2021 DODGE CHALLENGER OWNER’S MANUAL

Page 2

This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle. FCA US LLC reserves the right to make changes in design and specications, and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.

With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution therefore. If you are the rst registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Warranty Booklet by calling 1-800-423-6343 (U.S.) or

1-800-387-1143 (Canada) or by contacting your dealer. This Owner’s Manual is intended to familiarize you with the important features of your vehicle. Your most up-to-date Owner’s Manual, Navigation/Uconnect manuals and

Warranty Booklet can be found by visiting the website on the back cover. U.S. residents can purchase replacement kits by visiting www.techauthority.com and Canadian residents can purchase replacement kits by calling 1-800-387-1143.

WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when servicing your vehicle. For more information go to www.P65Warnings.ca.gov/passenger-vehicle.

Page 3

TABLE OF CONTENTS

1 INTRODUCTION.............................................................................................................................. 8

2 GETTING TO KNOW YOUR VEHICLE ..................................................................................13

3 GETTING TO KNOW YOUR INSTRUMENT PANEL ........................................................67

4 STARTING AND OPERATING ................................................................................................ 86

5 MULTIMEDIA ............................................................................................................................... 132

6 SAFETY .........................................................................................................................................198

7 IN CASE OF EMERGENCY .................................................................................................... 252

8 SERVICING AND MAINTENANCE ...................................................................................... 275

9 TECHNICAL SPECIFICATIONS ............................................................................................ 335

10 CUSTOMER ASSISTANCE .....................................................................................................344

11 INDEX .............................................................................................................................................349

Page 4

INTRODUCTION

Symbols Key............................................................ 9

VEHICLE MODIFICATIONS/ALTERATIONS........... 9

Symbol Glossary...................................................10

GETTING TO KNOW YOUR VEHICLE

KEYS ......................................................................13

Key Fob......................................................... 13

SENTRY KEY ..........................................................16

IGNITION SWITCH .................................................16

Keyless Enter-N-Go — Ignition.....................16

REMOTE START — IF EQUIPPED ........................18

How To Use Remote Start ...........................18

To Exit Remote Start Mode ......................... 19

Remote Start Front Defrost Activation —

If Equipped ................................................... 20

Remote Start Comfort Systems —

If Equipped ................................................... 20

Remote Start Windshield Wiper De–Icer

Activation — If Equipped.............................. 21

Remote Start Cancel Message —

If Equipped ................................................... 21

VEHICLE SECURITY SYSTEM — IF EQUIPPED .. 21

To Arm The System...................................... 21

To Disarm The System ................................22

Rearming The System ................................. 22

Security System Manual Override .............. 22

Tamper Alert................................................. 22

DOORS .................................................................. 22

Manual Door Locks...................................... 22

Power Door Locks ....................................... 23

Keyless Enter-N-Go — Passive Entry........... 24

Automatic Unlock Doors On Exit................. 26

Automatic Door Locks —

If Equipped................................................... 26

STEERING WHEEL ................................................ 27

Manual Tilt/Telescoping Steering Column —

If Equipped .................................................. 27

Power Tilt/Telescoping Steering Column —

If Equipped .................................................. 27

Heated Steering Wheel —

If Equipped .................................................. 28

UCONNECT VOICE RECOGNITION ...................... 28

Introducing Voice Recognition.................... 28

Basic Voice Commands............................... 29

Get Started................................................... 29

Additional Information................................. 29

DRIVER MEMORY SETTINGS — IF EQUIPPED ..30

Programming The Memory Feature............ 30

Linking And Unlinking The Key Fob

To Memory ................................................... 31

Memory Position Recall .............................. 31

SEATS.....................................................................31

Manual Adjustment (Front Seats) —

If Equipped................................................... 32

Manual Adjustment (Rear Seats) ............... 33

Power Adjustment (Front Seats) —

If Equipped................................................... 34

Heated Seats — If Equipped ...................... 35

Front Ventilated Seats —

If Equipped................................................... 36

Vehicles Without Passenger Seating

Installed........................................................ 36

Passenger Seat Easy Entry ........................ 37

Head Restraints .......................................... 38

MIRRORS ..............................................................39

Inside Rearview Mirror ................................ 39

Illuminated Vanity Mirrors .......................... 40

Outside Mirrors............................................ 40

Power Mirrors............................................... 41

Heated Mirrors — If Equipped..................... 41

Page 5

UNIVERSAL GARAGE DOOR OPENER

(HOMELINK®) ......................................................41

Before You Begin Programming

HomeLink® .................................................. 41

Erasing All The HomeLink® Channels........42

Identifying Whether You Have A Rolling

Code Or Non-Rolling Code Device ..............42

Programming HomeLink® To A Garage

Door Opener.................................................42

Programming HomeLink® To A

Miscellaneous Device.................................. 43

Reprogramming A Single HomeLink®

Button...........................................................44

Canadian/Gate Operator Programming..... 44

EXTERIOR LIGHTS.................................................45

Headlight Switch.......................................... 45

Multifunction Lever...................................... 46

Daytime Running Lights (DRLs) —

If Equipped ................................................... 46

High/Low Beam Switch ............................... 46

Automatic High Beam Headlamp Control —

If Equipped .................................................. 46

Flash-To-Pass ............................................... 47

Automatic Headlights .................................47

Parking Lights .............................................47

Automatic Headlights With Wipers ............. 47

Headlight Time Delay ..................................48

Lights-On Reminder .................................... 48

Fog Lights — If Equipped .............................48

Turn Signals ................................................48

Lane Change Assist — If Equipped .............49

INTERIOR LIGHTS ................................................ 49

Front Map/Reading Lights ......................... 49

Ambient Light — If Equipped ....................... 49

Dimmer Controls.......................................... 50

WINDSHIELD WIPERS AND WASHERS............. 51

Windshield Wiper Operation ....................... 51

Rain Sensing Wipers — If Equipped............ 52

CLIMATE CONTROLS ........................................... 53

Automatic Climate Control Descriptions

And Functions ............................................. 53

Automatic Temperature Control (ATC) ...... 56

Climate — Voice Recognition....................... 57

Operating Tips ............................................. 57

INTERIOR STORAGE AND EQUIPMENT ............. 59

Storage ......................................................... 59

Illuminated Cupholders —

If Equipped................................................... 59

USB/AUX Control .........................................60

Power Outlets............................................... 60

WINDOWS ............................................................ 62

Power Window Controls .............................. 62

Wind Buffeting ............................................. 62

POWER SUNROOF — IF EQUIPPED.................... 63

Opening And Closing The Sunroof.............. 63

Pinch Protect Feature.................................. 64

Venting Sunroof ........................................... 64

Sunshade Operation.................................... 64

Sunroof Maintenance.................................. 64

Ignition Off Operation ..................................64

HOOD......................................................................64

Opening The Hood ...................................... 64

Closing The Hood......................................... 65

TRUNK....................................................................65

Opening The Trunk ...................................... 65

Closing The Trunk........................................ 66

Trunk Safety................................................. 66

GETTING TO KNOW YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER .......................................67

Instrument Cluster Descriptions................. 68

INSTRUMENT CLUSTER DISPLAY.......................69

Location And Controls ................................. 69

Engine Oil Life Reset ................................... 70

Performance Shift Indicator (PSI) —

If Equipped................................................... 71

Instrument Cluster Display Selectable

Menu Items.................................................. 71

Battery Saver On/Battery Saver Mode Message — Electrical Load Reduction

Actions — If Equipped ................................. 74

WARNING LIGHTS AND MESSAGES ..................76

Red Warning Lights ..................................... 76

Yellow Warning Lights ................................. 79

Yellow Indicator Lights ................................ 82

Green Indicator Lights................................. 82

White Indicator Lights ................................. 83

Blue Indicator Lights ................................... 83

Page 6

ONBOARD DIAGNOSTIC SYSTEM — OBD II ......83

Onboard Diagnostic System

(OBD II) Cybersecurity.................................. 84

EMISSIONS INSPECTION AND MAINTENANCE

PROGRAMS ...........................................................84

STARTING AND OPERATING

STARTING THE ENGINE .......................................86

Manual Transmission — If Equipped ..........86

Automatic Transmission —

If Equipped ................................................... 86

Normal Starting............................................ 87

AutoPark.......................................................88

Cold Weather Operation

(Below –22°F Or −30°C) ........................... 89

If Engine Fails To Start ................................89

After Starting................................................ 90

ENGINE BLOCK HEATER — IF EQUIPPED ..........90

ENGINE BREAK-IN RECOMMENDATIONS —

3.6L & 5.7L ..........................................................90

PARKING BRAKE ..................................................91

MANUAL TRANSMISSION — IF EQUIPPED ........92

Six-Speed Manual Transmission ................92

Shifting .........................................................93

Recommended Shift Speeds ......................94

1–4 Skip Shift ............................................. 94

Downshifting ................................................ 95

AUTOMATIC TRANSMISSION —

IF EQUIPPED ........................................................ 95

Ignition Park Interlock ................................. 96

Brake Transmission Shift Interlock

(BTSI) System .............................................. 96

Eight-Speed Automatic Transmission ........96

SPORT MODE — WITHOUT PERFORMANCE

CONTROL.............................................................102

FUEL SAVER TECHNOLOGY 5.7L —

IF EQUIPPED .......................................................102

ELECTRIC POWER STEERING...........................103

CRUISE CONTROL SYSTEMS — IF EQUIPPED ... 103

Cruise Control — If Equipped ....................103

Adaptive Cruise Control (ACC) —

If Equipped.................................................106

PARKSENSE REAR PARK ASSIST —

IF EQUIPPED .......................................................115

ParkSense Sensors ...................................115

ParkSense Display.....................................115

ParkSense Warning Display...................... 118

Enabling And Disabling ParkSense ..........118

Service The ParkSense Rear Park

Assist System.............................................118

Cleaning The ParkSense System..............118

ParkSense System Usage Precautions ....119

PARKVIEW REAR BACK UP CAMERA..............120

REFUELING THE VEHICLE..................................121

Loose Fuel Filler Cap Message................. 122

VEHICLE LOADING ............................................ 122

Vehicle Certification Label ........................ 122

Gross Vehicle Weight Rating (GVWR)....... 122

Gross Axle Weight Rating (GAWR) ........... 122

Overloading................................................123

Loading ......................................................123

TRAILER TOWING ............................................. 123

Common Towing Definitions.....................123

Trailer Hitch Classification ........................ 124

Trailer Towing Weights (Maximum Trailer

Weight Ratings) .........................................125

Trailer And Tongue Weight ....................... 126

Towing Requirements ...............................126

Towing Tips ...............................................129

RECREATIONAL TOWING (BEHIND

MOTORHOME) ................................................... 129

DRIVING TIPS ..................................................... 130

Driving On Slippery Surfaces ....................130

Driving Through Water .............................130

MULTIMEDIA

UCONNECT SYSTEMS ....................................... 132

CYBERSECURITY ............................................... 132

UCONNECT SETTINGS ...................................... 133

Customer Programmable Features..........133

UCONNECT INTRODUCTION.............................. 147

System Overview ......................................147

Drag & Drop Menu Bar..............................149

Safety And General Information ............... 149

Page 7

UCONNECT MODES ........................................... 150

Steering Wheel Audio Controls .................150

Radio Mode ...............................................151

Media Mode ..............................................162

Phone Mode ..............................................165

ANDROID AUTO™ & APPLE CARPLAY® —

IF EQUIPPED....................................................... 177

Android Auto™ ...........................................177

Apple CarPlay® ..........................................180

Android Auto™ And Apple CarPlay®

Tips And Tricks...........................................182

PERFORMANCE PAGES .................................... 182

Home ..........................................................184

Timers.........................................................186

Gauges .......................................................188

G-Force .......................................................189

Engine.........................................................190

Dynamometer (DYNO) ...............................191

DODGE DRIVE MODES — IF EQUIPPED........... 191

Performance Control —

If Equipped .................................................191

RADIO OPERATION AND MOBILE PHONES.... 197

Regulatory And Safety Information...........197

SAFETY

SAFETY FEATURES.............................................198

Anti-Lock Brake System (ABS) ................. 198

Electronic Brake Control (EBC) System ...199

AUXILIARY DRIVING SYSTEMS.........................204

Blind Spot Monitoring (BSM) —

If Equipped.................................................204

Forward Collision Warning (FCW)

Operation - If Equipped .............................208

Tire Pressure Monitoring System (TPMS)... 210

OCCUPANT RESTRAINT SYSTEMS ..................214

Occupant Restraint Systems Features ....214

Important Safety Precautions...................214

Seat Belt Systems .....................................215

Supplemental Restraint Systems (SRS)...223

Child Restraints ........................................232

SAFETY TIPS ......................................................248

Transporting Passengers ..........................248

Transporting Pets .....................................248

Safety Checks You Should Make Inside

The Vehicle ................................................248

Periodic Safety Checks You Should Make

Outside The Vehicle...................................250

Exhaust Gas ...............................................250

Carbon Monoxide Warnings......................251

IN CASE OF EMERGENCY

HAZARD WARNING FLASHERS....................... 252

ASSIST AND SOS MIRROR — IF EQUIPPED.... 252

JACKING AND TIRE CHANGING ....................... 256

Preparations For Jacking ..........................257

Jack Location/Spare Tire Stowage ..........257

Jacking And Changing A Tire .................... 258

TIRE SERVICE KIT — IF EQUIPPED................... 261

Tire Service Kit Storage.............................261

Tire Service Kit Components And

Operation ...................................................261

Tire Service Kit Usage Precautions .......... 262

Sealing A Tire With Tire Service Kit ..........263

JUMP STARTING ............................................... 267

Preparations For Jump Start..................... 267

Jump Starting Procedure ..........................268

IF YOUR ENGINE OVERHEATS ......................... 269

MANUAL PARK RELEASE — 8 – SPEED

TRANSMISSION ................................................ 270

FREEING A STUCK VEHICLE ............................. 271

TOWING A DISABLED VEHICLE........................ 273

Rear-Wheel Drive (RWD) Models.............. 274

ENHANCED ACCIDENT RESPONSE

SYSTEM (EARS) ................................................. 274

EVENT DATA RECORDER (EDR)....................... 274

Page 8

SERVICING AND MAINTENANCE

SCHEDULED SERVICING .................................. 275

3.6L And 5.7L Engines .............................275

ENGINE COMPARTMENT ..................................280

3.6L Engine ...............................................280

5.7L Engine ...............................................281

Checking Oil Level......................................282

Adding Washer Fluid..................................283

Maintenance-Free Battery ........................283

Pressure Washing......................................284

VEHICLE MAINTENANCE................................... 284

Engine Oil ..................................................284

Engine Oil Filter..........................................286

Engine Air Cleaner Filter ...........................286

Air Conditioner Maintenance ...................287

Accessory Drive Belt Inspection................289

Body Lubrication........................................289

Windshield Wiper Blades ..........................290

Exhaust System .........................................291

Cooling System ..........................................292

Brake System ............................................295

Clutch Hydraulic System — Manual

Transmission (If Equipped) ....................... 296

Manual Transmission — If Equipped ........296

Automatic Transmission —

If Equipped.................................................297

All Wheel Drive (AWD) —

If Equipped ................................................298

Rear Axle ....................................................298

Fuses ..........................................................298

Bulb Replacement .....................................308

TIRES................................................................... 311

Tire Safety Information .............................311

Tires — General Information ....................319

Tire Types ................................................... 324

Spare Tires — If Equipped ......................... 325

Wheel And Wheel Trim Care ....................327

Snow Traction Devices..............................328

Tire Rotation Recommendations..............329

DEPARTMENT OF TRANSPORTATION UNIFORM

TIRE QUALITY GRADES .................................... 330

Treadwear .................................................. 330

Traction Grades .........................................330

Temperature Grades ................................. 330

Page 9

VEHICLE STORAGE ........................................... 331

BODYWORK........................................................ 331

Protection From Atmospheric Agents.......331

Body And Underbody Maintenance ..........332

Preserving The Bodywork..........................332

INTERIORS ......................................................... 333

Seats And Fabric Parts..............................333

Plastic And Coated Parts...........................333

Leather Surfaces .......................................334

Glass Surfaces ..........................................334

TECHNICAL SPECIFICATIONS

VEHICLE IDENTIFICATION NUMBER (VIN)....... 335

BRAKE SYSTEM ................................................ 335

WHEEL AND TIRE TORQUE

SPECIFICATIONS................................................ 335

Torque Specifications................................335

FUEL REQUIREMENTS ......................................336

3.6L Engine................................................336

5.7L Engine (With Automatic

Transmission) ............................................337

5.7L Engine (With Manual

Transmission) ............................................337

Reformulated Gasoline ............................337

Materials Added To Fuel ...........................337

Gasoline/Oxygenate Blends .....................337

Do Not Use E-85 In Non-Flex Fuel

Vehicles ......................................................338

CNG And LP Fuel System Modifications...338 Methylcyclopentadienyl Manganese

Tricarbonyl (MMT) In Gasoline..................338

Fuel System Cautions................................339

FLUID CAPACITIES .............................................340

ENGINE FLUIDS AND LUBRICANTS .................341

CHASSIS FLUIDS AND LUBRICANTS ...............343

CUSTOMER ASSISTANCE

SUGGESTIONS FOR OBTAINING SERVICE

FOR YOUR VEHICLE .......................................... 344

Prepare For The Appointment ..................344

Prepare A List.............................................344

Be Reasonable With Requests.................344

IF YOU NEED ASSISTANCE .............................. 344

FCA US LLC Customer Center...................345

FCA Canada Inc. Customer Center...........345

Mexico ........................................................ 345

Puerto Rico And US Virgin Islands............345

Customer Assistance For The Hearing Or

Speech Impaired (TDD/TTY) .....................345

Service Contract .......................................345

WARRANTY INFORMATION.............................. 346

MOPAR PARTS................................................... 346

REPORTING SAFETY DEFECTS ........................ 346

In The 50 United States And

Washington, D.C. .......................................346

In Canada...................................................347

PUBLICATION ORDER FORMS ........................ 347

General Information.......................................... 348

Page 10

INTRODUCTION

Dear Customer,

Congratulations on the purchase of your new Dodge vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This Owner's Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by customer-oriented documents. Within this information, you will find a description of the services that FCA US LLC offers to its customers as well as the details of the terms and conditions for maintaining its validity. Please take the time to read all of these publications carefully before driving your vehicle for the first time. Following the instructions, recommendations, tips, and important warnings in this manual will help ensure safe and enjoyable operation of your vehicle.

This Owner’s Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or versions are not expressly indicated in the text. Therefore, you should only consider the information that is related to the trim level, engine, and version that you have purchased. Any content introduced throughout the Owner’s Information, which may or may not be applicable to your vehicle, will be identified with the wording “If Equipped”. All data contained in this publication are intended to help you use your vehicle in the best possible way. FCA US LLC aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer.

When it comes to service, remember that authorized dealers know your Dodge best, have factory-trained technicians and genuine MOPAR® parts, and care about your satisfaction.

Page 11

SYMBOLS KEY

These statements are against operating

WARNING!

CAUTION!

NOTE:

TIP:

PAGE REFERENCE ARROW

FOOTNOTE

If you do not read this entire Owner’s Manual, you may miss important information. Observe all Cautions and Warnings.

procedures that could result in a collision, bodily injury and/or death.

These statements are against procedures that could result in damage to your vehicle.

A suggestion which will improve installation, operation, and reliability. If not followed, may result in damage.

General ideas/solutions/suggestions on easier use of the product or functionality.

Follow this reference for additional information on a particular feature.

Supplementary and relevant information pertaining to the topic.

VEHICLE MODIFICATIONS/ALTERATIONS

WARNING!

Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death.

WARNING!

To prevent SERIOUS INJURY or DEATH when using “Track-Use” parts and equipment:

 NEVER use any “Track-Use” equipment on public roads. FCA US LLC

does not authorize the use of “Track-Use” equipment on public roads.

 The intended use of “Track-Use” parts is for race vehicles on race

tracks. To help ensure the safety of the race driver, engineers should supervise the installation of “Track-Use” parts.

 FCA US LLC does not authorize the installation or use of any part

noted as “Track-Use” on any new vehicle prior to its first retail sale.

Page 12

WARNING!

To prevent SERIOUS INJURY or DEATH:

 ALWAYS remove any “Track-Use” equipment before driving on public

roads.

 ALWAYS properly use your three-point seat belts when driving on

public roads.

 In a collision, you and your passengers can suffer much greater inju-

ries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle.

SYMBOL GLOSSARY

Some car components have colored labels with symbols indicating precautions to be observed when using this component. It is important to follow all warnings when operating your vehicle. See below for the definition of each symbol Ú page 69.

Red Warning Lights

Air Bag Warning Light

Ú page 76

Brake Warning Light

Ú page 76

Red Warning Lights

Battery Charge Warning Light

Ú page 77

Door Open Warning Light

Ú page 77

Oil Pressure Warning Light

Ú page 78

Oil Temperature Warning Light

Ú page 78

Seat Belt Reminder Warning Light

Ú page 77

Electronic Throttle Control (ETC) Warning Light

Ú page 78

Engine Coolant Temperature Warning Light

Ú page 78

Transmission Temperature Warning Light —

If Equipped Ú page 78

Page 13

Red Warning Lights

Electric Power Steering (EPS) Fault Warning

Light

Ú page 77

Trunk Open Warning Light

Ú page 78

Vehicle Security Warning Light — If Equipped

Ú page 79

Yellow Warning Lights

Engine Check/Malfunction Indicator Warning

Light (MIL)

Ú page 80

Electronic Stability Control (ESC) Active Warning

Light — If Equipped

Ú page 79

Electronic Stability Control (ESC) OFF Warning

Light — If Equipped

Ú page 80

Tire Pressure Monitoring System (TPMS)

Warning Light

Ú page 81

Yellow Warning Lights

Anti-Lock Brake System (ABS) Warning Light

Ú page 79

Low Fuel Warning Light

Ú page 80

Service Forward Collision Warning (FCW) Light

— If Equipped

Ú page 81

Loose Fuel Filler Cap Warning Light — If

Equipped

Ú page 80

Service AWD Warning Light — If Equipped

Ú page 80

Service Adaptive Cruise Control Warning Light

— If Equipped

Ú page 79

Yellow Indicator Lights

Forward Collision Warning OFF Indicator Light —

If Equipped Ú page 82

Page 14

Green Indicator Lights

Adaptive Cruise Control (ACC) Set Without

Target Vehicle Light — If Equipped

Ú page 82

Adaptive Cruise Control (ACC) Set With Target

Vehicle Light — If Equipped

Ú page 82

Park/Headlight On Indicator Light

Ú page 82

Front Fog Indicator Light — If Equipped

Ú page 82

Turn Signal Indicator Lights

Ú page 82

ECO Mode Indicator Light — If Equipped

Ú page 82

Green Indicator Lights

Cruise Control Set Indicator Light — If Equipped

Ú page 83

Sport Mode Indicator Light — If Equipped

Ú page 83

White Indicator Lights

Cruise Control Ready Indicator

Ú page 83

Adaptive Cruise Control (ACC) Ready Light —

If Equipped Ú page 83

Blue Indicator Lights

High Beam Indicator Light

Ú page 83

Page 15

GETTING TO KNOW YOUR VEHICLE

KEYS

KEY FOB

Your vehicle is equipped with a key fob which supports Passive Entry, Remote Keyless Entry (RKE), Keyless Enter-N-Go (if equipped), Remote Start (if equipped), and remote trunk operation. The key fob allows you to lock or unlock the doors and trunk from distances up to approximately 66 ft (20 m). The key fob does not need to be pointed at the vehicle to activate the system. The key fob also contains an emergency key, which is stored in the rear of the key fob.

NOTE:

 The key fob’s wireless signal may be blocked

if the key fob is located next to a mobile phone, laptop, or other electronic device. This may result in poor performance.

 With ignition in the ON position and the

vehicle moving at 2 mph (4 km/h), all RKE commands are disabled.

Key Fob

1 — Unlock 2 — Trunk Open 3 — Lock 4 — Remote Start (If Equipped) 5 — PANIC Button 6 — Emergency Key

NOTE: In case the ignition switch does not change with the push of a button, the key fob may have a low or fully depleted battery. A low key fob battery can be verified by referring to the instrument cluster, which will display directions to follow Ú page 348.

To Lock/Unlock The Doors And Trunk

Push and release the unlock button on the key fob once to unlock the driver's door or twice within five seconds to unlock all doors. Push and release the lock button on the key fob to lock all doors.

When the doors are unlocked, the turn signals will flash and the illuminated entry system will be activated. When the doors are locked, the

Page 16

14 GETTING TO KNOW YOUR VEHICLE

turn signals will flash and the horn will chirp. This setting can be adjusted in the Uconnect system Ú page 133.

NOTE:

 If the vehicle is unlocked with the key fob,

and no door is opened within 60 seconds, the vehicle will re-lock and the security system will arm (if equipped).

 If one or more doors are open, or the trunk is

open, the doors will lock. The doors will unlock again automatically if the key is left inside the passenger compartment, otherwise the doors will stay locked.

All doors can be programmed to unlock on the first push of the unlock button through Uconnect Settings Ú page 133.

NOTE: When you use the key fob to open any door, the courtesy lights, overhead lights, and approach lighting in the outside mirrors (if equipped) will turn on Ú page 49.

To Unlatch The Trunk

Push the trunk button on the key fob two times within five seconds to unlatch the trunk.

Replacing The Battery In The Key Fob

The recommended replacement battery is one CR2032 battery.

NOTE:

 Customers are recommended to use a

battery obtained from Mopar. Aftermarket coin battery dimensions may not meet the original OEM coin battery dimensions.

 Perchlorate Material — special handling may

apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate for further information.

 Do not touch the battery terminals that are

on the back housing or the printed circuit board.

1. Remove the emergency key (2) by sliding the emergency key release (1) on the back of the key fob and pull the emergency key out with your other hand.

Emergency Key Removal

1 — Emergency Key Release Button 2 — Emergency Key

Page 17

GETTING TO KNOW YOUR VEHICLE 15

2. Separate the key fob halves using a #2 flat blade screwdriver or a coin, and gently pry the two halves of the key fob apart. Make sure not to damage the seal during removal.

Emergency Key Removal

Separating Case With A Coin

NOTE: Separating the case can also be done with a flat head screwdriver.

Separating Case With A Flat Blade Screwdriver

Key Fob Battery Replacement

3. Remove the back cover to access and replace the battery. When replacing the battery, match the (+) sign on the battery to the (+) sign on the inside of the battery clip, located on the back cover. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol.

4. To assemble the key fob case, snap the two halves together.

Programming And Requesting Additional Key Fobs

Programming the key fob may be performed by an authorized dealer.

NOTE:

 Once a key fob is programmed to a vehicle, it

cannot be re-purposed and reprogrammed to another vehicle.

 Only key fobs that are programmed to the

vehicle electronics can be used to start and operate the vehicle.

Page 18

16 GETTING TO KNOW YOUR VEHICLE

WARNING!

 Always remove the key fobs from the

vehicle and lock all doors when leaving the vehicle unattended.

 For vehicles equipped with Keyless

Enter-N-Go — Ignition, always remember to place the ignition in the OFF mode.

Duplication of key fobs may be performed at an authorized dealer. This procedure consists of programming a blank key fob to the vehicle electronics.

NOTE: When having the Sentry Key Immobilizer system serviced, bring all vehicle keys with you to an authorized dealer.

SENTRY KEY

The Sentry Key Immobilizer system prevents unauthorized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.

The system uses a key fob, keyless push button ignition and a Radio Frequency (RF) receiver to prevent unauthorized vehicle operation. Therefore, only key fobs that are programmed to the vehicle can be used to start and operate the vehicle. The system cannot reprogram a key fob obtained from another vehicle.

After placing the ignition switch in the ON/RUN position, the vehicle security light will turn on for three seconds for a bulb check. If the light remains on after the bulb check, it indicates that there is a problem with the electronics. In addition, if the light begins to flash after the bulb check, it indicates that someone attempted to start the engine with an invalid key fob. In the event that a valid key fob is used to start the engine but there is an issue with the vehicle electronics, the engine will start and shut off after two seconds.

If the vehicle security light turns on during normal vehicle operation (vehicle running for longer than 10 seconds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle serviced as soon as possible by an authorized dealer.

CAUTION!

The Sentry Key Immobilizer system is not compatible with some aftermarket remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection.

All of the key fobs provided with your new vehicle have been programmed to the vehicle electronics Ú page 348.

IGNITION SWITCH

KEYLESS ENTER -N-GO — IGNITION

This feature allows the driver to operate the ignition switch with the push of a button as long as the key fob is in the passenger compartment.

The START/STOP ignition button has four operating positions, three of which are labeled and will illuminate when in position. The three positions are OFF, ACC, and ON/RUN. The fourth position is START. During START, RUN will illuminate.

Page 19

GETTING TO KNOW YOUR VEHICLE 17

START/STOP Ignition Button

1 — OFF 2 — ACC 3 — ON/RUN

The push button ignition can be placed in the following modes:

OFF

 The engine is stopped.

 Some electrical devices (e.g. central locking,

alarm, etc.) are still available.

ACC

 Engine is not started.

 Some electrical devices are available (e.g.

power windows)

ON/RUN

 Driving position.

 All the electrical devices are available (e.g.

climate controls, etc.)

START

 The engine will start.

NOTE: If the ignition switch does not change with the push of a button, the key fob may have a low or depleted battery. In this situation, a back up method can be used to operate the ignition switch. Put the nose side (side opposite of the emergency key) of the key fob against the START/STOP ignition button and push to operate the ignition switch.

Depleted Key Fob Battery Procedure

WARNING!

 When exiting the vehicle, always remove

the key fob from the vehicle and lock your vehicle.

 Never leave children alone in a vehicle, or

with access to an unlocked vehicle.

 Allowing children to be in a vehicle unat-

tended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Children should be warned not to touch the parking brake, brake pedal or the gear selector.

 Do not leave the key fob in or near the

vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

 Do not leave children or animals inside

parked vehicles in hot weather. Interior heat build-up may cause serious injury or death.

Page 20

18 GETTING TO KNOW YOUR VEHICLE

CAUTION!

An unlocked vehicle is an invitation for thieves. Always remove key fob from the vehicle and lock all doors when leaving the vehicle unattended.

NOTE:

 When opening the driver's door with the igni-

tion in ON/RUN (engine not running), a chime will sound to remind you to place the ignition in the OFF position. In addition to the chime, the message will display “Ignition Or Accessory On” in the cluster.

 For more information on proper engine

starting procedures, see Ú page 86.

REMOTE START — IF EQUIPPED

This system uses the key fob to start the engine conveniently from outside the vehicle while still maintaining security. The system has a range of

328 ft (100 m).

Remote start is used to defrost windows in cold weather, and to reach a comfortable climate in all ambient conditions before the driver enters the vehicle.

NOTE: Obstructions between the vehicle and key fob may reduce this range.

WARNING!

 Do not start or run an engine in a closed

garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled.

 Keep key fobs away from children. Opera-

tion of the Remote Start system, windows, door locks or other controls could cause serious injury or death.

HOW TO USE REMOTE START

Push and release the remote start button on the key fob twice within five seconds. The vehicle doors will lock, the parking lights will flash, and the horn will chirp twice (if programmed). Then, the engine will start, and the vehicle will remain in the Remote Start mode for a 15 minute cycle. Pushing the remote start button a third time shuts the engine off.

To drive the vehicle, push the unlock button, and place the ignition in the ON/RUN position.

NOTE:

 With Remote Start, the engine will only run

for 15 minutes.

 Remote Start can only be used twice.

 If an engine fault is present or fuel level is

low, the vehicle will start and then shut down in 10 seconds.

Page 21

GETTING TO KNOW YOUR VEHICLE 19

 The park lamps will turn on and remain on

during Remote Start mode.

 For security, power window and power

sunroof operation (if equipped) are disabled when the vehicle is in the Remote Start mode.

 The ignition must be placed in the ON/RUN

position before the Remote Start sequence can be repeated for a third cycle.

All of the following conditions must be met before the engine will remote start:

 Gear selector in PARK

 Doors closed

 Hood closed

 Trunk closed

 Hazard switch off

 Brake switch inactive (brake pedal not

pushed)

 Battery at an acceptable charge level

 PANIC button not pushed

 System not disabled from previous remote

start event

 Vehicle Security system indicator flashing

 Ignition in the OFF position

 Fuel level meets minimum requirement

 Vehicle Security system is not signaling an

intrusion

 Malfunction Indicator Light is not illuminated

WARNING!

 Do not start or run an engine in a closed

garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled.

 Keep key fobs away from children. Opera-

tion of the Remote Start system, windows, door locks or other controls could cause serious injury or death.

TO EXIT REMOTE START MODE

To drive the vehicle after starting the Remote Start system, either push and release the unlock button on the key fob to unlock the doors, or unlock the vehicle using Keyless Enter-N-Go — Passive Entry via the door handles, and disarm the Vehicle Security system (if equipped). Then, prior to the end of the 15 minute cycle, push and release the START/STOP ignition button.

The Remote Start system will turn the engine off with another push and release of the Remote Start button on the key fob, or if the engine is allowed to run for the entire 15 minute cycle. Once the ignition is placed in the ON/RUN position, the climate controls will resume the previously set operations (temperature, blower control, etc.).

Page 22

20 GETTING TO KNOW YOUR VEHICLE

NOTE:

 To avoid unintentional shutdowns, the

system will disable for two seconds after receiving a valid remote start request.

 For vehicles equipped with the Keyless

Enter-N-Go — Passive Entry feature, the message “Remote Start Active — Push Start Button” will show in the instrument cluster display until you push the START/STOP ignition button.

Remote Starting will also cancel if any of the following occur:

 The engine stalls or engine speed exceeds

2500 RPM.

 Any engine warning lights come on.

 The Low Fuel Light turns on.

 The hood is opened.

 The hazard switch is pushed.

 The gear selector is moved out of PARK.

 The brake pedal is pushed.

REMOTE START FRONT DEFROST

CTIVATION — IF EQUIPPED

When remote start is active, and the outside ambient temperature is 40°F (4.5°C) or below, the system will automatically activate front defrost for 15 minutes or less. The time is dependent on the ambient temperature. Once the timer expires, the system will automatically adjust the settings depending on ambient conditions. See “Remote Start Comfort Systems — If Equipped” in the next section for detailed operation.

REMOTE START COMFORT SYSTEMS —

F EQUIPPED

When remote start is activated, the front and rear defrost will automatically turn on in cold weather. The heated steering wheel and driver heated seat feature will turn on if selected in the comfort menu screen within Uconnect Settings Ú page 133. In warm weather, the driver vented seat feature will automatically turn on when remote start is activated, if programmed in the comfort menu screen. The vehicle will adjust the climate control settings depending on the outside ambient temperature.

Automatic Temperature Control (ATC) — If Equipped

The climate controls will be automatically adjusted to the optimal temperature and mode settings depending on the outside ambient temperature. This will occur until the ignition is placed in the ON/RUN position where the climate controls will resume their previous settings.

Manual Temperature Control (MTC) — If Equipped

 In ambient temperatures at 40°F (4.5°C) or

below, the climate settings will default to maximum heat, with fresh air entering the cabin. If the front defrost timer expires, the vehicle will enter Mix Mode.

 In ambient temperatures from 40°F (4.5°C)

to 78°F (26°C), the climate settings will be based on the last settings selected by the driver.

 In ambient temperatures at 78°F (26°C) or

above, the climate settings will default to MAX A/C, Bi-Level Mode, with Recirculation on.

Page 23

GETTING TO KNOW YOUR VEHICLE 21

For more information on ATC, MTC, and climate control settings, see Ú page 53.

NOTE: These features will stay on through the duration of remote start until the ignition is placed in the ON/RUN position. The climate control settings will change if manually adjusted by the driver while the vehicle is in remote start mode, and exit automatic override. This includes the OFF button on the climate controls, which will turn the system off.

REMOTE START WINDSHIELD WIPER

E–ICER ACTIVATION — I F EQUIPPED

When remote start is active and the outside ambient temperature is less than 33°F (0.6°C), the Windshield Wiper De-Icer will be enabled. Exiting remote start will resume previous operation, except if the Windshield Wiper De-Icer is active. The Windshield Wiper De-Icer timer and operation will continue.

REMOTE START CANCEL MESSAGE —

F EQUIPPED

The following messages will display in the instrument cluster display if the vehicle fails to remote start or exits remote start prematurely:

 Remote Start Aborted — Door Open

 Remote Start Aborted — Hood Open

 Remote Start Aborted — Fuel Low

 Remote Start Aborted — Trunk Open

 Remote Start Disabled — Start Vehicle To

Reset

The message will stay active until the ignition is placed in the ON/RUN position Ú page 348.

VEHICLE SECURITY SYSTEM — IF EQUIPPED

The Vehicle Security system monitors the vehicle doors for unauthorized entry and the Keyless Enter-N-Go — Ignition for unauthorized operation. While the Vehicle Security system is armed, interior switches for door locks and trunk release are disabled. If something triggers the alarm, the

Vehicle Security system will provide the following audible and visible signals:

 The horn will pulse

 The turn signals will flash

 The vehicle security light in the instrument

cluster will flash

TO ARM THE SYSTEM

Follow these steps to arm the Vehicle Security system:

1. Make sure the vehicle’s ignition is placed in the OFF position.

2. Perform one of the following methods to lock the vehicle:

 Push lock on the interior power door lock

switch with the driver and/or passenger door open.

 Push the lock button on the exterior

Passive Entry Door Handle with a valid key fob available in the same exterior zone Ú page 24.

 Push the lock button on the key fob.

3. If any doors are open, close them.

Page 24

22 GETTING TO KNOW YOUR VEHICLE

TO DISARM THE SYSTEM

The Vehicle Security system can be disarmed using any of the following methods:

 Push the unlock button on the key fob.

 Grab the Passive Entry door handle to unlock

the door Ú page 24.

 Push the Keyless Enter-N-Go ignition button

(requires at least one valid key fob in the vehicle).

NOTE:

 The driver's door key cylinder and the trunk

button on the key fob cannot arm or disarm the Vehicle Security system.

 When the Vehicle Security system is armed,

the interior power door lock switches will not unlock the doors.

The Vehicle Security system is designed to protect your vehicle. However, you can create conditions where the system will give you a false alarm. If one of the previously described arming sequences has occurred, the Vehicle Security system will arm, regardless of whether you are in the vehicle or not. If you remain in the vehicle

and open a door, the alarm will sound. If this occurs, disarm the Vehicle Security system.

If the Vehicle Security system is armed and the battery becomes disconnected, the Vehicle Security system will remain armed when the battery is reconnected; the exterior lights will flash, and the horn will sound. If this occurs, disarm the Vehicle Security system.

REARMING T HE SYSTEM

If something triggers the alarm, and no action is taken to disarm it, the Vehicle Security system will turn the horn off after 29 seconds, five seconds between cycles, up to eight cycles if the trigger remains active. The Vehicle Security system will then rearm itself.

SECURITY SYSTEM MANUAL OVERRIDE

The Vehicle Security system will not arm if you lock the doors using the manual door lock.

TAMPER ALERT

If something has triggered the Vehicle Security system in your absence, the horn will sound three times and the exterior lights will blink three times when you disarm the Vehicle Security system.

DOORS

MANUAL DOOR LOCKS

The power door locks can be manually locked from inside the vehicle by using the door lock knob. To lock each door, push the door lock knob on each door trim panel downward. To unlock each door, pull the door lock knob on each door trim panel upward.

Door Lock Knob

If the door lock knob is down when you shut the door, the door will lock. Therefore, make sure the key fob is not inside the vehicle before closing the door.

Page 25

GETTING TO KNOW YOUR VEHICLE 23

NOTE: Manually locking the vehicle will not arm the Vehicle Security system.

WARNING!

 For personal security and safety in the

event of a collision, lock the vehicle doors before you drive as well as when you park and leave the vehicle.

 Before exiting a vehicle, always shift the

automatic transmission into PARK or the manual transmission into FIRST gear or REVERSE, apply the parking brake, turn the vehicle OFF, remove the key fobs from the vehicle and lock all doors, and lock your vehicle.

 When leaving the vehicle, always remove

the key from the ignition and lock your vehicle. Unsupervised use of vehicle equipment may cause severe personal injuries and death.

(Continued)

WARNING! (Continued)

 Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Children should be warned not to touch the parking brake, brake pedal or gear selector.

 Do not leave the key fob in or near the

vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

POWER DOOR LOCKS

The power door lock switches are located on each door trim panel. Push the switch to lock or unlock the doors.

Power Door Lock Switch

If you push the power door lock switch while the ignition is on, and either door is open, the power locks will not operate. This prevents you from accidentally locking the key fob in the vehicle. Turning off the ignition or closing the door will allow the locks to operate.

Page 26

24 GETTING TO KNOW YOUR VEHICLE

NOTE: If the key fob is located next to a mobile phone, laptop, or other electronic device, the wireless signal may get blocked, and the driver’s door may not unlock automatically.

If a door is open with the ignition either placed in the ACC or ON/RUN (engine not running) position, a chime will sound as a reminder.

KEYLESS ENTER -N-GO — PASSIVE

NTRY

The Passive Entry system is an enhancement to the vehicle’s key fob and a feature of Keyless Enter-N-Go. This feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock buttons.

NOTE:

 Passive Entry may be programmed on/off

through Uconnect Settings Ú page 133.

 The key fob may not be able to be detected by

the vehicle Passive Entry system if it is located next to a mobile phone, laptop or other electronic device; these devices may block the key fob’s wireless signal and prevent the Passive Entry handle from locking/unlocking the vehicle.

 Passive Entry Unlock initiates illuminated

approach (low beams, license plate lamp, position lamps) for whichever time duration is set between 0, 30, 60 or 90 seconds. Passive Entry Unlock also initiates two flashes of the turn signal lamps.

 If wearing gloves, or if it has been raining/

snowing on the Passive Entry door handle, the unlock sensitivity can be affected, resulting in a slower response time.

 If the vehicle is unlocked by Passive Entry

and no door is opened within 60 seconds, the vehicle will re-lock and (if equipped) will arm the Vehicle Security system.

To Unlock From The Driver Or Passenger Side

With a Passive Entry key fob within 5 ft (1.5 m) of the door handle, grab the handle to unlock the vehicle. Grabbing the driver’s door handle will unlock the driver door automatically. Grabbing the passenger door handle will unlock both doors automatically. The interior door panel lock knob will raise when the door is unlocked.

Grab The Door Handle To Unlock

NOTE:

 If “Unlock All Doors 1st Press” is

programmed, all doors will unlock when you grab hold of the front driver’s door handle. To select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press” through Uconnect Settings Ú page 133.

 All doors will unlock when the front

passenger door handle is grabbed regardless of the driver’s door unlock preference setting.

Page 27

GETTING TO KNOW YOUR VEHICLE 25

Frequency Operated Button Integrated Key (FOBIK-Safe)

To minimize the possibility of unintentionally locking a Passive Entry key fob inside your vehicle, the Passive Entry system is equipped with an automatic door unlock feature which will function if the ignition is in the OFF position.

There are three situations that trigger a FOBIK-Safe search in any Passive Entry vehicle.

1. A lock request is made by a valid Passive Entry key fob while a door is open.

2. A lock request is made by the Passive Entry door handle while a door is open.

3. A lock request is made by the door panel switch while the door is open.

When any of these situations occur, after all open doors are shut, the FOBIK-Safe search will be executed. If it finds a Passive Entry key fob inside the car, and it does not find any Passive Entry key fobs outside the car, the car will unlock and alert the customer.

NOTE: The vehicle will only unlock the doors when a valid Passive Entry key fob is detected inside the vehicle, and no valid Passive Entry key fob is detected outside the vehicle. The vehicle will not unlock the doors when any of the following conditions are true:

 The doors are manually locked using the door

lock knobs.

 Three attempts are made to lock the doors

using the door panel switch and then the doors are closed.

 There is a valid Passive Entry key fob outside

the vehicle and within 5 ft (1.5 m) of either Passive Entry door handle.

To Enter The Trunk:

With a Passive Entry key fob within 5 ft (1.5 m) of the deck lid, push the button located on the center of the light bar which is located on the deck lid above the license plate.

Trunk Passive Entry Button

NOTE: If you inadvertently leave your vehicle's Passive Entry key fob in the trunk and try to close the deck lid, the deck lid will automatically unlatch, unless another one of the vehicle’s Passive Entry key fobs is outside the vehicle and within 5 ft (1.5 m) of the deck lid.

Page 28

26 GETTING TO KNOW YOUR VEHICLE

To Lock The Vehicle’s Doors:

With one of the vehicle’s Passive Entry key fobs within 5 ft (1.5 m) of either door handle, pushing the Passive Entry lock button will lock both doors.

Push The Door Handle Button To Lock

Do NOT grab the door handle, when pushing the door handle button. This could unlock the door(s).

Do NOT Grab The Handle When Locking

NOTE:

 After pushing the door handle button, you

must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle unlocking.

 The Passive Entry system will not operate if

the key fob battery is depleted.

The vehicle doors can also be locked by using the key fob lock button or the lock button located on the vehicle’s interior door panel Ú page 348.

AUTOMATIC UNLOCK DOORS ON EXIT

The doors will unlock automatically on vehicles with power door locks if:

1. The Automatic Unlock Doors On Exit feature is enabled within Uconnect Settings Úpage 133.

2. The transmission gear selector was not in PARK, then is placed in PARK.

3. The driver door is opened.

4. The doors were not previously unlocked.

NOTE: Use the Automatic Unlock Doors On Exit feature in accordance with local laws.

AUTOMATIC DOOR LOCKS —

F EQUIPPED

The auto door lock feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle's speed exceeds 15 mph (24 km/h). The auto door lock feature can be enabled or disabled by an authorized dealer per written request of the customer. Please see an authorized dealer for service.

Page 29

GETTING TO KNOW YOUR VEHICLE 27

STEERING WHEEL

MANUAL TILT/TELESCOPING STEERING

OLUMN — IF EQUIPPED

This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping lever is located below the steering wheel at the end of the steering column.

Manual Tilt/Telescoping Control Handle

To unlock the steering column, pull the lever downward (toward the floor). To tilt the steering column, move the steering wheel upward or downward as desired. To lengthen or shorten

the steering column, pull the steering wheel outward or push it inward as desired. To lock the steering column in position, push the lever upward until fully engaged.

WARNING!

Do not adjust the steering column while driving. Adjusting the steering column while driving or driving with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.

POWER TILT/TELESCOPING STEERING

OLUMN — IF EQUIPPED

This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The power tilt/telescoping steering column control is located below the multifunction lever on the steering column.

Power Tilt/Telescoping Steering Column Control

Use the four-way control to adjust the steering column.

WARNING!

Page 30

28 GETTING TO KNOW YOUR VEHICLE

HEATED STEERING WHEEL —

F EQUIPPED

The steering wheel contains a heating element that helps warm your hands in cold weather. The heated steering wheel has only one temperature setting. Once the heated steering wheel has been turned on, it will stay on for an average of 80 minutes before automatically shutting off. This time will vary based on environmental temperatures. The heated steering wheel can shut off early or may not turn on when the steering wheel is already warm.

The heated steering wheel control button is located within the Uconnect system. You can gain access to the control button through the climate screen or the controls screen.

 Press the heated steering wheel button

once to turn the heating element on.

 Press the heated steering wheel button a

second time to turn the heating element off.

NOTE: The engine must be running for the heated steering wheel to operate.

For information on use with the Remote Start system, see Ú page 20.

WARNING!

 Persons who are unable to feel pain to the

skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions must exercise care when using the steering wheel heater. It may cause burns even at low temperatures, especially if used for long periods.

 Do not place anything on the steering wheel

that insulates against heat, such as a blanket or steering wheel covers of any type and material. This may cause the steering wheel heater to overheat.

UCONNECT VOICE RECOGNITION

INTRODUCING VOICE RECOGNITION

Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your vehicle’s Voice Recognition (VR) system.

Uconnect 4 With 7-inch Display

Uconnect 4C NAV With 8.4-inch Display

Page 31

GETTING TO KNOW YOUR VEHICLE 29

If you see the NAV icon on the bottom bar or in the Apps menus of your 8.4-inch touchscreen, you have the Uconnect 4C NAV system. If not, you have a Uconnect 4C with 8.4-inch display system.

BASIC VOICE COMMANDS

The basic Voice Commands below can be given at any point while using your Uconnect system.

Push the VR button . After the beep, say:

 “Cancel” to stop a current voice session

 “Help” to hear a list of suggested Voice

Commands

 “Repeat” to listen to the system prompts

again

Notice the visual cues that inform you of your VR system’s status. Cues appear on the touchscreen.

GET STARTED

The Voice Recognition (VR) button is used to activate/deactivate your Voice Recognition system.

Helpful hints for using Voice Recognition:

 Reduce background noise. Wind and

passenger conversations are examples of noise that may impact recognition.

 Speak clearly at a normal pace and volume

while facing straight ahead.

 Each time you give a Voice Command, you

must first push the Voice Recognition (VR) button, wait until after the beep, then say your Voice Command.

 You can interrupt the help message or

system prompts by pushing the VR button and saying a Voice Command from the current category.

Uconnect Voice Command Buttons

1 — Push To Start Or Answer A Phone Call And Send Or Receive A Text

2 — Push The Voice Recognition Button To Begin Radio, Media, And Climate Functions

ADDITIONAL INFORMATION

© 2020 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. Android™ is a trademark of Google Inc. SiriusXM® and all related marks and logos are trademarks of SiriusXM® Radio Inc. Ú page 348.

Page 32

30 GETTING TO KNOW YOUR VEHICLE

Uconnect System Support:

 US residents visit www.DriveUconnect.com or

call: 1-877-855-8400 (24 hours a day 7 days a week)

 Canadian residents visit www.DriveUcon-

nect.ca or call: 1-800-465-2001 (English) or 1-800-387-9983 (French)

SiriusXM Guardian™ services support:

 US residents visit www.driveuconnect.com/

sirius-xm-guardian or call: 1-844-796-4827

 Canadian residents visit www.siriusxm.ca/

guardian-v1/ or call: 1-877-324-9091

DRIVER MEMORY SETTINGS — IF EQUIPPED

This feature allows the driver to save up to two different memory profiles for easy recall through a memory switch. Each memory profile saves desired position settings for the following features:

 Driver seat cushion

 Easy Entry/Exit seat operation (on/off) (if

equipped)

 Side mirrors

 Power tilt/telescoping steering column

(if equipped)

 A set of desired radio station presets

NOTE:

 Your vehicle is equipped with two key fobs,

each can be linked to either memory position 1 or 2.

 Be sure to program the radio presets prior to

programming the memory settings.

The memory settings switch is located on the driver’s door trim panel. The switch consists of three buttons:

 The set (S) button, which is used to activate

the memory save function.

 The (1) and (2) buttons which are used to

recall either of two saved memory profiles.

Memory Settings Switch

PROGRAMMING THE M EMORY FEATURE

To create a new memory profile, perform the following:

NOTE: Saving a new memory profile will erase the selected profile from memory.

1. Place the vehicle’s ignition in the ON/RUN position (do not start the engine).

2. Adjust all memory profile settings to desired preferences (i.e., seat, side mirror, power tilt and telescopic steering column [if equipped], and radio station presets).

Page 33

GETTING TO KNOW YOUR VEHICLE 31

3. Push and release the set (S) button on the memory switch, and then push the desired memory button (1 or 2) within five seconds. The instrument cluster display will display which memory position has been set.

NOTE: Memory profiles can be set without the vehicle in PARK, but the vehicle must be in PARK to recall a memory profile.

LINKING AND UNLINKING THE KEY FOB

O MEMORY

Your key fobs can be programmed to recall one of two saved memory profiles by pushing the unlock button on the key fob.

NOTE: Before programming your key fobs you must select the “Memory Linked To Fob” feature through the Uconnect system Ú page 133.

To program your key fobs, perform the following:

1. Place the vehicle’s ignition in the OFF position.

2. Select a desired memory profile, 1 or 2.

3. Once the profile has been recalled, push and release the set (S) button on the memory switch.

4. Within five seconds, push and release button (1) or (2) accordingly. “Memory Profile Set” (1 or 2) will display in the instrument cluster.

5. Push and release the lock button on the key fob within 10 seconds.

NOTE: Your key fob can be unlinked from your memory settings by pushing the set (S) button, followed by pushing the unlock button on the key fob within 10 seconds.

MEMORY POSITION R ECALL

NOTE: If a recall is attempted when the vehicle is not in PARK, a message will be displayed in the instrument cluster display.

To recall the memory settings for driver one or two, push the desired memory button number (1 or 2) or the unlock button on the key fob linked to the desired memory position.

A recall can be canceled by pushing any of the memory buttons (S, 1, or 2) during a recall. When a recall is canceled, the driver seat will stop moving. A delay of one second will occur before another recall can be selected.

NOTE: If the vehicle is equipped with Passive Entry, the memory settings are recalled when using Passive Entry to unlock the driver's door with a linked key fob.

SEATS

Seats are a part of the Occupant Restraint System of the vehicle.

WARNING!

 It is dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.

 Do not allow people to ride in any area of

your vehicle that is not equipped with seats and seat belts. In a collision, people riding in these areas are more likely to be seriously injured or killed.

(Continued)

Page 34

32 GETTING TO KNOW YOUR VEHICLE

WARNING! (Continued)

 Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

MANUAL ADJUSTMENT (FRONT SEATS)

F EQUIPPED

— I

WARNING!

 Adjusting a seat while the vehicle is moving

is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured. Adjust the seat only while the vehicle is parked.

 Do not ride with the seatback reclined so

that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.

Manual Front Seat Forward/Rearward Adjustment

The seat can be adjusted forward or rearward by using a bar located by the front of the seat cushion, near the floor.

Adjusting Bar Location

While sitting in the seat, lift up on the bar located under the seat cushion and move the seat forward or rearward. Release the bar once you have reached the desired position. Then, using body pressure, move forward and rearward on the seat to be sure that the seat adjusters have latched.

WARNING!

 Adjusting a seat while driving may be

dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.

 Seats should be adjusted before fastening

the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt.

Page 35

GETTING TO KNOW YOUR VEHICLE 33

Manual Front Seat Recline

To adjust the seatback, lift the lever located on the outboard side of the seat, lean back to the desired position and release the lever. To return the seatback, lift the lever, lean forward and release the lever.

Recline Lever

WARNING!

Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death.

MANUAL ADJUSTMENT (REAR SEATS )

WARNING!

Do not pile luggage or cargo higher than the top of the seatback. This could impair visibility or become a dangerous projectile in a sudden stop or collision.

Folding Rear Seat

The rear seatbacks can be folded forward to provide additional storage area. Pull on the loops located on the upper part of the rear seatback to fold down either or both seatbacks. These loops can be tucked away when not in use.

NOTE: You may experience deformation in the seat cushion from the seat belt buckles if the seats are left folded for an extended period of time. This is normal and, by simply opening the seats to the open position, over time the seat cushion will return to its normal shape.

Folding Rear Seatback Loop Locations

Folded Rear Seat

When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap.

Page 36

34 GETTING TO KNOW YOUR VEHICLE

WARNING!

 Be certain that the seatback is securely

locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury.

 The cargo area in the rear of the vehicle

(with the rear seatbacks in the locked-up or folded down position) should not be used as a play area by children when the vehicle is in motion. They could be seriously injured in a collision. Children should be seated and using the proper restraint system.

POWER ADJUSTMENT (FRONT SEATS) —

F EQUIPPED

The power seat switches are located on the outboard side of the front seats. The power seat switches control the movement of the seat.

Power Seat Switch

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and rearward by using the power seat switch. The seat will move in the direction of the switch. Release the switch when the desired position has been reached.

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or down by using the power seat switch. The seat will move in the direction of the switch. Release the switch when the desired position has been reached.

Tilting The Seat Up Or Down

The angle of the seat cushion can be adjusted up or down using the power seat switch. The front of the seat cushion will move in the direction of the switch. Release the switch when the desired position has been reached.

Power Lumbar — If Equipped

Vehicles equipped with power driver or passenger seats may also be equipped with power lumbar. The power lumbar switch is located on the outboard side of the power seat. Push the switch forward or rearward to increase or decrease the lumbar support. Push the switch upward or downward to raise or lower the lumbar support.

Power Lumbar Switch

Page 37

GETTING TO KNOW YOUR VEHICLE 35

Easy Entry/Exit Seat — If Equipped

This feature provides automatic driver seat positioning to enhance driver mobility when entering and exiting the vehicle.

The distance the driver seat moves depends on where you have the driver seat positioned when you place the vehicle’s ignition in the OFF position.

 When you place the vehicle’s ignition in the

OFF position, the driver seat will move about

2.4 inches (60 mm) rearward if the driver seat position is greater than or equal to

2.7 inches (67.7 mm) forward of the rear stop. The seat will return to its previously set position when you place the vehicle’s ignition in the ACC or RUN position.

 The Easy Entry/Easy Exit feature is disabled

when the driver seat position is less than 0.9 of an inch (22.7 mm) forward of the rear stop. At this position, there is no benefit to the driver by moving the seat for Easy Exit or Easy Entry.

When enabled in Uconnect Settings, Easy Entry and Easy Exit positions are stored in each memory setting profile Ú page 30.

NOTE: The Easy Entry/Exit feature is enabled or disabled through the programmable features in the Uconnect system Ú page 133.

HEATED SEATS — IF EQUIPPED

On some models, the front seats may be equipped with heaters located in the seat cushions and seat backs.

WARNING!

 Persons who are unable to feel pain to the

skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.

 Do not place anything on the seat or seat-

back that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

Front Heated Seats

The front heated seats control buttons are located within the Uconnect system. You can gain access to the control buttons through the climate screen and the controls screen.

You can choose from HI, LO, or OFF heat settings. The indicator arrows in touchscreen buttons indicate the level of heat in use. Two indicator arrows will illuminate for HI, and one for LO. Turning the heating elements off will return the user to the radio screen.

 Press the heated seat button once to turn

the HI setting on.

 Press the heated seat button a second

time to turn the LO setting on.

 Press the heated seat button a third time

to turn the heating elements off.

NOTE:

 Once a heat setting is selected, heat will be

felt within two to five minutes.

 The engine must be running for the heated

seats to operate.

Page 38

36 GETTING TO KNOW YOUR VEHICLE

 If the HI-level setting is selected, the system

will automatically switch to LO-level after approximately 60 minutes of continuous operation. At that time, the display will change from HI to LO, indicating the change. The LO-level setting will turn off automatically after approximately 45 minutes.

For information on use with the Remote Start system, see Ú page 20.

WARNING!

 Persons who are unable to feel pain to the

 Do not place anything on the seat or seat-

FRONT VENTILATED SEATS —

F EQUIPPED

The ventilated seats are equipped with fans that can be controlled through the climate and control screen in the Uconnect system. The fans operate at two speeds, HI and LO.

 Press the ventilated seat button once to

choose HI.

 Press the ventilated seat button a second

time to choose LO.

 Press the ventilated seat button a third

time to turn the ventilated seat off.

NOTE: The engine must be running for the ventilated seats to operate.

For information on use with the Remote Start system, see Ú page 20.

VEHICLES WITHOUT PASSENGER

EATING INSTALLED

All passenger occupants within the vehicle must be in a seat equipped with a Seat Belt System and Head Restraint for the safety of the passenger. If the passenger and/or rear seats have been removed, do not ride in those areas.

This vehicle has been designed to maximize total performance. In doing so, the deletion of passenger seats and/or rear seat may affect the Noise, Vibration, and Harshness (NVH) characteristics. As a result, the interior will be louder overall.

WARNING!

 If the passenger and/or rear seats have

been removed, do not ride in those areas. In a collision, people riding in these areas are more likely to be seriously injured or killed.

 If this vehicle was not factory equipped with

a passenger seat, NEVER attempt to install a passenger seat because the safety systems, including the air bags and seat belt, may not properly protect you.

(Continued)

Page 39

GETTING TO KNOW YOUR VEHICLE 37

WARNING! (Continued)

 It is dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision, people riding in this area are more likely to be seriously injured or killed.

 Only ride in available seating positions

equipped with seat belt systems. Always properly wear your seat belt. Failure to do so could result in an increased risk of serious injury or death in the event of an accident.

 Be sure everyone in your vehicle is in a seat

and using a seat belt properly. Occupants, including the driver, should always wear their seat belts whether or not an air bag is also provided at their seating positions to minimize the risk of severe injury or death in the event of a crash.

(Continued)

WARNING! (Continued)

 All occupants, including the driver, should

not operate a vehicle or sit in a vehicle’s seat if the head restraints are not in place of their proper positions in order to minimize the risk of neck injury in the event of a crash.

 Head restraints should never be adjusted

while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.

PASSENGER SEAT EASY ENTRY

On the passenger seat, pull forward on the lever located on the side of the seatback in order to dump the seatback and slide the seat forward. You can also temporarily remove the seat belt from the guide loop on the seat and allow the seat belt to retract out of the way. This allows for easier access to the rear seat. To return the seat to a normal seating position, first return the seatback to its original recline location and then slide the entire seat back to the preset lock position.

Easy Entry Lever

NOTE:

 The front passenger seat needs to slide back

to a preset position for the fore-aft adjuster to be properly locked. For example, if the front passenger has the seat adjusted full rear and exits the vehicle to let a rear passenger enter using the easy entry handle, the fore-aft adjuster needs to slide back about 2/3 of the way rearward to hit the lock position. If the adjuster is not returned to this preset position, the seat will appear to be loose.

 Also, if the front passenger uses the easy entry

handle and then lifts up the recliner handle without moving the seat back to its original preset position, the recliner will not lock until it is moved to the full recline position.

Page 40

38 GETTING TO KNOW YOUR VEHICLE

Driver’s Side Easy Entry

The easy entry lever on the outboard side of the driver’s seatback will dump the seat back forward to allow for easier access to the rear seats. The seat bottom will not slide forward as the passenger side easy entry will. If needed, use the driver’s side seat control to slide forward.

To return the seat to the normal position, push the seatback up and it will lock into the previously set recline position. Then if needed, use the seat control to adjust the forward/ rearward position.

HEAD RESTRAINTS

Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear.

WARNING!

 All occupants, including the driver, should

not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.

(Continued)

WARNING! (Continued)

 Head restraints should never be adjusted

while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.

NOTE: Do not reverse the head restraints (making the rear of the head restraint face forward) in an attempt to gain additional clearance to the back of your head.

Reactive Head Restraints — Front Seats

The front driver and passenger seats are equipped with Reactive Head Restraints (RHR). In the event of a rear impact, the RHR will automatically extend forward minimizing the gap between the back of the occupants head and the RHR.

The RHR will automatically return to their normal position following a rear impact. If the RHR do not return to their normal position, see an authorized dealer immediately.

Head Restraint

1 — Release Button 2 — Adjustment Button 3 — Seat Belt Loop

To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button located at the base of the head restraint and push downward on the head restraint.

To remove the head restraint, remove the seat belt from the seat belt loop. Raise the head restraint as far as it can go. Then, push the adjustment button and the release button at the base of each post while pulling the head restraint up. To reinstall the head restraint, put

Page 41

GETTING TO KNOW YOUR VEHICLE 39

the head restraint posts into the holes while pushing the adjustment button and release button. Then, adjust it to the appropriate height.

NOTE: It may be necessary to recline the front seat before removing the head restraint to provide enough clearance from the roof.

WARNING!

 A loose head restraint thrown forward in a

collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow removed head restraints in a location outside the occupant compartment.

 ALL the head restraints MUST be rein-

stalled in the vehicle to properly protect the occupants. Follow the re-installation instructions above prior to operating the vehicle or occupying a seat.

(Continued)

WARNING! (Continued)

 Do not place items over the top of the Reac-

tive Head Restraint, such as coats, seat covers or portable DVD players. These items may interfere with the operation of the Reactive Head Restraint in the event of a collision and could result in serious injury or death.

Rear Head Restraints

The rear outboard head restraints are non-adjustable and are designed to reduce the risk of injury by restricting head movement in the event of a rear impact.

MIRRORS

INSIDE REARVIEW M IRROR

Automatic Dimming Mirror

The rearview mirror can be adjusted up, down, left, and right. The mirror should be adjusted to center on the view through the rear window.

This mirror automatically adjusts for headlight glare from vehicles behind you.

NOTE: The Automatic Dimming Mirror feature is disabled when the vehicle is in REVERSE to improve the driver’s rear view.

The Automatic Dimming feature can be turned on or off through the touchscreen.

Automatic Dimming Mirror

CAUTION!

To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean.

Page 42

40 GETTING TO KNOW YOUR VEHICLE

ILLUMINATED VANITY MIRRORS

To access an illuminated vanity mirror, flip down one of the visors and lift the cover.

Illuminated Vanity Mirror

Sun Visor “Slide-On-Rod” And Extender Feature

The sun visor “Slide-On-Rod” feature allows for additional flexibility in positioning the sun visor to block out the sun.

1. Fold down the sun visor.

2. Unclip the visor from the corner clip.

3. Pivot the sun visor toward the side window.

4. Extend the sun visor for additional sun blockage.

Slide-On-Rod Extender

To use the extender feature of the sun visor, grab the extender which is located at the rear of the visor and pull rearward.

OUTSIDE MIRRORS

The outside mirror(s) can be adjusted to the center of the adjacent lane of traffic to achieve the optimal view.

NOTE: The passenger side convex outside mirror will give a much wider view to the rear, and especially of the lane next to your vehicle.

WARNING!

Vehicles and other objects seen in an outside convex mirror will look smaller and farther away than they really are. Relying too much on side convex mirrors could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in a side convex mirror.

Page 43

GETTING TO KNOW YOUR VEHICLE 41

POWER MIRRORS

The power mirror switch is located on the driver's side door trim panel.

The power mirror controls consist of mirror select buttons and a four-way mirror control switch. To adjust a mirror, push the mirror select button for the mirror that you want to adjust. Using the mirror control switch, push on any of the four arrows for the direction that you want the mirror to move.

Power Mirror Control

1 — Mirror Adjustment 2 — Left Mirror Selection 3 — Right Mirror Selection

NOTE: A light in the select button will illuminate indicating the mirror is activated and can be adjusted.

HEATED MIRRORS — I F EQUIPPED

These mirrors are heated to melt frost or ice. This feature will be activated whenever you turn on the rear window defroster (if equipped) Ú page 53.

UNIVERSAL GARAGE DOOR OPENER (HOMELINK®)

HomeLink® Buttons And Indicator Light

 HomeLink® replaces up to three hand-held

transmitters that operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink® unit is powered by your vehicles 12 Volt battery.

 The HomeLink® buttons that are located in

the overhead console or sunvisor designate the three different HomeLink® channels.

 To operate HomeLink®, push and release

any of the programmed HomeLink® buttons. These buttons will activate the devices they are programmed to with each press of the corresponding HomeLink® button.

 The HomeLink® indicator light is located

above the center button Ú page 348.

BEFORE YOU BEGIN PROGRAMMING

OME LINK®

For efficient programming and accurate transmission of the radio-frequency signal, it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink® system. Make sure your hand-held transmitter is programmed to activate the device you are trying to program your HomeLink® button to.

Page 44

42 GETTING TO KNOW YOUR VEHICLE

Ensure that your vehicle is parked outside of the garage before you begin programming.

It is recommended that you erase all the channels of your HomeLink® before you use it for the first time.

If you require assistance, please call toll-free1-800-355-3515 or visit HomeLink.com

ERASING ALL THE HOMELINK®

HANNELS

To erase the channels, follow this procedure:

1. Place the ignition switch into the ON/RUN position.

2. Push and hold the two outside HomeLink® buttons (I and III) for up to 20 seconds, or until the HomeLink® indicator light flashes.

NOTE: Erasing all channels should only be performed when programming HomeLink® for the first time. Do not erase channels when programming additional buttons.

IDENTIFYING WHETHER YOU HAVE A

OLLING CODE OR NON-ROLLING CODE

EVICE

Before programming a device to one of your HomeLink® buttons, you must determine whether the device has a rolling code or non-rolling code.

Rolling Code Devices

To determine if your device has a rolling code, a good indicator is its manufacturing date. Typically, devices manufactured after 1995 have rolling codes. A device with a rolling code will also have a “LEARN” or “TRAIN” button located where the antenna is attached to the device. The button may not be immediately visible when looking at the device. The name and color of the button may vary slightly by manufacturer.

NOTE: The “LEARN” or “TRAIN” button is not the button you normally use to operate the device.

Non-Rolling Code Devices

Most devices manufactured before 1995 will not have a rolling code. These devices will also not have a “LEARN” or “TRAIN” button.

PROGRAMMING HOMELINK® TO A

ARAGE DOOR OPENER

To program any of the HomeLink® buttons to activate your garage door opener motor, follow the steps below:

NOTE: All HomeLink® buttons are programmed using this procedure. You do not need to erase all channels when programming additional buttons.

1. Place the ignition switch into the ON/RUN position.

2. Place the garage door opener transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink® button you wish to program, while keeping the HomeLink® indicator light in view.

Page 45

GETTING TO KNOW YOUR VEHICLE 43

3. Push and hold the HomeLink® button you want to program while you push and hold the garage door opener transmitter button you are trying to replicate.

4. Continue to hold both buttons and observe the HomeLink® indicator light. The HomeLink® indicator light will flash slowly and then rapidly. Once this happens, release both buttons.

NOTE: Make sure the garage door opener motor is plugged in before moving on to the rolling code/ non-rolling code final steps.

Rolling Code Garage Door Opener Final Steps

NOTE: You have 30 seconds in which to initiate rolling code final step 2, after completing rolling code final step 1.

1. At the garage door opener motor (in the garage), locate the “LEARN” or “TRAIN” button. This can usually be found where the hanging antenna wire is attached to

the garage door opener motor. Firmly push and release the “LEARN” or “TRAIN” button.

2. Return to the vehicle and push the programmed HomeLink® button three times (holding the button for two seconds each time). If the garage door opener motor operates, programming is complete.

3. Push the programmed HomeLink® button to confirm that the garage door opener motor operates. If the garage door opener motor does not operate, repeat the final steps for the rolling code procedure.

Non-Rolling Code Garage Door Opener Final Steps

1. Push and hold the programmed HomeLink® button and observe the HomeLink® indicator light. If the HomeLink® indicator light stays on constantly, programming is complete.

2. Push the programmed HomeLink® button to confirm that the garage door opener motor operates. If the garage door opener motor does not operate, repeat the steps from the beginning.

WARNING!

 Your motorized door or gate will open and

close while you are programming the universal transceiver. Do not program the transceiver if people or pets are in the path of the door or gate.

 Do not run your vehicle in a closed garage

or confined area while programming the transceiver. Exhaust gas from your vehicle contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous when inhaled and can cause you and others to be severely injured or killed.

PROGRAMMING HOMELINK® TO A

ISCELLANEOUS DEVICE

Follow the procedure on programming HomeLink® to a garage door opener Ú page 42. Be sure to determine if the device has a rolling code, or non-rolling code before beginning the programming process.

NOTE: Canadian radio frequency laws require transmitter signals to time-out (or quit) after several seconds of transmission, which may not be long

Page 46

44 GETTING TO KNOW YOUR VEHICLE

enough for HomeLink® to pick up the signal during programming. Similar to this Canadian law, some U.S. gate operators are designed to time-out in the same manner. The procedure may need to be performed multiple times to successfully pair the device to your HomeLink® buttons.

REPROGRAMMING A SINGLE

OME LINK® BUTTON

To reprogram a single HomeLink® button that has been previously trained, without erasing all the channels, follow the procedure below. Be sure to determine whether the new device you want to program the HomeLink® button to has a rolling code or non-rolling code.

1. Place the ignition in the ON/RUN position, without starting the engine.

2. Push and hold the desired HomeLink® button until the HomeLink® Indicator light begins to flash after 20 seconds. Do not release the button.

3. Without releasing the button, proceed with Step 2 in “Programming HomeLink® To A Garage Door Opener” and follow all remaining steps.

CANADIAN /GATE OPERATOR

ROGRAMMING

For programming transmitters in Canada/ United States that require the transmitter signals to “time-out” after several seconds of transmission.

Canadian radio frequency laws require transmitter signals to time-out (or quit) after several seconds of transmission – which may not be long enough for HomeLink® to pick up the signal during programming. Similar to this Canadian law, some U.S. gate operators are designed to time-out in the same manner.

It may be helpful to unplug the device during the cycling process to prevent possible overheating of the garage door or gate motor.

1. Place the ignition in the ON/RUN position.

2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink® button you wish to program while keeping the HomeLink® indicator light in view.

3. Continue to press and hold the HomeLink® button, while you press and release (cycle) your hand-held transmitter every two seconds until HomeLink® has successfully accepted the frequency signal. The indicator light will flash slowly and then rapidly when fully trained.

4. Watch for the HomeLink® indicator to change flash rates. When it changes, it is programmed. It may take up to 30 seconds or longer in rare cases. The garage door may open and close while you are programming.

5. Press and hold the programmed HomeLink® button and observe the indicator light.

NOTE:

 If the indicator light stays on constantly,

programming is complete and the garage door/device should activate when the HomeLink® button is pressed.

 To program the two remaining Home-

Link® buttons, repeat each step for each remaining button. DO NOT erase the channels.

Page 47

GETTING TO KNOW YOUR VEHICLE 45

If you unplugged the garage door opener/ device for programming, plug it back in at this time.

Reprogramming A Single HomeLink® Button (Canadian/Gate Operator)

To reprogram a channel that has been previously trained, follow these steps:

1. Place the ignition in the ON/RUN position.

2. Press and hold the desired HomeLink® button until the indicator light begins to flash after 20 seconds. Do not release the button.

3. Without releasing the button, proceed with “Canadian/Gate Operator Programming” step 2 and follow all remaining steps.

EXTERIOR LIGHTS

HEADLIGHT SWITCH

The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, instrument panel lights, instrument panel light dimming, interior lights and fog lights (if equipped).

Headlight Switch

1 — Rotate Headlight Control 2 — Push Fog Light Control 3 — Instrument Panel Dimmer Control 4 — Ambient Light Dimmer Control

Headlight Switch (Vehicles Sold In Canada Only)

1 — Rotate Headlight Control 2 — Push Fog Light Control 3 — Instrument Panel Dimmer Control 4 — Ambient Light Dimmer Control

NOTE: Vehicles sold in Canada are equipped with a headlight switch without the OFF position. In order to turn the exterior lights off, the headlight switch must be rotated to AUTO position.

To turn on the headlights, rotate the headlight switch clockwise. When the headlight switch is on, the parking lights, taillights, license plate light and instrument panel lights are also turned on. To turn off the headlights, rotate the headlight switch back to the O (off) position.

Page 48

46 GETTING TO KNOW YOUR VEHICLE

NOTE: For vehicles sold in Canada, rotate the headlight switch clockwise from the parking light and instrument panel light position to the first detent to turn the headlight switch to the AUTO position. Rotate to the second detent to turn on headlight, parking light, and instrument panel light operation.

MULTIFUNCTION LEVER

The multifunction lever is located on the left side of the steering column.

Multifunction Lever

DAYTIME RUNNING LIGHTS (DRLS) —

F EQUIPPED

The Daytime Running Lights will turn on when the engine is started and will remain on unless the headlamps are turned to the on position, the parking brake is applied, or the ignition is placed in the OFF position.

NOTE:

 For vehicles sold in Canada, the Daytime

Running Lights will automatically deactivate when the front fog lights are turned on.

 If allowed by law in the country in which the

vehicle was purchased, the Daytime Running Lights can be turned on and off using the Uconnect system Ú page 133.

 On some vehicles, the Daytime Running

Lights may deactivate, or reduce intensity, on one side of the vehicle (when a turn signal is activated on that side), or on both sides of the vehicle (when the hazard warning lights are activated).

HIGH/LOW BEAM SWITCH

Push the multifunction lever toward the instrument panel to switch the headlights to high beams. Pulling the multifunction lever back will turn the low beams on.

AUTOMATIC HIGH BEAM HEADLAMP

ONTROL — IF EQUIPPED

The Automatic High Beam Headlamp Control system provides increased forward lighting at night by automating high beam control through the use of a camera mounted on the windshield. This camera detects vehicle specific light and automatically switches from high beams to low beams until the approaching vehicle is out of view.

NOTE:

 The Automatic High Beam Headlamp Control

can be turned on or off using the Uconnect system Ú page 133.

 Broken, muddy, or obstructed headlights and

taillights of vehicles in the field of view will cause headlights to remain on longer (closer to the vehicle). Also, dirt, film, and other obstructions on the windshield or camera lens will cause the system to function improperly.

Page 49

GETTING TO KNOW YOUR VEHICLE 47

 To opt out of the Advanced Auto High-Beam

Sensitivity Control and enter Reduced High-Beam Sensitivity Control (not recommended), toggle the high beam lever six full on/off cycles within 10 seconds of placing the ignition in the ON position. The system will return to the default setting upon placing the ignition in the OFF position.

 If the windshield or Automatic High Beam

Headlamp Control mirror is replaced, the mirror must be re-aimed to ensure proper performance. See a local authorized dealer.

FLASH -TO-PASS

You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will cause the high beam headlights to turn on, and remain on, until the lever is released.

NOTE: If the multifunction lever is held in the flash-to pass position for more than 20 seconds, the high beams will shut off.

AUTOMATIC HEADLIGHTS

This system automatically turns the headlights on or off according to ambient light levels. To turn the system on, rotate the headlight switch counterclockwise to the AUTO position. When the system is on, the headlight time delay feature is also on.

When the system is on, the Headlight Delay feature is also on. This means the headlights will stay on for up to 90 seconds after you place the ignition into the OFF position. To turn the automatic headlights off, turn the headlight switch out of the AUTO position.

NOTE: The engine must be running before the headlights will come on in the automatic mode.

PARKING LIGHTS

To turn on the parking lights and instrument panel lights, rotate the headlight switch clockwise. To turn off the parking lights, rotate the headlight switch back to the O (off) position.

NOTE: For vehicles sold in Canada, rotate the headlight switch to the AUTO position to turn off the parking lights.

AUTOMATIC HEADLIGHTS WITH WIPERS

If your vehicle is equipped with Automatic Headlights, it also has this customer-programmable feature. When your headlights are in the automatic mode and the engine is running, they will automatically turn on when the wiper system is on. This feature is programmable through the Uconnect system Ú page 133.

In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature.

Page 50

48 GETTING TO KNOW YOUR VEHICLE

HEADLIGHT TIME DELAY

To assist when exiting the vehicle, the headlight delay feature will leave the headlights on for up to 90 seconds. This delay is initiated when the ignition is placed in the OFF position while the headlight switch is on, and then the headlight switch is cycled off within 45 seconds. Headlight delay can be cancelled by either turning the headlight switch on then off, or by placing the ignition in the ON position.

NOTE:

 This feature can be programmed through the

Uconnect system Ú page 133.

 If you turn the headlights off before the igni-

tion, they will turn off in the normal manner.

LIGHTS-ON REMINDER

If the headlights or parking lights are on after the ignition is placed in the OFF position, the vehicle will chime when the driver's door is opened.

FOG LIGHTS — IF EQUIPPED

To activate the front fog lights, turn on the parking lights or the low beam headlights, and push the fog light button on the headlight switch.

Fog Light Switch

Fog Light Switch (Vehicles Sold In Canada Only)

The fog lights will operate only when the parking lights are on or when the vehicle headlights are on low beam. An indicator light located in the instrument cluster will illuminate when the fog lights are on. The fog lights will turn off when the switch is pushed a second time, when the headlight switch is rotated to the off position, or the high beam is selected.

TURN SIGNALS

Move the multifunction lever up or down to activate the turn signals. The arrows on each side of the instrument cluster flash to show proper operation.

NOTE:

 If either light remains on and does not flash,

or there is a very fast flash rate, check for a defective outside light bulb.

 A “Turn Signal On” message will appear in the

instrument cluster display and a continuous chime will sound if the vehicle is driven more than 1 mile (1.6 km) with either turn signal on.

Page 51

GETTING TO KNOW YOUR VEHICLE 49

LANE CHANGE ASSIST — IF EQUIPPED

Lightly push the multifunction lever up or down, without moving beyond the detent, and the turn signal will flash three times then automatically turn off.

INTERIOR LIGHTS

The interior lights come on when a door is opened.

To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition is placed in the OFF position. This will occur if the interior lights were switched on manually or are on because a door is open. The Battery Protection also includes the glove compartment light and the trunk light. To restore interior light operation after automatic battery protection is enabled (lights off), either place the ignition in the ON/RUN position or cycle the light switch.

FRONT MAP/READING LIGHTS

These lights are mounted between the sun visors on the overhead console. Each light is turned on by pushing the lens. Push the lens a second time to turn off the light. These lights also turn on when a door is opened, when the unlock button on the remote keyless entry key fob is pushed, or when the dimmer control is turned fully upward, to the second detent.

Map/Reading Lights

AMBIENT LIGHT — IF EQUIPPED

The overhead console is equipped with an ambient light feature. This light casts illumination for improved visibility of the floor and center console area.

Rotate the right dimmer control upward or downward to increase or decrease the brightness of the door handle lights, map pocket lights, and ambient light located in the overhead console.

Door Handle/Ambient Light Dimmer

Page 52

50 GETTING TO KNOW YOUR VEHICLE

Door Handle/Ambient Light Dimmer

(Vehicles Sold In Canada Only)

DIMMER CONTROLS

The dimmer control is part of the headlight switch and is located on the left side of the instrument panel.

With the parking lights or headlights on, rotating the left dimmer control upward will increase the brightness of the instrument panel lights and lighted cupholders (if equipped).

Instrument Panel Dimmer

(Vehicles Sold In Canada Only)

Dome Light Position

Rotate the dimmer control completely upward to the second detent to turn on the interior lights. The interior lights will remain on when the dimmer control is in this position.

Interior Light Defeat (Off)

Rotate the instrument panel dimmer control to the extreme bottom (O) off position. The interior lights will remain off when the doors are open.

Parade Mode (Daytime Brightness Feature)

Rotate the instrument panel dimmer control upward to the first detent. This feature brightens all text displays such as the odometer, instrument cluster display, and radio when the parking lights or headlights are on.

Page 53

GETTING TO KNOW YOUR VEHICLE 51

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer controls are located on the multifunction lever on the left side of the steering column. The multifunction lever operates the windshield wipers and washer when the ignition is placed in the ACC or ON/RUN position.

Windshield Wiper/Washer Control

WINDSHIELD WIPER OPERATION

Rotate the end of the multifunction lever to the first detent, past the intermittent settings for low-speed wiper operation, or to the second detent past the intermittent settings for high-speed wiper operation.

Windshield Wiper Operation

Intermittent Wipers

Rotate the end of the multifunction lever to the first detent position, and then turn the end of the lever to select the desired delay interval. There are four delay settings, which allow you to regulate the wipe interval from a minimum of one cycle every second to a maximum of approximately 36 seconds between cycles. The delay intervals will double in duration when the vehicle speed is 10 mph (16 km/h) or less.

Windshield Washers

To use the washer, push the multifunction lever inward (toward the steering wheel) and hold. If the lever is pushed while in the intermittent setting, the wipers will turn on and operate for two cycles after the end of the lever is released, and then resume the intermittent interval previously selected.

If the end of the lever is pushed while the wipers are in the off position, the wipers will operate for three wipe cycles and then turn off.

WARNING!

Sudden loss of visibility through the windshield could lead to a collision. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use.

Page 54

52 GETTING TO KNOW YOUR VEHICLE

Mist

Rotate the end of the lever downward to the MIST position and release for a single wiping cycle. The wipers will continue to operate until you release the multifunction lever

NOTE: The Mist feature does not activate the washer pump; therefore, no washer fluid will be sprayed on the windshield. The wash function must be used in order to spray the windshield with washer fluid.

For information on wiper care and replacement, see Ú page 290.

CAUTION!

 Turn the windshield wipers off when driving

through an automatic car wash. Damage to the windshield wipers may result if the wiper control is left in any position other than off.

(Continued)

CAUTION! (Continued)

 In cold weather, always turn off the wiper

switch and allow the wipers to return to the park position before turning off the engine. If the wiper switch is left on and the wipers freeze to the windshield, damage to the wiper motor may occur when the vehicle is restarted.

 Always remove any buildup of snow that

prevents the windshield wiper blades from returning to the off position. If the windshield wiper control is turned off and the blades cannot return to the off position, damage to the wiper motor may occur.

RAIN SENSING WIPERS — IF EQUIPPED

This feature senses rain or snowfall on the windshield and automatically activates the wipers. Rotate the end of the multifunction lever to one of four settings to activate this feature.

The sensitivity of the system can be adjusted with the multifunction lever. Wiper delay position 1 is the least sensitive, and wiper delay position 4 is the most sensitive.

Wiper delay position three should be used for normal rain conditions.

NOTE:

 The Rain Sensing feature will not operate

when the wiper switch is in the low or high-speed position.

 The Rain Sensing feature may not function

properly when ice, or dried salt water is present on the windshield.

 Use of Rain-X or products containing wax or

silicone may reduce Rain Sensing performance.

 The Rain Sensing feature can be turned on

and off using the Uconnect system Ú page 133.

Page 55

GETTING TO KNOW YOUR VEHICLE 53

The Rain Sensing system has protection features for the wiper blades and arms, and will not operate under the following conditions:

 Low Ambient Temperature — When the igni-

tion is first placed in the ON position, the Rain Sensing system will not operate until the wiper switch is moved, vehicle speed is greater than 0 mph (0 km/h), or the outside temperature is greater than 32°F (0°C).

 Transmission In NEUTRAL Position — When

the ignition is ON, and the transmission is in the NEUTRAL position, the Rain Sensing system will not operate until the wiper switch is moved, vehicle speed is greater than 3 mph (5 km/h), or the gear selector is moved out of the NEUTRAL position.

 Remote Start Mode Inhibit — On vehicles

equipped with Remote Start system, Rain Sensing wipers are not operational when the vehicle is in the remote start mode.

CLIMATE CONTROLS

The Climate Control system allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the touchscreen (if equipped) and on the instrument panel below the radio.

AUTOMATIC CLIMATE CONTROL

ESCRIPTIONS AND FUNCTIONS

Uconnect 4 With 7–inch Display Automatic Climate

Controls

Uconnect 4C/4C NAV With 8.4–inch Display

Automatic Climate Controls

MAX A/C Button

Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output

of air. The MAX A/C indicator illuminates when MAX A/C is on. Pressing and releasing the button again will cause the MAX A/C operation to exit.

NOTE: The MAX A/C button is only available on the touchscreen.

Page 56

54 GETTING TO KNOW YOUR VEHICLE

A/C Button

Press and release this button on the touchscreen, or push the button on the faceplate to change the current setting. The A/C indicator illuminates

when A/C is ON.

The Air Conditioning (A/C) button allows the operator to manually activate or deactivate the air conditioning system. When the air conditioning system is turned on, cool dehumidified air will flow through the outlets into the cabin.

NOTE:

 If fog or mist appears on the windshield or

side glass, select Defrost mode, and increase blower speed if needed.

 If your air conditioning performance seems

lower than expected, check the front of the A/C condenser (located in front of the radiator), for an accumulation of dirt or insects. Clean with a gentle water spray from the front of the radiator and through the condenser.

Recirculation Button

Press and release this button on the touchscreen, or push the button on the faceplate to change the system

between recirculation mode and outside air mode. The Recirculation indicator and the A/C indicator illuminate when the Recirculation button is pressed. Recirculation can be used when outside conditions such as smoke, odors, dust, or high humidity are present. Recirculation can be used in all modes. Recirculation may be unavailable (button on the touchscreen greyed out) if conditions exist that could create fogging on the inside of the windshield. The A/C can be deselected manually without disturbing the mode control selection. Continuous use of the Recirculation mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended.

In cold weather, use of Recirculation mode may lead to excessive window fogging. The Recirculation feature may be unavailable if conditions exist that could create fogging on the inside of the windshield.

AUTO Button

Set your desired temperature and press AUTO. AUTO will achieve and maintain your desired temperature by

automatically adjusting the blower speed and air distribution. AUTO mode is highly recommended for efficiency. You can press and release this button on the touchscreen, or push the button on the faceplate, to turn AUTO on. The AUTO indicator illuminates when AUTO is on. Toggling this function will cause the system to switch between manual mode and automatic modes Úpage 56.

Front Defrost Button

Press and release the Front Defrost

button on the touchscreen, or push

and release the button on the

faceplate, to change the current airflow setting to Defrost mode. The Front Defrost indicator illuminates when Front Defrost is on. Air comes from the windshield and side window demist outlets. When the defrost button is selected, the blower level may increase. Use Defrost mode with maximum temperature settings for best windshield and side window defrosting and defogging. When toggling the front defrost mode button, the climate system will return to the previous setting.

Page 57

GETTING TO KNOW YOUR VEHICLE 55

Rear Defrost Button

Press and release the Rear Defrost button on the touchscreen, or push and release the button on the

faceplate, to turn on the rear window defroster and the heated outside mirrors (if equipped). The Rear Defrost indicator illuminates when the rear window defroster is on. The rear window defroster automatically turns off after 10 minutes.

CAUTION!

Failure to follow these cautions can cause damage to the heating elements:

 Use care when washing the inside of the

rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements. Labels can be peeled off after soaking with warm water.

 Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior surface of the window.

 Keep all objects a safe distance from the

window.

Driver And Passenger Up And Down Buttons

These buttons provide the driver and passenger with independent temperature control.

Push the red button on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow button on the touchscreen for

warmer temperature settings.

Push the blue button on the faceplate or touchscreen or press and slide the temperature bar towards the blue arrow on the touchscreen for cooler

temperature settings.

SYNC Button

Press the SYNC button on the touchscreen to toggle the Sync feature on/off. The SYNC indicator is

illuminated when SYNC is on. SYNC is used to synchronize the passenger temperature setting with the driver temperature setting. Changing the passenger temperature setting while in SYNC will automatically exit this feature.

NOTE: The SYNC button is only available on the touchscreen.

Blower Control

Blower Control is used to regulate the amount of air forced through the Climate Control system. There are

seven blower speeds available. Adjusting the blower will cause automatic mode to switch to manual operation. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen.

Faceplate

The blower speed increases as you turn the blower control knob clockwise from the lowest blower setting. The blower speed decreases as you turn the blower control knob counterclockwise.

Touchscreen

Use the small blower icon to reduce the blower setting and the large blower icon to increase the blower setting. Blower can also be selected by pressing the blower bar area between the icons.

Page 58

56 GETTING TO KNOW YOUR VEHICLE

Mode Control

Select Mode by pressing one of the Mode buttons on the touchscreen to change the airflow distribution mode.

The airflow distribution mode can be adjusted so air comes from the instrument panel outlets, floor outlets, defrost outlets and demist outlets.

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these

outlets can be individually adjusted to

direct the flow of air. The air vanes of the center outlets and outboard outlets can be moved up and down or side to side to regulate airflow direction. There is a shut off wheel located below the air vanes to shut off or adjust the amount of airflow from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets.

Mix Mode

Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold

or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.

Climate Control OFF Button

Press and release this button to turn

the Climate Control ON/OFF.

AUTOMATIC TEMPERATURE CONTROL (ATC)

Automatic Operation

1. Push the AUTO button on the faceplate, or the AUTO button on the touchscreen on the Automatic Temperature Control (ATC) Panel.

2. Next, adjust the temperature that you would like the system to maintain by adjusting the driver and passenger temperature control buttons. Once the desired temperature is displayed, the system will achieve and automatically maintain that comfort level.

3. When the system is set up for your comfort level, it is not necessary to change the settings. You will experience the greatest efficiency by simply allowing the system to function automatically.

Page 59

GETTING TO KNOW YOUR VEHICLE 57

NOTE:

 It is not necessary to move the temperature

settings for cold or hot vehicles. The system automatically adjusts the temperature, mode, and blower speed to provide comfort as quickly as possible.

 The temperature can be displayed in US or

Metric units within Uconnect Settings Ú page 133.

To provide you with maximum comfort in the Automatic mode during cold start-ups, the blower fan will remain on low until the engine warms up. The blower will increase in speed and transition into Auto mode.

Manual Operation Override

This system offers a full complement of manual override features. The AUTO symbol in the front ATC display will be turned off when the system is being used in the manual mode.

CLIMATE — VOICE RECOGNITION

Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.)

Push the VR button . After the beep, say one of the following commands:

 “Set driver temperature to 70 degrees”

 “Set passenger temperature to 70 degrees”

TIP: Voice Command for Climate may only be used to adjust the interior temperature of your vehicle. Voice Command will not work to adjust the heated seats or steering wheel if equipped.

OPERATING TIPS

NOTE: Refer to the chart at the end of this section for suggested control settings for various weather conditions.

Summer Operation

The engine cooling system must be protected with a high-quality antifreeze coolant to provide proper corrosion protection and to protect against engine overheating. OAT coolant (conforming to MS.90032) is recommended.

Winter Operation

To ensure the best possible heater and defroster performance, make sure the engine cooling system is functioning properly and the proper amount, type, and concentration of coolant is used. Use of the Air Recirculation mode during Winter months is not recommended, because it may cause window fogging.

Vacation/Storage

For information on maintaining the Climate Control system when the vehicle is being stored for an extended period of time, see Ú page 331.

Window Fogging

Vehicle windows tend to fog on the inside in mild, rainy, and/or humid weather. To clear the windows, select Defrost or Mix mode and increase the front blower speed. Do not use the Recirculation mode without A/C for long periods, as fogging may occur.

Page 60

58 GETTING TO KNOW YOUR VEHICLE

Outside Air Intake

Make sure the air intake, located directly in front of the windshield, is free of obstructions, such as leaves. Leaves collected in the air intake may reduce airflow, and if they enter the air distribution box, they could plug the water drains. In Winter months, make sure the air intake is clear of ice, slush, and snow.

Cabin Air Filter

The climate control system filters out dust and pollen from the air. Contact an authorized dealer to service your cabin air filter, and to have it replaced when needed.

Windshield Wiper De-Icer — If Equipped

The windshield wiper de-icer is a heating element located at the base of the windshield.

It operates automatically once the following conditions are met:

 Activation By Front Defrost

The wiper de-icer activates automatically during a cold weather manual start with full defrost, and when the ambient temperature is below 33°F (0.6°C).

 Activation By Rear Defrost

The wiper de-icer activates automatically when the Rear Defrost is operating and the ambient temperature is below 33°F (0.6°C).

 Activation By Remote Start Operation

When the Remote Start is activated and the outside ambient temperature is less than 33°F (0.6°C) the windshield wiper de-icer is activated. Upon exiting Remote Start, the climate control functions will resume their previous operation. If the de-icer is active, the de-icer timer and operation will continue.

Operating Tips Chart

WEATHER

Hot Weather And

Vehicle Interior Is Very

Hot

CONTROL SETTINGS

Set the mode control

to (Panel Mode),

(MAX A/C) on, and

blower on high. Roll

down the windows for

a minute to flush out the hot air. Adjust the controls as needed to

achieve comfort.

WEATHER

Warm Weather

Cool Sunny

Cool & Humid

Conditions

Cold Weather

CONTROL

SETTINGS

Turn (A/C)

on and set the mode

control to the

(Panel Mode)

position.

Operate in

(Bi-Level Mode)

position.

Set the mode control

to (Mix Mode) and

turn on (A/C) to

keep windows clear.

Set the mode control

to the (Floor

Mode) position. If

windshield fogging

starts to occur, move the control to the

(Mix Mode) position.

Page 61

GETTING TO KNOW YOUR VEHICLE 59

INTERIOR STORAGE AND EQUIPMENT

STORAGE

Glove Compartment

The glove compartment is located on the passenger side of the instrument panel.

Glove Compartment

To open the glove compartment, pull the release handle.

Console Features

The center console has a storage compartment located underneath the armrest. The compartment contains a 12 Volt power outlet, and is also equipped with a USB port featuring active charging, which will continue charging your device up to 60 minutes after the ignition is turned off. The USB port also may be equipped with an IPOD®/USB control Ú page 60, or Apple CarPlay® and Android Auto™ Ú page 177.

Center Console

WARNING!

Do not operate this vehicle with a console compartment lid in the open position. Driving with the console compartment lid open may result in injury in a collision.

ILLUMINATED CUPHOLDERS —

F EQUIPPED

The front cupholders are equipped with a light ring that illuminates the cupholders for the front passengers. The light ring is controlled by the dimmer control Ú page 50.

Light Ring In Front Cupholder

Page 62

60 GETTING TO KNOW YOUR VEHICLE

USB/AUX C ONTROL

Located in the front storage area of the center console, this feature allows an external USB device to be connected to the audio system.

Plugging in a smartphone device to a USB port may activate Android Auto™ or Apple CarPlay® features, if equipped

USB/AUX Ports

1 — USB 1 Port 2 — AUX Jack 3 — USB 2 Port

POWER OUTLETS

Your vehicle is equipped with 12 Volt (13 Amp) power outlets that can be used to power cellular

phones, small electronics and other low powered electrical accessories. The power outlets are labeled with either a “key” or a “battery” symbol to indicate how the outlet is powered. Power outlets labeled with a “key” can be powered when the ignition is in the ACC or ON/RUN position, while the outlets labeled with a “battery” are connected directly to the battery and powered at all times.

These power outlets can also operate a conventional cigar lighter unit.

The front power outlet is located next to the storage area on the integrated center stack of the instrument panel.

Power Outlet — Integrated Center Stack Front

NOTE: The front integrated center stack power outlet can be changed to “battery” (powered at all times) by moving the integrated center stack fuse #12 in the Rear Power Distribution Center from fuse location “IGN” to “B+” Ú page 298.

Power Outlet Fuse Locations

1 — #12 Fuse 20A Yellow Power Outlet Integrated Center Stack

2 — #38 Fuse 20A Yellow Power Outlet Center Console

Page 63

GETTING TO KNOW YOUR VEHICLE 61

In addition to the front center stack power outlet, there is also a power outlet located in the center console to the left of the media hub.

Power Outlet — Center Console

NOTE: All accessories connected to these powered outlets should be removed or turned off when the vehicle is not in use to protect the battery against discharge.

WARNING!

To avoid serious injury or death:

 Only devices designed for use in this type of

outlet should be inserted into any 12 Volt outlet.

 Do not touch with wet hands.

 Close the lid when not in use and while

driving the vehicle.

 If this outlet is mishandled, it may cause an

electric shock and failure.

CAUTION!

 Do not exceed the maximum power of

160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced.

 Power outlets are designed for accessory

plugs only. Do not insert any other object in the power outlets as this will damage the outlet and blow the fuse. Improper use of the power outlet can cause damage not covered by your New Vehicle Limited Warranty.

(Continued)

CAUTION! (Continued)

 Many accessories that can be plugged in

draw power from the vehicle's battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle's battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting.

 Accessories that draw higher power (i.e.,

coolers, vacuum cleaners, lights, etc.), will degrade the battery even more quickly. Only use these intermittently and with greater caution.

 After the use of high power draw accesso-

ries, or long periods of the vehicle not being started (with accessories still plugged in), the vehicle must be driven a sufficient length of time to allow the alternator to recharge the vehicle's battery.

 Power outlets are designed for accessory

plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage.

Page 64

62 GETTING TO KNOW YOUR VEHICLE

WINDOWS

POWER WINDOW CONTROLS

The window switches on the driver's door control all the door windows.

Power Window Switches

The passenger door window can also be operated by using the single window controls on the passenger door trim panel. The window controls will operate only when the ignition is in the ACC or ON/RUN position.

NOTE: The power window switches will remain active for up to 10 minutes after the ignition is placed in the OFF position. Opening either front door will cancel this feature. The timing is programmable within Uconnect Settings Ú page 133.

WARNING!

Never leave children unattended in a vehicle, and do not let children play with power windows. Do not leave the key fob in or near the vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. Occupants, particularly unattended children, can become entrapped by the windows while operating the power window switches. Such entrapment may result in serious injury or death.

Automatic Window Features

The driver and, in some models, passenger power window switches have an Auto-Down feature. Push the window switch to the second detent, release, and the window will go down automatically.

To open the window part way, push the window switch to the first detent and release it when you want the window to stop.

To stop the window from going all the way down during the Auto-Down operation, pull up on the switch briefly.

WIND BUFFETING

Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occurrence and can be minimized. If the

Page 65

GETTING TO KNOW YOUR VEHICLE 63

buffeting occurs with the windows open, partially close the windows to minimize the buffeting. If the buffeting occurs with the sunroof open, adjust the sunroof opening to minimize the buffeting or open any window.

POWER SUNROOF — IF EQUIPPED

The power sunroof switch is located between the sun visors on the overhead console.

Power Sunroof Switch

WARNING!

 Never leave children unattended in a

vehicle, or with access to an unlocked vehicle. Never leave the key fob in or near the vehicle, or in a location accessible to children. Do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. Occupants, particularly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.

 In a collision, there is a greater risk of being

thrown from a vehicle with an open sunroof. You could also be seriously injured or killed. Always fasten your seat belt properly and make sure all passengers are also properly secured.

 Do not allow small children to operate the

sunroof. Never allow your fingers, other body parts, or any object, to project through the sunroof opening. Injury may result.

OPENING AND CLOSING THE SUNROOF

Express Open/Close

Push the switch rearward and release it within one-half second, the sunroof and sunshade will open automatically and stop at full open position.

Push the switch forward and release it within one-half second and the sunroof will close automatically from any position.

During Express Open or Express Close operation, any other movement of the sunroof switch will stop the sunroof.

Manual Open/Close

Push and hold the switch rearward, the sunroof and sunshade will open and automatically stop at full open position.

Push and hold the switch forward and the sunroof will close from any position and stop at a full closed position.

Any release of the switch during open or close operation will stop the sunroof movement. The sunroof will remain in a partially opened position until the switch is operated and held again.

Page 66

64 GETTING TO KNOW YOUR VEHICLE

PINCH PROTECT FEATURE

This feature will detect an obstruction in the closing of the sunroof during the Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract. Remove the obstruction if this occurs.

NOTE: If three consecutive sunroof close attempts result in Pinch Protect reversals, Pinch Protect will disable and the sunroof must be closed in Manual Mode.

VENTING SUNROOF

Push and release the Vent switch within one half second and the sunroof will open to the vent position. During Express Vent operation, any other actuation of the sunroof switches will stop the sunroof operation.

SUNSHADE OPERATION

The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens.

NOTE: The sunshade cannot be closed if the sunroof is open.

SUNROOF MAINTENANCE

Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. Periodically check for and clear out any debris that may have collected in the tracks.

IGNITION OFF OPERATION

NOTE:

 The power sunroof switch can remain active

in Accessory Delay for up to approximately 10 minutes after the vehicle’s ignition is placed to the OFF position. Opening either front door will cancel this feature.

 This feature is programmable using the

Uconnect system Ú page 133.

HOOD

OPENING THE HOOD

To open the hood, two latches must be released.

1. Pull the release lever located underneath the driver’s side of the instrument panel.

Hood Release Lever

2. Reach under the hood, push the safety catch to the left and lift the hood.

Hood Safety Catch Location

Page 67

GETTING TO KNOW YOUR VEHICLE 65

CLOSING THE H OOD

WARNING!

Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.

CAUTION!

To prevent possible damage, do not slam the hood to close it. Lower hood to approximately 12 inches (30 cm) and drop the hood to close. Make sure hood is fully closed for both latches. Never drive vehicle unless hood is fully closed, with both latches engaged.

TRUNK

OPENING THE TRUNK

The trunk may be opened in several ways:

 Power trunk release button on the instru-

ment panel

 Trunk button on the key fob

 Trunk passive entry button Ú page 24

 External release switch located on the under-

side of the decklid overhang

NOTE: The release feature will function only when the vehicle is unlocked.

With the ignition in the ON/RUN position, the trunk open symbol will display in the instrument cluster indicating that the trunk is open. The odometer display will reappear once the trunk is closed.

With the ignition in the OFF position, the trunk open symbol will display until the trunk is closed.

Power Trunk Release Button

The trunk can be opened from inside the vehicle using the power trunk release button located on the instrument panel to the left of the

steering wheel.

NOTE: The automatic transmission must be in PARK before the button will operate. For manual transmissions, the vehicle must be in NEUTRAL.

Key Fob Trunk Release Button

Push the power trunk button on the key fob twice within five seconds to release the trunk.

Passive Entry Button

Push the trunk passive entry button which is located on the back of the trunk lid. With a valid Passive Entry key fob within 5 ft (1.5 m) of the trunk, push the passive entry button to open the trunk.

Trunk Passive Entry Button

Page 68

66 GETTING TO KNOW YOUR VEHICLE

CLOSING THE T RUNK

With one or more hands placed on the outside trunk surface push the trunk lid down until you hear the trunk lock latch into place.

NOTE: Before closing the trunk lid, make sure your key fob is not inside the trunk area. The trunk will latch then automatically unlock if the key fob is sensed, not allowing the key fob to be locked in the trunk area.

TRUNK SAFETY

Trunk Emergency Release

As a security measure, a trunk internal emergency release lever is built into the trunk latching mechanism. In the event of an individual being locked inside the trunk, the trunk can be opened by actuating the glow-in-the-dark handle attached to the trunk latching mechanism.

Trunk Emergency Release

WARNING!

Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended. Once in the trunk, young children may not be able to escape, even if they entered through the rear seat. If trapped in the trunk, children can die from suffocation or heat stroke.

Page 69

GETTING TO KNOW YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER

Instrument Cluster For 3.6L or 5.7L Engine

Page 70

68 GETTING TO KNOW YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DESCRIPTIONS

1. Tachometer

 Indicates the engine speed in revolutions

per minute (RPM x 1000).

2. Instrument Cluster Display

 When the appropriate conditions exist,

this display shows the instrument cluster display messages Ú page 69.

Instrument Cluster Display

3. Speedometer

 Indicates vehicle speed.

4. Temperature Gauge

 The temperature gauge shows engine

coolant temperature. Any reading within the normal range indicates that the engine cooling system is operating satisfactorily.

 The gauge pointer will likely indicate a

higher temperature when driving in hot weather, up mountain grades, or when towing a trailer. It should not be allowed to exceed the upper limits of the normal operating range.

WARNING!

A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. It is recommended to call an authorized dealer for service if your vehicle overheats Ú page 292.

CAUTION!

Driving with a hot engine cooling system could damage your vehicle. If the temperature gauge reads “H,” pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range. If the pointer remains on the “H,” turn the engine off immediately and call an authorized dealer for service.

5. Fuel Gauge

 The pointer shows the level of fuel in the

fuel tank when the Keyless Push Button Ignition is in the ON/RUN position.

 The fuel pump symbol points

to the side of the vehicle where the fuel door is located.

NOTE: The hard telltales will illuminate for a bulb check when the ignition is first cycled.

Page 71

GETTING TO KNOW YOUR INSTRUMENT PANEL 69

INSTRUMENT CLUSTER DISPLAY

Your vehicle is equipped with an instrument cluster display, which offers useful information to the driver. With the ignition in the OFF mode, opening/closing of a door will activate the display for viewing, and display the total miles, or kilometers, in the odometer. Your instrument cluster display is designed to display important information about your vehicle’s systems and features. Using a driver interactive display located on the instrument panel, your instrument cluster display can show you how systems are working and give you warnings when they are not. The steering wheel mounted controls allow you to scroll through the main menus and submenus. You can access the specific information you want and make selections and adjustments.

LOCATION AND CONTROLS

The instrument cluster display features an interactive display which is located in the instrument cluster.

Instrument Cluster Display

This system conveniently allows the driver to select a variety of useful information by pushing the arrow buttons located on the left side of the steering wheel. The instrument cluster display menu items consist of the following:

 Speedometer

 Vehicle Info

 Driver Assist — If Equipped

 Fuel Economy

 Trip

 Audio

 Messages

 Screen Setup

The system allows the driver to select information by pushing the following buttons mounted on the steering wheel:

Instrument Cluster Display Controls

Up And Down Arrow Buttons:

Using the up or down arrow button allows you to cycle through the Main Menu Items.

Changes the Main Screen area and Menu Title area.

Left And Right Arrow Buttons:

Using the left or right arrow button allows you to cycle through the submenu items of the Main menu item.

Page 72

70 GETTING TO KNOW YOUR INSTRUMENT PANEL

NOTE:

 Holding the up or down or left or

right arrow button will loop the user through the currently selected menu or options presented on the screen.

 Upon returning to a main menu, the last

submenu screen viewed within that main menu will be displayed.

OK Button:

For Digital Speedometer:

 Pushing the OK button changes units (mph or

km/h).

For Screen Setup:

 OK button allows user to enter menu and

submenus.

 Within each submenu layer, the up and

down arrow buttons will allow the user to select the item of interest.

 Pushing the OK button makes the selection

and a confirmation screen will appear (returning the user to the first page of the submenu).

 Pushing the left arrow button will exit each

submenu layer and return to the main menu.

For the Trip and Fuel Economy menus (and Performance Timers) — If Equipped:

 Information is reset by pushing and holding

the OK button.

ENGINE OIL LIFE RESET

Oil Change Required

Your vehicle is equipped with an engine oil change indicator system. The “Oil Change Required” message will display in the instrument cluster display for five seconds after a single chime has sounded, to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate, dependent upon your personal driving style.

Unless reset, this message will continue to display each time you place the ignition in the ON/RUN position. To turn off the message temporarily, push and release the OK or arrow buttons. To reset the oil change indicator system (after performing the scheduled maintenance), refer to the following procedure.

Vehicles Equipped With Keyless Enter-N-Go — Ignition

Use the steering wheel instrument cluster display controls for the following procedure(s):

1. Without pressing the brake pedal, push the ENGINE START/STOP button and place the ignition in the ON/RUN position (do not start the engine).

2. Push and release the down arrow button to scroll downward through the main menu to “Vehicle Info.”

3. Push and release the right arrow button to access the ”Oil Life” screen.

4. Push and hold the OK button to reset oil life. If conditions are met, the gauge and numeric display will update to show 100%. If conditions are not met a pop-up message of "To reset oil life engine must be off with ignition in run” will be displayed (for five seconds), and the user will remain at the Oil Life screen.

5. Push and release the up or down arrow button to return to previous main menu.

Page 73

GETTING TO KNOW YOUR INSTRUMENT PANEL 71

NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary, repeat this procedure.

Secondary Method Of Resetting Engine Oil Life

1. Without pressing the brake pedal, push the ENGINE START/STOP button and place the ignition to the ON/RUN position (do not start the engine).

2. Fully press the accelerator pedal, slowly, three times within ten seconds.

3. Without pushing the brake pedal, push the ENGINE START/STOP button once to return the ignition to the OFF/LOCK position.

NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary, repeat this procedure.

PERFORMANCE SHIFT INDICATOR (PSI)

F EQUIPPED

— I

The PSI is enabled on vehicles with manual transmission, or when a vehicle with automatic transmission is in manual shift mode. The PSI

provides the driver with a visual indication within the instrument cluster display when the driver configured gear shift point has been reached and the driver is still accelerating. This indication notifies the driver to change gear corresponding to the configured RPMs in the head unit.

INSTRUMENT CLUSTER DISPLAY

ELECTABLE MENU ITEMS

Push and release the up or down arrow button until the desired Selectable Menu item is displayed in the instrument cluster display.

Follow the Menu or submenu prompts as desired.

Speedometer

Push and release the up or down arrow button until the speedometer menu is displayed in the instrument cluster display. Push and release the OK button to toggle units (km/h or mph) of the speedometer.

Vehicle Info

Push and release the up or down arrow button until the “Vehicle Info” menu is displayed in the instrument cluster display. Push and

release the right or left arrow button to scroll through the submenus items of “Vehicle Info.” Follow the directional prompts to access or reset any of the following “Vehicle Info” submenu items:

Tire Pressure Monitor

If tire pressure is OK for all tires, a vehicle ICON is displayed with tire pressure values in each corner of the ICON.

If one or more tires have low pressure, “Inflate Tire To XX” is displayed with the vehicle ICON and the tire pressure values in each corner of the ICON with the pressure value of the low tire are displayed in a different color than the other tire pressure value.

If the Tire Pressure system requires service, “Service Tire Pressure System” is displayed.

Tire PSI is an information only function and cannot be reset Ú page 210.

Coolant Temp

 Displays the actual coolant temperature.

Trans Temp

 Displays the actual transmission tempera-

ture.

Page 74

72 GETTING TO KNOW YOUR INSTRUMENT PANEL

Oil Temp

 Displays the actual oil temperature.

Oil Pressure

 Displays the actual oil pressure.

Oil Life

To reset the Oil Life, you must hold the OK button. The “Hold OK to Reset” instruction will be displayed at all times, but the following conditions will need to be met in order to reset Oil Life:

 The vehicle must be off

 The ignition must be in the ON/RUN position

If the conditions are met, holding the OK button will reset the gauge and the numeric display will return to 100%.

If the conditions are not met, a pop-up message will display for 5 seconds, describing the required conditions, and then the Oil Life screen will reappear.

Battery Voltage

 Displays the actual battery voltage.

All Wheel Drive (AWD) Status — If Equipped

 Displays the status of the All - Wheel Drive

system.

Driver Assist — If Equipped

Adaptive Cruise Control (ACC) Menu

The instrument cluster display displays the current ACC system settings. The information displayed depends on ACC system status.

Push the ACC ON/OFF button (located on the steering wheel) until one of the following displays in the instrument cluster display:

Adaptive Cruise Control Off

When ACC is deactivated, the display will read “Adaptive Cruise Control Off.”

Adaptive Cruise Control Ready

When ACC is activated but the vehicle speed setting has not been selected, the display will read “Adaptive Cruise Control Ready.”

Push the SET + or the SET- button (located on the steering wheel) and the following will display in the instrument cluster display:

ACC SET

When ACC is set, the set speed will display in the instrument cluster.

If the Driver Assist main menu is not selected, an ACC pop - up message may display if any ACC activity occurs, which may include any of the following:

 Distance Setting Change

 System Cancel

 Driver Override

 System Off

 ACC Proximity Warning

 ACC Unavailable Warning

The instrument cluster display will return to the last display selected after five seconds of no ACC display activity Ú page 106.

Page 75

GETTING TO KNOW YOUR INSTRUMENT PANEL 73

Fuel Economy

Two submenu pages; one with Current Value (instantaneous calculation of the fuel economy) displayed and one without the Current Value

displayed (toggle the left or right arrow button to select one):

 Current Fuel Economy (MPG, L/100 km, or

km/L).

 Range To Empty (miles or km).

 Average Fuel Economy (MPG, L/100 km, or

km/L).

 The Max and Min values will correspond to

the particular engine requirements.

 Lower end of gauge will be displayed in an

amber color and turn green as Fuel Economy improves.

 Hold the OK button to reset average fuel

economy information.

Trip Info

Push and release the up or down arrow button until the Trip Menu item is displayed in the instrument cluster display. Toggle the left

or right arrow button to select Trip A or

Trip B. The Trip information will display the following:

 Distance – Shows the total distance (mi or

km) traveled for Trip A or Trip B since the last reset.

 Average Fuel Economy – Shows the average

fuel economy (MPG, L/100km or km/L) of Trip A or Trip B since the last reset.

 Elapsed Time – Shows the total elapsed time

of travel since the last reset.

Hold the OK button to reset feature information.

Audio

This menu displays the Audio information of the currently playing audio source (e.g. FM radio).

Messages

This feature shows the number of stored warning messages, if any. Pushing the right or left arrow button will allow you to scroll

through the stored messages.

Screen Setup

Push and release the up or down arrow button until the Screen Setup Menu displays in the instrument cluster display. Push and release the OK button to enter the submenus. The Screen Setup feature allows you to change what information is displayed in the instrument cluster as well as the location that information is displayed.

1. Upper Left

 Compass

 Outside Temp

 Time

 Range to Empty

 Average (MPG, L/100 km, or km/L)

 Current (MPG, L/100 km, or km/L)

 Trip A Distance

 Trip B Distance

 None

Page 76

74 GETTING TO KNOW YOUR INSTRUMENT PANEL

2. Upper Right

 Compass

 Outside Temp

 Time

 Range to Empty

 Average (MPG, L/100 km, or km/L)

 Current (MPG, L/100 km, or km/L)

 Trip A Distance

 Trip B Distance

 None

3. Center

 Menu Title

 Compass

 Outside Temp

 Time

 Range to Empty

 Average (MPG, L/100 km, or km/L)

 Current (MPG, L/100 km, or km/L)

 Trip A Distance

 Trip B Distance

 Audio Information

 Digital Speed

 None

4. Current Gear

 On

 Off

5. Odometer

 Show

 Hide

6. Gear Display

 Full

 Single

7. Restore Defaults

 Ok

 Cancel

BATTERY SAVER ON/BATTERY SAVER

ODE MESSAGE — ELECTRICAL LOAD

EDUCTION ACTIONS — IF EQUIPPED

This vehicle is equipped with an Intelligent Battery Sensor (IBS) to perform additional monitoring of the electrical system and status of the vehicle battery.

In cases when the IBS detects charging system failure, or the vehicle battery conditions are deteriorating, electrical load reduction actions will take place to extend the driving time and distance of the vehicle. This is done by reducing power to or turning off non-essential electrical loads.

Load reduction is only active when the engine is running. It will display a message if there is a risk of battery depletion to the point where the vehicle may stall due to lack of electrical supply, or will not restart after the current drive cycle.

When load reduction is activated, the message “Battery Saver On” or “Battery Saver Mode” will appear in the instrument cluster.

These messages indicate the vehicle battery has a low state of charge and continues to lose electrical charge at a rate that the charging system cannot sustain.

Page 77

GETTING TO KNOW YOUR INSTRUMENT PANEL 75

NOTE:

 The charging system is independent from

load reduction. The charging system performs a diagnostic on the charging system continuously.

 If the Battery Charge Warning Light is on it

may indicate a problem with the charging system Ú page 77.

The electrical loads that may be switched off (if equipped), and vehicle functions which can be affected by load reduction:

 Heated Seat/Vented Seats/Heated Wheel

 Heated/Cooled Cup Holders — If Equipped

 Rear Defroster And Heated Mirrors

 HVAC System

 115 Volts AC Power Inverter System

 Audio and Telematics System

Loss of the battery charge may indicate one or more of the following conditions:

 The charging system cannot deliver enough

electrical power to the vehicle system because the electrical loads are larger than the capability of the charging system. The charging system is still functioning properly.

 Turning on all possible vehicle electrical

loads (e.g. HVAC to max settings, exterior and interior lights, overloaded power outlets +12 Volts, 115 Volts AC, USB ports) during certain driving conditions (city driving, towing, frequent stopping).

 Installing options like additional lights,

upfitter electrical accessories, audio systems, alarms and similar devices.

 Unusual driving cycles (short trips separated

by long parking periods).

 The vehicle was parked for an extended

period of time (weeks, months).

 The battery was recently replaced and was

not charged completely.

 The battery was discharged by an electrical

load left on when the vehicle was parked.

 The battery was used for an extended period

with the engine not running to supply radio, lights, chargers, +12 Volts portable appliances like vacuum cleaners, game consoles and similar devices.

What to do when an electrical load reduction action message is present (“Battery Saver On” or “Battery Saver Mode”)

During a trip:

 Reduce power to unnecessary loads if

possible:

 Turn off redundant lights (interior or exterior)

 Check what may be plugged in to power

outlets +12 Volts, 115 Volts AC, USB ports

 Check HVAC settings (blower, temperature)

 Check the audio settings (volume)

Page 78

76 GETTING TO KNOW YOUR INSTRUMENT PANEL

After a trip:

 Check if any aftermarket equipment was

installed (additional lights, upfitter electrical accessories, audio systems, alarms) and review specifications if any (load and Ignition Off Draw currents).

 Evaluate the latest driving cycles (distance,

driving time and parking time).

 The vehicle should have service performed if

the message is still present during consecutive trips and the evaluation of the vehicle and driving pattern did not help to identify the cause.

WARNING LIGHTS AND MESSAGES

The warning/indicator lights will illuminate in the instrument panel together with a dedicated message and/or acoustic signal when applicable. These indications are indicative and precautionary and as such must not be considered as exhaustive and/or alternative to the information contained in the Owner’s Manual, which you are advised to read carefully in all cases. Always refer to the information in this chapter in the event of a failure indication. All active telltales will display first if applicable.

The system check menu may appear different based upon equipment options and current vehicle status. Some telltales are optional and may not appear.

RED WARNING LIGHTS

Air Bag Warning Light

This warning light will illuminate to indicate a fault with the air bag, and will turn on for four to eight seconds as

a bulb check when the ignition is placed in the ON/RUN or ACC/ON/RUN position. This light will illuminate with a single chime when a fault with the air bag has been detected, it will stay on until the fault is cleared. If the light is either not on during startup, stays on, or turns on while driving, have the system inspected at an authorized dealer as soon as possible.

Brake Warning Light

This warning light monitors various

brake functions, including brake fluid

level and parking brake application. If

the brake light turns on it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the Anti-Lock Brake System reservoir.

If the light remains on when the parking brake has been disengaged, and the fluid level is at the full mark on the master cylinder reservoir, it indicates a possible brake hydraulic system malfunction or that a problem with the Brake Booster has been detected by the Anti-Lock Brake System (ABS) / Electronic Stability Control (ESC) system. In this case, the light will remain on until the condition has been corrected. If the problem is related to the brake booster, the ABS pump will run when applying the brake, and a brake pedal pulsation may be felt during each stop.

The dual brake system provides a reserve braking capacity in the event of a failure to a portion of the hydraulic system. A leak in either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level.

The light will remain on until the cause is corrected.

Page 79

GETTING TO KNOW YOUR INSTRUMENT PANEL 77

NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level conditions. The vehicle should have service performed, and the brake fluid level checked.

If brake failure is indicated, immediate repair is necessary.

WARNING!

Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have a collision. Have the vehicle checked immediately.

Vehicles equipped with the Anti-Lock Brake System (ABS) are also equipped with Electronic Brake Force Distribution (EBD). In the event of an EBD failure, the Brake Warning Light will turn on along with the ABS Light. Immediate repair to the ABS system is required.

Operation of the Brake Warning Light can be checked by turning the ignition switch from the OFF position to the ON/RUN position. The light should illuminate for approximately two seconds. The light should then turn off unless

the parking brake is applied or a brake fault is detected. If the light does not illuminate, have the light inspected by an authorized dealer.

The light also will turn on when the parking brake is applied with the ignition switch in the ON/RUN position.

NOTE: This light shows only that the parking brake is applied. It does not show the degree of brake application.

Seat Belt Reminder Warning Light

This warning light indicates when the

driver or passenger seat belt is

unbuckled. When the ignition is first

placed in the ON/RUN or ACC/ON/ RUN position and if the driver’s seat belt is unbuckled, a chime will sound and the light will turn on. When driving, if the driver or front passenger seat belt remains unbuckled, the Seat Belt Reminder Light will flash or remain on continuously and a chime will sound Ú page 214.

Battery Charge Warning Light

This warning light will illuminate when

the battery is not charging properly. If

it stays on while the engine is running, there may be a malfunction with the charging system. Contact an authorized dealer as soon as possible.

This indicates a possible problem with the electrical system or a related component.

Door Open Warning Light

This indicator will illuminate when a door is ajar/open and not fully closed.

NOTE: If the vehicle is moving, there will also be a single chime.

Electric Power Steering (EPS) Fault Warning Light

This warning light will turn on when there's a fault with the EPS system Ú page 103.

WARNING!

Continued operation with reduced assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible.

Page 80

78 GETTING TO KNOW YOUR INSTRUMENT PANEL

Electronic Throttle Control (ETC) Warning Light

This warning light will illuminate to indicate a problem with the Electronic Throttle Control (ETC) system. If a

problem is detected while the vehicle is running, the light will either stay on or flash depending on the nature of the problem. Cycle the ignition when the vehicle is safely and completely stopped and the transmission is placed in the PARK position. The light should turn off. If the light remains on with the vehicle running, your vehicle will usually be drivable; however, see an authorized dealer for service as soon as possible.

NOTE: This light may turn on if the accelerator and brake pedals are pressed at the same time.

If the light continues to flash when the vehicle is running, immediate service is required and you may experience reduced performance, an elevated/rough idle, or engine stall and your vehicle may require towing. The light will come on when the ignition is placed in the ON/RUN or ACC/ON/RUN position and remain on briefly as a bulb check. If the light does not come on

during starting, have the system checked by an authorized dealer.

Engine Coolant Temperature Warning Light

This warning light warns of an overheated engine condition. If the engine coolant temperature is too

high, this indicator will illuminate and a single chime will sound. If the temperature reaches the upper limit, a continuous chime will sound for four minutes or until the engine is able to cool, whichever comes first.

If the light turns on while driving, safely pull over and stop the vehicle. If the Air Conditioning (A/ C) system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the vehicle. If the temperature reading does not return to normal, turn the engine off immediately and call for service Ú page 269.

Trunk Open Warning Light

This indicator will illuminate when the

trunk is open and not fully closed.

NOTE: If the vehicle is moving, there will also be a single chime.

Oil Pressure Warning Light

This warning light will illuminate to indicate low engine oil pressure. If the light turns on while driving, stop the

vehicle, shut off the engine as soon as possible, and contact an authorized dealer. A chime will sound when this light turns on.

Do not operate the vehicle until the cause is corrected. This light does not indicate how much oil is in the engine. The engine oil level must be checked under the hood.

Oil Temperature Warning Light

This warning light will illuminate to

indicate the engine oil temperature is

high. If the light turns on while driving,

stop the vehicle and shut off the engine as soon as possible. Wait for oil temperature to return to normal levels.

Transmission Temperature Warning Light — If Equipped

This warning light will illuminate to

warn of a high transmission fluid

temperature. This may occur with

strenuous usage such as trailer towing. If this light turns on, stop the vehicle and

Page 81

GETTING TO KNOW YOUR INSTRUMENT PANEL 79

run the engine at idle or slightly faster, with the transmission in PARK (P) or NEUTRAL (N), until the light turns off. Once the light turns off, you may continue to drive normally.

WARNING!

If you continue operating the vehicle when the Transmission Temperature Warning Light is illuminated you could cause the fluid to boil over, come in contact with hot engine or exhaust components and cause a fire.

CAUTION!

Continuous driving with the Transmission Temperature Warning Light illuminated will eventually cause severe transmission damage or transmission failure.

Vehicle Security Warning Light — If Equipped

This light will flash at a fast rate for approximately 15 seconds when the vehicle security system is arming, and then will flash slowly until the

vehicle is disarmed.

YELLOW WARNING LIGHTS

Service Adaptive Cruise Control Warning Light — If Equipped

This light will turn on when a ACC is not operating and needs service Ú page 106.

Anti-Lock Brake System (ABS) Warning Light

This warning light monitors the ABS. The light will turn on when the ignition is placed in the ON/RUN or ACC/ON/ RUN position and may stay on for as

long as four seconds.

If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not functioning and service is required as soon as possible. However, the conventional brake system will continue to operate normally, assuming the Brake Warning Light is not also on.

If the ABS light does not turn on when the ignition is placed in the ON/RUN or ACC/ON/ RUN position, have the brake system inspected by an authorized dealer.

Electronic Stability Control (ESC) Active Warning Light — If Equipped

This warning light will indicate when

the ESC system is Active. The ESC

Indicator Light in the instrument

cluster will come on when the ignition is placed in the ON/RUN or ACC/ON/RUN position, and when ESC is activated. It should go out with the engine running. If the ESC Indicator Light comes on continuously with the engine running, a malfunction has been detected in the ESC system. If this warning light remains on after several ignition cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see an authorized dealer as soon as possible to have the problem diagnosed and corrected.

 The ESC OFF Indicator Light and the ESC Indi-

cator Light come on momentarily each time the ignition is placed in the ON/RUN or ACC/ ON/RUN position.

 The ESC system will make buzzing or clicking

sounds when it is active. This is normal; the sounds will stop when ESC becomes inactive.

 This light will come on when the vehicle is in

an ESC event.

Page 82

80 GETTING TO KNOW YOUR INSTRUMENT PANEL

Electronic Stability Control (ESC) OFF Warning Light — If Equipped

This warning light indicates the ESC is off.

Each time the ignition is turned to ON/ RUN or ACC/ON/RUN, the ESC system will be on, even if it was turned off previously.

Low Fuel Warning Light

When the fuel level reaches

approximately 2 gal (7.5 L), this light

will turn on and a chime will sound. The

light will remain on until fuel is added.

Low Washer Fluid Warning Light

This warning light will illuminate when

the windshield washer fluid is low.

Loose Fuel Filler Cap Warning Light — If Equipped

This warning light will illuminate when

the fuel filler cap is loose. Properly

close the filler cap to disengage the

light. If the light does not turn off, please see an authorized dealer.

Engine Check/Malfunction Indicator Warning Light (MIL)

The Engine Check/Malfunction Indicator Light (MIL) is a part of an Onboard Diagnostic System called

OBD II that monitors engine and automatic transmission control systems. This warning light will illuminate when the ignition is in the ON/RUN position before engine start. If the bulb does not come on when turning the ignition switch from OFF to ON/RUN, have the condition checked promptly.

Certain conditions, such as a loose or missing gas cap, poor quality fuel, etc., may illuminate the light after engine start. The vehicle should be serviced if the light stays on through several typical driving styles. In most situations, the vehicle will drive normally and will not require towing.

When the engine is running, the MIL may flash to alert serious conditions that could lead to immediate loss of power or severe catalytic converter damage. The vehicle should be serviced by an authorized dealer as soon as possible if this occurs.

WARNING!

A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park over flammable substances such as dry plants, wood, cardboard, etc. This could result in death or serious injury to the driver, occupants or others.

CAUTION!

Prolonged driving with the Malfunction Indicator Light (MIL) on could cause damage to the vehicle control system. It also could affect fuel economy and driveability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required.

Service AWD Warning Light — If Equipped

This telltale will turn on to indicate the All Wheel Drive (AWD) system is not functioning properly and that service is required. Contact an authorized dealer.

Page 83

GETTING TO KNOW YOUR INSTRUMENT PANEL 81

Service Forward Collision Warning (FCW) Light — If Equipped

This warning light will illuminate to indicate a fault in the Forward Collision Warning System. Contact an authorized dealer for service Úpage 208.

Tire Pressure Monitoring System (TPMS) Warning Light

The warning light switches on and a message is displayed to indicate that the tire pressure is lower than the

recommended value and/or that slow pressure loss is occurring. In these cases, optimal tire duration and fuel consumption may not be guaranteed.

Should one or more tires be in the condition mentioned above, the display will show the indications corresponding to each tire.

CAUTION!

Do not continue driving with one or more flat tires as handling may be compromised. Stop the vehicle, avoiding sharp braking and steering. If a tire puncture occurs, repair immediately using the dedicated tire repair kit and contact an authorized dealer as soon as possible.

Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.

As an added safety feature, your vehicle has been equipped with a TPMS that illuminates a low tire pressure telltale when one or more of your tires is significantly underinflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly underinflated tire causes the tire to overheat and can lead to tire failure. Underinflation also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability.

Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if underinflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated. This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly.

Page 84

82 GETTING TO KNOW YOUR INSTRUMENT PANEL

CAUTION!

The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style. Aftermarket wheels can cause sensor damage. Using aftermarket tire sealants may cause the Tire Pressure Monitoring System (TPMS) sensor to become inoperable. After using an aftermarket tire sealant it is recommended that you take your vehicle to an authorized dealer to have your sensor function checked.

YELLOW INDICATOR LIGHTS

Forward Collision Warning OFF Indicator Light — If Equipped

This indicator light illuminates to

indicate that Forward Collision

Warning is off.

GREEN INDICATOR LIGHTS

Adaptive Cruise Control (ACC) Set Without Target Vehicle Light — If Equipped

This will display the distance setting for the ACC system when the system is engaged Ú page 106.

Adaptive Cruise Control (ACC) Set With Target Vehicle Light — If Equipped

This will display when the ACC is set and the vehicle in front is detected Ú page 106.

Park/Headlight On Indicator Light

This indicator light will illuminate when the park lights or headlights are turned on Ú page 45.

Front Fog Indicator Light — If Equipped

This indicator light will illuminate when the front fog lights are on Ú page 45.

Turn Signal Indicator Lights

When the left or right turn signal is activated, the turn signal indicator will flash independently and the

corresponding exterior turn signal lamps will flash. Turn signals can be activated when the multifunction lever is moved down (left) or up (right).

NOTE:

 A continuous chime will sound if the vehicle is

driven more than 1 mile (1.6 km) with either turn signal on.

 Check for an inoperative outside light bulb if

either indicator flashes at a rapid rate.

ECO Mode Indicator Light — If Equipped

This light will turn on when ECO Mode

is active. Refer to the Drive Modes

Supplement for further information.

Page 85

GETTING TO KNOW YOUR INSTRUMENT PANEL 83

Cruise Control Set Indicator Light — If Equipped

This indicator light will illuminate when the cruise control is set to the desired speed Ú page 103.

Sport Mode Indicator Light — If Equipped

This light will turn on when Sport Mode is active.

Refer to the Drive Modes Supplement

for further information.

WHITE INDICATOR LIGHTS

Cruise Control Ready Indicator

This indicator light will illuminate when the cruise control is ready, but not set Ú page 103.

Adaptive Cruise Control (ACC) Ready Light — If Equipped

This light will turn on when ACC has been turned on, but is not set Ú page 106.

Speed Warning Indicator Light — If Equipped

The indicator light will illuminate white along with a notification text message (Speed Warning Set to XX followed by

unit). When the set speed is just exceeded, a single chime will sound along with pop up message of Speed Warning Exceeded. When the set speed is exceeded, the indicator will light up yellow and flash along with a continuous chime (up to 10 seconds or until the speed is no longer exceeded).

NOTE: The number “31” is only an example of a speed that can be selected.

BLUE INDICATOR LIGHTS

High Beam Indicator Light

This indicator light will illuminate to indicate that the high beam headlights are on. With the low beams

activated, push the multifunction lever forward (toward the front of the vehicle) to turn on the high beams. Pull the multifunction lever rearward (toward the rear of the vehicle) to turn off the high beams. If the high beams are off, pull the lever toward you for a temporary high beam on, "flash to pass" scenario.

ONBOARD DIAGNOSTIC SYSTEM — OBD II

Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emissions well within current government regulations.

Page 86

84 GETTING TO KNOW YOUR INSTRUMENT PANEL

If any of these systems require service, the OBD II system will turn on the Malfunction Indicator Light (MIL). It will also store diagnostic codes and other information to assist your service technician in making repairs. Although your vehicle will usually be drivable and not need towing, see an authorized dealer for service as soon as possible.

CAUTION!

 Prolonged driving with the MIL on could cause

further damage to the emission control system. It could also affect fuel economy and driveability. The vehicle must be serviced before any emissions tests can be performed.

 If the MIL is flashing while the vehicle is

running, severe catalytic converter damage and power loss will soon occur. Immediate service is required.

ONBOARD DIAGNOSTIC SYSTEM (OBD II) C

Your vehicle is required to have OBD II and a connection port to allow access to information related to the performance of your emissions controls. Authorized service technicians may need to access this information to assist with the diagnosis and service of your vehicle and emissions system Ú page 132.

 ONLY an authorized service technician

should connect equipment to the OBD II connection port in order to read the VIN, diagnose, or service your vehicle.

 If unauthorized equipment is connected to

the OBD II connection port, such as a driver-behavior tracking device, it may:

 Be possible that vehicle systems,

 Access, or allow others to access, infor-

YBERSECURITY

WARNING!

including safety related systems, could be impaired or a loss of vehicle control could occur that may result in an accident involving serious injury or death.

mation stored in your vehicle systems, including personal information.

EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS

In some localities, it may be a legal requirement to pass an inspection of your vehicle's emissions control system. Failure to pass could prevent vehicle registration.

For states that require an Inspection

and Maintenance (I/M), this check

verifies the Malfunction Indicator

Light (MIL) is functioning and is not on when the engine is running, and that the OBD II system is ready for testing.

Normally, the OBD II system will be ready. The OBD II system may not be ready if your vehicle was recently serviced, recently had a dead battery or a battery replacement. If the OBD II system should be determined not ready for the I/M test, your vehicle may fail the test.

Your vehicle has a simple ignition actuated test, which you can use prior to going to the test station. To check if your vehicle's OBD II system is ready, you must do the following:

1. Cycle the ignition switch to the ON position,

but do not crank or start the engine.

Page 87

GETTING TO KNOW YOUR INSTRUMENT PANEL 85

NOTE: If you crank or start the engine, you will have to start this test over.

2. As soon as you cycle the ignition switch to the ON position, you will see the Malfunction Indicator Light (MIL) symbol come on as part of a normal bulb check.

3. Approximately 15 seconds later, one of two things will happen:

 The MIL will flash for about 10 seconds

and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle's OBD II system is not ready and you should not proceed to the I/M station.

 The MIL will not flash at all and will

remain fully illuminated until you place the ignition in the off position or start the engine. This means that your vehicle's OBD II system is ready and you can proceed to the I/M station.

If your OBD II system is not ready, you should see an authorized dealer or repair facility. If your vehicle was recently serviced or had a battery failure or replacement, you may need to do nothing more than drive your vehicle as you normally would in order for your OBD II system to update. A recheck with the above test routine may then indicate that the system is now ready.

Regardless of whether your vehicle's OBD II system is ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced before going to the I/M station. The I/M station can fail your vehicle because the MIL is on with the engine running.

Page 88

STARTING AND OPERATING

STARTING THE ENGINE

Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts.

WARNING!

 When exiting the vehicle, always make sure

the ignition is in OFF mode, remove the key fob from the vehicle and lock the vehicle.

 Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Children should be warned not to touch the parking brake, brake pedal or the transmission gear selector.

(Continued)

WARNING! (Continued)

 Do not leave the key fob in or near the

vehicle (or in a location accessible to children), and do not leave the ignition (of a vehicle equipped with Keyless Enter-N-Go) in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

 Do not leave children or animals inside

parked vehicles in hot weather. Interior heat build-up may cause serious injury or death.

MANUAL TRANSMISSION — IF EQUIPPED

Apply the parking brake, place the gear selector in NEUTRAL and press the clutch pedal before starting vehicle. This vehicle is equipped with a clutch interlocking ignition system. It will not start unless the clutch pedal is pressed to the floor.

AUTOMATIC TRANSMISSION —

F EQUIPPED

The gear selector must be in the PARK position before you can start the engine. Apply the brakes before shifting into any driving gear.

CAUTION!

 Shift into or out of PARK or REVERSE only

after the vehicle has come to a complete stop.

 Do not shift between PARK, REVERSE,

NEUTRAL, or DRIVE when the engine is above idle speed.

 Before shifting into any gear, make sure

your foot is firmly pressing the brake pedal.

Page 89

STARTING AND OPERATING 87

Tip Start Feature — Automatic Transmission

Place the ignition in the START mode and release it as the starter engages. The starter motor will automatically disengage itself once engine is running. If the engine fails to start, the starter will disengage automatically in 10 seconds. If this occurs:

1. Place the ignition in the OFF mode.

2. Wait 10 to 15 seconds.

3. Repeat the “Normal Starting” procedure.

NORMAL STARTING

To Turn On The Engine Using The ENGINE START/STOP Button — Manual Transmission Only

1. Press and hold the clutch pedal while pushing and holding the ENGINE START/ STOP button.

2. Release the ENGINE START/STOP button when the engine starts. If the vehicle fails to start within 15 seconds, release the

ENGINE START/STOP button, wait 10 to 15 seconds, then repeat the “Normal Starting” procedure.

3. If you wish to stop the cranking of the engine prior to the engine starting, release the ENGINE START/STOP button.

NOTE: Normal starting of either a cold or a warm engine is obtained without pumping or pressing the accelerator pedal.

To Turn On The Engine Using The ENGINE START/STOP Button — Automatic Transmission Only

1. The transmission must be in PARK.

2. Press and hold the brake pedal while pushing the ENGINE START/STOP button once.

3. If the vehicle fails to start, the starter will disengage automatically after 10 seconds.

4. If you wish to stop the cranking of the engine prior to the engine starting, push the ENGINE START/STOP button again.

NOTE: Normal starting of either a cold or a warm engine is obtained without pumping or pressing the accelerator pedal.

To Turn Off The Engine Using ENGINE START/STOP Button — Manual Transmission Only

1. With the vehicle stopped, place the gear selector in NEUTRAL, then push and release the ENGINE START/STOP button.

2. The ignition will return to the OFF mode.

3. Place the gear selector in FIRST gear or REVERSE and then apply the parking brake.

NOTE:

 If the ignition switch is left in the ACC posi-

tion, the system will automatically time out after 30 minutes of inactivity and the ignition will switch to the OFF position.

 If the ignition switch is left in the RUN posi-

tion, the system will automatically time out after 30 minutes of inactivity if the vehicle speed is 0 mph (0 km/h) and the engine is not running.

Page 90

88 STARTING AND OPERATING

 If the vehicle speed is above 5 mph (8 km/h),

the ENGINE START/STOP button must be held for two seconds or three short pushes in a row before the engine will shut off. The ignition switch position will remain in the ACC position until the vehicle is stopped, placed in park and the button is pushed twice to the OFF position.

To Turn Off The Engine Using ENGINE START/STOP Button — Automatic Transmission Only

1. Place the gear selector in PARK, then push and release the ENGINE START/STOP button.

2. The ignition will return to the OFF mode.

3. If the gear selector is not in PARK, the ENGINE START/STOP button must be held for two seconds or three short pushes in a row with the vehicle speed above 5 mph (8 km/h) before the engine will shut off. The ignition will remain in the ACC mode until the gear selector is in PARK and the button is pushed twice to the OFF mode. If the gear

selector is not in PARK and the ENGINE START/STOP button is pushed once, the instrument cluster will display a “Vehicle Not In Park” message and the engine will remain running. Never leave a vehicle out of the PARK position, or it could roll.

NOTE: If the ignition switch is left in the ACC or RUN (engine not running) position and the transmission is in PARK, the system will automatically time out after 30 minutes of inactivity and the ignition will switch to the OFF position.

AUTOPARK

AutoPark is a supplemental feature to assist in placing the vehicle in PARK should the situations on the following pages occur. It is a back up system and should not be relied upon as the primary method by which the driver shifts the vehicle into PARK.

The conditions under which AutoPark will engage are outlined on the following pages.

WARNING!

 Driver inattention could lead to failure to

place the vehicle in PARK. ALWAYS DO A VISUAL CHECK that your vehicle is in PARK by verifying that a solid (not blinking) “P” is indicated in the instrument cluster display and on the gear selector. If the “P” indicator is blinking, your vehicle is not in PARK. As an added precaution, always apply the parking brake when exiting the vehicle.

 AutoPark is a supplemental feature. It is not

designed to replace the need to shift your vehicle into PARK. It is a back up system and should not be relied upon as the primary method by which the driver shifts the vehicle into PARK.

If the vehicle is not in PARK and the driver turns off the engine, the vehicle may AutoPark.

AutoPark will engage when all of these conditions are met:

 Vehicle is equipped with an eight-speed

transmission

 Vehicle is not in PARK

Page 91

STARTING AND OPERATING 89

 Vehicle speed is 1.2 mph (1.9 km/h) or less

 Ignition switched from RUN to ACC

NOTE: For Keyless Enter-N-Go equipped vehicles, the engine will turn off and the ignition switch will change to ACC mode. After 30 minutes, the ignition switches to OFF automatically, unless the driver turns the ignition switch OFF.

If the vehicle is not in PARK and the driver exits the vehicle with the engine running, the vehicle may AutoPark.

AutoPark will engage when all of these conditions are met:

 Vehicle is equipped with an eight-speed

transmission

 Vehicle is not in PARK

 Vehicle speed is 1.2 mph (1.9 km/h) or less

 Driver’s seat belt is unbuckled

 Driver’s door is ajar

 Brake pedal is not pressed

The message “AutoPark Engaged Shift to P then Shift to Gear” will display in the instrument cluster.

NOTE: In some cases the ParkSense graphic will be displayed in the instrument cluster. In these cases, the gear selector must be returned to “P” to select desired gear.

If the driver shifts into PARK while moving, the vehicle may AutoPark.

AutoPark will engage ONLY when vehicle speed is 1.2 mph (1.9 km/h) or less.

The message “Vehicle Speed is Too High to Shift to P” will be displayed in the instrument cluster if vehicle speed is above 1.2 mph (1.9 km/h).

WARNING!

If vehicle speed is above 1.2 mph (1.9 km/h), the transmission will default to NEUTRAL until the vehicle speed drops below 1.2 mph (1.9 km/h). A vehicle left in the NEUTRAL position can roll. As an added precaution, always apply the parking brake when exiting the vehicle.

ALWAYS DO A VISUAL CHECK

that your vehicle is in PARK by looking for the "P" in the instrument cluster display and on the gear selector. As an added precaution, always apply the parking brake when exiting the vehicle.

COLD WEATHER OPERATION

ELOW –22°F OR −30°C)

To ensure reliable starting at these temperatures, use of an externally powered electric engine block heater (available from an authorized dealer) is recommended.

IF ENGINE FAILS TO START

If the engine fails to start after you have followed the “Normal Starting” or “Cold Weather Operation” procedure, it may be flooded. Push the accelerator pedal all the way to the floor and hold it there. Crank the engine for no more than 15 seconds. This should clear any excess fuel in case the engine is flooded. Leave the ignition key in the RUN position, release the accelerator pedal and repeat the “Normal Starting” procedure.

Page 92

90 STARTING AND OPERATING

WARNING!

 Never pour fuel or other flammable liquid

into the throttle body air inlet opening in an attempt to start the vehicle. This could result in flash fire causing serious personal injury.

 Do not attempt to push or tow your vehicle

to get it started. Vehicles equipped with an automatic transmission cannot be started this way. Unburned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle.

 If the vehicle has a discharged battery,

booster cables may be used to obtain a start from a booster battery or the battery in another vehicle. This type of start can be dangerous if done improperly Ú page 267.

CAUTION!

To prevent damage to the starter, do not continuously crank the engine for more than 25 seconds at a time. Wait 60 seconds before trying again.

AFTER STARTING

The idle speed is controlled automatically, and it will decrease as the engine warms up.

ENGINE BLOCK HEATER — IF EQUIPPED

The engine block heater warms the engine, and permits quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a grounded, three-wire extension cord.

The engine block heater must be plugged in at least one hour to have an adequate warming effect on the engine.

The engine block heater cord is routed under the hood on the driver side of the vehicle. It has a removable cap that is located near the air box.

WARNING!

Remember to disconnect the engine block heater cord before driving. Damage to the 110-115 Volt electrical cord could cause electrocution.

ENGINE BREAK-IN RECOMMENDATIONS —

3.6L & 5.7L

A long break-in period is not required for the drivetrain (engine, transmission, clutch, and rear axle) in your new vehicle.

Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.

While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. However, wide-open throttle acceleration in low gear can be detrimental and should be avoided.

The engine oil, transmission fluid, and axle lubricant installed at the factory are high-quality and energy-conserving. Oil, fluid, and lubricant changes should be consistent with anticipated climate and conditions under which vehicle operations will occur. For the recommended viscosity and quality grades Ú page 341.

Page 93

STARTING AND OPERATING 91

CAUTION!

Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result.

NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as an indication of difficulty. Please check your oil level with the engine oil indicator often during the break in period. Add oil as required.

PARKING BRAKE

Before leaving the vehicle, make sure that the parking brake is fully applied and place the gear selector in the PARK or REVERSE (manual transmission only) position.

When the parking brake is applied and the ignition switch is in the ON/RUN position, the “Brake Warning Light” in the instrument cluster will illuminate.

NOTE:

 When the parking brake is applied and the

transmission is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound to alert the driver. Fully release the parking brake before attempting to move the vehicle.

 This light only shows that the parking brake is

applied. It does not show the degree of brake application.

When parking on a hill, it is important to turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade. For vehicles equipped with an automatic transmission, apply the parking brake before placing the gear selector in PARK, otherwise the load on the transmission locking mechanism may make it difficult to move the gear selector out of PARK. The parking brake should always be applied whenever the driver is not in the vehicle.

Manual Transmission — If Equipped

The foot operated parking brake is positioned below the lower left corner of the instrument panel. To release the parking brake, pull the parking brake release handle.

Parking Brake Release

Automatic Transmission — If Equipped

The foot operated parking brake is located below the lower left corner of the instrument panel. To apply the parking brake, firmly push the parking brake pedal fully. To release the

Page 94

92 STARTING AND OPERATING

parking brake, press the parking brake pedal a second time and let your foot up as you feel the brake disengage.

Parking Brake

WARNING!

 Never use the PARK position as a substi-

tute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.

 When exiting the vehicle, always remove

the key fob from the ignition and lock your vehicle.

(Continued)

WARNING! (Continued)

 Never leave children alone in a vehicle, or

 When exiting the vehicle, always make sure

the keyless ignition node is in the OFF mode, remove the key fob from the vehicle and lock the vehicle.

 Do not leave the key fob in or near the

vehicle or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

 Be sure the parking brake is fully disen-

gaged before driving; failure to do so can lead to brake failure and a collision.

(Continued)

WARNING! (Continued)

 Always fully apply the parking brake when

leaving your vehicle, or it may roll and cause damage or injury. Also be certain to leave the transmission in PARK. Failure to do so may allow the vehicle to roll and cause damage or injury.

CAUTION!

If the Brake Warning Light remains on with the parking brake released, a brake system malfunction is indicated. Have the brake system serviced by an authorized dealer immediately.

MANUAL TRANSMISSION — IF EQUIPPED

SIX-SPEED MANUAL TRANSMISSION

WARNING!

You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied. The parking brake should always be applied when the driver is not in the vehicle, especially on an incline.

Page 95

CAUTION!

 Never drive with your foot resting on the

clutch pedal, or try to hold the vehicle on a hill with the clutch pedal partially engaged, as this will cause abnormal wear on the clutch Ú page 203.

 Failure to press the clutch pedal fully to the

floor may cause increased shift efforts, and may result in damage to the clutch and transmission.

 Do not rest your hand on the gear selector

while driving, as this may result in transmission synchronizer damage.

 Do not attempt to shift the transmission if

the rear wheels are spinning due to loss of traction. Damage to the transmission may occur.

NOTE: During cold weather, you may experience increased effort in shifting until the transmission fluid warms up. This is normal.

Manual Gear Selector

SHIFTING

Fully press the clutch pedal and lift your foot off the accelerator pedal before shifting gears. As you release the clutch pedal, lightly press the accelerator pedal. Damage to the transmission or clutch may occur if you do not fully press the clutch pedal and lift off of the accelerator pedal when shifting.

STARTING AND OPERATING 93

Shift Pattern

The six-speed manual transmission has a spring that centers the gear selector near THIRD and FOUTH gear. This spring helps you know which gear you are in when you are shifting. Be careful when shifting from FIRST to SECOND or downshifting from SIXTH to FIFTH.

Page 96

94 STARTING AND OPERATING

The spring will try to pull the gear selector toward THIRD and FOURTH gear. Make sure you move the gear selector into SECOND or FIFTH gear. If you let the gear selector move in the direction of the pulling, you may end shifting from FIRST to FOURTH or from SIXTH to THIRD gear.

MANUAL TRANSMISSION RECOMMENDED SHIFT SPEEDS

Axle Ratio 1-4 4-5 5-6

3.90

Earlier upshifts during cruise conditions (relatively steady speeds) may result in increased fuel economy.

Higher upshift speeds may be used to obtain a desired acceleration rate.

NOTE:

 Your vehicle is equipped with a transmission

reverse inhibitor system. Always depress the clutch pedal fully to the floor before shifting into REVERSE. When vehicle speed is greater than 3 mph (5 km/h), the reverse inhibitor activates to help prevent shifts into

mph 20 37 48

km/h 32 59 77

CAUTION!

Always make sure the vehicle comes to a complete stop before shifting into REVERSE. Failure to do so may result in transmission damage.

REVERSE. When at a complete stop, you may notice lighter shift efforts into REVERSE with the ignition switch in the ON position (RUN position for Keyless Enter-N-Go), as compared to the ignition LOCK position (OFF position for Keyless Enter-N-Go). This is normal operation of the transmission reverse inhibitor system.

 Due to the high performance nature of your

drivetrain, you may hear your transmission. This can be most noticeable when the vehicle is idling in NEUTRAL with the clutch engaged (clutch pedal released), but it may also be heard when driving at low engine RPM. Also,

You must always use FIRST gear (or REVERSE) when starting from a standing position.

RECOMMENDED SHIFT SPEEDS

To utilize your manual transmission efficiently for fuel economy, it should be upshifted as listed in recommended shift speed chart.

this may be more noticeable when the transmission is warm. This is a normal condition and is not an indication of a problem with your clutch or transmission.

1–4 SKIP SHIFT

In Auto Drive Mode, Default, or Street Drive Modes, there are times when you must shift the transmission directly from FIRST gear to FOURTH gear instead of from FIRST gear to SECOND gear. This is to help you get the best possible fuel economy from your vehicle. This occurs when the engine coolant (antifreeze) is higher than 106°F (41°C), vehicle speed is

Page 97

STARTING AND OPERATING 95

greater than 19 mph (30 km/h) but less than 21 mph (34 km/h), and the transmission is in FIRST gear, and the accelerator is at ¼ throttle or less.

After you shift the transmission to FOURTH gear, you can press the clutch in and shift to another forward gear.

DOWNSHIFTING

To maintain a safe speed and prolong brake life, downshift to maintain a safe speed when descending a steep grade.

WARNING!

Skipping more than one gear while downshifting, could cause you to lose control of your vehicle. You could have a collision.

CAUTION!

 If you skip more than one gear while down-

shifting or downshift at too high an engine speed, you could damage the engine, transmission, or clutch.

(Continued)

CAUTION! (Continued)

 Do not downshift into FIRST gear when the

vehicle is moving faster than 15 mph (24 km/h), as you could damage the engine and/or clutch.

AUTOMATIC TRANSMISSION — IF EQUIPPED

You must press and hold the brake pedal while shifting out of PARK.

WARNING!

 Never use the PARK position as a substi-

tute for the parking brake. Always apply the parking brake fully when exiting the vehicle to guard against vehicle movement and possible injury or damage.

 Your vehicle could move and injure you and

others if it is not in PARK. Check by trying to move the transmission gear selector out of PARK with the brake pedal released. Make sure the transmission is in PARK before exiting the vehicle.

(Continued)

WARNING! (Continued)

 The transmission may not engage PARK if

the vehicle is moving. Always bring the vehicle to a complete stop before shifting to PARK, and verify that the transmission gear position indicator solidly indicates PARK (P) without blinking. Ensure that the vehicle is completely stopped, and the PARK position is properly indicated, before exiting the vehicle.

 It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly pressing the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something. Only shift into gear when the engine is idling normally and your foot is firmly pressing the brake pedal.

(Continued)

Page 98

96 STARTING AND OPERATING

WARNING! (Continued)

 Unintended movement of a vehicle could

injure those in or near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, always come to a complete stop, then apply the parking brake, shift the transmission into PARK, and turn the ignition OFF. When the ignition is in the OFF mode, the transmission is locked in PARK, securing the vehicle against unwanted movement.

 When exiting the vehicle, always make sure

the ignition is in the OFF mode, remove the key fob from the vehicle, and lock the vehicle.

 Never leave children alone in a vehicle, or

(Continued)

WARNING! (Continued)

 Do not leave the key fob in or near the

vehicle (or in a location accessible to children), and do not leave the ignition in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle.

CAUTION!

 Shift into or out of PARK or REVERSE only

after the vehicle has come to a complete stop.

 Do not shift between PARK, REVERSE,

NEUTRAL, or DRIVE when the engine is above idle speed.

 Before shifting into any gear, make sure

your foot is firmly pressing the brake pedal.

IGNITION PARK INTERLOCK

This vehicle is equipped with an Ignition Park Interlock which requires the transmission to be in PARK before the ignition can be turned to the OFF mode. This helps the driver avoid inadvertently leaving the vehicle without placing

the transmission in PARK. This system also locks the transmission in PARK whenever the ignition is in the OFF mode.

NOTE: The transmission is NOT locked in PARK when the ignition is in the ACC mode (even though the engine will be off). Ensure that the transmission is in PARK, and the ignition is OFF (not in ACC mode) before exiting the vehicle.

BRAKE TRANSMISSION SHIFT

NTERLOCK (BTSI) S YSTEM

This vehicle is equipped with a BTSI system that holds the transmission gear selector in PARK unless the brakes are applied. To shift the transmission out of PARK, the engine must be running and the brake pedal must be pressed. The brake pedal must also be pressed to shift from NEUTRAL into DRIVE or REVERSE when the vehicle is stopped or moving at low speeds.

EIGHT -SPEED AUTOMATIC

RANSMISSION

The transmission gear range is displayed both on the gear selector and in the instrument cluster. To select a gear range, push the lock button on the gear selector and move the

Page 99

STARTING AND OPERATING 97

selector rearward or forward. To shift the transmission out of PARK, the engine must be running and the brake pedal must be pressed. You must also press the brake pedal to shift from NEUTRAL into DRIVE or REVERSE when the vehicle is stopped or moving at low speeds. Select the DRIVE range for normal driving.

NOTE:

 The transmission electronics are self-cali-

brating; therefore, the first few shifts on a new vehicle may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles (kilometers).

 In the event of a mismatch between the gear

selector position and the actual transmission gear (for example, driver selects PARK while driving), the position indicator will blink continuously until the selector is returned to the proper position, or the requested shift can be completed.

The electronically-controlled transmission adapts its shift schedule based on driver inputs, along with environmental and road conditions.

Only shift from DRIVE to PARK or REVERSE when the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when shifting between these gears.

The transmission gear selector provides PARK, REVERSE, NEUTRAL, DRIVE, and MANUAL (AutoStick) shift positions. Manual shifts can be made using the AutoStick shift control. Toggling the gear selector forward (-) or rearward (+) while in the MANUAL (AutoStick) position (beside the DRIVE position) will manually select the transmission gear, and will display the current gear in the instrument cluster Ú page 100.

Automatic Transmission Gear Selector

NOTE: If the gear selector cannot be moved to the PARK, REVERSE, or NEUTRAL position (when pushed forward) it is probably in the MANUAL (AutoStick, +/-) position (beside the DRIVE position). In MANUAL (AutoStick) mode, the transmission gear is displayed in the instrument cluster (as M1, M2, M3, etc.). Move the gear selector to the right (into the DRIVE [D] position) for access to PARK, REVERSE, and NEUTRAL.

Gear Ranges

Do not press the accelerator pedal when shifting out of PARK (P) or NEUTRAL (N).

NOTE: After selecting any gear range, wait a moment to allow the selected gear to engage before accelerating. This is especially important when the engine is cold.

PARK (P)

This range supplements the parking brake by locking the transmission. The engine can be started in this range. Never attempt to use PARK while the vehicle is in motion. Apply the parking brake when exiting the vehicle in this range.

Page 100

98 STARTING AND OPERATING

When parking on a hill, apply the parking brake before shifting the transmission to PARK. As an added precaution, turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade.

When exiting the vehicle, always:

 Apply the parking brake.

 Shift the transmission into PARK.

 Turn the ignition OFF.

 Remove the key fob from the vehicle.

WARNING!

 Never use the PARK position as a substi-

tute for the parking brake. Always apply the parking brake fully when exiting the vehicle to guard against vehicle movement and possible injury or damage.

 Your vehicle could move and injure you and

others if it is not in PARK. Check by trying to move the transmission gear selector out of PARK with the brake pedal released. Make sure the transmission is in PARK before exiting the vehicle.

(Continued)

WARNING! (Continued)

 The transmission may not engage PARK if

 It is dangerous to shift out of PARK or

(Continued)

WARNING! (Continued)

 Unintended movement of a vehicle could

 When exiting the vehicle, always make sure

the ignition is in the OFF mode, remove the key fob from the vehicle, and lock the vehicle.

 Never leave children alone in a vehicle, or

(Continued)
