user’s
guide
J50TL, J50FL & J50FL-S
MOBILITY SCOOTERS
1
hello
CONGRADULATIONS ON THE PURCHASE OF YOUR NEW SCOOTER.
WE ARE QUITE CONFIDENT THAT YOU ARE GOING TO GET ALONG.
We designed this scooter with one main objective - to provide mobility,
independance and freedom, all coupled with ease of use and a touch of
style.
is user guide is intended to help you become familiar with the ins and
outs of your scooter, so that you can ensure high performance and long
life for your scooter.
We also recommend you follow the maintanece schedule outlined in this
guide, and take advantage of our trained techinicians, both for regular
maintenance, and if you should encounter your problem.
Now, without further adieu, enjoy your mobility scooter!
2
ANATOMY OF A SCOOTER
BATTERY
BATTERY F.A.Q.
OPERATION
ELECTROMAGNETIC INTERFERENCE (EMI)
SAFETY
ASSEMBLY AND DISSASSEMBLY
MAINTENANCE
SPECIFICATIONS
WARRANTY
BUYER’S REGISTRATION FORM
TABLE OF CONTENTS
e manufacturer reserves the rights of nal interpretation on the manual. For any printing mistakes or new improvements, the manufacturer will update in the new editions.
3
FEATURES
Modular construction - disassembles in one minute without
use of tools
Adjustable seat height
Swing away armrests
360 degrees swivel seat
Adjustable Forward/Reverse Seat
Adjustable tiller
Dynamic regenerative braking coupled with fail-safe elec
tro-mechanical disk brake
Rear wheel direct drive with dierential
Fully solid state controller
External Battery Charger
24-volt permanent magnet heavy duty DC motor
ON/OFF switch lock
Horn
Head light
Turning lights
Rear lights
Battery-charging indicator
Anti-tip-o safety wheels
Front and rear bumpers
Accessories adapter
Automatic shut o while not in use
Electronic High/Low speed switch
