Morphy Richards 48951 User Manual

Juice extractor

Please read and keep these instructions

Odšťavovač

Přečtěte si tyto pokyny a uschovejte je.

∂

FP48951MCZ

FP48951MCZ-Rev1 9/1/07 3:35 pm Page 1

CONTENTS

Important safety instructions 2

lectrical requirements 3

Features 4

efore Use 5

ssembly 5

uicing 5

Speed Selector Table 6

After use 6

Cleaning 6

Top tips 6

Your guarantee 7

Getting the best from your new appliance...

Safety Do not operate the juice extractor for more than 5 minutes at a time. Allow to cool down for 5 minutes.

Always ensure the juice extractor is unplugged when assembling, disassembling or cleaning.

Do not remove cover until juice extractor has stopped.

Operation

Rinse mesh filter after each use to avoid blockages occuring.

IMPORTANT SAFETY INSTRUCTIONS

• The use of any electrical appliance requires the following basic common sense safety rules.

Primarily there is danger of injury or death and secondly the danger of damage to the appliance. These are indicated in the text by the following two conventions:

ARNING: Danger to the person!

IMPOR

TANT: Damage to the appliance!

In addition we offer the following essential safety advice.

FP48951MCZ-Rev1 9/1/07 3:35 pm Page 2

ocation

• Remove all packaging and retain for f

uture reference.

• Ensure the appliance is used on a firm, flat surface.

•

Do not use the appliance outdoors or in a bathroom.

•

Do not place the appliance on a h

ighly polished wooden surface as

amage may occur to the surface.

•

Do not place the appliance on or near a hot surface such as a hot plate or radiant rings or near a naked flame.

• Do not let the mains lead overhang the edge of the table or work-top, or touch hot surfaces.

Children

• Never allow a child to operate this appliance. Teach children to be aware of dangers in the kitchen, warn them of the dangers of reaching up to areas where they cannot see properly or should not be reaching.

• Young children should be supervised to ensure that they do not play with the appliance

Personal safety

• Avoid touching moving parts. Keep hands, hair, clothing as well as spatulas and other utensils away from appliance during operation, to prevent personal injury and/or damage to the appliance.

•

WARNING: To protect against risk of electric shock NEVER immerse the appliance body in water or in any other liquid and always ensur

e the electrical connections

are kept dry.

• This appliance is not intended for use by young children or infirm person unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safely

ther safety considerations

• Disconnect the appliance from the m

ains supply when not in use, before

aking off attachments and before

cleaning.

•

Do not operate any appliance with a d

amaged cord or plug or after the appliance malfunctions or has been damaged in any manner.

•

The power cord cannot be replaced. C

ontact Morphy Richards for advice.

•

The use of attachments or tools not recommended or sold by Morphy Richards may cause fire, electric shock or injury.

• Do not use the appliance for other than its intended use.

Product Specific Safety

• WARNING: The teeth in the mesh filter are very sharp. Handle with care when using and cleaning.

• Do not use the appliance if the mesh filter is damaged.

ELECTRICAL REQUIREMENTS

Check that the voltage on the rating plate of your appliance corresponds with your house electricity supply which must be A.C. (Alternating Current).

If the socket outlets in your home are not suitable for the plug supplied with this appliance, the plug should be removed and the appropriate one fitted.

WARNING: The plug removed from the mains lead, if severed, must be destr

oyed as a plug with

bar

ed flexible cord is hazardous if

engaged into a live socket outlet.

Where used, should the fuse in the 13amp plug require replacement, a 5 amp BS1362 fuse must be fitted.

WARNING: This appliance must be earthed.

FP48951MCZ-Rev1 9/1/07 3:35 pm Page 3

⁄

‹

›

‡

ﬁ

ﬂ

„

‚

‰

eatures

⁄ Small food pusher ¤ Large food pusher ‹ F

ruit shoot

› J

uice cover

ﬁ Mesh filter basket ﬂ Juice collector ‡ J

uice outlet spout

· M

otor base unit

‚ On/off/speed selector switch „ Locking arm ‰ C

ord storage

Â P

ulp collection container

Ê J

uice container

Á Removable froth guard

FP48951MCZ-Rev1 9/1/07 3:35 pm Page 4

efore use

WARNING: Never immerse the base unit in water.

•

Carefully unpack your juice extractor.

•

Lower the locking arm to remove t

he washable parts.

• Wash all parts except from the m

otor unit in hot soapy water. Rinse

ell and dry thoroughly. (see

leaning page 6).

•

All parts must be dry before mounting on the base unit.

• Wipe the base with a soft, clean cloth to remove small particles that may have collected during packing and handling.

Assembly

1 Place juice collector on top of the

motor base aligning the spout with the corresponding cut out in the base

2 Place the mesh filter basket inside,

pushing down to make sure it clicks firmly into place

3 Place the juicer cover on top

ensuring that the juice cover spout and outlet for the juice collector are aligned.

4 Lift the locking arm up and lock into

place on top of the juicer cover

NOTE: The juice extractor will not work if the locking arm is not correctly in place

IMPORTANT: Do not pick up the juice extractor using the locking arm.

Tilt the pulp container slightly to fit under the juice cover

6 Put the juice container under the

spout ensuring the froth guard is fitted correctly.

7 Place the large food pushers into

the food shoot and the small food pusher can be locked into place by rotating.

UICING

1 Plug the juicer into the electrical

socket.

2 E

nsure that both the juice container, pulp container and frothguard are in place.

3 M

ost fruit and vegetables can be put into the Juice Extractor with the peel in place. Ensure the fruit or v

egetables are throughly washed, to

emove any dirt or chemicals, if you

re concerned with the quality of the peel, remove it first. Remember w

hat you put into the Juicer, you

will get out as juice.

•

Citrus (eg. oranges, lemons) and thick fruit peel (eg. pineapple) must be removed first.

• Stones or large pips will have to be removed before juicing. Pips from apples and oranges are acceptable, anything larger or harder will need to be removed.

• Cut into suitable size pieces to fit into the fruit shoot. Usually apples need only to be cut in half.

4 Switch to the appropriate speed, as

indicated in the Speed Selector table.

5 If juicing larger pieces, use the large

food pusher (with the small pusher locked in place) apply gentle force, to press the fruit down

For juicing small pieces ie grapes, or carrots, unlock the small pusher (by rotating), place the large pusher in the fruit shoot, and feed the fruit/vegetables through the hole in the large pusher, apply gentle force to press the fruit down

Using the correct size pusher for the size of pieces being juiced is essential to pr

event splashing and

efficient juice yield.

6 With the motor running place food

into the fruit shoot.

WARNING: Always use the food pusher to push fruit into the feed tube.

Never use utensils or your fingers to push fruit down the feed tube. Ensure you use the food pusher at all times.

FP48951MCZ-Rev1 9/1/07 3:35 pm Page 5
