Morphy Richards 27005 User Manual
3 band RDS portable radio
27005 OPERATING INSTRUCTIONS
ILLUSTRATION
AC Input
socket
○ ○ ○ ○
+/-
Volume
Tone
control
Head
phone
socket
Telescopic aerial
Key
lock
Time
set
Traffic
Alarm button
Sleep
button
1/6...5/10
preset
buttons
Handle
grip
Distance
local switch
Snooze
Memory
Text
AF
Band
switch
Display
PTY
On/Off
1
CONTROLS
HEADPHONES - for headphones with 3.5mm jack plug. When connecting a
ON/OFF - to switch the radio on and off
VOLUME - to adjust the volume
TONE - For adjusting the treble/bass settings.
+/- - when radio is off, for setting the day of the week, clock time and
alarm time.
-When the radio is on, to start the station search (AUTO TUNING) or
to advance the frequency step by step (MANUAL TUNING)
-To select the respective alarm mode (radio alarm or buzzer alarm)
- Used with +/- to set the alarm time.
SNOOZE - to interrupt radio or buzzer alarm for approximately 5 minutes.
SLEEP -To switch on the radio for max. 90 minutes.
MEMORY - this button is used to store the tuned station in the memory
TEXT -to switch the radiotext display on and off.
DIST/LOCAL - to reduce sensitivity during FM reception
1/6 ....5/10 - station memory presets
AF - for switching to alternative frequencies (RDS)
FM/MW/LW - to select the waveband
DISPLAY - When the radio is off, used to display the alarm time
headphone to this socket, the built-in loudspeaker is
automatically switched off.
-To switch off the alarm (radio or buzzer) when alarm
function is activated
-To switch off the radio before the preset sleep time has elapsed
-When the radio is off, used with +/- to set the day of the week.
-To switch off the radio before the preset sleep time has elasped.
position you choose
-Press and hold to scroll the radio text quickly
-Local = Nearby stations
-DIST. = remote stations = normal setting
(press once for a number from 1 to 5 and twice for a
number from 6 to 10)
FM (VHF) = VHF waveband
MW = Mediumwave band
LW = Longwave band
-When the radio is on, used to switch display information
between RDS Name (if any), frequency and clock.
2
CONTROLS
PTY - press once to display the programme type of the current
programme.
-Press repeatedly to select a desired programme type and use the
+/- keys to search a station of the desired programme type.
TRAFFIC - When the radio is on, to switch the traffic announcement/EON
function on and off.
TIME SET - When the radio is off, use with the +/- to set the time
manually.
- When the radio is on, used to enable and disable the auto-time
function.
BASE OF THE RADIO
Key lock - to lock and unlock all buttons
REAR OF THE RADIO
AC mains input socket - for connecting the mains cable
BATTERY COMPARTMENT
-Insert four R14/size C batteries in the polarity indicated for radio operation.
-Insert two R03/AAA station memory backup batteries.
RESET
-Static charges of carpets etc. can effect the internal electronics which may
require resetting. Reset as follows:
1 Remove the batteries and disconnect the mains plug.
2 Reinstall them again after one minute.
-This resets the unit to its initial state. The stored data for the
individual station memory positions, the clock settings and the last
station memory are cleared.
DEMO MODE
Press the DISPLAY key for two seconds.
-The display will show a demo introducing briefly the RDS features available
in the radio.
- Press any key to stop the demo mode.
3
POWER SUPPL Y
BATTERY OPERATION
• Open the lid of the battery compartment (found at rear of unit)
• Insert 4 x R14/size C batteries. Ensuring correct polarity is observed.
• Close the battery compartment lid. (These batteries serve as a power
supply for radio operation without mains connection.
Back up batteries for clock and preset memory
• Place these batteries size RO3, AAA, alkaline type in the battery
compatment. These batteries should always be inserted, regardless of the
power supply (mains voltage or batteries).
If the unit is not to be used for a prolonged period, remove the batteries to
avoid leakage. In the interests of environmental safety, dispose of batteries
safely.
MAINS FAILURE
If the back-up batteries are fitted, the clock will continue to operate during
mains failure and the preset stations will be retained in the memory.
However, the display will not be illuminated and the alarm will not sound
unless the mains supply is restored within 90 minutes of the preset alarm
time.
MAINS OPERATION
The unit is designed to operate from a mains supply of 230v 50/60Hz.
• Connect one plug of the mains lead to the AC socket and the other
to the radio.The internal batteries will be automatically isolated.
Notes:
• Switch off the radio when connecting or disconnecting the mains cable.
• Remove the AC plug from the unit to use on the batteries.
The unit is only fully isolated from the mains when the wall plug is removed
from the wall socket.
If the socket outlets in your home are not suitable for the plug supplied
with this appliance the plug should be removed and the appropriate one
fitted.
IMP0RT ANT : THE PLUG REMOVED FROM THE MAINS LEAD, IF
SEVERED, MUST BE DESTROYED AS A PLUG WITH A BARED FLEXIBLE CORD IS HAZARDOUS IF ENGAGED INTO A LIVE SOCKET
OUTLET.
Should the fuse in the 13 amp mains plug require changing a 3 amp
BS1362 fuse must be fitted. The socket outlet should be installed near the
equipment and shall be easily accessible.
4
