immediately. Do not

stop to remove clothing, get medical help quickly.

Other Safety Considerations

• If the mains lead of this appliance is damaged do not use it.

Telephone Morphy Richards helpline for advice.

• The use of accessory attachments not recommended by the

manufacturer may cause damage to the unit.

• Do not place the appliance on or near heat sources such as

gas or electric stove, ovens, or burners.

• Keep the appliance and the cable away from heat, direct

sunlight, moisture, sharp edges and the like.

• When using the unit, ensure the lid is in place before

switching on.

• Do not remove the lid until the Serrator Blade has stopped.

• Do not operate the appliance for making soup

continuously.

• Be careful if hot liquid is poured into the Total Control Soup

Maker as it can be ejected out of the appliance due to sudden
steaming.

Electrical Requirements

Check that the voltage on the rating plate of your
appliance corresponds with your house electricity supply
which must be A.C. (Alternating Current).

WARNING: THIS APPLIANCE MUST BE EARTHED.

Should the fuse in the mains plug require changing a 13 amp
BS1362 fuse must be fitted.

Health And Safety

The use of any electrical appliance requires the following common sense safety rules.

Please read these instructions carefully before using the product.

• This appliance can be used by persons with reduced physical,

sensory or mental capabilities, or lack of experience and
knowledge, if they have been given supervision or instruction
concerning the use of the appliance in a safe way and
understand the hazards involved.

• Children shall not play with the appliance.

• The appliance shall not be used by children.

• Keep the appliance and cord out of the reach of children.

• After one operation cycle, you must allow the appliance to cool

down completely, then clean the appliance.

• This appliance is not intended to be operated by means of an

external timer or separate remote control system.

• If the supply cable is damaged, it must be replaced with a

special cable assembly available from the manufacturer or
its service agent.

• WARNING: The mixing blade is very sharp.

Handle with care when using and cleaning.

• For care and cleaning refer to pages 13 & 32.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:53 Page 2

3

I

ntroducing the Total Control Soup Maker – the

s

imple way to bring confidence to your cooking.

The Total Control Soup Maker is a multi-functional
design to give users the power to create with
confidence.

The Total Control Soup Maker features all the
functions you’d expect from the market leader,
but with extra innovative solutions allowing users
to make perfect soup from just 19 minutes.

W

ith sauté, reheat, keep warm and portion

c

ontrol functions, and 3 soup settings, users can

make soup, smoothies and juice to their taste.

Featuring a unique Removable Vessel, the Total
Control Soup Maker is a breeze to clean, and it
features a Pre-Clean function, so it can be used
again and again with no fuss.

With recipe inspiration from the dedicated Cook
and Create app, the Total Control Soup Maker
gives users the power to create with confidence.

Portion control

Total Control Panel

Pre-Clean

Giving you the power to create with confidence.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:53 Page 3

4

Health And Safety ........................................................ 2

Total Control ................................................................. 3

Introduction .................................................................. 4

Product Overview ........................................................ 5

Before First Use ............................................................ 6

How To Use Your Total Control Soup Maker ............... 6

How to Make Soup ...................................................... 7

How to Use Portion Control ........................................ 8

How to Use Sauté Function ........................................ 9

How to Use Drinks Function ........................................ 10

How to Use Reheat Function ...................................... 11

How to Use Blend Function ........................................ 12

How to Use Pre-Clean Function ................................. 13

A Dream To Clean ........................................................ 14

Using Your Total Control Soup Maker ........................ 15

The Benefits of Homemade Soup .............................. 16

What Makes Your Total Control

Soup Maker So Special ..............................................

16

Recipes ...................................................................... 17

FAQ’S ........................................................................... 31

Contact Us ................................................................... 33

Notes ............................................................................ 34

Guarantee ..................................................................... 36

Contents

Introduction

T

hank you for your recent purchase of the

M

orphy Richards Total Control Soup Maker.
Please read this instruction booklet carefully
b

efore you use your Total Control Soup Maker for

the first time.

W

e’ve designed your Total Control Soup Maker so
that it’s quick and easy to make homemade soup
a

nd smoothies to your own individual taste, with
minimum fuss. All you have to do is place the
ingredients needed for your favourite recipe

i

nside, then it’s as simple as selecting either the

s

mooth, medium or chunky soup setting or drinks
for juice and smoothies, depending on your
p

reference. A short wait while your Total Control
Soup Maker blends and gently cooks the
ingredients for perfectly delicious homemade
s

oup. It really couldn’t get any simpler!

Remember to visit www.morphyrichards.co.uk
to register your product’s two year guarantee.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:53 Page 4

5

P

R

E

C

L

E

A

N

D

R

I

N

K

S

START

STOP

PORTION

S

M

O

O

T

H

M

E

D

I

U

M

C

H

U

N

K

Y

S

A

U

T

E

R

E

H

E

A

T

MODE

P

M

B

L

E

N

D

1

2

9

5

6

8

1

0

1

1

1

2

4

2

3

1

3

1

4

2

4

2

2

1

8

1

9

2

0

1

5

1

6

1

7

3

7

2

1

2

5

Features

(10) Jug Body

(11) Jug Handle

(12) Power Socket

(13) Smooth Function Indicator

(14) Medium Function Indicator

(15) Chunky Function Indicator

(16) Sauté Function Indicator

(17) Drinks Function Indicator

(18) Reheat Function Indicator

(19) Blend Function Indicator

(20) Pre-Clean Function

Indicator

(21) LED Screen

(22) Mode Button

(23) Start/Stop Button

(24) Portion Button

(25) Keep Warm Indicator

Product Overview

(1) Lid Handle

(2) Control Panel

(3) Seal

(4) Lid

(5) Over Fill Sensor

(6) Motor Housing

(7) Removable Vessel

(8) Serrator Blade

(9) Vessel Release Button

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 5

6

4

Place the Lid (4) back onto the Jug Body (10)
ensuring it is securely in place.

You may need to twist the lid/motor housing
to allow the Blade (8) to pass through the
ingredients to locate the Lid (4) onto the
Jug Body (10) correctly.

3

Place all the ingredients into the Removable
Vessel (7). Add the liquid last, filling up to the
desired portion marked on the Removable
Vessel

(7). See individual recipes for more

information regarding liquid.

2

Remove the Lid (4), be careful not to touch
the Serrator Blade (8).

WARNING: Sharp Blade.

1

Ensure the Total Control Soup Maker is
unplugged from the mains.

5

Plug the lead into the Power Socket (12).

How To Use Your Total Control Soup Maker

It is important to clean your Total Control Soup Maker before first use or if it has not been used for a long
p

eriod of time. See the ‘Dream to clean’ section for more information.

When you first use your Total Control Soup Maker you may notice some smoke/vapour emitting from the
L

id, this is normal and is simply grease that is used on some parts of the appliance applied during the

manufacturing process. After using a few times this will stop.

Before First Use

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 6

7

How To Select Soup Function

1

START

STOP

P

ORTIONMODE

PM

Press the Mode Button (22) to select the
program. The Smooth Function Indicator (13)
will illuminate. Continue pressing Mode
Button (22) to go through the settings. Select
Smooth Function Indicator (13) for a smooth
soup.

2

START

STOP

P

ORTIONMODE

PM

Select Medium Function Indicator (14)
for a medium soup.

3

START

S

TOP

PORTIONMODE

PM

Select Chunky Function Indicator (15)
for a chunky soup.

4

START

S

TOP

P

ORTIONMODE

PM

Press the Start/Stop Button (23) and the
processing time will countdown on the
LED screen (21). Portion control is set to 2
portions. If 3 or 4 portions are required it
must be set before the Start/Stop Button (23)
is pressed. See portion control on page 8.

Smooth and drinks function will be set to
3 portions.

When finished, the Total Control Soup Maker
will beep for 10 seconds. Unplug from the
mains, remove the Lid

(4) and serve.

WARNING: Take care removing the Lid

(4)

when making soup to avoid splashing with
hot liquid and steaming.

5

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 7

8

How To Use Portion Control

5

START

STOP

PORTIONMODE

PM

After selecting your soup consistency press
the Portion Button

(24) to select the portion

of soup you would like to make (2, 3 or 4).

NOTE: Portion control available on certain
recipes only. Please see recipes from page
16 for details.

1

Ensure the Total Control Soup Maker is
unplugged from the mains. Remove the Lid

(4), be careful not to touch the Serrator Blade
(8). WARNING: Sharp Blade.

2

Fill up the Total Control Soup Maker to the
level shown on the Removable Vessel (7) for
the desired portion. See individual recipes for
more information.

4

START

STOP

P

ORTIONMODE

PM

Press the Mode Button (22) to select the
program. The Smooth Function Indicator (13)
will illuminate. Continue pressing Mode
Button (22) to go through the settings to
select your soup consistency.

6

START

STOP

PORTIONMODE

PM

Press the Start/Stop Button (23) and the
processing time will countdown on the
LED screen

(21). When finished, the Total

Control Soup Maker will beep for 10 seconds.
Unplug from the mains, remove the Lid (4)
and serve.

3

Place the Lid (4) back onto the Jug Body (10)
ensuring it is securely in place and plug the
Total Control Soup Maker into the mains.
See page 7.

NOTE: Depending on the type of soup you make the ingredients will absorb the added liquid
and can reduce in volume, hence the portions may be less than when started.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 8

9

How To Use Sauté Function

1

Ensure the Total Control Soup Maker is
unplugged from the mains. Remove the Lid

(4), be careful not to touch the Serrator Blade
(8). WARNING: Sharp Blade.

2

Add a little oil to the Removable Vessel (7). Plug
the Total Control Soup Maker into the mains.

3

START

S

TOP

PORTIONMODE

PM

Press the Mode Button (22) until the Sauté
Function Indicator (16) is highlighted.
Replace the Lid (4).

After a minute, remove the Lid

(4) and

carefully add the ingredients for sautéing to
the Removable Vessel (7). Replace the Lid (4)
and allow the program to continue.
You may need to remove the Lid and stir the
ingredients part way through, refer to
individual recipes from page 16.

WARNING: Add ingredients carefully to
avoid fat splashing.

4

START

STOP

P

ORTIONMODE

PM

Press the Start/Stop Button (23) and your
Soup Maker will now begin to heat up.

5

When finished press the Start/Stop Button

(23). Add the rest of the ingredients to the

Removable Vessel (7) and begin the soup
making process by selecting the desired
soup program as shown on page 7.

6

When the Lid (4) is removed during sauté function to stir or add ingredients simply replace the Lid

(4) to continue the process. The Lid (4) needs to be in place to continue sautéing. The Soup Maker

memory will retain the setting, there is no need to reset.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 9

10

How To Use Drinks Function

1

Ensure the Total Control Soup Maker is
unplugged from the mains. Remove the Lid

(4), be careful not to touch the Serrator Blade
(8). WARNING: Sharp Blade.

2

Place the ingredients for 3 or 4 portions into
the Removable Vessel (7). Add the liquid last.

4

START

STOP

PORTIONMODE

P

M

Press the Mode Button (22) until the Drinks
Function Indicator (17) is highlighted.

6

When finished, the Total Control Soup Maker
will beep for 10 seconds. Unplug from the
mains, remove the Lid (4) and serve.

5

START

STOP

PORTIONMODE

PM

Press the Start/Stop Button (23) and the
processing time will countdown on the
LED screen (21).

NOTE: Drinks function can be used for
3 and 4 portions only. Por tion size does
not need to be set.

3

Place the Lid (4) back onto the Jug Body (10)
ensuring it is securely in place and plug the
Total Control Soup Maker into the mains.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 10

11

How To Use Reheat Function

1

Ensure the Total Control Soup Maker is
unplugged from the mains. Remove the Lid

(4), be careful not to touch the Serrator Blade
(8). WARNING: Sharp Blade.

4

START

STOP

PORTIONMODE

P

M

Press the Mode Button (22) until the Reheat
Function Indicator (18) is highlighted. Press
the Portion Button (24) to select your portion
size (2, 3 or 4).

When finished, the Total Control Soup Maker
will beep for 10 seconds. Unplug from the
mains, remove the Lid

(4) and serve.

5

START

STOP

PORTIONMODE

PM

Press the Start/Stop Button (23) and the
processing time will countdown on the
LED screen (21) .

3

Place the Lid (4) back onto the Jug Body (10)
ensuring it is securely in place. Plug the Total
Control Soup Maker into the mains.

2

Place the home made soup you would like to
reheat into the Removable Vessel (7). 2
portions minimum, 4 portions maximum.

6

NOTE: The correct portion size must be selected on the control panel to match with the
portions of soup added, failure to do this will not heat the soup to the correct temperature.

Soup consistency may vary after the reheat process.

When reheating chunkier soups the soup will become smoother in consistency.

501020 Rev 1.qxp_Layout 1 26/08/2016 09:54 Page 11
