Hand Blender Set
48924 rev1_Layout 1 18/04/2012 09:37 Page 1
Please read and keep these instructions for future use
2
Features
(1) Speed Control
(2) Main Unit
(3) On Button
(4) Turbo Button
(5) Blending Leg
(6) Blade
(7) Whisk Gearbox
(8) Balloon Whisk
(9) Beaker
(10) Chopping Bowl Lid
(11) Chopping Blade
(12) Chopping Bowl
Product overview
48924 rev1_Layout 1 18/04/2012 09:37 Page 2
1
1
2
2
7
7
3
3
4
4
8
8
8
9
9
01
10
11
11
21
12
5
5
6
6
3
Move the Blade (6) through the food using an
up and down motion.
Select the speed on the Speed Control (1).
Hold the beaker steady in your other hand and
press and hold the On Button (3) to start.
Place the Blending Leg into the food to be
blended. We recommend using the Beaker (9)
for the best results.
Insert the Main Unit (2) into the Blending Leg
(5) and twist to secure into place.
Using your hand blender
Thank you for your recent purchase of this
Morphy Richards Hand Blender Set.
The hand blender set comes with a number of
attachments and a ‘quick twist’ connection
mechanism for safety.
Please read the instructions for information on
how to use each attachment throughly before
use.
Remember to visit www.morphyrichards.co.uk to
register your product’s two year guarantee.
• Wash the Blending Leg (5), Beaker (9), Balloon
Whisk (8), Chopping Blade (11) and Chopping
Bowl (12) in hot soapy water. Dry thoroughly
before use.
• Do not immerse the Main Unit (2) Whisk Gearbox
(7) or Chopping Bowl Lid (10) in water.
No parts are dishwasher safe.
• WARNING: Carefully unpack your hand blender
as the blades are very sharp.
Introduction
Before first use
Release the On Button to stop blending
BEFORE removing from the food
Twist the Blending Leg (5) to remove from the
Main Unit for cleaning. Rinse under running
water.
48924 rev1_Layout 1 18/04/2012 09:37 Page 3
11
33
55
2
4
66
4
Unplug from the mains before twisting the
Whisk Gearbox
(7) to unlock from the Main
Unit
(2). Pull the Balloon Whisk from the Whisk
Gearbox for cleaning.
To avoid splashing, select a slow speed on the
Speed Control
(1) and press and hold the On
Button
(3) to start. Release the button to stop
BEFORE removing the Balloon Whisk from the
food.
Place the Balloon Whisk into the ingredients.
Insert the Balloon Whisk (8) into the Whisk
Gearbox
(7). Attach the whisk onto the Main
Unit
(2).
Using the Balloon Whisk
1. Remove the saucepan from the heat.
2. To avoid excessive splashing, place the Blending
Leg (5) into the food before switching the Hand
Blender on.
3. Hold the pan steady with your other hand and
press the On Button (3). Use a low speed setting
to start and increase the speed as needed.
4. Move the Blade (6) through the food using a
up and down motion.
5. Allow the Blade to stop moving before removing
from the pan.
• WARNING: Lifting the Blade out of the food
while running, or using a high speed setting in a
small pan could splash hot liquid. Extra care
should be taken when using the Hand Blender
in this manner.
• Do not insert the hand blender into the food
past the join between the Main Unit
(2) and the
Blending Leg
(5).
• Ensure the power cable does not touch any hot
surfaces (including the side of the pan.)
• The hand blender has 8 different speeds as well
as a Turbo Button (4). Press the Turbo Button to
run the hand blender on speed 8 for intermittent
bursts.
• Note: The Chopping Bowl (12) attachment can
only be used with the Speed Control (1) set to the
highest setting or when using the Turbo Button
(4). Using on a lower setting may cause
irreparable damage to the Hand Blender.
• WARNING: Your hand blender set is designed
for intermittent use. Do not use continuously for
more than 1 minute. Allow to cool down for a
minimum of 5 minutes before further use.
• Do not use continuously for more than 10
seconds when lifted out of food.
Usage
Turbo Button
Blending in a saucepan
48924 rev1_Layout 1 18/04/2012 09:37 Page 4
11
33
2
44
5
Attach the Main Unit (2) to the Chopping Bowl
Lid, twist to secure into place.
Place the Chopping Bowl Lid (10) on the
Chopping Bowl. Twist to secure into place.
Place the food you wish to chop into the
Chopping Bowl. (Please refer to the maximum
quantities table on page 6)
CAREFULLY Insert the Chopping Blade (11)
into the Chopping Bowl (12).
Select the maximum speed on the Speed
Control
(1) and press and hold the On Button
(3) to start. Do not open the Lid while in use.
Using the Chopping bowl
Unplug from the mains before twisting the
Main Unit to detach from the Chopping Bowl
Lid.
CAREFULLY remove the Chopping Blade before
emptying the food from the Chopping Bowl.
Remove the Chopping Bowl Lid from the
Chopping Bowl.
48924 rev1_Layout 1 18/04/2012 09:37 Page 5
1
33
55
2
44
66
77
8
6
Blending Leg (5)
• The Blending Leg is designed for pureeing soft
foods for use in soups and baby food.
• The Blending Leg is not suitable for grinding
hard items such as coffee beans, ice, nuts, meat
or hard vegetables (raw potatoes, raw carrots
etc).
Balloon Whisk (8)
• The Balloon Whisk is ideal for whipping cream,
eggs and other soft foods. It should be used at
low speeds to avoid splashing.
• It is not suitable for stiffer mixtures such as cake
batter.
Chopping Bowl (12)
• The Chopper is suitable for chopping nuts, herbs,
boiled eggs and dried bread. The chopping bowl
should be used on maximum speed only.
• The Chopper is not suitable for grinding coffee
beans, ice or hard vegetables (raw potatoes, raw
carrots etc).
• When blending foods with strong colour (eg.
cooked carrots), the plastic parts of the appliance
may become discoloured. Wipe with cooking oil
to clean any discoloured parts.
• When blending using the Blending Leg (5), start
the process by plunging the blender into the
ingredients. This will ensure all the ingredients are
pulled into the blade to be processed. Continue
this movement until the mixture is to the desired
consistency.
• Do not lift the Blending Leg out of the mixture
completely when running, as splashing may
occur.
• WARNING: Always unplug the appliance from the
mains socket before cleaning and maintenance.
WARNING: Handle the blades with care as they
are sharp.
Wash the Blending Leg
(5) Beaker (9), Balloon
Whisk (8), Chopping Blade (11) and Chopping
Bowl
(12) thoroughly in hot soapy water. Dry
completely before reusing.
Clean the Main Unit
(2) Whisk Gearbox (7) or
Chopping Bowl Lid (10) with a damp cloth and
dry all the parts thoroughly.
WARNING: Never immerse the Main Unit, Whisk
Gearbox or Lid in water or any other liquid.
No parts are dishwasher safe.
Helpline
If you are having a problem with your appliance,
please call our Helpline, as we are more likely to
be able to help than the store you purchased the
item from.
Please have the product name, model number
and serial number to hand when you call to help
us deal with your enquiry quicker.
UK Helpline: 0844 871 0960
IRE Helpline: 1800 409 119
Spares: 0844 873 0726
Talk To Us
If you have any questions or comments, or want
some great tips or recipe ideas to help you get
the most out of your products, join us online:
Blog: www.morphyrichards.co.uk/blog
Facebook: www.facebook.com/morphyrichardsuk
Contact us
Care and cleaning
Top tips
Suitable foods
Ingredients Maximum Quantity Time
•
Onions • 200g • 3-8 seconds
• Carrots • 100g • 5-15 seconds
• Basil • 50g • 7-12 seconds
• Meat (fat free) • 100g • 7-13 seconds
• Peanuts • 100g • 5-15 seconds
Maximum quantities for use
in the Chopping Bowl (12)
• The amounts listed below should be used as a guide.
The Chopping Bowl (12) should not be filled more than half full.
48924 rev1_Layout 1 18/04/2012 09:37 Page 6
7
The use of any electrical appliance requires the following
common sense safety rules.
Primarily there is danger of injury or death and secondly
the danger of damage to the appliance. These are
indicated in the text by the following two conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance!
In addition, we offer the following safety advice.
Location
• This appliance is intended to be used in household and
similar applications such as:
farm houses;
by clients in hotels, motels and other residential type
environments;
bed and breakfast type environments.
It is not suitable for use in staff kitchen areas in shops,
offices and other working environments.
• Do not use outdoors or in a bathroom.
• Always locate your appliance away from the edge of the
worktop.
• Do not place a bowl when used with the appliance on a
highly polished wooden surface as damage may occur to
the surface.
• Do not place the appliance on or near a hot surface, such
as a hot plate or radiant rings or near a naked flame.
Mains cable
• Do not let the mains cable hang over the edge of the
worktop where a child could reach it.
• Do not let the lead run across an open space e.g.
between a low socket and a table.
• Do not let the cable run across a cooker or other hot area
which might damage the cable.
• The mains cable should reach from the socket to the
base unit without straining the connections.
• The power cord cannot be replaced. Contact Morphy
Richards for advice.
Personal safety
• Avoid touching moving parts. Keep hands, hair and
clothing, and utensils away from the hand mixer
attachment blades during operation, to prevent personal
injury and/or damage to the appliance.
• WARNING: To protect against the risk of electric shock,
NEVER immerse the appliance body in water or in any
other liquid and always ensure the electrical connections
are kept dry.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning the use of the appliance by a person
responsible for their safety.
Children
• Children do not understand the dangers associated with
operating electrical appliances. Never allow children to
use this appliance.
• Children should be supervised to ensure that they do not
play with the appliance.
• Teach children to be aware of dangers in the kitchen,
warn them of the dangers of reaching up to areas where
they cannot see properly or should not be reaching.
Other safety considerations
• Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions or has been
damaged in any manner.
• The use of attachments or tools not recommended or
sold by Morphy Richards may cause fire, electric shock
or injury.
• Do not use the appliance for anything other than it’s
intended purpose.
• Unplug from the outlet when not in use, or when left
unattended, and before assembling, disassembling or
cleaning.
Product specific safety
• WARNING: The blender blades are very sharp. Handle
with care when using and cleaning.
• WARNING: To protect against fire, electric shock and
personal injury, do not immerse the cord, plug or mixer in
water or other liquid.
• Do not clean the attachments under running water while
they are in position.
• Make sure the blender is switched off before connecting
to or disconnecting from the mains supply and when left
unattended.
Electrical requirements
Check that the voltage on the rating plate of your
appliance corresponds with your house electricity supply
which must be A.C. (Alternating Current).
If the socket outlets in your home are not suitable for the
plug supplied with this appliance, the plug should be re
moved and the appropriate one fitted.
WARNING : The plug removed from the mains lead, if
severed, must be destroyed, as a plug with a bared
flexible cord is hazardous if engaged into a live socket
outlet.
Should the fuse in the mains plug require changing, a 3
amp BS1362 fuse must be fitted.
Health and Safety
48924 rev1_Layout 1 18/04/2012 09:37 Page 7
FP48924 MUK Rev 1 04/12
The After Sales Division
Morphy Richards Ltd
Mexborough, South Yorkshire,
England, S64 8AJ
Helplines (office hours)
UK 0844 871 0960
Spare Parts 0844 873 0726
Republic of Ireland 1800 409 119
www.morphyrichards.com
IF YOU ARE HAVING A PROBLEM
WITH ONE OF OUR PRODUCTS, CALL
OUR HELPLINE:
UK: 0844 871 0960
EIRE: 1800 409 119
SPARES: 0844 873 0726
Your standard one year guarantee is extended for an
additional 12 months when you register the product within
28 days of purchase with Morphy Richards. If you do not
register the product with Morphy Richards within 28 days,
your product is guaranteed for 1 year. To validate your
2 year guarantee register with us online at
www.morphyrichards.co.uk
Or call our customer registration line
UK 0844 871 0962
IRE 1800 409 119
N.B. Each qualifying product needs to be registered with
Morphy Richards individually.
Please note that the 2 year guarantee is only available in
the UK and Ireland. Please refer to the one year guarantee
for more information.
It is important to retain the retailer’s receipt as proof of
purchase. Staple your receipt to this back cover for future
reference.
Please quote the following information if the product
develops a fault. These numbers can be found on the base
of the product.
Model no.
Serial no.
All Morphy Richards products are individually tested before
leaving the factory. In the unlikely event of any appliance
proving to be faulty within 28 days of purchase, it should
be returned to the place of purchase for it to be replaced.
If the fault develops after 28 days and within 12 months of
original purchase, you should contact the Helpline number
quoting Model number and Serial number on the product,
or write to Morphy Richards at the address shown.
You may be asked to return a copy of proof of purchase.
Subject to the exclusions set out below (see Exclusions),
the faulty appliance will then be repaired or replaced as
appropriate and dispatched usually within 7 working days
of receipt.
If, for any reason, this item is replaced or repaired during
the 1 year guarantee period, the guarantee on the new
item will be calculated from original purchase date.
Therefore it is vital to retain your original till receipt or
invoice to indicate the date of initial purchase.
To qualify for the 1 year guarantee, the appliance must
have been used according to the instructions supplied.
For example, crumb trays should have been emptied
regularly.
Morphy Richards shall not be liable to replace or repair the
goods under the terms of the guarantee where:
1 The fault has been caused or is attributable to accidental
use, misuse, negligent use or used contrary to the
manufacturer’s recommendations or where the fault has
been caused by power surges or damage caused in
transit.
2 The appliance has been used on a voltage supply other
than that stamped on the products.
3 Repairs have been attempted by persons other than our
service staff (or authorised dealer).
4 The appliance has been used for hire purposes or non
domestic use.
5 The appliance is second hand.
6 Morphy Richards reserves the right not to carry out any
type of servicing under the guarantee at its discretion
7 Plastic filters for all Morphy Richards kettles and coffee
makers are not covered by the guarantee.
8 Batteries and damage from leakage are not covered by
the guarantee.
• This guarantee does not confer any rights other than those
expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is offered
as an additional benefit and does not affect your statutory
rights as a consumer. Morphy Richards products are
intended for household use only. See usage limitations
within the location safety instructions.
Morphy Richards has a policy of continuous improvement
in product quality and design. The company, therefore
reserves the right to change the specification of
it’s models at any time.
For electrical products sold within the
European Community. At the end of the
electrical products useful life, it should not be
disposed of with household waste.
Please recycle where facilities exist. Check with
your Local Authority or retailer for
recycling advice in your country
Exclusions
Registering your 2 year
guarantee
Your 1 year guarantee
Disclaimer
48924 rev1_Layout 1 18/04/2012 09:37 Page 8
Loading...
