Morphy Richards 400505 Instruction manual

FP400505 MUK Rev 1

Please read and keep these instructions for future use

* Register online for your 2 year guarantee. See back of this instruction book for details. (UK and Ireland customers only)

www.facebook.com/morphyrichardsuk

@loveyourmorphy

www.morphyrichards.co.uk/blog

For competitions, product hints and tips and more join us at

download the free app

Hand Mixer

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 1

In addition, we offer the following safety advice.

Location

• Do not use outdoors or in a bathroom.

• Always locate your appliance away from the edge of the

worktop.

Mains cable

• Do not let the mains cable hang over the edge of the

worktop where a child could reach it.

• Do not let the lead run across an open space e.g.

between a low socket and a table.

• Do not let the cable run across a cooker or other hot area

which might damage the cable.

• The mains cable should reach from the socket to the

base unit without straining the connections.

• The power cord cannot be replaced. Contact Morphy

Richards for advice.

Other safety considerations

• Do not use the appliance for anything other than its

intended purpose.

• WARNING: Misuse of appliance could

cause personal injury.

• The use of attachments or tools not recommended or

sold by Morphy Richards may cause fire, electric shock or injury.

Product specific safety

• Do not operate any appliance with a damaged cord or

plug or after the appliance malfunctions or has been damaged in any manner.

Electrical requirements

Check that the voltage on the rating plate of your appliance corresponds with your house electricity supply which must be A.C. (Alternating Current). Should the fuse in the mains plug require changing, a 3 amp BS1362 fuse must be fitted.

The use of any electrical appliance requires the following common sense safety rules.

Please read these instructions carefully before using the product.

• This appliance can be used by persons with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

• Do not use your hand mixer continuously for longer than

6 minutes with the Beaters or 3 minutes with the Dough Hooks. After using for these lengths of time, allow to cool for 10 minutes.

• Avoid touching moving parts. Keep hands, hair and clothing, and

utensils away from the hand mixer attachments during operation, to prevent personal injury and/or damage to the appliance.

• Switch off the appliance and disconnect from the supply before

changing accessories or approaching parts that move in use.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

• Children shall not play with the appliance.

• This appliance shall not be used by children.

• Keep appliance and cord out of the reach of children.

• Unplug from the outlet when not in use, or when left unattended,

and before assembling, disassembling or cleaning.

• For cleaning refer to page 8.

Health And Safety

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 2

Health And Safety ......................................................... 2

Introduction .................................................................. 3

Total Control ................................................................. 4

Product Overview ........................................................ 5

Before First Use ........................................................... 6

Lock Button .................................................................. 6

Pulse Button ................................................................. 6

Inserting The Dough Hooks .......................................... 6

Inserting The Whisk ...................................................... 6

Inserting The Beaters ................................................... 6

Using Your Hand Mixer ................................................ 7

Top Tips ........................................................................ 8

Care And Cleaning ....................................................... 8

Recipes ......................................................................... 9

Guarantee ..................................................................... 24

Contents

hank you for your recent purchase of this Morphy Richards Total Control

Hand Mixer.

our Total Control Hand Mixer comes with Beaters, Dough Hooks and a Whisk enabling you to make a multitude of dishes. Please read the i

nstructions for information on how to use your Hand Mixer before use.

Remember to visit www.morphyrichards.co.uk to register your product’s t

wo year guarantee.

Introduction

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 3

Giving you the power to create with confidence.

ntroducing the Total Control Hand Mixer - the

simple way to bring confidence to your cooking.

The Total Control Hand Mixer combines ergonomic comfort and Smart Response Technology to give users the power to create with confidence.

Smart Response Technology allows you to have Total Control of the mixing process with the simple touch of a button. The Smart Response Technology gently feeds power into the hand mixer giving you perfect results every time.

eaturing variable speed control, speed lock and pulse functions, this mixer helps users maintain total control during the process. And with Smart R

esponse Technology, the soft start motor will

ease into any mixing task.

Simply select the right speed and this versatile mixer does all the hard work. And with whisk, dough hooks and beaters included, it can handle any food preparation task.

Plus the plug stores away neatly and easily in the base, making this mixer the perfect compact baking assistant.

Speed Lock and Pulse

Variable Speed Control

Vari-Speed Trigger

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 4

Features

(1) Speed Control Dial

(2) Vari-Speed Trigger

(3) Pulse

(4) Lock Button

(5) Release Button

(6) Sockets

(7) Beaters

(8) Dough Hooks

(9) Balloon Whisk

(10) Cord Storage/Stand

Product Overview

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 5

Before using your Total Control Hand Mixer for the f

irst time, wash the Beaters(7)Dough Hooks (8)

and Whisk (9) in warm soapy water, rinse and dry.

o not operate your Total Control Hand Mixer

ontinuously for more than 6 minutes with the

eaters or 3 minutes with the Dough Hooks. After using for these lengths of time, let your mixer cool down for 10 minutes before using again.

Your Hand Mixer has a Lock Button (4) that allows you to lock the speed reached from using the Vari-Speed Trigger (2). To operate press the Vari-Speed Trigger (2) to the desired speed, press the Lock Button (4). You can then remove your finger from the Vari-Speed Trigger

(2).

Your Hand Mixer has 5 different speeds utilising Total Control technology, as well as a Pulse Button (3). Press the Pulse Button (3) whilst holding the Vari-Speed Trigger (2) to run the Hand Mixer at high speed for intermittent bursts.

To store your Hand Mixer, wrap the cord into the space provided.

When fitting the Dough Hooks

(8) into the

ockets

(6),

the Dough Hook with the groove on

he shaft should be inserted into the Socket with

the sleeve.

Your Hand Mixer is supplied with one Whisk

(9).

This may be fitted in either Socket (6).

Your Hand Mixer is supplied with two Beaters

(7).

The Beaters (7) may be fitted in either Socket.

Inserting The Dough HooksBefore First Use

Lock Button

Important

Inserting The Whisk

Pulse Button

Cable Storage

Inserting The Beaters

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 6

After use switch off at the wall, unplug your Hand Mixer from the mains, and rest the Hand Mixer on its Stand (10). Press on the top edge of the Release Button (5) to remove the Beaters (7), Dough Hooks (8) or Whisk (9) for cleaning.

Turn Speed Control Dial (1) to the desired speed.

With your finger on the Vari-Speed Trigger (2) press to reach the desired speed, press the Pulse Button (3) to pulse at the selected speed if desired. With your finger is on the Vari-Speed Trigger (2), press the Lock Button

(4) to hold the desired speed you have

reached. Refer to page 6.

Increase speed gradually using the Vari-Speed Trigger (2). Remove your finger from the Vari-Speed Trigger (2) to switch off.

Place your mixer into the bowl of ingredients. Do not press the Vari-Speed Trigger (2) until it is placed in the mixing bowl.

Ensure your mixer is switched off and unplugged from the mains. Insert the Beaters

(7), Dough Hooks (8) or Whisk (9) into the

Sockets (6). See information on page 6. Switch on at the mains.

Using Your Total Control Hand Mixer

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 7

hen making dough, first mix the dry ingredients,

oils, fats or butter, with the Beaters

(7) for

pproximately 20-30 seconds on speed 2 until they form breadcrumbs. Change to the Dough Hooks

(8) and add the water using speed 2.

educe to speed 1 to knead the dough for

minute.

• Before cleaning, switch your Hand Mixer off and

unplug from the mains.

• Remove the Beaters, Dough Hooks or Whisk and

wash in warm soapy water, rinse and dry well.

• Wipe your mixer with a damp cloth. Do not use

any abrasive or solvent-based cleaner.

• The Beaters, Dough Hooks and Whisk are

dishwasher safe (We advise that they are placed in the top rack only or inside the cutlery basket.)

WARNING: Never immerse your Hand Mixer in water or other liquid.

Helpline

f you are having a problem with your Hand Mixer, please call our Helpline, as we are more likely to b

e able to help than the store you purchased the

item from.

Please have the product name, model number a

nd serial number to hand when you call to help

us deal with your enquiry quicker.

K Helpline: 0344 871 0944

RE Helpline: 1800 409 119

Spares: 0344 873 0710

Talk To Us

If you have any questions or comments, or want some great tips or recipe ideas to help you get the most out of your products, join us online:

Blog: www.morphyrichards.co.uk/blog

Facebook: www.facebook.com/morphyrichardsuk

Twitter: @loveyourmorphy

Website: www.morphyrichards.com

Top tips

Care And Cleaning

FP400505 MUK REV 1.qxp_Layout 1 07/04/2016 13:45 Page 8
