Morphy Richards 29007 User Manual

PLL Digital CD Clock Radio

29007 OPERATING INSTRUCTIONS

Illustration

14

17

22

78910111213

5

16

15

6

4

20

21

3

2
1

19

17

18

1 PTS button
2 Set / clock wake button
3 Down button
4 Mode button
5 Up button
6 Stop button
7 Play / pause button
8 Off button
9 Snooze button
10 Sleep button
11 Radio on / band button

12 Wake 1 button
13 Cancel button
14 Wake 2 button
15 Preset recall button
16 Preset set button
17 Speakers
18 Battery compartment (underneath)
19 Volume control
20 CD open / close button
21 LCD display
22 Earphone socket (rear of unit)

2

Display illustration

1 Track number / radio preset

7

6

2

45

3

number indicator
2 Random playback indicator
3 Repeat all indicator

8
9

4 Clock setting indicator
5 Wake to Radio indicator
6 Wake to cd indicator
7 Wake to buzzer indicator

10

8 Alarm / wake 1 indicator
9 Alarm / wake 2 indicator
10 AM / PM indicator
11 Clock digits

11

12

13

12 Function indicator
13 Radio frequency scale
14 Stereo indicator
15 Memory indicator

Speakers

The speakers are detachable
1 To remove the speakers hold in the clip at the rear of each speaker and slide the

speaker backwards.
2 Unwind the speaker wire to the length required. Position the speaker where

required (up to 2 metres away).

To re-insert the speakers
1 Wind the speaker wire back onto the pegs in the direction indicated on the

speaker.
2 Position the speaker flush with the main unit and slide forwards until a click is

heard.

1

15

14

3

Electrical requirements

Check the voltage on the rating plate of your clock radio corresponds with
your house electricity supply which must be A.C. (alternating current).
If the socket outlets in your home are not suitable for the plug supplied with
this appliance the plug should be removed and the appropriate one fitted.

IMPORTANT : THE PLUG IF SEVERED FROM THE MAINS LEAD MUST BE
DESTROYED AS A PLUG WITH A BARED FLEXIBLE CORD IS
HAZARDOUS IF ENGAGED INTO A LIVE SOCKET OUTLET.

Should the fuse in the 13 amp plug require changing a 3 amp BS1362 fuse
must be fitted.

Battery back-up facility (unit will work without a battery being fitted)

Your cd clock radio is equipped with a battery back-up facility.
1 Remove the battery compartment cover (underneath the unit) by

pushing in the clip and lifting off.
2 Insert a battery size 9 volts PP3/6LR61 (Ensure battery is inserted correctly).
3 Replace the battery compartment cover.

Should a power interruption occur the clock will continue to run, however, time
keeping will not be accurate. The time will be displayed but the backlight will be
extinguished to conserve battery life. The memory will retain details of the clock time
and alarm settings.
If the optional battery is not installed in case of the AC power failure the clock will
flash at 12:00 when power is restored. You will need to reset the clock and
alarm settings.

Battery back-up is designed to operate for a short period only.
If the unit is not to be used for a prolonged period, remove the battery to
avoid battery leakage.
In the interests of environmental safety : dispose of batteries safely.
