4 ‘’ Outdoor Loudspeaker

USER MANUAL

Content Installation Requires

X4X4X4X2 X2

Mounting Speakers

Using the bracket supplied, first make location and

placement and then mount the bracket. For safety
reasons do not mount a speaker on a wall made of
unreinforced drywall or plasterboard. If you are not

sure consult a professional installer.

Attach the speakers to the brackets, lightly screw the
bracket knobs into the cabinet and Point the speaker
toward the listening area. Once the direction of the
speaker has been determined tighten the bracket knobs
securely.

Connecting Speakers Specifications

Construction

Drive Units

Frequency Response

Nominal Impedance

Power Handling

Peak Power Handling

Sensitivity 1 W/1 M

Please note:

These weather resistant speakers are manufactured to

resist a variety of weather conditions with UV paint

protection, stainless steel grills, and aluminium

brace.These speakers are not waterproof and cannot

submerged under water

Crossover Point

Dimension(W x H x D)

Weight

Finish

Morel operates a product design improvement policy consequently specifications are
subject to alterations without prior notice

Bass reflex with port

Woofer: 4.5"(115mm) Ferrite
magnet system.

Tweeter: 0.7" (20mm) soft
dome.
Powerful Neodymium magnet
system.

Ferrofluid damped and cooled.

65-20,000Hz

4 Ohm

30W

60W

90 dB

4000 Hz / 12 dB octave

6.7” X 9.8” X 6.1”
(172mm X 250mm X 155mm)

1.84 KG

White sanded finish
